Sharp MXEB13 User Manual

When this indicator is blinking slowly, the adaptor is not communicating or no connection is established.

LED1

LED2

MX-EB13 WIRELESS LAN USB ADAPTER DATA SHEET

PART NAMES AND FUNCTIONS

Wireless LAN USB Adapter

LED indicator 1
When this indicator is blinking, the adaptor is communicating.

LED indicator 2
When this indicator is lit, a connection is established.
When this indicator is blinking fast, the wireless setting is enabled or no connection is established.
When this indicator is blinking slowly, the wireless setting is disabled.

ADAPTOR SPECIFICATIONS

Model
Type
Standards

Wireless LAN USB Adapter

MX-EB13

IEEE 802.11n/g/b

11n: 6.5/13/19.5/26/39/52/58.5/65Mbps (20MHz BW, Long Guard interval)

7.2/14.4/21.7/28.9/43.3/57.8/65/72.2Mbps (20MHz BW, Short Guard interval)

Wireless Signal Rates With
Automatic Fallback

Wireless Frequency Range
Protocol
Channel Number

Receiver sensitivity

Spread Spectrum Method

Power
Wireless Transmit Power

Security

Bus Interface
Antenna Integrated internal antenna
Emissions CE,FCC,IC
Package Content Wireless LAN Adapter , Manual
Dimensions (W x D x H) 22.5x64x9.6mm
Weight Approx.11g

13.5/27/40.5/54/81/108/121.5/135Mbps (40MHz BW, Long Guard interval)
15/30/45/60/90/120/135/150Mbps (40MHz BW, Short Guard interval)
11g: 6/9/12/18/24/36/48/54Mbps
11b: 1/2/5.5/11Mbps

2.400GHz to 2.483.5GHz
TCP/IP
Ch1-11

54M: -74dBm(typ) -65dBm(max)
11M: -90dBm(typ) -76dBm(max)
6M: -91dBm(typ) -82dBm(max)

1M: -95dBm(typ) -80dBm(max)
MCS 0(20MHz):-89dBm(typ) -80dBm(max)
MCS 7(20MHz):-70dBm(typ) -63dBm(max)
MCS 0(40MHz):-87dBm(typ) -77dBm(max)
MCS 7(40MHz):-68dBm(typ) -59dBm(max)

Orthogonal Frequency Division Multiplexing (OFDM)

(64QAM,16QAM,DQPSK,DBPSK)

Direct Sequence Spread Spectrum(DSSS)

(CCK,DQPSK,DBPSK)

5V Bus powers

Max. 19dBm

WPA2-PSK(AES),WPA2-EAP(AES),WPA-PSK(TKIP/AES)

WPA-EAP(TKIP/AES),WEP(128/64bit)

USB 2.0

For Users in the USA

For Users in Canada

This device complies with Part15 of FCC Rules . Operation is subject to the following two conditions:
(1) This device may not cause harmful interference ,and
(2) this device must accept any interference received, including interference that may cause undesired operation.

This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.

WARNING:

FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved
by the manufacturer could void the user's authority to operate this equipment.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets
RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated
keeping the radiator at least 20cm or more away from person’s body(excluding extremities: hands ,wrists ,feet
and ankles).

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 . This equipment should be
installed and operated keeping the radiator at least 20cm or more away from person’s body (excluding
extremities: hands ,wrists ,feet and ankles).

This device complies with industry Canada licence -exempt RSS standard(s). Operation is subject to the following
two conditions:
(1) this device may not cause interference ,and
(2) this device must accept any interference, including interference that may cause undesired operation of this
device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.

Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC.
Cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le dispositif rayonnant
et le corps (à l’exception des extrémités : mains, poignets, pieds et chevilles).

MX-EB13

WIRELESS

LAN

USB

ADAPTER

SAFETY G

UIDE

Notice for Users in Europe / Hinweis für Benutzer in Europa / Avis pour nos utilisateurs
en Europe / Opmerking voor gebruikers in Europa / Avviso per gli utenti europei / Aviso
para usuarios de Europa / Bemærkning til brugere i Europa / Huomautus Euroopassa
oleville käyttäjille / Bemerkning til brukere i Europa / Anvisningar för användare i
Europa

Hereby, SHARP Electronics (Europe) GmbH declares that this Wireless LAN USB Adapter MX-EB13 is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Par la présente, SHARP Electronics (Europe) GmbH déclare que l’appareil Wireless LAN USB Adapter MX-EB13 est
conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.

Hiermit erklärt SHARP Electronics (Europe) GmbH, dass sich das Gerät Wireless LAN USB Adapter MX-EB13 in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der
Richtlinie 1999/5/EG befindet.

С настоящето SHARP Electronics (Europe) GmbH декларира, че Wireless LAN USB Adapter MX-EB13 отговаря
на съществените изисквания и другите приложими изисквания на Директива 1999/5/ЕС.

SHARP Electronics (Europe) GmbH tímto prohlašuje, že Wireless LAN USB Adapter MX-EB13 splňuje základní
požadavky a všechna přísluöná ustanoveni Směrnice 1999/5/ES.

Undertegnede SHARP Electronics (Europe) GmbH erklærer herved, at følgende udstyr Wireless LAN USB Adapter MX-EB13
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.

Käesolevaga kinnitab SHARP Electronics (Europe) GmbH seadme Wireless LAN USB Adapter MX-EB13 vastavust
direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ SHARP Electronics (Europe) GmbH ∆ΗΛΩΝΕΙ ΟΤΙ Wireless LAN USB Adapter MX-EB13
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ.

Por la presente, SHARP Electronics (Europe) GmbH, declara que este Wireless LAN USB Adapter MX-EB13 cumple
con los requisitos esenciales y otras exigencias relevantes de la Directiva 1999/5/EC.

SHARP Electronics (Europe) GmbH vakuuttaa täten että Wireless LAN USB Adapter MX-EB13 tyyppinen laite on
direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Con la presente SHARP Electronics (Europe) GmbH dichiara che questo Wireless LAN USB Adapter MX-EB13 è
con-forme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.

Alulírott, SHARP Electronics (Europe) GmbH nyilatkozom, hogy a Wireless LAN USB Adapter MX-EB13 megfelel a
vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.

Ar šo SHARP Electronics (Europe) GmbH deklarē, ka Wireless LAN USB Adapter MX-EB13 atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.

Šiuo SHARP Electronics (Europe) GmbH deklaruoja, kad šis Wireless LAN USB Adapter MX-EB13 atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.

Hierbij verklaart SHARP Electronics (Europe) GmbH dat het toestel Wireless LAN USB Adapter MX-EB13 in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.

SHARP Electronics (Europe) GmbH erklærer herved at utstyret Wireless LAN USB Adapter MX-EB13 er i samsvar
med de grunnleggende krav og øvrige relevante krav i direktiv 1999/5/EF.

Niniejszym SHARP Electronics (Europe) GmbH deklaruje że Wireless LAN USB Adapter MX-EB13 jest zgodny z
zasadniczymi wymaganiami i innymi właściwymi postanowieniami Dyrektywy 1999/5/EC.

Prin prezenta, SHARP Electronics (Europe) GmbH, declară că aparatul Wireless LAN USB Adapter MX-EB13 este în
conformitate cu cerinţele esenţiale şi cu alte prevederi pertinente ale Directivei 1999/5/CE.

SHARP Electronics (Europe) GmbH týmto vyhlasuje, že Wireless LAN USB Adapter MX-EB13 spíňa základné
požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES.

SHARP Electronics (Europe) GmbH izjavlja, da je ta Wireless LAN USB Adapter MX-EB13 v skladu z bistvenimi
zahtevami in drugimi relevantnimi dolo.ili direktive 1999/5/ES.

Härmed intygar SHARP Electronics (Europe) GmbH att denna Wireless LAN USB Adapter MX-EB13 står Iöverensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

For Use in Europe

NC18000-0061
