Sharp LC-42LE540U, LC-46LE540U User Manual

LC-46LE540U LC-42LE540U

LIQUID CRYSTAL TELEVISION TÉLÉVISEUR ACL TELEVISOR CON PANTALLA

DE CRISTAL LÍQUIDO

OPERATION MANUAL MODE D'EMPLOI MANUAL DE OPERACIÓN

ENGLISHFRANÇAISESPAÑOL

ENGLISHFRANÇAISESPAÑOL ENGLISHFRANÇAISESPAÑOL

IMPORTANT : Please read this operation manual before starting operating the equipment. IMPORTANT : Veuillez lire ce mode d'emploi avant de commencer à utiliser l'appareil.

IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.

LC-46LE540U LC-42LE540U

LIQUID CRYSTAL TELEVISION

ENGLISH

OPERATION MANUAL

ENGLISH

IMPORTANT: To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space provided. The numbers are located at the rear of the TV.

Model No.:

Serial No.:

IMPORTANT INFORMATION

WARNING:

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

CAUTION:

WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly

approved by the manufacturer could void the user's authority to operate this equipment.

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning ﬂash with arrow-head

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

IMPORTANT INFORMATION

CAUTION:

This product satisﬁes FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

DECLARATION OF CONFORMITY:

SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-46LE540U/LC-42LE540U This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RESPONSIBLE PARTY:

For Business Customers: URL http://www.sharpusa.com

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Wireless Radio

For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible. This device is going to be operated in 5.15–5.25GHz frequency range, it is restricted in indoor environment only. Important: Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Wireless Radio

For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible. The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure. Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where required by the technology. Important: Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07495-1163 TEL: 1-800-BE-SHARP

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820 of the National Electrical Code that provides guidelines for proper grounding and, in particular, speciﬁes that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”

This product qualiﬁes for ENERGY STAR when "Home" is selected for "TV Location". Setting "TV Location" to "Home" allows the TV to achieve an energy-saving status for household use.

DEAR SHARP CUSTOMER

Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Instructions carefully before using this product.

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

10) Only use attachments/accessories speciﬁed by the manufacturer.

11) Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

12) Unplug this apparatus during lightning storms or when unused for long periods of time.

13) Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

14) WARNING: To reduce the risk of ﬁre or electric shock, do not expose this apparatus to rain or moisture.

15) Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device

shall remain readily operable.

16) The apparatus shall not be exposed to dripping or splashing and that no objects ﬁlled with liquids, suchas

vases, shall be placed on the apparatus.

Additional Safety Information

17) Power Sources—This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

18) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of ﬁre or electric shock.

19) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a ﬁre or electric shock. Never spill liquid of any kind on the product.

20) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualiﬁed service personnel under the following conditions:

a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment

of other controls may result in damage and will often require extensive work by a qualiﬁed technician

to restore the product to its normal operation, e) If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in performance - this indicates a need for service.

21) Replacement Parts—When replacement parts are required, be sure the service technician has used replacement parts speciﬁed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁre, electric shock, or other hazards.

22) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

23) Wall or ceiling mounting—Use a wall mount bracket that has been listed by an independent laboratory

(such as UL, CSA, ETL).

IMPORTANT SAFETY INSTRUCTIONS

• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.

Article 810 of the National Electrical Code, ANSI/NFPA 70,

provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.

• Selecting the location — Select a place with no direct sunlight and good ventilation.

• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufﬁ cient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer's instructions are followed.

• The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.

• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including ampliﬁ ers) that produce heat.

• The Liquid Crystal panel is a very high technology product with 2,073,600 pixels, giving you ﬁ ne picture details.

Occasionally, a few non-active pixels may appear on the screen as a ﬁ xed point of blue, green or red. Please note that

this does not affect the performance of your product.

• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

• To prevent ﬁ re, never place any type of candle or ﬂ ames on the top or near the TV set.

• To prevent ﬁ re or shock hazard, do not place the AC cord under the TV set or other heavy items.

• Do not display a still picture for a long time, as this could cause an afterimage to remain.

• To prevent ﬁ re or shock hazard, do not expose this product to dripping or splashing.

No objects ﬁ lled with liquids, such as vases, should be placed on the product.

• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may result in ﬁ re or electric shock. Exercise special caution when using the product around children.

Precautions when transporting the TV

• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always carry the TV by two people holding it with two hands — one hand on each side of the TV.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

ANTENNA LEAD IN WIRE

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMP

NEC — NATIONAL ELECTRICAL CODE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM (NEC ART 250)

Caring for the cabinet

• Use a soft cloth (cotton, ﬂ annel, etc.) and gently wipe the surface of the cabinet.

• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main unit cabinet or cause cracking.

• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.

• If the cabinet is very dirty, wipe with a soft cloth (cotton, ﬂ annel, etc.) soaked in neutral detergent diluted with water and thoroughly wrung out, and then wipe with a soft dry cloth.

• Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.

• Do not apply insecticides or other volatile liquids.

Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers

inside the plastic may cause the cabinet to deform and cause the paint to peel off.

IMPORTANT SAFETY INSTRUCTIONS

Caring for the front panel

• Turn off the main power and unplug the AC cord from the wall outlet before handling.

• Gently wipe the surface of the front panel with a soft cloth (cotton, ﬂ annel, etc.).

To protect the front panel, do not use a dirty cloth, liquid cleaners, or a chemical cloth (wet/dry

sheet type cloth, etc.). This may damage the surface of the front panel.

• Wiping with a hard cloth or using strong force may scratch the surface of the front panel.

• Use a soft damp cloth to gently wipe the front panel when it is really dirty.

(It may scratch the surface of the front panel when wiped strongly.)

• If the front panel is dusty, use an anti-static brush, which is commercially available, to clean it.

• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are

available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or VISIT http://www.sharpusa.com/SharpDirect.

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

• The home theater entertainment experience is a growing trend and larger ﬂ at panel displays are popular purchases. However, ﬂ at panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations.

• Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

• The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

• One size does NOT ﬁ t all. Follow the manufacturer’s recommendations for the safe installation and use of your ﬂ at panel display.

• Carefully read and understand all enclosed instructions for proper use of this product.

• Don’t allow children to climb on or play with furniture and television sets.

• Don’t place ﬂ at panel displays on furniture that can easily be used as steps, such as a chest of drawers.

• Remember that children can become excited while watching a program, especially on a “larger than life” ﬂ at panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down.

• Care should be taken to route all cords and cables connected to the ﬂ at panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

• Follow all instructions supplied by the display and wall mount manufacturers.

• If you have any doubts about your ability to safely install your ﬂ at panel display, contact your retailer about professional installation.

• Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

• A minimum of two people are required for installation. Flat panel displays can be heavy.

Note: CEA is the preeminent trade association promoting growth in the $161 billion U.S. consumer electronics industry. More than 2,200 companies enjoy the beneﬁ ts of CEA membership, including legislative advocacy, market research, technical training and education, industry promotion and the fostering of business and strategic relationships

Contents

IMPORTANT INFORMATION . . . .. . .. .. . .. . .. .. . 1-2

IMPORTANT SAFETY INSTRUCTIONS . . . .. . .. 3-5

Supplied Accessories . . .. . .. . .. .. . .. .. . .. .. . .. .. . 7

QUICK REFERENCE

Attaching/Detaching the Stand . . .. .. . .. .. . .. . .. 7

QUICK INSTALLATION TIPS . . .. . .. .. . .. .. . .. . . 8

Using the Remote Control Unit . .. . .. . .. .. . .. .. . 8

Preparation

Antennas . . .. . .. .. . .. .. . .. .. . .. . .. .. . .. .. . .. .. . . 9

Installing Batteries in the Remote Control Unit

Part Names

TV (Front) . . .. .. . .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. 10

TV (Rear/Side) . .. .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. 10

Remote Control Unit . . .. .. .. . .. .. . .. . .. .. . .. .. . 11

Introduction to Connections

Experiencing HD Images . .. . .. .. . .. .. . .. .. . .. . 12

Types of Connection . .. .. . .. .. . .. .. . .. .. . .. .. . 12

Displaying an External Equipment Image . .. .. . . 12

Connecting to External Equipment

Connecting a Blu-ray Disc/DVD Player or

HD Cable/Satellite Set-top Box . . . .. .. . .. . 13-14

Connecting a VCR, Game Console,

Camcorder or Cable/Satellite Set-top Box . .. . 14

Connecting an Audio Ampliﬁ er . .. .. .. . .. .. . .. .. 15

Connecting an AV Ampliﬁ er . . .. .. . .. . .. .. . .. .. . 15

Connecting a PC . .. .. .. . .. .. . .. .. . .. . .. .. . .. .. 16

Watching TV

Turning On/Off the Power . .. .. . .. .. . .. .. . .. . ..

Initial Installation . . .. . .. . .. .. . .. .. . .. .. . .. .. . .. . 17

Direct Button Operation

Changing Channels . . .. .. . .. .. . .. .. . .. .. . . 18

Changing Volume . .. . .. .. . .. .. . .. .. . .. .. . .. 18

MUTE . . .. .. . .. .. . .. .. . .. .. . .. . .. .. . .. .. . .. . 18

Sleep Timer . . .. . .. .. . .. .. . .. . .. .. . .. .. . .. .. 18

AUDIO . .. .. . .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. 18

FLASHBACK . . .. . .. .. . .. .. . .. .. . .. .. . .. . .. . 19

FREEZE . . .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. .. . . 19

APPS . . .. . .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. .. . 19

INPUTE . .. .. .. . .. .. . .. .. . .. . .. .. . .. .. . .. .. . 19

Closed Captions and

Digital Closed Captions . . .. . .. .. . .. . .. .. . . 19

AV MODE .. .. . .. .. . .. .. . .. . .. .. . .. .. . .. .. . . 20

VIEW MODE . . .. . .. .. . .. .. . .. . .. .. . .. .. .

On-Screen Display Menu

On-Screen Display Menu Operation . . .. .. . .. .. 22

Menu Operation Buttons . .. . .. .. . .. .. . .. .. . .. . 22

Menu Items . .. .. . .. .. . .. .. . .. .. . .. .. . .. . .. .. . . 23

Picture Settings . .. .. .. . .. .. . .. . .. .. . .. .. . .. 24-25

Audio Settings . .. .. .. . .. .. . .. .. . .. . .. .. . .. .. . . 25

Power Control . . .. . .. .. . .. . .. .. . .. .. . .. .. . .. .. . 25

System Options .. . .. .. . .. .. . .. .. . .. . .. .. . .. 26-27

Initial Setup. . .. .. . .. .. . .. .. . .. .. . .. .. . .. .. . . 27-31

Information . . .. .. . .. .. . .. .. . .. . .. .. . .. .. . .. . 31-32

.. . . 9

20-21

Enjoying Photo/Music/Video Playback

Connecting a USB Memory Device/

USB Hard Drive . .. .. . .. .. . .. .. . .. .. . .. . .. .. . . 33

Connecting a Home Network (DLNA) Server . .. 33

Select the Files to Play Back . .. .. .. . .. .. . .. .. . . 34

Playing Back Files

on a USB Memory Device . . . .. .. . .. .. . .. .. 34-36

Playing Back Files

on a Home Network (DLNA) Server . .. .. .. 37-38

Other Viewing Options

Presetting Remote Control Function

Operating the Connected Equipment .. . .. . . 39-40

Using AQUOS LINK

Controlling HDMI Equipment

Using AQUOS LINK . .. .. .. . .. . .. .. . .. .. . .. 41-43

Link Operation Menu .. . .. . .. . .. .. . .. .. . .. ..

Using a PC

Displaying a PC Image on the Screen . .. .. ..

Adjusting the PC Image . . .. .. . .. .. . .. .. . .. .. . . 46

PC Compatibility Chart . . .. .. . .. .. . .. .. . .. .. . .. 46

Setting Audio Input . . .. .. . .. .. . .. .. . .. .. . .. .. . 46

RS-232C Port Speciﬁ cations . . .. .. . .. .. . .. .. . . 47

Using the Internet

Connecting to the Internet . . .. .. . .. . .. .. . .. . 48-49

Internet Setup . . .. . .. .. . .. . .. .. . .. .. . .. .. . .. .. . 50

Displaying Updated Information and

Support Service . .. .. .. . .. .. . .. . .. .. . .. .. .

Using Applications Via the Internet . . .. .. .. .

Appendix

Troubleshooting . . .. .. . .. . .. .. . .. .. . .. .. . .. . 53-54

Trademarks . . . .. . .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. .. 55

Speciﬁ cations

TV . . .. .. . .. . .. .. . .. .. . .. .. . .. .. . .. . .. .. . .. .. . . 56

Wireless LAN . .. .. . .. .. . .. .. . .. .. . .. .. . .. .. . .. . 57

Information on the Software License for

This Product . . .. .. . .. .. . .. .. . .. . .. .. . .. .. . .. . 59-60

Calling for Service . . .. .. .. . .. . .. .. . .. .. . .. .. . .. .. 60

LIMITED WARRANTY . . .. .. .. . .. .. . .. . .. .. . .. .. . . 60

Dimensional Drawings

•

The dimensional drawings for the LCD TV set are shown on the inside back cover.

. . .. .. . .. .. 39

43-44

45-46

50-51 51-52

54-55Troubleshooting - Error Message .. . .. .. . .. .

• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from the actual operations.

Supplied Accessories

Make sure the following accessories are provided with the product.

Remote control unit

(g1) Page 8

• Always use the AC cord supplied with the TV.

• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.

“AAA” size battery

(g2) Page 9

Stand unit

(g1) Page 7

Operation manual

(g1)

Connection guide

(g1)

QUICK REFERENCE

Attaching/Detaching the Stand

• Before attaching (or detaching) the stand, unplug the AC cord.

• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

CAUTION

• Attach the stand in the correct direction.

• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.

Put the TV face down on a safe surface that is covered by a soft and smooth cloth.1. Adjust the TV stand to the bottom of the TV.2. Fasten the screws by using a cross-head screwdriver (Not supplied).3.

CAUTION

• Do not push too hard or put excessive pressure to the stand neck to avoid the damages when you turn the TV for

the most comfortable viewing angle.

To detach the stand, perform the steps in reverse order.

•

QUICK REFERENCE

QUICK INSTALLATION TIPS

1 Attach your antenna to the back of the television. (See page 9.)

2 Connect the AC plug for the television into the AC

outlet.

AC outlet

• Place the TV close to the AC outlet, and keep the power plug within reach.

• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT

TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE AC CORD CONNECTED.

When turning on the TV for the ﬁ rst time, press

POWER on the television.

POWER

Insert the batteries into the remote control unit. (See

page 9.)

Using the Remote Control Unit

Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects between the remote control unit and the remote control sensor may prevent proper operation.

Remote control sensor

30º 30º

30º

Cautions regarding the remote control unit

• Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to liquids, and do not place in an area with high humidity.

• Do not install or place the remote control unit under direct sunlight. The heat may cause deformation of the remote control unit.

• The remote control unit may not work properly if the remote control sensor on the TV is under direct sunlight or strong lighting. In such cases, change the angle of the lighting or the TV, or operate the remote control unit closer to the remote control sensor.

17´ (5 m)

• Speakers cannot be detached from the TV.

• The TV angle cannot be adjusted.

IMPORTANT:

IF THE UNIT DOES NOT POWER ON - UNPLUG THE TELEVISION FROM THE OUTLET AND REPEAT THE INSTALLATION STEPS.

IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.

Preparation

Antennas

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set. For connecting the antenna cable to the TV, use commercially available cables.

Connecting Antenna Cable

• Connect the antenna cable to the TV using one of the methods in the illustration as shown (1,2,3 or 4).

Cable without a CATV

converter

VHF/UHF antenna

Combination VHF/

UHF antenna

Separate VHF/UHF

antenna

Cable TV lead-In

75-ohm coaxial cable (round)

300-ohm twin-lead cable (ﬂat)

VHF

UHF

NTENNA

ANTENNA

300-ohm twin-lead cable

75-ohm coaxial cable

Home Antenna terminal (75-ohm)

Coaxial cable

Home Antenna terminal (75-ohm)

Coaxial cable

300/75-ohm adapter

IN OUT

Combiner

To TV antenna terminal

ANT./CABLE

INPUT 3

1. A 75-ohm system is generally a round cable with F-type connector that can easily be attached to a terminal without tools.

2. A 300-ohm system is a ﬂ at “twin-lead” cable that can be attached to a 75-ohm terminal through a 300/75-ohm adapter.

F-type connector

75-ohm coaxial cable (round)

300-ohm twin-lead cable (ﬂ at)

NOTICE

When connecting the RF cable to the TV set, do not tighten F-type

F-type connector should be ﬁ nger-tightened only.

F-type connector

connector with tools. If tools are used, it may cause damage to your TV set. (The breaking of internal circuit, etc.)

75-ohm coaxial cable

Installing Batteries in the Remote Control Unit

If the remote control fails to operate TV functions, replace the batteries in the remote control unit.

1 Open the battery cover.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage in old batteries.

• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a rash. If you ﬁ nd any chemical leakage, wipe thoroughly with a cloth.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove batteries from it.

2 Insert two “AAA” size batteries (supplied with

the product).

• Place the batteries with their terminals corresponding to the (e) and (f) indications in the battery compartment.

3 Close the battery cover.

Part Names

TV (Front)

TV (Rear/Side)

Channel buttons

(CH/)

Volume buttons

k/l

(VOL

)

button

INPUT

button

POWER

button

OPC sensor *

Remote control sensor POWER indicator

* OPC: Optical Picture Control（See page 24.)

RS-232C IOIOI

terminal

HEAD PHONE

terminal

DIGITAL AUDIO OUTPUT

terminal

INPUT 5

PC IN

AUDIO

PC/HDMI

Y/VIDEOPBPR

R-AUDIO-L

DIGITAL

AUDIO OUTPUT

PC IN

terminal

AUDIO PC/HDMI

terminal (shared for PC in and HDMI)

*1 See pages 12 to 16 and 41 for external equipment connection. *2 See pages 17 and 22 for button operations.

ETHERNET INPUT 5

terminaterminals (COMPONENT/AV)

ETHERNET

(10/100)

ANT./CABLE

INPUT 3

INPUT 4

Antenna/Cable in

INPUT 3

terminal(HDMI)

INPUT 4

terminal(HDMI)

INPUT 1

terminal (HDMI)

INPUT 2

terminal (HDMI)

USB

terminal

Part Names

Remote Control Unit

4 5

20 21

8 9

10 11

23 24

25 26

28 29

• When using the remote control unit, point it at the TV.

1 POWER: Switch the TV power on or enter standby. (See

page 17.)

2 TV, STB, DVD•VCR, AUDIO: Switches the remote

control for TV, STB, DVD, BD, VCR and AUDIO operation. (See pages 39 to 40 for details.)

* To enter the code registration mode, you need to press

an appropriate button (STB, DVD•VCR or AUDIO) and

DISPLAY at the same time.

3 External equipment operational buttons: Operate the

external equipment.

4 OPTION: Display the Link Operation Menu screen. This

button will function only when AQUOS LINK is used. (See pages 41 to 44 for details.)

5 SLEEP: Set the sleep timer. (See page 18.) 6 0–9: Set the channel. (See page 18.) 7 • (DOT): (See pages 18 and 39.) 8 CC: Display captions from a closed-caption source. (See

page 19.)

AV MODE: Select an audio or video setting.

(See pages 20 and 24.)

10 MUTE: Mute the sound. (See page 18.)

11 VOLk/l: Set the volume. (See page 18.) 12 MENU: Display the menu screen. (See page 22.) 13 USB: Direct switch USB source.. (See page 33.)

14a/b/c/d, ENTER: Select a desired item on the screen. 15 EXIT: Turn off the menu screen. 16 FAVORITE CH: Set the favorite channels. (See page 28.) 17 A, B, C, D: Select 4 preset favorite channels in 4 different

categories. (See page 28.) While watching, you can toggle the selected channels by

pressing A, B, C and D The every key of the favorite can . select the many channels.

18 DISPLAY: Display the channel information.

19 POWER (SOURCE):20 Turns the power of the external

equipment on and off.

FREEZE

Set the still image. Press again to return to

normal screen. (See page 19.)

21 AUDIO: Display the MTS/SAP setting menu.

(See page 18.)

22 ENT: Jumps to a channel after selecting with the 0–9

buttons.

23 FLASHBACK: Return to the previous channel or external

input mode. (See page 19.)

24 VIEW MODE: Select the screen size. (See pages 20、21

and 45.)

25 INPUT: Select a TV input source. (TV, HDMI1, HDMI2,

HDMI3, HDMI4, COMPONENT/AV, PC IN , Home Network (DLNA), USB) (See pages 12 and 19.)

/ : Select the channel. (See page 18.)

26 CH 27 APPS: Display the application window. (See page 19.) 28 RETURN: Return to the previous menu screen. 29 NETFLIX: NETFLIX HOT KEY. 30 FAV APP 1, 2, 3: You can assign your favorite

applications to these buttons. (See page 28.)

Introduction to Connections

Experiencing HD Images

An HDTV without an HD source is just an ordinary TV. To enjoy HD images on the TV, you should get HD programming from the following:

• Over-the-air broadcasting via HD quality antenna

• HD cable/satellite subscription

• HD compatible external equipment

• For information on updating to HD programming, ask your cable/satellite service provider.

Types of Connection

Image quality differs depending on the terminal used. To enjoy clearer images, check the output terminals of your external equipment and use its appropriate terminals for higher quality images. For connecting the TV to external equipment, use commercially available cables.

• The illustrations of the terminals are for explanation purposes and may vary slightly from the actual products.


Quality

Standard

Quality

Terminal on external

equipment

AUDIO

DVI OUT

Cable

HDMI-certiﬁed cable

Ø 3.5 mm stereo minijack cable

DVI-HDMI conversion cable

Component video cable

Audio cable

AV cable

Terminal

on the TV

INPUT 1, 2, 3,4

AUDIO

PC/HDMI

INPUT 1, 2, 3,4

INPUT 5

Y/VIDEOPBPR

R-AUDIO-L

INPUT 5

Y/VIDEOPBPR

R-AUDIO-L

Page 13

Page 14

Displaying an External Equipment Image

To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.

INPUT

Example

Input Source

INPUT 1 HDMI 1

INPUT 2 HDMI 2 INPUT 3 HDMI 3 INPUT 4 HDMI 4 INPUT 5 COMP/AV PC IN USB

DLNA

Press INPUT.

• The INPUT list screen displays.

Press a/b to select the input source.

• You can also select the input source by pressing INPUT. Each time INPUT is pressed, the input source toggles.

HDMI3 HDMI4

• An image from the selected source automatically displays.

COMP/AVHDMI2HDMI1

PC INUSBDLNA

Connecting to External Equipment

You can connect many types of external equipment to your TV. To view external source images, select the input source from INPUT on the remote control unit or on the TV. (See pages 12 and 19.) For connecting the TV to external equipment, use commercially available cables.

CAUTION

• To protect equipment, always turn off the TV before connecting any external equipment.

• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.

Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box

When using HDMI cable (INPUT 1, 2, 3 or 4):

The HDMI (High Deﬁ nition Multimedia Interface) terminal is an audio-video interface that enables a connection for audio and video signals using a single cable. The HDMI terminal supports high-resolution video input.

• Blu-ray disc player • DVD player

• HD cable/satellite set-top box

HDMI-certiﬁed cable

INPUT 3

INPUT 4

HDMI OUT

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certiﬁ ed cable or a component cable and set the equipment to 1080p output.

• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

• when you connect ARC-compatible equipment, use INPUT 4.

When using DVI-HDMI conversion cable (INPUT 1, 2, 3 or 4):

Blu-ray disc player •DVD player

•

• HD cable/satellite set-top box

Ø 3.5 mm stereo minijack cable

AUDIO

PC/HDMI

DVI-HDMI conversion cable

AUDIO DVI OUT

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to connecting a DVI-HDMI conversion cable to the INPUT 1, 2, 3 or 4 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO PC/HDMI terminal and set "Audio Select" to "HDMI+Analog". (See page 46.)

INPUT 3

INPUT 4

Connecting to External Equipment

When using Component cable (INPUT 5):

Blu-ray disc player •DVD player

•

• HD cable/satellite set-top box

INPUT 5

Y/VIDEOPBPR

Component video cable

Y (

Yellow

(Blue)

(Red)

)

AUDIO-L (White)

Audio cable

COMPONENT OUT

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certiﬁ ed cable or a component cable and set the equipment to 1080p output.

• See page 13 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the HDMI terminal.

AUDIO-R (Red)

R-AUDIO-L

Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box

When using Composite cable (INPUT 5):

Game console •VCR

•

Camcorder

•

• Cable/Satellite set-top box

AV cable

VIDEO (Yellow)

INPUT 5

Y/VIDEOPBPR

AUDIO-L (White)

AUDIO-R (Red)

R-AUDIO-L

Connecting to External Equipment

Connecting an Audio Ampliﬁ er

When using Digital coaxial cable:

It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 26 for details.) PCM audio outputs from the terminal.

Digital coaxial cable

DIGITAL AUDIO INPUT

• Digital Audio output is not available when using an HDMI input.

When using audio cable:

Audio cable

ANALOG AUDIO IN

• See page 27 for details on the Output Select function.

Connecting an AV Ampliﬁ er

HD Cable/Satellite set-top box

HDMI-certiﬁed cable

HDMI OUT

DIGITAL

AUDIO OUTPUT

INPUT 3

INPUT 4

HDMIINHDMI

OUT

• If the image is not in sync with the audio, check the settings of the connected surround system.

• Letting the TV output the audio to an AV ampliﬁ er:

When you connect ARC-compatible equipment, use the INPUT 4 terminal.

If the equipment to be connected is not compatible with the ARC, connect a digital coaxial cable.

Connecting to External Equipment

Connecting a PC

Refer to page 46 for a list of PC signals compatible with the TV.

When using HDMI cable (INPUT 1, 2, 3 or 4):

HDMI-certiﬁed cable

INPUT 3

INPUT 4

HDMI OUT

• Depending on the board, only video signals may be output. In this case, in addition to connecting an HDMI-certiﬁ ed cable to the INPUT 1, 2, 3 or 4 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO PC/HDMI terminal and set "Audio Select" to "HDMI+Analog". (See page 27.)

The HDMI terminals only support digital signal.

•

When using DVI-HDMI conversion cable (INPUT 1, 2, 3 or 4):

Ø 3.5 mm stereo minijack cable

AUDIO

DVI OUT

AUDIO

PC/HDMI

INPUT 3

DVI-HDMI conversion cable

INPUT 4

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to connecting a DVI-HDMI conversion cable to the INPUT 1, 2, 3 or 4 terminal, connect to the AUDIO PC/HDMI terminal and set "Audio Select" to "HDMI+Analog". (See page 27.)

a Ø 3.5 mm stereo minijack cable

When using analog RGB cable (PC IN):

Analog RGB cable

(D-sub 15-pin cable or VGA cable)

Ø 3.5 mm stereo minijack cable

AUDIORGB

PC IN

AUDIO

PC/HDMI

• When using an analog RGB cable, input the audio signal to the AUDIO PC/HDMI terminal of PC IN.

• When connecting a PC to the PC IN, set "Audio Select" to "Video+Audio". (See page 27.)

Watching TV

Turning On/Off the Power

POWER (On/Standby)

POWER

Press POWER on the TV or on the remote control unit to turn the power on.

• The Initial Installation starts when the TV powers on for the

ﬁ rst time. If the TV has been turned on before, the Initial Installation will not be invoked. For changing the settings of the Initial Installation, perform "EZ setup" on the Initial Setup menu on page 28.

Press POWER on the TV or on the remote control unit again to turn the power off.

• The TV enters standby and the image on the screen

disappears.

• If you are not going to use this TV for a long period of time,

be sure to remove the AC cord from the AC outlet.

• Weak electric power is still consumed even when the TV is

turned off.

Initial Installation

When you turn on the TV for the ﬁ rst time, it will automatically memorize the broadcasting channels available in the region where you live. Perform the following steps before you press POWER on the remote control unit.

Insert the batteries into the remote control unit. (See page 9.)

2. Connect the antenna cable to the TV. (See page 9.)

3. Plug in the AC cord to the AC outlet. (See page 8.)

Language (Language setting)

Select from among 3 languages: English, French and Spanish.

Press a/b to select the desired language listed

on the screen, and then press ENTER.

Select where the TVwill be placed. the picture will be optimized for that location.

Home

Store

Home:

“Power Saving” is set to "On", and AV MODE

to "STANDARD".

Store: “Power Saving” is set to "Off" and AV MODE is set

to "DYNAMIC (Fixed)". Picture Reset and Feature Demo can be set.

• ENERGY STAR qualiﬁ cation is based on AV MODE "STANDARD".

is set

Air/Cable (Antenna setting)

Make sure what kind of connection is made with your TV when selecting "Air" or "Cable".

Press /to select "Air" or "Cable".

Press ENTER to enter the setting.

Air

Cable

CH Search (Channel search)

Channel auto search makes the TV look for all channels viewable in the set area.

When "Air" or "cable" is selected in Antenna

setting:

Press / to select "Start", and then press ENTER.

a b

Start

Cancel

Completed

After setting complete.the screen will show EZ

setup Completed.

EZ Setup Completed

English

Français

Español

TV Location

Select "Home" or "Store" for the location where you plan to install the TV. This product qualiﬁ es for ENERGY STAR in Home mode default setting.

a/b

Press to select "Home" or "Store".

Press ENTER to enter the setting.

•

If no channel is found, conﬁ rm the type of connection made with your TV and try "EZ Setup" again. (See page 28.)

•

For changing the settings of the Initial Installation, perform "EZ setup" on the Initial Setup menu on page 28.

Direct Button Operation

Changing Channels

You can change channels in several ways.

Method 1 Using CH/ on the remote control unit or on the TV. Method 2 Using remote control buttons 0-9, • (DOT).

Examples: To select a 1 or 2-digit channel number (e. g., Channel 5): Press 5 ENT. To select a 3-digit channel number (e. g., Channel 115): Press 1 1 5 ENT. To select a 4-digit channel number (e. g., Channel 22.1):

Press 2 2 • (DOT) 1 ENT.

•

When selecting a 1-digit channel number, it is not necessary to press 0 before the number.

•

When you enter 0-9 only, channel selection will be made if there is no operation within a few seconds.

•

If you push "0" by itself, nothing will happen.

•

Complete the above steps within a few seconds.

•

When you enter 0-9 and • (DOT), channel selection will be made if there is no operation within a few seconds.

Changing Volume

You can change the volume by pressing VOLk/l on the TV or on the remote control unit.

•

To increase the volume, press VOLk.

•

To decrease the volume, press VOLl.

MUTE

Mutes the current sound output. Press MUTE

•

" " will be displayed on the screen , and the sound is

silenced.

•

Mute can be

canceled by pressing VOLk/l or MUTE.

Sleep Timer

Allows you to set a time when the TV automatically switches to standby. Press SLEEP.

•

The remaining time displays when the sleep timer has been set.

•

Each time you press SLEEP, the remaining time switches as shown below.

Off 30 60 90 120

•

When set, the time automatically starts counting down.

•

If you want to adjust the sleep timer, you can press SLEEP twice then change the time setting.

•

Select "Off" by pressing SLEEP to cancel the sleep timer.

•

The TV will enter standby when the remaining time reaches 0.

AUDIO

MTS/SAP stereo mode

The TV has a feature that allows reception of sound other than the main audio for the program. This feature is called Multi-channel Television Sound (MTS). The TV with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.

You can enjoy Hi-Fi stereo sound or SAP broadcasts where available.

• Stereo broadcasts: View programs like live sporting events, shows and concerts in dynamic stereo sound.

• SAP broadcasts: Receive TV broadcasts in either MAIN or SAP sound.

MAIN sound: The normal program soundtrack (either in mono or stereo). SAP sound: Listen to a second language, supplementary commentary or other information. (SAP is mono sound.)

If stereo sound is difﬁ cult to hear.

• Obtain a clearer sound by manually switching to ﬁ xed mono-sound mode.

You can change MTS as shown below to match the television broadcast signal.

Press ENTER to toggle between audio modes.

Examples: when receiving MTS and SAP

STEREO mode: STEREO + SAP mode:

MAIN + SAP mode: MONO mode: MONO

Digital broadcasting audio mode

The types of audio transmitted in a digital broadcast include SURROUND as well as MONO and STEREO. In addition, it is possible for multiple audio tracks to accompany a single video track.

Press ENTER to toggle between audio modes.

Example: when receiving Digital broadcasting

STEREO (Audio1) STEREO (Audio2) SURROUND (Audio3)

STEREO MONO

ST(SAP) SAP(ST) MONO

MAIN SAP

• MTS only operates while in TV mode.

Direct Button Operation

FLASHBACK

Press FLASHBACK to switch to the previously tuned channel.

•

Press FLASHBACK again to switch back to the currently tuned channel.

•

FLASHBACK will not work if no channel has been changed after the TV is turned on.

FREEZE

Allows you to capture and freeze a moving image that you are watching. Press FREEZE.

•

A moving image is captured.

•

Press FREEZE again to cancel the function.

•

When this function is not available, "No Function." will display.

•

If you are using the freeze function and a broadcast activates the V-CHIP BLOCK, the freeze function will be canceled and a V-CHIP BLOCK message will appear.

• You can have the same settings by choosing "Freeze" on the menu items. (See page 26.)

APPS

Allows you to directly activate various types of applications.

Press APPS to display the application window.

Press a/b/c/d to select the desired application,

and then press ENTER.

• If " " is displayed after you switch to USB mode, check the USB connection.

" or " " is displayed after you switch to Home

• If "

Network (DLNA) mode or after you connect to the Internet, check your TV's network settings and connection.

• See pages 34 to 38, 51 and 52 for details of viewable applications.

• You can display the application window by choosing "APPS" on the menu items. (See page 26.)

• When this function is not available, "Can not operate this function now" will display.

INPUT

To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.

Press INPUT.

• The INPUT list screen displays.

Press a/b or press INPUT again to select the

input source.

• An image from the selected source automatically displays.

• Each time INPUT is pressed, the input source toggles.

See pages 12 to 16 and 41 for external equipment

•

connection.

Closed Captions and Digital Closed Captions

Your TV is equipped with an internal Closed Caption decoder. It allows you to view conversations, narration and sound effects as subtitles on your TV. Closed Captions are available on some TV programs and on some VHS home video tapes at the discretion of the program provider. Digital Closed Caption service is a new caption service available only on digital TV programs (also at the discretion of the service provider). It is a more ﬂ exible system than the original Closed Caption system, because it allows for a variety of caption sizes and font styles. When the Digital Closed Caption service is in use, it will be indicated by the appearance of a 3-letter abbreviation that also indicates the language of the Digital Closed Captions: ENG (English), SPA (Spanish), FRA (French) or other language codes.

Not all programs and VHS videotapes offer closed captions. Please look for the “ that captions will be shown. In the Closed Caption system, there can be more than one caption service provided. Each is identiﬁ ed by its own number. The “CC1” and “CC2” services display subtitles of TV programs superimposed over the program's picture.

In the Closed Caption system, the “Text1” or “Text2” services display text that is unrelated to the program being viewed (e.g., weather or news). These services are also superimposed over the program currently being viewed.

Press CC.

•

This will present the Closed Caption information display.

Press CC while the Closed Caption information is

still on the screen.

• Press repeatedly until you select the desired closed caption service.

Air

ANALOG

Stereo 480i SD CC:CC4

MPAA-R

• In the Closed Caption system, there can be more than

one caption service provided. Each is identiﬁed by its own number. The “CC1” to “CC4” services display subtitles of TV programs superimposed over the program's picture. In the Closed Caption system, the “TEXT1” to “TEXT4” services display text that is unrelated to the program being viewed (e.g., weather or news). These services are also superimposed over the program currently being viewed.

Example:

CC1 CC2 CC3 CC4 TT1 TT2 TT3　 TT4 OFF

ANALOG

” symbol to ensure

Closed Caption information

CS5

DIGITAL

CS4

CS2CS3

CC1 CC2 CC3 CC4 TT1 TT2 TT3 TT4

OFF

CS6

CS1

+ 45 hidden pages
