Sharp LC-22AD1E Operating Manual

LC-22AD1E

LCD COLOUR TELEVISION
LCD-FARBFERNSEHGERÄT

ENGLISH

DEUTSCH

TÉLÉVISION COULEUR À ÉCRAN
À CRISTAUX LIQUIDES (LCD)

OPERATION MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI

FRANÇAIS

This equipment complies with the requirements of Directive 89/336/EEC and 73/23/EEC as amended by 93/68/

ASA

EEC.

Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/
68/EWG.

Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la
directive 93/68/CEE.

Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/EEG.

Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillæg nr. 93/68/EEC.

Quest’ apparecchio è conforme ai requisiti delle direttive 89/336/EEC e 73/23/EEC, come emendata dalla
direttiva 93/68/EEC.

« В„Н·Щ‹ЫЩ·ЫБ ·ıЩfi ·МЩ·ФНТflМВЩ·И ЫЩИЪ ··ИЩfiЫВИЪ Щ˘М Ф‰Б„И˛М ЩБЪ EıТ˘·˙НfiЪ EМ˘ЫБЪ 89/336/EOK Н·И
73/23/EOK, ¸˘Ъ ФИ Н·МФМИЫПФfl ·ıЩФfl ЫıПОБТ˛ЛБН·М ·¸ ЩБМ Ф‰Б„fl· 93/68/EOK.

Este equipamento obedece às exigências das directivas 89/336/CEE e 73/23/CEE, na sua versão corrigida pela
directiva 93/68/CEE.

Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/23/CEE, modificadas por medio de la
93/68/CEE.

Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/23/EEC så som kompletteras av 93/68/
EEC.

Dette produktet oppfyller betingelsene i direktivene 89/336/EEC og 73/23/EEC i endringen 93/68/EEC.

Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on muutettu direktiivillä 93/68/EEC.

SPECIAL NOTE FOR USERS IN THE U.K.

The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should
the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked or

and of the same rating
as above, which is also indicated on the pin face of the plug, must be used.
Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut off the
mains plug and fit an appropriate type.

DANGER:

The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of
in a safe manner.
Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket outlet, as a serious
electric shock may occur.
To fit an appropriate plug to the mains lead, follow the instructions below:

IMPORTANT:

The wires in the mains lead are coloured in accordance with the following code:

Blue: Neutral
Brown: Live

As the colours of the wires in the mains lead of this product may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:

• The wire which is coloured blue must be connected to the plug terminal which is marked N or coloured black.

• The wire which is coloured brown must be connected to the plug terminal which is marked L or coloured red.
Ensure that neither the brown nor the blue wire is connected to the earth terminal in your three-pin plug.
Before replacing the plug cover make sure that:

• If the new fitted plug contains a fuse, its value is the same as that removed from the cut-off plug.

• The cord grip is clamped over the sheath of the mains lead, and not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.

LC-22AD1E

LCD COLOUR TELEVISION

ENGLISH

OPERATION MANUAL

Contents

Dear SHARP customer .................................................... 2

Important Safety Precautions ........................................ 2

Supplied accessories ...................................................... 4

Trademarks ...................................................................... 4

Preparation ....................................................................... 5

Inserting the batteries ................................................ 5

Using remote control .................................................. 5

Power connection ....................................................... 6

Antenna connection ................................................... 6

First installation ........................................................... 7

Virgin mode................................................................. 8

Part names – Main unit ................................................... 9

How to fix the cables ................................................ 10

Part names – Remote control unit .............................. 11

Basic operation .............................................................. 13

Turning the main power on and off.......................... 13

STANDBY/ON ........................................................... 13

Switching the TV/VIDEO

(TV/DTV/AV1/AV2/AV3) mode ........................... 13

Listening with headphones ...................................... 13

Sound volume ........................................................... 14

Changing channels .................................................. 14

Digital TV features ......................................................... 15

Selecting digital menu items .................................... 15

Selecting DTV mode ................................................. 15

About colour buttons ................................................. 15

Time Zone ................................................................. 16

Search ....................................................................... 16

Found TV services..................................................... 17

Found radio services................................................. 17

Store .......................................................................... 18

Discard ...................................................................... 18

Banner duration......................................................... 19

Info banner ................................................................ 19

Audio ......................................................................... 20

Subtitle ...................................................................... 20

Teletext ...................................................................... 21

Reinstall all services .................................................. 22

Access restrictions .................................................... 22

Maturity rating ........................................................... 22

TV services ................................................................ 23

Radio services........................................................... 23

Selecting programme................................................ 24

Using EPG (Electronic Programme Guide) ............... 24

Setting the theme ...................................................... 25

Mode ......................................................................... 25

Audio language ......................................................... 26

Subtitle language ...................................................... 26

Service list type ......................................................... 27

Rearrange TV services .............................................. 28

Rearrange radio services .......................................... 28

New TV services........................................................ 29

New radio services.................................................... 29

Installed TV services ................................................. 30

Installed radio services ............................................. 30

Uninstalled TV services ............................................. 30

ENGLISH

Uninstalled radio services ......................................... 30

Country ...................................................................... 31

System software ........................................................ 31

Icons.......................................................................... 32

Common Interface .................................................... 32

Useful features ............................................................... 33

Selecting menu items ............................................... 33

Picture .......................................................................35

Sound ........................................................................ 36

Dolby Virtual ............................................................. 37

Programmes ............................................................. 38

Wide mode ................................................................ 42

Features .................................................................... 43

Cool climate .............................................................. 44

V.Position .................................................................. 44

Selecting speakers ................................................... 45

Connecting external speakers ................................. 45

Rotate ........................................................................ 46

On-screen display .................................................... 46

Child lock (for TV/DTV) ............................................. 47

AV connections ......................................................... 50

Timer functions ......................................................... 52

Sleep timer ................................................................ 52

NICAM broadcast selection .....................................53

A2 stereo broadcasts ............................................... 54

Teletext ........................................................................... 55

Teletext function ....................................................... 55

How to use p (DISPLAY/INFO) button (for TV/DTV) ....57

Connecting external devices ....................................... 58

Examples of external devices that can be

connected .......................................................... 58

Connecting a VCR or decoder

through the 21-pin Euro-SCART

(AV-IN 1/RGB) (AV-IN 2/AV) .............................. 59

Connecting a camcorder or a home video game

system (AV-IN 3) ................................................60

Outputting audio (AUDIO OUT) ...............................60

Troubleshooting ............................................................ 61

Specifications ................................................................ 62

Dimensional drawings .................................................. 63

The factory preset PIN is “1234”.

Dear SHARP customer

Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of trouble­free operation of your product, please read the Important Safety Precautions carefully before using this product.

Important Safety Precautions

Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential
danger, please observe the following instructions when installing, operating and cleaning the product. To
ensure your safety and prolong the service life of your LCD colour TV product, please read the following
precautions carefully before using the product.

1. Read instructions—All operating instructions must be read and understood before the product is operated.

2. Keep this manual in a safe place—These safety and operating instructions must be kept in a safe place for
future reference.

3. Observe warnings—All warnings on the product and in the instructions must be observed closely.

4. Follow instructions—All operating instructions must be followed.

5. Attachments—Do not use attachments not recommended by the manufacturer. Use of inadequate attachments
can result in accidents.

6. Power source—This product must operate on a power source specified on the specification label. If you are
not sure of the type of power supply used in your home, consult your dealer or local power company.

7. AC cord protection—The AC cords must be routed properly to prevent people from stepping on them or
objects from resting on them. Check the cords at the plugs and product.

8. Overloading—Do not overload AC outlets or extension cords. Overloading can cause fire or electric shock.

9. Entering of objects and liquids—Never insert an object into the product through vents or openings. High
voltage flows in the product, and inserting an object can cause electric shock and/or short internal parts. For
the same reason, do not spill water or liquid on the product.

10. Servicing—Do not attempt to service the product yourself. Removing covers can expose you to high voltage
and other dangerous conditions. Request a qualified service person to perform servicing.

11. Repair—If any of the following conditions occur, unplug the AC cord from the AC outlet, and request a qualified
service person to perform repairs.

a. When the AC cord or plug is damaged.
b. When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.

Do not touch the controls other than those described in the operating instructions. Improper adjustment
of controls not described in the instructions can cause damage, which often requires extensive adjustment

work by a qualified technician.
e. When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product indicates

that the product needs servicing.

12. Replacement parts—In case the product needs replacement parts, make sure that the service person uses
replacement parts specified by the manufacturer, or those with the same characteristics and performance as
the original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.

13. Safety checks—Upon completion of service or repair work, request the service technician to perform safety
checks to ensure that the product is in proper operating condition.

14. Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.

2

Important Safety Precautions

• Cleaning—Unplug the AC cord
from the AC outlet before cleaning
the product. Use a damp cloth to
clean the product. Do not use
liquid cleaners or aerosol
cleaners.

• Water and moisture—Do not use
the product near water, such as
bathtub, washbasin, kitchen sink,
laundry tub, swimming pool and in
a wet basement.

• Stand—Do not place the product
on an unstable cart, stand, tripod
or table. Doing so can cause the
product to fall, resulting in serious
personal injuries as well as
damage to the product. Use only
a cart, stand, tripod, bracket or
table recommended by the
manufacturer or sold with the
product. When mounting the
product on a wall, be sure to
follow the manufacturer’s
instructions. Use only the
mounting hardware recommended
by the manufacturer.

• The LCD panel used in this
product is made of glass.
Therefore, it can break when the
product is dropped or impact
applied. If the LCD panel is
broken be careful not to be injured
by broken glass.

• Heat sources—Keep the product
away from heat sources such as
radiators, heaters, stoves and
other heat-generating products
(including amplifiers).

• Do not place vases or any other
water-filled containers on this
product.
The water may spill onto the
product causing fire or electric
shock.

• To prevent fire, never place any
type of candle or naked flames on
the top or near the TV set.

• When relocating the product
placed on a cart, it must be
moved with utmost care. Sudden
stops, excessive force and
uneven floor surface can cause
the product to fall from the cart.

• Ventilation—The vents and other
openings in the cabinet are
designed for ventilation. Do not
cover or block these vents and
openings since insufficient
ventilation can cause overheating
and/or shorten the life of the
product. Do not place the product
on a bed, sofa, rug or other similar
surface, since they can block
ventilation openings. This product
is not designed for built-in
installation; do not place the
product in an enclosed place
such as a bookcase or rack,
unless proper ventilation is
provided or the manufacturer’s
instructions are followed.

• To prevent fire or shock hazard,
do not place the AC power cord
under the TV set or other heavy
items.

The LCD panel is a very high technology product
with 1,229,760 thin film transistors, giving you fine
picture details.
Due to the very large number of pixels,
occasionally a few non-active pixels may appear
on the screen as a fixed point of blue, green or
red.
This is within product specifications and does not
constitute a fault.

3

Supplied accessories

LC-22AD1E

Make sure the following accessories are provided with the product.

Remote control unit (×1)

Page 5, 11 and 12 Page 5

AC adapter (×1)

“AA” size battery (×2)

AC cord (×1)

Cable clamp (×2)

Page 10

Trademarks

*Product shape varies in some countries.

Page 6 Page 6

Antenna cable (×1)

* Already connected to the LCD TV set.

Page 6

Operation manual

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks
of Dolby Laboratories.

Manufactured under license from BBE Sound, Inc.
Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered
trademarks of BBE Sound, Inc.

4

Preparation

Inserting the batteries

Before using the System for the first time, insert two “AA” size batteries (supplied) into the remote control. When the
batteries become depleted and the remote control fails to operate, replace the batteries with new “AA” size batteries.

1 Open the battery cover. 2 Insert two supplied “AA” size

3 Close the battery cover.

batteries.

+

_

• Place batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.

_

+

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions
below.

• Place the batteries with their terminals corresponding to the (e) and (f) indications.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or

cause chemical leakage in old batteries.

• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash.
If you find any chemical leakage, wipe thoroughly with a cloth.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove the batteries from

it.

Using remote control

■ Use the remote control by pointing it towards the remote sensor
window of the main unit. Objects between the remote control and
sensor window may prevent proper operation.

Cautions regarding use of remote control

■ Do not expose the remote control to shock. In addition, do not
expose the remote control to liquids, and do not place it in an area
with high humidity.

■ Do not install or place the remote control under direct sunlight.
The heat may cause deformation of the unit.

■ The remote control may not work properly if the remote sensor
window is under direct sunlight or strong lighting. In such a case,
change the angle of the lighting or main unit, or operate the
remote control closer to the remote sensor window.

B

OPC

Headphone jack

Remote control sensor indicator

OPC indicator

STANDBY/ON indicator

OPC sensor window

Remote control sensor window

5

Preparation

Connect to the DC input terminal of the product.

Power connection

X (MAIN POWER)

POWER INPUT

Pull down the
hook to open
the cover.

DC 13 V

Household

power outlet

Plug into an AC outlet.

AC cord*

* Product shape varies in

some countries.

teote:

NOTE

• Always turn the X (MAIN POWER) switch of the LCD TV set to OFF when connecting the AC adapter.

• Unplug the AC adapter from the LCD TV set and power outlet when the LCD TV set is not to be used for a long period of

time.

To POWER INPUT

terminal

AC adapter

Antenna connection

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are
used for coaxial cable.

(ex. For viewing both analogue and digital broadcasts)

75-ohm coaxial cable (round cable)
(commercially available)

(ex. For viewing analogue broadcasts)

• For viewing analogue broadcasts only, disconnect the
supplied antenna cable and connect the 75-ohm coaxial
cable (commercially available) to ANALOG (input)
terminal.

Antenna cables – commercially available

If your outdoor antenna uses a 75-ohm coaxial cable with a standard
DIN45325 plug (IEC 169-2), plug it into the
ANALOG (input) terminal at the rear of the TV.

Standard DIN45325 plug

(IEC169-2)

Antenna cable (supplied)

For viewing only digital broadcasts, you do not need to connect
the antenna cable.

• OUT and ANALOG (input) terminals are already connected
with the supplied antenna cable when shipped from the factory.

IN DIGITAL and/or

6

OK

End

E

First installation
(

Language

)

English
Deutsch
Français
Español
Italiano

Nederlands
Svenska
Português
Suomi
Türkçe

Preparation

First installation

When you turn on the LCD TV set for the first time, the First installation routine, which makes installation easier, is
activated. Using this routine, you can select the on-screen display language, and automatically search for and
store all the receivable channels.

X (MAIN POWER)

1

Press the MAIN POWER switch.
The “First installation (Language)”
screen with a list of the languages
for the on-screen display appears.

2

Press a/b/c/d to select the
desired language, and then press
OK. The “First installation
(Automatic search)” screen
appears in the language selected.

t

NOTE

• You can change the on-screen display language after the First installation routine by selecting

“Language” on the TV menu (see pages 33 and 34).

3

4

Press a/b to select the desired
adjustment item, and then press
OK. Then press c/d to select the
desired item.

Press a/b to select “Start search”.

First installation
(

Automatic search

)

Country [UK]
Colour system [ PAL]
Sound system [ I]
Start search

OK

First installation
(

Automatic search

R

Back

E

End

)

Country [UK]
Colour system [ PAL]
Sound system [ I]
Start search

• The input mode is automatically switched to AV1 when “First installation” is selected. If you selected “First installation”, and

want to return to the previous screen, press Flashback (A).

NOTE

tes:

5

6

Press OK to begin the automatic
programme search.

Press END to exit.

OK

Start search

759.25MHz Auto-B/G

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

Start search

Search is completed

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

R

8 SHARP
9
10
11
12
13
14
15

SHARP

8
9
10
11
12
13
14
15

Back

16
17
18
19
21
22
23
24

R

16
17
18
19
21
22
23
24

E

End

Cancel

E

End

7

Preparation

Virgin mode

Digital Video Broadcasting is a transmission scheme. It is much more than a simple replacement for existing
analogue television transmission. DVB provides more stations, clearer picture quality and other services to
be displayed on screen. It also allows a range of new features and services including subtitling and multiple
audio tracks.

For viewing digital broadcasts, please follow the procedure below to set up.

• In DTV mode, some menu items displayed in black cannot be selected.

1

2

3

4

5

• If you exit DTV mode while Virgin mode is still incomplete, go back to step 1 and try it again.

Press DTV to switch to the DTV
mode.

Press a/b to select the country
where you are located.
When you cannot find the country
you live in, select the country from
the list which shares the same time
zone.

Press OK to enter the setting.

• Installation screen displays.
Press OK to go to the next step.

Press a/b to select “Service
scan”, and then press OK.

• Search screen displays.

Press OK, and Search finds all the
digital broadcasting channels
viewable in your area.

• The Search menu disappears and
you can watch the programme.

tes:

NOTE

Country

esp

fin

fra

gbr

grc

Country

Service scan

System software

Search

Country list

aut: Austria
bel: Belgium
che: Switzerland
deu: Germany
dnk: Denmark
esp: Spain
fin: Finland
fra: France
gbr: United Kingdom

grc: Greece
ita: Italy
lux: Luxembourg
nld: Netherlands
nor: Norway
prt: Portugal
swe: Sweden
tur: Turkey

8

Part names – Main unit

Controls

Upper control panel

Volume (il/k)

CH (s)/(r)

MENU

TV/VIDEO

XX

X (MAIN POWER)

XX

To change the vertical angle of the LCD
TV set, tilt the screen up to 5 degrees
forward or 10 degrees backward. The
TV set can also be rotated 25 degrees
to right and left. Please adjust the angle
so that the TV set can be watched most
comfortably.

Speaker

Remote control sensor window

OPC sensor window

How to adjust the angle

Hold the carrying handle and tilt
the screen while steadying the
stand with your other hand.

Headphone jack

Remote control sensor indicator

A red indicator blinks when the TV set
receives the remote control signal.

OPC (Optical Picture Control) indicator

A green indicator lights when “Brightness” is
set to “auto”.

STANDBY/ON indicator

A green indicator lights when the power is
on and a red indicator lights when in the
standby mode (the indicator will not light

tes:Note:

NOTE

• TV/VIDEO, CH(s)/(r), Volume (il/k) and MENU on the main unit have the same functions as the same buttons on the remote

control. Basically, this operation manual provides a description based on operation using the remote control.

when the main power is off).

9

Part Names – Main Unit

Terminals

S-VIDEO

AV-IN3

AV-IN2 (AV)
(21pin Euro-SCART)

AV-IN1 (RGB)
(21pin Euro-SCART)

AUDIO OUT (DIGITAL)
POWER INPUT

DC13V

VIDEO
AUDIO (L)
AUDIO (R)

ANTENNA INPUT
(ANALOG TUNER)

EXTERNAL
SPEAKER (4Ω 5W)

OUT

IN

RS-232C*
terminal

C.I.
(Common
Interface)

See page 32.

* Terminal for expanded

functionality in the near
future.

ANTENNA
(DIGITAL
TUNER)

How to fix the cables

Cable clamps

• Secure cables and cords with the supplied
cable clamps so that they do not get caught
when mounting the cover.

• Use the opening under the centre terminal cover to
guide cables to the right side.

Cautions when bundling the cables

■ If you connect cables to every rear terminal on the left side, bundle the AV, S-Video and optical fibre cables
along with the AC cord together and guide them through the opening on the right side terminal cover.

For the two SCART cables, guide them through the opening on the left side terminal cover.

How to bundle and guide the cables through the opening to the right side:

■ The same as connecting the antenna cable. Guide the bundled cables under the centre terminal cover so they
come out of the opening on the right side.

10

Part names – Remote control unit

Remote control unit

1
2
3
4

5

6
7
8
9

10
11
12

13

1 B (STANDBY/ON)

To switch the power on and off. (See page 13.)

2 k (Reveal hidden for TELETEXT)

TELETEXT mode: Display hidden characters.
(See page 55.)

3 [ (SUBTITLE for TELETEXT)

Analogue TV: To turn the subtitles on and off. (See
page 56.)
Digital mode: Display the subtitle selection
screen.

4 (HOLD for TELETEXT)

TELETEXT mode: Hold the current teletext page.
(See page 55.)

5 f (WIDE MODE)

TV/External input mode: Change the wide image
mode. (See page 42.)

6 SOUND

Select the sound multiplex mode. (See pages 53
and 54.)

7 ]

Select Virtual Dolby Surround settings. (See page

37.)

8 A (Flashback)

Press to return to the previous channel in normal
viewing mode.
Press to return to the previous page in TELETEXT
mode.

9 il/ik (VOLUME)

Set the volume. (See page 14.)

10 LIST

Digital mode: Display the favourite digital
programme list.

11 GUIDE

Digital mode: To Display EPG (Electronic
Programme Guide) screen.

12 DTV MENU

Digital mode: Display the digital TV menu screen.

13 END/EXIT

Turn off the On-screen display.

NOTE

• When using the remote control unit, point it at the Display.

11

Part names – Remote control unit

14
15
16
17

18
19

20
21

22
23

24
25
26

27

28

14 p (DISPLAY/INFO)

Analogue TV: Display the programme number
and time. (See page 57 for details on the time
display.)
Digital TV: Display the programme information.

15 b (INPUT SOURCE)

Select an input source. (TV, DTV, AV1, AV2, AV3)
(See pages 13 and 15.)

16 l (TOP Overview for TELETEXT)

TELETEXT mode: Display an index page for
CEEFAX/FLOF information. TOP Overview for TOP
programme. (See page 56.)

17 m (TELETEXT)

Select the TELETEXT mode. (all TV image, DTV/
DATA image, all TEXT image, TV/TEXT image)
(See pages 55 and 56.)
Digital mode: Select DTV data broadcasting and
TELETEXT.

18 ROTATE

Set the orientation of the picture. (See page 46.)

19 0 – 9

TV/External input mode: Set the channel.
TELETEXT mode: Set the page.

20 DTV

Switch from the Digital-TV mode and other input
source.
For example, when viewing an image from AV2,
press DTV to switch to the Digital-TV mode. Press

DTV again to return to AV2 screen.

21 Colour (RED/GREEN/YELLOW/BLUE)

TELETEXT mode: Select a page. (See page 55.)
DTV mode: The coloured buttons are used to
select correspondingly to the coloured items in
the menu screen.

22 CHa/CHb

TV/External input mode: Select the channel.
TELETEXT mode: Set the page. (See page 55.)

23 SLEEP

Display sleep timer information. (See page 52.)

24 e (MUTE)

Mute the sound. (See page 14.)

25 MENU

Display the analogue TV menu screen.

26 OK

Execute a command.

27 RETURN

MENU mode: Return to the previous menu
screen.

28 a/b/c/d (Cursor)

Select a desired item on the setting screen.
DTV mode: Select the channel with a/b.
Select the programme information area when
EPG is displayed.

TELETEXT mode: Set the area of magnification.
(full/upper half/lower half) (See page 55.)

12

AV3

DTV

AV1

AV2

1 S06

Basic operation

Turning the main power on and off

X (MAIN POWER)

STANDBY/ON
indicator

|

• The On-screen indicator disappears after a few
seconds.

|

STANDBY/ON

To turn off the LCD TV

Press B. The STANDBY/ON indicator will turn red.

To turn the LCD TV back on

Press B again. The STANDBY/ON indicator will turn green.

Switching the TV/VIDEO (TV/DTV/AV1/AV2/AV3) mode

Press the

XX

X (MAIN POWER) switch. The

XX

STANDBY/ON indicator instantaneously
changes from red to green and the main unit
is turned on.

NOTE

To turn off the main power, press the

XX

X

XX

(MAIN POWER) switch.

On-screen display

1 S06

1

Turn on the power of the connected video
equipment.

2

Press b to select the applicable input
source. The screen displays DTV, AV1, AV2,
AV3 or TV mode each time b is pressed.

NOTE

• About the video modes
TV: Select this when viewing analogue TV broadcasts.
DTV: Select this when viewing digital TV broadcasts.
AV1 and 2: Select this when viewing the signals

AV3: Select this when viewing the signals

• If both VIDEO and S-VIDEO terminals are connected
with cables, the S-VIDEO input terminal is selected as
the high priority.

from the video equipment connected to
the AV-IN 1 and 2 terminals.

from the video equipment connected to
the AV-IN 3 terminals using the VIDEO
or S-VIDEO terminal for video input.

Listening with headphones

■ Plug the headphone mini-plug into the headphone jack located on the front of the TV set.

Headph. vol.

30

OK

Headphones

NOTE

• Headphones are not included in the supplied accessories.

• Even if a headphone mini-plug is connected to the headphone jack, sound can be heard from the main unit speaker.

Please refer to page 36 to adjust the
sound volume.

0

R

Back

E

End

13

Basic operation

Control panel of the

main unit

Volume

(il/k)

CH s/r

Sound volume

To adjust the volume

Press ik to increase the sound volume. The

|

bar indicator shifts right.

Press il to decrease the sound volume. The

|

bar indicator shifts left.

To mute the sound

Press e (Mute) to temporarily turn off the sound.

|

“Sound off” is displayed.

Press e (Mute) to turn off the Mute function.

|

“Sound on” is displayed.

NOTE

• When Volume i (k/l) is pressed in the Mute mode,

the sound turns on and the volume indicator is displayed.

• The Mute function is cancelled when

BB

B is pressed.

BB

Volume
50

Volume
10

Sound off

Sound on

Changing channels

You can select channels using 0 – 9 or CH a/b.

• To handle the increasing number of channels available, this LCD TV set allows you
to select up to 200 channels (0 to 199).

Using 0 – 9 on the remote control unit

Select the channels directly by pressing buttons 0 – 9.

When selecting the channel using 0 – 9, finish inputting the channel number by holding
down the button for the last digit for a moment.

a

To select a 1-digit channel (e.g. channel 2):

• Press the 2 button.
To select a 2-digit channel (e.g. channel 12):

• Press 1, followed by 2.

• When you enter the channel, a 3-digit input underbar appears in digital TV mode and a 2-digit in
analogue TV mode.
Once you input a channel it is set after a few moments if there are no other operations. Or press OK
to set immediately after input.

Using CH a/b

Press CH a and the channels change in the order shown below:

1 → 2 → 3 → . . . → 198 → 199 → 0 → 1 → 2 → 3 → . . .

Press CH b and the channels change in the order shown below:

3 → 2 → 1 → 0 → 199 → 198 → . . . → 3 → 2 → 1 → . . .

14

NOTE

• Channel “0” is reserved for RF output of VCR.

• Complete this procedure within 3 seconds, otherwise the selection will not be made on the 2­digit channel mode.

When viewing Teletext information

View a page directly which is 3-digit page number from 100 to 899 by pressing buttons 0 – 9.

Using Flashback (A) on the remote control unit

Press A to switch the currently tuned channel to the previously tuned channel.
Press A again to switch back to the currently tuned channel.

Digital TV features

Selecting digital menu items

List of DTV menu items to help you with operations.

Numbers within brackets indicate the page where the topic is explained.

Guide
(RED)

Theme [25]
Mode [25]

Setup
(GREEN)

Preference
(BLUE)

Service lists Service list type

TV service lists

Radio services lists

System setting Languages Audio [20]

Time Zone [16]

Banner duration [19]

Installation Country [31]

Service scan Search [16]

Reinstall all services [22]

System software [31]

Access restrictions Maturity rating [22]

TV services [23]
Radio services [23]

Audio lang. [26]

Subtitle lang. [26]

Rearrange TV services [28]
New TV services [29]

Installed TV services [30]

Uninstalled TV services [30]
Rearrange radio services [28]

New radio services [29]

Installed radio services [30]

Uninstalled radio services [30]

Subtitle [20]

Teletext [21]

Found TV services [17]

Found radio services [17]

Store [18]

Discard [18]

NOTE

• mark indicates in some cases PIN input may be required.

• The illustrations and on-screen displays in this manual are for explanation purposes and may vary slightly from the actual
operations.

Selecting DTV mode

Press b to toggle between TV/DTV/AV1/AV2/AV3 mode.
Press DTV MENU to directly display DTV menu screen.

About colour buttons

Press DTV MENU to display the DTV Menu screen.

Guide Setup Preference

Simply press colour button (RED/GREEN/BLUE) to directly display desired DTV
menu.

Guide: RED button
Setup: GREEN button
Preference: BLUE button

15

Digital TV features

Time Zone

Select the time zone where your TV is installed.

1

2

3

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “System setting”, and
then press OK.

Service lists

System setting

Installation

Access restrictions

Search

You can also search and download TV channels while
keeping the original channel information by performing
the procedure below.

1

2

3

4

5

6

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Installation”, and then
press OK.

Press a/b to select “Service scan”, and then
press OK.

Press a/b to select “Search”, and then
press OK.

Search

Found TV services

Found radio services

Store

Discard

If you already set the PIN, enter it here. If
not, enter the factory preset PIN “1234”.

• See page 47 for setting PIN.

4

5

Press a/b to select “Time Zone”, and then
press OK.

Languages

Time Zone

Banner duration

Press a/b to select the Time Zone where
you are located, and then press OK.

Time Zone

[GMT] Lisbon, London

[GMT+ 1:00] Amsterdam, Berlin, Bern

[GMT+ 1:00] Brussels, Copenhagen

[GMT+ 1:00] Luxembourg, Madrid, Oslo

[GMT+ 1:00] Paris, Rome, Stockholm, Vienna

Search

• This window may remain blank for a short
period until services are found.

7

• If you only perform “Search”, you will not be able to watch
programmes that were found. To watch programmes found
by “Search”, you have to perform “Store”. For details about
“Store” see page 18.

After “Search” is finished, press OK and
“Store”.

NOTE

16

Digital TV features

Found TV services

The Found TV services function is used to see which
new TV services were found after performing a search
or after Reinstalling all services.

1

2

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Found radio services

The Found radio services function is used to see which
new radio services were found after performing a
search or after Reinstalling all services.

1

2

3

4

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Installation”, and then
press OK.

Press a/b to select “Service scan”, and then
press OK.

Country

Service scan

Reinstall all services

System software

3

4

5

Press a/b to select “Installation”, and then
press OK.

Press a/b to select “Service scan”, and then
press OK.

Country

Service scan

Reinstall all services

System software

Press a/b to select “Found TV services”,
and then press OK.

Search

Found TV services

Found radio services

Store

Discard

Found TV services

1 - BBC ONE

2 - BBC TWO

7 - BBC CHOICE

10- BBC TEXT

11 - BBC NEWS 24

5

Press a/b to select “Found radio services”,
and then press OK.

Search

Found TV services

Found radio services

Store

Discard

Found radio services

999 - BBC PARLMNT

17

Digital TV features

Store

Store all found services.

NOTE

• This item can only be selected after performing “Search”
or “Reinstall all services”.

1

Press DTV MENU to display the DTV Menu
screen.

Discard

Discard all services stored.

NOTE

• This item can only be selected after performing “Search”
or “Reinstall all services”.

1

2

3

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press GREEN button to display the Setup
menu.

Press a/b to select “Installation”, and then
press OK.

Service lists

System setting

Installation

Access restrictions

2

3

4

5

Guide Setup Preference

Press GREEN button to display the Setup
menu.

Press a/b to select “Installation”, and then
press OK.

Press a/b to select “Service scan”, and then
press OK.

Country

Service scan

Reinstall all services

System software

Press a/b to select “Store”, and then press
OK.

Search

Found TV services

Found radio services

Store

Discard

4

5

6

Press a/b to select “Service scan”, and then
press OK.

Country

Service scan

Reinstall all services

System software

Press a/b to select “Discard”, and then
press OK.

Search

Found TV services

Found radio services

Store

Discard

Press c/d to select “Yes”, and then press
OK.

Discard

Yes No

18

6

Press c/d to select “Yes”, and then press
OK.

Store

Yes No

Digital TV features

Banner duration

You can set the time (in seconds) to display the banner.

1

2

3

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “System setting”, and
then press OK.

Service lists

System setting

Installation

Access restrictions

Info banner

You can see the info banner while you are watching a
programme.

1

2

3

• The info banner displays each time you change the
channel.

• Some programmes do not contain any detailed
programme information.

• It may take a few moments to download the info banner
data.

Press p.

1 BBC ONE 14:47

Health & Sport

Current affairs 13:30-13:45 Min. left: 0

• The banner display time will vary depending
on its setting.

While the info banner is displaying, press p
again to display the detailed programme
information.

Press p to turn off the info banner and the
detailed programme information.

NOTE

4

5

Press a/b to select “Banner duration”, and
then press OK.

Languages

Time Zone

Banner duration

Press a/b to select the desired time, and
then press OK.

Banner duration

2

4

8

16

• Unit: seconds

19

Digital TV features

Audio

Select the default audio language for all services.

1

2

3

4

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “System setting”, and
then press OK.

Press a/b to select “Languages”, and then
press OK.

Subtitle

Select the default subtitle language for all services.

1

2

3

4

5

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “System setting”, and
then press OK.

Press a/b to select “Languages”, and then
press OK.

Languages

Time Zone

Banner duration

Press a/b to select “Subtitle”, and then
press OK.

Audio

Subtitle

Teletext

5

6

Languages

Time Zone

Banner duration

Press a/b to select “Audio”, and then press
OK.

Audio

Subtitle

Teletext

Press a/b to select the desired language,
and then press OK.

Audio

eng

nld

ger

fin

fra

• Languages listed may be different for each
programme.

• For details about the language list see page

21.

6

Press a/b to select the desired language,
and then press OK.

Subtitle

eng

nld

ger

fin

fra

• Languages listed may be different for each
programme.

• If you select “None”, no subtitles will be
displayed.

• For details about the language list see page

21.

20

Digital TV features

Teletext

Select the default teletext language for all services.

1

2

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

baq: Basque
cat: Catalan
ces: Czech
wel: Welsh
dan: Danish
ger: German
dut: Dutch
gre: Greek
eng: English
fin: Finnish
fre: French
gla: Gaelic

Language list

glg: Galician
cro: Croatian
ita: Italian
nor: Norwegian
pol: Polish
por: Portuguese
rus: Russian
slo: Slovak
spa: Spanish
scc: Serb
swe: Swedish
tur: Turkish

3

4

5

6

Press a/b to select “System setting”, and
then press OK.

Press a/b to select “Languages”, and then
press OK.

Languages

Time Zone

Banner duration

Press a/b to select “Teletext”, and then
press OK.

Audio

Subtitle

Teletext

Press a/b to select the desired language,
and then press OK.

Teletext

eng

nld

ger

fin

fra

• Languages listed in the list differ to each
programme.

21

Digital TV features

Reinstall all services

Cancel all channel information then download and
install again.

1

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Access restrictions

Allows you to set the PIN to limit viewing certain
services and protect certain settings from being
accidentally changed.

Maturity rating

This function allows TV and Radio services to be
restricted. It prevents children from watching violent
or sexual scenes that may be harmful.

1

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

2

3

4

5

6

Press the GREEN button to display the Setup
menu.

Press a/b to select “Installation”, and then
press OK.

Press a/b to select “Reinstall all services”,
and then press OK.
If you already set the PIN, enter it here. If
not, enter the factory preset PIN “1234”.

• See page 47 for setting PIN.

Country

Service scan

Reinstall all services

System software

Press c/d to select “Yes”, and then press
OK.

Reinstall all services

Yes No

After “Reinstall all services” is finished, press
OK and “Store”.

• If you only perform “Reinstall all services”, you
will not be able to watch programmes that were
found. To watch programmes found by
“Reinstall all services”, you have to perform
“Store”. For details about “Store” see page 18.

2

Press the GREEN button to display the Setup
menu.

3

Press a/b to select “Access restrictions”,
and then press OK.

4

Press a/b to select “Maturity rating”, and
then press OK.
If you already set the PIN, enter it here. If
not, enter the factory preset PIN “1234”.

• See page 47 for setting PIN.

Maturity rating

TV services

Radio services

5

Press a/b to select the rating you want to
set, and then press OK.

Maturity rating

None

age 4

age 5

age 6

age 7

NOTE

• Universal viewing and Parental approval preferable only
work in France.

• X-rated only works in Spain.

• For details about rating see page 64.

22

Digital TV features

TV Services

Use this function to restrict certain TV services for
viewing.

1

2

3

4

5

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Access restrictions”,
and then press OK.

Service lists

System setting

Installation

Access restrictions

Press a/b to select “TV services”, and then
press OK.
If you already set the PIN, enter it here. If
not, enter the factory preset PIN “1234”.

• See page 47 for setting PIN.

Maturity rating

TV services

Radio services

Press a/b to select the TV services you want
to restrict, then press c/d to select the
programme, and then press OK.

TV services

1 - BBC ONE

2 - BBC TWO

7 - BBC CHOICE

10- BBC TEXT

11 - BBC NEWS 24

Radio Services

Use this function to restrict certain Radio services for
viewing.

1

2

3

4

5

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Access restrictions”,
and then press OK.

Service lists

System setting

Installation

Access restrictions

Press a/b to select “Radio services”, and
then press OK.
If you already set the PIN, enter it here. If
not, enter the factory preset PIN “1234”.

• See page 47 for setting PIN.

Maturity rating

TV services

Radio services

Press a/b to select the Radio services you
want to restrict, then press c/d to select
the programme, and then press OK.

Radio services

1 - BBC Radio 1

2 - BBC Radio 2

3 - BBC Radio 3

6 - BBC 6 Music

8 - BBC Asian Network

23

Digital TV features

Selecting programme

You can select a programme from the preset list.

1

2

Press LIST.

Press a/b to select the desired programme,
and then press OK.

Preset list

1 - BBC ONE

2 - BBC TWO

7 - BBC CHOICE

10- BBC TEXT

11 - BBC NEWS 24

12 - BBC PARLMNT

997 - ZDFinfokanal

998 - ZDFdokukanal

999 - ZDF

• Data is broadcast along with the regular TV
programme.

Using EPG (Electronic Programme Guide)

You can select a programme from EPG while reading
the programme information on the screen.

1

2

• Press END/EXIT to return to the normal screen from EPG
screen without selecting a programme.
You cannot return to the normal screen by pressing
GUIDE.

Press GUIDE.

Now Next

1

BBC ONE

Trading Treasures 13:45 Passport To The Sun

2

BBC TWO

Anthony Ant 13:45 UGetMe

7

BBC CHOICE

Newsround 13:45 House Invaders

10

BBC TEXT

Mona the Vampire 13:45 Neighbours

11

BBC NEW ...

BBC News 14:00 BBC World News

12

BBC ...

Home Affairs Committee 14:00 Home Affairs Committee

997

ZDFinfo...

Gesun dheit &Sport 14:00 Info aus den Landern

999

ZDFdok...

National Geographic 14:00 Streit um Drei

999

ZDF

Discovery

Theme Mode

14:00 Heute - Sport

Press a/b/c/d to select a desired
programme, and then press OK.

• Information of the selected programme is
displayed on the banner.

NOTE

1 BBC ONE 14:47

Health & Sport

Current affairs 13:30-13:45 Min. left: 0

NOTE

• When the DTV menu screen is displayed, the Preset list
will not appear. In such case, press DTV MENU to turn off
the DTV menu screen.

24

Digital TV features

Setting the theme

You can categorise the programmes for easy channel
selection.

1

2

3

Press GUIDE to display the EPG screen.

Now Next

1

BBC ONE

Trading Treasures 13:45 Passport To The Sun

2

BBC TWO

Anthony Ant 13:45 UGetMe

7

BBC CHOICE

Newsround 13:45 House Invaders

10

BBC TEXT

Mona the Vampire 13:45 Neighbours

11

BBC NEW ...

BBC News 14:00 BBC World News

12

BBC ...

Home Affairs Committee 14:00 Home Affairs Committee

997

ZDFinfo...

Gesun dheit &Sport 14:00 Info aus den Landern

999

ZDFdok...

National Geographic 14:00 Streit um Drei

999

ZDF

Discovery

Theme Mode

14:00 Heute - Sport

Press RED button to display the Theme
screen.

Press a/b to select the desired category,
then press c/d to activate and then, press
OK.

• You can select multiple categories.

General

Movie

News

Entertainment

Sports

Mode

You can choose between TV and radio mode.

1

2

Press GUIDE.

Now Next

1

BBC ONE

Trading Treasures 13:45 Passport To The Sun

2

BBC TWO

Anthony Ant 13:45 UGetMe

7

BBC CHOICE

Newsround 13:45 House Invaders

10

BBC TEXT

Mona the Vampire 13:45 Neighbours

11

BBC NEW ...

BBC News 14:00 BBC World News

12

BBC ...

Home Affairs Committee 14:00 Home Affairs Committee

997

ZDFinfo...

Gesun dheit &Sport 14:00 Info aus den Landern

999

ZDFdok...

National Geographic 14:00 Streit um Drei

999

ZDF

Discovery

Theme Mode

14:00 Heute - Sport

Press the GREEN button to change to radio
mode.

Now Next

999

BBC...

House of Commons 13:45 House of Lords

Now Next

1

BBC ONE

Trading Treasures 13:45 Passport To The Sun

2

BBC TWO

Anthony Ant 13:45 UGetMe

7

BBC CHOICE

Newsround 13:45 House Invaders

10

BBC TEXT

Mona the Vampire 13:45 Neighbours

11

BBC NEW ...

BBC News 14:00 BBC World News

12

BBC ...

Home Affairs Committee 14:00 Home Affairs Committee

997

ZDFinfo...

Gesun dheit &Sport 14:00 Info aus den Landern

999

ZDFdok...

National Geographic 14:00 Streit um Drei

999

ZDF

Discovery

Theme Mode

14:00 Heute - Sport

• The categorised programmes are displayed in
blue.

NOTE

• If no services are found or received, the theme screen
will not appear.

Theme Mode

• Each time you press the GREEN button, the
mode will change between TV and radio.

• When caution appears in radio mode screen,
press END to turn it off.

25

Digital TV features

Audio lang. Subtitle lang.

Audio language

You can select the preferred audio language from the
list.

1

2

3

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the BLUE button to display the
Preference menu.

Press the RED button to display the Audio
language screen.

Subtitle language

You can select the preferred subtitle language from
the list.

1

2

3

4

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the BLUE button to display the
Preference menu.

Press the GREEN button to display the
Subtitle language screen.

Press a/b to select the desired language,
and then press OK.

Subtitle language

eng

nld

ger

fin

fra

4

Audio lang. Subtitle lang.

Press a/b to select the desired language,
and then press OK.

Audio language

eng

nld

ger

fin

fra

• Languages listed in the list differ to each
programme.

• This setting is disabled if the channel is
changed or the programme is finished.

• For details about setting the default language
see page 20.

• Languages listed in the list differ to each
programme.

• If you select “None”, no subtitles will be
displayed.

• This setting is disabled if the channel is
changed or the programme is finished.

• For details about setting the default language
see page 20.

26

Digital TV features

Service list type

You can select the original service list or a user-defined
list.

1

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Selected item

Original list of
services

User-definable
list of services

NOTE

• When “Original list of services” is selected, the settings
for “TV service lists” and “Radio service lists” are disabled
and you cannot select “TV service lists”, “Radio service
lists” and “Access restrictions” in the menu screen.

Original setting.

The setting user made is enabled.

Description

2

3

4

5

Press the GREEN button to display the Setup
menu.

Press a/b to select “Service lists”, and then
press OK.

Service lists

System setting

Installation

Access restrictions

Press a/b to select “Service list type”, and
then press OK.

Press a/b to select “Original list of services”
or “User-definable list of services”, and then
press OK.

Service list type

Original list of services

User-definable list of services

27

Digital TV features

Rearrange TV services

Channel positions can be sorted freely.

1

2

3

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Service lists”, and then
press OK.

6

7

8

Press a/b to select the channel you want
to move and press c/d to select the item.

Move it to the desired position by pressing
a/b, and then press c/d.

Repeat the steps 6 and 7 until all desired
channels are arranged.

Rearrange TV services

1 - BBC ONE

2 - BBC TWO

7 - BBC CHOICE

10- BBC TEXT

11 - BBC NEWS 24

Rearrange TV services

1 - BBC ONE

2 - BBC TWO

7 - BBC CHOICE

10- BBC TEXT

11 - BBC NEWS 24

4

5

Service lists

System setting

Installation

Access restrictions

Press a/b to select “TV service lists”, and
then press OK.

Service list type

TV service lists

Radio service lists

Press a/b to select the “Rearrange TV
services”, and then press OK.

Rearrange TV services

New TV services

Installed TV services

Uninstalled TV services

Rearrange TV services

10- BBC TEXT

2 - BBC TWO

7 - BBC CHOICE

1 - BBC ONE

11 - BBC NEWS 24

Rearrange radio services

To perform “Rearrange radio services”, select “Radio
service lists” instead of “TV service lists” in step 4
above and follow the same steps 5 to 8 as explained
in “Rearrange TV services”.

28

Digital TV features

New TV services

Displays a list with all new installed TV services.

1

2

3

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Service lists”, and then
press OK.

Service lists

System setting

Installation

Access restrictions

New radio services

Displays a list with all new installed radio services.

1

2

3

4

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Service lists”, and then
press OK.

Service lists

System setting

Installation

Access restrictions

Press a/b to select “Radio service lists”,
and then press OK.

Service list type

TV service lists

Radio service lists

4

5

Press a/b to select “TV service lists”, and
then press OK.

Service list type

TV service lists

Radio service lists

Press a/b to select the “New TV services”,
and then press OK.

Rearrange TV services

New TV services

Installed TV services

Uninstalled TV services

New TV services

997 - ZDFinfokanal

998 - ZDFdokukanal

999 - ZDF

5

Press a/ b to select the “New radio
services”, and then press OK.

Rearrange radio services

New radio services

Installed radio services

Uninstalled radio services

New radio services

6 - BBC 6 Music

8 - BBC Asian Network

9 - BBC World Service

• The services found by search are listed.

• The services found by search are listed.

29

Digital TV features

Installed TV services

You can confirm the installed services and delete the
unwanted services from the TV service list.

1

2

3

4

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Service lists”, and then
press OK.

Press a/b to select “TV service lists”, and
then press OK.

Uninstalled TV services

You can confirm the uninstalled services and put the
services back to the TV service list.

1

2

3

4

5

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Press a/b to select “Service lists”, and then
press OK.

Press a/b to select “TV service lists”, and
then press OK.

Press a/b to select the “Uninstalled TV
services”, and then press OK.

Rearrange TV services

New TV services

Installed TV services

Uninstalled TV services

5

6

Press a/b to select the “Installed TV
services”, and then press OK.

Rearrange TV services

New TV services

Installed TV services

Uninstalled TV services

Press a/b to select the channel you want
to delete from the list, then press c/d to
select the item, and then press OK.

• The channel you deleted is moved to
Uninstalled TV service list.

Installed TV services

1 - BBC ONE

2 - BBC TWO

7 - BBC CHOICE

10- BBC TEXT

11 - BBC NEWS 24

6

Press a/b to select the channel you want
to put to the installed TV services list, then
press c/d to select the item, and then press
OK.

Uninstalled TV services

BBC ONE

BBC TWO

BBC CHOICE

BBC TEXT

BBC NEWS 24

Uninstalled radio services

To perform “Uninstalled radio services”, select “Radio
service lists” instead of “TV service lists” in step 4
above and follow the same steps 5 and 6 as explained
in “Uninstalled TV services”.

Installed radio services

To perform “Installed radio services”, select “Radio
service lists” instead of “TV service lists” in step 4
above and follow the same steps 5 and 6 as explained
in “Installed TV services”.

30

Digital TV features

Country

Select the country where you are located.

1

2

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

Country list

aut: Austria
bel: Belgium
che: Switzerland
deu: Germany
dnk: Denmark
esp: Spain
fin: Finland
fra: France
gbr: United Kingdom

grc: Greece
ita: Italy
lux: Luxembourg
nld: Netherlands
nor: Norway
prt: Portugal
swe: Sweden
tur: Turkey

System software

Displays System Software version information.

1

2

Press DTV MENU to display the DTV Menu
screen.

Guide Setup Preference

Press the GREEN button to display the Setup
menu.

3

4

5

Press a/b to select “Installation”, and then
press OK.

Service lists

System setting

Installation

Access restrictions

Press a/b to select “Country”, and then
press OK.
If you already set the PIN, enter it here. If
not, enter the factory preset PIN “1234”.

• See page 47 for setting PIN.

Country

Service scan

Reinstall all services

System software

Press a/b to select the country where you
are located, and then press OK.

Country

esp

fin

fra

gbr

grc

3

4

Press a/b to select “Installation”, and then
press OK.

Service lists

System setting

Installation

Access restrictions

Press a/b to select “System software”, and
then press OK.

Country

Service scan

Reinstall all services

System software

Example

System software

V

1.0

• The version number may be different
dependent on the installed software.

NOTE

The following information is supported by selecting country:

• The logical channel numbering.

• The frequency band to be scanned during service scan.

• The maturity rating settings to be used.

• The time zone to be used.

• The daylight saving time period to be used.

31

Digital TV features

Icons

1 General EPG icon.

2 Indicates that at least one theme is selected.

12

3 Indicates that additional event information is

4 Indicates that at least one subtitle language is

345

5 Indicates that at least two audio languages are

6 General setup menu icon.

6

available.

available.

available.

Common Interface

A single DVB Common Interface (CI) will be implemented to allow adoption of a Conditional Access (CA)
system by means of a plug-in CA module.
Scrambled Broadcasting service can be routed via the CA system.
If the CA system on the CI module requires a smart-card reader, this reader shall be part of the CI module.

When the compatible CA card is inserted, you can view the
programme without any operations.

When the compatible card is not inserted:

1 Select the programme which needs the compatible

CA card.

• The caution screen appears

2 Insert the compatible CA card.

Common
Interface
Module

CA card

• The caution screen disappears and you can view
the programme.

CA system supported by

Crypto Works
MediaGuard
VIAccess
Conax
Nagra Vision
Irdeto

32

NOTE

• To view paid TV broadcasting, you need to make a contract
with a service provider.
Please contact a service provider for details.

• The Common Interface Module and the CA card are
neither supplied nor optional accessories.

• The RS-232C terminal is for future expansion only and
cannot be used for PC control of the unit.

Useful features

• The menus can be used to adjust the various settings of your LCD TV set.

■ Using TV Menus

Selecting menu items

Select the desired menu item by following the steps below.

1

2

3

4

5

Press MENU on the remote control to display
the TV menu.

Press a/b to select the desired menu item.

• The cursor moves up or down.

• The cursor indicates the selected menu item.

Press OK to display the setting screen for the
selected menu item.

• Press OK again to adjust the selected item.

• See the next page for a table of the setting
screens.

Press c/d to adjust the selected item.

Press RETURN to return to the previous
screen or END to return to the normal screen.

TV menu

Sound
Features
AV connections
Timer functions
Language

OK

R

Back

E

• “Programmes” and “First
installation” appear only
when PIN for Child lock is
entered (see page 47).

• During DTV mode,
“Programmes” and “First
installation” do not appear.

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

R

Back

E

End

End

Control panel of the

main unit

Volume

(il/k)

CH
(s/r)

MENU

TV/VIDEO

■ Using Direct Control Menu

1

2

3

4

5

• The items displayed differ depending on the setting condi­tions.

• The item selected is displayed in yellow.

• Settings most recently adjusted will be saved in memory.

Press MENU on the main unit to display the
TV menu.

Press CH s/r to select the desired menu
item.

• The cursor moves up or down.

• The cursor indicates the selected menu item.

Press TV/VIDEO to display the setting screen
for the selected menu item.

• Press TV/VIDEO again to adjust the selected
item.

Press il/k to make the adjustment.

Press MENU to return to the previous screen.

• Each time MENU is pressed, you will return to
the previous screen.

te:

NOTE

TV menu

Sound
Features
AV connections
Timer functions
Language

OK

R

Back

E

• “Programmes” and “First
installation” appear only
when PIN for Child lock is
entered (see page 47).

• During DTV mode,
“Programmes” and “First
installation” do not appear.

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

End

OK

R

Back

E

End

33

Useful features

Selecting menu items (Continued)

■ TV Menu Setting Screens

For details on using each setting screen, refer to the page number indicated.

(Page 35)

Picture menu

Contrast [ 30]
Colour [ 0]
Black level [ 0]
Sharpness [ 0]
Red-Blue [ 0]
Green [ 0]
Tint [ 0]
Reset

0
0
0
0
0
0
0

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

R

Back

E

End

•“Programmes” and “First
installation” appear only
when PIN for Child lock is
entered (see page 47).

(Page 52)

Timer functions
Time [ : : ]

Sleep Timer [ no]
Alarm [ no]
Alarm volume [ 0]

OK

R

Back

E

0

End

(Page 7)

First installation
(

Language

English
Deutsch
Français
Español
Italiano

OK

)

Nederlands
Svenska
Português
Suomi
Türkçe

E

End

(Page 7)

Language

English
Deutsch
Français
Español
Italiano

Nederlands
Svenska
Português
Suomi
Türkçe

OK

R

Back

E

End

(Page 36)

Sound menu

Headph. vol. [ 30]
Loudsp. sound[ Stereo]
Headph. sound[ Stereo]
AV audio sig.[Sound1+2]
Dolby Virtual[ off]
Treble [ ]
Bass [ ]
Balance [ ]

OK

R

Back

E

0

0
0
0

End

(Pages 38–41)

Programmes

Automatic search
Manual adjustment
Sort
Erase programme range
Enter/Change name

OK

R

Back

E

End

(Pages 43–49)

Features

Brightness [bright]
Cool climate [
V.Position
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]
Speaker [Detachable]
On-screen display
Child lock

OK

R

Back

off

[ 0]

E

End

]

0

(Pages 50–51)

AV connections

AV1
AV2
AV3(Y/C)
AV3(CVBS)
For programmes

OK

R

Back

E

End

OK

R

Back

E

End

NOTE

• The illustrations and on-screen displays in this manual are for explanation purposes and may vary slightly from the actual
operations.

34

OK

Back

R

End

E

Picture menu

Contrast [ 30]
Colour [ 0]
Black level [ 0]
Sharpness [ 0]
Red-Blue [ 0]
Green [ 0]
Tint [ 0]
Reset

0
0
0
0
0
0
0

OK

Back

R

End

E

Contrast

30

0

Useful features


1

2

3

4

5

Press MENU to display the TV menu.

Press a/b to select “Picture”, and then
press OK.

Press a/b to select the desired adjustment
item, and then press OK.

• The next menu appears.

Press c/d to make the adjustment.

Press END to exit.

Adjustment item

Contrast

Colour

Black level

Sharpness

Red-Blue

Green

Tint *

Reset

* “Tint” is only visible when “N358” or “N443” signal has been input into the unit.

Press Left (c)

Decrease contrast

Lower colour intensity

Less brightness

Soft picture

More red

Less green

Towards purple

Reset value (Press OK.)

Choice/Value range

0 – 60

-30 – 30

-30 – 30

-30 – 30

-30 – 30

-30 – 30

-30 – 30

Press Right (d)

Increase contrast

Higher colour intensity

More brightness

Sharp picture

More blue

More green

Towards green

35

OK

Back

R

End

E

Sound menu

Headph. vol. [ 3 ]
Loudsp. sound[ Stereo]
Headph. sound[ Stereo]
AV audio sig.[Sound1+2]
Dolby Virtual[ off]
Treble [ ]
Bass [ ]
Balance [ ]

0

0
0
0

Useful features

Sound

Adjustment item

Headph. vol.

Loudsp. sound*

Headph. sound*

1

2

Press MENU to display the TV menu.

Press a/b to select “Sound”, and then
press OK.

3

Press a/b to select the desired adjustment
item, and then press OK.

• Each item can now be selected or the next
menu appears.

4

5

Press c/d to make the adjustment.

Press END to exit.

Press Left (c)

Decrease headphones
volume

–

Choice/Value range

0 – 60

Stereo↔Mono/Sound1

↔

Sound2↔Sound1+2↔Mono

Nicam↔Mono/Mono

(* The choices differ depending on
whether or not a NICAM or A2 stereo
signal is received.) See pages 53 and 54.

Headph. vol.

30

OK

R

Back

0

Press Right (d)

Increase headphones
volume

–

E

End

AV audio sig.

Dolby Virtual

Treble

Bass

Balance**

* During DTV mode, “Loudsp. sound” and “Headph. sound” do not appear.
** “Balance” is not selectable when “Dolby Virtual” is set to “on”.

For weaker treble

For weaker bass

Increase the volume of
the left speaker

–

–

Sound1↔Sound2↔Sound1+2

on↔off

-30 – 30

-30 – 30

-30 – 30

–

–

For stronger treble

For stronger bass

Increase the volume of the
right speaker

NOTE

• In the “AV audio sig.” item, mono-video recorders should select “Sound1” or “Sound2”. Stereo-video recorders should select
“Sound1+2” so that the desired sound can be selected when playing back the video.

36

Useful features

OK

Back

R

End

E

Sound menu

Headph. vol. [ 3 ]
Loudsp. sound[ Stereo]
Headph. sound[ Stereo]
AV audio sig.[Sound1+2]
Dolby Virtual[ off]
Treble [ ]
Bass [ ]
Balance [ ]

0

0
0
0

Dolby Virtual

You can enjoy the Surround 2ch stereo with Dolby Pro Logic II technology.

Virtual Dolby Surround is a technology certified by Dolby Laboratories that creates a
virtualised surround sound experience from two speakers using Dolby Pro Logic or Dolby
Pro Logic II.

Virtual Dolby Surround retains all the original multichannel audio information and pro­vides the listener with the sensation of being surrounded by additional speakers.

Directly setting the Virtual Dolby Surround

1

Press ] to display the Dolby Virtual
screen.

2

Press ] to select “on”.

Setting the Virtual Dolby Surround on the menu screen

NOTE

1

2

“Programmes” and “First installation” appear only when
PIN for Child lock is entered (see page 47).

Press MENU to display the TV menu.

Press a/b to select “Sound”, and then
press OK.

3

Press a/b to select “Dolby Virtual”, and
then press OK.

4

Press c/d to select “on”.

Dolby Virtual on

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

R

Back

E

End

5

• Virtual Dolby Surround does not work when sound is output
from the headphones.

• When “on” is selected in the Dolby Virtual setting, you
cannot adjust “Balance”.

• For some discs, setup may be required on your DVD. In this
case, please refer to the operation manual of your DVD
player.

Press END to exit.

te:e:

NOTE

37

Useful features

OK

Back

R

End

E

Automatic search

Country [UK]
Colour system [ PAL]
Sound system [ I]
Store progr. from
Start search

Programmes

[1] Automatic search

Perform the procedure below to search for and store new programmes after
the First installation routine.

NOTE

“Programmes” and “First installation” appear only when PIN for
Child lock is entered (see page 47).

1

2

Press MENU to display the TV menu.

Press a/b to select “Programmes”, and then
press OK.

3

Press a/b to select “Automatic search”, and
then press OK.

4

Press a/b to select the desired item, and
then press OK.
Press c/d to select the desired item.

Note:

NOTE

• You can change “Colour system” and “Sound system”
only when “Other Countries” is selected in “Country”.

5

Press a/b to select “Store progr. from”, and
then press OK.

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

Programmes

Automatic search

R

Back

E

End

Manual adjustment
Sort
Erase programme range
Enter/Change name

OK

Automatic search

Country [UK]

R

Back

E

End

Colour system [ PAL]
Sound system [ I]
Store progr. from
Start search

OK

R

Back

E

End

Store progr. from

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

38

6

Press a/b/c/d to select the programme
position from which the programmes are to be
stored, and then press OK.

7

Press a/b to select “Start search”, and then
press OK to begin the automatic programme
search.

Note:

NOTE

• When the search is completed, the new programmes
found are displayed in yellow on the programme list.

8

After the search is completed, press END to
exit.

Store progr. from

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

Useful features

Programmes (Continued)

[2] Manual adjustment

Individual settings of programmes can be adjusted.

1

2

3

4

Perform steps 1 and 2 in [1] Automatic
search to display the “Programmes” screen.

Press a/b to select “Manual adjustment”,
and then press OK.

Press a/b to select the item, and then press
c/d to make the adjustment. (See the table
below for details.)

• You can also use 0 – 9 to adjust the “Fre­quency” items.

• To adjust “Name”, first press OK to activate the
text input mode. Press c/d to select the input
position and press a/b to select the desired
character. When you finish inputting, press OK to
set the name.

Press END to exit.

Programmes

Automatic search
Manual adjustment
Sort
Erase programme range
Enter/Change name

OK

Manual adjustment
Channel [ 1]

Frequency [055.25MHz]
Name [SHARP]
Colour system [ PAL]
Sound system [ I]
Skip [ off]

OK

R

R

Back

0

Back

E

E

End

End

Adjustment item

Channel

Frequency

Choice/Value range

0–199

044 – 859 (MHz)

The channel changes to the higher or lower channel.

Receivable frequencies depending on TV norm, installation

Description

site, and range.

Name

Colour system

Sound system

Skip

Note:

NOTE

• Depending on the settings in the colour system of the channels, switching between channels may be slow. If you want to speed up
channel switching, switch “Auto” in “Colour system” to the current reception system (PAL or SECAM).

A – Z, +, -, ., !, /, 0 – 9

Auto, PAL, SECAM

B/G, I, D/K, L

on↔off

Programme name (up to five characters).

Colour norm

TV norm

Channel numbers with a “(•) (RED)” mark on the left are set to
Skip.

39

Useful features

Programmes (Continued)

[3] Sort

The programme positions for individual programmes can be freely changed.

1

2

Perform steps 1 and 2 in
[1] Automatic search to display the

“Programmes” screen.

Press a/b to select “Sort,” and then press
OK.

Programmes

Automatic search
Manual adjustment
Sort
Erase programme range
Enter/Change name

OK

R

Back

E

End

40

3

4

Press a/b/c/d to select the desired
programme, and then press OK to sort.

• When OK is pressed, the Move mode is acti­vated. Press a/b to move the currently marked
programme to the desired programme position.
The marked programme is swapped with the
programme at the selected programme position.
Press OK to leave the Move mode.

Press END to exit.

Sort

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

[4] Erase programme range

The individual programme or programmes in a connected range can be erased.

1

Perform steps 1 and 2 in
[1] Automatic search to display the

“Programmes” screen.

2

3

4

5

6

Press a/b to select “Erase programme
range”, and then press OK.

Press a/b/c/d to select the programme to
be erased, and then press OK. The selected
programme is shown in yellow.

• If you want to erase programmes in a connected
range, select the programme at the beginning of
the desired range.

If you are erasing programmes in a connected
range, press a/b/c/d to select the
programme at the end of the range. The
selected programmes are shown in yellow.

Press OK to erase the selected programme(s).
All the subsequent programmes move up.

Press END to exit.

Programmes

Automatic search
Manual adjustment
Sort
Erase programme range
Enter/Change name

OK

R

Erase programme range

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Erase programme range

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Erase programme range

0

1 E 08
2 E 10
3 SHARP
4 ZDF
5 ARD
6 RTL
7 SAT1

OK

8
9
10
11
12
13
14
15

Pro7

R

16
17
18
19
21
22
23
24

Back

Back

16
17
18
19
21
22
23
24

Back

16
17
18
19
21
22
23
24

Back

16
17
18
19
21
22
23
24

Back

E

E

E

E

E

End

End

End

End

End

Useful features

Programmes (Continued)

[5] Enter/Change name

The name of an individual programme can be entered or changed.

1

2

3

4

Perform steps 1 and 2 in
[1] Automatic search to display the

“Programmes” screen.

Press a/b to select “Enter/Change name”,
and then press OK.

Press a/b/c/d to select the desired
programme, and then press OK. The
character at the input position blinks.

Press c/d to select the input position, and
then press a/b to select the desired
character.

Programmes

Automatic search
Manual adjustment
Sort
Erase programme range
Enter/Change name

OK

R

Back

E

End

Enter/Change name

0

1 _ 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

Enter/Change name

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

5

Press OK to accept the name entered, and
then press END to exit.

Enter/Change name

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

41

Useful features

Wide mode

You can change the screen size using f (WIDE) on the remote control.

1

2

Press f (WIDE) to select the Wide mode.

Each time you press f (WIDE), the mode
changes as follows. You can select the
desired mode.

Panorama

Full

Panorama

Full

Cinema 16:9

Auto

Normal

Zoom 14:9

Cinema 16:9

Zoom 14:9

Selected item

Panorama

Full

Cinema 16:9

Auto

Normal

Zoom 14:9

te:

NOTE

• WSS (Wide Screen Signalling) information refers to the original wide mode information sent from the broadcasting station.

• When Auto is selected, the Panorama mode is selected automatically in the case WSS information indicates the 4:3 mode.

• Try to set Wide mode if an image does not switch to the correct screen format. When the broadcast signal contains no WSS

information, the function will not work even if enabled.

• EXTERNAL SOURCE: When you are watching the TV-set through the Euro-SCART (AV-IN1 or AV-IN2) and it receives information of
16:9 format (through the audio-video control pin) the TV selects Full automatically.

• The Wide mode screen will disappear automatically after 4 seconds.

• Depending on the selected screen size, upper and lower part of an image might be cut in DTV mode.

In this mode the picture is progressively stretched toward each side of the screen.

For 16:9 squeeze pictures.

For 16:9 letterbox pictures. Bars may appear on the top and bottom with some programmes.

The Wide mode is switched automatically based on WSS (Wide Screen Signalling) informa­tion

For 4:3 “standard” pictures. A side bar appears on each side.

For 14:9 letterbox pictures. A thin side bar appears on each side, and you may
also see bars on the top and bottom with some programmes.

Description

Normal

Auto

42

Useful features

Features

The Features items can be set by the user.

NOTE

“Programmes” and “First installation” appear only when PIN for
Child lock is entered (see page 47).

Selected item

Brightness

1

2

3

4

5

Factory setting

[bright] Maximum

brightness

Press MENU to display the TV menu.

Press a/b to select “Features”, and then
press OK.

Press a/b to select the desired adjustment
item, and then press OK.

Press c/d to make the adjustment. (Except
“On-screen display” and “Child lock” menu
items)

Press END to exit.

Adjustable item/range

[medium] Brightness 60% → Suitable for viewing in well-lit areas. Saves

energy.

[dark] Brightness 20% → Sufficiently bright when viewing in

dim areas.

[auto] Screen brightness adjusts according to the ambient light of

the room to conserve power consumption. When setting to
“auto”, make sure no object obstructs the OPC sensor, which
could affect its ability to sense surrounding light.

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

Features

Brightness [bright]
Cool climate [off]
V.Position [ 0]
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]

Speaker [Detachable]
On-screen display
Child lock

OK

R

Back

R

Back

E

E

End

End

Cool climate

V.Position

Rotate
horizontally*

Rotate vertically*

Auto power off
(only TV mode)

Speaker

[off] This feature is

inactive.

[0] Normal image

[off] Normal

horizontal image
orientation

[off] Normal

vertical image
orientation

[off] This feature

is inactive.

[Detachable]
Select this when using internal
speaker.

[on] Improve the response of LCD when viewing

fast-moving image.

When screen size is Zoom 14:9, Panorama or Cinema 16:9:
Image shifts down. Image shifts up.f30 30

When screen size is Normal or Full:

Image shifts down. Image shifts up.

[on] Mirror image → To display mirror images for special uses.

[on] Inverted image → To display images upside down for special uses.

f15 15

ABC

ABC

ABC

[on] The power of the LCD TV set is turned off when there is no signal for

5 minutes.

[External] Select this when using external speaker.

* The picture orientation can be switched in one touch by pressing ROTATE on the remote control (See page 46).

43

Useful features

Cool climate

Improves the response of LCD when viewing fast-moving image.
The effect is greater at low room temperatures (at or below 15˚C/59˚F).

NOTE

“Programmes” and “First installation” appear only when PIN for Child
lock is entered (see page 47).

1

2

Press MENU to display the TV menu.

Press a/b to select “Features”, and then
press OK.

3

Press a/b to select “Cool climate”, and
then press OK.

4

5

• Cool climate may cause image noise. If this occurs turn the
function “off”.

Press c/d to select “on”, and press OK.

Press END to exit.

te:

NOTE

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

Features

Brightness [bright]
Cool climate [off]
V.Position [ 0]
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]

Speaker [Detachable]
On-screen display
Child lock

OK

R

Back

R

Back

E

E

End

End

V.Position

Allows you to shift the image up and down.

NOTE

1

2

3

4

5

NOTE

• When the screen size is Normal or Full, the value between

-15 and +15 is adjustable.

“Programmes” and “First installation” appear only when PIN for Child
lock is entered (see page 47).

Press MENU to display the TV menu.

Press a/b to select “Features” and then
press OK.

Press a/b to select “V.Position” and then
press OK.

Press c/d to make the adjustment.

Press END to exit.

te:

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

Features

Brightness [bright]
Cool climate [off]
V.Position [ 0]
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]

Speaker [Detachable]
On-screen display
Child lock

OK

R

Back

R

Back

E

E

End

End

44

V.Position -300

OK

R

Back

E

End

V.Position 00

OK

R

Back

E

End

V.Position +300

OK

R

Back

E

End

Useful features

Selecting speakers

You can output audio using the supplied speakers (detachable) or other external speak­ers.

NOTE

“Programmes” and “First installation” appear only when PIN for Child
lock is entered (see page 47).

1

2

Press MENU to display the TV menu.

Press a/b to select “Features”, and then
press OK.

3

Press a/b to select “Speaker”, and then
press OK.

4

Press c/d to select “Detachable” or
“External”, and then press OK.

5

Press END to exit.

Connecting external speakers

Rear view

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

Features

Brightness [bright]
Cool climate [off]
V.Position [ 0]
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]

Speaker [Detachable]
On-screen display
Child lock

OK

R

Back

R

Back

E

E

End

End

How to connect the

speaker cable

Push down the tab.

11

1

11

Insert the end of the

22

2

22

cable.

Lift the tab back

33

3

33

up.

• Bundle the cables of the external speakers with clamps as shown above.

CAUTION

• Make sure external speakers have 4 ohm and 5 watt specifications.

• Connect the plus/minus jacks with the correct cables. Incorrect connection may cause a short.

Make sure to connect the speaker jack and cable polarity (L, +) properly.

• The speaker jacks have plus (L) and minus (+) polarity.

• Plus is red and minus is black.

• The cables are also divided into plus and minus.

• When connecting the left/right speakers, be sure to connect the plus/minus jacks with the correct cables.

Note:

NOTE

• See page 10 for bundling the cables of the external speakers.

• Unplug the AC cord from the AC outlet before installing the speakers.

• When using the TV with the supplied stand attached, do not remove the speaker. Doing so may disturb the balance leading to product
damage or personal injury.

45

Useful features

Rotate

You can change the picture orientation directly
using the remote control unit.

1

2

• The Rotate screen automatically disappears after 4 sec­onds.

• When the picture orientation changes using this function, the
menu screen orientation changes as well.

• See the table of page 43 for details of the each rotate
setting.

Press ROTATE to display the Rotate screen.

Each time you press ROTATE, the mode
changes as follows. You can select the
desired mode.

Rotate hor. : off
Rotate vert. : off

(Normal)

Rotate hor. : on
Rotate vert. : on

(Rotate horizontally

and vertically)

NOTE

Rotate hor. : on
Rotate vert. : off

(Rotate horizontally)

Rotate hor. : off
Rotate vert. : on

(Rotate vertically)

ABC

Rotate hor. :off
Rotate vert.:off

Rotate vert.:on
Rotate hor. :on

ABC

Rotate hor. :on
Rotate vert.:off

Rotate vert.:on
Rotate hor. :off

ABC

On-screen display

You can adjust various settings for on-screen
displays.

1

2

3

4

5

Choice/Value rangeAdjustment item

Perform steps 1 and 2 in Features to display
the “Features” screen.

Press a/b to select “On-screen display” and

then press OK.

Press a/b
item. (See the table below.)

Press c/d to make the adjustment.

Press END to exit.

to select the desired adjustment

Description

ABC

Features

Brightness [bright]
Cool climate [off]
V.Position [ 0]
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]

Speaker [Detachable]
On-screen display
Child lock

OK

On-screen display
Position [bottom]

Sound info [ yes]
Time [ no]
Alarm time [ no]
Sleep time [ no]

OK

R

R

Back

Back

E

E

End

End

46

Position

Sound info

Time

Alarm time

Sleep time

bottom ↔ top

no ↔ yes

no ↔ yes

no ↔ yes

no ↔ yes

To select the position of the On-screen display.

To select whether or not sound information is to be displayed, when a
channel has been selected.

To select information to be displayed in the On-screen display. To
activate the On-screen display, use the p button.

OK

Back

R

End

E

Child lock

For all programmes
For individual progr. only
Change PIN [1234]
Reset

OK

Back

R

End

E

Child lock

For all programmes
For individual progr. only
Change PIN [1234]
Reset

OK

Back

R

End

E

Child lock

For all programmes
For individual progr. only
Change PIN [5678]
Reset

Useful features

Child lock (for TV/DTV)

Important:

• Please refer to page 65 for “IMPORTANT NOTE ON DISENGAGING ADVANCED CHILD
LOCK”.

Allows you to use a PIN to protect certain settings from being accidentally changed.

[1] Changing/Resetting PIN
To change PIN

You can change the factory preset PIN “1234” to another 4-digit number you like.

NOTE

1

2

“Programmes” and “First installation” appear only when PIN for Child
lock is entered.

Press MENU to display the TV menu.

Press a/b to select “Features”, and then
press OK.

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

3

Press a/b to select “Child lock”, and then
press OK.

4

When changing the PIN for the first time, enter
factory-preset PIN “1234” with 0 – 9. If not for
the first time simply enter your current PIN.

• When the PIN is correctly entered, the “Child
lock” screen appears.

Note:

NOTE

• Numbers entered are hidden with ????.

• If the PIN has been input incorrectly, “Wrong PIN!” is

displayed.

5

Press a/b to select “Change PIN”, and
then press OK. The currently defined PIN is
displayed.

OK

Features

Brightness [bright]
Cool climate [off]
V.Position [ 0]
Rotate horizontally[off]
Rotate vertically [off]
Auto power off [off]

Speaker [Detachable]
On-screen display
Child lock

OK

Child lock
Please enter your PIN.

Child lock [????]

OK

R

R

R

Back

Back

Back

E

E

E

End

End

End

6

Input the new four-digit PIN (e.g. 5678) with
0 – 9, and then press OK.

7

Press END to exit.

To reset a PIN

| In step 5 above, press a/b to select “Reset”, and

then press OK to cancel the currently defined PIN.
The PIN resets to factory-preset PIN “1234”.

47

OK

Back

R

End

E

Child lock

For all programmes
For individual progr. only
Change PIN [1234]
Reset

OK

Back

R

End

E

For all programmes

Immediately [ no]
Daily [ no]
Once [ no]

Useful features

Child lock (Continued)

[2] Setting a Child Lock

There are four different ways of activating a child lock:

1. General child lock for all programmes immediately

2. General child lock for all programmes with daily time limit

3. General child lock for all programmes with single time limit

4. Programme-position related child lock without time limit
The Child Lock comes into effect only after the LCD TV set has entered the
standby mode and is then turned on again.

To set a Child Lock for all
programmes with a time limit

1

Perform steps 1 to 3 in
[1] Changing/Resetting PIN to display the

Child lock screen.

2

Press a/b to select “For all programmes”,
and then press OK.

3

Press a/b to select the desired item. (See
the table below.)

4

Press c/d to select the desired choice, and,
if required, input digits with 0 – 9.

5

• If the current clock time is within the time limit, the Child Lock is activated immediately after the LCD
TV set is turned off and on again. For example, if the current clock time is 9:00 and the time limit is
specified from 22:00 to 14:00, the lock is effective from 9:00 to 14:00.

• When a Child Lock is set for all programmes with a time limit, the “Time” item is not displayed in
the TV menu and cannot be selected.

Press END to exit.

Note:

NOTE

Adjustment item

Choice/Input value

Immediately

Daily

Once

Warning:

• The timer takes its clock information from the Teletext broadcast. The teletext broadcast may be in a different time zone and
therefore child lock timer may not activate as expected.

48

no↔HH:MM-HH:MM

no↔HH:MM-HH:MM

no↔yes

Description

Select “yes” to activate the Child Lock immediately (after the LCD TV
set has been turned off and on again). The lock remains effective until
“no” is selected.

Input the start and end time for a daily-recurring Child Lock. The lock is
activated everyday unless “no” is selected.

Input the start and end time for a once-only Child Lock. The length of the
period should be up to 24 hours.

OK

Back

R

End

E

Child lock

For all programmes
For individual progr. only
Change PIN [1234]
Reset

Useful features

Child lock (Continued)

[2] Setting Child Lock (Continued)

To set a Child Lock for individual
programmes without time limit

1

Perform steps 1 to 3 in
[1] Changing/Resetting PIN to display the

“Child lock” screen.

2

Press a/b to select “For individual progr.
only”, and then press OK.

3

4

• To unlock the programme, select the programme and press

OK.

• The Child Lock remains effective until it is cancelled.

5

• When a Child Lock is activated, the “Programmes” and “First installation” items are not
displayed in the TV menu and cannot be selected.

Press a/b/c/d to select the desired
programme.

Press OK to lock the programme. The locked
programme is displayed in red.

Note:

NOTE

Press END to exit.

Note:

NOTE

For individual progr. only

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

[3] Temporarily cancelling the Child Lock setting

You can view a programme for which a Child Lock has been set by temporar­ily cancelling the Child Lock setting. Perform the procedure below to input
your PIN and cancel the Child Lock if you are prompted to do so.

When the PIN input screen appears, input your PIN

|

with 0 – 9. The normal screen appears when the PIN
is correctly entered.

NOTE

• If the PIN has been input incorrectly, “Wrong PIN!” is
displayed.

Child lock
Please enter your PIN.

Child lock [????]

OK

R

Back

E

End

49

Useful features

AV Connections

It is possible to manually adjust various settings for connections with external devices on
the “AV connections” screen.

[1] AV1/AV2/AV3

Select the appropriate signal type and colour standard for the signals from the video
equipment connected to the AV1, AV2 or AV3 terminal.

NOTE

“Programmes” and “First installation” appear only when PIN for Child
lock is entered.

1

2

3

4

5

6

Press MENU to display the TV menu.

Press a/b to select “AV connections”, and
then press OK.

Press a/b to select “AV1”, “AV2”, “AV3 (Y/
C)”, or “AV3(CVBS)”, and then press OK.

Press a/b to select the desired item, and
then press OK.

Press c/d to select the desired “Signal type”,
“AFC” and “Colour system”, and then press
OK.

Press END to exit.

TV menu

Sound
Programmes
Features
AV connections
Timer functions
First installation
Language

OK

AV connections

AV1
AV2
AV3(Y/C)
AV3(CVBS)
For programmes

OK

R

Back

R

Back

E

E

End

End

Example when AV2 is

selected:

AV2

Signal type [ Auto]
AFC [Mode1]
Colour system [ Auto]

OK

R

Back

E

End

Example when AV1 is

selected:

AV1

AFC [Mode1]
Colour system [ Auto]

Signal type*

AFC

Choice/Input valueAdjustment item

Auto, CVBS, Y/C

Mode1, Mode2

OK

Description

To select the signal type of external equipment.

To select frequency control modes. Mode1 is suitable for DVD players
or decoders, and Mode2 is suitable for VCRs or Camcorders.

R

Back

Auto, PAL, SECAM,

Colour system

N358 (NTSC 3.58),
N443 (NTSC 4.43),

Colour norm

PAL60, PAL-M, PAL-N

* “Signal type” is only visible when the AV2 is selected.

Note:

NOTE

• If no (colour) image displays, try to change to a different signal type.

• Depending on the compatibility with the various types of equipment, the picture may become skewed. In this case, select the “AFC”

(Automatic Frequency Control) mode that will improve the picture.

• Switching between AV input signals may be slow, depending on the settings in “Colour system”. If you want to speed up signal
switching, switch “Auto” in “Colour System” to the current reception colour system.

50

E

End

OK

Back

R

End

E

For programmes

AV control voltage [ no]
RGB select [

no

]
For decoder connected to AV1
Sound from AV1 [Dec.]

OK

Back

R

End

E

For programmes

AV control voltage [ no]
RGB select [

no

]
For decoder connected to AV1
Sound from AV1 [Dec.]

OK

Back

R

End

E

For programmes

AV control voltage [ no]
RGB select [

no

]
For decoder connected to AV1
Sound from AV1 [Dec.]

Useful features

AV Connections (Continued)

[2] For programmes

• It is possible to select AV control voltage and the RGB signal for programme
positions 1 to 199.

• When connecting a video device to the AV1 terminal, you need to adjust the
decoder programme settings.

1

Perform steps 1 and 2 in
[1] AV1/AV2/AV3 to display the “AV

connections” screen.

2

Press a/b to select “For programmes”,
and then press OK.

3

Press a/b to select the “AV control
voltage” or “RGB select”.

4

Press c/d to select “yes” or “no”.

NOTE

• After one or both items are set to “yes”, and when AV
control voltage or RGB signal is input, the appropriate
image is received for all programme positions 1 to 199.

5

Press a/b to select “For decoder
connected to AV1”, and then press OK
to display the decoder programme
selection screen.

AV connections

AV1
AV2
AV3(Y/C)
AV3(CVBS)
For programmes

OK

R

Back

E

End

6

7

8

9

Press a/b/c/d to select the
programme for the decoder, and then
press OK. Repeat the same procedure if
you want to specify other decoder
programmes.

Press RETURN to return to the “For
programmes” screen.

Press a/b to select “Sound from AV1”,
and then press c/d to select the
desired sound source.

Press END to exit.

For decoder connected to AV1

0

1 E 02
2 E 04
3 U 02
4 U 04
5 E 05
6 E 08
7 E10

OK

8
9
10
11
12
13
14
15

SHARP
ZDF
ARD
RTL
SAT1
Pro7

R

Back

16
17
18
19
21
22
23
24

E

End

51

Useful features

Sleep Timer off

Timer functions

1

2

3

4

5

6

7

Press MENU to display the TV menu.

Press a/b to select “Timer functions”, and
then press OK.

Press a/b

OK.

Input the current time (HH:MM:SS) with 0 – 9.

Press a/b to select the desired item. (See
the table below.)

Press c/d to make the adjustment. If you
select “00:00” for “Sleep Timer” or “Alarm”,
input the desired time with 0 – 9.

Press END to exit.

to select “Time”, and then press

NOTE

• You have to first set the current “Time” to adjust
“Sleep timer”, “Alarm” and “Alarm volume” settings.

Timer functions
Time [ : : ]

Sleep Timer [ no]
Alarm [ no]
Alarm volume [ 0]

OK

R

Back

E

0

End

Adjustment item

Time

Sleep Timer

Alarm

Alarm volume

Choice/Input value/Value range

HH:MM:SS

no↔HH:MM

no↔HH:MM

0 – 39

Description

The time can be manually set.

The LCD TV set automatically turns off at the specified
time everyday.

The alarm sound turns on at the specified time everyday.

The volume of the alarm sound is selected.

NOTE

• The time is automatically set/corrected via the Digital TV and teletext broadcast when available.

Sleep Timer

Directly setting the sleep timer

Press SLEEP to display the sleep timer information and/
or turn off the sleep timer.

Press SLEEP to display the sleep timer information

|

Press SLEEP again to deactivate the sleep timer.

|

Sleep Timer on (22:00

)

52

NOTE

• The Sleep timer screen automatically disappears in 3 seconds.

• After you set the sleep timer, turning off MAIN POWER on the TV set will cancel the sleep timer

setting.

Useful features

NICAM broadcast selection

This enables the selection of the reception mode when receiving a NICAM-I or
NICAM-B/G signal. To let you enjoy NICAM broadcasting, this LCD TV set re­ceives NICAM system stereo, bilingual, and monaural broadcasts.

Stereo

The LCD TV set is receiving a stereo broadcast.

• Each time you press SOUND, the mode changes
between “Stereo” and “Mono”.

• When “Mono” is selected, the TV sound is output
monaurally.

Stereo Mono

Bilingual

When the LCD TV set is receiving a bilingual programme,
the “Sound 1” mode is automatically selected.

• Each time you press SOUND, the mode changes as
follows:

Sound 1 Sound 2 Sound 1+2 Mono

Stereo

Mono

Sound 1

Sound 2

Sound 1+2

Mono

Monaural

The LCD TV set is receiving a monaural broadcast.

• Each time you press SOUND, the mode changes
between “Nicam” and “Mono”.

Nicam

Nicam Mono

Mono

Note:

NOTE

• If approximately 3 seconds pass without a button being pressed, the mode setting is
automatically terminated and the LCD TV set returns to the normal mode.

• The setting can be individually selected for each channel number.

• You can also turn off the NICAM mode by setting the “Loudsp. sound” item to “Mono” in

the Sound screen (see page 36).

53

Useful features

A2 stereo broadcasts

This enables the selection of the reception mode when receiving an A2 stereo
signal. To let you enjoy A2 stereo broadcasting, this LCD TV set receives A2
stereo system stereo and bilingual broadcasts.

Stereo

The LCD TV set is receiving a stereo broadcast.

• Each time you press SOUND, the mode changes
between “Stereo” and “Mono”.

• When “Mono” is selected, the TV sound is output
monaurally.

Stereo Mono

Bilingual

When the LCD TV set is receiving a bilingual programme,
the “Sound 1” mode is automatically selected.

• Each time you press SOUND, the mode changes as
follows:

Sound 1 Sound 2 Sound 1+2 Mono

Stereo

Mono

Sound 1

Sound 2

Sound 1+2

Mono

Note:

NOTE

• If approximately 3 seconds pass without a button being pressed, the mode setting is
automatically terminated and the LCD TV set returns to normal mode setting.

• The setting can be selected individually for each channel number.

• You can also turn off the A2 stereo mode by setting the “Loudsp. sound” item to “Mono” in

the Sound screen (see page 36).

54

Teletext

Teletext function

What is Teletext?

Teletext broadcasts pages of information and
entertainment to specially equipped television sets.
Your System receives Teletext signals broadcast by
a TV network, and decodes them into graphical
format for viewing. News, weather and sports
information, stock exchange prices and programme
previews are among the many services available.

Teletext mode

Teletext is turned on/off with m on the remote
control unit. You can operate your System in Teletext
mode directly by inputting commands with the
remote control unit.

TELETEXT

When viewing the Teletext information

• Press CH

• Press CH

aa

a to increase the page number.

aa
bb

b to decrease the page number.

bb

Button functions

Colour (RED/GREEN/YELLOW/BLUE):

You can select a group or block of pages displayed
in the coloured brackets at the bottom of the screen
by pressing the corresponding Colour (RED/

GREEN/YELLOW/BLUE) on the remote control unit.

Turning Teletext on and off

1

2

3

Select a TV channel or external input
source providing the Teletext programme.

Press m to display the Teletext.

Press m to return to normal screen.

• Each time you press m, the screen switches

as shown upper right.

• If you select a programme with no Teletext
signal, “No Teletext available.” displays.

TELETEXT

GREEN

RED

0 – 9:
Directly select any page from 100 to 899 by using 0 – 9.

aa

bb

a/

b:

aa

bb

Each time you press
switches as shown below.

Full

Upper half

k:
To reveal hidden information such as an answer to a
quiz, press k.

• Press k again to hide the information.

:

To stop updating Teletext pages automatically, press .

• Press again to release the hold mode.

Lower half

YELLOW BLUE

aa

bb

a/

b, the TELETEXT image

aa

bb

55

Teletext

Using Teletext menu

Select desired character set for Teletext.

To select the character set

1

Press MENU to display the “Character
set” screen.

Character set

West Europe
East Europe
Turkish/Greek
Cyrillic

2

3

OK

Press a/b to select the desired character
set.

• The colour of the letters will turn to yellow.
When selecting the character set, pressing
OK will change the letters to magenta for an
instant and then return them back to yellow.

Press END to exit.

E

End

Displaying TOP Overview

When receiving TOP Teletext, you can read a TOP
text overview.

Displaying Subtitle

You can display several subtitles as they are
transmitted.

1

2

• Subtitle will not be displayed when the service does not
contain the subtitle information.

Press [ to display the subtitle.

• Subtitle is updated by the information sent by
the broadcasting station.

Press [ to exit the subtitle screen.

NOTE

1

2

3

4

5

Press m to display Teletext.

Press l to display the TOP Overview as
shown below.

TOP Overview screen

INDEX

BLOCK PAGES

TV PROGRAMS
COLOR BAR
WEATHER
NEWS
MOVIE
LOCAL

SPORTS

BLOCK 1
BLOCK 2
BLOCK 3

GROUP PAGES

FOOT BALL
BASKETBALL

TENNIS

SKI
JUDO
SWIM
GROUP 1
GROUP 2
GROUP 3
GROUP 4

Select the desired block or group by using
a/b/c/d.

Press OK to display the selected block or
group pages.

Press l to exit the TOP Overview screen.

56

Teletext

How to use p (DISPLAY/INFO) button (for TV/DTV)

Analogue TV: Display the programme number and time.
Digital TV: Display the programme information.

You can display the time information included in the Teletext. Follow the steps
below to display the time.

NOTE

• If receiving a digital broadcast, you can only display the time by performing steps 2 and 3
below.

1

• The time is not captured when a selected channel has
no Teletext information.

2

3

4

• The time display cannot be stored once the power is
turned off. When you turn on the power, perform steps
1 – 4 again.

Select a TV channel providing Teletext
information.
(The time information is automatically
captured.)

NOTE

Press p. The channel display will appear on
the Display.

Press p again within the three-second interval
the channel display is on the screen.
Time information will display on the lower left of
the screen for about three seconds.

Even when you change the TV channel, you
can display the time information with steps 2 –
3 above.

NOTE

57

Connecting external devices

It is possible to enjoy video and sound by connecting a VCR and home video game system to the terminals located on
the rear of the main unit.
When connecting an external device, turn off the power of the main unit and connecting device to prevent any possible
damage.

Examples of external devices that can be connected

To AV-IN 1, 2 or 3 terminal

• Camcorder

• Home video game system

• VCR

• DVD player

• Decoder

• Receiver (AV amplifier)

* PC connection is not possible.

Note:

NOTE

• Use a commercially available audio/video cord for the cable.

• Make sure proper connection is made. Connecting other signals may result in a malfunction.

• The VIDEO input terminal and the S-VIDEO input terminal on the AV-IN 3 side are shared connections with priority given to the S-

VIDEO terminal. If both terminals are connected, the video signals from the S-VIDEO input terminal are selected for the AV-IN 3
input.
When viewing video from the VIDEO input terminal, do not connect anything to the S-VIDEO input terminal.

• For details concerning usage and connection of external devices, see the respective instruction manuals.

58

Connecting external devices

Connecting a VCR or decoder through the 21-pin Euro-SCART (AV-IN 1/RGB) (AV-IN 2/AV)

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

21-pin Euro-SCART (RGB) (AV-IN 1)

1. Audio right output 8. Audio-video control 15. RED input

2. Audio right input 9. Earth for green 16. RED/GREEN/BLUE control

3. Audio left output 10. Not used 17. Earth for video

4. Common earth for audio 11. GREEN input 18. Earth for RED/GREEN/BLUE control

5. Earth for blue 12. Not used 19. Video output

6. Audio left input 13. Earth for red 20. Video input (PAL/SECAM/NTSC)

7. BLUE input 14. Not used 21. Plug shield

21-pin Euro-SCART (AV) (AV-IN 2)

1. Audio right output 8. Audio-video control 15. Chroma S-Video input

2. Audio right input 9. Earth 16. Not used

3. Audio left output 10. Not used 17. Earth for video

4. Common earth for audio 11. Not used 18. Earth

5. Earth 12. Not used 19. TV Monitor output

6. Audio left input 13. Earth 20. Video input/S-video input

7. Not used 14. Earth 21. Plug shield

To AV-IN 1 or 2
(21-pin Euro-SCART) terminal

21-pin Euro-SCART

connector

VCR

Decoder

21-pin Euro-SCART

connector

59

Connecting external devices

Connecting a camcorder or a home video game system (AV-IN 3)

NOTE

Note:

To S-VIDEO
input terminal

S-Video cord

To S-Video
output terminal

Camcorder

Video

Audio

(R)

To AV-IN 3
terminals

Audio/video cord

To audio/video
output terminals

Audio

(L)

Home video
game system

• When connecting to both the VIDEO input and S-VIDEO input terminals for AV-IN 3, priority is given to the S-VIDEO input terminal.

• For details concerning usage and connection of external devices, see the respective instruction manuals.

Outputting audio (AUDIO OUT)

It is possible to output audio from the LCD TV set through the AUDIO OUT terminals.
PCM audio outputs from the terminal.

Optical fibre

cable

To optical digital input of external audio devices

60

Troubleshooting

■ Before calling for repair services, make the following checks for possible remedies to the symptoms encountered.

Problem Possible Solution

• No power.

• Unit cannot be operated.

• Remote control unit does not
operate.

• Picture is cut off.

• Strange colour, light colour, or
dark, or colour misalignment.

• Power is suddenly turned off.

• Check if you pressed B on the remote control unit. (See page 13.)
If the indicator on the Display lights up red, press B.

• Is the AC cord disconnected? (See page 6.)

• Has the main power been turned on? (See page 13.)

• External influences such as lightning, static electricity, etc., may cause improper
operation. In this case, operate the unit after first turning the power off the LCD
TV unit, or unplugging the AC cord and re-plugging it in after 1 or 2 minutes.

• Are batteries inserted with polarity (e, f) aligned? (See page 5.)

• Are batteries worn out? (Replace with new batteries.)

• Are you using it under strong or fluorescent lighting?

• Is a fluorescent light illuminated to remote control sensor?

• Is the image position correct? (See page 44.)

• Are screen mode adjustments such as picture size made correctly? (See page

42.)

• Adjust the picture tone. (See pages 35 and 44.)

• Is the room too bright? The picture may look dark in a room that is too bright.

• Check the input signal setting. (See page 50.)

• The unit’s internal temperature has increased.
Remove any objects blocking vent or clean.

• Check the sleep timer setting. (See page 52.)

• No picture.

• No sound.

• Is connection to other equipments correct? (See pages 58 to 60.)

• Has input signal setup been done correctly after connection? (See page 50.)

• Is the correct input selected? (See page 50.)

• Is picture adjustment correct? (See page 35.)

• Is the antenna connected properly? (See page 6.)

• Is the volume too low? (See page 14.)

• Make sure the sound is not set to mute. (See page 14.)

• Make sure the appropriate item is selected in “Speaker”. (See page 45.)

Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear
slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight
or near a heater, as this may cause the cabinet to deform and the LCD panel to malfunction.
Storage temperature: –20°C to +60°C (–4°F to +140°F).

61

Specifications

Item 22" LCD COLOUR TV, Model: LC-22AD1E

LCD panel 22" Advanced Super View & BLACK TFT LCD

Number of dots 1,229,760 dots (854 g 480 g 3 dots)

Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV TV-Standard Analogue CCIR (B/G, I, D/K, L)

Function Digital DVB-T (2K/8K OFDM)

Receiving VHF/UHF E2-E69 ch, I21-I69 ch, IR A-IR Jch, F2-F10 ch

Channel CATV Hyper-band, S1 – S41 ch

TV-Tuning Analogue Auto Preset 199 ch, Auto Label, Auto Sort

System Digital Auto Preset 999 ch, Auto Label, Auto Sort

STEREO/BILINGUAL NICAM/A2 stereo

Brightness 430 cd/m

Lamp life 60,000 hours

Viewing angles H: 170° V: 170°

Audio amplifier 5.0 W g 2

Speakers ø 6 cm 2 pcs, ø 2.5 cm 2 pcs

Terminals Rear ANTENNA IN UHF/VHF 75 q Din type (Analogue)

ANTENNA IN UHF/VHF 75 q Din type (Digital)

ANTENNA OUT UHF/VHF 75 q Din type (Digital)

AV-IN 1 SCART (AV in, RGB in, TV out)

AV-IN 2 SCART (AV in/out, S-Video in)

AV-IN 3 S-VIDEO, VIDEO, AUDIO

AUDIO OUT Digital audio output

SP OUTPUT External speaker (L and R)

Front Headphones ø 3.5 mm jack (Front)

OSD language English/German/French/Spanish/Italian/Swedish/Dutch/Portuguese/Finnish/

Turkish

Power requirement DC 13 V, AC 110 V – 240 V, (50/60 Hz)

Power Consumption 70 W (1.3 W at Standby) (Method IEC60107) : AC 230 V (with AC Adapter)

57 W (Method IEC60107) : DC 13 V

Weight 11.2 kg w/o accessories

Accessories Operation manual, Remote control, Battery (g 2), AC adapter, AC cord,

Cable clamps (

2

g 2), Antenna cable (g 1)

■ As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There
may be some deviations from these values in individual units.

62

Dimensional drawings

Unit: mm

420

582

91.5

510

180.7

492.6

367

462

270.2

100

43.9

100

53

99

183

250

63

Information for Customers

on environmentally friendly disposal of this SHARP product

If this product cannot be used any more, it should be disposed of in a legally correct and environmentally sound way.

DO NOT DISPOSE OF THIS PRODUCT WITH YOUR HOUSEHOLD WASTE

OR MIXED WITH OTHER WASTES! YOU MIGHT ENDANGER THE ENVIRONMENT!

Sharp Corporation is committed to protecting the environment and conserving energy. Our goal is to minimize the

environmental impact of our products by continually implementing and improving product technologies, designs, and

(1) For our customers in Belgium, The Netherlands, Sweden, and Switzerland

SHARP takes part in the respective national recycling systems for electronic equipment, which have been founded on the
basis of the environmental laws in these countries.

Please see here details on the respective countries.

Country Recycling Information for that Country

Sweden

customer information aimed at environmental conservation.

Please use the Swedish electronics recycling system called “ELRETUR”,
and see the website at http://www.el-kretsen.se

The Netherlands

Belgium

Switzerland

(2) For our customers in United Kingdom, Germany, France, and Italy

Please contact your local authorities for collection and recycling facilities, or contact a recycling service company, which is
licensed for the recycling of electronic equipment.

Please use the Dutch electronics recycling system called “ICT-Milieu”.
and see the website at http://www.nederlandict.nl/index.php

Please use the Belgian electronics recycling system called “Recupel”.
and see the website at http://www.recupel.be

Please use the Swiss electronics recycling system called “SWICO”.
and see the website at http://www.swico.ch

Maturity rating

Rating

Universal

viewing

Parental approval

preferable

X-rated

4

5 6 7 8 9 101112131415161718

——————————————

✓

✓✓✓✓✓✓——————————

✓✓✓✓✓✓✓✓✓✓✓✓✓✓

AGE

Rating

Universal

viewing

Parental approval

preferable

X-rated

64

Universal viewing

—

✓

✓

Parental approval

preferable

—

—

✓

X-rated

—

—

—

IMPORTANT NOTE ON DISENGAGING ADVANCED CHILD LOCK

We suggest removing the following instruction. As this Operation Manual is multilingual, we also suggest the same with each
language.
If you have forgotten your personal code number and cannot disengage ADVANCED CHILD LOCK, follow the procedure below.

1. Press MENU to display the TV menu.

2. Press a/b to select “Features”, and then press OK to display the “Features” screen.

3. Press a/b to select “Child lock,” then press OK.

4. The PIN input menu appears.

5. Input “3001” with 0 – 9.

The Child lock setting menu appears.
A new PIN can now be input.

ADVANCED CHILD LOCK will now be disengaged.
We suggest that you remove this instruction from the manual to prevent children from reading it. Keep it in a safe place for future
reference.

65
