SHARP S2S5 User Manual

S2S5 Series

1. Recognized by UL1577 (Double protection isolation),
file No. E64380 (as model No. S2S5)

2. Approved by CSA, file No. CA95323 (as model No.
S2S5)

3. Optionary available VDE Approved

(∗ )

(DIN EN

60747-5-2), file No. 40009162 (as model No. S2S5)

4. Package resin : UL flammability grade (94V-0)

(∗)

DIN EN60747-5-2 : successor standard of DIN VDE0884.
Up to Date code "RD" (December 2003), approval of DIN
VDE0884.
From Date code "S1" (January 2004), approval of DIN
EN60747-5-2.

■ Features

■ Agency approvals/Compliance

1. Triggering for Triacs used to switch on and off
devices which require AC Loads.

For example heaters, fans, motors, solenoids, and

valves.

2. Triggering for Triacs used for implementing phase
control in applications such as lighting control and
temperature control (HVAC).

3. AC line control in power supply applications.

■ Applications

V

DRM

: 600V, Cost effective
Non-zero cross type
Mini-Flat Package
Phototriac Coupler for triggering

1. High repetitive peak off-state voltage (V

DRM

: 600V)

2. Non-zero crossing functionality

3. IFT ranks available (see Model Line-up section in this
datasheet)

4. 4pin Mini-flat package

5. Superior noise immunity (dV/dt : MIN. 500V/µs)

6. Lead-free components are also available (see Model
Line-up section in this datasheet)

7. Double transfer mold construction (Ideal for Flow
Soldering)

8. High isolation voltage between input and output
(V

iso

(rms) : 3.75kV)

■ Description

S2S5 Series Phototriac Coupler include an infrared

emitting diode (IRED) optically coupled to an output
Phototriac.

These devices feature full wave control and are

ideal isolated drivers for medium to high current Triacs.

SOP package provides 3.75kV isolation from input

to output with superior commutative noise immunity.

1

Notice The content of data sheet is subject to change without prior notice.

In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.

S2S5 Series

Sheet No.: D2-A06701EN

Date Mar. 31. 2004

© SHARP Corporation

■ Internal Connection Diagram

2

■ Outline Dimensions

Product mass : approx. 0.09gProduct mass : approx. 0.09g

(Unit : mm)

VDE option

S2S5 Series

Sheet No.: D2-A06701EN

1

4

3

1

2

2

3

4

Anode
Cathode
Anode/Cathode
Cathode/Anode

2S5

SHARP

mark "S"

Date code (2 digit)

Model No.

Factory identification mark

5.3

±0.3

2.6

±0.2

0.1

±0.1

0.5

+0.4

−0.2

7.0

+0.2

−0.7

Anode
mark

Epoxy resin

45˚

6˚

0.2

±0.05

1 2

0.4

±0.1

4.4

±0.2

4 3

3.6

±0.3

2.54

±0.25

5.3

±0.3

2.6

±0.2

0.1

±0.1

0.5

+0.4

−0.2

7.0

+0.2

−0.7

Epoxy resin

45˚

6˚

0.2

±0.05

1 2

4.4

±0.2

4 3

3.6

±0.3

2.54

±0.25

2S5

4

SHARP

mark "S"

Date code (2 digit)

Model No.

Anode
mark

Factory identification mark

VDE identification mark

0.4

±0.1

Date code (2 digit)

Rank mark

There is no rank mark indicator.

A.D.
1990
1991
1992
1993
1994
1995
1996
1997
1998
1999
2000
2001

Mark

A
B
C
D

E
F

H

J

K

L
M
N

Mark

P
R
S
T

U
V
W
X
A

B
C

Mark

1
2
3
4
5
6
7
8

9
O
N
D

Month

January

February

March

April

May
June

July

August

September

October

November

December

A.D
2002
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012

·

·

·

·

·

·

2nd digit

Month of production

1st digit

Year of production

Factory identification mark

Factory identification Mark

no mark

Country of origin

Japan

Indonesia

Philippines

China

* This factory marking is for identification purpose only.

Please contact the local SHARP sales representative to see the actural status of the
production.

3

repeats in a 20 year cycle

S2S5 Series

Sheet No.: D2-A06701EN

■ Electro-optical Characteristics

■ Absolute Maximum Ratings

4

S2S5 Series

Sheet No.: D2-A06701EN

0.2mm or more

Soldering area

Parameter Symbol Rating Unit

Input

Output

(Ta=25˚C)

Forward current

Reverse voltage

RMS ON-state current

Peak one cycle surge current

Repetitive peak OFF-state voltage

Isolation voltage

Operating temperature

Storage temperature

Soldering temperature

*2

*1

I

F

V

R

IT(rms)

I

surge

V

DRM

V

iso

(rms)

T

opr

T

stg

T

sol

mA

V
A
A
V

kV

˚C
˚C
˚C

*3

50

6

0.05

0.6

600

3.75

−30 to +100

−40 to +125

260

*1 40 to 60%RH, AC for 1minute, f=60Hz
*2 For 10s
*3 f=50Hz sine wave

Parameter Symbol Unit

Input

Output

(Ta=25˚C)

Forward voltage
Reverse current
Repentitive peak OFF-state current
ON-state voltage
Holding current
Critical rate of rise of OFF-state voltage

Minimum trigger current

Isolation resistance
Turn-on time

V

F

I

R

I

DRM

V

T

I

H

dV/dt

I

FT

R

ISO

t

on

V

µA
µA

V

mA

V/µs

mA

Ω

µs

I

F

=20mA

V

R

=3V

V

D=VDRM

IT=0.05A

V

D

=6V

V

D

=1/√−2 ·V

DRM

VD=6V, RL=100Ω

DC500V, 40 to 60%RH

V

D

=6V, RL=100Ω, IF=20mA

Conditions

−

−

−

−

0.1

500

−

−

5×10

10

−

1.2

−

−

−

−

−

−

−

10

11

−

1.4
10

1

2.5

3.5

−

10

7

−

100

MIN. TYP. MAX.

Transfer

charac-

teristics

No rank
Rank R

5

S2S5 Series

Sheet No.: D2-A06701EN

■ Model Line-up (1) (Lead-free components)

Please contact a local SHARP sales representative to inquire about production status.

■ Model Line-up (2) (Lead solder plating components)

Shipping Package

DIN

EN60747-5-2

Model No.

Sleeve

100pcs/sleeve

Taping

3 000pcs/reel

S2S5000F
S2S5R00F

MAX.10

MAX.7

Approved

S2S5A00F

S2S5RA0F

S2S5Y00F

S2S5RY0F

S2S5AY0F

S2S5RAYF

Approved

I

FT

[mA]

(V

D

=6V, RL=100Ω)

No rank
Rank R

I

FT

rank

Shipping Package

DIN

EN60747-5-2

Model No.

Sleeve

100pcs/sleeve

Taping

3 000pcs/reel

S2S5

MAX.10

Approved

S2S5A-S2S5AY

Approved

I

FT

[mA]

(V

D

=6V, RL=100Ω)

No rank

I

FT

rank

Fig.4 Minimum Trigger Current vs.

Ambient Temperature

Fig.6 ON-state Voltage vs.

Ambient Temperature

Fig.3 Forward Current vs. Forward Voltage

Fig.2 RMS ON-state Current vs.

Ambient Temperature

Fig.1 Forward Current vs.

Ambient Temperature

6

S2S5 Series

Sheet No.: D2-A06701EN

0

10

20

30

40

50

60

70

−30 0 50 100

Forward current I

F

(mA)

Ambient temperature Ta (˚C)

1

5

10

010.5 1.5 2 2.5 3

50

100

Forward current I

F

(mA)

Forward voltage VF (V)

Ta=100˚C

25˚C

75˚C

50˚C

0˚C

−30˚C

0

10

20

30

40

50

60

−30 0 50 100

RMS ON-state current I

T

(rms) (mA)

Ambient temperature Ta (˚C)

0

1

2

3

4

5

6

7

8

9

10

−40 0−20 20 40 60 80 100

Minimum trigger current I

FT

(mA)

Ambient temperature Ta (˚C)

VD=6V
R

L

=100Ω

1

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

2

−40 0−20 20 40 60 80 100

ON-state voltage V

T

(V)

Ambient temperature Ta (˚C)

IT=50mA

Fig.5 Relative Repetitive Peak OFF-state

Voltage vs. Ambient Temperature

Relative repetitive peak OFF-state voltage

V

DRM

(T

j

=T

a

) / V

DRM

(T

j

=25°C)

0.7

1.3

1.2

1.1

1

0.9

0.8

−40 −20 0 20 40 60 80 100

Ambient temperature T

a

(°C)

Fig.9 Turn-on Time vs. Forward Current

Fig.8 Repetitive Peak OFF-state Current vs.

Ambient Temperature

7

S2S5 Series

Sheet No.: D2-A06701EN

Remarks : Please be aware that all data in the graph are just for reference.

10

100

1 000

110100

Turn-on time t

ON

(µs)

Forward current IF (mA)

VD=6V
R

L

=100Ω

T

a

=25˚C

10

−10

10

−8

10

−6

−40 0−20 20 40 60 80 100

Repetitive peak OFF-state current I

DRM

(A)

Ambient temperature Ta (˚C)

10

−7

10

−9

VD=600V

Fig.7 Holding Current vs.

Ambient Temperature

0.1

1

10

−40 0−20 20 40 60 80 100

Holding current I

H

(mA)

Ambient temperature Ta (˚C)

VD=6V

■ Design Considerations

In order for the Phototriac to turn off, the triggering current (IF) must be 0.1mA or less.

Please refrain from using these devices in a direct drive configuration.
These Phototriac Coupler are intended to be used as triggering device for main Triacs.
Please ensure that the output rating of these devices will be sufficient for triggering the main output Triac of
your choice. Failure to do may result in malfunctions.

In phase control applications or where the Phototriac Coupler is being by a pulse signal, please ensure that
the pulse width is a minimum of 1ms.

For designs that will experience excessive noise or sudden changes in load voltage, please include an
appropriate snubber circuit as shown in the below circuit.
Please keep in mind that Sharp Phototriac Couplers incorporate superor dV/dt ratings which can often
eliminate the need for a snubber circuit.

● Degradation

In general, the emission of the IRED used in Phototriac Couplers will degrade over time.
In the case where long term operation and / or constant extreme temperature fluctuations will be applied to
the devices, please allow for a worst case scenario of 50% degradation over 5years.
Therefore in order to maintain proper operation, a design implementing these Phototriac Couplers should
provide at least twice the minimum required triggering current from initial operation.

● Recommended Foot Print (reference)

8

(Unit : mm)

● Design guide

S2S5 Series

Sheet No.: D2-A06701EN

1.5

2.54

0.8

6.3

9

S2S5 Series

Sheet No.: D2-A06701EN

✩

For additional design assistance, please review our corresponding Optoelectronic Application Notes.

● Standard Circuit (Medium/High Power Triac Drive Circuit)

Triac

Load

S2S5

Note) Please add the snubber circuit according to a condition.
Any snubber or varistor used for the above mentioned scenarios should be located
as close to the main output triac as possible.

4

3

1

2

AC Line

■ Manufacturing Guidelines

Reflow Soldering:

Reflow soldering should follow the temperature profile shown below.
Soldering should not exceed the curve of temperature profile and time.
Please don't solder more than twice.

● Soldering Method

Flow Soldering :

Due to SHARP's double transfer mold construction submersion in flow solder bath is allowed under the below
listed guidelines.

Flow soldering should be completed below 260˚C and within 10s.
Preheating is within the bounds of 100 to 150˚C and 30 to 80s.
Please don't solder more than twice.

Hand soldering

Hand soldering should be completed within 3s when the point of solder iron is below 400˚C.
Please don't solder more than twice.

Other notices

Please test the soldering method in actual condition and make sure the soldering works fine, since the impact
on the junction between the device and PCB varies depending on the tooling and soldering conditions.

10

1234

300

200

100

0

0

(˚C)

Terminal : 260˚C peak
( package surface : 250˚C peak)

Preheat
150 to 180˚C, 120s or less

Reflow
220˚C or more, 60s or less

(min)

S2S5 Series

Sheet No.: D2-A06701EN

Solvent cleaning :

Solvent temperature should be 45˚C or below. Immersion time should be 3minutes or less.

Ultrasonic cleaning :

The impact on the device varies depending on the size of the cleaning bath, ultrasonic output, cleaning time,
size of PCB and mounting method of the device.
Therefore, please make sure the device withstands the ultrasonic cleaning in actual conditions in advance of
mass production.

Recommended solvent materials :

Ethyl alcohol, Methyl alcohol and Isopropyl alcohol.
In case the other type of solvent materials are intended to be used, please make sure they work fine in
actual using conditions since some materials may erode the packaging resin.

● Cleaning instructions

This product shall not contain the following materials.
And they are not used in the production process for this device.
Regulation substances : CFCs, Halon, Carbon tetrachloride, 1.1.1-Trichloroethane (Methylchloroform)
Specific brominated flame retardants such as the PBBOs and PBBs are not used in this product at all.

● Presence of ODC

11

S2S5 Series

Sheet No.: D2-A06701EN

■ Package specification

12

10.5

4.5

4.6

2.8

6.3

400

±2

● Sleeve package

Package materials

Sleeve : HIPS (with anti-static material)
Stopper : Styrene-Elastomer

Package method

MAX. 100pcs of products shall be packaged in a sleeve.
Both ends shall be closed by tabbed and tabless stoppers.
The product shall be arranged in the sleeve with its anode mark on the tabless stopper side.
MAX. 50 sleeves in one case.

Sleeve outline dimensions

(Unit : mm)

S2S5 Series

Sheet No.: D2-A06701EN

13

● Tape and Reel package
3 000pcs/reel

Package materials

Carrier tape : A-PET (with anti-static material)
Cover tape : PET (three layer system)
Reel : PS

Carrier tape structure and Dimensions

[Packing : 3 000pcs/reel]

Reel structure and Dimensions

Direction of product insertion

S2S5 Series

Sheet No.: D2-A06701EN

A

12.0

±0.3

B

5.5

±0.1

C

1.75

±0.1

D

8.0

±0.1

E

2.0

±0.1

H

7.4

±0.1

I

0.3

±0.05

J

3.1

±0.1

K

4.0

±0.1

F

4.0

±0.1

G

φ1.5

+0.1

−0

FEID

J

G

B

A

C

H

5˚

MAX.

K

H

Dimensions List (Unit : mm)

a

c

e

g

f

b

d

a

370

b

13.5

±1.5

c

80

±1.0

d

13

±0.5

e

21

±1.0

f

2.0

±0.5

g

2.0

±0.5

Dimensions List

(Unit : mm)

Pull-out direction

· The circuit application examples in this publication are
provided to explain representative applications of
SHARP devices and are not intended to guarantee any
circuit design or license any intellectual property rights.
SHARP takes no responsibility for any problems rela­ted to any intellectual property right of a third party re­sulting from the use of SHARP's devices.

· Contact SHARP in order to obtain the latest device
specification sheets before using any SHARP device.
SHARP reserves the right to make changes in the spec­ifications, characteristics, data, materials, structure,
and other contents described herein at any time without
notice in order to improve design or reliability. Manufac­turing locations are also subject to change without no­tice.

· Observe the following points when using any devices
in this publication. SHARP takes no responsibility for
damage caused by improper use of the devices which
does not meet the conditions and absolute maximum
ratings to be used specified in the relevant specification
sheet nor meet the following conditions:
(i) The devices in this publication are designed for use
in general electronic equipment designs such as:

--- Personal computers

--- Office automation equipment

--- Telecommunication equipment [terminal]

--- Test and measurement equipment

--- Industrial control

--- Audio visual equipment

--- Consumer electronics
(ii) Measures such as fail-safe function and redundant
design should be taken to ensure reliability and safety
when SHARP devices are used for or in connection

with equipment that requires higher reliability such as:

--- Transportation control and safety equipment (i.e.,
aircraft, trains, automobiles, etc.)

--- Traffic signals

--- Gas leakage sensor breakers

--- Alarm equipment

--- Various safety devices, etc.

(iii) SHARP devices shall not be used for or in connec­tion with equipment that requires an extremely high lev­el of reliability and safety such as:

--- Space applications

--- Telecommunication equipment [trunk lines]

--- Nuclear power control equipment

--- Medical and other life support equipment (e.g.,
scuba).

· If the SHARP devices listed in this publication fall with­in the scope of strategic products described in the For­eign Exchange and Foreign Trade Law of Japan, it is
necessary to obtain approval to export such SHARP de­vices.

· This publication is the proprietary product of SHARP
and is copyrighted, with all rights reserved. Under the
copyright laws, no part of this publication may be repro­duced or transmitted in any form or by any means, elec­tronic or mechanical, for any purpose, in whole or in
part, without the express written permission of SHARP.
Express written permission is also required before any
use of this publication may be made by a third party.

· Contact and consult with a SHARP representative if
there are any questions about the contents of this pub­lication.

14

■ Important Notices

S2S5 Series

Sheet No.: D2-A06701EN
