<P=001>
MINIDISC DECK
MODEL
MD-R1HMKII
OPERATION MANUAL
Thank you for purchasing this SHARP product.
CONTENTS
Page
SPECIAL NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
NAMES OF CONTROLS AND INDICATORS . . . . . . . . . 3
REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7
SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9
PLAYING A MINIDISC . . . . . . . . . . . . . . . . . . . . . . 10 - 14
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 19
EDITING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 - 30
HOW TO USE THE BUILT-IN TIMER . . . . . . . . . . 31 - 33
MINIDISC SYSTEM LIMITATIONS . . . . . . . . . . . . . . . . . .33
WHAT IS A MINIDISC? . . . . . . . . . . . . . . . . . . . . . 34 - 35
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . 35 - 37
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
ACCESSORIES
“AA” size battery
Remote control × 1
Note:
Parts and equipment mentioned in this operation manual other than those shown above are not included.
(UM/SUM-3, R6, HP-7
or similar) × 2
(for remote control)
Analogue connecting
cable × 2
Page
TINSE0211AWZZ
SM
<P=001>
SPECIAL NOTES
NOTE FOR USERS IN THE U.K.
The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should the
fuse need to be replaced, a BSI or ASTA approved BS
1362 fuse marked or and of the same rating as
above, which is also indicated on the pin face of the plug
must be used.
Always refit the fuse cover after replacing the fuse. Never
use the plug with out the fuse cover fitted.
In the unlikely event of the socket outlet in your home
not being compatible with the plug supplied, cut-off the
mains pl ug and fit an appropri ate type.
DANGER:
The fuse from the cut-off plug should be removed and
the cut-off plug destroyed immediately and disposed of
in a sa fe manner.
Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket outlet as a serious
electric shock may occur.
To fit an appropriate plug to the mains lead, follow the
instructions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance
with the fol lowing code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this
product may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
● The wire which is coloured blue must be connected to
the plug terminal which is marked N or coloured black.
● The wire which is coloured brown must be connected
to the plug terminal which is marked L or coloured red.
Ensure that neither the brown nor the blue wire is connected to the earth terminal in your three pin plug.
Before replacing the plug cover, make sure that:
● If the new fitted plug contains a fuse, its value is the
same as that removed from the cut-off plug.
● The cord grip is clamped over the sheath of the mains
lead and not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED
ELECTRICIAN.
SERVICE INFORMATION
In the unlikely event of your equipment requiring repair,
please contact the dealer or supplier from whom it was
purchased. Where this is not possible, please contact the
telephone number listed below. You will then be given
details of how to obtain service.
- 0345-125387 -
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may be ob-
tained from our main parts distributor.
WILLOW VALE ELECTRONICS LTD.
MANCHESTER 0161-682-1415
READING 01734-876444
In the unlikely event of this equipment requiring repair
during the guarantee period, you will need to provide
proof of the date of purchase to the repairing company.
Please keep your invoice or receipt, which is supplied at
the time of purchase.
● Recording and playback of any material may require
consent, which SHARP is unable to give. Please refer
particularly to the provisions of the Copyright Act 1956,
the Dramatic and Musical Performers Protection Act
1958, the Performers Protection Acts 1963 and 1972 and
to any subsequent statutory enactments and orders.
● This equipment complies with the requirements of
Directives 89/336/EEC and 73/23/EEC as amended by
93/68/EEC.
● When the ON/STAND-BY button is set at STAND-BY
position mains voltage is still present inside the unit.
When the ON/STAND-BY button is set at STAND-BY
position and the clock is displayed, the unit may be
brought into operation by use of (timer mode or) remote
control.
Warning:
This unit contains no user serviceable parts. Never remove
covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug from the socket
before any service operation and when not in use for a long
period.
US and foreign patents licensed from Dolby Laboratories
●
Licensing Corporation.
TINSE0211AWZZ
Caution:
Use the minidisc deck only in accordance with the instructions given in this manual and do not attempt to interfere
with the interlock switch or make any other adjustment as
this may result in exposure to hazardous radiation.
1
FEATURES
Recordings start automatically when the external sound
source starts to produce sound.
Comes with a sound synchro recording function, which allows
the unit to automatically begin recording when the external
equipment starts playing back. Lets you make MiniDisc recordings easily.
DAT tapes can be digitally recorded direc tly onto
a MiniDisc.
The MiniDisc unit has a built-in sampling rate convertor
which allows the unit to be connected to various types of
digital equipment. You can record from a large variety of
digital formats.
The recording time is doubled if you record in the monaural mode.
Comes with a monaural long-recording mode which doubles
the recording time. Best suited for recording monaural broadcasts or talk programmes.
PRECAUTIONS
■ General
● Do not use oil, solvents, petrol, paint thinners or
insecticides on the unit.
● Do not expose the unit to moisture, to temperatures
higher than 60oC (140oF) or to extreme low temperatures.
● Keep the unit away from direct sunlight, strong magnetic
fields, excessive dust, humidity and electronic/electrical
equipment (home computers, facsimiles, etc.) which
generates electrical noise.
● Hold the AC power plug by the head when removing it
from the AC socket, since pulling the lead can damage
internal wires.
● Never open the cabinet. If a foreign object drops into the
set, contact your dealer.
● Use the unit on a firm, level surface free from vibration,
and do not place anything on the top of the unit.
● If the unit mulfunctions whilst in use, press the
ON/STAND-BY button to enter the stand-by mode, then
discon nect th e AC power lead f rom the AC so cket . Plug
the AC power lead back in, and then press the
ON/STAND-BY button to turn the power on.
● If a lightning storm is taking place near you, it is
suggested that you disconnect the AC power lead from
the AC socket for safety.
Warning:
The voltage used must be the same as that specified on
this unit. Using this product with a higher voltage than that
which is specified is dangerous and may result in a fire or
other type of accident causing damage. SHARP will not be
held responsible for any damage resulting from use of this
unit with a voltage other than that which is specified.
Supports various types of digital/analogue equipment
Two digital input sockets and two analogue input sockets
are built in. They allow the unit to be connected to stereos
or headphone stereos.
Track selection with a jog dial
A jog dial makes it much easier to control the MD unit. It is
easy to select track numbers or enter characters.
Timer function/date stamp function
If the unit is used with other equipment that also has a timer
function, timer recording and timer playback are possible.
Also, the year, month, day, and time are automatically recorded on the MiniDisc.
■ Installation location
Do not install the unit in the following places.
Otherwise, it may cause trouble or accidents.
Places exposed to vibration
Places exposed to direct sunlight for many hours
● Places exposed to high humidity.
● Places exposed to excessive dust.
● Poorly ventilated places.
● Places exposed to water, for example, a bathroom.
● Places near objects which generate magnetism or
electric noise.
Hot places
Extremely cold places
■ Condensation
In the following cases, condensation (water droplets) may
form inside of the unit (optical section).
● Just after lighting a gas stove.
● When the unit is put in a room where steam or moisture
is present.
● When the unit is carried from a cool place (room) to a
warm room.
2
TINSE0211AWZZ
NAMES OF CONTROLS AND INDICATORS
■ Front panel
12345 6 7
11
12
13
MONO LP PRGM RANDOM
14 1516 1817 19 20
25
26
SAMPLING RATE CONVERTER
REMOTE
SENSOR
27
PHONES
28
1. TOC Ind icator: TOC
2. Total Ti me Indicator
3. Disc Name Indicator
4. Track N ame Indica tor
5. Date Indicator
6. Level Meter/Character Information Display
7. Recording Level Indicator
8. Recordin g Level Too High Indicator
9. Music Calendar
10. More Tracks Indicator
11. Pause Indicator:
12. Record Indicator: ●
13. Play Indicator:
14. Monaural Long-Play Mode Indicator
15. Programme Indicator
6
0
TOC
TRACK
TOTAL
REMAIN
12
DATE
AM
TIMER REC CLOCK
PM
4 0dB OVERDISC
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
21 22 23 24
INPUT SELECTON/STAND-BY
MINI DISC
REC LEVEL
MIN MAX
CLOCK/ TIMER
NAME•
TOC EDIT
TIMER/
DELETE
DISPLAY/
CHARACTER
353433
16. Repeat Indicator:
17. Remaining Time Indicator
18. Random Play Indicator
19. Timer Playback/Timer Recording Indicator
20. Clock Indicator
21. Input Select Button
22. Eject Button:
23. Stop Button: ■
24. Play/Pause Button:
25. On/Stand-by Button
26. Record Level Control
27. Remote Sensor
28. Headphone Socket
29. Record Button: ●
30. Cue/Review Button: 3 /
31. Enter Button
32. Jog Dial (Next/Previous)
R
33. Name • TOC Edit Button
34. Timer/Delete Button
35. Display/Character Button
7
06
2
8
14
9
10
RECORD
29
30
ENTER
31
32
■ Rear panel
1
DIGITAL
OPTICAL COAXIAL
OUT IN IN
ANALOG
LINE OUT LINE IN
L
R
L
R
PHONES
LEVEL
MIN MAX
23 45
3
TINSE0211AWZZ
RESET
6
1. AC Power Lead
2. Optical Input/Output Sockets
(Digital)
3. Coaxial Input Socket
(Digital)
4. Line Input/Output Sockets
(Analogue)
5. Headphones level control
6. Reset Button
REMOTE CONTROL
1
2
3
4
5
6
7
8
9
10
11
1
12
13
14
15
16
17
18
19
■ Names of controls
1. Remote Control Transmitter Window
2. Direct Key Buttons
3. Play Mode Button
4. Music Scan Button
5. Input Select Button
6. Display Button
7. Time Button
8. Auto Mark Button
9. Track Down/Review Button: 5 /
10. Track Up/Cue Button: 4 /
11. On/Stand-by Button
12. Programme Button
13. Clear Button
14. Sy nchro Record Button: ●
15. R ecord Cancel Button
16. R ecord Mode Bu tton
17. R ecord Button: ●
18. Pl ay/Pause Button:
19. Stop Button: ■
06
3
2
■ Loading the batteries for the remote control
1 Remove the battery compartment cover.
2
3
0.2 - 6m (8" - 20')
15
15
2 Insert 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar)
into the battery compartment.
● When inserting the batteries, push them towards the – battery
terminals.
● Placing the batteries the wrong way round may cause the unit
to malfunction.
3 Replace the battery compartment cover.
Battery removal:
● Push the batteries towards the – battery terminals and remove
them.
Precautions for battery use:
● Insert the batteries according to the direction indicated in the
battery compartment.
● Replace all batteries with new ones at the same time.
● Remove the batteries if weak or if the unit is not in use for
long periods to prevent potential damage due to battery
leakage.
● Do not mix old and new batteries.
Caution:
Do not use rechargeable batteries (nickel cadmium battery, etc.).
■ Proper use of the remote control
Aim the remote control at the remote control sensor within 30
with no obstacles, and operate as shown.
Notes concerning use:
● Replace the batteries if the control distance decreases or
operation becomes erratic.
● Periodically clean the transmitter window on the remote
control and the sensor on the main unit with a soft cloth.
● Exposing the sensor on the main unit to strong light may
interfere with operation. Change the lighting or the direction
of the unit.
● Keep the remote control away from moisture, excessive heat,
shock, and vibrations.
● The remote control’s usable range is between 0.2 m (8") and
6 m (20’) away from the sensor.
o
4
TINSE0211AWZZ
CONNECTIONS
■ Digital and analogue connections
This unit can be connected to your equipment by making a digital or analogue connection.
● When recording the playback signals from other equipment using this unit
Digital connection
Digital equipment with an optical output
socket or a coaxial output socket
Stereo system, CD player, MD player, MD recorder,
DAT, DSS tuner etc.
Equipment with line output sockets or a
headphone socket
CD player, headphone stereo, radio cassette player,
stereo system, video, etc.
Analogue connection
Can be recorded with high fidelity, without
converting the original digital signals.
● When listening to a recording on this unit or recording its output on other equipment
Digital connection
Digital equipment with an optical input socket
Stereo system, MD recorder, DAT, etc.
Can be played back or recorded from with
high fidelity, without converting the original
digital signals.
● Depending on the digital equipment, the sampling frequency may be different (DAT etc.) from this unit’s sampling
frequency. This unit supports these digital devices using an automatic switching function (Sampling rate converter: 32
kHz, 48 kHz → 44.1 kHz automatically switched).
Digital signals, such as those from a CD
player, can be recorded as analogue signals.
Analogue connection
Equipment with line input sockets
Stereo system, radio cassette recorder, video, etc.
Played back or recorded from with analogue
signals.
■ About the connecting cables
The type of cables required to make connections depends on the type of signal (digital/analogue) and input/output sockets
on the equipment being connected to the MD recorder.
Check the shape of the sockets carefully before making connections.
Sockets to be connected
Digital connection
Square plug
Cables used Sockets on this unit
Square plug
Optical input/output,
digital input/output, etc.
Optical input/output,
digital input/output, etc.
Digital output etc.
Analogue connection
LR
Line input/output,
AUX input/output, etc.
PHONES
Headphones etc.
Model: AD-M3DC
(available separately)
Round plug
Square plug
Model: AD-M1DC
(available separately)
Yellow
Pin plug
Yellow
Pin plug
Commercially available video coaxial cable
Pin plug
Pin plug
Connecting cable included with this unit
Stereo mini-plug
Pin plug
Commercially available audio
connecting cable
5
TINSE0211AWZZ
OPTICAL
OPTICAL
OUT IN
COAXIAL
COAXIAL
IN
LINE OUT LINE IN
L
R
L
R
(Continued)
■ When making a digital connection
When connecting the unit to equipment
that has square/round optical sockets:
Connect the other equipment to the “OPTICAL
sockets” on the back of this main unit.
To the optical
output socket
AD-M3DC
MD/CD player, etc.
AD-M1DC
When it’s
a round
optical
socket
OPTICAL
OUT IN
When connecting
this unit to a
recorder/player
When connecting this unit to
other equipment for playback
To the optical
output socket
■ When making an analogue connection
When connecting the unit to equipment
that has line sockets:
Connect the other equipment to the “ANALOG
sockets” on the back of this main unit.
ANALOG
LINE OUT LINE IN
Connecting cable
included with this unit
To the line
input (left) socket
L
R
L
R
Connecting cable
included with this unit
To the line
output (left) socket
To the optical
input socket
Stereo, DAT, MD recorder, etc.
with an optical input/output socket
● If this unit is connected to a stereo, the digital audio
section of a CD (or other digital source) can be
recorded. When recording from a cassette tape, radio
broadcast, etc. an analogue connection is required.
When connecting this unit to equipment
that has a coaxial socket:
Connect the other equipment to the “COAXIAL
socket” on the back of this main unit.
● The coaxial connection is only an input to this unit.
COAXIAL
IN
Commercially available
video coaxial cable
To the line
input (right) socket
Stereo, radio cassette
player, etc. with line
input/output sockets
To the line
output (right) socket
When connecting this unit to equipment
that only has a headphone socket:
Connect the other equipment to the "LINE IN
sockets" on the back of this main unit.
LINE IN
L
R
Commercially
available audio
connecting cable
To the digital
output socket
6
TINSE0211AWZZ
To the headphone
socket
Headphone stereo, radio
cassette player, CD player, etc.
(Continued)
■ Connecting the AC power lead
AC 230 V, 50 Hz
To an AC socket
■ How to turn the power on or off
If you will not be using this unit for a prolonged period of
time, unplug the AC power lead from the AC socket. Even
when the power is turned off, a small amount of current is
still consumed.
ON/STAND-BY
Press the or button.
ON/
STAND-BY
● When the power is turned on, the display will change.
● Press it again to enter the stand-by mode.
■ How to read the display
Various messages, describing the operations and contents
of MiniDiscs are displayed in the display section.
Indicators of the playback
and recording operations
Area where track names and disc names
are displayed.
During playback it becomes a level meter.
TOC
TOTAL
MONO LP PRGM RANDOM
Display related to
playback
Display related to
recording
REMAIN
12
TIMER REC CLOCK
4 0dB OVERDISC TRACK DATE
1 2 3 4 5 6 7
AM
8 9 10 11 12 13
PM
15 16 17 18 19 20
Area where playing time,
track numbers and the time
are displayed
Display related to the timer
Music calendar
Shows the number of
tracks recorded on an
MD.
14
■ Jog Dial
CLOCK
To change the brightness of the display
Turn the power on and hold down the DISPLAY/CHARACTER (DISPLAY) button for at least two seconds.
DISPLAY/CHARACTER
● The "DIMMER ON" display will appear, and the display
will become dimmer.
To return to the original brightness, hold down the DISPLAY/CHARACTER (DISPLAY) button for at least two seconds.
DISPLAY/CHARACTER
● The "DIMMER OFF" display will appear, and the original
brightness will be restored.
DISPLAY
DISPLAY
The jog dial on the main unit can be used to select track numbers (page 11) or to select characters (page 26).
Jog dial
Track
number
REMAIN
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
The track
number decreases.
● When the jog dial is turned gently, it will stop at 30˚ angle
steps. This has the same effect as pressing the 5 /
4
button on the remote control. (Track up/down)
● When the jog dial is turned continuously, it has the same
effect as pushing the 5 / 4 button on the remote
Track
number
The track
number increases.
REMAIN
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
control repeatedly. (Track up/down)
7
TINSE0211AWZZ
14
14
SETTING THE CLOCK
1
When recording, the date and time are recorded on the Minidisc,
provided they have been set (page 15).
■ Setting the date
1 Press the ON/STAND-BY button to turn the power on and
press the TIMER/DELETE button.
2 Within 10 seconds, turn the jog dial until “TIME ADJUST”
appears.
3 Within 10 seconds, press the ENTER button.
● The unit will enter the date setting mode.
4 Set the “year” using the jog dial.
2
3
4
5
6
CLOCK
DATE
CLOCK
Date setting mode
Each time the button is pressed,
the display will change.
● When you turn the jog dial one step, the year will change up
or down by one.
● The year 2000 or later is set as follows:
[00] indicates the year 2000
[01] indicates the year 2001
● The range of dates that can be entered is from January 1,
1998 to December 31, 2099.
5 Press the ENTER button to set the “year”.
6 Set the “month” repeating steps 4 and 5.
7 Set the “day” repeating steps 4 and 5.
● The unit will enter the time setting mode.
7
CLOCK
Time setting mode
8
TINSE0211AWZZ
(Continued)
■Setting the time
After step 7, described in the “Setting the date” section
8 Set the “hour” using the jog dial.
● When you turn the jog dial one step, the hour will change
up or down by one. When you turn and hold it, the hour will
change continuously.
● The clock uses the 24-hour system.
9 Press the ENTER button to set the “hour”.
10Adjust the “minute” using the jog dial.
8
9
10
11
DATE
DATE
DATE
DATE
CLOCK
CLOCK
CLOCK
CLOCK
11Press the ENTER button to set the “minute”.
● When the ENTER button is pressed, the clock will show the
correct time.
Checking the date and time
After pressing the TIMER/DELETE button, turn the jog dial until
the date and time are displayed.
Resetting the date and time
See “Setting the clock”.
● Once you have set the date and time, “TIME ADJUST” will
not be displayed in step 2. Turn the jog dial to make the date
and time appear.
● If you do not need to change the settings, just press the
ENTER button without turning the jog dial again.
9
TINSE0211AWZZ
PLAYING A MINIDISC
■Playback
1 Switch the external unit to the MD unit input.
2 Load a MiniDisc in the direction indicated by the arrow on the
MiniDisc, with the label side facing up.
(Insert the MiniDisc firmly, until a click is heard.)
DISPLAY
TIME
When a MiniDisc has not been given a track
name, the level meter will be displayed.
When it has been given a track name, the
track name will be displayed.
Playback
display
PAUSE indicator The elapsed playing
Track
name
Number of
recorded tracks
time for the track is
displayed.
when a track name has
not been programmed,
“NO NAME” will appear.
Remaining
recording time
TRACK DATE
Date and time recorded
12
PM
4 0dB OVER
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
3 Press the
06
button to start playback.
● The “0” indicator will light up.
● When the last track has been played back, this unit will stop
automatically.
● To stop playback before the last track has finished playing,
press the ■ button.
To remove a MiniDisc:
Press the 7 button.
● The MiniDisc will be ejected.
● If a MiniDisc has been left in the unit for several hours, when
it is removed it will be warm to the touch. This is normal.
To interrupt playback:
Press the 06 button during playback.
● To resume playback, press the 06 button again.
14
To check a track name or the date of a recording during playback:
Press the DISPLAY/CHARACTER (DISPLAY) button during playback or whilst the unit is in the pause mode.
● Each time this button is pressed, the display will switch.
● In the following cases, disc names, track names and recording
dates will not be displayed.
• A MiniDisc that has not been given a disc name or track name
• A MiniDisc that does not have a recording date on it
Level meter
Elapsed playing time
REMAIN
Remaining playing time
TOTAL
REMAIN
Total remaining playing time
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
1 2 3 4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
14
14
14
TINSE0211AWZZ
To check the playing time during playback:
(Remote control operation)
Press the TIME button on the remote control during playback or
whilst the unit is in the pause mode.
● Each time this button is pressed, the display will switch.
Note:
● Although MiniDiscs will not normally skip due to vibration, you
may hear a skip in the sound if there is a continuous vibration.
When you listen to MiniDiscs near a radio or a TV set, the
radio or the TV set may pick up noise.
Keep the unit as far away as possible from tuners.
10
(Continued)
1234
5678
9 10/0 10
■Track number selection
(Remote control operation)
Specify a track number, and playback will start from that track.
To select a track number directly:
Press the desired DIRECT KEY button.
● Playback will start from the specified track.
■ To select any track number from the 11th track to 99th
track
After p ressing , ent er the track nu mber by press ing the
numbers on the keypad.
Example: 28th track
→
Selected track number
12
4 0dB OVER
4 5 6 7
8 9 10 11 12 13
15 16 17 18 19 20
14
■ To select any track number from the 100th track on
After pressing t wice, enter the track number by pressing
the numbers on the keypad.
Example: 105th track
→
● You cannot select any track number larger than the number
of tracks on a particular MiniDisc.
● When entering 2 or 3 digit track numbers, the buttons should
all be pressed within 5 seconds of each other.
Note:
● During APMS play or random play, track number selection
play is not possible.
■APSS (Auto Program Search System)
APSS automatically locates the beginning of each track.
To move to the beginning of the next track:
During playback ... Turn the jog dial clockwise.
Or press the 4 button on the remote control.
To restart the track being played:
During playback ... Turn the jog dial anti-clockwise.
Or press the 5 button on the remote control.
Whilst listening to the 5th track
TRACK
8 9 10 11 12 13
15 16 17 18 19 20
TRACK
8 9 10 11 12 13
15 16 17 18 19 20
5 6 7
When using the jog dial whilst in the stop mode:
Every time the jog dial is turned (or each time the 5 or
6 7
14
14
button on the remote control is pressed), the track number will
go up or down by one. If you press the 06 button, playback
will begin from the track being displayed.
4
11
TINSE0211AWZZ
Loading...
