SHARP EBR-2610, EBR-2612, EBR-2620, EBR-2622 User Manual

Built-in Kit Instructions Built-in Kit Instructions Built-in Kit Instructions Built-in Kit Instructions Built-in Kit Instructions

EBR-2610 / EBR-2612 / EBR-2620 / EBR-2622

CONTENTS / CONTENTS / CONTENTS /

CONTENTS / CONTENTS /

Legend / Legend / Legend / Legend / Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation Instructions / Installation Instructions / Installation Instructions /

Installation Instructions / Installation Instructions / . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 7

Installation Diagrams / Installation Diagrams / Installation Diagrams /

Installation Diagrams / Installation Diagrams / . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Gedruckt in Grossbritannien

Imprimé au Royaume-Uni

Gedrukt in Groot-Brittannie

Stampato in Gran Bretagna

Impreso en el Reino Unido

SHARP ELECTRONICS (EUROPE) GMBH. Sonninstrasse 3, 20097 Hamburg Germany

TINS-A279URR0

R-2B34 B/I/K English 5/4/01 9:49 am Page 1

LEGEND / LEGEND / LEGEND / LEGEND / LEGEND

Reference Part Name / Part Name / Part Name / Part Name / Part Name No. of Pieces

Built-in Frame (supplied complete) / Built-in Frame (supplied complete) / Built-in Frame (supplied complete) / Built-in Frame (supplied complete) / Built-in Frame (supplied complete) 1

Oven Runners / Oven Runners / Oven Runners / Oven Runners / Oven Runners 2

Top Mounting Brackets / Top Mounting Brackets / Top Mounting Brackets / Top Mounting Brackets / Top Mounting Brackets 2

Air Seperator Cushion / Air Seperator Cushion / Air Seperator Cushion / Air Seperator Cushion / Air Seperator Cushion 1

Fixing Screws (Long) / Fixing Screws (Long) / Fixing Screws (Long) / Fixing Screws (Long) / Fixing Screws (Long) 8

Fixing Screws (Short) / Fixing Screws (Short) / Fixing Screws (Short) / Fixing Screws (Short) / Fixing Screws (Short) 2

Microwave Oven / Microwave Oven / Microwave Oven / Microwave Oven / Microwave Oven

Ventilation Gap / Ventilation Gap / Ventilation Gap / Ventilation Gap / Ventilation Gap

Oven Runners Recess / Oven Runners Recess / Oven Runners Recess / Oven Runners Recess / Oven Runners Recess

Power Supply Cord / Power Supply Cord / Power Supply Cord / Power Supply Cord / Power Supply Cord

Microwave Oven Foot / Microwave Oven Foot / Microwave Oven Foot / Microwave Oven Foot / Microwave Oven Foot

Back Wall of Cupboard / Back Wall of Cupboard / Back Wall of Cupboard / Back Wall of Cupboard / Back Wall of Cupboard

Ventilation Gap (Shelf) / Ventilation Gap (Shelf) / Ventilation Gap (Shelf) / Ventilation Gap (Shelf) / Ventilation Gap (Shelf)

Air Inlet Holes / Air Inlet Holes / Air Inlet Holes / Air Inlet Holes / Air Inlet Holes

Instruction Manual / Instruction Manual / Instruction Manual / Instruction Manual / Instruction Manual 1

R-2B34 B/I/K English 5/4/01 9:49 am Page 2

INSTALLATION INSTRUCTIONS

For Safety Warnings & Operating Instructions of oven (R-2B34) refer to the Operation Manual included inside the oven.

Refer to the Installation Diagrams on page 8.

1. The mains plug must be accessible after installation or the oven must be connected to an electric circuit provided with an all-pole switch (contact gap no less than 3 mm) to disconnect the oven in case of danger. A safety-device like a fuse in the installation may be used as a switch.

2. Remove the built-in kit mounting brackets from the package.

3. EBR-2610/EBR-2612 (500 mm cupboard) (Fig. 1, page 8) Position the two oven runners (B) with the front hooked over the front edge of the shelf and pressed against the right and left walls of the kitchen cabinet.

EBR-2620/EBR-2622 (600 mm cupboard) (Fig. 2, page 8) Position the two oven runners (B) with the front hooked over the front edge of the shelf and using the top mounting brackets (C) as spacers, press against the right and left walls of the kitchen cabinet.

Attach the oven runners with the four screws (E) as shown in Figs. 1 and 2 (page 8).

4. Attach the two top mounting brackets (C) to the ceiling of the kitchen cabinet with the two tabs firmly pressed against the front face, as shown in Figs. 1 and 2 (page 8). Secure each bracket with two screws (E).

5. Remove adhesive protection and attach the cushion (D) to the rear of the oven, as shown in Fig. 3 (page 8). FIT CLOSE TO, BUT DO NOT COVER THE AIR INLET HOLES (8) ON THE REAR OF THE OVEN.

6. Place the oven (1) onto the oven runners (B). Locate the front feet (5) into the recess of the oven runners (3) as shown in Fig. 5 (page 8).

7. Connect the oven to the power supply. Caution: Make sure that the power supply cord (4) does not cross over the cushion (D) as shown in Fig. 3 (page 8).

8. Place the built-in frame (A) over the oven (1) and engage the top mounting brackets (C) as shown in Fig. 4 (page 8). (Note: the cutouts for the screws go to the bottom.) Gently press the top of the frame down into the brackets, until the bottom of the frame engages under the oven and the oven runners (B) as shown in Fig. 5 (page 8).

9. Fasten the frame with two screws (F) secured from the underside into the oven runners (B) as shown in Fig. 5 inset (page 8).

NOTE: The R-2B34 is designed to be fitted and operated in a kitchen unit. Therefore it is not supplied

with a rear spacer. If for any reason, it is not operated built-in, ensure there is a minimum free space above the oven of 15 cm and a minimum gap of 44 mm between the rear of the oven and the adjacent wall, to provide air circulation.

Diagram of oven position will be inserted here after completion of VDE testing.

As request in fax SEGCC-940 - the information for seperate sheet has been

inserted on this page.

R-2B34 B/I/K English 5/4/01 9:49 am Page 3
