BL642W
OWNER’S GUIDE
®
®
HELP
LINE
1-877-646-5288
www.ninjakitchen.com
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING ELECTRICAL APPLIANCES,
BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS BEFORE
®
USING YOUR NUTRI NUTRI NINJA
| NINJA® BLENDER WITH AUTO-iQ™
TECHNOLOGY.
POLARIZED PLUG
WARNING: To reduce the risk of electric
shock, this appliance has a polarized plug
(one blade is wider than the other). This plug
will fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact
a qualified electrician to install the proper
outlet. DO NOT modify the plug in any
way.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
OR INJURY:
1 To protect against electrical shock, do not
submerge the appliance or allow the power
cord to come into contact with water or any
other liquid.
2 DO NOT allow young children to operate the
appliance or use as a toy. Close supervision
is necessary when any appliance is used by
or near children.
3 Never leave an appliance unattended when in
use.
4 Turn the appliance Off and remove the power
cord from the electrical outlet when not in
use, before assembling or disassembling
parts and before cleaning. To unplug, grasp
the plug and pull from the electrical outlet.
Never pull from the power cord.
5 DO NOT abuse the power cord. Never carry
the appliance by the power cord or yank it
to disconnect from electrical outlet; instead
grasp the plug and pull to disconnect.
6 DO NOT operate any appliance with a
damaged cord or plug, or after the appliance
malfunctions, has been dropped or damaged
in any manner. This appliance has no
serviceable parts. Return the appliance to
EURO-PRO Operating LLC for examination,
repair or adjustment.
7 DO NOT let the power cord hang over
the edge of table or counter or touch hot
surfaces such as the stove.
8 Always use appliance on a dry, level surface.
2
1-877-646-5288
9 Keep hands, hair, clothing, as well as
utensils out of container while processing to
reduce the risk of severe injury to persons
or damage to the appliance. A scraper may
be used but only when the appliance is not
running.
10 CAUTION: Blade assemblies are sharp and
removable, handle with care. When handling
the blade assemblies, always hold by the
shaft.
11 Avoid contact with moving parts.
12 DO NOT attempt to sharpen blades.
13 DO NOT use the appliance if blade assembly
is bent or damaged.
14 To reduce risk of injury, never place the blade
assembly on base without pitcher or bowl
properly attached.
15 DO NOT operate this appliance on or near
any hot surfaces (such as gas or electric
burner or in a heated oven).
16 The use of attachments or accessories
including canning jars, not recommended by
the manufacturer may result in fire, electric
shock or personal injury.
17 DO NOT remove the container from the
motor base while the appliance is in
operation.
18 To reduce the risk of injury, NEVER operate
the appliance without the lid in place; DO
NOT try to defeat the interlock mechanism;
make sure that the attachment is properly
installed before operating the appliance.
19 DO NOT expose containers to extreme
temperaturechanges.
20 CAUTION: DO NOT BLEND HOT LIQUIDS.
21 DO NOT overfill.
22 Never feed food by hand. Always use the
food pusher.
23 DO NOT operate the appliance empty.
24 To reduce the risk of burns, always allow the
appliance to cool before taking off parts and
before cleaning.
25 In the event that the unit overloads, the
control panel lights will flash and the unit
will shut down. Unplug the appliance and let
it cool down for approximately 15 minutes
before using again.
26 THIS PRODUCT IS INTENDED FOR
HOUSEHOLD USE ONLY. Do not use this
appliance for anything other than its intended
use. Do not use outdoors.
27 The maximum rating is based on the 6-Blade
Assembly (pitcher) that drives the greatest
power and other recommended attachments
may draw significantly less power or current.
WARNING: Extension cords are
not recommended for use with this
product.
SAVE THESE
INSTRUCTIONS
www.ninjakitchen.com
3
THIS BOOK COVERS MODEL NUMBERS:
BL642W 30
TECHNICAL SPECIFICATIONS
Voltage: 120V~, 60Hz.
Power: 1500 Watts
Pitcher Capacity: 72 ounces (9 cups, 2.1 L)
64 liquid ounces (8 cups, 1.9 L)
®
Nutri Ninja
Cup Capacity: 18 ounces (2 cups, 500 mL)
24 ounces (3 cups, 700 mL)
32 ounces (4 cups, 950 mL)
Euro-Pro, Auto-iQ, Nutri Ninja, Pro Extractor Blades
and Ninja are trademarks of Euro-Pro Operating LLC.
4
1-877-646-5288
Contents
Thank you for
purchasing the
®
Blender
®
|
™
Nutri Ninja
Ninja
with Auto-iQ
Technology.
Getting to Know Your Nutri Ninja® | Ninja® Blender with Auto-iQ™ Technology .....................6
Using the Nutri Ninja® | Ninja® Blender with Auto-iQ™ Technology . ....................................8
Assembly and Use for the Ninja® Blender ........................................................................9
Assembly and Use for the Nutri Ninja® Cups ..................................................................11
Programs, Speed Settings, & Uses ................................................................................12
Care & Maintenance ....................................................................................................13
Troubleshooting Guide ..................................................................................................14
Replacement Parts ....................................................................................................... 14
Warranty & Registration ................................................................................................15
www.ninjakitchen.com
5
Getting To Know Your Nutri Ninja® | Ninja® Blender
with Auto-iQ™ Technology
a
b
c
d
g
h
j
e
i
f
a Jumbo Multi Serve 32 oz. Nutri
Ninja® Cup
b Regular 24 oz. Nutri Ninja® Cup
c Small 18 oz. Nutri Ninja® Cup
d Pro Extractor Blades
™
e Sip & Seal™ Lids (x3)
6
1-877-646-5288
f Silicone Grip Sleeve (x3)
g Blender Pitcher
h Blender Lid with locking handle
i Stacked Blades (blender)
j Motor Base
NOTE: Blades are not
interchangeable.
The Nutri Ninja® | Ninja® Blender with Auto-iQ™ Technology is a professional, high powered innovative tool with a sleek
design and outstanding performance, a true asset to any kitchen. The Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology features intelligent programs that combine unique pulsing, blending and pausing patterns that do the work
for you! Get great results every time with no guesswork required! For best results, be sure to carefully read all the
instructions contained in the manual before using this appliance.
Nutri Ninja® | Ninja® Blender with Auto-iQ™ Technology Features:
• Patent Pending Ninja™ Blade Technology
• BPA Free Blender Pitcher, Nutri Ninja
• Total Crushing
™
Technology
• Drip-Free Pour Spout
• LED Control Panel with Timer
• Sturdy, Non-Slip Base
• Smart Lid technology for easy release
• 3 speeds: Low, Medium, & High
• 5 Auto-iQ
™
Programs - Auto-iQ™ Frozen Drinks/Smoothies, Auto-iQ™ Puree, Nutri Ninja® Auto-iQ™ Blend, Nutri Ninja®
Auto-iQ™ Ultra Blend and Auto-iQ™ Pulse
• Nutri Ninja
®
Nutrient & Vitamin Extraction
®
Cups and Lids
www.ninjakitchen.com
7
Using the Nutri Ninja® | Ninja® Blender with Auto-iQ™ Technology
PLEASE KEEP THESE IMPORTANT
SAFEGUARDS IN MIND WHEN USING THE
APPLIANCE:
IMPORTA NT: Never add ingredients into the
container before placing the blade in first.
IMPORTA NT: Blades are not interchangeable.
IMPORTANT: DO NOT attempt to operate the
appliance without the lid on.
IM PO RTAN T: Never run the appliance empty.
CAUTION: DO NOT PROCESS HOT FOODS OR
HOT LIQUIDS.
CAUTION: Never remove the container while the
appliance is still running.
WARNING: Never leave the appliance unattended
while in use.
CAUTION: If using
the pour spout,
ensure the lid
is fully locked
onto the blender
pitcher.
CAUTION: If
pouring with
the lid removed,
ALWAYS remove
the blade
assembly first.
CAUTION: Blade assemblies are sharp and
removable, handle with care. When handling the
blade assemblies, always hold them by the shaft.
BEFORE FIRST USE
1 Remove all packaging material and labels from the
appliance.
2 Wash the lids, blender pitcher, Nutri Ninja
blades in warm, soapy water with a soft cloth. Use
caution when washing the blade assemblies as
the blades are very sharp.
3 Rinse and dry thoroughly.
4 The blender pitcher, Nutri Ninja
®
are all dishwasher safe. It is recommended that the lids
and blades be placed on the top rack. Ensure that the
blades are removed from the containers before placing in
the dishwasher.
5 Wipe the motor base clean with a damp cloth.
®
cups and
cups, lids and blades,
8
1-877-646-5288
Assembly and Use for the Blender
HIGH
PULSE
LOW
DOUGH
SMOOTHIE
SINGLE
SERVE
PUREE
FROZEN
BLENDING
ASSEMBLY
Fig. 1
AUTO
FROZEN DRINKS
SMOOTHIES
AUTO
PUREE
AUTO
LOW
MED
HIGH
PULSE
Fig. 4a
Fig. 4b
Use caution when handling the blade assemblies
as the blades are very sharp.
WARNING: Never leave the appliance unattended while
in use.
IM PO RTAN T: Make sure that the motor base is
plugged in for use.
1 Holding the Stacked Blade Assembly by the top of the
shaft, place it onto the drive gear inside the pitcher.
Ensure that the attachment is seated properly and is
standing upright. (Fig. 1)
NOTE: The blade will fit loosely on the drive gear.
2 Place the motor base on a clean, dry, level surface such
as a counter or table top.
3 Align and lower the Pitcher onto the motor base.
(Fig. 2) Handle should be aligned slightly to the right
of the “LOCK” symbol on the motor base.
4 Rotate the pitcher clockwise until it locks in place, you
will hear a click when the lock is engaged. (Fig. 3)
5 The pitcher can be placed on the motor base two ways;
the handle can be on the front right corner or the front
left corner. (Fig. 4a, Fig. 4b)
Fig. 2
Fig. 3
Fig. 5a
6 Add the ingredients to the pitcher, making sure that
they do not exceed the highest measured marking line
on the side of the pitcher.
NOTE: When blending any kind of liquids, such as
mixtures of any drinks or smoothies, do not exceed the
“Max Liquid” mark (64 ounces) on the pitcher.
NOTE: If you need to add additional ingredients while
the appliance is processing, open the pour spout cap
and pour the ingredients in through the opening.
7 Holding the lid by the handle in the upright position, place
it on top of the pitcher aligning the triangle ( ) located
on the lid with the triangle ( ) located on the pitcher’s
handle. (Fig. 5a) Press the handle down until you hear
a click. The triangles on the lid and the blender handle
MUST be aligned in order for the blender to turn on.
(Fig. 5b)
8 Plug the power cord into the electrical outlet and press
the power button ( ).
NOTE: As a safety feature, the power light
( ) will flash and the motor will not work if the
pitcher and lid are not installed correctly. When
the pitcher and lid are installed properly, the
power light ( ) will be solid, indicating that the
appliance is ready for use.
Fig. 5b
www.ninjakitchen.com
9
Assembly and Use for the Blender - cont.
USE
AUTO
Fig. 6
REMOVAL
Fig. 7 Fig. 10
WARNING: Never leave the appliance unattended while
in use.
NOTE: Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology can sense which jar is on the motor base.
The available function lights will illuminate depending
on which jar is placed on the motor base. (Fig. 6)
9 Press the power button to turn on the unit. Select
the speed or Auto-iQ™ program that best suits your
needs. The Auto-iQ™ program will stop the appliance
automatically at the end of the program. (Fig. 7)
NOTE: Pulse ingredients for even chopping by
holding the Auto-iQ™ Pulse button until your desired
consistency is reached.
10 To pause the appliance, press the selected speed or
Auto-iQ™ program a second time. When the program is
paused, the light on the program button will flash until
you press it again to resume the rest of the program.
11 When you have reached your desired consistency, stop
the appliance by pressing the power button ( ) and
wait for the blade to stop turning. (Fig. 8)
10
1-877-646-5288
Fig. 8
Fig. 9
12 Turn the pitcher counter clockwise to remove and then
lift off the base. (Fig. 9)
CAUTION: Never insert your hands in the pitcher as the
blades are sharp. Always use a spatula to dislodge food
that has stuck to the sides of the pitcher.
CAUTION: If using the pour spout, ensure that the lid is
fully locked onto the blender pitcher.
CAUTION: If pouring with the lid removed, ALWAYS
remove the blade assembly first before pouring.
13 Depending on the consistency of the contents in the
container, open the pour spout cap and use the spout
to empty liquid contents.
14 For thicker consistencies, remove the lid and blade
attachment carefully (by its shaft), then empty contents
from the container. To remove the lid, press the release
button on the lid and pull the lid handle up to a 90°
angle ands lift the lid off the blender pitcher. (Fig. 10)
15 Make sure that the unit is unplugged when not in use.
Assembly and Use for the Nutri Ninja® Cups
Use caution when handling the blade assemblies as the blades are very sharp.
ASSEMBLY USE REMOVAL
Fig. 1
TO
AU
Fig. 2 Fig. 3
NOTE: Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology can sense which jar is on the motor base.
The available function lights will illuminate depending
on which jar is placed on the motor base. (Fig. 1)
WARNING: Never leave the appliance unattended while
in use.
IM PO RTAN T: Make sure that the motor base is
plugged in for use.
1 Place the motor base on a clean, dry, level surface such
as a counter or table top.
2 Add ingredients to the Nutri Ninja
3 Place the Pro Extractor Blades
®
cup.
™
onto the cup and tightly
screw it on clockwise until you have a good seal. (Fig. 2)
4 Turn the Nutri Ninja
®
cup upside down and place it
onto the motor base, aligning the tabs on the cup with
the motor base. Rotate the Nutri Ninja® cup clockwise
until it locks in place, you will hear a click when the
lock is engaged. (Fig. 3)
Fig. 4 Fig. 5 Fig. 6
5 Press the power button on, and select the speed
or Auto-iQ
(Fig. 4) The Auto-iQ
™
program that suits your needs.
™
program will stop the appliance
automatically at the end of the program.
6 To pause the appliance, press the selected speed or
™
Auto-iQ
program a second time. When the program is
paused, the light on the program button will flash until
you press it again to resume the rest of the program.
7 Once you have reached your desired consistency, stop the
appliance by pressing the power button and wait for the
blade to stop turning. Turn the Nutri Ninja
®
cup counter-
clockwise and pull straight up to remove. (Fig. 5, Fig. 6)
NOTE: Do not over fill! To avoid spilling, do not add
ingredients past the “Max Liquid” line.
8 Turn the cup upright and remove the Pro Extractor
™
Blades
by twisting the Pro Extractor Blades™ counter
clockwise.
9 Place the Sip & Seal
™
lid onto the Nutri Ninja® cup,
twist to seal and enjoy!
10 Make sure that the motor base is unplugged when
not in use.
www.ninjakitchen.com
11
Programs, Speed Settings & Uses for the Blender Pitcher
FUNCTION CONTAINER
BLADE
TYPE
Processing Blender Pitcher Stacked Blade
Chopping Blender Pitcher Stacked Blade
Frozen Drinks /
Ice Crush
Blender Pitcher Stacked Blade
Pureeing Blender Pitcher Stacked Blade Auto-iQ
SPEED or
PROGRAM
Auto-iQ™ Puree
Medium
Auto-iQ
™
Auto-iQ
Smoothies
™
Pulse
High
Frozen Drinks/
™
Puree
Programs, Speed Settings & Uses for the Nutri Ninja® Cup
FUNCTION CONTAINER
Smoothies Nutri Ninja® Cup
Green Smoothies Nutri Ninja
Grating Nutri Ninja
Chopping Nutri Ninja
®
®
®
Cup
Cup
Cup
BLADE
TYPE
Pro Extractor
™
Blades
Pro Extractor
™
Blades
Pro Extractor
™
Blades
Pro Extractor
™
Blades
SPEED or
PROGRAM
NutriNinja Auto-iQ™ Blend
NutriNinja Auto-iQ™ Ultra
Blend
Auto-iQ™ Pulse
High
Auto-iQ™ Pulse
High
TYPE OF FOOD
Dips
Batters
Salsa
Vegetables
Nuts
Ice
Frozen Drinks
Smoothies
Soups
Milkshakes
TYPE OF FOOD
Smoothies
Frappes
Milkshakes
Protein Drinks
Frozen Fruits
Frozen Vegetables
Kale
Celery
Spinach
Seeds
Ice
Grated Cheese
Bread Crumbs
Spices
Salsa
Vegetables
Nuts
12
1-877-646-5288
Care & Maintenance
HOW TO CLEAN
CAUTION: Make sure that the motor base is unplugged
from the power source before inser ting or removing any
attachment and before cleaning.
CAUTION: DO NOT immerse the motor base into water or
any other liquid.
1 Separate/remove all parts from each other.
2 Clean the motor base with a damp cloth and wipe dry.
3 Place the blender pitcher and Nutri Ninja
dishwasher. Place the lids and attachments on the
top rack. Use caution when handling the blade
assemblies as the blades are very sharp.
NOTE: You may also wash the containers by filling ¾ of
the container with warm water and a drop of dish washing
detergent, placing the corresponding lid on the container
and pressing the
Auto-iQ™
Pulse button a few times.
Once clean, remove the container from the motor base.
Rinse the container, attachment and lid under running
water. Allow all the parts to dry before storing.
Please call customer service if any servicing needs to be
performed on the appliance at 1-877-646-5288.
®
cup in the
HOW TO STORE
1 Store the
Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology
upright with the pitcher on the motor base,
6-Blade assembly inside the pitcher and lid on the
pitcher. Do not place anything on top. S
tore the Nutri
Ninja® cup and the rest of the attachments along side
the appliance or in a cabinet where they will not be
damaged and won’t cause a hazard.
RESETTING THE MOTOR THERMOSTAT
The Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology features a unique safety system which
prevents damage to the unit’s motor and drive system
should you inadvertently overload your appliance. If
the appliance is being overloaded, the motor
will stop. Allow the appliance to cool for
approximately 15 minutes. To reset the appliance,
follow the resetting procedure below:
1
Unplug the appliance from the electrical outlet.
2
Remove and empty the container and ensure that no
food is jamming the cutting blades or attachments.
3
Allow the appliance to cool for approximately 15
minutes.
4
Re-install the container onto the base and re-plug the
appliance into the electrical outlet.
5
Proceed to use the appliance as before making sure not
to exceed the recommended maximum capacities.
www.ninjakitchen.com
13
Troubleshooting Guide
PROBLEMS POSSIBLE REASONS & SOLUTIONS
Motor Doesn’t Start or
Attachment Doesn’t Rotate.
Food is Unevenly Chopped.
Make sure the container is securely placed on motor base.
Make sure the lid is securely on container in the correct position (align
arrows).
The appliance is turned “Off”. Press the power button (
Check that the plug is securely inserted into the electrical outlet.
Check the fuse or circuit breaker.
The unit has overloaded. The appliance will stop and the power light will
flash. Unplug and wait approximately 15 minutes before using again.
The unit has overheated. Unplug and wait approximately 15 minutes before
using again.
Check to make sure the unit is not overloaded.
Either you are chopping too much food at one time, or the pieces are not of
even size and processing smaller amounts per batch.
) to turn “On”.
Food is Chopped Too Fine or is
Too Watery.
Food Collects On Lid or On the
Sides of the Container.
You Cannot Achieve Snow
From Solid Ice.
Motor Base Won’t Stick to
Counter or Table Top.
You get an “Err” Message
You have a blinking red light
The food has been over processed. Use Auto-iQ™ Pulse button for
controlled processing.
The mixture is too thick. Add more liquid.
Do not use ice that has been sitting out or has started to melt. Use ice
straight from the freezer.
Start with a few pulses and then go to a continuous blending cycle.
Make sure surface and suction feet are wiped clean. Suction feet will only
stick to smooth surfaces. Suction feet WILL NOT stick on some surfaces
such as, wood, tile and non-polished finishes.
DO NOT attempt to use appliance when the motor base is stuck to a
surface that is not secure, (cutting board, platter, plates, etc.).
Your Ninja is able to detect which jar is on the base. You may be trying
to use a program that is not designed for the jar you have installed. The
programs will light up indicating which programs are available for each jar.
The unit is not installed properly. For your safety the unit will only be able to
be turned on when it is properly assembled. Please refer to the assembly
pages of this inspiration guide for assistance.
Replacement Parts
ORDERING REPLACEMENT PARTS
To order additional parts and attachments, please visit our website: www.ninjakitchen.com
or feel free to contact customer service: 1-877-646-5288.
14
1-877-646-5288
Available Accessories for the Nutri Ninja® | Ninja
Blender with Auto-iQ™ Technology
Thank you for purchasing your Nutri Ninja® | Ninja® Blender with Auto-iQ™ Technology. You may have purchased some of
the following additional accessories. Please refer to the assembly and usage instructions on the next few pages for the
accessories you purchased.
To purchase the additional accessories shown below, please call customer service at 1-877-646-5288.
®
www.ninjakitchen.com
15
Available Accessories for the Nutri Ninja® | Ninja
NEW SHOOT LID
JUNE 9/14
HAS NEW BASE
AU
TO
BLEND
BLAST
FROZEN DRINKS
SMOOTHIES
FOOD
PUREE
NutriNinja
NutriNinja
PULSE
HIGH
MED
ON
OFF
1500
WATTS
LOW
AU
TO
AU
TO
AU
TO
A
UTO
BLEND
A
UTO
BLAST
FROZEN DRINKS
SMOOTHIES
FOOD
PUREE
NutriNinja
NutriNinja
PULSE
HIGH
MED
ON
OFF
1500
WATTS
LOW
AU
TO
AU
TO
AU
TO
A
UTO
BLEND
A
UTO
BLAST
NEW SHOOT LID
JUNE 9/14
HAS NEW BASE
NEW BOWL AND BLADE
JUNE 9/14
FROZEN DRINKS
SMOOTHIES
FOOD
PUREE
NutriNinja
NutriNinja
PULSE
HIGH
MED
ON
OFF
1500
WATTS
LOW
AU
TO
AU
TO
AU
TO
A
UTO
BLEND
A
UTO
BLAST
FROZEN DRINKS
SMOOTHIES
FOOD
PUREE
NutriNinja
NutriNinja
PULSE
HIGH
MED
ON
OFF
1500
WATTS
LOW
AU
TO
AU
TO
AU
TO
A
UTO
BLEND
A
UTO
BLAST
FROZEN DRINKS
SMOOTHIES
FOOD
PUREE
NutriNinja
NutriNinja
PULSE
HIGH
MED
ON
OFF
1500
WATTS
LOW
AU
TO
AU
TO
AU
TO
A
UTO
BLEND
A
UTO
BLAST
NEW SHOOT LID
JUNE 9/14
HAS NEW BASE
NEW BOWL AND BLADE
JUNE 9/14
Blender with Auto-iQ™ Technology
a
®
c
e
h
a Food Processor Bowl
b Food Processor Lid
c Chopping Blade (food processor)
d Dough Blade (food processor)
e Feed Chute Lid
b
f
i
d
g
j
f Slicing/Shredding Disc
(food processor)
g Grating Disc (food processor)
h 24 oz. Mini Prep Bowl
i Spindle for Discs & Mini Prep Bowl
j Mini Prep Bowl Blade
CAUTION: Blade assemblies are sharp and
removable, handle with care. When handling the
blade assemblies, always hold them by the shaft.
BEFORE FIRST USE
1 Remove all packaging material and labels from the
2 Wash the lids, food processor bowl, mini prep bowl,
appliance.
discs, and blades in warm, soapy water with a soft
cloth. Use caution when washing the blade
assemblies as the blades are very sharp.
3 Rinse and dry thoroughly.
16
1-877-646-5288
4 The food processor bowl, mini prep bowl, discs, lids and
blades, are all dishwasher safe. It is recommended that
the lids and blades be placed on the top rack. Ensure
that the blades are removed from the containers before
placing in the dishwasher.
5 Wipe the motor base clean with a damp cloth.
Assembly and Use for the Processor Bowl
FROZEN DRINKS
SMOOTHIES
PUREE
PULSE
HIGH
MED
LOW
AUTO
AUTO
AUTO
ASSEMBLY
Fig. 1
AUTO
FROZEN DRINKS
SMOOTHIES
AUTO
PUREE
AUTO
LOW
MED
HIGH
PULSE
Fig. 5a Fig. 5b
NOTE: Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology can sense which jar is on the motor base.
The available function lights will illuminate depending
on which jar is placed on the motor base. (Fig. 1)
Use caution when handling the blade assemblies
as the blades are very sharp.
WARNING: Never leave the appliance unattended while
in use.
IMPO RTAN T: Make sure that the motor base is
plugged in for use.
1 Holding the desired blade by the top of the shaft, place
it onto the drive gear inside the bowl. Ensure that the
attachment is seated properly and is standing upright.
(Fig. 2)
NOTE: The blade will fit loosely on the drive gear.
2 Place the motor base on a clean, dry, level surface such
as a counter or table top.
3 Align and lower the Processor Bowl onto the motor
base. (Fig. 3) Handle should be aligned slightly to the
right of the “LOCK” symbol on the motor base.
4 Rotate the bowl clockwise until it locks in place, you will
hear a click when the lock is engaged. (Fig. 4)
Fig. 2
Fig. 3
Fig. 4
Fig. 6b
Fig. 6a
5 The bowl can be placed on the motor base two ways;
the handle can be on the front right corner or the front
left corner. (Fig. 5a, Fig. 5b)
6 Add the ingredients to the bowl, making sure that they
do not exceed the highest measured marking line on
the side of the bowl.
8 Holding the lid by the handle in the upright position,
place it on top of the Processor Bowl aligning the
triangle (
) located on the lid with the triangle ( )
located on the Processor Bowl handle. (Fig. 6a) Press
the handle down until you hear a click.
The triangles on the lid and the Processor Bowl handle
MUST be aligned in order for the blender to turn on.
(Fig. 6b)
NOTE: The 64 oz. bowl is not intended for blending
drinks. Do not overfill.
7 Plug the power cord into the electrical outlet and press
the power button ( ).
NOTE: As a safety feature, the power button ( ) will
flash and the motor will not work if the bowl and lid
are not installed correctly. When the bowl and lid
are installed properly, the power button ( ) will be
solid, indicating that the appliance is ready for use.
www.ninjakitchen.com
17
Assembly and Use for the Processor Bowl - cont.
Use caution when handling the blade assemblies as the blades are very sharp.
REMOVAL
Fig. 1
USE
Fig. 2 Fig. 3
USING THE CHOPPING BLADE ASSEMBLY
WARNING: Never leave the appliance unattended while
in use.
1 Holding the Chopping Blade assembly by the shaft,
place it onto the gear shaft inside the bowl. Ensure that
the attachment fits around the gear shaft and that it is
standing straight.
2 Add the ingredients and secure the bowl lid onto the
bowl. (Fig. 1)
3 Plug the power cord into the electrical outlet and press
on the power button (
4 Select the speed or Auto-iQ
your needs. Pulse ingredients for even chopping by
holding the Auto-iQ™ Pulse button until your desired
consistency is reached.
NOTE: Please refer to “Speed Settings & Uses” chart
for suggested uses and speeds.
5 When you have reached your desired consistency, stop
the appliance by pressing the power button (
wait for the blade to stop turning. (Fig. 2)
6 To remove the lid, press the release button on the lid
and pull the lid handle up to a 90° angle. (Fig. 2)
7 Turn the bowl counter-clockwise and lift it to remove it
from the motor base. (Fig. 3)
CAUTION: If pouring from the bowl, ALWAYS remove
the blade assembly first before pouring.
).
™
program that best suits
) and
USE
Fig. 4
USING THE DOUGH BLADE
WARNING: Never leave the appliance unattended while
in use.
1 Place the motor base on a clean, dry, level surface such
as a counter or table top. (Fig. 4) Press down on the
motor base to adhere it to a counter or table top to give
the unit a better grip using the suction cups.
2 Secure the bowl onto the motor base.
3 Holding the dough blade by the shaft, place it onto the
gear shaft inside the bowl. Ensure that the attachment
fits around the gear shaft and that it is standing straight.
4 Add the ingredients and secure the bowl lid onto the bowl.
5 Plug the power cord into the electrical outlet and press
on the power button (
suits your needs.
NOTE: Please refer to “Speed Settings & Uses” chart
for suggested uses and speeds.
6 Once finished making dough, stop the appliance by
pressing the power button (
stop turning. To remove the lid, press the release button
on the lid and pull the lid handle up to a 90° angle.
(Fig. 2)
7 Turn the bowl counter-clockwise and lift it to remove it
from the motor base. (Fig. 3)
). Select the speed that best
) and wait for the blade to
18
1-877-646-5288
Assembly and Use for the Disc Attachments
Use caution when handling the discs as the blades are very sharp.
USING THE DISCS
NOTE: Disc attachments must be used with the
feed chute lid.
IM PO RTAN T: Use only the High setting when using
either disc.
1 Place the motor base on a clean, dry, level surface such
as a counter or table top. (Fig. 5)
2 Secure the bowl onto the motor base.
3 Place the spindle inside the bowl.
4 Use the finger holes to grasp the selected disc and
place it over the spindle.
5 Place the feed chute lid on the bowl and turn clockwise
until you here a click indicating the lid is locked in
place. (Fig. 5)
6 Plug the power cord into the electrical outlet and press
up on the power toggle (
7 Select HIGH on the control panel. The discs will begin
spinning.
8 Add the food that you want to slice, shred or grate
through the feed chute on the lid. (Fig. 5) Use the
two-part food pusher to help guide the food through
the feed chute. The middle piece of the food pusher is
removable to use for smaller ingredients.
9 When finished,stop the appliance by pressing the power
button (
the button on the feed chute lid located near the handle
to unlock and turn the lid counter-clockwise. Lift to
remove from the processor bowl. Using the finger holes,
Fig. 5
carefully lift the disc out of the bowl and remove the
spindle.
) to turn the power “On”.
) and wait for the disc to stop turning. Press
www.ninjakitchen.com
19
Assembly and Use for the Mini Prep Bowl
WARNING: Never leave the appliance unattended while in use.
ASSEMBLY
Fig. 1
Fig. 3
USING THE 3 CUP MINI PREP BOWL
NOTE: The mini prep bowl must be used with the
flat food processor lid.
1 Place the 64 oz. bowl onto the motor base.
2 Holding the spindle by the shaft, place it onto the
gear shaft inside the 64 oz. bowl. Ensure that the
attachment fits around the gear shaft and that it is
standing straight. (Fig. 1)
3 Place the mini prep bowl aligning the spindle inside the
center post. (Fig. 2)
4 Hold the prep bowl blade by the shaft and carefully place
it over the center post of the mini prep bowl. (Fig. 3)
5 Add ingredients into the mini prep bowl.
6 Holding the lid by the handle in the upright position,
place it on top of the 64 oz. bowl aligning the arrow
(
) located on the lid with the arrow ( ) located on the
bowl’s handle. (Fig. 4) Press the handle down until you
hear a click.
Fig. 2
Fig. 4
USE
Fig. 5
7 Plug the power cord into the electrical outlet and press
on the power button (
8 Select the speed that best suits your needs. For best
results, hold the Auto-iQ
have reached your desired consistency. (Fig. 5)
NOTE: Please refer to “Speed Settings & Uses” chart
for suggested uses and speeds.
9 When you have reached your desired consistencey, stop
the appliance by pressing the power button
(
) and wait for the blade to stop turning.
10 To remove the lid, pull the lid handle up to a 90° angle
and lift the lid off. (Fig. 6)
11 Carefully hold the mini prep bowl blade by the shaft and
lift it out of the mini prep bowl. (Fig. 7)
12 Turn the bowl counter clockwise and then lift off the
base.
CAUTION: If pouring from the bowl, ALWAYS remove
the blade assembly first before pouring.
REMOVAL
Fig. 6
Fig. 7
).
™
Pulse button down until you
20
1-877-646-5288
Speed Settings & Uses for the Food Processor
FUNCTION CONTAINER BLADE TYPE
Mincing
Kneading and
Dough Mixing
Processing
Emulsifying
Grinding
Grating
Chopping
Batters
Slicing/Shredding
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Food Processor
Bowl
Chopping Blade Auto-iQ™ Pulse
Dough Blade Low
Chopping Blade
Chopping Blade
Chopping Blade Medium Meat
Chopping Blade
Grating Disc
Chopping Blade Auto-iQ™ Pulse
Dough Blade Low
Reversible Slicing
Shredding Disc
SPEED or
PROGRAM
™
Puree
Auto-iQ
Low
Medium
High
Low
Medium
™
Pulse
Auto-iQ
High (when using Disc)
High
TYPE OF FOOD
Onion
Garlic
Herbs
Bread Dough
Pie Dough
Pizza Dough
Pretzel Dough
Cookie Dough
Pâtés
Stewed Fruits
Dips
Apple Sauce
Spreads
Baby Food
Salad Dressings
Dips
Sauces
Grated Cheese
Bread Crumbs
Spices
Salsa
Vegetables
Nuts
Cake Mixes
Batters
Vegetables
Cheese
www.ninjakitchen.com
21
Care & Maintenance
HOW TO CLEAN
CAUTION: Make sure that the motor base is unplugged
from the power source before inser ting or removing any
attachment and before cleaning.
CAUTION: DO NOT immerse the motor base into water or
any other liquid.
1 Separate/remove all parts from each other.
2 Clean the motor base with a damp cloth and wipe dry.
3 Place the Food Processor Bowl and Mini Prep Bowl in
the dishwasher. Place the lids and attachments on the
top rack. Use caution when handling the blade
assemblies as the blades are very sharp.
NOTE: You may also wash the containers by filling ¾ of
the container with warm water and a drop of dish washing
detergent, placing the corresponding lid on the container
and pressing the
Once clean, remove the container from the motor base.
Rinse the container, attachment and lid under running
water. Allow all the parts to dry before storing.
Please call customer service if any servicing needs to be
performed on the appliance at 1-877-646-5288.
Auto-iQ™
Pulse button a few times.
HOW TO STORE
1 Store the
Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology
motor base, chopping blade inside the bowl and lid on the
pitcher. Do not place anything on top. S
attachments along side the appliance or in a cabinet
where they will not be damaged and won’t cause a
hazard.
upright with the Food Processor Bowl on the
tore the rest of the
RESETTING THE MOTOR THERMOSTAT
The Nutri Ninja® | Ninja® Blender with Auto-iQ™
Technology features a unique safety system which
prevents damage to the unit’s motor and drive system
should you inadvertently overload your appliance. If
the appliance is being overloaded, the motor
will stop. Allow the appliance to cool for
approximately 15 minutes. To reset the appliance,
follow the resetting procedure below:
1
Unplug the appliance from the electrical outlet.
2
Remove and empty the container and ensure that no
food is jamming the cutting blades or attachments.
3
Allow the appliance to cool for approximately 15
minutes.
4
Re-install the container onto the base and re-plug the
appliance into the electrical outlet.
5
Proceed to use the appliance as before making sure not
to exceed the recommended maximum capacities.
22
1-877-646-5288
ONE (1) YEAR LIMITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from material defects and workmanship for a period of one (1)
year from the date of purchase when utilized for normal household use, subject to the following conditions, exclusions and
exceptions.
The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at our option.
This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been tampered with or
used for commercial purposes. This Limited Warranty does not cover damage caused by misuse, abuse, negligent handling or
damage due to faulty packaging or mishandling in transit. This Limited Warranty does not cover damage or defects caused by
or resulting from damages from shipping or repairs, service or alteration to the product or any of its parts, which have been
performed by a repair person not authorized by EURO-PRO Operating LLC.
If your appliance fails to operate properly while in use under normal household conditions within the warranty period, return
the complete appliance and accessories, freight prepaid. For assistance with warranty service options or customer support,
please call our customer care and product specialists at , call 1 (877) 646-5288 or visit our website www.ninjakitchen.com.
If the appliance is found to be defective in material or workmanship, EURO-PRO Operating LLC will repair or replace it free of
charge. Proof of purchase is required and a fee of $19.95 will apply to cover the cost of return freight. *
This Limited Warranty is extended to the original purchaser of the unit and excludes all other legal, implied and/or conventional
warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations expressly assumed
by it under the terms of this Limited Warranty. In no event is EURO-PRO Operating LLC liable for incidental or consequential
damages to anyone of any nature whatsoever. Some states do not permit the exclusion or limitation of incidental or
consequential damages, so the above may not apply to you.
This Limited Warranty gives you specific legal rights, and you may also have other rights which vary from state to state or from
province to province.
*IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase date and
to attach tag to item before packing with your name, complete address and phone number with a note giving
purchase information, model number and what you believe is the problem with the item. We recommend you
insure the package (as damage in shipping is not covered by your Limited Warranty). Mark the outside of your
package “ATTENTION CUSTOMER SERVICE”.
Product Registration
Please visit www.ninjakitchen.com or call 1-877-646-5288 to register your new Ninja™ product within ten (10) days of
purchase. You will be asked to provide the store name, date of purchase and model number along with your name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification. By registering you
acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying instructions.
www.ninjakitchen.com
23
Euro-Pro Operating LLC
US: Newton, MA 02459
CAN: Ville St-Laurent, QC H4S 1A7
1-877-646-5288
www.ninjakitchen.com
Copyright © Euro-Pro Operating LLC 2014
Euro-Pro, Auto-iQ, Nutri Ninja, Pro Extractor Blades and Ninja
are trademarks of Euro-Pro Operating LLC.
Illustra tions may differ from a ctual product. We are c onstantly striv ing to improve our produ cts,
therefore the specifications contained herein are subject to change without notice.
Printed in China
BL6 42W_ 30_I B_E _140617_1
Loading...
