Page 1
MODEL
LC-40LE700X
LCD COLOUR TELEVISION
OPERATION MANUAL
Cover_LC-40LE700X.indd 1Cover_LC-40LE700X.indd 1 7/8/09 10:37:03 AM7/8/09 10:37:03 AM
Page 2
Cover_LC-40LE700X.indd 2Cover_LC-40LE700X.indd 2 6/12/09 1:42:46 PM6/12/09 1:42:46 PM
Page 3
OPERATION MANUAL
Dear SHARP customer
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of
trouble-free operation of your product, please read the Important Safety Precautions carefully before
using this product.
Contents
Introduction
Dear SHARP customer ................................................................................................................. 1
Contents ......................................................................................................................................... 1
Important Safety Precautions ...................................................................................................... 4
Supplied accessories .................................................................................................................... 5
Trademarks .................................................................................................................................... 5
Preparation
Attaching the stand ....................................................................................................................... 6
Part names ..................................................................................................................................... 7
Before turning on the power ...................................................................................................... 10
Supplying electric power to the antenna ................................................................................. 11
Initial auto installation................................................................................................................. 11
Checking signal strength and channel strength ...................................................................... 12
Connecting external devices ..................................................................................................... 13
Inserting the batteries ................................................................................................................ 15
Using the remote control unit .................................................................................................... 15
Turning the TV on/off .................................................................................................................. 16
About Menu operations .............................................................................................................. 17
Watching TV
Setting channels automatically .................................................................................................. 20
Selecting programmes ............................................................................................................... 21
Adjusting the volume .................................................................................................................. 21
Menu language settings ............................................................................................................. 21
Setting channels to your preference ......................................................................................... 22
Useful viewing functions ............................................................................................................ 26
TV (Front/Side) ................................................................................................................. 7
TV (Rear) .......................................................................................................................... 8
Remote control unit ......................................................................................................... 9
Connecting a VCR, game console or camcorder .......................................................... 13
Connecting a DVD player .............................................................................................. 13
Connecting a STB (Satellite, Cable, etc.) ....................................................................... 14
Connecting a PC ............................................................................................................ 14
Cautions regarding the remote control unit ................................................................... 15
Turning on the power ..................................................................................................... 16
Turning off the power..................................................................................................... 16
What is Menu? ............................................................................................................... 17
Basic Menu operations .................................................................................................. 17
About the Guide Display ................................................................................................ 17
Blue illumination Emblem .............................................................................................. 17
Menu items (TV/INPUT 4-6) ........................................................................................... 18
Menu items (HDMI/RGB) ............................................................................................... 19
Digital settings ...............................................................................................................22
Manual setting for each channel (Analogue) .................................................................. 23
Sorting programmes ...................................................................................................... 25
Erasing programmes...................................................................................................... 25
Returning to the previously selected channel ................................................................ 26
Freezing the image ........................................................................................................ 26
Muting the audio temporarily ......................................................................................... 26
Outputting only audio .................................................................................................... 26
Switching the analogue audio format ............................................................................ 27
Switching the digital audio format ................................................................................. 27
Password setting for the child lock (for TV input mode) ................................................ 28
Parental rate...................................................................................................................29
Programme title display ................................................................................................. 29
1
LC-40LE700X_en_a.indd 1LC-40LE700X_en_a.indd 1 7/1/09 9:40:54 AM7/1/09 9:40:54 AM
Page 4
Contents
Watching TV (Continued)
Energy conservation settings .................................................................................................... 30
Picture size settings ................................................................................................................... 31
Selecting a preset AV MODE .....................................................................................................33
Manual picture settings .............................................................................................................. 34
Other picture settings ................................................................................................................. 36
Audio adjustment ........................................................................................................................ 38
ATV (Analogue)/DTV/RADIO buttons ........................................................................................ 41
EPG ............................................................................................................................................... 42
Selecting a programme using EPG ........................................................................................... 43
Timer setting using EPG ............................................................................................................. 45
Cancelling the timer setting ....................................................................................................... 45
Settings when using external devices
Settings when using HDMI output devices ............................................................................... 46
Selecting the input source and signal type .............................................................................. 47
Labelling input sources .............................................................................................................. 48
Skipping HDMI/RGB input .......................................................................................................... 48
Colour system settings ............................................................................................................... 48
Setting display colour ................................................................................................................. 49
Channel selecting effect ............................................................................................................. 49
AQUOS LINK
Controlling HDMI devices using AQUOS LINK ......................................................................... 50
AQUOS LINK connection ............................................................................................................ 51
AQUOS LINK setup ..................................................................................................................... 51
Operating an AQUOS LINK device ............................................................................................ 52
Key lock ......................................................................................................................... 29
Auto power-off at a designated time ............................................................................. 30
ECO picture control ....................................................................................................... 30
Energy save ................................................................................................................... 30
Auto power-off after the end of broadcast .................................................................... 30
Auto power-off when there are no operations performed ............................................. 30
Quick start ..................................................................................................................... 31
Selecting the Wide Screen Signalling (WSS) picture size automatically ....................... 31
Selecting the Wide Screen Signalling (WSS) picture size manually .............................. 31
Selecting the picture size manually ............................................................................... 32
Picture adjustment ......................................................................................................... 34
Advanced picture settings ............................................................................................. 35
Adjusting the image position ......................................................................................... 36
Game play time .............................................................................................................. 36
Indicating time on the screen ........................................................................................ 37
Output volume select ..................................................................................................... 38
Automatic volume adjustment ....................................................................................... 39
Clear voice ..................................................................................................................... 39
Digital audio output........................................................................................................ 39
Using Digital Audio Output ............................................................................................ 40
Programme Guide.......................................................................................................... 40
Info ................................................................................................................................. 40
EPG display settings ...................................................................................................... 42
Time zone ......................................................................................................................42
Basic Operation ............................................................................................................. 43
Selecting a programme ................................................................................................. 43
Selecting input source ................................................................................................... 47
Selecting input signal type ............................................................................................. 47
Selecting the size of the picture for recording ............................................................... 47
Connecting an AQUOS BD Player/AQUOS Recorder via the
AQUOS AUDIO speaker system .............................................................................. 51
Connecting an AQUOS BD Player/AQUOS Recorder only ........................................... 51
AQUOS LINK control ..................................................................................................... 51
Auto power on ............................................................................................................... 52
Selecting recorder ......................................................................................................... 52
Selecting channel key .................................................................................................... 52
Using genre info. ........................................................................................................... 52
Listening with the AQUOS AUDIO speaker system ...................................................... 53
Listening with the AQUOS TV speaker system ............................................................ 53
Manually changing the AQUOS AUDIO speaker system’s sound
mode ........................................................................................................................ 53
Calling up the menu of an external device connected with the TV via HDMI ............... 53
2
LC-40LE700X_en_a.indd 2LC-40LE700X_en_a.indd 2 7/8/09 8:47:38 AM7/8/09 8:47:38 AM
Page 5
Contents
AQUOS LINK (Continued)
Connecting a PC
HDMI Connection ........................................................................................................................ 55
Analogue Connection ................................................................................................................. 55
PC audio select ........................................................................................................................... 56
Displaying a PC image on the screen ....................................................................................... 56
PC Control of the TV ................................................................................................................... 58
PC compatibility chart ................................................................................................................ 59
RS-232C commands list ............................................................................................................. 59
Teletext function
About Teletext ............................................................................................................................. 60
Teletext language setting ........................................................................................................... 61
Displaying Subpages .................................................................................................................. 61
Time display ................................................................................................................................. 61
Displaying Subtitles .................................................................................................................... 62
Switching subtitle languages .................................................................................................... 62
Appendix
Troubleshooting .......................................................................................................................... 63
Troubleshooting-Digital broadcasting ...................................................................................... 63
Error messages about recording using AQUOS LINK ............................................................. 64
Reset ............................................................................................................................................ 65
Download setup .......................................................................................................................... 65
Information .................................................................................................................................. 65
Identifi cation ................................................................................................................................ 65
Specifi cations .............................................................................................................................. 66
Optional accessory ..................................................................................................................... 66
Dimensional drawings ................................................................................................................ 67
Mounting the TV on the wall ...................................................................................................... 68
Protection against overturning .................................................................................................. 69
CLEARING THE PASSWORD ..................................................................................................... 70
Information on the software license for this product .............................................................. 71
Playback of titles using AQUOS LINK .......................................................................... 53
Selecting media type for CEC-compatible recorder ...................................................... 54
HDMI device selection ................................................................................................... 54
Recording via the AQUOS Recorder EPG (only for recorders) ...................................... 54
Selecting the picture size ............................................................................................... 56
Adjusting the PC image automatically ........................................................................... 57
Adjusting the PC image manually .................................................................................. 57
Message list ...................................................................................................................65
Receiver report .............................................................................................................. 65
Removing the stand ....................................................................................................... 68
Handling and precautions with the wall-mounted TV .................................................... 68
3
LC-40LE700X_en_a.indd 3LC-40LE700X_en_a.indd 3 7/9/09 7:06:59 PM7/9/09 7:06:59 PM
Page 6
Important Safety Precautions
• Cleaning — Unplug the AC cord
from the AC outlet before cleaning
the product. Use a soft damp cloth
to clean the product. Do not use
liquid cleaners, aerosol cleaners or
chemical cloth to clean it, as such
materials may damage the product.
• Water and moisture — Do not use
the product near water, such as
bathtub, washbasin, kitchen sink,
laundry tub, swimming pool and in a
wet basement.
• Do not place vases or any other
water-fi lled containers on this
product. The water may spill onto
the product causing fi re or electric
shock.
• Stand — Do not place the product
on an unstable cart, stand, tripod
or table. Doing so can cause the
product to fall, resulting in serious
personal injuries as well as damage
to the product. Use only a cart,
stand, tripod, bracket or table
recommended by the manufacturer
or sold with the product. When
mounting the product on a wall, be
sure to follow the manufacturer's
instructions. Use only the mounting
hardware recommended by the
manufacturer.
• When relocating the product
placed on a cart, it must be moved
with utmost care. Sudden stops,
excessive force and uneven fl oor
surface can cause the product to fall
from the cart.
• Heat sources — Keep the product
away from heat sources such as
radiators, heaters, stoves and other
heat-generating products (including
amplifi ers).
• To prevent fi re, never place any type
of candle or naked fl ames on the
top or near the TV set.
• To prevent fi re or shock hazard, do
not place the AC power cord under
the TV set or other heavy items.
• Do not place heavy objects on this
product or stand on it. Doing so
could cause injury if the product
overturns. Take special care near
children and pets.
The LCD panel is a very high technology product
with 2,073,600 pixels, giving you fi ne picture details.
Due to the very large number of pixels, occasionally
a few non-active pixels may appear on the screen
as a fi xed point of blue, green or red.
This is within product specifi cations and does not
constitute a fault.
Precautions when
transporting the TV
Be sure to always carry the TV
by two people holding it with two
hands — one hand on each side
of the TV.
• Ventilation — The vents and other
openings in the cabinet are designed
for ventilation. Do not cover or block
these vents and openings since
insuffi cient ventilation can cause
overheating and/or shorten the life
of the product. Do not place the
product on a bed, sofa, rug or other
similar surface, since they can block
ventilation openings. This product is
not designed for built-in installation;
do not place the product in an
enclosed place such as a bookcase
or rack, unless proper ventilation
is provided or the manufacturer's
instructions are followed.
• The LCD panel used in this product
is made of glass. Therefore, it can
break when the product is struck
forcefully or with a sharp object. If
the LCD panel is broken, be careful
not to be injured by broken glass.
4
LC-40LE700X_en_b.indd 4LC-40LE700X_en_b.indd 4 6/30/09 5:29:27 PM6/30/09 5:29:27 PM
• Do not display a still picture for a long time, as this could
cause an afterimage to remain.
• Install the product on the place where the AC cord can
be unplugged easily from the AC outlet, or from the AC
INPUT terminal on the rear of the product.
If a television is not positioned in a suffi ciently stable
location, it can be potentially hazardous due to falling.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as:
• Using cabinets or stands recommended by the
manufacturer of the television.
• Only using furniture that can safely support the
television.
• Ensuring the television is not overhanging the edge of
the supporting furniture.
• Not placing the television on tall furniture (for example,
cupboards or bookcases) without anchoring both the
furniture and the television to a suitable support.
• Not standing the televisions on cloth or other materials
placed between the television and supporting furniture.
• Educating children about the dangers of climbing on
furniture to reach the television or its controls.
Page 7
Supplied accessories
Make sure the following accessories are provided with the product.
Remote control unit
Used with batteries inserted.
Page 9
Cable clamp Stand unit
For bundling cables.
Page 10
Operation manual
“AAA” size battery (g2)
Page 15 Page 10
Stand base
Stand post
Put all parts of the stand unit together and then attach it to the TV. Page 6
AC cord
Always use the AC cord supplied with
the TV.
Short screws (g4)
Long screws (g4)
Safety restrains
Restraining
band
Screw for
band
Clamps
Page 69
Screws for
clamps
Trademarks
• TruSurround HD, SRS and symbol are trademarks of SRS Labs, Inc.
TruSurround HD technology is incorporated under license from SRS Labs, Inc.
• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
• “HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
• and LC logo mark are registered trademarks of SHARP Corporation.
This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly displaying
easy-to-read characters on LCD screens. However, other fonts are used for some screen pages, too.
5
LC-40LE700X_en_b.indd 5LC-40LE700X_en_b.indd 5 7/8/09 9:33:17 AM7/8/09 9:33:17 AM
Page 8
Preparation
Attaching the stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work, spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Confi rm the 8 screws supplied with the TV.
1 3
Short screws (g4)
(used in step 3)
Attach the supporting post for the stand unit
2
onto the base as shown below.
Long screw
Long screws (g4)
(used in step 2)
Screw
driver
(not supplied)
• To detach the stand, perform the steps in reverse order.
1 Insert the stand into the openings on the
bottom of the TV.
2 Insert and tighten the 4 short screws into
the 4 holes on the rear of the TV.
Screw
driver
(not supplied)
Short screw
Soft
cushion
1
1
NOTE
6
LC-40LE700X.indb 6LC-40LE700X.indb 6 6/26/09 4:25:31 PM6/26/09 4:25:31 PM
Page 9
Preparation
Part names
TV (Front/Side)
POWER (On/Off) button
MENU button
TV/VIDEO button
Channel up (r)/down (s) buttons
Volume up (e)/down (f) buttons
POWER indicator**
Blue illumination Emblem***
OPC indicator*
*OPC: Optical Picture Control (See page 34.)
** See page 16 for the TV status indicator.
*** Blue illumination Emblem (See page 17.)
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
LC-40LE700X.indb 7LC-40LE700X.indb 7 6/26/09 4:25:32 PM6/26/09 4:25:32 PM
OPC sensor
Remote control sensor
7
Page 10
Preparation
TV (Rear)
INPUT 3 (HDMI)
terminal
INPUT 5 terminals
AC INPUT terminal
Headphone jack
INPUT 2 (HDMI)
terminal
RS-232C terminal
MONITOR OUT
terminals
*Usually do not connect anything to this terminal as it is reserved only for service personnel.
**The INPUT 1 and INPUT 7 terminals can both use the same audio input terminal. However, the proper item must be selected
in the “PC audio select” menu. (See page 56.)
PD446WJ
INPUT 4 terminals
INPUT 6 terminals
INPUT 1 (HDMI)
terminals**
SERVICE ONLY
terminal*
INPUT 7 (PC)
terminals**
Antenna input
terminal
DIGITAL AUDIO OUTPUT terminal
Regarding the headphone jack
• Use headphones with a stereo mini plug ( 3.5 mm).
• Be sure to unplug headphones from the jack when they are not
in use.
• The speakers do not output volume when headphones are
plugged in.
• The “Audio” menu cannot be operated when headphones are
plugged in.
• You can set the volume to different levels for each input source.
8
LC-40LE700X.indb 8LC-40LE700X.indb 8 6/26/09 4:25:33 PM6/26/09 4:25:33 PM
Volume display when headphones are plugged in
20
Page 11
Preparation
Remote control unit
1
13
2
3
4
5
6
7
8
9
10
14
15
16
17
18
19
20
21
22
11
23
24
12
25
1 POWER (STANDBY/ON)
To switch the power on and off. (See page 16.)
2 0 – 9
Set the channel. (See page 21.)
TELETEXT mode: Set the page. (See pages 60 and 61.)
3 A (Flashback)
Press to return to the previous selected channel or external input
mode. (See page 26.)
4 ATV
Press to access ANALOGUE mode. (See page 41.)
5 DTV
Press to access DTV mode. (See page 41.)
6 MPX
Select the sound multiplex mode. (See page 27.)
7 VOLk/VOL
Set the volume. (See page 21.)
8 e (Mute)
Mute the sound. (See page 26.)
9 GUIDE
DTV mode: Display the programme list. (See page 40.)
l
10 EPG
DTV mode: To display EPG (Electronic Programme Guide) screen.
(See pages 42 to 45.)
11 EXIT
Turn off the On-Screen Display.
12 OPC
To switch the Optical Picture Control on and off. (See page 34.)
WIDE
Change the wide image mode. (See pages 32 and 56.)
FREEZE
Freeze a motion picture on the screen. (See page 26.)
13 m (TELETEXT)
Select the TELETEXT mode. (all TV image, all TEXT image, TV/
TEXT image) (See pages 60 to 61.)
(Reveal hidden for TELETEXT)
k
TELETEXT mode: Display hidden characters. (See page 60.)
(SUBTITLE)
[
To turn the subtitles on and off. (See page 62.)
(Hold)
3
TELETEXT mode: Stop updating Teletext pages automatically.
Press 3 again to release the hold mode. (See page 60.)
(Subpage)
1
Display the Teletext subpage directly. (See page 61.)
(Top/Bottom/Full)
v
TELETEXT mode: Set the area of magnifi cation. (See page 60.)
14 TV/VIDEO (INPUT SOURCE)
Select an input source. (TV, INPUT1, INPUT2, INPUT3, INPUT4,
INPUT5, INPUT6, INPUT7 (PC)) (See pages 13, 46, 48 and 55.)
15 AV MODE
Select a video setting. (See page 33.)
16 RADIO
Press to access RADIO mode. (See page 41.)
17 DISPLAY
Displays the channel or input information.
DTV mode: Displays the time information included in the DTV
broadcast.
ATV mode: Displays the time information included in the Teletext
broadcast. (See page 61.)
18 CHr/CH
TV input mode: Select the channel. (See page 21.)
TELETEXT mode: Select the page. (See pages 60 and 61.)
19 SLEEP
Set the Sleep timer. (See page 30.)
20 INFO
DTV mode: Display the programme information. (See page 40.)
21 MENU
Display the menu screen. (See page 17.)
22 a/b/c/d (Cursor)
Select a desired item on the setting screen.
ENTER
Execute a command.
23 RETURN
MENU mode: Return to the previous menu screen. (See page 17.)
24 Colour (Red/Green/Yellow/Blue)
TELETEXT mode: Select a page. (See page 60.)
25 AQUOS LINK buttons
If external equipment such as a AQUOS BD Player is connected
via HDMI cables and is AQUOS LINK compatible, you can use
these AQUOS LINK buttons. (See pages 50 to 54 for details.)
s
9
LC-40LE700X_en_b.indd 9LC-40LE700X_en_b.indd 9 7/9/09 7:07:43 PM7/9/09 7:07:43 PM
Page 12
Preparation
Before turning on the power
Notes on installing the TV
• Avoid direct sunlight and place the TV in a well-ventilated location.
• Place the TV in a level location.
• Do not turn on the power of the TV before connecting the AC cord.
Connecting the antenna cable
1
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of
connections that are used for coaxial cable.
Standard DIN45325 plug (IEC169-2)
75-ohm coaxial cable (round cable)
Antenna cable
(commercially available)
Room antenna terminal
(75-ohm type)
Connecting external devices
2
See pages 13 and 14 for connecting external equipment, such as a VCR and DVD player.
Connecting the AC cord
3
AC outlet
• Place the TV close to the AC outlet, and keep the power plug within reach.
• Disconnect the AC cord from the AC outlet if the TV will not be used for a long period of time.
Bundling the cables
4
Insert the cable clamp in the hole on the TV as shown.
To antenna
terminal
TV (rear view)
AC cord
Cable clamp
CAUTION
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE
AC CORD CONNECTED.
10
LC-40LE700X.indb 10LC-40LE700X.indb 10 6/26/09 4:25:34 PM6/26/09 4:25:34 PM
Page 13
Preparation
Supplying electric power to the
antenna
When you set-up the DTV antenna for the fi rst time,
or connect the antenna to a community antenna, you
need to proceed to set the antenna by following this
manual.
Press DTV to access DTV mode.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
3
Initial auto installation
When the TV powers on for the fi rst time after purchase,
the initial auto installation wizard appears. Follow the
menus and make the necessary settings one after
another.
Confi rm the following before turning on the
power
• Is the antenna cable connected?
• Is the AC cord plugged in?
Press POWER on the TV.
1
• The initial auto installation wizard appears.
Setting the on-screen display language.
2
Press a/b to select the desired language,
3
and then press ENTER.
Press c/d to select “HOME” or “STORE”,
and then press ENTER.
Display language settings
English
Select the location of TV.
The picture will be optimized for that location.
Press a/b to select “Antenna setup-DIGITAL”
4
and then press ENTER.
Press a/b to select “Supply voltage” and
5
then press ENTER.
Press c/d to select “On” and then press
6
ENTER.
Selected item Description
On Select “On” when your antenna is set-up
Off Select “Off” when you do not need to
and connected independently.
Typical supply voltage: 5V
Typical supply current: 50mA
supply voltage to your antenna, i.e.
when your antenna is connected to a
community antenna. (The factory default
setting of this function is “Off”.)
HOME
• HOME: “STANDARD” will be the default value for
the “AV MODE” setting.
• STORE: “DYNAMIC (Fixed)” will be the default
value for the “AV MODE” setting. If the “AV
MODE” is changed, the TV will automatically
switch back to “DYNAMIC (Fixed)” when there is
no further change to TV setting for 30 minutes.
Press ENTER.
4
Major Analogue Channel settings are pre-set.
However, if there are any channel(s) that you
cannot receive with the factory pre-sets, please
perform “Auto Installation” in “Setup” section
(refer chapter “Watching TV” on manual).
Digital Search
• Major Analogue Channel settings are pre-set.
However, if there are any channel(s) that you
cannot receive with the factory pre-sets, please
perform “Auto installation” in “Setup” section.
(See page 20.)
STORE
11
LC-40LE700X_en_b.indd 11LC-40LE700X_en_b.indd 11 7/8/09 9:34:53 AM7/8/09 9:34:53 AM
Page 14
Preparation
Initial auto installation (continued)
The TV searches for, sorts and stores all
5
the receivable TV stations according to their
settings and the connected antenna.
• To abort the initial auto installation in progress,
press RETURN.
NOTE
• HOME mode: Settings are optimised for normal home
viewing and energy effi ciency.
• STORE mode: Settings are designed for maximum impact
in retail store displays.
• To change the STORE mode to HOME mode, please refer
to page 65 to reset the unit.
• If you turn off the power on the TV after performing step
4, the initial auto installation wizard does not appear. The
auto installation function allows you to execute the auto
installation again from the Setup menu. (Page 20)
• The initial auto installation wizard will go off if you leave
the TV unattended for 30 minutes before searching for
channels in step 5.
Checking signal strength and
channel strength
If you install a DVB-T antenna for the fi rst time or
relocate it, you should adjust the alignment of the
antenna to receive a good reception while checking
the antenna setup screen.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Antenna setup-
3
DIGITAL”, and then press ENTER.
H Checking signal strength
Press a/b to select “Signal strength”.
Supply voltage
Signal strength
Channel strength
CH No. 21
Signal strength
Current Max. 0
Quality
Current Max. 0 0
0
H Checking channel strength
Press a/b to select “Channel strength”, and
then press ENTER.
Supply voltage
Signal strength
Channel strength
Position and align the antenna so that the
4
maximum possible values for “Signal strength”
and “Quality” are obtained.
NOTE
• The values of “Signal strength” and “Quality” indicate when
to check the appropriate alignment of the antenna.
12
LC-40LE700X.indb 12LC-40LE700X.indb 12 6/26/09 4:25:36 PM6/26/09 4:25:36 PM
2 6 5 . 2
CH No. 21
Signal strength
Current Max. 0
Quality
Current Max. 0 0
MHz
0
Page 15
Preparation
Connecting external devices
You can connect many types of external equipment to your TV, like a VCR, game console, camcorder, DVD player,
Digital TV STB (Set Top Box) and PC. To view input source images, select the input source from TV/VIDEO on
the remote control unit or TV/VIDEO on the TV.
CAUTION
• To protect all equipment, always turn off the TV before connecting to a VCR, game console, camcorder, DVD player, Digital
TV STB (Set Top Box), PC or other external equipment.
• Refer to the relevant operation manual (VCR, DVD player, etc.) carefully before making connections.
Connecting a VCR, game console or camcorder
A VCR, game console, camcorder and some other audiovisual equipment can be conveniently connected using
the INPUT 5 or INPUT 4/INPUT 6 terminals.
When using component cable
(commercially available)
VCR/Game console/
Camcorder
Y
(CB)
PB
R
P
R – AUDIO – L
(CR)
When using composite cable or
S-VIDEO cable (commercially available)
S-VIDEO
or
R
AUDIO
L
VIDEO
VCR/
Game console/
Camcorder
Connecting a DVD player
You can use the INPUT 1/INPUT 2/INPUT 3 (HDMI) or INPUT 4/INPUT 6 terminals when connecting to a DVD
player and other audiovisual equipment.
When using HDMI cable
(commercially available)
DVD player
When using component cable
(commercially available)
(CB)
Y
DVD player
P
B
R
P
R – AUDIO – L
(CR)
13
LC-40LE700X.indb 13LC-40LE700X.indb 13 6/26/09 4:25:37 PM6/26/09 4:25:37 PM
Page 16
Preparation
Connecting a STB (Satellite, Cable, etc.)
You can use the INPUT 1/INPUT 2/ INPUT 3 (HDMI) or INPUT 4/INPUT 6 terminals when connecting to a STB
(Satellite, Cable, etc.) and other audiovisual equipment.
When using HDMI cable
(commercially available)
When using component cable
(commercially available)
STB
(Set Top Box)
Connecting a PC
You can use the INPUT 7 (PC) terminal when connecting to a PC.
STB
(Set Top Box)
PB
R
P
R – AUDIO – L
(CB)
(CR)
Y
PC
14
LC-40LE700X.indb 14LC-40LE700X.indb 14 6/26/09 4:25:37 PM6/26/09 4:25:37 PM
Page 17
Preparation
Inserting the batteries
Before using the TV for the fi rst time, insert two “AAA” size batteries (supplied). When the batteries become
depleted and the remote control fails to operate, replace the batteries with new “AAA” size batteries.
1 Open the battery cover.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you fi nd any
chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.
• Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fi re or the like.
2 Insert the two supplied “AAA” size
batteries.
• Place batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
3 Close the battery cover.
Using the remote control unit
Use the remote control unit by pointing it towards the
remote sensor window.
Objects between the remote control unit and sensor
window may prevent proper operation.
Remote control sensor
Cautions regarding the remote control unit
• Do not subject the remote control unit to shock.
In addition, do not soak the remote control unit with liquids or place it in
an area with high humidity.
• Do not install or place the remote control unit under direct sunlight.
The heat may cause deformation of the unit.
• The remote control unit may not work properly if the remote sensor
window of the TV is under direct sunlight or strong lighting. In such
cases, change the angle of the lighting or TV, or operate the remote
control unit closer to the remote sensor window.
30º
5 m
30º 30º
30º
15
LC-40LE700X.indb 15LC-40LE700X.indb 15 6/26/09 4:25:38 PM6/26/09 4:25:38 PM
Page 18
Preparation
Turning the TV on/off
Turning on the power
Press POWER on the TV.
• POWER indicator (Green): The TV is on. (After a few
seconds, an image appears with sound.)
• After turning the power “ON” by pressing POWER on the
TV, you can turn the power ON/OFF by pressing POWER
on the remote control.
POWER button
Turning off the power
POWER button
Press POWER on the remote control.
• The TV enters standby mode and the image on the screen
disappears.
• The POWER indicator on the TV changes from green to
red.
Press POWER on the TV.
• The POWER indicator on the TV turns off.
• When the TV is turned off by POWER on the TV, you
cannot turn on the power by pressing POWER on the
remote control.
POWER indicator
Light off Power off
Lighted (Red) The TV is in standby mode.
Lighted (Green) The TV is on.
POWER indicator
NOTE
• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.
• Minor power is consumed when the unit is in standby
mode.
16
LC-40LE700X.indb 16LC-40LE700X.indb 16 6/26/09 4:25:38 PM6/26/09 4:25:38 PM
Page 19
Preparation
About Menu operations
What is Menu?
• You need to bring up the On-Screen Display to perform
settings for the TV. The On-Screen Display for the settings
is called “Menu”.
• The Menu enables various settings and adjustments. (See
pages 18 and 19.)
• The Menu can be operated with the remote control unit.
Basic Menu operations
Press MENU and the MENU screen displays.
1
2
3
4
5
[
]
MENU
Picture Audio ECO Setup
DYNAMIC
OPC [Off]
Backlight [+14] –16
Contrast
Brightness
Colour
Tint
Sharpness
Advanced
Reset
[+30]
[ 0]
[ 0]
[ 0]
[ 0]
0
–30
–30
–30
–10
+16
+40
+30
+30
+30
+10
Press c/d to select the desired menu, and
then press ENTER.
[
]
Audio
MENU
Audio ECO
DYNAMIC
Treble
Bass
Balance
SRS TS HD
Bass enhancer
Reset
[ 0] –15
[ 0]
–15
[ 0]
L
+15
+15
R
[Off]
[On]
Press a/b to select the desired menu item.
Press ENTER to proceed if necessary.
[
]
Audio
MENU
Audio ECO
DYNAMIC
Treble
Bass
Balance
SRS TS HD [Off]
Bass enhancer
Reset
[ 0] –15
[ 0]
–15
[ 0]
L
+15
+15
R
[On]
Press a/b or c/d to select the desired item
or adjust the item to the desired level. Press
ENTER if necessary.
Press EXIT or MENU to exit the MENU.
Press RETURN as necessary to return to the
previous MENUs.
Using the control panel of the TV
H
You can also operate the Menu using the control panel
of the TV.
Button operations on the control panel correspond to
the ones on the remote control as shown below.
Remote control
buttons
ENTER
a
b
d
c
NOTE
• Menu options differ in the selected input modes, but the
operating procedures are the same.
• The screens in the operation manual are for explanation
purposes (some are enlarged, others cropped) and may
vary slightly from the actual screens.
About the Guide Display
The Guide Display at the bottom of the screen shows
operations with an On-Screen Display.
ENTER
: Select : Enter
RETURN
: Back
MENU
: End
The bar above is an operational guide for
the remote control. The bar will change in
accordance with each menu setting screen.
Blue illumination Emblem
You can choose to light up the Blue illumination
Emblem.
Blue illumination Emblem
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Blue illumination”, and
3
then press ENTER.
Press a/b to select “On” or “Off”, and then
4
press ENTER.
17
LC-40LE700X.indb 17LC-40LE700X.indb 17 6/26/09 4:25:39 PM6/26/09 4:25:39 PM
Page 20
Preparation
Menu items (TV/INPUT 4-6)
List of menu items to help you with operations
OPC .............................................................................. Page 34
Backlight ..................................................................... Page 34
Contrast ....................................................................... Page 34
Brightness ................................................................... Page 34
Colour .......................................................................... Page 34
Tint ............................................................................... Page 34
Sharpness ................................................................... Page 34
Advanced
C.M.S.-hue . ..................................................... Page 35
C.M.S.-saturation . .......................................... Page 35
C.M.S.-value ................................................... Page 35
Colour temp. .. ................................................. Page 35
Fine motion advanced .................................... Page 35
Film mode ........................................................ Page 35
Active contrast ................................................ Page 35
Gamma adjustment ........................................ Page 35
DNR .................................................................. Page 35
3D-Y/C ............................................................. Page 35
Monochrome ................................................... Page 35
Range of OPC .................................................. Page 36
Reset ............................................................................ Page 34
Audio
Treble ........................................................................... Page 38
Bass ............................................................................. Page 38
Balance ........................................................................ Page 38
SRS TS HD .................................................................. Page 38
Bass enhancer ............................................................ Page 38
Reset ............................................................................ Page 38
ECO
Option
AQUOS LINK setup .................................................... Page 51
Input select ................................................................. Page 47
PC audio select ........................................................... Page 56
Output volume select ................................................. Page 38
Auto volume ................................................................ Page 39
Clear voice .................................................................. Page 39
Digital audio output .................................................... Page 39
Audio only.................................................................... Page 26
Programme title display ............................................. Page 29
Time display ................................................................ Page 37
Game play time ........................................................... Page 36
Colour system ............................................................. Page 48
Key lock ....................................................................... Page 29
Setting display colour ................................................ Page 49
Channel selecting effect ............................................ Page 49
Digital setup
REC picture size ......................................................... Page 47
Download setup .......................................................... Page 65
EPG setup ................................................................... Page 42
Subtitle ........................................................................ Page 62
Time zone .................................................................... Page 42
Information
Message list ................................................................ Page 65
Receiver report ........................................................... Page 65
Eco picture control ................................................... Page 30
Energy save ................................................................. Page 30
No signal off ................................................................ Page 30
No operation off .......................................................... Page 30
Setup
Auto installation .......................................................... Page 20
Programme setup ................................................ Pages 22-25
Child lock .................................................................... Page 28
Antenna setup-DIGITAL ............................................. Page 12
Input skip ..................................................................... Page 48
Input label .................................................................... Page 48
Position ........................................................................ Page 36
WSS ............................................................................. Page 31
4:3 mode ...................................................................... Page 31
Quick start .................................................................. Page 31
Language ..................................................................... Page 21
Text language ............................................................. Page 61
Blue illumination ......................................................... Page 17
Identifi cation ............................................................... Page 65
Reset ............................................................................ Page 65
NOTE
• Some menu items may not be displayed depending on the selected input source.
18
LC-40LE700X_en_c.indd 18LC-40LE700X_en_c.indd 18 7/9/09 7:08:21 PM7/9/09 7:08:21 PM
Page 21
Preparation
Menu items (HDMI/RGB)
List of menu items to help you with operations
OPC .............................................................................. Page 34
Backlight ..................................................................... Page 34
Contrast ....................................................................... Page 34
Brightness ................................................................... Page 34
Colour .......................................................................... Page 34
Tint ............................................................................... Page 34
Sharpness ................................................................... Page 34
Advanced
C.M.S.-hue . ..................................................... Page 35
C.M.S.-saturation . .......................................... Page 35
C.M.S.-value .................................................... Page 35
Colour temp. .. ................................................. Page 35
Fine motion advanced .................................... Page 35
Gamma adjustment ........................................ Page 35
Film mode ........................................................ Page 35
Active contrast ................................................ Page 35
DNR .................................................................. Page 35
Monochrome ................................................... Page 35
Range of OPC .................................................. Page 36
Reset ............................................................................ Page 34
Audio
Treble ........................................................................... Page 38
Bass ............................................................................. Page 38
Balance ........................................................................ Page 38
SRS TS HD .................................................................. Page 38
Bass enhancer ............................................................ Page 38
Reset ............................................................................ Page 38
ECO
Setup
Input skip ..................................................................... Page 48
Auto sync. ................................................................... Page 57
Input label .................................................................... Page 48
Position ........................................................................ Page 36
Fine sync. .................................................................... Page 57
HDMI auto view .......................................................... Page 46
Quick start ................................................................... Page 31
Language ..................................................................... Page 21
Blue illumination ......................................................... Page 17
Reset ............................................................................ Page 65
Option
AQUOS LINK setup .................................................... Page 51
PC audio select ........................................................... Page 56
Output volume select ................................................. Page 38
Auto volume ................................................................ Page 39
Clear voice .................................................................. Page 39
Audio only.................................................................... Page 26
Time display ................................................................ Page 37
Game play time ........................................................... Page 36
Key lock ....................................................................... Page 29
Setting display colour ................................................ Page 49
Channel selecting effect ............................................ Page 49
Information
Message list ................................................................ Page 65
Receiver report ........................................................... Page 65
ECO picture control.................................................... Page 30
Energy save ................................................................. Page 30
No signal off ................................................................ Page 30
No operation off .......................................................... Page 30
NOTE
• Some menu items may not be displayed depending on the selected input source.
19
LC-40LE700X_en_c.indd 19LC-40LE700X_en_c.indd 19 8/11/09 10:55:35 AM8/11/09 10:55:35 AM
Page 22
Watching TV
Setting channels automatically
You can run auto installation again, even after setting
up the preset channels.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
If you have already set the password, enter it
4
here.
• See page 28 for setting a password.
Press c/d to select “Yes”, and then press
5
ENTER.
Press a/b to select the desired language
6
listed on the screen, and then press ENTER.
Press c/d to select “Digital Search” or
“Analogue Search”, and then press ENTER.
You do not need to do anything during the
auto search.
Press RETURN to exit.
Press a/b to select “Auto installation”, and
3
then press ENTER.
...
[
Setup
MENU
Setup Option
Auto installation
Programme setup
Child lock
X Antenna setup-DIGITAL
Input skip
Position
WSS
4:3 mode
Quick start
Language
Text language
Blue illumination
Identification
Reset
Auto installation
[Normal]
[English]
[West Europe]
]
[On]
[Off]
[On]
20
LC-40LE700X_en_c.indd 20LC-40LE700X_en_c.indd 20 7/10/09 8:41:08 AM7/10/09 8:41:08 AM
Page 23
Watching TV
Selecting programmes Adjusting the volume
You can change channels in several ways.
Using CHr/s on the remote control unit
• Press CHr to increase the channel number.
• Press CHs to decrease the channel number.
NOTE
• CHr/s on the TV operates the same as CHr/s on
the remote control unit.
Changing the volume
You can change the volume on the TV or on the
remote control unit.
• To increase the volume, press VOLk.
• To decrease the volume, press VOLl.
Using 0l9 on the remote control unit
Select the channels directly by pressing buttons 0 to 9.
a
To select a 1-digit channel (e.g. channel 2):
• Press 0, followed by 2.
To select a 2-digit channel (e.g. channel 12):
• Press 1, followed by 2.
To select a 3-digit channel (e.g. channel 020):
• Press 0, press 2, followed by 0.
When viewing Teletext information
View a page directly which is 3-digit page number from
100 to 899 by pressing buttons 0 to 9.
20
NOTE
• “TV”, “INPUT1”, “INPUT2”, “INPUT3”, “INPUT4”, “INPUT5”,
“INPUT6” and “INPUT7” (PC) modes can store volume
adjustment values separately.
Menu language settings
You can also select a language from setup menu.
Select from among 3 languages: English, Simplifi ed
Chinese and Arabic.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Language”, and then
3
press ENTER.
Press a/b to select the desired language
4
listed on the screen, and then press ENTER.
21
LC-40LE700X.indb 21LC-40LE700X.indb 21 6/26/09 4:25:42 PM6/26/09 4:25:42 PM
Page 24
Watching TV
Setting channels to your preference
You can run the auto search procedure again at any
time by accessing the Setup menu and Programme
setup. Channels can be tuned automatically or
manually.
Digital settings
You can reconfi gure DTV services settings
automatically or manually.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”
2
Press a/b to select “Programme setup”, and
3
then press ENTER. If you have already set the
password, enter it here.
• See page 28 for setting a password.
The “Digital setting” screen displays and then
press ENTER.
Press a/b to select the desired menu item,
4
and then press ENTER.
Press c/d to select “Yes”, and then press
5
ENTER.
H Additional search
Use this menu to add new services automatically after
auto installation has been completed.
H Manual search
Add new services within a specifi ed frequency band.
• Enter the frequency using 0 - 9 numeric buttons.
Press a/b to select the desired service.
1
Press the colour button on the remote control
2
corresponding with the item you want to
reconfi gure.
• The ✔ mark indicates the operation is set to on.
Each time the colour button is pressed, you can
switch the corresponding operation on/off.
Buttons for Manual Adjust operation
Menu items
Remote control
buttons
Description
Lock R When the service is
locked, you must enter
your password whenever
you tune to the service.
CH Skip G Services with a ✓ mark
are passed over when
pressing r/s in the
TV/remote control unit.
EPG Skip Y Services with a ✓ mark
are passed over in the
Electronic Programme
Guide (EPG).
Sort B The item position of
services can be sorted.
The item position of services can be sorted
Press a/b to select the service whose item
1
position you want to move, and then press B.
DTV 994 SIT 2
DTV 995
Press a/b to move it to the desired position, and
2
SIT 1
then press ENTER.
DTV 994 SIT 1
DTV 995
Repeat steps 1 and 2 until all desired service
3
SIT 2
items are sorted.
H Manual adjust
Confi gure various settings for each service using the
Colour (R, G, Y, B) buttons.
...
[
Setup
MENU
DTV 993 SIT 3
DTV 994
DTV 995 SIT 1
DTV 996 Monosco 576-2
DTV 997 Monosco 576-1
DTV 998 Color Bar 576i
DTV 999 HD Monosco
R
22
LC-40LE700X.indb 22LC-40LE700X.indb 22 6/26/09 4:25:43 PM6/26/09 4:25:43 PM
P r ogramme setup
Select a service and then press the colour button
Service
Service
No.
Name
SIT 2
: Lock
G
: CH skip
...
Digital setting
to change service settings.
Lock
Y
: EPG skip
Skip
CH
...
Manual adjust
EPG
Skip
B
: Sort
LCN
]
Old
Page 25
Watching TV
Manual setting for each channel (Analogue)
You can set some channel items manually. They are
Search, Fine (TV frequency), Colour sys., Sound sys.,
Label (Network name), Skip and Lock (Child lock).
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Programme setup”, and
3
then press ENTER. If you have already set the
password, enter it here.
• See page 28 for setting a password.
The “Analogue setting” screen displays and
then press ENTER.
Press a/b to select “Manual adjust”, and
4
then press ENTER.
Press c/d to select “Yes”, and then press
5
ENTER.
Programme Setup “Manual adjust” menu
Please select channel to be edited
01
SAT.1 02 PR07 03
06
07
11
12
16
17
04
08
13
18
Next
05KABEL
09
10
14
15
19
20
You can select one of the following settings.
Search (See page 23.)
1
Fine (See page 23.)
2
Colour sys. (See page 23.)
3
Sound sys. (See page 24.)
4
Label (See page 24.)
5
Skip (See page 24.)
6
Lock (See page 24)
7
Search tuning
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information displays.
Press a/b to select “Search”, and then press
2
ENTER.
...
[
Setup
MENU
Search Channel frequency settings
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
Programme setup
[179.25]
[Auto]
[B/G]
[SAT.1]
[Off]
[Off]
]
179.25 MHz
Next
Store
Cancel
Press a/b to select item and press ENTER.
3
• Next: Search the next channel.
• Store: Memorise the current display channel.
• Cancel: Return to the previous screen. (The
search result will not be stored.)
Fine tuning
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information displays.
Press a/b to select “Fine”, and then press
2
ENTER.
Press c/d to adjust the frequency, and then
3
press ENTER.
• Adjust while checking the background picture as
a reference.
Sea r ch
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
• Instead of the method above, you can also set
by directly entering the frequency number of the
channel with 0
• When setting a frequency on the “Fine” screen,
the last fi gure of the frequency needs to be “0” or
“5”.
a
• 179.25 MHz: Press 1 s 7 s 9 s 2 s 5.
• 49.25 MHz: Press 4 s 9 s 2 s 5 s ENTER.
Colour system
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information displays.
Press a/b to select “Colour sys.”, and then
2
press ENTER.
• Receivable colour systems are listed.
Search
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
Press a/b to select the optimum colour
3
system, and then press ENTER.
[179.25]
[Auto]
[B/G]
[SAT.1]
[O f f]
[O f f]
l
Channel frequency settings
9.
Colour system menu
[179.25]
[Auto]
[B/G]
[SAT.1]
[Off]
[Off]
Colour system settings
179.25 MHz
Auto
PAL
SECAM
23
LC-40LE700X.indb 23LC-40LE700X.indb 23 6/26/09 4:25:44 PM6/26/09 4:25:44 PM
Page 26
Watching TV
Manual setting for each channel (continued)
Sound system (Broadcasting system)
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information displays.
Press a/b to select “Sound sys.”, and then
2
press ENTER.
• Receivable sound systems (Broadcasting systems)
are listed.
Sound system menu
Search
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
Press a/b to select the optimum sound
3
system, and then press ENTER.
[179.25]
[Auto]
[B/G]
[SAT.1]
[Off]
[Off]
Sound system settings
B/G
D/K
I
Labelling channels
When a TV channel sends its Network Name, the auto
installation detects the information and assigns a name
to it. However, you can change individual channel
names.
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information displays.
Press a/b to select “Label”, and then press
2
ENTER.
• The alphabet and numbers are listed.
Labelling menu
Search
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
[179.25]
[Auto]
[B/G]
[SAT.1]
[Off]
[Off]
Broadcasting station name settings
SAT . 1
UVWXYZ+ _.
CLEARABCDEFGHI J
BACKKLMNOPQRST
END0123456789
Skipping channels
Channels with “Skip” set to “On” are passed over
when using CHr/s even if selected while watching
the image from the TV.
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information will be displayed.
Press a/b to select “Skip”, and then press
2
ENTER.
• Skip menu displays.
Skip menu
Search Channel skip settings
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
Press a/b to set “Skip” to “On”, and then
3
press ENTER.
[179.25]
[Auto]
[B/G]
[SAT.1]
[Off]
[Off]
Off
On
Setting the child lock
You can block the viewing of any channel.
Press a/b/c/d to select the channel you
1
want to edit, and then press ENTER.
• The selected channel information will be displayed.
Press a/b to select “Lock”, and then press
2
ENTER.
• Child lock menu will be displayed.
[179.25]
[Auto]
[B/G]
[SAT.1]
[Off]
[Off]
Lock menu
Off
On
Search Applies child lock to this channel
Fine
Colour sys.
Sound sys.
Label
Skip
Lock
Press a/b/c/d to select each character of
3
the new name for the channel, and then
ENTER
.
Repeat until the name is fully spelt out.
4
• The name can be 5 characters or less.
• When you want to set a channel name of less
than 5 characters, select “END”.
press
• See page 28 for setting a password.
• If “Lock” is set to “On” for a channel, “Child lock has been
Press a/b to set “Lock” to “On”, and then
3
press ENTER.
NOTE
activated RETURN: Input password” is displayed when you
select the channel, and the image and sound of the channel
is blocked.
• When pressing RETURN while “Child lock has been
activated RETURN: Input password” is displayed, password
input menu will be displayed. Inputting the correct password
lifts the child lock temporarily until the power is turned off.
24
LC-40LE700X.indb 24LC-40LE700X.indb 24 6/26/09 4:25:46 PM6/26/09 4:25:46 PM
Page 27
Watching TV
Sorting programmes
Channel positions can be sorted freely.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Programme setup”, and
3
then press ENTER. If you have already set the
password, enter it here.
• See page 28 for setting a password.
The “Analogue setting” screen displays and
then press ENTER.
Press a/b to select “Sort”, and then press
4
ENTER.
Press c/d to select “Yes”, and then press
5
ENTER.
Press a/b/c/d to select the channel you
6
want to move, and then press ENTER.
Move it to the desired position by pressing
7
a/b/c/d
Repeat the steps 6 and 7 until all desired
8
channels are sorted.
, and then press ENTER.
Sort menus
Please select channel to replace
01 SAT.1
01
SAT.1 KABEL
02 03 04 05
06
07
08
11
12
13
16
17
18
Next
09
14
19
Erasing programmes
The individual programme can be erased.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Programme setup”, and
3
then press ENTER. If you have already set the
password, enter it here.
• See page 28 for setting a password.
The “Analogue setting” screen displays and
then press ENTER.
Press a/b to select “Erase programme”, and
4
then press ENTER.
Press c/d to select “Yes”, and then press
5
ENTER.
Press a/b/c/d to select the channel you
6
want to erase, and then press ENTER.
• A message screen pops up.
Press c/d to select “Yes”, and then press
7
ENTER to erase the selected programme. All
the subsequent programmes move up.
Repeat the steps 6 and 7 until all desired
8
channels are erased.
Erase programme menus
Please select channel to erase
01 SAT.1
01
SAT.1
10
15
20
PRO702 KABEL 03 04 05
06 07 08 09 10
11 12 13 14 15
16 17 18 19 20
Next
Please select channel to replace
01 SAT.1 02 KABEL
01 SAT.1 KABEL 02
06
11
16
01 KABEL SAT.1 02
06
11
16
LC-40LE700X.indb 25LC-40LE700X.indb 25 6/26/09 4:25:47 PM6/26/09 4:25:47 PM
03 04 05
07
08
12
13
17
18
Next
Please select channel to replace
01 KABEL
03 04 05
07
08
12
13
17
18
Next
09
10
14
15
19
20
09
10
14
15
19
20
01 SAT.1 03 KABEL PRO702
06 07 08 09 10
11 12 13 14 15
16 17 18 19 20
01 SAT.1 02 KABEL
06 07 08 09 10
11 12 13 14 15
16 17 18 19 20
Please select channel to erase
02 PRO7
Next
Please select channel to erase
02 KABEL
03 04 05
Next
04 05
25
Page 28
Watching TV
Useful viewing functions
Returning to the previously selected
channel
Press A to switch the currently tuned channel to the
previously tuned channel.
Press A again to switch back to the currently tuned
channel.
Press A to toggle between the currently selected
input source and the previously selected one.
Press A to return to the previous page in TELETEXT
mode.
Freezing the image
Allows you to capture and freeze one frame from a
moving image that you are watching.
Press FREEZE.
1
• Captures one frame from a moving image.
Press FREEZE again to cancel the function.
2
Muting the audio temporarily
Using Mute (e) on the remote control unit
mutes the current sound output.
e
Press e.
1
• The sound is silenced.
• “M” is displayed while the mute function is on.
Mute
NOTE
• Within 30 minutes after pressing e, press one of the
buttons below to cancel the mute.
– VOLl/VOL
–
e
• Mute will be cancelled after 30 minutes. However,
the TV will not suddenly output loud sound as the
volume level will be set to 0 automatically. Increase
the volume level by pressing VOLk.
2
k
Press e again within 30 minutes to cancel the
mute.
• Before 30 minutes, the volume level returns to the
previous setting.
Outputting only audio
When listening to music from a music programme, you
can set the display off and enjoy audio only.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
NOTE
• The still image automatically goes out after 30 minutes.
• When you make operations that change the picture on the
26
LC-40LE700X.indb 26LC-40LE700X.indb 26 6/26/09 4:25:48 PM6/26/09 4:25:48 PM
Press a/b to select “Audio only”, and then
3
press ENTER.
Press c/d to select “On”, and then press
4
ENTER.
Selected item Description
On Audio is output without screen image.
Off
NOTE
TV such as by changing the input source, the Audio only
function is set to “Off”.
Both screen images and audio are output.
Page 29
Watching TV
Switching the analogue audio format
You can switch between multiple audio modes
when watching a multiple audio or stereo broadcast
programme.
In the NICAM TV broadcasts
When receiving a stereo signal
Each time you press MPX, the mode switches
between NICAM STEREO and MONO.
Stereo mode
BBC1
ATV ATV
PAL
NICAM
01
B/G
STEREO
PAL
When receiving a bilingual signal
Each time you press MPX, the mode switches among
NICAM CH A, NICAM CH B, NICAM CH AB and
MONO.
Bilingual mode
BBC1
ATV ATV
PAL
NICAM
ATV ATV
PAL PAL
01
B/G
CH A
BBC1
01
B/G
MONO
PAL
NICAM
NICAM
BBC1
01
B/G
MONO
BBC1
01
B/G
CH B
BBC1
01
B/G
CH AB
When receiving a bilingual signal
Each time you press MPX, the mode switches among
CH A, CH B and CH AB.
Bilingual mode
BBC1
ATV ATV
PAL
NICAM
01
B/G
CH A
PAL
ATV
BBC1
01
B/G
CH AB
PAL
BBC1
01
B/G
CH B
When receiving a monaural signal
When you press MPX, “MONO” displays.
Monaural mode
BBC1
ATV
PAL
01
B/G
MONO
NOTE
• “BBC2”, “99” and “PAL” are tentative network name,
channel and colour system.
Switching the digital audio format
H If multi sound modes are received, each time you
press MPX the mode switches as follows.
(Example)
Audio (ENG) : STEREO
L/R LRLR
When receiving a monaural signal
Each time you press MPX, the mode switches
between NICAM MONO and MONO.
Monaural mode
BBC1
ATV ATV
PAL
NICAM
01
B/G
MONO
PAL
In the TV mode of A2 TV broadcasts
When receiving a stereo signal
Each time you press MPX, the mode switches
between STEREO and MONO.
Stereo mode
BBC1
ATV ATV
PAL PAL
01
B/G
STEREO
BBC1
01
B/G
MONO
BBC1
01
B/G
MONO
Audio (ENG) : CH A
CH A CH B CH AB
Audio (ENG) : MONO
H Press c/d to select L or R sound when the
STEREO or DUAL MONO screen is displayed.
Audio (ENG) : STEREO
L/R L RLR
NOTE
• The sound mode screen disappears in 6 seconds.
• Selectable items vary depending on the received
broadcasts.
27
LC-40LE700X.indb 27LC-40LE700X.indb 27 6/26/09 4:25:49 PM6/26/09 4:25:49 PM
Page 30
Watching TV
Password setting for the child lock (for TV
input mode)
Allows you to use a password to protect certain
settings from being accidentally changed.
Clearing the password
Allows you to clear your password.
Repeat steps 1 to 3 in Setting a password.
1
Enter the password.
2
Setting a password
Register a 4-digit password number to use the Child
lock function.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Child lock”, and then
3
press ENTER.
If you have already set the password, enter it
4
here.
Press a/b to select “Change password”, and
5
then press ENTER.
Change password Change password
X Clear password
X Clear password
X Parental rating
X Parental rating
New password
Reconfirm
–––
–
––––
Press a/b to select “Clear password”, and
3
then press ENTER.
Press c/d to select “Yes”, and then press ENTER.
4
Change password Clear password
Clear password
Parental rating
Yes No
NOTE
• As a precautionary measure, make a note of your
password and keep it in a familiar place. If you lose
or forget your password, initialise the TV to return all
settings except for the TV channel settings to factory
preset values. (See page 70.)
• This function is only available for TV input mode.
• To relock a channel which has been temporarily unlocked
by inputting the correct password, turn power off and then
on again.
Enter the 4-digit number as a password using
6
0 – 9.
Change password
X Clear password
X Parental rating
Enter the same 4-digit number as in step 6 to
7
confirm.
• “The new password was registered” displays.
Enter your new password. Use 4 digits.
– – –
New password
Reconfirm
–
–––
–
– – – –
––––
NOTE
• To view a locked channel (Lock setting in Programme setup
“Manual adjust” is set to “On”), you must enter a password.
(See page 24.) When you select a locked channel, a
password prompt message pops up. Press RETURN to
display the password input window.
28
LC-40LE700X.indb 28LC-40LE700X.indb 28 6/26/09 4:25:50 PM6/26/09 4:25:50 PM
Page 31
Watching TV
Parental rate
This function allows TV channels to be restricted.
It prevents children from watching violent or sexual
scenes that may be considered inappropriate.
Repeat steps 1 to 3 in Setting a password.
1
Press a/b to select “Parental rating”, and
2
then press ENTER.
Press a/b to select your desired rating, and
3
then press ENTER.
Selected item Description
General and
above (G)
Parental
guidance and
above (PG)
Mature and
above (M)
Mature adult
and above
(MA)
Adult
violence and
above (AV)
Restricted
and above
(R)
No block (-) Cancel the blocking.
Content is not offensive to most viewers.
Content is such that parents may
not want their children to view the
programme.
Mature audience only. This programme
is specifically designed to be viewed by
adults and therefore may be unsuitable
for children under 15.
Mature adult only. This programme is
specifically designed to be viewed by
adults and therefore may be unsuitable
for children under 15.
Not for children under age 15. Strong
elements of sex and/or violence.
Not for children under age 18. Strong
elements of sex and/or violence.
Key lock
This function allows you to lock the buttons on the
TV or remote control in order to prohibit children from
changing the channel or volume.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Key lock”, and then
3
press ENTER.
Press a/b to select “RC control lock” or
4
“Button control lock”, and then press ENTER.
Selected item Description
Off Unlock the buttons.
RC control
lock
Button
control lock
NOTE
• You cannot set both “RC control lock” and “Button control
lock” at the same time.
Lock all buttons on the remote control.
Lock the TV buttons except the power
switch.
H Cancelling the lock
To cancel “RC control lock” follow the below steps
using the TV control panel buttons on the TV.
Press MENU on the TV and VOL+/VOL- to
1
select “Option”.
Press CH r/s to select “Key lock”, and
2
then press TV/VIDEO.
Programme title display
This function allows you to display programme
information on the screen including the title and airtime
by tuning a channel.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Programme title
3
display”, and then press ENTER.
Press c/d to select “Yes”, and then press
4
ENTER.
NOTE
• The Programme title display function is only available for
the DTV mode.
LC-40LE700X.indb 29LC-40LE700X.indb 29 6/26/09 4:25:51 PM6/26/09 4:25:51 PM
• See page 17 for the functions of the TV control panel
buttons.
• To cancel “Button control lock”, use the remote
control.
Press CH r/s to select “Off”, and then
3
press TV/VIDEO.
NOTE
29
Page 32
Watching TV
Energy conservation settings
Auto power-off at a designated time
This function is conveniently used when, for instance,
going to bed while watching TV.
Press SLEEP.
1
• Remaining time displays when sleep timer has
been set.
Sleep Timer: Remain 2 hr. 00 min.
Each time you press SLEEP, the remaining
2
time switches as shown below.
0 hr. 30 min. 1 hr. 00 min. 1 hr. 30 min.
Off
NOTE
• When the time has been set, countdown automatically
starts.
• Five minutes before the preset of time expires, the
remaining time displays each minute.
• Select “Off” by pressing SLEEP to cancel the sleep timer.
2 hr. 30 min. 2 hr. 00 min.
ECO picture control
This function automatically detects the image source
and decreases the power consumption while keeping
the brightness of the image unchanged.
Press MENU and the MENU screen displays.
1
Press c/d to select “ECO”.
2
• ECO menu displays.
Press a/b to select “ECO picture control”,
3
and then press ENTER.
Press c/d to select “On” or “Off”, and then
4
press ENTER.
NOTE
• This function does not work when “AV MODE” is set to
“DYNAMIC (Fixed)” or “AUTO”.
• This function does not work when “Energy save” is set to
“Standard” or “Advanced”.
Energy save
This function enables you to automatically reduce the
backlight brightness in order to decrease the power
consumption and increase the backlight life span.
Press MENU and the MENU screen displays.
1
Press c/d to select “ECO”.
2
• ECO menu displays.
Press a/b to select “Energy save”, and then
3
press ENTER.
Press a/b to select “Standard” or
4
“Advanced”, and then press ENTER.
Selected item Description
Standard
Advanced Reduces the backlight brightness by 50%.
Off The backlight brightness is the same value
Reduces the backlight brightness by 25%.
of your settings in the selected “AV MODE ”.
Auto power-off after the end of broadcast
You can set the TV to automatically power off in about
15 minutes after the TV goes into a state of receiving no
programme signals, such as the end of a broadcast day.
Press MENU and the MENU screen displays.
1
Press c/d to select “ECO”.
2
• ECO menu displays.
Press a/b to select “No signal off”, and then
3
press ENTER.
Press
c/d
4
ENTER.
• Five minutes before the power shuts down, the
remaining time displays every minute.
NOTE
• “Disable” is the factory preset value.
• When a TV programme finishes, this function may not
operate.
to select “Enable”, and then press
Auto power-off when there are no
operations performed
You can set the TV to automatically power off when no
TV operation is performed for more than 3 hours.
Press MENU and the MENU screen displays.
1
Press c/d to select “ECO”.
2
• ECO menu displays.
Press a/b to select “No operation off”, and
3
then press ENTER.
Press a/b to select “30min.” or “3hr.”, and
4
then press ENTER.
• Five minutes before the power shuts down, the
remaining time displays every minute.
NOTE
• “Disable” is the factory preset value.
30
LC-40LE700X_en_d.indd 30LC-40LE700X_en_d.indd 30 7/8/09 11:33:07 AM7/8/09 11:33:07 AM
Page 33
Watching TV
Quick start
You can reduce the TV’s start-up time after turning on
the power with the remote control unit.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Quick start”, and then
3
press ENTER.
Press c/d to select “On” or “Off”, and then
4
press ENTER.
Selected item Description
On The TV quickly starts up from standby,
Off Power consumption is less than 1 W.
19 W or more of power consumption is
required during standby.
Picture size settings
Selecting the Wide Screen Signalling
(WSS) picture size automatically
WSS allows a television to switch automatically among
the different screen formats.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “WSS”, and then press
3
ENTER.
Press c/d to select “On” or “Off”, and then
4
press ENTER.
NOTE
• Try to set WIDE mode if an image does not switch to the
correct screen format. When the broadcast signal contains
no WSS information, the function will not work even if
enabled.
Selecting the Wide Screen Signalling
(WSS) picture size manually
The WSS signal has 4:3 auto-switching that allows you
to select between Panorama and Normal.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “4:3 mode”, and then
3
press ENTER.
Press c/d to select “Panorama” or “Normal”,
4
and then press ENTER.
WSS signal 4:3 screen
4:3 mode “Panorama”
Selected item Description
Panorama Wide image without side bars
Normal Normal range keeping 4:3 or 16:9 aspect
ratio
4:3 mode “Normal”
31
LC-40LE700X_en_d.indd 31LC-40LE700X_en_d.indd 31 7/8/09 9:58:31 AM7/8/09 9:58:31 AM
Page 34
Watching TV
Selecting the picture size manually
Manual Selection
You can select different picture sizes that account for
the kind of each picture.
Press WIDE.
1
• The WIDE MODE menu displays.
• The menu lists the wide mode options selectable
for the type of video signal currently received.
WIDE MODE
Normal
Zoom 14:9
Panorama
Full
Cinema 16:9
Cinema 14:9
Press WIDE or a/b while the WIDE MODE
2
menu displays on the screen.
• As you toggle down the options, each mode is
immediately reflected on the TV.
Auto Selection
If you set “WSS” and “4:3 mode” in the Setup menu on page
31, the optimum WIDE mode is automatically chosen for
every broadcast containing the WSS information.
“WSS” menu
To enable Auto Selection, set “WSS” in the Setup
menu to “On”. (See page 31.)
“4:3 Mode” menu
To set the type of the wide screen, select “Panorama”
or “Normal” in the 4:3 Mode menu. (See page 31.)
4:3 Mode set to “Panorama” 4:3 Mode set to “Normal”
NOTE
•
If the broadcast signal contains no WSS information, Auto
Selection will not function even when the WSS option is enabled.
Selected item Description
Normal For 4:3 “standard” pictures. A side bar appears on each side.
Zoom 14:9 For 14:9 letterbox pictures. A thin side bar appears on each side, and you may also see bars on the top and
Panorama In this mode the picture is progressively stretched toward each side of the screen.
Full For 16:9 squeeze pictures.
Cinema 16:9 For 16:9 letterbox pictures. Bars may appear on the top and bottom with some programmes.
Cinema 14:9 For 14:9 letterbox pictures. Bars may appear on the top and bottom with some programmes.
Dot by Dot Displays an image with the same number of pixels on the screen (only when receiving a 1080i/1080p signal).
Underscan Display with an Underscan image only when receiving a 720p signal. Display with the High-Definition image
Normal
bottom with some programmes.
adjusted optimally. Noise may appear on the edge of the screen with some programmes.
NOTE
Zoom 14:9 Panorama
• Some picture sizes may not be
displayable depending on the
input signal.
Cinema 14:9 Cinema 16:9 Full
32
LC-40LE700X.indb 32LC-40LE700X.indb 32 6/26/09 4:25:55 PM6/26/09 4:25:55 PM
Page 35
Watching TV
Selecting a preset AV MODE
The AV MODE function enables you to select
appropriate settings for audio and video to account for
the system environment which can vary due to factors
like room brightness, type of programme watched or
the type of image input from external equipment.
Using AV MODE on the remote control unit
Press AV MODE.
1
• Present AV MODE displays.
Press AV MODE again before the mode
2
displayed on the screen disappears.
• The mode changes as shown below.
When the input source is TV, INPUT4, 5 or 6 terminal
AV MODE: STANDARD
AV MODE: DYNAMIC
(Example)
AV MODE: MOVIE
AV MODE: GAME
Selected item Description
STANDARD For a highly defi ned image in a normally
bright room.
MOVIE For a movie.
GAME Lowers image brightness for easier
viewing.
PC* For PC. (Available only when inputting an
HDMI or RGB signal.)
USER Allows the user to customise settings as
desired. You can set the mode for each
input source.
AUTO The TV automatically sets the appropriate
selection from the “AV MODE” menu
depending on the lighting conditions and
the type of programme watched.
DYNAMIC
(Fixed)
Changes the image and sound settings to
the factory preset values. No adjustments
are allowed.
DYNAMIC For a clear-cut image emphasising high
contrast for sports viewing.
NOTE
• The item marked with * is available only when selecting
“INPUT1”, “INPUT2”, “INPUT3” or “INPUT7” from the
INPUT SOURCE menu.
• If you select “AUTO”, some selections in the “AV MODE”
menu may not be automatically set.
AV MODE: DYNAMIC (Fixed)
AV MODE: AUTO
AV MODE: USER [TV]
When the input source is INPUT 1, 2, 3 or 7 terminal
(Example)
AV MODE: STANDARD
AV MODE: DYNAMIC AV MODE: GAME
AV MODE: DYNAMIC (Fixed)
AV MODE: AUTO
AV MODE: MOVIE
AV MODE: PC
AV MODE: USER [ ]
33
LC-40LE700X_en_e.indd 33LC-40LE700X_en_e.indd 33 7/3/09 2:25:13 PM7/3/09 2:25:13 PM
Page 36
Watching TV
Manual picture settings
Picture adjustment
You can adjust the picture to your preference.
Follow the steps to adjust the picture.
Press MENU and the MENU screen displays.
1
Press c/d to select “Picture”.
2
[
]
MENU
Picture Audio ECO
DYNAMIC
OPC [Off]
Backlight [+14] –16
Contrast
Brightness
Colour
Tint
Sharpness
Advanced
Reset
Press a/b to select the desired menu item.
3
Press ENTER to proceed if necessary.
[+30]
[ 0]
[ 0]
[ 0]
[ 0]
0
–30
–30
–30
–10
+16
+40
+30
+30
+30
+10
Selected item
button
c
button
d
OPC Sets whether or not the screen brightness
is automatically adjusted according to
the lighting condition in the room. (OPC
setting: See this page.)
Backlight The screen dims The screen
brightens
Contrast For less contrast For more contrast
Brightness For less brightness
Colour For less colour
intensity
Tint Skin tones become
purplish
Sharpness For less sharpness
For more brightness
For more colour
intensity
Skin tones become
greenish
For more sharpness
Advanced For fi ner picture adjustments. (See page
35 and 36.)
Reset Resets all picture adjustment items to the
factory preset values.
H OPC (Optical Picture Control) setting
You can set the TV to automatically adjust the screen
to suitable backlight brightness according to the
lighting conditions.
Using OPC on the remote control unit
Press a/b or c/d to select the desired item
4
or adjust the item to the desired level. Press
ENTER if necessary.
NOTE
• For resetting all adjustment items to factory preset values,
press a/b to select “Reset”, press ENTER, press c/d
to select “Yes”, and then press ENTER.
• Select “Advanced” and then press ENTER to set “C.M.S.-
hue”, “C.M.S.-saturation”, “C.M.S.-value”, “Colour temp.”,
“Fine motion advanced”, “Film mode”, “Active contrast”,
“DNR”, “3D-Y/C”, “Monochrome” or “Range of OPC”. See
page 35 and 36.
34
Press OPC to switch the OPC function on or off.
Using OPC on the menu screen
Selected item Description
Off The brightness is fi xed at the value set in
“Backlight” (See this page).
On Automatically adjusts
On: Display Displays the OPC effect on the screen
while adjusting the brightness of the
screen.
NOTE
• Make sure no object obstructs the OPC sensor, which
could affect its ability to sense surrounding light.
LC-40LE700X_en_e.indd 34LC-40LE700X_en_e.indd 34 7/9/09 7:10:31 PM7/9/09 7:10:31 PM
Page 37
Watching TV
Advanced picture settings
The advanced settings enable you to set the picture
adjustment in more detail. There are twelve options
you can choose from.
Press MENU and the MENU screen displays.
1
Press c/d to select “Picture”.
2
Press a/b to select “Advanced”, and then
3
press ENTER.
Press a/b to select the desired menu, and
4
then press ENTER.
C.M.S.-hue
C.M.S.-saturation
C.M.S.-value
Colour temp.
Fine motion advanced
Film mode
Active contrast
Gamma adjustment
DNR
3D-Y/C
Monochrome
Range of OPC
Press a/b or c/d to select the desired level,
5
and then press ENTER.
Six-colour hue adjustments
[ 0] –30
[ 0]
–30
[ 0]
–30
[ 0]
–30
[ 0]
–30
[ 0]
–30
+30
+30
+30
+30
+30
+30
H C.M.S.-hue
This function adjusts the hue of a selected colour using
a six-colour adjustment system.
H C.M.S.-saturation
This function increases or decreases the saturation of
a selected colour using a six-colour adjustment system.
H C.M.S.-value
This function makes the image brighter or darker
depending on the value of the setting.
H Colour temp. (Colour temperature)
Adjusts the colour temperature to give the best white
image.
Selected item Description
High
Mid-High
Middle
Mid-Low
Low
R/G/B Gain (LO),
R/G/B Gain (HI)
Adjusts the white balance by changing
the value of each item.
White with bluish tone
White with reddish tone
H Fine motion advanced
Use Fine motion advanced to view fast-action images
more clearly.
H Film mode
Automatically detects a fi lm-based source (originally
encoded at 24/25 frames/second, depending on the
vertical frequency), analyses it then recreates each still
fi lm frame for high-defi nition picture quality.
Selected item Description
Advanced
(High)
Advanced
(Low)
Standard
Off Film mode off.
NOTE
• Film mode is not selectable depending on the input signal
type.
H
Active contrast
Automatically adjusts the contrast of an image according
to the scene.
H
Gamma adjustment
Adjust mid-level brightness. The adjustment range of the
gamma can be set to a maximum of +2 and a minimum
of -2 by pressing c or d.
H
DNR (Digital Noise Reduction)
Reduces noise on screen and produces a clearer video
image. (“Auto”, “High”, “Middle”, “Low”, “Off”).
3D-Y/C
H
Provides high quality images with minimal dot crawl and
cross colour noise.
Selected item Description
Standard Normal adjustment
Fast Set the optimum image quality for fast-
Slow Set the optimum image quality for slow-
NOTE
• 3D-Y/C is not selectable depending on the input
signal type.
• 3D-Y/C may not operate depending on the input
signal type or noisy input signal.
Monochrome
H
For viewing images in monochrome.
Display moving picture more smoothly
with high quality.
Display moving picture smoothly with
high quality.
Display every picture frame in equal
time, feeling like watching in cinema.
moving images.
moving images.
Selected item Description
On For obtaining a clear image
Off No adjustment
35
LC-40LE700X_en_e.indd 35LC-40LE700X_en_e.indd 35 8/11/09 10:57:11 AM8/11/09 10:57:11 AM
Page 38
Watching TV
Other picture settings
H Range of OPC
The brightness level range of the OPC sensor’s automatic
adjustments can be set according to your preferences.
The adjustment range of the OPC sensor can be set to a
maximum of +16 and a minimum of -16.
Selected item Description
Max. -15 through +16
Min. -16 through +15
NOTE
• This function is available only when the OPC setting is set to
On or On: Display.
• The maximum setting cannot be set to a smaller number
than the minimum setting.
• The minimum setting cannot be set to a bigger number than
the maximum setting.
• The maximum and minimum settings cannot be set to the
same number.
• Depending on the brightness of the surrounding light, the
OPC sensor might not operate if the adjustment range is
small.
Adjusting the image position
For adjusting a picture's horizontal and vertical
position.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Position”, and then
3
press ENTER.
Press a/b to select “H-pos.” or “V-pos.”.
4
H-pos. H-pos. adjustment
V-pos. V-pos. adjustment
Reset
Selected item Description
H-pos.
V-pos.
Press c/d to adjust the item to your desired
5
position.
Display position adjustment
[ 0] - +
[ 0]
- +
Return to factory pre-settings
Centres the image by moving it to the left
or right.
Centres the image by moving it up or
down.
NOTE
For resetting all adjustment items to the factory preset values,
•
press a/b to select “Reset”, and then press ENTER.
• Adjustments are stored separately according to input
source.
• Depending on the input signal type or “WIDE MODE” setting,
a position setting may not be available.
Game play time
This function displays the elapsed game time so you
do not lose track of the time.
To display the elapsed time, select “GAME” under “AV
MODE” for the input mode of the terminal connected
to the game console before starting the game.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Game play time”, and
3
then press ENTER.
Press c/d to select “On”, and then press
4
ENTER.
Selected item Description
On The elapsed time is displayed every 30
Off No adjustment
36
minutes when you switch to GAME mode
in external input mode.
LC-40LE700X_en_f.indd 36LC-40LE700X_en_f.indd 36 7/8/09 10:05:03 AM7/8/09 10:05:03 AM
Page 39
Watching TV
Indicating time on the screen
H Time display
This function allows you to display the clock time on
the lower right screen.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Time display” and then
3
press ENTER.
Time display Displaying the clock On/Off
Time format
On
On (half-hourly)
Off
Displaying the clock
Displays the clock
half-hourly
H Time format
You can select the time format (either 24HR or AM/PM)
for the clock time.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Time display” and then
3
press ENTER.
Press a/b to select “Time format” and then
4
press ENTER.
Press c/d to select the desired time format,
5
and then press ENTER.
Time display Selecting time format
Time format
24HR AM/PM
Press a/b to select “Time display” and then
4
press ENTER.
Press a/b to select “On” or “On (half-hourly)”
5
and then press ENTER.
Selected item Description
On Display the clock time.
On (halfhourly)
Off Hide the clock time.
Display the clock time in 30 minutes
increments.
37
LC-40LE700X.indb 37LC-40LE700X.indb 37 6/26/09 4:25:59 PM6/26/09 4:25:59 PM
Page 40
Watching TV
Audio adjustment
You can adjust the audio of the selected AV mode.
Press MENU and the MENU screen displays.
1
Press c/d to select “Audio”.
2
Press a/b to select the desired menu item.
3
Press ENTER to proceed if necessary.
Press a/b or c/d to select the desired item
4
or adjust the item to the desired level. Press
ENTER if necessary.
Selected item
Treble For weaker treble For stronger treble
Bass For weaker bass For stronger bass
Balance Increase audio from
NOTE
• For resetting all adjustment items to the factory preset
values, press a/b to select “Reset”, press ENTER, press
c/d to select “Yes”, and then press ENTER.
H SRS TruSurround (TS) HD
You can enjoy SRS TruSurround HD sound, the same
as you were in movie theatre.
Repeat steps 1 to 2 in Audio adjustment.
1
[
]
MENU
Audio
Audio ECO
DYNAMIC
Treble
Bass
Balance
SRS TS HD
Bass enhancer
Reset
[ 0] –15
[ 0]
–15
[ 0]
L
button
c
the left speaker
+15
+15
R
[Off]
[On]
dbutton
Increase audio from
the right speaker
H Bass enhancer
This function allows you to enjoy bass-enhanced
sound.
Repeat steps 1 to 2 in Audio adjustment.
1
Press a/b to select “Bass enhancer”, and
2
then press ENTER.
Press c/d to select “On”.
3
Selected item Description
On Bass enhancer function is on.
Off Outputs the normal sound.
Output volume select
Allows you to select what controls the audio output.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Output volume select”,
3
and then press ENTER.
Press c/d to select “Fixed” or “Variable”, and
4
then press ENTER.
Audio output settings
Variable Fixed
Adjustable with remote
control
(No sound from the speakers)
a/b
Press
2
press ENTER.
Press c/d to select “On”.
3
Selected item Description
On
Off Outputs the normal sound.
38
LC-40LE700X_en_f.indd 38LC-40LE700X_en_f.indd 38 7/8/09 10:05:41 AM7/8/09 10:05:41 AM
to select “SRS TS HD”, and then
TruSurround HD creates a high quality
surround sound experience, when
watching DVD movies and TV programmes
broadcast in surround sound.
Selected item Description
Fixed • Sound via speakers is adjusted with VOL
Variable • Sound via the MONITOR OUT terminal is
on the remote control unit or the
e/f
TV.
• Sound via the MONITOR OUT terminal is
not adjustable and constantly outputs.
adjusted with VOL e/f on the remote
control unit or the TV.
• Sound via speakers is muted.
Page 41
Watching TV
Automatic volume adjustment
Different sound sources sometimes do not have the
same volume level, such as a programme and its
commercial breaks. The Automatic volume control
(Auto volume) reduces this problem by equalizing
levels.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Auto volume”, and then
3
press ENTER.
Press c/d to select “On”, and then press
4
ENTER.
Clear voice
This function emphasises speech against background
noise for greater intelligibility.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Clear voice”, and then
3
press ENTER.
Digital audio output
This function allows you to select your favourite audio
output system.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Digital audio output”,
3
and then press ENTER.
...
[
Option
MENU
AQUOS LINK setup
PC audio select
Output volume select
Auto volume
Clear voice
Digital audio output
Audio only
Programme title display
Time display
Colour system
Key lock
Setting display colour
Channel selecting effect
Option
DigitaI audio output
]
[INPUT7(RGB)]
[Fixed]
[Off]
[Off]
[PCM]
[No]
[Auto]
[Off]
[GREEN]
[Yes]
Press c/d to select “On”, and then press
4
ENTER.
Press a/b to select your desired output
4
system, and then press ENTER.
Digital audio optical output
PCM
Dolby Digital
Selected item Description
PCM
Dolby Digital Dolby Digital audio will be output when
The optical output format is normally in PCM.
there is a Dolby Digital audio signal. The
output will be in PCM when there is no
Dolby Digital audio signal.
To stereo audio system
To multi-channel
Dolby Digital audio system
39
LC-40LE700X_en_f.indd 39LC-40LE700X_en_f.indd 39 7/8/09 10:10:06 AM7/8/09 10:10:06 AM
Page 42
Watching TV
Using Digital Audio Output
It is possible to output audio through the DIGITAL AUDIO
OUTPUT terminal. PCM audio outputs from the terminal.
Optical fi bre cable
(commercially available)
To optical digital input of external audio devices
NOTE
• The DIGITAL AUDIO OUTPUT terminal usually outputs the
same audio from the speakers. (The audio of the content
you are viewing is output from the terminal.)
• The DIGITAL AUDIO OUTPUT terminal does not output
some signals, depending on devices and software.
Programme Guide
You can check the current schedule of DTV events
and view detailed information about current events.
Info
While watching DTV you can check the extended
programme information on the screen using INFO on
the remote control.
ABC TV Sydney
Dorothy The Dinosaur
15 : 23 - 15 : 30
Programme Info.
Dorothy’s friends chat over Rosy Tea before
admiring her beautiful Rose Garden, with
Wags the Dog, Henry the Octopus and
Captain Feathersword, and four new fairy
friends, Clare, Larissa, Lucia and little
• If there is more information, pressing a/b allows you to go
to the next page or return to the previous page.
• You can cancel this info by pressing INFO again.
Press GUIDE to display the programme guide
1
list.
Press a/b to display your desired
2
programme, and then press ENTER.
• When you press ENTER, the TV jumps to the
channel.
[
]
CH LIST
40
DTV -TV
002 ABC TV Sydney 9:23 – 9:29
Global Grover
002
ABC TV Sydney
003
SBS
004
FTV Guide
009
NINE DIGITAL
010
TEN DIGITAL
011
TEN Guide
012
TEN HD
020 ABC HDTV
021 ABC 2
022 ABC TV
030 SBS HD
031 SBS 2
[Mon]19/6 9:29
Global Grover
Global Grover
ABC Asia Pacific News
Global Grover
LC-40LE700X.indb 40LC-40LE700X.indb 40 6/26/09 4:26:03 PM6/26/09 4:26:03 PM
Page 43
Watching TV
ATV (Analogue)/DTV/RADIO buttons
Use the following buttons on the remote control to
operate the menu.
When you watch the TV for the fi rst time
When the TV powers on for the fi rst time after
purchase, perform the auto installation.
ATV (Analogue TV)
You can run the auto installation to set channels
automatically.
To watch the analogue TV, select “Auto
1
installation” from Setup menu. (See page 20.)
After setting the channels, you can select
2
a channel using CH r/s or 0 – 9 on the
remote control unit. (See page 21.)
DTV
When the TV accesses to DTV mode for the fi rst time,
you need to run the auto search. To scan all available
services in your area, follow the procedures below.
To watch DTV broadcasts, select “Digital
1
search” from auto installation menu. (See page
11.)
After setting the channels, you can select
2
a channel using CH r/s or 0 – 9 on the
remote control unit. (See page 21.)
ATV: Press to switch to analogue mode. After
switching from DTV, radio or external input mode to
analogue mode, the TV jumps to the most recently
viewed analogue channel.
DTV: Press to switch to DTV mode. After switching
from analogue, radio or external input mode to DTV
mode, the TV jumps to the most recently viewed DTV
channel.
RADIO: Press to switch to radio mode. After switching
from DTV to radio mode, the TV jumps to the most
recently tuned radio channel. (DTV mode only)
41
LC-40LE700X.indb 41LC-40LE700X.indb 41 6/26/09 4:26:03 PM6/26/09 4:26:03 PM
Page 44
Watching TV
EPG
What is an EPG?
An “EPG (Electronic Programme Guide)” is a
programme schedule, which is displayed on the TV
screen. The EPG is broadcasted together with DTV.
The TV screen shows the EPG when the viewer
presses EPG on the remote control, provided that
the TV is receiving the digital broadcasting signal. The
EPG enables you to search for a programme, do timer
recording or view the programme schedule in detail.
EPG display settings
EPG (Electronic Programme Guide) is a programme
list that is displayed on the screen. With the EPG, you
can check the schedule of DTV/RADIO/DATA, view
detailed information about them, tune to an event
currently on-air and set a timer for future events.
Press MENU and the MENU screen displays.
1
Press c/d to select “Digital setup”.
2
[
Digital setup
MENU
Digital setup Information
REC pictur e size
Download Setup
EPG setup
Subtitle
Time zone
Press a/b to select “EPG setup”, and then
3
press ENTER.
Press a/b or c/d to select the desired item
4
or adjust the item to the desired level. Press
ENTER if necessary.
H EPG setup (setting for receiving EPG
data)
EPG setup must be selected to “YES” to enable
automatic capturing of data for all available channels
while the TV set is in standby mode. If EPG setup is
set to “NO”, only EPG data for the current channel will
be updated.
Selecting EPG setup to “YES” will result in higher
power consumption*.
Selecting EPG setup to “NO” will save power
consumption.
NOTE
Approximately 19W for 15-30 minutes (depending on
*
number of channels tuned) after power off from remote
control.
• EPG data will not update if the TV is turned off from the
mains power switch.
...
EPG setup
]
[16:9 TV]
H Display range setup
The Display range setup allows you to select three
types of time spans for display on the screen.
Selected item Description
Mode1
(Wide angle)
Mode2
(Zoom)
Mode3
(Vertical
angle)
Display six hours of programme
information.
Display three hours of programme
information.
Change to the EPG display format with a
vertical time span.
H Genre icon setup
You can grey out or place a mark on desired genres
and smoothly search for programmes you frequently
watch.
Genre icon list
Icon Genre Icon Genre
Movie Arts/Culture
News Current affairs
Entertainment
Sport Information
Children’s Comedy
Music Drama
NOTE
• You can easily distinguish the Genre icons by darkening or
lightening the icon’s shade.
Education/
Information
Time zone
This function enables you to select your local time
zone.
Press MENU and the MENU screen displays.
1
Press c/d to select “Digital setup”.
2
Press a/b to select “Time zone”, and then
3
press ENTER.
Press a/b to select the desired time zone
4
and then press ENTER.
• This function lets you select the right time zone in case the
time displayed in the EPG does not match the local time of
your area.
42
LC-40LE700X.indb 42LC-40LE700X.indb 42 6/26/09 4:26:04 PM6/26/09 4:26:04 PM
Page 45
Watching TV
Selecting a programme using EPG
Basic Operation
H Display the EPG screen
Press EPG.
EPG [DTV-TV]
TEN Digital
ABC TV Sydney
SBS
FTV Guide
TEN Digital
TEN Guide
TEN HD
: Select
ABC HDTV
ABC 2
ABC TV
SBS HD
SBS 2
SBS NEWS
SBS NEWS
D44
2
H Display the EPG screen
002
ABC TV Sydney Global Grover
9:23 – 9:29
002
007
010
012
030
061
062
340
351
994
995
996
997
998
999
ENTER
RETURN
: Enter
9
10 11 12 13 14
Arr...
Ba...
Pla...
Pla... Ba... Arr... Naked Scien… Catal… Parliament Qu…The… The…
ABC…
Stat… T… W… Se… Play S… G…
EPG
: Back
: Exit Programme info.
Naked Scien… Catal… Parliament Qu…The… The…
R
Search by genreGSearch by dateYTimer list
345
[Tue]19/6 9:28Today [Tue]20 [Wed]21 [Thu]22 [Fri]23 [Sat]24 [Sun]25 [Mon]26
1
B
1 Press c/d to select the time span you want to search.
• Continue to press d to display programmes in the next time span.
2 Press a/b to select the desired programme.
• If a or b are displayed on the left of the services, continue to
press a/b to display next or previous screen.
Selecting a programme
3 Check programme information
Press a/b/c/d to select the programme
1
you want to check.
Press R.
2
Programme information
EPG [DTV-TV]
002
ABC TV Sydney Trotro
9:23 – 9:29
TEN Digital
ABC TV Sydney
SBS
FTV Guide
TEN Digital
TEN Guide
TEN HD
ABC HDTV
ABC 2
SBS NEWS
D44
ENTER
: Select
: Enter
Press ENTER to tune to the selected
3
programme.
Programme info.
Back to EPG
R
10 11 12 13 14
9
002
007
010
012
030
061
062
340
351
998
999
RETURN
Ba...
Pla...
Pla... Ba... Arr... Naked Scien… Catal… Parliament Qu…The… The…
ABC…
Stat… T… W… Se… Play S… G…
EPG
: Back
: Exit
Trotro is a little donkey with a head full of ideas. He knows exactly what
he likes and doesn’t like. He’s a positive and engaging hero, with whom
young children will easily identify.
Next
B
Arr... Naked Scien… Catal… Parliament Qu…The… The…
[Tue]19/6 9:28Today [Tue]20 [Wed]21 [Thu]22 [Fri]23 [Sat]24 [Sun]25 [Mon]26
Close the EPG screen
H
Press EPG again.
43
LC-40LE700X.indb 43LC-40LE700X.indb 43 6/26/09 4:26:06 PM6/26/09 4:26:06 PM
Page 46
Watching TV
4 Search a programme in a category
Press G.
1
Press a/b to select the desired genre, and
2
then press ENTER.
Press a/b to select a programme you want
3
to watch, and then press ENTER.
EPG [Mon]19/6 10:57[DTV-TV]
Search by genre
Movie
News
Entertainment
Sport
Children’s
Music
Arts/Culture
Current Affairs
Education/Information
Information
Comedy
Drama
: Select
ENTER
: Enter
RETURN
Today
[Tue]20 [Wed]2 [Thu]22 [Fri]23 [Sat]24 [Sun]25 [Mon]26
Today [AM]
ABC HDTV 020 Global Grover [Mon] 19/06 10 : 50 11 : 10
ABC TV 022 Global Grover [Mon] 19/06 11 : 05 11 : 20
: Back
EPG
R
: Exit Back to EPG
5 Search for a programme by date/time
Press Y.
1
Press c/d to select the desired time span
2
and then press ENTER.
EPG [DTV-TV]
Search by time
0 – 6 6 – 12 12 – 18 18 – 0
ENTER
: Enter
R
Ba...
Pla...
Pla... Ba... Arr... Naked Scien… Catal… Parliament Qu…The… The…
Stat… T… W… Se… Play S… G…
EPG
: Exit
Arr...
TEN Digital
ABC TV Sydney
SBS
FTV Guide
TEN Digital
TEN Guide
TEN HD
ABC HDTV
ABC 2
SBS 2
SBS NEWS
SBS NEWS
D44
: Select
ENTER
: Enter
: Select time
9 10 11 12 13 14
002
007
010
012
030
061
062
340
351
ABC…
996
997
998
999
RETURN
: Back
Today [PM] [Tue] 20 AM [Tue] 20 PM
Today
-ABC TV Sydney 002 Global Grover [Mon] 19/06 10 : 50 11 : 05
Next
Back to EPG
Naked Scien… Catal… Parliament Qu…The… The…
Enter +1 Week
G Y
Next
B
Next
B
[Tue]19/6 9:28Today [Tue]20 [Wed]21 [Thu]22 [Fri]23 [Sat]24 [Sun]25 [Mon]26
Press a/b to select the desired programme,
3
and then press ENTER.
NOTE
• When you select a programme outside of the current time
span, the timer setting screen displays. (Page 45)
44
LC-40LE700X.indb 44LC-40LE700X.indb 44 6/26/09 4:26:06 PM6/26/09 4:26:06 PM
Page 47
Watching TV
Timer setting using EPG
You can select TV programmes using data from the
EPG.
Press EPG.
1
Press a/b/c/d to select the programme
2
you want to set, and then press ENTER.
Press c/d to select the timer setting, and
3
then press ENTER.
Select a kind of timer setup
NoWatch
• If you select “No”, the TV returns to the EPG screen.
H Selecting “Watch” in the timer setup
screen
This setting allows you to switch to a programme at a
set time.
Press c/d to select “Watch”, and then press
1
ENTER.
Press c/d to select “Yes”, and then press
2
ENTER.
• The selected TV programme is marked with an icon.
Cancelling the timer setting
Press EPG.
1
Press a/b/c/d to select the programme on
2
timer setup, and then press ENTER.
Press c/d to select “Cancel”, and then press
3
ENTER.
H Cancelling using B button on the remote
control
Press EPG.
1
Press B to display the timer list screen.
2
Press a/b to select a programme you want
3
to change, and then press ENTER.
Press c/d to select “Cancel” and then press
4
ENTER.
45
LC-40LE700X.indb 45LC-40LE700X.indb 45 6/26/09 4:26:07 PM6/26/09 4:26:07 PM
Page 48
Settings when using external devices
Settings when using HDMI output devices
HDMI terminals can carry audio and visual signals to the TV with an HDMI certifi ed cable. When you want to
output the audio and picture from an HDMI output device on the TV, select “INPUT1”, “INPUT2” or “INPUT3” by
switching the input source.
Connecting an HDMI output device
HDMI output device
HDMI cable
(commercially available)
HDMI (High-Defi nition Multimedia Interface)
H
Auto View
To watch an HDMI equipment image, select
1
“INPUT1”, “INPUT2” or “INPUT3” using TV/
VIDEO on the remote control unit or on the
TV.
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
3
Press a/b to select “HDMI auto view”, and
4
then press ENTER.
• The HDMI auto view can be selected only when
“INPUT1”, “INPUT2” or “INPUT3” is selected.
...
[
Setup
MENU
Setup Option
Input skip
Input label
X Position
HDMI auto view
Quick start
Language
Blue illumination
Reset
Press c/d to select the desired item, and
5
then press ENTER.
Selectable items
Enable/
Disable
HDMI auto view
Set whether or not to use WIDE MODE
based on signal recognition, including an
HDMI signal.
]
[DVD]
[Enable]
[On]
[English]
[On]
Description
46
LC-40LE700X_en_f.indd 46LC-40LE700X_en_f.indd 46 7/8/09 10:12:06 AM7/8/09 10:12:06 AM
Page 49
Settings when using external devices
Selecting the input source and
signal type
Selecting input source
Can use for selecting the input source.
Using TV/VIDEO on the remote control unit or on
the TV.
TV/VIDEO allows you to choose from the available
input sources.
Selecting input signal type
For setting the signal type of external equipment.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Input select”, and then
3
press ENTER.
Press a/b to select a signal type you want to
4
set, and then press ENTER.
Input source Selectable item
INPUT 4 Auto, COMPONENT, S-VIDEO, VIDEO
INPUT 6 Auto, COMPONENT, VIDEO
NOTE
• If no (colour) image displays, try changing the other
signal type.
• Check the operation manual of the external equipment for
the signal type.
• When the signal type is set to “Auto”, the input terminal
where a cable is connected is automatically selected.
• When the signal type is set to “Auto” and multiple video
signal cables are connected, the signal type is selected in
the following prioritised order:
INPUT 4: COMPONENT s S-VIDEO s VIDEO
INPUT 6: COMPONENT
s
VIDEO
Press TV/VIDEO on the remote control unit or
1
on the TV.
Press TV/VIDEO on the remote control unit or
2
on the TV to select the input source.
• The image and sound from the selected source
are output on the TV.
• You can also select the input source by pressing
.
a/b
Selecting the size of the picture for recording
You can use this function to set the appropriate
picture size for recording a 16:9 format TV programme
broadcast via DTV.
Press MENU and the MENU screen displays.
1
Press c/d to select “Digital setup”.
2
Press a/b to select “REC picture size”, and
3
then press ENTER.
Press c/d to select the desired picture size,
4
and then press ENTER.
Selected item Description
16:9 TV The TV displays the 16:9 format picture
4:3 TV The picture gets compressed in the
with black bands at the top and bottom
of the screen.
horizontal direction.
47
LC-40LE700X.indb 47LC-40LE700X.indb 47 6/26/09 4:26:08 PM6/26/09 4:26:08 PM
Page 50
Settings when using external devices
Labelling input sources Skipping HDMI/RGB input
You can assign each input source a label as you
prefer.
Press TV/VIDEO to select the desired input
1
source.
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
3
Press a/b to select “Input label”, and then
4
press ENTER.
Press a/b/c/d to select each character of
5
the new name for the input source, and press
ENTER.
External equipment name settings
This setting allows you to skip the HDMI or RGB input
on the input source selection operation.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Input skip”, and then
3
press ENTER.
Press a/b to select the Input (INPUT1 to
4
INPUT3 and INPUT7 ) you wish to skip, and
then press ENTER.
INPUT1 (HDMI)
INPUT2 (HDMI)
INPUT3 (HDMI)
INPUT7 (RGB)
Press c/d to select “Yes”, and then press
5
ENTER.
Press MENU to exit.
6
Skip input selection of HDMI
Yes
No
C
B
A
P
O
N
M
L
K
Z
Y
X
W
V
U
5
4
3
2
1
0
(Example)
Repeat until the name is fully spelt out.
6
• The name can be 6 characters or less.
• When you want to set an input source name of
less than 6 characters, select “END”, then press
ENTER to exit from the labelling menu.
CLEAR
J
I
R
Q
BACK
T
S
+
_
.
-
7
6
END
9
8
H
G
F
E
D
INPUT SOURCE
TV
DVD
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
(Example)
NOTE
• You cannot change labels if the input source is TV.
48
Colour system settings
You can change the colour system to one that is
compatible with the image on the screen.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Colour system”, and
3
then press ENTER.
Press
4
system of your equipment, and then press
ENTER.
NOTE
• Factory preset value is “AUTO”.
• If “AUTO” is selected, colour system for each channel is
automatically set. If an image does not display clearly,
select another colour system (e.g. PAL, NTSC 4.43).
• “Colour system” is selectable only when inputting an
S-VIDEO or composite signal.
to select a compatible video signal
a/b
Colour system settings
AUTO
PAL
SECAM
NTSC 3.58
NTSC 4.43
PAL-60
LC-40LE700X.indb 48LC-40LE700X.indb 48 6/26/09 4:26:09 PM6/26/09 4:26:09 PM
Page 51
Settings when using external devices
Setting display colour
You can change the background colour of the OSD
(menu screen), channel display and programme
information, etc. to the blue, gray, red or green.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Setting display colour”,
3
and then press ENTER.
Press a/b to select the desired colour, and
4
then press ENTER.
Colour setting, including Menu and EPG
BLUE
GRAY
RED
GREEN
Channel selecting effect
This function shows a screen effect when choosing or
changing channels.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Press a/b to select “Channel selecting effect”,
3
and then press ENTER.
Press c/d to select “On”, and then press
4
ENTER.
49
LC-40LE700X_en_f.indd 49LC-40LE700X_en_f.indd 49 7/8/09 11:16:09 AM7/8/09 11:16:09 AM
Page 52
AQUOS LINK
Controlling HDMI devices using AQUOS LINK
What is AQUOS LINK?
Using the HDMI CEC protocol, with AQUOS LINK you can interactively operate
compatible system devices (AV amplifi er, DVD player/recorder, Blu-ray player/
recorder) using a single remote control unit.
What you can do with AQUOS LINK
One Touch Recording (DTV only)
✔
You do not have to search for the remote control unit of your recording device. Press
the REC E or REC STOP H buttons inside the fl ip cover to start/stop recording
what you see on the recorder.
One Touch Play
✔
While the TV is in standby mode, it will automatically turn on and play back the image
from the HDMI source.
Single remote control operation
✔
AQUOS LINK automatically recognises the connected HDMI devices and you can
control the TV and the devices as if using a universal remote control unit.
✔ Operating Title list of external devices
In addition to displaying the TV’s own Timer list (Pages 43 and 44), you can also call
up the external player’s Top menu or AQUOS BD Player’s/AQUOS Recorder’s Title list
provided that the devices support AQUOS LINK.
✔ Multiple control of HDMI devices
You can select which HDMI device to operate using the OPTION button.
NOTE
• When you use AQUOS LINK, make sure to use a certifi ed HDMI cable.
• Point the remote control unit toward the TV, not to the connected HDMI device.
• Video noise may occur depending on the type of HDMI cable used. Make sure to use a
certifi ed HDMI cable.
• Up to three HDMI recording devices, one AV amplifi er and two players can be connected
using this system.
• These operations affect the HDMI device selected as the current external source. If the device
does not operate, turn on the device and select the appropriate external source using TV/
VIDEO.
• When you insert/remove HDMI cables or change connections, turn on all connected HDMI
devices before turning on the TV. Confi rm that picture and audio are correctly output by
selecting “INPUT1”, “INPUT2” or “INPUT3” from the “INPUT SOURCE” menu.
50
LC-40LE700X.indb 50LC-40LE700X.indb 50 6/26/09 4:26:11 PM6/26/09 4:26:11 PM
Page 53
AQUOS LINK
AQUOS LINK connection
First connect the AQUOS AUDIO speaker system or an AQUOS BD Player/AQUOS Recorder that supports the
HDMI CEC protocol.
NOTE
• Refer to the operation manual of the device to be connected for further details.
• After unplugging connection cables or changing the connection pattern, turn on the power of the TV after all relevant device’s
power have been turned on. Change the external input source by pressing TV/VIDEO, select the appropriate external source
and verify the audiovisual output.
• The cables illustrated in the following explanation are commercially available items.
Connecting an AQUOS BD Player/AQUOS Recorder via
the AQUOS AUDIO speaker system
Connecting an AQUOS BD Player/
AQUOS Recorder only
HDMI-certifi ed cable
HDMI-certifi ed cable
AQUOS BD Player/
AQUOS Recorder
AQUOS LINK setup
AQUOS LINK control
Set to “On” to enable HDMI CEC functions.
Press MENU and the MENU screen displays.
1
Press c/d to select “Option”.
2
Optical audio
cable
AQUOS AUDIO
speaker system
4
5
6
HDMI-certifi ed cable
AQUOS BD Player/
AQUOS Recorder
Press a/b to select “AQUOS LINK control”,
and then press ENTER.
AQUOS LINK control
Auto power on
Selecting recorder
Selecting channel key
Using genre info.
Setting for AQUOS LINK control
On Off
Press c/d to select “On”, and then press
ENTER.
Press MENU to exit.
Press a/b to select “AQUOS LINK setup”,
3
and then press ENTER.
51
LC-40LE700X.indb 51LC-40LE700X.indb 51 6/26/09 4:26:11 PM6/26/09 4:26:11 PM
Page 54
AQUOS LINK
Auto power on
If this is activated, the One Touch Play function is enabled.
While the TV is in standby mode, it automatically turns on
and plays back the image from the HDMI source.
Repeat steps 1 to 3 in AQUOS LINK control.
1
Press a/b to select “Auto power on”, and
2
then press ENTER.
AQUOS LINK control
Auto power on
Selecting recorder
Selecting channel key
Using genre info.
Press c/d to select “On”, and then press
3
ENTER.
Press MENU to exit.
4
NOTE
• The factory default for this item is “Off”.
Setting auto power on by AQUOS LINK
On Off
Selecting recorder
Here, you can select a recorder for the recording from
several connected recorders.
Repeat steps 1 to 3 in AQUOS LINK control.
1
Press a/b to select “Selecting recorder”, and
2
then press ENTER.
AQUOS LINK control
Auto power on
Selecting recorder
Selecting channel key
Using genre info.
Select the recorder, and then press ENTER.
3
Selecting recorder for recording
by [REC] button
Input Location
INPUT1
INPUT2
[1. 0. 0. 0]
[2. 0. 0. 0]
Selecting channel key
This function allows you to select the channel of the
connected HDMI device using the TV’s remote control
unit.
Repeat steps 1 to 3 in AQUOS LINK control.
1
Press a/b to select “Selecting channel key”,
2
and then press ENTER.
AQUOS LINK control
Auto power on
Selecting recorder
Selecting channel key
Using genre info.
Press a/b to select the input source of the
3
connected HDMI device you want to control
using the TV
Setting channel select key for AQUOS LINK
compatible device via the HDMI input
INPUT1 On
INPUT2
INPUT3
’
s remote control unit, and then
Off
On
Off
On
Off
press ENTER.
Press c/d to select “On”, and then press
4
ENTER.
Using genre info.
This function allows you to automatically switch to
the appropriate sound mode depending on the genre
information included in the digital broadcast.
Repeat steps 1 to 3 in AQUOS LINK control.
1
Press a/b to select “Using genre info.”, and
2
then press ENTER.
Press c/d to select “On”, and then press
3
ENTER.
Operating an AQUOS LINK device
AQUOS LINK allows you to operate the HDMIconnected device with a single remote control unit.
Open the remote control unit’s fl ip cover.
1
Press MENU to exit.
4
NOTE
• If you have connected the AQUOS AUDIO speaker system
between the TV and an AQUOS Recorder, the external
’s indication changes (e.g. from “INPUT 1” to
source
“INPUT 1 (Sub)”).
AQUOS LINK control
Auto power on
Selecting recorder
Selecting channel key
Using genre info.
52
LC-40LE700X.indb 52LC-40LE700X.indb 52 6/26/09 4:26:12 PM6/26/09 4:26:12 PM
Selecting recorder for recording
by [REC] button
Input Location
INPUT1
INPUT1 (Sub)
INPUT2
[1. 0. 0. 0]
[1. 1. 0. 0]
[2. 0. 0. 0]
Press PLAY I to start playback of a title.
2
• See page 53, section “Playback of titles using
AQUOS LINK” if you want to start playback using
the list of the titles of the AQUOS BD Player/
AQUOS Recorder.
Press FWD J to fast forward.
3
Press REV G to reverse.
Press STOP H to stop.
Press POWER to turn the HDMI-connected
device on/off.
Page 55
AQUOS LINK
Listening with the AQUOS AUDIO speaker
system
You can choose to listen to the TV sound only from
the AQUOS AUDIO speaker system.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “By AQUOS AUDIO SP”,
2
and then press ENTER.
AQUOS LINK Menu
Recorder EPG
Top Menu/Title List
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup Menu
Model select
• The sound from the TV speaker and headphone
terminal is silenced and only the sound from the
AQUOS AUDIO speaker system is audible.
Listening with the AQUOS TV speaker
system
You can choose to listen to the TV sound only from the
AQUOS TV speaker system.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Calling up the menu of an external device
connected with the TV via HDMI
You can call up the menu of an HDMI CEC-compatible
external device (player, recorder, decorder, etc.) using
the “Setup Menu” function.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “Setup Menu”, and then
2
press ENTER.
NOTE
• If a connected device does not have this function or the
device is in a status where the menu cannot be displayed
(recording, entering standby, etc.), this function may not be
available.
Playback of titles using AQUOS LINK
This section explains how to play back a title in the
AQUOS BD Player/AQUOS Recorder.
Press a/b to select “By AQUOS SP”, and
2
then press ENTER.
Manually changing the AQUOS AUDIO
speaker system’s sound mode
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “Sound mode change”.
2
AQUOS LINK Menu
Recorder EPG
Top Menu/Title List
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup Menu
Model select
The sound mode changes every time you
3
press ENTER.
• Refer to the operation manual of the AQUOS
AUDIO speaker system for details.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “Top menu/Title list”, and
2
then press ENTER.
AQUOS LINK Menu
Recorder EPG
Top Menu/Title List
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup Menu
Model select
• The linked recorder now powers on and the TV
automatically selects the appropriate external
input source.
• The title list data from the connected AQUOS BD
Player/AQUOS Recorder displays.
Select the title with a/b/c/d, and then
3
press PLAY I.
53
LC-40LE700X_en_f.indd 53LC-40LE700X_en_f.indd 53 7/8/09 10:16:58 AM7/8/09 10:16:58 AM
Page 56
AQUOS LINK
Selecting media type for CEC-compatible
recorder
If your recorder has multiple storage media, select the
media type here.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “Media change”, and
2
then press ENTER.
AQUOS LINK Menu
Recorder EPG
Top Menu/Title List
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup Menu
Model select
Select the desired medium, such as DVD
3
recorder or HDD. The media type changes
every time you press ENTER.
HDMI device selection
If multiple HDMI devices are connected in a daisy
chain, you can specify which device to control here.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “Model select”, and then
2
press ENTER. The HDMI device changes
every time you press ENTER.
Recording via the AQUOS Recorder EPG
(only for recorders)
You can call up the CEC-compatible recorder’s EPG
and preset timer recordings using the TV’s remote
control unit.
Open the remote control unit’s fl ip cover, and
1
then press OPTION.
Press a/b to select “Recorder EPG”, and
2
then press ENTER.
• The external input source switches and the
recorder’s EPG is displayed.
AQUOS LINK Menu
Recorder EPG
Top Menu/Title List
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup Menu
Model select
Select the programme to record.
3
• Refer to the operation manual of the recorder for
details.
54
LC-40LE700X_en_f.indd 54LC-40LE700X_en_f.indd 54 7/8/09 10:17:00 AM7/8/09 10:17:00 AM
Page 57
Connecting a PC
Use the PC terminals to connect a PC.
HDMI Connection
HDMI cable (commercially available)
PC
DVI/HDMI conversion cable
(commercially available)
3.5 mm stereo minijack cable
(commercially available)
PC
INPUT 2 or INPUT 3
INPUT 1*
* When using the INPUT 1 terminal, you must select the proper item in the “PC audio select” menu depending on
the type of HDMI cable connected. (See page 56.)
NOTE
• The PC INPUT terminals are DDC1/2B-compatible.
• Refer to page 59 for a list of PC signals compatible with the TV.
Analogue Connection
PC
3.5 mm stereo minijack cable
(commercially available)
RGB cable (commercially available)
INPUT 7*
3.5 mm stereo minijack
cable (commercially available)
RGB/DVI conversion cable
(commercially available)
INPUT 7*
PC
* When using the INPUT 7 terminal, you must select “INPUT7(RGB)” in the “PC audio select” menu. (See page 56.)
Signal names for 15-pin mini D-sub connector
Pin No. Signal name Pin No. Signal name Pin No. Signal name
5
4 321
10
15
141312
9
6
7
8
11
NOTE
• Macintosh adaptor may be required for use for some Macintosh computers.
• Pin No. 5 is not used for inputting the signal.
LC-40LE700X.indb 55LC-40LE700X.indb 55 6/26/09 4:26:16 PM6/26/09 4:26:16 PM
R GND (Ground) Not connected
G GND (Ground) SDA
B GND (Ground) HD
Not connected +5V VD
CSYNC GND (Ground) SCL
55
Page 58
Connecting a PC
PC audio select
When using the INPUT 7 terminal or INPUT 1 terminal, you must select which terminal uses the AUDIO (R/L) jack
for analogue audio input.
Selected item Description
INPUT1(HDMI)
INPUT7(RGB) When connecting a PC to the INPUT 7 terminal, and inputting analogue audio signals from the AUDIO
NOTE
• You must set this to “INPUT7(RGB)” when connecting devices (including a PC) with an HDMI-certifi ed cable to the INPUT 1
terminal. If “INPUT1(HDMI)” is set, there will be no sound output.
When connecting devices (including a PC) with DVI/HDMI cable to the
analogue audio signals from the AUDIO (R/L) jack.
(R/L) jack.
1 terminal and inputting
INPUT
Displaying a PC image on the screen
Selecting the picture size
You can select the picture size as illustrated below.
Press WIDE.
1
• The WIDE MODE menu displays.
WIDE MODE
Normal
Cinema
Full
Dot by Dot
a
Screen size images.
Input Signal CinemaNormal
1024g768
Input Signal
1360g768
Keeps the original
aspect ratio in a full
screen display.
Keeps the original
aspect ratio in a full
screen display.
Normal
Press WIDE or a/b to select a desired item
2
on the menu.
NOTE
• Connect the PC before making adjustments.
• Selectable screen size may vary with input signal type.
For viewing wide
screen programs. The
top and bottom of
the image is slightly
cropped.
(Example)
Full
An image fully fi lls the
screen.
Full
An image fully fi lls the
screen.
Dot by Dot
Detects the resolution
of the signal and
displays an image
with the same number
of pixels on the
screen.
Dot by Dot
Detects the resolution
of the signal and
displays an image
with the same number
of pixels on the
screen.
56
LC-40LE700X.indb 56LC-40LE700X.indb 56 6/26/09 4:26:17 PM6/26/09 4:26:17 PM
Page 59
Connecting a PC
Adjusting the PC image automatically Adjusting the PC image manually
This function enables the screen to be automatically
adjusted to its best possible condition when the
analogue terminals of the TV and PC are connected
with a commercially available DVI/D-sub conversion
cable, etc.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Auto sync.”, and then
3
press ENTER.
Press c/d to select “Yes”, and then press
4
ENTER.
• Auto sync. starts and “Adjusting the image”
displays.
...
MENU
[
Setup
]
Auto sync.
Auto adjustment of image display parameters
Yes
No
Ordinarily you can easily adjust the picture as
necessary to change image position using Auto sync.
In some cases, however, manual adjustment is needed
to optimise the image.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Fine sync.”, and then
3
press ENTER.
Press a/b to select the specifi c adjustment
4
item.
Image position adjustment, etc.
H-pos. [ 90] – +
V-pos.
[ 39]
–+
Clock
[ 90]
–+
Phase
[ 20]
–+
Reset
Selected item Description
H-pos. adjustment
V-pos. adjustment
Clock freq. adjustment
Clock phase adjustment
Return to factory pre-settings
Auto sync.
30%
Adjusting the image.
Press MENU to exit.
5
NOTE
• When Auto sync. is successful, “Auto sync completed
successfully” displays. If not, Auto sync. failed.
• Auto sync. may fail even if “Auto sync completed
successfully” displays.
• Auto sync. may fail if the computer image has low
resolution, has unclear (black) edges, or is moved while
executing Auto sync.
• Be sure to connect the PC to the TV and switch it on
before starting Auto sync.
• Auto sync. can be executed only when inputting analogue
signals.
H-pos. Centres the image by moving it to the left
or right.
V-pos. Centres the image by moving it up or
down.
Clock Adjusts when the image fl ickers with
vertical stripes.
Phase Adjusts when characters have low
contrast or when the image fl ickers.
Press c/d to adjust the item to your desired
5
position.
Press MENU to exit.
6
NOTE
• For resetting all adjustment items to the factory preset
values, press a/b to select “Reset”, and then press
ENTER.
• “Clock” and “Phase” in the “Fine sync.” menu can be
adjusted only when inputting analogue signals.
57
LC-40LE700X.indb 57LC-40LE700X.indb 57 6/26/09 4:26:18 PM6/26/09 4:26:18 PM
Page 60
Connecting a PC
PC Control of the TV
• When a programme is set, the TV can be controlled from the PC using the RS-232C terminal.
The input signal (PC/video) can be selected, the volume can be adjusted and various other adjustments and
settings can be made, enabling automatic programmed playing.
• Attach an RS-232C cable cross-type (commercially available) to the Din/D-sub RS-232C for the connections.
NOTE
• This operation system should be used by a person who is accustomed to using PCs.
Communication conditions
Set the RS-232C communications settings on the PC to match the communications conditions of the TV. The
communications settings of the TV are as follows:
Baud rate:
Data length:
Parity bit:
Stop bit:
Flow control:
9,600 bps
8 bits
None
1 bit
None
Communication procedure
Send the control commands from the PC via the RS-232C connector.
The TV operates according to the received command and sends a response message to the PC.
Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending the
next command.
Command format
Eight ASCII codes e CR
C1 C2 C3 C4 P1 P2 P3 P4
Command 4-digits Parameter 4-digits Return code
Parameter
Input the parameter values, aligning left, and fi ll with space(s) for the remainder. (Be sure that four values are input for the
parameter.)
When the input parameter is not correct, “ERR” returns. (Refer to “Response code format”.)
Command 4-digits: Command. The text of four characters.
Parameter 4-digits: Parameter 0 – 9, space, ?
0
0 0 0 9
a 3 0
1 0 0
0 0 5 5
When “?” is input for some commands, the present setting value responds.
?
? ? ? ?
Response code format
Normal response
O K
Return code (0DH)
58
LC-40LE700X.indb 58LC-40LE700X.indb 58 6/26/09 4:26:19 PM6/26/09 4:26:19 PM
Problem response (communication error or incorrect command)
E R R
Return code (0DH)
Page 61
Connecting a PC
PC compatibility chart
Resolution
VGA 640 g 480 31.5 kHz 60 Hz
SVGA 800 g 600 37.9 kHz 60 Hz
XGA 1024 g 768 48.4 kHz 60 Hz
WXGA 1360 g 768 47.7 kHz 60 Hz
SXGA 1280 g 1024 64.0 kHz 60 Hz
SXGA+ 1400 g1050 65.3 kHz 60 Hz
NOTE
• This TV has only limited PC compatibility, correct operation can only be guaranteed if the video card conforms exactly to the
VESA 60Hz standard. Any variations from this standard will result in picture distortions.
Horizontal
Frequency
Vertical
Frequency
Analogue
(D-Sub)
✔✔✔
✔✔✔
✔✔✔
✔✔✔
✔✔✔
Digital (HDMI) VESA Standard
✔✔
DDC is a registered trademark of Video Electronics Standards Association. Power Management is a registered
trademark of Sun Microsystems, Inc. VGA and XGA are registered trademarks of international Business
Machines Corp.
RS-232C commands list
Commands
• Commands not indicated here are not guaranteed to operate.
NOTE
• If an underbar (_) appears in the parameter column, enter a
space.
• If an asterisk (*) appears, enter a value in the range
indicated in brackets under CONTROL CONTENTS.
59
LC-40LE700X_en_g.indd 59LC-40LE700X_en_g.indd 59 7/8/09 10:25:50 AM7/8/09 10:25:50 AM
Page 62
Teletext function
About Teletext
What is Teletext?
Teletext broadcasts pages of information and
entertainment to specially equipped television sets.
Your TV receives Teletext signals broadcast by a TV
network, and decodes them into graphical format for
viewing. News, weather reports, sports information,
stock exchange prices and programme previews are
among the many services available.
Teletext mode
Teletext is turned on/off with m on the remote control
unit. You can operate your TV in Teletext mode directly
by inputting commands with the remote control unit.
TELETEXT
TELETEXT
When viewing the Teletext information
• Press CHr to increase the page number.
• Press CHs to decrease the page number.
Button functions
Colour (Red/Green/Yellow/Blue):
You can select a group or block of pages displayed
in the coloured brackets at the bottom of the screen
by pressing the corresponding Colour (Red/Green/
Yellow/Blue) on the remote control unit.
Turning on and off Teletext
Select a TV channel or external input source
1
providing the Teletext programme.
Press m to display the Teletext.
2
Press m again to display the Teletext on
3
the right screen and normal image on the left
screen.
• Each time you press m, the screen switches as
shown to the upper right.
• If you select a programme with no Teletext signal,
“No Teletext available” is displayed.
• The same message displays during other modes if
no Teletext signal is available.
TELETEXT
Red Green Yellow Blue
0 – 9:
Directly select any page from 100 to 899 by using 0 – 9.
(Top/Bottom/Full):
v
Each time you press v, the TELETEXT image
switches as shown below.
Full (Displays in full screen)
Top (Displays in the upper half of the screen)
Bottom (Displays in the lower half of the screen)
(Reveal hidden for TELETEXT):
k
To reveal hidden information such as an answer to a
quiz, press k.
• Press k again to hide the information.
(Hold):
3
To stop updating Teletext pages automatically, press
3.
• Press 3 again to release the hold mode.
60
LC-40LE700X_en_g.indd 60LC-40LE700X_en_g.indd 60 7/10/09 8:57:59 AM7/10/09 8:57:59 AM
Page 63
Teletext function
Teletext language setting
If Teletext information does not display correctly,
perform the procedure below.
Select from among 4 kinds of language tables: West
Europe, East Europe, Greek/Turkish, Cyrillic.
Each table is compatible with the Teletext languages
listed below.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Text language”, and
3
then press ENTER.
Press a/b to select receivable teletext
4
broadcasting language in your country.
...
[
Setup
MENU
• West Europe – English, French, Scandinavian,
Czech, German, Spanish, Italian
• East Europe – Polish, French, Scandinavian,
Czech, German, Slovenian/Croatian, Italian,
Rumanian
• Greek/Turkish – English, French, Scandinavian,
Turkish, German, Spanish, Italian, Greek
]
Text language
Teletext language settings
West Europe
East Europe
Greek/Turkish
Cyrillic
Displaying Subpages
You can display subpages as they are transmitted.
Press m to display Teletext.
1
Press 1 to display the subpage as shown
2
below.
Subpage screen
– +
Select the desired subpage by using CHr/
3
CHs, Red or Green.
• 0 – 9 directly selects the desired subpage.
Press 1 to exit the subpage screen.
4
Time display
You can display the time information included in the
Teletext broadcast.
• Cyrillic – English, Russian, Estonian, Czech,
German, Spanish, Ukrainian, Lettish
NOTE
• Teletext can display only when it is sent by a network. Not
used to convert between languages.
Select a TV channel providing Teletext
1
information.
(The time information is automatically
captured.)
Press DISPLAY. The channel display will
2
appear on the display.
Press DISPLAY again. The channel display
3
about three seconds on the screen. Time
information will continuously display on the
lower right of the screen.
Even when you change the TV channel, you
4
can display the time information with steps 2
to 3 above.
NOTE
•
The time display cannot be stored once the power is turned
off. When you turn on the power, perform steps 1 to 4 again.
• If acquired successfully the time information will appear in
the upper-right corner of the screen by pressing MENU.
61
LC-40LE700X.indb 61LC-40LE700X.indb 61 6/26/09 4:26:21 PM6/26/09 4:26:21 PM
Page 64
Teletext function
Displaying Subtitles
You can display subtitles as they are transmitted.
Press [ to display the subtitle.
1
• Subtitle is updated by information sent by the
broadcasting station.
Press [ to exit the subtitle screen.
2
NOTE
• Subtitle will not be displayed when the service does not
contain subtitle information.
Switching subtitle languages
Each time you press [ on the remote control, the
subtitle switches
Set “For hearing impaired” to “Yes”
H Displaying subtitles for the hearing
impaired
You can display subtitles for the hearing impaired in the
Teletext broadcast.
Press MENU and the MENU screen displays.
1
Press c/d to select “Digital setup”.
2
Press a/b to select “Subtitle”, and then press
3
ENTER.
Press a/b to select “For hearing impaired”,
4
and then press ENTER.
Press c/d to select “Yes”, and then press
5
ENTER.
(For hearing impaired) 1st Language
••••••••
Off
Set “For hearing impaired” to “No”
2nd Language
1st Language 2nd Language
••••
Off
(For hearing impaired)
H Selecting the Language
Press MENU and the MENU screen displays.
1
Press c/d to select “Digital setup”.
2
Press a/b to select “Subtitle”, and then press
3
ENTER.
Press a/b to select “1st language” or “2nd
4
language”, and then press ENTER.
Press a/b to select the desired language,
5
and then press ENTER.
62
LC-40LE700X_en_g.indd 62LC-40LE700X_en_g.indd 62 7/8/09 10:27:46 AM7/8/09 10:27:46 AM
Page 65
Appendix
Troubleshooting
The problems described below are not always caused by malfunctions. Check the TV again before having the TV
serviced.
Problem
• No power.
• Unit cannot be operated.
• Remote control unit does not
operate.
• Picture is cut off.
• Strange colour, light colour, or
dark, or colour misalignment.
• Power is suddenly turned off.
• No picture.
Possible Solution
• Check if you pressed POWER on the remote control unit. (See page 16.)
If the indicator on the TV lights up red, press POWER.
• Is the AC cord disconnected? (See page 10.)
• Has the power been turned on? (See page 16.)
• External infl uences such as lightning, static electricity, etc., may cause improper
operation. In this case, operate the unit after fi rst turning the power off the TV or
unplugging the AC cord and re-plugging it in after 1 or 2 minutes.
• Are batteries inserted with polarity (e, f) aligned? (See page 15.)
• Are batteries worn out? (Replace with new batteries.)
• Are you using it under strong or fl uorescent lighting?
• Is a fl uorescent light shining on the remote control sensor?
• Is the image position correct? (See page 36.)
• Are screen mode adjustments such as picture size made correctly? (See pages 31,
32 and 56.)
• Adjust the picture tone. (See pages 34 to 36.)
• Is the room too bright? The picture may look dark in a room that is too bright.
• Check the colour system setting. (See pages 23 and 48.)
• Check the HDMI auto view setting. (See page 46.)
• The unit's internal temperature has increased.
Remove any objects blocking the vent or clean.
• Check the ECO setting. (See page 30.)
• Is the sleep timer set? (See page 30.)
• Is the connection to external equipment correct? (See pages 13 and 14.)
• Is the correct input selected? (See page 47.)
• Is the picture adjustment correct? (See pages 34 to 36.)
• Is the antenna connected properly? (See page 10.)
• Is “On” selected in “Audio only”? (See page 26.)
• No sound.
• The TV sometimes makes a
cracking sound.
• Is the volume too low? (See page 21.)
• Make sure that headphones are not connected. (See page 8.)
•
This is not a malfunction. This happens when the cabinet slightly expands and contracts
according to changes in temperature. This does not affect the TV’s performance.
Troubleshooting-Digital broadcasting
The error message about reception of broadcast
The example of an error message
displayed on a screen
• Failed to receive broadcast.
• No broadcast now.
Cautions regarding use in high and low temperature environments
• When the unit is used in a low temperature space (e.g. room, offi ce), the picture may leave trails or appear slightly delayed.
This is not a malfunction, and the unit will recover when the temperature returns to normal.
• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a
heater, as this may cause the cabinet to deform and the LCD panel to malfunction.
Storage temperature: f20°C to e60°C.
Error code
E202
E203 • Check the broadcast time in the program guide.
• Check the antenna cable. Check that the antenna is correctly
setup.
Possible Solution
63
LC-40LE700X.indb 63LC-40LE700X.indb 63 6/26/09 4:26:23 PM6/26/09 4:26:23 PM
Page 66
Appendix
Error messages about recording using AQUOS LINK
The example of an error message
displayed on a screen
Failed to record
Cannot record the broadcast.
Failed to record
Cannot record the broadcast.
Failed to record
Cannot record the broadcast.
Failed to record
Failed to record
Failed to record
Failed to record
Failed to record
Cannot record the programme.
Failed to record
Cannot record the programme.
Failed to record
No record media available.
Failed to record
Cannot record while playback.
Failed to record
Cannot record while recording other
programme.
Failed to record
No record media available.
Failed to record
Cannot record while not receiving
broadcast.
Failed to record
No record media available.
Failed to record
No recordable memory available.
Failed to record
Age limitation is set.
Failed to record
Cannot record with the recorder.
Error code Possible Solution
S05
S06
S07
S09
S10
S11
S12
S13
S14
S16
S17
S18
S19 Check the recording medium.
S20
S21 Recording to the medium is not possible. Check
S22
S23 Deactivate the child lock and set up the recording
S31
Check the content (broadcast or programme)
or the recording medium such as HDD or DVD.
Either the content or the recording medium may
be incompatible.
This network cannot be recorded.
Use the recording function of your recording
device, not the AQUOS LINK function.
Use the recording function of your recording
device, not the AQUOS LINK function.
Check the content (broadcast or programme).
It may be incompatible.
Check the recording medium.
Stop playback and set up the recording again.
During recording, another recording is not possible.
Writing to the medium is prohibited.
Please check if the settings are properly set.
Broadcasts are not receivable.
the recording medium.
Check the capacity of the recording medium.
again.
Check your recording device.
64
LC-40LE700X.indb 64LC-40LE700X.indb 64 6/26/09 4:26:23 PM6/26/09 4:26:23 PM
Page 67
Appendix
Reset
If complex adjustments are made and the settings
cannot be restored to normal, you can reset the
settings to the factory preset values.
Press MENU and the MENU screen displays.
1
Press c/d to select “Setup”.
2
Press a/b to select “Reset”, and then press
3
ENTER.
If you have already set the password, enter it
4
here.
• “Return to factory pre-settings” displays on the
screen.
Press c/d to select “Yes”, and then press
5
ENTER.
• “Now, TV will restart automatically. OK?” displays
on the screen.
Press c/d to select “Yes”, and then press
6
ENTER.
• “Now initialising...” displays on the screen and
blinks.
• After the reset has completed, the power shuts
off and then comes back on. The screen will have
returned to its original settings.
After factory presetting,
TV will restart automatically
Now initialising...
Press a/b to select the desired language
7
listed on the screen, and then press ENTER.
“
Press c/d to select
then press
Press ENTER.
8
• Major analogue channel settings are pre-set.
However if there are any channel(s) that you
cannot receive with the factory pre-sets, please
perform “Auto installation” in “Setup” section.
(See page 20.)
ENTER.
Major Analogue Channel settings are pre-set.
However if there are any channel(s) that you
cannot receive with the factory pre-sets, please
perform “Auto installation” in “Setup” section
(refer chapter “Watching TV” on manual).
Digital Search
HOME
” or “
STORE
”, and
The TV searches for, sort and stores all the
9
receivable TV stations according to their settings and
the connected antenna.
• To abort the initial auto installation in progress,
press RETURN.
NOTE
• When the TV is in STORE mode, repeat steps 1 to 7 to
change to HOME mode.
Download setup
The TV automatically determines whether a new
software version is available when the TV is in standby
mode.
Selected item Description
Yes
No Does not search for update information.
Now
Automatically searches for new software
updates available when the TV is in
standby mode.
Checks if there is new software
immediately.
Downloading the software
You can select the method of update.
1 If the software is updated, the confi rmation message
“New download information has been detected.”
appears
• If the TV receives the update service while in standby
mode, a confi rmation message displays after turning on
the power.
2 Follow the screen prompts.
Selected item Description
Starts downloading immediately. It takes
approximately one hour to update. You
cannot carry out other operations while
Yes
No
NOTE
• The TV must remain in standby mode for download. Do not
turn off the power using POWER on the TV.
• Updating the software may take some time.
downloading.
• Cancels the download by pressing
ENTER on the remote control unit
when “Discontinue” is displayed on the
screen during the update.
Starts downloading automatically several
minutes after entering standby mode.
Information
Message list
When a new broadcast station is detected, the
message is updated in the “Message list” of the
“Information” menu.
Receiver report
Display reports regarding failures and changes for
timer settings.
Identifi cation
You can check the current version of the software on
the screen.
65
LC-40LE700X_en_h.indd 65LC-40LE700X_en_h.indd 65 7/1/09 2:21:30 PM7/1/09 2:21:30 PM
Page 68
Appendix
Specifi cations
Model
Item
LCD panel
Resolution 2,073,600 pixels (1920 g 1080)
Video Colour System
TV
Function
Backlight life
Viewing angles
Audio amplifi er
Speakers 10 g 4 cm 2pcs
Terminals
OSD language
Power Requirement
Power Consumption
Weight
Operating Temperature
TVStandard
Receiving
Channel
TV-Tuning System
STEREO/BILINGUAL NICAM: B/G, I, D/K A2 stereo: B/G
Rear
Analogue
Digital
VHF/UHF
CATV
ANTENNA IN
INPUT 1 HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
INPUT 2 HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
INPUT 3 HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
INPUT 4
INPUT 5
INPUT 6
INPUT 7 (PC input)
MONITOR OUT
RS-232C 9 pin D-sub male connector
DIGITAL AUDIO OUTPUT
without stand 12.5 kg
with stand
LC-40LE700X
40o (1016 mm) Advanced Super View & BLACK TFT LCD
PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
PAL: B/G, D/K, I SECAM: B/G, D/K, K/K
DVB-T
44.25 – 863.25 MHz
S1 – S41ch (including Hyperband)
Auto Preset 99 ch
100,000 hours (at Backlight Standard position)
H : 176º V : 176º
10W g 2
UHF/VHF 75 q DIN type
1080I/60Hz, 1080P/50Hz, 1080P/60Hz, 1080P/24Hz), AUDIO in (䪱 3.5 mm jack)
1080I/60Hz, 1080P/50Hz, 1080P/60Hz, 1080P/24Hz)
1080I/60Hz, 1080P/50Hz, 1080P/60Hz, 1080P/24Hz)
VIDEO in, AUDIO in, S-VIDEO in, COMPONENT in (480
VIDEO in, AUDIO in
VIDEO in, AUDIO in, COMPONENT in (480
15 pin mini D-sub, AUDIO in (common use with INPUT1) (䪱 3.5 mm jack)
VIDEO out, AUDIO out
Optical Digital Audio output
English/Simplifi ed Chinese/Arabic
AC 110 – 240 V, 50/60 Hz
139 W (0.4 W Standby)
15.5 kg
0°C – 40°C
1
I
, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080
I
, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080
I
/50Hz, 1080I/60Hz)
I
/50Hz, 1080I/60Hz)
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specifi cation changes for
product improvement without prior notice. The performance specifi cation fi gures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
Optional accessory
The listed optional accessory is available for the LCD colour
TV. Please purchase it at your nearest shop.
• Additional optional accessories may be available in the near
future. When purchasing, please read the newest catalogue for
compatibility and check the availability.
66
LC-40LE700X_en_h.indd 66LC-40LE700X_en_h.indd 66 7/8/09 10:28:28 AM7/8/09 10:28:28 AM
Part name Model number
Wall mount bracket AN-37AG2
Attachment AN-37P30*
* The AN-37P30 attachment is always required when
attaching the AN-37AG2 bracket to a wall.
Page 69
Appendix
Dimensional drawings
Unit: mm
964
887.8
665
300
612
53
170
300
500.3
378
99
420
104.8
92.5
309
67
LC-40LE700X_en_h.indd 67LC-40LE700X_en_h.indd 67 7/9/09 7:12:57 PM7/9/09 7:12:57 PM
Page 70
Appendix
Mounting the TV on the wall
Removing the stand
For wall mounting with the optional bracket, remove the stand.
Before detaching/attaching the stand
• Before detaching (or attaching) the stand, unplug the AC cord from the AC outlet.
• Remove all terminal covers and connected cables.
• Lay the TV down on cushioning (such as a blanket) over a table.
• Make sure two or more people perform the operation.
CAUTION
• Do not remove the stand from the TV unless using an optional bracket to mount it.
1
Screw
driver
(not
supplied)
2
Stand post
1
1 Detach the stand from the TV. (Hold the stand so
it will not drop from the edge of the base area.)
Unfasten the four screws used to secure the stand
in place.
NOTE
• To attach the stand, perform the above steps in reverse order.
2 Remove the stand post from the stand base and
attach it to the TV.
Handling and precautions with the wall-mounted TV
• You can mount the TV on the wall using the optional AN-37AG2 bracket and AN-37P30 attachment.
• For details, refer to the instructions supplied with the optional bracket.
CAUTION
• This TV should be mounted on the wall only with the AN-37AG2 (SHARP) / AN-37P30 (SHARP) wall mount bracket.
The use of other wall mount brackets may result in an unstable installation and may cause serious injuries.
• Installing the Liquid Crystal Television requires special skill that should only be performed by qualifi ed service
personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.
Using an optional bracket to mount the TV
• You can ask a qualifi ed service personnel about using an optional AN-37AG2 bracket and AN-37P30 attachment to mount the
TV to the wall.
• Carefully read the instructions that come with the bracket before beginning work.
Hanging on the wall
AN-37AG2/AN-37P30 wall mount bracket.
(See the bracket instructions for details.)
About setting the TV angle
Vertical mounting
NOTE
• Detach the cable clamps on the rear of the TV when using the optional mount bracket.
• To use this TV mounted on a wall, fi rst remove the cover at the 4 locations on the rear of the TV, and then use the screws
supplied with the wall mount bracket to secure the bracket to the rear of the TV.
68
LC-40LE700X.indb 68LC-40LE700X.indb 68 6/26/09 4:26:27 PM6/26/09 4:26:27 PM
Angular mounting
AN-37AG2 + AN-37P30
Page 71
Appendix
Protection against overturning
There is a danger of the product overturning in the case of a disaster or sudden collision. Carry out the following
tip-resistant measurement for your safety.
Anchoring the TV to the wall or a pillar
Fix the product with the 2 clamps
1
(supplied), using the screws (supplied).
Cup hook (commercially
available)
View from the top
Tie (commercially available)
Fix the TV to the wall using extrastrong
2
ties (commercially available).
Fixing the TV to the table
Lay the TV down on cushioning (such as a
1
blanket) over a table.
Attach the band (supplied) to the bottom
2
of the stand using the screw (supplied).
Transfer the product to the table where
3
you intend to fi x the TV.
Fix the TV to the table by the band with a
4
screw (commercially available).
• Use a screw (commercially available) whose
shape is compatible with the band.
Screws for attaching clamps
(supplied)
Thick soft cloth
(ex. Blanket)
Restraining band
(supplied)
Table
Clamps (supplied)
Stand
Wall
Screw for band
(supplied)
Screw
(commercially
supplied)
Table
Restraining band
(supplied)
CAUTION
• As this product is heavy, use a table that is wide enough to support the product and capable of withstanding the
product's weight. The table should be set where it will not be overturned.
69
LC-40LE700X_en_h.indd 69LC-40LE700X_en_h.indd 69 7/1/09 4:13:01 PM7/1/09 4:13:01 PM
Page 72
Appendix
CLEARING THE PASSWORD
If you forget the password, clear the password using the following procedure.
Press MENU to display the MENU screen, and then press c/d to
1
select “Setup”.
Press a/b to select “Auto installation”, “Programme setup”, “Child
2
lock”, “Reset”, and the password input screen displays.
Press and hold both CHr and VOLk on the TV simultaneously until
3
the message appears on the screen.
The Password is .
NOTE
• As a precautionary measure, make a note of your password above, remove it from this manual, and keep it in a familiar place.
70
LC-40LE700X_en_h.indd 70LC-40LE700X_en_h.indd 70 7/13/09 9:01:03 AM7/13/09 9:01:03 AM
Page 73
Appendix
Information on the software license for this product
Software composition
The software included in this product is comprised of various software components whose individual copyrights are held by
SHARP or by third parties.
Software developed by SHARP and open source software
The copyrights for the software components and various relevant documents included with this product that were developed or
written by SHARP are owned by SHARP and are protected by the Copyright Act, international treaties, and other relevant laws.
This product also makes use of freely distributed software and software components whose copyrights are held by third parties.
These include software components covered by a GNU General Public License (hereafter GPL), a GNU Lesser General Public
License (hereafter LGPL) or other license agreement.
Obtaining source code
Some of the open source software licensors require the distributor to provide the source code with the executable software
components. GPL and LGPL include similar requirements. For information on obtaining the source code for the open source
software and for obtaining the GPL, LGPL, and other license agreement information, visit the following website:
http://www.sharp.net.au/
We are unable to answer any questions about the source code for the open source software. The source code for the software
components whose copyrights are held by SHARP is not distributed.
Acknowledgements
The following open source software components are included in this product:
• linux kernel • busy box • uClibc • zlib • libpng • libjpeg
71
LC-40LE700X.indb 71LC-40LE700X.indb 71 6/26/09 4:26:29 PM6/26/09 4:26:29 PM
Page 74
Memo
72
LC-40LE700X_en_h.indd 72LC-40LE700X_en_h.indd 72 6/26/09 4:36:25 PM6/26/09 4:36:25 PM
Page 75
LC-40LE700X_en_h.indd 73LC-40LE700X_en_h.indd 73 6/26/09 4:36:26 PM6/26/09 4:36:26 PM
Page 76
Printed in Malaysia
TINS-E304WJZZ
09P07-MA-NF
LC-40LE700X_en_h.indd 74LC-40LE700X_en_h.indd 74 6/26/09 4:36:26 PM6/26/09 4:36:26 PM
Loading...
