Shark IF250UKT Instruction manual

DuoClean™ Cord-Free Vacuum

IF200UK IF250UK

Series

INSTRUCTIONS

sharkclean.eu

0800 862 0453

THANK YOU

for purchasing the Shark® DuoClean™ Cord-Free Vacuum

registermyshark.co.uk

0800 862 0453

Scan QR code using mobile device

TIP: You can ﬁnd the model and serial numbers on the QR code label which is located on the bottom of the dust cup.

RECORD THIS INFORMATION

Model Number: ��

Date of Purchase (Keep receipt): ��

Store of Purchase: ��

TECHNICAL SPECIFICATIONS

Voltage: 25.2V

Watts: 300W

Amps: 11.9A

PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.

This instruction manual is designed to help you get a complete understanding of your new Shark DuoClean Cord-Free Vacuum.

1 0800 862 0453

If you have any questions, please call the Customer Service line at 0800 862 0453.

CONTENTS

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Getting To Know Your Shark® DuoClean™ Cord-Free Vacuum . . . . . . . . . . . .6

Using Your Lithium ION Power Pack Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing Your Lithium ION Power Pack Battery � � � � � � � � � � � � � � � � � � � � � � � � � � 7 Charging Your Lithium ION Power Pack Battery � � � � � � � � � � � � � � � � � � � � � � � � � �7 Using the Lithium ION Power Pack Battery � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �7 Using the Lithium ION Power Pack Battery Charging Dock � � � � � � � � � � � � � � � � � 7 LED Battery Power Meter � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7 Recycling Your Lithium ION Power Pack Battery � � � � � � � � � � � � � � � � � � � � � � � � � �7

Assembling Your Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using the Flexology™ wand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Flexology Storage � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9

Using Smart Response™ Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Choosing a Surface Setting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10 Choosing a Suction Setting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10

Using Your Vacuum in Above-Floor Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Maintaining Your Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Emptying the Dust Cup � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15 Cleaning the Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16 Maintaining the Brushroll � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17 Maintaining the Soft Roller � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 18 Checking for Blockages � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 18

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Battery Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2sharkclean.eu

IMPORTANT SAFETY INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

WARNING

To reduce the risk of injury, ﬁre, electric shock, and property damage

resulting from improper use of the appliance, carefully observe the following instructions. This unit contains electrical connections and moving parts that potentially present risk to the user. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capacity or lack of experience and knowledge, unless they have been given supervision or instruction.

THE DUOCLEAN™ FLOOR

NOZZLE, WAND, AND HANDHELD VACUUM CONTAIN ELECTRICAL CONNECTIONS:

• These are NOT serviceable parts.

• DO NOT use to vacuum any liquids.

• DO NOT immerse in water when cleaning.

•

If handheld vacuum/wand is damaged,

discontinue use.

1 To avoid ﬁre, explosion, or injury, inspect

Lithium ION Power Pack and chargers for any damage before use. DO NOT use vacuum cleaner with a damaged power pack or charger.

2 DO NOT use outdoors or on wet surfaces.

Use only on dry surfaces.

3 If vacuum cleaner is not working as it

should, or has been dropped, damaged, left outdoors, or immersed in water, return it to Euro-Pro Europe Limited for examination, repair, or adjustment.

4 DO NOT handle charger or vacuum

cleaner with wet hands.

5 DO NOT leave vacuum cleaner

unattended.

6 Keep power pack away from heated

surfaces.

7 Always turn off this appliance before

connecting or disconnecting ﬂoor nozzle.

8 Use only Shark chargers and batteries.

Other types of batteries may burst, causing injury and damage.

9 Use Lithium-ION Power Pack Charging

Dock on ﬂat, stable surfaces only.

10 DO NOT incinerate appliance, even if it is

severely damaged, as power pack may explode in a ﬁre.

GENERAL USE

11 DO NOT hang vacuum cleaner from wall

mount when Flexology mode.

12 Use only as described in this manual.

13 Keep your work area well lit.

14 Keep the vacuum cleaner moving over

the carpet surface at all times to avoid damaging the carpet ﬁbres.

15 DO NOT place vacuum cleaner on

unstable surfaces such as chairs or tables.

16 DO NOT put any objects into openings.

DO NOT use with any opening blocked;

keep free of dust, lint, hair, and anything that may reduce airﬂow.

17 DO NOT allow young children to operate

the appliance or use as a toy. Close supervision is necessary when any appliance is used near children. Cleaning and user maintenance shall not be made by children without supervision.

18 DO NOT use without Soft Roller, dust cup

door, and all ﬁlters in place.

™

Wand is in storage

3 0800 862 0453

SAVE THESE INSTRUCTIONS

PLEASE READ CAREFULLY BEFORE USE

19 DO NOT use if airﬂow is restricted; if the air

paths or the ﬂoor nozzle become blocked, turn off the vacuum cleaner and remove battery. Clear all obstructions before returning battery to vacuum and powering on again.

20 Keep ﬂoor nozzle away from hair, face,

ﬁngers, uncovered feet, or loose clothing.

21 Only use manufacturer’s recommended

attachments.

DO NOT charge power pack at temperatures below 50°F (10°C) or above 100°F (38°C). Charging voltage is not to exceed DC 29.45V, charging current is not to exceed 1200mA.

23 Store the appliance indoors. DO NOT use

or store it below 37.4°F (3°C). Ensure the appliance is at room temperature before operating.

DUST CUP/FILTERS/ACCESSORIES

Before turning on the vacuum:

24 Make sure that all ﬁlters are thoroughly dry

after routine cleaning.

25 Make sure brushroll, Soft Roller, dust cup

door, and all ﬁlters are in place after routine maintenance.

26 Make sure accessories are free of

blockages and keep openings away from face and body.

27 Use only Shark

accessories. Using other brands will void warranty.

brand ﬁlters and

GENERAL CLEANING

28 DO NOT vacuum up hard or sharp objects

such as glass, nails, screws, or coins that could damage the vacuum cleaner.

29 DO NOT vacuum up drywall dust,

ﬁreplace ash, or embers. DO NOT use as an attachment to power tools for dust collection.

30 DO NOT vacuum up smoking or burning

objects such as hot coals, cigarette butts, or matches.

31 DO NOT vacuum up ﬂammable or

combustible materials (e.g., lighter ﬂuid, gasoline, or kerosene) or use vacuum in areas where they may be present.

DO NOT

chlorine bleach, ammonia, or drain cleaner).

33 DO NOT use in an enclosed space

where vapors are present from paint, paint thinner, moth-prooﬁng substances, ﬂammable dust, or other explosive or toxic materials.

34 DO NOT vacuum up any liquids.

35 DO NOT immerse vacuum cleaner in water

or other liquids.

36 Use extra care when cleaning on stairs.

CONTINUED ON PAGE 5

vacuum

up toxic solutions (e.g.,

4sharkclean.eu

IMPORTANT SAFETY INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

WARNING

To reduce the risk of injury, ﬁre, electric shock, and property damage

resulting from improper use of the appliance, carefully observe the following instructions. This unit contains electrical connections and moving parts that potentially present risk to the user.

LITHIUM ION POWER PACK BATTERY

37 The Lithium ION Power Pack Battery is

the power source for the appliance. When the Lithium ION Power Pack Battery is connected to the appliance, DO NOT carry the appliance with your ﬁnger on the power button. DO NOT charge appliance with the power on.

38 Disconnect the Lithium ION Power Pack

Battery from the appliance before making any adjustments or troubleshooting. If the appliance is to be stored unused for a long period, the batteries are removed.

39 Use only Shark chargers

YLS0243A-U288080 / YLS0483A-U2880802 to charge. Use of incorrect charger may create a risk of ﬁre when used with Lithium ION Power Pack Battery.

40 Use appliance only with speciﬁcally

designated Lithium ION Power Pack Batteries. Use of any other battery packs may create a risk of injury and ﬁre.

41 When Lithium ION Power Pack Battery

is not in use, keep it away from all metal objects, such as paper clips, coins, keys, nails, or screws. Shorting the battery terminals together increases the risk of ﬁre or burns.

Under abusive conditions, liquid may be ejected from the power pack. Avoid contact with liquid, as it may cause irritation or burns. If contact occurs, ﬂush with water. If liquid contacts eyes, seek medical help.

43 DO NOT expose power pack or appliance

to ﬁre or temperature above 266°F (130°C) as it may cause explosion.

44 Follow all charging instructions and DO

NOT charge the power pack or appliance

outside of the temperature range speciﬁed in the instructions (see #22). Charging improperly or at temperatures outside of the speciﬁed range may damage the Lithium ION Power Pack Battery and increase the risk of ﬁre.

45 Appliance should only be serviced by a

qualiﬁed repair person using only identical replacement parts. To ensure safety, DO NOT modify or attempt to repair the appliance or the power pack yourself, except as indicated in the instructions for use and care.

46 Lithium ION Power Pack Battery should not

be stored at temperatures below 37.4°F (3°C) or above 104°F (40°C) to maintain long-term battery life.

47 Lithium ION Power Pack Battery should not

be exposed to or submerged in any water, salt water, or other liquids.

SAVE THESE INSTRUCTIONS

PLEASE READ CAREFULLY BEFORE USE

5 0800 862 0453

GETTING TO KNOW YOUR SHARK® DUOCLEAN™ CORD-FREE VACUUM

WELCOME!

Congratulations on your purchase. Use this instruction manual to learn about your new vacuum’s great features. From assembly to use to maintenance, you will ﬁnd it all in here.

NOTE: Your Lithium ION Power Pack Battery does not come fully charged. Prior to ﬁrst use, fully charge. During ﬁrst use, discharge fully to condition your Lithium ION Power Pack Battery. Failure to do so may cause LED indications to work incorrectly. Always store Lithium ION Power Pack Battery with a partial charge.

A B

Wand

Release

A Power Switch

B Battery Release

C Handheld Vacuum

D Lithium ION Power Pack

Battery

E Dust Cup Release

F Flexology™ Wand Release

G Flexology Storage Carry

Handle

H Flexology Wand Button

I Flexology Wand

J DuoClean Floor Nozzle

K Lower Wand Release

Pedal

L Brushroll Garage Release

Buttons

M Headlights

N Soft Roller

O Soft Roller Access Tab

6sharkclean.eu

USING YOUR LITHIUM ION POWER PACK BATTERY

NOTE: Some charging

options may not be included with your vacuum.

To purchase additional or replacement Lithium ION Power Pack Batteries, chargers, and charging docks, visit sharkclean.eu

DID YOU KNOW?

The DuoClean™ ﬂoor nozzle has LED headlights that turn on automatically to illuminate the ﬂoor surface.

RECYCLING YOUR LITHIUM ION POWER PACK BATTERY

When your Lithium ION Power Pack Battery needs to be replaced, dispose of it or recycle it in accordance with local regulations. In some areas, it is illegal to place spent lithium-ion batteries in the bin or in a municipal solid waste stream. Return spent power packs to an authorised recycling center or to retailer for recycling. Contact your local recycling center for information on where to drop off the spentpower pack.

NOTE: Lithium-ION Power Pack takes approximately 3.5 hours for full charge.

NOTE: When used in handvac mode, the Lithium ION power Pack provides up to 22 minutes of runtime in EXTENDED RUNTIME setting and up to 10 minutes in MAX POWER setting.

INSTALLING YOUR LITHIUM ION Power Pack BATTERY

Slide the Lithium ION Power Pack Battery into the slot on the back of the handheld vacuum.

To remove, pinch the release tab and slide the Lithium ION Power Pack Battery out of the handheld vacuum.

CHARGING YOUR LITHIUM ION Power Pack BATTERY Using the LITHIUM ION Power Pack Battery Charger

Connect the Lithium ION Power Pack Battery Charger to the port on the side of the Lithium ION Power Pack Battery, then plug the charger into a wall outlet. The ION Power Pack Battery can be charged whether it is inside or outside the handheld vacuum.

Using the Lithium ION Power Pack Battery Charging Dock

ION

POW ER P AC K

Connect Lithium ION Power Pack Battery Charger to the Charging Dock. Place power pack onto dock, then connect charger to wall outlet.

LED BATTERY POWER METER In Use

As the Lithium ION Power Pack discharges, its 3 LED lights will gradually turn off in sequential order. When less than 5% of charge remains, the bottom LED light will ﬂash, indicating a charge is needed.

Full Charge

Mid Charge

Low Charge

Nearly Empty

No Charge

Charging

As the Lithium ION Power Pack Battery charges, the lights will ﬁrst blink and then illuminate steadily, in sequential order. All 3 lights will glow steadily upon receiving a full charge, and then turn off after a short period. This preserves long-term battery life and allows the battery to remain connected to the charger even after reaching full charge.

Low Charge

Mid Charge

Nearly Full

Full Charge

7 0800 862 0453
