Date: Aug. 25, 1995
DUPLICATOR : SD-2060
No. : DTE-212
1. REGARDING DOUBLE FEEDING OF THE CENTER TRAY.
2. IN RESPONSE TO PSD JAMS OF THE CENTER TRAY.
3. PREVENTING THE 1000 TRAY UNIT’S TRAY FROM GETTING
SNAGGED.
1. Regarding double feeding of the center tray.
1.Model Name: SD-2060/3062
2.General: Due to problems with the back end sheet, which is attached to the center tray, static
electric charge builds up on the paper, resulting in double feeding. In order to prevent
this problem, we have made the following changes.
3.Description: The back end sheet will be changed to one which is conductive. This should reduce
the build up of static electricity.
Back end sheet RN
Back end sheet FN
y
x
x
Back end sheet FN
• Procedure for attachment (x, y) = (± 0.5, ± 0.5)
• The x axis to must be perpendicular to the y axis.
y
• Make sure to remove all oily residue from the
attachment surface, using alcohol.
∗
The back end sheet RN must be symmetrical with the FN.
4.Action: From the middle of May, 1995 production on.
SHARP CORPORATION Reprography Division
1/3
Green
C
2. In response to PSD jams of the center tray.
1.Model Name: SD-2060/3062
2.General: Paper which has been copied may curl a little at the top as it is entering the center tray.
When this happens, the timing of the detection lever in the suction unit may become
inaccurate, resulting in PSD jams. There will be changes to the detection lever’s long
lead switch, and the detector will be changed so that its timing does not become
inaccurate even when the top of a page has curled.
3.Action: From the middle of June, 1995 production on. ( Running change )
3. Preventing the 1000 tray unit’s tray from getting snagged.
1.Model Name: SD-2060/3062
2.General: The 1000 tray unit’s tray catches onto the upper part of the size guide R when it moves
to any position lower than its highest one. To prevent this problem we have made the
following changes.
3.Description: To prevent the tray from getting caught on the size guide, a side plate sheet has been
added, as shown in the figure.
42
8 Side plate sheet small
4.Action: From the middle of February, 1995 production on.
2/3
Ref.
Model
No.
1
SD-2060
SD-3062
2
3
<Interchange>
1. Interc ha ng ea bl e. 4. N ot i nt er ch an ge ab l e.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with “ ” is important for maintaining the safety of the set. Be sure to replace these parts with
s p eci fi e d on es fo r m ain ta in i ng t he s a fe ty an d pe rf o rma nc e o f th e s et .
name
Version P/G No.
29
All
30 -19 QSW-L0403FCZ2 QSW-L0496FCZZ AX Lead switch
20 — PSHEP3568FCZZ AC
!
Current parts New parts
Parts code Parts code
PSHEP3704FCZZ PSHEP4027FCZZ
PSHEP3705FCZZ PSHEP4028FCZZ
5. Interchangeable if replaced with same types of
relate d parts in use .
6. Others .
Price
rank
AF
Parts name
Back end sheet
FN
Back end sheet
RN
Side plate sheet
small
Effec-
tive
time
Mid-
’95/5
See
text
Mid-
’95/2
Inter-
change-
ability
3
6
Note
3/3
