Shake Awake alarm clock User Manual
alarm clock
user guide
other resources on line at www.phonicearlogia.com
table of contents
Shake Awake instructions (English) . . . . . . . . . . . 1-13
Shake Awake-Anweisungen (Deutsch). . . . . . . . . 14-27
Instructions du Shake Awake (Français) . . . . . . . 28-41
Instrucciones de Shake Awake (Español). . . . . . . 42-55
shake awake features (English)
1
display screen
2 alarm button
For stopping the
snooze alarm
3 alarm switch
To adjust alarm functions
7 set switch
To set actual time and
desired alarm time
8 minute button
To adjust minute
setting of clock
English
4 hour button
To adjust hour
setting of clock
5 switch cover/stand
6
light button
To activate light on
display screen
9 battery
compartment
10 hour switch
To choose between 12
or 24 hour time
11 clip
1
shake awake features (cont’d)
Front
1
2
3
4
5
2
6
7
8
shake awake features (cont’d)
Back
9
English
10
11
3
1 insert batteries into battery compartment
• Remove battery compartment cover
• Slide switch to choose between 12 or 24 hour time 10
• Place batteries into compartment 9
2 set clock
• Open switch cover/stand 5
• Slide set switch to position 7
• Press hour and minute buttons to set time 4 & 8
• Slide set switch to position 7
4
3 set alarm time
• Slide set switch to position 7
• Press hour and minute buttons to set time
4 & 8
• Slide set switch to position 7
NOTE: Alarm is not activated until the alarm switch is set
4 choose type of alarm and activate
• Choose vibrating alarm or audible alarm on
the alarm switch 3
• will appear on the display 1
Alarm is now activated and will sound or vibrate
at the time set in section 3
English
5
5 turn alarm off
• To deactivate alarm, slide alarm switch
to position 3
OR
• Press to stop a sounding or vibrating alarm 2
6 choose snooze alarm setting
• Slide set switch to Zzz position 7
• Zz will appear on the display 1
• When alarm sounds or vibrates, press to stop
alarm for 8 minutes 2
Zz will flash continuously and alarm will repeat
every 8 minutes
NOTE: To have snooze alarm repeat every 8 minutes, you
6
must stop the alarm within 1 minute from start
7 turn off snooze alarm
• Slide set switch to position 7
• Zz will disappear from display 1
8 press display light button
• Press button to illuminate
time display 6
English
7
troubleshooting
Shake Awake is not working
• Check to see that batteries are placed in battery compartment properly
•
If clock display does not appear, insert
mini Penlight, 1.5V battery
a new IEC LR03
If vibration does not work, insert
•
Penlight,1.5V batteries
Contact your hearing care professional if the device is still
•
not working (see back page)
two new IEC LR6
tests and approvals
The Shake Awake Alarm Clock is CE-compliant according
to the EMC-directive (89/336/EEC)
8
warranty
A one-year limited warranty is issued to the original consumer of this product(s) by
PhonicEar Logia.
time period of warranty
This warranty will go into effect upon the date of original purchase of this equipment, and
will remain in effect for one calendar year from that date as long as the instrument remains
the property of the original consumer.
what is covered by this warranty
Any electronic component which, because of workmanship, manufacturing, or design
defects, fails to function properly under normal use during the life of this warranty
will be replaced or repaired at no charge for parts or labor when returned to the factory
service center. Transportation in is paid by the customer. If it is determined that repair
is not feasible, the entire unit may be replaced with an equivalent unit upon mutual
agreement of the manufacturer and customer.
what is not covered by this warranty
This one-year limited warranty does not apply to:
1 Malfunctions resulting from abuse, neglect, or accident.
2 Peripheral accessories as itemized within the product brochure, when such items are
returned after 90 days from the original purchase.
3 Alkaline batteries (if applicable).
4 Instruments connected, installed, used, or adjusted in a manner contrary to instruc-
tions provided by the manufacturer.
9
English
warranty (cont’d)
5 Consequential damages and damages resulting from delay or loss of this instrument.
The exclusive remedy under this warranty is strictly limited to repair or replacement
as herein provided.
6 Products damaged in transit unless investigated by the shipper and returned to the
warrantor with the investigation report.
PhonicEar Logia reserves the right to make changes in the design or construction of any of
its instruments at any time without incurring any obligation to make any changes whatsoever on units previously purchased. This warranty is in lieu of all other expressed warranties.
All expressed and implied warranties will terminate upon the expiration of this written warranty. No representative or person is authorized to represent or assume for us any liability
in connection with the sale or use of our products other than as set forth above.
The above warranty does not affect any legal rights that you might have under applicable
national legislation governing sale of consumer goods. Your distributor may have issued a
warranty that goes beyond the clauses of this limited warranty. Please consult your distributor for further information.
what to do if you need service
If you require service under the terms of this warranty, carefully package the instrument to
prevent damage and return it to your distributor (see information on back cover). Please
provide your receipt, a detailed description of the problem, your full name, billing address,
and telephone number.
10
Shake Awake-Funktionen
Anzeigefeld
1
2 Wecktaste
Alarm ausschalten
7
Einstellungsschalter SET
Aktuelle Zeit und
gewünschte W eckz eit
einstellen
Deutsch
3
Weckschalter
W eckfunktionen
einstellen
4
Stundentaste
Stunden einstellen
5 Schutzdeckel mit
Aufstellvorrichtung
6 Lichttaste
Beleuchtung des
Anzeigefeldes aktivieren
8 Minutentaste
Minuten einstellen
9 Batteriefach
10 hour switch
Zwischen 12 oder 24
Stunde Mal wählen
11 Befestigungsclip
11
