ADS1

Conventions used in this guide

Thank you for choosing ADS1, our latest 3G mobile phone.

ADS1 has many features designed to enhance your mobile experience. From its unique, stylish design and Best-in-class QWERTY keypad, 3.2” HVGA LCD with Touch Screen, Android OS 2.2(Froyo), Wi-Fi, we know you will enjoy the entire ADS1 experience with.

This User Guide contains important and useful information that will maximize your familiarity with all that ADS1 has to oer.

Conventions used in this guide

In this user guide, we use the following symbols to indicate useful and important information:

NOTE

NOTE Notes, usage tips or additional information.

Warning Situations that could cause injury to yourself or others.

Caution Situations that could cause damage to your device or other equipment.

AT&T LEGAL

Devices purchased for use on AT&T’s system are designed for use exclusively on AT&T’s system. You agree that you won’t make any modications to the Equipment or programming to enable the Equipment to operate on any other system. A voice plan is required on all voice-capable devices, unless specically noted otherwise in the terms governing your agreement. Some devices or plans may require you to subscribe to a data plan.

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, AT&T wants you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, AT&T oers privacy controls that let you decide how an application may use the location of your phone and other phones on your account. However, AT&T’s privacy tools do not apply to applications available outside of AT&T. Please review the terms and conditions and the associated privacy policy for each location-based service to learn how location information will be used and protected.

Your phone may be used to access the Internet and to download, and/or purchase goods, applications, and services from AT&T or elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain devices which bypass AT&T controls.

A&T may collect certain types of information from your device when you use AT&T services to provide customer support and to improve its services. For more information on AT&T’s Privacy Policy, visit att.com/privacy.

Contents

Speciﬁcations ................................................................................................................................ 6

Basics ............................................................................................................................................. 7

In Box ....................................................................................................................................................................................... 7

Phone Overview .......................................................................................................................................................................7

Battery ...................................................................................................................................................................................... 9

SIM Card .................................................................................................................................................................................10

microSD Card ..........................................................................................................................................................................11

Turning the Phone On or O ...................................................................................................................................................12

Phone Options ........................................................................................................................................................................12

Entering Your PIN ....................................................................................................................................................................12

Finger Gestures .......................................................................................................................................................................13

Keyboard ...................................................................................................................................... 14

Using the Onscreen Keyboard ................................................................................................................................................14

Using the Android keyboard ...................................................................................................................................................14

Using the Swype Keyboard ....................................................................................................................................................17

Using the QWERTY keypad ....................................................................................................................................................19

Editing Text .............................................................................................................................................................................20

Getting started ............................................................................................................................. 21

Google Account ......................................................................................................................................................................21

Getting to know the Home screen ..........................................................................................................................................23

Customizing the Home Screen ...............................................................................................................................................25

Essential Display Indications ..................................................................................................................................................26

Notications Panel .................................................................................................................................................................28

Opening and Switching Applications .....................................................................................................................................29

Sleep mode ............................................................................................................................................................................30

Adjusting the Volume ............................................................................................................................................................. 31

Searching Your Phone and the Web .......................................................................................................................................32

Connecting Your Phone to a Computer ...................................................................................................................................33

Phone Calls ................................................................................................................................... 34

Making Calls ...........................................................................................................................................................................34

Answering or rejecting calls ...................................................................................................................................................36

Using In-call Options ..............................................................................................................................................................37

Managing Multiple Calls ........................................................................................................................................................38

Using the Call log ....................................................................................................................................................................39

Listening to your voicemail ....................................................................................................................................................41

Dialing by Voice ......................................................................................................................................................................41

Contacts ....................................................................................................................................... 42

About Contacts .......................................................................................................................................................................42

Opening Your Contacts ...........................................................................................................................................................42

Getting Started ....................................................................................................................................................................... 42

Editing/ Deleting Contacts .....................................................................................................................................................46

Communicating ......................................................................................................................................................................48

Account Setting ......................................................................................................................................................................49

Groups ....................................................................................................................................................................................50

Messaging .................................................................................................................................... 52

About Messaging ...................................................................................................................................................................52

Sending a Message ................................................................................................................................................................ 52

Reading a Message ................................................................................................................................................................ 54

Changing Messaging Settings ................................................................................................................................................ 55

Google .......................................................................................................................................... 56

Gmail ......................................................................................................................................................................................56

Talk .........................................................................................................................................................................................59

Maps .......................................................................................................................................................................................62

Places .....................................................................................................................................................................................65

Navigation ..............................................................................................................................................................................66

Latitude ..................................................................................................................................................................................68

Calendar .................................................................................................................................................................................70

News & Weather .....................................................................................................................................................................73

Market ....................................................................................................................................................................................74

YouTube ..................................................................................................................................................................................76

Web ..............................................................................................................................................79

Email ......................................................................................................................................................................................79

Browser ..................................................................................................................................................................................83

Facebook ................................................................................................................................................................................86

Twitter ....................................................................................................................................................................................86

Wi-Fi .......................................................................................................................................................................................86

Bluetooth ..................................................................................................................................... 88

Using Bluetooth .....................................................................................................................................................................88

Disconnecting or Unpairing from a Bluetooth Device ............................................................................................................89

Connecting a Bluetooth Headset or Car Kit ............................................................................................................................89

Sending and Receiving Information Using Bluetooth ............................................................................................................90

Entertainment .............................................................................................................................. 91

Camera/Camcorder ................................................................................................................................................................91

Gallery .................................................................................................................................................................................... 93

Videos .....................................................................................................................................................................................95

Sound Recorder ......................................................................................................................................................................95

Music Player ...........................................................................................................................................................................96

Tools ............................................................................................................................................. 99

Clock .......................................................................................................................................................................................99

Calculator .............................................................................................................................................................................100

Memo ...................................................................................................................................................................................101

MY Files ................................................................................................................................................................................101

Polaris

Oce ......................................................................................................................................................................103

AT&T(Web) ................................................................................................................................. 105

AT&T Navigator .....................................................................................................................................................................105

AT&T FamilyMap ..................................................................................................................................................................106

YPmobile ..............................................................................................................................................................................107

Live TV ..................................................................................................................................................................................107

AT&T myWireless Mobile ......................................................................................................................................................108

AT&T Code Scanner ...............................................................................................................................................................108

Settings ...................................................................................................................................... 109

Settings on your phone ........................................................................................................................................................109

Safety information ..................................................................................................................... 113

Safety information for wireless handheld phones ...............................................................................................................113

Hearing AID compatibility with mobile phones ...................................................................................................................114

Safety information for FCC RF exposure ...............................................................................................................................115

SAR information ...................................................................................................................................................................115

FDA consumer update ..........................................................................................................................................................116

Emergency calls .................................................................................................................................................................... 120

Compliance with other FCC regulations ...............................................................................................................................120

General safety ......................................................................................................................................................................121

Antenna ................................................................................................................................................................................122

Battery ..................................................................................................................................................................................122

Adapter/Charger...................................................................................................................................................................123

Games ..................................................................................................................................................................................123

Recycle your cell phone! .......................................................................................................................................................124

FCC compliance information ................................................................................................................................................124

COPYRIGHT & PATENT .................................................................................................................. 126

Software Copyright Notice ...................................................................................................................................................126

Warranty .................................................................................................................................... 127

Manufacturer’s warranty ...................................................................................................................................................... 127

Specifications

Design

Android Quick Messaging Device with Touch & QWERTY

Displays

3.2” HVGA (480*320)

Melodies

AAC, AMR, MIDI, SP-MIDI, MP3, WAV(8bit/16bit PCM), MP4

Camera

3MP AF

Dimensions & Weight

Dimensions : 120 x 59.9 x 13.9 mm

Weight : 145g

Memory

512MB/512MB [External : 2GB microSD Card]

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Standard Lithium-lon(Li-ion) 1240mA Up to 250 hours Up to 3 hours

Operating Frequency

Network : UMTS/HSDPA (850/900/1800/1900 MHz)

UMTS/HSDPA(850/900/2100 MHz) Wi-Fi(802.11 b/g/n)

Data Speed : HSDPA 7.2Mbps / HSUPA 2Mbps

Operation System

Android OS 2.2 (Froyo)

I/F

micro SD card slot, Micro USB, 3.5mm headset jack, Bluetooth 2.1//Wi-Fi (802.11b/g/n), A-GPS, Accelerometer, light

ħ

sensor, E-Compass, proximity sensor

Basics

In Box

You will nd the followings inside the box:

ħMobile device

ħUSB to Micro USB cable

ħBattery Cover

ħCD with User Guide

Battery

Universal USB standard AC charger adaptor

Quick Start Guide

2GB microSD Card (Mounted in the device)

Phone Overview

168

Qwer ty

U S B

2 3 4

Menu Home Search

Back

1. QWERTY keypad

2. Search key All screen : Quick Search

3. Home key All screen : Move to Homescreen

4. Menu key Options

5. Back key All screen : Move to the previous screen

6. USB Port Charging / PC sync

Menu Home Search

Back

7. Volume key Volume up/down

8. Power/Lock key Press :Screen lock mode Press and Hold : Power ON/ Phone Options

9. Camera key Idle :Start Camera Camera Preview : Take a picture Camcorder Preview : Start video recording Camcorder Recording : Stop video recording

10. Ear-mic Jack

3.5mm Ear-mic Jack

QWERTY mode view

Back

Menu Home Search

Qwer ty

2 3

Q W E R T Y

A S D F G H

Fn Z X C V B

Shift

Sym

@ ,

4 5

Your phone has a QWERTY keypad which provides a superior typing experience on a small handheld for easy and comfortable texting. You can use all of the phone functions with the QWERTY keypad.

I O P

K L

M ؿ

ረ ف ሪ

Delete

Return

7 8

1. Function key

2. Shift key

3. Symbol key

4. @

5. Space bar

6. A-Z

7. Delete key

8. Return key

9. Navigation keys

Battery

To extend your battery’s life, do not browsing web frequently. Also poor signal area and extreme temperature discharge battery easily. If not necessary, it is recommended that you turn o Wi-Fi, Bluetooth, etc.

Battery installation

Please use only original batteries and accessories that came with your phone or replacements that we recommend.

1. Make sure that your device is turned o, and then remove the battery cover.

2. Align the battery’s exposed gold contacts with the battery connectors inside the battery compartment.

3. Insert the contact side of the battery rst and then gently push the battery into place.

4. Replace the battery cover by setting it to the slot of the phone and sliding it back into its place.

Battery removal

1. Make sure that your device is turned o, and then remove the battery cover.

2. Lift the tab of the battery to remove the battery.

Charging your battery

Before you turn on and start using your device, it is recommended that you charge the battery.

1.Plug the USB cable into the AC Charger port.

2. Plug the AC Charger into a standard outlet.

3.To access the USB port located on the left side of your device, open the ap and plug the other end of the AC Charger into the USB port. The battery must be installed for the phone to work properly.

4. The USB icon on the USB cable should always be face-up on the same side as the display screen when it is inserted into the your device. See the diagram to the right for proper positioning and insertion of the AC Charger adapter into the phone. You should never force the AC Charger adapter into the phone.

t*UJTNPSFFóDJFOUUPDIBSHFUIFCBUUFSZXJUIUIFZPVSEFWJDFQPXFSFEPò

NOTE

 t#BUUFSZPQFSBUJOHUJNFHSBEVBMMZEFDSFBTFTPWFSUJNF

 t*GUIFCBUUFSZGBJMTUPQFSGPSNOPSNBMMZZPVNBZOFFEUPSFQMBDFUIFCBUUFSZ

SIM Card

The SIM card contains your phone number, service details, and phonebook/message memory.

Inserting SIM card

1. Make sure that your device is turned o, and then remove the battery cover.

2. Lift the battery out of the device.

3. Locate the SIM card slot, then insert the SIM card with its gold contacts facing down and its cut-o corner facing out the card slot.

4. Slide the SIM card completely into the slot.

5. Replace the battery and battery cover.

tOnly AT&T SIM card can work on ADS1.

NOTE

Removing SIM card

1. Make sure that your device is turned o, and then remove the battery cover.

2. Lift the battery out of the device.

3. Slide the SIM card out from the slot with your nger.

microSD Card

Use the microSD card to store your photos, videos, and music. You can save, move and delete the les between your device and the external memory card. You can also move and copy the les to computer from your device.

Inserting the microSD card

1. Remove the battery cover.

2. Locate the microSD card slot.

3. Insert the microSD card into the slot with its gold contacts facing down until it clicks into the place.

4. Replace the battery cover.

Removing the microSD card

1. Make sure that your device is turned o, and then remove the battery cover.

2. Press it to eject it from the slot, and then remove it.

Removing the microSD card while the phone is on

If you need to remove the microSD card in case that the phone is on, unmount the microSD card rst to prevent corrupting or damaging the les in the microSD card.

1. From the Home screen, tap

2. Tap

3. Remove the microSD card by following the steps in “Removing the microSD card”.

SD card & phone storage > Unmount SD card > OK.

Apps > Settings. Or press Menu > Settings.

Turning the Phone On or Off

Turning your phone on

1. Press Power/Lock.

When you turn on the phone for the rst time, you’ll need to set it up. See the Getting Started chapter for details.

NOTE

Turning your phone oﬀ

1. If the display is o, press any button to turn it back on.

2. Press and hold

3. When Phone options menu appears, tap

Power/Lock for a few seconds.

Power oﬀ > OK.

Phone Options

Silent mode

1. Press and hold Power/Lock.

2. Tap

ħ

NOTE

Airplane mode

1. Press and hold Power/Lock.

2. Tap

ħ

Silent mode.

hen you set Silent mode,

W heard any longer(except media and alarms).

To release the mode, press and hold Power/Lock again, and then tap Silent mode.

Airplane mode.

hen you set Airplane mode,

W functions are deactivated.

To release the mode, press and hold Power/Lock again and tap Airplane mode.

NOTE

is displayed on Notice/Status bar, and then Ring tone, eects and other sounds will not be

is displayed on Notice/Status bar, and then Wi-Fi, Bluetooth, and mobile network



Entering Your PIN

Most SIM cards come with the PIN(Personal Identication Number) set by your mobile operator. If you’re asked for the PIN, enter it, and then tap OK.

Finger Gestures

Tap To select onscreen items such as application and settings icons or press onscreen buttons, simply tap them with

your nger.

Tap and hold To open available options for the item, simply tap and hold the item.

Swipe or slide Quickly drag your nger vertically or horizontally across the screen.

Drag Tap and hold your nger with some pressure before you start to drag. While dragging, do not release your nger

until you have reached to the target position.

Flick Flicking the screen is similar to swiping, but you need to swipe your nger in lighter and quicker strokes. This

nger gesture is always in a vertical direction, such as icking the contacts or the message list.

Rotate For most screens, you can automatically change the screen orientation from portrait to landscape by turning the

phone sideways. When entering text, you can turn the phone sideways to bring up a bigger keyboard. When you slide up the screen to use QWERTY keyboard, the screen automatically rotates to landscape mode.

Keyboard

Using the Onscreen Keyboard

You enter text using the onscreen keyboard. Some applications open the keyboard automatically. In others, you tap the text eld where you want to enter text to open the keyboard. You can choose the keyboard which suits your typing style among two dierent keyboard layouts.

Android keyboard This layout is similar to a desktop computer keyboard. This is the default keyboard layout. Swype Swype lets you enter a word with one continuous motion. To enter a word, just drag your nger over the letters

of the word.

By default, Android keyboard is set.

If you want to change keyboard type: Tap and hold the text input eld > tap Input method > select Swype or

ħ

Android keyboard.

ADS1 provides the useful built-in QWERTY keypad and you also use it for all the functions of the phone instead of the

onscreen keyboard.

You can change the keyboard settings for using Swype, Android keyboard, Device keyboard and User dictionary. From the Home screen, tap

NOTE

Apps > Settings > Language & keyboard. Or press Menu > Settings > Language & keyboard.

Using the Android keyboard

Displaying the keyboard and entering text

Use the following keys while entering text with the onscreen keyboard:

4 5

1 Tap the suggestion to enter it.

2 Shift key. Tap once to capitalize the next letter you type. Tap and hold it for all caps. 3 Backspace key. Tap to delete the previous character. 4 Symbol key. Tap to switch to the numeric and symbol keyboard. 5 Microphone key. Tap to enter text by speaking. 6 Enter key. Tap to create a new line.

1. Tap a text eld to open the onscreen keyboard.

2. Tap the keys on the keyboard to type.

ħThe characters you’ve entered appear in a strip above the keyboard with suggestions for the word you are typing to the

right. Tap a suggested word to enter it.

4. Use the

5. When you’ve nished typing, press

to erase characters to the left of the cursor.

Back to close the keyboard.

To enter numbers, symbols, and other characters

Tap

on the symbols keyboard

Tap

Tap and hold a vowel or the C, N, or S key To open a small window where you can tap an accented vowel or other alternate letter.

Tap and hold

Tap and hold a number or symbol key To open the window of additional symbols.

ħSlide your nger smoothly up from the main keyboard to open an extension keyboard, with numbers and symbols. To

enter a number or symbol from that keyboard, slide your nger onto it and then lift your nger.

ħWhen you tap a key, a larger version displays briey over the keyboard. Keys with alternate characters display an ellipsis (

... ) below the character.

To switch to the numeric and symbol keyboard.

To view additional symbols, tap it again to switch back.

To open a small window with a set of common symbols.

Changing the keyboard language

Setting the Android keyboard languages

1. Tap a text eld to open the onscreen keyboard.

2. Tap and hold

3. Tap Input languages > Select one or more languages.

ress

4. P

> Android keyboard settings.

Back to save it.

Changing the keyboard language

If you’ve used the Android keyboard settings to make more than one language available when using the onscreen keyboard, the current keyboard language is displayed on the Space bar and you can switch languages.

1. Tap and hold

2. Without lifting your nger, move it to the left or right until the language you want appears in the center of the small window above

3. Lift your nger.

If you have many languages available, you may have to repeat these steps to nd the language you want.

Entering Text by Speaking

You can use voice input to enter text by speaking. Voice input is the experimental feature that uses Google’s speechrecognition service, so you must have a data connection on a mobile or Wi-Fi network to use it.

Turning on voice input

If the onscreen keyboard does not display , voice input is not turned on or you have congured it to display on the symbol keyboard.

1. From the Home screen, tap

2. Tap

Language & keyboard > Android keyboard .

Apps > Settings. Or press Menu > Settings.

ħYou can also tap and hold on the onscreen keyboard. In the dialog that opens, tap Android keyboard settings.

3.Tap Voice input.

. Tap the option for where you want to use

(On main keyboard or On symbols keyboard). Or tap Oﬀ to turn o voice input.

Entering text by speaking

You can enter text by speaking, in most places that you can enter text with the Android keyboard.

1. Tap a text eld.

2.Tap the

3. When prompted to “Speak now,” speak what you want to enter.

ħSay “comma,” “period,” “question mark,” “exclamation mark,” or “exclamation point” to enter punctuation.

ħWhen you pause, what you spoke is transcribed by the speech-recognition service, entered in the text eld and underlined.

You can tap

ħYou can edit the text that you enter by typing or speaking.

on the keyboard. Or just swipe your nger across the keyboard from left to right.

to erase the underlined text. If you start typing or entering more text by speaking, the underline disappears.

Adding words to User dictionary

Sometimes you may need to add a word to the predictive text dictionary, for example a name or a specialized technical word. If you want to add the word to your User dictionary in the middle of entering text, tap and hold the text eld > select Add “***” to dictionary.

ou can also add a word to the list manually:

1. From the Home screen, tap

Apps > Settings. Or press Menu > Settings.

2. Tap

3. Press

4. Write the word > Tap OK.

Language & keyboard > User dictionary.

Menu > Add.

Editing or delete a word in the User dictionary

You can view, edit or delete the words that you’ve added to the dictionary.

1. From the Home screen, tap

2. Tap

ħTo edit words from the dictionary, tap the word you want to edit > Edit > Write the word > Tap OK.

ħT

Language & keyboard > User dictionary.

o delete words from the dictionary, tap the word you want to delete > Delete.

Apps > Settings. Or press Menu > Settings.

Using the Swype Keyboard

Enter text using the Swype keyboard

Swype lets you enter a word with one continuous motion. To enter a word, just drag your nger over the letters of the word.

1. Place your nger on the key with the rst letter of the word and drag your nger to the following letters without releasing the nger from the screen.

2. Continue until you have nished the word. lift your nger on the last letter.

3. If Swype doesn’t gure out the word you enter clearly, the new window with suggestions opens. select an alternative word from the list.

Love : To capitalize a letter, go above the keypad after each desired capital letter.

Good : To enter a double letter within a word, make a circle on the letter.

123... : To enter characters on the upper half of the key, tap and hold the key. When the character list appears, you can

enter special characters, symbols, and numbers. Or, tap SYM to enter several symbols.

I’ll: To enter apostrophes in common words, drag through the n as though it was an apostrophe.

ħIf Swype doesn’t know the word, you can tap the letter keys to enter it.

Using the QWERTY keypad

Your device has a specically designed QWERTY keypad that provides a superior typing experience on this small handheld device for easy and comfortable input. You can use all of the phone functions with the QWERTY keypad. When you open the keypad, you have the extra benet of a full messaging keypad.

Q W E R T Y

A S D F G H

1 2

Fn Z X C V B

Shift

Sym

@ ,

4 5

1. Fn (Function key) To type the number or symbol printed in Skyblue at the top of a key, hold down the Fn key and press one or more letter keys. To return to typing letters, release the Fn key.

o write in numbers or symbols printed in Skyblue at the top of a key only, press Fn key twice.

2. Shift (Shift key) To type upper-case letters, hold down the Shift key and press one or more letter keys. To return to

yping lower-case letters, release the Shift key, and then press a letter key.

3. Sym (Symbol Key) To select the input method - Swype or Android keyboard.

4. @ To type “@”

5. Spac

e bar To type a blank space.

6. A-Z (alphanumeric keys) To enter numbers, letters or special characters. Go to the dial screen if pressed on the Home screen.

7. Delete (Delete Key) To delete a character. Press and hold it to delete the entire entry.

8. Return (Return key) To write in the new line or to select the item.

9. Na

vigation keys To move to left, right, up, down.

I O P

K L

M ؿ

ረ ف ሪ

Delete

Return

7 8

For best performance in low-light environments, your handset includes a backlight feature that can illuminate both the display and the

NOTE

keyboard so you can keep reading and typing.

Editing Text

You can select, copy, or cut the text you’ve entered, then paste it in another text eld within or across applications.

Some applications may oer their own way of selecting or copying text.

NOTE

Selecting text

You select text that you want to cut or copy.

1. Tap the text eld of the screen that contains the text to select.

2. Use the navigation keys on QWERTY keypad to move the cursor to the beginning or end of the text to select.

ħYou can also tap in the text eld to move the cursor in text.

3. Tap and hold the text eld.

4. Tap Select text in the menu that opens.

r tap Select all to select all the text in the text eld.

ħO

5. U

se the navigation keys on QWERTY keypad to select the text you want. Selected text is highlighted in orange.

ħYou can also drag your nger to move the text cursor to a letter within the text that you want to select.

Cutting and copying text

1. Select the text to cut or copy it.

2. Tap and hold the selected text.

3. Tap Cut or Copy in the menu that opens.

ou tap Cut, the selected text is removed from the text eld. In this case, the text is stored in a temporary area on the

ħIf y

phone

, so that you can paste it into another text eld.

Pasting text

1. Cut or copy the text to paste.

2. Tap the text eld where you want to paste the text.

ħYou can paste text that you copied from one application into the text eld in any other application.

3. To move the cursor to the location where you want to paste the text.

4. Tap and hold the text eld.

5. Tap Paste in the menu that opens.

he text is inserted at the cursor. The text that you pasted also remains in a temporary area on the phone, so you can

ħT

paste that same text into another location.

Getting started

Google Account

You must sign into a Google Account to use Gmail, Google Talk, Google Calendar, and other Google Apps; to download applications from Android Market, to back up your settings to Google servers and to take advantage of other Google services on your phone.

Registering the account if you initially use the phone

1. Tap the android to begin.

2. Tap Begin after you are prompted to know about how to use your mobile phone. If you want to ignore it, tap Skip.

3. T

ap Next after you are prompted to know how to set up your mobile phone.

4. T

ap Sign in to register your Google account.

If y

ou don’t have a Google account, tap Create. And then you can create a new one.

ħ

. Enter your Google Account Username and Password > Tap Sign in.

o provide the your location information for using applications or data with Google’s location service, set your

ħ

preferences for Google’s location information and Tap Next. The Home screen appears. Now you can start to use your

phone

Once a Google account is registered, all your Contacts and gmail information from your Google account are

ħ

downloaded to your phone. Data of your Contacts, Gmail and Calendar will be synchronized between your phone and the registered Google account online.

To log into the Google account, network connection should be made beforehand.

Registering the account if you initially use Google’s services

If you don’t register a Google Account, you are prompted to sign in or to create a Google Account the rst time you start an application that requires one, such as Gmail or Market.

1. Tap Sign in to register your Google account.

ou don’t have a Google account, tap Create. And then you can create a new one.

If y

ħ

. Enter your Google Account Username and Password > Tap Sign in.

Creating a new Google account

1. Tap Create > Enter First name, Last name and Username > Tap Next.

2. Enter Type a password, Conﬁrm password > Tap Next.

assword strength : Minimum of 8 characters in length.

3. Select Security question and enter Answer, which will be useful if you happen to forget the password, and then enter a Secondary Email > Create.

4. Read thr

5. En

ough Google Terms of Service >Tap I agree, Next.

ter an letters shown on the screen > Tap Next > Tap ﬁnish.

Adding a Google account

1. From the Home Screen, tap Apps > Settings.

2. Tap

3. Tap Google > Tap Next.

4. T

5. En

ħ

Accounts & sync > Add account.

ap Sign in to register your Google account.

ter your Google Account Username and Password > Tap Sign in > ﬁnish.

If y

ou have no accounts registered or if you have several accounts, you can add an account.

If you add multiple accounts which have contact information, you can use a single contact by joining multiple contacts from all your Google Accounts.

Removing a Google account

1. From the Home Screen, tap Apps > Settings.

2. Tap

3. Select the account to be deleted > Tap Remove account > Remove account.

Accounts & sync.

t this time, all information on the contacts, emails and setting which are downloaded or synchronized from/with the

ħ

removed account will be deleted, too.

Getting to know the Home screen

When the device is in idle mode, you will see the home screen. You can add your favorite apps, shortcuts, folders and widgets so they’re always just taps away.

You can use up to seven extra screens. Slide your nger horizontally to the left or right and you’ll discover more space for adding icons, widgets, and more. Press

Home to return to the main Home screen (that is, the center home screen).

Previewing the Home screen

1. From the Home Screen, tap and hold Apps.

2. When you choose a desired Home screen, the screen moves to the selected Home screen.

Third Icon Menu

You can set and use three applications at most on the third icon from the left among four Dock menu, which are at the bottom of the Home Screen.

Using the Third icon menu

1. Swipe the third icon of the Home screen’s Dock menu lightly up/down/left/right.

You can check the icons of applications has been congured.

2. Tap the icon of the application you want to run.

You will be also able to see which application has been congured by holding down on the icon.

1. From the Home Screen, tap and hold Third icon menu on Dock menu(By default,

2. Three menu icons are displayed. You can select a desired menu by tapping it.

By default,

3. To go back to the original status, You can tap

Browser, Email , and Gallery are set.

. Or just press Back.

Browser is set).

Changing the Third icon menu

1. If you want to change the home screen menu, press Menu > Add > Third icon menu. Or just tap and hold on the Home screen >

2. Select up to three applications from the Applications list > tap OK.

Third icon menu.

Customizing the Home Screen

You can add Home screen menu, Shortcuts, Widgets, Folders and Wallpapers to any part of the Home screen. You can also change the wallpaper.

Adding an item to the Home screen

1. Open the Home screen where you want to add the item.

2. Press

3. In the menu that opens, tap the type of the item to add.

Home screen menu

Shortcuts

Widgets

Folders

Wallpapers

Menu > Add. Or just tap and hold an empty location on the Home screen.

In this menu, you can select up to three applications from the Applications menu and set them as Dock menu.

Shortcuts can cover such functions as Applications, Bookmark, Contact, Direct dial, Direct message, Directions & Navigation, Latitude, Music playlist, Settings and Gmail label.

With this application, you easily use such functions as Analog clock, AnalogClock, Bookmarks, Calendar, DigitalClock, DualClock, Facebook, Google Search, Home screen tips, Latitude, Mail, Market, Message, Music Player, News, News and Weather, Picture frame, Power Control, Rate Places, Twitter(large), Twitter(small), Weather and Youtube.

If you create a new folder, you can drag icons into the folder to arrange the icons. Or you can add All contacts, Bluetooth received, Contacts with phone numbers, Facebook phonebook, Polaris® Oce Recent Documents and Starred contacts folder to the Home screen.

You can choose one among Gallery, Live wallpaper or Wallpapers and change the background screen.

Moving an item on the Home screen

1. From the Home screen, tap and hold the item you want to move, until it vibrates. Don’t lift your nger.

2. Drag the item to a new location on the Home screen.

3. Lift your nger on the location where you want to put the item.

From the Home screen, tap Apps and move an item from the Launcher to the Home screen in the same way.

Removing an item from the Home screen

1. From the Home screen, tap and hold the item you want to remove, until it vibrates. Don’t lift your nger. The Dock menu changes into the

2. Drag the item to the

3. When the icon turns red, lift your nger.

Changing the Home screen Wallpaper

1. From the Home screen, press Menu > Wallpaper. Or just tap and hold an empty location on the Home screen >

Wallpapers.

2. Tap one of the following:

Gallery

Live wallpapers

Wallpapers

3. Tap Save or Set wallpaper.

Select Gallery or Polaris® Oce. Choose a photo that you have taken using the camera or copied to your microSD card. You can crop the picture before setting it as a wallpaper.

Choose from preset animated wallpapers.

Choose a present wallpaper.

Renaming a folder

1. Tap the folder to open it.

2. Tap and hold the title bar of the folder window.

3. Enter a new name in the dialog box that appears, and then tap OK.

Essential Display Indications

Status icons

You can tell a lot about your phone by checking the icons in its status bar. Here’s what each one means:

Signal strength

No signal

Airplane mode

GPRS Disconnected

GPRS connected

GPRS in use

EDGE Disconnected

EDGE connected

EDGE in use

UMTS Disconnected

UMTS connected

UMTS in use

HSDPA Disconnected

Wi-Fi is o

Connected to a Wi-Fi network

TTY connected

Battery is full

Battery is charging

Battery is low (20% remaining)

Battery is very low (10% remaining)

No battery

Unknown battery

Silent mode

Vibrate mode

Speakerphone is on

Wired microphone headset connected

HSDPA connected

HSDPA in use

Data synchronizing

The phone fails to be synchronized

Bluetooth is on

GPS is on

Tethering or hotspot in action

Notiﬁcation icons

Notication icons on the status bar make it easy for you to keep on top of your messages, calendar events and alarms. Here’s what each one means:

Call in progress Uploading data (animated)

Call using a Bluetooth headset

Call on hold USB debugging connected

Call is being forwarded SIM card connected

Missed call No SIM card installed

Connected to a computer via USB cable

Storage card is low on free space

More (not displayed) notications

Network sharing is on Connected to a Bluetooth device

New Google Talk instant message

New voicemail Wi-Fi is on and wireless networks are available

Downloading data (animated) Noise Suppression

General notication

External SIM card is being prepared

ECB mode

Microphone is mute

Alarm is set

Notifications Panel

When you get a new notication, you can open the Notications panel to see the message, reminder or event notication.

Opening the Notiﬁcations panel

1. Tap and hold the status bar, and then slide your nger downward to open the Notications panel.

If you get several notications, you can scroll down the screen to see them all.

Responding to a notiﬁcation

1. Open the Notications panel.

2. Your current notications are listed in the panel. Each notication has a brief description.

3. Tap a notication to respond to it.

Closing the Notiﬁcations panel

Drag the bar at the lower part of the Notications panel to upward. Or just press Back.

Opening and Switching Applications

The Launcher, which you open from the Home screen, holds icons for all of the applications on your phone, including any applications that you downloaded and installed from Android Market or other sources.

Opening and closing the Launcher

1. From the Home screen, tap Apps.

2. Press

Home or Back to close the Launcher.

Switching to a recently used application

1. From the Home screen, press and hold Home.

2. Tap the icon to open its application.

3. Press

Back to return to the current application.

Sleep mode

Sleep mode saves battery power by putting your phone into a low power state while the display is o. You’ll still receive messages and calls though.

Switching to Sleep mode

Press Power/Lock to turn o the display and switch your phone to Sleep mode.

Or, your phone is automatically switched to Sleep mode if you don’t use it for a while. To set screen timeout, from the Home screen, tap

Waking up from Sleep mode

Your phone automatically wakes up when you have an incoming call. To wake it up manually, press Power/Lock. You’ll need to unlock the screen.

Unlocking the screen

On the lock screen, tap the unlock icon and slide your nger to the right to unlock the screen or answer an incoming call.

NOTE

Unlocking your screen with unlock security

Apps > Settings > Display > Screen timeout.

If you have set up a screen unlock pattern, pin, or password, you will be asked to draw the pattern on the screen or enter the PIN or password before it

is unlocked.

1. From the Home screen, tap Apps > Settings. Or press Menu > Settings.

2. Tap

3. T

Location & security > Set up screen lock.

If you have already congured the screen lock, tap Change screen lock to change how to lock or unlock your screen.

ap Pattern, PIN, or Password. And then, enter the pattern, PIN or password according as you select.

ou select ‘None’, screen unlock security is cancelled.

If y

+ 98 hidden pages
