Sharp SD-AS10 User Manual
1-BIT DIGITAL HOME THEATER WITH DVD PLAYER
MODEL
SD-AS10
OPERATION MANUAL
Thank you for purchasing this SHARP product. To obtain the
best performance from this product, please read this manual
carefully. It will guide you in operating your SHARP product.
SD-AS10 1-Bit Digital Home Theater with DVD Player consisting of
SD-AS10 (main unit and amplifier unit), CP-AS10F (front speakers),
CP-AS10C (center speaker), CP-AS10R (surround speakers) and
CP-AS10W (subwoofer).
SD-AS10
SPECIAL NOTES
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
- SPECIAL NOTES -
Important Instruction
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 82040 of the National Electrical Code that provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
0010
0010
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
! Reorient or relocate the receiving antenna.
! Increase the separation between the equipment and receiver.
! Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
! Consult the dealer or an experienced radio/TV technician for help.
WARNING
FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user's authority to
operate this equipment.
CAUTION:
THIS PRODUCT IS A CLASS 1 LASER PRODUCT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
AS THE LASER BEAM USED IN THIS PRODUCT IS HARMFUL TO
THE EYES, DO NOT ATTEMPT TO DISASSEMBLE THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
0207
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft, please record
below the model number and serial number which are located on the bottom of
the amplifier unit.
Please retain this information.
Model number .................................................................................
Serial number .................................................................................
Date of purchase .................................................................................
Place of purchase .................................................................................
0407
2
IMPORTANT SAFETY INSTRUCTIONS
1
Read Instructions - All the safety and operating instructions should
be read before the product is operated.
2
Retain Instructions - The safety and operating instructions should be
retained for future reference.
3
Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4
Follow Instructions - All operating and use instructions should be
followed.
5
Cleaning - Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6
Attachments - Do not use attachments not recommended by the prod-
uct manufacturer as they may cause hazards.
7
Water and Moisture - Do not use this product near water - for ex-
ample, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.
8
Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to
a child or adult, and serious damage to the product. Use only with a
cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should
follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.
9
A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
10
Ventilation - Slots and openings in the cabinet are provided for venti-
lation and to ensure reliable operation of the product and to protect it
from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on
a bed, sofa, rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have been
adhered to.
11
Power Sources - This product should be operated only from the type
of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.
12
Grounding or Polarization - This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
Alternate Warnings - This product is equipped with a three-wire
grounding-type plug, a plug having a third (grounding) pin. This plug
will only fit into a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose
of the grounding-type plug.
13
Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the product.
14
Protective Attachment Plug - The product is equipped with an at-
tachment plug having overload protection. This is a safety feature. See
Instruction Manual for replacement or resetting of protective device. If
replacement of the plug is required, be sure the service technician has
used a replacement plug specified by the manufacturer that has the
same overload protection as the original plug.
0109
SD-AS10
Important Instruction
- IMPORTANT SAFETY INSTRUCTIONS -
3
SD-AS10
IMPORTANT SAFETY INSTRUCTIONS (continued)
15
Outdoor Antenna Grounding - If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical Code, ANSI/
NFPA 70, provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements
for the grounding electrode.
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
NEC - NATIONAL ELECTRICAL CODE
S2898A
16
Lightning - For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or cable
Important Instruction
- IMPORTANT SAFETY INSTRUCTIONS -
system. This will prevent damage to the product due to lightning and
power-line surges.
17
Power Lines - An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be
fatal.
18
Overloading - Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
ANTENNA LEAD IN WIRE
ANT EN NA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
19
Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage points
or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
20
Servicing - Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
21
Damage Requiring Service - Unplug this product from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:
a)When the power-supply cord or plug is damaged,
b)If liquid has been spilled, or objects have fallen into the product,
c)If the product has been exposed to rain or water,
d)If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation,
e)If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this
indicates a need for service.
22
Replacement Parts - When replacement parts are required, be sure
the service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.
23
Safety Check - Upon completion of any service or repairs to this prod-
uct, ask the service technician to perform safety checks to determine
that the product is in proper operating condition.
24
Wall or Ceiling Mounting - The product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
25
Heat - The product should be situated away from heat sources such
as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
0109
4
"DTS" and "DTS Digital Surround" are registered trademarks of Digital
Theater Systems, Inc.
Accessories
Please confirm that the following accessories are included.
SD-AS10
Manufactured unde r license fro m Dolby L aboratories. "Dolby", "P ro Logic"
and the double-D symbol are trademarks of Dolby Laboratories.
NOTE
Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678, 5,323,396,
5,530,655, 5,539,829, 5,544,247, 5,606,618, 5,610,985, 5,740,317, 5,777,992,
5,878,080 or 5,960,037.
0407
ENERGY STAR® Program Information
Products that have earned the
ENERGY STAR
protect the environment through
superior energy efficiency.
ENERGY STAR® is a U.S. registered mark.
The letters in brackets contained in the model number indicate the color of the product only. Operation and specifications are unaffected.
®
are designed to
0312
Remote control 1 "AA" size battery (UM/SUM-3, R6, HP-
(RRMCGA020AWSA) (UBATU0001AWZZ)
Main unit stand 1
(92LSTD5880ASY1) (QCNWGA012AWPZ) (QCNWGA013AWPZ)
FM antenna 1 AM loop antenna 1 Button name label 1
(92LFANT1535A) (QANTL0014AWZZ) (TLABHA006AWSA)
Non-slip sheet for main
unit 4
(PCUSGA027AWZZ)
Non-slip sheet for
speakers 20
(PCUSG0129AWSA) (QCNWHA006AWZZ)
System connection ca-
White
(for left front
speaker)
approx. 5 m (16 feet)
Purple
(for subwoofer)
approx. 5 m (16 feet)
ble 1
7 or similar) 2
Video cable 1
Green
(for center
speaker)
approx. 5 m (16 feet)
Blue
(for left surround
speaker)
approx. 15 m (49 feet)
Speaker wire 6
Red
(for right front
speaker)
approx. 5 m (16 feet)
Gray
(for right surround
speaker)
approx. 15 m (49 feet)
- Accessories -
General Information
Note:
Only the above accessories are included.
5
SD-AS10
Contents
" Gene ral Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8, 9
Controls and in dicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 13
" Preparation for Use
System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Main unit preparation
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 17
Antenna connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Speaker connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
TV connect io n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
AC powe r con ne c tion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
" DVD Operation
Inserting and removing discs
Inserting a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22, 23
To remove the disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
To exchange other discs while playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Playing a disc
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24, 25
- Contents -
To resume playback after stopping (resume play) . . . . . . . . . . . . . . . . . . . . . . . 25
Changing the progressive scan select mode
Basic operation
Fast forward/Fa st reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . .27
General Information
To start playba ck f rom t he d e s ir e d point (dire c t play) . . . . . . . . . . . . . . . . . . . . 27
To play by specifying time (time search)
Useful operation
To change the s ub t i t l e la nguage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
To change the audio language (audio output) . . . . . . . . . . . . . . . . . . . . . . . . . . 28
To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . . 29
To select a sub title or audio la nguage from the di s c m e nu . . . . . . . . . . . . . . . 29
Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
To zoom images (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
To play repeatedly (re peat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To play the contents between the specified points repeatedly (A-B repeat) . . 31
To change the di s play on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To change the display on the main unit
Page
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Page
" CD, CD-R and CD-RW Op eration
Playing a CD
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . . 33
To play by specifying time (time search)
To play in the desir e d order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . . 3 4
To play in random order (random play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
MP3/WMA and JPEG disc operation
Playback on the MP3/WMA and JPEG menu screen . . . . . . . . . . . . . . . . . . . . . 35
To play in the desir e d order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . . 3 6
Zoom function
Rotating a picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
" Radio Operation
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38, 39
" Advanced Features
Enjoying surround sound (sound mode) . . . . . . . . . . . . . . . . . . . . . . . . . . 40 - 42
Changing the default settings of the amplifier . . . . . . . . . . . . . . . . . . . . . . 43 - 45
Changing the initial setting of DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 - 49
Setting the timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50, 51
Operations after setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Operating the connecte d TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54, 55
Connecting other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 - 58
" References
Language code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60, 61
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62, 63
CONSUMER LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back cover
Icons used in this operation manual
Some functions may not be available depending on discs. The following icons
indicate the discs that can be used in the section.
... DVD-Video discs and DVD-R/DVD-RW for NTSC system.
... Audio CDs.
... CD-R/CD-RW with MP3 recording.
... CD-R/CD-RW with WMA recording.
... CD-R/CD-RW with JPEG recording.
6
Precautions
SD-AS10
" General
! Please ensure that the equipment is positioned in a well-ventilated area and that
there is at least 4" (10 cm) of free space along the sides and back. There must also
be a minimum of 6" (15 cm) of free space on the top of the unit.
Main unit
4" (10 cm)
4" (10 cm) 4" (10 cm)
4" (10 cm) 4" (10 cm)
Amplifier unit
4" (10 cm) 4" (10 cm)
! Use the unit on a firm, level surface free from vibra-
tion.
! Keep the unit away from direct sunlight, strong mag-
netic fields, excessive dust, humidity and electronic/
electrical equipment (home computers, facsimiles,
etc.) which generate electrical noise.
Position A
Position B
Position C
4" (10 cm)
6" (15 cm)
4" (10 cm)
6" (15 cm)
4" (10 cm)
6" (15 cm)
4" (10 cm)
6" (15 cm)
4" (10 cm)
! Do not place anything on top of the unit.
! Do not expose the unit to moisture, to temperatures
higher than 140°F (60°C) or to extremely low temperatures.
! If the unit does not work properly, unplug and plug it
in again. Then turn on the unit.
! In case of an electrical storm, unplug the unit for safe-
ty.
! Hold the AC power plug by the head when removing
it from the AC outlet, as pulling the cord can damage
internal wires.
! Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your local SHARP service facility.
! This unit should only be used within the range of 41°F
- 95°F (5°C - 35°C).
Warning:
The voltage used must be the same as that specified by this unit. Using this product
with a higher voltage other than that specified is dangerous and may result in a fire or
other types of accident, causing damage. SHARP will not be held responsible for any
damage resulting from the use of this unit with a voltage other than that specified.
Cooling fan
This amplifier unit is fitted with a cooling
fan at the rear for improved cooling. Do not
cover the opening in this section with any
obstacles.
Cooling fan
Caution:
! The amplifier unit will get warm while being used. Do not touch the warm areas of
the amplifier unit for prolonged periods to avoid damage to you.
! This amplifier unit contains an automatic protection circuit, which protects the am-
plifier unit from being damaged. All speaker outputs are muted when this circuit is
activated. Should the unit stop operating, first check the speaker terminals for
shorted wires, then press the POWER button to turn on the main unit.
" Volume control
The sound level at a given volume setting depends on speaker efficiency, location
and various other factors. It is advisable to avoid exposure to high volume levels,
which occurs while turning the unit on with the volume control setting up high, or
while continually listening at high volumes.
- Precautions -
General Information
7
SD-AS10
Description of discs
" Types of playable discs
The unit can play back discs bearing any of the following marks:
DVD-Video Disc for NTSC
system
Some DVD discs may not function as described in the manual. See the disc
jacket for restrictions.
Audio CD Audio CD-R Audio CD-RW
- Description of discs -
General Information
(*) Some discs may not play properly due to the status of the equipment used for re-
cording, characteristics of the discs, scratches, dirt, or dirty optical pickup lens.
DVD
DVD-R for NTSC system DVD-RW for NTSC sys-
4.7
Recorded in the video
mode (*)
CD
Or CD-R recorded in MP3/
WMA/JPEG format (*)
tem
Recorded in the video
mode (*)
Discs recorded in VR
mode (Video Recording
format) cannot be played
back.
Or CD-RW recorded in
MP3/WMA/JPEG format
(*)
" DVD-Video
A popular type of DVD disc of the same size as a CD, mainly containing video
images.
Region number
DVD discs are programmed with region
numbers indicating countries in which they
can be played. This system can play discs
with region number "1" or "ALL".
Title and chapter
DV D-Video discs are divided into "titles" and "chapters". If the disc has more than
one movie on it, each movie is a separate "title". "Chapters" are subdivisions of titles.
Title 1 Title 2
Chapter 1
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Region number
(playable area number)
1
1
2
6
ALL
" DVD-R/DVD-RW playback
! You can play DVD-R and DVD-RW discs recorded in the video mode.
! Before playing DVD-R/DVD-RW discs with this unit, finalize them with the
equipment used for recording.
" CD
Track
The audio CD is composed of "tracks". Tracks are equivalent to songs on a CD.
Track 1 Track 2 Track 3 Track 4
8
SD-AS10
" MP3/WMA/JPEG format on CD-R/CD-RW
An MP3 file is an audio data compressed in the MPEG 1 audio layer 3 for mat. MP3
files have the extension ".mp3". (Files with the extension ".mp3" may not play, or
noise may occur during playback if not recorded in the MP3 format.)
WMA is an audio file format developed by Microsoft with the ".wma" extension. This
type of audio file is recorded through Microsoft Windows operating system.
A JPEG file is still image data compressed in the JPEG (Joint Photographic Experts
Group) format. JPEG files have the extension ".jpg".
Folder and file
MP3/WMA/JPEG discs consist of "folders" and "files".
MP3
WMA
disc
JPEG
disc
Folder 1
File 1
File
Folder 2
2
File
File
3
File
1
2
disc
" Icons used on DVD discs
Check the icons of the DVD jacket before playing your discs.
Display Description
Format recorded on the DVD
Type of subtitles recorded
Example: You can select a subtitle language.
2
1: English
2: Japanese
Number of camera angles
2
Number of audio tracks and audio
recording systems
Example: ! You can change the audio language.
1: Original <English> (Dolby Dig-
ital 5.1 Surround)
2: Japanese (Dolby Digital 2 ch)
To adapt the video format to the connected TVs ("wide-screen TV" or "4:3 size
TV").
Recorded subtitle languages.
Number of angles recorded on the DVD.
You can view scenes from different an-
gles.
The number of audio tracks and audio recording systems are indicated.
! Audio and recording system vary de-
pending on the DVD. Check them in
the DVD's manual.
" Discs that cannot be played
! DVDs without the region number "1" or
"ALL"
! DV Ds with PAL system ! CDG
! DV Ds with SECAM system ! Video CD
! DV Ds with MPEG sound ! Photo CD
! DV D-ROM ! CD-ROM
! DV D-RAM ! Discs recorded in special formats, etc.
! The disc s above cannot be played at all, or no sound is heard although images
appear on the screen or vice versa.
! Faulty playback may damage the speakers and can have an adverse effect on
your hearing when played at high volume settings.
! Th is DVD player adopts th e NTSC system. Discs that were made in foreign
countries may not be played back. Check the recordi ng system before purchasing discs.
! You cannot play illegally produced discs.
Copyright Information:
! Unauthorized copying, broadcast, public display, transmission, public perfor-
mance and rental (regardless of whether or not such activities are for profit) of
disc contents are prohibited by law.
! This system is equipped with copy protection technology that causes substantial
degradation of images when the contents of a disc are copied to a video tape.
Copy Protection:
This unit supports Macrovision copy protection.
On DVD discs that include a cop y protection code, i f the contents of the DVD disc are
copied using a VCR, the copy protection code prevents the videotape copy from playing normally.
Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098 and
4,907,093 licensed for limited viewing uses only.
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
! DVD-Audio
! SACD
0407
- Description of discs -
General Information
9
SD-AS10
Controls and indicators
12
1
2 3 4 5 6
7
8
" Main unit
9
10
11
1.Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . .22, 24, 34, 61
2.Disc Compartment Open/Close Button
3.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
5.Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
6.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22, 25, 57, 61
7.Chapter (Track) Skip Up and Down, Search or Tuning Up and Down
buttons 26, 27, 38
8.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
9.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
10.Power Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20, 61
11.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
12.Disc Compartment
9
13.Main Unit Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
. . . . . . . . . . . . . . . . . . . . . .22
Reference page
- Controls and indicators -
General Information
10
13
(Display)
14 18
Indicators vary according to operations.
DVD/CD TUNER
15
16
L C R
SW
LFE
17
SRSL
21
20
(Right side)
26
27
28
19
22
RCL
SW
SRSL
29 30
23
24
25
14.Function Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
15.Track, Title, Chapter, Total Information Indicator . . . . . . . . . . . . . .32
16.Time and Present Disc Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . .32
17.Speaker Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
18.Operation Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
19.Audio Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
20.Surround Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
21.Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
22.Tuner (Band) Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
23.FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
24.FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
25.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
26.Component Video Output Jack s . . . . . . . . . . . . . . . . . . . . . . . . . . .19
27.S-video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
28.System Connection Jack (to amplifier unit)
29.Video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
30.Side Cover
Notes:
! Make sure to attach the main unit stand (see page 15).
! How to open side cover (see page 17).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
. . . . . . . . . . . . . . . . . .17
SD-AS10
" Amplifier unit
(Front)
1
(Rear)
3 4 5 6 7 8 9
14
13
12
1.Power Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
2.Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
3.FM 75 Ohm Antenna Jack
4.AM Antenna Ground Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5.AM Antenna Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
6.System Connection Jack (to main unit) . . . . . . . . . . . . . . . . . . . . .17
7.Coaxial Digital Audio Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . .57
8.Optical Digital Audio Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
9.Optical Digital Audio Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . .57
10.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
11.AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
12.Subwoofer Pre Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
(Connect a commercially available subwoofer with a built-in amplifier.)
13.TV Audio Input Jacks
14.VCR Audio Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
15.VCR Audio Output Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
16.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
15 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
2
10 11
Reference page
" Front/Surround speakers
(Front) (Rear)
1
1.Speaker
2.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2
Reference page
" Center speaker
(Front) (Rear)
21
1.Speaker
2.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Reference page
" Subwoofer
(Front) (Rear)
1
2
1.Woofer
2.Bass Reflex Duct
3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3
Reference page
- Controls and indicators -
General Information
11
SD-AS10
Controls and indicators (continued)
- Controls and indicators -
General Information
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
Set the MODE 1/MODE 2 switch to MODE 1 and press the following buttons.
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
2.MODE 1/MODE 2 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.Function Select Button (DIG1/DIG2)
4.Disc Compartment Open/Close Button . . . . . . . . . . . . . . . . . . . . . .22
5.Function Select Button (VCR/TV) . . . . . . . . . . . . . . . . . . . . . . . . . . .56
6.TV On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
7.TV/Video Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
8.Stereo (2 channel) Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . .41
9.Multi Channel Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
10.Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
11.TV Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .54
12.Direct Select Button
13.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
14.Review/Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 38
15.Chapter (track) Skip Down/Tuner Preset Down Button . . . . . .27, 39
16.Repeat Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
17.Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
18.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
19.Power Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
20.Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
21.Timer/Sleep/Clock Button
22.TV Channel Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .54
23.Program Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
24.Random Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
25.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
26.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
27.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
28.Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
29.Disc Select B utton
30.On Screen Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
31.Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
32.Cue/Tuning Up Button
33.Chapter (Track) Skip Up/Tuner Preset Up Button . . . . . . . . . . .27, 39
34.DVD Still Frame Advance/Disc Pause Button . . . . . . . . . . . . . .25, 29
35.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22, 25, 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
. . . . . . . . . . . . . . . . . . . . . . . . . . .21, 51, 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 38
. . . . . . . . . . . . . . . . . . . . . . . .56
Reference page
" Remote control
12
" Remote control
Set the MODE 1/MODE 2 switch to MODE 2 and press the following buttons (indicated in blue). Avail able operations change.
SD-AS10
1.DVD Top Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.Display (Dimmer) Button
4.DVD Angle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7
1
8
2
9
3
10
5.Progressive Scan Mode Select Button
6.A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.DVD Setup Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
8.Amplifier Setup Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
9.DVD Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
10.DVD Audio Language Select Button
11.DVD Subtitle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
12.Dolby Virtual Speaker button
13.DVD Slow Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Note:
In "MODE 2", you can use buttons other than t he above for the same operations as in
"MODE 1".
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21, 32
. . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Reference page
4
5
11
12
- Controls and indicators -
General Information
6
13
13
SD-AS10
System installation
Installation image (with optional accessories):
Front
speaker
(left)
Subwoofer
Center speaker
Front
speaker
(right)
" Placing the speaker system
The best surround effect will be achieved by placing each speaker at the same
distance from the listening position.
It is recommended to arrange the speakers as shown below.
Front
speaker (left)
Subwoofer
Center
speaker
Front
speaker (right)
Default setting:
6 feet (2 m)
14
Preparation for Use
Surround
speaker
(left)
Surround
speaker
(right)
" Magnetically shielded speakers
The front, surround and center speakers may be placed beside or near the TV as
- System installation -
they are magnetically shielded. However, discoloration may occur depending on the
TV type.
If color variation occurs...
Turn off the TV (with the power switch).
After 15 - 30 minutes, turn the TV on again.
If the color variation is still present...
Move the speakers further away from the TV.
Refer to the manual of the TV for details.
Note:
The subwoofer is not magnetically shielded.
Surround
speaker (left)
Surround
speaker (right)
Notes:
! The default distance is set to 6 feet (2 m). If speakers cannot be placed at equal
distances, refer to "Speaker delay setting" (see page 44).
! Place the TV halfway between the front speakers.
! It is recommended that the center speaker be placed near the television.
! Place the surround speakers at a position just above the height of your ears.
! You can place the subwoofer anywhere you like. As it vibrates while reproducing
bass, place it on a stable, sturdy surface.
Front speaker (left) Front speaker (right)
Center speaker
Main unit preparation
Select from three installation methods according to the location.
For position A or B, make sure to use the included main unit stand. Otherwise the unit may fall.
The display direction changes according to the installation direction.
SD-AS10
Position A
L R
SW
1 Remove the 2 screws.
2 Secure the stand with the removed screws.
Main unit stand
YES
Correct
Position B Position C
L R
SW
1 Remove the 2 screws.
Make all connections
1 Align the position with the remote sensor
and attach the included button name label.
before attaching the
stand (see pages 17,
19).
2 Secure the stand with the removed screws.
Remote
sensor
2 Fit the non-slip sheets into the groove.
Main unit stand
NO
YES
Correct
L R
SW
Button name label
Non-slip sheet
for main unit
NO
- Main unit preparation -
Preparation for Use
Notes:
! When attaching the stand, place the main unit on a cushion or soft cloth to avoid
damage.
! Use the removed screw to secure the stand. Otherwise, the unit may break.
Caution:
! Do not change the installation direction when the main unit is turned on. Discs may
not be read or may be damaged.
! Rem ove the only specified screws. Malfunction may occur. Be careful not to lose
the removed screws.
! To turn on the power after the first installation or after changing the installation
method, use the POWER button on the main unit. From the next time, you can also
use the remote control.
15
SD-AS10
System connections
Make sure to unplug the AC power cord before making any connections.
TV connection (see page 19)
Connect a TV and main unit with the included video cable.
If your TV is equipped with an S-video input jack or
component video input jacks, purchase an appropriate
cable to enjoy higher quality images.
TV
Antenna connection (see page 17)
Main unit
Connecting the system
connection cable
(see page 17)
16
Preparation for Use
FM antenna
- System connections -
Attaching the side cover (see page 19)
You can position cables differently by changing
installation.
AM loop antenna
Amplifier unit
Front speaker
(left)
Surround speaker
(left)
Center speaker
Subwoofer
AC power
connection
(see page 20)
Front speaker
(right)
Surround speaker
(right)
Speaker connection (see page 18)
Antenna connection
SD-AS10
" Connecting the system connection cable
Connect the main unit and amplifier unit as follows.
Amplifier unit
To connect:
The plug is directional.
Connect it with the arrow
facing toward the screw.
To disconnect:
Pull the plug straight out
pressing the plug.
System
connection cable
How to open side cover
Open the side cover to connect the system.
Screw
1
Push
Main unit
Arrow
2
Unplug
Supplied FM antenna:
Connect the FM antenna wire to the FM 75
OHMS jack and position the FM antenna wire in
the direction where the strongest signal can be
received.
FM antenna AM loop antenna
Supplied AM loop antenna:
Connect the AM loop antenna wire to the AM
and GND terminals. Position the AM loop antenna for optimum reception. Place the AM loop antenna on a shelf, etc., or attach it to a stand or a
wall with screws (not supplied).
Note:
Placing the antenna on the unit or near the AC
power cord may cause noise pickup. Place the
antenna away from the unit for better reception.
Black
White
Amplifier unit
Installing the AM loop antenna:
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
Outdoor FM or AM antenna:
Use an outdoor FM or AM antenna if you require better reception. Consult your
dealer.
When using an outdoor AM antenna, be sure to keep the wire of the AM loop antenna
connected.
Outdoor FM antenna
Outdoor AM antenna
49 feet (15 m)
Preparation for Use
- System connections / Antenna connection -
2
1
25 feet (7.5 m)
Ground rod
Ground wire
AM loop
antenna
17
SD-AS10
Speaker connection
Preparation for Use
Make sure to leave the AC power cord disconnected when connecting the
speakers.
To prevent accidental short circuits between and terminals, connect the
speaker wires to the speakers first and then to the unit.
Connect the speaker and the unit by matching the colors.
1 Connect the wires to the speakers.
Example :To connect the right surround speaker.
Black
Red
Tube (gray)
2 Connect the other end to the amplifier unit.
- Speaker connection -
Speaker terminal (gray)
Label
(gray)
Caution:
! The supplied speakers are designed exclusively for SD-AS10. Do not con-
nect these speakers to other equipment. Also, do not connect other speakers to SD-AS10. It may cause malfunction.
! Do not mistake the and , and right and left terminals of the speaker wires. (The
right speaker is placed on the right when you face the unit.)
! Do not let the bare speaker wires touch each other.
! Do not stand or sit on the speakers. You may be injured.
! Do not short-circuit the speaker wire. If it happens with the
power on, the protection circuit is activated and the unit is
set to the power stand-by mode. In this case, check that the
speaker wire is connected correctly before turning on the
power again.
! The speakers grilles are not removable.
! Do not allow any objects to fall into or to be placed in the bass
reflex ducts.
Incorrect
Non-slip sheet for speakers:
Attach the sheets to the bottom of the speaker to prevent it from sliding.
Front/Surround speakers
Non-slip sheet for speakers
Center speaker
Non-slip sheet
for speakers
18
Tube (gray)
Red
Black
Amplifier unit
TV connection
SD-AS10
Three types of jacks (VIDEO OUT, S-VIDEO OUT and COMPONENT VIDEO OUT)
are available for connection of a TV and this unit. Connect according to your TV.
Connect the optional S-video cable or component video cable for higher quality DVD
images. For the component video cable, the progressive video mode is available
and you can enjoy images with less flicker (default setting: PROGRESSIVE OFF).
See page 25 for details.
Connecting to a TV with a video input jack
Main unit
To video
output jack
Connecting to a TV with an S-video input jack
Main unit
Video cable (supplied)
TV
To video
input jack
TV
Connecting to a TV with component video input jacks
Main unit
To component
video output jacks
Green
Red
Blue
Component video cable
(commercially available)
To component
video input jacks
TV
Green
Blue
Red
Notes:
! Change the TV input in accordance with the connected jack.
! Do not conn ect other equipment between the TV and this unit. If they are con-
nected via a VCR, pictures may be distorted.
! If your TV has different indications for the component video inputs (Y, CB and CR
or Y, B-Y and P-Y), connect jacks with its matching color.
! Do not connect to a component video input jack designed for the high-vision sys-
tem, which is not DVD-c ompat ible (the images may be distorted or not appear).
! Us ing the audio cable, you can listen to the TV sound with this unit (see page 56).
" Attaching the side cover
- TV connection -
Preparation for Use
To S-video
output jack
S-video cable
(commercially available)
To S-video
input jack
1 After making all the connections, attach the side cover to the main unit. Fit the
claws into the holes.
2 Route all the cables through the hole of the cover.
19
SD-AS10
AC power connection
Remote control
Preparation for Use
" Connecting the AC power cord
After checking all the connections have been made correctly, plug in the amplifier
unit.
AC outlet
(AC 120 V, 60 Hz)
Note:
Unplug the AC power cord from the AC outlet if the unit will not be in use for a prolonged period of time.
" To turn the power on
Press the POWER button.
The power indicator on the amplifier unit lights up.
If the power does not turn on, check if the power cord and system connection cable
are plugged in properly.
To set the unit to stand-by mode:
Press the POWER button again.
Note:
After the unit enters the power stand-by mode, wait a few seconds to turn on again.
Power indicator
- AC power connection / Remote control -
Amplifier unit
Main unit
" Auto power off function
The unit enters the stand-by mode after 20 minutes of inactivity in DVD operation.
" Battery installation
1 Open the battery cover.
2 Insert the supplied batteries
according to the direction indicated in the battery compartment.
When inserting or removing the batteries, push th em toward th e ba ttery termin a ls.
3 Close the cover.
Precautions for battery use:
! Replace all old batteries with new ones at the same time.
! Do not mix old and new batteries.
! Remove the batteries if the unit will not be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
! Do not use rechargeable batteries (nickel-cadmium battery, etc.).
! Installing the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
! Replace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).
! Periodically clean the transmitter on the remote control and the s ensor on the unit
with a soft cloth.
! Exposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
! Keep the remote control away from moisture, heat, shock, and vibrations.
" Test of the remo te control
Point the remote control directly at the remote sensor on the unit.
The remote control can be used
within the range shown on the
right.
Press the POWER button. Does the power turn on? Now, you can enjoy your system.
! Use 2 remote sensors on the main unit
according to the installation method.
Main unit
Remote
sensor
8" - 20'
(0.2 m - 6 m)
20
