SFS15
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
001 00000001 0CW4025P067C/ B cover BD
001 00000002 0CW040060FNBi Screw AA
001 00000003 0CW4025P128E/ B stay L AU
001 00000004 0CW4025P191A/ B stay L reinforce bracket AD
001 00000005 0CW040060FZTP Screw [M4X6] AA
001 00000006 0CW4025P064D/ B latch lever AS
001 00000007 0CW4025P107A/ Screw AB
001 00000008 0CW4025P060B/ Lock pawl AE
001 00000009 0CW040100FNBi Screw AA
001 00000010 0CW4025P122C/ B latch lever spring AD
001 00000011 0CW4025P125B/ B Push pin spring AC
001 00000012 0CW4025P059A/ B push pin AE
001 00000013 0CW4025P124B/ B stud AM
001 00000014 0CcW4025P065B/ B stay U AX
001 00000015 0CW4025P126A/ B belt BC
001 00000016 0CW4032P071A/ B transport roller shaft BD
001 00000017 0CW4025P058C/ B transport roller AK
001 00000018 0CW4043P201A/ Fan [FAN-CBDC24B4-910-MK3] BK
001 00000019 0CW040060FNTW Screw AA
001 00000020 0CW4025K010A/ ASM earth wire A AD
001 00000021 0CW4025P061A/ B duct AK
001 00000022 0CWER070SKN// E type ring AA
001 00000023 0CW4025P016A/ Gear [GER- 1-23] AF
001 00000024 0CW634510//// Bearing AQ
001 00000025 0CW4025P127D/ B belt roller BB
001 00000026 0CW020120SCH/ Pin [2X12] AA
001 00000027 0CW020100SCH/ Pin [2X10] AA
001 00000028 0CW4025P018B/ Pulley[PLY-S3M-18] AF
001 00000029 0CW4025P053A/ Drive shaft AS
001 00000030 0CW4025P066C/ B plate AX
001 00000031 0CW4025P129C/ B blower BD
001 00000032 0CW040250FNBi Screw AA
001 00000033 0CWNT040FZ1// Nut AA
001 00000034 0CW684311//// Ball bearing AN
001 00000035 0CW030060FZWS Screw [M3X6] AA
002 00000001 0CW4043P005A/ R cover BK
002 00000002 0CW040060FNBi Screw AA
002 00000003 0CW4043K208B/ ASM-CN5 harness AP
002 00000004 0CW4043K205B/ ASM-CN2 harness AM
002 00000005 0CW4043K207C/ ASM-CN4 harness AV
002 00000006 0CWE450000377 Snap band [SG-130] AC
002 00000007 0CWE450000446 Wire saddle [WS-2NS] AB
002 00000008 0CW4043K210C/ ASM-CN7 harness AN
002 00000009 0CW4043K213C/ ASM-CN11 harness AU
002 00000010 0CW4043K211C/ ASM-CN8 harness AP
002 00000011 0CW4025P046D/ Pulley [PLY-S2M-64] AN
002 00000012 XRESP40-05000 E type ring AA
002 00000013 0CW4025P013A/ Pitch plate AB
002 00000014 0CW4025P029D/ Pulley [PLY-S2M-16-66] AH
002 00000015 0CW4025P047D/ Gear AN
002 00000016 0CW4025P039C/ Pulley [PLY-S3M-40] AH
002 00000017 0CW4025P040A/ Belt [BLT-S3M 121-6] AP
002 00000018 0CW4025K072A/ Bracket ass'y AX
1
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
002 00000019 0CW4025P090D/ Motor [MOT-NA3535A02] BG
002 00000020 0CW030060FZWS Screw [M3X6] AA
002 00000021 0CW4025P030B/ Pulley [PLY-S2M-13] AM
002 00000022 0CW030060FPWP Screw [M3X6] AA
002 00000023 0CWE314000386 Photo interrupter [TLP1209(C7)] AM
002 00000024 0CW040140FZWS Screw [M4X14] AA
002 00000025 0CW4025P043A/ Belt [BLT-S2M-90-6] AM
002 00000026 0CW040060FZTP Screw [M4X6] AA
002 00000027 0CW4043K114B/ Motor bracket N K ass'y AQ
002 00000028 0CW4025P017B/ Belt idler gear AN
002 00000029 0CW4025P041A/ Belt [BLTS2M80-6] AM
002 00000030 0CW4025P031B/ Pulley [PLY-S2M-18] AM
002 00000031 0CW4025P012C/ BR stopper AC
002 00000032 XRESP50-06000 E type ring AA
002 00000033 0CW4025P015B/ Gear [GER-1-24] AF
002 00000034 0CW040060FBiT Screw [4X6] AA
002 00000035 0CW319290//// Bearing [6MM] AC
002 00000036 0CW4025P018B/ Pulley [PLY-S3M-18] AF
002 00000037 0CW4043P062A/ Cord holder bracket S AF
002 00000038 0CW4043K204A/ ASM-CN1 harness BF
002 00000039 0CW040200FZWS Screw AA
002 00000040 0CW4043P008A/ Cord holder SHA AG
002 00000041 0CWE120001111 Microswitch [DD1L-A1AA] AS
002 00000042 0CW040060FBBi Screw AA
002 00000043 0CW030160FZWS Screw AA
002 00000044 0CW4025P034A/ Lock pin AN
002 00000045 0CWE450000411 Bushing [TB-1116] AD
002 00000046 0CWE450000437 Card spacer [KGLS-6S] AB
002 00000047 0CW4043K200D/ PBA control board ass'y [125V][100V series] BX
002 00000047 0CW4043K215D/ PBA control board ass'y [250V][200V series] BX
002 00000048 0CW030080FZWS Screw [M3X8] AA
002 00000049 0CW2106P027A/ D tap plate AC
002 00000050 0CW2095P287A/ Magnet catch AM
002 00000051 0CW4032P084B/ Pulley [PLY-S3M23] AF
002 00000052 0CW4025P226A/ Washer AA
002 00000053 0CW4025P223A/ Spring AD
002 00000054 0CW4032P082A/ Belt [BLT-S3M095-06] AN
002 00000055 0CW4025P130A/ Tension spring AD
002 00000056 0CW040080FZSW Screw AA
002 00000057 0CW4025K063A/ Tension bracket ass'y AH
002 00000058 0CW4025P023B/ Pulley [PLY-S3M-24] AF
002 00000059 0CW4025P150C/ Tension spring AF
002 00000060 0CW4025P024B/ Pulley [PLY-S3M-20] AF
002 00000061 0CW690381//// Bearing MF AE
002 00000062 0CWER030SKP// E type ring AA
002 00000063 0CW4025P140B/ Top cover sw cover AF
002 00000064 0CW4025P164i/ Side plate R BC
002 00000065 0CW4025P028A/ Tension pulley AE
002 00000066 0CW4025P042A/ Belt [BLT S2M 100-5] AN
002 00000067 0CW040100FZBP Screw AA
002 00000068 0CW040080FNBi Screw AA
002 00000069 0CW4043K212A/ ASM-CN9 harness AK
002 00000070 0CW040060BNTR Screw AA
002 00000071 0CW4043P200B/ Motor [MOT-MB6030A01] BU
002 00000072 0CWE450000167 Bushing [OCB-625] AD
2
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
002 00000073 0CW4043P065B/ S body cord bracket AH
002 00000074 0CW040060FZWS Screw [M4X6] AA
002 00000075 0CW040060FPWP Screw AA
003 00000001 0CW4043P007A/ S side guide cover R AF
003 00000002 0CW040060FNBi Screw AA
003 00000003 0CW4025P018B/ Pulley [PLY-S3M-18] AF
003 00000004 0CW4025P133A/ EXIT guide AP
003 00000005 0CW4025P132A/ EXIT shaft AL
003 00000006 0CW020100SCH/ Pin [2X10] AA
003 00000007 0CW040080FZNP Screw AA
003 00000008 0CW4025P097B/ Belt [BLTS3M 430-6] AT
003 00000009 0CW4025P141C/ Top cover sw plate spring AP
003 00000010 0CWCL040120FZ Spacer AA
003 00000011 0CW040160FBBi Screw AA
003 00000012 0CW4025P165C/ Guide rail AT
003 00000013 0CW4043P016B/ Reel stopper AC
003 00000014 0CW4043K209B/ ASM-CN6 harness AK
003 00000015 0CW649590//// Screw AA
003 00000016 0CW4025K022D/ PBA-LED 2 PWB ass'y AX
003 00000017 0CW4025P136A/ Sensor base AF
003 00000018 0CW4025P054B/ Delivery roller AY
003 00000019 0CW4025P050C/ Delivery guide AW
003 00000020 0CW4025P151A/ Reel adjust bar AF
003 00000021 0CW4025P152A/ Reel fixing spring AD
003 00000022 0CW4025P154C/ Reel pulley AD
003 00000023 0CW4025P153B/ Coil spring cover AC
003 00000024 0CW4025P156B/ Reel spring AC
003 00000025 0CW4032P102B/ Reel film TA AL
003 00000026 0CW4032P103B/ Reel film TB AM
003 00000027 0CW4025P157B/ Reel shaft AX
003 00000028 0CW030060FBNB Screw [M3X6] AA
003 00000029 0CW4025P227B/ Reel collar AD
003 00000030 0CW4025P135B/ Change pawl BA
003 00000031 0CW4025P026B/ Flapper bumper AF
003 00000032 0CW4025P134C/ Solenoid spring AD
003 00000033 0CW4025P051B/ Entrance guide AX
003 00000034 0CW4025P052C/ Guide roller shaft AU
003 00000035 0CW4025P027B/ Guide roller AE
003 00000036 0CW4025P225A/ Guide roller band AG
003 00000037 0CW4032P079A/ Paper feeding roller T AZ
003 00000038 0CW030060FZWS Screw [M3X6] AA
003 00000039 0CW4025P160C/ Sensor spring AD
003 00000040 0CW4025P159B/ Sensor shaft AE
003 00000041 0CW040100FZWS Screw [M4X10] AA
003 00000042 0CW385550//// Washer AB
003 00000043 0CW4025P062A/ B slide plate AG
003 00000044 0CW4043K206C/ ASM-CN3 harness AW
003 00000045 0CW4043K214B/ ASM-CN12 harness AP
003 00000046 0CW4025P162B/ Entrance frame guide AS
003 00000047 0CW4025P161C/ Sensor lever AF
003 00000048 0CWE314000386 Photo interrupter [TLP1209[C7]] AM
003 00000049 0CW030080FZNB Screw AA
003 00000050 0CW4025P115C/ Eject spring guide AD
003 00000051 0CW4025P116A/ Eject spring AC
003 00000052 0CW4025P070B/ Eject shaft AM
3
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
003 00000053 0CW4025P117B/ Eject roller AC
003 00000054 0CW4032P092C/ Eject roller A AD
003 00000055 0CW4025P149B/ Bracket R AF
003 00000056 0CW4025P148A/ Belt holder AK
003 00000057 0CW338432//// Bearing AC
003 00000058 0CW4025P071A/ Gear [GER 0.5-21-A] AE
003 00000059 0CW012060SCH/ Pin AB
003 00000060 0CW4025P112A/ Gear shaft AG
003 00000061 0CW030030FZBi Screw AA
003 00000062 0CW4025P120D/ Frame U AS
003 00000063 0CW4025P109B/ I discharge brush AS
003 00000064 0CW4025P108A/ Earth spring A AD
003 00000065 0CW4025K052A/ I frame R ass'y AN
003 00000066 0CW4025P111B/ Gear plate A AB
003 00000067 0CW030006FZBi Screw AA
003 00000068 0CW4025P019B/ I belt fixing roller AG
003 00000069 0CWPW060050// Washer AA
003 00000070 0CW4025P110A/ Gear plate B AC
003 00000071 0CW4025P020A/ Flange AE
003 00000072 0CW030040FBBi Screw [3X4] AA
003 00000073 0CW4025P022A/ Pulley 14 [P14S3M060] AF
003 00000074 0CW040080FZSW Screw AA
003 00000075 0CW4025P114A/ I joint AH
003 00000076 0CWER030SKP// E type ring AA
003 00000077 0CW4032P093B/ Eject roller shaft A AY
003 00000078 0CW4043P064A/ Joint guide S AQ
003 00000079 0CW4025P121D/ Eject frame D AS
003 00000080 0CW4025P011A/ Side frame F AF
003 00000081 0CW4025P068A/ Earth spring B AC
003 00000082 0CW4025P147A/ Bracket F AE
003 00000083 0CW030080FZTP Screw [M3X8] AA
003 00000084 0CW4025P146B/ Sensor cover AE
003 00000085 0CW4025K020B/ PBA-SEN 2 PWB ass'y AX
003 00000086 0CW4025P057G/ Bottom plate AY
003 00000087 0CWKW040RM-// Washer AA
003 00000088 0CW4025K018A/ ASM earth wire B AE
003 00000089 0CW4043K113A/ Joint S bracket K ass'y AK
003 00000090 0CW4043P010A/ Joint S lever AE
003 00000091 XRESP50-06000 E type ring AA
003 00000092 0CW319290//// Bearing [6MM] AC
003 00000093 0CW040060FZTP Screw [M4X6] AA
003 00000094 0CW040140FZWS Screw [M4X14] AA
003 00000095 0CW4025P143A/ Spring holder AF
003 00000096 0CW040060FBBi Screw AA
003 00000097 0CW4025P034A/ Lock pin AN
003 00000098 0CW040060FZWS Screw [M4X6] AA
003 00000099 0CW2095P287A/ Magnet catch AM
003 00000100 0CW2106P027A/ D tap plate AC
003 00000101 0CW4043P006A/ S side guide cover F AF
003 00000102 0CW4025P150C/ Tension spring AF
003 00000103 0CW4025K128A/ Solenoid assy [Include No.124] AZ
003 00000104 0CW4025P163J/ Side plate F BB
003 00000105 0CW4025P106B/ Collar AC
003 00000106 0CW030040FZiT Screw [M3X4] AA
003 00000107 0CW4025P206A/ Plate spring B AD
4
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
003 00000108 0CW4025P105B/ Collar shaft AM
003 00000109 0CW675840//// Hold plate screw AB
003 00000110 0CW4025P103G/ Top guide BA
003 00000111 0CW4025P166B/ Brush AS
003 00000112 0CW4043P003A/ Top cover AY
003 00000113 0CW4043P001A/ Tray AY
003 00000114 0CW4043P002A/ Tray AY
003 00000115 0CW4032P094B/ Tray brush A AL
003 00000116 0CW4025P056F/ Frame BD
003 00000117 0CW4043P004A/ F cover BF
003 00000118 0CW4025P069A/ Switch plate AC
003 00000119 0CW4025P021B/ Gear [GEAR 0.5-21-B] AG
003 00000120 0CW4025P073E/ K actuator AF
003 00000121 0CW4025P142A/ Blower switch cover AG
003 00000122 0CW4025P104B/ Plate spring AC
003 00000123 0CW012080FPA/ Spring pin AA
003 00000124 0CW030100FPA/ spring pin AA
003 00000125 0CWE450000005 Wire tie [SKB- 1M] AA
003 00000126 0CW030040FZBi Screw AA
003 00000127 0CWHW060FZM// Washer AA
003 00000128 0CW030080FZWS Screw [M3X8] AA
003 00000129 0W040080FBBi Screw [M4X8] AA
003 00000130 0CW4043K103A/ RK base frame ass'y BG
003 00000131 0CW4025P012C/ BR Stopper AC
004 00000001 0CW4043P155A/ Inst. book [Export] AR
004 00000001 0CW4043P153A/ Inst. book [Japan] BA
004 00000001 0CW4043P154A/ Inst. book ENG [English] AG
004 00000002 0CW4043P143B/ Packing ADD UR AX
004 00000003 0CW4043P142B/ Packing ADD UL AX
004 00000004 0CW4043P140B/ Vinyl bag S AK
004 00000005 0CW4043P146B/ Packing ADD DL AX
004 00000006 0CW4043P145B/ Packing ADD DR AX
004 00000007 0CW4043P135A/ Packing case [Export] BF
004 00000007 0CW4043P134A/ Packing case [JAPAN] BF
004 00000008 0CW4043P136B/ Packing case Accessories AR
004 00000009 0CW4025P217A/ Packing ADD AX
004 00000010 0CW4043P138A/ Packing ADD AD
004 00000011 0CW4043P009A/ Guide AS
004 00000012 0CW4043K108B/ RK base ass'y BQ
004 00000013 0CW4043P132B/ Screw AC
004 00000014 0CW040080FBBi Screw [M4X8] AA
004 00000015 0CW4043P106A/ Screw AF
004 00000016 0CW4043P053A/ RK set stopper AE
004 00000017 0CW4043P139B/ Packing ADD AF
004 00000018 0CW342680//// Vinyl bag AA
004 00000019 0CW4043P141A/ vinyl bag AB
004 00000020 0CW2112P021A/ Vinyl bag AB
004 00000021 0CW4043P162A/ Packing ADD AD
004 00000101 0CW4025P215A/ Packing ADD [for AC cord] AC
005 00000001 0CWE74322WE06 Connector [53253-0610] [CN3] AB
005 00000002 0CWE74322WE05 Connector [53253-0510] [CN4] AB
005 00000003 0CWE74322WE04 Connector [53253-0410] [CN5] AB
005 00000004 0CWE74322WE02 Connector [53253-0210] [CN6] AA
005 00000005 0CWE74073WE05 Connector [5483-05AX] [CN7] AD
005 00000006 0CWE74073WE03 Connector [5483-03AX] [CN8] AC
5
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
005 00000007 0CWE74073WE02 Connector [5483-02AX] [CN9] AC
005 00000008 0CWE74105WE04 Connector [5566-04A] [CN10] AE
005 00000009 0CWE74041WE03 Connector [5281-03A] [CN11] AD
005 00000010 0CWE74073WE04 Connector [5483-04AX] [CN12] AD
005 00000011 0CWE74322WE11 Connector [53253-1110] [CN1] AC
005 00000012 0CWE74322WE03 Connector [53253-0310] [CN2] AA
005 00000013 0CW2158P408A/ IC [LSI-N9101MTD] [IC3] AY
005 00000014 0CWE321000333 Transistor [M5261L] [IC4] AG
005 00000015 0CWE321000541 IC [MP4005] [IC5] AS
005 00000016 0CWE321000456 IC [MB3773FP] [IC6] AN
005 00000017 0CWE7701708// IC [HD74HC08FP] [IC7] AE
005 00000018 0CWE321000599 IC [ID62305F] [IC8] AM
005 00000019 0CWE7701714// IC [HD74HC14FP] [IC9,10] AF
005 00000020 0CWE7702006// IC [HD74LS06FP] [IC11] AG
005 00000021 0CWE77017373/ IC [HD74HC373FP] [IC12] AH
005 00000022 0CW71010J1038 Resistor network [RGLD8X103J] [RA1,3,7] AC
005 00000023 0CW71014J4734 Resistor network [RGLD4Y473J] [RA2] AC
005 00000024 0CW71014J4732 Resistor network [RGLD2Y473J] [RA4] AB
005 00000025 0CW71010J4728 Resistor network [RGLD8X472J] [RA5] AC
005 00000026 0CW71010J1033 Resistor network [RGLD3X103J] [RA6] AA
005 00000027 0CWE70106J7R5 Resistor [RSS X 27.50J] [R1] AB
005 00000028 0CWE70165J103 Resistor [ERJ6GEYJ103V] [R2,3,4,8,9,14,15,20,22] AA
005 00000029 0CWE70165J221 Resistor [ERJ6GEYJ221V] [R5,6,7] AA
005 00000030 0CWE250000069 Crystal [HC49/U11.0592MHz] [X1] AP
005 00000031 0CWE70165J510 Resistor [ERJ6GEYJ510V] [R10] AA
005 00000032 0CWE70165J101 Resistor [ERJ6GEYJ101V] [R11,12,13] AA
005 00000033 0CWE70165J473 Resistor [ERJ6GEYJ473V] [R16] AA
005 00000034 0CWE70165J681 Resistor [ERJ6GEYJ681V] [R17,21] AA
005 00000035 0CWE70165J203 Resistor [ERJ6GEYJ203V] [R18,19] AA
005 00000036 0CW73037M105H capacitor [50TWSS1M] [C1] AB
005 00000037 0CW73037M336C capacitor [16TWSS33M] [C2] AB
005 00000038 0CW73037M107H Capacitor [50TWSS100M] [C3] AC
005 00000039 0CW73328K471H Capacitor [GRM40B471K50PT] [C4] AA
005 00000040 0CW73303Z102H Capacitor [GRM40F102Z50PT] [C5,11,- 16,24,25] AA
005 00000041 0CW73295Z105C Capacitor [GRM42-6F105Z16PT] [C6] AC
005 00000042 0CW73328K104E capacitor [GRM408104K25PT] [C7,8,17~21,26~29] AB
005 00000043 0CW73268K330H Capacitor [GRM40CH330K50PT] [C9,10] AA
005 00000044 0CW73305K101H Capacitor [GRM40SL101K50PT] [C22,23] AB
005 00000045 0CW73303Z104H capacitor [GRM40F104Z50PT] [C30,31] AB
005 00000046 0CW73303Z103H Capacitor [GRM40F103Z50PT] [C32,33,34] AA
005 00000047 0CWE321001081 Transistor [FA1L3N] [Q1,2] AB
005 00000048 0CWE311000786 Diode [P10-4003] [D1,2,3,4,5,6,7] AB
005 00000049 0CWE314000337 LED [GL3PR3] [LED1,2.3] AC
005 00000050 0CWE76008H120 Zener diode [RD12MB2] [ZD1,2] AB
005 00000051 0CWE76005B6R2 Zener diode [RD6.2FB] [ZD3] AD
005 00000052 0CWE120001115 Push switch [SKHHAM] [SW1] AC
005 00000053 0CWE120000696 Dip switch [DSS-704] [SW2] AL
005 00000054 0CWE72027M101 Volume [PK502H101H0] [VR1] AF
005 00000055 0CWE120000919 Fuse holder [H0011-1] [FH] AB
005 00000056 0CWE420000391 Check pin [LC-2-SBK] ! AB
005 00000057 0CWE120000662 Fuse[125V][UL-TSC1.25A-N1][100V series] [F1] ! AG
005 00000058 0CWE120000666 Fuse[125V][UL-TSC3.15A-N1][100V series] [F2] ! AG
005 00000059 0CWE120000595 Fuse[250V][BET-1.25][200V series] ! AH
005 00000060 0CWE120000599 Fuse[250V][BET-3.15][200V series] ! AH
005 00000061 0CWE323000153 IC [uPD78C10AGQ-36] [IC1] BA
6
SFS15
SECTION REFNO PARTCODE DESCRIPTIO PRICE
005 00000062 0CW4043K203A/ Rom assembly [IC2] AY
005 00000063 0CWE74269BK28 IC socket for IC2[2-641605-3] AD
005 00000064 0CWE311000977 Diode [DSA010] [D8] AB
005 00000901 0CW4043K215D/ PBA control board ass'y [250V][200V series] PBA BX
005 00000901 0CW4043K200D/ PBA control board ass'y [125V][100V series] PBA BX
7
SFS15
Section 1
SFS15
Section 2
SFS15
Section 3a
SFS15
Section 3b
SFS15
Section 4
Loading...
