With 4096 bit EEPROM, Anti-Collision and Anti-Clone Functions
DATA BRIEFING
FEATURES SUMMARY
■ ISO 14443 - 2 Type B Air Interface Compliant
■ ISO 14443 - 3 Type B Frame Format Compliant
■ 13.56MHz Carrier Frequency
■ 847kHz Sub-carrier Frequency
■ 106 Kbit/s Data Transfer
■ France Telecom Proprietary Anti-Clone
Function
■ 8 bits Chip_ID based anticollision system
■ 2 Count-Down Binary Counters
– 32 b i ts each
32
units to be counted-down
–2
■ 64-bit Unique Identifier
■ 4096-bit EEPROM with Write Protect Feature
■ READ BLOCK & WRITE BLOCK (3 2 Bits)
■ Internal Tuning Capacitor
■ 1million ERASE/WRITE Cycles
■ 10-Year Data Retention
■ Self-Tim e d P rogramming Cycle
■ 5ms Typical Programming Time
Figure 1. Delivery Forms
Antenna (
Antenna (A4)
A3)
July 2003
Complete data available under NDA.
Antenna (A5)
Wafer
1/5
SRIX4K
SUMMARY DESCRIPTION
The SRIX4K is a contactless memory, powered by
an externally transmitted radio wave. It contains a
4096-bit user EEPROM fabricated with STMicroelectronics CMOS techn ology. T he memory is organised as 128 blocks of 32 bits. The SR IX4K is
accessed via the 13.56MHz carrier. Incoming data
are demodulated and d ecoded from t he received
Amplitude Shift Keying (ASK) modulation signal
and outgoing data are generated by load variation
using Bit Phase Shift Keying (B PSK) coding of a
847kHz sub-carrier. The received ASK wave is
10% modulated. The Data transfer rate bet ween
the SRIX4K and the reader is 106Kbit/s in both reception and emission modes.
The SRIX4K follows t he ISO 14443 part 2 t ype B
recommendation for the radio-frequency power
and signal interface.
Figure 2. Logic Diagram
SRIX4K
Power
Supply
Regulator
4 Kbit
User
EEPROM
ASK
Demodulator
BPSK
Load
Modulator
The SRIX4K targets short range applications
which need secure an d re-usable products. The
SRIX4K includes an anti-collision mechanism that
allows it to detect and select tags present at the
same time within range of the reader. The anti-collision is based on a probabilistic scanning method
using slot markers. The SRIX4K prov id es an ant i-
AC1
AC0
AI06829
clone function which allows its authentication. Using the STMicroelectronics single chip coupler,
CRX14, it is easy to design a reader with the authentication capability and to build a system with a
high level of security.
Table 1. Signal Names
AC1Antenna Coil
AC0Antenna Coil
The SRIX4K contactless EEPROM can be randomly read and write in block mode. Each block is
composed by 32 bits. It offers a set of 10 commands:
■ READ_BLOCK
■ WRITE_BLOCK
■ INITIATE
■ PCALL16
■ SLOT_MARKER
■ SELECT
■ COMPLETION
■ RESET_TO_INVENTORY
■ AUTHENTICATE
■ GET_UID
The SRIX4K memory is organized in three areas,
as described in Figure 3. The first area is a resettable OTP (one time programmable) area in which
bits can only be switched from 1 to 0. Using a special command, it is possible to erase all bits of this
area to 1. The second area provides two 32-bit binary counters which can only be decremented
from FFFFFFFF h to 00000000h, and gives a capacity of 4,294,967,296 units per counter. The last
area is the EEPROM memory. It is accessible by
block of 32 bits and includes an auto-erase cycle
during each WRITE_BLOCK command.
2/5
MEMORY MAPP I N G
The SRIX4K is organised as 128 blocks of 32 bits
as shown in Figure 3. All blocks are accessible by
the READ_BLOCK command. Depending o n the
Figure 3. SRIX4K Memory Mapping
SRIX4K
write access, they can be updated by the
WRITE_BLOCK command. A WRITE_BLOCK updates all the 32 bits of the block.
Block
Addr
127User Area
Msb32 bits BlockLsb
b
31
032 bits Boolean Area
132 bits Boolean Area
232 bits Boolean Area
332 bits Boolean Area
432 bits Boolean Area
532 bits binary counter
632 bits binary counter
7User Area
8User Area
9User Area
10User Area
11User Area
12User Area
13User Area
14User Area
15User Area
16User Area
b
24 b23
b16 b
15
b8 b
7
b
Description
0
Resettable OTP bits
Count down
Counter
Lockable EEPROM
EEPROM...User Area
255OTP_Lock_RegST Reserved
UID0
UID1
64 bits UID AreaROM
Fixed Chip_ID
(Option)
System OTP bits
3/5
SRIX4K
PART NUMBERING
For a list of available options (speed, package,
etc.) or for further information on any aspect of this
Table 2. Ordering Information Scheme
Example:SRIX4K–W4/XXX
Device Type
SRIX4K
Package
W4 =180µm ± 15µm Unsawn Wafer
SBN18= 180µm ± 15 µm Bumped and Sawn Wafer on 8-inch Frame
A3T= 38mm x 38mm Copper Antenna on Continuous Tape
A3S= 38mm x 38mm Copper Singulated Adhesive Antenna on Tape
A4T= 15mm x 15mm Copper Antenna on Continuous Tape
A4S= 15mm x 15mm Copper Singulated Adhesive Antenna on Tape
A5T= 42mm x 65mm Copper Antenna on Continuous Tape
A5S= 42mm x 65mm Copper Singulated Adhesive Antenna on Tape
Customer Code
XXX = Given by STMicroelectronics
device, please contact your nearest ST Sales O ffice.
