SHARP lc 26dv24u Diagram

SERVICE MANUAL

LCD COLOR TELEVISION/

DVD VIDEO PLAYER

S38OHLC26DV24

MODEL

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

CONTENTS

CAUTION..............................................................................................................................

•

IMPORTANT SAFEGUARDS...............................................................................................

•

WHEN REPLACING DVD DECK .........................................................................................

•

DISC REMOVAL METHOD AT NO POWER SUPPLY........................................................

•

ABOUT LEAD FREE SOLDER (PbF) ..................................................................................

•

GENERAL SPECIFICATIONS..............................................................................................

•

DISASSEMBLY INSTRUCTIONS ........................................................................................

•

SERVICE MODE LIST..........................................................................................................

•

SERVICING FIXTURES AND TOOLS .................................................................................

•

RE-WRITE FOR DVD FIRMWARE ......................................................................................

•

RE-WRITE FOR DIGITAL SOFT FIRMWARE .....................................................................

•

WHEN REPLACING EEPROM (MEMORY) IC ....................................................................

•

ELECTRICAL ADJUSTMENTS ............................................................................................

•

TROUBLESHOOTING GUIDE .............................................................................................

•

BLOCK DIAGRAM ................................................................................................................

•

PRINTED CIRCUIT BOARDS ..............................................................................................

•

SCHEMATIC DIAGRAMS ....................................................................................................

•

WAVEFORMS ......................................................................................................................

•

MECHANICAL EXPLODED VIEWS .....................................................................................

•

DVD DECK EXPLODED VIEWS ..........................................................................................

•

REPLACEMENT PARTS LIST .............................................................................................

•

LC-26DV24U

Page A1-1 A1-2~A1-4 A1-5 A1-6 A1-7 A2-1~A2-7 B1-1~B3-2 C-1 C-2 C-2 C-3 C-4 D-1~D-5 E-1~E-9 F-1~F-8 G-1~G-10 H-1~H-50 I-1, I-2 J1-1~J1-4 J2-1 K1-1~K3-9

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used for

SHARP CORPORATION

after sales service only. The contents are subject to change without notice.

CAUTION

THIS

LCD COLOR TELEVISION

TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS LASER RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. VISIBLE LASER RADIA TION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT ST ARE INTO BEAM.

Location of the required Marking

The rating sheet and the safety caution are on the rear of the unit.

EMPLOYS A LASER SYSTEM.

CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.

PREPARATION OF SERVICING

The laser diode used for a pickup head may be destroyed with external static electricity. Moreover, even if it is operating normally after repair, when static electricity discharge is received at the time of repair, the life of the product may be shortened. Please perform the following measure against static electricity, be careful of destruction of a laser diode at the time of repair.

• Place the unit on a workstation equipped to protect against static electricity, such as conductive mat.

• Soldering iron with ground wire or ceramic type is used.

• A worker needs to use a ground conductive wrist strap for body.

A1-1

IMPORTANT SAFEGUARDS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such a vases, shall be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.

PORTABLE CART WARNING

(symbol provided by RETAC)

S3126A

A1-2

IMPORTANT SAFEGUARDS (CONTINUED)

19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

ANTENNA LEAD IN WIRE

GROUND

CLAMP

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

ELECTRIC SERVICE

EQUIPMENT

GROUND CLAMPS

NEC-NATIONAL ELECTRICAL CODE

S2898A

20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.

22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.

23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections.

24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

A1-3

IMPORTANT SAFEGUARDS (CONTINUED)

25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating and fire.

26) When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.

27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam. It may cause eye damage.

28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

CONDENSATION

Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired. To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually. Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In such cases, change the location of the player.

HOW TO HANDLE THE LCD PANEL

• Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause

skin inflammation. If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

A1-4

WHEN REPLACING DVD DECK

[ When removing the DVD Deck ]

Before removing Pick Up PCB and DVD MT PCB connector, the short circuit the position shown in Fig. 1 using a soldering iron. If you remove the DVD Deck with no soldering, the Laser may be damaged.

[ When installing the DVD Deck ]

Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD MT PCB connector.

NOTE

Before your operation, please read “PREPARATION OF SERVICING”.

•

Use the Lead Free solder.

•

Manual soldering conditions

•

• Soldering temperature: 320 ± 20˚C

• Soldering time: Within 3 seconds

• Soldering combination: Sn-3.0Ag-0.5Cu When Soldering/Removing of solder, use the draw in equipment over the Pick Up Unit to keep the

•

Flux smoke away from it.

Pick Up PCB

Short circuit using a soldering iron.

Fig. 1

A1-5

DISC REMOVAL METHOD AT NO POWER SUPPLY

1.

Remove the Back Cabinet and Angle Deck. (Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.)

2.

Slide the Belt Loading toward the arrow direction by hand to release the lock. (Refer to Fig. 1)

3.

Take out the Disc from the DVD Deck. Be careful not to scratch on the Disc.

DVD Deck

Belt Loading

Fig. 1

A1-6

ABOUT LEAD FREE SOLDER (PbF)

Distinction of PbF PCB:

PCBs (manufactured) using lead free solder will have a PbF printing on the PCB. (Please refer to figures.)

Caution:

Pb free solder has a higher melting point than standard solder;

•

Typically the melting point is 86°F~104°F(30°C~40°C) higher. Please use a soldering iron with temperature control and adjust it to 650°F ± 20°F (350°C ± 10°C). In case of using high temperature soldering iron, please be careful not to heat too long. Pb free solder will tend to splash when heated too high (about 1100°F/ 600°C).

•

All products with the printed circuit board with PbF printing must be serviced with lead free solder.

•

When soldering or unsoldering, completely remove all of the solder from the pins or solder area, and be sure to heat the soldering points with the lead free solder until it melts sufficiently.

Recommendations

Recommended lead free solder composition is Sn-3.0Ag-0.5Cu.

A1-7

GENERAL SPECIFICATIONS

G-1 TV LCD LCD Size / Visual Size 25.5 inch / 647.7mmV

System LCD Type Color TFT LCD

Number of Pixels 1366(H) x 768(V)

View Range Left/Right 80/80 degree

Up/Down 80/80 degree Bright Dot -Zero Bright Dot Ratio --

Color System NTSC Speaker 2 Speaker

Position Front Size 1.6 x 4.8 inch Impedance 8 ohm

Sound Output Max 5.0W + 5.0W

10%(Typical) ---

G-2

G-3 Tuning Broadcasting System Analog US System M

G-4 Signal Video Signal Input Level 1 V p-p/75 ohm

DVD

System Disc DVD, CD-DA, CD-R/RW

System Digital ATSC(8VSB)/QAM

Color System NTSC

DVD-R/RW (Video Format Only) Disc Diameter 120 mm , 80 mm Drive DSM-2 Search speed Fwd 4 step

Actual 2-45 times (DVD)

4-40 times (CD)

Rev 4 step

Actual 2-45 times (DVD)

4-40 times (CD) Slow speed Fwd 1/7 -1/2 times

Actual --

Rev 1/7 -1/2 times

Actual --

Tuner and System 1Tuner Receive CH Destination US (W/CABLE)

CH Coverage Intermediate Digital 44.00MHz Frequency Analog Picture(FP) 45.75MHz

Sound(FS) 41.25MHz

FP-FS 4.50MHz Preset CH No Stereo/Dual TV Sound US-Stereo Tuner Sound Muting Yes

Output Level --

S/N Ratio (Weighted) --

Horizontal Resolution at DVD Mode

RGB Signal Output Level -Audio Signal Input Level 0.85 V p-p/50k ohm

Output Level at DVD

at TV 0-1.7 V p-p/1k ohm Digital Output Level 0.5 V p-p/75 ohm S/N Ratio at DVD (Weighted) 85dB Harmonic Distortion 0.02% (1KHz)

Frequency Response : at DVD

at Video CD --

at SVCD --

at CD 4 Hz - 20 KHz

2~69, 4A, A-5~A-1, A~I, J~W, W+1~W+84

--

0.56 V p-p/ 1k ohm (-20dBFs, 0dBFs=5.6 V p-p)

4 Hz - 44 KHz (96KHz)

A2-1

GENERAL SPECIFICATIONS

G-5 Power Power Source AC 120V, 60Hz

DC --

Power Consumption at AC 120W at 120V 60Hz

at DC -Stand by (at AC) 1W at 120V 60Hz Energy Star Yes Per Year -- kWh/Year

Protector Power Fuse Yes

Safety Circuit Yes IC Protector(Micro Fuse) Yes

G-6 Regulation Safety

Radiation FCC / IC Laser DHHS

G-7 Temperature Operation

Storage

G-8 Operating Humidity Less than 80% RH G-9 Clock and Clock No

Timer Sleep Timer Max Time 120 Min

On Timer Program No Off Timer Program No Game Timer No Wake Up Timer No Timer Back-up (at Power Off Mode) more than -- Min Sec

G-10 Remote Unit RC-MR

Control Glow in Dark Remocon No

Remocon Format SHARP Format TV:SHARP, DVD:KASEIKYO Custom Code Power Source Voltage(D.C) 3V

UM size x pcs UM-3 x 2 pcs

Total Keys 47 Keys Keys

POWER DISPLAY SLEEP VIEW MODE INPUT SELECT 1 2 3 4 5 6 7 8 9 0 MUTE AUDIO VOL+ VOLCH+ CHLEFT/SLOWENTER RIGHT/SLOW+

UL(UL6500_2nd)/CSA(E60065_00)

o

C ~ +40oC

+5

o

-20

C ~ +60oC

TV:SHARP 15bit, DVD:KASEIKYO 48bit

Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

A2-2

GENERAL SPECIFICATIONS

･

UP DOWN SETUP/TV MENU EXIT/CANCEL RETURN

/SUBTITLE TV/DVD OPEN/CLOSE(EJECT) FWD(SEARCH+) REV(SEARCH-) SKIP+ SKIPPAUSE/STILL PLAY STOP PLAY MODE ANGLE ZOOM DVD MENU TOP MENU REPEAT A-B MARKER DIRECT SKIP(JUMP) FREEZE

G-11 Features Auto Shut Off Yes

(TV) Auto Search No

Power On Memory Yes Comb Filter Yes

Game Position No Auto Setup(Language/CH Program) No Picture Setting(TV) Yes

AV Mode(Picture Preference) Yes Brightness , Contrast , Color Yes Tint Yes Sharpness Yes Color Temperature Yes DNR Yes Cable Clear No

Picture Setting(PC) Yes

HOR Position , VER Position Yes Phase, Clock Yes Red, Green, Blue No Auto Adjust No Backlight No

Audio MTS Yes

Tone Control (Bass/Treble/Balance)

Stable Sound No Surround No BBE No

SRS WOW (SRS 3D/Focus/Tru Bass)

Variable Audio Out Yes

Tuning CH Program Yes

Air/Cable Yes ADD/DELETE Yes

Label CH Label Yes

Video Label Yes

Favorite CH No

Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

3 -D

Yes

No

A2-3

GENERAL SPECIFICATIONS

V-Chip Yes

Type

RRT Setup Lock Hotel Lock No

Channel Lock No Video Lock No Panel Lock No

Menu Language Closed Caption CC Advanced View Mode (Picture Size) Yes Picture Scroll Film Mode Yes Aspect Backlight Yes PFC(Power Factor circuit) Freeze frame No PIP/POP No Direct Input Selection Yes Digital Out Dolby Digital Yes

MPEG No PCM No DTS No

PC Monitor Input Yes

VGA (640x480) Yes (60Hz) VGA (720x400) Yes (70Hz) WVGA (848x480) No SVGA (800x600) Yes (60Hz) XGA (1024x768) Yes (60Hz) WXGA (1280x768) Yes (60Hz) WXGA (1280x720) Yes (60Hz) WXGA (1360x768) Yes (60Hz) SXGA (1280x1024) No

HDMI Input Yes

VGA (640x480) Yes (60Hz) 720x480i (4:3) Yes (60Hz) 720x480i (16:9) Yes (60Hz) 720x480p (4:3) Yes (60Hz) 720x480p (16:9) Yes (60Hz) 720x576i (4:3) No 720x576i (16:9) No 720x576p (4:3) No 720x576p (16:9) No 1280x720p Yes (60Hz) 1920x1080i Yes (60Hz) CEC (ORION Standard) No Deep Color No xvYCC No

USA/CANADA Type Yes

English French Spanish Yes Yes

No

A2-4

(

)

G-12

GENERAL SPECIFICATIONS

Component Input Yes

720x480i (4:3) Yes (60Hz) 720x480i (16:9) Yes (60Hz) 720x480p (4:3) Yes (60Hz) 720x480p (16:9) Yes (60Hz) 720x576i (4:3) No 720x576i (16:9) No 720x576p (4:3) No 720x576p (16:9) No 1280x720p Yes (60Hz) 1920x1080i Yes (60Hz)

Wall Mount Size W x H(mm) Yes (100 x 100)

Screw Size M4 x 10

Features Video CD Playback No (DVD) SVCD Playback

MP3 Playback Yes JPEG Yes WMA Yes Digital Out (Dolby Digital) Yes

Down Mix Out (Dolby Digital) Yes

Closed Caption Yes Screen Saver No

TV Screen Audio DAC 192kHz / 24bit

Accessories

Owner's Manual Language English/French/Spanish

Remote Control Unit Yes Rod Antenna

Loop Antenna

U/V Mixer DC Car Cord (Center+) Guarantee Card Warning Sheet Circuit Diagram Antenna Change Plug Service Facility List Important Safeguard Dew/AHC Caution Sheet Quick Set-up Sheet Battery Yes

AC Adapter AC Cord (for AC Adapter) AC Cord (Flat Polarity Plugs) Yes Cable Cramp Yes Stand Yes Stand Screw Yes Hexagon Wrench Yes

(MPEG) Yes (PCM) Yes (DTS) Yes

(DTS) No

Letter Box⁄Pan Scan

4:3 16:9 (Wide) Yes

w/Guarantee Card Yes

Poles -Terminal --

Terminal --

UM size x pcs UM-3 x 2 pcs OEM Brand No

Yes

No

No No No No No No No No No No

No No

A2-5

GENERAL SPECIFICATIONS

AV Cord (2Pin-1Pin) Registration Card (NDL Card) Yes 300 to 75ohm Antenna Adapter Sheet Information (Return) No Sheet Information (HDMI) Cleaning Cloth No

G-13 Interface Switch Top Power (Tact) Yes

Channel Up Yes Channel Down Yes Volume Up Yes Volume Down Yes Menu No Play Yes Eject Yes Skip+, Search+ Yes Skip-, Search- Yes Still/Pause No Stop Yes Main Power SW No Input Select Yes

Rear Main Power SW No

Indicator Power/Stand-By Yes (Green / Red)

Power Wake Up No On Timer No

Terminals Side Video Input 1 RCA x 1

Audio Input 1 RCA x 2(L/MONO, R) S - Input 1 Video Input 2 RCA x 1 Audio Input 2 RCA x 2(L/MONO, R) S - Input 2 No Video Output No Audio Output Component Input 1 Analog Audio Video Input 2 Audio Input Alternative Component Input 2 No Analog Audio No HDMI Input 1 Analog Audio PC Monitor Audio Input Alternative HDMI Input 2 No Analog Audio No Sub Woofer Out No PC Monitor Input Analog Audio Digital Audio Output Coaxial DC Jack (Center +) No VHF/UHF Antenna Input Video Input 3 No Audio Input 3 No S - Input 3 No Other Terminal No AC Inlet

Yes

RCA x 2 (Variable) (L, R) RCA x 3

Yes

Yes Mini Pin Jack( 3.5), STEREO

F Type

Yes

No

A2-6

GENERAL SPECIFICATIONS

G-14 Set Size Approx. W x D x H (mm) 663 x 243 x 500

w/o Handle, Stand Approx. W x D x H (mm)

G-15 Weight Net (Approx.) 13.5kg (29.8lbs)

Net w/o Handle, Stand (Approx.) 12.0kg (26.5lbs) Gross (Approx.) 16.0kg (35.3lbs)

G-16 Carton Master Carton No

Content --- Sets Material --- / --Dimensions W x D x H(mm) --Description of Origin ---

Gift Box Material Double/Brown

W/Color Photo Label No W/Handle No Dimensions W x D x H(mm) 762 x 277 x 567 Description of Origin Yes

Drop Test 1 Corner / 3 Edges / 5 Surfaces

Height (cm) 32

Container Stuffing (40' container) 516 w/Pallet No w/Wrapping No

G-17 Material Cabinet Front PC+ABS 94V0 NON-HALOGEN

Rear PS 94V0 NON-DECABROM Jack Panel --

PCB Non-Halogen Demand No

Eyelet Demand Yes

G-18 Environment Environmental standard requirement Green procurement of SHARP

Pb-free Phase3(Phase3A)

Measures for Whisker Yes

Rohs Yes

663 x 116 x 451

Sets/40' container

A2-7

DISASSEMBLY INSTRUCTIONS

1. REMOVAL OF MECHANICAL PARTS AND P.C. BOARDS

1-1: BACK CABINET (Refer to Fig. 1-1)

1.

Remove the 14 screws (1).

2.

Remove the 7 screws (2).

3.

Remove the Back Cabinet in the direction of arrow.

(1)

(2)

(1)

(2)

(1)

(2)

(1)

Fig. 1-1

(2)

(1)

Back Cabinet

(2)

(1)

1-2: DVD MT PCB/DVD DECK (Refer to Fig. 1-2)

1.

Short circuit the position shown in Fig. 1-2 using a soldering iron. If you remove the DVD Deck with no soldering, the Laser may be damaged.

2.

Disconnect the following connectors: (CP403 and CP4301).

3.

Remove the 2 screws (1).

4.

Remove the 2 screws (2).

5.

Remove the DVD Deck in the direction of arrow (A).

6.

Remove the 2 screws (3).

7.

Remove the Angle MPEG in the direction of arrow (B).

8.

Disconnect the following connectors: (CP2301, CP2302 and CP2303).

9.

Remove the 4 screws (4).

10.

Remove the DVD MT PCB in the direction of arrow (C).

11.

Remove the 2 screws (5).

12.

Remove the Angle DVD-1 in the direction of arrow (D).

(1)

(2)

(1)

(A)

(5)

(D)

DVD Deck

Short circuit using a soldering iron.

Pick Up PCB

(4)

(2)

(4)

DVD MT PCB

(C)

(3)

Angle MPEG

Angle DVD-1

OPERATION PCB/OPERATION2 PCB and

1-3:

(B)

(3)

(5)

STAND ASS'Y (Refer to Fig. 1-3)

1.

Disconnect the following connector: (CP6202).

2.

Remove the Plate Button Ass'y in the direction of arrow (A).

3.

Remove the 6 screws (1).

4.

Remove the Operation PCB and Operation 2 PCB in

5.

the direction of arrow (B).

6.

Remove the 2 screws (2).

7.

Remove the 7 screws (3).

8.

Remove the Angle Hinge in the direction of arrow (C).

Operation 2 PCB

Plate Button Ass'y

(1)

(B)

Operation PCB

(A)

(1)

(C)

(1)

(3)

(1)

(3)

Angle Hinge

(2)

(3)

Fig. 1-2

(3)

NOTE

Before your operation, please read "PREPARATION

1.

OF SERVICING". Use the Lead Free solder.

2.

Manual soldering conditions

3.

ï Soldering temperature: 320 ± 20∞C ï Soldering time: Within 3 seconds ï Soldering combination: Sn-3.0Ag-0.5Cu When Soldering/Removing of solder, use the drawing

4.

equipment over the Pick Up Unit to keep the Flux smoke away from it. When installing the DVD Deck, remove all the soldering

5.

on the short circuit position after the connection of Pick Up PCB and DVD MT PCB connector.

Fig. 1-3

B1-1

DISASSEMBLY INSTRUCTIONS

1-4: REMOCON PCB (Refer to Fig. 1-4)

1.

Disconnect the following connector: (CP4201).

2.

Remove the 2 screws (1).

3.

Remove the Remocon PCB in the direction of arrow (A).

(1)

Remocon PCB

(A)

Fig. 1-4

(3)

(2)

(4)

Plate Jack

(2)

(1)

(A)

(B)

(5)

Shield Digital

Digital PCB

1-5: LCD BLOCK (Refer to Fig. 1-5)

1.

Disconnect the following connectors: (CP302, CP2804 and CP4303).

2.

Remove the Holder Panel.

3.

Remove the 4 screws (1).

4.

Remove the LCD Block in the direction of arrow (A).

5.

Remove the 4 screws (2).

6.

Remove the Angle Main.

(2)

(1)

(2)

Angle Main

(1)

(A)

(2)

(1)

LCD Block

Holder Panel

Angle Main

(2)

Holder Panel

(1)

1-7: POWER PCB (Refer to Fig. 1-7)

1.2.Remove the 5 screws (1). Remove the Power PCB in the direction of arrow.

(1)

Power PCB

1-8: COVER LCD (Refer to Fig. 1-8)

1.

Remove the 4 screws (1).

2.

Remove the screw (2).

3.

Remove the Cover LCD in the direction of arrow.

Fig. 1-6

Fig. 1-7

1-6: DIGITAL PCB (Refer to Fig. 1-6)

1.

Disconnect the following connector: (CP3001 and CP4302).

2.

Remove the screw (1).

3.

Remove the 5 screws (2).

4.

Remove the 2 screws (3).

5.

Remove the screw (4).

6.

Remove the Plate Jack in the direction of arrow (A).

7.

Remove the 5 screws (5).

8.

Remove the Digital PCB and Shield Digital in the direction of arrow (B).

Fig. 1-5

B1-2

(2)

(1)

LCD Panel

(1)

Cover LCD

Fig. 1-8

DISASSEMBLY INSTRUCTIONS

2. REMOVAL OF DVD DECK PARTS

NOTE

1. Disassemble only the DVD DECK PARTS parts listed here. Minute adjustments are needed if the disassembly is done. If the repair is needed except listed parts, replace the DVD MECHA ASS'Y.

2-1: TRAVERSE ASS'Y (Refer to Fig. 2-1-A)

Remove the 3 screws 1.

1. Unlock the 2 supports 2.

2. Remove the Insulator (R) from the Loader Sub Ass'y.

3. Remove the Traverse Ass'y.

4.

2

Loader Sub Ass'y

2

2-2:

SWITCH PCB ASS'Y/GEAR MIDDLE/GEAR FEED/RACK FEED ASS'Y/FEED MOTOR (Refer to Fig. 2-2-A)

Remove the Insulator (F).

1. Remove the Insulator (R).

2. Unlock the support 1.

3. Remove the Gear Middle.

4. Remove the screw 2.

5. Remove the Rack Feed Ass'y.

6. Remove the screw 3.

7. Remove the Switch PCB Ass'y.

8. Remove the screw 4.

9. Remove the Gear Feed.

10. Remove the 2 screws 5.

11. Remove the Feed Motor.

12. Remove the Gear Motor.

13.

Feed Motor

Traverse Ass'y

Gear Motor

Insulator (R)

Traverse Ass'y

1

• Screw Torque: 2.0 ± 0.3kgf•cm

1

Fig. 2-1-A

NOTE

1. In case of the Traverse Ass'y installation, hook the wire on the Loader Ass'y as shown Fig. 2-2-B to Fig. 2-2-D.

Loader Ass'y (Bottom Side)

Check Lock Check Lock

Check Hook

80 ± 5mm

Loader Ass'y

Fig. 2-1-B

Check Hook

Fig. 2-1-C

Insulator (F)

5

1

5

Gear Feed

Insulator (F)

Rack Feed Ass'y

• Screw Torque: 1.3 ± 0.3kgf•cm (Screw 2)

• Screw Torque: 3.0 ± 0.3kgf•cm (Screw 3)

• Screw Torque: 1.0 ± 0.3kgf•cm (Screw 4, 5)

4

Gear Middle

2

Switch PCB Ass'y

3

Fig. 2-2-A

NOTE

1.

When installing the Rack Feed Ass'y, push both ends to align the teeth as shown Fig. 2-2-B. Then install it.

2.

In case of the Gear Motor installation, check if the value of the Fig. 2-2-C is correct.

3.

When installing the wire of the Switch PCB Ass'y, install it correctly as Fig. 2-2-D. Manual soldering conditions

• Soldering temperature: 320 ± 20˚C

• Soldering time: Within 3 seconds

• Soldering combination: Sn-3.0Ag-0.5Cu

4.

After the assembly of the Traverse Ass'y, hook the wire on the Traverse Ass'y as shown Fig. 2-2-E.

Rack Feed Ass'y

Check Hook

Loader Ass'y (Top Side)

Check Hook

Fig. 2-1-D

B2-1

Push

[OK] [NG]

Fig. 2-2-B

DISASSEMBLY INSTRUCTIONS

Feed Motor

Check Hook

Gear Motor

Safety surface for pressing of the insert.

Switch PCB Ass'y

~ SPINDLE MOTOR ~

YELLOW (2) GREEN (1)

Traverse Ass'y

8.0 ± 0.2mm

Fig. 2-2-C

~ FEED MOTOR ~

WHITE (4) BROWN (3)

• Install wire from (1) to (4) in order.

Fig. 2-2-D

[ 6 pin FFC ]

40 ± 1mm

Fold

60 ± 1mm

Fig. 2-3-B

Check Hook

• Loosen the wire in the direction of the arrow.

Fig. 2-2-E

2-3: FFC WIRE HANDLING

1.

When installing the FFC, fold it correctly and install it as shown from Fig. 2-3-A to Fig. 2-3-B.

NOTE

Do not make the folding lines except the specified

1. positions for the FFC.

[ 24 pin FFC ]

Fold it by 90˚

Pick Up Side

Printing Surface

20 ± 1mm

Fold it by 90˚

30 ± 1mm

Fig. 2-3-A

B2-2

DISASSEMBLY INSTRUCTIONS

3.

REMOVAL AND INSTALLATION OF FLAT PACKAGE IC

REMOVAL

Put Masking Tape (cotton tape) around the Flat Package

1. IC to protect other parts from any damage.

(Refer to Fig. 3-1.) NOTE

Masking is carried out on all the parts located within 10 mm distance from IC leads.

When IC starts moving back and forth easily after

3. desoldering completely, pickup the corner of the IC using tweezers and remove the IC by moving with the IC desoldering machine. (Refer to Fig. 3-3.)

NOTE

Some ICs on the PCB are affixed with glue, so be careful not to break or damage the foil of each IC leads or solder lands under the IC when removing it.

Blower type IC desoldering machine

Masking Tape (Cotton Tape)

Heat the IC leads using a blower type IC desoldering

2.

IC

machine. (Refer to Fig. 3-2.)

NOTE

Do not rotate or move the IC back and forth , until IC can move back and forth easily after desoldering the leads completely.

Blower type IC desoldering machine

Fig. 3-1

Tweezers

IC

Peel off the Masking Tape.4. Absorb the solder left on the pattern using the Braided

5. Shield Wire. (Refer to Fig. 3-4.)

NOTE

Do not move the Braided Shield Wire in the vertical direction towards the IC pattern.

Fig. 3-3

Braided Shield Wire

Soldering Iron

IC

Fig. 3-2

IC pattern

Fig. 3-4

B3-1

DISASSEMBLY INSTRUCTIONS

INSTALLATION

Take care of the polarity of new IC and then install the

1. new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily.

(Refer to Fig. 3-5.)

Soldering Iron

Solder temporarily

Supply the solder from the upper position of IC leads

2.

Solder temporarily

sliding to the lower position of the IC leads. (Refer to Fig. 3-6.)

Fig. 3-5

When bridge-soldering between terminals and/or the

4. soldering amount are not enough, resolder using a Thintip Soldering Iron. (Refer to Fig. 3-8.)

Thin-tip Soldering Iron

IC

Fig. 3-8

Finally, confirm the soldering status on four sides of the

5. IC using a magnifying glass. Confirm that no abnormality is found on the soldering position and installation position of the parts around the IC. If some abnormality is found, correct by resoldering.

NOTE

When the IC leads are bent during soldering and/or repairing, do not repair the bending of leads. If the bending of leads are repaired, the pattern may be damaged. So, always be sure to replace the IC in this case.

Soldering IronSolder

IC

Absorb the solder left on the lead using the Braided

3.

Supply soldering from upper position to lower position

Shield Wire. (Refer to Fig. 3-7.)

NOTE

Do not absorb the solder to excess.

Soldering Iron

IC

Braided Shield Wire

Fig. 3-6

Fig. 3-7

B3-2

SERVICE MODE LIST

This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter to the SERVICE MODE function, press and hold both buttons simultaneously on the main unit and on the remote

control for more than a the standard time in the appropriate condition. (See below chart.)

Set

Condition

TV mode

DVD mode

(No disc)

DVD mode

(No disc)

TV mode

ALL mode

DVD mode

(No disc)

Set Key Operations

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

STOP 1 2 sec.

Remocon

Key

0 2 sec.

1 2 sec.

4 2 sec.

5 2 sec.

6 2 sec.

8

9 2 sec.

Standard

Time

2 sec.

Releasing of V-CHIP PASSWORD. Initialization of factory TV data.

NOTE:

DVD Write mode. Refer to the “RE-WRITE FOR DVD FIRMWARE”. NOTE: Do not use this for normal servicing.

POWER ON total hours are displayed on the screen. Can be checked of the INITIAL DATA of MEMORY IC. Refer to the "WHEN REPLACING EEPROM (MEMORY) IC".

Check of the SUM DATA and MICON VERSION on the screen. Refer to the "WHEN REPLACING EEPROM (MEMORY) IC".

Display of the Adjustment MENU on the screen. Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).

Check of the firmware version.

DVD

Refer to the “RE-WRITE FOR DVD FIRMWARE”. NOTE: Do not use this for normal servicing.

If you set factory initialization, the memories are reset such as the channel setting, and the POWER ON total hours.

Initialization of factory DVD data.

C-1

SERVICING FIXTURES AND TOOLS

JG176 Up-Date Disc

Ref. No. Part No. Parts Name Remarks

JG176

APJG176126

JG176

2007 USA DTV LCD Rom Disc

Up-Date of the FirmwareAPJG176123JG176 Up-Date Disc

Up-Date of the Firmware

RE-WRITE FOR DVD FIRMWARE

Turn on the power, and set the DVD mode.

1. Confirm that the “No Disc” will be appeared on the screen.

2. Press both VOL. DOWN button on the set and Channel button (5) on the remote control for more than 2 seconds.

3. Press VOL. UP/DOWN button on the unit to check if all the keys on the unit do not function.

4.

NOTE: To check if DVD Write mode is set. When inserting Up-Date Disc at Non DVD Write mode, the read error will happen.

Insert the Up-Date Disc. (Refer to SERVICING FIXTURE AND TOOLS)

5. Automatic read will start and "Firmware upgrade Programing, Please Wait... Do not switch the player off!" will be displayed

6. on the screen. At this time, the horizontal noise lines may appear. But no problem.

NOTE: Do not turn off the unit on the way or operate the keys on the unit and remocon. Up-Date error will happen and can not be done with the Up-Date of Up-Date Disc.

After the Up-Date, Logo screen will appear.

7. Unplug the AC cord, then plug it in.

8. After the write, set to the initializing of shipping.

Turn on the power, and set the DVD mode.

9. Press both VOL. DOWN button on the set and Channel button (4) on the remote control for more than 2 seconds.

10. The "INITIALIZE 5 ---> COMPLETE" will appear on the screen.

Then unplug the AC cord, and plug it in.

11.

CHECK FOR THE FIRMWARE VERSION

Turn on the power, and set the DVD mode.

12. Press both Channel button (1) on the remote control and the STOP button on the set for more than 2 seconds.

13. Firmware version will be displayed on the top left of the screen.

F/W Ver. ADLLA8111A Initialize: Complete

Laser drive time DVD LD: 0Hour CD LD : 0Hour

A D L L A 8 1 1 1 A

Fixed

Release date (Example: 2008.01.11)

Released times on the same date

Turn off the power

14.

When the changed version displays, the Re-write will be completed.

C-2

A = October B = November C = December

RE-WRITE FOR DIGITAL SOFT FIRMWARE

Copy the "update.dat" in CD to USB Flash Memory.

1.

Recommended USB Flash Memory

• SanDisk Cruzer Mini USB Flash Drive 128Mb

• SanDisk Cruzer Mini USB Flash Drive 256Mb

• SanDisk Cruzer Micoro USB Flash Drive 128Mb

• SanDisk Cruzer Micoro USB Flash Drive 256Mb

• TwinMos ModileDisk3 128Mb (USB 2.0)

• TwinMos ModileDisk3 256Mb (USB 2.0)

NOTE:

2.

Confirm that the AC cord is plugged out.

3.

Set the minus driver to the topside of the USB connector cover, remove the USB connector cover. Insert the USB Flash Memory to USB connector. (Refer to Fig.1)

After Format is done with FAT32 File system beforehand, USB Flash Memory is used. The computer of WINDOWS2000 is used.

SET (REAR)

Fig.1

4.

Insert the AC CORD of the set and turn on the power. The Up-Date will start automatically. During the writing, "PLEASE WAIT" will appear on the screen.

USB connector cover

5.

After the Up-Date, the screen will return to normal screen.

6.

Turn off the power.

7.

Unplug the AC CORD, and remove the USB Flash Memory.

8.

Insert the AC CORD again.

After the data input, set to the initializing of shipping.

9.

Turn on the power.

10.

Press both Channel button (1) on the remote control and the VOLUME DOWN button on the set for more than 2 seconds. The unit will now have the correct DATA for the new DIGITAL SOFT FIRMWARE.

C-3

WHEN REPLACING EEPROM (MEMORY) IC

CONFIRMATION OF CHECK SUM, POWER ON TOTAL HOURS AND MICON VERSION

Initial total of MEMORY IC, POWER ON total hours and MICON VERSIONcan be checked on the screen. Total hours are displayed in 16 system of notation.

NOTE:

1.

2.

3.

4.

NOTE:The each item value might be different according to each set.

If you set a factory initialization, the total hours is reset to "0". Please refer to "CONFIRMATION OF INITIAL DATA" when SUM DATA is not corresponding.

Turn on the POWER, and set to the TV mode. Set the VOLUME to minimum. Press both VOL. DOWN button on the set and Channel button (8) on the remote control for more than 2 seconds. After the confirmation of each check sum, turn off the power.

Initial setting data check sum.

Sub Micon check version

Main Micon check version

EEPROM check version

Parameter

CHECK SUM : 3D08 LCD ON : 0000 SUB : DA0E77V221 DTV : CA09E82081 EEPROM : W50Q01AM00 Picture : _dispSmartPic

POWER ON total hours.

= (16 x 16 x 16 x thousands digit value) + (16 x 16 x hundreds digit value) + (16 x tens digit value) + (ones digit value)

FIG. 1

CONFIRMATION OF INITIAL DATA

If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to INITIAL SETTING TABLE (Attached "INITIAL DATA").

Turn on the POWER, and set to the TV mode.

1. Set the VOLUME to minimum.

2. Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 2 seconds.

3. ADDRESS and DATA should appear as FIG 2.

ADDRESS DATA

INIT 0000 3D08 SUB : DA0E77V221 DTV : CA09E82081 EEPROM : W50Q01AM00

FIG. 2

ADDRESS is now selected and should "blink". Using the UP/DOWN buton on the remote, step through the ADDRESS

4. until Press RIGHT/LEFT button to select DATA. When DATA is selected, it will "blink". Again, step through the DATA using UP/DOWN button until required DATA value has been selected.

5. Pressing RIGHT/LEFT button will take you back to ADDRESS for further selection if necessary.

6. Repeat steps 4 to 6 until all data has been checked.

7. When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.

8.

After the data input, set to the initializing of shipping.

Turn on the POWER.

9. Set the VOLUME to minimum.

10. Press both VOL. DOWN button on the set and Channel button (1) on the remote control for more than 2 seconds.

11. After the finishing of the initializing of shipping, the unit will turn off automatically.

The unit will now have the correct DATA for the new MEMORY IC.

C-4

ELECTRICAL ADJUSTMENTS

1. ADJUSTMENT PROCEDURE

Read and perform these adjustments when repairing the circuits or replacing electrical parts or PCB assemblies.

CAUTION

•

Use an isolation transformer when performing any service on this chassis.

•

When removing a PCB or related component, after unfastening or changing a wire, be sure to put the wire back in its original position.

•

When you exchange IC and Transistor with a heat sink, apply silicon grease (YG6260M) on the contact section of the heat sink. Before applying new silicon grease, remove all the old silicon grease. (Old grease may cause damages to the IC and Transistor).

Prepare the following measurement tools for electrical adjustments.

1. Pattern Generator

On-Screen Display Adjustment

1.2.Set the VOLUME to minimum.

Press the VOL. DOWN button on the set and the channel button (9) on the remote control for more than 2 seconds to display adjustment mode on the screen as shown in Fig. 1-1.

TV FULL 480i

Function

3.

Use the CH. UP/DOWN button or Channel button (0-9)

03 R DRIVE (N)

2

on the remote control to select the options shown in Fig. 1-2.

4.

Press the SETUP/TV MENU button on the remote control to end the adjustments.

5.

To display the adjustment screen for TV, AV, COMPONENT, HDMI and PC mode, press the INPUT SELECT button on the remote control.

6.

To display the adjustment screen for DVD mode, press the TV/DVD button on the remote control.

7.

Receive the DIGITAL broadcasting.

8.

To display the adjustment screen for DTV mode, select the digital channel.

9.

Press the VOL.DOWN button on the set and the channel (9) on the remote control for more than 2 seconds.

Step No.

Fig. 1-1

NO.

FUNCTION

NO.

R DRIVE(N)

03

R CUT OFF(N)

04

G DRIVE(N)

05

G CUT OFF(N)

06

B DRIVE(N)

07

B CUT OFF(N)

08

R DRIVE(C)

09

R CUT OFF(C)

10

G DRIVE(C)

11

G CUT OFF(C)

12

B DRIVE(C)

13

B CUT OFF(C)

14

R DRIVE(W)

15

R CUT OFF(W)

16

G DRIVE(W)

17

G CUT OFF(W)

18

B DRIVE(W)

19

B CUT OFF(W)

20

BAK LIGHT CENT

29

BAK LIGHT MAX

30

FUNCTION

31

BAK LIGHT MIN

32

BRIGHTNESS CENT

33

BRIGHTNESS MAX

34

BRIGHTNESS MIN

35

TINT

36

SHARP H1 MAX

37

SHARP H1 MIN

38

SHARP H2 MAX

39

SHARP H2 MIN

40

SHARP V1 MAX

41

SHARP V1 MIN

42

CONTRAST CENTER

43

CONTRAST MAX

44

CONTRAST MIN

45

COLOR CENTER

46

COLOR MAX

47

COLOR MIN

50

CONTRAST 40

Fig. 1-2

2. BASIC ADJUSTMENTS

2-1: WHITE BALANCE

1.

Place the set in Aging Test for more than 15 minutes.

2.

Receive the gray scale pattern from the Pattern Generator.

3.

Press the INPUT SELECT button on the remote control to set to the AV mode.

4.

Using the remote control, set the brightness and contrast to normal position.

5.

Activate the adjustment mode display of Fig. 1-2 and press the channel button (03) on the remote control to select "R DRIVE(N)".

6.

Press the CH. UP/DOWN button on the remote control to select the "R DRIVE (N)", "R CUT OFF (N)", "B DRIVE (N)", "B CUT OFF (N)", "R DRIVE (C)", "R CUT OFF (C)", "B DRIVE (C)", "B CUT OFF (C)", "R DRIVE (W)","R CUT OFF (W), "B DRIVE (W)" or "B CUTOFF(W)".

7.

Adjust the LEFT/RIGHT button on the remote control to whiten the R DRIVE (N), R CUT OFF (N), B DRIVE (N), B CUT OFF (N), R DRIVE (C), R CUT OFF (C), B DRIVE (C), B CUT OFF (C), R DRIVE (W) ,R CUT OFF (W), B DRIVE (W) and B CUTOFF(W) at each step tone sections equally.

8.

Perform the above adjustments 6 and 7 until the white color is achieved.

D-1

ELECTRICAL ADJUSTMENTS

2-2: BRIGHT CENT

1.

Receive the monoscope pattern. (RF Input)

2.

Using the remote control, set the brightness and contrast to normal position.

3.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (32) on the remote control to select "BRIGHTNESS CENT".

4.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "121".

5.

Check if the picture is normal.

6.

Receive the monoscope pattern. (VIDEO Input)

7.

Press the INPUT SELECT button on the remote control to set to the AV mode.

8.

Using the remote control, set the brightness and contrast to normal position.

9.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (32) on the remote control to select "BRIGHTNESS CENT".

10.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "125".

11.

Check if the picture is normal.

12.

Receive the monoscope pattern. (S-VIDEO Input)

13.

Press the INPUT SELECT button on the remote control to set to the AV(S) mode. Then perform the above adjustments 8~11.

14.

Playback the DVD(480i) disc. (COMPONENT Input)

15.

Press the INPUT SELECT button on the remote control to set to the COMPONENT mode.

16.

Using the remote control, set the brightness and contrast to normal position.

17.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (32) on the remote control to select "BRIGHTNESS CENT".

18.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "126".

19.

Check if the picture is normal.

20.

Playback the DVD(480i) disc. (HDMI Input)

21.

Press the INPUT SELECT button on the remote control to set to the HDMI mode.

22.

Using the remote control, set the brightness and contrast to normal position.

23.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (32) on the remote control to select "BRIGHTNESS CENT".

24.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "139".

25.

Check if the picture is normal.

2-3: CONTRAST MAX

1.

Receive the color bar pattern. (RF Input)

2.

Using the remote control, set the brightness and contrast to normal position.

3.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (43) on the remote control to select "CONTRAST MAX".

4.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "153".

5.

Check if the picture is normal.

6.

Receive the color bar pattern. (VIDEO Input)

7.

Press the INPUT SELECT button on the remote control to set to the AV mode.

8.

Using the remote control, set the brightness and contrast to normal position.

9.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (43) on the remote control to select "CONTRAST MAX".

10.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "159".

11.

Check if the picture is normal.

12.

Receive the color bar pattern. (S-VIDEO Input)

13.

Press the INPUT SELECT button on the remote control to set to the AV(S) mode.

14.

Using the remote control, set the brightness and contrast to normal position.

15.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (43) on the remote control to select "CONTRAST MAX".

16.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "164".

17.

Check if the picture is normal.

18.

Playback the DVD(480i) disc. (COMPONENT Input)

19.

Press the INPUT SELECT button on the remote control to set to the COMPONENT mode.

20.

Using the remote control, set the brightness and contrast to normal position.

21.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (43) on the remote control to select "CONTRAST MAX".

22.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "134".

23.

Check if the picture is normal.

24.

Playback the DVD(480i) disc. (HDMI Input)

25.

Press the INPUT SELECT button on the remote control to set to the HDMI mode.

26.

Using the remote control, set the brightness and contrast to normal position.

27.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (43) on the remote control to select "CONTRAST MAX".

28.

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "139".

29.

Check if the picture is normal.

D-2

2-4: Confirmation of Fixed Value (Step No.) Please check if the fixed values of each of the adjustment item is set correctly referring below. (TV/AV/COMPONENT/HDMI/DVD/PC/DTV)

ELECTRICAL ADJUSTMENTS

NO.

1 H POSI OSD 1 1 1 - 1 1 1 1 1 1 1 1 1 - - 1 1 1 1 1 1 1 - 1 - - 1 1 1 2 V POSI OSD 194 194 194 - 194 194 194 194 194 194 194 194 194 - - 194 194 194 194 194 194 194 - 194 - - 194 194 194 3 R.DRIVE (N) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 4 R CUTOFF(N) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 5 6 G CUTOFF(N) 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 7 B DRIVE(N) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 8 B CUTOFF(N) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * *

9 R.DRIVE(C) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 10 R CUTOFF(C) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 11 G DRIVE(C) 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 12 G CUTOFF(C) 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 13 B DRIVE(C) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 14 B CUTOFF(C) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 15 R.DRIVE(W) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 16 R CUTOFF(W) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 17 G DRIVE(W) 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 18 G CUTOFF(W) 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 19 B DRIVE(W) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 20 B CUTOFF(W) * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 21 H POSI CENTER X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 22 H POSI MAX X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 23 H POSI MIN X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 24 V POSI CENTER X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 25 V POSI MAX X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 26 V POSI MIN X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 27 H POSI 50 X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 28 V POSI 50 X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 29 BAK LIGHT CENT 50 50 50 - 50 50 50 50 50 50 50 50 50 - - 50 50 50 50 50 50 50 - 50 - - 50 50 50 30 BAK LIGHT MAX 100 100 100 - 100 100 100 100 100 100 100 100 100 - - 100 100 100 100 100 100 100 - 100 - - 100 100 100 31 BAK LIGHT MIN 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 32 BRIGHT CENT 123 124 125 - 128 141 133 132 131 131 132 132 135 - - 124 128 128 128 128 128 128 - 128 - - 132 131 132 132 33 BRIGHT MAX 200 200 200 - 200 200 200 200 180 180 160 160 180 - - 200 140 140 140 140 140 140 - 140 - - 200 200 200 200 34 BRIGHT MIN 60 60 60 - 60 100 60 70 60 60 60 70 60 - - 60 110 110 110 110 110 110 - 110 - - 50 60 60 60 35 TINT 146 124 124 - 118 112 118 118 130 130 130 130 118 - - 124 128 128 128 128 128 128 - 128 - - 130 130 130 130 36 SHARP H1 MAX 511 511 511 - 511 511 511 511 511 511 511 511 511 - - 511 511 511 511 511 511 511 - 511 - - 511 511 511 511 37 SHARP H1 MIN 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 38 SHARP H2 MAX 511 511 511 - 511 511 511 511 511 511 511 511 511 - - 511 511 511 511 511 511 511 - 511 - - 511 511 511 511 39 SHARP H2 MIN 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 40 SHARP V1 MAX 511 511 511 - 511 511 511 511 511 511 511 511 511 - - 511 511 511 511 511 511 511 - 511 - - 511 511 511 511 41 SHARP V1 MIN 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 42 CONT CENTER * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 43 CONT MAX * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 44 CONT MIN 80 60 60 - 60 60 50 70 60 60 70 60 60 - - 60 60 60 60 60 60 60 - 60 - - 60 70 60 60 45 COLOR CENT 115 108 108 - 118 153 160 150 140 140 140 140 157 - - 108 128 128 128 128 128 128 - 128 - - 140 140 140 117 46 COLOR MAX 255 255 255 - 255 255 255 255 255 255 255 255 255 - - 255 255 255 255 255 255 255 - 255 - - 255 255 255 255 47 COLOR MIN 0 0 0 - 0 0 0 0 0 0 0 0 0 - - 0 0 0 0 0 0 0 - 0 - - 0 0 0 0 48 H.POZI TEXT X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 49 VPOZI TEXT X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X 50 CONT 40 * * * - * * * * * * * * * - - * * * * * * * - * - - * * * * 51 52 BRIGHT (NTSC) X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X

53 CONTRAST (NTSC) X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X

NOTE:

FUNCTION

G DRIVE(N）

INVERSION

BRIGHT (PAL) X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X BRIGHT (SECAM) X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X

CONTRAST (PAL) X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X CONTRAST (SECAM) X X X - X X X X X X X X X - - X X X X X X X - X - - X X X X

For the step no. with * mark, please adjust it according to the situation of the set. For the step no. with x mark, no use.

TV

Step No. Step No. Step No. - Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No.

000-000000000--0000000 - 0 - - 00 0 0

XXX-XXXXXXXXX- -XXXXXXX - X - - XX X X

AV

CVBS Y/C 480i/576i 480p/576p 720p 1080i 480i/576i 480p/576p 720p 1080i VGA 640x480 1280x720 640*480 720*400 800*600 1024*768 1280*68 1280*720 852*480 1360*768 1280*1024 1440*900 480i 480p 720p 1080i

GAME

COMPONENT HDMI

DVD

PC

DTV

1

194

50

100

0

D-3 D-4

ELECTRICAL ADJUSTMENTS

3. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION)

LCD PANEL

OPERATION 2 PCB

CP2251

DVD DECK

REMOCON PCB

CP2201

OS2201

CD2301

OPERATION PCB

CP2204

CD2001

CP406

CP2303

CP8502

CP2302

CP2301

CP8501

DVD MT PCB

CP403

CP2203

CP4301

CP2804

CP6202

CP3001

CP401

DIGITAL PCB

CP4303

CP4302

CP4203

J4201

J4202

J4206

J4205

J4203

TU5801

J4301

CP3602

CP3601

SPEAKER

CP4201

CP302

J401

POWER PCB

D-5

(LCD SECTION)

POWER DOES NOT TURN ON

TROUBLESHOOTING GUIDE

Is F401 broken?

No

Is there voltage at pin 1 of IC402 6V?

Yes

Is R412 broken?

No

Is there voltage at pin 10 of IC401 19V?

Yes

No

Yes

No

Change F401.

Check IC402 and peripheral circuit.

Change R412.

Check IC401 and peripheral circuit.

Yes

Change DIGITAL PCB.

E-1

THE PICTURE APPEARS, BUT THE AUDIO DOES NOT APPEARS. (AT RF MODE)

TROUBLESHOOTING GUIDE

Is CP302 connected?

Yes

Is there signal at pins 1 and 4 of CP302?

No

Is there signal at pins 2 and 5 of IC302?

No

Is there signal at pins AA3 and AA4 of IC2801?

No

Yes

Connect CP302.

Change SP301 and SP302.

Check IC302 and peripheral circuit.

Check Connection of CP4302.

No

Is there signal at pins 1 and 2 of IC6551?

No

Is there signal at pin 3 of IC6552, IC6553?

No

Is there signal at pin 5 of TU5801?

No

Change TU5801.

Yes

Check IC6551 and peripheral circuit.

Check IC6552, IC6553 and peripheral circuit.

Check IC5801 and peripheral circuit.

E-2

THE PICTURE DOES NOT APPEAR

TROUBLESHOOTING GUIDE

Does backlight shine?

Yes

Is CD2804 connected?

Yes

Is there voltage at pins 1, 2, 3, 4 and 5 of CP2804 5V?

Yes

Is there signal at pins 13, 14, 16, 17, 19, 20, 22, 23, 25 and 26 of CP2804?

No No

No

Yes

Is there voltage at pins 1, 2, 3, 4 and 5 of CP406 24V?

Yes

Connected CD2804.

Check IC407 and peripheral circuit.

Check IC401, T401, D437 and peripheral circuit.

Change V2301 (PANEL).

No

Change DIGITAL PCB.

E-3

THE COLOR DOES NOT APPEAR

TROUBLESHOOTING GUIDE

Is setting of color normal?

Yes

Is the color signal received?

Yes

Is there color signal at IC2801?

Yes

Change DIGITAL PCB.

No

Adjust the color.

Receive the color signal.

Check IC2801 and peripheral circuit.

E-4

(DVD SECTION)

DOES NOT DISPLAY DVD PICTURE

TROUBLESHOOTING GUIDE

Does this display logo picture?

No

Is there signal at pins 149 and 151 of IC4001?

No

Does IC4001 gets P.CON+3.3V and P.CON+1.8V?

No

Check P.CON+3.3V and P.CON+1.8V line.

Yes

Check the disc.

Check pins 8 and 10 of CP8501 and peripheral circuit.

Change IC4001.

E-5

DISC DOES NOT EJECT

TROUBLESHOOTING GUIDE

Does OSD appear on the screen?

Yes

Does this eject disc at change DVD DECK?

Yes

Change DVD DECK.

No No

No

Is remote key set effectively?

Yes

Check pins 138 and 139 of IC4001 and peripheral circuit.

Is there signal at pins 4 and 5 of CP2302?

Yes

Is there signal at pins 1 and 2 of CP2302?

No

Check pins J18 and J19 of IC2801 and peripheral circuit.

Check IC4001 and peripheral circuit.

Change IC2301.

Yes

Change IC4001.

E-6

TROUBLESHOOTING GUIDE

DOES NOT PLAY DVD

Does this display "INCORRECT DISC"?

No

Does this display reading mark?

Yes

No

Does CD2001 connect with CP2301 correctly?

No

Connect CD2001.

Change IC4001.

Yes

Change DVD DECK.

No

Is the voltage between JG017 and JG018 less than 0.6V?

Yes

Does disc rotate?

Yes

Change IC4001.

No

Change DVD DECK.

E-7

TROUBLESHOOTING GUIDE

DOES NOT PLAY CD

Does this display "INCORRECT DISC"?

No

Does this display reading mark?

Yes

No

Does CD2001 connect with CP2301 correctly?

No

Connect CD2001.

Change IC4001.

Yes

Change DVD DECK.

No

Is the voltage between JG019 and JG018 less than 0.6V?

Yes

Does disc rotate?

Yes

Change IC4001.

No

Change DVD DECK.

E-8

NO SOUND DVD/CD ANALOG AUDIO

TROUBLESHOOTING GUIDE

Is there signal at pins 113, 114, 115 and 116 of IC4001?

Yes

Is there signal at pins 1 and 7 of IC8501?

Yes

Does CD8501 connected?

Yes

Change DIGITAL PCB.

No

Change IC4001.

Check pins 1 and 7 of IC8501 and peripheral circuit.

Connected CD8501.

NO SOUND DVD/CD DIGITAL AUDIO

Is there signal at pin1 of CP8501?

No

Is there signal at pin122 of IC4001?

No

Change IC4001.

Yes

Change DIGITAL PCB.

Check line circuit IC4001 to CP8501.

E-9

/

DVD LOADER

A

DSM2

DVD BLOCK DIAGRAM

LCD BLOCK

OPU

SPINDLE/ STEPING SLED MOTOR

MD_DVD, MD_CD

RF, A, B, C, D, E, F

DVD_CD, DVD_LD, CD_LD

TR+/-, FO+/-, MOT_LD+/-, MOT_SLED+/MOT_SPDL+/-

HOME, TIN_SW, TOUT_SW

Motor Drive

IC2301

LA6565VR-TLM-E

SST39VF1601-70-4C-EKE

SPINDLE/SLED/ FOCUS/TRACK_PWM, TRAY_CLOSE/OPEN

SPDL_SENS+/-

HA0~A19, HD0~D15, MEMCS0, RD, WR

FLASH 16M

IC4007

MPEG/MICON/DSP/RF_AMP

IC4001

ZR36966ELCG-D

SD_A0~A11

SD_D0~D15

RAMDQM, CLK, CKE, WE#, CAS#, CS0#, CS1#, RAS# SD_BAO

PWM_L+/-, PWM_R+/-

64M SDRAM

IC4005

M12L64164A-7TG

AUDIO AMP

IC8501

NJM4565M(TE1)

DUPRD1

DUPTD1

TIN_SW

SPDIF

DAC_VIDEO_C/D

DAC_VIDEO_A

RESET

SYS_MUTE

DVD_AUDIO_L

DVD_AUDIO_R

TX

RX

START_SW

SPDIF-134

C_VIDEO

Y_VIDEO

DVD RESET

ZERO

DVD_A_OUT_L

DVD_A_OUT_R

F-1 F-2

POWER BLOCK DIAGRAM

A

_

A

C IN

CD3805

F401

J401

POWER SW IC401 MP3A5038

Vcc

Q2g

20

10 18

L401

Q1d

1

3

D405

C403

FB 13

+

P.GND

8

2

4

D407

C404

VW

15

L402

1

3

Q2d

22 23

D415

2

4

TRANSFORMER

T402

1

+

C455

POWER SW IC402 MIP2F4

D Vcc FB

4

+

5

Vdd

2 1

3

5

PS2561AL1-1-V(W)

VccS

TRANSFORMER

T401

8

7

5

2

1

9

8

7

FEED BACK

IC410

431

41

10

13

14

15

2

23

POWER SW

IC406

PS2561AL1-1-V(W)

REGULATOR IC404 KIA431A-AT

1 3

SW

SOUND +B

Q409

Q416

SW

Q417

SW

CP401__1.TUNER+30V

CP401__7.8. AT+5V

CP401__2. POWER FAIL

CP401__6.P.CON+5V

CP401__3.

POWER_H

SYS

CP401__18.SW+12V

CP406__1,2,3,4,5. +24V

SOUND AMP IC302

N17808B

IC407

DC/DC(5V)

LA5779-E

CP401__11,12. LCD+B

FEED BACK

IC408

PS2561AL1-1-V(W)

41

23

SW

3 1

REGULATOR IC403 KIA431A-AT

CP401__13. LCD_H

F-3 F-4

_

_A

_

R

POWER(DIGITAL PCB) BLOCK DIAGRA

M

CP3001

1 TUNER+30V

2 POWER FAIL 3 SYS_POWER_H 4 AT+3.3V 5 GND

6 P.CON+5V 7 8 9

10

11 12 13 LCD 14 P.CON+9V 15 16 17 STBY_H 18 SW+12V 19 REMOCON 20 LIGHT 21 KEY 22 LIGHT_POWER_H 23 KEY

AT+5V

GND

LCD+B

H

GND

IN

CTL

B

SUB MICON

IC6202

R5F21124FP

EEP-ROM

IC3601

S-24CS02AFJ-TB-GE

VDD CORE 1V

IC3001

BD9130NV

DC/DC CNT

IC3002

AL1015

DC/DC FET

IC3004

TPC6108

LCD PANEL

V2301

V260B1-L01

AUDIO Lch SW

IC6552

NJM2534V(TE2)

EEP-ROM

IC2805

M24256-BWMN6TP

1V

3.3V

FLASH IC

IC2804

EN29LV320AB-70TCP

AUDIO Rch SW

IC6553

NJM2534V(TE2)

BTSC DEMODULATOR

IC5801

AN5832SA-E1V

HDMI SW

IC3603

STHDMI002ABT

AUDIO ADC

IC6551

AK5358A

REG+1.8V

IC3003

PQ035ZN1HZPH

DIGITAL TUNER

TU5801

ENG36E19KF

SCALER IC

IC2801

R8J66954BG

1.8V

DDR SDRAM

IC2802

HYB18TC256160BF-3S

F-5 F-6

Y

R

Y

(IF)

)

_L/R

R

X

O

_

4

AUDIO OUT

_AG(

)

M

J4301

OUT

AV3-13P2-60S1

ANALOG AUDIO OUT L/R

COAXIAL

S VIDEO IN

IN S1 C

IN

CVBS IN2/YUV AUDIO IN

IN

DVD CP701 13 R 14 T 6 DVD_A_OUT_L 4 DVD_A_OUT_R

1 SPDIF-134 8 [Y]VIDE 10 [U]C_VIDEO 11 START 7 DVD 3 ZERO

J4202

DIN-409B

COMPONENT IN

J4203

AV3-13P2-31S1

HDMI IN 1

CP3601

5-1903015-

TUNER TU5801

ENG36E19KF

CVBS IN1/ S AUDIO IN

J4206

RCA-349-00C-02

J4205

RCA-349-00C-02

PC/DVI AUDIO IN

J4201

MSJ-2000B

087

SW

RESET

SIGNAL BLOCK DIAGRA

SPDIF

S1

COMPONENT

COMPONENT U

COMPONENT V

HDMI 1

DIGITAL RF

ANALOG RF(CVBS

SIF TUNER AUDIO L

AV 1 CVBS PC G IN

AV 1/S AUDIO L/R PC B

AV 2 CVBS AUDIO DATA

AV 2/YUV AUDIO

PC/DVI AUDIO L/

BTSC DEMODULATOR IC

IC5801

AN5832SA -E1V

NJM2750M(TE1)

HDMI SW IC

IC3603

STHDMI002ABTR

AUDIO SW IC

IC6502

TUNER AUDIO R

SW AUDIO L

SN74LVC1G3157DCKR

HDMI

SW AUDIO R

DIGITAL_A_SW

IC6556

AUDIO Lch SW IC

IC6552

NJM2534V(TE2)

AUDIO Rch SW IC

IC6553

NJM2534V(TE2)

Y SW

IC6554

MM1501XNRE

AUDIO L

AUDIO R

AUDIO ADC IC

AK5358A

C SW

IC6555

MM1501XNRE

SCALER IC

IC2801

R8J66954BG

IC6551

SUB MICON

IC6202

R5F21124FP

AUDIO L/

LVDS DATA/CLK

SPEAKER L/R SP301, SP302

SOUND AMP IC

LCD PANEL

V260B1-L01

PC R

S0412F06

AMP L/

IC302

AN17808B

V2301

PC IN

CP4303

1B630020

F-7 F-8

PRINTED CIRCUIT BOARDS

SH8504

C4078

C2341

C4016

MPEG

C4014

C4013

C2327

53

C4009

NTSC

1

C4018

B4008

PAL

C2340

C4099

DVD MT (TOP SIDE)

R2360

C4083

B4016

C4025

CP2301_1

C4058

C2328

C2348

C4085

157

R4001

C4034

W836 R4012 R4042 C4035

B4015

C4069

B4010

R4071

R8517

R8521

C4012

R8523

105

R8522

C4042

R4009

C4030

C4038

D8510

C4082

B4006

C8542

4

B2305

C4002

C4015

IC4001

R4008

C4022

C4029

C4019

C4067

DMG097A

C2316

C4023

C4020

C4024

C4072

B4005

X4001

C2337

C8530

C4070

R2321

R2320 R2302 C2365

R8528

C8529

R8527

CP8501

R2327

R2326

B4001

C8531 R8529

R2301 R8530

C4053

C8532

C8528

C8527

C8544

IC8501

R8533

C2329

C4075

R2319

R8531

R8532

R8534

R2305

MOTOR

IC2301

C8534

C8526

C8533

C8525

CP2302

C2303

C2302

R2304

C2315

C4071

R8510

R2303

R2329

C2310

C8513

C8516

C8514

R2323

C2307

CP2303

C8517

C8515

C8539

C8538

C8518 C8519

B8501

CP8502

SH8502

REGULATOR

C2360

C2358

C2357

C2319

C2359

B8502

R8506 C8521

B8504

B8503

R2350

C4076

R2342 R2349 R2352

C2330

C2339

C2321

R2353

B4002

C2306

C2301

C8502

L8501

C8503

C8501

R8508

R8509 R8507

IC8502

C8543

C8520

C8537 C8536

DVD MT (BOTTOM SIDE)

R2309

R8535

C2332

C2304

R2339

R2328

R2358 R2357 C2305

D2304

R8516

R8539

C2331

B2304

R2330

D2303

R8537

R2325

R8536

R2307

R2355

R2313

C8504

R2308

C8505

C8506

R2337

R2310

R8524

R2324 C4037 C4011

R2338

L8502

B4003

W818

C2323

W807

D4005

R4039

C8541

C8510

C8511

R8526

R4016

C2335

C2333 R4002

C8512

C4044

R4036 R4037 R4038

L8504

R4003

C4051

C4105

W825

C2338 C2336

W824

C2334

C4005 C4054

C4052

D4002

C4007

C4028 C4079

R4005

D4003 C4049

C4086

C4026

R4089

R4024

R4067

C2350

R4045 R4078

R4052

R4032

C4096

R4004 R4086

R4065 R4087

C4059

R4019 R4043

R4018

C4004

C4006

C4091

C4027

C4081

C4032

D4008

C4036

C4021

R4014

C4050

R2336R2335

R2334

W813

R4022

C4055

C2326 C2317C2309

W812

C4060

C4045

R4063

C4001

W841

R4062 C4057

R4048

C4041C4040

IC4005

C4039

W860

R2306

R4060

R2318

R4061

R2332

R2333

Q2301

C4003 C4056

R4023

Q2302

C4033

C4010

C4047C4046

R2341 R2340

DMG097A

C4008

IC4007

C4095

C4062 C4064

R4040

R4054 R4053

C4077

G-1

G-2

PRINTED CIRCUIT BOARDS

DIGITAL (TOP SIDE)

CP2803

C2807

SH3003

CP2801

SH3002

B2800

CP2804

SH3001

W849

W854

LVDS

C2801

B4304

CP6201

C3038

R3009 R3016 R3018 R3008 C3016

C3032

C3029

C3033

C2800

R6215 R6214 R6219

C6205

MICON

C3013

R3014

Q3003

L3001

Q3004

B4302

C3024

C3031

B3003

L3005

R6205

C3019

IC3002

C3014

B4306

C3026

B4305

IC3001

C2882

R6206

R6227

R6228

C3011

R3011

C3027

R6213

R6223

R6224

R3023

C3017

C3023

L3002

R6216

C6216

R6225

R3024

R3019

B4303

C3015

R6221

R3025

B3005 B3004

C3012

CP4301

W827

W828

B6552

B6553

L6551

C6564

CEG352A

C3035

R2817

C2959C2965 R2846R2850

C2866 C2867C2876

C2869

C6212

X6201

C6215 C6213

W901

W900

C3022

D3004

C6559

IC2802

CP3001

C6560

X6551

C6555

R6569

W894

C2865

C3021

R4322

Q3608

Q3607

C4342

R3639

R3640

R4332 R4344 R4340 R4334

SH3005

R3606

R3605

L3601 L3602

D3605

C3601

J4301

CP3601

D3604

R3601

CP4303

CP6202

SH3004

R6202

R6201

C6202

D6201

B6551

3

R2827

R2823

C6201

C6553

R6566

R2824

R2826

R2825

NR2806

R2830 R2800

NR2811

R3001

D6202

TUNER

R2820

NR2807

NR2810

C2809

C2877

NR2802

C2802

R3428 R3427

Q3411

C3003

C5833

C5839

C5841

DDR

NR2808

A21

C2810

R2812

C2811

NR2804

R2814

R2805

R2808

Q3410

C5825 C5826 C5827

C5830

R2813

C2812

NR2801

NR2803

B4312

R2815

D3405

C4313

IC2801

R3437

D3406

C4315

C5819

R3406

C4317

B5804

Q5801

R5808 R5809

R2806

R3414

Q3409

CP4302

Q5802

R5817

R5821

R2810

IC2804

B4313

R5818

R5822

R5823

R2811

C5822

R2842

AA1AA21

C5821

C2947 C2936 C2944 C2933

C2940

A1

C5820

C2951

R2838

C4321

C5847

R2839

C5855

R3634

C3618

R3635 R3633

R3422

C4322

C2950

C3613

C3408

B4314

B2817 B2816

R2837 C2945 C2935 C2943

C2931 C2946

C3614

W890

Q3405

R5820

R5819

C5845

C5844 C5846

L5805

C2948

B2815

C2905

C2929

C2924

C3615 C3616

C3610

C3611

R3641

FLASH

Q3406

C4326

C4324

B4315

AV

C6569

B6556

B2813

B2814

B2822

C2923

SCALER

NTSC

B2811

R3632

X3601

D3401

R3413

R3412

Q3404

C3036

C3420

C4329 R4309

C5803C5801

R4317 R4316

C4333

R4320

R4342

C4339

C2914

C2921

B2821

B2820

C2891

B2810

C2883

PC

Q3402

R3405

C3417

B4308

Q4304

Q4310

R4341

TU5801

C4336

C4328

B3601

C3401

L3401

C4332

R4336

R4345

R4326 R4321

R4335

C4341

37

C3402

R4323

R4329

Q4306

C4335

R4330

C4338

B4309

R4337

L4301

HDMI

1325

IC3603

1

R3631

W826

R3630

C6561

R6560

C6562

C6556

IC6551

R6567

NR6551

R6563

AV

C2860

R1R9

A1A9

C2975

C2974

X2801

X2802

L3004_1

G-3 G-4

PRINTED CIRCUIT BOARDS

DIGITAL (BOTTOM SIDE)

D3610

IC3601

C3604 R3609

R3613 R3615

R3617

D3607

R3611

Q3609

Q3606

R4347 R4346 R4343

R3625

R4303

R4304

R4305

R4351

C3602

C3606C3607

C3608

R3642

C4343

R4352

C4344

C3609

L5801

Q4303

Q4307

Q4311

C4346

R3401

C5814

R4350

R4349

R3622

C5805

W878

C4331

R4307

R3402

R3431

R3407 R3417

B5802

R4331

R4318

Q4308

R4348

Q4312

R3432

Q3408

Q3403

R3408 R3418

B5808

Q4301

C4345

R4319

C2939

R3435

C3419

C3418

R3404

R5803

R4306

C6572

C6573

C6574

R3416 R3420

R3433 R3403 R3434

R5804

R5801

IC6554

IC6555

C6577

C2937

Q3412Q3401

C5806

C6575 C6576

C2925

C2932

B5809

R5807

R5802

R3436

W881

R2857

C2927

R2853

C2928

W889

R2841

R2840

C2918

C2926

C2934

C2938

R2802

R2807 R2809

R5825

C3612

C2803

R5824

C5853

C2912

C2908

C2920 C2911 C2907 C2906 C2910

C2903

R3629

C2808

C2949

C5852

R5813 C5818 C5824 C5817

C2909

C2913

C2896

C2901

C2941

C2922

C2917

C3416

C3415

R5810 R5812 R5811

C2843

C2900

C2919

C2902

C2942

C2904

C2898

C3413

C2884

C2885

C2887

C2890

C2894

R3426

R3425

C5823

C2842

C2841

C2845

C2875

C2844

C2872 C2871 C2879

R2836

C2881

R2828

R2829

C2851

C2850

C5834 C5835

IC5801

C2831

C2840

NR2809

R2835

C2868

CEG352A

C2806

B2801

C5837 C5838 C5840

C2839

R6551

C6554_1

C2836

NR2805

C2859

B4301

IC6556

R6552

C2822

C6567

B2807 B2806

R6558

C6557

R6573

R6562

C6565

IC6552 IC6553

C6568

C6570

C6571

R6578

C2821

R2819 R2818

B2803 B2809

L3003

R6559

R6561

R6572

C6566

C6563

R3007

C2815 C2813

B2804

C2968

Q6201

R6222 Q6202

IC3003

C2814

B2808

IC3004

IC2805

R6220

C3037

C3018

C2816

R6203

IC6201

R6204

C6209

R2847

R3013

R3017

B2805 D6205

R6217

R3022

R3015

R6209

1

9

R2856

R2860

R2862

W813

R6210

IC6202

R6231

R3020

R6211

R6212

25

17

C6218

R6226

C6210

C6206

R3010

W857

W858

C3009

G-5

G-6

PRINTED CIRCUIT BOARDS

CP302

CP4201

W062

CP406

OS2201

SH407

W826

C498

W054

W810

R486

W028

W027

SH404

CEG359A

W843

C343_1

R481

W069

C458_2

W039

C345_1

C350_1

C348_1

C349_1

W819

R473

W822

D2201

HS405

W829

W042

IC302

W828

W867

W036

HS302

D437

R2208

C2205_1

W040

CP2201

W043

C

401

CP403

R528

W045

W049

W061

C433_1

R432

W029

W044

CP2204

R522

W840

W887

C346_1

D435

D4214

POWER/OPERATION/OPERATION2/REMOCON (INSERTED PARTS)

SOLDER SIDE

SH410

C406

IC401

W053

W056

D412

R429

W046

W034

W004

W058

D416

W881

R421

B401

R406

R410

C423

W823

W886

D440

W063

R498 R423

C435_1

W048

C407_3

B404

Q401

R401

D408

IC408

R438

IC403

C437_1

L411

C462_1

R490

W057

CEG353A

CEG358A

F404

L403

C494_1

W059

R412

IC406

R503

R477

W806

W889

R478

SW2206_3SW2205_3SW2204_3SW2203_3

C404_1

W080

D413

W890

C463

W805

IC405

W037

R475

D407

C500_1

C446_1

W026

W035

C403_1

W047

IC409

CP2203_1

W023

W834

W814

C431_1

SH406

SW2251

W078

C502_1

R434

D405

W836

R437

W010

C453

SW2254

D415

W021

C461

IC404

L408

W020

IC410

IC407

W024

W025

C455_1

D433

L404

W016

SW2255

D411

C475 Q406

D427

D425

R428

SW2201_3

R511

Q407

R536

W038

D410

R416

W051

R431

D426

R487

T401

C438_1

W052

SW2202_3

HS403

W005

W842

W033

W065

W055

C434_1

W050

D424

W011

W017

C491_2

W012

L402_1

IC402

C444

Q417

W015

R506

L413

R513

R497

T402

W006

C440_1

W009

SW2252

C464

C448

R464

W019

C493_1

D443

C430

D432

R447

D444

D442

R452

C497_1

W839

SW2253

D445

R436

CP4203CP401

L401

R445

C441_1

W067

D401

R502

C442_1

R501

W002

CEG361A

C402

W884

C6509_1

W014

CP2251

W070

D404_1

CP404

W032

W885

W883

C6513_1

W075

W064

R404

F401 FH401FH402

W041

W022

W076 W072

ASMARKED.

- REPLACE

RISK OFFIRE

R4224

R4219

R4221

R4239

R4236

SH402

J401

J4203

J4205

J4206

J4202

J4201

SW

SOLDER SIDE

CD2301

SW2

DED020A

YE

WH

BR

M2602 M2601

GR

G-7

G-8

PRINTED CIRCUIT BOARDS

POWER/OPERATION/OPERATION2 (CHIP MOUNTED PARTS)

SOLDER SIDE

R4273

R4267

R4207

R4203 R4216

R4202

R4201

R4270 R4241

R4208

R4214

C4225

C4228

R4272

C4224

R4240

R4269

C4205

C4207

C4209

R4215

D4211

C4223

R4252

R4278

C4221

R4271

R4275

R4212

C4222

D4210

D4207

R4277

C4208

R4248

C4227

D4209

D4213

D4212

C4220

IC6502

C6512

C2251

R2251

R2253 R2254 R2252

R6510

R6511

R496

Q409

R523

CEG361A

Q410

IC411

C436

R505

R460

R430

Q416 R458

R480

Q408

C425

R433

C428

C426

R2255

R461

R444

C429

R454

R443

R455

R483

R482

R456

R484

D406

R451

C443

R441

Q411

C454

C452

R485

R469

R494

R476

R439

Q404 R521

R2206_2

R2207_2

CEG358A

CEG353A

C476

D417

C466

C468

R422

R409

C481

C480

R448

R449

R446

R450

Q412

C495

C419

Q405

C405

R2217

R2203_2

R2201

C477

C472

IC413

C439

R472

Q403

R466

R463

C479

C478

R435

C470

R467

R2207

R2214

R418

R465

R407

R2202_2

Q421

R408

C471

IC412

R405

R2212

C412C411

R414

R417

C418

C408

C409

R411

C414

R420 R508

R471

D421

R2213

C2203

C488

C490

C487

C489

Q307

C307 C341

C342C344

CEG359A

R336

R337

R334

R335

C357

Q4211

Q4212

C456

R4279

C358

R4280

R4283

R303 R305

G-9

G-10

ABC D E F GH

MPEG/MICON/DSP/RF_AMP SCHEMATIC DIAGRAM

(DVD MT PCB)

8

CD_LD

MD_CD

DVD_LD

SLED_PWM

TRACK_PWM

JG001 JG002 JG003 JG004 JG005 JG006 JG007 JG008

7

JG009

FROM/TO MEMORY

6

+3.3V

HA0 HA1 HA2 HA3 HA4 HA5 HA6 HA7 HA8

HA9 HA10 HA11 HA12 HA13 HA14 HA15 HA16

5

HA17 HA18 HA19

HD0

HD1

HD2

HD3

HD4

HD5

HD6

HD7

HD8

HD9 HD10 HD11 HD12 HD13 HD14

4

HD15

MEMCS0

SD_A0 SD_A1 TIN_SW SD_A2 SYS_MUTE SD_A3 DAC_VIDEO_A SD_A4 SD_A5 SD_A6 SD_A7 SD_A8

SD_A9 SD_A10 SD_A11

SD_D0

3

SD_D1

SD_D2

SD_D3 P.CON+3.3V_D

SD_D4

SD_D5

SD_D6

SD_D7

SD_D8

SD_D9 SD_D10 SD_D11 SD_D12 SD_D13 SD_D14 SD_D15

RAMCS0# RAMCS1# RAMRAS# RAMCAS#

2

SD_BA0 RAMDQM RAMWE# RAMCLK

RAMCKE

C4038 0.01 B

BOOT2 BOOT1

D4005

DUPTD1

MA111

DUPRD1 DUPTD0 DUPRD0

P.CON+5V_D

4.7K

C4105 10P CH

R4037 4.7K

R4038 4.7K

R4036 4.7K

R4039

HD2 HD10 HD3 HD11 HD4 HD12 HD5 HD13 HD6 HD14

HD7 HD15

HA16

HA15 DUPRD1 HA14 DUPTD1 HA13 DUPRD0 HA12 DUPTD0 HA11 HA10 IRRCV HA9 HA8 WR HA18 HA17 HA7 DVD_CD HA6 DRVSB

RD WR

HA5 HA4 HA3 HOME

HA2 HA1 HA19

SD_A4 APWM_RSD_A3 APWM_R+ SD_A5

SD_A2 SD_A6 SD_A1 SD_A7

R4054

1K

R4053

1K

C4016 0.1 F

BOOTSEL2

BOOTSEL1

C4008 0.1 F C4010 0.1 F

C4014 0.1 F

C4013 0.1 F

0.1 F

C4077

C4078 476.3V SJV

F

C4033

0.1 R4023

4.7K

RD

HD9

HD1

HD8

HD0

HA0

MEMCS0

3.3

1.9

1.5

2.9

3.3

C4018 0.1 F

GNDC

000

2.4

MEMADD(0)

RAMADD(11)/GPO(64)

RAMADD(9)

RAMCS0#

3.303.3

2.4

110

MEMDAT(2)

2.4

MEMDAT(10)/GPIO(0)

2.2

3

MEMDAT(3)

2.2

4

MEMDAT(11)/GPIO(1)

1.7

5

MEMDAT(4)

2.0

MEMDAT(12)/GPIO(2)

2.2

MEMDAT(5)

1.2

MEMDAT(13)/GPIO(3)

1.9

MEMDAT(6)

1.5

MEMDAT(14)/GPIO(4)

0

GNDC

111213141516171819 22021222324

2.5

MEMDAT(7)

1.9

MEMDAT(15)

1.8

VDDC

3.3

VDDP

2.5

MEMADD(16)

3.3

MEMCS1#/GPIO(5)

NC

0.7

MEMADD(15)

0.6

MEMADD(14)

0.6

MEMADD(13)

1.0

MEMADD(12)

2.5

MEMADD(11)

0.7

MEMADD(10)

1.0

MEMADD(9)

2.4

MEMADD(8)

2526272829

3.3

MEMWR#

0

MEMADD(18)/GPIO(6)

2.8

MEMADD(17)

1.7

MEMADD(7)

0

MEMADD(6)

30313233343536373839

0

GNDC

1.7

MEMADD(5)

1.7

MEMADD(4)

1.7

MEMADD(3)

3.3

VDDP

1.0

MEMADD(2)

2.6

MEMADD(1)

0

MEMADD(19)/IGPIO(7)

3.3

USBVDD

0

USBDP/GPO(67)

NC

40414243444546474849

0

USBDN/GPO(68)

NC

0

USBGND

1.6

RAMADD(4)

1.6

RAMADD(3)

1.6

RAMADD(5)

3.3

VDDIP

0

GNDC

0.7

RAMADD(2)

1.6

RAMADD(6)

1.2

RAMADD(1)

50

1.6

RAMADD(7)

5152

1.8

VDDC

53 545556 57 58 59660 61 62 63 64 65 66 67 68 69770 71 72 73 74 75 76 77 78 79880 81 82 83 84 85 86 87 88 89990 91 92 93 94 95 96 97 98 99

0

1.0

V_SW

0

NCNC

NC 0

NC

0

3.3000001.800

GPIO(63)/MEMCS2#

GPIO(59)/FCU_CS2#

GPIO(60)/FCU_SCLK

GPIO(61)/FCU_IOWR#

GPIO(62)/FCU_IORD#

53 RAMADD(0)

RAMADD(8)

54

RAMADD(10)

55

VDDP

56

RAMBA

RAMCS1#/GPO(65)

RAMRAS#

RAMCAS#

VDDP

3.3

3.303.3

0.1 F

C4019

GPIO(56)/FCU_RST

IGPIO(55)/FCU_IRQ

GPIO(58)/FCU_CS3#

GPIO(57)/FCU_WAIT#

208

VDDP

207

GPIO(9)/MEMDAT(9)

206

MEMDAT(1)

205

GPIO(8)/MEMDAT(8)

204

MEMDAT(0)

203

MEMRD#

202 MEMCS0#

RAMWE#

GNDC

RAMDQM

GNDPCLK

1.900.5

R4008 47

SPINDLE_PWM

B

0.027 B

C4056

C4003 0.027

0.1 F

C4015

GNDC

VDDC

SGND

R4060 11K

R4061 11K

R4062 39K

NCNCNCNCNCNC

1.7

1.001.6

GNDPWM

GPIO(51)/PWMCO(2)

GPIO(52)/PWMCO(3)

GPIO(53)/PWMCO(4)

IGPIO(54)/PWMCO(5)

MPEG/MICON/DSP/RF_AMP IC

ZR36966ELCG-D

100 APWM6+/GPIO(14) 101

APWM6-/GPIO(15)

102

APWM5+/GPIO(16)

103

APWM5-/GPIO(17)

104 AIN/SPDIFIN/GPIO(18) 105 VDDAPWM

106 GPIO(19)/PWMCO(5)/APWM4+ 107 GPIO(20)/APWM4108 GPIO(21)/APWM3+ 109 GPIO(22)/AOUT(3)/APWM3-

PCLK

VDDPCLK

RAMDAT(8)

RAMDAT(7)

RAMDAT(9)

RAMDAT(6)

VDDP

3.3

1.8

1.3

1.2

3.301.0

0.1 F

C4029 100PCH

C4022 0.01 B

C4020

MD_DVD

FOCUS_PWM

(VR_CD)

180P CH

0.0039 B

C4057

C4001

C4059 560P CH

C4002 0.1 F

R4063 15K

3.3

1.8

2.4

3.300

CD_LD

DVD_MD

DVD_LD

VDDPWM

GPIO(49)/PWMCO(0)

GPIO(50)/PWMCO(1)

IC4001

GNDC

RAMDAT(10)

RAMDAT(5)

RAMDAT(11)

RAMDAT(4)

RAMDAT(12)

1.2

2.3

1.7

1.8

(VR_DVD)

C4055 0.001 B

CD_MD

110 GNDAPWM 111 IGPIO(23)/APWM2+ 112 113

RAMDAT(3)

2.2

VC

4.7K

TACT_OFFSET

R4019

0.1 F

C4004

R4043 390 +-1%

15K+-1%

B4016

EBMS160808A102_RDC45

R4022

3.300.9

1.7

2.10000 H

VC

VREF

GNDREF

RESLOAD

A VDD1AFE RFN RFP

GNDC

RAMDAT(13)

0.8

GND1AFE

94PIN STBY_L FOR PLAYER

RAMDAT(2)

VDDC

RAMDAT(14)

1.8

1.2

C4024 0.1 F

RAMDAT(1)

1.2

VDDSAFE

160 159 158 157

GPIO(24)/AOUT(2)/APWM2GPIO(25)/APWM1+

104PIN FPCSTRB

FOR PLAYER

VDDP

3.301.7

0.1 F

C4023

OPU_F

OPU_E

SPDL_SENS+

4.7K

FACT_OFFSET

R4018

2.1

2.7

2.1

F

G

GNDAFE

RAMDAT(15)

RAMDAT(0)

VDDP

RAMDQM2/RAMCKE/GPO(66)

GNDC

1.2

1.3

3.3

3.301.0

NC

F

0.1

C4025

OPU_D

OPU_C

OPU_B

OPU_A

SPDL_SENS-

B

0.01

C4058 0.001 B

C4086 0.001 B

C4006

RFINN

2.3

2.2

2.3

3.3

2.3

3.3

1.6

B

C

D

JEK

GPIO(45)/PWMCO(5)/DUPTD0

GPIO(41)/TDI/NMI SSCRXD

GPIO(34)/RAMCKE/SPDIFIN

GPIO(28)/AOUT(0)/APWM0-

GPIO(26)/AOUT(1)/APWM1-

RAMCKE/SDI_PSC/GPIO(10)

GNDDACBS2

VDDAFE

VDDDAC

GNDDAC_D

VDDPLL GNDPLL RESET#

GPIO(48)/DUPRD1 GPIO(47)/DUPTD1 GPIO(46)/DUPRD0

IGPIO(44) GPIO(43)/TDO SSCTXD GPIO(42)/TCK SSCCLK

GPIO(40) GPIO(39) GPIO(38)

IGPIO(37)/TMS/NMI

GPIO(36) GPIO(35)

GPIO(33)/AIN/SPDIFIN

GPIO(32)/SPDIFO

GPIO(31)/ABCLK

GPIO(30)/ALRCLK

GPIO(29)/AMCLK

GPIO(27)/APWM0+

GPAIO/IGPIO(11)

APWM7+/GPIO(12)

APWM7-/GPIO(13)

101102103104

100

0

NC NC NC

NC

3.3 0

0

4.7K TP4010

R4014

RSET DAC1

DAC2 DAC3

DAC4

DAC5

XIN

GNDC VDDC

VDDP

GNDC

0

XO

RF

VDDPWM

C4085 0.001 B

(AFEGND)

47

6.3V SJV

0.1 F

C4075

C4070

C4021 0.1 F

RFINP

+1.8V P.CON+3.3V_D +3.3V

1.6

157158159160161162163164165166167168169170171172173174175176177178179180181182183184185186187188189190191192193194195196197198199200201202203204205206207208

0

1.3

3.3

1.2

3.3

1.1 0

1.1

1.4

R4042 100

1.6

1.8 0

1.8

3.3

1.6

3.3

1.6

3.3

105106107108109110 111112113114115116117 118119120121122123124125126127 128129130131132133134 135136137 138139140141142143144 145146147148149150151 152153154 155156

0

NCNCNC

3.3 0

R4052 4.7K R4065 4.7K R4087 4.7K

R4032 4.7K

0 0

R4024 4.7K

0

NC

0

NC

0

NC

0

NC

0

NC

0 0

NC NC

0

NC

0

NC

C4042

0.1 F

C4030

C4069

R4009

33

2206.3V SJV

476.3V SJV

R4078 4.7K

R4089 4.7K

C4082

C4076 0.1 F

C4072 0.1 F

C4071 476.3V SJV

C4067 476.3V SJV

B4001

(10mA)

EBMS160808A102_RDC45

C4007 R4001

R4086

R4005

R4004

75 +-1%

W836

X4001

100GT02727

52

27MHz

C4028 0.1 F

C4051 0.1 F

JG029

R4067 10K

B4015

EBMS160808A102_RDC45

R4071 150

B4010

EBMS160808A102_RDC45

C4026 0.1 F

B4006

EBMS160808A102_RDC45

1006.3V SJV

0.1 F

C4083

0.1

F

390

+-1%

75 +-1%

R4003

75 +-1%

C4034 27P CH

1M

R4012

C4035 27P CH

C4027 0.01 B

C4053

0.001 B (DVD-L/CD-H)

C4011 100P CH

C4037 100P CH

C4012

100P CH

0.01 B

(250mA)

R4002

(MUTE-L)

C4107

75 +-1%

VDDDAC VDDAFERF

C4079 0.001 B

C4091 100P CH

C4005 56P CH

C4096 0.001 B

C4032

0.001 B C4081 0.1 F

DAC_VIDEO_D DAC_VIDEO_A DAC_VIDEO_E

R4016 100

RESET

TIN

TOUT_SW

TRAY_CLOSE

TRAY_OPEN

SPDIF

54

APWM_LAPWM_L+

(D_GND) (RF_GND) (A_GND)

B4002 EBMS160808A102_RDC45 B4003 EBMS160808A102_RDC45

B4005 EBMS160808A102_RDC45

R4045 4.7K

W807

C4044

100P CH

D4002 MA111 D4003 MA111

C4049 68P CH

C4052 68P CH

C4054 68P CH

(D_GND)

(185mA) (120mA)

(130mA)

DAC_VIDEO_C/D

TIN

(D_GND)

FROM/TO MOTOR DRIVE

D4008 MA111

(RF_GND)

FROM/TO AUDIO/VIDEO

DAC_VIDEO_C/D RESET

SPDIF DUPRD1

DUPTD1 APWM_L+ APWM_LAPWM_R+ APWM_RP.CON+1.8V_D

P.CON+5V_D

TIN_SW TRAY_OPEN TRAY_CLOSE VDDPWM3.3V

GND GND

HOME TOUT_SW DVD_CD DRVSB RF OPU_A OPU_B OPU_C OPU_D OPU_E OPU_F VC SPDL_SENSSPDL_SENS+ MD_DVD MD_CD DVD_LD CD_LD SPINDLE_PWM SLED_PWM TRACK_PWM FOCUS_PWM

GND

8

7

6

5

4

3

2

W841

SD_A0

SD_A8

SD_A10

SD_A11

SD_BA0

SD_A9

RAMCS0#

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

RAMCS1#

RAMRAS#

RAMCAS#

RAMWE#

RAMDQM

RAMCLK

53

SD_D8

SD_D7

SD_D9

SD_D6

SD_D5

SD_D4

SD_D10

NOTE:THE DC VOLTAGE EACH PART WAS

SD_D3

SD_D11

SD_D12

MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK.

SD_D2

SD_D13

SD_D1

SD_D14

SD_D0

SD_D15

RAMCKE

SYS_MUTE

PCB130 DMG097

1

ABC D E F GH

H-2H-1

ABC D E F GH

MEMORY SCHEMATIC DIAGRAM

8

FROM/TO MPEG/MICON/DSP/RF_AMP

SD_A0 SD_A1 SD_A2 SD_A3 SD_A4 SD_A5 SD_A6 SD_A7 SD_A8

SD_A9 SD_A10 SD_A11

7

6

5

4

3

SD_D0

SD_D1

SD_D2

SD_D3

SD_D4

SD_D5

SD_D6

SD_D7

SD_D8

SD_D9 SD_D10 SD_D11 SD_D12 SD_D13 SD_D14 SD_D15

RAMCS0# RAMCS1# RAMRAS# RAMCAS#

SD_BA0 RAMDQM RAMWE# RAMCLK RAMCKE

HA0 HA1 HA2 HA3 HA4 HA5 HA6 HA7 HA8

HA9 HA10 HA11 HA12 HA13 HA14 HA15 HA16 HA17 HA18 HA19

HD0

HD1

HD2

HD3

HD4

HD5

HD6

HD7

HD8

HD9 HD10 HD11 HD12 HD13 HD14 HD15

MEMCS0

+3.3V

FROM AUDIO/VIDEO

P.CON+3.3V_D

GND

RD WR

MEMCSO

D_GND

HA16 HA15

C4064

0.1 F

HD15 HA12

HD7 HA11

HD14 HA10

HD6 HA9

HD13 HA8

HD5 HA19

HD12

HD4 WR

C4062

HD11 RAMDQM

HD3

HD10 HA19 RAMRAS#

HD2 HA18

HD9 HA17 SD_A9 RAMCS0#

HD1 HA7

HD8 HA6 SD_A6 SD_A1

HD0 HA5

RD HA4

HA0 HA1

C4099

0.01 B

0.1 F

EBMS160808A102_RDC45

FLASH IC 16M

IC4007 SST39VF1601-70-4C-EKE

2.5 A16

3.3 VCCQ

0

VSS

1.9 DQ15

2.5 DQ7

1.5 DQ14

1.9 DQ6

1.2 DQ13

2.2 DQ5

40 41 42 43 44 45 46 47 48

2.0 DQ12

1.7 DQ4

3.3 VDD

2.2 DQ11

2.2 DQ3

2.4 DQ10

2.4 DQ2

1.9 DQ9

1.5 DQ1

1.5 DQ8

30 31 32 33 34 35 36 37 38 39

1.5 DQ0

2.9 DE#

0

VSS

2.9 CE#

2.4 A0

25 26 27 28 29

4.7K

R4040

B4008

(DVD MT PCB)

0.7

110111213141516171819 22021222324

A15

0.6

A14

0.6

3

A13

1.0

4

A12

2.5

56789

A11

0.7

A10

1.0

A9

2.4

A8

0

A19

0

A20

NC

3.3

WE#

0

RP#

3.3

VPP

3.3

WP#

0

A19

0

A18

2.8

A17

1.7

A7

0

A6

1.7

A5

1.7

A4

1.7

A3

1.0

A2

2.6

A1

1B

C4095

C4060 330P CH

C4039

0.1 F

W860

RESET

HA14

HA13

HA3

HA2

64M SDRAM IC IC4005 M12L64164A-7TG

VDDQ

VSSQ

VDDQ

VSSQ

LDQM

A10/AP

VDD DQ0

DQ1 DQ2

DQ3 DQ4

DQ5 DQ6

DQ7 VDD

CAS RAS

BA0 BA1

VDD

3.3

110111213141516171819 22021222324252627

1.3

3.3

3

1.2

4

0.8

5

0

6789

2.2

1.7

3.3

1.2

1.2 0

1.3

3.3

1.9

3.3

WE

3.3

CS

0

3.3 0

1.0

A0

1.2

A1

0.7

A2

1.6

A3

3.3

0

VSS

R4048

4.7K

2206.3V SJV

1.2 DQ15

0

VSSQ

1.2 DQ14

1.7 DQ13

50 51 52 53 54

3.3 VDDQ

1.8 DQ12

2.3 DQ11

0

VSSQ

1.0 DQ10

1.2 DQ9

3.3 VDDQ

1.8 DQ8

0

VSS

0

NC

40 41 42 43 44 45 46 47 48 49

1.8 UDQM

0.5 CLK

3.3 CKE

0

NC

36 37 38 39

0

A11

0

A9

0

A8

1.6 A7

1.6 A6

1.6 A5

30 31 32 33 34 35

1.6 A4

0

VSS

28 29

SD_D15 SD_D0

SD_D14 SD_D1 SD_D13 SD_D2

C4040

0.01 B

SD_D12 SD_D3 SD_D11 SD_D4

SD_D10 SD_D5 SD_D9 SD_D6

C4041

0.01 B

SD_D8 SD_D7

RAMDQM RAMWE# RAMCLK RAMCAS#

55

SD_A11 SD_BA0

SD_A8 SD_A10 SD_A7 SD_A0

SD_A5 SD_A2 SD_A4 SD_A3

RAMCKE

C4009

C4036

0.001 B C4050

0.01 B

C4045

0.1 F

C4046

0.1 F

RAMCS1#

C4047

0.1 F

8

7

6

5

4

3

MEMCS0

RESET

2

PCB130 DMG097

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE EACH PART WAS

MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK.

2

1

ABC D E F GH

H-4H-3

8

7

6

5

4

3

2

DSM2(06SD)

FROM/TO LOADER

CP2301_1 LD07T2-24ND-03

1

GND

2

F

3

Vref

4

VCC

5

E

6

D

7

C

8

SW1(DVD/CD)

9

VRF(RF_OUT)

10

B

11

A

12

VR(DVD)

13

VR COM

14

VR(CD)

15

GND

16

LD(CD)

17

PD/GND

18

LD(DVD)

19

GND

20

NC

21

T DRV

22

T RTN

23

F DRV

24

F RTN

ABC D E F GH

MOTOR DRIVE SCHEMATIC DIAGRAM

8

7

6

5

4

3

2

NC

CP2302

04_6232_105_015_800+

5

CLOSE

4

OPEN

3

GND(D)

2

LD-

1

LD+

CP2303 04_6232_106_015_800+

SW(GND)

6

LIMIT SW

5

SLD-

4

SLD+

3 2

SP1-

1

SP1+

C2321

C2350

0.1 B

TP2305

100P CH

C2339

C2348 0.1 B

C2329

C2331 0.1 B C2333 33P CH

C2334 33P CH C2335 33P CH C2336 33P CH

C2337 33P CH C2338 33P CH

JG037

TP2303

TP2304

4.7K

R2350

100P CH

4.7K

R2342

R2349

100

C2319

100P CH

226.3V SJV

JG034

JG035 JG036

JG056

TR+ TR-

FO+ FO-

C2309

R2352

R2353

HOME MOT_SLEDMOT_SLED+ MOT_SPDLMOT_SPDL+

0.1 F

100

C2357

JG015 JG012

JG026

JG014 JG013 JG040 JG025 JG016 JG011 JG010

JG027

TP2309 TP2310 TP2311 TP2312

P.CON+3.3V_D

TP2306

C2358

100P CH

C2328

226.3V SJV

OPU_VREF

DVD_CD

DVD/VR

C2317

TIN_SW

C2330

10P CH

TOUT_SW

MOT_LDMOT_LD+

100P CH

C2359

OPU_F

OPU_E OPU_D OPU_C

OPU_B OPU_A

0.1 F CDLD

DVDLD

C2360

100P CH

(DVD MT PCB)

VC

DVD_CD

33

R2360

3.3K

R2355

C2323

0.1 B

RF

DVD LD CTL

Q2301

KTA1505S-Y-RTK/P

DVDLD

CDLD

CD LD CTL

Q2302

KTA1544T-RTK/P

JG019

B2305

EBMS160808A102_RDC45

(D_GND)

100P CH

MD_DVD

(VR_CD)

W813

2.6

1.9

2.3

0

3.0

3.2

W812

R2306

6.8

R2318

6.8

R2332

220

C2340

476.3V SJV

C2341

R2333

220

R2340

R2341

6.8

MD_CD

(VR_DVD)

JG018JG017

SJV

476.3V

6.8

DVD_LD

TP2307

CD_LD

TP2308

(RF_GND)

(D_GND)

R2310

4.7K

VIN-OP

VD2-

C2316

R2309

30313233343536373839

VO_OP

VD1-

TP2315

VC2

476.3V SJV

100 +-1%

R2321

R2323

TP2320

15K

VIN3

VD1+

1.2

33K

R2319

TP2319

NC

VIN3-

VCC1

NC

C2306 0.1 F

R2357 1K

C2307 0.1 B

1.2

R2329

C2310

C2332

0.1 F

RF_A5V

R2305

VIN4

VD4+

27K

FOCUS_PWM

R2320

4.7K

VREF-IN

VREF-OUT

VD4-

VD3+

226.3V SJV C2326

C2327

R2338

4.7K

0.1 F

1K

R2301

TP2322

10K

R2308

MUTE1

VCONT

S-GND

MOTOR DRIVE IC

FWD

REV

IC2301 LA6565VR-TLM-E

1 1011121314151617 18 192 20 21 22

0 0 6.0 0 1.9 1.9 2.6 2.7 2.6 2.8 0 0 3.7 1.7 2.6 2.7 0 6.0 6.0 1.6 1.6 1.6

TP2302

TP2301

3

C2301

VCC2

0.1 F

MUTE234

NC

4

NC

C2315

0.1 F

TRACK_PWM

75K

R2307

4041424344

NC

VIN4-

VLD-

VLD+

56789

C2302 0.1 B

R2303 2.2

C2303 0.1 B

R2304 2.2

EBMS160808A102_RDC45

NCNCNC

NC

REG-OUT

VD3-

PGND2

B2304

R2313

4.7K

NC NC

VIN+OP

REG-IN

VD2+

PGND1

TP2313

TP2314

R2334

R2324

R2326

VIN2

VCCS

10K

1K

5.6K

10016V SJV

TP2318

JG057

JG058

VIN2-

VIN1+A

R2327

R2358

120

4.7K

VIN2+

VIN1-A

FROM/TO MPEG/MICON/DSP/RF_AMP

MD_DVD MD_CD DVD_CD DVD_LD CD_LD RF GND OPU_A OPU_B OPU_C OPU_D OPU_E OPU_F VC

P.CON+A5V_D

P.CON+3.3V_D

390

R2336

R2339

1.2K

R2335

3.3K

01.61.61.801.61.6000001.601.61.601.63.23.24.10

NCNC

23242526272829

NC

VIN 1

R2325

6.8K

R2328

C2304

0.022 B

4.7K

D2303

R2337

R2330

TP2317

MA111

10K

1K

D2304

TP2316

MA111

C2365 0.1 B

C2305

R2302 100 +-1%

0.1 B

HOME TOUT_SW TIN_SW FOCUS_PWM TRACK_PWM VDDPWM3.3V DRVSB SPINDLE_PWM TRAY_CLOSE

TRAY_OPEN

SPDL_SENS+

SPDL_SENSSLED_PWM

FROM AUDIO/VIDEO

P.CON+A5V_D P.CON+3.3V_D P.CON+6V_D

(D_GND)

GND

M_GND

MOT_LD-

TRAY_CLOSE

TRAY_OPEN

1

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

MOT_LD+

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

TR+

TR-

FO+

FO-

MOT_SPDL+

MOT_SPDL-

MOT_SLED-

MOT_SLED+

NOTE:THE DC VOLTAGE EACH PART WAS

MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK.

PCB130 DMG097

1

ABC D E F GH

H-6H-5

8

FROM/TO MPEG/MICON/DSP/RF_AMP

7

6

5

DAC_VIDEO_C/D

DAC_VIDEO_A

SYS_MUTE

APWM_L+ APWM_LAPWM_R+ APWM_R-

P.CON+1.8V_D P.CON+3.3V_D

P.CON+5V_D

P.CON+3.3V_D

TO MOTOR DRIVE

P.CON+A5V_D

P.CON+3.3V_D

P.CON+6V_D

ABC D E F GH

AUDIO/VIDEO SCHEMATIC DIAGRAM

RESET

DUPRD1

SPDIF

DUPTD1

GND

TIN_SW

TO MEMORY

RESET

GND

M_GND

DAC_VIDEO_C/D

DAC_VIDEO_A

C8504

C8510

(DVD MT PCB)

FROM/TO REGULATOR

CP8502

(CP403)

A2001WV2-8P

GND(M)

C8517

1006.3V SJV

10016V SJV

B8501

HCB1608KF-121T20

EBMS160808A102_RDC45

B8502

C8518

P.CON+6V

P.CON+A5V

0.001 B

C8519

B8504

EBMS160808A102_RDC45

C8521

0.1 B

0.001 B

SH8502

YQ-12

B8503

HCB1608KF-121T20

C8520

2.2 B

SH8504

C8538

C8539

YQ-12

P.CON+12V P.CON+3.3V P.CON+3.3V

0.001 B

P.CON+6V_D

C8515

M_GND

C8505

12P CH

L8502

1uHNLV25

150P CH

C8511

12P CH

L8504

1uHNLV25

150P CH

C8506

C8512

150P CH

59

58

DAC_C[U]C_VIDEO

DAC_A[Y]_VIDEO

P.CON+5V_D P.CON+A5V_D

P.CON+3.3V_D

P.CON+1.8V_D

C8501

C8502

1F

R8507

L8501

2.2uHNLV25

1K +-1%

0.1 B

C8503

0.1 B

1.8V REG IC IC8502

LM1117S-ADJ

INADJ OUT

123

C8516

R8509

R8508

68 +-1%

2.2K +-1%

GND

8 7 6 5 4 3 2 1

CD8502

CU282701

8

7

6

5

R8532

47K

R8530

2.2K

4.3 4.3 6.9

0

R8531

47K

+

-

C8531

47P CH

+

A_GND

5678

4.3 4.3 6.9 10.9

R8529

2.2K

C8532

47P CH

1234

C8533

1016V SJV

R8533

VCC

15K

R8534

15K

IC8501

NJM4565M(TE1)

AUDIO_AMP IC

C8526

0.1 B

C8534

1016V SJV

R8535

R8539

1K

10K

R8537

R8536

1K

10K

56

57

R8510

R8516

24K

10K

R8522

47K

R8523 47K

C8525

R8517

47K

R8521

47K

4716V SJV

C8514

C8530

0.0012 B

47K

0.1 B

C8528

R8528

150P CH

47K

R8527

C8527

150P CH

C8529

0.0012 B

APWM_L-

4

APWM_L+

R8506

220

C8513

4716V SJV

3

APWM_R+

APWM_R-

2

TIN_SW

DUPTD1

DUPRD1

RESET

SYS_MUTE

SPDIF

W825

W824

D8510

MA111

C8542

FROM/TO JACK3

CP8501

(CP4301)

A2001WR-14A

SSCRXD/TX

W818

C8541

0.01 B

C8537

C8536

C8543

560P CH

0.01 B

C8544

0.01 B

SSCTXD/RX

START_SW [U]C_VIDEO [V]Y_VIDEO

[Y]_VIDEO

DVD RESET DVD_A_OUT_L

DVD_A_OUT_R

SPDIF-134

GND

ZERO

GND

14 13 12 11 10

9 8 7 6 5 4 3 2 1

CD8501

CU2E2701

4

3

2

PCB130 DMG097

1

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE EACH PART WAS

MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK.

1

ABC D E F GH

H-8H-7

ABC D E F GH

FLASH SCHEMATIC DIAGRAM

8

ACCESSORY

BT001 GR6M

BT002 GR6M

TM101

ETR0088-010171

CD3805

P201-2739-1

7

EEP/PC_TOOL_JIG_CON CP2801

A2001WV-9A

NC/RESET

9

D3.3V

8

PC_TOOL_TX

7

PC_TOOL_RX

6

D_GND

5

IIC_OFF

4

SDA

3

SCL

2

GND

1

TCK

TRST_N

NC

D3.3V PC_TOOL_RX PC_TOOL_TX

IIC_OFF

I2C_DATA

I2C_CLK

GND

TDO

ASEBRKAK_N

TMS TDI

RESET_N ASEBRKAK_N

FLASH_WP

ASEMD0

(DIGITAL PCB)

C2807

0.1 B

A2001WV-12A

TCK

TRST_N

TDO

ASEBRKAK_N

TMS

TDI RESET_N FLASH_WP

ASEMD0

GND

VDD33

GND

CP2803

8

7

1 2 3

R2807

4

10K

5 6 7 8

9 10 11 12

R2808

10K

R2809

10K

C2808

0.1 B

D3.3V

RESET_N

ASEMD0

TDO TDI TMS TCK TRST_N

3.3 A1

RESET_N

3.3

MODE0

E4

0

F4

MODE1

3.2

ASEMD0

B1

3.4

ASEBRKAK_N

C2

0.3

TDO

A2

3.2

TDI

B2

3.2

TMS

C3

3.3

TCK

D3

3.3

TRST_N

D4

RESET/MODEE10A DEBUGFLASH I/FM32R DEBUG27MHz CLK25MHz CLK

SCALER IC

IC2801

R8J66954BG

D3.3V D3.3V_FLASH

TO HDMI

6

5

4

FROM/TO SCALER VIDEO/AUDIO

HDMI_SW

IIC_OFF

I2C_DATA

I2C_CLK

A16 A17 A19 A15 A14 A16 A13 D7 A12 A13 A11 A10 A10 A9 D13 A20 A7 A21 D4 WE0_N A4

RESET_N

FLASH_WP

A19 A18 A8 D9 D15 A7 A6 D0 D12 A5 RD_N A4 D9 A3 CS0_N A2 D6

A1

3

TO SURROUND

A_MUTE

B2801

HCB1608KF-221T20

C2802

C2803

2210V V-S

0.1 B NOR FLASH IC

IC2804 EN29LV320AB-70TCP

3.4

110111213141516171819 22021222324

A15

3.4 A14

3.4

3

A13

3.4

4

A12

3.4

56789

A11

3.4 A10

3.4 A9

3.4 A8

3.4 A19

3.4 A20

3.4 WE#

3.4 RESET#

A21/NC

NC

0

JG2801

WP#/ACC RY/BY#

3.4 A18

3.4

A17

3.4

A7

3.4

A6

3.4

A5

3.4

A4

3.4

A3

3.4

A2

3.4

A1

BYTE#

DQ15/A-1

DQ14

DQ13

DQ12

DQ11

DQ10

A16

VSS

DQ7

DQ6

DQ5

DQ4 VCC

DQ3

DQ2 DQ9 DQ1 DQ8 DQ0 OE# VSS CE#

R2810

10K

R2802

10K

3.4

3.4 0

3.4

40 41 42 43 44 45 46 47 48

3.4

30 31 32 33 34 35 36 37 38 39

3.4

3.4 0

3.4

A0

25 26 27 28 29

R2805

10K

R2806

C2806

10K

0.1 B

NEAR FLASH

CRA108100JV

NR2802

NR2803

NR2804

NR2801

D15 D14

D6

D5

D12

D11 A1

D3

D10

D2

D1 D14 D8 D13

R2811

10K

USB_CS WE0_N CS0_N RD_N

BLON

D11 D10

D8 D7

D5 D4 D3 D2 D1 D0

PC_TOOL_RX

PC_TOOL_TX HDMI_SW A_MUTE

3.3 WAIT_N(GPIO)

A6

3.4 WE0_N

C6

3.4 CS0_N

B9

3.4 RD_N

A9

3.5

A22 A21 A20

A18 A17

A15 A14

A12 A11

A9 A8

A6 A5

A3 A2

JG2803

JG2804 JG2805

JG2806

JG2802

A22(GPIO)

B6

3.5

A21

D6

3.4

A20

A5

3.4

A19

D7

3.4

A18

C7

3.4

A17

A14

3.4

A16

B3

3.4

A15

A3

3.4

A14

C4

3.4

A13

B4

3.4

A12

A4

3.4

A11

D5

3.4

A10

C5

3.4

A9

B5

3.4

A8

B7

3.4

A7

3.4

A6

D8

3.4

A5

C8

3.4

A4

B8

3.4

A3

A8

3.4

A2

D9

3.4

A1

C9

3.3

(GPIO)

B14

3.2

D15

A13

3.2

D14

C13

3.2

D13

A12

3.2

D12

C12

3.2

D11

A11

3.2

D10

C11

3.2

A10

D9

3.2

D8

C10

3.2

D7

B13

3.2

D6

D13

3.2

D5

B12

3.2

D4

D12

3.2

D3

B11

3.2

D2

D11

3.2

D1

B10

3.2

D0

D10

3.2

M32TDI

C16

3.2

M32TDO

D16

3.2

M32TCK

C17

2.9

M32TMS

C18

M32TRST_N

B18

6

5

4

3

VCNT(GPIO)

C14

R2814

R2815

NC

1.7

1M

1.7

1M

1.7

XOUT

A16

XIN

B16

XOUT25

A15

XIN25

B15

PCBDH0 CEG352

2

1

2

X2801

X2802

R2812

1.8K

27MHz

100GT02728

R2813

1.8K

25MHz

100GT02509

FROM/TO MICON

ASEMD0

2

IIC_OFF

FROM/TO REGULATOR2

BLON

D3.3V

GND

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

C2809

8P CH

C2810

8P CH

C2811

27P CH

C2812

20P CH

ABC D E F GH

H-10H-9

ABC D E F GH

DDR2 SCHEMATIC DIAGRAM

8

DDR_SDRAM IC IC2802 HYB18TC256160BF-3S

1.8

DAA0 DAQ0

M8

DAA1 DAQ1 DAA2 DAQ2 DAA3 DAQ3 DAA4 DAQ4 DAA5 DAQ5 DACLK_N DAA6 DAQ6 DAA7 DAQ7

DAA8 DAQ8 DAA9 DAQ9 DAA8

7

DAA10 DAQ10 DAA11 DAQ11 DAA12 DAQ12

DADQS0 DADQS0_N DACLK_N DADQS1 DACS_N DAA3 DADQS1_N DARAS_N

6

DAQM0 DACAS_N DAQM1 DAODT DACKE

DAWE_N

DABA0 DABA1

A0

1.5

A1

M3

1.9

A2

M7

1.9

A3

N2

1.9

N8

A4

1.9

A5

N3

1.9

A6

N7

1.9

A7

P2

1.9 A8

P8

1.9

P3

A9

1.9

M2

A10

1.9

P7

A11

1.9

R2

A12

1.8 LDQS

F7

1.8

LDQS

E8

1.8

B7

UDQS

1.8 UDQS

A8

1.8

F3

LDM

1.8

UDM

B3

1.6

CKE

K2

1.8 WE

K3

1.3

L2

BA0

2.0

L3

BA1

DQ0 DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7

DQ8 DQ9

DQ10 DQ11 DQ12

DQ13 DQ14 DQ15

CK CK CS RAS CAS ODT

1.8

G8

1.8

G2

1.8

H7

1.8

H3

1.8

H1

1.8

H9

1.8

F1

1.8

F9

1.8

C8

1.8

C2

1.8

D7

1.8

D3

1.8

D1

1.8

D9

1.8

B1

1.8

B9

1.1

J8

1.1

K8

1.9

L8

1.8

K7

1.5

L7

2.0

K9

R2817

160

DAQ13 DAQ14 DAQ15

DACLK

R2820

DACLK

160

DACLK_N DAA1

DACLK

DACAS_N

DAQM0 DAQM1

DADQS0 DADQS1

DADQS0_N DADQS1_N

R2825 5.1 R2826 5.1

R2827

27

(DIGITAL PCB)

SCALER IC IC2801 R8J66954BG

1.1 W20

1.1 W21

1.6 Y20

1.9 V21

1.8 V19

1.5 Y21

1.8 Y19 U20

1.8 P21

1.8 L21

AA14

NC

AA11

NC

1.8 N18

1.8 K18

V13

NC

V10

NC

1.8 N19

1.8 K19

W13

NC

W10

NC

SDCLK SDCLK_N

SDCKE SDCS_N

SDRAS_N

SDCAS_N

SDWE_N

SDDM0 SDDM1

SDDM2

SDDM3 SDDQS0

SDDQS1 SDDQS2 SDDQS3

SDDQS0_N

SDDQS1_N

SDDQS2_N SDDQS3_N

SDODT

SDBA0 SDBA1

SDA0 SDA1

SDA2 SDA3 SDA4 SDA5 SDA6 SDA7 SDA8 SDA9 SDA10 SDA11 SDA12

V18

AA19

V17

AA18 AA20 AA17

U18 V16 U21 Y16 T20 Y17 Y18 W16 T18

R2823 27

R2824 27

NR2805

CRA108270JV

2.0

1.3

2.0

1.8

NR2806

CRA108270JV

NR2807

CRA108270JV

NR2808

CRA108270JV

NR2809

CRA108270JV

NCNCNC

NC

DARAS_N

DACKE

DABA1 DAODT

DAA4

DAA12

DAA6 DAA0

DACS_N

DAA2

DAWE_N

DABA0 DAA10

DAA9 DAA7

DAA11 DAA5

8

7

6

0

A3

VSS

5

4

3

0

E3

VSS

0

VSS

J3

0

N1

VSS

0

VSS

P9

0

A7

VSSQ

0

B2

VSSQ

0

VSSQ

B8

0

VSSQ

D2

0

D8

VSSQ

0

E7

VSSQ

0

F2

VSSQ

0

VSSQ

F8

0

VSSQ

H2

0

H8

VSSQ

0

VSSDL

J7

NC

R8

NC6

NC

R7

NC5

NC

R3

NC4

NC

L1

NC3

NC

NC2

E2

NC

NC1

A2

VDD VDD VDD

VDD VDD VDDQ

VDDQ

VDDQ VDDQ

VDDQ

VDDQ VDDQ

VDDL

VREF

1.9

A1

1.9

E1

1.9

J9

1.9

M9

1.9

R1

1.9

A9

1.9

C1

1.9

C3

1.9

C7

1.9

C9

1.9

E9

1.9

G1

1.9

G3

1.9

G7

1.9

G9

1.9

J1

0.9

J2

C2815 1 B

C2813 0.1 B

C2816 1 B

C2814 0.1 B

D1.8V

B

R2818

C2821

0.1

1K +-1%

C2822

R2819

0.1 B 1K +-1%

C2831

C2836

C2839

C2840

0.1 B

DAQ3 DAQ1 DAQ4 DAQ5 DAQ0 DAQ2 DAQ7 DAQ6 DAQ12

DAQ8 DAQ14 DAQ10 DAQ13 D1.8V DAQ11 DAQ15

DAQ9

2

1.8 R20

SDDQ0

1.8 R21

SDDQ1

1.8 T21

SDDQ2

1.8 R18

SDDQ3

1.8 P18

SDDQ4

1.8 R19

SDDQ5

1.8

SDDQ6

N20

1.8

SDDQ7

P20

1.8

SDDQ8

M20

1.8

SDDQ9

L18

1.8

SDDQ10

L20

1.8

SDDQ11

M18

1.8

SDDQ12

L19

1.8 N21

SDDQ13

1.8 K21

SDDQ14

1.8 M21

SDDQ15

SDDQ16

Y14

NC

W15

NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC

V14 V15 AA16 Y15 AA15 Y13 V11 W11 Y11 V12 AA13 AA12 Y12 AA10

SDDQ17 SDDQ18 SDDQ19 SDDQ20 SDDQ21 SDDQ22 SDDQ23 SDDQ24 SDDQ25 SDDQ26

SDDQ27

SDDQ28 SDDQ29

SDDQ30

SDDQ31

VCCQ18 VSS VSS VSS VCCQ18 SDVREF0 VCCCQ18 VSS VSS VCCQ18 VCCQ18 VSS VSS VCCQ18 VCCQ18 VCCQ18 VSS VSS VSS VSS VCCQ18 VSS SDVREF1 VCCQ18 VSS VSS VSS VCCQ18

K20 K17 L17 M19 M17 N17 P19 P17 R17 T19 T17 U19 U17 V20 W19 W18 W17

AA21

U16 U15 U14 W14 U13 W12 U12 U11 Y10 U10

1.8 0 0 0

1.8

1.9

1.8 0 0

1.8

1.8 0 0

1.8

1.8 0 0 0 0

1.8 0

1.9

1.8 0 0 0

1.8

0.1 B

C2841

1B

C2842

0.1 B

C2843

C2844 0.1 B

C2845

0.1 B

C2850 0.1 B

C2851

+-1%

1K

+-1%

C2859

1B

C2860

1K

2210V V-S

FROM REGULATOR2

GND

D1.8V

R2828

R2829

0.1 B

5

4

3

2

PCBDH0 CEG352

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

1

ABC D E F GH

H-12H-11

ABC D E F GH

HDMI SCHEMATIC DIAGRAM

8

EEP_ROM IC

IC3601

S-24CS02AFJ-TB-GE

0

1234

A0

0

A1

0

A2 SCL

0

GND SDA

7

PORT1 HDMI CONNECTOR CP3601 5-1903015-4

19

HOT PLUG

18

6

5

GND

D5.0V

+5V_POWER

17

DDC_GND

16

DDC_SDA

15

DDC_SCL

14

RESERVED 13 12

TMDS_CLK-

11

TMDS_CLK_SH

10

TMDS_CLK+

9

TMDS_DATA0-

8

TMDS_DATA0_SH

7

TMDS_DATA0+

6

TMDS_DATA1-

5

TMDS_DATA1_SH

4

TMDS_DATA1+

3

TMDS_DATA2-

2

TMDS_DATA2_SH

1

TMDS_DATA2+

NC

CEC

NC

C3604

C3601

D3604

AVRL161A1R1NT

D3605

AVRL161A1R1NT

D3607

SS160

0.1 B

VCC

WP

R3601

10

R3605 100 R3606 100

12

3

4

5.0

4.9

5678

D3610

8 7 6 5

4

BAT54WS

L3601 EXC28CG900U

12

3 4

WP SCL SDA

R3609 10K

R3611

NC SCL SDA

8

7

6

5

JG3601 JG3602 JG3603

R3613 47K

1K

WP

R3615 4.7K

L3602

EXC28CG900U

JG3604 JG3605 JG3606

HPD_SW

Q3609

KTC3875S_Y_RTK

R3617

22K

HDMI1_SCL HDMI1_SDA

3.3 D

G

BUFFER

4.9 Q3606

2SK3019_TL

S

3.3

10K

R3625

4.6 0

0

R3642

4.7K

HDMI_P5V_1

HP_RST1

HDMI1_CLK_N HDMI1_CLK_P

HDMI1_D0N HDMI_D0N HDMI1_D0P

HDMI1_D1N HDMI1_D1P

HDMI2_SDA HP_RST1

HDMI2_SCL HP_RST

HDMI1_D2N HDMI1_D2P HDMI_D2P

HDMI2_SCL HDMI2_SDA

3

FROM SCALER POWER

D3.3V

VDD33

B3601

HCB1608KF-181T20

(DIGITAL PCB)

HDMI1_D2P

C3602

C3607

0.01 B

C3606

0.01 B

0.1 B

3.1 3.1 0 3.1 3.1 0 3.1 3.1 0 3.1 3.1 3.4

3.4 13141516171819

B_HPD

NC

0

GND

4.9

B_DDC_SDA

4.9

B_DDC_SCL

3.4

VCC

3.1

BCLK-

NC

3.1

BCLK+

2021222324

NC

0

GND

3.1

B0-

NC

3.1

B0+

NC

0

GND

25 26 27 28 29330 31 32 33 34 35 36

A2+

HDMI1_D2N

A2-

GND

13 VCC

25 B1-

B1+

GND

HDMI1_D1P

HDMI1_D1N

A1-

A1+

HDMI_SW IC IC3603 STHDMI002ABTR

B2-

B2+

NCNCNCNC

3.3 03.13.103.13.13.13.103.13.1

GND

SEL

HDMI_SW

10K

R3622

HDMI1_D0P

HDMI1_D0N

56789

A0-

A0+

48 A_DDC_SCL

37 Y0+

Y2+

Y2-

HDMI_D2P

HDMI_D2N

4

GND

HDMI1_CLK_P

HDMI1_CLK_N

2

ACLK-

ACLK+

A_DDC_SDA

A_HPD

Y_HPD

Y_DDC_SDA

Y_DDC_SCL

YCLK-

YCLK+

Y1+

Y1-

HDMI_D1P

HDMI_D1N

VCC

GND

FROM FLASH

HDMI_SW

FROM SCALER VIDEO/AUDIO

HP_RST

SCALER IC2801

3.1

3.3

2.3

1.0

R8J66954BG

E3

PWR0

F1

RXCN

F2

RXCP

G1

RX0N

G2

RX0P

G3

RX1N

H3

RX1P

H1

RX2N

H2

RX2P

HDMI_SCL10

G4

HDMI_SDA10

F3

HDMI_XIN

E1

HDMI_XOUT

E2

J2

EXT_RES

PLL_XFC_A

C1

PLL_XFC_P

D1

PLL_XFC_X

D2

4.7K

R3640

W826

BUFFER Q3607 2SK3019_TL

BUFFER Q3608

4.7K

2SK3019_TL

C3610

8PCH

C3611 10P CH

R3629

470

C3612

D

G

D

G

X3601

0.1 B

C3613

4.7 B

C3614

0.0022 B

C3615

0.027 B

S

R3630

3.3K

S

R3631

3.3K

3

18.432MHz

100GT01807

R3641

1K

C3616

0.1 B

C3618

0.001 B

HDMI_POWER

HDMI_CLKN HDMI_CLKP

HDMI_D0P

HDMI_D1N HDMI_D1P

HDMI_D2N

HDMI_SDA

HDMI_XIN

R3632

HDMI_XOUT

EXT_RES

R3633

4.7K

R3634

3.3K

R3635

8.2K

1M

PLL_XFC_A

PLL_XFC_P

PLL_XFC_X

HDMI_P5V_1

0.1 B

C3608

C3609

0.1 B

1101112

5.0

40 41 42 43 44 45 46 47 48

37 38 39

5.0

3.4

3.3

5.1

3.1

0

3.1

HDMI1_SCL

HDMI1_SDA

Y_HDMI_SDA

Y_HDMI_SCL

HDMI_CLKN

HDMI_CLKP

HDMI_D0N

HDMI_D0P

Y_HDMI_SCL HDMI_SCL Y_HDMI_SDA

R3639

VCC

Y0-

GND

8

7

6

5

4

3

2

PCBDH0 CEG352

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

2

1

ABC D E F GH

H-14H-13

ABC D E F GH

JACK3 SCHEMATIC DIAGRAM

8

FROM/TO AUDIO/VIDEO

CP4301

(CP8501)

A2001WR-14A

1

SPDIF-134

2

GND

3

ZERO

4

DVD_A_OUT_R

5

GND

6

7

6

5

4

3

DVD_A_OUT_L

7

DVD_RESET

8

[Y]VIDEO

9

10

[U]C_VIDEO

11

START_SW 12 13 14

FROM/TO JACK2

CP4302

TWG-P23P-A1

23

LOUT_SOUND 22 21

ROUT_SOUND 20 19

FILTER_MUTE

18

POP_MUTE

17

YUV_SW_Y 16 15

YUV_SW_U 14 13

YUV_SW_V 12 11

AUDIO_SW_R

10

AUDIO_SW_L

9 8 7 6 5 4 3 2 1

GND

RX TX

(CP8104)

GND

ASW2

GND

VIDEO2

GND

VIDEO1

ASW1

AV1_C

S1_DET

AV1_Y

NC

C4312 10P CH

B4312

FCM1608KF-102T02

B4313

FCM1608KF-102T02

B4314

FCM1608KF-102T02

B4315

FCM1608KF-102T02

C4314 10P CH

B4305

FCM1608KF-102T02

C4316 10P CH

C4313

FCM1608KF-102T02

C4315

22P CH

B4301

FCM1608KF-102T02

B4302

FCM1608KF-102T02

B4303

FCM1608KF-102T02

B4304

B4306

FCM1608KF-102T02

C4321

C4317

22P CH

R4301_1

C4322

75 +-1%

22P CH

W827

W828

R4302_1

C4326

DVD_SPDIF

ZERO_MUTE

DVD_R

DVD_L

DVD_RESET

DVD_Y

DVD_C

START_SW

TWIRE_TXDC TWIRE_RXDC

75 +-1%

LOUT_SOUND

ROUT_SOUND

POP_MUTE

AV3/AV4_Y

AV3/AV4_PB

AV3/AV4_PR

SW_R ASW2 SW_L

AV2_CVBS

AV1_CVBS

ASW1

AV1_C

S1_DET SPDIF_OUT

AV1_Y

C4324

22P CH

DVD-H

DVD_SPDIF

SPDIF SPDIF_OUT

SPDIF_OUT

VGA-R

VGA-G

VGA-B

PC_H

PC_V

D5.0V

ROUT_FI LOUT_FI

P.CON+9V

AT+5V

L4301

22uHNLCV32T

FCM1608KF-151T06

C4329

0.1

B

V-S 22

C4328

16V

MUTE_SW

Q4303

KRA101SRTK

CAUTION: DIGITAL TRANSISTOR

2

R4306

0

10K

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

EXT_MUTE-H

MUTE_SW

Q4301

KTC3875S_Y_RTK

(DIGITAL PCB)

R6551

100

R6552

100

R4303

100

B4308

R4309

2.2K

5.0

5.0 0

R4307

1.5K

5.0

0

C4331

10 C

R4319

GND

C4332

C4333 10 C

10016V V-S

C4335

R4316

1.3

AMP

R4317

R4318

1K

SN74LVC1G3157DCKR

2.9

0

2.9

D AUDIO DRIVER Q4306 KTC3875S_Y_RTK

1.5K

R4322

3.3K

R4323

0.022 B

430K

R4320

8.2K

4.7

0.7

Q4304

KTC3875S_Y_RTK

68K

1K

R4321

1K

DIGITAL AUDIO SW IC

IC6556

123

SWB2

GNDAVCC

B1

R4304

100

R4332

R4330

2.85.0

3.2

R4329

AMP

Q4308

KTC3875S_Y_RTK

8.7

R4326

4.6

1K

4.0

C4345

10 C

C4336

100P CH

0.1

0

MUTE_SW

Q4307

KTC3875S_Y_RTK

3.3

456

R4305

100

R4334

3.3K

C4338

68

0.1 B

220

R4331

R4337

R4335

C4339 10 C

1K

R4336

R4340

2.2K

3.3K

B4309

FCM1608CF-600T06

100K

430K

R4341

4.7

1.3

0.7

R4342

68K

C6553

R4343 75

R4347 75

R4346 75

R4344

2.2K

AMP

8.2K Q4310

KTC3875S_Y_RTK

R4345 1K

C4346

1K

C4341

100P CH

0.1

0

2206.3V V-S

NC

NC NC

NC

C4342

4.6

10 C

MUTE_SW

Q4311 KTC3875 S_Y_RTK

CH

100P

C6554_1

4.7 F

VGA-R VGA-G VGA-B

NC DGND AGND AGND AGND

NC DGND

NC DDCD

VGAHS VGAVS

DDCC

AMP Q4312 KTC3875S_Y_RTK

8.7

4.0

1K

R4348

B6551

HCB1608KF-121T20

DB15ds

CP4303

1B630020

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15

560

R4350

C4343 10 C

C4344 10 C

R4349

FROM REGULATOR2

D3.3V GND

FROM MICON

START_SW EXT_MUTE-H

TO AV SWITCH2

SW_L SW_R

AV1_Y AV1_C

DVD_L DVD_R

DVD_Y DVD_C

FROM/TO SCALER VIDEO/AUDIO

PC_V PC_H

S1_DET

AV1_CVBS AV2_CVBS VGA-R VGA-G VGA-B AV3/AV4_Y AV3/AV4_PB AV3/AV4_PR

TWIRE_RXDC TWIRE_TXDC

DVD-H ROUT_FI

LOUT_FI ASW2 ASW1

SPDIF

FROM MICON

DVD_RESET

AUDIO OUT

J4301

AV3-13P2-60S1

4

H1H1 H2

4

5

6

R4351

100K

560

R4352

EE

L

1

23

R

100K

FROM REGULATOR

D5.0V P.CON+9V

FROM/TO SURROUND

ZERO_MUTE

LOUT_SOUND ROUT_SOUND

POP_MUTE

GND

PCBDH0 CEG352

8

7

6

5

4

3

2

1

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

1

ABC D E F GH

H-16H-15

ABC D E F GH

LVDS SCHEMATIC DIAGRAM

8

SCALER IC IC2801

7

C2865

2210V V-S

B2806

HCB1608KF-221T20

B2807

HCB1608KF-221T20

B2808

HCB1608KF-221T20

B2809

HCB1608KF-221T20

C2869

C2974

474V V-S

C2875

474V V-S

0.1 B

C2881

C2877

FROM REGULATOR2

D3.3V

6

GND

D1.0V

5

1K

R2835

5.6K

C2868

B2804

4

GND

HCB1608KF-221T20

B2805

HCB1608KF-221T20

B2803

HCB1608KF-221T20

C2866

C2867

R2836

0.01 B

2210V V-S

C2871

474V V-S

C2872

2210V V-S

C2879

C2876

0.1 B

R8J66954BG

3.3

C15

PLLAVCC_1

3.3

A17

PLLAVCC_2

1016V V-S

C2975

0

D14

PLLAVSS

0

A18

PLLAVSS

1.0

E13

PLLDVDD_1

1.0

B17

PLLDVDD_2

0.1 B 0

E14

PLLDVSS

0

D15

PLLDVSS

1.6

E18

LPFP

2.7

D18

REFR

0

D17

VSS33BIAS

3.3

F17

VCC33BIAS

3.3

E17

VCC33LVDS

3.3

F18

VCC33LVDS

0

E16

VSS33LVDS

0

G17

VSS33LVDS

1.0

H17

VCC10LVDS

0

J17

VSS10LVDS

LVDS POWER/REF PLL POWER

(DIGITAL PCB)

LVDS0OUT0M LVDS0OUT0P

LVDS0OUT1M LVDS0OUT1P

LVDS0OUT2M LVDS0OUT2P

LVDS_CH0

LVDS0CLKOUTM LVDS0CLKOUTP

LVDS0OUT3M LVDS0OUT3P LVDS0OUT4M LVDS0OUT4P

LVDS1OUT0M LVDS1OUT0P LVDS1OUT1M LVDS1OUT1P LVDS1OUT2M LVDS1OUT2P

LVDS_CH1

LVDS1CLKOUTM LVDS1CLKOUTP

LVDS1OUT3M LVDS1OUT3P LVDS1OUT4M LVDS1OUT4P

RSDSA RSDSB

TO PANEL

CP2804

A2006WR0-2X15P-HK

VDD+3.3V/NC/GND

C2801

100P CH

1.5

E19

1.5

F19

1.5

E20

1.5

E21

1.5

F20

1.5

F21

1.5

G18

1.5

G19

1.5

G20

1.5

G21 H20

NC

H21

NC

A19

NC

B19

NC

A20

NC

A21

NC

B20

NC

B21

NC

C19

NC

D19

NC

C20

NC

C21

NC

D20

NC

D21

NC

H18

NC

H19

NC

NR2811

CRA108220JV

NR2810

CRA108220JV

R2800

22

R2830

22

C2800

LCD_TXOUT0LCD_TXOUT0+

LCD_TXOUT1LCD_TXOUT1+

LCD_TXOUT2LCD_TXOUT2+

LCD_TXCLKOUTLCD_TXCLKOUT+

LCD_TXOUT3LCD_TXOUT3+

W854

W849

B2800

HCB1608KF-181T20

22016V V-S

NC

VDD+3.3V/NC/GND

VDD+5V/12V/GND

VDD+5V/12V VDD+5V/12V VDD+5V/12V VDD+5V/12V

GND

GND RXIN0RXIN0+

GND RXIN1RXIN1+

GND RXIN2RXIN2+

GND

RXCLK INRXCLK IN+

GND RXIN3RXIN3+

GND

NC / GND

GND

30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10

9 8 7 6 5 4 3 2 1

LCD PANEL

V2301_1

V260B1-L01

CD2804 CURU1704

3

8

7

6

5

4

3

VDD_PANEL

2

PCBDH0 CEG352

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

2

1

ABC D E F GH

H-18H-17

ABC D E F GH

MICON SCHEMATIC DIAGRAM

8

(DIGITAL PCB)

KEY_A

TO REGULATOR2

1V_CTL

TO JACK3

KEY_B

EXT_MUTE-H

7

3.4 3.3

6

FROM OPERATION/REMOCON

CP6202

(CP2203_1)

A2001WR2-3P

5

KEY_B KEY_A

C6201 47P CH

C6202 47P CH

R6202

100

R6201

100

D6201

D6202

UDZSNP5.6B

GND KEY B KEY A

1 2 3

4

3

2

ROM WRITER

SUB MICON CP6201 A2001WV-11A

1

GND

2

TX

3

BUSY

4

NC

5

VCC

6

CLK

7

RX

8

NC

9

RESET

10

GND

11

GND

(MODE)

(CNVSS)

FLASH_WRITE_TXD

MODE

NC

AT+5V

CNVSS

FLASH_WRITE_RXD

NC

RESET

R6203

2206.3V V-S

C6205

10K

C6206

RESET IC

IC6201 PST3229NR

0.01 B

NC NC

00

45

NC

OUT

123

R6204

NC

GND

IN

3.43.4

0

D6205

BAT54WS

10K

C6209

2.2 B

R6205

33K

R6206

4.7K

R6210

4.7K

R6209

4.7K

R6211

100

R6212 100

SUB MICON IC IC6202

R6213

R6214

0.5

3.4

2.9

3.4

R5F21124FP

4.7K

R6215

2.2K

2526272829

303132

0

B

C6210

0.1

2.8 2.5 3.4 0 3.4 3.4 3.4

KEY_B

1

4.7K

R6217

IIC_OFF

KEY_A25 32 MAIN_MICON_TXD 17 HDMI_CEC 16 POWER_FAIL

DISC_IN_DET9

REMOCON_IN8

1 MAIN_MICON_RXD

RESET

CNVSS IVCC

3

3.1

4.7K

B

C6212

1

DTV_RESET

1V_CTL

MODE

EXT_MUTE

AUDIO_MUTE

DVD_RESET

0.5 0 3.4

R6216

4.7K

R6219

2.2K

S

D

G

Q6201

2SK3019_TL

3.4

R6220

100

NC NC

17181922021222324

AVSS

VREF

SUR_SW

ASEMD0

3.3V_POWER_H STBY-H

DVD_POWER

SYS_POWER_H

EEPROM_SDA

EEPROM_SCL

VSS

XOUT

XIN

X6201

C6215

VCC

7

16MHz

100GT01615

20P CH

B

C6216

0.01

R6221

45678

0 2.8 3.4 3.3

18P CH

C6213

0.5 3.3

D

G

2SK3019_TL

3.4

100

R6222

3.2

3.4

3.3

NC

3.3

3.4

10 11 12 13 14 15 16

0

9

27K

S

Q6202

R6231

4.7K

R6223 100

R6228

4.7K

R6225

4.7K

C6218

0.1 B

R6226

100

R6227

100

R6224

4.7K

FROM/TO SCALER VIDEO/AUDIO

MCU_SCITXD MCU_SCIRXD

I2C_DATA I2C_CLK

TO SURROUND

AUDIO_MUTE

FROM/TO FLASH

IIC_OFF

RESET_N

ASEMD0

FROM/TO JACK3

DVD_RESET

START_SW

FROM/TO REGULATOR2

STBY-H POWER_FAIL

3.3V_POWER_H

SYS_POWER_H

AT+5V AT+3.3V

KEY_A KEY_B

IR_REMO

GND

8

7

6

5

4

3

2

PCBDH0 CEG352

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ABC D E F GH

H-19 H-20

1

ABC D E F GH

SCALER POWER SCHEMATIC DIAGRAM

8

7

FROM REGULATOR2

D3.3V

6

D1.0V

5

4

B2810

HCB1608KF-221T20

W813

HCB1608KF-221T20

C2882

B2811

2210V V-S

C2883

1004V V-S

C2884 1 B

C2887

C2890

1B

0.1 B

1B

C2894

C2898

C2885 0.1 B

0.1 B

C2900

C2896 1 B

2210V V-S

C2891

C2901

0.1 B

3.4 E5

VCCQ33

3.4

E6

VCCQ33

3.4

E11

VCCQ33

3.4

U5

VCCQ33

3.4

U8

VCCQ33

1.0

E7

VDD

1.0

E9

VDD

1.0

E15

VDD

1.0

J9

VDD

1.0

J10

VDD

1.0

J11

VDD

1.0

J12

VDD

1.0

J13

VDD

1.0

K9

VDD

1.0

K13

VDD

1.0

L9

VDD

1.0

L13

VDD

1.0

M9

VDD

1.0

M13

VDD

1.0

N9

VDD

1.0

N10

VDD

1.0

N11

VDD

1.0

N12

VDD

1.0

N13

VDD

1.0

T5

VDD

1.0

U6

VDD

1.0

U9

VDD

3.3

M4

DVDDABC

0

M5

DVSSABC

0

E8

0

E10

0

E12

0

K10

0

K11

0

K12

0

L10

0

L11

0

L12

0

M10

0

M11

0

M12

0

U7

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

IC2801 R8J66954BGSCALER IC

Io_Power

Core_Power

GND

(DIGITAL PCB)

AVDDA AVDDB AVDDC

ADVSS ADVSS

ADVSS

A3.3V

D3.3V

D1.8V

PLLVDD

PLLVSS DLLVDD

DLLVSS

VCC33AD_A

VSS33AD_A VCC33DA_A

VSS33DA_A

VDD33 VDD33

VSS33 VSS33

VDD33ADDA

VSS33ADDA

VDD18 VDD18

VSS18 VSS18

TO SCALER VIDEO/AUDIO

AD_A3.3V

3.3

J4

3.3

K4

3.3

L4

C2903

C2906

C2907

C2908

C2909

0.1 B

B

0.1

B

0.1

0.1 B

C2920

0.1 B

C2921

0.1BC2922

0.1 B

C2910

C2911

C2912

C2913

C2904

C2923

2210V V-S

0.1 B

1B

C2924

C2902

0

F5

0

G5

0

H4

0

J5

0

L5

3.3

P4

0

N5

3.3

T4

0

P5

3.3

V3

0

W1

3.3

Y4

0

Y3

3.3

J3

3.3

U4

C2917

0

H5

0

R5

3.3

V2

C2918

0

U3

1.8

K3

1.8

T3

C2919

0

K5

0

R4

HCB1608KF-121T20

B

C2905

0.1

HCB1608KF-121T20

2210V V-S

HCB1608KF-121T20

2210V V-S

B2813

3306.3V V-S

B2814

B2815

B2816

B2817

B2820

B2821

B2822

C2914

3306.3V V-S

D3.3V

FROM HDMI

VDD33

3

8

7

6

5

4

3

GND

D1.8V

GND

2

PCBDH0 CEG352

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ABC D E F GH

H-21 H-22

2

1

ABC D E F GH

SURROUND SCHEMATIC DIAGRAM

8

FROM SCALER VIDEO/AUDIO

DVD-H

D3401

R3405

10K

MA111

R3412

10K

R3413

R3414

10K

7

6

5

FROM REGULATOR2

D3.3V AT+5V

FROM JACK3

ZERO_MUTE LOUT_SOUND

FROM FLASH

A_MUTE

FROM MICON

AUDIO_MUTE

FROM REGULATOR2

GND

MUTE_SW

Q3402

KRA101SRTK

3.3

0

R3406

10K

R3437

(DIGITAL PCB)

5.0

KTC3875S_Y_RTK

MUTE SW

Q3405

1B

C3408

0

MUTE SW

0

4.7K

KTC3875S_Y_RTK

0

Q3406

0

5.0

0

MUTE_SW Q3404

5.0

0

R3422

560

MUTE_SW

Q3409

KRA101SRTK

5.0

C3413

TO JACK3

MUTE SW

Q3411

4.5

0

Q3410

4.5

0

ROUT_SOUND

0

POP_MUTE

D3405

MA111

D3406

MA111

R3428

1K

KTC3875S_Y_RTK

R3427

1K

MUTE SW

KTC3875S_Y_RTK

0

10 C

8

7

6

5

1B

R3425

1K

R3426

1K

4

3

2

8.7

3.8

R3436

C3415

1B

C3416

4.7K

P.CON+9V

4

FROM SCALER VIDEO/AUDIO

3

LOUT_FI

ROUT_FI

L3401

330uHNLCV32T

C3401

10 C

C3417

22016V V-S

C3402 10 C

C3420

BUFFER

R3431

6.8K

Q3403

180K

KTC3875S_Y_RTK

68K

6.3

2.3

1.7

R3416

4.7K

R3417

R3418

R3401

R3407

R3408

100

R3402

22016V V-S

BUFFER

Q3408

180K

KTC3875S_Y_RTK

68K

R3432

6.8K

6.3

2.3

1.7

R3420

4.7K

C3418

1B

R3403

R3404

180K

220K

AMP

Q3401

KTC3875S_Y_RTK

4.4

8.7

R3433

R3434

3.8 C3419

1B

4.7K

R3435

Q3412

180K

KTC3875S_Y_RTK

220K

AMP

4.4

2

PCBDH0 CEG352

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION: DIGITAL TRANSISTOR

ABC D E F GH

H-23 H-24

1

ABC D E F GH

TUNER SCHEMATIC DIAGRAM

8

7

TU5801 ENG36E19KF

NC(BB)

NC

1

2

3

22 23

0

NC

4

0

NC

2.6NC0.2

SIF-out 5

2.0

C5803

AGC 7

NC

SDA

+5V

V_OUT

9

8

5.0

1.5

B5808

FCM1608K

F-102T02

C5856

2206.3V V-S

1.0

0.1 B C5805

0.1 B

+30V

TU 11

12

NC

31.5

C5806

SCL

14

15

3.3

0.1 B

(DIGITAL PCB)

IF_OUT

AFT

+5V

18

16

17

0

NC

5.0

B5809

FCM1608K

F-102T02

C5857

0.1 B

0.9

2.6

IF_AGC 19

IF_O

IF_OUT1 20

0.2

IF_OUT2 21

0.4

W878

TO SCALER VIDEO/AUDIO

24 25

8

L5801

22uHNLV25

C5814

33P CH

TU_CVBS

8

7

C5801

2206.3V V-S

6

5

FROM REGULATOR2

D3.3V

D5.0V

TUNER+30V

GND

IF_AGC

4

TU_I2C_CLK

TU_I2C_DATA

3

FCM1608KF-102T02

40

SIF_OUT

C5820

0.33 B

C5821

47P CH

C5822

47P CH

B5802

R5801

R5802

R5807

150K

47K

100K

100

R5803

R5804

TU_I2C_DATA

TU_I2C_CLK

100

IF_OUT_1

IF_OUT_2

TU_AFT

IF_AGC

R5817

3.3K

R5818

R5819

100

R5820

100

3.3K

C5844

0.01

C5845

0.01 B

R5821

47

1.6 ADIN1

AA1

B

L5805

C5846

0.22uHLQW18AN

R5822

47

56P CH

NEAR IC2401

C5847

R5823

1K

0.1 B

R5824

R5825

47K

C5852 0.1 B

1.6

Y1

ADIN0

1.8

W2

47K

C5855 0.1 B

C5853 0.1 B

ADVREF0

1.6

Y2

ADVREF1

1.6

AA2

ADVREF2

3.3

AA7

IF_AGC

2.8

AA5

3.3 SICL0

Y9

3.3

AA9

MCUADIN0

SIDA0

IC2801 R8J66954BGSCALER IC

VSB_ADC

TUNER_IF

MCU_ADC

IIC0

6

5

4

3

B5804

FCM1608KF-151T06

4.7K

R5808

R5809

2

1

FROM/TO SCALER VIDEO/AUDIO

I2C_DATA

I2C_CLK

D3.3V

TO AV SWITCH2

TU_AUDIO_R TU_AUDIO_L

S

D

BUFFER

G

2SK3019_TL

Q5801

S

D

BUFFER

G

Q5802

2SK3019_TL

SIF_OUT

C5817

0.001 B

C5819 2206.3V V-S

C5823 0.33 B C5818 0.22 B C5824 0.1 B

C5825 4.7 B C5826 2.2 B R5810 100

R5811 180K R5812 100

C5827 2.2 B

C5830 2.2 B

R5813

3.3K

BTSC DEMODULATOR IC

IC5801 AN5832SA-E1V

3.5

PILOT DET

171819

3.5 0

VCC NC

20212223242526272829

INPUT SIF REF STEREO REF SDA/SAPID GND PE

ROUT LOUT

303132

NC L-R RBF

NOISE DET

NC

2.2

3.3

2.2

5.0

0

NC

5.0

1.7

2.2

NC

1.3

L+R REFPLL

SAP DET

SIF/BB

MUTE FOMO MODE

AGC SW

IIC/PARA

SPE FILSCL/STID SPE DELAGC DET

SPE TIME

WB DET

WB TIME

NC

C5833 2.2 B

2.2 C5834 0.033 B

2.8 C5835 0.1 B

2.9

NC NC NC NC

8 9

NC

5.0 C5837 0.022

2.4 C5838 0.1 B

2.4 C5839 3.3

0.5

4567

C5840 0.33

2.9

3

C5841 10

0.5

2 1 10 11 12 13 14 15 16

NC

B

B B C

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

CAUTION

ATTENTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

ARE

PCBDH0 CEG352

ABC D E F GH

H-25 H-26

2

1

ABC D E F GH

SCALER VIDEO/AUDIO SCHEMATIC DIAGRAM

8

FROM/TO JACK3

PC_V PC_H

AV3/AV4_Y

AV1_CVBS

7

VGA-G

AV3/AV4_PB

VGA-B

AV3/AV4_PR

VGA-R

S1_DET

SPDIF

6

FROM TUNER

TU_CVBS

TO HDMI

HP_RST

PC_V PC_H

SW_Y_IN

TU_CVBS AV1_CVBS

AV3/AV4_Y

SW_C_IN

AV2_CVBS

VGA-G

AV3/AV4_PB

VGA-B

AV3/AV4_PR

C2927

0.1 B

C2925

0.1 B

C2928

0.1 B

C2937

0.1 B

C2938

0.1 B

C2931

0.1 B

C2932

0.1 B

C2933

0.1 B C2934

0.1 B

C2935

0.1 B

C2936

0.1 B

5

FROM SCALER POWER

AD_A3.3V

FROM/TO AV SWITCH2

SW_Y_IN SW_C_IN

MCLK

SDOUT

4

LRCK BCLK

VGA-R

C2926

0.1 B

C2929

0.1 B

3.2 J1

PCVIN

3.2 K1

C2946

9

0.1 B

C2939

0.1 B

11

C2940

0.1 B

12

C2941

0.1 B 10

C2942

0.1 B

C2943

0.1 B

13

C2944

0.1 B

C2945

0.1 B C2947

0.1 B R2837

1K

SSIN1

3.2 K2

SSIN2

1.7 L1

VIN3A

2.6 L2

VIN1A

1.3

VIN2A

L3

0

VREFA

M1

1.9

VIN4A

M2

1.6

VRPA

M3

2.0

VIN2B

N1

3.3

VIN6A

N2

0.9

VIN5A

N3

3.2

VRMA

N4

1.6

VRPB

P1

1.6

VREFB

P2

1.9

VIN3B

P3

1.6

VREFC

R1

1.3 R2

VRMB

2.7 R3

VIN4B

1.6

VRPC

T1

1.6

T2

14

3.3

VRMC

U1

3.3 U2

3.3 V1

3

2

2210V V-S

0.1 B

C2948

C2949

C2950

(DIGITAL PCB)

IC2801 R8J66954BGSCALER IC

VIN2C

VIN3C LPF

ROUT

DAC_VREF

W3

AA3

1.7

1.6

R2838

R2839

C2951

0.001 B

ROUT

LOUT

AA4V4W4Y5V5W5W6Y6AA6V6Y7

0

1.7

4.7K

R2840

LOUT

0

3.3

10K

R2842

S1_DET

R2841

10K

SPDIFO

3.3

10K

SPDIF

3.3

MCLK

ACLK

ADATAO

3.3

SDOUT

LRCKO

3.5

LRCK

BCKO

3.4

BCLK

3.3

W881

DVD-H

SANT

RFAGC(GPIO)

3.3

HP_RST

SICL

SCLK0(GPIO) SRXD0(GPIO) STXD0(GPIO)

QBLCA

QBLCB(GPIO) QBLCC(RXD0)

SCIRXD

SCISCK(GPIO)

3.3

V9

3.3

W9

10K

R2856

I2C_CLK

I2C_DATA

10K

R2857

10K

C2965

0.1 B

R2860

4.7K

R2850

4.7K

Vcc

SCL

WP

R2853

C2959

0.1 B

3.4 0

3.4

5678

3.3

AA8

3.3

Y8

3.3

ASW2 ASW2

W8

BL_PWM

R2847

R2846

4.7K

0

1234

A0

0

A1

0

A2

0

Vss SDA

M24256-BWMN6TP

10K

EEP_ROM IC

IC2805

3.3

J21 J20

3.3

J19

3.3

J18

3.3

V8

3.3

V7

3.3

W7

C2968

0.1 B

R2862

4.7K

ROUT LOUT

I2C_CLK

I2C_DATA

ASW0

ASW1

VDIM

LCD-H TWIRE_RXDC TWIRE_TXDC

MCU_SCIRXD MCU_SCITXD

IIC_OFF

W889

W890

TO SURROUND

LOUT_FI

ROUT_FI

FROM/TO JACK3

LOUT_FI ROUT_FI

AV2_CVBS ASW2

ASW1 TWIRE_RXDC TWIRE_TXDC

FROM/TO FLASH

IIC_OFF

I2C_CLK

I2C_DATA

TO AV SWITCH2

ASW0

DVD-H

FROM/TO MICON

MCU_SCIRXD

MCU_SCITXD

TO REGULATOR2

LCD-H

VDIM

GND

D3.3V

GND

AT+3.3V

PCBDH0 CEG352

8

7

6

5

4

3

2

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ABC D E F GH

H-27 H-28

1

ABC D E F GH

AV SWITCH2 SCHEMATIC DIAGRAM

8

Lch SW IC

1016V V-S

C6563

1B

P.CON+9V

L6551

22uHNLCV32T

C6564

7

DIF

PDN

SCLK

MCLK

LRCK

15

16

4.7K

R6566

4.7K

R6567

4.7K

X6551

100DT01217

12.288MHz

34

100

R6569

NC 12

VCCOUT

W894

0

3.3

R6563

3.3

2.3

10 11 12 13 14 15 16

2.1

9

R6559

3.3K

R6558

3.3K

AUDIO_L DVD-H

AUDIO_R

C6562 10 C

C6561 10 C

6

4.7K

C6557 2.2 B

C6555 10 C C6556 0.1 B

5

RESET_N

SDOUT

4

LRCK

MCLK BCLK

NR6551

CRA108470JV

C6559 10 C C6560 0.1 B

R6560

B6552

FCM1608KF-102T02

B6553

FCM1608KF-102T02

R6561

2.7K

AUDIO_ADC IC IC6551 AK5358A

2.6

1

AINR

2.6

2345678

AINL

5.1 CKS1

2.5 VCOM

0

AGND

5.1

VA

3.3

VD

0

DGND SDTO

R6562

2.7K

CKS0

CKS2

IC6552 NJM2534V

0

9.3

4.9

5678

C6565 10 B

Rch SW IC IC6553 NJM2534V

0

4.0

9.3

4.9

5678

(DIGITAL PCB)

BUFFER

BAIAS

BUFFER

BAIAS

C6566

10 B

R6572

100

4.3

1234

3.34.0 C6567

4.8 10 B

3.2

R6573

100

1234

C6568

4.8 10 B

3.2

B6556

HCB1608KF-181T20

C6569

1B

R6578

C6570

10 B

10K

C6571 10 B

SW_L

ASW0

TU_AUDIO_L

D3.3V

DVD_L

SW_R

TU_AUDIO_R

DVD_R

Y SW IC

IC6554 MM1501XNRE

0/3.3

123

L

BUFFER

4.5 0

5.0

C6572 1B

H

VCC

C6574

4.5 10 B

4.5

456

C6575

10 B

SW_Y_IN

AV1_Y

DVD_Y

DVD-H

FROM/TO SCALER VIDEO/AUDIO

LRCK SDOUT

BCLK MCLK

ASW0 SW_Y_IN SW_C_IN

DVD-H

FROM TUNER

TU_AUDIO_L TU_AUDIO_R

FROM JACK3

AV1_Y AV1_C

SW_L SW_R

DVD_Y DVD_C DVD_L DVD_R

8

7

6

5

4

C SW IC

IC6555 MM1501XNRE

0/3.3

123

BUFFER

3

4.5 0

5.0

VCC

C6573

1B

4.5

L

H

4.5

456

C6577 10 B

C6576

10 B

SW_C_IN

AV1_C

DVD_C

FROM MICON

RESET_N

FROM REGULATOR2

P.CON+9V D3.3V D5.0V

GND

2

PCBDH0 CEG352

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ABC D E F GH

H-29 H-30

3

2

1

ABC D E F GH

REGULATOR2 SCHEMATIC DIAGRAM

8

FROM/TO REGULATOR

CP3001

(CP401)

TWG-P23P-A1

TUNER+30V

1

POWER_FAIL

2

SYS_POWER_H

3

AT+3.3V

4

GND

5

P.CON+5V

7

6

AT+5V

7

AT+5V

8 9

10

LCD+B

11

LCD+B

12

LCD_H

13

P.CON+9V

14 15 16

STBY_H

17

SW+12V

18

REMOCON_IN

19

LIGHT_CTL

20

KEY_A

21

LIGHT_POWER_H

22

KEY_B

23

GND GND

C3003

100K

R3001

0.001 B

L3003

330uHNLCV32T

C3001_1

10P CH

NC

C3036

22016V V-S

C3009

5

4

0.001 B

TUNER+30V

POWER_FAIL

SYS_POWER_H

AT+3.3V

D5.0V AT+5V

VDD_PANEL

LCD-H

P.CON+9V

STBY-H

IR_REMO

VDIM KEY_A BLON

KEY_B

AT+5V

1V_CTL

GND

AT+5V

3.3V_POWER_H

W857 W858

R3010

1K

3

D3.3V

SH3001

2

YQ-12

SH3002

YQ-12

SH3003 YQ-12

SH3004

YQ-12

SH3005 YQ-12

(DIGITAL PCB)

L3001

22uH TSL0808

R3011

1K

R3014

3.3K

SW

Q3004

KRC103SRTK

SW Q3003 KRC103SRTK

4.5

0

VCC1.0V DC/DC

VDD CORE 1.05V IC

BD9130NV

IC3001

0.8

1234

5.3

0.2 0

10K

R3008

C3015

C3014

0.1 B

C3011

C3012

0

0.1 B

C3013

0.1 B

C3016

686.3V CD

R3019

0.01 B

R3009

4.7K +-1%

680P CH

13.9

4.5

1.2

1.3

CH

33K

C3017

27P

1.8V_REGULATOR IC PQ035ZN1HZPH

R3007

100

0.047 1/4W

IC3002

1234

IC3003

EN

ADJ

PVCC

VCC

SW

ITH

PGND

GND

R3022

R3020

VDD CORE 1.8V

AL1015

VIN

CS

V5/PWON

EXT

Vref/SS

GND

CC

5678

FB

V_IN V_OUT V_ADJ GND

VB

12 456

C3018

2.2 B

C3035

3.5

5.3

2.5

0

5678

C3024

for CORE

C3019

13.9

0.1

13.1 0

1.3

R3023

1K +-1%

1B

C3023

1016V V-S

R3016

1.5K +-1%

L3002

10uHTSL0808

10 C

C3026

C3027

456

G

DC DC FET

IC3004 TPC6108

1.9 3.33.3

B

R3024

+-1%

1.5K

01.33.3 1.85.0

R3013

3.3K +-1%

R3015

6.8K +-1%

R3018

100

+-1%

10 C

DDDDS

123

R3025

220 +-1%

R3017

150

+-1%

3.33.35.3

10 C

C3029

VCC+3.3V DC/DC

B3004

D3004

10 C

C3031

C3032

L3004

22uH

SLF10145T

B3005

HCB1608KF-181T20

C3021

0.001 B

EC31QS04

L3005

22uH TSL0808

10 B

C3037

C3033

C3022

10 C

C3038

B3003

HCB1608KF-181T20

(SCALER:typ 1800mA)

W900

W901

686.3V CD

(DDR2:typ 1095mA)

3306.3V V-S

(typ 1.8A)

D1.0V

D3.3V

D1.8V

TO FLASH

D3.3V BLON GND

TO DDR2

D1.8V GND

TO HDMI

D3.3V GND

D5.0V

FROM/TO SCALER VIDEO/AUDIO

LCD-H AT+3.3V

VDIM GND

D3.3V

TO TUNER

TUNER+30V D3.3V D5.0V

TO SURROUND

P.CON+9V AT+5V D3.3V

TO LVDS

D3.3V D1.0V VDD_PANEL GND

TO MICON

SYS_POWER_H

3.3V_POWER_H AT+3.3V

STBY-H KEY_A KEY_B IR_REMO POWER_FAIL AT+5V D3.3V

1V_CTL GND

TO SCALER POWER

GND D3.3V D1.8V

D1.0V

TO AV SWITCH2

P.CON+9V D5.0V D3.3V

TO JACK3

GND D5.0V P.CON+9V

8

7

6

5

4

3

2

PCBDH0 CEG352

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

CAUTION: DIGITAL TRANSISTOR

ABC D E F GH

H-31 H-32

1

ABC D E F GH

POWER SCHEMATIC DIAGRAM

10

9

8

7

6

1

2

100025V ZL

2.4

0 NC

1.2

5.2

0

0 NC

5.0

R476

C462_1

C438_1

R446

10K

REFERENCE

123

R447

15 1/4W

D443

31DQ09-FC

D442

1H3-E

R443

1K

D413

MTZJ30B

10K

ZL 1000

16V

120035V ZL

W822

R444

R445 100

1/4W

D444

1F5-E

C440_1

2.2K

4.0 0 2.5

4.7K 1/4W

R467

R448

39K +-1%

R449

6.8K +-1%

R450

+-1%

3.9K

4750V MHE

C442_1

22006.3V ZL

C441_1

MTZJ15B

CATHODE

R451

1K

R477

75K +-1%

L413

10uH

TSL0808

2.250V YXF

R452

1K

D445

POWER FAIL SWITCH

KTA1504S_Y_RTK

REFERENCE

ANODE

123

C443

0.01 B

470 1/4W

W887 W840

R528

100 1/4W

C444

R458

10K

4.4

1/4W

Q416

REGULATOR IC

IC404

KIA431A-AT

R478

R522

47K 1/4W

L411 10uH

AT+34V

R523

100K

AT+5V

22006.3V YK

P_GND

5.2 47K

R460

5.2

R505

R454

R455

R456

18K +-1%

330

2.2K +-1%

SYS_POWER_H

SW+6V[UNREG]

SW+12V[UNREG]

POWER_FAIL

INV_SW+24V

AT+5V

P_GND

SOUND+B

SOUND_GND

P_GND

INV_SW+24V

INV_GND

FROM/TO POWER2

AT+5V INV_SW+24V SW+12V[UNREG] INV_GND SYS_POWER_H

P_GND

TO SOUND

SOUND_GND SOUND+B

FROM/TO REGULATOR

POWER_FAIL AT+34V SW+6V[UNREG]

SYS_POWER_H

8

7

6

5

4

3

2

D432_2

R437

2.2 1/4W

Q418 2SA1759_T100

180K

R548

180K

R540

34

6V

12V

GND

24V

S+B

S GND

20.5

1

19.4

2

SH406 YQ-12

11W

R541 180K

100K

10

11

12

13

14

15

16

R497

R436

68K

C430

0.00222KV R

D433

1H3-E

R542

180K

KTC3875S_Y_RTK

R543

180K

R544 220K

1050V

C483

YXF

1

2

POWER SW

IC406

PS2561AL1-1-V(W)

1

2

HS405

763WAA0365

2.2K 1/4W

1K

R435

1/2W

R494

ERC91-02

R438

Q424

R545

D435

C494_1

T402 81190084

166.0 1

0

2

NC

166.0 3

0

4

0

5

FEED BACK IC410

5.0

1.0

SSM3K302T (TE85L,F)

D

G

S

D416

100035V ZL

C433_1

2

C401

0.00152KV R

D437

FCH10A20

R503

470 1/2W C437_1

0.033100V MMTS

19.4

PS2561AL1-1-V(W)

34

R475

220 1/4W

SOFT SWITCH

Q412

SSM3K302T

C435_1

120035V ZL

C434_1

C439

220P B

REGULATOR IC

IC403

KIA431A-AT

CATHODE

ANODE

0

R441

15K

R546

10K

D

G Q425

S

220K

10K

R549

1K

R439

31DQ06-FC

1 3

D440

YG862C15R

R432

22

1W

1

2

3

4.750V MHE

8

J401

YKE31-0149N

BLACK

12

WHITE

7

6

5

4

3

6.3A125V 51MS063L

FH401

EYF-52BCY

6.3A 125V

C406

F401

0.0022250V KX

FH402

EYF-52BCY

R434

1.2

D404_1

SH402 YQ-12

1N5406FL-6737

7W

1N5406FL-6737

CP404

003P-2100

1

C402

ENE241D-10A-Q6

D405

390200V EE

C403_1

W834

D407

0.22275V ECQUL

SH410

YQ-12

1.2M 1W RCR60

R404

COIL,LINE FILTER

390200V EE

C404_1

12

34

L401

SS30V-R200132

R406

HS403

763WAA0367

C448

0.22275V ECQUL

C464

0.0022250V KX

POWER CONTROL IC

IC401

Q1-s

0

R410

820 1/4W

0.047 1W

NCNC

12

34

COIL,LINE FILTER

L402_1

SS11V-R22020-CH

(SMALL)

MP3A5038

S-GND

P-GND

0

C408

470P B

C409

0.1 R411

10K

C407_3

10035V

MHE

D415

1N4005-EIC

47200V PX

C455_1

C493_1

VCC SW

Q401

KTA1281_Y

R463

22K

10K 1/4W

D408

1SS133

R508

R417

R466

C405

R429

1M 1/4W RCR

D425

47K

R420

D427

D412

100K

R521

0.1 B

KTC3875S_Y_RTK

EC31QS04

MTZJ27B

Q2 DRIVE Q407

KTA1281_Y

165.6

MTZJ27B

2.2K 1/2W

MTZJ3.9B

D418

1N4005-EIC

R401

VCC SW

Q403

KRC102SRTK

R412

0.22

1W

5.002.5

C418

B

C412

R414

1B

VW

CON

1.3

B

0.1

10K

C414 0.0022 B

Vcc

VrefISFB

10 11 12 13 14 15 18 19 20 22 2345 78

19.0

B

0.001

C411

1.3

B404

W5RH3.5X5X1.0

Q2-g

Q1-d&Q2-s

165.6

165.5

R498

100 1/4W

Q2-d

323.0

R416

10 1/4W

323.0

2

(POWER PCB)

164.0 0 0

578 DSS

2.5

1.0

R433 270K

C428

4750V MHE

0.001 B

C426

0.1 B R506

100 1/4W

R469

PROTECT

10K

Q404

KTA1504S_Y_RTK

22K

Q405

D421

159.0

D426

R423

R421

R428

330 1/2W

R536

270 1/2W

1SS133

Q406

2SC2120Y

W889

C419

C423

0.082630V FGSM

R471

R431

10K 1/2W

W886

5.916.0

MTZJ3.3B

C495

2.2 B

W5RH3.5X5X1.0

75K

C475

IC402

MIP2F4

VddFBCLVcc

1234

SW REGULATOR CONTROL IC

C429

0.1 B

R472

0.0018 M

B401

R511

D410

D411

C431_1

2.2K

39K 1/2W

1SS133

D424

2.2 B

RL106F-E

1050V YXF

R531

220K

R532

220K

R538

R533

220K

R534

220K

R539

R535

220K

R537

220K

OVP PROTECT IC405

PS2561AL1-1-V(W)

T401 81400854

89

Vcc

7

GND

5

DC INPUT

4

NC NC

3

2

1

FEED BACK

IC408

PS2561AL1-1-V(W)

2.5 0

34

IS THE LIVE CONNECTIONCAUTION:

PCB240 CEG353

1

ATTENTION

6.3A 125V

CAUTION

:FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,

REPLACE ONLY WITH THE SAME TYPE FUSE

6.3A 125V(F401).

:POUR UNE PROTECTION CONTINUE LES RISQUES D’INCEIE

N’UTILISER QUE DES FUSIBLE DE MEME TYPE

6.3A 125V(F401).

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION

P_GND

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CAUTION: DIGITAL TRANSISTOR

ABC D E F GH

H-33 H-34

1

ABC D E F GH

POWER2 SCHEMATIC DIAGRAM

8

7

FROM/TO POWER INV_SW+24V

SW+12V[UNREG]

AT+5V P_GND

INV_GND

SYS_POWER_H

INV_GND

6

(POWER PCB)

LCD+B REG BLOCK

R486

R481

1K 1/4W

CP406 A2001WR-14A

2W

1K

R487

4.7K 1/4W

R473

C458_2

2W 1K

C456

0.01 B

Analog/Dimming

NC

W810

10 50V YXF

NC

PWM/Dimming

N.C(open)

+24V +24V +24V +24V +24V

GND GND GND GND GND

ON/OFF

1 2 3 4 5 6 7 8

9 10 11 12 13 14

14PIN

CD406_1 E82E1301

8

7

6

LIGHT_CTL LIGHT_POWER_H

LCD+B

PANEL_POWER_H

47016V MHE

C491_2

2206.3V YK

W814

L404

P.CON+5V

VIN VOUT G ON/OFF2.5V

12345

12.4 5.1 0 2.5 0

C453

100016V ZL

22uH

TSL0808

DC/DC(5V) IC

IC407

LA5779

D406

EC31QS04

R482

2.7K +-1%

R483

8.2K

+-1%

L408

47uH 1315

R484

820

+-1%

C461

W836

R485

47K

LCD+B SW

Q411

KRC102SRTK

0

3.2

0

10006.3V ZL

2A 125V

SW+12V[UNREG] LCD+B

5

P.CON+5V

P_GND

F404

20N_2000FS

2A 125V

R495 100

4

R480

2.2K

3

AT+5V

SYS_POWER_H

13.5

12.8

5.1

SW+12V REG

Q420

KTC3875S_Y_RTK

22K

R461

1050V MHE

C497_1

12.8

4.5

R470

12.4

EV+17V REG

Q422

KTB1151

13.5

SW+12V REG

4.5

KTC3875S_Y_RTK

560 1/4W

P.CON+5V SW

Q417

KTA1281_Y

5.2

4.4

R513

R464

P_GND

5.2

Q423

5.2

1/4W 47

Q408 KTC3875S_Y_RTK

1/4W

100

R491

R492

R493

+-1%

330

+-1%

2.7K

C446_1

2.2K +-1%

VDIM BLON

SW+12V

LCD-H

FROM/TO REGULATOR

P_GND SW+12V VDIM BLON AT+5V

P.CON+5V

LCD-H LCD+B

5

4

3

2

PCB240 CEG353

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CAUTION: DIGITAL TRANSISTOR

ABC D E F GH

H-35 H-36

2

1

ABC D E F GH

REGULATOR SCHEMATIC DIAGRAM

8

AT+5V

FROM/TO POWER2

7

6

SW+12V

P.CON+5V

FROM/TO POWER

SW+6V[UNREG]

POWER_FAIL

AT+34V

SYS_POWER_H

VDIM BLON GND

AT+5V LCD-H LCD+B P_GND

P_GND

D401

C425

MTZJ33B

TU+32V SW

Q409

AT+34V TUNER+30V

P.CON+5V P_GND

KTA1504S_Y_RTK

R496

36.3

22K

R501

0

R502

36.936.9

1.5K 1/4W

22K 1/4W

P.CON SW

Q410

KRC102SRTK

9.0

9V REG. IC

IC409 KIA7809API

R430

1K

4.7 B

OUT

IC411

S-1170B33UC-OTSTFG

123

ON/OFF GND

IN

45

NC

C436

4.7 B

AT+3.3V

5

OUTGNDIN

SW+12V P.CON+9V

123

(POWER PCB)

P.CON+5V

SW+12V

W806

W805

P_GND

W823

SW+6V[UNREG]

SYS_POWER_H

C463

68016V ZL

C466

W881

IC413

LV5795-TE-L-E

1234

BOOTFBSS

R422

2.7K +-1%

R465

3.9K +-1%

R490 1K 1/4W

C487

FROM/TO AUDIO/VIDEO

0.1 B

C489

0.1 B

C490

C488

0.1 B

C498

W839

100P B

V_IN

EN

C478

R409

3.6K

C480

C481

0.1 B

0.015 B

C479

22 B

W842

0.0047 B

R418

4.7K +-1%

SW

51

R407

C468

10 B

C470

0.022 B

D417

EC31QS04

456

DDS

R405

G

8.2K

R408

6.8K Q421

KRC101S-RTK

COMP

C476

L403

RTQ035P02

0.33 B

5678

C477

22 B

GND

C472

0.001 B

22uH1315

IC412

DD 123

C471

CP403 A2001WR2-8P

GND(M)

P.CON+6V

P.CON+A5V

GND

P.CON+12V P.CON+3.3V P.CON+3.3V

GND

SYS_POWER_H

(CP8502)

8 7 6 5 4 3 2 1

GND

FROM/TO JACK

FROM/TO JACK2

STBY-H

IR_REMO

AT+5V GND

FROM/TO SOUND

GND

TO AV SWITCH

P.CON+9V GND

8

7

6

5

10025V YK

C500_1

4

P_GND

3

2

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

1

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

10016V YK

SH407

C502_1

SH404

YQ-12

THE RESISTOR MARKED F IS FUSE RESISTOR.NOTE: THE ALUMI ELECTROLYTIC CAPACITOR MARKED NP IS NON POLAR ONE.

YQ-12

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CAUTION

FROM/TO REGULATOR2

(CP3001)

CP401 127301123K2

1

TUNER+30V

2

POWER_FAIL

3

SYS_POWER_H

4

AT+3.3V

5

GND

6

P.CON+5V

7

AT+5V

8

AT+5V

9

GND

10

GND

11

LCD+B

12

LCD+B

13

LCD_H

14

P.CON+9V

15

GND

16

GND

17

STBY_H

18

SW+12V

19

REMOCON_IN

20

LIGHT_CTL

KEY_A

21

LIGHT_POWER_H

22

KEY_B

23

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

NC

ARE

C454

C452

0.001 B

CAUTION: DIGITAL TRANSISTOR

TUNER+30V

POWER_FAIL

SYS_POWER_H

AT+3.3V

P.CON+5V

AT+5V

P_GND

LCD+B LCD-H

P.CON+9V

STBY-H SW+12V

IR_REMO

VDIM

BLON

PCB240 CEG353

4

3

2

1

ABC D E F GH

H-37 H-38

ABC D E F GH

AV SWITCH SCHEMATIC DIAGRAM

8

(POWER PCB)

8

7

P.CON+9V

IC6502 NJM2750M(TE1)

C6512

1B

0

4.8 OUTa

9.6

4.8

4.8 Vref

4.8 OUTb

0

NC

10 11 12 13 14 15 16

4.8

9

AV_SW IC

IN1a

GND

CNT1

IN2a

Vcc

IN3a CNTT2

IN4a

IN1b

IN2b

NC

IN4bIN3b

FROM JACK

4.8

1

3.2

2

4.8

345678

NC

3.2

4.8

4.8 NC

4.8

ASW2

DVI_A_IN_L

DVI_A_IN_R

AL1

AL2

AR2

FROM/TO JACK2

FROM REGULATOR

(A_GND)

AL1 AR1

AL2 AR2 DVI_A_IN_L DVI_A_IN_R AV3_Y AV3_PB AV3_PR

ASW2 ASW1 SW_L SW_R AV3/AV4_Y AV3/AV4_PB AV3/AV4_PR

P.CON+9V

GND

R6511

R6510

1K

C6509_1

1K

4716V YK

C6513_1

4716V YK

6

AV3_PR

W885

AV3/AV4_PR

AV3_PB AV3/AV4_PB

5

AV3_Y AV3/AV4_Y

W884

W883

SW_L ASW1

SW_R AR1

4

7

6

5

4

3

2

PCB240 CEG353

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ABC D E F GH

H-39 H-40

3

2

1

ABC D E F GH

SOUND SCHEMATIC DIAGRAM

SP302

S0412F06

SP301

S0412F06

8

7

6

5

8

7

CH1

FROM JACK2

ROUT_SOUND

LOUT_SOUND

FILTER_MUTE

POP_MUTE

C307

1B

NC

1 10111223456789

0.2 16.0 0 0.2 0.7 0 16.5

NC

C341

1B

6

FROM REGULATOR

(A_GND)

GND

SOUND+B

W819

5

SOUND_GND

P_GND

P.CON+5V

R303

3.3K

R305

10K

0

STANDBY SW

5.0 Q307

KRC103SRTK

3.3

(POWER PCB)

SOUND AMP IC

IC302 AN17808B

+

RIPPLE FILTER

GND

RF

C342

0.0047 B

10025V MHE

C343_1

+

ATT.CONT.

CH2 CH1

MUTE

NC

OUT

3.7

NC

0.0047 B

150V MHE

C345_1

W867

CH2

+ATT.

ININ

C344

+

-

STAND

VCCGND

-BY OUT

3.3

0.70

C346_2

C348_1

100035V ZL

10016V MHE

R334

3.9K

R335

4.7K

R336

C349_1

100025V MHE

R337

3.9K

25V MHE

4.7K

C350_1

1000

HS92 HS302 763WAA0368

W828

W829

C357

C358

17

0.1 B

W826

0.1 B 18

C359_2

1

F

CP302 A2502WR-4A

SP OUT L

GND GND

SP OUT R

CD301 E8144301

1

4

2

3

2

4

1

SPEAKER

(R)

4

3

2

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

1

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CAUTION: DIGITAL TRANSISTOR

PCB240 CEG353

4

3

2

1

ABC D E F GH

H-41 H-42

ABC D E F GH

JACK SCHEMATIC DIAGRAM

8

HDMI AUDIO IN

J4201

MSJ-2000B_AG(O87)

7

1 3

R

2

L

R4208

R4207

1K

C4207

R4212

C4205

47K

22P CH

47K

R4214

C4208 1B

C4209 1B

19

DVI_A_IN_L

20

DVI_A_IN_R

AV2_CVBS

AR2

AL2

6

AV1_CVBS

AR1

AL1

5

(POWER PCB)

D4210

D4207

UDZSNP12B

D4209

UDZSNP12B

D4211

UDZSNP12B

D4212

UDZSNP12B

D4213

C4220

1B

C4221

1B

C4222

1B

C4223

1B

UDZSNP12B

C4224

22P CH

C4225

R4240

CH

22P

R4241

C4227

47K

100 1/4W

22P CH

R4248

R4236

100 1/4W

CH

C4228

22P

R4239

R4252

FROM/TO REGULATOR

GND

(A_GND)

CVBS_IN_2

J4205

RCA-349-00C-02

V2 L2

R4271

R2

1K

R4269

1K

75

R4272

1K

R4270

1K

R4277

R4278

V1 L1 R1

75

47K

2345

NC H1 H2 H3

CVBS_IN_1

J4206

RCA-349-00C-02

2345

NC H1 H2 H3

1

E

1

E

TO AV SWITCH

DVI_A_IN_L DVI_A_IN_R AR2 AL2

AR1 AL1 AV3_Y AV3_PB AV3_PR

TO JACK2

S1_DET AV2_CVBS AV1_CVBS

AV1_Y AV1_C

8

7

6

5

COMPONENT_VIDEO_IN_1

J4203

R4275

AV3-13P2-31S1

H1H1 H2

Y1

RB1 PR1

75

5

23

4

EE

1

4

3

2

PCB240 CEG353

S-VIDEO IN

4

J4202

DIN-409B

R4203

1K

R4216

100

R4215

AV1_Y

S1_DET

AV1_C

100

YC

34

12

567

75

R4201

R4202

75

AV3_Y

AV3_PB

AV3_PR

R4224 100 1/4W

R4221 100 1/4W

R4219 100 1/4W

R4267

75

R4273

3

2

1

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

ABC D E F GH

H-43 H-44

1

ABC D E F GH

JACK2 SCHEMATIC DIAGRAM

8

7

6

5

D4214

IR_REMO

AT+5V

4

P.CON+5V

STBY-H

P_GND

5.0 5.0

5.0

1SS133

0

KRA103SRTK

0

LED SW Q4211 KRC102SRTK

0

LED SW

Q4212

R4279

470

R4280

330

R4283

470

(POWER PCB)

FROM/TO OPERATION/REMOCON

CP4201

(CP2201)

A2001WR2-5P

REMOCON IN

STANDBY LED

POWER ON LED

GND

AT+5V

1 2 3 4 5

FROM/TO JACK3

CP4203 127301123K2

LOUT_SOUND

23 22

ROUT_SOUND

21 20

FILTER_MUTE

19

POP_MUTE

18

YUV_SW_Y

17 16

YUV_SW_U

15 14 13 12

AUDIO_SW_R

11 10

AUDIO_SW_L

9 8 7 6 5 4 3 2 1

(CP4203)

GND

YUV_SW_V

GND

ASWW2

GND

VIDEO02

GND

VIDEO01

ASW1 AV1_C S1_DET

AV1_Y

LOUT_SOUND

ROUT_SOUND

FILTER_MUTE

POP_MUTE AV3/AV4_Y

AV3/AV4_PB

AV3/AV4_PR

SW_R

ASW2

SW_L

AV2_CVBS

AV1_CVBS

ASW1 AV1_C S1_DET

AV1_Y

FROM JACK

S1_DET AV2_CVBS

AV1_CVBS AV1_Y

AV1_C

TO SOUND

ROUT_SOUND LOUT_SOUND FILTER_MUTE

POP_MUTE

FROM/TO AV SWITCH

ASW2 ASW1 SW_L SW_R AV3/AV4_Y AV3/AV4_PB AV3/AV4_PR

FROM/TO REGULATOR

STBY-H IR_REMO

AT+5V P_GND

GND

8

7

6

5

4

3

2

PCB240 CEG353

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

1

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION: DIGITAL TRANSISTOR CAUTION: DIGITAL TRANSISTOR

ABC D E F GH

H-45 H-46

3

2

1

ABC D E F GH

8

OPERATION/REMOCON SCHEMATIC DIAGRAM

8

(REMOCON PCB)

OS2201

ROM-V338TAO

7

Vout

GND

1 2

B+

3

C2205_1

KA 100

6.3V

R2208

47 1/4W

STANDBY/POWER

D2201

LTL-1BEFJ-002A

G

R

6

FROM/TO JACK2

CP2201

A2001WR2-5P

REMOCON IN

GND

AT+5V

STANDBY LED

POWER ON LED

(CP4201)

1 2 3 4 5

OS 26

CD2201

E8253101

PCBDA0 CEG359

7

6

(OPERATION PCB)

TO OPERATION2_PCB

(CP2251)

CP2204

5

CU221603

2 1

KEY_1

GND

R2207_2

330

5

C2203

R2217

10

R2201

SW2205_3

SH VOL UP

330

EVQ21505R

4

R2213

10

0.01 B

10

R2214

SW2201_3

SH POWER

EVQ21505R

3

SH INPUT

R2203_2

1.2K

R2202_2

2.2K

SW2202_3

EVQ21505R

R2212

SW2204_3

EVQ21505R

SH CH DOWN

5.6K

R2206_2

1.5K

SW2203_3

SH CH UP

SW2206_3

EVQ21505R

SH VOL DOWN

EVQ21505R

TO MICON

CP2203_1

A2001WR2-3P

KEY_A KEY_B

GND

(CP6202)

3

OS 32

2 1

CD2202_1 CU233301

PCB270 CEG358

4

3

(OPERATION2 PCB)

C2251

0.001 B

R2251

390

SW2251

EJECT_1

FROM OPERATION_PCB

(CP2204)

CP2251 A2001WR2-2P

1

GND

2

KEY_1

EVQ21505R

R2252

820

SW2252

STOP_1

EVQ21505R

R2253

1.2K

SW2253

PLAY_1

EVQ21505R

R2254

2.2K

SW2254

SKIP+_1

EVQ21505R

R2255

5.6K

SW2255

SKIP-_1

EVQ21505R

2

PCB280 CEG361

1

NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

ABC D E F GH

H-47 H-48

1

ABC D E F GH

INTERCONNECTION DIAGRAM

8

H1H1 H2

4

5

CP4203

1

NC

LIGHT_POWER_H

NC

REMOCON IN

CP4201

CD2201

1

CP2201

REMOCON IN

REMOCON PCB

AV1_Y

S1_DET

AV1_C

ASW1

VIDEO01

GND

VIDEO02

GND

AUDIO_SW_L

ASWW2

AUDIO_SW_R

GND

YUV_SW_V

GND

YUV_SW_U

GND YUV_SW_Y POP_MUTE

FILTER_MUTE

GND

ROUT_SOUND

GND

TUNER+30V

POWER_FAIL

SYS_POWER_H

AT+3.3V

GND

P.CON+5V

AT+5V AT+5V

GND

GND LCD+B LCD+B LCD_H

P.CON+9V

GND

GND STBY_H SW+12V

REMOCON_IN

LIGHT_CTL

KEY_A

KEY_B

GND

AT+5V

STANDBY LED

45321

432

GND

AT+5V

STANDBY LED

PCBDA0 CEG359

GND KEY B KEY A

EE

H1 H1H2

COMPONENT_VIDEO_IN_1

1

2345

J4203

7

E

1

CVBS_IN_1

J4206

2 345

NCH1H2H3

E

1

CVBS_IN_2

J4205

2 345

1 2

YC 34

L R

J4201

12

SP OUT L

GND GND

SP OUT R

NCH1H2H3

567

S-VIDEO IN

J4202

POWER PCB

PCB240 CEG353

14PIN

CD406_1

CP406

+24V

1

+24V

2

+24V

3

+24V

4 5

+24V 6 7 8 9

10 11

Analog/Dimming

12

ON/OFF

13

PWM/Dimming

14

N.C(open)

GND GND GND GND GND

6

HDMI AUDIO IN

WHITE

CD301

2 3 1

CP302

4

1

3

2

3

1

4

J401

5

SP302

SPEAKER

(L)

SP301

SPEAKER

4

(R)

CD3805

BLACK

3

Vout GND B+

1 2

STANDBY/POWER

CP2204 1

2

KEY_1

OPERATION PCB

D2201

R

PCB270 CEG358

G

OS2201 1

2 3

TM101

2

OPERATION2 PCB

1

COMMAND TRANSMITTER

CP2251

GND

KEY_1 2

PCB280 CEG361

1

1 2

NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

2 3 4 5 6 7 8 9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

23LOUT_SOUND

CP401

1

1 2

2 3

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

POWER ON LED 54321

5 54321

POWER ON LED

1

2

3

1 2

3 4 5 6 7 8 9

CD2202_1

1 2

3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

1 2

3 4 5 6 7 8 9

10 11 12 13 14 15 16 17 18 19 20 21 22 23

1GND 2 3

CP4302 1 2 3 4 5 6 7 8 9

AUDIO_SW_L 10 11

AUDIO_SW_R 12 13

YUV_SW_V 14 15

YUV_SW_U 16 17

YUV_SW_Y 18

POP_MUTE 19

FILTER_MUTE 20 21

ROUT_SOUND 22 23

LOUT_SOUND

CP3001

TUNER+30V

1

POWER_FAIL

2

SYS_POWER_H

3

AT+3.3V

4 5

P.CON+5V

6 7 8

9 10 11 12 13

P.CON+9V

14 15 16 17 18

REMOCON_IN

19

LIGHT_CTL

20 21

LIGHT_POWER_H

22 23

DB15ds

CP4303

1

2

3

4

5

6

7

8

9 10 11 12 13 14 15

CP6202CP2203_1 1 2 3

AV1_Y

S1_DET

AV1_C

ASW1

VIDEO1

GND

VIDEO2

GND

ASW2

GND

AT+5V AT+5V

GND

GND LCD+B LCD+B LCD_H

GND

STBY_H

SW+12V

KEY_A

KEY_B

VGA-R VGA-G VGA-B

NC

DGND AGND AGND AGND

NC

DGND

NC

DDCD VGAHS VGAVS

DDCC

GND KEY B KEY A

NC

NC NC

NC

CAUTION

SUBMICON CP6201

1

GND

2

TX

3

BUSY

(MODE) 4 5

VCC

6

CLK

7

RX

8

NC

9

RESET

10

GND

11

GND

HDMI CONNECTOR

TMDS_DATA2+

TMDS_DATA2_SH

TMDS_DATA2TMDS_DATA1+

TMDS_DATA1_SH

TMDS_DATA1TMDS_DATA0+

TMDS_DATA0_SH

TMDS_DATA0-

TMDS_CLK+

TMDS_CLK_SH

TMDS_CLK-

CEC

NC

RESERVED DDC_SCL DDC_SDA DDC_GND

+5V_POWER

HOT PLUG

:SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES DESCRIBED IN PARTS LIST ONLY

(CNVSS)

(PORT1)

CP3601

NCNC

NC

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19

CP2801

1 2 3 4 5 6 7 8 9

CP2803

1 2 3 4 5 6 7 8

9 10 11 12

ARE

GND SCL SDA

IIC_OFF

D_GND PC_TOOL_RX PC_TOOL_TX

D3.3V

TCK

TRST_N

TDO

ASEBRKAK_N

TMS

TDI RESET_N FLASH_WP

ASEMD0

GND

VDD33

GND

NCNC

NC NC

NC

L

1

2 3

R

AUDIO OUT

J4301

TU5801

22 23

NC(BB)

1 2

NC

3

NC

4

SIF-out

5

AGC

7

V_OUT

8

+5V

9

TU

11

+30V

12

SDA

14

SCL

15

AFT

16

+5V

17

IF_OUT

18

IF_AGC

19

IF_O

IF_OUT1

20

IF_OUT2

21

24 25

ATTENTION

EE

CP4301

SPDIF-134

GND

ZERO

DVD_A_OUT_R

GND

DVD_A_OUT_L

DVD_RESET [Y]VIDEO

GND

[U]C_VIDEO

START_SW

GND

RX TX

GND P.CON+3.3V P.CON+3.3V

P.CON+12V

GND

P.CON+A5V

P.CON+6V

GND(M)

POWER PCB

PCB240 CEG353

CP2804

VDD+3.3V/NC/GND

NC

VDD+3.3V/NC/GND

GND

GND RXIN0RXIN0+

GND RXIN1RXIN1+

GND RXIN2RXIN2+

GND

RXCLK INRXCLK IN+

GND RXIN3RXIN3+

GND

VDD+3.3V/NC/GND

GND

VDD+5V/12V/GND

VDD+5V/12V VDD+5V/12V VDD+5V/12V VDD+5V/12V

DIGITAL PCB

PCBDH0 CEG352

:LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES

CP403

CD8501

1

2

3

4

5

6

7

8

9

10

11

12

13

14

CD8502

1

2

3

4

5

6

7

8

30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10

9 8 7 6 5 4 3 2 1

CD2804

LCD PANEL

V2301_1

1 2 3 4 5 6 7 8

9 10 11 12 13 14

1

2

3

4

5

6

7

8

CP8501

1

SPDIF-134 2 3 4

DVD_A_OUT_R 5 6

DVD_A_OUT_L

7

DVD RESET 8

[Y]_VIDEO

9

[V]Y_VIDEO

10

[U]C_VIDEO 11 12 13

SSCTXD/RX 14

SSCRXD/TX

CP8502 1 2

P.CON+3.3V

3

P.CON+3.3V

4

P.CON+12V 5 6

P.CON+A5V 7 8

DVD MT PCB

GND

ZERO

GND

START_SW

GND

P.CON+6V

GND(M)

PCB130 DMG097

SW1(DVD/CD) VRF(RF_OUT)

VR(DVD) VR COM

VR(CD)

LD(CD) PD/GND LD(DVD)

NC NC

T DRV T RTN F DRV F RTN

GND(D) OPEN

CLOSE

SP1+

SP1-

SLD+

SLD-

LIMIT SW

SW(GND)

GND

Vref

VCC

GND

LD+ LD-

F

E D C

B A

CP2301_1

CP2302

CP2303

FFC

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

FFC

1

2

3

4

5

FFC

1

2

3

4

5

6

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

1

2

3

4

5

1

2

3

4

5

6

GND

F

Vref

VCC

E D C

SW1(DVD/CD)

VRF(RF_OUT)

B A

VR(DVD)

VR COM

VR(CD)

GND

LD(CD)

PD/GND

LD(DVD)

GND

NC T DRV T RTN F DRV F RTN

LDLD+

OPEN

GND(D)

CLOSE

SP1+ SP1SLD+ SLD-

LIMIT SW

SW(GND)

DSM2(06SD)

SLOT IN DVD

DRIVE

DK1

CV_VTM101A

OPTICAL PICK-UP

SPINDLE MOTOR

LOADING MOTOR

SLED MOTOR

ABC D E F GH

H-49 H-50

8

7

6

5

4

3

2

1

WAVEFORMS

FLASH MICON

20ns 20ns 10us 200mV 200mV 100mV

1 7 13

20ns 10us 10us 200mV 0.5V 100mV

2 8 14

HDMI SCALER VIDEO/AUDIO AV SWITCH 2

TUNER

20ns 20us 2ms 200mV 500mV 100mV

3 9 15

JACK 3

0.2us 20us 2ms 200mV 500mV 100mV

4 10 16

2ms 10us 1ms 500mV 0.5V 200mV

5 11 17

SOUND

2ms 10us 1ms 500mV 200mV 200mV

6 12 18

NOTE:

The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

I-1

WAVEFORMS

200µs

10µs

100µs10µ

s

100µs

JACK AUDIO/VIDEO

2ms 100mV 1.0V

19 56

2ms 100mV 1.0V

20 57

MPEG/MICON/DSP/RF_AMP

10ns 500mV 200mV

52 58

500mV 100mV

53 59

200ns

1.0V

54

MEMORY

500mV

55

The following waveforms were measured

NOTE:

at the point of the corresponding balloon number in the schematic diagram.

I-2

211

109

211

127

209

211

211 102B

209

102F

102A

211

209

205

124

126

125

102F

211

209

205

211

102G

211

102E

102C

211

102D

102

MECHANICAL EXPLODED VIEW

210

206

121

206

120

206

117

206 206

206

103

103A

103C

103A

103B

104A

104C

202

104C

202

104C

202

202 104C

104B

104

PCB280 (OPERATION 2 PCB ASS'Y)

202

PCB270 (OPERATION PCB ASS'Y)

105C

128

105A

105

105B

202

101E

123

101E

131

115

101F

101D

205

101E

123

131

116

101F

205

123

101C

114

205

121

131

114

132

PCBDA0 (REMOCON PCB ASS'Y)

131

212

209

207

209

208

PCBDH0 (DIGITAL PCB ASS'Y)

114

113

122

133

206

203

205

111

210

203

113

203

111

206

203

112

210

203

106B

110

210

106

201

204

203

206

133

108

106A

210

203

201

PCB240 (POWER PCB ASS'Y)

203

PCB130 (DVD MT PCB ASS'Y)

213

130

206

111

213

203

111

213

203

107

213

214

118

205

119

J1-1

101F

101

101E

101A

101B

129

J1-2

MECHANICAL EXPLODED VIEW

(PACKING DIAGRAM)

CD3805 HOLDER CORD

POLYBAG INSTRUCTION(RED CAUTION)

TM101

PACKAGE TOP

INSTRUCTION BOOK(E/F/S) REGISTRATION CARD(SHARP)

GIFT BOX

PACKAGE STAND-TOP PACKAGE STAND-BOTTOM SCREW

LAMIFILM BAG

PACKAGE BOTTOM

SHEET BARCODE

J1-3

MECHANICAL EXPLODED VIEW

(PACKING DIAGRAM)

PACKAGE STAND-TOP

SCREW

FILM BAG (791WHA0159)

FILM BAG (791WHA0160)

J1-4

PACKAGE STAND-BOTTOM

600

DVD DECK EXPLODED VIEW

601

608

CD2001

M2602

605

703

605

703

602

SW2

705

603

AA

607

701

704

PCB640 (SW PCB ASS'Y)

CD2301

702

604

606 703

Do not replace the parts. Because, minute adjustments are needed if this condition is disassembled further more. If the repair is needed, replace the DVD MECHA ASS'Y.

CLASS

GREASE G-555G

PART NO.

Y315061000

PART NAME

MARK

AA

J2-1

NOTE:

Applying positions AA for the grease are displayed for this section. Check if the correct grease is applied for each position.

MECHANICAL REPLACEMENT PARTS LIST

A

REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION

101 7A708A004A FRONT CABI ASS'Y 201 810763080U SCREW TAP TITE(S) BRAZIER 3x8 101A 708WPJA001 CABINET FRONT 202 811063080U SCREW TAP TITE(P) BRAZIER 3x8 101B 702WNA0003 SHEET SPEAKER 203 810923080U SCREW TAP TITE(B) BIND 3x8 101C 713WPA0415 GLASS LED 204 8109I30A0U SCREW TAP TITE(B) WH7 3x10 101D 7235270066 BADGE BRAND 205 8110630A0U SCREW TAP TITE(P) BRAZIER 3x10 101E 800WQ0A110 FELT SHEET 206 810A14080U SCREW WASHER(A) M4x8 101F 800WQ00127 FELT SHEET 207 810213080S SCREW PAN M3x8

102 7A702A537A BACK CABI ASS'Y 209 810923080S SCREW TAP TITE(B) BIND 3x8 102A 702WPAB210 CABINET BACK 102B 706WPA0027 COVER CONNECTOR 210 8117540A0U SCREW TAPPING(B0) TRUSS 4x10 102C 711WPD0721 PANEL SIDE 211 8110230B5S SCREW TAP TITE(P) BIND 3x25 102D 771WPB0085 SLOT DVD 212 810913060S SCREW TAP TITE(B) PAN 3x6 102E 706WPA0032 COVER AC INLET 213 810923060U SCREW TAP TITE(B) BIND 3x6 102F 800WQ0A113 FELT SHEET 214 8109230D2U SCREW TAP TITE(B) BIND 3x42 102G 800WQ00105 FELT SHEET

103 7A764A008A FRAME STAND ASS'Y --- 792WHA0718 PACKAGE TOP 103A 704WPA0081 HOLDER STAND --- 792WHA0719 PACKAGE BOTTOM 103B 761WEA0035 FRAME STAND --- 792WHA0745 PACKAGE STAND TOP 103C 761WPA0470 COVER FRAME STAND --- 793WCDD668 GIFT BOX

104 7A7040033C STAND ASS'Y --- 723000D773 SHEET BARCODE 104A 704WPA0078 STAND --- 774WPA0012 HOLDER CORD 104B 761WSA0465 ANGLE STAND --- 791WHA0159 FILM BAG 104C 800WFA0120 CUSHION LEG --- 791WHA0160 FILM BAG

105 7A711A027A PLATE BUTTON ASS'Y --- J3Y00417A REGISTRATION CARD(SHARP) 105A 711WPD0730 PLATE BUTTON --- J50Q0131A INSTRUCTION BOOK(E/F/S) 105B 735WPB0360 BUTTON FRAME --- JB5ND000 POLYBAG,INSTRUCTION(RED C 105C 735WPB0374 BUTTON FRAME DVD

106 7G761A047A COVER LCD ASS'Y 106A 761WSAA100 COVER LCD 106B 744WUA0024 SPRING EARTH

107 761WSA0628 ANGLE MPEG 108 761WSA0459 SHIELD IC 109 706WPA0027 COVER CONNECTOR

110 706WPA0033 PLATE POWER 111 709WPA0054 HOLDER WIRE 112 752WSA0705 SHIELD DIGITAL 113 753WUA0063 SPRING EARTH 114 761WPAA183 HOLDER PANEL 115 761WPA0473 HOLDER SPEAKER-L 116 761WPA0474 HOLDER SPEAKER-R 117 761WPA0477 COVER HINGE 118 761WPA0508 HOLDER DVD 119 761WSAA098 ANGLE DVD-1

120 761WSA0466 ANGLE HINGE 121 761WSA0480 ANGLE MAIN 122 761WSBA015 PLATE JACK 123 800WR00084 DAMPER SPEAKER 124 722000A642 SHEET SERIAL 125 723000D739 MERCURY CAUTION LABEL (SHARP) 126 723527A117 SHEET RATING

127 723000D797 SHEET JACK 128 723000D800 POP LABEL 129 7230008343 POP LABEL DVD

130 726000A073 SHEET CAUTION 131 800WQ00127 FELT SHEET 132 800WQ00134 FELT SHEET 40x60xT0.5 133 8965TS1210 CUSHION W10/H12/L10

208 810223040S SCREW BIND M3x4

--- 792WHA0717 PACKAGE STAND BOTTOM

--- 89001122A2 SCREW

--- 791WHAA204 LAMIFILM BAG 900x700 8 LANGU

K1-1

DVD DECK REPLACEMENT PARTS LIST

REF. NO. PART NO. DESCRIPTION

! 600 A50N01P650 DVD MECHA ASS'Y A50N01P650

601 92SBB0033A LOADER SUB ASS'Y DLM1D29-31 602 92AAA0017A FEED RACK ASS'Y 603 92P100088A GEAR,MOTOR 604 92P100117A GEAR,MIDDLE 605 92P200017A INSULATOR, F 606 92P200018A INSULATOR, R 607 92P100116A GEAR,FEED 608 800WFAA008 CUSHION C

701 92P700007A SCREW,GEAR FEED 702 814011723U SCREW,PAN M1.7x2.3 P3 703 816112080U SEMS.TAP TITE(P) PAN W10 2x8 704 813381750U SCREW,T-TITE(B)CAMERA PAN M1.7x5.0 P3 705 811022080U SCREW,TAP TITE(P) BIND 2x8

CD2001 12C14O1602 CORD JUMPER FFC05241600408T1-A04 or CD2001 122J4O1603 CORD JUMPER 127000-2933 CD2301 122H062102 CORD JUMPER 2H062102 M2602 1515T98006 MOTOR WRF-300CA-10460A or M2602 1515S98004 MOTOR BCZ3B05 PCB640 A5X002C640 SW PCB ASS'Y DED020A SW2 0500101036 PUSH SWITCH ESE22MH22

K2-1

ELECTRICAL REPLACEMENT PARTS LIST

REF. NO. PART NO. DESCRIPTION

REMOCON PCB ASS'Y

*** PCB ***

PCBDA0 A50Q01PDA0 REMOCON PCB ASS'Y CEG359A

*** DIODES ***

D2201 0021E9Q010 LED LTL-1BEFJ-002A

*** CONNECTORS ***

CP2201 069S250639 CONNECTOR PCB SIDE A2001WR2-5P

*** OTHERS ***

OS2201 077A033001 REMOTE RECEIVER ROM-V338TAO

DIGITAL PCB ASS'Y

*** PCB ***

PCBDH0 A50Q01PDH0 DIGITAL PCB ASS'Y CEG352A

*** RESISTORS ***

R3019 R808R9333J RC 33K OHM 1/16W

!

*** DIODES ***

D3004 D28R1QS040 DIODE EC31QS04-TE12L D3401 DGERMA1110 DIODE SILICON MA111-(TX) D3405 DGERMA1110 DIODE SILICON MA111-(TX) D3406 DGERMA1110 DIODE SILICON MA111-(TX) D3604 D77R1A1R10 DIODE VARISTA AVRL161A1R1NT D3605 D77R1A1R10 DIODE VARISTA AVRL161A1R1NT D3607 DDLRS160T0 DIODE SCHOTTKY BARRIER SS160-T D3610 DGJRT54WS0 DIODE SCHOTTKY BARRIER BAT54WS D6201 DE7RB5R62B DIODE ZENER UDZSNP5.6B TE-17 D6202 DE7RB5R62B DIODE ZENER UDZSNP5.6B TE-17 D6205 DGJRT54WS0 DIODE SCHOTTKY BARRIER BAT54WS

*** ICS ***

IC2801 I56M069540 SCALER R8J66954BG IC2802 IGGM061600 256MB DDR2 SDRAM HYB18TC256160BF-3S

IC2804 S50Q01PF01 MEMORY DATA 32MBIT FLASH 48PIN TSOP EN29LV320AB-70TCP

IC2805 S50Q01PE01 MEMORY DATA EEPROM 256KBIT SO8 M24256-BWMN6TP

IC3001 I07F091300 1CH DC-DC CONVERTER BD9130NV

!

IC3002 I1LF010150 DC-DC CONVERTER CONTROLLER AL1015

!

IC3003 I0GF95ZN10 VO=0.8-3.5V I=1.5A TAPING PQ035ZN1HZPH

!

IC3004 TJ5MC61080 FET TPC6108(TE85L,F,M)

IC3601 S50Q01PE02 MEMORY DATA EEPROM 2K SOP8 S-24CS02AFJ-TB-GE

IC3603 I0WF0002A0 2IN1_HDMI_SW_IC STHDMI002ABTR IC5801 I01FF58320 USA STEREO AN5832SA-E1V IC6201 I9UF032290 RESET IC 2.9V TYPE PST3229NR

IC6202 S34L01PM01

IC6551 IC1J053580 A/D CONVERTER AK5358A IC6552 I0QF02534V A/V SW 3INPUT 1OUTPUT NJM2534V(TE2) IC6553 I0QF02534V A/V SW 3INPUT 1OUTPUT NJM2534V(TE2) IC6554 I0UF015010 A/V SW 2INPUT 1OUTPUT MM1501XNRE IC6555 I0UF015010 A/V SW 2INPUT 1OUTPUT MM1501XNRE IC6556 I5CJ031570 A/V SW 2INPUT 1OUTPUT SN74LVC1G3157DCKR

MEMORY DATA FLASH MICOM ROM16K 2KX2 RAM1 R5F21124FP

K3-1

ELECTRICAL REPLACEMENT PARTS LIST

*** TRANSISTORS ***

Q3003 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK Q3004 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK Q3401 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3402 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK Q3403 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3404 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3405 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3406 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3408 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3409 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK Q3410 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3411 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3412 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q3606 T27T030190 FET 2SK3019_TL Q3607 T27T030190 FET 2SK3019_TL Q3608 T27T030190 FET 2SK3019_TL Q3609 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4301 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4303 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK Q4304 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4306 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4307 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4308 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4310 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4311 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q4312 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q5801 T27T030190 FET 2SK3019_TL Q5802 T27T030190 FET 2SK3019_TL Q6201 T27T030190 FET 2SK3019_TL Q6202 T27T030190 FET 2SK3019_TL

*** COILS ***

B2800 024HC51816 CORE,BEADS HCB1608KF-181T20 B2801 024HC52216 CORE,BEADS HCB1608KF-221T20 B2803 024HC52216 CORE,BEADS HCB1608KF-221T20 B2804 024HC52216 CORE,BEADS HCB1608KF-221T20 B2805 024HC52216 CORE,BEADS HCB1608KF-221T20 B2806 024HC52216 CORE,BEADS HCB1608KF-221T20 B2807 024HC52216 CORE,BEADS HCB1608KF-221T20 B2808 024HC52216 CORE,BEADS HCB1608KF-221T20 B2809 024HC52216 CORE,BEADS HCB1608KF-221T20 B2810 024HC52216 CORE,BEADS HCB1608KF-221T20 B2811 024HC52216 CORE,BEADS HCB1608KF-221T20 B2813 024HC51216 CORE,BEADS HCB1608KF-121T20 B2814 024HC51216 CORE,BEADS HCB1608KF-121T20 B2815 024HC51216 CORE,BEADS HCB1608KF-121T20 B2816 024HC51216 CORE,BEADS HCB1608KF-121T20 B2817 024HC51216 CORE,BEADS HCB1608KF-121T20 B2820 024HC51216 CORE,BEADS HCB1608KF-121T20 B2821 024HC51216 CORE,BEADS HCB1608KF-121T20 B2822 024HC51216 CORE,BEADS HCB1608KF-121T20 B3003 024HC51816 CORE,BEADS HCB1608KF-181T20 B3004 024HC51816 CORE,BEADS HCB1608KF-181T20 B3005 024HC51816 CORE,BEADS HCB1608KF-181T20 B3601 024HC51816 CORE,BEADS HCB1608KF-181T20 B4301 024HC51023 CORE,BEADS FCM1608KF-102T02 B4302 024HC51023 CORE,BEADS FCM1608KF-102T02 B4303 024HC51023 CORE,BEADS FCM1608KF-102T02 B4304 024HC51023 CORE,BEADS FCM1608KF-102T02 B4305 024HC51023 CORE,BEADS FCM1608KF-102T02 B4306 024HC51023 CORE,BEADS FCM1608KF-102T02 B4308 024HC51513 CORE,BEADS FCM1608KF-151T06 B4309 024HC56005 CORE,BEADS FCM1608CF-600T06 B4312 024HC51023 CORE,BEADS FCM1608KF-102T02

K3-2

ELECTRICAL REPLACEMENT PARTS LIST

B4313 024HC51023 CORE,BEADS FCM1608KF-102T02 B4314 024HC51023 CORE,BEADS FCM1608KF-102T02 B4315 024HC51023 CORE,BEADS FCM1608KF-102T02 B5802 024HC51023 CORE,BEADS FCM1608KF-102T02 B5804 024HC51513 CORE,BEADS FCM1608KF-151T06 B5808 024HC51023 CORE,BEADS FCM1608KF-102T02 B5809 024HC51023 CORE,BEADS FCM1608KF-102T02 B6551 024HC51216 CORE,BEADS HCB1608KF-121T20 B6552 024HC51023 CORE,BEADS FCM1608KF-102T02 B6553 024HC51023 CORE,BEADS FCM1608KF-102T02 B6556 024HC51816 CORE,BEADS HCB1608KF-181T20

L3001 02167E220K COIL 22 UH L3002 02167E100K COIL 10 UH L3003 0216S8331K COIL 330 UH L3004 0216MG220M COIL 22 UH L3005 02167E220K COIL 22 UH L3401 0216S8331K COIL 330 UH L3601 02D1000119 COIL CHOKE EXC28CG900U L3602 02D1000119 COIL CHOKE EXC28CG900U L4301 0216S8220K COIL 22 UH L5801 0216SD220J COIL 22 UH L5805 021AS9224J COIL 0.22 UH L6551 0216S8220K COIL 22 UH

*** JACKS ***

J4301 060K411055 RCA JACK AV3-13P2-60S1

*** CONNECTORS ***

CP2804 069S2U005A CONNECTOR PCB SIDE A2006WR0-2X15P-HK CP3001 06CK7N0301 CORD CONNECTOR TWG-P23P-A1 CP3601 0694YJ3038 CONNECTOR PCB SIDE 5-1903015-4 CP4302 06CK7N0301 CORD CONNECTOR TWG-P23P-A1 CP6202 069S230639 CONNECTOR PCB SIDE A2001WR2-3P

*** CRYSTAL & CERAMIC OSCILLATORS ***

X2801 100GT02728 CRYSTAL SMD-49 C27000B030 X2802 100GT02509 CRYSTAL SMD-49 C25000H025 X3601 100GT01807 CRYSTAL SMD-49 C18432B022 X6201 100GT01615 CRYSTAL B16000E007 X6551 100DT01217 CRYSTAL DS0321SRAB

*** TUNER ***

TU5801 0164100026 DIGITAL TUNER ENG36E19KF

!

*** NETWORKS ***

NR2801 11074100M7 R,NETWORK CRA108100JV NR2802 11074100M7 R,NETWORK CRA108100JV NR2803 11074100M7 R,NETWORK CRA108100JV NR2804 11074100M7 R,NETWORK CRA108100JV NR2805 11074270M7 R,NETWORK CRA108270JV NR2806 11074270M7 R,NETWORK CRA108270JV NR2807 11074270M7 R,NETWORK CRA108270JV NR2808 11074270M7 R,NETWORK CRA108270JV NR2809 11074270M7 R,NETWORK CRA108270JV NR2810 11074220M7 R,NETWORK CRA108220JV NR2811 11074220M7 R,NETWORK CRA108220JV NR6551 11074470M7 R,NETWORK CRA108470JV

*** OTHERS ***

CP2801 06GG290029 CONNECTOR PCB SIDE A2001WV-9A

K3-3

ELECTRICAL REPLACEMENT PARTS LIST

CP2803 06GG2C0029 CONNECTOR PCB SIDE A2001WV-12A CP4301 06GG2E0019 CONNECTOR PCB SIDE A2001WR-14A CP4303 06G8S21504 CONNECTOR PCB SIDE 1B630020 CP6201 06GG2B0029 CONNECTOR PCB SIDE A2001WV-11A

SH3001 126D000045 TERMINAL PIN YQ-12 SH3002 126D000045 TERMINAL PIN YQ-12 SH3003 126D000045 TERMINAL PIN YQ-12 SH3004 126D000045 TERMINAL PIN YQ-12 SH3005 126D000045 TERMINAL PIN YQ-12

DVD MT PCB ASS'Y

*** PCB ***

PCB130 A50Q01P130 DVD MT PCB ASS'Y DMG097A

*** DIODES ***

D2303 DGERMA1110 DIODE SILICON MA111-(TX) D2304 DGERMA1110 DIODE SILICON MA111-(TX) D4002 DGERMA1110 DIODE SILICON MA111-(TX) D4003 DGERMA1110 DIODE SILICON MA111-(TX) D4005 DGERMA1110 DIODE SILICON MA111-(TX) D4008 DGERMA1110 DIODE SILICON MA111-(TX) D8510 DGERMA1110 DIODE SILICON MA111-(TX)

*** ICS ***

IC2301 I03FV65650 5CH MOTOR DRIVER IC LA6565VR-TLM-E

!

IC4001 ICQK069660 VADDIS9 MPEG/MICON/DSP/RF-AMP ZR36966ELCG-D or ICQK06966A VADDIS9 MPEG/MICON/DSP/RF-AMP ZR36966ELCG-D-G IC4005 IF9J0164AG 1M*16*4BANK SDRAM TSOP54 M12L64164A-7TG IC4007 ICMJ016017 16M FLASH MEMORY PB FREE SST39VF1601-70-4C-EKE IC8501 I0QF045650 DUAL OPEAMP NJM4565M(TE1)

IC8502 I1TF911170 VO=1.5-7V IO=1A TAPING LM1117S-ADJ

!

*** TRANSISTORS ***

Q2301 TAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P Q2302 TAAA1544T0 TRANSISTOR SILICON KTA1544T-RTK/P

*** COILS ***

B2304 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B2305 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4001 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4002 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4003 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4005 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4006 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4008 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4010 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4015 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B4016 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B8501 024HC51216 CORE,BEADS HCB1608KF-121T20 B8502 024NC51021 CORE,BEADS EBMS160808A102_RDC45 B8503 024HC51216 CORE,BEADS HCB1608KF-121T20 B8504 024NC51021 CORE,BEADS EBMS160808A102_RDC45

L8501 0216SD2R2J COIL 2.2 UH L8502 0216SD1R0J COIL 1 UH L8504 0216SD1R0J COIL 1 UH

*** CONNECTORS ***

CP2301 069KYOT159 CONNECTOR PCB SIDE LD07T2-24ND-03

K3-4

ELECTRICAL REPLACEMENT PARTS LIST

CP2302 069EV5T060 CONNECTOR PCB SIDE 04_6232_105_015_800+ CP2303 069EV6T060 CONNECTOR PCB SIDE 04_6232_106_015_800+ CP8502 069S280629 CONNECTOR PCB SIDE A2001WV2-8P

*** CRYSTAL & CERAMIC OSCILLATORS ***

X4001 100GT02727 CRYSTAL SMD-49 C27000J029

*** OTHERS *** CP8501 06GG2E0019 CONNECTOR PCB SIDE A2001WR-14A SH8501 126D000045 TERMINAL PIN YQ-12

SH8502 126D000045 TERMINAL PIN YQ-12 SH8503 126D000045 TERMINAL PIN YQ-12 SH8504 126D000045 TERMINAL PIN YQ-12

POWER PCB ASS'Y

*** PCB *** PCB240 A50Q01P240 POWER PCB ASS'Y CEG353A

*** RESISTORS ***

R404 RC31X1125J RC 1.2M OHM 1W

!

R406 R3K681S47J R,METAL OXIDE 0.047 OHM 1W

!

R412 R63881R22J R,FUSE 0.22 OHM 1W

!

R416 R65584100J R,FUSE 10 OHM 1/4W

!

R432 R3K781220J R,METAL OXIDE 22 OHM 1W

!

R434 R5X2CE1R2J R,CEMENT 1.2 OHM 7W

!

R445 R002T4101J RC 100 OHM 1/4W

!

R447 R65584150J R,FUSE 15 OHM 1/4W

!

R473 R3K78A102J R,METAL OXIDE 1K OHM 2W R481 R3K78A102J R,METAL OXIDE 1K OHM 2W

R497 R63881010J R,FUSE 1 OHM 1W

!

*** CAPACITORS *** C346 E7EYF4471M CE 470 UF 35V

C349 E7ESF3102M CE 1000 UF 25V C350 E7ESF3102M CE 1000 UF 25V C401 C0PLRR7E3K CC 0.0015 UF 2KV R

C402 P2122B224M CMP 0.22 UF 275V ECQUL

!

C403 E71JFC391D CE 390 UF 200V

!

C404 E71JFC391D CE 390 UF 200V

!

C406 CD39E0MH3M CC 0.0022UF 250V

!

C423 P4NBE5823H CMPP 0.082 UF 630

!

C430 C0PLRR7H3K CC 0.0022 UF 2KV R

C433 E7EYF4102M CE 1000 UF 35V

!

C434 E7EYF4122M CE 1200 UF 35V

C435 E7EYF3102M CE 1000 UF 25V

!

C438 E7EYF4122M CE 1200 UF 35V

!

C440 E7EYF0222M CE 2200 UF 6.3V

C441 E8E2U52R2D CE 2.2 UF 50V

!

C442 E7ESU5470M CE 47 UF 50V

!

C444 E7EPT0222M CE 2200 UF 6.3V

!

C448 P2122B224M CMP 0.22 UF 275V ECQUL

!

C453 E7EYF2102M CE 1000 UF 16V

!

C455 E8E6FC470M CE 47 UF 200V

!

C462 E7EYF2102M CE 1000 UF 16V

!

C464 CD39E0MH3M CC 0.0022UF 250V

!

C500 E7EPU3101M CE 100 UF 25V

!

C502 E7EPU2101M CE 100 UF 16V

!

K3-5

ELECTRICAL REPLACEMENT PARTS LIST

*** DIODES *** D401 D97U03301B DIODE,ZENER MTZJ33B T-77

D404 D6CE24110A DIODE VARISTA ENE241D-10A-Q6

!

D405 D4CKN54060 DIODE SILICON 1N5406FL-6737

!

D406 D28R1QS040 DIODE EC31QS04-TE12L

D407 D4CKN54060 DIODE SILICON 1N5406FL-6737

!

D408 D1VT001330 DIODE,SILICON 1SS133T-77 D410 D1VT001330 DIODE,SILICON 1SS133T-77 D411 D1VT001330 DIODE,SILICON 1SS133T-77 D412 D97U03R91B DIODE,ZENER MTZJ3.9B T-77 D413 D97U03001B DIODE,ZENER MTZJ30B T-77

D415 D2WXN40050 DIODE SILICON 1N4005-EIC

!

D416 D28F31DQ06 DIODE,SILICON 31DQ06-FC

!

D417 D28R1QS040 DIODE EC31QS04-TE12L D418 D2WXN40050 DIODE SILICON 1N4005-EIC D421 D28R1QS040 DIODE EC31QS04-TE12L D424 D97U03R31B DIODE,ZENER MTZJ3.3B T-77 D425 D97U02701B DIODE,ZENER MTZJ27B T-77 D426 D1VT001330 DIODE,SILICON 1SS133T-77 D427 D97U02701B DIODE,ZENER MTZJ27B T-77 D432 D4AT106FE0 DIODE RECTIFIER RL106F-E D433 D4AT01H3E0 DIODE RECTIFIER 1H3-E

D435 D2CFC91020 DIODE SILICON ERC91-02J11SC

!

D437 D28AH10A20 DIODE SCHOTTKY BARRIER FCH10A20

D440 D2CA2C15R0 DIODE SCHOTTKY BARRIER YG862C15R

!

D442 D4AT01H3E0 DIODE RECTIFIER 1H3-E

!

D443 D28F31DQ09 DIODE SCHOTTKY 31DQ09-FC

!

D444 D2LT001F50 DIODE SILICON 1F5-E

!

D445 D97U01501B DIODE,ZENER MTZJ15B T-77 D4207 DE7RB1202B DIODE ZENER UDZSNP12B TE-17 D4209 DE7RB1202B DIODE ZENER UDZSNP12B TE-17 D4210 DE7RB1202B DIODE ZENER UDZSNP12B TE-17 D4211 DE7RB1202B DIODE ZENER UDZSNP12B TE-17 D4212 DE7RB1202B DIODE ZENER UDZSNP12B TE-17 D4213 DE7RB1202B DIODE ZENER UDZSNP12B TE-17 D4214 D1VT001330 DIODE,SILICON 1SS133T-77

*** ICS ***

IC302 I0FSP7808B SOUND AMP STEREO AN17808B

!

IC401 I2GT050380 VDS=500V RDS1=0.77 RDS2=0.38 MP3A5038

!

IC402 I5SD0P2F40 VD=700V RDS(ON)=9.5OHM MIP2F4

!

IC403 I1KJ9A431A VARIABLE SHUNT REGULATOR TAPE KIA431A-AT

!

IC404 I1KJ9A431A VARIABLE SHUNT REGULATOR TAPE KIA431A-AT

!

IC405 000220002W PHOTO COUPLER PS2561AL1-1-V(W)

!

IC406 000220002W PHOTO COUPLER PS2561AL1-1-V(W)

!

IC407 I03T057790 VIN=30V I0=3A LA5779-E

!

IC408 000220002W PHOTO COUPLER PS2561AL1-1-V(W)

!

IC409 I1KA97809A 9V REGULATOR 1A KIA7809API

IC410 000220002W PHOTO COUPLER PS2561AL1-1-V(W)

!

IC411 I5HJ0170B0 REGULATOR VO=3.3V IO=800MA S-1170B33UC-OTSTFG IC412 TJ7T35P020 FET RTQ035P02-TR IC413 I03F957950 1CH STEP DOWN DC-DC CONTROL LV5795-TE-L-E IC6502 I0QF027500 4INPUT 1OUTPUT AUDIO SW NJM2750M(TE1)

*** TRANSISTORS *** Q307 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK

Q401 TAAT01281Y TRANSISTOR SILICON KTA1281_Y Q403 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK Q404 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK Q405 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q406 TC5T021204 TRANSISTOR,SILICON 2SC2120Y(TPE2)

Q407 TAAT01281Y TRANSISTOR SILICON KTA1281_Y

!

Q408 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK

K3-6

ELECTRICAL REPLACEMENT PARTS LIST

Q409 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK Q410 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK Q411 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK Q412 TJ5AK302T0 FET SSM3K302T(TE85L,F) Q416 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK Q417 TAAT01281Y TRANSISTOR SILICON KTA1281_Y Q418 T67J017590 TRANSISTOR SILICON 2SA1759_T100 Q420 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q421 TNAAA05001 COMPOUND TRANSISTOR KRC101S-RTK Q422 TBA0011510 TRANSISTOR SILICON KTB1151 Q423 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q424 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK Q425 TJ5AK302T0 FET SSM3K302T(TE85L,F) Q4211 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK Q4212 TPAAC05002 COMPOUND TRANSISTOR KRA103SRTK

*** COILS *** B401 024HT03553 CORE,BEADS W5RH3.5X5X1.0

B404 024HT03553 CORE,BEADS W5RH3.5X5X1.0

L401 029X000167 COIL,LINE FILTER SS30V-R200132

!

L402 029X000166 COIL,LINE FILTER SS11V-R22020-CH L403 021U0L220M COIL 22 UH L404 02167E220K COIL 22 UH L408 021U0L470M COIL 47 UH L411 02167E100K COIL 10 UH L413 02167E100K COIL 10 UH

*** TRANSFORMERS ***

T401 0481400854 TRANSFORMER,SWITCHING 81400854

!

T402 0481190084 TRANSFORMER,SWITCHING 81190084

!

*** JACKS *** J401 064A1A0005 SOCKET,AC YKE31-0149N

J4201 060J131019 HEADPHONE JACK MSJ-2000B_AG(O87) J4202 063Y700014 JACK DIN-409B J4203 060K411053 RCA JACK AV3-13P2-31S1 J4205 060R431035 RCA JACK RCA-349-00C-02 J4206 060R431035 RCA JACK RCA-349-00C-02

*** CONNECTORS *** CP401 06977NM020 CONNECTOR PCB SIDE 127301123K2

CP403 069S280639 CONNECTOR PCB SIDE A2001WR2-8P CP404 069D01001A CONNECTOR PCB SIDE 003P-2100 CP4201 069S250639 CONNECTOR PCB SIDE A2001WR2-5P CP4203 06977NM020 CONNECTOR PCB SIDE 127301123K2

*** FUSES ***

F401 081PC6R305 FUSE 51MS063L

!

F404 0835C02003 MICRO FUSE 20N_2000FS

!

FH401 06710T0009 HOLDER,FUSE EYF-52BCY FH402 06710T0009 HOLDER,FUSE EYF-52BCY

*** OTHERS *** CP302 06GG140019 CONNECTOR PCB SIDE A2502WR-4A

CP406 06GG2E0019 CONNECTOR PCB SIDE A2001WR-14A EL2401 124116281A EYE LET XRY16X28BD

EL2402 124120301A EYE LET XRY20X30BD SH402 126D000045 TERMINAL PIN YQ-12

K3-7

ELECTRICAL REPLACEMENT PARTS LIST

SH404 126D000045 TERMINAL PIN YQ-12 SH406 126D000045 TERMINAL PIN YQ-12 SH407 126D000045 TERMINAL PIN YQ-12 SH410 126D000045 TERMINAL PIN YQ-12

OPERATION PCB ASS'Y

*** PCB *** PCB270 A50Q01P270 OPERATION PCB ASS'Y CEG358A

*** SWITCHES *** SW2201 0504101T34 SWITCH,TACT EVQ21505R

SW2202 0504101T34 SWITCH,TACT EVQ21505R SW2203 0504101T34 SWITCH,TACT EVQ21505R SW2204 0504101T34 SWITCH,TACT EVQ21505R SW2205 0504101T34 SWITCH,TACT EVQ21505R SW2206 0504101T34 SWITCH,TACT EVQ21505R

*** CONNECTORS *** CP2203 069S230639 CONNECTOR PCB SIDE A2001WR2-3P

CP2204 06CU221603 CORD CONNECTOR CU221603

OPERATION 2 PCB ASS'Y

*** PCB *** PCB280 A50Q01P280 OPERATION 2 PCB ASS'Y CEG361A

*** SWITCHES *** SW2251 0504101T34 SWITCH,TACT EVQ21505R

SW2252 0504101T34 SWITCH,TACT EVQ21505R SW2253 0504101T34 SWITCH,TACT EVQ21505R SW2254 0504101T34 SWITCH,TACT EVQ21505R SW2255 0504101T34 SWITCH,TACT EVQ21505R

*** CONNECTORS *** CP2251 069S220639 CONNECTOR PCB SIDE A2001WR2-2P

AND OTHERS

*** CONNECTORS *** CD2202 06CU233301 CORD CONNECTOR CU233301

CD2804 06CURU1704 CORD CONNECTOR CURU1704 CD8501 06CU2E2701 CORD CONNECTOR CU2E2701 CD8502 06CU282701 CORD CONNECTOR CU282701

*** AC CORD *** CD3805 120Q119906 CORD SET AC P201-2739-1

*** OTHERS *** BT001 141R003018 BATTERY,MANGAN GR6M

BT002 141R003018 BATTERY,MANGAN GR6M CD301 06E8144301 CORD CONNECTOR E8144301

CD406 06E82E1301 CORD CONNECTOR E82E1301 CD2201 06E8253101 CORD CONNECTOR E8253101 CUS151 800WFAA006 CUSHION A

SP301 070Y056007 SPEAKER S0412F06

!

K3-8

ELECTRICAL REPLACEMENT PARTS LIST

.

SP302 070Y056007 SPEAKER S0412F06

!

TM101 076B0MR030 TRANSMITTER ETR0088-010171

V2301 09EV126010 LCD V260B1-L01_M

!

RESISTOR

RC................... CARBON RESISTOR

CAPACITORS

CC................... CERAMIC CAPACITOR

CE................... ALUMI ELECTROLYTIC CAPACITOR

CP................... POLYESTER CAPACITOR

CPP.................. POLYPROPYLENE CAPACITOR

CPL.................. PLASTIC CAPACITOR

CMP...................

CMPL................ METAL PLASTIC CAPACITOR

CMPP................ METAL POLYPROPYLENE CAPACITOR

METAL POLYESTER CAPACITOR

K3-9

COPYRIGHT

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

2008 BY SHARP CORPORATION

©

SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP lc 26dv24u Diagram

Specifications and Main Features

Frequently Asked Questions

User Manual
