Cordless Detect Pro™
Vacuum
IW1600ANZ Series
IW3600ANZ Series
OWNER’S GUIDE
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
WARNING
When using an electrical appliance, to reduce the risk of fire, electric shock, injury, or
property damage, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
THIS VACUUM:
1. This vacuum consists of a dock, motorised
nozzle, wand, and handheld vacuum. These
components contain electrical connections,
electrical wiring, and moving parts that
potentially present risk to the user. The floor
nozzle, wand, and handheld vacuum contain
electrical connections.
2. Before each use, carefully inspect all parts
for any damage. If a part is damaged,
discontinue use.
3. Use only identical replacement parts.
4. This vacuum contains no serviceable parts.
5. Use only as described in this manual.
DO NOT use the vacuum for any purpose
other than those described in this manual.
6. With the exception of the filters and dust
cup, DO NOT expose any parts of the
vacuum to water or other liquids.
7. Keep the appliance and its cord out of reach
of children. DO NOT allow the appliance to
be used by children.
DO NOT allow to be used as a toy.
Close supervision is necessary when
used near children.
GENERAL USE
8. This appliance can be used by persons
with reduced physical, sensory, or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Cleaning and user
maintenance shall not be made by children.
9. Always turn o the vacuum before
connecting or disconnecting any current
dock, carrying hoses, motorised nozzles,
chargers, batteries, or other electrical or
mechanical parts.
10. DO NOT handle plug or vacuum with
wet hands.
11. DO NOT use without dust cup, HEPA and
Pre-motor filter, and soft roller in place.
12. Only use Shark® branded filters and
accessories. Failure to do so will void
the warranty.
13. DO NOT put any objects into nozzle or
accessory openings. DO NOT use with any
opening blocked; keep free of dust, lint, hair,
and anything that may reduce airflow.
14. DO NOT use if dock, nozzle or accessory
airflow is restricted. If the air paths or
the motorised floor nozzle become
blocked, turn the vacuum o. Remove
all obstructions before you turn on the
unit again.
15. Keep nozzle and all vacuum openings away
from hair, face, fingers, uncovered feet, or
loose clothing.
16. DO NOT use if vacuum is not working as it
should, or has been dropped, damaged, left
outdoors, or dropped into water.
17. Use extra care when cleaning on stairs.
18. DO NOT leave the vacuum unattended
while powered on.
19. When powered on, keep the vacuum
moving over the carpet surface at
all times to avoid damaging the
carpet fibers.
20. DO NOT place vacuum on unstable
surfaces such as chairs or tables.
21. DO NOT use to pick up:
a) Liquids
b) Large objects
c) Hard or sharp objects (glass, nails,
screws, or coins)
d) Large quantities of dust (including
drywall, fireplace ash, or embers).
DO NOT use as an attachment to power
tools for dust collection.
e) Smoking or burning objects (hot coals,
cigarette butts, or matches)
f) Flammable or combustible materials
(lighter fluid, gasoline, or kerosene)
g) Toxic materials (chlorine bleach,
ammonia, or drain cleaner)
22. DO NOT use in the following areas:
a) Poorly lit areas
b) Wet or damp surfaces
c) Outdoor areas
d) Spaces that are enclosed and may
contain explosive or toxic fumes or
vapours (lighter fluid, gasoline, kerosene,
paint, paint thinners, mothproofing
substances, or flammable dust)
23. Turn o the vacuum before plugging in or
unplugging the charger.
24. Turn o the vacuum before any adjustment,
cleaning, maintenance, or troubleshooting.
25. During cleaning or routine maintenance,
DO NOT cut anything other than hair, fibers,
or string wrapped around the brushrolls.
26. Allow all filters to air-dry completely before
replacing in the vacuum to prevent liquid
from being drawn into electric parts.
27. DO NOT modify or attempt to repair the
vacuum or the battery yourself, except as
indicated in this manual. DO NOT use the
battery or vacuum if it has been modified or
damaged. Damaged or modified batteries
may exhibit unpredictable behavior
resulting in fire, explosion, or risk of injury.
28. Always turn o this appliance before
connecting or disconnecting motorised
nozzle or hand tool.
BAT TERY PAC K
29. The battery is the power source for the
vacuum. Carefully read and follow all
charging instructions.
30. To prevent unintentional starting, ensure the
vacuum is powered o before picking
up or carrying the vacuum. DO NOT carry the
appliance with your finger on the power switch.
31. Keep the battery away from all metal
objects such as paper clips, coins, keys,
nails, or screws. Shorting the battery
terminals increases the risk of fire or burns
32. Under abusive conditions, liquid may be
ejected from the battery. Avoid contact
with this liquid, as it may cause irritation or
burns. If contact occurs, flush with water. If
liquid contacts eyes, seek medical help.
33. Battery should not be stored at
temperatures below 3°C (37.4°F)
or above 104°F (40°C) to maintain
long-term battery life.
34. DO NOT charge battery at temperatures
below 5°C (40°F) or above 104°C (104°F).
Charging improperly or at temperatures
outside of the specified range may damage
the battery and increase the risk of fire.
35. Store the appliance indoors. DO NOT use or
store it below 3°C (37.4°F). Ensure the appliance
is at room temperature before operating.
36. DO NOT expose the battery to fire or
temperatures above 265°F (130°C) as it may
cause explosion.
37. Use appliances only with specifically designated
battery packs. Use of any other battery packs
may create a risk of injury and fire.
38. Disconnect the battery pack from the
appliance before making any adjustments,
changing accessories, or storing appliance.
Such preventive safety measures reduce the
risk of starting the appliance accidentally.
39. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agentor similarly qualified persons in order to
avoid a hazard. b. During charging, the battery
must be placed in a well-ventilated area.
SAVE THESE INSTRUCTIONS
40. For IW3600ANZ Series use only the
charging dock XDCKIW3500LEU. For
IW1600ANZ Series use only battery charger
YLS0251A-A2600800 For IW3600ANZ
use only battery pack XBTR625KSLEU.
For IW1600ANZ use only battery pack
XBTR625KDCEU.
41. If the charging cord plug does not fit
fully into the outlet, reverse the plug. If
it still does not fit, contact a qualified
electrician. DO NOT force into outlet or
try to modify to fit.
42. To reduce the risk of shock and unintended
operation, turn o power and remove the
Li-Ion battery before servicing.
43. Unplug the power cord from outlet when
not in use and before servicing.
44. Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
45. Turn o all controls before unplugging.
46. Do not pull or carry by cord, use cord as a
handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run
appliance over cord. Keep cord away from
heated surfaces.
47. The product ’s power supply cord should be
directly plugged into an electrical outlet.
Extension cord should not be used.
48. The length of the power supply cord
provided on the product is 1.2m .
ODOUR NEUTRALISER TECHNOLOGY
CARTRIDGE (IW3600ANZ Series)
48. Observe the following when interacting with
the odour neutralising cartridge:
a) DO NOT attempt to disassemble odour
neutraliser cartridge.
b) Avoid direct contact with the fragrance
puk in the cartridge.
c) DO NOT directly inhale from the odour
neutralising cartridge.
d) Keep away from children and pets.
e) Keep away from heat, sparks, and open
flame.
f) DO NOT place in direct sunlight.
FRAGRANCE PUK FIRST AID
a) Avoid contact with fabrics and finished
surfaces.
b) Eye contact: Remove contact lenses if
present. Rinse continuously with water
for several minutes.
c) Skin contact: Wash hands thoroughly
after handling. If irritation or rash
develops, seek medical advice/attention.
d) Inhalation: Move person to fresh air if
they are experiencing any
respiratory symptoms. If symptoms
persist, seek medical advice/attention.
e) Ingestion: DO NOT induce vomiting.
Seek medical advice/attention.
sharkclean.co.nz sharkclean.com.au
AUTO-EMPTY ASSEMBLY (IW3600ANZ) NON-AUTO-EMPTY ASSEMBLY (IW1600ANZ)
1. Slide the Wand onto the neck of the Floor
Nozzle until it clicks into place.
2. Align the Hand Vacuum nozzle opening
with the top of the wand and slide it on
until it clicks into place.
3. Make sure the Dock is facing upright. Slide
the Charging Post into the slot on front of
dock until it clicks.
Handheld
Vacuum
2.
(Click)
4. Place the dock on the floor near a wall
outlet. Connect the Power Cord to the port
on the back of the charging post, then plug
into the outlet.
5. Store the crevice tool accessory on the
mount on the dock.
6. Refer to Odour Installation and
Replacement instructions.
For proper operation, ensure all components
are completely connected and clicked
into place.
3.
Assembled
Dock
6.
Odour
Installation
4. Power Cord
1. Slide the Wand onto the neck of the Floor
Nozzle until it clicks into place.
2. Align the Hand Vacuum nozzle opening
with the top of the wand and slide it on
until it clicks into place.
Handheld
Vacuum
2.
(Click)
For proper operation, ensure all components
are completely connected and clicked
into place.
1.
(Click)
Floor Nozzle Floor Nozzle
NOTE: Once the charging post is installed, it can’t be removed.
5.
Accessory
Storage
1.
(Click)
sharkclean.co.nz sharkclean.com.au
ODOUR NEUTRALISER TECHNOLOGY
ODOUR NEUTRALISER TECHNOLOGY
ADJUSTING THE ODOUR INTENSITY
ODOUR DIAL
Flip up the handle and rotate the Odour
Neutraliser Technology Dial to adjust fragrance
puk intensity or to remove cartridge.
Insertion/Removal: Rotate the Odour Neutraliser Technology Dial to align the teal
arrows. Remove the dial to access the fragrance puk for removal or replacement.
Low: Rotate the Odour Neutraliser Technology Dial toward the Low position to minimise
the intensity to the lowest level when the vacuum is in use.
High: Rotate the Odour Neutralisier Technology Dial toward the High position for the highest
level of intensity when the vacuum is in use. This position is the recommended
setting for optimal performance.
ODOUR NEUTRALISER TECHNOLOGY TIPS
Odour Neutraliser Technology Dial Must be Installed for Vacuum to Function Properly
• Remove the Fragrance Puk from dial if you don’t want the benefits of the Odour Neutraliser
Technology.
ODOUR NEUTRALISER TECHNOLOGY FRAGRANCE PUK REPLACEMENT
1. REMOVE ODOUR
NEUTRALISER TECHNOLOGY
DIAL FROM FLOORHEAD
Flip up the handle and rotate the Odour
Neutraliser Technology Dial clockwise until
the two teal arrows are aligned. Pull the
handle to remove the Odour Neutraliser
Technology Dial from the floorhead.
3.REMOVE NEW FRAGRANCE
PUK FROM PACKAGIN G
Remove the new fragrance puk fromthe can.
To maintain the life of the fragrance puk, keep
it in the can until you are ready to install it.
Rotate the fragrance puk anticlockwise in the
Odour Neutraliser Technology Dial housing
and pull out the fragrance puk to remove it.
Align the yellow arrow on the side of the
fragrance puk with the yellow arrow on the
side of the Odour Neutraliser Technology Dial
cover, then insert the fragrance puk into the
dial. Rotate clockwise to lock it in place.
2. REMOVE OLD
FRAGRANCE PUK
TURN UNTIL
CLICK TO LOCK
4. REPLACE CARTRIDGE
WITH FRAGRANCE PUK
Maintenance Required
• Clean all filters as recommended under Cleaning Filters.
• Empty the dust cup before storing your vacuum.
• Replace the fragrance puk as recommended under Odour Neutraliser Technology fragrance
puk replacement.
• Visit sharkclean.com.au sharkclean.co.nz to learn more and purchase replacements.
• If wet pet messes are cleaned up, thoroughly clean the vacuum.
Fragrance Strength Over Time
• The intensity of the Odour Neutraliser Technology fragrance puk may diminish over time.
It may also have no noticeable fragrance at all. This is natural and does not indicate the
technology isn’t working. Follow replacement instructions to ensure continued performance.
NOTES: • T he odou r dial ne eds to be install ed for the vacuum to f unction prop erly, with or without the odou r cartridge.
• Odour Neutraliser technology eectively deodourizes while interacting with odours from inanimate sources.
5. INSTALL DIAL IN THE
AUTO-EMPTY DOCK
Align the teal arrow on the dial cover with the
arrow on the auto-empty dock, then reinsert
the dial into the auto-empty dock. Rotate the
dial counterclockwise until it clicks into an
intensity setting to engage. Rotate further to
change the intensity setting.
6. USED FRAGRANCE PUK
DISPOSAL
Dispose of old fragrance puk into the bin.
Please do not throw the Odour Neutraliser
Technology Dial into the bin.
NOTE: Fr agran ce Puks should be replac ed every
6 months for optim al Odour Neutraliser techno logy
performance.
sharkclean.co.nz sharkclean.com.au
LI -ION BAT TERY
CHARGING
Prior to first use, charge the battery completely. A full charge takes approximately 5 hours.
RUNTIMES PER FULLY CHARGED BATTERY
With a full charge, the unit will have up to a 60-minute runtime.
LED BATTERY POWER AND CHARGING INDICATORS
Charging
LED on the battery pack will pulse yellow when reaching 0-75% charge.
LED on the battery pack will pulse green from 75% - 100% charge.
White LED the battery pack is fully charged.
NOTE: Full charge takes approximately 5 hours.
Additional Notes
1. LEDs turn o once the battery is fully charged.
2. Unit will not power on when charger is connected.
In Use
CHARGING WHILE IN STORAGE MODE
CONTACTS
UPRIGHT DOCK CHARGING IW3600ANZ SERIES
Charge the unit by placing it on the dock. Make
sure the contacts on the wand are aligned
with the contacts on the charging post.
When charging is complete and you need
to use the unit again, lift it o the dock.
HAND VACUUM RELEASE BUTTONS
To detach the hand vacuum from the wand,
press the front latch release button on the
hand vac where it meets the wand, then lift
o the hand vacuum. To reattach the hand
vacuum to the wand, align the hand vacuum
opening over the top of the wand and slide it
on until it clicks into place.
Full Mid Low Nearly No
Charge Charge Charge Empty Charge
RECYCLING THE LI-ION BATTERY
When the Shark® Li-ion battery needs to be replaced, dispose of it or recycle it in accordance
with local ordinances or regulations. In some areas, it is illegal to place spent lithium-ion
batteries in the rubbish or municipal solid waste stream. Return spent batteries to an authorised
recycling center or to the retailer for recycling. Contact your local recycling center for
information on where to drop o the spentbattery.
NOTE: The Shark battery, like all lithium-ion batteries, will naturally decrease in capacity over time from the 100% capacity of
a new battery.
OUT OF THE VACUUM IW1600ANZ SERIESIN HANDHELD VACUUM IW600ANZ SERIES
To charge the battery inside the handheld
vacuum, insert the charger into the port below
the handle on the handheld vacuum, then plug
the charger into an electrical outlet.
Press and hold the Battery Release Button,
then pull out the battery. Plug the charger
into the charging port on the battery. To
reinstall the battery, insert it into the slot in
the back of the handheld vacuum.
NOTE: Whe n the unit is docked properly, the charging lights on th e battery will bl ink, indicating that chargin g has begun.
NOTE: The m ain unit comes with a parti al charge. For maximum r untime, charg e fully b efore fir st use (approximately 5
hours). Leaving the u nit plugged in will not damage battery life.
sharkclean.co.nz sharkclean.com.au
BATTERY REMOVAL
USING YOUR VACUUM
REMOVING THE BATTERY
BATTERY
To remove the battery from the hand vacuum,
press the release tab on the battery cap and
slide out the battery. To reinstall, slide the
battery into the compartment in the handle
until it clicks into place.
STORAGE ON THE GO
CONTROLS AND CLEANING MODES
POWER
Press the
turn on power. To turn o power, press
the button again. To toggle between ECO,
AUTO, and BOOST modes, press the mode
selection button.
button on the UI Screen to
UPRIGHT
When upright, the nozzle will lock to allow
for free standing storage when the hand vac
is detached. Place your foot on the nozzle to
disengage the lock to begin floor cleaning.
For quick and easy short-term storage, attach the hand vacuum to the wand by placing it
onto the pre-assembled wand storage clip.
CLEAN INDICATOR EDGE INDICATOR
When the LED Indicator light is blue, this
means no heavy debris is detected and suction
power is normal. When the vacuum senses
heavy debris, the light will turn red, and
suction will increase for more cleaning power.
When the indicator light turns amber, debrisis
being removed—continue cleaning until the
indicator turns blue again.
When an edge is detected, the headlights
will illuminate on one side where the edge
is detected, to focus on targeted debris.
sharkclean.co.nz sharkclean.com.au
USING YOUR VACUUM
USING THE AUTO-EMPTY DOCK (IW3600ANZ SERIES)
Place the vacuum on the dock in a downward
motion. Once properly attached, the
auto evacuation process will begin. The
evacuation cycle will last for 15 seconds.
USING THE AUTO-EMPTY DOCK
Once evacuation is complete, the vacuum
will continue charging until it is removed
from the dock.
USING THE FLEX WAND
Press the unlock latch on the back of the
wand, then adjust the angle.
ABOVE-FLOOR CLEANING
QUIET MODE BUTTON LOCATION DUST BIN FULL INDICATOR
Press the button on the top of the dock that
shows an image of a moon. This will initiate
Quiet Mode. When the dock is in Quiet Mode,
you can dock the vacuum without auto
The Dust Bin Full indicator will illuminate
when the dust bin is full of debris and needs
to be emptied. To reset the indicator, remove
the dust bin and empty it.
evacuation occurring.
Note: do not remove the vacuum while the evacuation cycle is taking place.
ABOVE-FLOOR WITH HAND VACUUM
Detach the hand vacuum to clean abovefloor areas. Press the front latch release
button on the hand vac where it meets the
wand, then lift o the hand vacuum. To
attach an accessory to the hand vacuum,
slide it into the opening in the nozzle. To
remove, press the front latch release button
To detach the floor nozzle from the wand,
step on the nozzle while pressing the
nozzle release button at the bottom of
the wand. Lift the wand to remove it. To
reattach the wand, align it over the neck
of the floor nozzle, then slide it on until it
clicks into place.
on the hand vac where it meets the wand,
and slide out the accessory.
NOTE: All accessories are compatible with both the wand and the hand vacuum.
ABOVE-FLOOR WITH WAND
sharkclean.co.nz sharkclean.com.au
MAINTAINING YOUR VACUUM
MAINTAINING YOUR VACUUM
EMPTYING THE DOCK DUST BIN (FOR IW3600ANZ SERIES)
The dock dust bin holds up to 30 days’ worth
of dust and debris. Empty the dock dust bin
when the dust bin full indicator light comes on.
To remove the bin, lift it out by the handle.
EMPTYING THE HANDHELD VACUUM DUST CUP
To empty the bin, hold it over the trash and
press the release button on the side. The
bottom will open to release the debris.
CLEANING THE DUST CUP AND FILTER
With the dust cup open and the power o,
press both release buttons and slide the
dust cup out of the hand vac.
Press the tabs on both sides of the filter housing
and pull the filter out of the housing. To clean
the filter, rinse it with water only and allow it to
air-dry for at least 24 hours before reinstalling.
To reinstall the filter, slide it back into the
housing, then slide the housing back into place.
To deep-clean the dust cup, slide the release
button until the lid opens completely. Wipe
away any dust and debris with a dry cloth,
then rinse it out with water. Use a damp cloth
to remove any remaining debris. Allow the
dust cup to air-dry completely for at least
24 hours before reinstalling it.
To empty the handheld vacuum (IW3600ANZ
Series) dust cup, turn o the power and hold
the hand vac over the trash. Press the release
button and the dust cup lid will drop open,
releasing debris.
To empty the handheld vacuum (IW1600ANZ
Series) dust cup, turn o the power and hold
the hand vac over the trash. Press the release
button and the dust cup lid will drop open,
releasing debris.
REMOVING THE HAND VAC HEPA FILTER
1. To access the HEPA filter, rotate the filter
cover on the the handheld vacuum to the
unlocked position.
2. Pull o the filter cover and lift out the
HE PA filter.
3. Reinsert the filter, then replace the cover
and rotate it back to the locked position.
Regularly rinse and replace the filters to
maintain your vacuum’s
clean filters, rinse them with water only. Allow
all filters to air-dry completely for up to 48
HEPA
Filter
hours before reinstalling to prevent liquid
from being drawn into electricparts.
Clean the pre-motor and post-motor filters
as least once a month. Tap o loose dirt
between washes when needed. More frequent
cleaning may sometimes be necessary with
heavy use.
IM POR TAN T: DO NOT use soap when cle aning the filter s. Use water only. Th e vacuum will not have suctio n if the pos t-motor fil ter is not
insta lled. E nsure th at all filte rs are in stalled before using.
suction power.
sharkclean.co.nz sharkclean.com.au
To
MAINTAINING YOUR VACUUM
MAINTAINING YOUR VACUUM
CLEANING THE AUTO-EMPTY DOCK FILTER (IW3600ANZ SERIES)
To access the filter in the dock, remove the Filter
Door. Press the button at the bottom of the door,
then tilt the door and lift it o. Remove the filter
from the dock. After the filter has been rinsed
and dried, reinstall it by reinserting it into the
dock and replacing the filter door.
For best result s, clea n your Auto -Empty filters at leas t once a mo nth and re place th e filters regularly. To clean filters, rinse with cold water
ONLY to prevent d amage from cleaning chemic als. Allow all filters to air-dry for at least 24 hours before rein stalling them to prevent
liquid from being drawn i nto elec trical parts. Main taining your Ex haust Foam Filte r will ensure succ essfu l Auto-Empty eva cuatio n.
To access the the Auto-Empty Exhaust Foam
Filter, remove the dust bin. Before removing
the Exhaust Foam Filter, vacuum o any fine
debris from the surface. Lift the Exhaust
Foam Filter out of the dock, then rinse it with
water only (do not use soap). Allow the filter
to air-dry completely before reinstalling it.
NOZZLE MAINTENANCE
CLEANING THE SENSORS
Dust cup
Battery
DIRTDETECT SENSORS
Fig. 1
Air path
Make sure to clean the Detect sensors
regularly, as hair and other debris may build
up and obstruct them. If the sensors are
partially obstructed, Auto mode will not
function as expected.
To clean the sensors :
1. Turn o power and remove the floor nozzle.
2. Locate the DirtDetect Sensor in the nozzle
of the hand vac (Fig. 1), the LightDetect
Sensor on the top of the nozzle (Fig. 2),
and the EdgeDetect sensor on the side of
the nozzle (Fig. 3).
3. Gently wipe the sensors with a microfibre
cloth and remove all hair and debris.
4. Reattach the floor nozzle to the rest of the
unit and turn on power. Verify that the unit
is functioning normally.
Fig. 3Fig. 2
POWERFIN FLOOR NOZZLE
1. Turn o the vacuum.
2. Press the nozzle release button to detach
the nozzle from the wand.
3. Press the brushroll release button and
slide the brushroll out of the nozzle.
4. Clear any blockages and remove any
debris from the brushroll and floor nozzle.
5. Tap o loose debris and wipe the brushroll
clean with a dry towel. Hand wash the
brushroll if needed, using only water,
and then let it air dry completely for at
least 24 hours.
6. When the brushroll is dry, reinstall it into
the nozzle by inserting it into the nozzle
until it clicks.
CLEANING THE LIGHTDETECT SESNOR
CLEANING THE EDGEDETECT SENSOR
sharkclean.co.nz sharkclean.com.au
MAINTAINING YOUR VACUUM
MAINTAINING YOUR VACUUM
CHECKING FOR BLOCKAGES IN THE VACUUM
If you run over a hard or sharp object or notice a noise change while vacuuming, check for
blockages or objects caught in the brushroll.
Checking for B lockages in the
Hand Vacuum:
1. Turn o the vacuum.
2. Remove the hand vacuum from the
wand.
3. Check all intake openings to the
dust cup and remove any debris
or blockages.
Checking for Blockages in
the Wand:
1. Turn o the vacuum.
2. Detach the hand vacuum and
floor nozzle from the wand.
3. Check both ends of the wand for
blockages and debris.
4. Clear away any debris or
blockages.
CHECKING FOR BLOCKAGES IN THE AUTO-EMPTY
DOCK (IW3611ANZ)
Checking for Blockages
in the Charging Post:
1. Unplug the dock.
2. Remove the vacuum from the
dock.
3. Press the latch on the back of
the charging post and lift the
post away from the dock.
4. Check the end of the charging
post and top of the dock
for any debris or blockages.
Checking for Blockages in the Dock:
1. Unplug the dock.
2. Remove the vacuum from the
dock.
3. Remove the dust bin from the
dock.
4. Check the exit for any debris
or blockages.
Checking for B lockages in the
Floor Nozzle:
1. Turn o the vacuum.
2. Detach the wand from the floor
nozzle.
3. Press the brushroll release
button and slide the brushroll
out of the nozzle.
4. Clear any blockages and release
any debris from the brushroll
and floor nozzle.
5. Slide the brushroll back into the
nozzle, ensuring everything is
lined up and in place.
TROUBLESHOOTING
WARNING: To reduce the risk of shock and unintended operation, turn o
power and remove the battery before servicing.
Vacuum is not picking up debris . No suction or light suction. Third indicator light on hand vacuum is
solid yellow.
(Refer to Checking for B lockages section for more information.)
1. Dust cup may be full; empty dust cup.
2. Check floor nozzle for blockages; clear blockages if required.
3. Remove any string, carpet fibers, or hair that may be wrapped around the brushroll.
4. Check connection between hand vacuum and wand for blockages; clear blockages if required.
5. Check filters to see if they need cleaning. Follow instructions for rinsing and completely air-drying
the filters before reinstalling them.
Vacuum lifts area rugs.
1. Make sure you are not engaging Boost mode. Take care when vacuuming area rugs or rugs with
delicately sewn edges.
2. Turn o the unit to disengage from the carpet, then restar t.
The brushroll in the floor nozzle doesn’t spin.
1. Immediately turn o the vacuum. Remove any blockages before turning the vacuum back on. Make sure
the hand vacuum is tilted back far enough for the brushroll to engage while in use.
2. If the floor nozzle has headlights and they are not illuminated, there is a connection issue between the
hand vacuum, wand, and nozzle. Try detaching the parts, then reconnecting them.
Vacuum turns o on its own.
There are several possible reasons for the vacuum turning o on its own, including blockages, battery
issues, and overheating. If vacuum turns o on its own, perform the following steps:
1. Turn on the vacuum and check the battery indicator lights on the hand vacuum. If recharging is needed,
make sure vacuum power is o placing it on the charging dock .
2. Empty dust cup and clean filters (See the Cleaning the Dust Cup and Filter section).
3. Check wand, accessories, and inlet openings and remove any blockages.
4. Allow unit and battery to cool for at least 45 minutes, until they return to room temperature.
5. Press the On/O switch to restart the vacuum.
Battery Indicator Lights on hand vacuum are flashing.
• Nozzle Ring Light flashes red (Fig. A): Nozzle clog.
(See the Maintaining Your Vacuum section.)
Contact Customer Service at
AU 02 8801 7666 | NZ 0800 112 660
AU sharkclean.com.au | NZ sharkclean.co.nz
if you experience any of the indications listed below:
• ECO and BOOST LEDs are flashing (Fig. B):
Overcurrent or short.
• All LEDs except ECO are flashing (Fig. C):
Motor is overheating.
• All LEDs except ECO and AUTO are flashing
(Fig. D): Overspeed.
• All LEDs except BOOST and AUTO are flashing
(Fig. E): Communication .
• AUTO and BOOST LEDs are flashing (Fig. F): There
may be an electrical problem with the nozzle.
• AUTO and UI RING are flashing (Fig. G): Debris
Detect Error. Wipe debris detect sensor.
• HEADLIGHTS and AUTO LEDs are flashing (Fig. H):
Edge Detect Error.
NOTE: If vacuum still does not operate prope rly, contact Custo mer Se rvice at AU 02 8801 76 66 | NZ 0800 112 66 0
AU sharkclean.com.au | NZ sharkclean.co.nz
Fig. A
Fig. D
Fig. B Fig. C
Fig. E Fig. F
Fig. HFig. G
sharkclean.co.nz sharkclean.com.au
ADDITIONAL ACCESSORIES AVAILABLE ON AU SHARKCLEAN.COM.AU
NZ SHARKCLEAN.CO.NZ
A
Crevice Tool
B
Duster Crevice Tool
C
Upholstery Tool
D
Wide Upholstery Tool
E
Pet Multi-Tool
F
Replacement Battery
G
Hand Vac Pre-Motor Filter
H
Auto-Empty Dock
Post-Motor HEPA Filter
I
Auto-Empty Exhaust Foam Filter
J
Hand Vac Post-Motor HEPA Filter
A
B
C
D
E
TWO (2) YEAR LIMITED REPLACEMENT WARRANTY
The warranty commences on the date of purchase and expires at the end of the two-year period. In the unlikely
event of a defect due to faulty materials or workmanship within the guarantee period we will replace the defective/
faulty part with a new product, free of charge, or if the unit is deemed defective/fault y we replace the unit with an
equivalent or upgraded model, at our discretion.
F
G
H
I
J
For warranty claims, you will need to submit a proof of purchase in the form of a valid receipt that displays date
and place of purchase.
Your warranty is subject to the following conditions
• DO NOT operate the appliance with a damaged plug or cord, or if the unit has been dropped, damaged
or dropped in water.
• To avoid the risk of electric shock, do not disassemble or attempt to repair the appliance on your own. If the
supply cord is damaged, it must be replaced by a qualified electrician to avoid a hazard. Incorrect re-assembly
or repair can cause a risk of electric shock or injur y to persons when the appliance is used.
• The item has not been misused, abused, neglected, altered, modified or repaired by anyone.
• The item has been subjected to fair wear and tear.
• The item has not been used for trade, professional or hire purposes.
• The item has not sustained damage through foreign objects, substances or accident
Customer costs within warranty
The customer is responsible for any inwards freight charge to return a product for warranty if requested,
and outward freight charge for warranty parts and or replacement unit.
Who is covered?
This warranty applies only to the original purchaser, who bought the product from an authorised retailer and may
not be transferred. Proof of purchase is required.
What is not covered?
• Filters and brush rolls
• Accessories supplied with the item.
• Components that are subject to natural wear and tear caused by normal use in accordance with operating
instructions.
• Unauthorised/improper maintenance/handling or overload is excluded from this warranty.
• Accidental damage
• Damage as a result of use not in accordance with the rating plate
• Removal of blockages. If a blockage does occur please refer to the trouble shooting guide within your
Shark Operating manual
• Use of parts and accessories that are not genuine Shark components
NOTE: Not a ll acces sories come with a ll units. Please see the enclosed Quic k Start Guide fo r your unit's con figuration.
To order add itiona l access ories , visit AU sharkclean.com.au NZ sharkclean.co.nz
sharkclean.co.nz sharkclean.com.au
REGISTER YOUR PURCHASE
AU sharkclean.com.au
NZ sharkclean.co.nz
TECHNICAL SPECIFICATIONS
Voltage: 21.6V
NOTES
Scan QR code using
mobile device
RECORD THIS INFORMATION
Model Number: �����������������������������
Date Code: ���������������������������������
Date of Purchase: ���������������������������
(Keep receipt)
Store of Purchase: ���������������������������
TIP: You can find the model and serial numbers on
the QR code label on the bottom of the back of the
hand vacuum and battery.
ODOUR NEUTRALISER SPECIFICATIONS
1. Product Name: Odour Neutraliser Cartridge
2. Manufacturer: Shark Ninja 89 A Street,
Needham, MA 02494
3. Weight: 17.4g / 0.61oz
4. Ingredients: Solid SM composite polymer
C17 + fragrance SE 272235
sharkclean.co.nz sharkclean.com.au
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
This Owner’s Guide is designed to help you get a complete understanding of your new
Shark® Cordless Detect Pro™ Vacuum.
Mann&Noble Pty Ltd
Building D, 33 Quarry Road
Erskine Park NSW, Australia, 2759
AU 02 8801 7666 | NZ 0800 112 660
AU sharkclean.com.au | NZ sharkclean.co.nz
Illustrations may dier from actual product. We are constantly striving to improve our products;
therefore the specifications contained herein are subject to change without notice.
This product may be covered by one or more U.S. patents. See sharkninja.com/patents for
more information.
© 2023 SharkNinja Ope rating LLC. SHARK is a registered tradem ark of SharkNinja Operating LLC.
DETECT PRO, FLOORDETECT, and LIGHTDETECT are trademarks of SharkNinja Operating LLC.
RBRC is a tradem ark of Rechargeable Battery Recycling Corporation .
IW1600ANZ�IW3600ANZ�IB�MP�Mv7
Loading...
