DUPLICATOR : SD-2260
Date
:
May. 29, 1997
1. CHANGE IN THE MICRO-SWITCH IN THE OPERATIONS PANEL.
2. MEASURE TO IMPROVE THE FUSING PERFORMANCE OF THE 200 V SERIES.
3. MEASURE TO INCREASE THE PRESSURE OF THE CENTER TRAY DRAWER
CONNECTOR.
No. : DTE-274
1. Change in the micro-switch in the operations panel.
1.Model Name: SD-2060/3062/2260
2.General: A change has been carried out in the micro-switch used in the 200 V series of the
models listed above. This change has been carried out as a measure to improve
productivity.
QSW-M0454FCZZ
(Old)
QSW-M0406FCZZ
(New)
3.Action: From 1997 January production.
2. Measure to improve the fusing performance of the 200v series.
1.Model Name: SD-2260
2.General: A change has been carried out in the pressure spacer in the 200 V series of the model
listed above. The pressure spacer has been changed to a shorter one to increase the
pressure of the heat roller. This change has been carried out as a measure to increase
the fusing performance of half-tone copy operations.
3.Description:
Old New
Pressure spacer 16 mm (Q'ty: 1) 7 mm (Q'ty: 2)
4.Action: From 1996 November production.
SHARP CORPORATION Reprography Division
1/3
Green
C
3. Measure to increase the pressure of the center tray drawer connector.
1.Model Name: SD-2060/3062/2260
2.General: There were some problems with the connector of the drawer in the center tray UN of the
models listed above. The connector could not easily be pushed all the way to the back.
As a measure to alleviate this problem a change has been carried out in the pressure
spring of the drawer connector to increase the pressure.
The color of the spring
black → silver
3.Action: From 1996 mid-November production.
2/3
The change has been carried out only in
No. 44 in the figure above.
Ref.
Model
No.
name
SD-2060
1
SD-3062
SD-2260
2 SD-2260 13 -98 PCLR-0390FCZZ PSPAZ0388FCZZ AA
SD-2260 All
3
SD-2060
SD-3062
<Interchange>
1. Interchangeable. 4. Not interchangeable.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
Version P/G No.
200V
Series
Overseas
2 -38
9 -44
8 -44
Current parts New parts
Parts code Parts code
QSW-M0454FCZZ QSW-M0406FCZZ AG Micro switch
MSPRC0950FCZZ MSPRC2363FCZZ AD ADU drawer SP
Price
5. Interchangeable if replaced with same types of
related parts in use.
6. Others.
Parts name
rank
Separator
solenoid spacer
Effec-
tive
time
1st lot
'97/1
1st lot
'96/11
Mid-
'96/11
Inter-
change-
ability
1
3
Note
3/3
