Sharp Aquos Phone Extended User Guide

SH80F

’11.9 (1st Edition)

Extended User Guide

Thank you for purchasing “AQUOS PHONE SH80F”.

AC Adapter

Battery Pack SH30

microUSB cable SH10

Start-up Guide

microSDHC Card is inserted to the

phone by default.

microSDHC Card (4 GB) (sample) (includes user’s guide)

SH80F

Be sure to read this manual before and during use to ensure proper operation.

Basic package

The screens and illustrations in this manual are shown as examples. The actual screens and illustrations may differ. The explanations in this manual are based on default settings. The actual screens may differ depending on settings changed after purchase. Note that “SH80F” is referred to as “phone” in this manual. This manual refers to microSD™ Card as “microSD Card” or “microSD”. Reproduction of this manual in part or in whole is prohibited. The contents of this manual are subject to change without prior notice.

Introduction

Basic package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Notes on using SH80F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Before using the handset P. 3

Basic operation P. 13

Phone/Message P. 20

Various settings P. 23

Internet P. 29

Multimedia P. 30

File management P. 35

Applications P. 39

Appendix/Index P. 42

Assembly, Part names and functions, microSD Card, Charging, Turning power ON/OFF, Touch panel operations, Operation while using applications, Searching for information in the phone and online, Character entry, Changing the phone language, Initial setting

Home screen, Application screen, Screen display/icon, Market

Phone, Contacts, Importing/Exporting contacts, Mail

Setting menu, Profile, Energy saving settings, Wireless & networks, Call settings, Sound, Display, USB connection, Location & security, Applications, Accounts & synchronisation, Privacy, Storage, Language & keyboard, Voice input & output, Accessibility, Date & time, About phone, Security codes

Browser

Camera, Gallery, Picture (3D-capable), Music

Contents manager, Bluetooth® function, External connector device, Home network settings

GPS/Navigation, Compass, Calendar, Clock, Notepad, Voice recorder, Calculator

Troubleshooting (FAQ), OS version upgrade, Safety precautions, Intellectual property right, Support on the web, General enquiries, Index

Notes on using SH80F

Google applications and its service contents are subject to change without prior notice. This phone automatically performs communication for some functions, for example, to synchronise data, check the latest software version or maintain connection

with the server. Also, making a communication with large-volume data such as downloading applications or watching videos will lead to higher packet communication charges. Subscription to flat-rate packet communication services is highly recommended.

Setting this phone to Silent mode does not mute sounds (camera shutter sound etc.) other than the ring tone, operation sound, and various notification sounds. For details on checking your phone number (own number) nP. 23 For details on software version of your phone nP. 28 New functions may be added to this phone and the operation method may change by upgrading the OS version. Check the SHARP website for the latest information

of additions and changes.

If the OS is upgraded, some applications that used in the previous OS version may not be available or some unintended bugs may occur. Read the terms of use of Google Inc. for details on Google services. Also, read each terms of use for details on other web services. If your phone is lost, change your password for each account using a PC to prevent other persons from using Google services such as Google Talk, Gmail and

Android Market.

The phone is available without microSD Card. However, some data such as images shot with camera or voices recorded with voice recorder can be saved only to

microSD Card. Also, data cannot be sent and received using Bluetooth connection without microSD Card. It is recommended that microSD Card be inserted to use the phone.

Introduction

Assembly

Hook fingers onto the A area

Tray

Ta b

Fit the notch of the SIM card to that of the tray.

You cannot make a call and use functions such as packet communication etc. on the phone without inserting a SIM card. Before inserting or removing the SIM card, turn off the power, position the back facing upwards and remove the battery pack. Hold the phone securely with your both

hands.

Use the Battery Pack SH30 exclusive to the phone. For attaching or removing the battery pack, turn off the power, position the back facing upwards, and hold the phone securely with your both hands.

/ Inserting SIM card and battery pack

Hook your finger into the slot and open the external connector terminal cover

Slot

Hook your fingertip under the back cover as shown and remove it upward

Hook your finger onto the SIM card tab and pull out the tray (1)

: Pull the tray out straight until it stops.

Hold the SIM card with the IC (gold) side turned up and set on the tray (2)

Notch

IC (gold)

Push the tray all the way in (3)

Attach the battery pack

: With the recycle mark side turned up, place the connector terminal of the phone to that of the battery pack and attach the battery pack.

With recycle mark side up

Connector terminal

Put the back cover onto the phone in the correct direction and press around the back cover securely to attach

: After attaching the back cover, replace the external connector terminal cover.

Before using the handset

/ Removing SIM card and battery pack

Remove the battery pack

: The battery pack has a tab that makes it easy to remove. Hook a finger on the tab to prevent excessive force on it and remove the battery pack upward.

Ta b

Hook a finger on the tab, pull the tray out (1) and remove the SIM card (2)

: Do not allow the SIM card to fall when removing it.

Note that inserting or removing the SIM card forcibly may damage the SIM card or deform the tray.

Refer to the SIM card user’s guide for more information on the SIM card.

Do not misplace the SIM card once it is taken out.

When the tray falls off, slide the tray in straight along the guide rail.

Securely close the back cover. If not closed securely, the back cover may come off and the battery pack may fall out due to vibration.

The back cover may be damaged when attaching or removing it forcibly. Make sure not to use unnecessary force.

Using unnecessary force when attaching or removing the battery pack may damage the connector terminal for the battery pack (charger terminal) on the phone.

Before using the handset

Part names and functions

1 Incoming/Charging lamp

The lamp will illuminate/flash according to the function being used and the situation.

2 H: Power key

Use to set/disable the sleep mode, turn the power on/off, etc.

3 Display/Touch panel 4 Sub camera 5 Earpiece 6 Proximity sensor/Brightness sensor

The proximity sensor detects the distance to the face and prevents inadvertent operation of the touch panel during a call. The brightness sensor detects the brightness of the surrounding area and adjusts the brightness of the backlight.

Do not cover the sensor area with your hand or a sticker. The sensor may not work properly.

7 z: Menu key

Displays available functions (menus) in a screen.

8 |: Home key

Displays the main page of the home screen.

9 {: Back key

Returns to the previous screen.

a HDMI terminal (type D)

Use to connect commercially available HDMI cable.

b x/y: Volume UP/DOWN key

Adjusts the volume in each function.

c }: Search key

Displays the quick search box.

d G: Shutter key

Shoots pictures or videos.

e Earphone/Microphone terminal f Speaker

Ring tone, music, etc. can be heard from here. The other party’s voice can be heard from here during a hands-free call.

g Internal antenna h External connector terminal i Strap hole j GPS antenna k microSD Card slot l Mobile light

Illuminates/flashes while you are activating the camera/video camera.

m Mouthpiece/Microphone n Back cover o Twin camera

*1 The display for the phone is manufactured using high-precision technology, but it may occasionally contain dots that fail to light or that remain permanently lit. This is

not a malfunction.

*2 The antenna is built into the phone. Covering the antenna area with your hand may influence the quality.

Before using the handset

microSD Card

You can save data in the phone to microSD Card or import data in microSD Card to the phone.

The SH80F is compatible with microSD Card of up to 2 GB and microSDHC Card of up to 32 GB (as of 2011). Note that the provided information is the information checked for operation. SHARP shall not be liable for all operations.

The size of a file that can be used is up to 2 GB. Do not turn off the phone immediately after inserting the microSD Card in the phone (while writing information needed for phone operation) or while editing data on the

microSD Card. Data may be damaged and operation may not work properly.

Format unformatted microSD Cards on the phone before use (nP. 27). microSD Cards formatted by PCs or other devices may not be used properly by the phone. Data saved on the microSD Cards from other devices may not be displayed or played on the phone. Some data saved to the microSD Card from the phone may not be

displayed or played on other devices.

Back up the data saved in a microSD Card and store in another place. SHARP shall not be liable for any loss or change of the saved data. Before inserting or removing (including after unmounting) the microSD Card, turn off the power and position the back facing upwards. Hold the phone securely with

your both hands. Data may be damaged and operation may not work properly.

/ Inserting microSD Card

Unlock the microSD Card slot by sliding it in the direction of the arrow (1)

: Slide the microSD Card slot until a click is heard.

Open the microSD Card slot and insert the microSD Card straight into inside with the metal terminal side turned inside (2)

: Do not force the microSD Card in at an angle or with the wrong side up.

The microSD Card slot may be damaged.

Close the microSD Card slot slowly and lock the microSD Card slot by sliding it in the direction of the arrow (3)

: Slide the microSD Card slot until a click is heard.

/ Removing microSD Card

Unlock the microSD Card slot (1) in the same procedure as step 1 of “Inserting microSD Card”

Open the microSD Card slot and remove the microSD Card by pulling it straight out (2)

Close the microSD Card slot in the same procedure as step 3 of “Inserting microSD Card” and lock it (3)

Before using the handset

Charging

microUSB plug (with the character side down)

External connector terminal

Charging lamp

The battery pack is not fully charged at the time of purchase. Be sure to charge the battery using the exclusive AC adapter and microUSB cable SH10 before use.

/ Cautions while charging

Do not charge for a long time with the power left on. If the phone is left on after charging is complete, the battery pack charge decreases.

In that case, the AC adapter charges the battery again. However, depending on the time when the phone is disconnected from the AC adapter, the battery charge level may be low or the battery may only be usable for a short time.

If the phone is left for a long time even after the charging is completed, the battery level may decrease. When the battery is empty and the phone is recharging, charging lamp may not illuminate immediately. If the battery empty alert is displayed and the power cannot be turned on, charge the battery for a while. While charging, the phone may not turn on even when charging lamp is illuminated in red. Charge longer and try turning power on again. Frequently recharging the battery while there is a reasonable charge remaining may shorten the life of the battery pack. It is recommended that the battery be reduced

to a minimum level before recharging.

/ Lamp display

Charging lamp illuminates in red while charging, and it turns off when charging is completed. Check that the battery pack has been properly attached when charging lamp flashes red. The lamp also flashes red when the battery pack has reached the end of its

service life.

The battery pack can also be charged with the phone turned on (While charging, the battery icon appears with [w] superimposed). When the battery becomes warm, charging may automatically stop even if the battery has not been fully charged. Charging resumes after the temperature lowers to an

appropriate temperature.

/ Battery pack service life

Battery pack is a consumable product. Service time per charge is gradually reduced every time the battery is charged. When service time per charge is reduced to about half of the default time, this means that the battery pack is approaching the end of its service life. In such a case, it

is recommended to replace the battery pack as soon as possible. Depending on usage, the battery pack may swell as it approaches the end of its service life, but this will not cause problems.

If you operate the phone while charging for a long time, the service life of the battery pack may become shorter than estimated.

/ AC adapter

Refer to user’s guide of AC Adapter. AC Adapter covers from 100 to 240V AC.

Charging with AC adapter

Insert the AC adapter connector horizontally into the external connector terminal of the microUSB cable

: Check the direction (front or rear) of the connector, keep it parallel with the microUSB cable and securely push all the way in.

Open the external connector terminal cover of the phone and insert the microUSB plug of the microUSB cable horizontally

into the external connector terminal

: Insert the microUSB plug horizontally with the character side turned down.

When inserting the AC adapter power plug into an outlet, charging lamp illuminates and charging starts

When charging lamp turns off, charging is complete

: When charging is complete, remove the microUSB plug horizontally from the phone. : When removing the connector from the microUSB cable and unplug it horizontally.

Do not forcibly insert or remove. May cause damage to the external connector terminal, the microUSB plug and the connector.

Pull the adapter out of the outlet if it will not be used for a long time.

Do not forcibly pull the external connector terminal cover. May damage the cover.

Do not place objects near the phone when charging. May damage the phone.

Charging with microUSB cable

When the phone is turned on, you can charge the phone by connecting the phone to a PC with the microUSB cable SH10.

Install the USB driver to the PC in advance. And also enable USB battery charge (nP. 26). For details on connecting to a PC nP. 37

Before using the handset

Turning power ON/OFF

/ Turning power ON

H (for at least 2 seconds)

: When you use your phone for the first time, setting guide helps you enter essential settings.

/ Turning power OFF

H (for at least 1 second)/[Power off]/[OK]

/ Sleep mode

The screen is off and the sleep mode is activated when H is pressed or the phone is not in use for a set length of time. Press H/| in the sleep mode to deactivate the sleep mode.

/ Touch panel lock

When the power is turned on or the sleep mode is deactivated, the touch panel is locked. Tap and hold [J] and slide it up into [K] to unlock.

Key operation in touch panel unlock screen

To set/disable Silent mode: y (for at least 1 second)

To illuminate the mobile light: G (for at least 1 second)

• Press any key or tap [J] to turn off.

Touch panel operations

You can operate by touching the touch panel (display) directly with your finger.

Operations differ depending on the function and screen in use.

Cautions when using the touch panel

The touch panel is designed to be lightly touched with your finger. Do not forcefully press with your finger or press with a pointed object (fingernail, ballpoint pen, pin,

etc.).

In the following cases, the touch panel may not work even if you touch it.

Operation with a gloved finger Operation with a fingernail Operation with foreign objects placed on the operation pad Operation on the touch panel on which a protective sheet or a sticker is put

/ Tap

Touch a key or an item displayed on the screen to select or set it.

Tap your finger on the touch panel

/ Tap and hold

When you tap and hold on the screen, a menu may appear depending on the function and screen in use.

Keep your finger on the touch panel

/ Slide

Slide your finger up/down while a menu is displayed etc. to scroll the screen. When you touch a menu or item by mistake, slide your finger away from the menu or item to cancel the selection.

Keep your finger on the touch panel and slide it

Before using the handset

/ Flick

Set item list

Flick left/right in the home screen etc. to switch pages.

Quickly slide your finger then raise it from the screen

/ Pinch

Pinch while displaying an image etc. to zoom.

Put two fingers on the touch panel and slide them with putting a distance between two fingers further apart/closer to zoom

in/out

Operation while using applications

/ Switching the settings

When a check box is displayed beside the setting item, you can set it enabled/disabled or [ON]/[OFF] by tapping it.

Example: Energy saving settings screen, Alarm setting contents screen

[0]: Enabled, [1]: Disabled

/ Retrieving menu

When you press z or tap and hold on the screen, functions (menus) available in that screen appear.

Example: Notepad screen

/ TapFlow UI

TapFlow UI is a menu to be displayed by tapping [T] when using Camera, Video Camera and Picture (3D-capable). The kinds, position and size of the displayed menu differ depending on the frequency of using menu.

Example: Picture shooting screen

/ Vertical/Horizontal display

The screen display is switched when you tilt the phone.

Vertical/Horizontal display will not switch if the phone is turned while parallel to the ground. The screen display may not be switched depending on the application being used. The screen display may not be switched properly when a sound or a vibration is activated. Vertical/Horizontal display may not appear properly right after the screen or power is turned on. You can set the display not to automatically switch (nP. 25). Screens may be displayed in the full screen depending on the application when switching the vertical display to the horizontal display.

Before using the handset

/ Multi Assistant (Multitask)

If you cancel the use of function by pressing | etc., the function does not end and remains activated in background. Display running functions as a list and switch functions to use by using Multi Assistant (Multitask).

In the home screen, [W]

: Alternatively, | (for at least 1 second).

Select a function to be used

: To terminate a function: [Y] : To terminate all functions: [Quit all]/[Yes]

The functions being activated in background may end depending on the memory usage or application. Also, the display of running function on the Multi Assistant

(Multitask) screen may change depending on the memory usage.

/ Shooting screenshot

Press H + | to save the screen being displayed to the microSD Card.

Data cannot be saved while using home network or displaying e-books. In addition, image part cannot be saved while playing video such as YouTube.

Data may not be saved completely or partially depending on the application.

Searching for information in the phone and online

In the home screen, }

: Alternatively, [R]/[Google Search] in the home screen. : Quick search box appears.

Enter the keyword

: Search applications and data that start with the entered character and display a list of them.

Select the search result

: When a search result is an application, the corresponding application is activated.

/ Searching sites by voice

In the quick search box, [!]

: Alternatively, } (for at least 1 second) in the home screen. : Or, [R]/[Voice Search] in the home screen.

Enter the keyword by voice

Select the keyword

Character entry

Entering characters

Select the first character of a word and slide your finger to the second character without removing the finger from the screen

Keep your finger on the second character for a moment and then slide the finger to the next character

Continue until you have finished the word

Raise your finger from the last character

Keyboard layout

1 Character entry keys

Tap to enter characters, symbols or numbers. Tap and hold to enter additional characters.

2 Shift key

Tap to switch between upper/lower case letters.

3 Help key

Tap to view help information etc.

4 Delete key

Tap to delete characters.

5 Enter key

Tap to insert a line break.

6 Symbol/ABC key

Tap to switch between symbols/numbers and alphabet.

7 Language key

Tap to switch input languages.

8 Space key

Tap to enter a space.

9 Voice inputting key

Tap to change to the voice input mode.

Changing the phone language

In the home screen, [R]/[Settings]/[Language & keyboard]/[Select language]

Select the language

Before using the handset

Initial setting

Setting access point

You can add or change the access point if necessary.

/ Checking access point in use

In the home screen, [R]/[Settings]/[Wireless & networks]/[Mobile networks]/[Access Point Names]

/ Setting additional access points

In the home screen, [R]/[Settings]/[Wireless & networks]/[Mobile networks]/[Access Point Names]/z/[New APN]

[Name]/enter the name of the network profile to create/[OK]

[APN]/enter the access point name/[OK]

Enter other items required by telecommunications carriers/z/[Save]

If the settings of MCC and MNC are changed and they do not appear on the screen, reset the settings or set the access point manually.

Resetting an access point

Reset an access point to default setting.

In the home screen, [R]/[Settings]/[Wireless & networks]/[Mobile networks]/[Access Point Names]/z/[Reset to

default]

If the phone fails the automatic resetting of an access point due to signal status e.g. outside of the network service area etc., you will be required to reset the access

point again manually.

Wi-Fi settings

Wi-Fi allows you to access the Internet using wireless LAN function. To use Wi-Fi, you need to connect to the wireless LAN access point (Wireless LAN base unit).

The radio interference with Bluetooth devices

Wireless LANs (IEEE 802.11b/g/n) use the same frequency band (2.4 GHz) as Bluetooth devices. Therefore, using the wireless LAN device near a Bluetooth device

may cause radio interference, lowering of communication speed, noise or connection failure. In this case, turn off the Bluetooth device or keep the phone and the wireless LAN device at least approximately 10 m away from the Bluetooth device.

Packet communication is also available while Wi-Fi function is enabled. Wi-Fi connection is prioritised while Wi-Fi connection is set, but the connection will be

automatically switched to that of packet communication once Wi-Fi connection is terminated. Note that packet communication charges will be incurred in such cases.

Refer to the manual of your wireless LAN base unit when using the access point at home. Operate access point registration near the access point. Enable Wi-Fi function in advance (nP. 24).

In the home screen, [R]/[Settings]/[Wireless & networks]/[Wi-Fi settings]

Select an item

Wi-Fi: Enable Wi-Fi function. Network notification: You get notified by the notification icon when open Wi-Fi network is detected. Wi-Fi sleep policy: Set the timing to switch Wi-Fi sleep. Easy Wi-Fi registration: Register WPS-compatible access point with each method. Add WiFi network: Register access points which are not compatible with WPS manually.

: Available access points are displayed as items in “Wi-Fi networks”. To connect, select an access point to be used/[Connect].

[Easy Wi-Fi registration]

The registration process takes a few minutes. After completing the registration process, ensure that it is possible to connect to the access point.

[Add WiFi network]

This function supports WEP, WPA/WPA2 PSK, 802.1xEAP as the security setting.

/ Disconnecting

In the home screen, [R]/[Settings]/[Wireless & networks]/[Wi-Fi settings]

Select the connected access point/[Forget]

: Disconnect with the password retained.

Wi-Fi connection can be terminated by disabling the Wi-Fi function. Wi-Fi will automatically connect to a previously connected access point as long as it is available

when the function is re-activated.

Setting up mail account

In the home screen, [R]/[Email]

: Only when an account is not set, the account setting screen appears.

Enter mail address and password/[Next]

: Provider information is preset for some mail accounts, and a receiving mail server and a sending mail server are automatically set.

When you use an account whose provider information is not preset, it is necessary to set a receiving mail server and a sending mail server manually. For details on

those settings, contact the Internet service provider you use.

Enter an account name and your name/[Done]

The account which is registered first is automatically given priority to normal use. To change an account’s priority, you will need to set it as the default account.

When you delete an account, all mails delivered to that account are deleted. When there is any protected mail, the account cannot be deleted.

When the account type is Exchange, entering “\UsernameDomain” in the “Domain\Username” area is required to set a receiving mail server manually depending on the provider to use. Contact the administrator of the server for details.

Before using the handset

Setting up Google account, etc.

In the home screen, [R]/[Settings]/[Accounts & sync]/[Add account]

Select the account type

Set up an account

The account setup screen appears when an application that requires an account is activated without an account set.

Keep a separate memo of the set account and password.

Retrieving your Google account password

If you forget your Google account password, retrieve it.

In the home screen, [R]/[Internet]

Enter “http://www.google.com/” in the URL entry field/[I]/[Sign in]/[Can’t access your account?]/follow the

instructions on the screen

Before using the handset

Home screen

Viewing home screen

The home screen appears when the phone power is turned on. You can paste widgets or activate applications by selecting shortcuts or quick menus.

The desktop display has five pages, and you can paste shortcuts, widgets or folders in each page.

1 Folder

Paste a folder to display the data in the folder quickly and to store shortcuts into the folder.

2 Switch 2D/3D display of the home screen and application screen

Tap to switch 2D/3D display of the home screen and application screen.

3 Display application screen

Tap to display an application screen.

4 Widget

Paste a widget to use simple functions such as calendar or compass. The phone supports standard Android widgets.

5 Shortcut

Paste a shortcut to quickly activate a frequently used application.

6 Indicator

Indicates the displayed page. Tap to display a thumbnail of the selected pages. Tap the thumbnail to move to the desired page.

7 All the pages as a list

Tap to display all the pages as a list. Tap the thumbnail to move to the desired page. [P] appears in the main page.

8 Quick menu

Paste a shortcut to quickly activate an application. Slide your finger to the left/right to navigate through the shortcuts.

Managing pages

/ Adding pages

You can add up to ten pages in the home screen.

In the home screen, z/[Home settings]/[Add sheet]

: Alternatively, [Q]/[Add] to add the pages.

Select the destination

/ Sorting pages

In the home screen, [Q]/tap and hold a thumbnail

Slide it to the destination

/ Deleting pages

In the home screen, z/[Home settings]/[Delete sheet]

: [Q]/tap and hold a thumbnail/slide it to [X] to delete pages.

Managing quick menu

/ Creating a shortcut in the quick menu

You can add up to nine shortcuts to a quick menu. If there are already nine, move or delete an application before adding another.

In the home screen, tap and hold a shortcut

Slide it to the quick menu

/ Moving a shortcut from the quick menu

Tap and hold a shortcut in the quick menu

Slide it to the destination

/ Deleting a shortcut from the quick menu

Tap and hold a shortcut in the quick menu

Slide it to [X]

Managing shortcut/widget/folder

/ Pasting shortcut/widget/folder

In the home screen, z/[Home settings]/[Add shortcut]/[Add widgets]/[Add folders]

Select a type

/ Moving shortcut/widget/folder

In the home screen, tap and hold a shortcut/widget/folder

Basic operation

Slide it to the destination

: If you slide it to the end of the page and stop, the previous/next page is displayed and you can move to the previous/next page. : If you slide it to [Q] and stop, a thumbnail is displayed and you can move to other pages by using it.

/ Deleting shortcut/widget/folder

If you delete the widgets installed by default, you can download them from the manufacturer’s site.

In the home screen, tap and hold a shortcut/widget/folder

Slide it to [X]

/ Renaming folder

In the home screen, select a folder

z/[Change folder name]

: Alternatively, tap and hold the folder name on the top of the folder.

Enter a folder name/[OK]

/ Displaying application information

In the home screen, tap and hold a shortcut/widget

Slide it to [S]

/ Deleting all invalid icons

If applications are installed in the microSD Card, the icons of them will turn to [T] when the microSD Card is removed. You can delete all the [T] collectively.

In the home screen, z/[Home settings]/[Delete all invalid icons]/[Yes]

Application icons in the application screen will not be deleted. Uninstall the applications or perform Delete all invalid icons in the application screen (nP. 16, 26).

Changing wallpaper

In the home screen, [R]/[Settings]/[Display]/[Wallpaper]

Select an application

Select a wallpaper

Application screen

Application screen layout

Loaded applications are displayed as icons in the application screen. Select an icon to activate an application. You can also use a quick menu.

If you install a new application, an icon is added to the application screen. If you uninstall an application, its icon is deleted. If an icon is deleted, other icons are moved over and aligned on the screen. However, icons in the next page are not

moved.

1 Application icon 2 Switch 2D/3D display

Tap to switch 2D/3D display.

3 Display home screen

Tap to display home screen.

4 Indicator

Indicates the displayed page. Tap to display a thumbnail of the selected pages. Tap the thumbnail to move to the page.

5 All the pages as a list

Tap to display all the pages as a list. Tap the thumbnail to move to the page.

6 Quick menu

Paste a shortcut to quickly activate an application. Slide your finger to the left/right to navigate through the shortcuts.

Application list

Icon Application Description

Phone Make and receive calls and view your call history (nP. 20).

Internet Display a website using packet communication or Wi-Fi (nP. 29).

Email Send and receive Email messages (nP. 21).

Gmail Send and receive Gmail messages (nP. 22).

Basic operation

Icon Application Description

Messaging Use SMS to send and receive text and multimedia messages (nP. 22).

Market Use Android Market to download free and paid applications on your phone (nP. 19).

Maps Use Google Maps. You can find your present location, and use the navigation function to get

Clock Use WorldClock (nP. 40), Alarm (nP. 40), StopWatch (nP. 41) and Timer (nP. 41).

Settings Change the settings for each area of the phone.

Contacts Keep track of your contacts (nP. 20).

Camera Shoot pictures (nP. 32).

Video Camera Shoot videos (nP. 32).

HDMI Connect the phone to TV with HDMI terminal (nP. 37).

YouTube Use YouTube. YouTube is a free online video streaming service. You can play, search, and

Picture (3D-capable) Sort images and videos by people, event and location and use them (nP. 33).

Contents Manager Manage data stored to the microSD Card (nP. 35).

Gallery Displays images (nP. 33).

Music Play music (nP. 34).

Voice Recorder Record your voices and replay them (nP. 41).

directions to your destination (nP. 39).

The same operation can be performed by selecting z/[Settings] on the home screen.

upload videos.

Voice Search Search information online using voice (nP. 10).

Built-in 3D Play 3D videos and view 3D images which are pre-installed on the phone.

TV Use Orange TV player. You can watch TV on your phone.

Talk Use Google Talk. Google Talk is an instant message service provided by Google.

Compass Check present location and azimuth (nP. 40).

Places Use Google Places. You can search for facilities near your present location according to

Latitude Use Google Latitude. You can check where a friend is on the map and share status

Navigation Use Google Maps Navigation. You can search for a route from the present location to the

NFS Shift A racing game in which you can drive your car by tilting the phone.

The Sims 3 A life simulation game in which you can control your own Sims.

Google Search Find information in the phone and online (nP. 10).

Calculator Performs calculations (nP. 41).

Calendar Manage the schedule (nP. 40).

You can communicate with other users in real time with phone or on the website by using Google Talk.

genre by using Places.

messages by using Latitude.

destination by using Navigation (nP. 39).

This is a trial version of The Sims 3.

Notepad Save a note (nP. 41).

Basic operation

+ 35 hidden pages
