Sharp LC-43SFE7451K, LC-49SFE7451K, LC-49SFE7452K, LC-55SFE7451K, LC-55SFE7452K User Manual

LED SMART TV with Freeview HD, Saorview & USB PVR

User Guide

Model No

LC-43SFE7451K
LC-49SFE7451K
LC-49SFE7452K
LC-55SFE7451K
LC-55SFE7452K

Important safety instruction

Please read these instructions. All
the safety and operating instructions
should be read before the appliance
is operated.

Warnings

• Television sets with 40”screen size or more must be

lifted and carried by at least 2 people.

• This television does not contain any parts that are

serviceable by the user. In case of a fault, contact the
manufacturer or authorised service department.
Exposing the internal parts inside the TV may
endanger your life. The manufacturers guarantee
does not extend to faults caused by repairs carried
out by unauthorised third parties.

To prevent spread of fi re,
keep candles or other open
fl ames away from this product
at all times

• To reduce the risk of fi re, electric shock or damage

to the TV, do not expose it to dust, rain or moisture.
Never expose the TV to dripping or splashing and do
not place objects fi lled with liquids on or near the TV.

• Do not connect any external devices (DVD player,

games console etc) when the TV is switched on.
Disconnect both the TV and device from the mains
before connecting. Only switch appliances on when
the connection process is complete.

• Do not place the television in a confi ned space and

do not obstruct the ventilation openings at the rear
of the television.

• When installing on a wall, ensure the TV is at

least 5cm from the wall for ventilation.

• Always ensure that the TV’s ventilation openings

are not covered with items such as newspapers,
table-cloths, curtains, etc.

• Dispose of this television and any components

including batteries in an environmentally friendly
manner. If in doubt, please contact your local
authority for details of recycling.

• Ensure this TV is used in moderate climates only.

WARNING: Never place a television set on an
unstable location. A television set may fall,
causing serious personal injury or death. Many
injuries, particularly to children, can be avoided
by taking simple precautions such as:

• Use cabinets or stands recommended by the

manufacturer of the television set.

• Only use furniture that can safely support the

television set.

• Ensure the television set is not overhanging the edge

of the supporting furniture.

• Do not place the television set on tall furniture

(for example, cupboards or bookcases) without
anchoring both the furniture and the television
set to a suitable support.

• Do not place the television set on cloth or other

materials that may be located between the television
set and supporting furniture.

• Please educate children about the dangers of

climbing on furniture to reach the television set or
its controls.

• If your existing television set is being retained and

relocated, the same considerations as above should
be applied.

Safety

• For your safety, this appliance is fi tted with a

fused 3 pin mains plug. Should the fuse need to be
replaced, ensure that any replacement is of the same
amperage and approved with the BSI mark.

• Never try and replace the mains plug unless you have

adequate qualifi cations and are legally authorised to
do so. In the event that a replacement mains cable
is required, contact the manufacturer for a suitable
replacement.

• Never use the television if it is damaged in any way.

• Always place the television on a fl at level surface

avoiding anywhere which may be subject to
strong vibration.

• The ideal distance to watch the television is

approximately fi ve times the length of the diagonal
measurements of the TV screen.

• Ensure the television is not placed on top of the

power cable as the weight of the television may
damage the cable and cause a safety hazard.

• Never place mobile phones, speakers or any

other device which may cause magnetic or radio
interference, near the television. If interference is
apparent, move the device causing the interference
away from the television.

• To disconnect the apparatus from the mains, please

use the mains plug located on the underside/rear of
the TV.

• Ensure that the mains plug is always easily accessible.

WARNING: Excessive noise when using
earphones and headphones can cause loss of
hearing.

4

5

Important safety instruction

Maintenance

• To clean your TV, wipe with a soft, dry cloth. If the

surfaces are extremely dirty, use a soft cloth dipped
in a soap and water solution or a weak detergent
solution.

• Never use alcohol, paint thinner or benzene to clean

this unit.

• Before using a chemically treated cloth, read the

instructions that came with the cloth carefully.

Examples of images that are more likely to cause “screen burn”
are as follows (this is not an exhaustive list):

• TV channel logos: e.g. shopping channel logos and

pricing displays - especially if they are bright and
stationary. Moving or low-contrast graphics are less
likely to cause ageing of the screen.

• Time displays.

• Teletext: Do not view a stationary page for a long

period of time

• TV/DVD menus: e.g. listings of DVD disc content.

• Pause mode: Do not leave the TV in pause mode

for long periods of time, e.g. when watching DVDs
or videos.

Important: Once ‘shadow image/screen burn’
occurs, it will never disappear and is not
repairable under warranty.

How do I dispose of this product?

CAUTION: If water or other liquid enters the
television through the display panel surface,
a malfunction may occur.

Packaging

• The safest way to transport your item is in the

original box/packaging - please save your packaging
for this.

• You will need the original box/packaging in the

event of warranty/service repair or support. We
are unable to carry out warranty/service if you are
unable to package the item correctly.

Important information regarding use of video
games, computers, captions or other  xed image
displays

The extended use of  xed image program material can cause
a permanent “shadow image” on the LCD/LED panel, also
known as “screen burn”.

UK: Waste electrical products should not
be disposed of with household waste.
Please dispose of the product at a
designated collection point for recycling
of WEEE. For your nearest facilities, please
see www.recycle-more.co.uk or in store
for details.

ROI: Waste electrical products should not be
disposed of with household waste. Separate
disposal facilities exist. Check with your local
authority or retailer for recycling advice.

Cd

Batteries

• Do not expose batteries to high temperatures,

excessive heat, prolonged sunshine or fi re as this may
cause leakage, explosion or ignition.
Observe the correct polarity when inserting batteries.

• Do not use different types of batteries together or

mix old and new batteries.

• Dispose of batteries in an environmentally

friendly way.

• Certain regions may regulate the disposal of

batteries. Please consult your local authority.

This “shadow image” can appear in the background during
normal viewing. This type of irreversible LCD/LED panel
deterioration can be limited by observing the following steps:

1. Reduce the brightness/contrast setting to a minimum
suitable viewing level.

2. Do not display the  xed image for extended periods
of time.

3. Turn the power o when not in use.

5

Important safety instruction

3D safety information

• If you watch the 3D imaging too closely or for a

long period of time, it may harm your eyesight.

• Watching the TV or playing video games that

incorporate 3D imaging with the 3D glasses
for a long period of time can cause drowsiness,
headaches or fatigue to you and/or your eyes. If
you have a headache, feel fatigued or drowsy,
stop watching the TV and take a rest.

• Pregnant woman, seniors, persons with heart

problems or persons who experience frequent
drowsiness should refrain from watching 3D TV.

• Please prevent children under the age of 5 from

watching 3D TV as it may harm their vision
development.

Warning for photosensitization seizure

• Some viewers may experience a seizure or

epilepsy when exposed to certain factors
including fl ashing lights or images in TV or video
games. If you or anybody from your family has a
history of epilepsy or seizure, please consult with
your doctor before watching 3D TV.

• Certain symptoms can occur in unspecifi ed

conditions without any previous history.

• If you experience any of the following symptoms,

immediately stop watching the 3D content and
consult a doctor: dizziness or light headedness,
altered vision, visual or facial instability, such
as eye or muscle twitching, convulsion, loss of
consciousness, confusion or disorientation, loss of
directional sense, cramps, or nausea.

• Parents should monitor their children, including

teenagers, for these symptoms as they may be
more sensitive to the effects of watching 3D TV.

The terms HDMI and HDMI High-De nition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing, LLC in the United States and
other countries.

HDTV

The “HD TV” Logo is a trademark of DIGITALEUROPE.

HDTV 1080p

The “HD TV 1080p” Logo is a trademark of DIGITALEUROPE.

DVB

The DVB logo is the registered trademark of the Digital Video
Broadcasting (DVB) project.

FREEVIEW

The FREEVIEW words and logos are trade marks of DTV
Services LTD. © DTV Services Ltd.

SAORVIEW

SAORVIEW is a registered trademark owned by RTÉ.

Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio and the double-D symbol are trademarks
of Dolby Laboratories.

The “CI plus” Logo is a trademark of CI Plus LLP.

YouTube

YouTube and the YouTube logo are trademarks of Google Inc.

CE Statement:

Hereby, Universal Media Corporation l.t.d. declares
that this LED TV is in compliance with the essential
requirements and other relevant provisions of
Dirrective 1999/5/EC.

http://www.sharp.eu/av/documents-of-conformity

Risk of photosensitization seizure can
bereduced with the following actions.

• Take frequent breaks from watching 3D TV.

• For those who have vision that is different in

each eye, they should watch the TV after taking
vision correction measures.

• Watch the TV so that your eyes are on the same

level as the 3D screen and refrain from sitting too
closely to the TV.

• Do not watch the 3D imaging when tired or sick

and avoid watching the 3D imaging for a long
period of time.

• Do not wear the 3D glasses for any other purpose

than viewing 3D content on a 3D TV.

• Some viewers may feel disorientated after

watching 3D TV. Therefore, after you watch 3D
TV, take a moment to regain awareness of your
situation before moving.

6

7

CONTENTS

Manufacturers guarantee information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

What is included in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Attaching / detaching the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Securing the TV to a wall / wall mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

TV buttons and Input Source menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting the TV to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

TV menu operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-28

Picture menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-19

Sound menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

Channel menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Lock menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Time menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Network menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Settings menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Applications menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-29

7 day TV guide and channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

USB record - Freeview / Saorview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-39

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

Technical specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-39

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-15

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited.
DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a
trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.

7

What is included in the box

WHAT IS INCLUDED IN THE BOX

Accessories

Included with this TV are the following accessories.

1 x User guide

User guide

1 x Quick start guide

Quick start

guide

1 x Remote control and 2 x AAA batteries

USB

RADIO

NET+

123

5

6

4

8

7

9

TV

0

GUIDE


SOUND

VOL

CH

SOURCE

EXIT

MENU

OK

BACK

FAV

INFO

SUBTITLE

SLEEP

AUDIO

DISPLAY

TEXT

TEXT/DVD

TEXT

HOLD

ZOOM

PVR / DVD

REC LIST

GOTO

REPEAT

A-B

ANGLE

1 x RF cable

1 x Mini composite / AV cable

1 x TV

4 x 3D glasses

1 x Mini component / YPbPr cable

1 x Stand installation pack

4 x

1 x L (left)

1 x R (right)

Please save your box/packaging as you will need this in the event of warranty/service repair or support.
We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to
package your item in the event of warranty/service repair is in it’s original box/packaging.

8

9

Attaching/detaching the stand

ATTACHING THE STAND

Attaching the stand feet

To complete the stand feet installation you will require a cross head screw driver.

Screws that are included.

4 x

TV panel must be facing downwards.

1

TV panel must be facing downwards.

L

(fi g.1) Place the TV set on a fl at and
clean surface with the panel facing
downwards to avoid damage, then
fi x the stand feet shown. The feet are

marked L (left) and R (right).

R

(fi g.2) Secure the stand feet to
the underside of the TV set using

3
4

the screws provided.

R

1

2

2

L

4 x

Detaching the stand

Remove the screws highlighted then remove the stand feet from the underside of the TV set.

TV panel must be facing downwards.

3
4

R

1

2

L

4 x

9

Securing the TV to a wall/wall mounting

SECURING THE TV TO A WALL

Securing the TV to a wall using anti-tip straps

For maximum security in the home, when using a TV with its stand, anti-tip straps should be fi tted. These
are available from supermarket websites and other websites and are an easy, inexpensive and effective
way of ensuring your TV stays safely upright. Straps are designed to be attached to the rear of the TV and
then tethered to the wall or the furniture the TV is stood on, these are fi tted as follows.

A) Using one or both of the top wall-mounting
holes and screws fasten one end of the fastening
cord/s to the TV. (the screws are already supplied in
the wall mounting holes)

B) Secure the other end of the fastening cord/s to
your wall. (you will need screws/fi xings suitable
for your wall type - available separately from most
DIY stores).

Note - Please ensure that children do not climb on the TV set.

The Royal Society for the Prevention of Accidents is urging people to take care with fl at-screen televisions.

RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling fl at-screen televisions on to
themselves. They are unsteady on their feet and are attracted by colourful television images.”

The risk is increased as televisions become lighter.

Wall mounting

IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there
could be any electrical wires, water or gas pipes.

1) Remove the four screws located at the back of the TV set.

2) The wall mount can now be easily attached to the mounting holes, located
on the back of the TV, using the same four screws removed.

For VESA wall mounting information please refer to the Technical
Specifi cation page.

For optimum viewing, if wall mounting the TV higher than eye level, the TV should be tilted downwards
so that the TV’s screen is ‘face on’. See fi g 1 and 2.

fig 1 fig 2

INCORRECT

TV

CORRECT

TV

Viewing angle

Important – If wall mounting this TV, only use the screws already provided in the wall mounting holes
located at the back of the TV, using other screws which are longer could cause irreparable damage to
internal parts.

10

Viewing angle

11

Remote control

REMOTE CONTROL

During the initial set up of your TV you will need to pair the remote control to the TV.
To pair the remote control to the TV, ensure the TV is in standby mode, press and hold the green
and yellow buttons (highlighted below) on the remote control for a few seconds.

Key

For models with integrated DVD players.
For models with PVR Function.
For models with USB Playback.

1

STANDBY - Switch on the TV when in standby or vice versa.
MUTE - Mute the sound or vice versa.
NET+ - Access the Aquos Net application.
DTV - Switch to digital TV source.
USB - Switch to USB source.
YOUTUBE - Access the Youtube App.

2

NUMBER BUTTONS - 0–9 to select a TV channel directly.
TV GUIDE - Opens the 7 day TV guide (digital TV mode).

- To return to the previous channel viewed.

1

USB

RADIO

DTV

NET+

2

1
4
7

2
5
8

3
6
9

3

VOL (+/-) - To increase/decrease the sound level.
PICTURE - Scrolls through picture mode options.
SOUND - Scrolls through sound mode options.
SOURCE - To display the input/source menu.
CH (+/-) - To increase or decrease the channel being watched.
MENU - To display OSD menu.
EXIT - To exit all menus.

- Allows you to navigate the on-screen menus and adjust

the system settings to your preference.

BACK - To go back a previous step.
FAV - To display favourites menu.

4

INFO - Press once for now/next channel information.

- Press twice for information about the current programme.

SLEEP - Press repeatedly to cycle through the sleep options.
AUDIO - To change the audio language (if available).
SUBTITLE - To switch the dialogue at the bottom of the screen (on/off).
TEXT - To enter/exit Text.
TEXT HOLD - Teletext mode - Holds current page which is

displayed (Analogue TV).

TEXT/ZOOM - Zoom function for Teletext and DVD.
DISPLAY - To switch off the screen when listening to radio.
RECORD - Access the USB record function.

- To restart the current chapter

- To advance forward to the next chapter

- To stop the playback/Eject Disc

(To EJECT the disc press/hold the button for 4 seconds)

- To play in fast rewind mode

- To play in fast forward mode

- To play/pause

TV

GUIDE

0


3

VOL

SOUND

CH

SOURCE

EXIT

MENU

OK

BACK

FAV

INFO

TEXT

REC LIST

GOTO

SLEEP

TEXT

HOLD

PVR / DVD

A-B

4

AUDIO

TEXT/DVD

ZOOM

ANGLE

SUBTITLE

DISPLAY

REPEAT

REC LIST - Opens the list of what has been previously recorded.
GOTO - To go to a specifi c chapter.
A-B - Press once to set point, press a second time to return to point.
ANGLE - Select different angle of DVD.
REPEAT - To repeat playback.

Buttons to use when
pairing the remote
control to the TV.

11

TV Buttons and Input Source Menu

TV BUTTONS AND INPUT SOURCE MENU

1

2

3

4

5

6

7

Volume up and menu right

1

Volume down and menu left

2

Programme/channel up and menu up

3

Programme/channel down and menu down

4

Displays menu/OSD

5

Displays the ‘Input Source’ menu

6

Standby power On/Off

7

Note: The shape of the TV buttons may vary by model.

Choosing Mode Input/Source

Use the source menu to switch between
input/connections.

A) Using the buttons on the remote control:

1) Press [SOURCE] - The source menu will appear.

2) Press [\/] or [/\] to select the input you require.

3) Press [OK].

B) Using the buttons on the Television:

1) Press [SOURCE].

2) Scroll up / down using CH+/ CH- buttons to
the input/source you require.

3) Press Vol+ to change input/source to the
one selected.

For further information on input/connections please
view ‘Connections’ pages.

12

An example of the ‘Input Source’ menu

(will vary by model)

13

CONNECTIONS

Connections

O

EARPHONE

N

M

CI CARD IN

L

AV IN Y Pb Pr

K

VGA /PC (Audio in)

VGA/PC IN

A

A

LAN/Ethernet* Network connection

B

HDMI 1 HDMI input

C

HDMI 2 HDMI input (ARC)

D

VGA PC VGA-PC input

E

SCART SCART input

F

RF in RF / TV aerial input

SAT in** Satellite input

G

Digital audio Digital optical audio output

H

B

C

D E

J

USB

I

Digital Audio

Output

F

G

HDMI 3*** HDMI input (MHL Port)

USB x 2 USB port

VGA PC audio in 3.5mm PC audio input

AV in Audio/video input

CI card in Common interface module

YPbPr HD input (Ypbpr)

Earphones Earphone input

H

I

J

K

L

M

N

* The LAN/Ethernet port is used for Freeview HD services and smart functions.

**Satellite input available for LC-49SFE7452K and LC-55SFE7452K models only.

*** HDMI 3 (MHL Port) - MHL is a wired solution that allows you to access the media from your phone or
tablet onto the big screen in the highest quality.
By connecting an MHL cable (sold separately) from your mobile device and into your TV you can playback all
your videos, games and photographs directly onto your TV.
MHL simply mirrors the screen of your mobile device so will work with all applications, whilst connected it
will also charge your device too.

13

Connections

CONNECTIONS

Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is
Included In The Box’ page.

Connecting to a device with Composite AV/Video output

TV Source should be set to Composite/AV

L (white)

R (red)

Mini
AV in

Connecting to a device with SCART output

TV source should be set to SCART

Video
(yellow)

Scart

Scart

Connecting to a device with HDMI output

A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio
with minimal loss of quality.

TV Source should be set to the corresponding HDMI port (HDMI 1, HDMI 2 etc)

HDMI HDMI

HDMI 3 (MHL Port) - MHL is a wired solution that allows you to access the media from your phone or
tablet onto the big screen in the highest quality.
By connecting an MHL cable (sold separately) from your mobile device and into your TV you can
playback all your videos, games and photographs directly onto your TV.
MHL simply mirrors the screen of your mobile device so will work with all applications, whilst connected
it will also charge your device too.

14
