Date: Mar. 11, 1997
DUPLICATOR : SD-4085
1. MEASURE CARRIED OUT TO ALLEVIATE PROBLEMS OF ORIGINAL DOCUMENT MIS-COUNTS IN THE
RDH UNIT.
2. MEASURE CARRIED OUT TO ALLEVIATE PROBLEMS OF ABNORMAL NOISE DURING OPENING AND
CLOSING OPERATIONS OF THE PAPER ENTRANCE OPEN AND CLOSING PAPER GUIDE OF THE RDH.
3. CHANGE IN THE SHAPE OF THE DRIVE FRAME CARRIED OUT AS A MEASURE TO ESTABLISH
CONFORMITY WITH THE EUROPEAN STANDARDS.
4. MEASURE CARRIED OUT TO IMPROVE PAPER FLOW EFFICIENCY IN THE RDH.
No. : DTE-267
1. Measure carried out to alleviate problems of original document mis-counts in the
RDH unit.
1.Model Name: SD-4085
2.General: There was a problem of mis-counts sometimes occurring in the1-cycle detection arms
of the models listed above in cases when approximately 20 mm of the original
document upper curl is used. As a measure to alleviate this problem, a change has
been carried out in the method of assembly used for the 1-cycle detection unit. As a
result of this change the detection area has been improved. As a permanent measure a
change has been carried out in the alignment positioning holes of the gears.
3.Description: Marking of the gears has been carried out on the metal molds, to be used as alignment
positioning marks. The position of the marking hole(ø1) has been moved to the marking
position location as described in the figure shown below. In accordance with this
change a change has been carried out in the part code, and the color of the part has
been changed from white to black.
Alignment positioning hole
Alignment positioning hole
Gear alignment position
Marking
4.Action: From 1996 mid-September production.
SHARP CORPORATION Reprography Division
1/3
Green
C
2. Measure carried out to alleviate problems of abnormal noise during opening and
closing operations of the paper entrance open and closing paper guide of the RDH.
1.Model Name: SD-4085
2.General: There have been problems with abnormal noise which sometimes occurs during
opening and closing operations of the paper entrance open and closing paper guide of
the RDH in the models listed above. As a measure to alleviate this problem a change
has been carried out on the gear axles of the gears in the rotary damper section to
correct the interval between the axles.
3.Action: From 1996 mid-October production.
3. Change in the shape of the drive frame carried out as a measure to establish
conformity with the European standards.
1.Model Name: SD-2075/3075/3076/4085
2.General: The addition of attachment holes for the PWB has been carried out on the reversion
drive frame of the models listed above. This change has been carried as a measure to
establish and maintain conformity with the European standards.
3.Description:
Abnormally shaped holes (Q’ty: 2)
Reversion drive frame A As → CFRM-0625FC02
Reversion drive frame B → LFRM-0626FCZ1
ø3.65 holes (Q’ty: 2)
4.Action: SD-2075/3075/3076: From 1996 October production.
SD-4085: From 1996 mid-October production.
2/3
4. Measure carried out to improve paper flow efficiency in the RDH.
1.Model Name: SD-4085
2.General: Roller collars have been added to the original document tray of the RDH units in the
models listed above. This addition has been carried out as a measure to improve
problems of the original document becoming soiled or dirty, and to improve the lowering
performance of the RDH.
3.Description: New addition: Roller collar PCLR-0435FCZZ (Q’ty: 0 → 4)
4.Action: From 1996 mid-October production.
Ref.
Model
No.
name
1 SD-4085 All
2 SD-4085 All
SD-2075
SD-3075
SD-3076
SD-4085 All
3
SD-2075
SD-3075
SD-3076
SD-4085 All
4 SD-4085 All
<Interchange>
1. Interc ha ng ea bl e . 4. N ot i n te r cha ng ea bl e.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts ma r ked w i th “ ” is imp or t an t fo r m a in ta i ning t he s a fe ty of the s e t. B e su r e to re pl ac e t he se pa r ts with
specified on es fo r m a inta i ni ng t he s a fe ty an d perform an c e of t he s e t.
Version P/G No.
54 -9 MARMP0210FCZZ MARMP0210FCZ1 AF 1-cycle detection arms
40 -9 CPLTM5203FC01 CPLTM5203FC02 AR
Overseas
32 -41 CFRM-0625FC01 CFRM-0625FC02 AZ
Overseas
32 -60 LFRM-0626FCZZ LFRM-0626FCZ1 AR Reversio n d rive fra me B
41 —
!
Current parts New parts
Parts code Parts code
New
PCLR-0435FCZZ
5. Interchangeable if replaced with same types of
related parts in use.
6. Others .
Price
rank
AD Roller collar
Parts name
Rotary damper
attachment plate As
Reversi on drive frame
A As
Effec-
Inter-
tive
change-
time
ability
1st lot
’96/11
Mid-
’96/10
1st lot
’96/10
Mid-
’96/10∗6
1st lot
’96/10
Mid-
’96/10∗6
Mid-
’96/10
Note
3
3
1
∗Interchangeability “3"
only European market
1
∗Interchangeability “3"
only European market
6 Q’ty: 4
3/3
