Sharp GX-T25 User Guide

Introduction

Congratulations and thank you for choosing the GX-T25.

About This User Guide

This user guide is carefully designed to help you learn about your phone’s features and operations quickly and effectively.

NOTICE

We strongly recommend that you keep separate

• permanent written records of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, we assume no responsibility for data lost or otherwise rendered unusable, whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired or any other cause.

• We assume no responsibility, directly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss or alteration of stored data, etc.

• All company and/or product names are trademarks and/or registered trademarks of their respective holders.

• Screen layout illustrated in this user guide may differ from the actual one. The information described in this user guide is subject to change without notice.

• All the functions described in this user guide may not be supported in all networks.

• We assume no responsibility for downloaded contents, information, etc. from network.

• Occasionally, a few black or bright pixels may appear on the screen. Please note that this will not have any impact on any of the features or performance.

According to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from the copyright owner to reproduce, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.

Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Introduction 1

Powered by JBlend™ Copyright 19972004 Aplix Corporation. All rights reserved. JBlend and all JBlend-based trademarks and logos are trademarks or registered trademarks of Aplix Corporation in Japan and other countries.

Licensed by Inter Digital Technology Corporation under one or more of the following United States Patents and/or their domestic or foreign counterparts and other patents pending, including U.S. Patents: 4,675,863: 4,779,262: 4,785,450 & 4,811,420.

T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/ DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional patents are pending worldwide.

is a registered trademark of HI Corpora-

/Micro3D Edition™

2Introduction

Bluetooth is a trademark of the Bluetooth SIG, Inc.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sharp is under license. Other trademarks and trade names are those of their respective owners.

CP8 PATENT

Information contained in this manual is the property of FarEasTone and Sharp. FarEasTone and Sharp reserve the right to change product specifications without prior notice. FarEasTone and Sharp reserve the right to change information contained in this manual without prior notice.

This product is licensed under the MPEG-4 Visual Patent Portfolio License for the personal and non-commercial use of a consumer to encode video in compliance with the MPEG-4 Video Standard (“MPEG-4 Video”) and/or decode MPEG-4 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a licensed video provider. No license is granted or implied for any other use. Additional information may be obtained from MPEG LA. See http://www.mpegla.com.

This product is licensed under the MPEG-4 Systems Patent Portfolio License for encoding in compliance with the MPEG4 Systems Standard, except that an additional license and payment of royalties are necessary for encoding in connection with data stored or replicated in physical media which is paid for on a title by title basis and/or data which is paid for on a title by title basis and is transmitted to an end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. See http:// www.mpegla.com for additional details.

Useful Functions and Services

Your phone offers you the following features:

• A built-in digital camera for taking pictures and video clips.

• A message function for reading and creating SMS messages.

• MMS (Multimedia Messaging Services) for personalising your phone in various ways.

• A WAP browser for accessing information on the mobile Internet.

• Java™ applications. You can also download various applications from FarEasTone via the mobile Internet.

• The external display (blue) for quickly checking the information of incoming calls or messages.

• The mobile light (white) has a large number of uses: auxiliary light for the camera, battery charge notification, incoming call indicator, and makeshift torch.

• A melody editing function for creating original ringtones using up to 32 voices.

• A voice recorder function for recording and playing back voice clips.

•A Bluetooth

wireless technology interface for establishing contact and transmitting data with certain devices. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.

• An infrared interface for data communication. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.

• A data synchronization function for synchronizing the Phonebook and schedule entries with Microsoft Outlook or Outlook Express on a PC.

• A schedule alarm for creating and sending schedule entries with alarm settings.

Introduction 3

Introduction .................................................. 1

Useful Functions and Services..................... 3

Your Phone ...................................................7

Optional Accessories.................................... 7

Getting Started ............................................. 8

Inserting the SIM Card and the Battery ..... 11

Charging the Battery .................................. 13

Turning Your Phone On and Off................ 14

Main Display Indicators............................. 15

External Display Indicators........................ 17

Navigating Functions.................................18

Call Functions............................................. 19

Making a Call............................................. 19

Speed Dialling............................................ 19

Redialling ................................................... 20

Answering a Call........................................ 20

Incall Menu ................................................ 21

Entering Characters...................................25

Changing the Input Languages................... 26

Changing the Input Method........................ 26

Using Text Templates ................................ 31

4 Table of Contents

Using the Menu...........................................32

List of Menu Functions...............................33

Phonebook ..................................................34

Selecting the Storage Memory ...................34

Changing the List Displayed ...................... 34

Add New.....................................................35

Copying Phonebook Entries between SIM

Card and Handset........................................ 35

Finding a Name and Number......................36

Dialling from the Phonebook .....................36

Editing Phonebook Entries.........................37

Deleting Phonebook Entries.......................37

Viewing Groups..........................................37

Memory Status............................................39

Speed Dial List ...........................................39

Sending a Phonebook Entry .......................39

Receiving a Phonebook Entry .................... 40

Camera.........................................................41

Digital Camera............................................41

Video Camera.............................................45

Messages.................................................... 49

MMS...........................................................49

SMS ............................................................53

Alert Inbox..................................................56

Voicemail....................................................56

Cell Broadcasts ...........................................56

Area Info.....................................................57

FET Mobile Internet.................................... 58

Starting the WAP Browser .........................58

Navigating a WAP Page.............................58

Visiting the FET Mobile Internet

Web Site......................................................60

Visiting Your Preferred URL .....................60

Gallery......................................................... 62

Picture Gallery............................................62

Java™ Gallery ............................................65

Sound Gallery .............................................66

Video Gallery..............................................68

Bookmarks..................................................69

Text Templates ...........................................70

My Chinese Beloved...................................71

Memory Status............................................73

Java™ ..........................................................74

Java™ Gallery.............................................74

Java™ Wallpaper........................................75

Download More ..........................................75

Settings........................................................76

Java™ Information......................................77

Organiser.....................................................78

SIM Application..........................................78

Calendar ......................................................78

Alarms.........................................................80

Calculator....................................................82

Voice Recorder ...........................................83

Melody Editor .............................................84

Help List......................................................88

Profiles ........................................................89

Call Manager ...............................................95

Call Log.......................................................95

Speed Dial List............................................96

My Numbers ...............................................96

Call Timers..................................................96

Data Counter ...............................................96

Table of Contents 5

Settings .......................................................97

Display ....................................................... 97

Call Settings ............................................. 101

Date & Time............................................. 105

Language .................................................. 106

Connectivity ............................................. 106

Network Settings...................................... 110

Security..................................................... 112

Master Reset............................................. 113

Connecting GX-T25 to Your PC .............. 114

System Requirements............................... 114

GSM/GPRS Modem................................. 114

Handset Manager...................................... 115

Software Installation ................................ 115

Note .......................................................... 115

Troubleshooting.......................................117

Safety Precautions and Conditions

of Use ........................................................119

Conditions of Use..................................... 119

Environment............................................. 122

Precautions Concerning Vehicle Use....... 122

SAR .......................................................... 123

Precautions for Use in USA..................... 123

6 Table of Contents

Out of Warranty List .................................126

Index ..........................................................127

Quick Reference .......................................131

Your Phone

Please check the following carefully. Your phone should come complete with:

• GSM phone

• Rechargeable Li-ion battery

• AC Charger

• Handsfree kit

•User guide

Optional Accessories

• Li-ion Spare battery

• Cigarette lighter charger

• USB data cable

The above accessories may not be available in all regions.

For details, please contact your dealer.

Your Phone 7

Getting Started

8 Getting Started

1. Earpiece

2. Navigation Keys (Arrow Keys):

Moves cursor to select menu items, etc.

Up/Down arrow keys: a b

Displays Phonebook entries in stand-by mode. a and b indicate in this manual these keys.

Left arrow key:

Displays the list of Java™ Gallery in stand-by mode. c indicates in this manual this key.

Right arrow key:

Displays Saved Pictures in stand-by mode. d indicates in this manual this key.

3. Left Soft Key:

4. Send Key:

Executes the function at the bottom left of the screen.

Makes or accepts calls, views the call logs in stand-by mode.

5. Centre Key: Displays Main menu in stand-by mode and executes functions. Long press this key to start the digital camera in standby mode.

6. Voicemail Key:GLong press this key to

connect to the Voicemail centre automatically. (Depends on the SIM card.)

7. */Shift Key:

Switches character case among four modes: Abc, ABC, 123 and abc.

8. Main Display

9. Right Soft Key:C Executes the function at the

bottom right of the screen.

10.End/Power Key:FEnds a call, turns power on/

off.

11.Browser Key: Launches the browser in stand-by mode.

12.Keypad

Getting Started 9

13.# Key:

Switches symbol screens, and long press R launches “Profiles” screen.

Long press this key on the text entry screen to shift text input method between multi-tap and T9 mode. Press , then R during stand-by to activate Voice Recorder.

14.Microphone

15.Self-Portrait Mirror: For taking a self-portrait.

16.Camera

17.Speaker

18.Mobile Light: Used as an auxil iary light in

digital camera/video camera mode, as a battery charge indicator, or notification for incoming calls, data/fax calls or messages.

19.External Display

20.Handsfree Kit Connector

10 Getting Started

21.External Connector:

Used to connect either the charger or USB data cable.

22.RF Connector

23.Battery Cover

24.Built-in Aerial: Warning: Do not cover the

hinge area of the phone with your hand when in use as this may interfere with the performance of the built-in aerial.

25.Side-Up/Side-Down Keys:

V W Moves cursor to select

menu items, adjusts earpiece volume, etc. Long press this key during stand-by to turn the mobile light on or off.

26.Infrared Port: Sends and receives data via infrared.

Inserting the SIM Card and the Battery

1. Slide off the battery cover ( ).

3. Hold the battery so that the metal contacts of the

battery are facing down, slide the guides on the top of the battery into the battery slots , and then insert it .

2. Slide the SIM card into the SIM holder.

4. Replace the battery cover and slide it as shown

below.

SIM card

Note

• Make sure that only 3V SIM cards are used.

• Make sure that the standard accessory battery is used.

Getting Started 11

Removing the SIM Card and the Battery

1. Make sure to turn off your phone and disconnect the

charger and other accessories. Slide off the battery cover ( ).

3. Hold down gently whilst sliding the SIM card

out of the SIM holder .

2. Pick up the battery using the protruding edge and

remove the battery from the phone.

12 Getting Started

Battery Disposal

The device is supported by a battery. In order to protect the environment, please read the following points concerning battery disposal:

• Take the used battery to your local waste depot, dealer or customer service centre for recycling.

• Do not expose the used battery to an open flame, into water or dispose with the household waste.

Charging the Battery

You must charge the battery for at least 2 hours before using your phone for the first time.

Using the Charger

1. Remove the cover of the external connector, and

connect the charger to the external socket located at the bottom of the phone by pressing both sides indicated with arrows. Connect the charger to an AC outlet. Keep the cover in a safe place so as not to lose it.

Mobile light

The mobile light turns white when the battery needs to charge. When the phone is charging, the animated battery status icon ( ) in the upper right of the screen displays the current status. Standard charging time: Approx. 2 hours.

Note

• Charging time may vary depending on the state of the

battery and other conditions. (See “Battery” on page 120.)

To Disconnect the Charger

Long press the side buttons of the charger, then disconnect the charger from the external socket of the phone.

2. When charging is complete, the battery indicator

icon displays the full charge status and the mobile light turns off. Unplug the charger from the AC outlet, then unplug the charger connector from the phone. Put the cover back.

Note

• Do not use any non approved charger, this may

damage your phone and invalidate any warranty, please see “Battery” on page 120 for details.

Getting Started 13

To Charge Using the Cigarette Lighter Charger

The optional cigarette lighter charger supplies power for charging from the cigarette lighter socket of a car.

Battery Level Indicator

The current battery level is displayed in the upper right hand side of the main display and in the external display.

Low Battery During Use

When the battery is running low, an alarm will sound and the “ ” is displayed on the main display and the external display.

If you are using your phone and you hear the “low battery” alarm, attach your charger as soon as possible. The phone may not be able to continue normal operation if you continue to use it. The battery may only last approximately five minutes before the phone itself powers down during a call.

Battery Indicators Charge Level

Sufficiently charged

Partially charged

Charging recommended

Charging required

Empty

14 Getting Started

Turning Your Phone On and Off

To turn the power on, long press F for approximately 2 seconds.

The stand-by screen is displayed. To turn the power off, long press F for approximately

2 seconds.

To Enter the PIN Code

If activated you are asked to enter a PIN (Personal Identification Number) code after turning on your phone.

1. Enter your PIN code.

2. Press .

Note

• If your PIN code is entered incorrectly three times in a row, the SIM card is locked. See “PIN Entry” on page 112.

To Copy Phonebook Entries from the SIM Card

When you insert the SIM card into your phone for the first time and start Call Manager application, you are asked whether you wish to copy Phonebook entries on the SIM card. Follow the on-screen instructions, or you can do it later using the Phonebook menu as follows:

→

“Call Manager” “Advanced”

“Phonebook” → [Options] →

→

“Copy All Entries”

1. Select “From SIM to Handset”.

Main Display Indicators

Left soft key

Centre key/Navigation keys

Status indicators

Right soft key

Getting Started 15

Status Indicators

1. / : Strength of received signal/Service out of range

//:

GPRS within range and enabled/ Roaming outs ide network/GPRS with in range, enabled and roaming

2. : Call incoming

3. : Call in progress

4. / : Current WAP or MMS communication mode [CSD/GPRS]

5. / : Data communication mode enabled/ Fax communication mode enabled

6. “Diverts” (p. 101) set to “All Calls”

7. / : Secure WAP page displayed

8. / : SMS alerts [unread/mailbox full]

9. / : MMS alerts [unread/mailbox full]

10. : USB data cable connected

11. / : “Infrared” connection [enabled/ communicating]

16 Getting Started

12. //: Bluetooth wireless setting [enabled/ communicating with handsfree headset/ communicating with handsfree car kit]

13. / : Java™ application [executed (colour)/ suspended (grey)]

14.(No display) /////: Current profile [Normal/Meeting/ Activity/Car/Headset/Silent]

15. / / : T9 text input method or Chinese character input methods (T9 Stroke/T9 BoPoMoFo) enabled

16. ///: Current text input method [First letter uppercase/Uppercase/Lowercase/ Numeric]

17. //: “Ringer Volume” (p. 90) set to “Silent”/Vibration [enabled/enabled when silent]

18. : Battery level

19. : WAP message alert

20. / : Schedule entry enabled [with/without reminder alarm]

21. : Outbox contains unsent MMS

22. : Alarm settings enabled

23. : Voicemail message alert

External Display Indicators

Status Indicators

1. : Strength of received signal

2. : Battery level

3. : USB data cable connected

4. / : “Infrared” connection [enabled/ communicating]

5. / : Bluetooth wireless connection [enabled/communicating]

Getting Started 17

Navigating Functions

All applications are accessed from the Main menu. To open the Main menu, press the centre key ( ) during stand-by.

To launch applications, you will need to highlight menu items, and make selections. To select a menu item (indicated in quotation marks), move the cursor using a, b, c and d, and press to confirm your selection.

In certain procedures, you will need to press one of the soft keys (indicated in square brackets), which are displayed at the bottom left and right of the screen. Press the corresponding soft key (A or C).

To return to the previous screen, press the right soft key if it displays “Back”. To close the Main menu, press the right soft key if it displays “Exit”.

Each section in this user guide starts with a list of items you will need to select in order (indicated in italics) before performing the procedures shown. Select each item to reveal the next set of items that you have to select. Open subsection items after opening those listed in the main section.

Example:

→

“Call Manager” “Advanced”

18 Navigating Functions

“Phonebook” → [Options] →

Call Functions

Making a Call

1. Enter the area code and the phone number you wish

to dial and press D to dial. If you enter the wrong number, press [Clear] to

delete the number to the left of the cursor.

Emergency Calls

1. Enter 112 or 911 (international emergency number)

using the keypad and press D to dial.

Note

• Emergency calls may not be available on all mobile phone networks when certain network services and/ or phone features are in use. Contact your network operator for more information.

• This Emergency number can normally be used to make an emergency call in any country, with or without a SIM card inserted, if a GSM network is within range.

International Calls

1. Long press P until a “+” (international dialling

prefix) sign is displayed.

2. Enter the country code, followed by the area code

(without the leading zero) and the phone number, and press D to dial.

Speed Dialling

Up to 9 phone numbers from the Phonebook memory (Handset and SIM) can be assigned to speed dials. You can call the numbers using the digit keys (H to O and Q).

For details on setting the Speed Dial List, see “Speed Dial List” on page 39.

1. To dial a number using the speed dial, long press

any of the digit keys (H to O and Q). The phone number stored in the Speed Dial List is

dialled.

Call Functions 19

Redialling

You can redial numbers in the call log. Select from specific categories or “All Calls”. Specific category contains up to 10 numbers and the “All Calls” list contains up to 30.

1. Press D during stand-by.

2. Select the category from “All Calls”, “Dialled

Nos.”, “Missed Calls” or “Received Calls”. To switch logs, press c or d.

3. Select the phone number you wish to call.

4. Press D to redial the call.

Automatic Redialling

This setting allows you to automatically redial the number if the first attempt was unsuccessful because the called party was busy.

If you wish to stop redialling, press F or [End].

To Set the Auto Redial Function

→

“Settings”

1. Select “On” or “Off”.

Note

• When you receive an incoming call, the Auto Redial function is interrupted.

20 Call Functions

“Call Settings” → “Auto Redial”

• Automatic redialling is not available for fax and data calls.

Answering a Call

When an incoming call is detected, the phone rings and the mobile light flashes.

1. Press D, or [Answer] to answer the call.

Or press any key except F and [Busy] when the “Any Key Answer” function is enabled. Set the Any Key Answer function in the profile of each mode (p. 94).

Tip

• When the personal handsfree kit is connected to the phone, you can answer calls by pressing the Answer button.

• If you have subscribed to the Calling Line Identification (CLI) service and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are stored in the Phonebook, the caller’s name and phone number are displayed on the screen.

• If the number is a restricted number, the display shows “Withheld”.

• When receiving a call from the person whose picture is registered in the Phonebook, receiving display and the picture are displayed alternately.

Rejecting an Incoming Call

1. Press F or long press the side-up or side-down key

whilst the phone is ringing to reject a call you do not wish to answer.

Letting the Caller Know You are Unavailable

1. Press [Busy] whilst the phone is ringing to let the

caller of an incoming call know that you cannot answer the call.

Incall Menu

Your phone has additional functions available whilst a call is in progress.

Adjusting the Earpiece Volume

During a call, you can adjust the earpiece volume (and handsfree volume, if connected).

1. During a call, press the side-up or side-down key to

display the Earpiece Volume screen.

2. Press the side-up key (or a/d) to increase the

volume of the call or press the side-down key (or b/c) to decrease the volume.

Five levels (level 1 to 5) are selectable.

3. Press when the volume is set to the desired

level. The phone returns to the in-call screen

automatically if left unoperated.

Putting a Call on Hold

This function allows you to manage two calls at the same time. If you wish to make another call whilst you are talking to someone, you can put the current call on hold to call someone else.

To Make Another Call during a Call

1. During a call, press [Options].

2. Select “Hold”.

The current call is put on hold. To retrieve a call, press [Options] and select “Retrieve”.

3. Select “Call”.

4. Enter the phone number you wish to make another

call to, then press D.

Call Functions 21

Tip

• You can also make another call by entering the phone number directly during a call instead of steps 1 and 2, or by pressing [Options], selecting “Call” and entering the phone number. The current call is automatically put on hold.

Call Waiting

This service notifies you of another incoming call whilst you have a call in progress.

1. During a call, press [Options] and select “Hold &

Answer” to answer the second call. The first call is put on hold and you can now talk to

the second caller.

2. Press [Options] and select “Swap Calls”, or press

“Swap Calls” directly during a call to switch between the two calls.

3. Press [Options] and select “Release Call” to end the

current call and return to the held call.

Note

• You need to set “Call Waiting” to “On” if you use the Call Waiting service (p. 102).

• Call Waiting service may not be available on all networks. Contact your network operator for more information.

22 Call Functions

• If you do not wish to answer the second call, press [Busy], or press [Options], and select “Busy” or “Reject”, in step 1. If “Reject” is selected, the call log of the second call is saved as a missed call.

Accessing SMS Menu During a Call

1. During a call, press [Options] and select “SMS”.

The following options are available: “Create Message” to make an SMS, or “Inbox”, “Sent” or “Drafts” to access these folders. For details on SMS, see “SMS” on page 53.

Conference Call

Conference call is a call with more than 2 participants. You may include up to 5 participants in a conference call.

To Make a Conference Call

To make a conference call, you must have one active call and one held call.

1. During a call, press [Options] and select

“Multiparty”.

2. Select “Conference All” to make all participants

join the conference call.

3. Press F to end the conference call.

Note

• Conference call service may not be available on all networks. Contact your network operator for more information.

• You have more options for the Conf. call in step 2:

• To put all participants on hold, select “Conf. Hold

All”.

• To put all participants except the current call on

hold, select “Private”.

• To end the call with all participants, select

“Release All”.

• To disconnect from the conference call but still

allow the other participants to continue talking together, select “Transfer”.

• To put the current call on hold and continue to

have a conference call with the remaining participants, select “Exclude”.

• To reject adding more participants to the current

party, select “Reject”, or you can reject incoming calls by selecting “Busy”.

To Add New Participants to the Conference Call

1. Press [Options] and select “Dial”.

2. Enter the number you wish to include in the

conference call and press D to dial.

3. Press [Options] and select “Multiparty”.

4. Select “Conference All” to make all participants

join the conference call. If you wish to add other participants, repeat steps 1

to 4.

To End the Call with a Conference Call Participant

1. During a conference call, highlight the person that

you wish to disconnect from the conference call.

2. Press [Options] and select “Release Call”.

Call Functions 23

To Have a Private Conversation with One of the Participants

If you wish to have a private conversation with one of the participants, you may select the participant from the conference list and put the other participants on hold.

1. During a conference call, select the person that you

wish to talk to.

2. Press [Options] and select “Multiparty”.

3. Select “Private”.

4. Once you have finished the private conversation,

press [Options] and select “Multiparty”.

5. Select “Conference All” to return to the conference

call.

Muting the Dial Tone (DTMF Tone)

1. During a call, press [Options].

2. Select “DTMF Tones Off”.

To unmute, select “DTMF Tones On”.

Muting the Microphone

1. During a call, press [Mute] to mute the microphone.

To unmute the microphone, press [Unmute].

24 Call Functions

Entering Characters

When entering characters to create Phonebook entries, SMS or MMS messages, etc., press the corresponding keys.

In multi-tap input method, press each key until the desired character is displayed. For example, press H once for the letter “A” or twice for the letter “B”.

Table of Characters

Pressing each key scrolls characters in the following order. The order varies depending on the language selected.

English Mode

Key

G H I J

K L

Upper Case

Characters

. (full-stop) , (comma) - (hyphen) ? ! ’ (apostrophe) @ :1

ABC2 abc2 2

DEF3 def3 3

GHI4 ghi4 4

JKL5 jkl5 5

MNO6 mno6 6

Lower Case

Characters

Numeric

Key

M N

O Q

GQO

P R

Upper Case

Characters

PQRS7 pqrs7 7

TUV8 tuv8 8

WXYZ9 wxyz9 9

(space)+ = < > € £ $ ¥ % &0 0

Switches character case among four modes: Abc, ABC, 123 and abc.

.,?!:;-+#* @' '' ( )_&€£$ %/ ˜<>§= \ | ¥

¿¡^[ ]{ }¤ЕД Же дж а ЗЙи й м СсЦШцштЯЬь

ù ∆ΦΓ ΛΩΠΨΣΘ Ξ (space) ↵

- : Long press to enter 0 - 9 numbers.

: Long press to enter *. : Long press to shift between multi-tap

and T9 mode.

Lower Case

Characters

Entering Characters 25

Numeric

Changing the Input Languages

You can change the input language on the text entry screen.

1. On the text entry screen, press [Options].

2. Select “Input Language”.

If “Input Language” is not displayed, select “Text Options” and then select “Input Language”.

3. Select the desired language.

Changing the Input Method

1. On the text entry screen, press [Options].

2. Select “Input Method”.

If “Input Method” is not displayed, select “Text Options” and then select “Input Method”.

3. Select the input method you

wish to use.

26 Entering Characters

When “English” is selected for the Input Language option

...

When “Chinese” is selected for the Input Language option

Input Language = English Input Language = Chinese

T9 Abc

T9 ABC

T9 abc

Abc

ABC

abc

Symbol Table

Numeric

T9 BoPoMoFo

T9 Stroke

Abc

ABC

abc

Symbol Table

Numeric

Tip

In T9 or multi-tap mode, you can switch input mode as follows by pressing P.

English/T9 mode

English/Multi-tap mode

Chinese/T9 mode

(T9 BoPoMoFo) (T9 Stroke)

T9 Text Input

T9 text input method is a shortcut to enter text easily and quickly.

1. When English is selected for the input language,

long press R to enter T9 mode on the text entry screen. “ ” is displayed on the main display.

2. Press [Options].

3. Select “Input Method”.

If “Input Method” is not displayed, select “Text Options” and then select “Input Method”.

4. Select the T9 mode (T9 Abc, T9 ABC, T9 abc) you

wish to change.

5. Press each key to enter the letter.

6. If you wish to correct the word, highlight the word,

then press [Clear] to correct.

Entering Characters 27

Note

• If the correct word is not shown in step 6, enter the correct word again after switching to the multi-tap input method.

Tip

• If you press Q instead of step 6, a space is inserted next to the selected word.

Symbols and Punctuations

1. On the text entry screen, press [Options].

2. Select “Add Symbol”, or press R from any input

mode. If “Add Symbol” is not displayed, select “Text

Options” and then select “Add Symbol”. The first symbol page is displayed. In the Chinese input mode, the FullWidth Symbols screen is displayed.

3. Press a or b to switch pages (1 through 7), or use

the numeric keys (1 through 7).

28 Entering Characters

Table of BoPoMoFo and Stroke characters

Pressing each key scrolls characters in the following order.

When “Chinese” is selected for the Input Language option

Key BoPoMoFo Stroke

Wildcard

M N O P Q

Go to the FullWidth Symbols screen.

Space

Changing the Input Mode between BoPoMoFo and Stroke

See the section above,

page 26

Using BoPoMoFo Input Mode

Long press the

corresponding numeric

key to select the desired

character directly from

the Candidate field.

Candidate field

“Changing the Input Method” on

Input field

The following is an example of entering “ ” for “”.

1. Press J, Q, and M (2 times

quickly) to enter reading. The candidates with the same

reading are displayed in the Candidate field.

2. Long press K if the desired

character is displayed.

3. Repeat steps 1 and 2 to complete messages.

Entering Characters 29

Tip

• When the cursor is placed after the first character, the Candidate field displays characters most likely to follow.

• If you want to use tone options, long press P instead of step 2 to display the desired character. The tone symbols are displayed in the Candidate field. The candidates are displayed. Press the corresponding numeric key (H).

30 Entering Characters

Using Stroke Mode

The following is an example of entering “ ”.

1. Change the input mode to T9

Stroke mode.

2. Press IGJ to display the

corresponding stroke for “ ”.

3. Long press M to complete the

selection.

Using Text Templates

You can use the sentences registered in Text Templates when entering characters.

For details on creating the text template, see “Adding Phrases to Text Templates” on page 70.

1. On the text entry screen, move the cursor to the

point you wish to insert the template.

2. Press [Options].

3. Select “Text Template”.

If “Text Template” is not displayed, select “Text Options” and then select “Text Template”.

4. Select the text template you wish to use.

The selected text template is inserted.

Copying, Cutting and Pasting Text

Using these options, you can complete editing smoothly.

To Copy and Cut Text

1. On the text entry screen, press [Options].

2. Select “Copy” or “Cut”.

If “Copy” or “Cut” is not displayed, select “Text Options” and then select “Copy” or “Cut”.

3. Navigate the cursor to the first letter to be copied or

to be cut, then press A.

4. Navigate the cursor to the last letter to highlight the

area, then press A.

To Paste Text

1. On the text entry screen, navigate the cursor to the

point you wish to paste the letters.

2. Press [Options].

3. Select “Paste”.

If “Paste” is not displayed, select “Text Options” and then select “Paste”. Saved text is pasted.

Entering Characters 31

Using the Menu

Using the Main Menu

1. Press during stand-by.

The Main menu is displayed.

2. Navigate to required location.

3. Press to access function.

32 Using the Menu

Shortcut Keys

You can shortcut to the specified menus by pressing

and digit keys for the menu’s corresponding number on the Main menu. See the following table for reference.

Shortcuts are listed in the headings of this manual. For example: “M 9-6”.

Example: To Access “Network Settings” Sub

Menu Using Shortcut Keys

Press O L.

Note

• The shortcut keys work for the first three menu levels

only.

List of Menu Functions

Menu No./

Main Menu

1 Java™ 1 Java™ Gallery

2 FET Mobile Internet 1 Homepage

3 Organiser

4 Messages 1 MMS

5 Camera 1 Digital Camera

2 Java™ Wallpaper 3 Download More 4 Settings 5 Java™ Information

2 Bookmarks 3 Go to URL

1 SIM Application 2 Calendar 3 Alarms 4 Calculator 5 Voice Recorder 6 Melody Editor 7 Help List

2 SMS 3 Alert Inbox 4 Voicemail 5 Cell Broadcasts 6 Area Info

2 Video Camera

Menu No./

Sub Menu1

Menu No./

Main Menu

6 Gallery 1 Picture Gallery

7 Profiles 1 Normal

8 Call Manager 1 Phonebook

9 Settings 1 Display

2 Java™ Gallery 3 Sound Gallery 4 Video Gallery 5 Bookmarks 6 Text Templates 7 My Chinese Beloved 8 Memory Status

2 Meeting 3 Activity 4 Car 5 Headset 6 Silent

2 Add New 3 Call Log 4 Speed Dial List 5 My Numbers 6 Call Timers 7 Data Counter 8 Call Costs

2 Call Settings 3 Date & Time 4 Language 5 Connectivity 6 Network Settings 7 Security 8 Master Reset

Menu No./

Sub Menu1

* Depends on SIM card contents.

Using the Menu 33

Phonebook

You can store the phone numbers and e-mail addresses of your friends, family and colleagues in the Phonebook.

Depending on the size of the entry, your phone can store up to 640 phone numbers. In a Phonebook, you can store the following items.

Items stored in the handset memory

Last Name First Name Tel Mobile Private Tel Private Tel Office E-mail Private E-mail Business Group Address (Street & Number, City, State/Province, Postal

Code, Country) Note

34 Phonebook

(M 8-1)

Items stored in the SIM memory

Name: The number of characters that can be

Phone number: Up to 40 digits Using the infrared or Bluetooth wireless function, you

can send the Phonebook entry to a PC to share the same entries.

stored differs depending on the SIM card you use.

Selecting the Storage Memory

“Call Manager” → “Phonebook” → [Options] → “Advanced” → “Save to”

1. Select Phonebook location from “To Handset”, “To

SIM” or “Choice”.

Tip

• “Choice” prompts you to choose the memory every

time you save a new entry.

Changing the List Displayed

“Call Manager” → “Phonebook” → [Options] → “Advanced” → “Source”

1. Select from “Handset Memory”, “SIM Memory” or

“Both”.

Add New

You can choose either the Handset Memory or SIM Memory to store the new entry. For switching locations, see “Selecting the Storage Memory” on page 34.

The amount of phone numbers that you can store to the SIM card is dependent on its capacity. Contact your network operator for details.

“Call Manager”

(M 8-2)

→

“Add New”

1. Select the location you wish to save from “To

Handset” or “To SIM”.

2. Highlight the field you wish to fill in, and enter the

relevant information.

3. Press [Save] when finished.

Tip

• To create an entry, at least one field must be filled. If you create a new entry on the SIM card, you need to enter a phone number.

Adding a Thumbnail to Entries

→

“Call Manager”

“Phonebook”

1. Select the desired entry.

2. Press [Options] and select “Edit”.

3. Press [Options] and select “Thumbnail”.

4. Select the desired picture.

5. Press [Save] when finished.

Note

• Thumbnails can be added only to the entries stored in the handset memory.

• From the Phonebook entry that has a thumbnail added, you can change or delete it by selecting “Change” or “Remove” after step 3.

• If you delete a picture in Picture Gallery, the corresponding thumbnail is also deleted.

Copying Phonebook Entries between SIM Card and Handset

“Call Manager” → “Phonebook” → [Options] → “Advanced” → “Copy All Entries”

1. Select “From SIM to Handset” or “From Handset to

SIM”.

Phonebook 35

Note

• When you insert the SIM card into your phone for the first time and start the Call Manager application, the confirmation screen appears automatically, asking you if you wish to copy or not. The number of Phonebook entries to be copied varies depending on the SIM capacity.

Copying a Single Entry from Handset to SIM Card

→

“Call Manager”

“Phonebook”

1. Select the desired entry.

2. Highlight the desired phone number.

3. Press [Options] and select “Copy to SIM”.

Finding a Name and Number

“Call Manager” → “Phonebook”

1. Select from “Character Search”, “BoPoMoFo

Search” or “English Search”.

2. Enter the first few letters of the name or BoPoMoFo

characters. Search results of names or BoPoMoFo characters

are displayed in alphabetical order.

36 Phonebook

Tip

• You can select the source from “Handset Memory”, “SIM Memory” or “Both” before searching.

• To view the details of the item such as address, highlight the desired item, press [Options] and select “View”.

Dialling from the Phonebook

“Call Manager” → “Phonebook”

1. Highlight the desired entry and Press D.

Tip

• If more than one phone number is registered for the entry, select the desired phone number after step 1 and press D. You can also dial the desired phone number by pressing the digit key corresponding to the position the entry is on the list.

• You can also dial from the details screen of the Phonebook. On the details screen, select the desired phone number and press D.

• If you select “SIM Memory” for the “Source” option in Phonebook menu (p. 34), only one phone number entry is displayed.

Editing Phonebook Entries

“Call Manager” → “Phonebook” → [Options] → “Edit”

1. Select the field you wish to edit, and modify the

information.

2. Press [Save] when finished.

Deleting Phonebook Entries

Deleting All Phonebook Entries

“Call Manager” “Advanced” → “Delete All Entries”

1. Enter your handset code.

2. Select “Handset Entries” or “SIM Entries”.

The default handset code is “0000”. For details on changing the handset cod e, see “To Change Handset Code” on page 113.

Deleting a Phonebook Entry

“Call Manager”

1. Highlight the desired entry.

2. Press [Options] and select “Delete”.

→

“Phonebook” → [Options] →

→

“Phonebook”

Viewing Groups

You can set group icons when storing Phonebook entries so that you can easily find and edit them.

“Call Manager” “Advanced” → “Group” → “View Groups”

1. Select the desired group.

“ ” appears next to the selected group. Select the group again to cancel, and the checkbox becomes unchecked.

Tip

• When “Group” is not displayed, check if the source

of the phonebook is set to “Handset Memory”.

• Press [Options] and select “Current Only” to view

only the selected group or “Select All” to view all groups.

→

“Phonebook” → [Options] →

Phonebook 37

Group Call

Different ringtones can be set for each group. When you purchase this phone, groups are set to off. If you do not set a group ringtone, the ringtone assigned in the Settings menu is used.

→

“Call Manager” “Advanced”

“Phonebook” → [Options] →

→

“Group” → “Group Call”

1. Select the desired group.

2. Select “Switch On/Off”.

3. Select “On” or “Off”.

4. Select “Assign Melody”.

5. Select “Preset Melodies” or “Sound Gallery”.

6. Select the desired ringtone.

For details on selecting a ringtone, see “Assigning Melody” on page 90.

7. Select “Vibration” and select from “Enable”,

“Disable” or “Link to Sound”. For details on selecting a vibration, see “Vibration”

on page 90.

8. Select “Light” and select “On”, “Off” or “On &

Link to Sound”. For details on selecting a light, see “Light” on

page 91.

9. Press [OK].

38 Phonebook

Assigning a Ringtone to Each Phonebook Entry

A specified ringtone or vibration setting can be associated to a pre-registered entry.

→

“Call Manager”

“Phonebook”

1. Select the desired entry.

2. Press [Options] and select “Edit”.

3. Press [Options] and select “Ringtone”.

4. Select “Switch On/Off”.

5. Select “On” or “Off”.

6. Select “Assign Melody”.

7. Select “Preset Melodies” or “Sound Gallery”.

8. Select the desired ringtone.

For details on selecting a ringtone, see “Assigning Melody” on page 90.

9. Select “Vibration” and select from “Enable”,

“Disable” or “Link to Sound”. For details on selecting a vibration, “Vibration” on

page 90.

10. Select “Light” and select “On”, “Off” or “On &

Link to Sound”. For details on selecting a light, see “Light” on

page 91.

11. Press [OK].

12. Press [Save].

Memory Status

This function helps you to check the memory used in the Phonebook.

“Call Manager” “Advanced” → “Memory Status”

→

“Phonebook” → [Options] →

Speed Dial List

You can set a maximum of 9 phone numbers in the Speed Dial List (p. 96).

Setting Phonebook Entries in the Speed Dial List

“Call Manager” → “Phonebook”

1. Select the desired entry.

2. Highlight the desired phone number.

3. Press [Options] and select “Add to Speed Dial”.

4. Select the desired list number (H to O and Q).

5. Press “Select” or to save.

Tip

• The nine digit keys correspond to list numbers.

• To view the speed dial list, see page 96.

Sending a Phonebook Entry

“Call Manager” → “Phonebook”

1. Highlight the desired entry.

2. Press [Options] and select “Send Recipient”.

3. Select “Via Bluetooth” or “Via Infrared”.

Phonebook 39

For “Via Bluetooth”

The phone starts searching for Bluetooth wireless technology enabled devices within 10 metres.

When detected, a list of enabled devices is displayed allowing you to select the desired device. The connection can be established and the entry is sent.

For “Via Infrared”

The phone starts searching for an infrared-enabled device within 20 cm.

When detected, the infrared connection is established and the entry is sent.

Note

• When pairing, you need to enter your passcode when establishing contact with a Bluetooth wireless technology enabled device for the first time except when “Authentication” (p. 109) is set to “Off”.

Tip

• You can send your own Phonebook entry. Select “My Card” in step 1. For details on storing your information in My Card, see “Registering Your Information as a Phonebook Entry”.

40 Phonebook

Receiving a Phonebook Entry

When the phone receives a Phonebook entry, the message “Save (file name) to Phonebook?” appears in the stand-by mode screen.

1. Press [Yes].

The received entry is registered in the Phonebook. Press [No] to reject.

Tip

• For details on making Infrared or Bluetooth wireless settings, see “Connectivity” on page 106.

Registering Your Information as a Phonebook Entry

You can store your information in the Phonebook.

→

“Call Manager”

1. Press [Options] and select “Edit”.

2. Select the field you wish to fill in, and enter the

relevant information.

3. Press [Save] when finished.

Tip

• You can send your Phonebook entry via Bluetooth or Infrared. Highlight “My Card” in the Phonebook and press [Options]. Select “Send Recipient” and then select “Via Bluetooth” or “Via Infrared”.

“Phonebook” → “My Card”

Camera

Your phone has an integrated digital camera. This allows you to take and send pictures or video clips

wherever you are.

Digital Camera

Put the phone into the digital camera mode to take a picture. Pictures are saved in Picture Gallery in JPEG format in the following three picture sizes.

Taking Pictures

“Camera”

The preview is displayed through the screen.

(M 5)

(M 5-1)

L: 480 × 640 dots M: 240 × 320 dots S: 120 × 160 dots

→

“Digital Camera”

1. Press or the side-down key to take the picture.

The shutter sounds and the still image of the taken picture is displayed. Press [Cancel] to retake a picture.

2. Press [Save].

“Saving (file name) to Gallery…” is displayed, then the picture is registered.

3. Press F to return to stand-by.

Remaining shots indicator

123: Indicates the remaining number of

Tip

• If you wish to use a flash, press R or the side-up key

before step 1. Press it again to turn the flash off.

appears or disappears on the upper part of the

screen.

• If you wish to send a picture by MMS message after

taking the picture, press before step 2. Large MMS messages may cause the size of attached pictures to be reduced.

Using the Full Screen

The preview can be displayed on the full screen without the soft key area and indicators.

“Camera” Viewfinder”

pictures that can be taken.

→

“Digital Camera” → [Options] →“Full

1. Select “On” or “Off”.

Tip

• You can also turn on or off the full screen mode by

pressing Q.

Camera 41

Taking a Self-Portrait

To take a self-portrait, hold the phone with the mirror facing you whilst holding the phone at least 40 cm away. Press or the side-down key to take the picture.

Using the Zoom Function

Press c or d to change the zooming ratio. Zooming ratio indicators

Note

• When “Picture Size” is set to “S”, the zoom function has 3 magnifications (

• When “Picture Size” is set to “M”, the zoom function has 2 magnifications (

Selecting the Picture Size

“Camera” “Picture Size”

:Magnification

1, ×2, ×4).

1, ×2).

→

“Digital Camera” → [Options] →

1. Select the desired picture size.

42 Camera

Selecting the Picture Quality

“Camera” “Picture Quality”

→

“Digital Camera” → [Options] →

1. Select “Normal” or “Fine”.

Picture quality indicators

: Normal :Fine

Selecting the Anti-flicker

→

“Camera” “Anti-flicker”

“Digital Camera” → [Options] →

1. Select “Mode1” or “Mode2”.

Note

• Vertical stripes may occur on the picture due to the light source. Change the mode to rectify.

• The digital camera uses a C-MOS sensor. Although this camera has been manufactured to the highest specifications, some pictures may still appear too bright or too dark.

• If the phone has been left in a hot place for a long time before taking or registering a picture, the picture quality may be poor.

In the Case of No Available Memory

When the number of pictures that can be taken becomes 3 or less, the remaining shots indicator in the upper left of the screen turns red. (The number of pictures that can be taken is approximate.)

Even if the number of pictures that can be taken becomes 0, you can continue to take and save pictures until the message, “Memory full. Please delete some data!” appears. After that, no pictures can be saved. Try to delete or move the data to make some space.

Adjusting the Brightness of the Picture According to Lighting Conditions

Press a or b to adjust the brightness of the picture. Picture brightness (exposure level) indicators

→

: (Bright → Normal Once the phone has returned to the stand-by screen, the brightness settings return to default.

Dark)

Viewing the Taken Pictures

→

“Camera” “Picture Gallery”

The list of pictures is displayed.

“Digital Camera” → [Options] →

1. Select the file you wish to view.

The selected picture is displayed.

Tip

• Your pictures are given file names which are “pictureNNN.jpg” (NNN is a consecutive number). The file name (without an extension), date and size of your pictures are displayed in the list.

Using the Timer (Delay Timer)

→

“Camera” “Delay Timer”

“Digital Camera” → [Options] →

1. Select “On” or “Off”.

“ ” is displayed on the screen and the phone returns to digital camera mode.

2. Press or the side-down key to start the delay

timer. 10 seconds after the timer sounds, the shutter

sounds, and the camera takes a picture.

Camera 43

Note

• The countdown sounds whilst the delay timer is operating.

• The flash light and t he indicator flash whilst the delay timer is operating.

• If or the side-down key is pressed whilst the delay timer is operating, the picture is taken instantly.

• The zoom function with c or d, or brightness adjustment of the picture with a or b, is unavailable whilst the delay timer is operating.

• If you wish to stop taking pictures with the timer, press [Cancel] whilst the delay timer is operating.

Continuous Shot

Four pictures are taken in succession. Auto shot and manual shot are available.

Continuous shot indicators

When pictures are taken in continuous shot mode, these indicators appear on the screen.

* When delay timer and continuous shot functions

are simultaneously set, “ ” is displayed instead.

44 Camera

→

“Camera” “Continuous Shot”

“Digital Camera” → [Options]→

1. Select “Auto Shot” or “Manual Shot”.

Select “Off” to cancel.

2. Press or the side-down key to start continuous

shot. Auto Shot: Four pictures are taken in a row.

Manual Shot: Pictures are taken one by one by

The taken pictures are saved automatically. To stop continuous shot, press [Cancel].

Note

• When “Picture Size” is set to “L”, you cannot use the continuous shot function.

• When you select a frame for taking pictures, you cannot use the continuous shot function.

• Delay timer cannot be used with the manual shot setting.

pressing or the side-down key.

Selecting a Frame

You can select the frame from preset patterns. You can also select a frame in Picture Gallery.

→

“Camera” Frame”

“Digital Camera” → [Options] → “Add

1. Select “Preset Frames” or “Picture Gallery”.

2. Select the desired frame.

The selected frame is confirmed on the display.

3. Press .

Note

• When “Picture Size” is set to “L”, you cannot use the Frame function.

• When you activate the Continuous Shot function, you cannot use the Frame function.

• Only the images of PNG format can be selected as the frame if you select “Picture Gallery” in step 1. However, images larger than 120 [W] cannot be used as frames.

Selecting the Shutter Sound

You can select the shutter sound from 3 preset patterns.

→

“Camera” “Shutter Sound”

“Digital Camera” → [Options] →

160 [H]

1. Select the desired shutter sound.

To play back the shutter sound, press [Play].

Note

• Continuous Shot uses the specialised shutter sound that cannot be changed for the above settings.

Sending Pictures

To send your picture to another phone or e-mail address, see “Sending a Picture File” on page 64 for instructions.

Video Camera

Put the phone into the video camera mode to record a video.

Video clips are saved in “.3gp” format in the following two modes:

Record time indicators

: Message sending mode enabled : Extended video mode enabled

(M 5-2)

Camera 45

Recording Video Clips

Sound can be recorded with the video clip.

→

“Camera” → “Video Camera”

The preview is displayed through the screen.

1. Press or the side-down key to start recording

the video clip. The sound for recording the video clip occurs.

If you press or the side-down key again, or when the recording is completed, the sound for ending the video clip recording occurs and the display transits to step 2.

2. Select “Save”.

“Saving (file name) to Gallery…” is displayed, then the video clip is registered. To preview a video clip before saving, select “Preview”. To send a video clip by MMS message after recording the video clip, select “Save and Send”. To record a video clip again, press [Cancel].

Remaining sets indicator

123 : Indicates the remaining sets of video

46 Camera

clips that can be recorded.

Using the Zoom Function

Press c or d to change the zooming ratio. Zooming ratio indicators

Selecting the Recording Size Mode

You can select the recording size mode. This function is available when the “Message Size” is set to “30KB” in MMS settings (p. 53).

→

“Record Size”

:Magnification

→

“Camera” → “Video Camera” → [Options]

1. Select “Extended Video” or “For MMS”.

Note

• If “For MMS” is selected, the size of the video clip that can be recorded depends on the message size set in MMS settings (p. 53).

• When the Message Size described on page 53 is set to“100 KB”, “Record Size” is not displayed.

• “Save and Send” is not displayed after recording in extended video mode.

• This option is not applicable to some service providers. Please contact your service provider for more information.

Selecting Video Quality

→

“Camera” → “Video Camera” → [Options]

→

“Video Quality”

1. Select “Normal” or “Fine”.

Video quality indicators

: Normal :Fine

Selecting the Anti-flicker

→

“Camera” → “Video Camera” → [Options]

→

“Anti-flicker”

1. Select “Mode1” or “Mode2”.

Note

• Vertical stripes may occur on the video clip due to the light source. Change the mode to rectify.

• The video camera uses a C-MOS sensor. Although this camera has been manufactured to the highest specifications, some video clips may still appear too bright or too dark.

• If the phone has been left in a hot place for a long time before recording a video clip, the video quality may be poor.

In the Case of No Available Memory

When the number of video clips that can be recorded becomes 3 or less, the remaining sets indicator in the upper left of the screen turns red. (The number of sets that can be recorded is approximate.)

Even if the number of video clips that can be recorded becomes 0, you can continue to record and save video clips until the message, “Memory full. Please delete some data!” appears. After that, no video clips can be saved. Try to delete or move the data to make some space.

Adjusting the Brightness of the Video Clips According to Light Conditions

Press a or b to adjust the brightness of the video clip. Picture brightness (exposure level) indicators

→

: (Bright → Normal Once the phone has returned to the stand-by screen, the brightness settings return to default.

Dark)

Camera 47

Viewing Recorded Video Clips

→

“Camera” → “Video Camera” → [Options]

→

“Video Gallery”

The list of video clips is displayed.

1. Select the file you wish to view.

2. Press .

The selected video clip is played back. To pause playback, press . To resume playback, press again. To stop playback, press [Back].

Tip

• Your video clips are given file names such as “videoNNN.3gp” (NNN is a consecutive number). The file name (without an extension), date and size of your video clips are displayed in the list.

• If the video clip has been recorded with sound, the volume can be adjusted by pressing a (or d/the side-up key) or b (or c/the side-down key).

• The volume varies depending on the Settings of Ringer (p. 90). The sound is deactivated when “Ringer Volume” is set to “Silent”.

48 Camera

Using the Timer (Delay Timer)

To Record a Video Clip with the Timer

→

“Camera” → “Video Camera” → [Options]

→

“Delay Timer”

1. Select “On” or “Off”.

“ ” is displayed on the screen and the phone returns to video camera mode.

Press or the side-down key to start the delay timer. 10 seconds after the timer sounds, the camera starts

recording the video clip.

Note

• The countdown sounds whilst the delay timer is operating.

• If or the side-down key is pressed whilst the delay timer is operating, the video clip is recorded instantly.

• The zoom function with c or d, or brightness adjustment of the video with a or b, is unavailable whilst the delay timer is operating.

• If you wish to stop recording video clips with the timer, press [Cancel] whilst the delay timer is operating.

Recording Video Clips with Sound

→

“Camera” → “Video Camera” → [Options]

→

“Voice Record”

1. Select “On” or “Off”.

Messages

Your phone allows you to send and receive SMS or MMS and to receive WAP alerts.

(M 4-1)

MMS

About MMS

Multimedia Messaging Service (MMS) allows you to send and receive multimedia messages with graphical images, photographs, sound, animations or video clips attached.

Note

• Some MMS functions may not always be available

depending on your network. Contact your network operator for more information.

Creating a New MMS

→

“MMS” → “Create Message”

(M 4)

(M 4-1-1)

1. Enter the message.

To use the text template, move the cursor to the point you wish to insert the template. Press [Options] and select “Text Options”. Select “Text Template” and then select the desired template.

2. Enter the phone number or e-mail address of the

recipient. You can enter the phone number or e-mail address

from the phonebook entries (p. 34). If desired entry does not exist, select “Enter Number” or “Enter E-mail Address” and enter the phone number or E-mail address.

3. Select “Send”.

After the message is sent, the message is moved to the Sent box.

Note

• The current message size displayed whilst you are

creating the message is an approximation.

• If a message cannot be sent for some reason, the

message stays in the Outbox and “ ” is displayed on the stand-by screen.

Tip

• To save the message without sending, select “Save to

Drafts” instead in step 3.

• To enter the subject, select “Subject” in step 3 and

enter it. This is optional. Up to 40 characters as the subject (and up to 20 recipients (for To and Cc)) can be entered. However, these may be limited depending on your network. In this case, you may not be able to send MMS. Contact your network operator for more information.

Messages 49

• To add more recipients, select “Add Recipient” in step 3. Select “To” or “Cc” and select the desired number of the recipient. Then enter the phone number or e-mail address.

To Send a Message Template MMS

Your phone provides message templates with an image and voice attachment that help you create easily.

→

“MMS” → “Create Message” → [Options] →

A “Message Template”

A confirmation screen asking whether you wish to discard the current text is displayed.

1. Confirm by selecting [Yes] or [No].

2. Select the desired template.

3. Enter the message.

4. Enter the phone number or e-mail address of the

recipient.

5. Select “Send”.

Note

• Selecting “Message Template” deletes messages or images you have entered or attached. To prevent deletion, select “Message Template” first, then enter messages.

50 Messages

Turning the Slide Show Setting On or Off

→

“MMS” → “Settings” → “Slide Show”

1. Select “On” or “Off”.

If You Select “On”

• You can create messages which have up to 10 slides. Each slide can contain one picture, one sound file and up to 1000 characters of text (up to the message total 30 Kbytes or 100 Kbytes limit).

• If you wish to add a slide to a single slide when editing MMS, press [Options] and select “Add Slide”. If you wish to perform slide operations for multiple slides, press [Options] and select “Slide Control”. The slide control options available are: Add: To add a new slide. Remove: To remove the active slide. Previous: To navigate to the previous slide. Next: To navigate to the next slide.

• Video clip data cannot be attached as slide data to the message.

If You Select “Off”

• You can attach a maximum of 20 pictures, sounds or video clips and up to 2000 characters of text (up to the message total 30 Kbytes or 100 Kbytes limit).

Inserting Attached Data

You can send pictures, sounds and video clips saved in the handset memory attached to MMS messages. When attaching video clips, “Slide Show” must be set to “Off”.

→

“MMS” → “Create Message”

1. Press [Options] and select from “Picture”, “Sound”

or “Video Clip”.

2. Select the desired file name.

The selected picture/sound/video clip is attached. When attaching is complete, press [Back] to return to the message creation screen.

• To remove the attached files, press [Options] and select “Remove” in the menu of attaching pictures, sounds or video clips.

Note

• Pictures/Sounds/Video clips protected with a copyright cannot be sent attached to a message.

• Instead of performing step 2, you can send data recorded with “Digital Camera”, “Voice Recorder” or “Video Camera” options.

Reading MMS

Messages you receive are stored in the Inbox.

Incoming Messages

The MMS indicator ( ) will appear when you are receiving an incoming message.

→

“MMS” → “Inbox”

1. Select the message you wish to view.

The message is displayed.

2. Scroll the screen to read the message.

3. Press when finished.

Tip

• The volume varies depending on the Multimedia Volume settings (p. 93). The sound is deactivated when “Multimedia Volume” is set to “Silent”.

Storing the Phone Number or E-mail Address of a Sender in the Phonebook

→

“MMS” → “Inbox”

1. Highlight the message from which you want to store

the phone number or e-mail address.

2. Press [Options] and select “Save to Phonebook”.

For details on entering a name, see “Add New” on page 35.

Messages 51

Retrieving MMS

When “ ” is in the Inbox, the following can be done.

→

“MMS” → “Inbox”

1. Highlight the alert you wish to download.

2. Press [Options] and select “Download”.

Tip

• You can press instead of step 2 to start downloading.

Confirming Arrival of Delivery Report

→

“MMS” → “Sent”

1. Highlight the message of w hich you wish to confirm

arrival of delivery report.

2. Press [Options] and select “Delivery Report”.

This menu is available only for sent messages that have the “Delivery Report” set to “On”. For details on selecting “Delivery Report”, see “Setting Up MMS”.

52 Messages

Setting Up MMS

→

“MMS” → “Settings”

1. Select the desired item you wish to set up.

• Download Msg. (Immediate, Deferred): Controls MMS download timing. Immediate:Downloads MMS immediately from

Deferred: Asks if you would like to download

• Intl. Download Msg. (Immediate, Deferred): Controls MMS download timing when roaming outside of your network.

• Delivery Rep. Allow (On, Off): Enables or disables Delivery Report when receiving a message which applies to the Delivery Report function.

• Anonymous Reject (On, Off): Rejects a messages from an unknown or empty address name.

• Auto Delete (Off, Inbox, Sent, Both): Deletes the oldest message automatically, when the Inbox, Sent or Both (Inbox and Sent) is full.

• Slide Show (On, Off): Enables or disables Slide Show when sending a message.

the server.

from the server.

• Message Size (30 KB, 100 KB): Sets the maximum message size that can be sent.

The maximum message size that can be sent differs according to the network operator. Contact your network operator for more information.

• Advanced

• Priority:

Prioritises composed messages.

• Delivery Report:

Enables Delivery Report.

• Expiry Time:

Sets Expiry Time for a message to be stored in the Server.

• Sender Visibility:

Displays the information about the sender.

• Slide Interval:

Sets the slide display time when sending a message.

2. Change each item.

Memory Status

This function helps you to check the memory status of MMS.

→

“MMS” → “Memory Status”

(M 4-1-7)

(M 4-2)

SMS

About Text Messaging

The Short Message Service (SMS) allows you to send text messages of up to 1024 characters to other GSM users.

To Use SMS with Your Phone

Messages longer than 160 characters may be composed. During sending, the messages are split. If the receiver has a suitable phone the messages recombines during reception, if not your message appears as a number of separate 152 characters messages. You can send or receive SMS even if you are talking on the phone. You can also use Text Templates to help you compose SMS.

Messages 53

Creating and Sending a New SMS

→

“SMS” → “Create Message”

(M 4-2-1)

1. Enter your message.

To use the text template, move the cursor to the point you wish to insert the template. Press [Options] and select “Text Template” and then select the desired template.

2. After entering the message, press and select

the desired recipient from the Phonebook entries. If the desired entry does not exist, select “Enter

Number” and enter the phone number.

3. After confirming the recipient, press [OK] and

select “Send”. The phone begins the sending process and the SMS

is sent. After the message has been sent, the message is added to the Sent box. To save the message in the Drafts box without sending it, select “Save to Drafts”.

Note

• When you send a message of more than 160 characters, the confirmation message is displayed.

54 Messages

Tip

• To add more recipients, select “Add Recipient” in step 3. Select an item number for adding the recipient’s phone number. Then enter the phone number.

Reading SMS

Incoming Messages

The SMS indicator ( ) will appear when an incoming message arrives.

1. When you receive a SMS, press during stand-

by.

2. Select the message you wish to view.

The sender’s phone number and a part of the message are displayed. When the sender’s phone number is stored in the Phonebook, the sender’s name is displayed instead of the phone number.

3. Scroll the screen to read the message.

4. Press F when finished.

Extracting Phone Numbers from the Received Messages and Making a Call

You can make a call using the phone number embedded in the received SMS message.

→

“SMS” → “Inbox”

1. Select the message from which you wish to extract

phone numbers.

2. Press [Options] and select “Extract Numbers”.

Telephone numbers embedded in the message are displayed.

3. Highlight the phone number.

4. Press [Options] and select “Make Call”.

To save this phone number in the Phonebook, select “Save Number”.

Setting Up SMS

To Set Up the Service Centre Address

→

“SMS” → “Settings” → “Message Centre”

(M 4-2-5)

1. Enter the centre phone number.

If you wish to enter a country code for a message to an international number, long press P until a “+” sign is displayed.

Message Lifetime

This indicates the number of days and hours for which a message you send may remain undelivered to the message recipient.

During this period, the message service centre will continually try to deliver the message to the recipient.

→

“SMS” → “Settings” → “Message Lifetime”

1. Select the validity period.

Message Format

→

“SMS” → “Settings” → “Message Format”

1. Select the message format.

Messages 55

Connection Type

→

“SMS” → “Settings” → “Connection Type”

1. Select the desired setting of “Connection Type”.

Confirm Delivery

→

“SMS” → “Settings” → “Confirm Delivery”

1. Select the desired setting of “Confirm Delivery”.

Alert Inbox

See your list of WAP push messages. You can receive push messages via WAP Services.

This means that a service provider sends WAP content to your phone, without any set up.

Voicemail

You can use Voicemail by connecting to the Voicemail centre. Voicemail service depends on the SIM card.

Getting Voicemail

→

“Voicemail”

(M 4-3)

(M 4-4)

1. Select “Get Voicemail”.

Configuring Voicemail Settings

You can select the mailbox for use inside your home network area, or for roaming use.

→

“Voicemail” → “Voicemail Settings”

1. Select “Home Mailbox” for use inside your home

network area, or “Roam Mailbox” for roaming use.

56 Messages

Cell Broadcasts

You can receive Cell Broadcast messages or general messages such as weather forecasts and traffic reports. This information is broadcast to subscribers in certain network areas.

This function may not be available on all mobile phone networks. Contact your network operator for more information.

Enabling/Disabling Cell Broadcasts

→

“Cell Broadcasts” → “On/Off”

(M 4-5)

(M 4-5-1)

1. Select “On” or “Off”.

Reading Cell Broadcast Messages

→

“Cell Broadcasts” → “Read Messages”

(M 4-5-2)

1. Select the desired subject.

2. Scroll the screen to read the message.

3. Press [Back].

Setting Languages

You can select your preferred language for the cell broadcast message display.

→

“Cell Broadcasts” → “Settings” →

A “Language”

The current language is displayed.

(M 4-5-3)

1. Press . The language list is displayed.

2. Select the desired language.

3. Press [Back].

Subscribing to Cell Broadcasts

Select the page of the cell broadcast message that you want.

→

“Cell Broadcasts” → “Settings” → “Set Info

A Subjects”

1. Select “Add/Remove”.

2. Select the desired page.

3. Press [Back].

Tip

• If the desired page is not in the list that appears in step 2, select “Create Subject” in step 1, then enter the subject code to add a page. For details on the subject code, contact your service provider.

Area Info

The Area info is the message information that operators sent to subscribers in certain areas.

When you receive Area Info, the message (area code) is displayed on the stand-by screen.

Note

• This function may not be available on all mobile phone networks. Contact to your network operator for more information.

Enabling/Disabling Area Info

(M 4-6)

1. Press A during stand-by.

2. Select “Area Info”.

3. Select “On” or “Off”.

Note

• If Area Info is set to “On”, the stand-by time will decrease.

Messages 57

FET Mobile Internet

Your phone contains a WAP browser used for surfing on the Mobile Internet. Your phone is already setup to browse FET Mobile Internet, where you can get a lot of useful information. Normally, pages are designed for a mobile phone.

(M 2)

Starting the WAP Browser

1. Press E during stand-by.

2. Press a or b to highlight the menu you wish to

view, then press A.

To Exit the WAP Browser

1. Press F to exit the browser.

58 FET Mobile Internet

Navigating a WAP Page

• a b c d:

Move the highlights around in the screen.

• : Executes the option displayed in the lower centre of the screen.

• A: Launches browser option menu.

• C: Selects an action displayed in the lower right corner of the screen.

• E: Used to access “Homepage” by opening the browser.

• Q (long press): Starts the “Go to URL”.

• G to O (long press): Launches the Bookmark (WAP) after assigning hot keys with the “Bookmark” option of the browser.

• F: Exits the browser (short press). Turns off the phone (long press).

Browser Menu

When you are browsing, you can reach browsing options by pressing [Options].

•Select: Selects the link you wish to see. (“Select” is displayed only when the link is highlighted.)

•Home: Goes to the homepage you set in the WAP Settings.

• Alert inbox: See your list of WAP push messages. You can receive push messages via WAP Services. This means that a service provider sends WAP content to your phone, without any set up.

• Add bookmark: Adds the site you are currently browsing to your

list of bookmarks.

• View bookmarks: Displays a list of bookmarks.

• Save items: Saves pictures, sounds or video clips in the

appropriate Gallery folder.

•Go to URL: Inputs the URL of the site you wish to go to.

•History: Displays a history list.

•Forward: Moves to the recorded URL of cache. (You should

select “Previous” first, then you can use the function after recording the URL.)

• Reload page: Refreshes the contents of the WAP page.

• Advanced...:

• Show URL:

Displays the URL of the site you are currently browsing.

• Save page:

Saves the page you are currently browsing to your list of Snap Shots.

• Snapshots:

Displays a list of Snap Shots.

•Settings:

Includes “Downloads”, etc.

•Security:

Sets the security.

• Clear...:

Clears history, cache, etc.

FET Mobile Internet 59

• Restart Browser: Restarts the browser.

• About..: Displays the browser information

Visiting the FET Mobile Internet Web Site

You can access the FET Mobile Internet website by selecting from the FET Mobile Internet menu.

→

“FET Mobile Internet” → “Homepage”

The “FET Mobile Internet” top page is displayed. If you want to change the default homepage setting, see “WAP/MMS Settings” on page 111.

Visiting Your Preferred URL

→ “FET Mobile Internet” → “Go to URL”

1. Enter your preferred Web address.

Bookmarks

With this menu, you can register up to 50 entries and manage them (confirm, edit, copy, delete and add).

60 FET Mobile Internet

To Add a Bookmark

→

“FET Mobile Internet” → “Bookmarks”

1. Press [Options] to display the Options Menu. When

you add a bookmark for the first time, press [New Bookmark] then go to step 3.

2. Select “New Bookmark”.

3. Enter the bookmark title.

4. Enter the URL address.

To Edit Bookmarks

→

“FET Mobile Internet” → “Bookmarks”

1. Highlight the bookmark you wish to edit, then press

[Options].

2. Press [Details].

3. Press [Options] and select “Edit”.

4. Edit the bookmark title.

For details on entering characters, see “Entering Characters” on page 25.

5. Edit the URL address.

To Delete Bookmarks

→

“FET Mobile Internet” → “Bookmarks”

1. Highlight the bookmark you wish to delete, then

press [Options].

2. Select “Delete”.

Saving incoming call screen and ringtone downloaded from the browser

You can save incoming call screens and ringtones downloaded from the WAP browser to your Gallery.

1. Select the screen or ringtone you wish to save.

2. Press [Options].

3. Select “Save items”.

4. Press [Options].

5. Select “Save”.

FET Mobile Internet 61

Gallery

Gallery contains several types of picture, sound and video clip data. Also included in Gallery are frequently used text message phrases and accessed WAP pages (addresses) which you can use. You can also transmit picture, sound and video clip data via infrared or Bluetooth wireless technology to OBEX-enabled phones.

Note

• The phone can store approximately 2100 KB of data across Pictures, Java™, Sounds and Videos.

Picture Gallery

Pictures that are taken by a digital camera or images that are downloaded from mobile Internet sites can be managed.

You can register pictures in the following formats.

: PNG format :JPEG format : GIF format :BMP format :WBMP format : WPNG format

62 Gallery

(M 6)

(M 6-1)

Viewing Pictures

→

“Gallery” → “Picture Gallery” → “Saved

Pictures”

1. Select the file you wish to view.

The selected picture is displayed.

Using Images as Wallpaper

→

“Gallery” → “Picture Gallery” → “Saved

Pictures”

The list of pictures is displayed.

1. Highlight the file you wish to use as wallpaper.

2. Press [Options] and select “Set as Wallpaper”.

3. Press [OK].

Saving to Phonebook

You can use this option only for pictures saved in the handset memory.

→

“Gallery” → “Picture Gallery” → “Saved

Pictures”

1. Highlight the file you wish to add to Phonebook.

2. Press [Options] and select “Save to phonebook”.

To overwrite, select “Existing Entry” and select the data you wish to save to. If the picture size exceeds 240 dots in width or 320 dots in height, specify the area you wish to display. To save as a new entry, select “New Entry”. For details on entering a name, see “Add New” on page 35.

Editing Pictures

→

“Gallery” → “Picture Gallery” → “Saved

Pictures”

1. Highlight the file you wish to edit.

2. Press [Options] and select “Edit Picture”.

3. Select the desired option:

“Rotate”: The picture is rotated 90º

“Adjust Size”: Select the desired option. “Rename”: Rename the desired file. “Retouch”: Select the retouching option. “Add Frame”: Select the desired frame pattern. “Add Stamps”: Press [Stamps] and select the

anticlockwise. Press [Rotate] again for another 90º.

desired stamp pattern. Repeat this step to add more patterns.

Gallery 63

Note

• The size of pictures that you can retouch is 52 dots

52 dots [H] minimum.

[W]

• The size of pictures that you can add stamps to is 48

• Images exceeding 240 [W] or 320 [H] are saved as

• “Adjust Size” may not be available depending on the

Sending a Picture File

Pictures”

dots [W]

240 [W]

original picture and copyright issued.

48 dots [H] minimum.

320 [H] regardless of the original size.

→

“Gallery” → “Picture Gallery” → “Saved

1. Highlight the file you wish to send.

2. Press [Options] and select “Send”.

3. Select “As MMS”.

For details on creating a message, see “Creating a New MMS” on page 49.

Note

• Pictures protected with a copyright cannot be sent attached to a message.

• Pictures with a faint icon cannot be sent attached to a message.

64 Gallery

Tip

• For details on transmitting Gallery data, see “Sending Gallery Data to OBEX-enabled Phones” on page 68.

Downloading Picture Files

→

“Gallery” → “Picture Gallery” →

“Download More”

The picture file download site is displayed.

(M 6-1-3)

Java™ Gallery

Along with the preloaded Java™ application, downloaded Java™ applications are stored in Saved Java™.

Note

• Java™ applications can store up to 50 Java™ applications.

Using Applications

Various kinds of FarEasTone specific Java™ applications can be used in this phone.

To use Java™ applications, download the Java™ applications via FET Mobile Internet.

Some Java™ applications offer the ability to connect to a network either within a game or network based application.

Note

• Java™ applications may be both localised (no connectivity) and network based (using the mobile Internet to update information/play games). The network may charge you more for using networkbased applications. Please contact your service provider for more information. FarEasTone ensures the quality and the validity of games downloaded in FET Java™ portal only.

(M 6-2)

Downloading Applications

Confirmation Screen

Before downloading the Java™ application you are asked to confirm what you are about to receive.

After checking the information on the confirmation screen, the Java™ application can be downloaded.

Note

• User authentication may be required before downloading the application on some information screens.

Executing Saved Java™

→

“Gallery”→ “Java™ Gallery” → “Saved

Java™”

Downloaded Java™ applications are sequentially displayed from the latest one.

(M 6-2-1)

1. Select the title of the Java™ application you wish to

execute. The selected Java™ application is executed.

When using network connection type Java™ applications, connection to the network can be selected.

2. To end the Java™ application, press F and select

“End”.

Gallery 65

Download More

→

“Gallery” → “Java™ Gallery” → “Download

More”

(M 6-2-2)

1. Select the Java™ application you wish to download.

The confirmation screen is displayed after a few seconds.

2. Press [Get] to start downloading.

3. Press [OK] when finished.

Sound Gallery

The ringtones created using the Melody Editor and the AMR data recorded by Voice Recorder are managed in Saved Sounds. The default ringtones are not contained within Saved Sounds.

: SMAF format : Original ringtone (composed in Melody Editor) : Standard MIDI format : i Melody format :WAVE format :AMR format

66 Gallery

(M 6-3)

Tip

• SMAF (Synthetic music Mobile Application Format) is a format of music data for mobile phones.

Playing Back Sound Files

→

“Gallery” → “Sound Gallery” → “Saved

Sounds”

1. Select the sound file you wish to play back.

To stop playback, press .

Note

• This option may not be available in all regions.

• The volume varies depending on the Multimedia Volume settings (p. 93). The sound is deactivated when “Multimedia Volume” is set to “Silent”.

• To adjust the volume, press a (or d/the side-up key) or b (or c/the side-down key).

Using the Sound Files as Ringtone

“Gallery”

→

“Sound Gallery” → “Saved Sounds”

1. Highlight the sound file you wish to use as ringtone.

2. Press [Options] and select “Set as Ringtone”.

The selected sound is automatically used for the ringtone of the current Profiles.

Note

• Files in AMR or WAVE format cannot be used for the ringtone.

• The volume varies depending on the Multimedia Volume settings (p. 93). The volume is 0 when “Multimedia Volume” is set to “Silent”.

Sending Messages

→

“Gallery”

“Sound Gallery” → “Saved Sounds”

1. Highlight the name of the sound file you wish to

send.

2. Press [Options] and select “Send”.

If you select your original ringtone in step 1, perform the following, otherwise go to step 4.

3. Select “As MMS”.

4. Select the file format “SMAF”, “MIDI” or

“i Melody”. For details on creating a message, see “Creating a

New MMS” on page 49.

Note

• Sounds with a faint icon cannot be sent attached to a message.

• Sounds protected with a copyright cannot be sent attached to a message.

• Only the first part of the data is converted if you select “i Melody” in step 4.

Recording Sounds

→

“Gallery” → “Sound Gallery” → “Record

Sounds”

For details, see “Recording a Voice Clip” on page 83.

Melody Editor

→

“Gallery” → “Sound Gallery” → “Melody

Editor”

For details, see “Melody Editor” on page 84.

Downloading Sound Files

→

“Gallery” → “Sound Gallery” → “Download

More”

The sound file download site is displayed.

(M 6-3-2)

(M 6-3-3)

(M 6-3-4)

Gallery 67

Video Gallery

Video clips that are recorded by a video camera or video clips that are downloaded from mobile Internet sites can be managed.

Playing Back Video Clip Files

→

“Gallery” → “Video Gallery” → “Saved

Videos”

(M 6-4)

1. Select the video clip file you wish to play back.

2. Press .

To resume, press again. To stop playback, press [Back].

Note

• The volume varies depending on the Multimedia Volume settings (p. 93). The volume is 0 when “Multimedia Volume” is set to “Silent”. To adjust the volume, press a (or d/the side-up key) or b (or c/the side-down key).

Sending a Video Clip File with MMS

→

“Gallery” → “Video Gallery” → “Saved

Videos”

1. Highlight the file you wish to send.

2. Press [Options] and select “Send”.

68 Gallery

3. Select “As MMS”.

For details on creating a message, see “Creating a New MMS” on page 49.

Note

• Video clips protected with a copyright cannot be sent attached to a message.

• Video clips with a faint icon cannot be sent attached to a message.

Sending Gallery Data to OBEX-enabled Phones

OBEX stands for Object Exchange Protocol that enables wireless data transmission between devices with Bluetooth or Infrared.

1. Choose the appropriate menu.

→

“Gallery” → “Picture Gallery” → “Saved

Pictures”

→

“Gallery” → “Sound Gallery” → “Saved

Sounds”

→

“Gallery” → “Video Gallery” → “Saved

Videos”

2. Highlight the desired file.

3. Press [Options] and select “Send”.

4. Select “Via Bluetooth” or “Via Infrared”.

For “Via Bluetooth”

The phone starts searching for Bluetooth wireless technology enabled devices within 10 metres. When detected, a list of enabled devices is displayed allowing you to select the desired device. The connection can be established and the file sent.

For “Via Infrared”

The phone starts searching for an infrared-enabled device within 20 cm.

When detected, the infrared connection is established and the file is sent.

Note

• Pictures/Sounds/Video clips protected with a copyright cannot be sent.

• When pairing, you need to enter your passcode when establishing contact with a Bluetooth wireless technology enabled device for the first time except when “Authentication” (P. 109) is set to “Off”.

Receiving the Gallery Data

When the phone receives the Gallery data, the message “Save (file name) to Gallery?” appears in the stand-by mode screen.

1. Press [Yes].

2. Press [OK] to return to the stand-by mode screen.

The received data is registered in the corresponding Gallery folder.

Tip

• For details on Infrared or Bluetooth wireless settings, see “Connectivity” on page 106.

Recording Video Clips

→

“Gallery” → “Video Gallery” → “Record

Video”

For details, see “Recording Video Clips” on page 46.

Downloading Video Clip Files

→

“Gallery” → “Video Gallery” → “Download

More”

The video clip file download site is displayed.

Bookmarks

You can store desired (or frequently used) pages (addresses) in Bookmarks. It can save your time in accessing WAP pages sites. For further details, see “FET Mobile Internet” on page 58.

(M 6-5)

(M 6-4-2)

(M 6-4-3)

Gallery 69

Text Templates

You can register up to 20 text templates for use in text messages and multimedia messages.

120 characters may be registered in any text template.

Adding Phrases to Text Templates

→

“Gallery” → “Text Templates”

(M 6-6)

1. Select the number you wish to add.

2. Enter the text and press .

Editing Text Templates

→

“Gallery” → “Text Templates”

1. Highlight the number you wish to edit and press

2. Enter new text and press .

Viewing Text Templates

→

“Gallery” → “Text Templates”

The list of Text Templates is displayed.

1. Highlight the number you wish to view.

2. Press [Options] and select “View”.

70 Gallery

Deleting Text Templates

→

“Gallery” → “Text Templates”

1. Highlight the text template you wish to delete.

2. Press [Options] and select “Delete”.

My Chinese Beloved

You can store Chinese shortcut sentences in My Chinese Beloved and call the stored word by short operation when editing.

Your phone can store up to 204 entries. In My Chinese Beloved, you can store up to 30

characters for each entry. You can input Chinese characters, alphabets, symbols

& numbers for your entry.

Note

• To fully use this function, you need to include at least 4 Chinese characters for entry.

Creating a New Entry

→

“Gallery” → “My Chinese Beloved”

(M 6-7)

1. Press [Options].

2. Select “Add New”.

3. Enter new sentence.

4. Press [Options] and select “OK”.

Editing Entries

→

“Gallery” → “My Chinese Beloved”

1. Highlight the entry and press [Options].

2. Select [Edit].

3. Edit new sentence.

4. Press [Options] and select [OK].

Deleting Entries

→

“Gallery” → “My Chinese Beloved”

1. Highlight the entry and press [Options].

2. Select “Delete”.

3. Select from “One Entry” or “All Entries”.

4. Confirm by selecting [Yes] or [No].

Gallery 71

To Call the Entry

When Chinese character was entered after two characters, following entry word appears at once.

Please ref Spec for operation

The following is an example of calling My Chinese Beloved.

Please notice the word is already stored at this example.

1. Press L (3 times quickly),

then long press G and enter “”.

This example is using

BoPoMoFo mode

2. The character “ ” appears at

Normally “ ” appears here.

3. Long press O and enter

“”.

72 Gallery

4. Long press O, then the

following characters appear.

Note

• This function doesn’t appear, if the entry word was made by less than 4 letters or no Chinese characters included. Though, you can use this as a shortcut if the word was created by Chinese character, since candidate character appears at so you only have to press O without searching for following characters.

• If there were a stored word which shares the first 1-4 character such as “ ”, candidate “ ” appears at or . The latest entry comes to , and if there were three or more entry starts with “ ”, old candidate appears at in lower list, and so on.

• If there were a stored word which shares the first 5 or more characters, such as “ ”, after “ ” was entered, the latest character of entry completes.

Memory Status

This function helps you to check the memory status of Gallery. Memory status covers Java™ applications, pictures, sounds, and videos.

→

“Gallery” → “Memory Status”

(M 6-8)

Gallery 73

Java™

Java™ Gallery

The list of the Java™ Gallery is displayed. Downloaded Java™ applications are displayed in order

starting from the latest one.

Executing Java™ Applications

For details on executing applications, see “Executing Saved Java™” on page 65.

Setting Permission

When using Java™ applications that access the network, you may decide your security level. With this option, you can set the confirmation method when the Java™ application accesses the network.

To Select the Confirmation Method

“Java™”

(M 1)

(M 1-1)

→

“Java™ Gallery”

1. Highlight the desired Java™ application.

2. Press [Options] and select “Permission”.

3. Select “Network Access” to set the confirmation

method when the Java™ application accesses the network.

4. Select the desired confirmation method.

74 Java™

Always Connect:

Allows the Java™ application access without confirmation.

First Time: Informs you when the Java™ application

accesses the network for the first time. If allow is selected, no more confirmations are made until you delete the Java™ application.

Per Session: Informs you when the Java™ application

accesses the network for the first time. If allow is selected, no more confirmations are made until the Java™ application finishes operation.

Per Access: Informs you every time the Java™

application accesses the network regardless of whether you select allow or deny.

Never Connect:

Prevents the Java™ application from accessing the network and no confirmation is made.

To Reset Permissions

You can reset all permissions you made.

“Java™”

→

“Java™ Gallery”

1. Highlight the desired Java™ applications.

2. Press [Options].

3. Select “Permission”.

4. Select “Reset Permissions”.

5. Confirm by selecting [Yes] or [No].

Java™ Wallpaper

You can download Java™ Wallpaper applications for the stand-by screen.

“Java™” On/Off”

→

“Java™ Wallpaper” → “Switch

(M 1-2)

1. Select “On” or “Off”.

Note

• If you select “On” when an application has not yet been set, a screen is displayed that prompts you to select an application.

• In the list that appears after step 1, only the available Java™ Wallpaper can be selected.

Setting the Java™ Wallpaper

→

“Java™” Application”

The downloaded Java™ Wallpapers are displayed.

“Java™ Wallpaper” → “Set

(M 1-2-2)

1. Select the desired Java™ Wallpaper.

Resume Time

You can set the time period for the Java™ Wallpaper application to activate.

“Java™”

(M 1-2-3)

→

“Java™ Wallpaper” → “Resume Time”

1. Enter the resume time in two digits using the digit

key.

Download More

You can download Java™ applications.

“Java™”

The Java™ application download site is displayed.

→

“Download More”

(M 1-3)

1. Select the Java™ application you wish to download.

Details about the Java™ application will be displayed.

2. Select the Java™ application you wish to download.

Java™ 75

Settings

Calls & Alarms

You can set the priority of incoming calls and alarms whilst an application is operating.

“Java™”

(M 1-4)

(M 1-4-1)

→

“Settings” → “Calls & Alarms”

1. Select “Incoming Call” or “Alarm”.

2. Select methods.

• “Call Priority” or “Alarm Priority”: You can receive a call or ring the alarm while a Java™ application is running. The Java™ application is suspended automatically when receiving a call or when the alarm is ringing. After finishing the call or the alarm ends, the suspend icon ( ) is displayed on the stand-by screen, letting you know there is a suspended Java™ application.

• “Call Notice” or “Alarm Notice”: The marquee (character scrolls) is displayed on the first line of the screen whilst the Java™ application continues. If you press D, the Java™ application is suspended, and you can receive a call. After finishing the call, the suspend icon ( ) is displayed on the stand-by screen, letting you know there is a suspended Java™ application.

76 Java™

Sound Volume

You can set the volume of the application such as sound effect to one of the five levels or silent. When “Multimedia Volume” (p. 93) is set to “Silent”, this setup has priority.

“Java™”

The current volume level is displayed.

(M 1-4-2)

→

“Settings” → “Sound Volume”

1. Press a (or d) to increase the volume or press b

(or c) to decrease the volume and then press .

Backlight

“Java™” On/Off”

(M 1-4-3)

→

“Settings” → “Backlight” → “Switch

1. Select from “On”, “Off” or “Default Settings”.

• “On”: Lit whilst the Java™ application

• “Off”: Unlit whilst the Java™

• “Default Settings”: Works with the main backlight

is operated.

application is operated even if a key is pressed.

setting (p. 98).

To Set the Blinking Operation

This setting enables the backlight to be controlled by the Java™ application. If set to “Off”, the backlight cannot be turned on from the Java™ application.

→

“Java™”

“Settings” → “Backlight”→ “Blink”

1. Select “On” or “Off”.

Vibration

For Java™ applications which support the vibration function, you can choose whether to enable or disable this function.

When a SMAF file is specified in the Java™ application, you can synchronise the vibrator with the sound.

Note

• SMAF (Synthetic music Mobile Application Format)

“Java™”

(M 1-4-4)

is a music data format for mobile phones.

→

“Settings” → “Vibration”

1. Select from “Enable”, “Disable” or “Link to

Sound”. When you set “Link to Sound”, the sound of SMAF

file in the application is synchronised with the vibrator.

Java™ Reset

To Reset All Items in Settings Menu

“Java™”

(M 1-4-5)

→

“Settings” → “Java™ Reset”

1. Enter your handset code.

The default handset code is “0000”. For details on changing the handset code, see “To Change Handset Code” on page 113.

Java™ Information

The information about the licenses belonging to Java™ is displayed.

(M 1-5)

Java™ 77

Organiser

SIM Application

You can refer to the information on the SIM. Contact your service provider for further details.

Calendar

Calendar allows you to easily schedule appointments or events, which are associated with the date and time. These entries can also be sent via infrared or Bluetooth wireless technology to a PC to share the same schedules.

Creating a New Entry

“Organiser”

1. Highlight the desired day to which you want to add

an event.

2. Press [Options] and select “Add New Entry”.

3. Enter the subject and location.

78 Organiser

(M 3)

(M 3-2)

→

“Calendar”

(M 3-1)

To Set an Appointment

1. Select the category.

2. Enter the start date and start time.

3. Select the duration of the alarm.

4. Select the time to sound the remind.

Note

• When “Other” is selected in step 3, the end date can be entered.

To Set an All Day Event

1. Enter the start date.

To Set an Anniversary by date

1. Enter the date.

To Set an Anniversary by day.

1. Enter the day, week and month.

Sending a Schedule Entry

“Organiser”

→

“Calendar”

1. Select the day including schedule entries you wish

to send.

2. Press [Options] and select “Send”.

3. Select “Via Bluetooth” or “Via Infrared”.

The phone starts searching for Bluetooth wireless technology enabled devices within 10 metres, or an infrared-enabled device within 20 cm. When an infrared-enabled device is detected, the infrared connection is established and the entry is sent. When Bluetooth wireless technology enabled devices are detected, a list of enabled devices is displayed.

4. Select the desired Bluetooth wireless technology

enabled device. The connection is established and the entry is sent.

Tip

• For details on Infrared or Bluetooth wireless settings, see “Connectivity” on page 106.

Viewing an Entry

→

“Organiser”

“Calendar”

1. Select the day you wish to view.

The day view is displayed.

To Search By Date

1. In the monthly or daily view, press [Options].

2. Select “Go to”.

3. Select “Today” to display today or “Enter date” to

enter the desired date.

To Search By Subject

1. In the monthly or daily view, press [Options].

2. Select “Find”.

3. Enter the desired text.

To Change the Week Format

1. In the monthly view, press [Options].

2. Select “Week Format”.

3. Select “Monday-Sunday” or “Sunday-Saturday”.

Organiser 79

Deleting Entries

1. In the monthly or daily view, press [Options].

2. Select “Delete”.

3. Select the desired option.

• “All this Day”: Deletes all entries for the selected day.

• “All this Month”: Deletes all entries for the selected month.

• “All till Last Month”: Deletes all entries till last month.

• “All Entries”: Deletes all entries in this application.

80 Organiser

Alarms

Setting the Alarms

The alarm function allows you to be alerted at a specified time. Note that the alarm may not function correctly if the clock has not been set.

Note

• The alarm functions even if the phone is switched off.

• The alarm will not ring when “Ringer Volume”

“Organiser”

(M 3-3)

(p. 90) is set to “Silent”.

→

“Alarms”

1. Select the blank setting.

2. Enter the desired time.

To Change the Type of Alarm Tone

3. Select “Set Alarm Tone”.

4. Select “Tone”.

5. Select “Preset Melodies” or “Sound Gallery”.

6. Select the desired tone. For details on selecting a

ringtone, see “Assigning Melody” on page 90.

To Change the Vibration of Alarm Tone

7. Select “Vibration” in step 3.

8. Select “Enable”, “Disable” or “Link to Sound”.

For details on selecting a vibration, see “Vibration” on page 90.

To Change the Duration of Alarm Tone

9. Select “Duration”.

10. Enter the desired time (02-59).

11. Press [Back].

To Set the Repeating Option

12. Repeat steps 1 and 2, then select “Repeat Daily”.

13. Select “On” or “Off”.

14. Press [Save].

Editing the Alarm Setting

“Organiser”

→

“Alarms”

1. Select the desired setting to edit.

Resetting an Alarm Setting

“Organiser”

→

“Alarms”

1. Select the desired alarm you wish to reset.

2. Select “Reset Alarm”.

Resetting All Alarm Settings

“Organiser”

→

“Alarms”

1. Select “Clear All”.

Organiser 81

Calculator

The calculator function performs the 4 arithmetic calculations using up to 12 digits.

“Organiser”

The calculator is displayed on the display. Key operations for calculation are as follows.

To enter a decimal point, press R. To clear the entered number or operand, press [Clear]. To do the calculations, press . To start a new calculation, press [Clear].

82 Organiser

(M 3-4)

→

“Calculator”

Exchange Rate

You can also use the calculator as a currency calculator to convert from/to a home currency using a conversion rate that you enter.

To Set a Currency Conversion Rate

→

“Organiser”

“Calculator”

1. Press [Options] and select “Exchange Rate”.

2. Select “Foreign → Domestic” or “Domestic →

Foreign”.

3. Enter the currency conversion rate.

To delete all digits, press [Clear].

To Convert a Value

→

“Organiser”

“Calculator”

1. Enter the value to be converted.

2. Press [Options] and select “In Domestic” or “In

Foreign”. The result is displayed.

If you select “Exchange Rate” in step 2, you can set a currency conversion rate.

Note

• You cannot perform step 2 when an arithmetic symbol (

+, −, ×

or ÷ ) is displayed.

Voice Recorder

This allows you to record a voice clip of up to 60 seconds, which can be used to remind you of schedule entries or be sent within a multimedia message. The recorded voice clip is stored in Sound Gallery. Voice clips are saved in “.amr” format.

Recording a Voice Clip

“Organiser”

→

(M 3-5)

“Voice Recorder”

1. Press to start recording.

To stop recording before the recording time is over, press .

2. Select “Save” to save the voice clip.

To play back the recorded voice clip, select “Playback”. To record a voice clip again, press [Cancel].

Note

• To change recorded size before recording, press [Options] and select “Record Size”. Then select “Extended Voice” or “For MMS”.

• When the Message Size described on page 53 is set to “100 KB”, “Record Size” is not displayed.

Tip

• You can also activate Voice Recorder by pressing

, then R during stand-by.

Sending Voice Clips

→

“Organiser”

“Voice Recorder”

1. Press to start recording.

2. Press to stop recording.

3. Select “Save and Send”.

For details on creating a message, see “Creating a New MMS” on page 49.

Note

• “Save and Send” is not displayed after recording in extended voice mode.

Organiser 83

Melody Editor

You can create an original ringtone, or you can send a melody attached to a MMS message.

You can input up to 95 tones × 32 voices, 190 tones × 16 voices, or 380 tones × 8 voices per melody.

The original ringtone is stored in Sound Gallery.

Creating Your Original Ringtone

“Organiser”

(M 3-6)

(M 3-6-1)

→

“Melody Editor” → “Create New”

1. Enter the title.

Up to 24 characters can be entered.

2. Select a tempo.

The music tempo is described below.

• “Allegro (Fast)”: 150

• “Moderato (Normal)”: 125

• “Andante (Slow)”: 107

• “Adagio (Very Slow)”: 94

3. Select from “8 Chords”, “16 Chords” or “32

Chords”.

4. Press the digit keys to specify the musical scale and

rest. For details on specifying the sound level and rest,

see “To Specify the Musical Scale and Rest” on page 85.

84 Organiser

5. Press P or R to specify the types of musical

notes or rest. For details on specifying the musical notes and rest,

see “To Specify the Types of Notes and Rests” on page 86.

6. Press d after inputting one note.

Input the next note after the cursor moves to the right.

7. Repeat steps 5 and 6 to input notes.

When entering notes, you can do the following:

• Press to play back all input notes.

• Press [Options] and select: “Play before cursor” to play back notes up to the

cursor position. “Select Part” to select another chord. “Set Tone” to set or change the tone using different instruments (p. 86). “Set Strength” sets the strength of the original ringtone (p. 87).

• To specify the types of notes or rests, see page 86.

8. When you finish inputting, press [Options] and

select “Save”.

9. Select “Save to Gallery”.

Note

• The volume varies depending on the Ringer Volume settings (p. 90). The sound is deactivated when “Ringer Volume” is set to “Silent”.

• If the capacity or memory in Saved Sounds becomes insufficient, the message, “Maximum capacity : 250 Not registered.” or “Not registered. Memory full.” is displayed. The screen returns to step 9. Try again after deleting unnecessary data.

• Melodies consisting of too many short notes (semiquavers and triplets) cannot be played back in step 7 and the following message is displayed: “Can not play due to too many notes per sec.” The screen returns to step 5. The message “Can not save due to too many notes per sec.” may also be displayed, and the screen returns to step 5. Reduce the number of melodies, replace short notes, cancel triplets, etc. to remedy.

To Specify the Musical Scale and Rest

Using the keys shown below, specify the musical scale and rest.

Do Re Mi Fa Sol La Ti Rest

GHIJKLMQ

When you press the key shown above once, a crotchet is specified in the middle scale (no mark).

When you press the same key repeatedly, the note will shift cycle through the available octave ranges.

LLL

When you press a or b whilst a note is selected, the note will move one semitone higher or lower.

When entering rest, crotchet rest is entered.

Organiser 85

To Specify the Types of Notes and Rests

Press P or R repeatedly.

( )

When you make a dotted note or a triplet, press O after selecting the target note.

Note

• You cannot make a dotted semiquaver (semiquaver rest) or a dotted semibreve (semibreve rest).

• Three continuous notes are required for a triplet.

86 Organiser

To specify a tie, press N after selecting the target notes.

An underscore ( _ ) is displayed next to the note, and the note is tied with the next one.

To enter the next note, press d to move the cursor to the right. Then, repeat the operation on the previous pages.

If the cursor is positioned next to a note, you can repeat the note immediately left of the cursor when a or b is pressed.

To Set the Tone

The phone can play notes using different instruments. You can select from 128 basic tones (8 types of: Pianos,

Chimes, Organs, Guitars, Basses, Strings 1, Strings 2, Brasses, Reeds, Flutes/Pipes, Synth Leads, Synth Pads, Synth Effects, Ethnics, Percussions, Effects) and 61 extended tones (40 types of Drums (FM) and 21 types of Drums (WT)).

1. Press [Options] and select “Set Tone” in step 7 on

page 84.

2. Press c or d to highlight a category of the tone.

3. Press a or b to highlight a tone.

4. Press .

Now you can create an original ringtone.

Tip

• You can play back the melody in the selected tone by

pressing [Options] and selecting “Play Current Part” in step 4, or play back the syllable names in the selected tone by selecting “Confirm Tones” instead.

To Set the Strength of the Tone

The strength of the tone can be set in 3 levels for each part.

When you purchase this phone, the strength of the original ringtone is set to “Loud”.

1. Press [Options] and select “Set Strength” in step 8

on page 85.

2. Select a strength of the tone.

3. Press .

Now you can create an original ringtone.

Editing Original Ringtones

“Organiser” Melodies”

→

“Melody Editor” → “Existing

(M 3-6-2)

1. Highlight an original ringtone you wish to edit.

2. Press [Options] and select “Edit Data”.

3. Edit the title.

4. Select a tempo and number of chords.

5. Edit the data.

6. When you finish editing, press [Options] and select

“Save”.

7. Select “Save to Gallery”.

8. Select “Overwrite” or “New”.

Note

• When the number of chords is modified in step 4, the confirmation message may be displayed. When you press [Yes], a section of the melody may be deleted.

Tip

• You can delete the melody after or before the cursor by pressing [Options] and selecting “Delete after cursor” or “Delete before cursor”.

Organiser 87

Copying and Pasting Notes

You can copy and move a part of the melody to another position.

Only original ringtones or editable melodies can be copied or moved.

1. In the Score input screen, press [Options] and select

“Copy” or “Cut”.

2. Move the cursor to the first note to be copied or to

be cut, then press .

3. Move the cursor to the last note to highlight the

area, then press .

4. Press [Options] and select “Paste”.

5. Move the cursor to the point you wish to paste the

notes and press .

Help List

You can view the help list and use it to guide you in the phone’s functions.

“Organiser”

(M 3-7)

→

“Help List”

1. Press a or b to view the desired function.

88 Organiser

Profiles

Tone sound and vibration set can be customised for each profile according to your environment.

There are 6 profiles including one user definable profile: Normal, Meeting, Activity, Car, Headset and Silent.

Activating a Profile

“Profiles”

(M 7)

(M 7-1)

1. Select the desired profile.

Note

• When a profile is set, the corresponding icon described on page 16 is displayed on the stand-by screen.

Normal: This is the default setup (not

Meeting: For use when discretion needed. Activity: For use in busy environments. Car: For use in the car (connected to a

Headset: For use with a headset (connected

displayed in the stand-by screen).

handsfree car kit).

via Bluetooth).

Silent: For use when silence is needed. All

sounds are muted and you are alerted to calls with the vibrator.

Tip

• Long press R to switch Profiles settings between

Normal and Silent mode during stand-by.

Customising Profiles

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select the setting you wish to customise and change

as desired. For details about settings, see pages 90 to 94.

4. Press [Save] when finished.

Resetting Profile Settings

“Profiles”

1. Highlight the profile you wish to reset.

2. Press [Options] and select “Set to Default”.

3. Enter your handset code.

The default handset code is “0000”. For details on changing the handset code, see “To Change Handset Code” on page 113.

Profiles 89

4. Press [OK], and select [Yes].

Ringer Volume

You can adjust the ringer volume to one of 5 levels or a step tone, and silent.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Ringer Volume”.

The current volume level is displayed.

4. Press a to increase the ringer volume or press b

to decrease the ringer volume and then press . You can select “Step Tone”, press a at level 5.

You can select “Silent”, press b at level 1.

Assigning Melody

You can select the ringtone from 28 tones including 5 patterns, 13 sound effects and 10 melodies. You can also select a sound in Sound Gallery as the default ringtone excluding the AMR or WAVE format.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Assign Melody”.

4. Select “Preset Melodies” or “Sound Gallery”.

90 Profiles

5. Select the ringtone you wish to use.

To hear the demo play, press . To stop playing, press again.

6. Press [Options] and select “Assign”.

Note

• If you delete a ringtone that uses a sound in Sound Gallery, the default ringtone is set.

Vibration

When the vibrator option is set on, the phone will vibrate for incoming calls regardless of the ringer volume and tone settings.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Vibration”.

4. Select from “Enable”, “Link to Sound” or

“Disable”.

Tip

• When the “Link to Sound” option is selected in step 4, the vibrator synchronises with your selected melody to pulse in time with the melody. Please note that not all melodies support the “Link to Sound” option. Should you select such a melody, only the “Enable” option in step 4 will allow vibrator function.

• When you select “Enabl e” or “Link to Sound” in step 4, “ ” is displayed on the stand-by screen.

Light

When the light option is on, the mobile light turns on whilst the phone receives a call.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Light”.

4. Select from “On”, “Off” or “On & Link to Sound”.

Alerts

You can personalise profiles for alerts including warning tone, message alert and low battery alert.

Warning Tone

This function enables your phone to emit the warning tone when an error occurs.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Alerts”.

4. Select “Warning Tone”.

5. Select “Switch On/Off”.

6. Select “On”. Select “Off” to cancel.

7. Select “Volume”.

8. Adjust the volume by pressing a or b.

9. Select “Tone”.

10. Select “Preset Melodies” or “Sound Gallery”.

11. Select the warning tone.

For details on selecting a ringtone, see “Assigning Melody” on page 90.

12. Select “Duration” and select desired duration.

Profiles 91

Message Alert

When receiving messages, special ringtones can be set.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Alerts”.

4. Select “Message Alert”.

5. Select from “MMS”, “SMS” or “WAP”.

6. Select “Volume”.

7. Adjust the volume by pressing a or b.

8. Select “Sound”.

9. Select “Preset Melodies” or “Sound Gallery”.

10. Select the ringtone.

For details on selecting a ringtone, see “Assigning Melody” on page 90.

11. Select “Vibration”.

12. Select from “Enable”, “Link to Sound” or

“Disable”.

13. Select “Light”.

14. Select from “On”, “Off” or “On & Link to Sound”.

15. Select “Duration”.

16. Enter the duration of ringtone in 2 digits.

92 Profiles

Low Battery Alert

Adjust the volume of the alarm when the battery becomes low.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Alerts”.

4. Select “Low Battery Alert”.

5. Select from “High”, “Low” or “Silent”.

Keypad Tones

When the keypad tone is set on, you will hear a confirmation tone each time you press any keys.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Keypad Tones”.

4. Select “Switch On/Off” and select “On”.

Select “Off” to cancel.

5. Select “Volume” and select from “High”, “Middle”

or “Low”.

6. Select “Tone” and select from “Preset Melodies”,

“Sound Gallery” or “Default Tone”. When selecting “Default Tone”, go to step 8.

7. Select the desired tone.

For details on assigning the tone, see “Assigning Melody” on page 90.

8. Select “Duration” and select the desired time.

Multimedia Volume

You can adjust volume for Video Camera, Voice Recorder, Melody Editor, Gallery, browser and MMS messages.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Multimedia Volume”.

4. Select the desired volume level.

Power On/Off Sound

The phone can be set up to emit a sound when it is switched on or off. You can define the volume, duration and the melody to be used for this task.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Power On Sound” or “Power Off Sound”.

4. Select “Switch On/Off”.

5. Select “On”. Select “Off” to cancel.

6. Select “Volume”.

7. Adjust the volume by pressing a or b.

8. Select “Sound”.

9. Select “Preset Melodies” or “Sound Gallery”.

10. Select the ringtone.

For details on selecting a ringtone, see“Assigning Melody” on page 90.

11. Select “Duration”.

12. Enter the desired duration of the ringtone in 2 digits

(01 to 10 seconds).

Profiles 93

Echo Cancel

This function is for cancelling irritating echoes, especially when using the handsfree car kit.

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Echo Cancel”.

4. Select “On” or “Off”.

Any Key Answer

You can also answer a call by pressing any key except F or [Busy]. For details, see page 20.

“Profiles”

1. Select the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Any Key Answer”.

Select “On” or “Off”.

Auto Answer

The Auto Answer function allows you to answer calls automatically by connecting wired headset device or by connecting the handsfree device for Bluetooth to your phone.

You can select the desired time until your phone answers.

94 Profiles

“Profiles”

1. Press [Options] and select “Personalise”.

2. Select “Auto answer”.

3. Select the desired time.

Select “Off” to disable it.

Call Manager

Call Log

The phone will record the last 10 missed calls, received calls and dialled numbers.

Viewing Call Log

“Call Manager”

(M 8-3)

(M 8)

→

“Call Log”

1. Select from “All Calls”, “Dialled Nos.”, “Missed

Calls” or “Received Calls”. The selected call log list is displayed.

2. Select the phone number you wish to view.

If you wish to dial the number, press D. Call log “1” is the most recent. When you press b, call log “2” is displayed.

Tip

• You can also confirm call logs by pressing D during stand-by mode.

Sending Messages

1. In call log list, highlight the call log you wish to

send a message to. The selected call log is displayed in detail.

2. Press [Options] and select “Send Message”.

3. Select “MMS” or “SMS”.

For details on creating a message, see “Creating a New MMS” on page 49 or “Creating and Sending a New SMS” on page 54.

Saving the Number

→

“Call Manager”

“Call Log”

1. Select from “All Calls”, “Dialled Nos.”, “Missed

Calls” or “Received Calls”. The selected call log list is displayed.

2. Highlight the call log you wish to save.

3. Press [Options] and select “Save Number”.

4. Select from “New Recipient” for the new entry, or

“Existing Recipient” for adding to the existing entry of the Phonebook.

Deleting a Call Log

1. In call log list, press [Options] and select “Delete”.

Call Manager 95

Speed Dial List

You can view and perform other operations for phone numbers registered in the Speed Dial List.

“Call Manager”

The names and phone numbers stored in the Speed Dial List are displayed in order.

My Numbers

You can check your own voice, data and fax phone numbers.

“Call Manager”

(M 8-4)

→

“Speed Dial List”

(M 8-5)

→

“My Numbers”

1. Select the phone number you wish to check from

“Voice”, “Data” or “Fax”.

Note

• “Data” or “Fax” may not be displayed depending on the SIM card.

96 Call Manager

Call Timers

This function lets you check the duration of your calls.

Checking the Duration of the Last Call and All Calls

“Call Manager”

(M 8-6)

→

“Call Timers”

1. Select “Received Calls” or “Dialled Nos.”.

The duration of the last call and all calls are displayed.

Data Counter

You can confirm the amount of bytes that you used in the GPRS transmission.

“Call Manager”

(M 8-7)

→

“Data Counter”

1. Select from “Last Data” or “All Data”.

Resetting All Data Counter

“Call Manager” Counter”

→

“Data Counter” → “Clear

1. Confirm by selecting [Yes] or [No].

Settings

Display

You can change the settings of the screen.

Wallpaper

For the stand-by screen, 3 pictures are provided. Pictures taken with the digital camera or images

downloaded from a WAP site can be used for wallpapers.

Setting from Picture Gallery

“Settings” “Wallpaper”

(M 9)

(M 9-1)

→

“Display” → “Main Display” →

→

“Picture Gallery”

1. Select the desired picture.

2. After displaying the picture, press .

3. Press [OK].

Note

• Some pictures cannot be used because of their

picture and data types.

To Display Monthly Calendar

You can display the monthly calendar during stand-by. By default, a two-month calendar is displayed.

→

“Settings” “Standby Calendar”

“Display” → “Main Display” →

1. Select “One Month” or “Two Months”.

Select “Off” to turn it off.

Assign Pictures

Pictures can be displayed when turning the power on or off, when receiving an incoming call, or when operating the alarm.

Pictures taken by a digital camera or images downloaded from a WAP site can be used.

To Set Built-in Pictures

“Settings” “Assign Pictures”

→

“Display” → “Main Display” →

1. Select the desired situation to set the picture.

2. Select “Default” when you select “Power On” or

“Power Off” in step 1. Select “Pattern 1”, “Pattern 2” or “Pattern 3” when

you select “Incoming” or “Alarm” in step 1.

Settings 97

To Set Saved Pictures

“Settings” “Assign Pictures”

→

“Display” → “Main Display” →

1. Select the desired situation to set the picture.

2. Select “Picture Gallery”.

3. Select the desired picture.

4. After displaying the picture, press .

5. Specify the area you wish to display using the

navigation keys.

Note

• Some pictures cannot be used because of their picture and data types.

Setting the Greeting Message

You can set the message which will appear when the phone is turned on.

→

“Settings” “Greeting Message”

“Display” → “Main Display” →

1. Select “Switch On/Off”.

2. Select “On” or “Off”.

3. Select “Edit Message” and enter the message.

Up to 16 characters can be stored as a message. For details on entering characters, see “Entering Characters” on page 25.

98 Settings

Show Clock

You can display the current date and/or time on the stand-by screen.

→

“Settings” Clock”

“Display” → “Main Display” → “Show

1. Select from “Time Only”, “Date & Time” or “Off”.

Backlight

You can turn the backlight of the screen on or off when you press the keypad or the optional cigarette lighter charger is connected to the phone.

You can change time the backlight is on for, which will help conserve battery life.

To Select the Backlight Time Out

→

“Settings” “Backlight”

“Display” → “Main Display” →

→

“Time Out”

1. Select the desired time.

Select “Off” to turn it off.

To Turn On/Off the Backlight whilst Charging with the Cigarette Lighter Charger

With this setting On, the phone’s backlight is on when the cigarette lighter charger is connected.

→

“Settings” “Backlight”

“Display” → “Main Display” →

→

“In Car”

1. Select “On” or “Off”.

Brightness of the Backlight

You can adjust the brightness of the backlight of the screen from 4 levels.

→

“Settings” “Backlight”

“Display” → “Main Display” →

→

“Brightness”

1. Adjust the brightness by pressing a (Light) and b

(Dark) for maximum clarity.

2. Press .

To Set the Display Saving

This phone’s screen will automatically turn off. You can change the time before the Display Saving will

go into effect, which will help conserve battery life.

Tip

• When you purchase this phone, Display Saving is set

to 10 minutes.

→

“Settings” “Display Saving”

“Display” → “Main Display” →

1. Select the desired time.

Note

• Display Saving does not work whilst you are calling, using WAP, or using an application.

• To cancel the Display Saving: The display saving continues until either a key is pressed or there is an incoming alert. The first key press only cancels this function. You must press another key in order to input any numerical or text value.

Settings 99

Sharp GX-T25 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Useful Functions and Services

Table of Contents

Your Phone

Optional Accessories

Getting Started

Inserting the SIM Card and the Battery

Charging the Battery

Turning Your Phone On and Off

Main Display Indicators

External Display Indicators

Navigating Functions

Call Functions

Making a Call

Speed Dialling

Redialling

Answering a Call

Incall Menu

Entering Characters

Changing the Input Languages

Changing the Input Method

Using Text Templates

Using the Menu

List of Menu Functions

Phonebook

Selecting the Storage Memory

Changing the List Displayed

Add New

Copying Phonebook Entries between SIM Card and Handset

Finding a Name and Number

Dialling from the Phonebook

Editing Phonebook Entries

Deleting Phonebook Entries

Viewing Groups

Memory Status

Speed Dial List

Sending a Phonebook Entry

Receiving a Phonebook Entry

Camera

Digital Camera

Video Camera

Messages

Alert Inbox

Voicemail

Cell Broadcasts

Area Info

FET Mobile Internet

Starting the WAP Browser

Navigating a WAP Page

Visiting the FET Mobile Internet Web Site

Visiting Your Preferred URL

Gallery

Picture Gallery

Java™ Gallery

Sound Gallery

Video Gallery

Bookmarks

Text Templates

My Chinese Beloved

Memory Status

Java™

Java™ Gallery

Java™ Wallpaper

Download More

Settings

Java™ Information

Organiser

SIM Application

Calendar

Alarms

Calculator

Voice Recorder

Melody Editor

Help List

Profiles

Profiles
