Page 1

32N-S500 32N-X2000

SERVICE MANUAL

S60B432N-S500

COLOR TELEVISION

Chassis No. SN-93

32N-S500

MODELS

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

32N-X2000

CONTENTS

Page

» ELECTRICAL SPECIFICATIONS ...........................................................................................................1

» IMPORTANT SERVICE SAFETY PRECAUTION ...................................................................................2

» LOCATION OF USER'S CONTROL .......................................................................................................4

» INSTALLATION AND SERVICE INSTRUCTIONS..................................................................................5

» CHASSIS LAYOUT ...............................................................................................................................12

» BLOCK DIAGRAM ................................................................................................................................16

» SCHEMATIC DIAGRAMS.....................................................................................................................20

» PRINTED WIRING BOARD ASSEMBLIES ..........................................................................................40

» REPLACEMENT PARTS LIST..............................................................................................................45

» PACKING OF THE SET........................................................................................................................65

ELECTRICAL SPECIFICATIONS

POWER INPUT...................................................... 120V AC 60 Hz

POWER RATING .................................................................. 158W

PICTURE SIZE ........................................... 3,073cm2 (476sq inch)

CONVERGENCE ............................................................. Magnetic

SWEEP DEFLECTION .................................................... Magnetic

FOCUS ............................................... Hi-Bi-Potential Electrostatic

INTERMEDIATE FREQUENCIES

Picture IF Carrier Frequency ..................................... 45.75 MHz

Sound IF Carrier Frequency...................................... 41.25 MHz

Color Sub-Carrier Frequency .................................... 42.17 MHz

(Nominal)

AUDIO POWER

OUTPUT RATING .................... 5W + 5W (at 10% distortion and

Dual CH Operate)

SPEAKER

SIZE ............................................................... 12 x 6 cm (2 pcs.)

VOICE COIL IMPEDANCE .............................. 6 ohm at 400 Hz

ANTENNA INPUT IMPEDANCE

VHF/UHF.....................................................75 ohm Unbalanced

TUNING RANGES

VHF-Channels...............................................................2 thru 13

UHF-Channels ............................................................14 thru 69

CATV Channels...........................................................1 thru 125

(EIA, Channel Plan U.S.A.)

Specifications are subject to change without prior notice.

SHARP CORPORATION

This document has been published to be used for after sales service only. The contents are subject to change without notice.

Page 2

32N-S500 32N-X2000

IMPORTANT SERVICE SAFETY PRECAUTION

Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow:

WARNING

1. For continued safety, no modification of any circuit should be attempted.

2. Disconnect AC power before servicing.

3. Semiconductor heat sinks are potential shock hazards when the chassis is operating.

4. The chassis in this receiver has two ground systems which are separated by insulating material. The nonisolated (hot) ground system is for the B+ voltage regulator circuit and the horizontal output circuit. The isolated ground system is for the low B+ DC voltages and the secondary circuit of the high voltage transformer. To prevent electrical shock use an isolation transformer between the line cord and power receptacle, when servicing this chassis.

CAUTION: FOR CONTINUED PROTECTION AGAINST A RISK OF FIRE, REPLACE

5A 125V

ONLY WITH SAME TYPE 5A125V FUSE.

SERVICING OF HIGH VOLTAGE SYSTEM AND PICTURE TUBE

When servicing the high voltage system, remove the static charge by connecting a 10k ohm resistor in series with an insulated wire (such as a test probe) between the picture tube ground and the anode lead. (AC line cord should be disconnected from AC outlet.)

1. Picture tube in this receiver employs integral implosion protection.

2. Replace with tube of the same type number for continued safety .

3. Do not lift picture tube by the neck.

4. Handle the picture tube only when wearing shatterproof goggles and after discharging the high voltage anode completely.

X-RADIATION AND HIGH VOLT AGE LIMITS

1. Be sure all service personnel are aware of the procedures and instructions covering X-radiation. The only potential source of X-ray in current solid state TV receivers is the picture tube. However, the picture tube does not emit measurable X-Ray radiation, if the high voltage is as specified in the "High Voltage Check" instructions. It is only when high voltage is excessive that Xradiation is capable of penetrating the shell of the picture tube including the lead in the glass material. The important precaution is to keep the high voltage below the maximum level specified.

2. It is essential that servicemen have available at all times an accurate high voltage meter. The calibration of this meter should be checked periodically.

3. High voltage should always be kept at the rated value

−no higher. Operation at higher voltages may cause a failure of the picture tube or high voltage circuitry and;also, under certain conditions, may produce radiation in exceeding of desirable levels.

4. When the high voltage regulator is operating properly there is no possibility of an X-radiation problem. Every time a colour chassis is serviced, the brightness should be tested while monitoring the high voltage with a meter to be certain that the high voltage does not exceed the specified value and that it is regulating correctly.

5. Do not use a picture tube other than that specified or make unrecommended circuit modifications to the high voltage circuitry.

6. When trouble shooting and taking test measurements on a receiver with excessive high voltage, avoid being unnecessarily close to the receiver. Do not operate the receiver longer than is necessary to locate the cause of excessive voltage.

Page 3

IMPORTANT SERVICE SAFETY PRECAUTION

1.5k ohm 10W

0.15µF

TEST PROBE

TO EXPOSED METAL PARTS

CONNECT TO KNOWN EARTH GROUND

VOLTMETER

(Continued)

32N-S500 32N-X2000

BEFORE RETURNING THE RECEIVER (Fire & Shock Hazard)

Before returning the receiver to the user, perform the following safety checks.

1. Inspect all lead dress to make certain that leads are not pinched or that hardware is not lodged between the chassis and other metal parts in the receiver.

2. Inspect all protective devices such as non-metallic control knobs, insulating materials, cabinet backs, adjustment and compartment covers or shields, isolation resistor-capacity networks, mechanical insulators, etc.

3. To be sure that no shock hazard exists, check for leakage current in the following manner.

• Plug the AC cord directly into a 120 volt AC outlet, (Do not use an isolation transformer for this test).

• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paralleled by a 0.15µF capacitor in series with all exposed metal cabinet parts and a known earth ground, such as electrical conduit or electrical ground connected to earth ground.

• Use an AC voltmeter having with 5000 ohm per volt, or higher, sensitivity to measure the AC voltage drop across the resistor.

• Connect the resistor connection to all exposed metal parts having a return to the chassis (antenna, metal cabinet, screw heads, knobs and control shafts, escutcheon, etc.) and measure the AC voltage drop across the resistor. AII checks must be repeated with the AC line cord plug connection reversed. (If necessary, a nonpolarized adapter plug must be used only for the purpose of completing these check.) Any current measured must not exceed 0.5 milliamp. Any measurements not within the limits outlined above indicate of a potential shock hazard and corrective action must be taken before returning the instrument to the customer.

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

SAFETY NOTICE

Many electrical and mechanical parts in television receivers have special safety-related characteristics. These characteristics are often not evident from visual inspection, nor can protection afforded by them be necessarily increased by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this manual; electrical components having such features are identified by "å" and shaded areas in the

Replacement Parts Lists

and

Schematic Diagrams.

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

For continued protection, replacement parts must be identical to those used in the original circuit. The use of substitute replacement parts which do not have the same safety characteristics as the factory recommended replacement parts shown in this service manual, may create shock, fire, X-radiation or other hazards.

Page 4

32N-S500 32N-X2000

LOCATION OF USER'S CONTROL

Page 5

32N-S500 32N-X2000

INSTALLATION AND SERVICE INSTRUCTIONS

Note: (1)When performing any adjustments to resistor controls and transformers use non-metallic

screwdrivers or TV alignment tools.

(2)Before performing adjustments, the TV set must be on at least 15 minutes.

CIRCUIT PROTECTION

The receiver is protected by a 5.0A fuse (F701), mounted on PWB-C, wired into one side of the AC line input.

X-RADIATION PROTECTOR CIRCUIT TEST

After service has been performed on the horizontal deflection system, high voltage system, B+ system, test the X-Radiation protection circuit to ascertain proper operation as follows:

1. Apply 120V AC using a variac transformer for accurate input voltage.

2. Allow for warm up and adjust all customer controls for normal picture and sound.

3. Receive a good local channel.

4. Connect a digital voltmeter to TP653 and make sure that the voltmeter reads 11.83±0.7V.

5. Apply external 14.5V DC at TP653 by using an external DC supply, TV must be shut off.

6. To reset the protector, unplug the AC cord and plug the AC cord power on. Now make sure that normal picture appears on the screen.

7. If the operation of the horizontal oscillator does not stop in step 5, the circuit must be repaired before the set is returned to the customer.

HIGH VOLTAGE CHECK

High voltage is not adjustable but must be checked to verify that the receiver is operating within safe and efficient design limitations as specified. Checks should be as follows:

1. Connect an accurate high voltage meter between ground and anode of picture tube.

2. Operate receiver for at least 15 minutes at 120V AC line voltage, with a strong air signal or a properly tuned in test signal.

3. Enter the service mode and select the service No. "S21" and Bus data "01" (Y-mute on).

4. The voltage should be approximately, 32.8kV (at zero beam). If a correct reading cannot be obtained, check circuitry for malfunctioning components. After the voltage test, make Y-mute off to the normal mode.

Page 6

32N-S500 32N-X2000

For adjustments of this model, the bus data is converted to various analog signals by the D/A converter circuit.

Note: There are still a few analog adjustments in this series such as focus and master screen voltage.

Follow the steps below whenever the service adjustment is required. See "Table-C" to determine, if service adjustments are required.

1. Service Mode

Before putting unit into the service mode, check that customer adjustments are in the normal mode. Use the reset function in the video adjustment menu to ensure customer controls are in their proper (reset) position.

2. Service Number Selection

Once in the service mode, press the Ch-up or Chdown button on the remote controller or at the set. The service adjustment number will vary in increments of one, from "S01" to "I10". Select the item you wish to adjust.

3. Data Number Selection

Press the Vol-up or down button to adjust the data number.

SERVICE ADJUSTMENT NUMBER

To enter the service mode and exit service mode.

While pressing the Vol-up and Ch-up buttons at the sametime, plug the AC cord into a wall socket. Now the TV set is switched on and enters the service mode. To exit the service mode, turn the television off by pressing the power button.

DA T A NUMBER

CHANNEL

S01 55 2

Figure A.

Page 7

32N-S500 32N-X2000

SERVICE NUMBER

S01 PICTURE HEIGHT 71 00~127 S02 V-LINEARITY 27 00~31 S03 V-S CORRECTION 40 00~63 Must be set to "40" S04 PICTURE WIDTH 50 00~63 S05 E-W PARABOLA 15 00~63 S06 E-W CORNER 13 00~31 S07 TRAPEZIUM 65 00~127 S08 AGC SW 01 00~01 Must be set to "01" S09 PICTURE (SUB CONTRAST) 20 00~31 S10 TINT 31 00~63 S11 COLOR (SUB COLOR) 15 00~31 S12 BRIGHT (BRIGHTNESS) 58 00~101 S13 SHARP (SHARPNESS) 00 00~27 Must be set to "00" *32N-S500 Must be set to "5" S14 V-POSITION 00 00~07 Must be set to "00" S15 H-POSITION 17 00~31 S16 R CUT-OFF 64 00~255 S17 G CUT-OFF 64 00~255 S18 B CUT-OFF 64 00~255 S19 G (R) DRIVE 64 00~127 S20 B DRIVE 64 00~127 S21 Y-MUTE/V-OFF 00 00~02 S22 Y-γ CURVE 03 00~03 Must be set to "03" S23 VSM PHASE 01 00~03 Must be set to "01" S24 APACON PEAK f0 01 00~07 Must be set to "01" S25 DC RESTORATION RATE 21 00~63 Must be set to "21" S26 DC RESTORATION LIMIT 00 00~03 Must be set to "00" S27 BLACK STRETCH POINT 03 00~07 Must be set to "03" S28 APL VS BPS 01 00~03 Must be set to "01" S29 B.L.C. 01 00~01 Must be set to "01" S30 DYNAMIC ABL POINT 04 00~07 Must be set to "04" S31 DYNAMIC ABL GAIN 04 00~07 Must be set to "04" S32 ABL POINT 03 00~07 Must be set to "03" S33 ABL GAIN 03 00~07 Must be set to "03" S34 Y-DL 00 00~01 Must be set to "00" S35 TOF-f0 07 00~07 Must be set to "07" S36 TOF-Q 04 00~07 Must be set to "04" S37 VSM GAIN 01 00~03 Must be set to "01" S38 OSD SL 00 00~01 Must be set to "00" S39 C-DECODE 161 00~255 Must be set to "161" S40 OSD POSITION 11 00~15 S41 NERGY SAVE 10 00~53 Must be set to "10" S42 VIDEO TINT 26 00~63 M01 INPUT LEVEL (ATT) 07 00~15 M02 MTS VCO 37 00~63 M03 FILTER 30 00~63 M04 WIDE BAND 35 00~63 M05 SPECTRAL 22 00~63 P01 PIP Y-LEVEL (CONTRAST) 43 00~127 P02 PIP TINT (TINT) 41 00~63 Must be set to "41" P03 PIP COLOR (COLOR-SAT) 55 00~127 P04 Y-OFFSET (Y-OFFSET) 09 00~31 Must be set to "09" P05 PIP H-POSI (HXA) 10 00~255 Must be set to "10" P06 BGP (HADJ) 00 00~15 Must be set to "00" P07 C01 C02 TINT-C 21 00~63 Must be set to "21" C03 COLOR-C (SUB COLOR) 15 00~63 Must be set to "15"

ADJUSTMENT ITEM

FREE RUN (FREE-RUN-ADJ) PICTURE-C (SUB CONTRAST)

INITIAL VALUE

DATA

RANGE

"00" = NORMAL, "01" = No Y, "02" = No VERTICAL

11 00~15 Must be set to "11" 20 00~31 Must be set to "23"

ADJUSTMENT CONTENTS

Table - A

Page 8

32N-S500 32N-X2000

SERVICE

NUMBER

C04 BRIGHT-C (BRIGHTNESS) 58 00~101 C05 SHARP-C (SHARPNESS) 00 00~27 Must be set to "00" C06 V-POSITION-C 00 00~07 Must be set to "00" C07 H-POSITION-C 19 00~31 C08 R CUT-OFF-C 64 00~255 C09 G CUT-OFF-C 64 00~255 C10 B CUT-OFF-C 64 00~255 C11 G (R) DRIVE-C 64 00~127 C12 B DRIVE-C 64 00~127 C13 VSM GAIN-C 02 00~03 Must be set to "02" C14 COMP. C-DECODER 105 00~255 Must be set to "105"

ADJUSTMENT ITEM

INITIAL VALUE

DATA

RANGE

ADJUSTMENT CONTENTS

Table - A

SERVICE

NUMBER

I01 E-SOUND 01 00 / 01 01 01 I02 DSE 01 00 / 01 00 01 I03 SRS 01 00 / 01 01 01 I04 SRS 32, 36/27 01 00 / 01 01 01 I05 A/V IN 3/2 01 00 / 01 01 01 I06 V-CHIP 01 00 / 01 01 01 I07 PIP ON/OFF 01 00 / 01 01 01 I08 COMPNENT 01 00 / 01 00 01 I09 ENGL/ESPA 01 00 / 01 01 01 I10 DSE SHIPPED POSITION 00 00 / 01 00 00

ADJUSTMENT ITEM

INITIAL VALUE

DATA

RANGE 32N-S500 32N-X2000

ADJUSTMENT CONTENTS

Table - B

Holding down both the CH-up/down buttons on the TV set at service mode for more than 2 seconds will automatically write the above initial values into IC2002.

PART REPLACED

NECESSARY

IC2001

IC401

IC2002 X

CRT X IC3001 X

IC1801

ADJUSTMENT

UNNECESSARY

Data is stored in IC2002. The adjustment is needed to compensate for characteristics

of parts including IC401.

Holding down both the CH-up/down buttons on the TV set in the service mode for more than 2 seconds will automatically write the above initial values into IC2002. Then perform a complete adjustment.

Adjust items related to picture tube only. Adjust items related to MTS only (M01~M05).

Adjust items related to P-IN-P only (P01~P07).

NOTES

Table - C

Page 9

SERVICE ADJUSTMENT

32N-S500 32N-X2000

Screen Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "S11" and set the data value to "00" to set the color level to minimum. (Record original data code under No. "S1 1" before changing) You may skip this step, if you selected a B/W picture or monoscope pattern.

3. Select the service No. "S21" and adjust the data value to "01", this turn off the luminance signal (Y-mute).

4. Select the service No. "S12" and adjust data value to "58".

5. Adjust the master screen control until the raster darkens to the point where raster is barely seen.

6. Adjust the service numbers "S16" red, "S17" green and "S18" blue to obtain a good grey scale with normal whites at low brightness level.

7. Select the service No. "S21" and reset data to "00". Select the service No. "S11" and reset data to obtain normal color level.

8. Reset the master screen control to obtain normal brightness range.

White Balance Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "S1 1" and set to "00" (minimum color)(Record original data code under adjustment "S11" before changing). "S11" does not have to be adjusted, if you selected a B/W picture or monoscope pattern.

3. Alternately adjust the service numbers "S19" and "S20" until a good grey scale with normal whites is obtained.

4. Select the service No. "S1 1" and adjust data to obtain normal color level.

Sub-Picture Adjustment

1. Receive a good local channel.

2. Make sure the customer picture control is set to maximum.

3. Enter the service mode and select the service No. "S09".

4. Adjust the data value to achieve normal contrast range.

Sub-Tint Adjustment

Video-Tint Adjustment

1. Enter the service mode and select the service No. "S42".

2. Adjust "S42" data value to "S10" data value-5step.

Sub-Color Adjustment

1. Receive a good local channel.

2. Make sure the customer color control is set to center position .

3. Enter the service mode and select the service No. "S11".

4. Adjust "S11" data value to obtain normal color level.

Sub-Brightness Adjustment

1. Receive a good local channel.

2. Make sure the customer brightness control is set to center position.

3. Enter the service mode and select the service No. "S12".

4. Adjust "S12" data value to obtain normal brightness level.

Vertical Linearity Adjustment

1. Receive a good CATV channel.

2. Set to standard setting mode.

3. Enter the service mode and select the service No. "S02".

4. While observing the top and bottom of the screen, adjust "S02" data value to proper vertical linearity.

Vertical Phase Adjustment

1. Enter the service mode and select the service No. "S14".

2. Adjust data value to "00". Note: This must be set "00" when changed data

retrace line will appear.

Vertical-Size Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "S01".

3. While observing the top and bottom of the screen, adjust "S01" data value to proper vertical size.

1. Receive a good local channel.

2. Set customer tint control to center of it's range.

3. Enter the service mode and select the service No. "S10".

4. Adjust "S10" data value to obtain normal flesh tones.

Page 10

32N-S500 32N-X2000

Side Pincushion Adjustment

1. Receive a good CATV channel or crosshatch pattern signal.

2. Set to standard setting mode.

3. Enter the service mode and select the service No. "S05".

4. Adjust the data of service No. "S05" so that the outermost line on the screen be straight.

Horizontal Position Adjustment

1. Receive a good CATV channel or crosshatch pattern signal.

2. Set to standard setting mode.

3. Enter the service mode and select the service No. "S15".

4. Adjust so that the left and right overscans are equal to each other.

Horizontal Size Adjustment

1. Receive a good CATV channel or crosshatch pattern signal.

2. Set to standard setting mode.

3. Enter the service mode and select the service No. "S04".

4. Vary the data of service No. "S04" to obtain the best horizontal size.

Corner Distortion Adjustment

1. Receive a good CATV channel or crosshatch pattern signal.

2. Set to standard setting mode.

3. Enter the service mode and select the service No. "S06".

4. Adjust so that the vertical lines should be straight.

Caption Position Adjustment (Horizontal)

1. Receive a good local channel.

2. Enter the service mode and select the service No. "S40".

3. A black text box appears on the screen. (see Figure B below)

4. Adjust "S40" data value so that text box is positioned in the center of the screen.

Sharpness Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "S13".

3. Adjust data value to "05" (32N-S500), "00" (32NX2000) (center of data range).

Trapezoidal Distortion Adjustment

1. Receive a good CATV channel or crosshatch pattern signal.

2. Set to standard setting mode.

3. Enter the service mode and select the service No. "S07".

4. Adjust so that the leftmost and rightmost vertical lines are parallel to each other.

Figure B.

Page 11

32N-S500 32N-X2000

MTS ADJUSTMENT

MTS Level Adjustment

1. Feed the following monaural signal to pin (14) of IC3001.

Monaural signal : 300Hz, 245mVrms

2. Connect the rms voltmeter to pin (39) of IC3001.

3. Enter the service mode and select the service No. "M01".

4. Adjust the data so that the rms voltmeter reads.

Spec : 490 ±10mVrms.

MTS VCO Adjustment

1. Keep the unit in no-signal state.

2. Connect the frequency counter to pin (39) of IC3001.

3. Connect a capacitor (100µF, 50V) in between positive(+) side of C3005 and ground.

4. Enter the service mode and select the service No. "M02"

5. Adjust the data so that the frequency counter reads.

Spec : 62.94 ±0.75kHz.

Filter Adjustment

1. Feed the following stereo pilot signal to pin (14) of IC3001 . Stereo pilot signal: 9.4kHz, 600mVrms.

2. Enter the service mode and select the service No. "M03".

3. Adjust the data until "OK" appears in position on the screen. Make sure the "OK" is displayed almost at the center of the data range.

Separation Adjustment

1. Connect the rms voltmeter to pin (39) of IC3001.

2. Receive the following composite stereo signal 1. Composite stereo signal: 30% modulation, left channel only, noise reduction on, 300Hz

3. Enter the service mode and select the service No. "M04".

4. Adjust the data until the AC voltage reading of the rms voltmeter is minimum.

5. Receive the following composite stereo signal 2. Stereo signal: 30% modulation, left channel only, noise reduction on, 3kHz

6. Enter the service mode and select the service No. "M05".

7. Adjust the data until the AC voltage reading of the rms voltmeter is minimum.

8. Take the above steps 1 thru 7 again for fine adjustment.

P-IN-P ADJUSTMENT

P-IN-P Y Level Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "P01".

3. Adjust "P01" data value to obtain normal contrast level.

P-IN-P TINT Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "P02".

3. Adjust data value to "41".

P-IN-P Color Adjustment

1. Receive a good local channel.

2. Make sure the customer color control is set to center position.

3. Enter the service mode and select the service No. "P03".

4. Adjust "P03" data value to obtain normal color level.

P-IN-P Y -Off Set Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "P04".

3. Adjust data value to "09".

P-IN-P H-Position Adjustment

1. Receive a good local channel.

2. Enter the service mode and select the service No. "P05".

3. Adjust data value to "10".

P-IN-P Burst Gate Pulse (for MAIN)

1. Receive a good local channel.

2. Enter the service mode and select the service No. "P06".

3. Adjust data value to "00".

P-IN-P Free Run

1. Receive a good local channel.

2. Enter the service mode and select the service No. "P07".

3. Adjust data value to "11".

Page 12

MODEL 32N-S500 CHASSIS LAYOUT

32N-S500 32N-X2000

PWB-B

PWB-F

PWB-A

PWB-C

121110987654321

Page 13

MODEL 32N-X2000 CHASSIS LAYOUT

32N-S500 32N-X2000

PWB-B

PWB-F

PWB-A

PWB-C

121110987654321

Page 14

MODEL 32N-S500 BLOCK DIAGRAM

32N-S500 32N-X2000

121110987654321

Page 15

MODEL 32N-X2000 BLOCK DIAGRAM

32N-S500 32N-X2000

121110987654321

Page 16

32N-S500 32N-X2000

DESCRIPTION OF SCHEMATIC DIAGRAM

NOTES:

1. The unit of resistance "ohm" is omitted. (K=kΩ=1000Ω, M=MΩ)

2. All resistors are 1/16 watt, unless otherwise noted.

3. All capacitors are µ F, unless otherwise noted. (P=pF=µµF)

4. (G) indicates ±2% tolerance may be used.

indicates line isolated ground.

VOLTAGE MEASUREMENT CONDITIONS:

1. All DC voltages are measured with DVM connected between points indicated and chassis ground, line voltage set at 120V AC and all controls set for normal picture unless otherwise indicated.

2. All voltages measured with 1000µ V B & W or Color

signal.

WAVEFORMS

WAVEFORM MEASUREMENT CONDITIONS:

1. Photographs taken on a standard gated color bar signal, the tint setting adjusted for proper color. The wave shapes at the red, green and blue cathodes of the picture tube depend on the tint, color level and picture control.

indicates waveform check points (See chart, waveforms are measured from point indicated to chassis ground.)

AND SHADED ( ) COMPONENTS

= SAFETY RELATED PARTS.

MARK= X-RAY RELATED PARTS.

This circuit diagram is a standard one, printed circuits may be subject to change for product improvement without prior notice.

87109654321

Page 17

SCHEMATIC DIAGRAM: CONTROL Unit

32N-S500 32N-X2000

1716 1918151413121110

654321

Page 18

32N-S500 32N-X2000

MODEL 32N-S500 SCHEMATIC DIAGRAM: CRT Unit

87109654321

654321

Page 19

MODEL 32N-X2000 SCHEMATIC DIAGRAM: CRT Unit

32N-S500 32N-X2000

1716 1918151413121110

654321

Page 20

MODEL 32N-S500 SCHEMATIC DIAGRAM: MAIN Unit-1/3

32N-S500 32N-X2000

121110987654321

Page 21

MODEL 32N-S500 SCHEMATIC DIAGRAM: MAIN Unit-2/3

32N-S500 32N-X2000

121110987654321

Page 22

MODEL 32N-S500 SCHEMATIC DIAGRAM: MAIN Unit-3/3

32N-S500 32N-X2000

121110987654321

Page 23

MODEL 32N-X2000 SCHEMATIC DIAGRAM: MAIN Unit-1/3

32N-S500 32N-X2000

121110987654321

Page 24

MODEL 32N-X2000 SCHEMATIC DIAGRAM: MAIN Unit-2/3

32N-S500 32N-X2000

121110987654321

Page 25

MODEL 32N-X2000 SCHEMATIC DIAGRAM: MAIN Unit-3/3

32N-S500 32N-X2000

121110987654321

Page 26

MODEL 32N-S500 SCHEMATIC DIAGRAM: POWER Unit

32N-S500 32N-X2000

121110987654321

Page 27

MODEL 32N-X2000 SCHEMATIC DIAGRAM: POWER Unit

32N-S500 32N-X2000

121110987654321

Page 28

32N-S500 32N-X2000

PRINTED WIRING BOARD ASSEMBLIES

PWB-A: Main Unit (Wiring Side)

654321

Page 29

32N-S500 32N-X2000

PWB-A: Main Unit (Chip Parts Side)

654321

Page 30

32N-S500 32N-X2000

PWB-B: CRT Unit (Wiring Side)

654321

Page 31

32N-S500 32N-X2000

PWB-C: POWER Unit (Wiring Side)

654321

Page 32

32N-S500 32N-X2000

PWB-F: Control Unit (Wiring Side)

654321

Page 33

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PARTS LIST

PARTS REPLACEMENT

Replacement parts which have these special safety characteristics identified in this manual; electrical components having such features are identified by å and shaded areas in the Replacement Parts Lists and Schematic Diagrams. The use of a substitute replacement part which dose no have the same safety characteristic as the factory recommended replacement parts shown in this service manual may create shock, fire or other hazards.

"HOW TO ORDER REPLACEMENT PARTS"

To have your order filled promptly and correctly, please furnish the following informations.

1. MODEL NUMBER 2. REF . NO.

3. PART NO. 4. DESCRIPTION

in USA: Contact your nearest SHARP Parts Distributor to order.

For location of SHARP Parts Distributor, Please call TollFree; 1-800-BE-SHARP

★ MARK: SPARE PARTS-DELIVERY SECTION

' MARK: X- RAY RELATED PARTS

Ref. No. Part No. ★ Description Code

'å VB80LJF3016*S M

or VB80LJF30X/*S or VB80ECK27296S or VB80JUA061X*S Picture Tube

'åDY601 RCiLH0108MEZZ M Defrection Yoke BV

or A80LJF30X) RCiLH0104MEZZ Defrection Yoke or (CRT: A80JUA061X) RCiLH0109MEZZ Defrection Yoke

å L703 RCiLG0034MEZZ M Degaussing Coil AV

or RCiLG0028MEZZ

å QEARC3102MEZZ M Ground-Part AH

MSPRT0002MEZZ M Spring for CRT AA

Picture Tube (DY: H0108ME) Picture Tube (DY: H0108ME) Picture Tube (I.T.C)

(DY: H0104ME or H0109ME) (CRT: A80LJF30X16 or

(CRT: A80JUA061X)

32N-X2000

PICTURE TUBE

'å VB80ECK272X2E M Picture Tube (I.T.C) CZ

or VB80ECK27296S Picture Tube (I.T.C) or VB80LJF3015*S Picture Tube (I.T.C) or VB80LJF30X/*S or VB80JUA061X*S Picture Tube

'åDY601 RCiLH0108MEZZ M Defrection Y oke BV

or (CRT: A80LJF30X) RCiLH0104MEZZ Defrection Yoke or (CRT: A80JUA061X) RCiLH0109MEZZ Defrection Yoke

å L703 RCiLG0034MEZZ M Degaussing Coil AV

or RCiLG0028MEZZ

å QEARC3202MEZZ M Ground-Part AE

MSPRT0002MEZZ M Spring for CRT AA

32N-S500

Picture Tube (DY:H0108ME)

(DY:H0104ME or H0109ME)

(CRT: A80JUA061X)

PRINTED WIRING BOARD ASSEMBLIES

(NOT REPLACEMENT ITEM)

32N-S500

PWB-ADUNTK9833WEL2 – Main Unit — PWB-BDUNTKA119WEK4 – CRT Unit — PWB-CDUNTK9834WEL2 – Power Unit — PWB-F DUNTK9514WEK4 – Control Unit —

32N-X2000

PWB-ADUNTK9833WEK8 – Main Unit — PWB-BDUNTKA119WEK2 – CRT Unit — PWB-CDUNTK9834WEK8 – Power Unit — PWB-F DUNTK9514WEK4 – Control Unit —

Page 34

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEL2 (32N-S500)

MAIN UNIT

TUNER

NOTE: THE PARTS HERES SHOWN ARE SUPPLIED

AS AN ASSEMBLY BUT NOT INDEPENEDENTLY.

å TU51 VTUVTBT5UB202 M Tuner AZ å TU52 VTUVTBT5UR202 M Tuner AZ

INTEGRATED CIRCUITS

å IC362 VHiLA4277++-1 M I.C. AE

IC401 RH-iX3113CEZZ J TA1276AN AZ

å IC740 VHiKA7809AP-1 M KIA7809AP AE å IC741 VHiKA7805AP-1 M KIA7805AP AE

IC753 VHiKA7805AP-1 M KIA7805AP AE IC1301 VHiMM1313AD-1 J MM1313AD AP IC1401 VHiTC90A45F-1 J TC90A45F AM IC1403 VHiMM1111XF1E J MM1111XFBE AE IC1801 VHiM65667FP-2 J M65667FP BC

'åIC2001 RH-iX3400CEZZ M M37271MF AN

IC2002 VHiBR24C16/-1 J BR24C16 AL

or VHiM24C16B/-1

IC2003 VHiKiA7045P-1 J KIA7045P AD

or VHiKiA7045A-1 or VHiPST994C/-1

IC2004 VHiTA78L05S-1 J TA78L05S AC

VHiKA78L05B-1 IC3001 VHiCXA2074Q-1 J CXA2074Q AY IC3201 VHiAN5285K/-1 J AN5285K AP IC3301 VHiM62494SP-1 J M62494SP AN

TRANSISTORS

Q360 VS2SD601AR/-1 J 2SD601AR AC Q403 VS2SA1266-Y-1 J 2SA1266(Y) AA Q901 VS2SD601AR/-1 J 2SD601AR AC Q902 VS2SD601AR/-1 J 2SD601AR AC Q903 VS2SD601AR/-1 J 2SD601AR AC Q904 VS2SD601AR/-1 J 2SD601AR AC Q905 VS2SD601AR/-1 J 2SD601AR AC Q906 VS2SD601AR/-1 J 2SD601AR AC Q1301 VS2SD601AR/-1 J 2SD601AR AC Q1302 VS2SD601AR/-1 J 2SD601AR AC Q1303 VS2SD601AR/-1 J 2SD601AR AC Q1401 VS2SD601AR/-1 J 2SD601AR AC Q1402 VS2SD601AR/-1 J 2SD601AR AC Q1404 VS2SD601AR/-1 J 2SD601AR AC Q1405 VS2SD601AR/-1 J 2SD601AR AC Q1406 VS2SD601AR/-1 J 2SD601AR AC Q1407 VS2SB709AR/-1 J 2SB709AR AC Q1408 VS2SB709AR/-1 J 2SB709AR AC Q1409 VS2SD601AR/-1 J 2SD601AR AC Q1410 VS2SB709AR/-1 J 2SB709AR AC Q1411 VS2SB709AR/-1 J 2SB709AR AC Q1412 VS2SD601AR/-1 J 2SD601AR AC Q1436 VS2SD601AR/-1 J 2SD601AR AC Q1450 VS2SD601AR/-1 J 2SD601AR AC Q1721 VS2SD601AR/-1 J 2SD601AR AC Q1741 VS2SD601AR/-1 J 2SD601AR AC Q1742 VS2SB709AR/-1 J 2SB709AR AC Q1791 VS2SC1959Y/1E J 2SC1959Y AC Q1813 VS2SD601AR/-1 J 2SD601AR AC Q1814 VS2SD601AR/-1 J 2SD601AR AC Q1815 VS2SD601AR/-1 J 2SD601AR AC Q1861 VS2SB709AR/-1 J 2SB709AR AC Q2003 VS2SD601AR/-1 J 2SD601AR AC Q2004 VSUN2212///-1 J UN2212 AA Q2005 VS2SD601AR/-1 J 2SD601AR AC Q2008 VS2SD601AR/-1 J 2SD601AR AC Q2009 VS2SD601AR/-1 J 2SD601AR AC

D52 RH-EX0673GEZZ J Zener Diode, 32V AB D62 RH-EX0673GEZZ J Zener Diode, 32V AB D361 VHD1SS119//-1 J Diode AB D362 VHD1SS119//-1 J Diode AB D405 RH-EX0628GEZZ J Zener Diode, 8.2V AC D406 VHD1SS119//-1 J Diode AB D412 RH-EX0618GEZZ J Zener Diode, 6.2V AA D413 RH-EX0618GEZZ J Zener Diode, 6.2V AA D414 RH-EX0618GEZZ J Zener Diode, 6.2V AA D617 RH-EX0631GEZZ J Zener Diode, 9V AA D619 VHD1SS119//-1 J Diode AB D620 RH-EX0604GEZZ J Zener Diode, 3.9V AB D721 VHD1SS119//-1 J Diode AB D1301 RH-EX0631GEZZ J Zener Diode, 9V AA D1302 RH-EX0631GEZZ J Zener Diode, 9V AA D1303 RH-EX0631GEZZ J Zener Diode, 9V AA D1304 RH-EX0631GEZZ J Zener Diode, 9V AA D1305 RH-EX0631GEZZ J Zener Diode, 9V AA D1306 RH-EX0631GEZZ J Zener Diode, 9V AA D1308 RH-EX0631GEZZ J Zener Diode, 9V AA D1310 RH-EX0631GEZZ J Zener Diode, 9V AA D1311 RH-EX0631GEZZ J Zener Diode, 9V AA D1401 VHD1SS119//-1 J Diode AB D1402 VHD1SS119//-1 J Diode AB D1403 VHD1SS119//-1 J Diode AB D1791 RH-EX0604GEZZ J Zener Diode, 4.3V AB D1801 VHD1SS119//-1 J Diode AB D1821 VHD1SS119//-1 J Diode AB D2004 VHD1SS119//-1 J Diode AB D2005 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2006 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2007 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2008 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2010 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2014 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2024 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2025 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2026 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2030 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2031 RH-DX0441CEZZ J Diode AC D2033 RH-EX0616GEZZ J Zener Diode, 6.2V AA

PACKAGED CIRCUITS

DIODES

X801 RCRSB0001PEZZ R Crystal AL X1861 RCRSB0283CEZZ J Crystal AG

FILTERS

CF501 RFiLA0034CEZZ J Filter AD CF2001

RFiLC0121GEZZ J Filter AD

COILS

L401 VP-XF4R7K0000 J Peaking 4.7µH AB L404 VP-XF4R7K0000 J Peaking 4.7µH AB L405 VP-XF4R7K0000 J Peaking 4.7µH AB L1401 VP-XF100K0000 J Peaking 10µH AB L1402 VP-XF100K0000 J Peaking 10µH AB L1403 VP-XF150K0000 J Peaking 15µH AB L1404 VP-XF330K0000 J Peaking 33µH AB L1405 VP-XF1R0K0000 J Peaking 1µH AB L1407 VP-XF1R0K0000 J Peaking 1µH AB L1412 VP-XF1R0K0000 J Peaking 1µH AB L1721 VP-XF680K0000 J Peaking 68µH AB L1741 VP-XF1R0K0000 J Peaking 1µH AB L1742 VP-DF1R0K0000 J Peaking 1µH AB L1801 VP-XF100K0000 J Peaking 10µH AB L1811 VP-XFR27K0000 J Peaking 0.27µH AB L1812 VP-XFR27K0000 J Peaking 0.27µH AB L1821 VP-XF100K0000 J Peaking 10µH AB L1822 VP-XF100K0000 J Peaking 10µH AB L1823 VP-XF100K0000 J Peaking 10µH AB L1861 VP-XF100K0000 J Peaking 10µH AB L1862 VP-XF100K0000 J Peaking 10µH AB L1863 VP-XF100K0000 J Peaking 10µH AB L2001 VP-XF100K0000 J Peaking 10µH AB

Page 35

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEL2 (32N-S500)

MAIN UNIT (Continued)

L2002 VP-MK100K0000 J Peaking 10µH AB T2001 RCiLB0158CEZZ M Oscillation Coil AC

CAPACITORS

[EL.··· Electrolytic]

C51 VCKYPA1HF103Z J 0.01 50V Ceramic AA C52 VCEA0A0JW108M J 1000 6.3V EL. AC C54 VCEA0A1HW105M J 1.0 50V EL. AB C56 VCQYTA1HM104K J 0.1 50V Mylar AC C61 VCKYPA1HF103Z J 0.01 50V Ceramic AA C62 VCEA0A0JW108M J 1000 6.3V EL. AC C64 VCEA0A1HW105M J 1.0 50V EL. AB C66 VCQYTA1HM104K J 0.1 50V Mylar AC C360 VCEA0A1HW225M J 2.2 50V EL. AB C361 VCEA0A1HW225M J 2.2 50V EL. AB C363 VCEA0A1VW477M J 470 35V EL. AB C364 VCEA0A1VW227M J 220 35V EL. AC C365 VCEA0A1AW107M J 100 10V EL. AB C368 RC-EZ1086CEZZ J 1000 16V EL. AD C369 RC-EZ1086CEZZ J 1000 16V EL. AD C370 VCEA0A1AW107M J 100 10V EL. AB C371 VCQYTA1HM104K J 0.1 50V Mylar AC C372 VCQYTA1HM104K J 0.1 50V Mylar AC C380 VCQYTA1HM103K J 0.01 50V Mylar AB C381 VCQYTA1HM103K J 0.01 50V Mylar AB C401 VCEA0A1CW337M J 330 16V EL. AC C402 VCEA0A1VW226M J 22 35V EL. AB C403 VCKYCY1EB103K J 0.01 25V Ceramic AA C404 VCEA0A1HW105M J 1.0 50V EL. AB C405 VCEA0A1HW225M J 2.2 50V EL. AB C406 VCKYCY1EB103K J 0.01 25V Ceramic AA C407 VCEA0A1CW337M J 330 16V EL. AC C408 VCEA0A1HW474M J 0.47 50V EL. AB C409 VCFYFA1HA334J J 0.33 50V Mylar AB C410 VCEA0A1HW105M J 1.0 50V EL. AB C411 VCKYPA1HF103Z J 0.01 50V Ceramic AA C412 VCCCCY1HH560J J 56p 50V Ceramic AA C427 VCFYFA1HA104J J 0.1 50V Mylar AA C440 VCKYCY1EB103K J 0.01 25V Ceramic AA C447 VCEA0A1CW337M J 330 16V EL. AC C601 VCFYFA1HA103J M 0.01 50V Mylar AA C613 VCKYCY1EB103K J 0.01 25V Ceramic AA C616 VCEA0A1HW225M J 2.2 50V EL. AB C617 VCEA0A1HW225M J 2.2 50V EL. AB C618 VCFYFA1HA223J M 0.022 50V Mylar AA C619 VCEA0A1CW337M J 330 16V EL. AC C620 VCKYCY1HB271K J 270p 50V Ceramic AA C621 VCKYCY1HB152K J 1500p 50V Ceramic AA C743 VCEA0A1EW476M J 47 25V EL. AB C744 VCEA0A1CW227M J 220 16V EL. AC C745 VCEA0A1EW476M J 47 25V EL. AB C746 VCEA0A1HW106M J 10 50V EL. AB C782 VCEA0A1HW106M J 10 50V EL. AB C783 VCEA0A1EW476M J 47 25V EL. AB C803 VCKYCY1HF103Z J 0.01 50V Ceramic AA C806 VCKYCY1CB104K J 0.1 16V Ceramic AB C807 VCEA0A1HW225M J 2.2 50V EL. AB C812 VCEAGA1HW224T J 0.22 50V EL. AB C813 VCQYTA1HM222J J 2200p 50V Mylar AA C814 VCCCCY1HH110J J 11p 50V Ceramic AA C817 VCCCCY1HH1R0C J 1.0p 50V Ceramic AA C818 VCKYCY1CB104K J 0.1 16V Ceramic AB C819 VCKYCY1CB104K J 0.1 16V Ceramic AB C843 VCKYCY1EB103K J 0.01 25V Ceramic AA C844 VCKYCY1EB103K J 0.01 25V Ceramic AA C845 VCKYCY1EB103K J 0.01 25V Ceramic AA C901 VCEA0A1HW475M J 4.7 50V EL. AB C903 VCEA0A1HW475M J 4.7 50V EL. AB C905 VCEA0A1EW476M J 47 25V EL. AB C956 VCEA0A1CW337M J 330 16V EL. AC C1301 VCQYTA1HM104K J 0.1 50V Mylar AC

C1302 VCEA0A1HW105M J 1.0 50V EL. AB C1303 VCEA0A1HW105M J 1.0 50V EL. AB C1304 VCQYTA1HM104K J 0.1 50V Mylar AC C1305 VCEA0A1HW105M J 1.0 50V EL. AB C1306 VCEA0A1HW105M J 1.0 50V EL. AB C1307 VCQYTA1HM183J J 0.018 50V Mylar AB C1308 VCEA0A1HW225M J 2.2 50V EL. AB C1309 VCEA0A1HW225M J 2.2 50V EL. AB C1310 VCQYTA1HM104K J 0.1 50V Mylar AC C1311 VCQYTA1HM183J J 0.018 50V Mylar AB C1312 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1313 VCKYCY1HB271K J 270p 50V Ceramic AA C1314 VCKYCY1HB271K J 270p 50V Ceramic AA C1315 VCKYCY1HB271K J 270p 50V Ceramic AA C1316 VCKYCY1HB271K J 270p 50V Ceramic AA C1317 VCKYCY1CB104K J 0.1 16V Ceramic AB C1318 VCKYCY1CB104K J 0.1 16V Ceramic AB C1322 VCKYCY1CB104K J 0.1 16V Ceramic AB C1323 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1324 VCQYTA1HM104K J 0.1 50V Mylar AC C1325 VCEA0A1VW226M J 22 35V EL. AB C1326 VCEA0A1CW107M J 100 16V EL. AC C1327 VCKYCY1HB271K J 270p 50V Ceramic AA C1328 VCKYCY1HB271K J 270p 50V Ceramic AA C1329 VCEA0A1HW105M J 1.0 50V EL. AB C1330 VCEA0A1HW105M J 1.0 50V EL. AB C1331 VCCCCY1HH680J J 68p 50V Ceramic AA C1332 VCQYTA1HM104K J 0.1 50V Mylar AC C1333 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB C1334 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB C1338 VCQYTA1HM104K J 0.1 50V Mylar AC C1339 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1340 VCKYCY1CB104K J 0.1 16V Ceramic AB C1341 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1401 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1402 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1404 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1405 VCKYCY1CB104K J 0.1 16V Ceramic AB C1406 VCEA0A1EW476M J 47 25V EL. AB C1407 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1408 VCCCCY1HH181J J 180p 50V Ceramic AA C1409 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1410 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1411 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1412 VCEA0A1EW476M J 47 25V EL. AB C1413 VCKYCY1CB104K J 0.1 16V Ceramic AB C1414 VCFYFA1HA474J J 0.47 50V Mylar AC C1415 VCCCCY1HH150J J 15p 50V Ceramic AA C1416 VCEA0A1CW107M J 100 16V EL. AC C1417 VCCCCY1HH390J J 39p 50V Ceramic AA C1418 VCCCCY1HH120J J 12p 50V Ceramic AA C1420 VCCCCY1HH120J J 12p 50V Ceramic AA C1421 VCKYCY1CB104K J 0.1 16V Ceramic AB C1423 VCQYTA1HM473J J 0.047 50V Mylar AA C1424 VCEA0A1HW105M J 1.0 50V EL. AB C1425 VCQYTA1HM472J J 4700p 50V Mylar AB C1426 VCQYTA1HM473J J 0.047 50V Mylar AA C1428 VCQYTA1HM472J J 4700p 50V Mylar AB C1429 VCEA0A1HW105M J 1.0 50V EL. AB C1430 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1431 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1432 VCKYCY1CB104K J 0.1 16V Ceramic AB C1433 VCKYCY1CB104K J 0.1 16V Ceramic AB C1435 VCKYCY1CB104K J 0.1 16V Ceramic AB C1437 VCCSPA1HL102J J 1000p 50V Ceramic AA C1438 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1439 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1450 VCKYCY1CB104K J 0.1 16V Ceramic AB C1719 VCKYCY1CB104K J 0.1 16V Ceramic AB C1721 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1722 VCCCCY1HH330J J 33p 50V Ceramic AA C1724 VCFYFA1HA104J J 0.1 50V Mylar AA C1725 VCFYFA1HA104J J 0.1 50V Mylar AA C1726 VCFYFA1HA104J J 0.1 50V Mylar AA C1729 VCEA0A1HW106M J 10 50V EL. AB C1741 VCQYTA1HM473J J 0.047 50V Mylar AA

Page 36

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEL2 (32N-S500)

MAIN UNIT (Continued)

C1742 VCEA0A1HW105M J 1.0 50V EL. AB C1743 VCQYTA1HM472J J 4700p 50V Mylar AB C1744 VCKYCY1CB104K J 0.1 16V Ceramic AB C1747 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1791 VCEA0A1AW107M J 100 10V EL. AB C1792 VCEA0A1AW107M J 100 10V EL. AB C1793 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1801 VCKYCY1CB104K J 0.1 16V Ceramic AB C1802 VCKYCY1EB103K J 0.01 25V Ceramic AA C1803 VCKYCY1EB103K J 0.01 25V Ceramic AA C1804 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1805 VCEA0A1HW106M J 10 50V EL. AB C1806 VCKYCY1CB104K J 0.1 16V Ceramic AB C1807 VCKYCY1EB103K J 0.01 25V Ceramic AA C1809 VCKYCY1EB103K J 0.01 25V Ceramic AA C1810 VCEA0A1VW226M J 22 35V EL. AB C1811 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1812 VCEA0A1HW106M J 10 50V EL. AB C1817 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1821 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1822 VCEA0A1HW106M J 10 50V EL. AB C1833 VCQYTA1HM562J J 5600p 50V Mylar AA C1841 VCEA0A1HW106M J 10 50V EL. AB C1842 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1843 VCCCCY1HH680J J 68p 50V Ceramic AA C1844 VCKYCY1CB104K J 0.1 16V Ceramic AB C1845 VCKYCY1EB103K J 0.01 25V Ceramic AA C1846 VCCCCY1HH151J J 150p 50V Ceramic AA C1847 VCKYCY1EB103K J 0.01 25V Ceramic AA C1848 VCKYCY1CB104K J 0.1 16V Ceramic AB C1849 VCEA0A1HW106M J 10 50V EL. AB C1850 VCKYCY1CB104K J 0.1 16V Ceramic AB C1851 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1861 VCKYCY1CB104K J 0.1 16V Ceramic AB C1862 VCKYCY1CB104K J 0.1 16V Ceramic AB C1863 VCCCCY1HH101J J 100p 50V Ceramic AA C1865 VCFYFA1HA154J J 0.15 50V Mylar AC C1866 VCQYTA1HM103J J 0.01 50V Mylar AA C1867 VCKYCY1CB104K J 0.1 16V Ceramic AB C1868 VCFYFA1HA474J J 0.47 50V Mylar AC C1869 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1870 VCEA0A1HW106M J 10 50V EL. AB C1871 VCEA0A1HW106M J 10 50V EL. AB C1872 VCKYCY1EB103K J 0.01 25V Ceramic AA C2006 VCEA0A1HW105M J 1.0 50V EL. AB C2007 VCKYCY1HB561K J 560p 50V Ceramic AA C2008 VCQYTA1HM104J J 0.1 50V Mylar AA C2009 VCKYCY1HB102K J 1000p 50V Ceramic AA C2010 VCKYCY1HB221K J 220p 50V Ceramic AA C2011 VCEA0A1HW105M J 1.0 50V EL. AB C2012 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2013 VCKYCY1CB104K J 0.1 16V Ceramic AB C2014 VCKYCY1HB102K J 1000p 50V Ceramic AA C2016 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2017 VCCCCY1HH101J J 100p 50V Ceramic AA C2018 VCCCCY1HH101J J 100p 50V Ceramic AA C2019 VCKYCY1HB102K J 1000p 50V Ceramic AA C2020 VCKYCY1HB102K J 1000p 50V Ceramic AA C2021 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2022 VCEA0A1HW106M J 10 50V EL. AB C2023 VCEA0A1AW107M J 100 10V EL. AB C2025 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2026 VCEA0A0JW477M J 470 6.3V EL. AC C2027 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2028 VCEA0A1AW107M J 100 10V EL. AB C2029 VCFYFA1HA474J J 0.47 50V Mylar AC C2030 VCEA0A1HW106M J 10 50V EL. AB C2031 VCEA0A1AW228M J 2200 10V EL. AD C2032 VCCCCY1HH270J J 27p 50V Ceramic AA C2034 VCCCCY1HH390J J 39p 50V Ceramic AA C2040 VCKYCY1CB104K J 0.1 16V Ceramic AB C2042 VCKYCY1HF103Z J 0.01 50V Ceramic AA

C3001 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA C3003 VCQYTA1HM123K J 0.012 50V Mylar AA C3004 VCEA0A1HW105M J 1.0 50V EL. AB C3005 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3006 VCEA0A1HW106M J 10 50V EL. AB C3007 VCEA0A1HW475M J 4.7 50V EL. AB C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3009 VCEA0A1CW227M J 220 16V EL. AC C3010 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3011 VCEA0A1HW475M J 4.7 50V EL. AB C3012 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA C3014 VCQYTA1HM473K J 0.047 50V Mylar AB C3015 VCSATA1CE335K J 3.3 16V Tantalum AC C3016 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3017 VCSATA1CE106K J 10 16V Tantalum AD C3018 VCEA0A1HW105M J 1.0 50V EL. AB C3029 VCKYCY1HB682K J 6800p 50V Ceramic AA C3030 VCKYCY1HB682K J 6800p 50V Ceramic AA C3031 VCKYCY1CB473K J 0.047 16V Ceramic AA C3032 VCKYCY1CB473K J 0.047 16V Ceramic AA C3201 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3202 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3203 VCEA0A1HW475M J 4.7 50V EL. AB C3204 VCEA0A1HW106M J 10 50V EL. AB C3205 VCEA0A1HW106M J 10 50V EL. AB C3206 VCKYCY1HB103K J 0.01 50V Ceramic AA C3207 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3208 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3209 VCEA0A1HW106M J 10 50V EL. AB C3301 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3302 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3303 VCKYCY1HB183K J 0.018 50V Ceramic AB C3304 VCKYCY1HB471K J 470p 50V Ceramic AA C3305 VCFYFA1HA103J M 0.01 50V Mylar AA C3306 VCFYFA1HA824J M 0.82 50V Mylar AC C3307 VCKYCY1HB471K J 470p 50V Ceramic AA C3308 VCEA0A1CW107M J 100 16V EL. AC C3309 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3310 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3311 VCFYFA1HA103J M 0.01 50V Mylar AA C3312 VCFYFA1HA224J J 0.22 50V Mylar AB C3313 VCQYTA1HM472J J 4700p 50V Mylar AB C3314 VCFYFA1HA104J J 0.1 50V Mylar AA C3315 VCFYFA1HA103J M 0.01 50V Mylar AA C3316 VCEA0A1HW106M J 10 50V EL. AB

RESISTORS

[M-Ox.··· Metal Oxide]

RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ30 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ32 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ33 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ34 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ38 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ40 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ41 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ42 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ43 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ48 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ49 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ50 VRS-CY1JF000J J 0 1/16W M-Ox. AA

Page 37

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEL2 (32N-S500)

MAIN UNIT (Continued)

RJ51 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ52 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ53 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ54 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ55 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ56 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ57 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ58 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ59 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ60 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ61 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ62 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ63 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ64 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ65 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ67 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ68 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ69 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ70 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ72 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ73 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ77 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ78 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ81 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ82 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ83 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ84 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ85 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ90 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ91 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ92 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ93 VRS-TV1JD000J J 0 1/16W M-Ox. AA RJ94 VRS-TV1JD000J J 0 1/16W M-Ox. AA RJ96 VRS-CY1JF000J J 0 1/16W M-Ox. AA R52 VRD-RA2BE101J J 100 1/8W Carbon AB R53 VRD-RA2BE101J J 100 1/8W Carbon AB R54 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA R62 VRS-CY1JF101J J 100 1/16W M-Ox. AA R63 VRS-CY1JF101J J 100 1/16W M-Ox. AA R64 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA R351 VRS-CY1JF101J J 100 1/16W M-Ox. AA R360 VRS-CY1JF221J J 220 1/16W M-Ox. AA R361 VRD-RA2BE562J J 5.6k 1/8W Carbon AA R362 VRD-RA2BE562J J 5.6k 1/8W Carbon AA R363 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R364 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R365 VRS-CY1JF221J J 220 1/16W M-Ox. AA R370 VRS-CY1JF221J J 220 1/16W M-Ox. AA R371 VRD-RA2EE3R3J J 3.3 1/4W Carbon AA R372 VRD-RA2EE3R3J J 3.3 1/4W Carbon AA R401 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA R402 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R403 VRD-RA2EE680J J 68 1/4W Carbon AA R405 VRS-CY1JF471J J 470 1/16W M-Ox. AA R406 VRS-CY1JF471J J 470 1/16W M-Ox. AA R407 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R410 VRS-CY1JF820J J 82 1/16W M-Ox. AA R411 VRS-CY1JF820J J 82 1/16W M-Ox. AA R412 VRS-CY1JF820J J 82 1/16W M-Ox. AA R414 VRS-CY1JF101J J 100 1/16W M-Ox. AA R415 VRS-CY1JF101J J 100 1/16W M-Ox. AA R416 VRS-CY1JF101J J 100 1/16W M-Ox. AA R418 VRS-CY1JF101J J 100 1/16W M-Ox. AA R419 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA R425 VRS-CY1JF474J J 470k 1/16W M-Ox. AA R435 VRS-CY1JF395J J 3.9M 1/16W M-Ox. AA R540 VRS-CY1JF391J J 390 1/16W M-Ox. AA R541 VRS-CY1JF101J J 100 1/16W M-Ox. AA R602 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R603 VRD-RA2EE331J J 330 1/4W Carbon AA R613 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R616 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA

R617 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R620 VRD-RA2BE153J J 15k 1/8W Carbon AA R627 VRS-SV2HC101J J 100 1/2W M-Ox. AA

å R738 VRS-RG3LB123J J 12k 3.0W M-Ox. AB å R744 VRS-RG3DB330J J 33 2W M-Ox. AA å R745 VRS-RG3LB120J J 12 3.0W M-Ox. AB å R746 VRS-RG3DB330J J 33 2W M-Ox. AA å R782 VRS-VV3DB270J J 27 2W M-Ox. AA

R784 VRS-VV3DB151J J 150 2W M-Ox. AA R803 VRS-CY1JF101J J 100 1/16W M-Ox. AA R807 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R814 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R817 VRS-CY1JF273J J 27k 1/16W M-Ox. AA R820 VRD-RA2BE101J J 100 1/8W Carbon AB R821 VRD-RA2BE101J J 100 1/8W Carbon AB R822 VRD-RA2BE101J J 100 1/8W Carbon AB R823 VRD-RA2BE101J J 100 1/8W Carbon AB R827 VRS-CY1JF181J J 180 1/16W M-Ox. AA R828 VRS-CY1JF181J J 180 1/16W M-Ox. AA R829 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA R830 VRS-CY1JF101J J 100 1/16W M-Ox. AA R903 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R904 VRS-CY1JF683J J 68k 1/16W M-Ox. AA R905 VRS-CY1JF123J J 12k 1/16W M-Ox. AA R906 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R907 VRS-CY1JF821J J 820 1/16W M-Ox. AA R908 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R910 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R911 VRS-CY1JF683J J 68k 1/16W M-Ox. AA R912 VRS-CY1JF123J J 12k 1/16W M-Ox. AA R913 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R914 VRS-CY1JF821J J 820 1/16W M-Ox. AA R915 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R920 VRS-CY1JF683J J 68k 1/16W M-Ox. AA R921 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R922 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R963 VRD-RA2BE101J J 100 1/8W Carbon AB R1301 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1302 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1303 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1305 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1306 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1307 VRS-CY1JF680J J 68 1/16W M-Ox. AA R1308 VRS-CY1JF8R2J J 8.2 1/16W M-Ox. AA R1309 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1310 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1311 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1312 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1313 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1314 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1315 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1316 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R1317 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1318 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1319 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1320 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R1321 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1322 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1323 VRS-CY1JF181J J 180 1/16W M-Ox. AA R1324 VRS-CY1JF181J J 180 1/16W M-Ox. AA R1325 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA R1326 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1327 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1328 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1329 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1330 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1331 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1332 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1333 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1334 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1335 VRD-RA2BE100J J 10 1/8W Carbon AA R1336 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1337 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1338 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1340 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1342 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA

Page 38

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEL2 (32N-S500)

MAIN UNIT (Continued)

R1359 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1360 VRS-CY1JF680J J 68 1/16W M-Ox. AA R1361 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1362 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1363 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1364 VRS-CY1JF8R2J J 8.2 1/16W M-Ox. AA R1401 VRS-CY1JF821J J 820 1/16W M-Ox. AA R1402 VRS-CY1JF561J J 560 1/16W M-Ox. AA R1403 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R1404 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1405 VRS-CY1JF331J J 330 1/16W M-Ox. AA R1406 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1407 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1408 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1411 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1412 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA R1413 VRS-CY1JF561J J 560 1/16W M-Ox. AA R1414 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1415 VRS-CY1JF471J J 470 1/16W M-Ox. AA R1416 VRS-CY1JF821J J 820 1/16W M-Ox. AA R1418 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1419 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1420 VRS-CY1JF151J J 150 1/16W M-Ox. AA R1421 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1422 VRS-CY1JF684J J 680k 1/16W M-Ox. AA R1423 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1424 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1425 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1426 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1427 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1428 VRS-CY1JF151J J 150 1/16W M-Ox. AA R1429 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1430 VRS-CY1JF684J J 680k 1/16W M-Ox. AA R1431 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1432 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1433 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1443 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1444 VRD-RA2BE182J J 1.8k 1/8W Carbon AA R1445 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1446 VRD-RA2BE101J J 100 1/8W Carbon AB R1447 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1448 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1450 VRS-CY1JF273J J 27k 1/16W M-Ox. AA R1452 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA R1453 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1718 VRD-RA2BE101J J 100 1/8W Carbon AB R1720 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R1721 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1722 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1723 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA R1724 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1741 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1742 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1743 VRS-CY1JF151J J 150 1/16W M-Ox. AA R1744 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1745 VRS-CY1JF474J J 470k 1/16W M-Ox. AA R1746 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA R1747 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1791 VRD-RA2BE151J J 150 1/8W Carbon AA R1801 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R1810 VRD-RA2BE473J J 47k 1/8W Carbon AA R1812 VRD-RA2BE123J J 12k 1/8W Carbon AA R1813 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1816 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R1817 VRD-RA2BE123J J 12k 1/8W Carbon AA R1819 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1821 VRS-CY1JF123J J 12k 1/16W M-Ox. AA R1822 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1823 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R1825 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R1828 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1831 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA

R1832 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R1833 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA R1834 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R1841 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1842 VRS-CY1JF471J J 470 1/16W M-Ox. AA R1843 VRS-CY1JF391J J 390 1/16W M-Ox. AA R1861 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1862 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1863 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R1864 VRS-CY1JF221J J 220 1/16W M-Ox. AA R1865 VRS-CY1JF474J J 470k 1/16W M-Ox. AA R1866 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R1867 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R1868 VRS-CY1JF510J J 51 1/16W M-Ox. AA R1869 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1870 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2001 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2002 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2003 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2004 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2005 VRD-RA2BE682J J 6.8k 1/8W Carbon AA R2006 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2007 VRS-CY1JF223J J 22k 1/16W M-Ox. AA

'åR2008 VRD-RA2BE273J J 27k 1/8W Carbon AA

R2009 VRD-RA2BE223J J 22k 1/8W Carbon AA R2010 VRS-CY1JF103J J 10k 1/16W M-Ox. AA

'åR2011 VRS-CY1JF473J J 47k 1/16W M-Ox. AA

R2012 VRD-RA2BE101J J 100 1/8W Carbon AB R2013 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2014 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2015 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2016 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R2017 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2018 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2019 VRD-RA2BE682J J 6.8k 1/8W Carbon AA R2020 VRD-RA2EE821J J 820 1/4W Carbon AA R2021 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2022 VRD-RA2BE682J J 6.8k 1/8W Carbon AA R2024 VRD-RA2BE101J J 100 1/8W Carbon AB R2025 VRD-RA2BE682J J 6.8k 1/8W Carbon AA R2026 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2027 VRD-RA2BE682J J 6.8k 1/8W Carbon AA R2028 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R2030 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2031 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2032 VRD-RA2EE182J J 1.8k 1/4W Carbon AA R2033 VRS-CY1JF471J J 470 1/16W M-Ox. AA R2034 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA R2035 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R2036 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2037 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2038 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2039 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2040 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2043 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2045 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2046 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2048 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2051 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2052 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2053 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R2054 VRD-RA2BE472J J 4.7k 1/8W Carbon AA R2057 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2058 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2059 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R2060 VRS-CY1JF184J J 180k 1/16W M-Ox. AA R2061 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2062 VRD-RA2BE823J J 82k 1/8W Carbon AA R2063 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2064 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R2065 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2066 VRD-RA2BE183J J 18k 1/8W Carbon AA R2067 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2068 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2069 VRD-RA2BE123J J 12k 1/8W Carbon AA R2070 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA

Page 39

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEL2 (32N-S500)

MAIN UNIT (Continued)

R2071 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2073 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2074 VRD-RA2BE103J J 10k 1/8W Carbon AA R2075 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2076 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2077 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2078 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R2080 VRS-CY1JF471J J 470 1/16W M-Ox. AA R2081 VRS-CY1JF471J J 470 1/16W M-Ox. AA R2084 VRD-RA2BE472J J 4.7k 1/8W Carbon AA R2092 VRD-RA2BE101J J 100 1/8W Carbon AB R2093 VRD-RA2BE101J J 100 1/8W Carbon AB R2094 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R2095 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2097 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2099 VRD-RA2BE101J J 100 1/8W Carbon AB R3001 VRD-RA2BE221J J 220 1/8W Carbon AA R3002 VRD-RA2BE221J J 220 1/8W Carbon AA R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R3006 VRS-CY1JF623J J 62k 1/16W M-Ox. AA R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R3011 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R3012 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R3013 VRD-RA2BE101J J 100 1/8W Carbon AB R3014 VRD-RA2BE101J J 100 1/8W Carbon AB R3015 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R3016 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R3017 VRD-RA2BE101J J 100 1/8W Carbon AB R3018 VRD-RA2BE101J J 100 1/8W Carbon AB R3104 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R3201 VRS-CY1JF225J J 2.2M 1/16W M-Ox. AA R3202 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R3203 VRS-CY1JF101J J 100 1/16W M-Ox. AA R3301 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA R3302 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA R3303 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R3304 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R3305 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R3306 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R3307 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R3308 VRS-CY1JF101J J 100 1/16W M-Ox. AA

J1301 QTANJ0821CEZZ M Terminal Video/Audio-IN AL J1302 QSOCD0430CEZZ J Socket, Video-1 S-Video AE J1303 QSOCD0430CEZZ J Socket, Video-3 S-Video AE P109 QPLGN0661CEZZ J Plug 6-pin(EJ) AD P351 QPLGN0461CEZZ J Plug 4-pin(S) AB P603 QPLGN0861CEZZ J Plug 8-pin(D) AC P706 QPLGN0160CEZZ J Plug 1-pin(SG) AB P1801 QPLGN0961CEZZ J Plug 9-pin(C) AD P1802 QPLGN0561CEZZ J Plug 5-pin(GBN) AB P1803 QPLGN1061CEZZ J Plug10-pin(H) AC P2001 QPLGN0561CEZZ J Plug 5-pin(TP2001-5) AB P2002 QPLGN0561CEZZ J Plug 5-pin(KA) AB P2003 QPLGN0461CEZZ J Plug 4-pin(YR) AB RDA362 RDA740 RDA741 SLD1801

MISCELLANEOUS PARTS

PRDAR1012MEFW M Heat Sink, for IC362 AE PRDAR5072CEFW J Heat Sink, for IC740 AC PRDAR5072CEFW J Heat Sink, for IC741 AC PSLDM0012MEFW J Shield AD LHLDW1002PEZZ R Holder AB LX-BZ3049GEFD J Screw AA

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT

TUNER

NOTE: THE PARTS HERES SHOWN ARE SUPPLIED

AS AN ASSEMBLY BUT NOT INDEPENEDENTLY.

å TU51 VTUVTBT5UB202 M Tuner AZ å TU52 VTUVTBT5UR202 M Tuner AZ

INTEGRATED CIRCUITS

å IC362 VHiLA4277++-1 M I.C. AE

IC401 RH-iX3113CEZZ J TA1276AN AZ

å IC740 VHiKA7809AP-1 M KIA7809AP AE å IC741 VHiKA7805AP-1 M KIA7805AP AE

IC753 VHiKA7805AP-1 M KIA7805AP AE IC1301 VHiMM1313AD-1 J MM1313AD AP IC1401 VHiTC90A45F-1 J TC90A45F AM IC1403 VHiMM1111XF1E J MM1111XFBE AE IC1702 VHiM52055FP-1 J M52055FP AH IC1703 VHiMM1111XF1E J MM1111XFBE AE IC1801 VHiM65667FP-2 J M65667FP BC

'åIC2001 RH-iX3400CEZZ M M37271MF AN

IC2002 VHiBR24C16/-1 J BR24C16 AL

or VHiM24C16B/-1

IC2003 VHiKiA7045P-1 J KIA7045P AD

or VHiKiA7045A-1 or VHiPST994C/-1

IC2004 VHiTA78L05S-1 J TA78L05S AC

VHiKA78L05B-1 IC2007 VHiMM1112XF1E J MM1112XFBE AF IC3001 VHiCXA2074Q-1 J CXA2074Q AY IC3201 VHiAN5285K/-1 J AN5285K AP IC3301 VHiM62494SP-1 J M62494SP AN IC4001 RH-iX3232CEZZ J SSE96G AV IC4002 VHiBA15218F-1 J BA15218F AD

TRANSISTORS

Q360 VS2SD601AR/-1 J 2SD601AR AC Q403 VS2SA1266-Y-1 J 2SA1266(Y) AA Q404 VS2SK30AG//2E J 2SK30AG AD Q405 VS2SD601AR/-1 J 2SD601AR AC Q406 VS2SD601AR/-1 J 2SD601AR AC Q408 VS2SC3198-Y-1 J 2SC3198(Y) AA Q409 VS2SD601AR/-1 J 2SD601AR AC Q410 VS2SC3198-Y-1 J 2SC3198(Y) AA Q901 VS2SD601AR/-1 J 2SD601AR AC Q902 VS2SD601AR/-1 J 2SD601AR AC Q903 VS2SD601AR/-1 J 2SD601AR AC Q904 VS2SD601AR/-1 J 2SD601AR AC Q905 VS2SD601AR/-1 J 2SD601AR AC Q906 VS2SD601AR/-1 J 2SD601AR AC Q1301 VS2SD601AR/-1 J 2SD601AR AC Q1302 VS2SD601AR/-1 J 2SD601AR AC Q1303 VS2SD601AR/-1 J 2SD601AR AC Q1401 VS2SD601AR/-1 J 2SD601AR AC Q1402 VS2SD601AR/-1 J 2SD601AR AC Q1404 VS2SD601AR/-1 J 2SD601AR AC Q1405 VS2SD601AR/-1 J 2SD601AR AC Q1406 VS2SD601AR/-1 J 2SD601AR AC Q1407 VS2SB709AR/-1 J 2SB709AR AC Q1408 VS2SB709AR/-1 J 2SB709AR AC Q1409 VS2SD601AR/-1 J 2SD601AR AC Q1410 VS2SB709AR/-1 J 2SB709AR AC Q1411 VS2SB709AR/-1 J 2SB709AR AC Q1412 VS2SD601AR/-1 J 2SD601AR AC Q1436 VS2SD601AR/-1 J 2SD601AR AC Q1450 VS2SD601AR/-1 J 2SD601AR AC Q1721 VS2SD601AR/-1 J 2SD601AR AC Q1741 VS2SD601AR/-1 J 2SD601AR AC Q1742 VS2SB709AR/-1 J 2SB709AR AC

Page 40

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT (Continued)

Q1791 VS2SC1959Y/1E J 2SC1959Y AC Q1813 VS2SD601AR/-1 J 2SD601AR AC Q1814 VS2SD601AR/-1 J 2SD601AR AC Q1815 VS2SD601AR/-1 J 2SD601AR AC Q1861 VS2SB709AR/-1 J 2SB709AR AC Q2003 VS2SD601AR/-1 J 2SD601AR AC Q2004 VSUN2212///-1 J UN2212 AA Q2005 VS2SD601AR/-1 J 2SD601AR AC Q2008 VS2SD601AR/-1 J 2SD601AR AC Q2009 VS2SD601AR/-1 J 2SD601AR AC Q4001 VS2SD601AR/-1 J 2SD601AR AC Q4002 VS2SD601AR/-1 J 2SD601AR AC Q4003 VS2SD601AR/-1 J 2SD601AR AC Q4004 VS2SD601AR/-1 J 2SD601AR AC Q4071 VS2SD601AR/-1 J 2SD601AR AC Q4072 VS2SD601AR/-1 J 2SD601AR AC

DIODES

D52 RH-EX0673GEZZ J Zener Diode, 32V AB D62 RH-EX0673GEZZ J Zener Diode, 32V AB D361 VHD1SS119//-1 J Diode AB D362 VHD1SS119//-1 J Diode AB D405 RH-EX0628GEZZ J Zener Diode, 8.2V AC D406 VHD1SS119//-1 J Diode AB D411 VHD1SS119//-1 J Diode AB D412 RH-EX0618GEZZ J Zener Diode, 6.2V AA D413 RH-EX0618GEZZ J Zener Diode, 6.2V AA D414 RH-EX0618GEZZ J Zener Diode, 6.2V AA D617 RH-EX0631GEZZ J Zener Diode, 9V AA D619 VHD1SS119//-1 J Diode AB D620 RH-EX0604GEZZ J Zener Diode, 3.9V AB D721 VHD1SS119//-1 J Diode AB D1301 RH-EX0631GEZZ J Zener Diode, 9V AA D1302 RH-EX0631GEZZ J Zener Diode, 9V AA D1303 RH-EX0631GEZZ J Zener Diode, 9V AA D1304 RH-EX0631GEZZ J Zener Diode, 9V AA D1305 RH-EX0631GEZZ J Zener Diode, 9V AA D1306 RH-EX0631GEZZ J Zener Diode, 9V AA D1308 RH-EX0631GEZZ J Zener Diode, 9V AA D1310 RH-EX0631GEZZ J Zener Diode, 9V AA D1311 RH-EX0631GEZZ J Zener Diode, 9V AA D1401 VHD1SS119//-1 J Diode AB D1402 VHD1SS119//-1 J Diode AB D1403 VHD1SS119//-1 J Diode AB D1701 RH-EX0631GEZZ J Zener Diode, 9V AA D1702 RH-EX0631GEZZ J Zener Diode, 9V AA D1704 RH-EX0631GEZZ J Zener Diode, 9V AA D1705 RH-EX0631GEZZ J Zener Diode, 9V AA D1791 RH-EX0604GEZZ J Zener Diode, 4.3V AB D1801 VHD1SS119//-1 J Diode AB D1821 VHD1SS119//-1 J Diode AB D2004 VHD1SS119//-1 J Diode AB D2005 RH-EX0616GEZZ J Zener Diode 6.2V AA D2006 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2007 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2008 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2010 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2014 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2024 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2025 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2026 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2030 RH-EX0616GEZZ J Zener Diode, 6.2V AA D2031 RH-DX0441CEZZ J Diode AC D2033 RH-EX0616GEZZ J Zener Diode, 6.2V AA D4001 VHD1SS119//-1 J Diode AB D4102 VHD1SS119//-1 J Diode AB

PACKAGED CIRCUITS

X801 RCRSB0001PEZZ R Crystal AL X1861 RCRSB0283CEZZ J Crystal AG

CF501 RFiLA0034CEZZ J Filter AD CF2001

RFiLC0121GEZZ J Filter AD

COILS

FILTERS

CAPACITORS

[EL.··· Electrolytic]

Page 41

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT (Continued)

C447 VCEA0A1CW337M J 330 16V EL. AC C601 VCFYFA1HA103J M 0.01 50V Mylar AA C613 VCKYCY1EB103K J 0.01 25V Ceramic AA C616 VCEA0A1HW225M J 2.2 50V EL. AB C617 VCEA0A1HW225M J 2.2 50V EL. AB C618 VCFYFA1HA223J M 0.022 50V Mylar AA C619 VCEA0A1CW337M J 330 16V EL. AC C620 VCKYCY1HB271K J 270p 50V Ceramic AA C621 VCKYCY1HB152K J 1500p 50V Ceramic AA C743 VCEA0A1EW476M J 47 25V EL. AB C744 VCEA0A1CW227M J 220 16V EL. AC C745 VCEA0A1EW476M J 47 25V EL. AB C746 VCEA0A1HW106M J 10 50V EL. AB C782 VCEA0A1HW106M J 10 50V EL. AB C783 VCEA0A1EW476M J 47 25V EL. AB C803 VCKYCY1HF103Z J 0.01 50V Ceramic AA C806 VCKYCY1CB104K J 0.1 16V Ceramic AB C807 VCEA0A1HW225M J 2.2 50V EL. AB C812 VCEAGA1HW224T J 0.22 50V EL. AB C813 VCQYTA1HM222J J 2200p 50V Mylar AA C814 VCCCCY1HH110J J 11p 50V Ceramic AA C817 VCCCCY1HH1R0C J 1.0p 50V Ceramic AA C818 VCKYCY1CB104K J 0.1 16V Ceramic AB C819 VCKYCY1CB104K J 0.1 16V Ceramic AB C843 VCKYCY1EB103K J 0.01 25V Ceramic AA C844 VCKYCY1EB103K J 0.01 25V Ceramic AA C845 VCKYCY1EB103K J 0.01 25V Ceramic AA C901 VCEA0A1HW475M J 4.7 50V EL. AB C903 VCEA0A1HW475M J 4.7 50V EL. AB C905 VCEA0A1EW476M J 47 25V EL. AB C956 VCEA0A1CW337M J 330 16V EL. AC C1301 VCQYTA1HM104K J 0.1 50V Mylar AC C1302 VCEA0A1HW105M J 1.0 50V EL. AB C1303 VCEA0A1HW105M J 1.0 50V EL. AB C1304 VCQYTA1HM104K J 0.1 50V Mylar AC C1305 VCEA0A1HW105M J 1.0 50V EL. AB C1306 VCEA0A1HW105M J 1.0 50V EL. AB C1307 VCQYTA1HM183J J 0.018 50V Mylar AB C1308 VCEA0A1HW225M J 2.2 50V EL. AB C1309 VCEA0A1HW225M J 2.2 50V EL. AB C1310 VCQYTA1HM104K J 0.1 50V Mylar AC C1311 VCQYTA1HM183J J 0.018 50V Mylar AB C1312 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1313 VCKYCY1HB271K J 270p 50V Ceramic AA C1314 VCKYCY1HB271K J 270p 50V Ceramic AA C1315 VCKYCY1HB271K J 270p 50V Ceramic AA C1316 VCKYCY1HB271K J 270p 50V Ceramic AA C1317 VCKYCY1CB104K J 0.1 16V Ceramic AB C1318 VCKYCY1CB104K J 0.1 16V Ceramic AB C1319 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1320 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1322 VCKYCY1CB104K J 0.1 16V Ceramic AB C1323 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1324 VCQYTA1HM104K J 0.1 50V Mylar AC C1325 VCEA0A1VW226M J 22 35V EL. AB C1326 VCEA0A1CW107M J 100 16V EL. AC C1327 VCKYCY1HB271K J 270p 50V Ceramic AA C1328 VCKYCY1HB271K J 270p 50V Ceramic AA C1329 VCEA0A1HW105M J 1.0 50V EL. AB C1330 VCEA0A1HW105M J 1.0 50V EL. AB C1332 VCQYTA1HM104K J 0.1 50V Mylar AC C1333 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB C1334 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB C1338 VCQYTA1HM104K J 0.1 50V Mylar AC C1339 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1340 VCKYCY1CB104K J 0.1 16V Ceramic AB C1341 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1401 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1402 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1404 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1405 VCKYCY1CB104K J 0.1 16V Ceramic AB C1406 VCEA0A1EW476M J 47 25V EL. AB

C1407 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1408 VCCCCY1HH181J J 180p 50V Ceramic AA C1409 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1410 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1411 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1412 VCEA0A1EW476M J 47 25V EL. AB C1413 VCKYCY1CB104K J 0.1 16V Ceramic AB C1414 VCFYFA1HA474J J 0.47 50V Mylar AC C1415 VCCCCY1HH150J J 15p 50V Ceramic AA C1416 VCEA0A1CW107M J 100 16V EL. AC C1417 VCCCCY1HH390J J 39p 50V Ceramic AA C1418 VCCCCY1HH120J J 12p 50V Ceramic AA C1420 VCCCCY1HH120J J 12p 50V Ceramic AA C1421 VCKYCY1CB104K J 0.1 16V Ceramic AB C1423 VCQYTA1HM473J J 0.047 50V Mylar AA C1424 VCEA0A1HW105M J 1.0 50V EL. AB C1425 VCQYTA1HM472J J 4700p 50V Mylar AB C1426 VCQYTA1HM473J J 0.047 50V Mylar AA C1428 VCQYTA1HM472J J 4700p 50V Mylar AB C1429 VCEA0A1HW105M J 1.0 50V EL. AB C1430 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1431 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1432 VCKYCY1CB104K J 0.1 16V Ceramic AB C1433 VCKYCY1CB104K J 0.1 16V Ceramic AB C1435 VCKYCY1CB104K J 0.1 16V Ceramic AB C1437 VCCSPA1HL102J J 1000p 50V Ceramic AA C1438 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1439 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1450 VCKYCY1CB104K J 0.1 16V Ceramic AB C1704 VCEA0A1HW106M J 10 50V EL. AB C1705 VCEA0A1EW476M J 47 25V EL. AB C1706 VCEA0A1HW106M J 10 50V EL. AB C1707 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1708 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1710 VCEA0A1HW105M J 1.0 50V EL. AB C1711 VCEA0A1EW476M J 47 25V EL. AB C1712 VCKYCY1CB104K J 0.1 16V Ceramic AB C1714 VCEA0A1HW106M J 10 50V EL. AB C1715 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1716 VCKYCY1HB271K J 270p 50V Ceramic AA C1717 VCKYCY1HB271K J 270p 50V Ceramic AA C1718 VCEA0A1HW105M J 1.0 50V EL. AB C1719 VCKYCY1CB104K J 0.1 16V Ceramic AB C1720 VCEA0A1HW106M J 10 50V EL. AB C1721 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1722 VCCCCY1HH330J J 33p 50V Ceramic AA C1723 VCEA0A1HW106M J 10 50V EL. AB C1724 VCFYFA1HA104J J 0.1 50V Mylar AA C1725 VCFYFA1HA104J J 0.1 50V Mylar AA C1726 VCFYFA1HA104J J 0.1 50V Mylar AA C1727 VCEA0A1HW106M J 10 50V EL. AB C1728 VCE9GA1CW106M J 10 16V EL.(N.P) AB C1729 VCEA0A1HW106M J 10 50V EL. AB C1741 VCQYTA1HM473J J 0.047 50V Mylar AA C1742 VCEA0A1HW105M J 1.0 50V EL. AB C1743 VCQYTA1HM472J J 4700p 50V Mylar AB C1744 VCKYCY1CB104K J 0.1 16V Ceramic AB C1747 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1791 VCEA0A1AW107M J 100 10V EL. AB C1792 VCEA0A1AW107M J 100 10V EL. AB C1793 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1801 VCKYCY1CB104K J 0.1 16V Ceramic AB C1802 VCKYCY1EB103K J 0.01 25V Ceramic AA C1803 VCKYCY1EB103K J 0.01 25V Ceramic AA C1804 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1805 VCEA0A1HW106M J 10 50V EL. AB C1806 VCKYCY1CB104K J 0.1 16V Ceramic AB C1807 VCKYCY1EB103K J 0.01 25V Ceramic AA C1809 VCKYCY1EB103K J 0.01 25V Ceramic AA C1810 VCEA0A1VW226M J 22 35V EL. AB C1811 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1812 VCEA0A1HW106M J 10 50V EL. AB C1817 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1821 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1822 VCEA0A1HW106M J 10 50V EL. AB C1833 VCQYTA1HM562J J 5600p 50V Mylar AA

Page 42

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT (Continued)

C1841 VCEA0A1HW106M J 10 50V EL. AB C1842 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1843 VCCCCY1HH680J J 68p 50V Ceramic AA C1844 VCKYCY1CB104K J 0.1 16V Ceramic AB C1845 VCKYCY1EB103K J 0.01 25V Ceramic AA C1846 VCCCCY1HH151J J 150p 50V Ceramic AA C1847 VCKYCY1EB103K J 0.01 25V Ceramic AA C1848 VCKYCY1CB104K J 0.1 16V Ceramic AB C1849 VCEA0A1HW106M J 10 50V EL. AB C1850 VCKYCY1CB104K J 0.1 16V Ceramic AB C1851 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1861 VCKYCY1CB104K J 0.1 16V Ceramic AB C1862 VCKYCY1CB104K J 0.1 16V Ceramic AB C1863 VCCCCY1HH101J J 100p 50V Ceramic AA C1865 VCFYFA1HA154J J 0.15 50V Mylar AC C1866 VCQYTA1HM103J J 0.01 50V Mylar AA C1867 VCKYCY1CB104K J 0.1 16V Ceramic AB C1868 VCFYFA1HA474J J 0.47 50V Mylar AC C1869 VCKYCY1HF103Z J 0.01 50V Ceramic AA C1870 VCEA0A1HW106M J 10 50V EL. AB C1871 VCEA0A1HW106M J 10 50V EL. AB C1872 VCKYCY1EB103K J 0.01 25V Ceramic AA C2005 VCEA0A1HW225M J 2.2 50V EL. AB C2006 VCEA0A1HW105M J 1.0 50V EL. AB C2007 VCKYCY1HB561K J 560p 50V Ceramic AA C2008 VCQYTA1HM104J J 0.1 50V Mylar AA C2009 VCKYCY1HB102K J 1000p 50V Ceramic AA C2010 VCKYCY1HB221K J 220p 50V Ceramic AA C2011 VCEA0A1HW105M J 1.0 50V EL. AB C2012 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2013 VCKYCY1CB104K J 0.1 16V Ceramic AB C2014 VCKYCY1HB102K J 1000p 50V Ceramic AA C2016 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2017 VCCCCY1HH101J J 100p 50V Ceramic AA C2018 VCCCCY1HH101J J 100p 50V Ceramic AA C2019 VCKYCY1HB102K J 1000p 50V Ceramic AA C2020 VCKYCY1HB102K J 1000p 50V Ceramic AA C2021 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2022 VCEA0A1HW106M J 10 50V EL. AB C2023 VCEA0A1AW107M J 100 10V EL. AB C2024 VCEA0A1HW106M J 10 50V EL. AB C2025 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2026 VCEA0A0JW477M J 470 6.3V EL. AC C2027 VCKYCY1HF103Z J 0.01 50V Ceramic AA C2028 VCEA0A1AW107M J 100 10V EL. AB C2029 VCFYFA1HA474J J 0.47 50V Mylar AC C2030 VCEA0A1HW106M J 10 50V EL. AB C2031 VCEA0A1AW228M J 2200 10V EL. AD C2032 VCCCCY1HH270J J 27p 50V Ceramic AA C2034 VCCCCY1HH390J J 39p 50V Ceramic AA C2040 VCKYCY1CB104K J 0.1 16V Ceramic AB C2042 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3001 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA C3003 VCQYTA1HM123K J 0.012 50V Mylar AA C3004 VCEA0A1HW105M J 1.0 50V EL. AB C3005 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3006 VCEA0A1HW106M J 10 50V EL. AB C3007 VCEA0A1HW475M J 4.7 50V EL. AB C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3009 VCEA0A1CW227M J 220 16V EL. AC C3010 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3011 VCEA0A1HW475M J 4.7 50V EL. AB C3012 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA C3014 VCQYTA1HM473K J 0.047 50V Mylar AB C3015 VCSATA1CE335K J 3.3 16V Tantalum AC C3016 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3017 VCSATA1CE106K J 10 16V Tantalum AD C3018 VCEA0A1HW105M J 1.0 50V EL. AB C3019 VCEA0A1HW225M J 2.2 50V EL. AB C3020 VCEA0A1HW225M J 2.2 50V EL. AB

C3029 VCKYCY1HB682K J 6800p 50V Ceramic AA C3030 VCKYCY1HB682K J 6800p 50V Ceramic AA C3031 VCKYCY1CB473K J 0.047 16V Ceramic AA C3032 VCKYCY1CB473K J 0.047 16V Ceramic AA C3201 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3202 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3203 VCEA0A1HW475M J 4.7 50V EL. AB C3204 VCEA0A1HW106M J 10 50V EL. AB C3205 VCEA0A1HW106M J 10 50V EL. AB C3206 VCKYCY1HB103K J 0.01 50V Ceramic AA C3207 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3208 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3209 VCEA0A1HW106M J 10 50V EL. AB C3301 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3302 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB C3303 VCKYCY1HB183K J 0.018 50V Ceramic AB C3304 VCKYCY1HB471K J 470p 50V Ceramic AA C3305 VCFYFA1HA103J M 0.01 50V Mylar AA C3306 VCFYFA1HA824J M 0.82 50V Mylar AC C3307 VCKYCY1HB471K J 470p 50V Ceramic AA C3308 VCEA0A1CW107M J 100 16V EL. AC C3309 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3310 VCKYCY1HF103Z J 0.01 50V Ceramic AA C3311 VCFYFA1HA103J M 0.01 50V Mylar AA C3312 VCFYFA1HA224J J 0.22 50V Mylar AB C3313 VCQYTA1HM472J J 4700p 50V Mylar AB C3314 VCFYFA1HA104J J 0.1 50V Mylar AA C3315 VCFYFA1HA103J M 0.01 50V Mylar AA C3316 VCEA0A1HW106M J 10 50V EL. AB C4002 VCE9GA1HW105M J 1.0 50V EL.(N.P) AB C4003 VCKYCY1HF103Z J 0.01 50V Ceramic AA C4004 VCEA0A1CW337M J 330 16V EL. AC C4005 VCCCCY1HH101J J 100p 50V Ceramic AA C4006 VCCCCY1HH101J J 100p 50V Ceramic AA C4007 VCEA0A1CW337M J 330 16V EL. AC C4020 VCEA0A1EW476M J 47 25V EL. AB C4071 VCEA0A1CW107M J 100 16V EL. AC C4072 VCKYCY1HB152K J 1500p 50V Ceramic AA C4073 VCKYCY1HB152K J 1500p 50V Ceramic AA C4101 VCE9GA1HW105M J 1.0 50V EL.(N.P) AB

RESISTORS

[M-Ox.··· Metal Oxide]

RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ23 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ24 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ38 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ40 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ41 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ42 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ43 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ45 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ48 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ49 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ50 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ51 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ52 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ53 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ54 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ55 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ56 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ57 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ58 VRS-CY1JF000J J 0 1/16W M-Ox. AA

Page 43

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT (Continued)

RJ59 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ60 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ61 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ62 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ63 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ64 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ65 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ67 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ68 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ69 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ70 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ72 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ73 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ77 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ78 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ81 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ82 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ83 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ84 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ85 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ89 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ90 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ91 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ92 VRS-CY1JF000J J 0 1/16W M-Ox. AA RJ96 VRS-CY1JF000J J 0 1/16W M-Ox. AA R52 VRD-RA2BE101J J 100 1/8W Carbon AB R53 VRD-RA2BE101J J 100 1/8W Carbon AB R54 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA R62 VRS-CY1JF101J J 100 1/16W M-Ox. AA R63 VRS-CY1JF101J J 100 1/16W M-Ox. AA R64 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA R351 VRS-CY1JF101J J 100 1/16W M-Ox. AA R360 VRS-CY1JF221J J 220 1/16W M-Ox. AA R361 VRD-RA2BE562J J 5.6k 1/8W Carbon AA R362 VRD-RA2BE562J J 5.6k 1/8W Carbon AA R363 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R364 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R365 VRS-CY1JF221J J 220 1/16W M-Ox. AA R370 VRS-CY1JF221J J 220 1/16W M-Ox. AA R371 VRD-RA2EE3R3J J 3.3 1/4W Carbon AA R372 VRD-RA2EE3R3J J 3.3 1/4W Carbon AA R401 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA R402 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R403 VRD-RA2EE680J J 68 1/4W Carbon AA R405 VRS-CY1JF471J J 470 1/16W M-Ox. AA R406 VRS-CY1JF471J J 470 1/16W M-Ox. AA R407 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R410 VRS-CY1JF820J J 82 1/16W M-Ox. AA R411 VRS-CY1JF820J J 82 1/16W M-Ox. AA R412 VRS-CY1JF820J J 82 1/16W M-Ox. AA R414 VRS-CY1JF101J J 100 1/16W M-Ox. AA R415 VRS-CY1JF101J J 100 1/16W M-Ox. AA R416 VRS-CY1JF101J J 100 1/16W M-Ox. AA R418 VRS-CY1JF101J J 100 1/16W M-Ox. AA R419 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA R425 VRS-CY1JF474J J 470k 1/16W M-Ox. AA R428 VRS-CY1JF101J J 100 1/16W M-Ox. AA R432 VRS-CY1JF823J J 82k 1/16W M-Ox. AA R434 VRS-CY1JF124J J 120k 1/16W M-Ox. AA R435 VRS-CY1JF395J J 3.9M 1/16W M-Ox. AA R436 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R437 VRS-CY1JF154J J 150k 1/16W M-Ox. AA R438 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R439 VRS-CY1JF273J J 27k 1/16W M-Ox. AA R440 VRS-CY1JF101J J 100 1/16W M-Ox. AA R441 VRS-CY1JF471J J 470 1/16W M-Ox. AA R444 VRS-CY1JF471J J 470 1/16W M-Ox. AA R445 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R447 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R448 VRS-CY1JF151J J 150 1/16W M-Ox. AA R449 VRS-CY1JF100J J 10 1/16W M-Ox. AA R455 VRS-CY1JF101J J 100 1/16W M-Ox. AA

R456 VRD-RA2EE152J J 1.5k 1/4W Carbon AA R461 VRD-RA2BE182J J 1.8k 1/8W Carbon AA R462 VRS-CY1JF393J J 39k 1/16W M-Ox. AA R463 VRS-CY1JF273J J 27k 1/16W M-Ox. AA R464 VRS-CY1JF393J J 39k 1/16W M-Ox. AA R540 VRS-CY1JF391J J 390 1/16W M-Ox. AA R541 VRS-CY1JF101J J 100 1/16W M-Ox. AA R602 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R603 VRD-RA2EE331J J 330 1/4W Carbon AA R613 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R616 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA R617 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R620 VRD-RA2BE153J J 15k 1/8W Carbon AA R627 VRS-SV2HC101J J 100 1/2W M-Ox. AA

å R738 VRS-RG3LB123J J 12k 3.0W M-Ox. AB å R744 VRS-RG3DB330J J 33 2W M-Ox. AA å R745 VRS-RG3LB120J J 12 3.0W M-Ox. AB å R746 VRS-RG3DB330J J 33 2W M-Ox. AA å R782 VRS-VV3DB270J J 27 2W M-Ox. AA

R784 VRS-VV3DB151J J 150 2W M-Ox. AA R803 VRS-CY1JF101J J 100 1/16W M-Ox. AA R807 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R814 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R817 VRS-CY1JF273J J 27k 1/16W M-Ox. AA R820 VRD-RA2BE101J J 100 1/8W Carbon AB R821 VRD-RA2BE101J J 100 1/8W Carbon AB R822 VRD-RA2BE101J J 100 1/8W Carbon AB R823 VRD-RA2BE101J J 100 1/8W Carbon AB R827 VRS-CY1JF181J J 180 1/16W M-Ox. AA R828 VRS-CY1JF181J J 180 1/16W M-Ox. AA R829 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA R830 VRS-CY1JF101J J 100 1/16W M-Ox. AA R903 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R904 VRS-CY1JF683J J 68k 1/16W M-Ox. AA R905 VRS-CY1JF123J J 12k 1/16W M-Ox. AA R906 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R907 VRS-CY1JF821J J 820 1/16W M-Ox. AA R908 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R910 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R911 VRS-CY1JF683J J 68k 1/16W M-Ox. AA R912 VRS-CY1JF123J J 12k 1/16W M-Ox. AA R913 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R914 VRS-CY1JF821J J 820 1/16W M-Ox. AA R915 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R920 VRS-CY1JF683J J 68k 1/16W M-Ox. AA R921 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R922 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R963 VRD-RA2BE101J J 100 1/8W Carbon AB R1301 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1302 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1303 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1304 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1305 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1306 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1307 VRS-CY1JF680J J 68 1/16W M-Ox. AA R1308 VRS-CY1JF8R2J J 8.2 1/16W M-Ox. AA R1309 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1310 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1311 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1312 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1313 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1314 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1315 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1316 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R1317 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1318 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1319 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1320 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R1321 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1323 VRS-CY1JF181J J 180 1/16W M-Ox. AA R1324 VRS-CY1JF181J J 180 1/16W M-Ox. AA R1325 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA R1326 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1327 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1328 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1329 VRS-CY1JF101J J 100 1/16W M-Ox. AA

Page 44

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT (Continued)

R1330 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1331 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1332 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1333 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1334 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1335 VRD-RA2BE100J J 10 1/8W Carbon AA R1336 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1337 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1338 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1341 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1342 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1359 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1360 VRS-CY1JF680J J 68 1/16W M-Ox. AA R1361 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1362 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1363 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1364 VRS-CY1JF8R2J J 8.2 1/16W M-Ox. AA R1401 VRS-CY1JF821J J 820 1/16W M-Ox. AA R1402 VRS-CY1JF561J J 560 1/16W M-Ox. AA R1403 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R1404 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1405 VRS-CY1JF331J J 330 1/16W M-Ox. AA R1406 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1407 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1408 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1411 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1412 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA R1413 VRS-CY1JF561J J 560 1/16W M-Ox. AA R1414 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1415 VRS-CY1JF471J J 470 1/16W M-Ox. AA R1416 VRS-CY1JF821J J 820 1/16W M-Ox. AA R1418 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1419 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1420 VRS-CY1JF151J J 150 1/16W M-Ox. AA R1421 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1422 VRS-CY1JF684J J 680k 1/16W M-Ox. AA R1423 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1424 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1425 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1426 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1427 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1428 VRS-CY1JF151J J 150 1/16W M-Ox. AA R1429 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1430 VRS-CY1JF684J J 680k 1/16W M-Ox. AA R1431 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1432 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1433 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1443 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1444 VRD-RA2BE182J J 1.8k 1/8W Carbon AA R1445 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1446 VRD-RA2BE101J J 100 1/8W Carbon AB R1447 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1448 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1450 VRS-CY1JF273J J 27k 1/16W M-Ox. AA R1452 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA R1453 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1701 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1702 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1703 VRS-CY1JF750J J 75 1/16W M-Ox. AA R1704 VRD-RA2BE101J J 100 1/8W Carbon AB R1705 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1706 VRD-RA2BE101J J 100 1/8W Carbon AB R1715 VRD-RA2BE101J J 100 1/8W Carbon AB R1717 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1718 VRD-RA2BE101J J 100 1/8W Carbon AB R1720 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R1721 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R1722 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1723 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA R1724 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1726 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1729 VRD-RA2BE101J J 100 1/8W Carbon AB

R1731 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1732 VRS-CY1JF681J J 680 1/16W M-Ox. AA R1733 VRD-RA2BE471J J 470 1/8W Carbon AA R1734 VRS-CY1JF101J J 100 1/16W M-Ox. AA R1741 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1742 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1743 VRS-CY1JF151J J 150 1/16W M-Ox. AA R1744 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA R1745 VRS-CY1JF474J J 470k 1/16W M-Ox. AA R1746 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA R1747 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1791 VRD-RA2BE151J J 150 1/8W Carbon AA R1801 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R1810 VRD-RA2BE473J J 47k 1/8W Carbon AA R1812 VRD-RA2BE123J J 12k 1/8W Carbon AA R1813 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1816 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R1817 VRD-RA2BE123J J 12k 1/8W Carbon AA R1819 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R1821 VRS-CY1JF123J J 12k 1/16W M-Ox. AA R1822 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R1823 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R1825 VRS-CY1JF183J J 18k 1/16W M-Ox. AA R1828 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1831 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R1832 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R1833 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA R1834 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R1841 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1842 VRS-CY1JF471J J 470 1/16W M-Ox. AA R1843 VRS-CY1JF391J J 390 1/16W M-Ox. AA R1861 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R1862 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R1863 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R1864 VRS-CY1JF221J J 220 1/16W M-Ox. AA R1865 VRS-CY1JF474J J 470k 1/16W M-Ox. AA R1866 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R1867 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R1868 VRS-CY1JF510J J 51 1/16W M-Ox. AA R1869 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R1870 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2001 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2002 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2003 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2004 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R2005 VRD-RA2BE682J J 6.8k 1/8W Carbon AA R2006 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2007 VRS-CY1JF223J J 22k 1/16W M-Ox. AA

'åR2008 VRD-RA2BE273J J 27k 1/8W Carbon AA

R2009 VRD-RA2BE223J J 22k 1/8W Carbon AA R2010 VRS-CY1JF103J J 10k 1/16W M-Ox. AA

'åR2011 VRS-CY1JF473J J 47k 1/16W M-Ox. AA

Page 45

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-A: DUNTK9833WEK8 (32N-X2000)

MAIN UNIT (Continued)

R2038 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2039 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2040 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2043 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2045 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2046 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2048 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2049 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2050 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA R2051 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R2052 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2053 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R2054 VRD-RA2BE472J J 4.7k 1/8W Carbon AA R2057 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2058 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2059 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA R2060 VRS-CY1JF184J J 180k 1/16W M-Ox. AA R2061 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2062 VRD-RA2BE823J J 82k 1/8W Carbon AA R2063 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2064 VRS-CY1JF153J J 15k 1/16W M-Ox. AA R2065 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2066 VRD-RA2BE183J J 18k 1/8W Carbon AA R2067 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2068 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2069 VRD-RA2BE123J J 12k 1/8W Carbon AA R2070 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2071 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2073 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2074 VRD-RA2BE103J J 10k 1/8W Carbon AA R2075 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R2076 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R2077 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2078 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R2080 VRS-CY1JF471J J 470 1/16W M-Ox. AA R2081 VRS-CY1JF471J J 470 1/16W M-Ox. AA R2084 VRD-RA2BE472J J 4.7k 1/8W Carbon AA R2092 VRD-RA2BE101J J 100 1/8W Carbon AB R2093 VRD-RA2BE101J J 100 1/8W Carbon AB R2094 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R2095 VRS-CY1JF101J J 100 1/16W M-Ox. AA R2097 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R2099 VRD-RA2BE101J J 100 1/8W Carbon AB R3001 VRD-RA2BE221J J 220 1/8W Carbon AA R3002 VRD-RA2BE221J J 220 1/8W Carbon AA R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R3006 VRS-CY1JF623J J 62k 1/16W M-Ox. AA R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R3011 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R3012 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R3013 VRD-RA2BE101J J 100 1/8W Carbon AB R3014 VRD-RA2BE101J J 100 1/8W Carbon AB R3015 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R3016 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R3017 VRD-RA2BE101J J 100 1/8W Carbon AB R3018 VRD-RA2BE101J J 100 1/8W Carbon AB R3104 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R3201 VRS-CY1JF225J J 2.2M 1/16W M-Ox. AA R3202 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA R3203 VRS-CY1JF101J J 100 1/16W M-Ox. AA R3301 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA R3302 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA R3303 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R3304 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R3305 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA R3306 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R3307 VRS-CY1JF104J J 100k 1/16W M-Ox. AA R3308 VRS-CY1JF101J J 100 1/16W M-Ox. AA R4012 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA

R4013 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R4014 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA R4015 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R4017 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R4020 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R4021 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R4023 VRS-CY1JF473J J 47k 1/16W M-Ox. AA R4025 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA R4026 VRD-RA2BE183J J 18k 1/8W Carbon AA R4027 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R4028 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R4071 VRD-RA2BE332J J 3.3k 1/8W Carbon AA R4072 VRD-RA2BE562J J 5.6k 1/8W Carbon AA R4073 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R4074 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R4075 VRD-RA2EE561J J 560 1/4W Carbon AA R4076 VRD-RA2EE561J J 560 1/4W Carbon AA R4101 VRS-CY1JF471J J 470 1/16W M-Ox. AA R4103 VRS-CY1JF333J J 33k 1/16W M-Ox. AA R4104 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R4105 VRS-CY1JF471J J 470 1/16W M-Ox. AA R4106 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA R4108 VRS-CY1JF103J J 10k 1/16W M-Ox. AA R4109 VRS-CY1JF223J J 22k 1/16W M-Ox. AA R4110 VRS-CY1JF223J J 22k 1/16W M-Ox. AA

MISCELLANEOUS PARTS

J1301 QTANJ0821CEZZ M Terminal Video/Audio-IN AL J1302 QSOCD0430CEZZ J Socket, Video-1 S-Video AE J1303 QSOCD0430CEZZ J Socket, Video-3 S-Video AE J1701 QTANJ0527CEZZ J Terminal Component-IN AL P109 QPLGN0661CEZZ J Plug 6-pin(EJ) AD P351 QPLGN0461CEZZ J Plug 4-pin(S) AB P404 QPLGN0361CEZZ J Plug 3-pin(PA) AB P603 QPLGN0861CEZZ J Plug 8-pin(D) AC P706 QPLGN0160CEZZ J Plug 1-pin(SG) AB P1801 QPLGN0961CEZZ J Plug 9-pin(C) AD P1802 QPLGN0561CEZZ J Plug 5-pin(GBN) AB P1803 QPLGN1061CEZZ J Plug10-pin(H) AC P2001 QPLGN0561CEZZ J Plug 5-pin(TP2001-5) AB P2002 QPLGN0561CEZZ J Plug 5-pin(KA) AB P2003 QPLGN0461CEZZ J Plug 4-pin(YR) AB RDA362

PRDAR1012MEFW M Heat Sink, for IC362 AE RDA740

PRDAR5072CEFW J Heat Sink, for IC740 AC RDA741

PRDAR5072CEFW J Heat Sink, for IC741 AC

SLD1801

PSLDM0012MEFW J Shield AD

LHLDW1002PEZZ R Holder AB

LX-BZ3049GEFD J Screw AA

Page 46

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-B: DUNTKA119WEK4 (32N-S500)

CRT UNIT

IC850 VHiTDA6103Q-1 J TDA6103Q/N3 AL

Q850 VS2SA1266-Y-1 J 2SA1266(Y) AA Q851 VS2SC3198-Y-1 J 2SC3198(Y) AA

D850 RH-DX0220CEZZ J Diode AB D851 RH-DX0220CEZZ J Diode AB D852 RH-DX0220CEZZ J Diode AB D853 RH-EX0647GEZZ J Zener Diode, 15V AA

D854 VHD1SS119//-1 J Diode AB D855 VHD1SS119//-1 J Diode AB D856 RH-EX0722GEZZ J Zener Diode, 3.0V AA

C850 VCFYSB2EB823J J 0.082 250V Mylar AD C851 RC-KZ018JCEZZ J 0.01 1.5kV Ceramic AC

C852 VCEA0A1CW227M J 220 16V EL. AC C853 VCFYFA1HA224J J 0.22 50V Mylar AB C854 VCEA0A1CW227M J 220 16V EL. AC C855 VCEA0A2EW106M J 10 250V EL. AD

R850 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA R851 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA R852 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA R853 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA R854 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA R855 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA R856 VRD-RM2HD224J J 220k 1/2W Carbon AA R857 VRD-RM2HD224J J 220k 1/2W Carbon AA R858 VRD-RM2HD224J J 220k 1/2W Carbon AA R862 VRC-MA2HG152K J 1.5k 1/2W Solid AA R863 VRC-MA2HG152K J 1.5k 1/2W Solid AA R864 VRC-MA2HG152K J 1.5k 1/2W Solid AA R867 VRS-SV2HC332J J 3.3k 1/2W M-Ox. AA R868 VRS-SV2HC222J J 2.2k 1/2W M-Ox. AA R869 VRD-RA2BE223J J 22k 1/8W Carbon AA R870 VRD-RA2BE223J J 22k 1/8W Carbon AA R871 VRD-RA2BE223J J 22k 1/8W Carbon AA R872 VRD-RA2EE680J J 68 1/4W Carbon AA R873 VRD-RM2HD224J J 220k 1/2W Carbon AA R874 VRD-RM2HD184J J 180k 1/2W Carbon AA R875 VRD-RM2HD184J J 180k 1/2W Carbon AA R876 VRD-RM2HD184J J 180k 1/2W Carbon AA

å R877 VRS-SV2HC120J J 12 1/2W M-Ox. AA

P850 QPLGN0561CEZZ J Plug 5-pin(GBN) AB P855 QPLGN0461CEZZ J Plug 4-pin(YBN) AB SC850 QSOCV0937CEZZ J CRT Socket AL RDA850

INTEGRATED CIRCUIT

TRANSISTORS

DIODES

or RH-EX0417GEZZ

or RH-EX0349GEZZ

CAPACITORS

[EL.··· Electrolytic]

or RC-KZ015JCEZZ

RESISTORS

[M-Ox.··· Metal Oxide]

MISCELLANEOUS PARTS

PRDAR0248PEFW R Heat Sink, for IC850 AF LX-BZ3100CEFD J Screw AA

PWB-B: DUNTKA119WEK2 (32N-X2000)

CRT UNIT

INTEGRATED CIRCUIT

IC850 VHiTDA6103Q-1 J TDA6103Q/N3 AL

TRANSISTORS

Q850 VS2SA1266-Y-1 J 2SA1266(Y) AA Q851 VS2SC3198-Y-1 J 2SC3198(Y) AA Q1504 VS2SC3198-Y-1 J 2SC3198(Y) AA Q1505 VS2SA1266-Y-1 J 2SA1266(Y) AA Q1506 VS2SA1964E/-1 J 2SA1964E AF Q1507 VS2SC5248E/-1 J 2SC5248E AE

DIODES

D850 RH-DX0220CEZZ J Diode AB D851 RH-DX0220CEZZ J Diode AB D852 RH-DX0220CEZZ J Diode AB D853 RH-EX0647GEZZ J Zener Diode, 15V AA

RH-EX0417GEZZ D854 VHD1SS119//-1 J Diode AB D855 VHD1SS119//-1 J Diode AB D856 RH-EX0722GEZZ J Zener Diode, 3.0V AA

RH-EX0349GEZZ D1502 VHD1SS119//-1 J Diode AB D1503 VHD1SS119//-1 J Diode AB D1506 RH-DX0487CEZZ J Diode AC D1507 RH-DX0487CEZZ J Diode AC D1508 VHD1SS119//-1 J Diode AB

CAPACITORS

[EL.··· Electrolytic]

C850 VCFYSB2EB823J J 0.082 250V Mylar AD C851 RC-KZ018JCEZZ J 0.01 1.5kV Ceramic AC

RC-KZ015JCEZZ C852 VCEA0A1CW227M J 220 16V EL. AC C853 VCFYFA1HA224J J 0.22 50V Mylar AB C854 VCEA0A1CW227M J 220 16V EL. AC C855 VCEA0A2EW106M J 10 250V EL. AD C1501 VCEA0A1EW476M J 47 25V EL. AB C1506 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1508 VCKYPA2HB472K J 4700p 500V Ceramic AB C1509 VCKYPA1HB472K J 4700p 50V Ceramic AA C1510 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1511 VCKYPA1HF103Z J 0.01 50V Ceramic AA C1515 VCEA0A1EW476M J 47 25V EL. AB C1516 VCEA0A1EW476M J 47 25V EL. AB C1517 VCEA0A2AW106M J 10 100V EL. AC C1518 VCCSPA2HL560K J 56p 500V Ceramic AA C1519 VCEA4A2CN106M J 10 160V EL. AC

RESISTORS

[M-Ox.··· Metal Oxide]

Page 47

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-B: DUNTKA119WEK2 (32N-X2000)

CRT UNIT (Continued)

R873 VRD-RM2HD224J J 220k 1/2W Carbon AA R874 VRD-RM2HD184J J 180k 1/2W Carbon AA R875 VRD-RM2HD184J J 180k 1/2W Carbon AA R876 VRD-RM2HD184J J 180k 1/2W Carbon AA

å R877 VRS-SV2HC120J J 12 1/2W M-Ox. AA

R1511 VRD-RA2BE101J J 100 1/8W Carbon AB

å R1513 VRS-VV3DB561J J 560 2W M-Ox. AA

R1514 VRD-RA2BE100J J 10 1/8W Carbon AA R1515 VRD-RA2BE820J J 82 1/8W Carbon AA R1516 VRD-RA2BE820J J 82 1/8W Carbon AA R1517 VRD-RA2BE122J J 1.2k 1/8W Carbon AA R1518 VRD-RA2BE683J J 68k 1/8W Carbon AA R1519 VRD-RA2BE123J J 12k 1/8W Carbon AA R1520 VRD-RA2BE683J J 68k 1/8W Carbon AA R1521 VRD-RA2BE122J J 1.2k 1/8W Carbon AA R1522 VRD-RA2EE471J J 470 1/4W Carbon AA R1525 VRD-RA2EE560J J 56 1/4W Carbon AA R1526 VRD-RA2EE560J J 56 1/4W Carbon AA R1527 VRD-RA2EE4R7J J 4.7 1/4W Carbon AA R1528 VRD-RA2EE4R7J J 4.7 1/4W Carbon AA

å R1529 VRS-VV3DB221J J 220 2W M-Ox. AA

R1530 VRD-RA2BE122J J 1.2k 1/8W Carbon AA

FB1501 P850 QPLGN0561CEZZ J Plug 5-pin(GBN) AB P851 QPLGN0361CEZZ J Plug 3-pin(PA) AB P852 QPLGN0361CEZZ J Plug 3-pin(PU) AB P854 QPLGN0661CEZZ J Plug 6-pin(BBN) AD SC850 QSOCV0937CEZZ J CRT Socket AL RDA850

RDA1506 RDA1507

MISCELLANEOUS PARTS

RBLN-0047CEZZ J Ferrite Bead AB

PRDAR0248PEFW R Heat Sink, for IC850 AF PRDAR5072CEFW J Heat Sink, for Q1506 AC PRDAR5072CEFW J Heat Sink, for Q1507 AC LX-BZ3100CEFD J Screw AA

PWB-C: DUNTK9834WEL2 (32N-S500)

POWER UNIT

INTEGRATED CIRCUITS

å IC501 VHiTA8427K/-1 J TA8427K AL

IC502 VHiTA1241AN-1 J TA1241AN AM IC504 VHiUPC358C/-1 J UPC358C AD

å IC701 VHiSTRF66261E J STR-F6626 AX å IC702 RH-FX0034CEZZ J PC817 AE

or RH-FX0029CEZZ

å IC703 VHiSE125N//-1 M SE125N AG å IC750 VHiKA7809AP-1 M KIA7809AP AE

TRANSISTORS

Q501 VS2SC3198-Y-1 J 2SC3198(Y) AA Q601 VS2SC2482//-1 J 2SC2482 AD

å Q602 VS2SD2500//2E J 2SD2500 AT

Q672 VS2SA1266-Y-1 J 2SA1266(Y) AA Q673 VS2SD2045//-1 J 2SD2045 AL Q751 VS2SC3198-Y-1 J 2SC3198(Y) AA

DIODES

D501 RH-DX0302CEZZ J Diode AC D502 RH-EX0604GEZZ J Zener Diode, 3V AB D504 RH-EX0631GEZZ J Zener Diode, 9.1V AA D507 RH-DX0441CEZZ J Diode AC D508 RH-EX0616GEZZ J Zener Diode, 6.2V AA D509 RH-EX0616GEZZ J Zener Diode, 6.2V AA D511 RH-EX0654CEZZ J Zener Diode, 75V AD D602 VHD1SS119//-1 J Diode AB

å D605 RH-DX0255CEZZ J Diode AC

D621 RH-EX0631GEZZ J Zener Diode, 9.1V AA

å D622 RH-DX0131CEZZ J Diode AC 'åD651 RH-DX0130CEZZ J Diode AE 'åD652 RH-EX0641GEZZ J Zener Diode, 12V AA 'åD653 VHD1SS119//-1 J Diode AB 'åD654 VHD1SS119//-1 J Diode AB

å D673 RH-DX0229CEZZ J Diode AF

D705 VHD1SS82///1A J Diode AC D706 RH-DX0130CEZZ J Diode AE D707 VHD1SS82///1A J Diode AC D708 RH-DX0130CEZZ J Diode AE

å D709 RH-DX0229CEZZ J Diode AF

D710 RH-EX0673GEZZ J Zener Diode, 30V AB

å D712 RH-DX0468CEZZ J Diode AE

å D713 RH-DX0477CEZZ J Diode AE

D715 RH-EX0610GEZZ J Zener Diode, 4.7V AA D716 VHD1SS119//-1 J Diode AB D723 RH-EX0650GEZZ J Zener Diode, 16V AB

å D725 RH-DX0420CEZZ J Diode AE

å D751 RH-DX0441CEZZ J Diode AC

å D752 RH-DX0441CEZZ J Diode AC

å D753 RH-DX0441CEZZ J Diode AC

å D754 RH-DX0441CEZZ J Diode AC

D755 VHD1SS119//-1 J Diode AB

å VA701 RH-VX0048CEZZ J Varistor AE

or RH-VX0035CEZZ

å PR701 RMPTP0059CEZZ J Packaged Circuit AH

L501 VP-XF8R2K0000 J Peaking 8.2µH AB L671 RCiLZ1005CEZZ J Coil AH

or RCiLZ0868CEZZ

L672 RCiLZ1027CEZZ J Coil AK

or RCiLZ0789CEZZ

å L701 RCiLF0313CEZZ J Coil AH

or RCiLF0273CEZZ

COILS AND PACKAGED CIRCUIT

Page 48

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-C: DUNTK9834WEL2 (32N-S500)

POWER UNIT (Continued)

å L702 RCiLF0313CEZZ J Coil AH

RCiLF0273CEZZ L705 RCiLP0179CEZZ J Coil AD L729 RCiLP0179CEZZ J Coil AD L740 VP-XF101K0000 J Peaking 100µH AB

TRANSFORMERS

å T601 RTRNZ0057PEZZ R Transformer AK

'åT602 RTRNF0035MEZZ M H-Out AZ

å T701 RTRNP0547CEZZ J Power AK å T702 RTRNZ0021MEZZ M Transformer AM

CAPACITORS

[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]

C451 VCQYTA2AA104K J 0.1 100V Mylar AB C501 VCKYPA2HB102K J 1000p 500V Ceramic AA C502 VCEA0A1VW108M J 1000 35V EL. AD C503 VCEA0A1CW477M J 470 16V EL. AC C505 VCFYFA1HA223J M 0.022 50V Mylar AA C506 VCKYPA1HF103Z J 0.01 50V Ceramic AA C507 VCEAGA1HW334T J 0.33 50V EL. AC C508 VCFYHA1HA104J J 0.1 50V Mylar AB C509 VCEACA1HC225J J 2.2 50V EL. AC C511 VCQYTA1HM103K J 0.01 50V Mylar AB C512 VCEA0A1VW107M J 100 35V EL. AC C514 VCQYTA1HM683J J 0.068 50V Mylar AB C516 VCFYSA1JB564J J 0.56 63V Mylar AE C517 VCFYHA1HA473J J 0.047 50V Mylar AB C518 VCQYTA1HM473J J 0.047 50V Mylar AA C519 VCEA0A1VW108M J 1000 35V EL. AD C520 VCEACA1HC225J J 2.2 50V EL. AC C530 VCEA0A1VW476M J 47 35V EL. AB C533 VCFYSA1JB473J J 0.047 63V Mylar AC C538 VCCSPA1HL101J J 100p 50V Ceramic AA C539 VCKYPA2HB102K J 1000p 500V Ceramic AA C605 VCKYPA1HB102K J 1000p 50V Ceramic AA C606 VCKYPA2HB561K J 560p 500V Ceramic AA C607 VCKYPA1HB472K J 4700p 50V Ceramic AA C608 RC-KZ0033CEZZ J 150p 2kV Ceramic AB

'åC609 VCFPPD3CA912H J 9100p 1600V M-Poly. AE 'åC610 VCFPPD3CA912H J 9100p 1600V M-Poly. AE

C615 VCKYPA2HB272K J 2700p 500V Ceramic AA C622 VCKYPA2HB102K J 1000p 500V Ceramic AA

å C624 VCEA0A2CW336M J 33 160V EL. AE å C652 VCEA0A1VW476M J 47 35V EL. AB

C677 RC-FZ0374CEZZ J 4.7 100V Mylar AF

RC-FZ0184CEZZ

'åC678 VCQPPC2GB393J J 0.039 400V M-Poly. AB

C680 VCFPPD2DB624J J 0.62 200V M-Poly. AF C681 VCQYTA1HM104J J 0.1 50V Mylar AA C682 VCKYPA2HB102K J 1000p 500V Ceramic AA C683 VCCSPA2HL560K J 56p 500V Ceramic AA

å C701 RC-FZ037SCEZZ M 0.22 275V Mylar AD

RC-FZ012SGEZZ

RC-FZ004SCEZZ

RC-FZ032CUMZZ

RC-FZ029SCEZZ

RC-FZ017SCEZZ C702 RC-KZ0029CEZZ J 0.01 500V Ceramic AC C703 RC-KZ0029CEZZ J 0.01 500V Ceramic AC

å C705 RC-EZ0720CEZZ J 680 200V EL. AN

å C706 RC-KZ0092GEZZ J 3300p AC250V Ceramic AC

RC-KZ0311CEZZ C707 VCFPPC3CA222H J 2200p 1600V M-Poly. AD C708 VCCSPA1HL471J J 470p 50V Ceramic AA C709 VCEA0A1VW107M J 100 35V EL. AC C710 VCQYTA1HM152J J 1500p 50V Mylar AA C712 VCKYPA2HB331K J 330p 500V Ceramic AA C717 VCKYPA2HB472K J 4700p 500V Ceramic AB C722 VCQYTA1HM104K J 0.1 50V Mylar AC

å C723 RC-EZ0724CEZZ J 100 160V EL. AG å C725 RC-EZ0810CEZZ M 330 160V EL. AG

C726 RC-KZ0338CEZZ J 560p 2kV Ceramic AD C727 RC-KZ0338CEZZ J 560p 2kV Ceramic AD C730 VCEA4A1VN108M J 1000 35V EL. AD C731 RC-EZ0385CEZZ J 1000 16V EL. AE C732 VCKYPA2HB102K J 1000p 500V Ceramic AA C741 VCKYPA2HB102K J 1000p 500V Ceramic AA C742 VCKYPA2HB102K J 1000p 500V Ceramic AA C751 VCKYPA1HF103Z J 0.01 50V Ceramic AA C753 VCEA0A1CW107M J 100 16V EL. AC C760 VCQYTA1HM393K J 0.039 50V Mylar AB C772 VCEA0A1EW477M J 470 25V EL. AD C773 VCCSPA1HL101J J 100p 50V Ceramic AA

RESISTORS

[M-Ox.··· Metal Oxide, M-Film··· Metal Film]

å R451 VRS-RG3AB103J J 10k 1W M-Ox. AB

R452 VRD-RM2HD823J J 82k 1/2W Carbon AA R453 VRD-RA2EE274J J 270k 1/4W Carbon AA R501 VRN-RL3LB2R2J M 2.2 3.0W M-Film. AB R502 VRD-RA2BE184J J 180k 1/8W Carbon AA R503 VRD-RA2BE124J J 120k 1/8W Carbon AA R504 VRD-RA2BE393J J 39k 1/8W Carbon AA R505 VRD-RA2BE153J J 15k 1/8W Carbon AA R506 VRD-RA2BE223J J 22k 1/8W Carbon AA R507 VRD-RA2BE101J J 100 1/8W Carbon AB R508 VRD-RA2BE101J J 100 1/8W Carbon AB R509 VRD-RA2BE181J J 180 1/8W Carbon AA R510 VRD-RA2BE332J J 3.3k 1/8W Carbon AA R511 VRD-RA2BE101J J 100 1/8W Carbon AB R512 VRD-RA2EE102J J 1.0k 1/4W Carbon AA R514 VRD-RA2BE103J J 10k 1/8W Carbon AA R515 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R516 VRD-RA2BE274J J 270k 1/8W Carbon AA R517 VRD-RA2BE823J J 82k 1/8W Carbon AA R520 VRD-RA2BE181J J 180 1/8W Carbon AA R521 VRD-RA2BE562J J 5.6k 1/8W Carbon AA R522 VRS-RG3AB102J M 1.0k 1W M-Ox. AA R523 VRD-RA2BE183J J 18k 1/8W Carbon AA R524 VRD-RM2HD152J J 1.5k 1/2W Carbon AA R525 VRD-RA2BE473J J 47k 1/8W Carbon AA R527 VRD-RA2BE103J J 10k 1/8W Carbon AA R529 VRD-RA2BE273G J 27k 1/8W Carbon AA R530 VRD-RA2BE683G J 68k 1/8W Carbon AA R531 VRD-RA2BE563J J 56k 1/8W Carbon AA R532 VRD-RA2BE824J J 820k 1/8W Carbon AA R533 VRD-RA2BE151J J 150 1/8W Carbon AA R534 VRD-RA2BE181J J 180 1/8W Carbon AA R535 VRN-RL3DB1R5J M 1.5 2W M-Film. AA R549 VRS-RG3DB391J M 390 2W M-Ox. AA R558 VRD-RA2BE104J J 100k 1/8W Carbon AA R605 VRD-RM2HD470J J 47 1/2W Carbon AA R606 VRD-RM2HD271J J 270 1/2W Carbon AA

å R607 VRS-KA3HG122J J 1.2k 5W M-Ox. AD

R608 VRS-RG3LB391J M 390 3.0W M-Ox. AB

å R609 VRS-RG3AB562J M 5.6k 1W M-Ox. AA

R610 VRD-RM2HD220J J 22 1/2W Carbon AA

å R611 VRW-KQ41C3R3K J 3.3 15W Cement AG å R621 VRN-RL3DB3R3J M 3.3 2W M-Film. AA å R622 VRN-RL2HCR68J M 0.68 1/2W M-Film. AA å R623 VRS-RG3AB150J M 15 1W M-Ox. AA å R624 VRS-RG3DB332J M 3.3k 2W M-Ox. AA

R625 VRD-RA2BE102J J 1.0k 1/8W Carbon AA

'åR651 VRN-RL2HC1R0J M 1.0 1/2W M-Film. AA

Page 49

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-C: DUNTK9834WEL2 (32N-S500)

POWER UNIT (Continued)

'åR652 VRD-RA2EE333J J 33k 1/4W Carbon AA 'åR653 VRD-RA2EE562J J 5.6k 1/4W Carbon AA 'åR654 VRD-RA2EE682J J 6.8k 1/4W Carbon AA

R681 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R682 VRD-RA2BE102J J 1.0k 1/8W Carbon AA R684 VRD-RA2BE472J J 4.7k 1/8W Carbon AA R685 VRD-RA2EE562J J 5.6k 1/4W Carbon AA R686 VRD-RA2EE222J J 2.2k 1/4W Carbon AA R687 VRD-RA2BE103J J 10k 1/8W Carbon AA

å R688 VRN-RL3DB3R3J M 3.3 2W M-Film. AA

R689 VRD-RA2EE104J J 100k 1/4W Carbon AA

å R690 VRS-RG3LB561J M 560 3.0W M-Ox. AB å R701 RR-HZ0048CEZZ J 3.9M 1/2W Carbon AB å R702 VRW-KQ4AC1R2K J 1.2 10W Cement AE å R703 VRS-RG3LB101J J 100 3.0W M-Ox. AC

R704 VRD-RM2HD154J J 150k 1/2W Carbon AA

å R705 VRN-RL3DBR22J J 0.22 2W M-Film. AA å R706 VRN-RL3DBR27J M 0.27 2W M-Film. AA

R707 VRS-RG2HC681J J 680 1/2W M-Ox. AA R708 VRS-RG3DB123J J 12k 2W M-Ox. AA R709 VRN-GA2EB1R0J J 1.0 1/4W M-Film. AA R710 VRD-RM2HD330J J 33 1/2W Carbon AA R711 VRD-RA2BE182J J 1.8k 1/8W Carbon AA R713 VRD-RA2EE152J J 1.5k 1/4W Carbon AA

å R715 VRS-RG3DB153J J 15k 2W M-Ox. AA å R723 VRN-RL3LBR56J M 0.56 3.0W M-Film. AB

R724 VRS-RG2HC332J J 3.3k 1/2W M-Ox. AA

å R725 VRS-RG3AB182J J 1.8k 1W M-Ox. AA

R734 VRD-RM2HD124J J 120k 1/2W Carbon AA

å R737 VRN-RL3DBR68J M 0.68 2W M-Film. AA

R751 VRD-RA2BE473J J 47k 1/8W Carbon AA

å R753 VRS-RG3AB391J M 390 1W M-Ox. AA

R760 VRD-RA2EE822J J 8.2k 1/4W Carbon AA

S502 QSW-B0015CEZZ J V-Center AC

MISCELLANEOUS PARTS

å RY701 RRLYJ0081CEZZ J Relay AL

å F701 QFS-B5023CEZZ J Fuse 5A AC125V AC

or RRLYJ0094CEZZ

FB501 RBLN-0037CEZZ J Ferrite Bead AB FB601 RBLN-0047CEZZ J Ferrite Bead AB FB671 RBLN-0047CEZZ J Ferrite Bead AB FB701 RBLN-0037CEZZ J Ferrite Bead AB FB702 RBLN-0036CEZZ J Ferrite Bead AB FB704 RBLN-0037CEZZ J Ferrite Bead AB FB706 RBLN-0037CEZZ J Ferrite Bead AB FH701 QFSHD1013CEZZ J Fuse Holder AC FH702 QFSHD1014CEZZ J Fuse Holder AC P501 QPLGN0961CEZZ J Plug 9-pin(C) AD P601 QPLGN0161FJZZ J Plug 6-pin(K) AE P602 QPLGN0861CEZZ J Plug 8-pin(D) AC P622 QPLGN0461CEZZ J Plug 4-pin(YBN) AB P651 QPLGN0361CEZZ J Plug 3-pin(TP651-3) AB P701 QPLGN0460CEZZ J Plug 4-pin(M) AC

QPLGN0404CEZZ P703 QPLGN0269GEZZ J Plug 2-pin(P) AB P705 QPLGN1061CEZZ J Plug 10-pin(H) AC P707 QPLGN0160CEZZ J Plug 1-pin(SG) AB RDA501

PRDAR0234PEFW R Heat Sink, for IC501 AH RDA601

PRDAR0150PEFW R Heat Sink, for Q602 AL RDA671

PRDAR1007MEFW J Heat Sink, for Q673 AH RDA701

PRDAR1006MEFW J Heat Sink, for IC701 AH

QCNW-0251MEZZ J Connecting Cord AC

LX-BZ3049GEFD J Screw AA

LX-HZ3007MEFD M Screw AA

SWITCH

PWB-C: DUNTK9834WEK8 (32N-X2000)

POWER UNIT

INTEGRATED CIRCUITS

å IC501 VHiTA8427K/-1 J TA8427K AL

IC502 VHiTA1241AN-1 J TA1241AN AM IC504 VHiUPC358C/-1 J UPC358C AD

å IC701 VHiSTRF66261E J STR-F6626 AX å IC702 RH-FX0034CEZZ J PC817 AE

or RH-FX0029CEZZ

å IC703 VHiSE125N//-1 M SE125N AG å IC750 VHiKA7809AP-1 M KIA7809AP AE

TRANSISTORS

Q501 VS2SC3198-Y-1 J 2SC3198(Y) AA Q601 VS2SC2482//-1 J 2SC2482 AD

å Q602 VS2SD2500//2E J 2SD2500 AT

Q672 VS2SA1266-Y-1 J 2SA1266(Y) AA Q673 VS2SD2045//-1 J 2SD2045 AL Q751 VS2SC3198-Y-1 J 2SC3198(Y) AA

DIODES

å D605 RH-DX0255CEZZ J Diode AC

D621 RH-EX0631GEZZ J Zener Diode, 9.1V AA

å D622 RH-DX0131CEZZ J Diode AC 'åD651 RH-DX0130CEZZ J Diode AE 'åD652 RH-EX0641GEZZ J Zener Diode, 12V AA 'åD653 VHD1SS119//-1 J Diode AB 'åD654 VHD1SS119//-1 J Diode AB

å D673 RH-DX0229CEZZ J Diode AF

D705 VHD1SS82///1A J Diode AC D706 RH-DX0130CEZZ J Diode AE D707 VHD1SS82///1A J Diode AC D708 RH-DX0130CEZZ J Diode AE

å D709 RH-DX0229CEZZ J Diode AF

D710 RH-EX0673GEZZ J Zener Diode, 30V AB

å D712 RH-DX0468CEZZ J Diode AE

å D713 RH-DX0477CEZZ J Diode AE

D715 RH-EX0610GEZZ J Zener Diode, 4.7V AA D716 VHD1SS119//-1 J Diode AB D723 RH-EX0650GEZZ J Zener Diode, 16V AB

å D725 RH-DX0420CEZZ J Diode AE

å D751 RH-DX0441CEZZ J Diode AC

å D752 RH-DX0441CEZZ J Diode AC

å D753 RH-DX0441CEZZ J Diode AC

å D754 RH-DX0441CEZZ J Diode AC

D755 VHD1SS119//-1 J Diode AB

å VA701 RH-VX0048CEZZ J Varistor AE

or RH-VX0035CEZZ

COILS AND PACKAGED CIRCUIT

å PR701 RMPTP0059CEZZ J Packaged Circuit AH

L501 VP-XF8R2K0000 J Peaking 8.2µH AB L671 RCiLZ1005CEZZ J Coil AH

or RCiLZ0868CEZZ

L672 RCiLZ1027CEZZ J Coil AK

or RCiLZ0789CEZZ

å L701 RCiLF0313CEZZ J Coil AH

or RCiLF0273CEZZ

Page 50

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-C: DUNTK9834WEK8 (32N-X2000)

POWER UNIT (Continued)

å L702 RCiLF0313CEZZ J Coil AH

RCiLF0273CEZZ L705 RCiLP0179CEZZ J Coil AD L729 RCiLP0179CEZZ J Coil AD L740 VP-XF101K0000 J Peaking 100µH AB

TRANSFORMERS

å T601 RTRNZ0057PEZZ R Transformer AK

'åT602 RTRNF0035MEZZ M H-Out AZ

å T701 RTRNP0547CEZZ J Power AK å T702 RTRNZ0021MEZZ M Transformer AM

CAPACITORS

[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]

C451 VCQYTA2AA104K J 0.1 100V Mylar AB C501 VCKYPA2HB102K J 1000p 500V Ceramic AA C502 VCEA0A1VW108M J 1000 35V EL. AD C503 VCEA0A1CW477M J 470 16V EL. AC C505 VCFYFA1HA223J M 0.022 50V Mylar AA C506 VCKYPA1HF103Z J 0.01 50V Ceramic AA C507 VCEAGA1HW334T J 0.33 50V EL. AC C508 VCFYHA1HA104J J 0.1 50V Mylar AB C509 VCEACA1HC225J J 2.2 50V EL. AC C511 VCQYTA1HM103K J 0.01 50V Mylar AB C512 VCEA0A1VW107M J 100 35V EL. AC C514 VCQYTA1HM683J J 0.068 50V Mylar AB C516 VCFYSA1JB564J J 0.56 63V Mylar AE C517 VCFYHA1HA473J J 0.047 50V Mylar AB C518 VCQYTA1HM473J J 0.047 50V Mylar AA C519 VCEA0A1VW108M J 1000 35V EL AD C520 VCEACA1HC225J J 2.2 50V EL. AC C530 VCEA0A1VW476M J 47 35V EL. AB C533 VCFYSA1JB473J J 0.047 63V Mylar AC C538 VCCSPA1HL101J J 100p 50V Ceramic AA C539 VCKYPA2HB102K J 1000p 500V Ceramic AA C605 VCKYPA1HB102K J 1000p 50V Ceramic AA C606 VCKYPA2HB561K J 560p 500V Ceramic AA C607 VCKYPA1HB472K J 4700p 50V Ceramic AA C608 RC-KZ0033CEZZ J 150p 2kV Ceramic AB

'åC609 VCFPPD3CA912H J 9100p 1600V M-Poly. AE 'åC610 VCFPPD3CA912H J 9100p 1600V M-Poly. AE

C615 VCKYPA2HB272K J 2700p 500V Ceramic AA C622 VCKYPA2HB102K J 1000p 500V Ceramic AA

å C624 VCEA0A2CW336M J 33 160V EL. AE å C652 VCEA0A1VW476M J 47 35V EL. AB

C677 RC-FZ0374CEZZ J 4.7 100V Mylar AF

RC-FZ0184CEZZ

'åC678 VCQPPC2GB473J J 0.047 400V M-Poly. AB

C680 VCFPPD2DB624J J 0.62 200V M-Poly. AF C681 VCQYTA1HM104J J 0.1 50V Mylar AA C682 VCKYPA2HB102K J 1000p 500V Ceramic AA C683 VCCSPA2HL560K J 56p 500V Ceramic AA

å C701 RC-FZ037SCEZZ M 0.22 275V Mylar AD

RC-FZ012SGEZZ

RC-FZ004SCEZZ

RC-FZ032CUMZZ

RC-FZ029SCEZZ

RC-FZ017SCEZZ C702 RC-KZ0029CEZZ J 0.01 500V Ceramic AC C703 RC-KZ0029CEZZ J 0.01 500V Ceramic AC

å C705 RC-EZ0720CEZZ J 680 200V EL. AN

å C706 RC-KZ0092GEZZ J 3300p AC250V Ceramic AC

å C723 RC-EZ0724CEZZ J 100 160V EL. AG å C725 RC-EZ0810CEZZ M 330 160V EL. AG

RESISTORS

[M-Ox.··· Metal Oxide, M-Film··· Metal Film]

å R451 VRS-RG3AB103J J 10k 1W M-Ox. AB

å R607 VRS-KA3HG122J J 1.2k 5W M-Ox. AD

R608 VRS-RG3LB391J M 390 3.0W M-Ox. AB

å R609 VRS-RG3AB562J M 5.6k 1W M-Ox. AA

R610 VRD-RM2HD220J J 22 1/2W Carbon AA

å R611 VRW-KQ41C3R3K J 3.3 15W Cement AG å R621 VRN-RL3LB1R2J M 1.2 3.0W M-Film. AB å R622 VRN-RL2HCR68J M 0.68 1/2W M-Film. AA å R623 VRS-RG3AB150J M 15 1W M-Ox. AA å R624 VRS-RG3DB332J M 3.3k 2W M-Ox. AA

R625 VRD-RA2BE102J J 1.0k 1/8W Carbon AA

'åR651 VRN-RL2HC1R0J M 1.0 1/2W M-Film. AA

Page 51

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PWB-C: DUNTK9834WEK8 (32N-X2000)

POWER UNIT (Continued)

'åR652 VRD-RA2EE333J J 33k 1/4W Carbon AA 'åR653 VRD-RA2EE562J J 5.6k 1/4W Carbon AA 'åR654 VRD-RA2EE682J J 6.8k 1/4W Carbon AA

å R688 VRN-RL3DB3R3J M 3.3 2W M-Film. AA

R689 VRD-RA2EE104J J 100k 1/4W Carbon AA

å R690 VRS-RG3LB561J M 560 3.0W M-Ox. AB å R701 RR-HZ0048CEZZ J 3.9M 1/2W Carbon AB å R702 VRW-KQ4AC1R2K J 1.2 10W Cement AE å R703 VRS-RG3LB101J J 100 3.0W M-Ox. AC

R704 VRD-RM2HD154J J 150k 1/2W Carbon AA

å R705 VRN-RL3DBR22J J 0.22 2W M-Film. AA å R706 VRN-RL3DBR27J M 0.27 2W M-Film. AA

å R715 VRS-RG3DB153J J 15k 2W M-Ox. AA å R723 VRN-RL3LBR56J M 0.56 3.0W M-Film. AB

R724 VRS-RG2HC332J J 3.3k 1/2W M-Ox. AA

å R725 VRS-RG3AB182J J 1.8k 1W M-Ox. AA

R734 VRD-RM2HD124J J 120k 1/2W Carbon AA

å R737 VRN-RL3DBR68J M 0.68 2W M-Film. AA

R751 VRD-RA2BE473J J 47k 1/8W Carbon AA

å R753 VRS-RG3AB391J M 390 1W M-Ox. AA

R760 VRD-RA2EE822J J 8.2k 1/4W Carbon AA

S502 QSW-B0015CEZZ J V-Center AC

MISCELLANEOUS PARTS

å RY701 RRLYJ0081CEZZ J Relay AL

å F701 QFS-B5023CEZZ J Fuse 5A AC125V AC

or RRLYJ0094CEZZ

FB501 RBLN-0037CEZZ J Ferrite Bead AB FB601 RBLN-0047CEZZ J Ferrite Bead AB FB671 RBLN-0047CEZZ J Ferrite Bead AB FB701 RBLN-0037CEZZ J Ferrite Bead AB FB702 RBLN-0036CEZZ J Ferrite Bead AB FB704 RBLN-0037CEZZ J Ferrite Bead AB FB706 RBLN-0037CEZZ J Ferrite Bead AB FH701 QFSHD1013CEZZ J Fuse Holder AC FH702 QFSHD1014CEZZ J Fuse Holder AC P501 QPLGN0961CEZZ J Plug 9-pin(C) AD P601 QPLGN0161FJZZ J Plug 6-pin(K) AE P602 QPLGN0861CEZZ J Plug 8-pin(D) AC P621 QPLGN0661CEZZ J Plug 6-pin(BBN) AD P651 QPLGN0361CEZZ J Plug 3-pin(TP651-3) AB P701 QPLGN0460CEZZ J Plug 4-pin(M) AC

QPLGN0404CEZZ P703 QPLGN0269GEZZ J Plug 2-pin(P) AB P705 QPLGN1061CEZZ J Plug 10-pin(H) AC P707 QPLGN0160CEZZ J Plug 1-pin(SG) AB

RDA501

PRDAR0234PEFW R Heat Sink, for IC501 AH RDA601

PRDAR0150PEFW R Heat Sink, for Q602 AL RDA671

PRDAR1007MEFW J Heat Sink, for Q673 AH RDA701

PRDAR1006MEFW J Heat Sink, for IC701 AH

QCNW-0251MEZZ J Connecting Cord AC

LX-BZ3049GEFD J Screw AA

LX-HZ3007MEFD M Screw AA

SWITCH

PWB-F: DUNTK9514WEK4

CONTROL UNIT

D4002 RH-PX0383CEZZ J LED Power AC D4003 RH-PX0383CEZZ J LED V-LIM AC

C4001 VCEA0A1HW475M J 4.7 50V EL. AB

R4001 VRD-RA2BE103J J 10k 1/8W Carbon AA R4003 VRD-RA2BE273J J 27k 1/8W Carbon AA R4004 VRD-RA2BE563J J 56k 1/8W Carbon AA R4005 VRD-RA2BE331J J 330 1/8W Carbon AA R4006 VRD-RA2BE563J J 56k 1/8W Carbon AA R4007 VRD-RA2BE123J J 12k 1/8W Carbon AA R4008 VRD-RA2BE750J J 75 1/8W Carbon AA R4009 VRD-RA2BE153J J 15k 1/8W Carbon AA R4010 VRD-RA2BE272J J 2.7k 1/8W Carbon AA

S4001 QSW-K0202PEZZ R Power AC S4002 QSW-K0202PEZZ R CH-Up AC S4003 QSW-K0202PEZZ R CH-Down AC S4004 QSW-K0202PEZZ R Vol-Up AC S4005 QSW-K0202PEZZ R Vol-Down AC

MISCELLANEOUS PARTS

J4001 QJAKE0179CEZZ J Jack Audio-IN 2(L)(MONO) AB J4002 QJAKE0180CEZZ J Jack Audio-IN 2(R) AE J4003 QJAKE0181CEZZ J Jack Video-IN 2 AC P4001 QPLGN0461CEZZ J Plug 4-pin(YR) AB P4002 QPLGN0561CEZZ J Plug 5-pin(KA) AB P4003 QPLGN0661CEZZ J Plug 6-pin(EJ) AD

RMC4001

RRMCU0230CEZZ J R/C Receiver AF or RRMCU0231CEZZ QCNW-0182MEZZ M Connecting Cord AF QCNW-0183MEZZ M Connecting Cord AC QCNW-0184MEZZ M Connecting Cord AR

DIODES

CAPACITOR

[EL.··· Electrolytic]

RESISTORS

SWITCHES

Page 52

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

MISCELLANEOUS PARTS

ACC701

QACCD3065CESA M AC Cord AN QCNW-0187MEZZ M Connecting Cord AD

QCNW-0190MEZZ M Connecting Cord AE QCNW-0191MEZZ M Connecting Cord AD QCNW-0192MEZZ M Connecting Cord AD QCNW-0193MEZZ M Connecting Cord AE QCNW-0195MEZZ M Connecting Cord AF QCNW-0243MEZZ M Connecting Cord QCNW-0250MEZZ M Connecting Cord AC QCNW-0253MEZZ M Connecting Cord AD QCNW-0254MEZZ M Connecting Cord AD

QCNW-0255MEZZ M Connecting Cord AC

SP1 VSP1206PB396E M Speaker(L) AN SP2 VSP1206PB396E M Speaker(R) AN

(32N-X2000)

(32N-S500)

(32N-X2000) (32N-X2000)

SUPPLIED ACCESSORIES

TGAN-1006MEZZ M Guarantee Card AA TiNS-7020MEZZ M Operation Manual AD

TiNS-6957MEZZ M Operation Manual AD RRMCG1494CESA M Infrared R/C Unit AU RRMCG1419CESA M Infrared R/C Unit AW

(32N-S500) (32N-X2000) (32N-S500) (32N-X2000)

PACKING PARTS

(NOT REPLACEMENT ITEM)

SPAKC0675MEZZ – Packing Case (32N-S500) — SPAKC0668MEZZ – Packing Case —

SPAKX0171MEZZ – Buffer Material — SSAKA0004MEZZ – Polyethylene Bag — SPAKP0030MEZZ – Polyethylene sheet —

(32N-X2000)

CABINET PARTS

1 CCABA1335MES0 M Front Cabinet Ass’y BM 1-1

Not Availlable

1-2 GCOVA1040MEKA M Cover for R/C AG 1-3 HBDGB1009MESA M Badge, “SHARP” AD 1-4 JBTN-1105MEKA M Button,

2 GCABB1139MEKA M Rear Cabinet BF

1 CCABA1330MES0 M Front Cabinet Ass’y BG 1-1

Not Availlable

1-2 GCOVA1040MEKA M Cover for R/C AG 1-3 HBDGB1009MESA M Badge, ”SHARP” AD 1-4 JBTN-1105MEKA M Button,

2 GCABB1139MEKA M Rear Cabinet BF

32N-S500

– Front Cabinet —

(Power,

Vol-up/down,CH-up/down)

32N-X2000

– Front Cabinet —

(Power,

Vol-up/down,CH-up/down)

CABINET PARTS LOCATION

1-4

1-3

1-1

1-2

1-4

Page 53

32N-S500

REAR

Use 2 tape fix the packing case.

★ Bar Code Label

★ Packing Case

MARK ★ : Not replacement items.

FRONT

★Buffer Material

★ Polyethylene Sheet

★ Polyethylene Bag

Operation Manual Infrared R/C unit Registration Card ★Batteries

32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

PACKING OF THE SET

Page 54

32N-S500 32N-X2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

TQ0910-S

Jun. 2000 Printed in Japan

MI. KG

SHARP CORPORATION AV Systems Group Quality & Reliability Control Center Yaita, Tochigi 329-2193, Japan
