MUSIC SYSTEM FOR iPod
MODEL
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
OPERATION MANUAL
iPod is a trademark of Apple Inc.,
registered in the U.S. and other
countries.
Thank you for purchasing this SHARP product. To obtain the
best performance from this product, please read this manual
carefully. It will guide you in operating your SHARP product.
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Special notes
Warning:
z When the unit is set at STAND-BY mode, mains voltage
is still present inside the unit.
z This unit contains no user serviceable parts. Never
remove covers unless qualified to do so. This unit
contains dangerous voltages, always remove mains plug
from the socket before any service operation and when
not in use for a long period.
z The supplied AC/DC adaptor contains no user
serviceable parts.
Never remove covers unless qualified to do so.
It contains dangerous voltages, always remove mains
plug from the main outlet socket before any service
operation or when not in use for a long period.
z The AC/DC adaptor supplied with the DK-AP7N(R)/DK-
AP7N(S)/DK-AP7N(W) must not be used with other
equipment.
z Never use an AC/DC adaptor other than the one
General Information
specified. Otherwise, problems or serious hazards may
be created.
z To prevent fire or shock hazard, do not expose this
appliance to dripping or splashing. No objects filled with
liquids, such as vases, shall be placed on the apparatus.
z Do not turn the volume on to full at switching the unit on.
Listen to music at moderate levels.
E-1
ENGLISH
Note for users in United Kingdom:
Recording and playback of any material may require
consent, which SHARP is unable to give. Please refer
particularly to the provisions of the Copyright Act 1956, the
Dramatic and Musical Performers Protection Acts 1958,
the Performers Protection Acts 1963 and 1972 and to any
subsequent statutory enactments and orders.
Note for users in Australia:
Copyright may exist in material you wish to record. Copying
or broadcasting such material without permission of the
relevant licensees or owners of the copyright is prohibited
by law. SHARP is not in a position to authorize the copying
or broadcasting of copyright materials and nothing in this
OPERATION MANUAL should be implied as giving that
authority.
For other countries:
Audio-visual material may consist of copyrighted works
which must not be recorded without the authority of the
owner of the copyright. Please refer to the relevant laws in
your country.
“Made for iPod” means that an electronic accessory has
been designed to connect specifically to iPod and has been
certified by the developer to meet Apple performance
standards.
Apple is not responsible for the operation of this device or
its compliance with safety and regulatory standards.
Accessories
Please confirm that only the following accessories are included.
AC/DC adaptor x 1 AC/DC adaptor x 1
AC/DC adaptor x 1
(for United Kingdom
and Eire only)
RADPAA057AWZZ
(for Australia only)
Plug adaptor x 1
(for Philipines only)
Contents
General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
Basic Operation
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
iPod
Listening to the iPod . . . . . . . . . . . . . . . . . . . . . . . 9 - 10
Advanced Feature
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . .11
References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . 12-13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Page
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Carry case x 1 (unit) Carry case x 1
iPod adaptor x 4
(AC/DC adaptor)
General Information
E-2
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
Precautions
ENGLISH
General
z Please ensure that the equipment is
positioned in a well-ventilated area
and ensure that there is at least
10 cm (4") of free space along the
sides, top and back of the equipment.
z Use the unit on a firm, level surface
free from vibration.
z
Keep the unit away from direct
sunlight, strong magnetic fields,
excessive dust, humidity and
electronic/electrical equipment
(home computers, facsimiles,
etc.) which generate electrical
noise.
z Do not place anything on top of the unit.
z Do not expose the unit to moisture, to temperatures higher
General Information
than 60°C (140°F) or to extremely low temperatures.
z If your system does not work properly, disconnect the AC/DC
adaptor from the wall socket. Plug the AC/DC adaptor back
in, and then turn on your system.
z In case of an electrical storm, unplug the unit for safety.
z Do not use an external power supply other than the 6V DC
supplied with this unit as it may be damaged.
z SHARP is not responsible for damage due to improper use.
Refer all servicing to a SHARP authori sed service centre.
E-3
10 cm (4")
10 cm (4")
z Hold the AC/DC adaptor by the head when removing it from
the wall socket, as pulling the lead can damage internal wires.
z The AC/DC adaptor is used as a discon nect device and shall
always remain readily operable.
z Do not remove the outer
cover, as this may result in
electric shock. Refer internal
service to your local SHARP
service facility.
z The ventilation should not be impeded
by covering the ventilation openings
with items, such as newspapers,
tablecloths, curtains, etc.
z No naked flame sources, such as lighted candles, should be
placed on the apparatus.
z Attention should be drawn to the environmental aspects of
battery disposal.
z The apparatus is designed for use in moderate climates.
z This unit should only be used within the range of 5°C - 35°C
(41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this
unit. Using this product with a higher voltage other than that
which is specified is dangerous and may result in a fire or other
type of accident causing damage. SHARP will not be held
responsible for any damage resulting from use of this unit with
a voltage other than that which is specified.
Volume co n t r o l
The sound level at a given volume setting depends on speaker
efficiency, location and various other factors. It is advisable to
avoid exposure to high volum e levels. Do not turn the volume on
to full at switch on. Listen to music at moderate levels.
Controls and indicators
STEREO SPEAKER
2.1
BUILT-IN SUBWOOFER
1
2
3
VOL
–
VOL
+
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
Front View
1. iPod Dock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4
2. ESOUND/TV Out Button. . . . . . . . . . . . . . . . . . . . . . . . . 8
3. Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . . . 8
4. Subwoofer Duct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. ON/STAND-BY Button . . . . . . . . . . . . . . . . . . . . . . . . . .8
Y
-B
ND
A
T
N/S
O
6. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5
Reference page
ENGLISH
6
Back View
1. Video Out Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2. Auxiliary Input Socket . . . . . . . . . . . . . . . . . . . . . . . . .11
3. DC Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Reference page
General Information
312
E-4
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Controls and indicators (continued)
The spec label (*)
General Information
E-5
1
Bottom View
1. Battery Compartment . . . . . . . . . . . . . . . . . . . . . . . .7
Reference page
The spec label illustration may be different
from the actual label used.
(*) Label is located at the bottom of the unit.
System connections
Make sure to unplug the AC/DC adaptor before making
any connections.
Connecting iPod to TV
Photo and video files from iPod can be viewed by connecting the
system to TV/monitor.
If the TV/monitor has a video input, connect it to the VIDEO OUT
socket at the back of the unit and set the TV Out on the iPod unit to
“ON” position.
TUO OEDIV
Video cable
(not supplied)
To video
input socket
TV
z Please make sure to set iPod unit to either NTSC or PAL to
match your TV signal. Please visit Apple’s home page for further
information.
z Customer should also refer iPod operation manual before
making video out setting.
Using with the AC/DC adaptor
1 Plug the AC/DC adaptor cable into the DC IN socket on
the unit.
2 Plug the AC/DC adaptor into a wall socket.
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Watching videos on a TV connected
to iPod
1 Enter the iPod menu.
Press the ESOUND (-TV OUT) button until the ESOUND
LED blinks twice to display video on the TV screen.
2 Select the desired video from the iPod unit.
3 Press the button on the iPod unit to start
playback.
For iPod touch, playback will automatically start once the
desired video is selected.
Notes:
z If the TV Out setting is already turned ON at video menu, the
video is automatically displayed on the TV screen when iPod
starts playback.
z To return to watching video on iPod screen, repeat steps 1 to 3.
z During iPod video playback, pressing the ESOUND (-TV OUT)
button until the ESOUND LED blinks twice will not toggle video out
display between iPod and TV.
AC/DC
Adaptor
Cable
DC IN socket
(DC 6V)
Wall Socket
Notes:
z Unplug the AC/DC adaptor from the wall socket if the unit will
not be used for a prolonged period of time.
z Connecting the AC/DC adaptor to the unit disconnects the
batteries.
z Use only the supplied AC/DC adaptor. Using other AC/DC
adaptor may cause an electric shock or fire.
(AC 100 - 240 V, 50/60 Hz)
Preparation for Use
E-6
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Preparation for Use
E-7
System connections (continued)
Using with the batteries
Use 4 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
1 Open the battery cover.
Slide the cover in the direction of the arrow.
2
Insert the batteries according to the direction indicated in
the battery compartment.
3 Close the cover.
Note:
Remove the batteries if the unit is not to be used for long period
of time to prevent battery leakage which may cause potential
damage.
Battery replacement:
When batteries are low, sound may become distorted and unit
may automatically turn off during high volume level. Reduce the
volume level or replace the batteries.
Battery life:
Battery type ALKALINE (AA) (1.5V)
Usage time Approx. 8 hrs.
Output Front 48mW + 48mW
Output Subwoofer 80mW
Note:
Battery life may vary depending on the temperature, battery
types and usage conditions.
Precautions for battery use:
z Installing the batteries incorrectly may cause the unit to
malfunction.
z Insert the batteries according to the direction indicated in the
battery compartment.
z Remove the batteries if the unit will not be used for a long
period of time. This will prevent potential damage due to
battery leakage.
z When using batteries, the brightness of all illumination light
(indicators) is reduced compared to using AC/DC adaptor.
z Replace all old batteries with new ones at the same time.
z Do not mix old and new batteries.
z Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
Caution:
Do not use rechargeable batteries (nickeI-cadmium battery,
etc.).
Changing power source:
Turn off the unit before changing the power source. If the 6V DC
power supply is directly plugged in during power on, the unit
may automatically enter to stand-by mode. Press the ON/
STAND-BY button again to turn on the unit.
General control
STEREO SPEAKER
2.1
BUILT-IN SUBWOOFER
Y
AND-B
T
ON/S
VOL
–
To turn the power on
Press the ON/STAND-BY button to turn the power on. The
POWER and ESOUND indicator will turn on.
After use:
Press the ON/STAND-BY button to enter the power stand-by
mode. The POWER indicator will turn off.
Note:
This unit consumes low current during stand-by mode. However,
please remove the batteries if the unit will not be used for a long
period of time.
VOL
+
Volume control
Press the VOL (+ or –) button to increase or decrease the
volume.
POWER indicator will be blinking when the volume reaches
maximum or minimum level.
ESOUND control
When ON/STAND-BY button is pressed, the ESOUND indicator
turns yellowish orange. You are now in the ESOUND mode,
where low bass and high frequency are automatically adjusted
according to the volume input.
To tu r n o f f E SOUND, press the ESOUND (-TV OUT) button. The
ESOUND indicator will go off.
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Basic Operation
E-8
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
iPod
E-9
Listening to the iPod
Supported iPod models:
z iPod nano (software 1.2 above)
z iPod mini (software 1.2 above)
th
z iPod (5
z iPod (4
z iPod nano (2
z iPod nano (3
z iPod nano (4
z iPod classic (software 1.0.3 above)
z iPod touch (software 1.1 above)
z iPod touch (2
Caution:
z Please update your iPod unit to the latest software version
Notes:
z Once the iPod is connected to the unit it will begin charging
z The iPod unit will not be charged whilst the main unit use the
generation) (software 1.3 above) (Dock connector
equipped Click Wheel model)
th
generation) (software 3.0.2 above) (Dock connector
equipped Click Wheel model)
before using it. Please visit Apple’s homepage to download
the latest version for your iPod.
nd
generation) (software 1.0.0 above)
rd
generation) (software 1.0.3 above)
th
generation) (software 1.0.3 above)
nd
generation) (software 2.1 above)
when AC/DC adaptor is used.
batteries as power supply.
iPod adaptor connection
Choose the iPod adaptor that fits your iPod. Your iPod will fit
snuggly into the correct adaptor. If your iPod is not mentioned
below, an iPod adaptor may have been included with your iP od
unit.
The marking
shows which iPod fits
iPod
Adaptor No.
iPod Description Capacity
9
9 5G iPod (with video) 30GB
9 U2 iPod with video 30GB
9 iPod classic 80GB, 120GB
10 5G iPod with video 60GB & 80GB
10 iPod classic 160GB
A iPod mini 4GB & 6GB
A 4G iPod & U2 iPod 20GB
A iPod photo & Colour U2 iPod 20GB & 30GB
A iPod with colour display 20GB
B 4G iPod 40GB
B iPod photo 40GB & 60GB
B iPod with colour display 60GB
Notes:
z iPod nano (2
nano (4th generation), iPod touch and iPod touch
(2nd generation) are not compatible with the iPod adaptors listed
above. Please use the adaptor supplied with your iPod unit.
z If you have an iPod that does not have an iPod 30 Pin
connector, you can use an audio cable to connect it to the
AUX IN socket.
z iPhone is not supported by this system.
nd
generation), iPod nano (3rd generation), iPod
To insert iPod adaptor
1. Insert the iPod adaptor into unit and connect your iPod.
iPod (bottom)
Dock connector
iPod
iPod playback
1 Press the ON/STAND-BY button to turn the power on.
2 Insert iPod unit in the iPod dock of main unit.
3 Press the button on the iPod unit to start
playback.
For iPod touch, playback will automatically start once the
desired file is selected.
iPod
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
iPod adaptor
iPod dock
iPod connector
Caution:
Unplug all accessories for the iPod before inserting it into the
iPod dock.
To remove iPod
adaptor
Insert the tip of a screwdriver (“-”
type, small) into the iPod adaptor
hole as shown and lift upward to
remove.
iPod adaptor
To disconnect iPod
Simply remove the iPod from the iPod dock. It is safe to do so
even during playback.
iPod
E-10
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
Advanced Feature
E-11
Enhancing your system
The audio cable is not included. Purchase a separate audio
cable as shown below.
Portable audio
player
NI XUA
Computer
To the line
output socket
Audio cable
(not supplied)
Listening to the audio/video
sounds from portable audio player,
computer, etc.
1 Use Audio cable to connect the portable audio
player, computer etc. to the AUX IN socket.
When using video equipment, connect the audio output
to this unit and the video output to a television.
2 Press the ON/STAND-BY button to turn the power
on.
3 Play the connected equipment.
If volume level of the connected device is too high,
sound distortion may occur. Should this happen, lower
the volume of the connected device.
Notes:
z To prevent noise interference, place the unit away from the
television.
z Make sure to undock the iPod before making any
connections to AUX IN. Otherwise, sound from AUX IN will
not be heard.
Troubleshooting chart
Many potential problems can be resolved by the owner without
calling a service technician.
If something is wrong with this product, check the following
before calling your authorised SHARP dealer or service centre.
General
Symptom Possible cause
z When a button is
pressed, the unit does
not respond.
z No sound is heard. z Is the volume level set to
z Set the unit to the power
stand-by mode and then
turn it back on.
minimum?
iPod
Symptom Possible cause
z No sound is produced.
No image appears on the
TV/monitor.
z iPod will not charge. z The iPod is not making full
z The iPod is not playing.
z The iPod is not properly
connected to the unit.
z Is the AC/DC adaptor of the
unit plugged in?
z The video cable is not
properly connected.
z The TV/monitor’s input
selection is not properly set.
contact with the iPod
connector.
z The main unit is using
batteries as power supply.
rd
z Using 3
generation iPod.
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
References
E-12
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
References
E-13
Condensation
Sudden temperature changes, storage or operation in an
extremely humid environment may cause condensation inside
the cabinet.
Condensation can cause the unit to malfunction. If this happens,
leave the power on until normal playback is possible (about 1
hour) before operating the unit.
If problem occurs
When this product is subjected to strong external interference
(mechanical shock, excessive static electricity, abnormal supply
voltage due to lightning, etc.) or if it is operated incorrectly, it
may malfunction.
If such a problem occurs, do the following:
1 Set the unit to the stand-by mode and tu rn the power on
again.
2 If the unit is not restored in the previous operation, unplug
and plug in the unit, and then turn the power on.
Before transporting the unit
Undock the iPod and close the unit. The unit will automatically
enter stand-by mode.
CAUTION: Carrying the unit with iPod docked might damage
both the system and the iPod.
Maintenance
Cleaning the unit
Periodically wipe the unit with a clean soft cloth.
Caution:
z Do not use chemicals for cleaning (petrol, paint thinner, etc.).
It may damage the unit finishing.
z Do not apply oil to the inside of the unit. It may cause
malfunctions.
Specifications
As part of our policy of continuous improvement, SHARP
reserves the right to make design and specification changes for
product improvement without prior notice. The performance
specification figures indicated are nominal values of production
units. There may be some deviations from these values in
individual units.
General
Power source
Power
consumption
Output power
Speaker
Speaker maximum
input power
Speaker rated
input power
DC IN 6V 2A: AC/DC adaptor
(AC 100 - 240 V ~ 50/60 Hz)
DC IN 6V [ “AA” size (UM/SUM-3, R6 or
HP-7) battery x 4]
Power on: 5 W
Power stand-by: 0.6 W(*)
Front speakers:
MPO: 3.04 W (1.52 W + 1.52 W) (10% T.H.D.)
RMS: 2.4 W (1.2 W + 1.2 W) (10% T.H.D.)
RMS: 2.08 W (1.04 W + 1.04 W) (0.9% T.H.D.)
Subwoofer:
MPO: 2.23 W (10% T.H.D.)
RMS: 2 W (10% T.H.D.)
RMS: 1.6 W (0.9% T.H.D.)
2.1-way type speaker system
Front speaker: 3.0 cm (1-1/8")
Subwoofer: 4.6 cm (1-3/4")
Front speaker: 2.0 W / channel
Subwoofer: 4 W
Front speaker: 1.2 W / channel
Subwoofer: 2 W
Output terminals
Input terminals
Dimensions
Weight
(*) This power consumption value is obtained when in the power
stand-by mode.
Video output: 1Vp-p
Auxiliary (audio signal):
500 mV/47 k ohms
Width: 198 mm (7-4/5")
Height: 69.8 mm (2-7/10")
Depth: 77 mm (3")
0.59 kg (1.3 lbs.)
DK-AP7N(R)
DK-AP7N(S)
DK-AP7N(W)
ENGLISH
References
E-14
SHARP CORPORATION
TINSEA285AWZZ
09D R KI 1
Loading...
