Sharp SD-PX2 User Manual

Download

1-BIT DIGITAL RECEIVER WITH DVD

AMPLITUNER NUMÉRIQUE 1-BIT AVEC DVD

MODEL MODÈLE

SD-PX2

OPERATION MANUAL

MODE D’EMPLOI

ENGLISH

Please refer to pages i to iv and E-1 to E-62.

FRANÇAIS

Se reporter aux pages i et iv F-1 à F-62.

Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product.

Nous vous remercions d'avoir porté votre choix sur ce produit SHARP. Pour en tirer le meilleur parti, veuillez lire ce mode d'emploi très attentivement.

SPECIAL NOTES

(for Users in the U.S.A.)

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Explanation of Graphical Symbols:

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

0010

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

0010

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 82040 of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

NOTE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the re-

ceiver is connected.

z Consult the dealer or an experienced radio/TV technician for help.

WARNING

FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user's authority to operate this equipment.

CAUTION:

THIS PRODUCT IS A CLASS 1 LASER PRODUCT. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. AS THE LASER BEAM USED IN THIS PRODUCT IS HARMFUL TO THE EYES, DO NOT ATTEMPT TO DISASSEMBLE THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

0207

FOR YOUR RECORDS

For your assistance in reporting this unit in case of loss or theft, please record below the model number and serial number which are located on the rear of the unit. Please retain this information.

Model number .................................................................................

Serial number .................................................................................

Date of purchase .................................................................................

Place of purchase .................................................................................

0010

IMPORTANT SAFETY INSTRUCTIONS

Read Instructions - All the safety and operating instructions should

be read before the product is operated.

Retain Instructions - The safety and operating instructions should be

retained for future reference.

Heed Warnings - All warnings on the product and in the operating

instructions should be adhered to.

Follow Instructions - All operating and use instructions should be

followed.

Cleaning - Unplug this product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Attachments - Do not use attachments not recommended by the prod-

uct manufacturer as they may cause hazards.

Water and Moisture - Do not use this product near water - for ex-

ample, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

Accessories - Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces

may cause the product and cart combination to overturn.

Ventilation - Slots and openings in the cabinet are provided for venti-

lation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

Power Sources - This product should be operated only from the type

of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

Grounding or Polarization - This product may be equipped with a

polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

Alternate Warnings - This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

Power-Cord Protection - Power-supply cords should be routed so

that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

Protective Attachment Plug - The product is equipped with an at-

tachment plug having overload protection. This is a safety feature. See Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug.

(for Users in the U.S.A.)

0109

IMPORTANT SAFETY INSTRUCTIO NS

Outdoor Antenna Grounding - If an outside antenna or cable system

is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/ NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Example of antenna grounding as per National Electrical Code, ANSI/NFPA 70

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANT EN NA DISCHARGE UNIT

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELECTRICAL CODE S2898A

Lightning - For added protection for this product during a lightning

(NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

Power Lines - An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Overloading - Do not overload wall outlets, extension cords, or integral

convenience receptacles as this can result in a risk of fire or electric shock.

Object and Liquid Entry - Never push objects of any kind into this

product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

Servicing - Do not attempt to service this product yourself as opening

or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Damage Requiring Service - Unplug this product from the wall outlet

and refer servicing to qualified service personnel under the following conditions:

a)When the power-supply cord or plug is damaged, b)If liquid has been spilled, or objects have fallen into the product, c)If the product has been exposed to rain or water, d)If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation,

e)If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in performance - this

indicates a need for service.

Replacement Parts - When replacement parts are required, be sure

the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

Safety Check - Upon completion of any service or repairs to this prod-

uct, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

Wall or Ceiling Mounting - The product should be mounted to a wall

or ceiling only as recommended by the manufacturer.

Heat - The product should be situated away from heat sources such

as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

(for Users in the U.S.A.) (continued)

0109

iii

SPECIAL NOTES REMARQUES SPÉCIALES

"DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems, Inc.

"DTS" et "DTS Digital Surround" sont des marques déposées de Digital Theater Systems, Inc.

Manufactured unde r license fro m Dolby L aboratories. "Dolby", "Pro L ogic" and the double-D symbol are trademarks of Dolby Laboratories.

Fabriqué sous licence de Dolby Laboratories. "Dolby", "Pro Logic" et le symbole double D sont des marques de commerce de Dolby Laboratories.

NOTE

Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678, 5,323,396, 5,530,655, 5,539,829, 5,544,247, 5,606,618, 5,610,985, 5,740,317, 5,777,992, 5,878,080 or 5,960,037.

ENERGY STAR® Program Information

Products that have earned the ENERGY STAR protect the environment through superior energy efficiency.

ENERGY STAR® is a U.S. registered mark.

are designed to

0312

SD-PX2

ENGLISH

Contents

 General Information

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Optional accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 7

Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8, 9

 Preparation for Use

System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Speaker connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 12

Antenna connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

TV connect io n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

AC powe r con ne c tion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

 DVD Operation

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 18

Basic operation

To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . . 19

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

- Contents -

To start playback from the desired point (direct p lay) . . . . . . . . . . . . . . . . . . . . 2 0

Useful operation

To play in the desired order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . . 21

To play repe a tedly (repeat p lay ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

To play the contents between the specified points repeatedly (A-B repeat) . . 22

General Information

Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Resume play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

To zoom images (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . . 25

To sele c t a su btitle or audio languag e from th e disc menu . . . . . . . . . . . . . . . 25

To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

To change the audio language (audio output) . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Page

Various settings

Page

Brightening the image (Gamma correction) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Sharpening the image (Supe r pic ture) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

To change the display on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

To change the display on the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Switching elapsed time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Switching playing time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

To change the setting on the playb ack control screen . . . . . . . . . . . . . . . . . . . 28

Playing a DVD-Audio disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

 SACD and CD Operation

Playing an SACD disc

Playing hy brid SACD sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

To play in random order (random pla y) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Playing an MP3 disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

 Radio Operation

Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Listening to the memorized station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

 Advanced Features

Enjoying surround sound (sound mode) . . . . . . . . . . . . . . . . . . . . . . . . . . 35 - 38

Changing the initial setting of DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 - 42

Changing the default settings of the amplifier . . . . . . . . . . . . . . . . . . . . . . 43 - 46

Timer playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Setting the timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47, 48

Operations after setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Operating the connecte d TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51, 52

Mounting the unit on the wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53, 54

Connecting other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 - 57

 References

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59, 60

Language code list for disc language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

E-1

Accessories

Please confirm that the following accessories are included.

Optional accessory

Use only the specified optional accessory to operate this product properly.

OPTICAL DIGITAL CABLE

Model: AD-M3DC

SD-PX2

ENGLISH

Remote control 1 "AA" size battery (UM/SUM-3, R6,

(RRMCGA003AWSA) (UBATU0001AWZZ)

Video cable 1 AM loop antenna 1

(QCNWG0045AWZZ) (QANTL0012AWZZ)

FM antenna 1 Screw [1/8" (4 mm) in diameter 3/8"

(92LFANT1535A) (XBPSN40P08KS0)

Main unit bracket 1

(GDAI-A003AWPA)

Note:

Only the above accessories are included.

HP-7 or similar) 2

(8 mm)] 2

z Unauthorized copying, broadcast, public display, transmission, public perfor-

mance and rental (regardless of whether or not such activities are for profit) of disc contents are prohibited by law.

z This system is equipped with copy protection technology that causes substantial

degradation of images when the contents of a disc are copied to a video tape.

Copy Protection:

This unit supports Macrovision copy protection. On DVD discs that include a cop y protection code, i f the contents of the DVD disc are copied using a VCR, the copy protection code prevents the videotape copy from playing normally.

Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098, and 4,907,093, licensed for limited viewing uses only.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.

Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

Reverse engineering or disassembly is prohibited.

General Information

- Accessories / Optional accessory -

E-2

SD-PX2

ENGLISH

Precautions

 General

z Please ensure that the equipment is positioned in a well-ventilated area and that

there is at least 4" (10 cm) of free space along the sides and back. There must also be a minimum of 6" (15 cm) of free space on the top of the unit.

z Do not remove the outer cover, as this may result

in electric shock. Refer internal service to your local SHARP service facility.

4" (10 cm)

z Use the unit on a firm, level surface free from vibra-

tion.

z Keep the unit away from direct sunlight, strong mag-

netic fields, excessive dust, humidity and electronic/ electrical equipment (home computers, facsimiles, etc.) which generate electrical noise.

- Precautions -

z Do not place anything on top of the unit. z Do not expose the unit to moisture, to temperatures

General Information

higher than 140°F (60°C) or to extremely low temperatures.

z If the unit does not work properly, unplug and plug it

in again. Then turn on the unit.

z In case of an electrical storm, unplug the unit for safe-

ty.

z Hold the AC power plug by the head when removing

it from the AC outlet, as pulling the cord can damage internal wires.

4" (10 cm)

6" (15 cm)

4" (10 cm)

z This unit should only be used within the range of 41°F

- 95°F (5°C - 35°C).

Warning:

The voltage used must be the same as that specified by this unit. Using this product with a higher voltage other than that specified is dangerous and may result in a fire or other types of accident, causing damage. SHARP will not be held responsible for any damage resulting from the use of this unit with a voltage other than that specified.

 Volume control

The sound level at a given volume setting depends on speaker efficiency, location and various other factors. It is advisable to avoid exposure to high volume levels, which occurs while turning the unit on with the volume control setting up high, or while continually listening at high volumes.

 Care of DVD/SACD/CD discs

DVD/SACD/CD discs are fairly resistant to damage, however mistracking can occur due to an accumulation of dirt on the disc surface. Follow the guidelines below for maximum enjoyment from your DVD/SACD/CD collection and player. z Do not write on either side of the disc, particular ly the non-label side from which

signals are read. Do not mark this surface.

z Keep your discs awa y from direct sunlight, heat, and excessive moisture. z Always hold the DVD/SACD/CDs by the edges. Fingerprints, dirt, or water on the

DVD/SACD/CDs can cause noise or mistracking. If a DVD/SACD/CD is dirty or does not play properly, clean it with a soft, dry cloth, wiping straight out from the center, along the radius.

YES Correct

E-3

Controls and indicators

5 6 7

8 9

SD-PX2

ENGLISH

 Main unit (front panel)

1.Sliding Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 4

3.Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

2 3 4

5.SACD/DVD-AUDIO Stereo Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.Dolby Pro Logic Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.Dolby Digital Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

8.DTS Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

9.PCM Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

10.Daily Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

11.Once Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

12.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

13.Title Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

14.Group Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

15.Chapter Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

16.Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

17.Total Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

18.SACD/DVD-AUDIO Multi Indicator . . . . . . . . . . . . . . . . . . . . . . . . . .30

19.Angle Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

20.Audio Signal/Speaker Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

21.Repeat/One Track Repeat/A-B Repeat Indicator . . . . . . . . . . . . . . . 22

22.Random Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

23.Program Indicator

24.FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

25.FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Reference page

- Controls and indicators -

14 15 16 17

21 22

24 25

General Information

E-4

SD-PX2

ENGLISH

Controls and indicators (continued)

- Controls and indicators -

General Information

1 2 3 4 5

1.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 60

2.Sliding Door Open/Close Button. . . . . . . . . . . . . . . . . . . . . . . . . . . .17

3.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

4.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

5.Disc Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

6.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 18

7.Chapter (track) Skip Up and Down Buttons . . . . . . . . . . . . . . .19, 33

6 7

43 5 6 7 8 9

12 1514

 Main unit (rear panel)

1.Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

2.Coaxial Digital Audio Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . .55

3.Optical Digital Audio Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . .57

4.Optical Digital Audio TV Input Jack . . . . . . . . . . . . . . . . . . . . . . . . .55

5.Audio TV Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

6.Audio VCR Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

7.Audio VCR Output Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

8.Subwoofer Pre Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

(Connect a subwoofer with a built-in amplifier.)

9.AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

10.FM 75 Ohm Antenna Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

11.Antenna Ground Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

12.AM Antenna Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

13.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

14.Component Video Output Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . .13

15.S-video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

16.Video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Reference page

 Main unit (right side panel)

E-5

2 3 4 5 6 7 8 9

10 11 12

13 14

15 16 17 18

SD-PX2

ENGLISH

 Remote control

20 21

23 24

26 27

29 30 31

34 35

1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Reference page

2.MODE 1/MODE 2 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.VCR Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

4.Sliding Door Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . .17

5.TV Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

6.TV On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

7.TV/Video Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

8.Stereo (2 channel) Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

9.Multi Channel Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

10.Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

11.TV Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .51

12.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

13.Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

14.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

15.Fast Reverse or Preset Down Button . . . . . . . . . . . . . . . . . . . . 19, 34

16.Chapter (track) Skip Down or Tuning Down Button . . . . . . . . . 19, 33

17.Repeat Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

18.Disc Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

19.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

20.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

21.Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

22.Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

23.TV Channel Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

24.TV Channel Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

25.Program Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

26.Random Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

27.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

28.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

29.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

30.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 0

31.Unit Display Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 27

32.Fast Forward or Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . 19, 34

33.Chapter (track) Skip Up or Tuning Up Button . . . . . . . . . . . . . . 19, 33

34.DVD Frame Advance, Disc Pause Button . . . . . . . . . . . . . . . . . 18, 23

35.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 18

- Controls and indicators -

General Information

E-6

SD-PX2

ENGLISH

Controls and indicators (continued)

 Remote control

Set the MODE 1/MODE 2 switch to MODE 2 and press the following buttons (indicated in blue). Available operations change.

- Controls and indicators -

General Information

1.DVD Top Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

2.DVD Page Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

3.DVD Super Picture Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

4.DVD Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

5.DVD Gamma Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

6.Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 48

7.A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

8 9

2 3 4 5

12 13 14 15

8.DVD Setup Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28, 39

9.Amplifier Setup Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

10.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

11.On-Screen Display Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

12.DVD Page Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

13.DVD Audio Language or CD Audio Output Select Button . . . . . . . 26

14.DVD Subtitle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

15.DVD Angle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

16.DVD Slow Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Notes:

z In "MODE 2", you can use buttons other than the above for the same operations

as in "MODE 1".

z After operations in "MODE 2", switch to "MODE 1".

Reference page

6 7

E-7

Description of discs

 Types of playable discs

The unit can play back discs bearing any of the following marks:

DVD

DVD-Video Disc for NTSC system DVD-Audio Disc for NTSC system

DVD-R for NTSC system DVD-RW for NTSC system

4.7

Recorded in the video mode (*) Recorded in the video mode (*)

Some DVD discs may not function as described in the manual. See the disc jacket for restrictions.

SACD

Audio CD Audio CD-R Audio CD-RW

 DVD-Video

A popular type of DVD disc of the same size as a CD, mainly containing video images.

Region number

DVD discs are programmed with region numbers indicating countries in which they can be played. This system can play discs with region number "1" or "ALL".

Region number (playable area number)

ALL

Title and chapter

DVD-Video discs are divided into "titles" and "chapters". If the disc has more than one movie on it, each movie is a separate "title". "Chapters" are subdivisions of titles.

Title 1 Title 2

Chapter 1

Chapter 2 Chapter 3 Chapter 1 Chapter 2

 DVD-Audio

Whereas DVD-Videos mainly contain video images, DVD-Audios mostly contain highquality sound data. Its recording capacity is seven times as much as a CD. Its physical structure is the same as DVD-Videos, but largely differs in data and directory structures. It consists of the audio zone, which is the main par t, and the video zone, which records video images.

SD-PX2

ENGLISH

- Description of discs -

Or CD-R recorded in MP3 format (*)

(*) Some discs may not play properly due to the status of the equipment used for re-

cording, characteristics of the discs, scratches, dirt, or dirty optical pickup lens.

Or CD-RW recorded in MP3 format (*)

Group and track

A DVD-Audio disc consists of "groups" and "tracks". Groups are equivalent to albums containing multiple songs. Tracks are the individual songs within a group.

Group 1 Group 2

Track 1

Track 2 Track 3 Track 1 Track 2

General Information

E-8

SD-PX2

ENGLISH

Description of discs (continued)

 DVD-R/D VD-RW playback

z You can play DVD-R and DVD-RW discs recorded in the video mode. z Before playing DVD-R/DVD-RW discs with this unit, finalize them with the

equipment used for recording.

 SACD (Super Audio CD)

An SACD is a high-quality audio disc, capable of recording seven times as much data as a CD. There are three types of SACD: single layer, dual layer and hybrid. Hybrid disc contains both SACD and CD structures. Some SACD discs contain multi channel audio recordings.

Track

SACD and music CD are composed of "tracks". Tracks are equivalent to songs on a CD.

 MP3 format on CD-R/CD-RW

An MP3 file is an audio data compressed in the MPEG 1 audio layer 3 format. MP3 files have the extension ".mp3". (Files with the extension ".mp3" may not play, or noise may occur during playback if not recorded in the MP3 format.)

Folder and track

- Description of discs -

MP3 discs consist of "folders" and "tracks".

General Information

MP3

disc

Folder 1

Track 1

Track 1 Track 2 Track 3 Track 4

Folder 2

Track 2 Track 1

Track 2Track 3

 Icons used on DVD discs

Check the icons of the DVD jacket before playing your discs.

Display Description

Format recorded on the DVD To adopt the video format to the connect-

Type of subtitles recorded

Example: You can select a subtitle language. 1: English 2: Japanese

Number of camera angles

Number of audio tracks and audi o recording systems

Example: z You can change the audio language. 1: Original <English>

(Dolby Digital 5.1 Surround)

2: Japanese (Dolby Digital 2 ch)

ed TVs ("wide-screen TV" or "4:3 size TV").

Recorded subtitle languages.

Number of angles recorded on the DVD. You can view scenes from different an-

gles.

The number of audio tracks and audio recording systems are indicated.

z Audio and recording system vary de-

pending on the DVD. Check them in the DVD's manual.

 Discs that cannot be played

z DVDs without the region number "1" or

"ALL".

z DVDs with PAL system z Photo CD z DVDs with SECAM system z CD-ROM z DVDs with MPEG sound z Discs recorded in special formats, etc. z DVD-ROM z DVD-RAM

z The discs above cannot be played at all, or no sound is heard although images

appear on the screen or vice versa.

z Faulty playback may damage the speakers and can have an adverse effect on

your hearing when played at high volume settings.

z This DVD player adopts the NTSC system. Discs that were made in foreign

countries may not be played back. Check the recording system before purchasing discs.

z You cannot play illegally produced discs.

z CDG z Video CD

E-9

System installation

 Placing the speaker system

The best surround effect will be achieved by placing each speaker at the same distance from the listening position. It is recommended to arrange the speakers as shown below.

Front

speaker (left)

Subwoofer

Center

speaker

Front speaker (right)

SD-PX2

ENGLISH

Notes:

z Place the TV halfway between the front speakers. z It is recommended that the center speaker be placed near the television. z Place the surround speakers at a position just above the height of your ears. z The subwoofer vibrates while reproducing bass. Place it on a stable, sturdy sur-

face.

z The subwoofer reproduces bass. Place it anywhere you like.

Default setting: 6 feet (2 m)

Surround speaker (left)

Note:

The default distance is set to 6 feet (2 m). If speakers cannot be placed at equal distances, refer to "Speaker delay setting" (see page 44).

Surround speaker (right)

Installation image:

Front speaker (left) Front speaker (right)

Center speaker

 Cooling fan

This unit is fitted with a cooling fan at the rear for improved cooling. Do not cover the opening in this section with any obstacles.

Cooling fan

- System installation -

Preparation for Use

Caution:

z The unit will get warm while being used. Do not touch the warm areas of the unit

for prolonged periods to avoid damage to you.

z Protect the amplifier unit from damage. When it is activated, the sound switch is

turned off. In this case, set the unit to the stand-by mode and turn on again.

E-10

SD-PX2

ENGLISH

Speaker connection

Make sure to leave the AC power cord disconnected when connecting the speakers.

See page 10 for placing the speakers. To enjoy the high-quality sound of DVD-Audio or SACD discs, it is recommended to connect speakers with a wide frequency range.

- Speaker connection -

Preparation for Use

Front speaker

(right)

(not supplied)

Speaker wire (not supplied)

Center speaker

(not supplied)

Front speaker

(left)

(not supplied)

Speaker wire (not supplied)

E-11

Surround speaker

(right)

(not supplied)

You can connect a commercially available subwoofer with a built-in amplifier (see page

55).

Surround

(left)

(not supplied)

speaker

 Connecting speaker wires

z Make sure to leave the AC power cord disconnected when connecting the

speakers.

z Connect the speaker wires to the speakers first, then to the unit.

Caution:

z Use a speaker system which has 35 W or more rated power input and 4 ohm

impedance.

z If the volume is turned up too high with the speakers of less than 4 ohm imped-

ance connected, the protection circuit of the amplifier is activated. No sound is produced temporarily.

z Do not mistake the and , and right and left terminals of the speaker wires. (The

right speaker is placed on the right when you face the unit.)

z Do not short-circuit the speaker wire. If it happens with the

power on, the protection circuit is activated and the unit is set to the power stand-by mode. In this case, check that the speaker wire is connected correctly before turning on the power again.

Incorrect

z When the center and surround speakers and subwoofer are not connected, set the

speaker size to "C-NO", "S-NO" and "SW-NO". Otherwise, the protection circuit may be activated and the power is turned off.

Antenna connection

Supplied FM antenna:

Connect the FM antenna wire to the FM 75 OHMS jack and position the FM antenna wire in the direction where the strongest signal can be received.

FM antenna

Black

Supplied AM loop antenna:

Connect the AM loop antenna wire to the AM and GND terminals. Position the AM loop antenna for optimum reception. Place the AM loop antenna on a shelf, etc., or attach it to a stand or a wall with screws (not supplied).

Note:

Placing the antenna on the unit or near the AC power cord may cause noise pickup. Place the antenna away from the unit for better reception.

Installing the AM loop antenna:

< Assembling > < Attaching to the wall >

Wall Screws (not supplied)

Outdoor FM or AM antenna:

Use an outdoor FM or AM antenna if you require better reception. Consult your dealer. When using an outdoor AM antenna, be sure to keep the wire of the AM loop antenna connected.

Outdoor FM antenna

Ground rod

Outdoor AM antenna 49 feet (15 m)

25 feet (7.5 m)

Ground wire

White

AM loop antenna

SD-PX2

ENGLISH

Preparation for Use

- Speaker connection / Antenna connection -

E-12

SD-PX2

ENGLISH

TV connection

Unplug all equipment before making any connections.

Connect a TV with the supplied video cable.

If your TV is equipped with an S-video input jack or component video input jacks, purchase an appropriate cable to enjoy higher quality images. When you use a TV supporting progressive scan, open the initial setting screen and set "PROGRESSIVE OUT" to "ON" in "TV MODE" (see page 41).

Notes:

z Change the TV input in accordance with the connected jack.

- TV connection -

z Do not connect other equipment between the TV and this unit. If they are con- z Using the audio cable, you can listen to the TV sound with this unit.

Preparation for Use

Video cable (supplied)

nected via a VCR, pictures may be distorted.

To video input jack

To S-video input jack

To component

S-video cable (commercially available)

Component video cable (commercially available)

video input jacks

Notes:

z Change the TV input in accordance with the connected jack. z Do not connect other equipment between the TV and this unit. If they are con-

nected via a VCR, pictures may be distorted.

z Using the audio cable, you can listen to the TV sound with this unit. z If your TV has different indications for the component video inputs (Y, CB and CR

or Y, B-Y and P-Y), connect jacks with its matching color.

z Do not connect to a component video input jack designed for the high-vision sys-

tem, which is not DVD-compatible (the images may be distorted or not appear).

z Use a video cable, S-video cable or component video cable to connect the unit to

a TV.

E-13

Remote control

 Battery installation

1 Open the battery cover. 2 Insert the supplied batteries

according to the direction indicated in the battery compartment.

When inserting or removing the batteries, push them toward the battery terminals.

3 Close the cover.

AC power connection

 Connecting the AC power cord

After checking all the connections have been made correctly, plug the AC power cord of this unit into the AC outlet.

AC outlet (AC 120 V, 60 Hz)

SD-PX2

ENGLISH

Precautions for battery use:

z Replace all old batteries with new ones at the same time. z Do not mix old and new batteries. z Remove the batteries if the unit will not be used for long periods of time. This will

prevent potential damage due to battery leakage.

Caution:

z Do not use rechargeable batteries (nickel-cadmium batter y, etc.). z Installing the batteries incorrectly may cause the unit to malfunction.

Notes concerning use:

z Replace the batteries if the operating distance is reduced or if the operation

becomes erratic. Purchase 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).

z Periodically clean the transmitter on the remote control and the sensor on the unit

with a soft cloth.

z Exposing the sensor on the unit to strong light may interfere with operation.

Change the lighting or the direction of the unit.

z Keep the remote control away from moisture, heat, shock, and vibrations.

 Test of the remote control

Point the remote control directly at the remote sensor on the unit.

The remote control can be used within the range shown on the right:

Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy your system.

Remote sensor

8" - 20' (0.2 m - 6 m)

Note:

Unplug the AC power cord from the AC outlet if the unit will not be in use for a prolonged period of time.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

 To turn the power on

Press the ON/STAND-BY button.

If the power does not turn on, check if the power cords are plugged in properly .

To set the unit to stand-by mode:

Press the ON/STAND-BY button again.

Notes:

z After the unit enters the power stand-by mode, wait a few seconds to turn on

again.

z You can also use the ON/STAND-BY button on the remote control.

Preparation for Use

- Remote control / AC power connection -

E-14

SD-PX2

ENGLISH

Preparation for Use

Setting the clock

By setting the unit to the correct time, you can use it not only as a clock but also for timer playback.

- Setting the clock -

In this example, the clock is set to 9:30 AM.

1 Turn on the power, set the MO DE 1/MO DE 2 switch to MODE 2 an d

press the TIMER/SLEEP button.

2 Within 10 seconds, press the or

button to select "CLOCK ADJUST", and then press the ENTER button.

3 Press the or button to adjust the

hour and then press the ENTER button.

z Press the or button once to advance the time by 1 hour. Hold it down to

advance continuously.

z The 12-hour display will appear. z "AM" will change to "PM" automatically.

4 Press the or button to adjust the

minutes and then press the ENTER button.

z Press the or button once to advance the time by 1 minute. Hold it down

to advance continuously.

z The hour will not advance even if minutes advance from "59" to "00". z The clock starts from "0" second (seconds are not displayed). z The time disappears after approx. 2 seconds.

To confirm the time display: [When the unit is in the stand-by mode]

Set the MODE 1/MODE 2 switch to MODE 1 and press the DISPLAY button. The time display will appear for about 5 seconds.

[When the power is on]

Set the MODE 1/MODE 2 switch to MODE 2 and press the TIMER/SLEEP button. Within 10 seconds, press the or button to select "CLOCK". The time display will appear for about 10 seconds.

To readj ust the clock:

Perform "Setting the clock" from the beginning.

z In step 2, the time will be displayed. z Follow steps 3 - 4.

Note:

Unplugging the unit or power failure will clear the clock setting. Readjust the clock.

E-15

General control

 Volume control

Main unit operation:

When the VOLUME control is turned clockwise, the volume will increase. When it is turned counterclockwise, the volume will decrease.

Remote control operation:

Press the VOL + button to increase the volume and the VOL - button for decreasing.

0 1 2

.....

38 39 40

 Muting

The volume is muted temporarily when pressing the MUTE button on the remote control.

z Press again to restore the volume. z The mute status is canceled when you adjust

the volume.

 To change the display brightness (2 levels)

Set the MODE 1/MODE 2 switch to MODE 1 and hold down the DISPLAY b utton for 3 seconds or more. Each time you press, brightness changes.

Dimmed (*) Brightened

SD-PX2

ENGLISH

- General control -

(*) After approx. 5 seconds of DVD-Video playback, the display dims and the original

brightness returns when you stop playback. The brightness remains unchanged during playback of other media.

Note:

The blue light on the right side of the volume control goes out when the display dims with "DIM ON" or "DIM AUTO".

Preparation for Use

E-16

SD-PX2

ENGLISH

Playing a disc

 Playback

z For a wide-screen TV, set the video output to (see page 40). z Turn on the TV, and switch the input to the "VIDEO 1", "VIDEO 2", etc. according-

ly.

1 Turn on the power and press the

button to set the input to "DVD".

You can also use the button on the main unit.

DVD Operation

E-17

- Playing a disc -

Volume control (See page 16).

2 Press the OPEN/CLOSE button to

open the sliding door.

The sliding door closes after approx. 2 minutes of inactivity.

3 Insert a disc.

To avoid damage, insert the disc carefully.

Click sound

Label side

4 Press the OPEN/CLOSE button to

close the sliding door.

Some discs play automatically.

5 If you cannot start playback in step 4, press the button.

When you press the button with the sliding door open, it closes and playback starts.

You can also use the or button on the main unit.

DDV

Operations during disc playback

Action Remote

control

To stop playback

To pause playback

Main unit Operation

When you press once, "RESUME" appears. Press again to enter the stop mode.

While "RESUME" appears, press the button. Playback resumes from the point where it was stopped.

(Resume play: See page 23.)

Not available Press during playback.

In the pause mode, press the button. Playback resumes from the point where it was paused.

Removing discs:

1 Stop playback and press the OPEN/CLOSE

button. 2 Press the eject button to remove the disc. 3 Press the OPEN/CLOSE button to close the

sliding door.

If you turn off the power with the sliding door

open, the door closes.

Eject button

Caution:

Do not touch the sliding door while it is moving, and be careful not to pinch your fingers.

Notes:

z Some DVD discs may not function as described in the manual. See the disc jacket

for restrictions.

z During an operation, " " may appear indicating that the operation is disabled by

the disc.

z Some DVD-R/DV D-RW/CD-R/CD-RW may not play properly due to the status of

the disc or equipment used for recording. Change the recording speed or disc. For more details, see the manual for the equipment.

z When you turn on the power or switch the input to "DVD", initialization starts and

operation is not possible for a few seconds.

z Sound may skip at high volume depending on the disc. In this case, turn down the

volume.

z Do not insert more than one disc. Discs may be damaged. z A disc with scratches or fingerprints may not play properly. Refer to "Care of DVD/

SACD/CD discs (page 3)" and clean the disc.

z Do not play the discs of special shapes (heart or octagon shaped) as they can be

ejected while rotating and cause injury.

An error message appears on TV or the unit when you try to play the following discs (see page 58):

z Scratched discs z Unplayable discs z The region number is neither 1 nor ALL. z Discs supporting parental control (*)

(*) Some DVDs support parental control which restricts viewing according to the

age (see page 41).

Icons used in this operation manual

Some functions may not be available depending on discs. The following icons indicate the discs that can be used in the section.

... DVD-Videos and DVD-Audios. ... Super Audio CDs. ... Audio CDs and CD-R/CD-RW with MP3 recording.

SD-PX2

ENGLISH

- Playing a disc -

DVD Operation

E-18

SD-PX2

ENGLISH

DVD Operation

Basic operation

 To locate the beginning of a chapter (track)

- Basic operation -

(skip)

You can move to other chapter (track) with simple operations.

While a disc is playing, press the or button.

z Press the button to skip to the next chapter (track). z Press the button to skip to the beginning of the current chapter (track).

Press the button again to skip to the beginning of the previous chapter (track).

z The same operation can be performed by pressing the or button on

the main unit.

Notes:

z Some discs do not display the chapter (track) and the skip feature is disabled. z On a DVD, the skip function may not be available between titles (groups).

 Fast forward/Fast reverse (search)

You can search the desired point as you play the disc.

1 While a disc is playing, press the or button.

Example: When the button is pressed

DDV

15/ 13/

::01 23

2 Press the or button repeatedly to select a search speed.

1 (about 2 times) 2 (about 8 times) 3 (about 32 times)

z The disc is forwarded by the button and reversed by the button. z The same operation can be performed by holding down the or button

on the main unit for 2 seconds or more.

Press the button to return to normal playback.

Notes:

z On some discs, the search function is disabled. z The search function is not possible across titles (groups). z During fast forward, subtitles appear and sound is heard only at the search speed

1 (about 2 times). Sound is not heard on SACD discs.

z Depending on the disc or scene, the search speed may differ from that in this man-

ual.

E-19

 To start playback from the desired point

(direct play)

1 During playback, set the MODE 1/MODE 2 switch to MODE 1. 2 Selecting a title of DVD:

Press the DIRECT button.

Selecting a chapter of DVD: Press the DIRECT button twice.

Selecting a track on SACD/CD discs: Press the DIRECT button.

TV screen

83/5/0

::23 40

35/

::23 40

Unit display

3 Within 10 seconds, enter a number with the direct number buttons

(0 - 9) and press the ENTER button.

z To correct the number, enter again. z To cancel, press the RETURN button. z Instead of the direct number buttons (0 - 9), you can use the or button.

How to specify:

Example: To select chapter 12: Press 1, 2, and the ENTER button.

Notes:

z Direct play feature is disabled on some discs. z Some DVD discs may not display the chapter number. z During programmed play, this operation is not available . z On DVD-Audio discs, groups and tracks are played directly instead of titles and

chapters.

To play by specifying time (time search):

You can play back from the desired point by specifying the time.

1 During playback, set the MODE 1/MODE 2 switch to MODE 1. 2 DVD:

Press the DIRECT button three times.

SACD (CD): Press the DIRECT button twice.

TV screen

35/ 83/

-- --

Unit display

3 Within 10 seconds, enter a number with the direct numb er buttons

(0 - 9) and press the ENTER button.

z To specify 1 hour 23 minutes and 40 seconds, enter "012340". z To correct the number, enter again. z To cancel, press the RETURN button. z When you use the or button instead of the direct number buttons (0 - 9),

press the or to switch among hour, minute and second.

z For DVD-Video discs, specify the elapsed time of the title. z For DVD-Audio, SACD, CD discs specify the elapsed time of the track.

Notes:

z Time search is not possible across titles (tracks). z On DVD-Audio discs, time search is not possible across tracks. z Some discs cannot play from the specified point. z Time search feature is disabled on some discs. z During programmed play, this operation is not available . z For MP3 discs, time search is not available. z Some discs contain time portions you cannot specify.

SD-PX2

ENGLISH

- Basic operation -

DVD Operation

E-20

SD-PX2

ENGLISH

DVD Operation

Useful operation

 To play in the desired order (programmed

play)

You can play chapters (tracks) in the desired order within a title (group). 24 chapters can be programmed (programmed play). Titles (groups) cannot be programmed.

- Useful operation -

1 In the stop mode, set the MODE 1/MODE 2 switch to MODE 1 and

press the PROGRAM button.

Example: DVD

The programming screen is displayed. To program tracks on SACD/CD discs, go to

step 3.

2 Select a title number with the or

button and press the ENTER button.

The chapter selection screen appears. Cursor

DVD-VIDEO PROGRAM

TITLE

T 1 T 2

DVD-VIDEO PROGRAM

TITLE

T 1 T 2

3 Use the or button to select a

chapter (track) number, and press the ENTER button.

z The number is saved in the confirmation

area.

z Repeat the operation to program another number. z To correct, press the button to move the cursor to the confirmation area, se-

lect the chapter (track) number with the or button, and press the CLEAR button. After deleting the number, press the button to return the cursor to the selection area.

DVD-VIDEO PROGRAM

T : 1

C 1 C 2 C 3 C 4 C 5 C 6

Selection area Confirmation

T : 1

1: C 1 2: C 3: C 4: C 5: C 6: C

area

4 Press the button to start playback.

z The unit stops after playing the chapters (tracks) in the programmed order. z The programmed contents will be stored until the disc is removed.

To add numbers to the program:

Repeat steps 1 and 3. Additional chapter (track) numbers are added immediately after the chapter (track) already programmed.

To delete all numbers in the program:

1 In the stop mode, press the PROGRAM button. 2 Press the button to move the cursor to the confirmation area. 3 Press the CLEAR button for 4 seconds or more.

To cancel the operation:

Press the PROGRAM button.

To repeat the disc using programmed play:

Press the PROGRAM button, and then press the button. Programmed play is canceled when playback stops.

Notes:

z Programming cannot be performed while paused or in the playback mode. z Programmed play is prohibited on some discs. z Chapters in other titles cannot be programmed together. z For programmed play on DVD-Audio discs, select groups or tracks. z For an MP3 disc, programmed play is not available.

E-21

SD-PX2

 To play repeatedly (repeat play)

You can play a chapter (track) or a title (group) repeatedly by specifying it during playback.

1 During playback, set the MODE 1/MODE 2 switch to MODE 1 and

press the button.

TV screen Unit display

Each time the button is pressed, the repeat play mode changes in the following order.

The repeat play mode changes as follows on DVD:

No display

The repeat play mode changes as follows on SACD/CD:

No display

On DVD-Audio discs, the mode switches as follows: T (track), G (group), no display (normal playback).

DDV

"1-REPEAT "

"REPEAT"

"NORMAL"

"1-REPEAT "

"REPEAT"

"NORMAL"

Repeat the currently playing chapter.

Repeat the currently playing title.

Normal playback.

Repeat the currently playing track.

Repeat the currently playing disc.

Normal playback.

2 To return to normal playback, press the button repeatedly to se-

lect "NORMAL".

Caution:

After performing repeat play, be sure to press the button. Otherwise, the disc will play continuously.

Notes:

z On some discs, the repeat play function is disabled. z To repeat SACD/CD programmed play, perform repeat play during playback. z If you press the RANDOM button, the current SACD/CD repeat play is canceled

and switched to random play.

z During DVD programmed play, repeat play is not available. z When you press the button, the current repeat play of DVD, it is canceled.

 To play the contents between the specified

points repeatedly (A-B repeat)

You can play the desired portion repeatedly by specifying it during playback.

1 During playback, set the MODE 1/MODE 2 switch to MODE 2 and

press the A B button.

TV screen Unit display

The start point (A) is created.

DDV

2 Press the A B button again to enter the end point (B).

A-B repeat starts from the start point (A) to the end point (B).

DDV

3 Press the A B button to return to normal playback.

Notes:

z A-B repeat play is disabled on some discs. z A-B repeat play for DVD-Video is possible only within a title. z A-B repeat play for DVD-Audio/SACD/CD is possible only within a track. z Some scenes on DVD may not allow A-B repeat play. z During programmed play, A-B repeat play is not available. z When you press the button, the current A-B repeat play is canceled. z For MP3 discs, A-B repeat play is not available. z An end point (B) is created when playback of the title (track) ends.

ENGLISH

- Useful operation -

DVD Operation

E-22

SD-PX2

ENGLISH

Useful operation (continued)

 Slow-motion play

You can slow down the playback speed.

 Still picture/Frame advance

You can freeze the image and advance frame by frame.

1 During playback, set the MODE 1/MODE 2 switch to MODE 1 and

- Useful operation -

DVD Operation

2 Press the STILL button during still picture playback. 3 Press the button to return to normal playback.

Notes:

z Still picture and frame advance features are disabled on some discs. z Frame advance is not available on DV D-Audio discs.

press the STILL button.

A still picture appears.

Each press of the STILL button advances the frame.

1 During playback, set the MODE 1/

MODE 2 switch to MODE 2 and press the SLOW button.

15/ 13/

::01 23

DDV

2 Press the SLOW button repeatedly to select a playback speed.

1 (about 1/2 times) 2 (about 1/8 times) 3 (about 1/16 times)

3 Press the button to return to normal playback.

Notes:

z On some discs, the slow-motion playback functions are disabled. z Slow-motion play is not available on DVD-Audio discs.

 Resume play

You can resume playback from the point where it was stopped.

1 While the disc is playing, press the

button.

The system stores the point.

15/ 13/

::01 23

RESUME

2 To resume playback, press the button.

Play resumes from the point.

To cancel resume pl ay:

Press the button while "RESUME" is displayed.

Notes:

z The resume play feature is disabled on some discs. z Depending on the disc, playback may resume from slightly before the stopped

position.

z For MP3 discs, resume play is not available.

E-23

 To zoom images (zoom)

You can magnify images during playback.

SD-PX2

ENGLISH

 To change the angle

You can change the angle of view when playing a DVD disc that contains scenes recorded from multiple angles.

1 When "ANGLE" appears on the unit

display during playback, set the MODE 1/MODE 2 switch to MODE 2 and press the ANGLE button.

2 Use the ANGLE button to select an

angle number.

Each time you press, the angle changes.

Notes:

z Some DVDs prohibit changing the angle. z The angle number is not displayed if there is no other angle recorded. "XX" is dis-

played instead.

z Refer to the manual of the disc as the operation may vary depending on the disc.

1 In the pause mode or during play-

back, set the MODE 1/MODE 2 switch to MODE 2 and press the ZOOM button.

Pressing the button cycles through the zoom settings as follows: ZOOM: 1 ( 1.2) ZOOM: 2 ( 1.5) ZOOM: 3 ( 2.0) Off (The indicator goes

out.).

ZOOM : 1

ZOOM indicator

2 To shift the view and display the desired part of a zoomed image,

press the , , or button repeatedly.

To return to normal view:

Press the ZOOM button repeatedly to select "Off" (the indicator goes out). When you cancel the zoom function, you cannot shift the view.

Notes:

z An image may become distorted when zoomed. z Subtitles cannot be zoomed. z When the zoom indicator changes from white to red while shifting the image, you

cannot shift it any further.

- Useful operation -

DVD Operation

E-24

SD-PX2

ENGLISH

Useful operation (continued)

 To select a subtitle or audio language from

the disc menu

You can select the desired subtitle/audio language and sound system [Dolby Digital (5.1 ch) or DTS sound] on your DVD if it has a disc menu.

1 In the stop mode or during play-

back, set the MODE 1/MODE 2 switch to MODE 1 and press the MENU button.

Example

1.Highlights

2.Start Movie

2 Press the , , or button to select a subtitle/audio language and

press the ENTER button.

You can also use the direct number buttons for some discs.

Notes:

z The procedure shown here provides only general steps. The actual procedure for

using the disc menu depends on the disc you are using. See the disc jacket for details.

z During programmed play, setting is not possible on the disc menu.

DVD Operation

E-25

 To select a title from the top menu of the

disc

On a DVD with multiple titles, y ou can select a title from the top menu.

1 In the stop mode or during playback,

- Useful operation -

set the MODE 1/MODE 2 switch to MODE 2 and press the TOP MEMU button.

Example

21 Drama Action 43 SF Comedy

2 Use the , , , or button to select the title, and then press the

ENTER button.

z The selected title is played. z You can also use the direct number buttons for some discs.

Notes:

z The procedure shown here provides only general steps. The actual procedure for

using the disc menu depends on the disc you are using. See the disc jacket for details.

z On DVD-Audio discs, select a group instead of title. z During programmed play, setting is not possible on the top menu.

 To change the subtitle language

You can change the subtitle language or hide subtitles during playback.

1 During playback, set the MODE 1/MODE 2 switch to MODE 2 and

press the SUBTITLE button.

2 Press the SUBTITLE button repeatedly to

select the subtitle language.

z You can select one of the subtitle languages that are recorded on a DVD.

ENGLISH

z To hide subtitles on the screen, press the or button to select "OFF".

Notes:

z The subtitle language on some DVDs may not be changed. z If no subtitles are recorded on the disc, "XX" is displayed. z It may take a little time to switch the subtitle language to the selected one. z When you set the unit to the stand-by mode or replace the disc, settings return t o

the default.

FRENCH

83/0

SPANISH

ENGLISH

 To change the audio language (audio out-

put)

During playback, you can change the audio language (audio output).

1 During playback, set the MODE 1/MODE 2 switch to MODE 2 and

press the AUDIO button.

2 Press the AUDIO button repeatedly to select

the audio language (audio output).

Each time you press, audio language (audio output) changes. Example:

1: Original <English> (Dolby Digital 5.1 Surround)

hc15

2: Original <English> (DTS 5.1 Surround)

3: Japanese (Dolby Digital 2 ch)

hc2

1 1

Notes:

z The audio language on some DVDs may not be changed. z For available audio languages (audio outputs), see the disc jacket. z When you switch the audio language (audio output) during DVD-Audio playback,

the unit may return to the beginning of the track. In this case, it takes longer to switch the language.

z During CD playback, the audio output switches as follows: "L + R", "L", "R". z When you set the unit to the stand-by mode or replace the disc, settings return to

the default.

z For MP3 discs, you cannot change the audio output.

hc15

Various settings

 Brightening the image (Gamma correction)

1 During playback, set the MODE 1/

MODE 2 switch to MODE 2 and press the GAMMA button to select "ON".

"ON" and "OFF" will be switched with each press of this button.

2 Within 10 seconds, press the or

button to set the level.

Level Setting Level Setting

OFF Normal ON Brighter ON Slightly brighter ON A lot brighter

To restore the original brightness:

In step 1, select "OFF".

 Sharpening the image (Super picture)

1 During playback, set the MODE 1/

MODE 2 switch to MODE 2 and press the S.PICTURE button to select "ON".

"ON" and "OFF" will be switched with each press of this button.

2 Within 10 seconds, press the or

button to set the level.

SD-PX2

ENGLISH

DVD Operation

- Useful operation / Various settings -

Level Setting Level Setting

OFF Normal ON A lot clearer ON Slightly clearer ON Soft ON Clearer

To restore the original image quality:

In step 1, select "OFF".

E-26

SD-PX2

ENGLISH

DVD Operation

Various settings (continued)

 To change the display on TV screen

- Various settings -

During playback, set the MODE 1/MODE 2 switch to MODE 2 and press the ON SCREEN button.

Each time you press, the display changes. Example: DVD

Always displayed Not displayed Displayed for approx. 3

25/ 83/

::23 40

DDV

25/ 83/

seconds

::23 40

 To change the display on the unit

During playback, set the MODE 1/MODE 2 switch to MODE 1 and press the DISPLAY button.

Each time you press, the display changes.

DVD-Video:

Title elapsed time Title/Chapter number Chapter elapsed time

DVD-Audio:

Track elapsed time Group/Track number Group elapsed time

After approx. 2 seconds After approx. 2 seconds

Sampling frequency

(low frequency effects)(*)

(*) Sampling frequency display may differ or may not appear depending on the

disc.

Notes:

z Title/Chapter numbers or elapsed time may not appear depending on the disc. z The playing time of the disc specified on the jacket, etc. may not include silence

between tracks, and may differ from that displayed on the unit.

z Elapsed time on the display does not indicate the actual time.

DDV

z During MP3 playback, total elapsed time does not appear, and elapsed time can-

not be switched.

Sampling frequency

(surround)(*)

Sampling frequency

(2 channel)(*)

E-27

 Switch ing elapsed time

During playback, set the MODE 1/MODE 2 switch to MODE 1 and press the DISPLAY button.

Each time you press, the display changes.

SACD:

Track elapsed time Track number Total elapsed time

CD:

Track elapsed time Total elapsed time

 Switching playing time

In the stop mode (SACD/CD), select a track number with the or button.

SACD: CD:

Track number Track playing time Track playing time

 To change the setting on the playback con-

trol screen

On the playback control screen, various settings can be changed at the same time.

1 During playback, set the MODE 1/MODE 2 switch to MODE 2 and

press the DVD SET UP button.

2 Press the or button to select the item, and press the ENTER

button.

Example: DVD 1 Title number 2 Chapter number 3 Elapsed playing time 4 Subtitle 5 Angle 6 Audio language 7Gamma 8 Super picture

9 BIT RATE indicator (unchangeable)

1 2 3 4 5 6 7

25/

83/

::23 40

ENGLISH

2 1

OFF

DDV

hc15

BIT RATE

SELECT

ENTER

DDV

05 10

Mbps

RETURNENTER

3 Press the , , or button to change the setting and press the

ENTER button.

Example: Gamma is selected

hc15

05 10

BIT RATE

ENTER

Mbps

SELECT

RETURN

SD-PX2

ENGLISH

- Various settings -

DVD Operation

After approx. 2 seconds

Repeat the operation as instructed.

(The number of repetition depends on the setting item.)

To change other settings, begin from step 2.

4 Press the RETURN button twice.

The setting is memorized and the playback screen reappears.

Notes:

z Some items may not be selected depending on the type of the disc. z If the RETURN button is pressed while selecting an item or setting, the previ-

ous screen appears.

z On DVD-Audio discs, groups and tracks appear instead of titles and chapters.

E-28

SD-PX2

ENGLISH

DVD Operation

Playing a DVD-Audio disc

Some DVD-Audio discs contain still pictures, or grouped tracks called "bonus group". A 4-digit password may be required to play a bonus group.

- Playing a DVD-Audio disc -

 Switching still pictures on a DVD-Audio

disc

1 Play a DVD-Audio disc (see page 17). 2 During playback, set the MODE 1/MODE 2 switch to MODE 2 and

press the PAGE UP or PAGE DOWN button.

Each time you press, the image switches.

Notes:

z This operation is not available for some still pictures. z On DVD-Video discs, you can enjoy various sounds by changing the multi channel

mode or stereo mode (see pages 37, 38). On DVD-Audio discs (audio part only), you cannot change the two modes.

 Playing bonus groups

1 During playback, set the MODE 1/MODE 2 switch to MODE 1 and

press the DIRECT button.

2 Enter a bonus group number with

the direct number buttons (0 - 9) and press the ENTER button.

RETURN

3 Enter a 4-digit password with the direct number buttons (0 - 9) and

press the ENTER button.

E-29

Notes:

z For a 4-digit password, see the disc jacket, etc. z On some discs, a password is not required to play bonus groups.

Playing an SACD disc

The procedure of the f ollow ing pla ybac k functions are the same as the DVD operation.

Page

To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . . .19

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . .20

To play in th e de s i r e d order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . . .21

To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

To play the contents between the specified points repeatedly (A-B repeat) . .22

Resume play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

To chang e t he audio lan g ua ge (audio output) . . . . . . . . . . . . . . . . . . . . . . . . . .26

To chang e t he display on TV s c r e e n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Switching el a ps e d t ime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Switching playing time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

 Playing hybrid SACD sound

On hybrid discs (consisting of an SACD layer and a CD layer), you can select sound to play.

1 Insert an SACD disc and press the button. 2 In the stop mode, set the MODE 1/

MODE 2 switch to MODE 2 and press AUDIO button to select the desired layer.

It takes a few seconds to switch the audio output for reading the disc information.

Example: Playing a multi channel SACD disc

You can switch the audio output if the multi channel and stereo 2 channel systems are supported.

TV screen Unit display

5.1 channel SACD layer

MULTI

2 channel SACD layer

2 ch

2 channel CD layer

C D

TV screen

MULTI

3 Press the button.

Playback starts.

Notes:

z For sound types, see the manual for the hybrid disc. z When you remove the disc, the audio output returns to "MULTI". z On SACD (CD lay er only)/CD discs, you can enjoy various sounds by changing the

multi channel mode or stereo mode (see pages 37, 38). You cannot change the two modes for the SACD (SACD la yer).

SD-PX2

ENGLISH

- Playing an SACD disc -

SACD and CD Operation

E-30

SD-PX2

ENGLISH

Playing an SACD disc (continued)

 To play in random order (random play)

The tracks on the disc can be played in random order automatically.

1 While in the stop or playback mode,

press the RANDOM button.

2 In the stop mode, press the button.

All tracks play in random order.

To cancel random play, press the RANDOM button.

When you press the button, the current random play is canceled.

Notes:

z Random play is not allowed during programmed playback. z In random play, the unit will select and play tracks automatically. (You cannot select

the order of the tracks.)

z For MP3 discs, random play is not available. z In random play, press the button to switch to repeat play.

- Playing an SACD disc -

SACD and CD Operation

E-31

Playing an MP3 disc

You can play back a CD-R/CD-RW disc on which tracks are recorded in the MP3 format.

 Selecting a folder on an MP3 disc

1 Insert an MP3 disc and press the

button.

The folder selection screen appears.

1/ 4

MUSIC1 MUSIC2 MUSIC3 MUSIC4

Cursor Folder

MP 3

2 Select a folder using the , , or button and press ENTER but-

ton.

z The track selection screen appears. z Move the cursor to a folder and press the button. Playback starts from the

first track.

z Press the RETURN button to return to the folder selection screen.

3 Select a t rack usin g the , , o r

button and press the ENTER button.

Playback starts from the track. Track number

Skipping tracks:

While a disc is playing, press the or button. Tracks skip within a folder.

Playing repeatedly (Repeat play)

While a disc is playing, press the button. The mode switches as follows: " T (track)", " (folder)", "no display (normal playback)".

Notes:

z Alternatively, select a track number with the direct number buttons (0 - 9) and

press the ENTER button to play .

z If the cursor is placed on a track (not playing) for 10 seconds or more, it starts to

play.

z Tracks may not play in the recorded order. z The unit recognizes up to 8 levels in the folder tree, including folders and tracks. z 256 tracks can be recognized. z You can also play multi session discs. z When the first session contains audio tracks in the CD format, the unit recognizes

the disc as a CD and plays only those tracks.

z It may take some time to read a disc depending on the number of files or folder

tree structure.

z Up to 8 characters are displayed for folder or track names. Some characters and

symbols may not appear properly.

z MP3 discs with data recorded at high speed may not play, or noise may occur dur-

ing playback.

z The MP3 functions are not available when you burn MP3 files on a CD-R/CD-RW

disc to create an audio CD. Play the disc as a standard CD.

MUSIC1

1TRACK01 3TRACK03

MP 3

2TRACK02 4TRACK04

SD-PX2

ENGLISH

- Playing an MP3 disc -

SACD and CD Operation

E-32

SD-PX2

ENGLISH

Listening to the radio

- Listening to the radio -

Radio Operation

1 Turn on the power and press the TUNER (BAND) button to set the

input to "FM (AM)".

2 Press the TUNER (BAND) button repeatedly to select the desired

frequency band.

STEREO

FM stereo FM mono AM

3 Press the TUNING ( or ) button to tune in to the desired station.

Manual tuning:

Press the TUNING button as many times as required to tune in to the desired station.

Auto tuning:

When the TUNING button is pressed for 0.5 seconds or more, scanning will start automatically and the tuner will stop at the first receivable broadcast station.

z When radio interference occurs, auto scan tuning may stop automatically.

Should this happen, tune in manually.

z Auto scan tuning will skip weak signal stations. z To stop the auto tuning, press the TUNING button again.

To receive an FM stereo transmission:

Press the TUNER (BAND) button to display the "STEREO" indicator. z " " will appear when an FM broadcast is in stereo.

E-33

Volume control (See page 16).

FM stereo mode indicator FM stereo receiving indicator

z If the FM reception is weak, press th e TUNER (BAND) button to extinguish the

"STEREO" indicator. The reception changes to mono, and the sound becomes clearer.

After use:

Press the ON/STAND-BY button to enter the power stand-by mode.

Listening to the memorized station

You can store 40 AM and FM stations in memory and recall them at the push of a button. (Preset tuning)

1 Tune in the desired station and

press the ENTER button.

z For FM stations, stereo and mono modes are memorized. z Store the stations in memory, in order, starting with preset channel 1.

2 Within 5 seconds, press the TUNER

PRESET ( or ) button to select the preset channel number.

3 Within 5 seconds, press the ENTER

button to store that station in memory.

z Repeat steps 1 - 3 to set other stations, or to change a preset station. z When a new station is stored in memory, the station previously memorized will

be erased.

To recall a memorized station:

Press the TUNER PRESET ( or ) button to select the desired station.

To select a preset station with the direct number buttons:

1 Press the corresponding number ("0" - "9"). 2 Press the ENTER button.

For example, to choose 28 1 Press the "2" button.

2 Press the "8" button. 3 Press the ENTER button.

z Press buttons within 5 seconds. z To correct, enter the number again.

To erase all the contents of the preset memory:

1 Hold the CLEAR button down for 4 seconds or

more.

2 Within 10 seconds, press the ENTER button.

SD-PX2

ENGLISH

Preset channel number

Radio Operation

- Listening to the memorized station -

Note:

The backup function protects the memorized stations for a few hours should there be a power failure or the AC power cord disconnection.

E-34

SD-PX2

ENGLISH

Enjoying surround sound (sound mode)

This product is equipped with Dolby Digital and DTS decoders. You can enjoy powerful and high-quality surround sound as if you were on the scene.

Dolby Di gital

Disc with this trademark

One of the digital audio systems for theatrical use. You can enjoy the stereophonic effect in the home theater system.

When you set the audio output to Dolby Digital for a disc recorded in Dolby Digital, the DIGITAL indicator lights up (see page 26).

DTS (Digital Theater Systems)

Dolby Pro Logic reproduces 5.1 channel surround from 2 channel stereo sound.

Stereo-recorded discs and video tapes

Dolby Pro Logic decodes 2 channel stereo sound from discs, videotapes, etc. to reproduce 5.1 channel surround sound. You can enjoy a three-dimensional sound field.

When Dolby Pro Logic is activated, the PRO LOGIC indicator lights up.

A signal recording format without compression

Used in DVD and CD featuring a musical or concert.

Dolby Pro Logic

Linear PCM

One of the digital audio systems for theatrical use. As the sound quality is empha-

Advanced Features

sized, you can enjoy the realistic sound effect in the home theater system. When you set the audio output to DTS for a disc recorded in DTS, the indicator

lights up (see page 26).

- Enjoying surround sound (sound mode) -

E-35

Disc with this trademark

 Audio signal/Speaker indicators

Audio signal indicators light up for the corresponding audio source, and speaker indicators are illuminated according to signals sent to the speakers.

(3)(4) (6)(5)

(2)(1)

Audio signal indicator

Speaker indicator

Example:

When 2.1 channel audio signals (L, R, LFE) are received, the audio signal indicators "L", "R" and "LFE" light up. The illustration on the right indicates that 2 channel stereo sound (L and R) is reproduced.

(7)

(10) (11)(9)

(8)

(12) (13)

Audio Signal/Speaker Indicators:

(1) Left Front Speaker Indicator (2) Left Indicator (3) Center Indicator (4) Center Speaker Indicator (5) Right Indicator (6) Right Front Speaker Indicator (7) Low Frequency Effect Indicator (8) Surround Monaural Signal Indicator

(Lights up when the surround speakers receive monaural signals.)

(9) Left Surround Speaker Indicator (10) Left Surround Indicator (11) Subwoofer Indicator (12) Right Surround Indicator (13) Right Surround Speaker Indicator

Notes:

z You can switch the audio output when the disc contains sounds of multiple audio

formats (Dolby Digital, DTS, etc.). See page 26.

z Sound may not be produced from the subwoofer depending on the disc. z You cannot change the multi channel mode or s tereo mode on DVD-Audio discs

(audio part only) or SACD discs (SACD layer only), or while listening to the radio.

SD-PX2

ENGLISH

When Dolby Pro Logic is activated

2 channel stereo sound is converted to 5.1 channel surround sound, and all the speaker indicators " " light up.

L, R, LFE: Incoming audio

signals

Advanced Features

- Enjoying surround sound (sound mode) -

" " appears when the speakers are receiving audio signals.

E-36

SD-PX2

ENGLISH

Enjoying surround sound (sound mode) (continued)

You can enjoy spacious sound recorded in Dolby Digital or DTS. Also, Dolby Pro Logic allows you to enjoy spacious 2 channel stereo sound.

 Listening to sounds in the multi channel

mode (5.1 ch, etc.)

While the disc is playing, press the MULTI-CH button.

Example: DTS format

A maximum of 5.1-ch surround sound is reproduced to provide three-dimensional effect.

When you press once, the last used setting appears. To change it, press the button repeatedly within 3 seconds.

DVD (Dolby Digital or DTS)

STANDARD MOVIE

MUSICNIGHT

Notes:

Advanced Features

z You cannot change the multi channel mode or stereo mode on DVD-Audio

discs (audio part only) or SACD discs (SACD layer only), or while listening to the radio.

z If sound is unpleasant to listen to, change the multi channel mode or stereo mode.

- Enjoying surround sound (sound mode) -

z Settings for the multi channel mode and stereo mode are retained by input (DVD,

TV, AUX and VCR).

E-37

STANDARD: You can enjoy the original sound as it is. MOVIE: The bass level is increased for powerful sound effect. MUSIC: You can enjoy lively sound by producing the articulate sound. NIGHT: Soft but powerful sound is achieved even at low volumes.

Note:

When listening to Dolby Digital or DTS sound, you cannot select "STADIUM" and "HALL".

2 channel stereo sound (CD, videotapes, etc.)

While the disc is playing, press the MULTI-CH button.

Example: 2-ch stereo sound

SD-PX2

ENGLISH

 Listening to 2 channel stereo sounds

While the disc is playing, press the STEREO button.

Example: DTS format

You can enjoy 2 channel stereo sound.

Dolby Pro Logic converts 2 channel stereo sound of CDs, etc. to 5.1 channel.

When you press once, the last used setting appears. To change it, press the button repeatedly within 3 seconds.

STANDARD MOVIE MUSIC

NIGHTSTADIUMHALL

Notes:

z When monaural signals are received in the multi channel mode, only the center

speaker and subwoofer produce sound.

z When you play Dolby Digital or DTS sound with "STADI UM" or "HALL" set, sur-

round is automatically set to "STANDARD".

When you press once, the last used setting appears. To change it, press the button repeatedly within 3 seconds.

STEREO VIRTUAL

STEREO: You can enjoy the great acoustic effects of the front speakers and

subwoofer.

VIRTUAL: Although the surround speaker does not work, you can enjoy spa-

cious surround effects. It sounds as if speakers were also placed in .

Advanced Features

- Enjoying surround sound (sound mode) -

Notes:

z When the surround mode is set to "STEREO" or "VIRTUAL", the same monaural

sound is reproduced in the both of the right and left channels.

z Some discs are recorded at 96 kHz of sampling frequency. When this type of disc

is played, the sound mode is changed to "STEREO" automatically. The sound mode cannot be changed during playback.

E-38

SD-PX2

ENGLISH

Changing the initial setting of DVD

A new setting will be retained even if the unit is set to the stand-by mode. If you want to restore or change the setting, reset it.

1 Press the button, set the MODE 1/

MODE 2 switch to MODE 2 and press

Advanced Features

- Changing the initial setting of DVD -

the DVD SE T UP b u t t o n .

The initial setting screen appears.

DVD SETUP TV MODE PARENTAL AUDIO DISC LANGUAGE OSD LANGUAGE

ENTER

SELECT ENTER

RETURN

2 Press the or button to select a setting item and press the EN-

TER button.

For setting items, see the table on page 40.

3 Press the , , or button to select a parameter and press the

ENTER button.

Example: "TV MODE" is selected

To change other settings, begin from step 2.

TV MODE

PROGRESSIVE OUT

DVD-AUDIO

TV MODE

4:3

16 : 9

TV MODE

4:3

16 : 9

OFF AUDIO

4 Press the RETURN button twice.

The new setting is memorized.

Notes:

z You cannot display the initial setting screen while a disc is playing. z The previous screen appears by pressing the RETURN button while selecting

an item or setting.

E-39

SD-PX2

Se t t ing Sel e c tab l e para m e ters

TV MODE TV MODE

PARENTAL PASSWORD Please enter a 4-

AUDIO DIGITAL BITSTREAM*

DISC

LANGUAGE

OSD

LANGUAGE

(* indicates initial settings.)

PROGRESSIVE OUT

DVD-AUDIO AUDIO* (Selectable when

a disc is not inserted.)

LEVEL LEVEL 1 - 8

CODE USA*

AUDIO ENGLISH*

SUB TITLE ENGLISH

MENU EN* Select a language for the disc menu, etc. If the selected language is not available, the display appears

ENGLISH* DEUTSCH Select an OSD (On Screen Display) language for initial settings and operations. ESPAÑOL FRANÇAIS SVENSKA ITALIANO NEDERLANDS

ON OFF*

VIDEO

digit password.

OFF*

CANADA

D-PCM

SPANISH OTHER

OFF*

Description Reference

Select according to the TV. P. 41

If the TV supports progressive scan, select "ON" to enjoy high resolution images. If not, set to "OFF". P. 41

Some DVD-Audio discs contain both DVD-Audio and DVD-Video contents. Select either as default. P. 29

You can set a 4-digit password required to change the "LEVEL" and "CODE" (country code). If you forget the password, press the button four times.

Restrict viewing by selecting a level. P. 41

Set a country code according to a parental control level of discs. P. 41

Select the audio output according to the external equipment connected to the optical digital audio output jack.

Select a language to play. If the selected language is not available, the disc plays in a default language.

Select a language for subtitles (displayed on the TV screen). If the selected language is not available, subtitles appear in a default language.

OFF: Select this to hide subtitles.

in a default language.

page

P. 41

P. 57

P. 42

ENGLISH

Advanced Features

- Changing the initial setting of DVD -

E-40

SD-PX2

ENGLISH

Changing the initial setting of DVD (continued)

 Video format

Indicator Setting

Note:

Advanced Features

When playing the disc with a fixed video format, it will not change even if the TV screen size is changed.

- Changing the initial setting of DVD -

 Progressive scan playback

Connect the unit to a TV support ing progressive scan with a compon ent v ideo cable. You can enjoy flicker-free images.

Setting Description

ON (Progressive)*1 If the TV supports progressive scan, set to "ON".

OFF (Interlace)*2 If the TV does not support progressive scan, set to

When playing a wide image (16:9) disc, the left and right sides of the image are cut (pan scan) to display a natural-looking 4:3 size image.

A wide image disc without pan scan

is played back in letterbox . A 4:3 disc is played in 4:3. When playing a wide image (16:9) disc,

black bands are inserted at the top and bottom and you can enjoy full wide images (16:9) on a 4:3 size TV.

A 4:3 disc is played in 4:3. A wide image (16:9) is displayed when

playing a wide image (16:9) disc.

z When playing a 4:3 image disc, the image size depends on the

setting of the connected TV.

z If you play back a wide image (16:9) disc with the unit connected

to a 4:3 TV, images appear stretched vertically.

You can enjoy flicker-free images.

"OFF". Images are displayed in the interlaced system.

*1 Progressive

525 scanning lines are drawn in order without interlacing (first field), and then 525 scanning lines are drawn in the same pass on the next field.

*2 Interlace (Interlaced scan)

Following odd-numbered scan lines, even-numbered scan lines (262.5 lines each) are drawn in 1/60 seconds. This occurs in two separate fields. As a result, a 525line image (frame) is created.

Notes on a non-progressive scan TV

If "PROGRESSIVE OUT" is set to "ON", the TV does not display images. Connect the supplied video cable, switch the input to video, and set "PROGRESSIVE OUT" to "OFF".

Compatibility of the progressive scan TV

Some progressive scan TVs are not fully compatible with this product, which may cause image distortion. In this case, set "PROGRESSIVE OUT" to "OFF".

 Parental setting

Indicator Setting

LEVEL 1 Only DVD software intended for children can be played back. LEVEL 2 to 7 Only DVD software intended for general use and children can be

LEVEL 8 DVD software of any grade (adult/general/children) can be played

OFF Parental control is canceled. CODE Country code for parental control

Country code list:

USA CANADA JAPAN GERMANY FRANCE UK ITALY

Notes:

z For the parental setting, enter a 4-digit number (example: 1234), which will be your

password. Enter "1234" from the next time.

z While playing a disc with parental control, the display may appear requesting a

password in order to watch some restricted scenes. In such a case, enter the password to temporarily change the control level.

played back.

back.

SPAIN SWISS SWEDEN HOLLAND NORWAY DENMARK FINLAND

BELGIUM HONG KONG SINGAPORE THAILAND MALAYSIA INDONESIA TAIWAN

PHILIPPINE AUSTRALIA RUSSIA CHINA

E-41

 Disc language  Selecting a language for "DISC LAN-

SD-PX2

ENGLISH

Indicator Setting

AUDIO A language for audio can be set.

You can specify a language for dialogues and narration.

English French

Thank you

SUB TITLE A language for subtitle can be set.

The subtitle is displayed in a specified language.

English French

Thank you

MENU A language for disc menus can be set.

Menu screens are displayed in a specified language.

English French

CAST

STAFF

Merci

ACTEURS

PERSONNEL

Merci

GUAGE", etc.

Check the code of the language (See the language code list on page 61). Example: When you select HU (Hungarian)

1 On the initial setting screen, select

"DISC LANGUAGE" (see steps 1 - 2 on page 39), and select "MENU" and press the ENTER button.

DISC LANGUAGE

AUDIO SUB TITLE MENU

SELECT

ENTER

ENGLISH ENGLISH ENGLISH

2 Press the or button to select "H"

for the first letter.

DISC LANGUAGE

MENU 1 H MENU 2 A

3 Press the or button to move the

cursor to the "MENU 2".

DISC LANGUAGE

MENU 1 H MENU 2 A

4 Press the or button to select "U"

for the second letter.

DISC LANGUAGE

MENU 1 H MENU 2 U

5 Press the ENTER button. 6 Press the RETURN button twice.

The new setting is memorized.

RETURN

Advanced Features

- Changing the initial setting of DVD -

E-42

SD-PX2

ENGLISH

Changing the default settings of the amplifier

Change settings according to the connected speakers.

Speaker size setting (See pages 43, 44). Speaker delay setting (See page 44). Speaker level setting (See page 45). Test tone (See page 45). Changing crossover frequency (See page 46).

Example:

If the right surround speaker is 10 feet (3.3 m) away from the listening position, change settings as shown below (adjust the SR).

Default setting: 6 feet (2 m)

1 In "Speaker delay setting", set the right surround speaker (SR) to 10 feet (3.3 m). 2 In "Speaker level setting", slightly increase the level of the right surround speaker

as it is a little farther than others (see page 45).

Advanced Features

3 In "Test tone", check the sound from each speaker (see page 45).

Notes:

z The subwoofer setting applies to a subwoofer connected to SUBWOOFER PRE

OUT.

- Changing the default settings of the amplifier -

z You cannot change the default settings while playing SACD/DVD-Audio discs.

10 feet (3.3 m)

If you press during the operation, you can go back one step.

 Speaker size setting

You can change the sizes of the front speakers, center speaker, and surround speakers, or turn on or off the center speaker, surround speakers, or subwoofer.

1 Set the MODE 1/MODE 2 sw itch to MO DE 2 and p ress the AMP SET

UP button.

2 Within 10 seconds, press the or button to

select "SP SIZE", and press the ENTER button.

E-43

3 Within 10 seconds, press the or button to

select the desired speaker.

The indicators of selected speakers flash.

4 Within 10 seconds, press the or button to

select their sizes.

To set sizes of other speakers, repeat the operation from step 3.

5 Press the RETURN button twice.

The setting is complete.

When you select "LARGE", all channel signals are sent to the speaker. When you select "SMALL", frequencies below the value you set for crossover frequency (see page 46) are sent to the subwoofer.

Speaker type Speaker size

Front speaker (Left, Right) F-SMALL * Small diameter

F-LARGE Large diameter

Center speaker C-SMALL * Small diameter

C-LARGE Large diameter C-NO OFF

Surround speaker (Left, Right) S-SMALL * Small diameter

S-LARGE Large diameter S-NO OFF

Subwoofer SW-YES * ON

SW-NO OFF

(*) indicates the default setting.

Notes:

z The speaker size setting is only available for the subwoofer if the input is set to

tuner, or the surround is "STEREO" or "VIRTUAL".

z On some DVD-Audio or SACD discs, the subwoofer may not produce sound even

if the speaker size is set to "SMALL".

z "F-SMALL" and "SW-NO" cannot be combined. If the subwoofer is changed to

"SW-NO" while the front speakers are set to "F-SMALL", they are changed to "FLARGE". When the front speakers are changed to "F-SMALL" while the subwoofer is set to "SW-NO", it is changed to "SW-YES".

z If "LARGE" is set for a small speaker, malfunction may result. Be sure to set the

speaker size to "SMALL".

z When the center and surround speakers and subwoofer are not connected, set the

speaker size to "C-NO", "S-NO" and "SW-NO". Otherwise, the protection circuit may be activated and the power is turned off.

 Speaker delay setting

When some of the speakers are at a different distance from the listening point, you can select the speaker delay to make it seem as though the speaker distances are the same.

1 Set the MODE 1/MODE 2 switch to MODE 2 and press the AMP SET

UP button.

2 Within 10 seconds, press the or button to

select "SP DELAY", and press the ENTER button.

3 Within 30 seconds, press the or button to

select the desired speaker.

The indicator of the selected speaker flashes.

4 Within 30 seconds, press the or button to

select the distance.

z You can change the distance in 1 foot (0.3 m) steps. z To set the distance of other speakers, repeat the op-

eration from step 3.

5 Press the RETURN button twice.

The setting is complete.

Speaker type Delay range Default setting

FL Front speaker (Left) 1 to 29 ft 6 ft (2 m) CT Center speaker 1 to 29 ft 6 ft (2 m) FR Front speaker (Right) 1 to 29 ft 6 ft (2 m) SR Surround speaker (Right) 1 to 29 ft 6 ft (2 m) SL Surround speaker (Lef t) 1 to 29 ft 6 ft (2 m)

SW Subwoofer 1 to 29 ft 6 ft (2 m)

Notes:

z The speaker delay setting is only available for the front speakers and subwoofer if

the input is set to tuner, or the surround is "STEREO" or "VIRTUAL".

z The speaker delay setting is invalid while playing DVD-Audio or SACD discs (valid

for the CD lay er of SACD discs).

SD-PX2

ENGLISH

Advanced Features

- Changing the default settings of the amplifier -

E-44

SD-PX2

ENGLISH

Changing the default settings of the amplifier (continued)

 Speaker level setting

If sounds from the speakers are uneven, you can equalize them by adjusting the speaker levels.

1 Set the MODE 1/MODE 2 switch to MODE 2 and press the AMP SET

UP button.

2 Within 10 seconds, press the or button to

select "SP LEVEL", and press the ENTER button.

 Test tone

You can check each speaker sound by a test tone. Readjust the volume set in "Speaker level setting".

1 Set the MODE 1/MODE 2 sw itch to MO DE 2 and p ress the AMP SET

UP button.

2 Within 10 seconds, press the or button to

select "TONE", and press the ENTER button.

3 Within 10 seconds, press the or button to

select the desired speaker.

The indicator of the selected speaker flashes.

4 Within 10 seconds, press the or button to

adjust the level.

z You can adjust the level at 1 dB intervals. z To adjust the levels of other speakers, repeat the op-

eration from step 3.

5 Press the RETURN button twice.

The setting is complete.

Speaker type Level range Default setting

FL Front speaker (Left) - 10 dB to + 10 dB 0 dB CT Center speaker - 10 dB to + 10 dB 0 dB

Advanced Features

FR Front speaker (Right) - 10 dB to + 10 dB 0 dB SR Surround speaker (Right) - 10 dB to + 10 dB 0 dB SL Sur round speaker (Left) - 10 dB to + 10 dB 0 dB

SW Subwoofer - 10 dB to + 10 dB 0 dB

- Changing the default settings of the amplifier -

Notes:

z The speaker level setting is only available for the front speakers and subwoofer if

the input is set to tuner, or the surround is "STEREO" or "VIRTUAL".

z If subwoofer sound is distorted, lower the subwoofer level.

The test tone will be heard from each speaker, in order, at about 2-second intervals.

FL CT FR

SW SL SR

To adjust speaker levels

While the test tone is heard: Adjust the level with the or button. Press the or to select a speaker.

3 Press the RETURN button twice.

The setting is complete.

Notes:

z The test tone is produced only from the front speakers and subwoofer if the input

source is set to tuner or the surround is "STEREO" or "VIRTUAL".

z If NO (OFF) is selected for a speaker in the speaker size setting, no test tone will

be heard from it.

E-45

 Changing crossover frequency

Change the level above which subwoofer frequencies are cut, to adjust the balance with the front speakers. When the speaker setting is "SMALL", low frequencies from the speaker are cut. It is recommended to set the level slightly above that of the lowest front speaker frequency (the lowest reproducible frequency).

1 Set the MODE 1/MODE 2 switch to MODE 2 and press the AMP SET

UP button.

2 Within 10 seconds, press the or button to

select "X-FREQ", and press the ENTER button.

3 Within 10 seconds, press the or button to

select frequency and pr ess the ENTER button.

4 Press the RETURN button twice.

The setting is complete.

In the stop mode, you can change the amplifier settings on the TV screen.

1 Set the MODE 1/MODE 2 switch to MODE

2 and press the AMP SET UP button.

The amplifier setting screen appears.

AMPLIFIER SETUP

SPEAKER SIZE SPEAKER DELAY SPEAKER LEVEL TEST TONE CROSSOVER

ENTER

SELECT ENTER

RETURN

2 Press the or button to select the menu and press the ENTER

button.

3 Press the , , or button to change the

setting and press the ENTER button.

SPEAKER SIZE

FRONT CENTER SURROUND SUB WOOFER

SELECT

SMALL SMALL SMALL YES

RETURN

CHANGE

SD-PX2

ENGLISH

Adjustable frequency

range

80 Hz The lowest reproducible frequency of the front speakers

is below 80 Hz.

100 Hz * The lowest reproducible frequency of the front speakers

is between 80 and 100 Hz.

120 Hz T he lowest reproducible frequency of the front speakers

is between 100 and 120 Hz.

150 Hz T he lowest reproducible frequency of the front speakers

is between 120 and 150 Hz.

(*) indicates the default setting.

Recommended frequency range

Note:

The crossover frequency setting is invalid when playing DVD-Audio discs.

Repeat the operation as instructed.

(The number of repetition depends on the setting item.)

To change other settings, begin from step 2.

4 Press the RETURN button twice.

The setting is complete.

Note:

You cannot change the amplifier settings unless the input source is set to DVD/CD.

Advanced Features

- Changing the default settings of the amplifier -

E-46

SD-PX2

ENGLISH

Timer playback

The unit starts playback or turns on the radio at a specified time. This unit has 2 types of timer functions: "once timer" and "daily timer".

Once timer:

Once timer playback works for one time only at a preset time.

Use when...

You want to listen to a radio program on the day. (After operation, the timer setting is canceled.)

Daily timer:

Daily timer playback works at the same preset time every day.

Use when...

You want to use the timer as a wake up call, or listen to the radio at the same time every day.

You can use the once timer and daily timer together.

For example, use the timer as a wake-up call (daily timer), and listen to the radio later on the day.

1 Set the daily timer (pages 47 - 48). 2 Set the once timer (pages 47 - 48).

1 minute or more

Setting the timer

Start

Notes:

z If both timers are set for the same time, the once timer setting will start. z When using both timers, allow at least 1 minute between operations. Otherwise

the timer used later will not work.

Before setting timer:

Advanced Features

1 Set the clock (see page 15).

- Timer playback / Setting the timer -

If the clock is not set to the correct time, the timers do not work properly.

2 Prepare a source to play back.

z Insert a disc to play. z To use the radio for timer playback, store a station (see page 34).

Notes:

z When you use the timer to play a DVD with a menu screen, playback stops at the

menu screen.

z If the unit is unplugged or a power failure occurs after timer setting, the clock stops

and the timer setting will be canceled. Set the clock and timer again.

z You cannot use the timer to operate other equipment. z Timer playback does not start if the unit is turned on at the start time.

E-47

Daily timer

Once timer

Stop Start Stop

SD-PX2

ENGLISH

1 Turn on the power, set the MODE 1/MODE 2 switch to MODE 2 and

press the TIMER/SLEEP button.

2 Within 10 seconds, press the or button to select "TIMER

ONCE" or "TIMER DAILY", and press the ENTER button.

Once timer Daily timer

3 Within 10 seconds, press the or button to select "ONCE SET"

or "DAILY SET", and press the ENTER button.

Once timer Daily timer

4 Press the or button to adjust

the hour and then press the ENTER button.

5 Press the or button to adjust

the minutes and then press the ENTER button.

6 Set the time to finish as in steps

4 and 5 above.

7 Switch the input with the or button, and then press the ENTER

button.

z Available playback sources: DVD/CD, TUNER, TV, AUX and VCR. z If you select TV, AUX or VCR, connect the unit to the corresponding equip-

ment and set the timer.

z When you select "TUNER", select a station by pressing the or button, and

then press the ENTER button.

z If a station has not been programmed, "NO P.SET" will be displayed and timer

setting will be canceled.

Preset channel number

8 Adjust the volume with the or

button and press the ENTER

button.

Do not set the volume too high.

9 Press the ON/STAND-BY button to enter the power stand-by mode.

z The unit enters the timer stand-by mode.

(The timer set indicator lights up. See page 49.)

z The timer setting is retained.

- Setting the ti me r -

Advanced Features

E-48

SD-PX2

ENGLISH

Operations after setting the timer

1 After setting the timer

z The unit is in the timer stand-by mode. z If the timer set indicator does not light up, turn on the power and set t he timer

again.

2 At the start time

Advanced Features

- Operations after setting the timer -

Lights up

flashes

 In the timer stand-by mode

Checking the timer setting:

1 Set the MODE 1/MODE 2 switch to MODE 2 and press the TIMER/SLEEP button. 2 Within 10 seconds, press the or button to select "TIMER ONCE" or "TIMER

DAILY", and press the ENTER button.

3 Within 10 seconds, press the or button to select "ONCE CALL" or "DAILY

CALL", and press the ENTER button. The unit returns to the timer stand-by mode after displaying the settings in order.

Canceling the timer setting:

1 Set the MODE 1/MODE 2 switch to MODE 2 and press the TIMER/SLEEP button. 2 Within 10 seconds, press the or button to select "TIMER ONCE" or "TIMER

DAILY", and press the ENTER button.

3 Within 10 seconds, press the or button to select "ONCE OFF" or "DAILY OFF",

and press the ENTER button. Timer will be canceled (the setting will be retained).

 To use the same timer setting

Once timer:

1 Turn on the power, set the MODE 1/MODE 2 switch to MODE 2 and press the TIM-

ER/SLEEP button.

2 Within 10 seconds, press the or button to select "TIMER ONCE", and press

the ENTER button.

3 Within 10 seconds, press the or button to select "ONCE ON", and press the

ENTER button.

4 Press the ON/STAND-BY button to enter the power stand-by mode.

Daily timer:

The timer will operate at the same time every day. It will continue until the daily timer setting is canceled. Cancel the daily timer when it is not in use. When you use the same setting for the daily timer, select "TIMER DAILY" instead of "TIMER ONCE", and select "DAILY ON" instead of "ONCE ON".

E-49

The volume will increase gradually until it reaches the preset volume.

3 When the finish time is reached:

The unit is set to the power stand-by mode automatically.

Sleep timer

The unit turns off at a specified time when listening to a disc or the radio.

To confirm the remaining sleep time:

1 While "SLEEP" appears, set the MODE 1/MODE 2 switch to MODE 2 and press

the TIMER/SLEEP button.

2 Within 10 seconds, press the or button to select "SLEEP".

Remaining sleep time

z The remaining sleep time is displayed for about 10 seconds. z You can change th e remaining sleep time while it is displayed by pressing the

ENTER button (steps 3 - 4).

To cancel the sleep operation:

Press the ON/STAND-BY button while "SLEEP" is indicated. To cancel the sleep operation without setting the unit to the stand-by mode, proceed as follows.

1 Set the MODE 1/MODE 2 switch to MODE 2 and press

the TIMER/SLEEP button.

2 Within 10 seconds, press the or button to select

"SLEEP OFF".

3 Within 10 seconds, press the ENTER button.

("SLEEP" goes out.)

SD-PX2

ENGLISH

1 During playback, set the MODE 1/MODE 2 switch to MODE 2 and

press the TIMER/SLEEP button.

2 Within 10 seconds, press the or button to

select "SLEEP SET", and press the ENTER button.

3 Press the or button to select the time.

(Maximum: 2 hours - Minimum: 1 minute)

z 2 hours - 5 minutes 5-minute intervals z 5 minutes - 1 minute 1-minute intervals

4 Press the ENTER button.

z The unit will enter the power stand-by mode auto-

matically after the preset time has elapsed.

z The volume will be turned down 1 minute before the sleep operation finishes,

and then you cannot change the volume.

 To use timer and sleep operation together

For example, you can fall asleep to the radio, and wake up to CD.

1 Set the sleep time (steps 1 - 4). 2 Set the timer playback (steps 1 - 8, page 48).

Make sure timer playback does not start while sleep timer is active.

The unit enters into the power stand-by mode after the time set for sleep timer, and turns on at the start time of timer playback.

Sleep timer setting

1 minute - 2 hours

Sleep operation starts.

Timer playback setting

Sleep operation will automatically stop.

Start time Finish time

Desired time1minute - 2hours

Timer playback starts.

Timer playback will automatically stop.

- Sleep timer -

Advanced Features

E-50

SD-PX2

ENGLISH

Operating the connected TV

You can operate Shar p TVs with the remote control. Change the remo te control setting if operating other manufacturers' TV, or if you cannot operate a Sharp TV.

 Watching TV

1 Press the TV I button to turn on the TV. 2 Press the TV CH ( or ) button to set the channel.

Other buttons available for operating TVs

- Operating the connected TV -

Advanced Features

Operation Button

Volume control

Switching the input

 Changing the TV registration

1 While holding down the TV button, enter the manufacturer setting

number (4 digits).

2 Release the TV button.

The setting is registered and the TV can be operated with the remote control of this unit.

Notes:

z You cannot operate some Shar p TVs with the remote control. z As for manufacturers with 2 or more setting numbers, select one with which you

can operate the TV.

z Once you set a number, the number previously memorized will be canceled. z After replacing the batteries in the remote control, the registered number may

automatically be set to 1044 (SHARP). If it occurs, register the desired number again.

z Registration cannot be executed depending on TVs. Even if numbers can be set,

some buttons may not work.

TV manufacturer Setting number TV manufacturer Setting number

SHARP AIWA 1052 ADMIRAL 1037 AIKO 1019 AKAI 1009 ALARON 1031 AMBASSADOR 1029 AMPRO 1045 AMSTRAD 1034 ANAM 1004, 1024, 1035 ANAM NATIONAL 1024, 1035 AOC 1007, 1009 AUDIOVOX 1019, 1036, 1041 BAUR 1039 BELCOR 1007

1011, 1025, 1044 (*)

BELL & HOWELL 1005, 1021 BROCKWOOD 1007 BROKSONIC 1032, 1037 CANDLE 1009, 1015 CARNIVALE 1009 CARVER 1014, 1026 CELEBRITY 1001 CINERAL 1019, 1036 CITIZEN 1009, 1011, 1015,

1016, 1019 CME 1039 CONCERTO 1015 CRAIG 1024 CROSLEY 1014 CROWN 1011

E-51

(*): The default manufacturer number is 1044 (SHARP).

SD-PX2

ENGLISH

TV manufacturer Setting number TV manufacturer Setting number

CURTIS MATHES 1005, 1009, 1011,

1012, 1013, 1014, 1015, 1016, 1020, 1021, 1036, 1038, 1044, 1048, 1050

DAEWOO 1007, 1011, 1017,

1019, 1021, 1036,

1041, 1042 DAYTRON 1007 DENON 1020 DUMONT 1006, 1007 DWIN 1044, 1046 ELECTRONBAND 1001 EMERSON 1007, 1010, 1011,

1021, 1029, 1030,

1031, 1032, 1037,

1041, 1042 ENVISION 1009 ETRON 1043 FISHER 1021 FORTRESS 1044 FUJITSU 1031 FUNAI 1027, 1031 GE 1008, 1012, 1013,

1030, 1036, 1048,

1050 GIBRALTER 1006, 1007, 1009 GOLDSTAR 1002, 1007, 1009,

1011, 1015, 1030 GRADIENTE 1015, 1026 GRANADA 1033 GRUNPY 1031 HALLMARK 1030 HARLEY DAVIDSON HARMAN/KARDON HCM 1034 HITACHI 1010, 1015, 1020 INFINITY 1014

1031

1014

INTEQ 1006 INTERFUNK 1039 JBL 1014 JCB 1001 JVC 1018, 1023 KENWOOD 1007, 1009 KONIG 1039 KTV 1009, 1011 LG 1015 LOEWE 1039 LOGIK 1005 LUXMAN 1015 LXI 1012, 1014, 1021,

1022, 1030 MAGNAVOX 1009, 1014, 1031 MAJESTIC 1005 MARANTZ 1009, 1014 MEGATRON 1020, 1030 MEMOREX 1005, 1015, 1021,

1030, 1037 METZ 1007, 1009, 1030 MGA 1007, 1009, 1028 MIDLAND 1006, 1011, 1012,

1013 MINOKA 1034 MINUTZ 1008 MITSUBISHI 1007, 1030, 1039 MTC 1007, 1009, 1015,

1016, 1039 NAD 1022, 1030 NEC 1007, 1009, 1015,

1026 NIKKO 1009, 1019, 1030 NTC 1019 OPTIMUS 1021 OPTONICA 1025, 1044 ORION 1031, 1032, 1037 OSAKA 1034

TV manufacturer Setting number TV manufacturer Setting number

OTTO 1039 PANASONIC 1013, 1024 PENNEY 1003, 1007, 1008,

1009, 1011, 1012, 1013, 1015, 1016, 1022, 1030, 1050

PHILCO 1007, 1009, 1014,

1020, 1037 PHILIPS 1014 PILOT 1007, 1009, 1011 PIONEER 1010, 1028 PORTLAND 1007, 1011, 1019 PRISM 1013 PROSOCAN 1012 PROTON 1030, 1038 PULSAR 1006, 1007 QUASAR 1013, 1025 QUELLE 1039 RADIO SHACK 1007, 1009, 1011,

1012, 1015, 1028,

1030 RCA 1007, 1010, 1012,

1013, 1044, 1047,

1048, 1049, 1050,

1051 REALISTIC 1007, 1009, 1011,

1015, 1021, 1025,

1030 RUNCO 1006, 1009, 1040 SAMPO 1009, 1011 SAMSUNG 1007, 1009, 1015,

1016, 1030 SAMSUX 1011 SANSEI 1036 SANSUI 1037 SANYO 1021, 1033 SCIMITSU 1007 SCOTCH 1030

SCOTT 1007, 1030, 1031,

1032

SEARS 1012, 1014, 1015,

1021, 1022, 1027,

1030, 1031 SEMP 1022 SHOGUN 1007 SIGNATURE 1005 SONY 1001 SOUNDESIGN 1030, 1031 SQUAREVIEW 1027 SSS 1007 SUPREME 1001 SYLVANIA 1009, 1014 SYMPHONIC 1027 TANDY 1044 TECHNICS 1013 TECHNOL ACE 1031 TECHWOOD 1013, 1015 TEKNIKA 1005, 1007, 1011,

1014, 1015, 1016,

1019, 1031 TELEFUNKEN 1015 THORN 1039 TMK 1015, 1029, 1030 TOSHIBA 1016, 1021, 1022 TOTEVISION 1011 VECTOR RESEARCH VICTOR 1023 VIDIKRON 1014 VIDTECH 1007, 1030 WARDS 1005, 1007, 1008,

WHITE 1037, 1041, 1042 WESTINGHOUSE YAMAHA 1007, 1009 ZENITH 1005, 1006, 1019,

1009

1009, 1014, 1015,

1025, 1030, 1031

1037

- Operating the connected TV -

Advanced Features

E-52

SD-PX2

ENGLISH

Mounting the unit on the wall

 Attaching the main unit bracket to the unit 1

Route all connection cables through the main unit bracket.

Main unit bracket

2 Attach the main unit bracket to the unit.

Place the main unit on a cushion or a soft cloth to avoid damage.

 Mounting the main unit bracket on the wall

VESA (*) compliant fittings (commercially available) can be attached to the main unit bracket. A wall bracket and adaptor not supplied, but can be purchased.

Note:

(*) VES A (Video Elect ronics Standards Assoc iation) is an organization to promote

the standardization of digital imaging device for PCs.

Types of fittings:

Fittings must satisfy the following.

z Compatible with the VESA standard. z Have a gap of 3.973" (100 mm) 3.973" (100 mm) between the screw holes on the

section to be attached.

z Sturdy and stable to prevent fall or breakage.

3.973" (100 mm)

- Mounting the unit on the wall -

Advanced Features

z Fix them securely with the supplied 2 screws. z Do not use other screws. The unit may fall or break.

E-53

How to attach the main unit bracket

z There are four VESA (*) screw holes on the main unit bracket. You can use com-

mercially available fittings f or mounting.

z Follow the method recommended by the bracket manufacturer.

Supplied screw

Warning:

z Install brackets properly following the operation manual. Improper installation may

cause the main unit to fall leading to injury or breakage.

z To ensure a proper installation, contact your dealer or installer. z During installation, be careful not to pinch your fingers. z The wall should be strong enough to support the weight of the main unit. (Install

on a reinforced part.)

z Do not impose an extra load on a wall bracket. It may cause the main unit to fall

leading to injury or breakage.

z Do not modify or change the main unit bracket. It may cause the main unit to fall

leading to injury or breakage.

Caution:

z Do not block the ventilation opening of the main unit with a tablecloth, etc. Heat

may be kept inside causing fire.

z Select a mounting position carefully to avoid injury by hitting head. z Never step on or hang from the main unit. Pay special attention to children. It may

cause injury or breakage to the main unit.

z Check the wall strength. SHARP is not liable for accidents caused by insuffi-

cient strength of the wall or improper mounting.

z Improper mounting may cause the main unit to fall. If you need assistance,

contact your dealer or installer.

SD-PX2

ENGLISH

- Mounting the unit on the wall -

Advanced Features

E-54

SD-PX2

ENGLISH

Connecting other equipment

Turn off the other equipment before making this connection.

z An optical digital cable, audio digital cable and audio cable are not supplied. Purchase an optional or commercially available cable. z If using an audio cable, purchase one without resistance. If you use an audio cable with resistance, sound volume will decrease.

DIGITAL OUT

To optical digital audio output jack

Digital tuner

- Connecting other equipment -

Advanced Features

To coaxial digital audio output jack

AUDIO OUT L

Optical digital cable (option: AD-M3DC)

To audio output jacks

Headphones

Audio digital cable

(commercially available)

Audio cable

(commercially available)

To audio output jacks

Audio cable

(commercially available)

Optical digital jack cap

When using the optical digital jack, remove the cap first. After using the jack, replace the cap.

Audio cable

(commercially available)

Audio cable

(commercially available)

To audio input jack

VCR

To audio input jacks

Subwoofer

(with a built-in

amplifier)

AC outlet (AC 120 V, 60 Hz)

E-55

 Audio connection to TV

You can listen to TV sound from the speakers by connecting the unit using an optical digital cable or audio cable (not supplied).

SD-PX2

ENGLISH

 Audio connection to a digital tuner

You can listen to sound f rom the digital tuner, etc. from the speakers by connecting the unit using an audio digital cable.

To listen to TV sound:

Turn the power on and press the TV button. Each press of this button changes the input in the order of "AUTO" "DIGITAL" "ANALOG".

AUTO: The audio input switches automatically. (*) DIGITAL: The audio input is switched to digital. ANALOG: The audio input is switched to analog.

(*) When digital and analog signals are received, the unit selects digital signals.

Notes:

z Plug in each cable fully to prevent noise interference. z Refer to the manual for the connected equipment. z You can also use the FUNCTION button to set the input to TV.

 Audio connection to VCR

You can listen to VCR sound from the speakers by connecting the unit using an audio cable.

To listen to VCR sound:

Turn the power on and press the VCR button.

Notes:

z The audio VCR output jacks sends signals coming from a DVD/CD, the tuner,

audio TV input jacks, digital audio input jack, and digital audio TV input jack. Signals from the audio VCR input jacks are not sent.

z When sending signals coming from the digital audio input jack or digital audio TV

input jack via the audio VCR output jacks on the unit, set the stereo mode to "STEREO" (see page 38). In the multi channel mode, signals may not be sent properly. When sending signals from the digital audio input jack to the audio VCR output jacks, the audio output level decreases. (Leave headphones unplugged while recording to avoid further level decrease.)

z Plug in each cable fully to prevent noise interference. z Refer to the manual for the connected equipment. z You can also use the FUNCTION button to set the input to "VCR".

To listen to the digital tuner:

Turn the power on and press the AUX button.

Notes:

z You can also listen to the digital tuner sound by connecting the tuner to the digital

audio TV input jack. Set the input to TV in this case.

z Plug in each cable fully to prevent noise interference. z Refer to the manual for the connected equipment. z You can also use the FUNCTION button to switch the input to auxiliary.

 Using other subwoofer

You can connect a subwoofer with an amplifier to the subwoofer pre output jack.

Note:

No sound is heard from the speaker in which an amplifier is not built in.

 Headphones

z Before plugging in or unplugging the headphones, reduce the volume. z Be sure your headphones have a 1/8" (3.5 mm) diameter plug and are between 16

ohm and 50 ohm impedance. The recommended impedance is 32 ohms.

z While headphones are connected, sound is not produced from the speakers. z You cannot use the surround feature with headphones. z Do not plug in or unplug headphones while recording. The sound may skip.

- Connecting other equipment -

Advanced Features

E-56

SD-PX2

ENGLISH

Connecting other equipment (continued)

Turn off the other equipment before making this connection.

An optical digital cable is not supplied. Purchase an optional optical digital cable.

- Connecting other equipment -

Advanced Features

Optical digital cable (option: AD-M3DC)

Digital audio recorder, etc.

 Digital connection to a digital audio

recorder, etc.

You can record sound on a digital audio recorder by connecting to the digital audio output jack using an optical digital cable.

When connecting a digital audio recorder to the digital audio output jack, set the " DI GITAL" to "D-PCM" (see page 39).

BITSTREAM For 5.1 channel Dolby Digital/DTS surround processors, etc. D-PCM For 2 channel digital input amplifiers, etc.

To record sound on a digital audio recorder:

Turn the power on and press the button.

Notes:

z Some discs are copy protected and digital recording is not possible (including DTS

signals).

z The digital audio output jack sends signals coming from a DVD/CD, the digital

audio TV input jack, and digital audio input jack. Signals from the tuner, audio TV input jacks and the audio VCR input jacks are not sent.

z When you play DVD-Video discs with Linear PCM sound recorded at a 96 kHz

sampling rate, sound may be sampled at 96 kHz (or 48 kHz depending on the disc).

z The digital audio output jack does not send signals coming from SACD or

MP3 discs.

z In DVD-Audio playback, the digital audio output jack does not send some

signals. Also, the sampling rate of digital audio signals may reduce or no signals may be sent.

z Plug in each cable fully to prevent noise interference.

E-57

To optical digital audio input jack

Maintenance

 Cleaning the cabinet  Cleaning the laser pickup lens

Periodically wipe the cabinet with a soft cloth and a diluted soap solution, then with a dry cloth.

z Do not use chemicals for cleaning (gas-

oline, paint thinner, etc.). It may damage the cabinet finish.

z Do not apply oil to the inside of the unit.

It may cause malfunctions.

Do not touch the laser pickup lens. If fingerprints or dust accumulate on the pickup, clean it gently with a dry cotton swab.

Laser pickup lens

Notes:

z Close the disc compartment when it is not used. z Be careful not to damage the optical pickup or to touch it by hand.

Error indicators and warnings

SD-PX2

ENGLISH

When you load an unplayable disc or fail to perform operations properly, the f ollowing messages are displayed on the unit and the TV screen.

Display Meaning

DSP NG z Place the unit away from noise source or plug the

Er-** z The unit considers the DVD mechanism is defective.

(** indicates numbers/symbols.)

FAN LOCK z The cooling fan on the back of the main unit does not

NO DISC z The disc is not loaded.

NO PLAY z The disc's region number is neither 1 nor ALL. No Signal z The digital audio input jack is not connected proper-

(*): Should the same message appear even if the unit is unplugged and plugged in or

is set to the stand-by mode and on again, contact your local dealer where you purchased the unit.

AC power cord to another AC outlet. (*)

z The amplifier is defective.

Set this unit to the stand-by mode and turn the power on again. (*)

run due to foreign objects caught in it. Set this unit to the stand-by mode and remove the

foreign objects around the fan.

z The disc is loaded upside down.

ly.

z Unspecified signal is received and cannot be recog-

nized.

TV screen Meaning

The disc cannot be played with this unit or the

15/

WRO NG D CIS T EYP 83/

::23 40

15/

REG NIO DCO E RER OR 83/

::23 40

NO DISC

NOT

LAL OWED

ACC SES

NDE I ED

disc is loaded in an incorrect way.

The region number of the DVD is not "1" or "ALL".

A disc has not been loaded.

z You are trying to perform an incorrect oper-

ation.

z The operation is prohibited. The disc does not support the operation de-

scribed in this operation manual.

References

- Maintenance / Error indicators and warnings -

E-58

SD-PX2

ENGLISH

References

Troubleshooting chart

Many potential problems can be resolved by the owner without calling a service technician. If something is wrong with this product, check the following before calling your authorized SHARP dealer or service center.

 General

Symptom Possible cause Reference

No sound is heard. z Is the volume level set to "0"? P. 16

z Are the headphones connected? P. 55 z Are the speaker wires disconnect-

ed?

The sounds from speakers are not well balanced.

Noise is heard during playback.

When a button is pressed, the unit does not respond.

Interference or noise occurs on the TV image.

Timer playback does not start.

"CLOCK ADJUST" appears

- Troubleshooting chart -

when checking the clock.

The display on the unit is dark.

The display does not appear. z Is the sliding door open? P. 17 The power is not turned on. z Is the unit unplugged? P. 14 No images are displayed. z Is TV turned on? P. 51

z Are the speaker wires connected to

the wrong channels?

z Move the unit away from any com-

puters or mobile phones.

z Set this unit to the power stand-by

mode and then turn it back on. If the unit still malfunctions, reset it.

z Is the unit placed near TV with inter-

nal antenna? Use an outdoor antenna.

z Did you remove the plug from the

AC outlet, or did a power failure occur? Reset the clock and timer.

z Did you remove the plug from the

AC outlet, or did a power failure occur? Reset the clock.

z Is the display in the dimmer mode? P. 16

z Is the input of TV switched? P . 51

page

P. 11

P. 60

P. 12

P. 15, 48

P. 15

 Tuner

Symptom Possible cause Reference

The radio makes unusual noises continuously.

The preset channel cannot be recalled.

 Remote control

Symptom Possible cause Reference

The remote control does not operate properly.

The unit cannot be turned on with the remote control.

page

z Is the unit placed near the TV or

computer?

z Is the FM antenna or AM loop anten-

na placed properly? Move the antenna away from the AC power cord or the unit if located near.

z Did you remove the plug from the

AC outlet, or did a power failure occur?

Preset the channel again.

z Is the battery polarity respected? P. 14 z Are the batteries dead? z Is the distance or angle incorrect? P. 14 z Are there any obstructions in front of

the unit?

z Is the remote control sensor ex-

posed to strong light (inverter fluorescent light, direct sunlight, etc.)?

z Is the remote control for another

equipment used simultaneously?

z Is the AC power cord of the unit

plugged in?

z Are the batteries inserted? P. 14

P. 12

P. 34

page

P. 14

E-59

 DVD/CD player  Condensation

Symptom Possible cause Reference

Even though a disc is loaded, "NO PLAY" is displayed.

Playback sounds are skipped.

The control buttons do not function. Music or video playback is interrupted.

Pictures and sound are skipped.

The system does not operate even if the power is on.

Image cannot be played back. (Sound is not heard.)

page

z Is the disc loaded upside down? z Is the disc very dirty? z Does the disc satisfy the standards? z Is the unit located near excessive vi-

brations?

z Has condensation formed inside the

unit?

z Is the disc very dirty? z Does the disc satisfy the standards? z Is the unit located near excessive vi-

brations?

z Has condensation formed inside the

unit?

z Is the disc very dirty? z Is the unit located near excessive vi-

brations?

z Has condensation formed inside the

unit?

z Is a disc other than a DVD (region

number 1 or ALL) and an audio CD loaded?

z Are the video and audio cables con-

nected improperly?

z Is a disc other than a DVD (region

number 1 or ALL) and an audio CD loaded?

z Is the disc very dirty? z Is the disc loaded upside down? z Clean the optical pickup if it is dirty. P. 58 z Is the TV input set to "VIDEO 1/VID-

EO 2" etc.?

z Is the unit turned on? P. 14

P. 60

P. 8

P. 13, 55

P. 8

P. 51

Sudden temperature changes, storage or operation in an extremely humid environment may cause condensation inside the cabinet (laser pickup, etc.) or on the transmitter on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc in the unit until normal playback is possible (about 1 hour). Wipe off any condensation on the transmitter with a soft cloth before operating the unit.

 If troub le occurs

When this product is subjected to strong external interference (mechanical shock, excessive static electricity, abnor mal supply voltage due to lightning, etc.) or if it is operated incorrectly, it may malfunction.

If such a problem occurs, do the following:

Clearing all the memory (reset)

1 Unplug the unit. 2 While holding down the ON/STAND-BY button, plug in the AC power cord.

"RESET" appears for about 1 second and the power turns off.

Caution:

When you reset, all data is deleted and the settings return to the default. (DVD initial settings are retained.)

SD-PX2

ENGLISH

References

- Troubleshooting chart -

E-60

SD-PX2

ENGLISH

References

Language code list for disc language

Code Language name Code Language name

AA Afar FY Frisian AB Abkhazian GA Irish AF Afrikaans GD Scots Gaelic AM Amharic GL Galician AR Arabic GN Guarani AS Assamese GU Gujarati AY Aymara HA Hausa AZ Azerbaijani HI Hindi BA Bashkir HR Croatian BE Byelorussian HU Hungarian BG Bulgarian HY Armenian BH Bihari IA Interlingua BI Bislama IE Interlingue BN Bengali; IK Inupiaq

Bangla IN Indonesian BO Tibetan IS Icelandic BR Breton IT Italian CA Catalan IW Hebrew CO Corsican JA Japanese CS Czech JI Yiddish CY Welsh JW Javanese DA Danish KA Georgian DE German KK Kazakh DZ Bhutanese KL Greenlandic EL Greek KM Cambodian

- Language code list for disc language -

EN English KN Kannada EO Esperanto KO Korean ES Spanish KS Kashmiri ET Estonian KU Kurdish EU Basque KY Kirghiz FA Persian LA Latin FI Finnish LN Lingala FJ Fiji LO Laotian FO Faroese LT Lithuanian FR French LV Latvian, Lettish

Code Language name Code Language name

MG Malagasy S N Shona MI Maori SO Somali MK Macedonian SQ Albanian ML Malayalam SR Serbian MN Mongolian SS Siswati MO Moldavian ST Sesotho MR Marathi SU Sundanese MS Malay SV Swedish MT Maltese SW Swahili MY Burmese TA Tamil NA Nauruan TE Telugu NE Nepali TG Tajik NL Dutch TH Thai NO Norwegian TI Tigrinya OC Occitan TK Turkmen OM (Afan) Oromo TL Tagalog OR Oriya TN Setswana PA Panjabi TO Tonga PL Polish TR Turkish PS Pashto, Pushto TS Tsonga PT Portuguese TT Tatar QU Quechua TW Twi RM Rhaeto-Romance UK Ukrainian RN Kirundi UR Urdu RO Romanian UZ Uzbek RU Russian VI Vietnamese RW Kinyarwanda VO Volapuk SA Sanskrit WO Wolof SD Sindhi XH Xhosa SG Sango YO Yoruba SH Serbo-Croatian ZH Chinese SI Singhalese ZU Zulu SK Slovak SL Slovenian SM Samoan

E-61

Specifications

As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

 General

Power source AC 120 V, 60 Hz Power consumption 60 W Dimensions Width: 14-1/2" (368 mm)

Weight 8.2 lbs. (3.7 kg) Audio output

terminals

Audio input terminals Audio input (TV, VCR): RCA type 2 pairs (L/R)

Monitor output terminals

Height: 9-11/16" (245 mm) Depth: 4-1/2" (114 mm)

Front speakers, Center speaker and Surround speakers: more than 4 ohms

Headphones: 16 - 50 ohms (recommended: 32 ohms) Subwoofer pre-out: RCA type 1 Optical digital output: Square type 1 Audio output (VCR): RCA type 1 pair (L/R)

Coaxial digital input (AUX): RCA type 1 Optical digital input (TV): Square type 1 Video output: RCA type 1 S-video output: S-terminal 1 Component video output: RCA type 3

 SACD/DVD player

Signal system NTSC color Supported disc types DVD-Video/Audio (Region number 1, ALL), SACD, DVD-

Video signal Horizontal resolution: 500 lines

Audio signa l Frequ e n c y

R/RW (video mode), audio CD, CD-R, CD-RW

S/N ratio: 70 dB

characteristics

S/N ratio CD: 96 dB (1 kHz) Dynamic range Linear PCM DVD: 95 dB

Total harmonic distortion ratio

Linear PCM DVD: 4 Hz to 22 kHz

(sampling rate: 48 kHz) 4 Hz to 44 kHz

(sampling rate: 96 kHz) CD: 4 Hz to 20 kHz

CD: 94 dB

0.006 % maximum

 Tuner

Frequency range FM: 87.5 - 108 MHz

AM: 530 - 1,720 kHz

SD-PX2

ENGLISH

References

- Specifications -

 Amplifier

Amplification system 5.6448 MHz (128 fs) 1-bit switching (Remarks: fs = 44.1

kHz)

Power output (FTC) 25 watts minimum RMS per channel into 4 ohms from 120

Hz to 20 kHz, 2 % total harmonic distortion

Rated power output Front: 35 W + 35 W, Center: 35 W,

Surround: 35 W + 35 W (4 ohms at 1 kHz)

A/D noise shaping 7th-order (delta - sigma) modulation

E-62

VALID IN U.S.A. ONLY

CONSUMER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer. The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Model Specific Section Your Product Model Number & Description:

Warranty Period for this Product: Additional Item(s) Excluded from Warranty Coverage (if any): Where to Obtain Service: At a Sharp Authorized Servicer located in the United States.

What to do to Obtain Service: Ship prepaid or carry in your Product to a Sharp Authorized Servicer.

SD-PX2 1-Bit Digital Receiver with DVD

(Be sure to have this information available when you need service for your Product.) One (1) year parts and labor from the date of purchase. Non-functional accessories, supplies, and consumable items.

To find a location of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP.

Be sure to have Proof of Purchase available. If you ship the Product, be sure it is insured and packaged securely.

TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP.

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP CORPORATION

9910

0207

PRINTED IN MALAYSIA IMPRIMÉ EN MALAISIE TINSKA014AWZZ 04A R AO

Sharp SD-PX2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
