Sharp R-T10, RK-T10 User Manual
ENGLISH
RK-T10
INFORMATION & RECIPES Pages 1 - 4
GB
RK-T10 English 15/07/2000 09:22 Page A
RK-T10 English 15/07/2000 09:23 Page B
1
OVEN AND ACCESSORIES
ENGLISH
B
ACCESSORIES:
Check to make sure the following accessories are supplied: A Square tin, B Square shelf.
NOTE: When using the square shelf or square tin, place them onto the shelf runners as shown in Fig. A.
When using the square shelf, ensure the shelf locator is on the right side.
1 Grill heating element
2 Oven lamp
3 Control panel
4 Shelf runners
5 Waveguide cover
6 Oven cavity
7 Coupling
8 Door seals and sealing
surfaces
9 Door opening handle
2
4
1
8
9
6
5
7
A
3
Shelf locator
Square shelf
Fig. A
Use for convection only.
Shelf runners
1
2
SPECIAL NOTES FOR SQUARE SHELF & SQUARE TIN:
1. When using either the square shelf or the square tin, place it at position
1. When using both of them, place the square tin at position 1 and the
square shelf at position 2 as shown in the diagram.
2. When using the square shelf and/or the sqaure tin, leave the turntable
in the oven.
3. When using the square shelf or the square tin, rotate the square tin or
the container on the square shelf 90˚ halfway to achieve better results.
4. When using the square shelf follow the notes below to prevent them
slipping out:
• Do not place container with food weighing more than 5 kg on
the square shelf.
• Ensure that the square shelf is in the correct position and does
not rattle.
• When removing the food, pull the square shelf until it is slightly
locked, and then remove the food.
5. Some recipes for using the square shelf or the square tin are included
on pages 2 to 4.
WARNING: Never use the square shelf and square tin for microwave cooking and dual cooking as this
may cause arcing.
RK-T10 English 15/07/2000 09:23 Page 1
