Shop fox W1849 User Manual

MODEL W1849 

14" RESAW BANDSAW

OWNER'S MANUAL

(FOR MODELS MANUFACTURED SINCE 11/16)

Phone: [phone] • Online Technical Support: [e-mail]

COPYRIGHT © JANUARY, 2017 BY WOODSTOCK INTERNATIONAL, INC.

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT

V1.02.17

THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.

#18655KB  Printed in Taiwan

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.

Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.

The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre­hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.

The manufacturer will not be held liable for injury or property
damage from negligence, improper training, machine modifications or
misuse.

Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State of
California to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip­ment, such as those dust masks that are specially designed to filter
out microscopic particles.

Contents

INTRODUCTION .....................................2

Contact Info ....................................... 2

Manual Accuracy .................................. 2

Machine Specifications .......................... 3

Identification ..................................... 5

Controls & Components ......................... 6

SAFETY ............................................... 9

Standard Machinery Safety Instructions ...... 9

Additional Safety for Bandsaws .............. 11

ELECTRICAL ....................................... 12

Circuit Requirements .......................... 12

Grounding Requirements ...................... 13

Extension Cords ................................ 13

Converting Voltage to 220V .................. 14

SETUP .............................................. 15

Unpacking ....................................... 15

Items Needed for Setup ....................... 15

Inventory ........................................ 16

Hardware Recognition Chart ................. 17

Cleaning Machine ............................... 18

Machine Placement ............................ 19

Lifting & Moving ................................ 20

Anchoring to Floor ............................. 21

Assembly ......................................... 22

Dust Collection ................................. 26

Adjustment Overview.......................... 27

Initial Blade Tracking .......................... 27

Test Run .......................................... 29

Tensioning Blade ............................... 30

Fine-Tune Tracking ............................. 32

Adjusting Blade Support Bearings ........... 33

Adjusting "Euro-Style" Roller-Disc Guides .. 34

Installing Blade Guide Roller Bearings ...... 36

Adjusting Blade Guide Roller Bearings ...... 37

Aligning Table ................................... 39

Aligning Fence .................................. 41

OPERATIONS....................................... 42

General .......................................... 42

Workpiece Inspection .......................... 43

Setting Upper Blade Guide Height .......... 44

Blade Selection ................................. 44

Blade Selection Chart ......................... 48

Blade Care & Break-In ......................... 49

Blade Breakage ................................. 49

Changing Blade ................................. 50

Tilting Table ..................................... 51

Ripping ........................................... 52

Crosscutting ..................................... 52

Resawing ......................................... 53

Cutting Curves .................................. 53

Stacked Cuts .................................... 54

ACCESSORIES ...................................... 55

Bandsaw Accessories ........................... 55

MAINTENANCE .................................... 57

Schedule ......................................... 57

Wheel Brushes .................................. 57

Cleaning & Protecting ......................... 57

Lubrication ...................................... 58

SERVICE ............................................ 60

Troubleshooting ................................. 60

Tensioning/Replacing V-Belt .................. 63

Blade Lead ...................................... 65

Adjusting Wheel Brushes ...................... 66

Adjusting Quick-Release Lever ............... 66

Adjusting Guide Post Parallelism ............ 67

Aligning Wheels ................................. 70

Calibrating Table Tilt Scale Pointer ......... 74

Electrical Safety Instructions ................. 75

Wiring Diagram ................................. 76

PARTS .............................................. 77

Main .............................................. 77

Main Parts List .................................. 78

Table, Trunnion, & Blade Guides ............ 79

Table, Trunnion, & Blade Guides Parts List 80

Fence ............................................. 81

Labels & Cosmetics ............................ 82

SAFETYINTRODUCTION

SET UPELECTRICAL MAINTENANCE

OPERATIONS

SERVICE PARTS

WARRANTY ........................................ 85

USE THE QUICK GUIDE PAGE LABELS TO SEARCH OUT INFORMATION FAST!

INTRODUCTION

We are proud to provide a high-quality owner’s
manual with your new machine!

We

the
instructions, specifications, drawings, and pho­tographs contained inside. Sometimes we make
mistakes, but our policy of continuous improve­ment

machine
you receive will be slightly different than what
is shown in the manual

If you find this to be the case, and the difference
between the manual and machine leaves you
confused about a procedure

check our website

for an updated version. W

manuals

and

on our website at

www.

Alternatively, you can call our Technical Support
for help. Before calling, make sure you write
down the
from the machine ID label (see below). Also, if
available, have a copy of your original purchase
receipt on hand. This information is required for
all Tech Support calls.

MODEL XXXX

MACHINE NAME

Motor:
Specification:
Specification:
Specification:
Specification:
Weight:

Specifications

To reduce risk of serious personal injury when using this
machine:

1. Read & understand owner’s manual before operating.

2. Always wear approved eye protection and respirator.

3. Only plug power cord into a grounded outlet.

4. Only use this machine to collect wood dust/chips—never
use to collect glass, metal, liquids, asbestos, silica,
animal parts, biohazards, burning material/ashes, etc.

5. Always disconnect power before servicing or cleaning.

6. Do not expose to rain or wet areas.

7. Keep hands, long hair, and loose clothing away from
inlet.

8. Never leave machine unattended while it is running.

9. Do not use if cord/plug becomes damaged—promptly
repair and protect cord from future damage.

10. Do not use without dust bag or filters in place.

11. Always wear a respirator when emptying bags.

12. Prevent unauthorized use by children or untrained users.

Date

Serial Number

Manufactured for Woodstock in Taiwan

WARNING!

We are committed to customer satisfaction. If
you have any questions or need help, use the
information below to contact us.

IMPORTANT: Before contacting, please get the
original purchase receipt, serial number, and
manufacture date of your machine. This infor­mation is required for all Technical Support
calls and it will help us help you faster.

We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.

Email: [e-mail]

Contact Info

Woodstock International Technical Support

Phone: [phone]

SET UP ELECTRICALMAINTENANCE

Email: [e-mail]

Technical Documentation Manager

P.O. Box 2309

Bellingham, WA 98227

Manual Accuracy

made every effort to be exact with

also means that sometimes the

.

,

e post current

manual updates for free

woodstockint.com.

Manufacture Date and Serial Number

OPERATIONS SAFETY INTRODUCTION

SERVICEPARTS

USE THE QUICK GUIDE PAGE LABELS TO SEARCH OUT INFORMATION FAST!

Manufacture

Date

Serial Number

Model W1849 (For Machines Mfd. Since 11/16)

MODEL W1849

14" RESAW BANDSAW

Product Dimensions

Weight.......................................................................................................... 261 lbs.

Width (side‐to‐side) x Depth (front‐to‐back) x Height................................... 27‐1/2 x 32 x 76 in.

Footprint (Length x Width).............................................................................. 23 x 18 in.

Shipping Dimensions

Type....................................................................................................... Wood Crate

Content........................................................................................................ Machine

Weight.......................................................................................................... 332 lbs.

Length x Width x Height........................................................................... 30 x 24 x 79 in.

Must Ship Upright.................................................................................................. Yes

INTRODUCTION

Electrical

Power Requirement.......................................................... 110V or 220V, Single‐Phase, 60 Hz

Prewired Voltage................................................................................................. 110V

Full‐Load Current Rating.............................................................. 15A at 110V, 7.5A at 220V

Minimum Circuit Size................................................................... 20A at 110V, 15A at 220V

Connection Type......................................................................................... Cord & Plug

Power Cord Included.............................................................................................. Yes

Power Cord Length............................................................................................... 6 ft.

Power Cord Gauge............................................................................................ 14 AWG

Plug Included....................................................................................................... Yes

Included Plug Type............................................................................................... 5‐15

Recommended Plug Type............................................................................. 6‐15 for 220V

Switch Type.......................................... ON/OFF Push Button Switch w/Emergency Stop Paddle

Motors

Main

Type......................................................................... TEFC Capacitor‐Start Induction

Horsepower................................................................................................. 2 HP

Phase.............................................................................................. Single‐Phase

Amps................................................................................................... 15A/7.5A

Speed.................................................................................................. 1720 RPM

Power Transfer ..................................................................................... Belt Drive

Bearings............................................................... Shielded & Permanently Lubricated

Main Specifications

Main Specifications

Bandsaw Size.............................................................................................. 14 in.

Max Cutting Width (Left of Blade)............................................................... 13‐1/2 in.

Max Cutting Width (Left of Blade) w/Fence......................................................... 12 in.

Max Cutting Height (Resaw Height)................................................................... 14 in.

Blade Speeds......................................................................................... 2820 FPM

-3-

INTRODUCTION

Model W1849 (For Machines Mfd. Since 11/16)

Blade Information

Standard Blade Length................................................................................. 120 in.

Blade Width Range.............................................................................. 1/8 – 3/4 in.

Type of Blade Guides...................................................... "Euro Style" Roller‐Disc Guides

Guide Post Adjustment Type.............................................................. Rack‐and‐Pinion

Has Quick‐Release.......................................................................................... Yes

Table Information

Table Length......................................................................................... 21‐3/4 in.

Table Width.......................................................................................... 16‐1/8 in.

Table Thickness....................................................................................... 1‐1/2 in.

Table Tilt............................................................................... Left 5, Right 45 Deg.

Table Tilt Adjustment Type............................................................... Rack‐and‐Pinion

Floor‐to‐Table Height................................................................................... 37 in.

Fence Locking Position.................................................................................. Front

Fence is Adjustable for Blade Lead...................................................................... Yes

Resaw Fence Attachment Included......................................................................

Miter Gauge Included.......................................................................................

Construction Materials

Table................................................................................................... Cast Iron

Trunnion.................................................................................................... Steel

Fence..................................................................................... Extruded Aluminum

Base/Stand................................................................................................. Steel

Frame/Body................................................................................................ Steel

Wheels................................................................................................. Cast Iron

Tire................................................................................................ Polyurethane

Wheel Cover .............................................................................................. Steel

Paint Type/Finish............................................................................. Powder Coated

Yes

No

Other Related Information

Wheel Diameter.......................................................................................... 14 in.

Wheel Width.......................................................................................... 1‐1/8 in.

Number of Dust Ports......................................................................................... 2

Dust Port Size.............................................................................................. 4 in.

Compatible Mobile Base............................................................................... D2057A

Other

Country of Origin ............................................................................................. Taiwan

Warranty ....................................................................................................... 2 Years

Approximate Assembly & Setup Time ...................................................................... 1 Hour

Serial Number Location .......................................................................... Machine ID Label

ISO 9001 Factory .................................................................................................. Yes

Features

14" Resaw Capacity
Equipped with Roller‐Disc ("Euro Style") Blade Guides
Optional Ball‐Bearing Blade Guides Available
Modular Blade Guide Design for Easy Changeovers Between Styles
Rack‐and‐Pinion Table Tilt Adjustments
Cast‐Iron Fence Base with 2‐Position Extruded‐Aluminum Fence
Storage Area for Extra Blades, Miter Gauge, and Blade Guide Assemblies When Not In Use
Cast‐Iron Wheels and Steel Table Trunnion
Blade Tension Indicator with Window in Wheel Cover

-4-

Model W1849 (For Machines Mfd. Since 11/16)

Become familiar with the names and locations of the controls and features shown below to better

Identification

INTRODUCTION

Upper
Wheel

Cover

Blade

Tension

Window

& Scale

Blade

Tension

Handwheel

ON/OFF

Switch

Fence

Lock

Handle

Lower
Wheel

Cover

Blade Tracking

Window

Guide Post

Elevation

Handwheel

Guide Post

Guide Post

Lock Knob

Fence

Table Tilt

Lock Lever

4" Dust Port

(Upper)

Lower Wheel

Adjustment Hub

Blade

Tension

Quick-

Release

Lever

Tracking

Control

Knob

w/Lock

Lever

Table Tilt

Adjustment

Lever

Motor

Blade

Storage

Area

4" Dust Port

(Lower)

For Your Own Safety, Read Instruction
Manual Before Operating Saw.

a) Wear eye protection.
b) Do not remove jammed cutoff pieces

until blade has stopped.

c) Maintain proper adjustment of blade

tension, blade guides, and thrust
bearings.

d) Adjust upper guide to just clear

workpiece.

e) Hold workpiece firmly against table.

-5-

Controls & Components

INTRODUCTION

Refer to Figures 1–8 and the following descriptions to
become familiar with the basic controls and components
of this machine. Understanding these items and how they
work will help you understand the rest of the manual and
stay safe when operating this machine.

ON/OFF Switch & Fence

A. ON Button: Turns motor ON when pressed.

Model W1849 (For Machines Mfd. Since 11/16)

To reduce your risk of serious injury
or damage to the machine, read this
entire manual BEFORE using machine.

A

B. Stop Paddle: Turns motor OFF when pressed.

C. Fence: Used for ripping or resawing. Distance

from blade determines width of cut. Can be used
in horizontal position (as shown in Figure 1) for
thin workpieces or in vertical position (as shown in

Figure 2) for normal workpieces.

D. Fence Lock Lever: Secures fence to fence base

when mounted horizontally or vertically.

E. Fence Base: Mounts fence to rail, and allows fence

to be switched between horizontal or vertical
positions.

F. Fence Lock Handle: Secures fence position along

fence rail.

B

D

E

F

Figure 1. ON/OFF switch and fence

mounted in horizontal position.

D

E

C

C

F

-6-

Figure 2. Fence mounted vertically.

Model W1849 (For Machines Mfd. Since 11/16)

INTRODUCTION

Guide Post

K

H

I

J

Figure 3. Guide post controls.

H. Guide Post Handwheel: Adjusts height of

guide post above workpiece, using a rack­and-pinion system.

I. Guide Post w/Scale: Houses upper blade

guides and support bearing, and shields
operator from upper portion of blade.
Adjusts up or down as necessary to position
upper blade guides/support bearing as
close as possible to workpiece for maximum
cutting accuracy and minimum blade
exposure to operator. Scale on side of guide
post indicates height of upper blade guide
above table.

Blade Tension & Tracking

O

M

N

Figure 5. Blade tension scale, blade tension

handwheel, and tracking window.

M. Blade Tension Scale: Displays blade tension

using numbers 1–8. For reference purposes
only—after you have found the proper
tension for the particular blade installed.

N. Blade Tension Handwheel: Increases/

decreases blade tension (refer to Page 30
for more information).

O. Blade Tracking Window: Allows

monitoring/adjustment of blade tracking
without requiring w heel cover to be open
(refer to Page 27 for more information).

J. "Euro-Style" Upper Blade Guides &

Support Bearing: Supports blade above

workpiece during operations.

K. Guide Post Lock Knob: Secures guide post

in position after adjustment.

L

Figure 4. Hinge-open blade cover.

L. Hinge-Open Blade Cover: Opens for blade

changes and upper blade guide adjustments
(refer to Page 50).

Q

R

P

Figure 6. Blade tracking controls and blade

tension quick-release lever.

P. Tracking Control Lock Lever: Secures

position of blade tracking control knob.

Q. Tracking Control Knob: Sets tilt position of

upper wheel to set/control blade tracking
(refer to Page 27 for more information).

R. Blade Tension Quick-Release Lever:

Quickly releases blade tension to speed up
blade changes and prevent unnecessary
wear on blade and saw components when
not in use. Move UP to release blade
tension. Move DOWN to re-tension blade.

-7-

Model W1849 (For Machines Mfd. Since 11/16)

entire manual before using

Table Tilt

S

Figure 7. Table tilt controls.

S. Table Tilt Lock Lever: Secures table tilt

position on trunnion. Must be loosened
before table tilt can be adjusted.

T. Table Angle Indicator: Shows table tilt

angle.

U. Trunnion w/Table Tilt Scale: Functions as a

SETUP

tilting base for table. Graduated in degrees
from 5° left—45° right for setting bevel
angle.

VUT

Lower Wheel Adjustment

X

W

Figure 8. Lower wheel adjustment controls.

X. Lower Wheel Adjustment Hub: Adjusts

position of lower wheel to upper wheel if
coplanar adjustments become necessary
(refer to Page 73 for more information).

Note: The wheels are factory-set to be

coplanar, so we strongly recommend that
you avoid making adjustments here unless
it becomes absolutely necessary.

V. Table Tilt Adjustment Lever: Adjusts angle

of table tilt using a rack-and-pinion system.

W. Positive Stop: Allows for quickly returning

table to a calibrated 0° setting after it has
been tilted to the right (refer to Page 51
for more information).

READ and understand this

this machine. Serious per­sonal injury may occur
if safety and operational
information is not under­stood and followed. DO
NOT risk your safety by
not reading!

-8-

Model W1849 (For Machines Mfd. Since 11/16)

SAFETY

OWNER’S MANUAL.

TRAINED OPERATORS ONLY.

DANGEROUS ENVIRONMENTS.

MENTAL ALERTNESS REQUIRED.

electrical components or improperly grounded

manual uses a series of symbols and signal words intended to convey the level of importance of the
safety messages. The progression of symbols is described below. Remember that safety messages by

SAFETY

For Your Own Safety,

Read Manual Before Operating Machine

The purpose of safety symbols is to attract your attention to possible hazardous conditions. This

themselves do not eliminate danger and are not a substitute for proper accident prevention mea­sures—this responsibility is ultimately up to the operator!

NOTICE

Standard Machinery Safety Instructions

Standard Machinery Safety Instructions

Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury.

This symbol is used to alert the user to useful information about
proper operation of the equipment or a situation that may cause
damage to the machinery.

SAFETY

Read and understand this

owner’s manual BEFORE using machine.

have a higher risk of being hurt or killed. Only
allow trained/supervised people to use this
machine. When machine is not being used,
disconnect power, remove switch keys, or
lock-out machine to prevent unauthorized
use—especially around children. Make
workshop kid proof!

machinery in areas that are wet, cluttered,
or have poor lighting. Operating machinery
in these areas greatly increases the risk of
accidents and injury.

alertness is required for safe operation of
machinery. Never operate under the influence
of drugs or alcohol, when tired, or when
distracted.

Untrained operators

Do not use

Full mental

ELECTRICAL EQUIPMENT INJURY RISKS. You can

be shocked, burned, or killed by touching live

machinery. To reduce this risk, only allow an
electrician or qualified service personnel to
do electrical installation or repair work, and
always disconnect power before accessing or
exposing electrical equipment.

DISCONNECT POWER FIRST. Always disconnect

machine from power supply BEFORE making
adjustments, changing tooling, or servicing
machine. This eliminates the risk of injury
from unintended startup or contact with live
electrical components.

EYE PROTECTION. Always wear ANSI-approved

safety glasses or a face shield when operating
or observing machinery to reduce the risk of
eye injury or blindness from flying particles.
Everyday eyeglasses are not approved safety
glasses.

-9-

WEARING PROPER APPAREL. Do not wear

clothing, apparel, or jewelry that can become

HAZARDOUS

HEARING PROTECTION.

REMOVE ADJUSTING TOOLS.

INTENDED USAGE.

AWKWARD POSITIONS.

CHILDREN & BYSTANDERS.

GUARDS & COVERS.

FORCING MACHINERY. Do not force machine. It

will do the job safer and better at the rate for

loss of control. Before starting, verify machine

malfunction, leading to serious personal injury

from heated surfaces, high traffic areas, harsh

entangled in moving parts. Always tie back
or cover long hair. Wear non-slip footwear to
avoid accidental slips, which could cause loss
of workpiece control.

DUST. Dust created while using

SAFETY

machinery may cause cancer, birth defects,
or long-term respiratory damage. Be aware of
dust hazards associated with each workpiece
material, and always wear a NIOSH-approved
respirator to reduce your risk.

Always wear hearing
protection when operating or observing
loud machinery. Extended exposure to this
noise without hearing protection can cause
permanent hearing loss.

Tools left on
machinery can become dangerous projectiles
upon startup. Never leave chuck keys,
wrenches, or any other tools on machine.
Always verify removal before starting!

Only use machine for its
intended purpose—never make modifications
without prior approval from Woodstock
International. Modifying machine or using
it differently than intended will void the
warranty and may result in malfunction or
mechanical failure that leads to serious
personal injury or death!

Keep proper footing and
balance at all times when operating machine.
Do not overreach! Avoid awkward hand
positions that make workpiece control difficult
or increase the risk of accidental injury.

Keep children and
bystanders at a safe distance from the work
area. Stop using machine if they become a
distraction.

Model W1849 (For Machines Mfd. Since 11/16)

which it was designed.

NEVER STAND ON MACHINE. Serious injury may

occur if machine is tipped or if the cutting
tool is unintentionally contacted.

STABLE MACHINE. Unexpected movement during

operation greatly increases risk of injury or

is stable and mobile base (if used) is locked.

USE RECOMMENDED ACCESSORIES. Consult

this owner’s manual or the manufacturer for
recommended accessories. Using improper
accessories will increase risk of serious injury.

UNATTENDED OPERATION. To reduce the risk

of accidental injury, turn machine OFF and
ensure all moving parts completely stop
before walking away. Never leave machine
running while unattended.

MAINTAIN WITH CARE. Follow all maintenance

instructions and lubrication schedules to
keep machine in good working condition. A
machine that is improperly maintained could

or death.

CHECK DAMAGED PARTS. Regularly inspect

machine for any condition that may affect
safe operation. Immediately repair or replace
damaged or mis-adjusted parts before
operating machine.

MAINTAIN POWER CORDS. When disconnecting

cord-connected machines from power, grab
and pull the plug—NOT the cord. Pulling the
cord may damage the wires inside, resulting
in a short. Do not handle cord/plug with wet
hands. Avoid cord damage by keeping it away

chemicals, and wet/damp locations.

accidental contact with moving parts or flying
debris—make sure they are properly installed,
undamaged, and working correctly.

Guards and covers reduce

EXPERIENCING DIFFICULTIES. If at any time

you experience difficulties performing the
intended operation, stop using the machine!

-10-

Contact Technical Support at [phone].

Model W1849 (For Machines Mfd. Since 11/16)

Additional Safety for Bandsaws

Serious cuts, amputation, or death can occur from contact with the moving saw blade during
operation or if blade breakage occurs. To reduce this risk, anyone operating this machine MUST
completely heed the hazards and warnings below.

SAFETY

HAND PLACEMENT. Placing hands or fingers in

line with blade during operation may result
in serious injury if hands slip or workpiece
moves unexpectedly. Do not position fingers
or hands in line with blade, and never reach
under table while blade is moving.

SMALL/NARROW WORKPIECES. If hands slip

during a cut while holding small workpieces
with fingers, serious personal injury could
occur. Always support/feed small or narrow
workpieces with push sticks, push blocks,
jig, vise, or some type of clamping fixture.

BLADE SPEED. Cutting workpiece before blade

is at full speed could cause blade to grab
workpiece and pull hands into blade. Allow
blade to reach full speed before starting
cut. DO NOT start machine with workpiece
contacting blade.

FEED RATE. To avoid risk of workpiece slipping

and causing operator injury, always feed
stock evenly and smoothly.

BLADE CONDITION. Dull blades require more

effort to perform cut, increasing risk of
accidents. Do not operate with dirty, dull,
cracked or badly worn blades. Inspect blades
for cracks and missing teeth before each
use. Always maintain proper blade tension
and tracking while operating.

CLEARING JAMS AND CUTOFFS. Always stop

bandsaw and disconnect power before
clearing scrap pieces that get stuck between
blade and table insert. Use brush or push
stick, not hands, to clean chips/cutoff scraps
from table.

GUARDS/COVERS. Blade guards and covers

protect operator from the moving bandsaw
blade. The wheel covers protect operator
from getting entangled with rotating wheels
or other moving parts. ONLY operate this
bandsaw with blade guard in proper position
and wheel covers completely closed.

BLADE REPLACEMENT. To avoid mishaps that

could result in operator injury, make sure
blade teeth face down toward table and
blade is properly tensioned and tracked
before operating.

UPPER BLADE GUIDE SUPPORT. To reduce

exposure of operator to blade and provide
maximum blade support while cutting, keep
upper blade guides adjusted to just clear
workpiece.

CUTTING TECHNIQUES. To avoid blade getting

pulled off wheels or accidentally breaking
and striking operator, always turn bandsaw
OFF and wait for blade to come to a
complete stop before backing workpiece out
of blade. DO NOT back workpiece away from
blade while bandsaw is running. DO NOT
force or twist blade while cutting, especially
when sawing small curves. This could result
in blade damage or breakage.

WORKPIECE SUPPORT. To maintain maximum

control and reduce risk of blade contact/
breakage, always ensure adequate support
of long/large workpieces. Always keep
workpiece flat and firm against table/fence
when cutting to avoid loss of control. If
necessary, use a jig or other work-holding
device.

BLADE CONTROL. To avoid risk of injury due

to blade contact, always allow blade to stop
on its own. DO NOT try to stop or slow blade
with your hand or the workpiece.

WORKPIECE MATERIAL. This machine is

intended for cutting natural and man-made
wood products, and laminate covered wood
products. This machine is NOT designed to
cut metal, glass, stone, tile, etc.

-11-

Model W1849 (For Machines Mfd. Since 11/16)

This machine must be connected to the correct size and
type of power supply circuit, or fire or electrical damage
may occur. Read through this section to determine if an
adequate power supply circuit is available. If a correct
circuit is not available, a qualified electrician MUST install
one before you can connect the machine to power.

A power supply circuit includes all electrical equipment
between the breaker box or fuse panel in the building
and the machine. The power supply circuit used for
this machine must be sized to safely handle the full­load current drawn from the machine for an extended
period of time. (If this machine is connected to a circuit
protected by fuses, use a time delay fuse marked D.)

This machine can be converted to operate on a power
supply circuit that has a verified ground and meets the
requirements listed below. (Refer to
instructions for details.)

This machine is prewired to operate on a power supply
circuit that has a verified ground and meets the following
requirements:

The full-load current rating is the amperage a machine
draws at 100% of the rated output power. On machines
with multiple motors, this is the amperage drawn by the
largest motor or sum of all motors and electrical devices
that might operate at one time during normal operations.

or machine damage. To reduce this risk,

a dedicated circuit—

where only one machine will be running

multiple machines will be running at the

ELECTRICAL

Circuit Requirements

The machine must be properly set up
before it is safe to operate. DO NOT
connect this machine to the power
source until instructed to do so later in
this manual.

ELECTRICAL

Full-Load Current Rating

Full-Load Current Rating at 110V .................. 15 Amps

Full-Load Current Rating at 220V ................. 7.5 Amps

Circuit Requirements for 110V (Prewired)

Circuit Type ............... 110V/120V, 60 Hz, Single-Phase

Circuit Size ............................................. 20 Amps

Plug/Receptacle .................................... NEMA 5-15

Circuit Requirements for 220V

Circuit Typ e ...............220V/240V, 60 Hz, Single-Phase

Circuit Size ............................................. 15 Amps

Plug/Receptacle .................................... NEMA 6-15

Voltage Conversion

Incorrectly wiring or grounding this
machine can cause electrocution, fire,

only an electrician or qualified service
personnel should do any required
electrical work on this machine.

NOTICE

The circuit requirements listed in this
manual apply to

at a time. If this machine will be
connected to a shared circuit where

same time, consult with an electrician
to ensure that the circuit is properly
sized for safe operation.

-12-

Model W1849 (For Machines Mfd. Since 11/16)

This machine MUST be grounded. In the event of certain
types of
a path of least resistance for electric current
order

Improper connection of the equipment-grounding

will
increase
insulation
grounding
cord or plug is necessary, do not connect the equipment­grounding

Check with a qualified electrician or service personnel
if
or if
properly grounded.
plug is damaged or worn, disconnect it from power, and
immediately replace it with a new one.

A NEMA 6-15 plug (see figure) has a grounding prong that
must be attached to the equipment-grounding wire inside
the included power cord.
into a matching
and grounded in accordance with all local codes and
ordinances.

This machine is equipped with a power cord with an
equipment-grounding
plug
a matching
grounded in accordance with local codes and ordinances.

We do not recommend using an extension cord with

Any extension cord used with this machine must contain a

plug and receptacle, and

meet the following requirements:

Grounding Requirements

malfunctions or breakdowns, grounding provides

to travel—in

to reduce the risk of electric shock.

wire

the risk of electric shock. The wire with green

(with/without yellow stripes) is the equipment-

wire. If repair or replacement of the power

wire to a live (current carrying) terminal.

The machine must be properly set up
before it is safe to operate. DO NOT
connect this machine to the power
source until instructed to do so later in
this manual.

110V

GROUNDED

5-15 RECEPTACLE

ELECTRICAL

you do not understand these grounding requirements,

you are in doubt about whether the tool is

If you ever notice that a cord or

For 110V Connection (Prewired)

wire and NE M A 5-15 grounding

(see figure). The plug must only be inserted into

receptacle that is properly installed and

For 220V Connection

The plug must only be inserted

receptacle that is properly installed

this machine. Extension cords cause voltage drop, which
may damage electrical components and shorten motor
life. Voltage drop increases with longer extension cords
and smaller gauge sizes (higher gauge numbers indicate
smaller sizes).

ground wire, match the required

Minimum Gauge Size .................................. 12 AWG

Maximum Length (Shorter is Better)..................50 ft.

Extension Cords

-13-

Grounding Prong

5-15 PLUG

Neutral Hot

Figure 9. NEMA 5-15 plug & receptacle.

DO NOT modify the provided plug or
use an adapter if the plug will not
fit the receptacle. Instead, have an
electrician install the proper receptacle
on a power supply circuit that meets
the requirements for this machine.

220V

Current Carrying Prongs

6-15 PLUG

Figure 10. NEMA 6-15 plug & receptacle.

GROUNDED

6-15 RECEPTACLE

Grounding Prong

Converting Voltage

MOTOR

220V

START

CAPACITOR

200MFD
250VAC

RUN

CAPACITOR

50MFD

250VAC

Ground

MOTOR

110V

START

CAPACITOR

200MFD
250VAC

RUN

CAPACITOR

50MFD

250VAC

Ground

to 220V

For your own safety and protection of property,
consult an electrician if you are unsure about wiring
practices or electrical codes in your area.

The voltage conversion MUST be performed by an
electrician or qualified service personnel. The voltage
conversion procedure requires rewiring the motor and
installing the correct plug. The necessary wiring diagrams
are provided in the Wiring section, beginning on Page 75
for your reference.

IMPORTANT: If the diagram on the motor conflicts with
the diagrams in the Wiring section, the motor may have
changed since the manual was printed. Use the diagram
on the motor instead.

Model W1849 (For Machines Mfd. Since 11/16)

SETUP

Items Needed Qty

• Phillips Head Screwdriver #2 ............................1

• Electrical Tape ................................. As Needed

• Wire Nut (14 AWG x 3) ....................................1

• Plug 6-15 ....................................................1

Remove These

Wire Nuts

E

U

V

• Wire Cutters/Stripper.....................................1

To convert Model W1849 to 220V, do these steps:

3

124

1. DISCONNECT MACHINE FROM POWER!

2. Cut off existing 5-15 plug.

3. Open motor junction box, then remove two wire

Figure 11. Inside motor junction box.

nuts indicated in Figure 11.

4. Connect wires as indicated in Figure 12. Secure wire

connections with wire nuts, and wrap them with
electrical tape so they will not vibrate loose during
operation.

5. Close and secure motor junction box.

6. Install a 6-15 plug on power cord, according to plug

Connect

Wires with

Nuts Here

U

124

V

To Switch

E

3

manufacturer's instructions. If plug manufacturer's
instructions are not available, NEMA standard 6-15
plug wiring is provided on Page 76. Figure 12. Motor rewired to 220V.

-14-

To Switch

Model W1849 (For Machines Mfd. Since 11/16)

This machine has been carefully packaged for safe
transportation. If you notice the machine has been
damaged during shipping, please contact your authorized
Shop Fox dealer immediately.

The following items are needed, but not included, to set
up your machine.

Immediately discard all

materials to eliminate

This machine presents
serious injury hazards
to untrained users. Read

to become familiar with

tions before starting the

Straining or crushing

improperly lifting the

parts. To reduce this

SETUP

Unpacking

through this entire manual

the controls and opera-

Items Needed for Setup

Description Qty

• Safety Glasses for Each Person ..........................1

• Degreaser or Solvent for Cleaning ................Varies

• Disposable Rags for Cleaning ......................Varies

• Lifting Strap/Chain (rated for at least 400 lbs.) .....1

• Lifting Equipment (rated for at least 400 lbs.) .......1

• Dust Collection System ...................................1

• 4" Dust Hose ................................................1

• 4" Hose Clamp ..............................................1

• Assistant for Lifting .......................................1

• 1 X 4 Block 12" .............................................1

• 2 x 4 Block 12" .............................................1

machine!

Wear safety glasses during
entire setup process!

SETUP

SUFFOCATION HAZARD!

plastic bags and packing

choking/suffocation
hazards for children and
animals.

HEAVY LIFT!

injury may occur from

machine or some of its

risk, get help from other
people and use a forklift
(or other lifting equip­ment) rated for weight of
this machine.

-15-

Inventory

The following is a list of items shipped with your machine.
Before beginning setup, lay these items out and inventory
them.

Note:

check around/inside the machine and packaging materials.
Often, these items get lost in packaging materials while
unpacking or they are pre-installed at the factory.

If you cannot find an item on this list, carefully

Inventory (Figures 13-14) Qty

A. Main Bandsaw Body (not shown) ........................1

B. Table .........................................................1

C. Table Insert ................................ .................1

D. Fence Face .................................................1

E. Fence Base Guide Assembly .............................1

F. Fence Rail ..................................................1

G. Gap Screw Lock Lever M8-1.25 x 35 ....................1

H. Fence Support Bracket ...................................1

I. Cap Screws M6-1 x 12 (Fence Support) ................2

J. Hex Bolts M8-1.25 x 16 (Table/Trunnion) ..............4

K. Flat Washer 8 x 20 (Table/Gap Screw) .................1

SETUP

L. Flat Washers 6mm (Fence Support) ....................2

M. Flat Washers 8mm (Table/Trunnion)....................4

N. Hex Bolt M8-1.25 x 110 (Positive Stop/Saw Body) ...1

O. Hex Nut M8-1.25 Thin (Table/Trunnion) ...............1

P. Hex Nut M8-1.25 (Positive Stop/Saw Body) ...........1

Q. Lock Washers 8mm (Table/Trunnion) ...................4

R. Fence Base Lock Lever ...................................1

S. Fence Face Lock Lever M8-1.25 x 50 ...................1

T. Fence Guide Plate .........................................1

U. Flat Washer 8mm (Fence Base) .........................1

V. Hex Nut M8-1.25 (Fence Base) ..........................1

W. Hex Bolts M6-1 x 20 (Fence Rail) .......................2

X. Flat Washers 6mm (Fence Rail) .........................2

Y. Lock Washers 6mm (Fence Rail) ........................2

Z. Hex Wrench 5mm ..........................................1

AA. Hex Wrench 6mm ..........................................1

AB. Open-End Wrench 10/13mm .............................1

Model W1849 (For Machines Mfd. Since 11/16)

B

C

D

E

F

Figure 13. Box 1 inventory.

G

I

K

O

R

L

P

J

S

H

M

Q

U

T

N

V

-16-

W

Z

Figure 14. Box 2 hardware inventory.

X

AA

Y

AB

Model W1849 (For Machines Mfd. Since 11/16)

Hardware Recognition Chart

USE THIS CHART TO IDENTIFY
HARDWARE DURING THE
INVENTORY/ASSEMBLY
PROCESS.

1

⁄4"

3

⁄8"

1

⁄2"

5

⁄8"

⁄16" INCH APART

1

LINES ARE

5

⁄16"

7

⁄16"

9

⁄16"

3

⁄4"

7

⁄8"

1

1

1

1

1

3

1

2

1

2

1

2

3

2

3

⁄4"

⁄2"
⁄4"

⁄4"

⁄2"

⁄4"

#10

1

⁄4"

5

⁄16"

3

⁄8"

7

⁄16"

1

⁄2"

D

I

A

R

E

H

S

A

W

R

E

H

8mm

S

A

W

R

E

H

S

7

A

⁄16"

W

D

R

E

H

S

A

W

WASHERS ARE MEASURED BY THE INSIDE DIAMETER

#10

M

E

T

E

5

⁄8"

D

I

A

D

I

A

I

A

M

E

T

E

R

R

M

E

T

E

R

M

E

T

E

R

E

H

S

A

D

R

E

H

S

A

W

4mm

R

E

H

S

10mm

A

W

D

R

3

⁄8"

W

I

A

M

E

T

E

R

D

I

A

R

E

A

E

T

9

⁄16"

M

E

T

E

R

M

E

T

E

R

H

S

A

A

I

D

M

R

S

A

I

A

R

5

⁄16"

W

M

E

T

E

E

T

E

R

E

H

D

R

E

H

S

A

W

E

H

S

A

W

D

I

I

A

M

R

5mm

E

H

S

A

W

R

E

12mm

W

R

D

1

⁄2"

I

D

I

A

A

M

E

R

E

H

1

S

A

W

D

R

E

H

S

A

W

6mm

M

T

E

R

D

I

⁄4"

I

A

R

E

T

E

R

A

M

E

T

E

R

M

E

T

E

SETUP

5mm

10mm
15mm
20mm
25mm
30mm
35mm

MEASURE BOLT DIAMETER BY PLACING INSIDE CIRCLE

40mm
45mm
50mm
55mm

LINES ARE 1MM APART

60mm
65mm
70mm
75mm

4mm

5mm

6mm

8mm

10mm

12mm

16mm

Cap
Screw

Hex
Bolt

External
Retaining
Ring

Key

Carriage
Bolt

Flat
Head
Screw

Internal
Retaining
Ring

Flat Washer

Flange
Bolt

Tap
Screw

E-Clip

Lock
Washer

Button
Head
Screw

Set
Screw

Lock
Nut

Hex
Nut

Phillips
Head
Screw

Wing
Nut

Hex
Wrench

-17-

To prevent
machine, the factory has coated t
of your machine
compound

I
be difficult to
coating is as easy as possible, please gather the correct
cleaner, lubricant, and tools listed below:

• Cleaner/degreaser
and grease

• Safety glasses & disposable gloves

•

• Disposable Rags

To

1.

2.

3

4

5

6

immediately coat with a quality metal protectant.

Cleaning Machine

corrosion during shipment and storage of your

with a heavy-duty rust prevention

.

f you are unprepared or impatient, this compound can

remove. To ensure that the removal of this

designed to remove storage wax

Solvent brush or paint brush

remove rust preventative coating, do these steps:

DISCONNECT MACHINE FROM POWER!

Model W1849 (For Machines Mfd. Since 11/16)

he bare metal surfaces

Gasoline and petroleum
products have low flash
points and can explode
or cause fire if used to
clean machinery. Avoid
using these products
to clean machinery.
Many cleaning solvents
are toxic if inhaled.
Minimize your risk
by only using these
products in a well
ventilated area.

SETUP

Put on safety glasses and disposable gloves.

. Coat the rust preventative with a liberal amount of

cleaner/degreaser, then let it soak for 5–10 minutes.

. Wipe off surfaces. If your cleaner/degreaser is

effective, the coating will wipe off easily.

Tip: An easier way to clean off thick coats of rust
preventative from flat surfaces is to use a PLASTIC
paint scraper to scrape off the majority of the
coating before wiping it off with your rag. (Do
not use a metal scraper or you may scratch your
machine.)

. Repeat cleaning steps as necessary until all of the

compound is removed.

. To prevent rust on freshly cleaned surfaces,

In a pinch, automotive degreasers,
mineral spirits or WD•40 can be used
to remove rust preventative coating.
Before using these products, though,
test them on an inconspicuous area of
your paint to make sure they will not
damage it.

-18-

Model W1849 (For Machines Mfd. Since 11/16)

Weight Load

Refer to the
weight of your machine. Make sure that the
surface upon which the machine is placed will
bear the weight of the machine, additional
equipment that may be installed on the
machine, and the heaviest workpiece that will
be used. Additionally, consider the weight of
the operator and any dynamic loading that may
occur when operating the machine.

Space Allocation

Consider the largest size of workpiece that
will be processed through this machine and
provide enough space around the machine
for adequate operator material handling or
the installation of auxiliary equipment. With
permanent installations, leave enough space
around the machine to open or remove doors/
covers as required by the maintenance and
service described in this manual.

required space allocation.

Physical Environment

The physical environment where your machine is
operated is important for safe operation and the

ambient temperature range exceeds 41°–104°F;

(non-condensing); or the environment is subject

source. Make sure all power cords are protected

chemicals, or other hazards. Make sure to leave

Machine Placement

Machine Specifications for the

longevity of its components. For best results,
operate this machine in a dry environment
that is free from excessive moisture, hazardous
chemicals, airborne abrasives, or extreme
conditions. Extreme conditions for this type
of machinery are generally those where the

the relative humidity range exceeds 20–95%

to vibration, shocks, or bumps.

Electrical Installation

Place this machine near an existing power

See below for

Children or untrained people
may be seriously injured by this
machine. Only install in an access
restricted location.

= Electrical
Connection

from traffic, material handling, moisture,

access to a means of disconnecting the power
source or engaging a lockout/tagout device.

27½"

Lighting

Lighting around the machine must be adequate
enough that operations can be performed
safely. Shadows, glare, or strobe effects that
may distract or impede the operator must be
eliminated.

Keep Workpiece
Unloading Area
Unobstructed

32"

Keep Workpiece
Loading Area
Unobstructed

SETUP

Figure 15. W1849 working clearances.

-19-

Lifting & Moving

Straining or crushing

improperly lifting the

parts. To reduce this

Special care should be taken when moving this bandsaw.
To reduce your risk of injury or accidental damage,
use one of the following methods to lift or move this
bands aw.

Using Forklift & Eye Bolt

1. Use forklift to move crate to prepared location, then

remove crate from shipping pallet.

2. Unbolt bandsaw from pallet.

3. Make sure eye bolt is securely threaded, then place

lifting hook through eye bolt (see Figure 16) and lift
bandsaw slowly with forklift enough to clear pallet.

Model W1849 (For Machines Mfd. Since 11/16)

HEAVY LIFT!

injury may occur from

machine or some of its

risk, get help from other
people and use a forklift
(or other lifting equip­ment) rated for weight of
this machine.

4. Remove pallet and slowly set bandsaw into position.

Using Forklift & Wood Blocks

1. Use forklift to move crate to prepared location, then

SETUP

remove crate from shipping pallet.

2. Unbolt bandsaw from pallet.

3. Carefully place forklift forks under bandsaw head.

Insert a 1x4 block between head and left fork, and a
2x4 block between head and right fork so bandsaw is
level, as shown in Figure 17.

4. Lift bandsaw off of pallet, remove pallet, then

slowly lower bandsaw into position.

Note: If you are concerned about your forklift forks

hitting the tension handwheel, remove handwheel
before positioning forks, then re-install it after
placing bandsaw in final location.

Using Pallet Jack & Furniture Dolly

1. Use pallet jack to move crate to prepared location,

then remove crate from shipping pallet.

Eye Bolt

Lifting Hook

Figure 16. Lifting bandsaw with eye bolt

and chain.

2x4 1x4

2. Unbolt bandsaw from pallet.

3. With help of another person, carefully "walk"

bandsaw (or use furniture dolly to move bandsaw)
off of pallet and into position.

Figure 17. Example of lifting bandsaw

with forklift using wood shims.

-20-

Model W1849 (For Machines Mfd. Since 11/16)

Anchoring to Floor

Number of Mounting Holes ....................................4

Diameter of Mounting Hardware ..........................

Anchoring machinery to the floor prevents tipping or
shifting and reduces vibration that may occur during
operation, resulting in a machine that runs slightly quieter
and feels more solid.

If the machine will be installed in a commercial or
workplace setting, or if it is permanently connected
(hardwired) to the power supply, local codes may require
that it be anchored to the floor.

If not required by any local codes, fastening the machine
to the floor is an optional step. If you choose not to do
this with your machine, we recommend placing it on
machine mounts, as these provide an easy method for
leveling and they have vibration-absorbing pads.

3

⁄8"

Anchoring to Concrete Floors

Lag shield anchors with lag screws (see Figure 18) are
a popular way to anchor machinery to a concrete floor,
because the anchors sit flush with the floor surface,
making it easy to unbolt and move the machine later, if
needed. However, anytime local codes apply, you MUST
follow the anchoring methodology specified by the code.

Lag Screw

Flat Washer

Machine Base

Lag Shield Anchor

Concrete

Drilled Hole

Figure 18. Popular method for anchoring

machinery to a concrete floor.

SETUP

-21-

Assembly

Before beginning the assembly process, refer to Items
Needed for Setup and gather everything you need.

Ensure all parts have been properly cleaned of the
heavy-duty rust-preventative applied at the factory, if
applicable. Be sure to complete all steps in the assembly
procedure prior to performing the Test Run.

Model W1849 (For Machines Mfd. Since 11/16)

31/2"

To assemble bandsaw, do these steps:

1. Thread (1) M8-1.25 hex nut partially onto M8-1.25

x 110 hex bolt, as shown in Figure 19, then thread
bolt into panel above lower wheel until top of bolt is
approximately 3
nut for now. (Refer to Adjusting Positive Stop on

Page 40.)

2. Remove protective shipping cover from blade, then

remove table insert and shipping screw from table
(see Figure 20).

3. Place table on saw, sliding table gap around blade

SETUP

(see Figure 20).

4. Carefully position table so gap faces to right (see
Figure 21).

1

/2" above panel. Finger-tighten hex

Figure 19. Installing hex bolt to set

positive stop.

Blade

Table

Gap

Table Insert

Removed

Figure 20. Placing table on saw with gap

positioned around blade.

Shipping Screw

Removed

5. Secure table to trunnion using (4) M8-1.25 x 16
hex bolts, (4) 8mm lock washers, and (4) 8mm flat
washers (see Figure 22).

-22-

Table

Gap

Figure 21. Table rotated with gap facing

to the right.

x 4

Figure 22. Table-to-trunnion mounting

hardware installed.

Model W1849 (For Machines Mfd. Since 11/16)

6. Install table insert (see Figure 23).

7. Install table gap screw lock lever, secure with (1)

M8-1.25 thin hex nut and (1) 8 x 20mm flat washer
(see Figure 23), then tighten gap screw to ensure
table surface is flush across gap.

Table Insert

Gap Screw

Assembly

Figure 23. Table insert and gap screw

installed.

8. Install fence support using (2) M6-1 x 12 cap screws
and (2) 6mm flat washers (see Figure 24).

9. Install fence rail using (2) M6-1 x 20 hex bolts, (2)
6mm flat washers, and (2) 6mm lock washers (see
Figure 25).

Fence Support

SETUP

x 2

Figure 24. Installing fence support.

x 2

-23-

Fence Rail

Figure 25. Installing fence rail.

10. Thread (1) M8-1.25 hex nut onto lock lever, install

lock lever onto fence base, then tighten hex nut to
secure (see Figure 26).

11. Install adjustable handle onto fence base with (1)
8mm flat washer, and thread into fence base guide
plate (see Figure 27).

Model W1849 (For Machines Mfd. Since 11/16)

Lock

Lever

Fence

Base

Hex Nut
M8-1.25

Figure 26. Fence base lock lever installed.

Fence Base

Flat Washer

Guide Plate

SETUP

12. Place fence base guide on fence rail with lock lever
raised up. Push lock lever down to secure fence in
place (see Figure 28).

Adjustable

Handle

Figure 27. Fence base adjustable handle

and guide plate installed.

Fence Base Guide

Rail

Lock Lever in

Down (Locked)

Position

-24-

Figure 28. Fence base installed on fence

rail.

Model W1849 (For Machines Mfd. Since 11/16)

13. Mount fence to fence base guide, sliding T-channel
around fence base guide plate (see Figure 29).

— For normal workpieces or resawing, mount fence

in vertical position, as shown in Figure 29, then
rotate fence base lock lever to secure.

— For thin workpieces, mount fence in horizontal

position, as shown in Figure 30, then rotate fence
base lock lever to secure.

T-Channel

Fence

Fence Lock

Lever

Figure 29. Installing fence in vertical

T-Channel

Fence Base Guide

position.

Fence

SETUP

Fence Lock

Lever

Figure 30. Fence installed in horizontal

position.

-25-
