Sharp MD-M3H User Manual

MD MICRO SYSTEM OPERATION MANUAL

MODEL

MD-M3H

Thank you for purchasing this SHARP product. To obtain the best performance from this product,

please read this manual carefully. It will guide you in operating your SHARP product.

MD-M3H MD micro system consisting of MD-M3H MD (Main unit) and CP-M3H (Speaker system).

CONTENTS

SPECIAL NOTES .............................................. 1

ACCESSORIES ................................................. 2

PRECAUTIONS ................................................. 2

NAMES OF CONTROLS AND INDICATORS

PREPARATION FOR USE.............................. 6-8

SETTING THE CLOCK ...................................... 9

SOUND CONTROL ......................................... 10

COMPACT DISC OPERATION ........................ 11

MINIDISC OPERATION ................................... 12

CONVENIENT CD AND MD OPERATIONS ....

RADIO OPERATION .................................. 16-17

RDS (Radio Data System) OPERATION ...

Page

.... 3-5

13-15 18-27

RECORDING .............................................. 28-31

Page

EDITING ..................................................... 32-38

TIMER OPERATION................................... 39-41

USING EXTERNAL UNITS ........................ 42-43

WHAT IS A MINIDISC? ................................... 44

MINIDISC SYSTEM LIMITATIONS.................. 45

TROUBLESHOOTING................................ 45-46

ERROR MESSAGES....................................... 47

RESETTING THE MICROCOMPUTER ........... 48

MAINTENANCE .............................................. 48

SPECIFICA TIONS ........................................... 49

TERMS OF GUARANTEE

Sharp Electronics (UK) Ltd. ("Sharp") guarantees to provide for the repair , or at its option the replacement, of this product subject to the conditions listed below:-

1. This guarantee shall only apply to faults which are due to inferior workmanship or materials. It does

not cover faults or damage caused b y accident, misuse, f air wear and tear , neglect, tampering with the product, or repair other than by a Service Facility appointed by Sharp.

2. As this product is intended for private domestic use only, the guarantee will not apply if the product

is used in the course of a business, trade or profession.

3. To benefit from this guarantee, any fault which occurs must be notified to Sharp, or its appointed

Service Facility within one year from the date this product was purchased. Proof of purchase must be provided.

4. The guarantee does not cover carriage costs, jewelled styli, audio tapes, compact discs or batter-

ies.

5. In the unlikely event of this product requiring repair, please contact the supplier from whom it was

purchased. Where this is not possible, please contact the Sharp Customer Information Centre on the telephone number given below.

6. No person has any authority to vary the terms or conditions of this guarantee.

7. This guarantee is offered as an additional benefit to your statutory rights, and does not affect these

rights in any way.

If you have any difficulty operating this product, or would like information on other Sharp products, please telephone the Sharp Customer Information Centre on the number given below.

TINSE0236AWZZ

Sharp Customer Information Centre - Telephone 0345 125387

SHARP ELECTRONICS (U.K.) LTD.

Sharp House, Thorp Road, Newton Heath, Manchester, M40 5BE

SHARP CORPORATION

A9903.YT

SPECIAL NOTES

NOTE FOR USERS IN THE U.K.

The mains lead of this product is fitted with a nonrewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked or and of the same rating as above, which is also indicated on the pin face of the plug must be used.

Always refit the fuse cover after replacing the fuse . Never use the plug without the fuse cover fitted.

In the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut-off the mains plug and fit an appropriate type.

DANGER:

The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of in a safe manner.

Under no circumstances should the cut-off plug be inserted else-where into a 13A socket outlet as a serious electric shock may occur.

T o fit an appropriate plug to the mains lead, f ollow the instructions below:

IMPORTANT:

The wires in the mains lead are coloured in accordance with the following code:

Blue : Neutral Brown : Live

As the colours of the wires in the mains lead of this product may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

● The wire which is coloured blue must be connected to the plug terminal which is marked N or coloured black.

● The wire which is coloured brown must be connected to the plug terminal which is marked L or coloured red.

Ensure that neither the brown nor the blue wire is connected to the earth terminal in your three pin plug.

Before replacing the plug cover, make sure that:

● If the new fitted plug contains a fuse, its value is the same as that removed from the cut-off plug.

● The cord grip is clamped over the sheath of the mains lead and not simply over the lead wires.

IF Y OU HAVE ANY DOUBT , CONSULT A QU ALIFIED ELECTRICIAN.

SERVICE INFORMATION

In the unlikely event of your equipment requiring repair, please contact the dealer or supplier from whom it was purchased. Where this is not possible, please contact the telephone number listed below.

Y ou will then be giv en details of how to obtain service.

Please note; all calls will be charged at local rate. Certain replacement parts and accessor ies may

be obtained from our main parts distributor.

WILLOW VALE ELECTRONICS LTD.

In the unlikely event of this equipment requiring repair during the guarantee period, you will need to provide proof of the date of purchase to the repairing company.

Please keep your invoice or receipt, which is supplied at the time of purchase.

- 0345-125387 -

MANCHESTER0161-682-1415 READING 01189-876444

● Recording and playback of any material may require consent, which SHARP is unable to give. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the P erformers Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders.

● This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC.

● When the ON/ST AND-BY button is set at STANDBY position, mains voltage is still present inside the unit. When the ON/ST AND-BY button is set at STANDBY position, the unit may be brought into operation by the timer mode or remote control.

Warning:

This unit contains no user serviceable parts. Never remove covers unless qualified to do so. This unit contains dangerous voltages, alwa ys remove mains plug from the socket before any service operation and when not in use for a long period.

CAUTION

Use the MD micro system only in accordance with the instructions given in this manual and do not at-

tempt to interfere with the interlock switch or make

ACCESSORIES

cushion

Speaker

Remote control × 1

"AA" size battery (UM/SUM-3, R6, HP-7 or similar) × 2

AC power lead × 1

AM loop

Note:

Parts and accessories mentioned in this operation manual other than those in the drawing are not included.

aerial × 1

FM aerial × 1

Speaker wire × 2

PRECAUTIONS

■ General

● Please ensure that the equipment is positioned

in a well ventilated area and ensure that there is at least 10cm (4") of free space along the sides and back. There must also be a minimum of 20cm (8") of free space on the top of the unit.

● Do not use oil, solvents, petrol, paint thinners or insecticides on the unit.

● Do not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to extreme low temperatures.

● Keep the unit away from direct sunlight, strong magnetic fields, excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generates electrical noise.

● Hold the AC power plug by the head when removing it from the AC socket, since pulling the lead can damage internal wires.

● Do not remove the outer cover, as this may result in electric shock. Refer internal service to your local SHARP service facility.

● Use the unit on a firm, level surface free from vibration, and do not place anything on the top of the unit.

● If the unit malfunctions whilst in use, press the ON/STAND-BY button to enter the stand-by mode, then disconnect the AC power lead from the AC socket. Plug the AC power lead back in, and then press the ON/ST AND-BY button to turn the power on.

● If an electrical storm is taking place near you, it is suggested that you disconnect the AC power lead from the AC socket for safety.

Warning:

The voltage used must be the same as that specified on this unit. Using this product with a higher voltage other than which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.

■ Volume control

The sound level at a giv en volume setting depends on a combination of speaker efficiency , location and various other factors.

It is advisable to avoid exposure to high volume levels, which occur whilst turning the unit on with the volume control setting up high, or whilst continually listening at high volumes.

■ Condensation

Sudden temperature changes, storage or operation in an extremely humid environment ma y cause condensation inside the cabinet (CD pickup, MD pickup, etc.) or on the transmitter LED on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc in the unit until normal playback is possible (about 1 hour). Wipe off any condensation on the transmitter LED with a soft cloth before operating the unit.

Warning:

CD players use a laser pickup which can damage the eyes if viewed directly. Do not look at the pickup, and do not touch the pickup directly.

NAMES OF CONTROLS AND INDICATORS

■ Front panel

1. Power On/stand-by Button

2. (MD) Display Button

1 2 3

11 12

13 14 15

4 5 6 7 8

16 17

18 19 20

21 22

23 24

3. Timer Stand-by Indicator

4. MD Compornent

5. (MD) Record Button

6. (CD/MD/TUNER) Memory Button

7. (CD/MD) Stop Button (TUNER) Tuning Down Button

8. (CD/MD) Play/Pause Button (TUNER) Tuning Up Button

9. Function Selector Buttons

10. CD Eject Button

11. (RDS) Programme Type/Traffic Information Search Button

12. (RDS) EON Button

13. (RDS) Auto Station Programme Memory Button

14. (RDS) Display Mode Button

15. (RDS) Station Selector Button

16. MD Eject Button

17. (CD/MD) Track Up/Cue Button (TUNER) Preset Up Button

18. (CD/MD) Track Down/Review Button (TUNER) Preset Down Button

19. CD 0MD Normal Speed Edit Button

20. CD 0MD High Speed Edit Button

21. Surround Button

22. Preset Equalizer Button

23. Extra Bass Button

24. Headphone Socket

25. Volume Control

5 6

■ Rear panel

1. Speaker Terminals

2. FM 75 Ohms Aerial Socket

3. AM Loop Aerial Socket

4. Auxiliary Input (Analogue) Level Control

5. Demo Switch

6. Auxiliary Input (Analogue) Sockets

7. AC Input Socket

(Continued)

L R

OVER

RDS

EON

TP TI PTYTA PTYI

REC PLAY

RECkHz

MHzSLEEP

AM PM

888 8888 88

DISC TOC

SURROUND

X-BASS

TRACK MEMORY RANDOM TOTAL REMAIN

SURROUND

X-BASS

DISC TOC

RDS

TRACK MEMORY RANDOM TOTAL REMAIN

EONTP TI PTYTAPTYI

8888888 88

3 4 5 6 7 8 9

16 17 18 19 20 21 22

27 28

10 11 12 13 14 15

AM PM

■ Display window

1. Level Meters

2. Character Information Display

OVER

REC OFF PLAY ON

RECkHz

MHzSLEEP

23 24

25 26

3. Surround Indicator

4. Extra Bass Indicator

5. FM Stereo Indicator

6. FM Stereo Mode Indicator

7. (CD/MD) Disc Indicator

8. (CD/MD) Trac k Indicator

9. (CD/MD/TUNER) Memory Indicator

10. (CD/MD) Repeat Indicator

11. (CD/MD) Play/Pause Indicator

12. (MD) TOC Indicator

13. (CD/MD) Random Play Indicator

14. (CD/MD) Total Indicator

15. (CD/MD) Remaining Time Indicator

16. RDS Indicator

17. (RDS) Traffic Programme Indicator

18. (RDS) Traffic Announcement Indicator

19. (RDS) EON Indicator

20. (RDS) Traffic Information Indicator

21. (RDS) Programme Type Indicator

22. (RDS) Dynamic PTY Indicator

23. Timer Record /Timer Play Indicator

24. CD Indicator

25. MD Indicator

26. (MD) Record Indicator

27. AM/PM Indicator

28. Sleep Indicator

■ Speaker section

1. Tweeter

2. Woofer

3. Speaker Grille

4. Bass Reflex Duct

5. Speaker Terminals

4 5

(Continued)

2 3 4

5 6

7 8

17 18 19

1514 16

11 12

■ Remote control

1. Remote Control Transmitter LED

2. (RDS) Programme Type/Traffic Information Search Button

3. (RDS) Station Selector Button

4. Clock Button

5. Surround Button

6. Timer Button

7. Name/TOC Edit Button

8. Sleep Button

9. (TUNER) Preset Up/Down Buttons

10. Extra Bass Button

11. Preset Equalizer Button

12. (MD) Display Button

13. Enter Button

14. Clear Button

15. Character Select Buttons

16. (CD/MD/TUNER) Memory Button

24 25

22 23

● MD/CD Section

17. (CD/MD) Time Display Button

18. (CD/MD) Play Mode Button

19. (CD/MD) Track Down/Review Button

20. (CD/MD) Track Up/Cue Button

21. (MD) Record Button

22. (CD/MD) Stop Button

23. (CD/MD) Play/Pause Button

24. Power On/stand-by Button

25. Dimmer Button

26. Function Selector Buttons

27. Volume Button

PREPARATION FOR USE

● Unplug the AC power lead from the A C socket

before connecting or disconnecting any component.

■ Aerial connection

External FM aerial

Supplied FM aerial

Connect the FM aerial wire to the FM 75 OHMS socket and position the FM aerial wire in the direction where the strongest signal can be received.

Supplied AM loop aerial

Connect the AM loop aerial wire to the AM ANTENNA socket. Position the AM loop aerial for optimum reception. Place the AM loop aerial on a shelf, etc., or attach it to a stand or a wall with screws (not supplied).

Notes:

● Do not place the aerial on the main unit as it may result in noise pickup from the internal digital electronics. Place the aerial away from the unit for better reception.

● If the AM loop aerial and the FM aerial wire are placed near the AC power lead, interference ma y result.

External FM aerial

Use an external FM aerial if you require better reception. Consult your dealer.

FM aerial

75 OHMS

AM LOOP

AM loop aerial

■ Speaker connection

Black

Left speaker

Red

Right speaker

Black

LEFT

RIGHT

RATESD SPEAKER

IMPEDANCE :

Red

4 OHMS MIN.

Connect each speaker wire to the SPEAKER terminals as shown. Use speakers with an impedance of 4 ohms or more, as lower impedance speakers can damage the unit.

Caution:

● Before connecting the speakers to the unit, connect the speaker wires to the speakers first. Then, connect the speaker wire to the terminals on the unit.

● Connect the speakers to the main unit, and then use the system. If any of the speak ers is not connected, the main unit or the speakers may malfunction or may be damaged.

Notes:

● Connect the black wire to the minus (–) terminal, and the red wire to the plus (+) terminal.

● Do not mix the right channel and left channel wiring when connecting the speakers to the unit.

● Do not let bare speaker wires touch each other as this may damage the amplifier and/or speakers.

(Continued)

■ Removing the speaker grilles ■ Connecting the AC power lead

1 Remove the lower part of the speaker grille first. 2 Remove the upper part of the speaker grille.

Caution:

When the speaker grilles are removed, the speaker diaphragms are exposed. Make sure nothing comes into contact with the speaker diaphragms.

■ Speaker cushion

Attach the cushions to the bottom of the speaker to prevent it from sliding.

■ Placing the system

10 cm (4")

AC INPUT

To AC INPUT

Connect the AC power lead to the AC INPUT soc ket, then connect the AC power lead plug to an AC socket.

Notes:

● Unplug the AC power lead from the AC soc k et if the unit will not be in use for a prolonged period of time.

● Never use a power lead other than the one supplied. Use of a power lead other than the one supplied may cause an electric shock or fire.

AC 230 V, 50 Hz

To an AC socket

■ Demo mode

DEMO

ON OFF

20 cm (8")

10 cm (4")

● Be sure to keep space between the units for ventilation.

● Keep the top of this unit at least 20 cm (8") awa y from the wall, and the back at least 10 cm (4") away.

Note:

● Do not place the system or speakers near the television set as the magnetic fields produced may cause irregular colours to be displayed.

When the AC power lead is first connected, the unit will enter the demonstration mode and the words will scroll across the display continuously.

To cancel the demonstration mode:

When in the demonstration mode, set the DEMO switch to OFF. Then turn the power on and enter the stand-by mode to cancel the demonstration mode and to enter the low power consumption mode.

Note:

● When the unit is in the low power consumption mode, the display will disappear.

To return to the demonstration mode:

Set the DEMO switch to ON. Then turn the power on and enter the stand-by mode.

(Continued)

■ Remote control ■ To change the brightness of the dis-

play

2 "AA" size batteries

●

(UM/SUM-3, R6, HP-7

or similar)

Remote sensor

0.2m - 6m (8" - 20")

● When inserting or removing the batteries, push them towards the battery terminal.

● Installing the batteries incorrectly may cause the unit to malfunction.

Precautions for battery use:

● Insert the batteries according to the direction indicated in the battery compartment.

● Replace all old batteries with new ones at the same time.

● Do not mix old and new batteries.

● Remove the batteries if they are weak or if the

unit will not be used for long periods of time. This will prevent potential damage due to battery leakage.

(Remote control)

When bright

When dark

1 Press the ON/STAND-BY button to turn the

power on.

2 Press the DIMMER button.

● The display will become dimmer, and the displa y illumination will be dark.

To return to the original brightness:

Press the DIMMER button again.

Caution:

Do not use rechargeable batteries (nickel-cadmium battery, etc.).

Notes concerning use:

● Replace the batteries if the operating distance is reduced or if the operation becomes erratic.

● Periodically clean the transmitter LED on the remote control and the sensor on the main unit with a soft cloth.

● Exposing the sensor on the main unit to strong light may interfere with operation. Change the lighting or the direction of the unit.

● Keep the remote control away from moisture, excessive heat, shock, and vibrations.

SETTING THE CLOCK

In this example, the clock is set for the 24-hour (0:00) system.

4,6,8

3,5,7,9

1 Press the ON/STAND-BY button to turn the

power on.

2 Press the CLOCK button.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

MHzSLEEP

RECkHz

3 Within 5 seconds, press the ENTER button.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

MHzSLEEP

RECkHz

4 Press the or button to select the time

display mode.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

"0:00" →The 24-hour display will appear.

→(0:00 - 23:59)

"12:00 AM" →The 12-hour display will appear.

→(AM or PM 12:00 - 11:59)

"0:00 AM" →The 12-hour display will appear.

→(AM or PM 0:00 - 11:59)

● Note that this can only be set when the unit is first installed or it has been reset (see page 46).

5 Press the ENTER button.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

MHzSLEEP

RECkHz

7Press the ENTER button.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

MHzSLEEP

RECkHz

8 Adjust the minutes by pressing the or

button.

● When the button is pressed once , the time will increase by 1 minute. When the button is pressed once, the time will decrease by 1 minute.

● The hour setting will not advance even if minutes advance from "59" to "00".

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

MHzSLEEP

RECkHz

9 Press the ENTER button.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

● The clock starts operating from "0" seconds. (Seconds are not displayed.)

To see the time display:

Press the CLOCK button.

● The time display will appear for about 5 seconds even if stand-by mode.

Note:

● The clock display will flash on and off at the push of the CLOCK button when the AC power supply is restored after a power failure occurs or after the AC power lead is disconnected. If this happens, follow the procedure below to change the clock time.

To change the clock time:

Press the CLOCK button.

Within 5 seconds, press the ENTER button.

Perform steps 6 - 9 above.

To change the time display mode:

Reset the microcomputer (see page 48).

Perform steps 1 - 9 above.

MHzSLEEP

RECkHz

6 Adjust the hour by pressing the or button.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

● When the button is pressed once, the time will increase by 1 hour. When the button is pressed once, the time will decrease by 1 hour.

● When the 12-hour display selected, “AM” will change to “PM” automatically.

MHzSLEEP

RECkHz

SOUND CONTROL

■ V olume

(Main unit)

0 1 2 29 30 MAX

(Main unit operation)

When the V OLUME control is turned clockwise, the volume will increase. When it is turned anti-clockwise, the volume will decrease.

(Remote control operation)

Press the VOLUME button to increase the volume and the V OLUME button to decrease the volume.

(Remote control)

.....

■ Pre-programmed equalizer

(Main unit)

(Remote control)

■ Extra bass (X-BASS)

(Main unit)

X-BASS

Press the X-BASS button to emphasise the bass region of the frequency spectrum.

"X-BASS ON" will appear. Press the X-BASS button again to cancel the extra

bass mode. "X-BASS OFF" will appear.

●

(Remote control)

■ Surround

(Main unit)

SURROUND

(Remote control)

SURROUND

FLAT

HEAVY

VOCALSOFT

When the EQUALIZER button is pressed, the current mode setting will be displayed. To change to a different mode, press the EQUALIZER button repeatedly.

FLAT: The sound is not modified. HEAVY: Bass and treble are emphasised. VOCAL: V ocals (midrange tones) are emphasised. SOFT: Treble is reduced.

DISC TOC TRACK MEMORY RANDOM TOTAL REMAIN

RDS

EON TP TI PTY TA PTYI

AM PM

MHzSLEEP

RECkHz

Press the SURROUND button to allow you to enjoy music that seems to surround you.

● "SURROUND" will appear. Press the SURROUND button again to cancel the

surround mode.

● "PASS" will appear.

COMPACT DISC OPERATION

■ CD playback

3 45

PUSU CLOSE

Flash

DISC TOC TRACK MEMORY RANDOM

TOTAL

TOTAL REMAIN

Total number of tracks Total playing time

MHzSLEEP

1 Press the ON/STAND-BY button to turn the

power on.

2 Press the CD button. 3 Press the 7 CD EJECT button to open the CD

compartment.

4 Place the CD on the spindle, label side up. 5 Close the CD compartment by firmy pushing the

corner marked "PUSH CLOSE".

● The total number of tracks and the total playing time will be displayed.

6 Press the 0 6 button to start playback from track

● When the last track has been played back, the unit will stop automatically.

To interrupt playback:

Press the 0 6 button.

● “6” will appear.

● Press the 0 6 button again to resume playback

from the same point.

To stop playback:

Press the ■ button.

After use:

Press the ON/ST AND-BY button to enter the standby mode.

RECkHz

Caution:

● Do not open the CD compartment during playback (or whilst paused).

● Keep foreign objects out of the CD compartment.

● Subjecting the unit to shock or vibration may

cause mistracking.

● When the unit is not being used, be sure to close the CD compartment. If it is left open, the lens may become covered with dust and the unit ma y not operate properly.

● Playing certain compact discs at a high volume may cause mistracking. In this case, listen at a lower volume.

● If TV or radio interf erence occurs during CD operation, move the unit awa y from the TV or radio .

MINIDISC OPERATION

■ MD playback

DISC

MEMORY RANDOM TOTAL REMAIN

Disc name

(Displayed only when a disc name has been programmed)

DISC TOC TRACK MEMORY RANDOM

TOTAL

REMAIN

Total number of tracks

Total playing time

MHzSLEEP

1 Press the ON/STAND-BY button to turn the

power on.

2 Press the MD button. 3 Load a MiniDisc in the direction indicated by the

arrow on the MiniDisc, with the labeled side facing up.

● The total number of tracks and the total playing time on the MiniDisc will be displayed.

4 Press the 0 6 button.

● If the MD has a track name, the name will appear and scroll across the display. Then, the elapsed playing time will appear.

● If the MD has no track names, the elapsed playing time will appear.

● When the last track has been played back, the unit will stop automatically.

To interrupt playback:

Press the 0 6 button.

● " 6 " will appear.

● Press the 0 6 button again to resume playback

from the same point.

To stop playback:

Press the ■ button.

To remove a MiniDisc:

Press the 7 MD EJECT button.

RECkHz

Flash

RECkHz

Notes:

● If TV or radio interference occurs when using the MD, move the unit away from the TV or radio.

● Although MiniDiscs will not normally skip due to vibration, you may hear a skip in the sound if there is continuous vibration. If the volume is turned up too high, a skip may occur depending on the contents of the MD. If this happens, turn the volume down and the skipping should stop.

● If any (or some) error messages is displayed during MD operation, see "ERROR MESSAGES" on page 47.

CONVENIENT CD AND MD OPERATION

■ APSS (Auto Program Search Sys-

tem)

APSS automatically locates the beginning of any track.

2 4

5 3 06

5 3

2 4

To listen again to the track being played:

Press the 5 3 button for less than 0.5 seconds during playback.

T o move to the beginning of the next track:

Press the 2 4 button for less than 0.5 seconds during playback.

T o skip a number of tracks at one time:

Press the 5 3 or 2 4 button repeatedly until the desired track number is shown.

To start playing at a desired track:

Press the 5 3 or 2 4 button whilst in the stop mode to select the track number, and then press the 0 6 button.

■ Cue and review

1 Load a disc and begin playback. 2 Hold the 2 4 button down for audible fast

forward, and hold the 5 3 button down for audible fast reverse.

3 Normal playback will resume when the 2 4

or 5 3 button is released.

Notes:

● When the beginning of the first track is reached, normal playback will start.

● When the end of the last track is reached, "END" will light, and the unit will pause. If you want to listen to a portion of a track again, press the 5 3 button to return to the point in the track you want to listen to. Normal playback will start from that point.

■ Repeat and random play

(Remote control operation)

P-MODE

MD CD

1 Select the desired programme source, CD or

MD button.

2 Press the P-MODE button.

● Each time this button is pressed, the mode will change in the following order:

Repeat indicator Random indicator Disappears

3 Press the 0 6 button to start playback.

Repeat play

After the last track has been played, playback will return to the first track and begin again.

Random play

When the 0 6 button is pressed, all of the tracks will be played at random, and then playback will stop. (The same track will not be play ed back twice.)

To cancel repeat or random play:

Press the P-MODE button until the " R " or "RANDOM" display disappears.

To repeat playback of selected tracks:

Enter the programme for the tracks you want and start repeat play.

You can programme a single track and play it repeatedly (Refer to page 14).

Notes:

● During APMS play, random play is not possible.

● When random or repeat play is selected during

CD or MD playback, random or repeat play will start at that point.

● When using repeat play, be sure to press the ■ button after you are through listening. Otherwise, the disc will play continuously.

(Continued)

■ APMS (Automatic Programmable

Music Selector)

(Remote control operation)

CLEAR

4 2

7 6

1 Select the desired programme source, CD or

MD, by pressing the CD or MD button.

2 Press the MEMORY button.

MEMORY

REC

3 Press the 5 3 or 2 4 button.

MEMORY

Selected track number

REC

4 Press the ENTER button.

MEMORY

To clear the programmed selections:

Press the CLEAR button whilst the “MEMORY” indicator is flashing.

● Each time the button is pressed, one track will be cleared, beginning with the last track programmed.

To cancel the APMS:

Whilst the unit is stopped in the APMS mode, press the CLEAR button to turn off the “MEMORY” display.

● The programme contents will be erased.

● When you open the CD compartment or a

MiniDisc is ejected, the APMS mode will be cancelled.

To check which tracks are programmed:

Whilst the unit is stopped in the APMS mode, press the 5 3 or 2 4 button.

Adding tracks to the programme

If a programme has been previously stored, the “MEMORY” indicator will be displayed. Then follow steps 2 - 6 to add additional tracks , the newly selected tracks will be stored after the last track of the original programme.

Notes:

● It is not possible to insert an additional track between programmed tracks that have already been entered.

● Programming and cancelling are not possible during playback or in the pause mode.

Playback order

5 Repeat steps 3 and 4 for any other tracks up to

20 tracks (P-20) can be programmed.

6 Press the ■ button.

MEMORY

● The total playing time of the programmed tracks will be automatically displayed.

MEMORY

Total playing time

7 Press the 0 6 button to start playback of the

programmed selections.

● After all of the programmed tracks have finished playback, the unit will automatically stop.

+ 36 hidden pages
