Sharp PN-R603, PN-R903 Brochure

LCD MONITOR

PN-R903
PN-R703
PN-R603

Stupendous Views from Ultra-Large

LCD Monitors at Bring Images to Life

(Image)

LED backlight dimmed

LED backlight brightened

Local Dimming

A standard-equipped interface expansion board gives PN-R903/
R703/R603 monitors a comprehensive range of input/output jacks,
including the DisplayPort interface.

Interface Expansion

PN-R903/R703/R603 monitors offer a choice of landscape or
portrait installation, allowing customers to select the mode that

best suits their display content and application. While portrait
installation offers the look and impact of a poster, landscape
installation puts wide images on vivid display.

Choice of Installation Mode

Built solid, PN-R903/R703/R603 monitors are ideal for use in
24-hour stores and in other demanding professional applications
that require around-the-clock operation seven days a week.

24/7 Operation

Picture-in-Picture (PIP) mode allows an AV-sourced image to be
displayed within a PC-sourced one (or vice versa), while
Picture-by-Picture (PbyP) mode puts images from AV and PC
sources side by side for split-screen viewing.

Dual Screen Display

Multiple monitors can be grouped together to display one enlarged
image, thanks to Enlarge (Zoom) Display mode, which corrects the
framing of that image to eliminate misalignment between monitors.

Enlarge

(Zoom)

Display Mode

With Mirror Display mode, the same image can be displayed on a
daisy chain of PN-R903/R703/R603 monitors for the powerful
impact of visual repetition.

* The number of monitors possible in a daisy chain varies depending
on the connection method: Up to 25 (for non-HDCP-encoded
content) or 4 (for HDCP-encoded content) via DisplayPort; or up to 5
(for HDCP-encoded content) via DVI.

Mirror Display Mode (Daisy Chain)*

Built-in speakers eliminate the need for external speakers and
keep PN-R903/R703/R603 monitors stylishly streamlined. The
speakers emit sound from both sides of the monitors, making them
ideal for conveying audio
information and playing
location-appropriate
background music.

Built-In Speakers

Sized for eye-catching impact, Sharp’s new PN-R903 LCD monitor
features a towering 90-inch screen large enough to realistically

showcase life-size images of people. This top-quality LCD
colossus excels in a variety of indoor venues, including retail
locations, educational institutes, conference rooms, and public
spaces. Incorporating a single, seamless screen, the PN-R903
LCD monitor can make an unforgettable impact on any audience.

High-Impact 90-Inch Screen

High Contrast and Superb Energy Efficiency

Breathtaking Image Quality

The 90-inch LCD panel incorporates Sharp’s UV2A* technology,
which ensures highly efcient use of light from the backlight and
prevents light leakage. The result: truly bright whites and extremely
deep blacks. The panel also boasts a full-array LED backlight, in
which LED elements are evenly positioned across the entire panel
to give on-screen images remarkably uniform brightness.

* UV2A stands for Ultraviolet-induced Multi-domain Vertical Alignment, a photo­alignment technology that ensures uniform alignment of liquid crystal molecules.

For its outstanding black levels, amazing contrast, and superb
energy efciency, the PN-R903 owes much to local dimming of its
LED backlight. Local dimming allows specic groups of LEDs to be
independently dimmed or brightened for greater control of the
darkness and brightness in different areas of the monitor, resulting
in considerably reduced
power consumption.
That’s why the PN-R903
can deliver signicantly
better contrast and
brightness than
conventional LCD
monitors while using
remarkably less power.

PN-R903/R703/R603 Key Features

Clearly colossal, Sharp’s PN-R903 boasts an ultra-large 90-inch screen that towers seamlessly above other professional LCD

monitors in size, quality, and impact. With its full-HD resolution, brilliant image quality, and streamlined prole, this premium

professional LCD monitor was designed to lead the large-format digital signage market. Local dimming of the LED backlight

partnered with 700 cd/m

2

brightness keep the PN-R903 well ahead of the pack, ensuring outstanding energy efciency and

high-contrast images that multiply the awe factor.

PN-R903—A Gargantuan 90-Inch LCD Monitor
