Sharp EL-1611E Operating Manual
ELECTRONIC PRINTING CALCULATOR
DRUCKENDER TISCHRECHNER
CALCULATRICE IMPRIMANTE ÉLECTRONIQUE
CALCULADORA IMPRESORA ELECTRONICA
CALCOLATRICE ELETTRONICA STAMPANTE
ELEKTRONISK SKRIVANDE OCH VISANDE RÄKNARE
ELEKTRONISCHE REKENMACHINE MET AFDRUK
EL-1611E
ENGLISH ......................................... Page 1
DEUTSCH........................................ Seite 12
FRANÇAIS....................................... Page 23
ESPAÑOL ........................................ Página 34
98305_EL-1611E(LC7)_Cover.pm65 0.3.6, 1:37 PM1
ITALIANO......................................... Pagina 45
SVENSKA ........................................ Sida 56
NEDERLANDS ................................ Pagina 67
OPERATION MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE MANEJO
MANUALE DI ISTRUZIONI
BRUKSANVISNING
GEBRUIKSAANWIJZING
This equipment complies with the requirements of Directive 89/336/EEC as amended by 93/68/EEC.
Dieses Gerät entspricht den Anforderungen der EG-Richtlinie 89/336/EWG mit Änderung 93/68/EWG.
Ce matériel répond aux exigences contenues dans la directive 89/336/CEE modifiée par la directive
93/68/CEE.
Dit apparaat voldoet aan de eisen van de richtlijn 89/336/EEG, gewijzigd door 93/68/EEG.
Dette udstyr overholder kravene i direktiv nr. 89/336/EEC med tillæg nr. 93/68/EEC.
Quest’ apparecchio è conforme ai requisiti della direttiva 89/336/EEC come emendata dalla direttiva
93/68/EEC.
89/336/,
! "! ! "#$ ! 93/68/.
Este equipamento obedece às exigências da directiva 89/336/CEE na sua versão corrigida pela directiva
93/68/CEE.
Este aparato satisface las exigencias de la Directiva 89/336/CEE modificada por medio de la 93/68/CEE.
Denna utrustning uppfyller kraven enligt riktlinjen 89/336/EEC så som kompletteras av 93/68/EEC.
Dette produktet oppfyller betingelsene i direktivet 89/336/EEC i endringen 93/68/EEC.
Tämä laite täyttää direktiivin 89/336/EEC vaatimukset, jota on muutettu direktiivillä 93/68/EEC.
98305_EL-1611E(LC7)_Cover.pm65 0.3.6, 1:37 PM2
ENGLISH
OPERATIONAL NOTES
Thank you for your purchase of the SHARP electronic printing
calculator, model EL-1611E.
To insure trouble-free operation of your SHARP calculator, we
recommend the following:
1. The calculator should be kept in areas free from extreme
temperature changes, moisture, and dust.
2. A soft, dry cloth should be used to clean the calculator. Do not
use solvents or a wet cloth.
3. Since this product is not waterproof, do not use it or store it
where fluids, for example water, can splash onto it. Raindrops,
water spray, juice,coffee, steam, perspiration, etc. will also cause
malfunction.
4. If service should be required, use only a SHARP servicing dealer,
a SHARP approved service facility or SHARP repair service.
5. If you pull out the power cord to cut electricity completely or
replace the batteries, the presently stored exchange rate will be
cleared.
98305_EL-1611E(LC7)_Eng.pm65 0.3.6, 1:24 PM1
CONTENTS
Page
OPERATING CONTROLS ........................................................ 2
INK ROLLER REPLACEMENT................................................. 3
PAPER ROLL REPLACEMENT................................................ 5
POWER SUPPLY ..................................................................... 7
ERRORS................................................................................... 9
SPECIFICATIONS .................................................................... 10
RESETTING THE UNIT ............................................................ 11
CALCULATION EXAMPLES ..................................................... 78
EURO CURRENCY TABLE ...................................................... 86
1
ON
OPERATING CONTROLS
POWER ON KEY / CLEAR / CLEAR ENTRY KEY:
C·CE
Clear - This key also serves as a clear key for the calculation
register and resets an error condition.
Clear entry - When pressed after a number and before a
function, clear the number.
OFF
POWER OFF KEY:
When this key is pressed, the power is turned off.
P
PRINT KEY:
To save paper you can only print what is displayed, even in
non-print mode.
Pressing
with the symbol “#” even in non-printing mode.
Pressing
as a code, date, etc. Separators are displayed as a period
and dashes but printed as periods.
P/NP
+
M
MEMORY + KEY / PRINT ON / OFF KEY:
Pressing
Causes the calculator to operate in a display / print or display
2
98305_EL-1611E(LC7)_Eng.pm65 0.3.6, 1:24 PM2
P
after the entry of a number will print the entry
•
will insert a separator into a number entry such
P/NP
2nd
selects print mode or non-print mode.
only mode, depending upon the calculator’s present state.
“P” on the display: Print mode.
“NP” on the display: Non-print mode.
DEC
–
M
MEMORY – KEY / DECIMAL SELECTION KEY:
Pressing
DEC
2nd
sets the number of decimal places in the
result.
→ F → 3 → 2 → 1 → 0 → A
“F” on the display:
The answer is displayed in the floating decimal system.
“3, 2, 1, 0” on the display:
Presets the number of decimal places in the answer.
“A” on the display (Add mode):
The decimal point in addition and subtraction entries is
automatically positioned to the 2nd digit from the lowest
digit of entry number. Use of the add mode permits addition
and subtraction of numbers without entry of the decimal
point. Use of
•
, × and ÷ will automatically override
the add mode and decimally correct answers will be
printed.
CONVERSION KEY (TO THE EURO CURRENCY) :
RATE SET
CONVERSION KEY (TO A NATIONAL CURRENCY) /
CONVERSION RATE SETTING KEY:
Y ou can set the exchange rate by pressing
maximum of 6 digits excluding the decimal point can be stored
as the exchange rate.)
2nd FUNCTION KEY :
2nd
T o use the functions shown above the keys, such as “DEC”,
press the
will appear at the top of the display.)
Example: To change decimal place setting from F to 2
PAPER FEED KEY:
When pressed, the paper tape advances.
2nd
key first. (When the
2nd DEC, 2nd DEC
DISPLAY:
F: Floating decimal mode
3, 2, 1, 0: Preset decimal mode
A: Add mode
P: Print mode
NP: Non-print mode
2nd
functions are available
2nd:
98305_EL-1611E(LC7)_Eng.pm65 0.3.6, 1:24 PM3
2nd RATE SET
2nd
key is pressed, “2nd”
: Euro Currency Symbol
: National Currency Symbol
M: Memory
–: Minus
E: Error
• For illustration purposes, all the relevant symbols are visible in
the display above. However, in actual use, this would never
. (A
happen.
INK ROLLER REPLACEMENT
If printing is blurry even when the ink roller is in the proper position,
replace the roller.
Ink roller: Type EA-732R
WARNING
APPLYING INK TO WORN INK ROLLER OR USE OF
UNAPPROVED INK ROLLER MAY CAUSE SERIOUS DAMAGE
TO PRINTER.
1) Turn the power off.
2) Remove the printer cover. (Fig. 1)
3) Remove the ink roller by turning it counterclockwise and pulling
it upward (Fig. 2)
4) Install new ink roller and press it in the correct position. Make
sure that the ink roller is securely in place. (Fig. 3)
5) Put back the printer cover.
3
Fig. 1
Fig. 2
4
98305_EL-1611E(LC7)_Eng.pm65 0.3.6, 1:24 PM4
Fig. 3
Cleaning the printing mechanism
If the print becomes dull after long time usage, clean the
printing wheel according to the following procedures:
1) Remove the printer cover and the ink roller.
2) Install the paper roll and feed it until it comes out of the front of
the printing mechanism.
3) Put a small brush (like a tooth brush) lightly to the printing wheel
and clean it by pressing
.
4) Put back the ink roller and the printer cover.
Notes: • Never attempt to turn the printing belt or restrict its
movement while printing. This may cause incorrect printing.
• Do not rotate the printing mechanism manually, this may
damage the printer.
PAPER ROLL REPLACEMENT
Never insert paper roll if torn. Doing so will cause paper to jam. Always cut leading edge with scissors first.
♦ When using the paper that is less than or equals to 25 mm (31/32") in outside diameter:
Paper roll : Type EA-7100P
STEP 1
leading edge
Paper
cutter
STEP 4
98305_EL-1611E(LC7)_Eng.pm65 0.3.6, 1:24 PM5
STEP 2
Note: Paper tape replacement rolls are available where the EL-1611E calculator is sold.
STEP 3
5
