Shark NV680UK Instruction manual

Model

NV680UK

™

Powered Lift-Away

™

ww w.sharkclean.eu

0800 862 0453

Contents

Thank you for purchasing the Shark®

Rotator™ Powered Lift-Away™. NV680UK

Getting to Know Your Shark® Rotator™ Powered Lift-Away™ Vacuum ................................................................................................3

Assembly .............................................................................................................................................................................................. 4

Upright Cleaning .................................................................................................................................................................................. 5

What Does the Brushroll Indicator Light Mean? ................................................................................................................................. 5

Above Floor Cleaning. .......................................................................................................................................................................... 6

Changing Floor Nozzles ........................................................................................................................................................................ 7

Powered Lift-Away™ Cleaning .............................................................................................................................................................8

Lift-Away™ Cleaning ............................................................................................................................................................................. 8

Maintenance ....................................................................................................................................................................................... 9

Empty the Dust Cup...........................................................................................................................................................................9

Clean the Filters ................................................................................................................................................................................ 9

Check for Blockages ........................................................................................................................................................................ 10

Trouble-Shooting Guide .....................................................................................................................................................................11

Warranty ............................................................................................................................................................................................14

TECHNICAL SPECIFICATIONS:

Voltage: 220-240V~, 50/60Hz Main Body Motor Watts: 850W Power Nozzle Watts: 80W

RECORD THIS INFORMATION:

Model Number: ��

Date of Purchase (Keep receipt):

��

RECOMMENDED FILTER CLEANING SCHEDULE:

See the MAINTENANCE section for filter cleaning instructions

Foam filter: XFF650 Every 3 months Felt Filter: XFF650 Every 3 months HEPA Filter: XHF650 Every 12 months

This appliance complies with the WEEE-Directive 2012/19/EU on the disposal of electrical and electronic equipment (WEEE).

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material sources. To return your used device, please use the return and collection systems or contact the retailer where this product was purchased. They can take this product for environmental safe recycling.

This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC and its revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions.

www.sharkclean.eu

READ ALL INSTRUCTIONS BEFORE USE

IMPORTANT SAFEGUARDS

When using an electrical appliance, basic safety precautions should always be observed, including the following:

WARNING

This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children shall not use or play with this appliance. Close supervision is necessary to keep appliance out of reach of children during use.

CAUTION

THE POWER NOZZLE, WAND, HOSE, AND HANDLE CONTAIN ELECTRICAL CONNECTIONS:

• These are not serviceable parts.

• Do not use to vacuum any liquids.

• Do not immerse in water when cleaning.

• Prior to use, inspect hose, handle/wand for damage. Discontinue using if damaged.

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY: 1 DO NOT use outdoors or on wet surfaces. 2 Unplug from electrical outlet when not in use and before cleaning or servicing. 3 Inspect power cord or plug for any damage before use. DO NOT use vacuum cleaner with a

damaged cord or plug.

4 DO NOT use if the appliance is not working, has been dropped, dropped into water,

damaged or left outdoors.

5 NO SERVICEABLE PARTS. Incorrect re-assembly or repair can cause a risk of electrical

shock or injury to persons when the appliance is used. Contact Customer Service.

6 The hose contains electrical wires. Do not use when damaged, cut or punctured. 7 DO NOT pull or carry vacuum cleaner by the cord or use the cord as a handle. 8 DO NOT unplug by pulling on cord; to unplug, grasp the plug, not the cord. 9 DO NOT handle plug or vacuum cleaner with wet hands. 10 DO NOT run the vacuum cleaner over the power cord, close a door on the cord or pull cord

around sharp corners.

11 The use of an extension cord is not recommended. 12 DO NOT leave vacuum cleaner unattended when plugged in. 13 Keep cord away from heated surfaces. 14 Turn off all controls before plugging or unplugging the vacuum cleaner. 15 Always turn off the vacuum cleaner before connecting or disconnecting power nozzle. 16 Store your vacuum cleaner with the power cord secured around the two cord holders.

17 Use only as described in this manual. 18 DO NOT put any objects into openings. DO NOT use with any opening blocked; keep free

of dust, lint, hair, and anything that may reduce air ﬂow.

19 Keep your work area well lit. 20 Keep the vacuum cleaner moving over the carpet surface at all times to avoid damaging

the carpet ﬁbers.

21 DO NOT place vacuum cleaner on unstable surfaces such as chairs or tables. 22 DO NOT use without dust cup and/or ﬁlters in place. 23 DO NOT step on, run over, or bend hose. The hose is powered by electrical wires that may

be damaged as a result.

HOSE ATTACHMENTS

24 DO NOT use if air ﬂow is restricted; if the air paths, the hose, or the accessories become blocked,

turn the vacuum cleaner off. Remove all obstructions before you turn on the unit again.

25 Keep the end of the hose and accessory openings away from face and body. 26 Keep cleaning tools and hose suction openings away from hair, face, ﬁngers, uncovered

feet, or loose clothing.

27 Only use manufacturer’s recommended attachments.

DUST CUP/FILTERS/ACCESSORIES

Before turning on the vacuum:

28 Make sure that all ﬁlters are thoroughly dry after routine cleaning. 29 Make sure that dust cup and all ﬁlters are in place after routine maintenance. 30 Make sure accessories are free of blockages. 31 Use only manufacturer’s recommended accessories and replacement parts.

32 DO NOT pick up large-sized objects. 33 DO NOT pick up hard or sharp objects such as glass, nails, screws or coins that could

damage the vacuum cleaner.

34 DO NOT use to pick up drywall dust. 35 DO NOT pick up smoking or burning objects such as hot coals, cigarette butts, ﬁreplace

ash or matches.

36 DO NOT pick up ﬂammable or combustible materials such as lighter ﬂuid, gasoline, or

kerosene or use vacuum in areas where they may be present.

37 DO NOT pick up toxic solutions such as chlorine bleach, ammonia, or drain cleaner. 38 DO NOT use in an enclosed space where vapors are present from paint, paint thinner,

moth-prooﬁng substances, ﬂammable dust or other explosive or toxic materials.

39 DO NOT vacuum up any liquids. 40 DO NOT immerse vacuum cleaner in water or other liquids. 41 DO NOT use outdoors or on wet surfaces; use only on dry surfaces. 42 Use extra care when cleaning on stairs. 43 Remove brushroll from unit before rinsing.

GENERAL USE

GENERAL CLEANING

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

0800 862 0453

Wand Release

ETTING TO KNOW YOUR SHARK ROTATOR® POWERED LIFT-AWAY™ SPEED

Articulated Upholstery Tool

312FV680

Two cleaning tools in one. The stiff bristle brush gets stuck-on debris off a multitude of surfaces. Remove the bristles to reveal an upholstery tool for removing stubborn pet hair from upholstery and more.

MAIN UNIT 1 Surface Selector 2 Suction Control 3 Hose 4 Hose Clip 5 Upper Cord Hook 6 Power Switch

2-in-1 Crevice Tool

189FLI680

Two cleaning tools in one. The crevice tool gives you extended cleaning reach for small spaces, while the dusting brush cleans a multitude of surfaces.

Dust-Away™ Hard Floor

Attachment & Microﬁber Pad

XGNWL580EU

Durable enough for big crumbs and debris, but gentle enough for the most delicate dusting on hard wood and tile ﬂoors.

7 Wand Release 8 Lift-Away Pod 9 Lower Cord Hook 10 Motorised Floor Nozzle 11 Headlights 12 Brushroll Indicator Light

www.sharkclean.eu

ASSEMBLY

STEP 1 STEP 2 STEP 3 STEP 4 STEP 5

SLIDE

CLICK

1 Place the selected ﬂoor nozzle on the ﬂoor and insert

the wand.

2 Insert the handle into the wand.

3 Slide the pod onto the wand.

4 Slide the hose clip into the notch at the back of the

wand.

0800 862 0453

5 Insert the 2-in-1 Crevice Tool and Articulated

Upholstery Tool into the accessory posts as shown.

TIP: For quick cord access, rotate upper hook down and

remove cord. Rotate back for cord storage.
