1 Introduction

Introduction

Congratulations and thank you for choosing the GX12.

About This User Guide

This user guide is carefully designed to help you learn about your phone’s features and operations quickly and effectively.

NOTICE

• We strongly recommend that you keep separate permanent written records of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, we assume no responsibility for data lost or otherwise rendered unusable, whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired or any other cause.

• We assume no responsibility, directly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss or alteration of stored data, etc.

• All company and/or product names are trademarks and/or registered trademarks of their respective holders.

• Screen layout illustrated in this user guide may differ from the actual one. The information described in this user guide is subject to change without notice.

• All the functions described in this user guide may not be supported in all networks.

• We assume no responsibility for downloaded contents, information, etc. from network.

According to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from the copyright owner to reproduce, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.

Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Powered by JBlend®, ©1997-2002 Aplix Corporation. All rights reserved. Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and ot her countries. JBlend and all JBlend-based trademar ks and logos are trademarks or registere d trademarks of Aplix Corporation in Japan and other countries.

In this product, JBlend

is a Java execution environment

JBlend that Aplix developed for implementing advanced performance and fast operat ion on small-memory systems. JBlend and JBlend logo are trademar ks or registered trademarks of Aplix Cor poration in Japan and other countries.

Licensed by Inter Dig ital Technology Corporation under o ne or more of the following United States Patents and/or their domestic or foreign cou nterparts and other patents pending, including U.S . Patents: 4,675,863: 4,779 ,262: 4,785,450 & 4,811,420.

is incorporated.

/Micro3D Editio n™

is a registered trademar k of HI

Introduction 2

Licensed under U.S. Patent 4,558,3 02 and foreign counterparts.

T9 Text Input is covered by the Hong Kong Standard Patent No. HK0940329 and HK1010924.

T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,43 7, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. N o. 727539; Canadian Pat. No. 1,331,057; Unite d Kingdom Pat. No. 2238 414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pa t. Nos. KR201211B1 and KR226206B1; and ad ditional patents are pending worldwide.

3 Introduction

Useful functions and services of the phone

Your phone offers you the following features:

• The built-in digital camera can take pictures.

• Create and read SMS.

• Multimedia Messaging Service (MMS) can personalise your phone in various ways: you can send and receive multimedia messages with graphical images, photographs or sound attached.

• WAP browser helps you to access a variety of information on the mobile Internet.

• You can play with Java™ applications. You can also download various kinds of Java™ applications from SmarTone via the mobile Internet.

• The main display of colour TFT-LCD makes the screens clearer, more beautiful and easier to view.

• Sub-Screen allowing you to see who is calling and new message indicators.

• You can create the various melodies for your original ringing tones using up to 16 chords.

• Voice memo function allows you to record and play back your vocal message.

Introduction .................................................. 1

Useful functions and services of the phone ..3

Table of Contents......................................... 4

Your Phone ................................................... 7

Accessory .....................................................7

Getting Started ............................................. 8

Inserting the SIM Card and the Battery ......10

Charging the Battery ...................................13

Turning Your Phone On and Off ................15

Display Indicators .......................................15

Sub-Screen .................................................. 17

Call Functions ............................................ 19

Making a Call ............................... ............... 19

Speed Dialling.............................................19

Redialling ....................................................20

Ending a Call ................................ ............... 20

Answering a Call.........................................20

Incall Menus ................................................ 21

Entering Characters................................... 24

Phonebook.................................................. 30

Creating a New E ntry..................................30

Finding a Name and Number ..................... 32

Editing Phonebook Entries......................... 33

Deleting Phonebook Entries ....................... 33

Checking Your Own Numbers ................... 33

View Groups .............................................. 34

Memory Status ........................................... 34

Speed Dial List .......................... ................. 34

Sending Messages ...................................... 35

Using the Menu........................................... 36

List of Menu Functions .............................. 37

Camera ........................................................38

Using the Timer .......................................... 40

Sending Pictures ......................................... 41

Deleting Pictures ........................................ 41

My Phone.....................................................42

Java™ ......................................................... 42

Java™ Gallery ............................................ 42

Image Gallery ............................................. 44

Sound Gallery ............. ................................ 46

Text Templates ........................................... 49

Memory Status ........................................... 50

Table of Contents 4

Fun & Games .............................................. 51

Java™..........................................................51

Games.......................................................... 54

Melody Editor .............................................55

Tone Editor .................................................62

Profiles ........................................................ 66

Activating a Profile .....................................66

Customising Profiles ...................................66

Resetting Profile Settings............................67

Ringer Volume ............................................ 67

Ringer Type.................................................67

Vibration .....................................................68

Keypad Tones ......... ....................................68

Warning Tone .............................................69

Power On/Off Sound ...................................69

Message Alert .............................................70

Low Battery Aler t ....................................... 71

Any Key Answer .........................................71

Organiser ....................................................72

Calculator ............................ ........................72

Calendar ......................................................73

Clock & Alarm ............................................74

Voice Memo ................................................ 78

5 Table of Contents

Help List ................................................. .... 79

Call Manager ...............................................80

Call Log ...................................................... 80

Call Timers ................................................. 81

Call Costs ................................................... 82

Data Counter............................................... 84

Diverts ........................................................ 85

Settings .......................................................87

Phone Settings ............................................ 87

Call Settings ............................................... 92

Network Settings ........................................ 96

Internet Settings.......................................... 97

Infrared ..................................................... 101

Security..................................................... 102

Master Reset ............................................. 106

Browser .....................................................107

Viewing the WAP Browser ...................... 107

Navigating a WAP Page........................... 107

Messages ..................................................110

MMS (Multimedia Messaging Service) ... 110

SMS (Short Message Service).................. 117

Cell Broadcast .......................................... 121

Cell Information .................................. ..... 122

Voicemail ..................................................122

Data Transmission ................................... 123

System Requirements................................ 123

Software Installation and Setup ................123

Using the Mode m Setup............................123

Troubleshooting....................................... 125

Safety Precautions and

Conditions of Use .................................... 127

CONDITIONS OF USE............................ 127

ENVIRONMENT .....................................129

PRECAUTIONS CONCERN ING

VEHICLE USE .........................................130

Out of warranty list .................................. 131

Index.......................................................... 132

Quick Reference ...................................... 138

Table of Contents 6

Your Phone

Please check the following carefully. Your phone should come complete with:

• GSM 900/1800 GPRS phone

• Rechargeable Li-ion battery

• AC charger

• Hands free

•CD-ROM

• User guide

Accessory

• Li-ion spare battery (XN-1BT11)

Some of the above accessory may not be offered by region.

For details, please contact your dealer.

7 Your Phone

(option)

Getting Started

Getting Started 8

1. Earpiece

2. Navigation Keys (Arrow Keys):

Up/Down arrow keys:

Left arrow key: Adjusts the earpiece

Right arrow key: Displays the Phonebook

3. M Key: Displays the Main Menu

4. Left Soft Key: Executes the function at

5. Send Key: Makes or accepts calls,

6. Voice Mail Key: Used to connect to Voice

7. #, * /Shift Key: Used to enter * and # or

8. Main-Screen Display

9 Getting Started

Move the cursor to select menu items, adjust the earpiece volume, etc.

Search the Phonebook entries in stand-by mode.

volume in stand-by mode.

menu in stand-by mode.

and executes the functions.

the bottom left on the screen.

views the call history in stand-by mode.

mail centre. (Depends on the SIM card.)

switch the text mode.

9. Hands free Connector

10. Right Soft Key: Executes the function at

11. End/Power Key: Ends a call, turns power

12. Keypad

13. 0/Space Key: Enter 0 or a space.

14. Microphone

15.

External Connector

16. Aerial

17. Sub-Screen Display

18. Camera

19. Mirror: For self portraits.

20. LED Indicator

21. Infrared Port: Sends and receives data

22. Speaker

23. Side Keys

Up/Down keys: Move the cursor to select

24. Battery Cover

the bottom right on the screen.

on/off.

: Used to connect either

the charger or data cable.

via infrared.

menu items, etc.

Inserting the SIM Card and the Battery

1. Slide off the battery cover.

2. Slide the SIM card into the SIM holder.

SIM card

Getting Started 10

3. Hold the battery so that the metal contacts of the

battery are facing down, slide the guides on the top of the battery into the battery slots , and then insert it .

11 Getting Started

4. Replace the battery cover so that the marks are

aligned and slide it as shown.

Note

• Make sure that only 3V SIM cards are used.

• Use only the approved battery (XN-1BT11).

Removing the SIM Card and the Battery

1. Make sure to turn off your phone and disconnect

charger and other accessories. Slide off the battery cover.

2. Pick up the battery using the protruding edge and

remove the battery from the phone.

3. Slide the SIM card by pushing the back of the card

and remove it from the SIM holder.

Getting Started 12

Battery Disposal

The device is supported by a battery. In order to protect the environment, please read the following points concerning battery disposal:

• Take the used battery to your local waste depot, dealer or customer service centre for recycling.

• Do not expose the used battery to an open flame, into water or dispose with the household waste.

Charging the Battery

You must charge the battery for at least 2 hours before using your phone for the first time.

13 Getting Started

To Charge Using the Charger

1. Connect the charger to the external socket located at

the bottom of the phone with the charger’s “PUSH TOP” mark facing towards you, and to an AC outlet.

LED indicator

The LED indicator lights in red. Standard charging time: Approx. 2 hours.

Note

• Charging time may be longer than above depending on the state of a battery and a surrounding situation. (See “Battery” on page 128.)

To disconnect the charger

Push and hold the side buttons of the charger, then disconnect the charger from the external socket of the phone.

2. When charging is complete, the LED indicator turns

off. Unplug the charger from the AC outlet, then unplug the charger connector from the phone.

Note

• Do not use any non approved charger, this may damage your phone and void any warranty, please see “Battery” on page 128 for details.

• When the phone is charging, the animated battery status icon ( ) will be displayed in the upper right of the screen.

To Charge Using the Cigarette Lighter Charger

The cigarette lighter charger (option) supplies power for charging from the cigarette lighter socket of a car.

Battery Level Indicator

The current battery level is displayed in the upper right hand side of the screen and the Sub-screen.

Low Battery During Use

When the battery is running low, an alarm will sound and the “ ” will appear on the screen and the Subscreen.

If you are using your phone and you hear the “low battery” alarm, attach your charger as soon as possible. The phone may not be able to continue normal operation if you continue to use it. The battery may only last five minutes before the phone itself powers down during a call.

Charge Level Indicators

Full level (greater than 60%)

Partial level (less than 60%)

Partial level (less than 30%)

Low level (less than 10%)

Empty

Charging the battery is recommended.

Charge the battery.

Getting Started 14

Turning Your Phone On and Off

To turn the power on, press and hold for approximately 2 seconds.

The stand-by screen appears. To turn the power off, press and hold for

approximately 2 seconds.

Entering the PIN Code

If activated you will be asked to enter a PIN (Personal Identification Number) code after turning on your phone.

1. Enter your PIN code.

2. Press .

Note

• If your PIN code is entered incorrectly three times consecutively, the SIM card is locked. See “Enabling/ Disabling the PIN Code” on page 102.

• Some functions of your phone may be limited depending on your SIM card.

15 Getting Started

Display Indicators

Left softkey

Status Indicators

Right softkey

1. / : Indicates the strength of received signal/the service is out of range.

2. : Appears when in call.

3. ///: Indicates the input mode (Upper case only the first letter of the word mode/Upper case mode/Lower case mode/Numeric mode).

4.//: Appears when the T9 text input mode is activated. Chinese character input modes are T9 Stroke and T9 BoPoMoFo.

5. / / : Appears when a new SMS, MMS Alert or WAP Alert has arrived.

6. / : Appears when viewing secured WAP browser.

7. / : Appears when a picture or image/ sound is attached to MMS.

8. : Indicates a Phonebook entry stored in the phone memory.

9. : Indicates a Phonebook entry stored on the SIM card.

10. : Indicates the battery level.

11. : Appears when your phone is roaming outside of your network.

12. : Appears when your phone is in data communication mode.

13. : Appears when your phone is in fax communication mode.

14. : Appears when your phone is GPRS enabled and within range. Flashes during GPRS transmission.

15. : Appears when Alarm is set.

16. : Appears when “Diverts” (p. 85) is set to “All Calls”.

17. : Appears when the data cable is connected to your phone.

18. : Appears when “Ringer Volume” (p. 67) is set to “Silent”.

19. : Appears when Vibration alert is set.

Getting Started 16

20.(No display)/ / / / :

21. : Appears when up, down, right or

22. / : Appears when “Infrared” is on/

23. / : Appears when the Java™

Softkey Indicators

To execute the operation indicated, press each corresponding key.

24.Area at the lower left of a screen:

25.Area at the lower right of a screen:

17 Getting Started

Indicates the phone’s mode (Normal mode/Meeting mode/ Activity mode/Car mode/Silent mode).

left navigation is available.

during connection.

application is executed/ suspended.

Displays the operation executed by left softkey.

Displays the operation executed by right softkey.

Sub-Screen

Status Indicators

1. : Indicates the received signal

2. : Appears when GPRS is within

3. : Appears when a new SMS, MMS

4. : Appears when Alarm is set.

5. : Indicates the battery level.

6. / : Appears when “Infrared” is on/

7. : Appears when “Diverts” (p. 85) is

strength.

range and can be used. Flashes during GPRS communication mode.

Alert or WAP Alert has arrived.

during connection.

set to “All Calls”.

8. : Appears when the data cable is connected to your phone.

9. : Appears when “Ringer Volume” (p. 67) is set to “Silent”.

Getting Started 18

Call Functions

Making a Call

1. Enter the area code and the phone number you wish

to dial. If you enter the wrong number, press [Clear] to

delete the number to the left of the cursor.

2. Press to dial.

Emergency Calls

1. Enter 112 (international emergency number) using

the keypad.

2. Press to dial.

Note

• Emergency calls may not be available on all mobile phone networks when certain network services and/ or phone features are in use. Contact your network operator for more information.

• This Emergency number can normally be used to make an emergency call in any country, with or without a SIM card inserted, if a GSM network is within range.

19 Call Functions

International Calls

1. Press and hold until a “+” (international

dialling prefix) sign appears.

2. Enter the country code, followed by the area code

and the number.

3. Press to dial.

Note

• Enter the area code omitting the first 0 when making international calls, in most cases. (It differs for some countries.)

Speed Dialling

In the Speed Dial List, up to 9 phone numbers out of the Phonebook can be set. You can call the numbers using the digit keys ( to and ).

For details on setting the Speed Dial List, see “Speed Dial List” on page 34.

1. Press and hold any of the digit keys ( to

and ). The phone number stored in the Speed Dial List is

displayed, then dialled.

Redialling

You can redial the numbers in the call log list that you may have missed, received or dialled. Each list can contain up to 10 numbers.

1. Press during stand-by.

2. Press or to select a category between

“Dialled Numbers”, “Missed Calls” and “Received Calls”.

3. Select the number you wish to call by pressing

or .

4. Press to redial the call.

Automatic Redialling

This setting allows you to automatically redial the number if the first attempt was unsuccessful.

If you wish to stop redialling, press or [End].

To Set the Auto Redial Function

1. Press to display the Main Menu.

2. Press or to select “Settings”, then press .

3. Press or to select “Call Settings”, then press

4. Press or to select “Auto Redial”, then press

5. Select “On” to enable the Auto Redial function or

“Off” to disable it, then press .

Note

• When you receive an incoming call, the Auto Redial function will be interrupted.

• Automatic redialling is not available for fax and data calls.

Ending a Call

1. Press to end the call.

Answering a Call

When an incoming call is detected, the phone rings and the LED indicator flashes green.

1. Open your phone.

2. Press to answer the call.

or Press any key except , [Reject], and when the “Any Key Answer” function is enabled. Set the Any Key Answer function in the profile in each mode. (p. 71)

Call Functions 20

Tip

• When the hands free kit is connected to the phone, you can answer calls by pressing the Side keys (up or down).

• If you have subscribed to the Calling Line Identification (CLI) service and the caller’s network sends the number, the caller’s number will appear on the screen. If the caller’s name and number are stored in the Phonebook, the caller’s name will appear on the screen.

• If the number is a restricted number, the display shows “Withheld”.

• When receiving a call from the person whose picture is registered in the Phonebook, receiving display and the picture are displayed alternately.

Rejecting an Incoming Call

You can reject a call you do not wish to answer.

1. Press or [Reject] or press and hold the Side

keys (up or down) whilst the phone is ringing.

Incall Menus

Your phone has additional functions available whilst a call is in progress.

21 Call Functions

Adjusting the Earpiece Volume

You can adjust the earpiece volume during a call.

1. During a call, press .

2. Press to increase the earpiece volume or press

to decrease the earpiece volume.

Each press of or adjusts the earpiece volume by one of 5 levels.

3. Press [OK].

Tip

• You can also adjust the earpiece volume using the Side keys (Volume up key or Volume down key) during a call.

Putting a Call on Hold

This function allows you to manage two calls at the same time. If you wish to make another call whilst you are talking to someone, you can put the current call on hold to call someone else.

To make another call during a call

1. During a call, press [Options] to display the

Options Menu.

2. Select “Hold”, then press .

The current call is put on hold. To retrieve a call, press [Options] and select “Retrieve”, then press .

3. Enter the phone number you wish to make another

call to, then press .

Tip

• You can also make another call by entering the phone number during a call instead of steps 1 and 2. The current call is automatically put on hold.

Call Waiting

This service notifies you of another incoming call whilst you have a call in progress.

1. During a call, press [Answer] to answer the

second call. The first call is put on hold and you can now talk to

the second caller.

2. Press [Options] and select “Swap” to switch

between the two calls.

3. Press [Options] and select “End Call”,

then press to end the current call and return to the held call.

Note

• You need to set “Call Waiting” to “On” if you use Call Waiting service (p. 92).

• Call Waiting service may not be available on all networks. Contact your network operator for more information.

• If you do not wish to answer the second call, press [Reject] in step 1. The call log of the second call

will be saved as a missed call.

Conference Call

Conference call is a call with more than 2 participants. You may include up to 5 participants in a conference call.

Making a Conference Call

To make a conference call, you must have one active call and one held call.

1. Press [Options] to display the Options Menu.

2. Press or to select “Multiparty”, then press

3. Press or to select “Join All”, then press

to join the conference call.

4. Press to end the conference call.

Note

• Conference call service may not be available on all

networks. Contact your network operator for more information.

Call Functions 22

Adding New Participants to the Conference Call

1. Press [Options] to display the Options Menu.

2. Press or to select “Dial”, then press .

3. Enter the number you wish to include in the

conference call.

4. Press to dial.

5. Press [Options] to display the Options Menu.

6. Press or to select “Multiparty”, then press

7. Press or to select “Join All”, then press

to join the conference call. If you wish to add other participants, repeat steps 1

to 7.

To End the Call with a Conference Call Participant

1. During a conference call, select the person who you

wish to disconnect the call by pressing or .

2. Press [Options] to display the Options Menu.

3. Press or to select “End Call”, then press

23 Call Functions

To Have a Private Conversation with one of the participants

If you wish to have a private conversation with one of the participants, you may select the participant from the conference list and put the other participants on hold.

1. During the conference call, select the person that

you wish to talk to by pressing or .

2. Press [Options] to display the Options Menu.

3. Press or to select “Multiparty”, then press

4. Press or to select “Private”, then press .

5. Once you have finished the private conversation,

press [Options] and select “Multiparty”, then press .

6. Press or to select “Join All”, then press

to return to the conference call.

Muting the Microphone

1. During a call, press [Mute] to mute the

microphone. To unmute the microphone, press [Un mute].

Entering Characters

When entering characters to create Phonebook entries, SMS or MMS, etc., press the corresponding keys.

Table of Characters

Pressing each key scrolls characters in the following order.

Note:

• Depending on the type of the data entry screen, usable characters are limited.

English Mode

Key

Upper Case Characters

(full-stop)

(comma)

’

(apostrophe)

ABC2ГБАВДЕЖЗ abc2гбавдежз 2

DEF3ÉÊÈË def3éêèë 3

GHI4Í

JKL5 jkl5 5

MNO6ХУФТЦШС mno6хуфтцшс 6

PQRS7 pqrs7ß 7

@ _ ( ) / ” :1

Î Ì Ï ghi4í î ì ï4

(hyphen)

Lower Case

Characters

? !

Numeric

Key

Upper Case Characters

TUV8ÚÜÙÛ tuv8úüùû 8

WXYZ9ÝÞ wxyz9ýþ 9

(space)+ = < > £ $ ¥ % &0

*+P?

+Navigation

Keys+

, - : Press and hold to enter 0 - 9

: Press and hold to display the

: During text imput mode, press and

numbers.

Input Mode Select screen.

hold to alternate between T9, Multi-tap, and Numeric modes. (See the section described later.)

Lower Case

Characters

(space)

Entering Characters 24

Numeric

Changing the Input Mode

To change the input mode, repeat pressing for approximately 2 seconds.

The input mode switches as follows:

T9 mode

Multi-tap mode

Numeric mode

Changing the Character Input Mode

1. Press and hold to change

the character input mode. The Input Mode Select screen is

displayed.

25 Entering Characters

2. Press or to select the desired option, then

press .

T9 Chinese

T9 English

Multi-tap

Symbols (Half-sized symbols) Fullwidth

Symbols Numeric (numeric mode)

T9 Stroke T9 BoPoMo Fo T9 Abc T9 ABC T9 abc Abc ABC abc

(Full-sized symbols)

Symbols and Punctuation

1. Perform steps in the above

section, or press from any input mode. The first symbol page is displayed.

2. Press or to switch pages

(1 and 2), or use the numeric keys (1 and 2).

T9 Text Input (T9 Abc)

T9 text input method is a shortcut to enter text easily and quickly.

1. Press and hold until “

”

is displayed.

2. Press each key once for any letter you require on

that key. To enter the word “How”, press .

3. Press or until the correct word is shown if

the character combination, that was initially displayed, is not correct.

4. Press to select the word.

Note

• If the correct word is not shown in step 3, enter the correct word again after switching to the normal input mode.

Tip

• If you press instead of step 4, a space is inserted next to the selected word.

Entering Characters 26

Table of Stroke and BoPoMoFo characters

BoPoMoFo

Wildcard

Space

Pressing each key scrolls characters in the following order.

Chinese Mode

27 Entering Characters

trok

o to the Chines

symbol scree

Changing the Input Mode between Stroke and BoPoMoFo

See the section above, page 25

“Changing the Input Mode” on

Using Stroke Mode

Input field

Press and hold the

corresponding numeric

key to select the desired

character directly from

the Candidate field.

Candidate field

Example of entering “ ”.

1. Change the input mode to T9

Stroke mode.

2. Press

to display the

corresponding stroke for .

3. Press and hold to complete

the selection.

Using BoPoMoFo Input Mode

The following is an example of entering “ ” for “”.

1. Press , , and (2

times quickly) to enter reading. The candidates with the same

reading are displayed in the Candidate field.

2. Press or until the desired character is

displayed.

3. Press and hold if the

desired character is displayed.

4. Repeat steps 1 through 4 to complete messages.

Entering Characters 28

Tip

• After step 4, the Candidate field predicts and displays the candidate that frequently follows the previous character, when the cursor places after the first character.

• If you want to use 4-tone option to display the desired character, press instead of step 2. The 4-tone symbols are displayed in the Candidate field. The candidates are displayed. Press the corresponding numeric key ( ).

29 Entering Characters

Using Text Template

You can use the sentences registered in Text Templates when entering characters.

For details on creating the text template, see “Adding Phrases to Text Templates” on page 49.

1. Press [Options] to display the Options Menu.

2. Press or to select “Insert Template”, then

press .

3. Select a desired text template by pressing or

, then press .

The selected text template will be inserted.

Phonebook

You can store the phone numbers and E-mail addresses of your friends, family and colleagues in the Phonebook.

Group name (p. 31)

You can classify the phone numbers and names stored in the Phonebook, such as “Family” and “Business”.

Creating a New Entry

You can choose either the phone (up to 500) or SIM card memory locations to store the new entry.

The amount of phone numbers that you can store to the SIM card is dependent on its capacity. Contact your network operator for SIM details.

Phonebook Memories

Select the location for storing the Phonebook memory before storing a new entry.

1. Press to display the Phonebook menu.

2. Press or to select “Settings”, then press .

3. Press or to select “Save Nos. to”, then press

4. Select “SIM Card” to store the entry on the SIM

memory or “Phone Memory” by pressing or

, then press .

When selecting “Choice”, you can choose SIM card or phone memory every time you store a new Phonebook entry.

Storing Names and Numbers

1. Press to display the Phonebook menu.

2. Press or to select “Add New Name”, then

press .

3. If you select “Choice” in step 4 in “Phonebook

Memories”; Select “SIM Card” or “Phone Memory” by pressing

or , then press .

The name entry prompt appears.

4. Enter a name, then press .

For details on entering characters, see “Entering Characters” on page 24. The phone number prompt appears.

5. Enter the phone number, then press .

Up to 40 digits can be entered.

6. Select a desired number type by pressing or ,

then press .

7. Press [Save].

8. You can divide the phone numbers of the

Phonebook into groups. You can also register E-

Phonebook 30

mail address, personal data, and picture/image data. (See “Storing Optional Data” for details.)

Storing Optional Data

You can store optional data after entering a phone number. (See “Storing Names and Numbers” for details.)

Note

• E-mail address, personal data, and picture/image data cannot be stored on the SIM card.

Selecting Group Name

1. Press or to highlight the right side of

“ ”, then press .

2. Select a desired group name by pressing or ,

then press . You can set to display the available group names

when you store/edit the Phonebook, see “View Groups” on page 34.

Entering E-mail Address

3. Press or to highlight the right side of

“ ”, then press .

4. Enter the E-mail address, then press .

Up to 60 characters can be entered.

31 Phonebook

Entering Personal Data

5. Press or to highlight the right side of

“ ”, then press .

6. Enter the personal data, then .

Up to 60 characters can be entered.

Storing Picture/Image Data

You may store a picture/image for use with the Phonebook.

When you receive a call from a person with a Phonebook entry which also has a linked picture/image, the linked picture/image will be displayed.

7. Press or to highlight the right side of

“ ”, then press .

8. Select the desired picture/image, then press .

The selected picture/image will appear on the screen.

9. Specify the range for displaying the picture/image

by pressing , , or , then press .

Note

• The stored picture/image is automatically saved under the “in Phonebook” section of the Image Gallery.

• The picture/image cannot be deleted in the Image Gallery. Remove the picture/image data from the Phonebook.

Adding the Phone Number from the Call Log Entries

1. Display the call log entry you wish to store (p. 80).

2. Press .

3. Press or to select “Save to Phonebook”, then

press .

4. Follow the procedure from step 3 in “Storing Names

and Numbers” on page 30.

Storing after Inputting a Phone Number

1. Enter the phone number, then press [Save].

2. Follow the procedure from steps 3 to 7 in “Storing

Names and Numbers” on page 30.

Finding a Name and Number

Two methods of searching through the Phonebook are available:

Search by Name

1. Press to display the Phonebook menu.

2. Select “View Names”, then press .

3. Enter a name or the first character(s) of the name.

Matched results will be displayed alphabetically. If there is no entry in the Phonebook that satisfies the exact search criteria, the name that is nearest alphabetically matching will be displayed.

4. Scroll through list by pressing or to select

the desired name, then press [Select]. The detailed screen of the Phonebook appears.

5. Press .

6. Press or to select the desired phone number,

then press to dial.

Tip

• If you press and select “Search” after step 2, you can also search the name and number.

• You can also dial the desired phone number by pressing the digit key corresponding to the list number instead of step 6.

Phonebook 32

Search in Alphabetical Order

1. Press or whilst in stand-by to open the

Phonebook.

2. Scroll the list by pressing or to find the

desired name.

3. If you wish to do a name search, perform steps 3 and

4 in “Search by Name”.

Editing Phonebook Entries

You can edit Phonebook entries.

1. Search for the desired Phonebook entry.

For details on searching through Phonebook entries, see “Finding a Name and Number” .

2. Press .

3. Press or to select “Edit”, then press .

4. Select an entry you wish to change by pressing

or , then press [Edit].

5. Edit entry as required.

6. Press .

If you wish to edit another item, repeat steps 4 to 6.

7. Press [Save] to save the change(s).

33 Phonebook

Deleting Phonebook Entries

1. Search for the desired Phonebook entries.

For details on searching through Phonebook entries, see “Finding a Name and Number” on page 32.

2. Press .

3. Press or to select “Delete”, then press .

4. Select “Yes”, then press .

The selected entry will be deleted. To cancel deleti on, select “No” at step 4, the n press .

Checking Your Own Numbers

You can check and edit your own voice, data and fax phone numbers in the Phonebook.

1. Press to display the Phonebook menu.

2. Press or to select “Own Numbers”,

then press .

3. Press or to select the phone number you

wish to check from either “Voice”, “Data” or “Fax”, then press .

Note

• “Data” or “Fax” may not be displayed depending on SIM card.

Editing Your Phone Numbers

1. Perform steps 1 to 3 in “Checking Your Own

Numbers”.

2. Press .

3. Press [Clear] to erase the phone number and

enter a new phone number.

4. Press to save the phone number.

View Groups

You can set the available group names when you store/ edit the Phonebook.

1. Press to display the Phonebook menu.

2. Press or to select “Settings”, then press .

3. Select “View Groups”, then press .

4. Select a desired group name by pressing .

“ ” indicates that the group has been selected. To cancel the selected group, press again. The checkbox becomes blank again.

Memory Status

This function helps you to check the number of entries stored in the Phonebook.

1. Press to display the Phonebook menu.

2. Press or to select “Settings”, then press .

3. Press or to select “Memory Status”, then

press .

You can check the following memory status. “SIM Card : xxx/xxx” “Speed Dial : xx/xx” “Phone : xxx/500”

Note

• The number of locations available on the SIM is dependant on its capacity.

Speed Dial List

You can set a maximum of 9 phone numbers to the Speed Dial List.

Use the phonebook entries on the SIM card.

Adding Phonebook entries to the Speed Dial List

1. Search for the desired Phonebook entries.

For details on searching through Phonebook entries, see steps 1 to 4 in “Search by Name” on page 32.

2. Press or to select the phone number.

3. Press .

Phonebook 34

4. Press or to select “Add to Speed”, then press

5. Select the number you wish to add by pressing

or , then press .

Viewing the Speed Dial List

1. Press to display the Phonebook menu.

2. Press or to select “Settings”, then press .

3. Press or to select “Speed Dial List”, then

press . The stored names and phone numbers in the

selected entry are displayed in order.

Sending Messages

1. Search for the desired Phonebook entries.

For details on searching through Phonebook entries, see steps 1 to 4 in “Search by Name” on page 32.

2. Press or to highlight the right side of

“ ”, “ ” or “ ”, then press or Press or to highlight the right side of “ ”, then press .

3. Press or to select “Send Message”, then

press .

35 Phonebook

If you highlight the right side of “ ”, “ ” or “” in step 2:

4. Press or to select “MMS” or “SMS”, then

press .

5. Enter your message.

For details on creating a message, see “Creating a New MMS” on page 110 or “Creating a New SMS” on page 118.

Using the Menu

Using the Main Menu

1. Press during stand-by mode.

2. Press or to navigate to required location.

3. Press or to access function.

To Select Another Item within the Main Menu

To return to the previous screen after selecting a function from the Main Menu or Sub Menu, press .

Every time you press , the screen goes back one by one.

Operation Guidance

Your phone uses softkeys to help you to navigate the phone ( and ). These keys change usage depending on the situation. The function of each softkey at any given time is highlighted at the bottom left and bottom right of the screen.

Shortcut Keys

When pressing several key combinations during standby mode, you can shortcut to the specified menus.

To access the desired menu directly, press and digit keys for the menu’s corresponding number during stand-by mode. See the following table as reference.

Example: To access “Language” Sub Menu using shortcut keys

Press .

Note

• The shortcut keys work for the first three menu levels only.

Side Keys

The Side keys (up or down) function the same as pressing or .

Using the Menu 36

List of Menu Functions

Menu No./ Main Menu

1 Camera 2 My Phone 1 Java™ Gallery

3 Fun & Games 1 Java™

4 Profiles 1 Normal

5 Organiser 1 Calculator

6 Call Manager 1 Phoneboo k

37 Using the Menu

2 Image Gallery 3 Sound Gallery 4 Tex t Tem pla te s 5 Memory Status

2 Games 3 Melody Editor 4 Ton e E dit or

2 Meeting 3 Activity 4 Car 5 Silent

2 Calendar 3 Clock & Alarm 4 Voice Memo 5 Help List

2 Call Register 3 Diverts

Menu No./

Sub Menu1

Menu No./

Main Menu

7 Settings 1 Phone Settings

8 Browser 1 SmarTone 'in'

9 SMARTMENU* 0 Messages 1 MMS

Menu No./

Sub Menu1

2 Call Settings 3 Network Settings 4 Internet Settings 5 Infrared 6 Security 7 Master Reset

2 Bookmarks

2 SMS 3 Cell Broadcast 4 Cell Info 5 Voicemail

* Depends on the contents of SIM card.

Camera

Your phone incorporates an integrated digital camera. This allows you to take and send pictures wherever you

are.

Taking Pictures

Put the phone into the camera mode to take a picture. You can send the pictures registered in the Image

Gallery with your message.

1. Press and hold for approximately 2 seconds

(M 1)

whilst stand-by. The phone switches to the camera mode.

The camera view can be seen through the “on screen” viewer.

2. Press to take the picture.

The shutter sound occurs and the static image of the taken picture is displayed.

3. Press [Save].

“Save to Gallery...” is displayed, then the picture is registered. If you wish to send a picture by MMS after taking the picture, press . The camera returns to step 1. Repeat process as desired.

4. Press to return to stand-by.

Tip

• To leave Camera Mode without registering the taken picture after step 2 in “Taking Pictures”: Press and select “Yes”, then press .

• To take a picture of yourself, press or the Side keys (up or down) whilst checking the image reflected on the mirror on the back of the phone. Place/Hold the phone at least 40 cm away from yourself.

Using the Zoom Function

Press [Zoom] to magnify the photographic subject. Press [Wide] to restore the original magnification.

Note

• When “Select Size” is set to “Large”, you cannot use the zoom function.

To select the picture size

1. Press [Options] before step 2 in “Taking

Pictures” to display the Options Menu.

2. Press or to select “Select Size”, then press

3. Select the picture size by pressing or , then

press .

Camera 38

To select the mode

1. Press [Options] before step 2 in “Taking

Pictures” on page 38 to display the Options Menu.

2. Press or to select “Select Mode”, then press

3. Select the mode by pressing or , then press

Note

• Vertical stripes may be reflected to a picture by light source. Change the mode in this case.

Retaking Pictures

After steps 1 and 2 in “Taking Pictures” on page 38, press [Back].

Further shooting is available.

Note

• The Digital Camera uses a C-MOS Sensor. Although this camera has been manufactured to the highest specification, some pictures may still appear too bright or too dark.

• If the phone has been left in a warm place for a long time before taking or registering a picture, the picture quality may be poor.

39 Camera

In the Case of No Available Memory

When the number of pictures that can be taken becomes 5 or less, or when the remaining capacity becomes 27.5 Kbytes (when “Medium” is selected as the picture size) or less, “ ” will appear on screen. The screen returns to step 2 in “Taking Pictures” on page 38. The number of pictures that can be taken is displayed in the upper left of the screen. (The number of pictures that can be taken is approximate.)

When the number of pictures that can be taken becomes 0, and when you try to take a picture again, “Can not take a picture. Maximum Capacity” is displayed.

Meanings of Indicators in Camera Mode

Delay timer indicator (p. 40)

: Whilst the timer setting is on.

Picture brightness indicators (p. 40)

: Bright : : Normal : :Dark

Picture size indicators (p. 38)

Large: 288 × 352 dots Medium (default): 120 × 160 dots Small: 60 × 80 dots

Mode indicator (p. 39) By setting the indicator to the electrical frequency of

the region, picture quality of shots taken with indoor illumination is improved.

: Mode 1 (50 Hz) : Mode 2 (60 Hz)

Making Adjustments According to Lighting Conditions

Adjusting the Brightness of the Picture

Adjust the brightness of the picture by pressing or

Once the phone has returned to the stand-by screen the brightness settings return to default.

Viewing the Taken Pictures

The taken pictures can be viewed in the Image Gallery.

1. In camera mode, press [Options].

The Options Menu is displayed.

2. Select “Existing Images”, then press .

The list of Image Gallery is displayed.

3. Select the file name you wish to view by pressing

or , then press .

The selected picture is displayed.

4. Once you have finished, press [Back] to return

to the list.

Tip

• Your pictures are given file names which show the time and date when the picture was taken. Example: The file name “13-05-02_12-34-56” is displayed for the picture taken at 12:34:56 of 13th May 2002. The file names of your pictures can be changed (p. 44).

Using the Timer

Taking a Picture with the Timer

1. In camera mode, press [Options].

The Options Menu is displayed.

2. Press or to select “Delay Timer”, then press

3. Press or to select “On”, then press .

“ ” appears on the screen and the phone returns to camera mode.

4. Press to take the picture.

Delay timer begins. 10 seconds after the timer sound occurs, the camera takes a picture, and sounds a tone.

Camera 40

Note

• Whilst the delay timer is operating, the LED indicator and the icon flash.

• If is pressed whilst the delay timer is operating, the picture is taken instantly.

• If there is an incoming call or alarm functioning, or is pressed, whilst the delay timer is operating, the camera operation is cancelled. In this case, the timer setting is cancelled.

• The zooming function with [Zoom] / [Wide], or the adjustment of brightness of the picture with or

, is unavailable whilst the delay timer is

operating.

Cancelling the Delay Timer

1. Press [Options] whilst the delay timer setting is

on. The Options Menu is displayed.

2. Press or to select “Delay Timer”, then press

3. Press or to select “Off”, then press .

“ ” goes off.

41 Camera

Sending Pictures

See “Sending Messages” on page 45 for instructions.

Deleting Pictures

See “Deleting Pictures/Images” on page 46 for instructions.

My Phone

My Phone contains several types of picture/image and sound data along with Java™ applications which can be controlled collectively. Also included in My Phone are frequently used text message phrases.

(M 2)

Java™

Using Java™ Applications

Various kinds of SmarTone specific Java™ applications can be used in this phone.

To use Java™ applications, download the Java™ applications via the mobile Internet.

Some Java™ a network either within a game or network based application.

Note

• Java™ applications may be both localised (no

applications offer the ability to connect to

connectivity) and network based (using the mobile Internet to update information/play games). The network may charge you more for using networkbased applications. Please contact your service provider for more information.

Java™ Gallery

Downloaded applications are stored in the Java™ Gallery.

Note

• The phone can store approximately 700Kbytes of information across the Java™ Gallery, Image Gallery and Sound Gallery. The Java™ Gallery can store up to 50 applications.

Executing Java™ Applications

(M 2-1)

1. Press to display the Main Menu.

2. Press or to select “My Phone”, then press

3. Select “Java™ Gallery”, then press .

The list of Java™ Gallery is displayed. The downloaded Java™ applications are sequentially displayed from the latest one.

4. Select the title of the Java™ application you wish to

execute by pressing or , then press . The selected Java™ application is executed.

When using network connection type Java™ applications, connection to the network can be selected.

My Phone 42

To end the Java™ application

1. Press .

2. Press or to select “End”, then press .

The screen returns to stand-by screen.

To suspend the Java™ application

1. Press .

2. Press or to select “Suspend”, then press .

To resume the Java™ application, press during stand-by screen and select “Resume”, then press

Checking the Information of the Java™ Application

1. Perform steps 1 to 3 in “Executing Java™

Applications” on page 42.

2. Select the Java™ application you wish to check,

then press [Options]. The Options Menu is displayed.

3. Select “File Information”, then press .

The detailed information screen is displayed.

4. Press or to scroll through the screen.

5. When you have finished, press [Back].

The screen returns to the Java™ Gallery.

43 My Phone

Deleting Java™ Applications

1. Perform steps 1 to 3 in “Executing Java™

Applications” on page 42.

2. Select the Java™ application you wish to delete,

then press [Options]. The Options Menu is displayed.

3. Press or to select “Delete”, then press .

4. Select “Yes”, then press .

The selected application is deleted. To cancel deletion, select “No” at step 4, then press

Image Gallery

Pictures that are taken by a digital camera or images that are downloaded from mobile Internet sites can be managed.

: This is the folder where the pictures/images

registered in the Phonebook are saved. : Images in PNG format : Pictures/Images in JPEG format : e-Animation file (NEVA) : Images in GIF format : Images in BMP format : Images in WBMP format : Images in WPNG format

The date and time when the photo was taken is displayed as a file name for the picture.

Viewing Pictures/Images

(M 2-2)

1. Press to display the Main Menu.

2. Press or to select “My Phone”, then press

3. Select “Image Gallery”, then press .

The list of Image Gallery is displayed.

4. Select the file name you wish to view by pressing

or , then press .

The selected picture/image is displayed.

5. Once you have confirmed the picture/image, press

[Back] to return to the Image Gallery.

Checking the Picture/Image Data

Select the desired data in step 5 in “Viewing Pictures/ Images”, then select “File Information” after pressing

[Options] to display the Options Menu.

The file type and size of the selected picture/image are displayed. Whether the picture/image can be copied, forwarded, or saved is also displayed.

To return to the Image Gallery, press [Back].

Changing the File Name

1. Perform steps 1 to 3 in “Viewing Pictures/Images”.

2. Select the file name you wish to change by pressing

or , then press [Options].

The Options Menu is displayed.

3. Select “Rename”, then press .

4. Enter a new file name.

To correct the last character, press [Clear] briefly. Press and hold [Clear] to clear all characters.

My Phone 44

5. Press .

Note

• Following characters cannot be used for a file name:

/, \, :, *, ?, ", <, > and . (full-stop).

Adjusting the Size of the Picture/Image

The pictures/images that are registered in the Image Gallery can be adjusted for use as a wallpaper during stand-by or as an incoming call display. When the picture/image size is modified, the data size is updated.

1. Perform steps 1 to 3 in “Viewing Pictures/Images”

on page 44.

2. Select the file name you wish to adjust by pressing

or , then press [Options].

The Options Menu is displayed.

Press or to select “Adjust Size”, then press .

4. Select the picture/image size you wish to change by

pressing or , then press .

5. Specify the range for displaying the picture/image

by pressing , , or then press .

6. Press .

To cancel registration, press [Back] at any time before step 6.

45 My Phone

Note

• “Adjust Size” may not be available depending on the picture/image original and copyright issued.

Sending Messages

1. Perform steps 1 to 3 in “Viewing Pictures/Images”

on page 44.

2. Select the file name you wish to send by pressing

or , then press [Options].

The Options Menu is displayed.

3. Press or to select “Send Message”, then

press .

4. Enter your message.

For details on creating a message, see “Creating a New MMS” on page 110.

Note

• Pictures/images with a red icon cannot be sent attached to a message.

Deleting Pictures/Images

1. Perform steps 1 to 3 in “Viewing Pictures/Images”

on page 44.

2. Select the file name you wish to delete by pressing

or , then press [Options].

The Options Menu is displayed.

3. Press or to select “Delete”, then press .

4. Select “Yes”, then press .

The selected picture/image is deleted. To cancel deletion, select “No” at step 4, then press

Sound Gallery

The ring tones instead created by Melody Editor and the WAVE data recorded by Voice Memo are managed in the Sound Gallery. Default ring tones are not contained.

: Sound file in SMAF format : Original ringing tone (composed in Melody

Editor) : Sound file in Standard MIDI format : Sound file in i Melody format : Sound file in WAVE format

Note

• SMAF (Synthetic music Mobile Application Format) is a format of music data for mobile phones.

(M 2-3)

My Phone 46

Playing Back Sounds

1. Press to display the Main Menu.

2. Press or to select “My Phone”, then press

3. Select “Sound Gallery”, then press .

The list of Sound Gallery is displayed.

4. Select the sound you wish to play back by pressing

or , then press .

The selected sound is played. To stop playing, press [Stop].

Checking the Sound Data

Select the desired sound as in step 5 in “Playing Back Sounds”, then select “File Information” after pressing

[Options].

The file type and size of the selected sound are displayed. Whether the sound can be copied, forwarded or saved is also displayed.

To return to the Sound Gallery, press [Back].

47 My Phone

Changing the File Name

1. Perform steps 1 to 3 in “Playing Back Sounds”.

2. Select the file name you wish to change by pressing

or , then press [Options].

The Options Menu is displayed.

3. Select “Rename”, then press .

4. Enter a new file name.

To delete the last character, press [Clear] briefly. Press and hold [Clear] to clear all characters.

5. Press .

Note

• Following characters cannot be used for a file name:

/, \, :, *, ?, ", <, > and . (full-stop).

Tip

• When “Data Edit” is displayed in the menu in step 2, you are able to edit the sound (p. 60). Once you have completed editing the newly saved file overwrites the old file. This new file then becomes the original ring tone.

Setting the Tone and Strength

1. Perform steps 1 to 3 in “Playing Back Sounds” on

page 47.

2. Select the file name you wish to edit by pressing

or , then press [Options]. The Options Menu is displayed.

3. Press or to select “Tone Set” or “Strength

Set”, then press . For full details, see pages 58 to 60.

Note

• If “Tone Set” and “Strength Set” are not displayed in the menu in step 2, you cannot change the settings.

Sending Messages

1. Perform steps 1 to 3 in “Playing Back Sounds” on

page 47.

2. Select the file name you wish to send by pressing

or , then press [Options].

The Options Menu is displayed.

3. Press or to select “Send Message”, then

press .

If you select your original ringing tone in step 2;

4. Press or to select the file format “SMAF”,

“MIDI” or “i Melody”, then press .

5. Enter your message.

For details on creating a message, see “Creating a New MMS” on page 110.

Note

• Sounds with a red icon cannot be sent attached to a message.

• Only the first part of the data will be converted if you select “i Melody” in step 4.

Deleting Sounds

1. Perform steps 1 to 3 in “Playing Back Sounds” on

page 47.

2. Select the file name you wish to delete by pressing

or , then press [Options].

The Options Menu is displayed.

3. Press or to select “Delete”, then press .

4. Select “Yes”, then press .

The selected sound has been deleted. To cancel deletion, select “No” at step 4, then press

My Phone 48

Text Templates

You can register up to 20 text templates for use in SMS and MMS.

You can input messages or others more easily by registering frequently used text.

64 characters may be registered in any text template.

Adding Phrases to Text Templates

(M 2-4)

1. Press to display the Main Menu.

2. Press or to select “My Phone”, then press

3. Press or to select “Text Templates”, then

press . The list of Text Templates is displayed.

4. Select the number you wish to register by pressing

or , then press

5. Enter the text, then press .

For details on entering characters, see “Entering Characters” on page 24.

Editing Text Templates

1. Perform steps 1 to 3 in “Adding Phrases to Text

Templates”.

2. Select the number you wish to edit by pressing

or , then press .

49 My Phone

3. Press or to select “Edit”, then press .

4. Enter new text.

To correct the last character, press [Clear] briefly. Press and hold [Clear] to clear all characters.

5. Press .

Viewing Text Templates

1. Perform steps 1 to 3 in “Adding Phrases to Text

Templates”.

2. Select the number you wish to view by pressing

or , then press .

3. Press or to select “Confirm”, then press .

The selected text template is displayed.

4. After confirmation, press [Back] to return to

template list.

Deleting Text Templates

1. Perform steps 1 to 3 in “Adding Phrases to Text

Templates”.

2. Select the text template you wish to delete by

pressing or , then press .

3. Press or to select “Delete”, then press .

4. Select “Yes”, then press .

The selected text template is deleted. To cancel deletion, select “No” at step 4, then press

Memory Status

This function helps you to check the memory status of the Galleries.

(M 2-5)

1. Press to display the Main Menu.

2. Press or to select “My Phone”, then press

3. Press or to select “Memory Status”, then

press .

My Phone 50

Fun & Games

Java™

(M 3-1)

Settings (M 3-1-2)

Operation Priority

You can set the method of incoming phone calls and alarm whilst a Java™ application is operated.

(M 3)

1. Press to display the Main Menu.

2. Press or to select “Fun & Games”, then

press .

3. Press or to select “Java™”, then press .

4. Press or to select “Settings”, then press .

5. Select “Operation Priority”, then press .

6. Select the option you wish to set by pressing or

, then press .

The options available are:

• “Incoming Call”

•“Alarm”

7. Press or to select methods, then press .

51 Fun & Games

• “Priority”: The Java™ application is suspended automatically, and you can receive the call or alarm will sound. After finishing the call or alarm, the suspend icon ( ) is displayed and you will know there is a suspended Java™ application.

• “Notice”: The marquee (character scrolls) is displayed on the first line on the screen whilst the Java™ application continues. If you press , the Java™ application is suspended, and you can receive the call. After finishing the call, the suspend icon ( ) is displayed and you will know there is a suspended Java™ application.

Sound Volume

You can set the sound volume of the Java™ application such as sound effect to one of the five levels or silent. When “Ringer Volume” (p. 67) is set to “Silent”, the set up has a priority.

1. Perform steps 1 to 4 in “Operation Priority”.

2. Press or to select “Sound Volume”,

then press . The current volume level is displayed.

3. Press to increase the volume or press to

decrease the volume and then press .

Backlight

You can select the method of backlight during the operation of the Java™ three types:

• “On”: Lit whilst the Java™

• “Off”: Unlit whilst the Java™

• “Normal Settings”:Works with the main backlight

1. Perform steps 1 to 4 in “Operation Priority” on

page 51.

application from the following

application is operated.

application is operated even if a key is pressed.

setting. (p. 88)

2. Press or to select “Backlight”, then press

3. Select “On/Off”, then press .

4. Select “On”, “Off” or “Normal Settings” by

pressing or , then press .

To Set the Blinking Operation

You can set whether the blinking operation, which is embedded in Java™

application, is enabled.

1. Perform steps 1 and 2 in “Backlight”.

2. Press or to select “Blink”, then press .

3. Select “On” or “Off” by pressing or , then

press .

Vibration

When vibrator is set in the Java™ application, you can choose whether the operation is enabled or disabled.

When a SMAF file is specified in the Java™ application, you can operate the vibrator set in the SMAF file.

Note

• SMAF (Synthetic music Mobile Application Format) is a format of music data for mobile phones.

1. Perform steps 1 to 4 in “Operation Priority” on

page 51.

2. Press or to select “Vibration”, then press

3. Press or to select “Enable”, “Disable” or

“Link to Sound”, then press . When you set “Link to Sound”, the Java™

application is synchronised with the vibrator.

Fun & Games 52

Online Services

You can adjust the display settings of the confirmation screen when a Java™ application attempts to connect to the network.

1. Perform steps 1 to 4 in “Operation Priority” on

page 51.

2. Press or to select “Online Services”, then

press .

3. Press or to select “Yes”, then press .

To cancel confirmation, select “No”, then press

Java™ Reset To reset all settings in a Java™ application

1. Perform steps 1 to 4 in “Operation Priority” on

page 51.

2. Press or to select “Java™ Reset”, then press

3. Enter your handset code, then press .

If you enter a wrong handset code, the screen will return to step 4 in “Operation Priority” on page 51.

4. Select “Settings Reset”, then press .

53 Fun & Games

5. Press or to select “Yes”, then press .

All settings in a Java™ application will be reset. To cancel resetting, select “No”, then press .

To clear all Java™ applications

All Java™ applications stored in Java™ Gallery are cleared.

1. Perform steps 1 to 4 in “Operation Priority” on

page 51.

2. Press or to select “Java™ Reset”, then press

3. Enter your handset code, then press .

If you enter a wrong handset code, the screen will return to step 4 in “Operation Priority” on page 51.

4. Press or to select “All Clear”, then press

5. Press or to select “Yes”, then press .

All Java™ applications are cleared. To cancel clearing, select “No”, then press .

Java™ Information (M 3-1-3)

The information about the license of Java™ can be displayed.

Games

(M 3-2)

Your phone comes complete with 3 games (Penalty Kick, Collection Hunter, Air Hockey).

You can enjoy these 3 games soon after purchase. You can also enjoy various games by downloading Java™ application games provided in the Internet sites.

Starting Games

1. Press to display the Main Menu.

2. Press or to select “Fun & Games”, then

press .

3. Press or to select “Games”, then press .

The game list is displayed.

4. Press or to select the desired game, then

press .

5. Select “New Game”, then press .

6. When you have finished playing, press .

Note

• If an incoming call is detected during gameplay, the game will be stopped.

Game Guide

1. Perform steps 1 to 4 in “Starting Games”.

2. Press or to select “Guide”, then press .

Game instructions are displayed.

Collection Hunter (M 3-2-2)

Check of a collection and reset of a game can be performed in “Collection Hunter”.

To Check Collection

1. Perform steps 1 to 3 in “Starting Games”.

2. Press or to select “Collection Hunter”,

then press .

3. Press or to select “Collection View”,

then press .

To Reset the Game

1. Perform steps 1 to 3 in “Starting Games”.

2. Press or to select “Collection Hunter”,

then press .

3. Select “Reset Game”, then press .

4. Press or to select “Yes”, then press .

Fun & Games 54

Air Hockey (M 3-2-3)

The level of the game can be chosen for “Air Hockey”.

To Select a Game Level

1. Perform steps 1 to 3 in “Starting Games” on

page 54.

2. Press or to select “Air Hockey”, then press

3. Press or to select “Level”, then press .

4. Press or to select the level, then press .

Setting up Game Options (M 3-2-4)

1. Perform steps 1 to 3 in “Starting Games” on

page 54.

2. Press or to select “Game Settings”, then

press .

3. Press or to select “Backlight” or “Enable

Vibrate” to change the settings, then press .

4. Press or to select “On” or “Off”, then press

5. Press or to select “Sound Volume” to adjust

the sound volume, then press .

6. Press to increase the sound volume or press

to decrease the sound volume and then press .

55 Fun & Games

Note

• If you wish to mute the sound during gameplay, press . Press again to return the volume.

Melody Editor

You can create an original ringing tone by yourself, or you can send a melody attached to an MMS.

You can input up to 190 tones × 16 chords, or 380 tones × 8 chords per melody.

The original ringing tone is registered in the Sound Gallery.

Creating Your Original Ringing Tone

(M 3-3)

(M 3-3-1)

1. Press to display the Main Menu.

2. Press or to select “Fun & Games”,

then press .

3. Press or to select “Melody Editor”,

then press .

4. Select “Create New”, then press .

5. Enter the title.

Up to 24 characters can be entered. For details on entering characters, see “Entering Characters” on page 24.

6. Press .

7. Press or to select a tempo, then press .

The music tempo is described below.

• “Allegro (Fast)”: 150

• “Moderato (Normal)”: 125

• “Andante (Slow)”: 107

• “Adagio (Very Slow)”: 94

Tempo is defined by the number of crotchets ( ) played per minute.

8. Select “8 Chords” or “16 Chords” by pressing

or , then press .

9. Specify the musical scale and rest using the digit

keys. For details on specifying the sound level and rest,

see “Specify the Musical Scale and Rest” on page 57.

10.Specify the types of musical notes or rest using

or keys.

For details on specifying the musical notes and rest, “Specifying the Types of Notes and Rests” on page 57.

11.Press key after inputting one note.

Input the next note after the cursor moves to the right.

12.Repeat steps 9 to 11 to input notes.

When you press during input, the melody that you have entered is played back.

When you press [Options] and select “Play before Cursor” whilst entering notes, the melody, that is displayed on the screen, is played back up to the cursor position.

When you press [Options] and select “Select Chord”, you can select another chord. Repeat steps 9 to 11 to input notes for the new chord.

13.When you finish inputting, press [Options] to

display the Options Menu.

14.Select “Save”, then press .

15.Press or to select “Save to Gallery”, then

press . Your original ringing tone is registered in the Sound

Gallery.

Note

• If the capacity or memory in the Sound Gallery becomes insufficient, the message of “Maximum Capacity : 80 Not registered” or “Not registered. Memory Full” is displayed respectively. At that time, the display returns to the screen of step 15. Try again after deleting unnecessary data (p. 48).

Fun & Games 56

Specify the Musical Scale and Rest

Using the key shown below, specify the musical scale and rest.

Do Re Mi Fa Sol La Ti Rest

When you press the key shown above once, a crotchet is specified in the middle scale (no mark).

When you press the same key repeatedly, the note will shift cycle through the available octave ranges.

When you press or whilst a note is selected, the note will raise one semitone higher or lower.

When entering rest: Crotchet rest is entered.

57 Fun & Games

Specifying the Types of Notes and Rests

Specify notes and rests by pressing or repeatedly.

( )

Crotchet (Crotchet rest)

Quaver (Quaver rest)

( )

Semiquaver (Semiquaver rest)

( )

Semibreve (Semibreve rest)

( )

Minim (Minim rest)

When you make a dotted note or triplet, press after selecting the target note.

Note

• You cannot make a dotted semiquaver (semiquaver rest) or a dotted semibreve (semibreve rest).

• Three continuous notes are required for triplet.

To specify a tie, press after selecting the target notes.

An underscore (_) is displayed next to the note, and the note is tied with the next one.

To enter the next note, press and move the cursor to the right. Then, repeat the operation on the previous page.

If the cursor is positioned next to a note, you can repeat the note immediately left of the cursor when or is pressed.

Set the Tone

The phone can play notes using different instruments.

1. Perform steps 1 to 13 in “Creating Your Original

Ringing Tone” on page 55.

2. Press or to select “Tone Set”, then press

3. Select a category of the tone by pressing or .

4. Select a tone by pressing or , then press .

When “Play Current Chord” is selected, the melody entered is played back in the selected tone. When “Confirm Tones” is selected, the syllable names are played back in the selected tone.

5. Select “OK”, then press .

Now you can create a melody.

You can select from the following 128 tones.

Category

Pianos

Tone Piano

Bright Piano E. Grand Piano Honky-Tonk Electric Piano 1 Electric Piano 2 Harpsichord Clavi

Category

Chimes

Celesta Glockenspiel Music Box Vibraphone Marimba Xylophone Tubular Bells Dulcimer

Fun & Games 58

Tone

Category

Organs

Basses

Strings 2

Ton e Drawbar Organ

Perc. Organ Rock Organ Church Organ Reed Organ Accordion Harmonica Tango Accordion

Acoustic Bass Finger Bass Pick Bass Fretless Bass Slap Bass 1 Slap Bass 2 Synth Bass 1 Synth Bass 2

Str. E nsembl e 1 Str. E nsembl e 2 Synth Strings 1 Synth Strings 2 Choir Aahs Voice Oohs Synth Voice Orchestra Hit

59 Fun & Games

Category

Guitars

Stri ngs 1

Brasses

Tone

Nylon Guitar Steel Guitar Jazz Guitar Clean Guitar Muted Guitar Overdriven Gtr. Distortion Gtr. Gtr. Harmonics

Violin Viola Cello Contrabass Tremolo Strings Pizz. Strings Harp Timpani

Trumpet Trombone Tuba Muted Trumpet French Horn Brass Section Synth Brass 1 Synth Brass 2

Category

Reeds

Synth Leads

Synth Effects

Ton e Soprano Sax

Alto Sax Tenor Sax Baritone Sax Oboe English Horn Bassoon Clarinet

Square Lead Sawtooth Lead Calliope Lead Chiff Lead Charang Lead Voice Lead Fifth Lead Bass & Lead

Rain Soundtrack Crystal Atmosphere Brightness Goblins Echoes Science Fiction

Category

Flutes/ Pipes

Synth Pads

Ethnics

Tone

Piccolo Flute Recorder Pan Flute Blown Bottle Shakuhachi Whistle Ocarina

New Age Pad Warm Pad Polysynth Pad Choir Pad Bowed Pad Metallic Pad Halo Pad Sweep Pad

Sitar Banjo Shamisen Koto Kalimba Bagpipe Fiddle Shanai

Ton e

Category

Tinkle Bell Agogo Steel Drums Woodblock

Percussio

Tai ko Dru ms

Melodic Tom Synth Drum Reverse Cymbal

Original 1 (Piano)* Original 2 (Glockenspiel)*

Original

Original 3 (Reed Organ)* Original 4 (Nylon Guitar)* Original 5 (Violin)*

* The default setting tone.

To create your original tone, see “Creating Your Original Tone” on page 64.

Category

Effects

Tone

Gtr. Fret Noise Breath Noise Seashore Bird Tweet Telephone Ring Helicopter Applause Gunshot

Setting the Strength of the Original Ringing Tone

The strength of the original ringing tone can be set in 3 levels for each melody.

When you purchase this phone, the strength of the original ringing tone is set to “forte (Loud)”.

1. Perform steps 1 to 13 in “Creating Your Original

Ringing Tone” on page 55.

2. Press or to select “Strength Set”, then press

3. Select a strength of the tone by pressing or ,

then press . When “Play Current Chord” is selected, the original

ringing tone entered is played back in the selected strength of the tone.

4. Select “OK”, then press .

Now you can create an original ringing tone.

Deleting an Original Ringing Tone

Perform steps 1 to 4 in “Deleting Sounds” on page 48.

Editing Original Ringing Tones

1. Perform steps 1 to 3 in “Creating Your Original

Ringing Tone” on page 55.

2. Press or to select “Existing Melodies”, then

press .

Fun & Games 60

3. Press or to select an original ringing tone

you wish to edit, then press [Options]. The Options Menu is displayed.

4. Press or to select “Data Edit”, then press

5. Edit the title and press .

6. Press or to select a tempo, then press .

7. Press or to select the number of chords, then

press .

8. Select a note you wish to change by pressing or

, then edit notes.

For details on editing tones, see “Tone Editor” on page 62. When you add notes, enter the note correctly on the cursor. To delete a note, press [Clear] briefly.

Press and hold [Clear] to clear all tones.

9. When you finish editing, press [Options] to

display the Options Menu.

10.Select “Save”, then press .

11.Select “Save to Gallery”, then press .

12.Press or to select “Over Write”, then press

61 Fun & Games

The original ringing tone is changed. If you select “New”, the melody before the correction is not modified. The original ringing tone is registered as a new original ringing tone.

Note

• When the number of chords is modified in step 7, the confirmation screen may be displayed. When you select “Yes”, a section of the melody may be deleted.

• When you are going to add notes in step 8, you cannot add any notes if you have already entered 380 notes (for 8 chords melodies) or 190 notes (for 16 chords melodies).

Tip

• To delete the continuous melody, press [Options] and then press after selecting “DEL after Cursor” or “DEL before Cursor.” You can delete the melody after the cursor or before the Cursor.

Copying and Pasting Notes

You can copy and move a part of a melody to another position.

Only original ringing tones or editable melodies can be copied or moved.

1. Perform steps 1 to 7 in “Editing Original Ringing

Tones” on page 60.

2. Press [Options] to display the Options Menu.

3. Press or to select “Copy” or “Cut”, then

press .

4. Move the cursor to the first note to be copied or to

be cut and press .

5. Move the cursor to the last note to highlight the area

and press . The highlighted area will be saved temporarily in

the memory.

6. Press [Options] to display the Options Menu.

7. Press or to select “Paste”, then press .

8. Move the cursor to the point you wish to paste the

notes, then press . Saved notes are pasted.

Tone Editor

You can make a tone and use it for the original ringing tone.

Up to five types of tones can be registered respectively for 8 chords and 16 chords.

FM Sound Source

Various types of tones can be composed by combining the functions that generate one sine wave called an “Operator”. The combination of the operator is called an algorithm.

The operator acts as the modulator (modulating part) or the carrier (modulated part) depending on the algorithm.

• In each operator, various parameters such as multiple or envelope can be set.

• By setting the feedback to the specified operator, wider tone ranges can be created.

(M 3-4)

Fun & Games 62

Setting an Algorithm

Set the combination of the operator. Select from 4 types of combinations in 8 chords, and 2

types in 16 chords.

8 Chords

Algorithm3

Algorithm1

16 Chords

Algorithm4

Algorithm2

Algorithm5

Algorithm6

(Green number): The modulator (modulating part)

(White number): The carrier (modulated part)

63 Fun & Games

Setting the Operator

The meaning and content of the parameter that can be set to the operator is described below.

Parameter Meaning

Multiple (13 levels)

Envelope (Continuous /Decay)

Sustain (On/Off)

Key Scale Rate (2 levels)

Key Scale Level (4 levels)

Total Level (64 levels)

Attack Rate (15 levels)

When the value of the carrier is large, the sound becomes high. You can set various types of notes by changing th e values of the modulator.

This sets continuous sam e note or fade-out.

This sets a note to be sustained after completing the note. If yo u want to have a note with reverberation , set this function on.

Set the function to “2” if you want to a short note.

This function sets the rate of reducing the volume as a note become s higher.

In the carrier, the volume becom es large as this level becomes higher. In the modulator, the melody becomes brighter as this level becomes higher. The melody becomes softer as this level becomes smaller.

This sets the time from the beginning of the sound to the maximum volume.

Parameter Meaning

Decay Rate (16 levels)

Sustain Level (16 levels)

Release Rate (16 levels)

Wave Shape (8 types)

Vibrato (4 levels/ Off)

Tremolo (4 levels/ Off)

Feedback (8 levels)

This sets the time from the maxim um volume to the volume of the sustain level.

In sustaining note, this displays the volume of the sound that continues to produce. In fading-out note, this displays the volume when the note starts fading-out.

In sustaining note, this displays the sustaining time from note completion to no sound. In fading-out note, this displays the time from starting fade-ou t to no sound.

Select the basic wave type from eight types.

Type 1 Type 2 Typ e 3 Type 4

Type 5 Type 6 Type 7 Type 8

Set the vibrato. If the vibrato is used, select from 4 levels.

Set the tremolo. If the tremolo is used , select from 4 levels.

Set the level of modulation in the modulator feedback for Operator 1.

Set the Effect Frequency

Define the frequency of the vibrato or tremolo. The frequency becomes faster as the figure increases.

Creating Your Original Tone

1. Press to display the Main Menu.

2. Press or to select “Fun & Games”, then

press .

3. Press or to select “Tone Editor”, then press

4. Select “For 8 Chords” or “For 16 Chords” by

pressing or , then press .

5. Select the number you wish to register and press

6. Press or to select “Rename”, then press .

7. Enter the title.

Up to 16 characters can be entered. For details on entering characters, see “Entering Characters” on page 24.

8. Press .

9. Press or to select “Base Tone Set”, then

press .

10.Select a category of the tone by pressing or .

Fun & Games 64

11.Select a base tone by pressing or , then press

When “Confirm Tones” is selected, the syllable names are played back in the selected tone.

12.Select “OK”, then press .

13.Press or to select “Details Editor”, then

press .

14.Press or to select “Algorithm x”, then press

15.Select an algorithm you wish to set by pressing

or , then press . If you do not wish to change the operator, skip to

step 20.

16.Select an operator you wish to change by pressing

or , then press .

The basic note parameter is set in advance.

17.Select a parameter you wish to change by pressing

or .

18.Press or to change the content of the

parameter. For details of parameter, see pages 63 to 64. When you press , the syllable names are played

back in the selected content of the parameter.

65 Fun & Games

Repeat steps 17 and 18 to change another content of the parameter.

19.Press or to select “Setup End”, then press

If you do not wish to change the effect frequency, skip to step 22.

20.Press or to select “Effect Frequency”, then

press .

21.Select the effect frequency you wish to set by

pressing or , then press .

22.Press or to select “Details End”, then press

23.Press or to select “Save”, then press .

Your original tone is registered.

Profiles

You can easily alter the phone tone (e.g. the ringer volume, keypad tones, etc.) according to your environment.

Tone sound and vibration set can be customized for each profile.

There are 5 profiles including one user definable profile:

• Normal

• Meeting

• Activity

•Car

• Silent

(M 4)

Activating a Profile

1. Press to display the Main Menu.

2. Press or to select “Profiles”, then press .

3. Select the profile you wish to activate by pressing

or , then press .

4. Press or to select “Activate”, then press .

The profile will now be activated.

Note

• When a profile is set, the icon which corresponds to the profile name appears in the stand-by screen:

Normal: Is the default setup. (not displayed

Meeting: For use when discretion is needed. Activity: For use in busy environments. Car: For use in the car. (connected to a

Silent: For use when silence is needed.

Tip

• You can also activate a profile by pressing and holding for approximately 2 seconds instead of steps 1and 2.

in the stand-by screen)

hands free kit)

All sounds are muted and you are alerted to calls with the vibrator.

Customising Profiles

1. Perform steps 1 and 2 in “Activating a Profile”.

2. Select the profile you wish to customise by pressing

or , then press .

3. Press or to select “Edit”, then press .

4. Select the setting you wish to customise by pressing

or , then press .

Profiles 66

5. Change the setting you want.

For details about settings, see pages 67 to 71.

Resetting Profile Settings

1. Perform steps 1 and 2 in “Activating a Profile” on

page 66.

2. Select the profile you wish to reset by pressing

or , then press .

3. Press or to select “Edit”, then press .

4. Press or to select “Set to Default”, then

press .

5. Enter your handset code, then press .

6. Press or to select “Yes”, then press .

7. To cancel the resetting, select “No”, then press .

Note

• If you enter a wrong handset code in step 5, the screen returns to step 4.

67 Profiles

Ringer Volume

You can adjust the ringer volume to one of 5 levels. When it is set to “Silent”, the volume of games and

Java™ applications is muted.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Ringer Volume”, then

press . The current volume level is displayed.

3. Press to increase the ringer volume or press

to decrease the ringer volume and then press . To select “Step Tone”, press at level 5.

To select “Silent”, press at level 1.

Ringer Type

You can select the ringing tone from 30 tones including 5 patterns, 15 sound effects and 10 melodies. You can also select a sound in the Sound Gallery as the default ringing tone excluding the WAVE format.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Assign Melody”, then

press .

3. Press or to select “Preset Melody” or

“Sound Gallery”, followed by .

4. Select the ringing tone you wish to use by pressing

or .

If you wish to hear the demo, press [Play]. To stop playing, press [Stop].

5. When selection is complete, press .

Vibration

When the vibrator option is set to on, the phone will vibrate for incoming calls regardless of the ringer volume and tone settings.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Vibration”, then press

3. Press or to select “Enable”, “Disable” or

“Link to Sound”, then press .

Tip

• When “Link to Sound” is selected in step 3, melodies are synchronised with the vibrator for the ringing tone. However, this function may not work depending on data.

• When you select “Enable” or “Link to Sound” in step 3, “ ” appears on the stand-by screen.

Keypad Tones

When the keypad tone is set to on, you will hear a confirmation tone each time you press a numerical key.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Keypad Tones”, then

press .

3. Press or to select “On” or “Off”, then press

If you select “Off”, the screen returns to step 1.

4. Set “Volume”, then press .

5. Press to increase the volume or press to

decrease the volume, then press .

6. Press or to select “Melody”, then press .

7. Press or to select either “Preset Melody”,

“Sound Gallery” or “Default Tone”, then press .

Profiles 68

When you select “Preset Melody” or “Sound Gallery” in step 7:

8. Select the keypad tone.

For details on selecting a ringing tone, see “Ringer Type” on page 67.

9. Press or to select “Duration”, then press

10.Set the duration by pressing or , then press

Warning Tone

This function enables your phone to emit the warning tone when an error occurs.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Warning Tone”, then

press .

3. Press or to select “On” or “Off”, then press

If you select “Off”, the screen returns to step 1.

4. Select “Volume”, then press .

5. Press to increase the volume or press to

decrease the volume, then press .

69 Profiles

6. Press or to select “Melody”, then press .

7. Press or to select “Preset Melody” or

“Sound Gallery”, then press .

8. Select the warning tone.

For details on selecting a ringing tone, see “Ringer Type” on page 67.

9. Press or to select “Duration”, then press

10.Select the duration by pressing or , then

press .

Power On/Off Sound

You can set up to emit a sound and select the melody, volume and duration when the phone is turned on or off.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Power On Sound” or

“Power Off Sound”, then press .

3. Press or to select “On” or “Off”, then press

If you select “Off”, the screen returns to step 1.

4. Select “Volume”, then press .

5. Press to increase the volume or press to

decrease the volume and then press .

6. Press or to select “Melody”, then press .

7. Press or to select “Preset Melody” or

“Sound Gallery”, then press .

8. Select the ringing tone.

For details on selecting a ringing tone, see “Ringer Type” on page 67.

9. Press or to select “Duration”, then press

10.Enter the duration of ringing tone in 2 digits (01 to

10 seconds) using the digit keys, then press .

Message Alert

When receiving messages, special ring tones can be set.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Message Alert”, then

press .

3. Press or to select “MMS”, “SMS” or

“WAP”, then press .

4. Select “Volume”, then press .

5. Press to increase the volume or press to

decrease the volume and then press .

6. Press or to select “Melody”, then press .

7. Press or to select “Preset Melody” or

“Sound Gallery”, then press .

8. Select the ringing tone.

For details on selecting a ringing tone, see “Ringer Type” on page 67.

9. Press or to select “Vibration”, then press

10.Press or to select “Enable”, “Disable” or

“Link to Sound”, then press .

Profiles 70

11.Press or to select “Duration”, then press

12.Enter the duration of ring tone in 2 digits (01 to 99

seconds) using the digit keys, then press .

Low Battery Alert

Adjust the volume of the alarm when the battery becomes low.

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Press or to select “Low Battery Alert”, then

press .

3. Press to increase the volume or press to

decrease the volume and then press .

Any Key Answer

1. Perform steps 1 to 3 in “Customising Profiles” on

page 66.

2. Select “Any Key Answer”, then press .

3. Select “On” or “Off” by pressing or , then

press .

71 Profiles

Organiser

Calculator

The calculator function performs the 4 arithmetic calculations using up to 12 digits.

1. Press to display the Main Menu.

2. Press or to select “Organiser”, then press

3. Select “Calculator”, then press .

4. Select “Calculator”, then press .

The calculator appears on the display.

5. Key operations for calculation are as follows.

To enter a decimal point, press . To clear the entered number or operand, press [C]. To do the calculations, press .

(M 5)

(M 5-1)

6. If you wish to start a new calculation, press [C].

When calculation is complete, press .

Rate Conversion

You can also use the calculator as a currency calculator to convert from/to a home currency using a conversion rate that you enter.

To Set a Currency Conversion Rate (M 5-1-2)

1. Perform steps 1 to 3 in “Calculator”.

2. Press or to select “Exchange Rate”, then

press .

3. Press or to select “Foreign Domestic” or

“Domestic Foreign”, then press . To delete all digits, press [Clear].

4. Enter the currency conversion rate, then press .

To Convert a Value

1. Perform steps 1 to 4 in “Calculator”.

2. Enter the value to be converted, then press .

Organiser 72

3. Press or to select “In Domestic” or “In

Foreign”, then press . The result is displayed.

If you select “Exchange Rate” in step 3, you can set a currency conversion rate.

4. When calculation is complete, press .

Note

• You cannot perform step 2 when a sign of the four fundamental processes of arithmetic is displayed.

Calendar

The Calendar function helps you organise and manage your busy schedule. You can view the stored schedule on a monthly basis.

(M 5-2)

1. Press to display the Main Menu.

2. Press or to select “Organiser”, then press

3. Press or to select “Calendar”, then press

The current month will be displayed and current date will be highlighted.

4. Select the day for the schedule by pressing , ,

or , then press .

73 Organiser

5. Press or and select the note number, then

press .

6. Enter the schedule content, press .

Up to 3 schedule items can be stored. For details on entering characters, see “Entering Characters” on page 24. If you wish to add another item, repeat steps 5 and 6.

7. When you have finished entering, press [Back].

The screen returns to the calendar. Dates with scheduled tasks/meetings are underlined.

Note

• The calendar can be displayed for dates from January 2000 through to December 2099.

Find a Particular Date

You can move the view to a specified date in the calendar.

1. Press [Options] to display the Option Menu.

2. Select “Go to Date”, then press .

3. Enter the date of the calendar that you wish to

display, then press . The specified date is displayed.

Deleting Schedules

To Delete Schedule Items

1. Perform steps 1 to 3 in “Calendar” on page 73.

2. Select the day by pressing , , or , then

press .

3. Select the item you wish to delete by pressing or

, then press [Options].

The Options Menu is displayed.

4. Press or to select “Delete”, then press .

5. Select “1 Data”, then press .

6. Select “Yes”, then press .

To cancel deleting, select “No” at step 6, then press

To Delete All Scheduled Tasks/Meetings for a Specific Day

1. Perform steps 1 to 3 in “Calendar” on page 73.

2. Select the day you wish to delete by pressing ,

, or , then press [Options].

The Options Menu is displayed.

3. Press or to select “Delete”, then press .

4. Select “1 Day” to delete all contents for a day, then

press .

5. Select “Yes”, then press .

To cancel deleting, select “No” at step 5, then press

To Delete All Scheduled Entries

1. Perform steps 1 to 3 in “Calendar” on page 73.

2. Press [Options] to display the Options Menu.

3. Press or to select “Delete” to delete all

scheduled entries, then press .

4. Press or to select “All Data” to delete all

scheduled entries, then press .

5. Select “Yes”, then press .

To cancel deleting, select “No” at step 3, then press

Clock & Alarm

You need to set the correct time and date in order for your phone’s various time-based functions to work correctly.

Setting the Date and Time

(M 5-3)

(M 5-3-4)

1. Press to display the Main Menu.

2. Press or to select “Organiser”, then press

3. Press or to select “Clock & Alarm”, then

press .

Organiser 74

4. Press or to select “Set Date/Time”, then

press .

5. Enter the day, month, year and time using the digit

keys, then press . When you enter the time in a 12-hour clock format,

press and change am/pm. The order in which the date and time appears is based on the format setting. See “To Select the Date Format”.

To Select the Time System

1. Perform steps 1 to 3 in “Setting the Date and Time”

on page 74.

2. Press or to select “Clock Settings”, then

press .

3. Select “Time Format”, then press .

4. Press or to select “12 hour” or “24 hour”,

then press .

To Select the Date Format

The date format can be switched between “Day-MonthYear”, “Month-Day-Year” or “Year-Month-Day”.

1. Perform steps 1 to 3 in “Setting the Date and Time”

on page 74.

2. Press or to select “Clock Settings”, then

press .

75 Organiser

3. Press or to select “Date Format”, then press

4. Press or to select “D-M-Y”, “M-D-Y” or

“Y-M-D”, then press .

To Set the Clock Display

1. Perform steps 1 to 3 in “Setting the Date and Time”

on page 74.

2. Press or to select “Clock Settings”, then

press .

3. Press or to select “Display Format”, then

press .

4. Press or to select “Time Only”, “Date Only”

or “Date & Time”, then press . To set hide clock, select “Off” at step 4, then press

. When “Wallpaper” is set to “On”, the date is not displayed in the main screen.

To Set Daylight Saving Time

You can switch to daylight saving time without changing the clock time itself.

1. Perform steps 1 to 3 in “Setting the Date and Time”

on page 74.

2. Press or to select “Clock Settings”, then

press .

3. Press or to select “Daylight Saving”, then

press .

4. Press or to select “On”, then press .

Setting the Time Zone (M 5-3-3)

1. Perform steps 1 to 3 in “Setting the Date and Time”

on page 74.

2. Press or to select “Set Time Zone”,

then press .

3. Select “Change Zone”, then press .

4. Press or to set the home city, then press .

To Customise the Time Zone

1. Perform steps 1 to 3 in “Setting the Date and Time”

on page 74.

2. Press or to select “Set Time Zone”, then

press .

3. Press or to select “Set Custom Zone”, then

press .

4. Enter the time using the digit keys, then press .

Each press of switches - and +.

Setting Alarm

Alarm function allows you to be alerted at a specified time.

Note that the alarm may not function correctly if the clock has not been set.

(M 5-3-1)

1. Press to display the Main Menu.

2. Press or to select “Organiser”, then press

3. Press or to select “Clock & Alarm”, then

press .

4. Select “Set Alarm”, then press .

5. Select “List Alarms”, then press .

6. Press or to select the desired alarm number,

then press . Up to 5 alarm times can be specified.

7. Select “Set Time”, then press .

8. Enter the alarm time using the digit keys, then press

When you enter the alarm time in a 12-hour clock format, press and change am/pm.

9. Press or to select “Repeat Daily”, then press

Organiser 76

10.Press or to select “On” or “Off”, then press

11.Press or to select “Alarm Status”, then press

12.Press or to select “On”, then press .

13.Press [Save]

To Change the Type of Alarm Tone

1. Perform steps 1 to 6 in “Setting Alarm” on page 76.

2. Press or to select “Alarm Tone”, then press

3. Select “Melody”, then press .

4. Press or to select “Preset Melody” or

“Sound Gallery”, then press .

5. Select the alarm tone.

If you wish to hear the demo play, press [Play]. To stop playing, press [Stop].

6. When selection is complete, press .

77 Organiser

To Change the Vibration of Alarm

1. Perform steps 1 to 6 in “Setting Alarm” on page 76.

2. Press or to select “Alarm Tone”, then press

3. Press or to select “Vibration”, then press

4. Press or to select “Enable”, “Disable” or

“Link to Sound”, then press .

To Change the Duration of Alarm

1. Perform steps 1 to 10 in “Setting Alarm” on

page 76.

2. Press or to select “Alarm Tone”, then press

3. Press or to select “Duration”, then press

. The current duration is displayed.

4. Enter the length of the duration in 2 digits (02 to 59

seconds) using the digit keys, then press .

Changing Alarm Settings

1. Perform steps 1 to 5 in “Setting Alarm” on page 76.

2. Select the number you wish to change by pressing

or , then press .

3. Change Alarm settings.

For details on changing Alarm settings, see “To Change the Type of Alarm Tone” on page 77.

Disabling Alarm Function

1. Perform steps 1 and 2 in “Changing Alarm

Settings”.

2. Press or to select “Alarm Status”, then press

3. Press or to select “Off”, then press .

4. Press [Save]

“ ” disappears from the screen.

Resetting an Alarm Setting

1. Perform steps 1 to 5 in “Setting Alarm” on page 76.

2. Select the number you wish to reset by pressing

or , then press .

3. Press or to select “Reset Alarm”, then press

4. Press or to select “Yes”, then press .

Resetting All Alarm Settings

1. Perform steps 1 to 4 in “Setting Alarm” on page 76.

2. Press or to select “Reset Alarm”, then press

Press or to select “Yes”, then press .

Voice Memo

This allows you to record a voice message of up to 10 seconds, which can be used to remind you of schedule entries or be sent within an MMS. The recorded voice memo is registered in the Sound Gallery.

Recording a Voice Memo

(M 5-4)

1. Press to display the Main Menu.

Press or to select “Organiser ”, then press .

3. Press or to select “Voice Memo”, then press

Press to start recording. To stop recording before the recording time is over,

press [Stop]

Organiser 78

5. Select “Save” to save the voice memo, then press

If you wish to exit the voice memo, press [Exit], then select “Yes”.

Tip

• You can also record a voice memo by pressing and instead of steps 1 to 3.

• If you wish to record a voice memo again, select “Record Again” in step 5. The screen will return to step 4.

To Play Back the Saved Voice Memo

1. Perform steps 1 to 4 in “Recording a Voice Memo”

on page 78.

Press or to select “Playback”, then press .

Press . The recorded voice memo is played back. To stop playback, press [Stop].

79 Organiser

Help List

You can view the help list and use it to guide you in the phone’s functions.

(M 5-5)

1. Press to display the Main Menu.

Press or to select “Organiser”, then press .

3. Press or to select “Help List”, then press

The help list is displayed.

4. Check the key operation by pressing and .

5. When you have finished, press [Back].

Call Manager

Call Log

The phone will record the last 10 missed calls, received calls and dialled numbers.

Viewing Call Log

(M 6)

1. Press to display the Main Menu.

Press or to select “Call Manager”, then press

3. Press or to select “Call Register”, then press

4. Press or to select “Missed Calls”, “Received

Calls” or “Dialled Numbers”, then press . The selected call log list is displayed.

5. Select the number you wish to view by pressing

or .

6. Press [View].

Call record “1” is the most recent. When you press , call record “2” will be displayed. If you wish to dial the number, press .

7. When you have finished, press [Back] to return

to step 4.

Tip

• You can also confirm call records by pressing in stand-by mode.

• You can switch between histor ies by pressing or

in step 5 only when you ent er by in stand-by

mode.

Sending Messages

1. Perform steps 1 to 5 in “Viewing Call Log”.

2. Select the file name you wish to send by pressing

or , then press .

3. Press or to select “Send Message”, then

press .

4. Press or to select “MMS” or “SMS”, then

press .

5. Enter your message.

For details on creating a message, see “Creating a New MMS” on page 110 or “Creating a New SMS” on page 118.

Deleting Call Log

Deleting Single Call Record

1. Perform steps 1 to 5 in “Viewing Call Log”.

2. Press .

Press or to select “Del ete”, then press .

Call Manager 80

4. Press or to select “Yes”, then press .

The selected call record will be deleted. To cancel deletion, select “No” in step 4, then press

To Delete All Call Log (M 6-2-4)

1. Perform steps 1 to 3 in “Viewing Call Log” on

page 80.

2. Press or to select “Clear Logs”, then press

3. Select “All Calls”, then press .

4. Press or to select “Yes”, then press .

All call log records will be deleted. To cancel deleting, select “No” in step 4, then press

Tip

• If you select “Missed Calls”, “Received Calls” or “Dialled Numbers” in step 3, the call log in the selected category will be deleted.

81 Call Manager

Call Timers

This function lets you check the duration of your calls.

Checking the Duration of the Last Call

(M 6-2-5)

1. Press to display the Main Menu.

2. Press or to select “Call Manager”, then

press .

3. Press or to select “Call Register”, then press

4. Press or to select “Call Timers”, then press

5. Select “Last Call”, then press .

The duration of the last call is now displayed.

6. When you have finished, press [Back] to return

to call timers menu.

Checking the Total Call Time

1. Press or to select “All Calls”, then press

in step 5 in “Checking the Duration of the Last Call”.

2. When you have finished, press [Back].

Resetting All Call Timers

1. Perform steps 1 to 4 in “Checking the Duration of

the Last Call” on page 81.

2. Press or to select “Clear Timers”, then press

3. Press

4. Enter your handset code, then press .

to select “Yes”, then press .

To cancel resetting, select

The Call Timers are reset to zero.

“No”

, then press .

Call Costs

This function lets you check the charges for your calls. Charging Advice is not supported on all networks. Please check with your service provider for availability.

Checking the Cost of the Last Call

(M 6-2-6)

1. Press to display the Main Menu.

2. Press or to select “Call Manager”, then

press .

3. Press or to select “Call Register”, then press

4. Press or to select “Call Costs”, then press

5. Select “Last Call”, then press .

6. The cost of the last call is now displayed.

7. When you have finished, press [Back] to return

to call costs menu.

Checking the Total Call Cost

1. Press or to select “All Calls”, then press

in step 5 in “Checking the Cost of the Last Call”.

2. When you have finished, press [Back].

Call Manager 82

Setting the Charge Rate

Set the charge rate to calculate the call cost and set the maximum limit for call cost.

1. Perform steps 1 to 4 in “Checking the Cost of the

Last Call” on page 82.

2. Press or to select “Cost Units”, then press

3. Press or to select “Set Units”, then press

4. Enter your PIN2 code, then press .

5. Enter a cost per unit, then press .

To enter a decimal point, press .

6. Enter a currency unit (up to 3 characters), then press

[OK].

7. Press [OK].

83 Call Manager

Checking the Charge Rate

1. Select “Read Units”, then press at step 3 in

“Setting the Charge Rate”. The charge rate is now displayed.

2. When you have finished, press [Back].

Setting the Charge Limit

This function is useful if you wish to make sure you do not exceed a certain charge limit.

1. Perform steps 1 to 4 in “Checking the Cost of the

Last Call” on page 82.

2. Press or to select “Max Cost”, then press

3. Press or to select “Set Limit”, then press

4. Enter your PIN2 code, then press .

5. Enter a value, then press .

To enter a decimal point, press .

Checking the Charge Limit

1. Select “Read Limit”, then press at step 3 in

“Setting the Charge Limit”. The value of the charge limit is now displayed.

2. When you have finished, press [Back].

Resetting All Call Costs

1. Perform steps 1 to 4 in “Checking the Cost of the

Last Call” on page 82.

Press or to select

“Clear Costs”, then press

3. Press or to select “Yes”, then press .

To cancel resetti ng, select “No” , then press .

4. Enter your PIN2 code, then press .

The Call Costs are reset to zero.

Checking the Residual Credit

1. Perform steps 1 to 4 in “Checking the Cost of the

Last Call” on page 82.

2. Press or to select “Residual Credit”, then

press .

3. When you have finished, press [Back].

Data Counter

You can confirm the amount of bytes which you used in the GPRS transmission.

(M 6-2-7)

1. Press to display the Main Menu.

Press or to select “Call Manager”, then press

Press or to select “Call Register”, then press

Press or to select “Data Counter”, then press

5. Press or to select “Last Data” or “All Data”,

then press . You can now check the amount of bytes.

6. When you have finished, press [Back].

Resetting All Data Counter

1. Perform steps 1 to 4 in “Data Counter”.

Press or to select “Clear Counter”, then press

Press or to select “Yes”, then press . The Data Counter is reset to zero. To cancel

resetting,

select “No” at step 3, then press .

Call Manager 84

Diverts

This service is used to divert incoming calls to your voice mail system or to another number depending on certain conditions in which you cannot answer a call.

Divert Calls

(M 6-3)

1. Press to display the Main Menu.

2. Press or to select “Call Manager”,

then press .

3. Press or to select “Diverts”, then press

4. Select one of the divert options by pressing or

, then press .

The divert options available are:

• “All Calls”: Diverts all voice calls without

• “When Busy”:

•

“No Answer”

• “Not Reachable”: Diverts incoming calls when your

85 Call Manager

ringing. Diverts incoming calls when you are on a call.

: Diverts incoming calls if you do

not answer a call within a certain period of time.

phone is out of network service or switched off.

5. Select “On”, then press .

6. If you wish to divert calls to a number which is

located in the Phonebook, search for the desired Phonebook entry. Press or [Search] to search the number by name or press or to search in alphabetical order, then press . For details on searching the Phonebook entries, see “Finding a Name and Number” on page 32.

7. If you wish to divert calls to a number which you

can enter manually, enter the phone number.

8. Press .

If you select “No Answer” in step 4:

9. Enter the period of time using the digit keys (05 to

30 seconds), then press .

Note

• When a divert is set to “All Calls”, “ ” appears on the stand-by screen.

Tip

• If you select “By Service” in step 5, you can select the divert option further in the selected option in step 4.

Checking the Divert Status

1. Perform steps 1 to 3 in “Divert Calls” on page 85.

2. Select the divert option you wish to check by

pressing or , then press .

3. Press or to select “Status”, then press .

You can now check the status of the selected divert option.

4. When you have finished, press [Back].

Cancelling All Divert Settings

1. Perform steps 1 to 3 in “Divert Calls” on page 85.

2. Press or to select “Cancel All”, then press

3. Press or to select “Yes”, then press .

To cancel the resetting, select “No” in step 3, then press .

4. Press [OK].

All divert settings are cancelled.

To cancel the Divert Settings Individually

1. Perform steps 1 to 3 in “Divert Calls” on page 85.

2. Select the divert option you wish to cancel by

pressing or , then press .

3. Press or to select “Off”, then press .

4. Press [OK].

The selected divert has been cancelled.

Call Manager 86

Settings

Phone Settings

Changing the Language

You can change the display language that the phone uses for the display messages and text entry.

(M 7)

(M 7-1)

(M 7-1-1)

1. Press to display the Main Menu.

2. Press or to select “Settings”, then press .

3. Select “Phone Settings”, then press .

4. Select “Language”, then press .

5. Press or to select the desired language, then

press .

Wallpaper for the Stand-by Screen (M 7-1-2)

For the stand-by screen, an animation and 3 illustrations are provided.

Pictures taken with the digital camera or images downloaded from a WAP site can be used for wallpapers.

87 Settings

To Set Built-in Animations or Illustrations

1. Perform steps 1 to 3 in “Changing the Language”.

2. Press or to select “Wallpaper”, then press

3. Press or to select “On”, then press .

4. Select “Animation” or “Illustration 1” to

“Illustration 3” by pressing or , then press

5. Press again to set.

The selected animation or illustration is displayed on the stand-by screen.

Note

• Even if an animation is selected, the stand-by screen displays a static picture/image when you do not operate the phone for about 30 seconds (It is different according to the selected data).

Tip

• To cancel the Wallpaper setting, select “Off” in step

To Set Image Gallery for the Stand-by Screen

1. Perform steps 1 to 3 in “To Set Built-in Animations

or Illustrations” on page 87.

2. Press or to select “Original”, then press .

The file names of the pictures/images that are registered in the Image Gallery is displayed.

3. Select the picture/image by pressing or ,

then press . The selected picture/image is displayed.

4. Specify the range for displaying the picture/image

by pressing , , or , then press . The selected picture/image is displayed on the

stand-by screen.

Note

• Some pictures/images cannot be used because of their picture/image and data types.

Backlight (M 7-1-3)

You can turn the backlight of the main screen display on or off when you press the keypad or the optional cigarette lighter charger is connected to the phone.

You can change or specify t he amount of time the backlight is ON for , which will help conserve batte ry life.

To Turn On/Off the Backlight

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “Backlight”, then press

3. Press or to select “On/Off”, then press .

4. Select “On” to set backlight on or “Off” to set

backlight off by pressing or , then press .

When you select “On” in step 4:

5. Enter the duration of the backlight using 2 digits,

then press .

To Turn On/Off the Backlight whilst Charging with the Cigarette Lighter Charger

1. Perform steps 1 and 2 in “To Turn On/Off the

Backlight”.

2. Press or to select “In Car”, then press .

3. Select “On” to set backlight on or “Off” to set

backlight off by pressing or , then press .

Settings 88

Adjust the Brightness of the Backlight (M 7-1-4)

You can adjust the brightness of the backlight of the main screen display at four levels.

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “Brightness”, then press

3. Press (Light) or (Dark) to adjust the

brightness for maximum clarity.

4. Press .

Note

• The brightness of the backlight does not affect the brightness of the Sub-Screen.

Display Saving (M 7-1-5)

This phone’s screen will automatically turn off after a given amount of time if the phone is left open. This is in order to conserve battery life.

You can change the time the Display Saving will go into effect works between 2 and 20 minutes or disable this function.

Tip

• When you purchase this phone, the Display Saving is set to work 10 minutes later.

89 Settings

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “Display Saving”, then

press .

3. Select “On” to set the Display Saving function on or

“Off” to set it off by pressing or , then press

When you select “On” in step 3:

4. Enter the time until the Display Saving works in two

digits (02 to 20 minutes) using the digit keys, then press .

Note

• The Display Saving does not work whilst you are calling, using WAP, or use a Java™ application.

To Cancel the Display Saving Function

The display saving continues until either a key is pressed or there is an incoming alert. The first key press will only cancel the display saver. You must press another key in order to input any numerical or text value.

Setting the Greeting Message (M 7-1-6)

You can set the message which will appear when the phone is turned on.

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “Greeting Message”, then

press .

3. Press or to select “On”, then press .

4. Enter the message, then press .

Up to 16 characters can be stored as a message. For details on entering characters, see “Entering Characters” on page 24.

Tip

• To cancel the Greeting Message setting, select “Off” in step 3.

Assign Images (M 7-1-7)

Pictures/images can be displayed when turning the power on or off, when receiving an incoming call, or when operating the alarm.

Pictures taken by a digital camera or images downloaded from a WAP site can be used.

To Set Built-in Pictures/Images

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “Assign Images”, then

press .

3. Select the screen to set the picture/image by

pressing or , then press .

4. Select “Animation 1” or “Animation 2” by pressing

or , then press . or Select “Illustration 1” or “Illustration 2” by pressing

or , then press when you select “Alarm” in step 3. The selected picture/image is displayed.

5. Press .

Tip

• To cancel the picture/image setting, select “Set to Default” in step 4.

To Set Image Gallery

1. Perform steps 1 to 3 in “To Set Built-in Pictures/

Images”.

2. Press or to select “Original”, then press .

The file name of the pictures/images that are registered in the Image Gallery is displayed.

Settings 90

3. Select the picture/image by pressing or ,

then press . The selected picture/image is displayed.

4. Specify the range for displaying the picture/image

by pressing , , or , then press .

Note

• Some pictures/images cannot be used because of their picture/image and data types.

External Display (M7-1-8)

You can change the settings of the Sub-Screen Display.

To Turn On/Off the Sub-Screen Display

You can turn the Sub-Screen Display on or off when the phone is closed.

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “External Display”,

then press .

3. Press or to select “LCD On/Off”, then press

4. Select “On” to set Sub-Screen Display on or “Off”

to set Sub-Screen Display off by pressing or

, then press .

91 Settings

To Turn On/Off the Backlight of the Sub-Screen Display

You can turn the backlight of the Sub-Screen Display on or off when the phone is closed.

You can also change or specify the duration of the SubScreen Display backlight.

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “External Display”,

then press .

3. Press or to select “Backlight”, then press

4. Select “On” to set backlight on or “Off” to set

backlight off by pressing or , then press .

When you select “On” in step 4:

5. Enter the duration of the backlight using 2 digits,

then press .

To Adjust the LCD Contrast of the Sub-Screen

You may sometimes need to adjust the LCD contrast of the Sub-Screen to suit certain lighting conditions.

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “External Display”,

then press .

3. Press or to select “LCD Contrast”,

then press .

4. Press (Dark) or (Light) to adjust the contrast

for maximum clarity. LCD contrast can be adjusted in 9 levels.

5. Press .

Phone Setting Reset (M 7-1-9)

The phone settings can be reset to their default settings.

1. Perform steps 1 to 3 in “Changing the Language” on

page 87.

2. Press or to select “Set to Default”, then

press .

3. Enter your handset code, then press .

4. Press or to select “Yes”, then press .

To cancel resetting, select “No” in step 4, then press

All phone settings are reset.

Note

• If you enter a wrong handset code in step 3, operation is cancelled.

Call Settings

Set various types of functions and services.

Call Waiting

If you wish to be able to receive another incoming call whilst you have a call in progress, you must activate the Call Waiting service.

(M 7-2)

(M 7-2-1)

1. Press to display the Main Menu.

2. Press or to select “Settings”, then press .

3. Press or to select “Call Settings”, then press

4. Select “Call Waiting”, then press .

5. Select “On” to activate the Call Waiting service or

“Off” to deactivate it by pressing or , then press .

6. Press [OK].

Note

• Call Waiting service may not be available on all mobile phone networks. Contact your network operator for more information.

Settings 92

To Check the Call Waiting Service Status

1. Perform steps 1 to 4 in “Call Waiting” on page 92.

2. Press or to select “Status”, then press .

Now you can check the status of the Call Waiting service.

3. Press [Back].

Display Call Timers (M 7-2-2)

1. Perform steps 1 to 3 in “Call Waiting” on page 92.

2. Press or to select “Display Call Timers”,

then press .

3. Select “On” or “Off” by pressing or , then

press .

93 Settings

Personal Call (M 7-2-3)

A specified ringing tone or vibrator setting can be associated to a pre-registered phone number.

Up to 20 phone numbers can be registered.

1. Perform steps 1 to 3 in “Call Waiting” on page 92.

2. Press or to select “Personal Call”, then press

3. Select the number you wish to set by pressing or

, then press .

4. Enter the phone number, then press .

If you wish to select the phone number in the Phonebook, search for the desired Phonebook entry. Press or [Search] to search the number by name or press or to search in alphabetical order, then press . For details on searching the Phonebook entries, see “Finding a Name and Number” on page 32.

5. Press or to select “Assign Melody”, then

press .

6. Select a ringing tone.

For details on selecting a ringing tone, see “Ringer Type” on page 67.

7. Press or to select “Vibration”, then press

8. Press or to select “Enable”, “Disable” or

“Link to Sound”, then press . For details on setting the vibrator, see “Vibration”

on page 68.

9. When setting is complete, select “Setup End”, then

press .

Group Call (M 7-2-4)

Phone numbers can be registered or updated in groups.

To Set Group Ringing Tone

Different ringing tones can be set for each group. When you purchase this phone, groups are set to off. If you do not set a group ringing tone the default ringing

tone will be used.

1. Perform steps 1 to 3 in “Call Waiting” on page 92.

2. Press or to select “Group Call”, then press

3. Select the group you want to set by pressing

or , then press .

4. Press or to select “On”, then press .

5. Press or to select “Assign Melody”, then

press .

6. Select a ringing tone.

For details on selecting a ringing tone, see “Ringer Type” on page 67.

7. Press or to select “Vibration”, then press

Settings 94

8. Press or to select “Enable”, “Disable” or

“Link to Sound”, then press . For details on setting the vibration, see “Vibration”

on page 68.

9. When setting is complete, select “Setup End”, then

press .

Tip

• To cancel the ringing tone setting, select “Off” in step 4.

Auto Redial (M 7-2-5)

See “Automatic Redialling” on page 20 about this function.

Minute Minder (M 7-2-6)

Minute Minder function informs you of your talk time by sounding a tone after every minute.

1. Perform steps 1 to 3 in “Call Waiting” on page 92.

2. Press or to select “Minute Minder”, then

press .

3. Press or to select “On” or “Off”, then press

95 Settings

Call Setting Reset (M 7-2-7)

The call settings can be reset to their default settings.

1. Perform steps 1 to 3 in “Call Waiting” on page 92.

2. Press or to select “Set to Default”, then

press .

3. Enter your handset code, then press .

4. Press or to select “Yes”, then press .

To cancel resetting, select “No” at step 4, then press

All call settings are reset.

Note

• If you enter the wrong handset code in step 3, the operation is cancelled and the screen returns to step 3 in “Call Waiting” on page 92.

Network Settings

Selecting a Network Automatically

Each time the power is turned on, your phone will always try to connect first to the most recently available network, then to the subscribed network, and lastly to the preferred network.

If none of these are found, it will then search for any other available GSM networks.

(M 7-3)

(M 7-3-1)

1. Press to display the Main Menu.

2. Press or to select “Settings”, then press .

3. Press or to select “Network Settings”, then

press .

4. Select “Select Network”, then press .

5. Select “Automatic”, then press .

To Set the Network Manually

1. As in step 5 in “Selecting a Network

Automatically”, press or to select “Manual”, then press .

2. Select the network from the list by pressing or

, then press .

Adding a New Network

1. Perform steps 1 to 4 in “Selecting a Network

Automatically”.

2. Press or to select “Add New Network”, then

press .

3. Press or to select “Add”, then press .

4. Enter the country code.

5. Press .

6. Enter the network code.

7. Press .

8. Enter a new network name.

9. Press [OK].

Editing the Preferred List

To Change the Position of a Network in the Preferred List

1. Perform steps 1 to 4 in “Selecting a Network

Automatically”.

2. Press or to select “Set Preferred”, then press

3. Select the name of the network to change the

position from the list by pressing or , then press .

Settings 96

4. Press or to select “Insert” or “Add to End”,

then press .

To Delete a Network from the Preferred List

1. Perform steps 1 to 3 in “To Change the Position of

a Network in the Preferred List” on page 96.

2. Press or to select “Delete”, then press .

Changing the Network Password

(M 7-3-2)

1. Perform steps 1 to 3 in “Selecting a Network

Automatically” on page 96.

2. Press or to select “Change Password”, then

press .

3. Enter the old password, then press .

4. Enter a new password, then press .

5. Enter a new password again, then press .

If you enter the incorrect password in step 5, the screen will return to step 4 and you will be asked to enter the password again.

6. Press .

97 Settings

Internet Settings

WAP/MMS Settings

WAP Settings and MMS Settings can perform following various setups, respectively.

(M 7-4)

WAP Settings

Item Description Operation

Profile Name*

IP Address* IP add ress

Homepage Homepage

Port Number*

WAP Profile Name (Unique Name)

Security Option

Select “Profile Name” and press .

Enter the strings you like and press .

Select “IP Address” and press .

Enter IP address for WAP and press . Select “Homepage” an d press .

Enter Homepage URL, if needed, and press . Select “Port Number ” and press .

Enter Port Number (1024-

65535) and press .

Item Description Operation

Circuit Prompt Circuit Prompt

Connection Type

GPRS Settings (If “GPRS Then CSD” or “GPRS” will be selected as connection type, they should be set)

APN*

UserName User Name

Bearer Connection Typ e

Access Point Name

Select “Circuit Prompt” and press .

Select “Enable” or “Dis able” and press . Select “Connection Type” and press .

Select “GPRS Then CSD”, “GPRS” or “CSD” and press

Select “APN” and press

Enter Access Point Name and press . Select “UserName” and press .

Enter User Name and press

Item Description Operation

Password Password

Linger Time Linger Time

CSD Settings (If “GPRS Then CSD” or “C SD” will be selected as connection type, they should be set)

Phone No.*

Line Type

UserName User Name

Access Point Number

ISDN or Analogue

Select “Password” and press .

Enter Password and press

. Select “Linger Time” and press .

Enter second time (0-

99999) and press .

Select “Phone No .” and press .

Enter Access Point Number and press . Select “Line Type” and press .

Select “ISDN” or “ Analogue” and press . Select “UserName” and press .

Enter User Name and press

Settings 98

Item Description Operation

Password Password

Linger Time Linger Time

Select “Password” and press .

Enter Password and p ress

Select “Linger Time” and press .

Enter second time (0-

99999) and press .

*: Item to be set as mandatory.

MMS Settings

Item Description Operation

Profile Name*

IP Address* IP address

MMS Profile Name (Unique Name)

99 Settings

Select “P rofile Name” and press .

Enter the strings you like and press . Select “IP Address” and press .

Enter IP address for MMS and press .

Item Description Operation

Relay Server

URL*

Port Number*

Connection Type

GPRS Settings (If “GPRS Then CSD” or “GPRS” will be selected as connection type, they should be set)

APN*

MMS Relay Server

Security Option

Bearer Connection Typ e

Access Point Name

Select “Relay Server URL” and press .

Enter URL of the Relay Server and press . Select “Port Number ” and press .

Enter Port Number (1024-

65535) and press . Select “Connection Type” and press .

Select “GPRS Then CSD”, “GPRS” or “CSD” and press

Select “APN” and pr ess

Enter Access Point Name and press .

Item Description Operation

Username User Name

Password Password

Linger Time Linger Time

CSD Settings (If “GPRS Then CSD” or “CSD” will be selected as connection type, they should be set)

Phone No.*

Line Type

Access Point Number

ISDN or Analogue

Select “UserName” and press .

Enter User Name and press

. Select “Password” and press .

Enter Password and press

. Select “Linger Time” and press .

Enter second time ( 0-

99999) and press .

Select “Phone No.” a nd press .

Enter Access Point Number and press . Select “Line Type” and press .

Select “ISDN” or “A nalogue” and press .

Item Description Operation

Username User Name

Password Password

Linger Time Linger Time

Select “UserName” and press .

Enter User Name and press

Select “Password” and press .

Enter Password and press

Select “Linger Time” and press .

Enter second time (0-

99999) and press .

*: Item to be set as mandatory.

Settings 100

Sharp GX-12 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Useful functions and services of the phone

Table of Contents

Your Phone

Accessory

Getting Started

Inserting the SIM Card and the Battery

Charging the Battery

Turning Your Phone On and Off

Display Indicators

Sub-Screen

Call Functions

Making a Call

Speed Dialling

Redialling

Ending a Call

Answering a Call

Incall Menus

Entering Characters

Phonebook

Creating a New Entry

Finding a Name and Number

Editing Phonebook Entries

Deleting Phonebook Entries

Checking Your Own Numbers

View Groups

Memory Status

Speed Dial List

Sending Messages

Using the Menu

List of Menu Functions

Camera

Using the Timer

Sending Pictures

Deleting Pictures

My Phone

Java™

Java™ Gallery

Image Gallery

Sound Gallery

Text Templates

Memory Status

Fun & Games

Java™

Games

Melody Editor

Tone Editor

Profiles

Activating a Profile

Customising Profiles

Resetting Profile Settings

Ringer Volume

Ringer Type

Vibration

Keypad Tones

Warning Tone

Power On/Off Sound

Message Alert

Low Battery Alert

Any Key Answer

Organiser

Calculator

Calendar

Clock & Alarm

Voice Memo

Help List

Call Manager

Call Log

Call Timers

Call Costs

Data Counter

Diverts

Settings

Phone Settings

Call Settings

Network Settings
