Senwa S905 User Manual

Phone user manual

User Guide

S905

Preface

Thank you for choosing S905 Smart phone is an Android intelligent mobile phone, it has the ultra-thin fashion appearance, it supports application software installation and unloading from Android electronic market, WLAN network connection, touch capacitive screen, high-pixels cameras, high-quality audio and ultra HD video, etc. These will lead you into an entirely new and fascinating mobile internet world.

This manual systematically introduces many functions of S905 Smart phone, tips and notes. Please carefully read it before using S905.

The illustrations in this manual are only for reference, and their functions are based on the real product. The company reserves the right of final interpretation.

Basic Information

1. Safety Notice

If your phone is lost or stolen, please immediately inform the telecom department or commission

agents of forbidding the use of SIM card, so that avoid the economic loss caused by false calling of others.

When you contact with telecom department or commission agents, they need to know your phone IMEI number (printed on the label on the back of the phone and can be found after taking down the battery). Please copy the number and keep it safe for future use.

In order to use the phone more safely, please adopt preventive measures, for example: set up the PIN code of SIM card, PIN code can prevent your SIM card from being used by others without

permission. When leaving the car, please don’t place the phone in a place easy to be seen, you had

better to carry with you or lock in the suitcase.

2. Safety Alert and Cautions

Before using the phone, please read these cautions carefully so that make sure to use the phone correctly.

3.1 General Cautions

On the plane, in the hospital and other places that forbidden to use the mobile phone, please turn off the phone; otherwise it may affect the normal operation of electronic equipments and medical instruments. Please comply with the relevant regulations if using the phone in these places,

Please strictly comply with the laws and regulations about the phone use in the driving place. If you use the phone while you are driving, please comply with the following rules: concentrate on driving, pay attention to the road conditions; if the phone has hands-free function, please make a phone call hands-free; if the driving conditions are not good, please stop the car, and then dial or receive a call.

When approaching the places that storing fuel, chemicals or explosives, and etc., please comply with the laws, regulations and the relevant signs.

Please place the phone, battery and charger in the place out of children’s reach, for fear that the

children use them as tools and cause personal injury.

Your phone only can use the batteries, chargers and other accessories specified by the company for fear that the phone is damaged. If using other batteries and chargers, it may cause liquid leaking, overheat, explosion, fire breakout and other failures of batteries.

Please don’t use the phone close to weak signal or high precision electronic equipments. Wireless wave interference may cause the mis-operation of these electronic equipments.

The phone has the function of timely auto power-on, please check the auto power-on and shut down settings of the phone, so that confirm that the phone will not power on automatically during the flight.

Please don’t strike, shake or sling the phone violently for fear that the phone is failed or fire

breakout.

Please don’t place the battery, the phone and the charger in the micro-wave oven or high-voltage equipment; otherwise may cause circuit damage or fire breakout and other accidents.

Please don’t use the phone in the places with inflammable and explosive gas; otherwise may

cause phone failure or fire hazard.

Please don’t place the phone in the places with high temperature, high humidity or a large amount of dust; otherwise it may cause phone failure.

Please don’t place the phone in the uneven or unstable place, prevent the phone from falling off

and then cause failure or damage.

Please only use the original antenna or the antenna being approved by the company. Unapproved and modified antenna or the antenna with additional accessories may damage the phone. Please don’t touch the antenna during a call. Touching the antenna may affect the call quality and make the phone power higher than the required power in normal use. In addition, using the unapproved antenna may violate the regulations in your country.

3.2 Cautions of Using the Phone

Don’t take down or modify the phone; otherwise it may cause the damage, leakage and circuit failure of the phone.

Please don’t knock the LCD by force or use the LCD to knock other things; otherwise may cause

the damage of liquid crystal plate and the leaking of liquid crystal. If liquid crystal enters the eyes, it

may damage eyesight. At this time, please rinse the eyes immediately with clean water (don’t rub

the eyes), and see a doctor immediately.

In very rare cases, if the phone is used in some types of vehicles, it may have bad effect on the

electronic equipments in the vehicle. At this time, please don’t use the phone for fear of losing the

safety guarantee.

If your vehicle is equipped with the air bag, please don’t place the phone above the air bag or the

area that can be touched after the air bag is swelled, for fear that the phone is applied very strong external force and cause serious damage on the vehicle owner when the air bag is swelled.

Please don’t touch the key-stoke using needles, pen nibs and other sharp objects; otherwise it may damage the phone or cause mis-operation.

If the antenna is damaged, please don’t use the phone; otherwise it may cause the personal injury.

Don’t make the phone approach to the magnetic card and other magnetic objects too closely;

radiation wave of the phone may clean out the information stored in the floppy disks, stored value cards and credit cards.

Please place the drawing pin and other small metal objects in the place that far from the headphone of the phone. The loudhailer is magnetic when it is working and will attract these small metal objects so that may cause personal injury or damage the phone.

Avoid phone damping, prevent water and other liquid from entering the phone, and then cause short circuit, leakage or other failures of the phone.

Please use the phone in the place that far from fixed telephone, TV, radio and office automation equipments, for fear that it may affect the using effects of these equipments and the phone.

3.3 Cautions of Using the Battery

Please don’t take down or modify the battery; otherwise it may cause liquid leaking, overheat, explosion or fire breakout of battery.

Don’t throw the old battery into general life rubbish. Treat the battery according to the regulated

indication in the place that definitely regulates the waste battery treatment.

Please don’t throw the battery into the fire otherwise it may cause the fire breakout or explosion of the battery.

When installing the battery, don’t apply pressure forcefully; otherwise it may cause liquid leaking,

overheat, explosion or fire breakout of the battery.

Please don’t make the battery short circuit using the electrical wire, needle and other metal objects;

don’t place the battery, necklace and other metal objects together; otherwise it may cause liquid

leaking, overheat, explosion or fire breakout of the battery.

Please don’t solder the battery contact; otherwise it may cause liquid leaking, overheat, explosion or fire breakout of the battery.

If battery liquid enter the eyes, it may damage eyesight; at this time, please don’t rub the eyes

using the hand, please rinse the eyes with clean water, and then see a doctor immediately.

Please don’t use or place the battery near the fire or oven and other high temperature places; otherwise it may cause liquid leaking, overheat, explosion or fire breakout of the battery.

If the battery is increasing the temperature abnormally, color change, distortion and other phenomena during the using, charging or storing process, please stop using it and then change new battery.

If leaking liquid of the battery contacts with the skin and clothing, it may cause skin burn, please rinse it with clean water immediately, and see a doctor if necessary.

If the battery is leaking liquid or giving out strange odor, please take the battery away from open fire immediately, avoid fire breakout or explosion.

Please don’t make the battery damp, otherwise it may cause overheat, smoking or corrosion of the battery.

Please don’t use or place the battery under direct sunlight and other high temperature places,

otherwise it may cause liquid leaking or overheat, reduce the performance and shorten the service life.

Please don’t charge the battery continuously for more than 24 hours.

Please place the battery in the cool and ventilated place away from direct sunlight.

Service life of the battery is limited. Service time of the battery is gradually shortened after the frequent charging. If many times of charging is failed, it means that battery life is drained, please replace the new battery of designated type.

3.4 Cautions of Using the Charger

Please don’t take down or modify the charger; otherwise it may cause personal injury, electric

shock, fire breakout or charger damage.

Please use 220V alternating current. Using other voltage may cause leakage, fire breakout and damage the phone and the charger.

Short circuit of the charger is forbidden; otherwise it may cause electric shock, smoking and charger damage.

Please don’t use the charger when the power cord is damaged; otherwise it may cause fire

breakout or electric shock.

Please clean the dirt that accumulates in the power socket in time.

Please don’t place the water container, and etc. near the charger, for fear of water splashing and then cause short circuit, leakage or other failures.

If the charger contacts water or other liquid, please cut off power supply immediately, so that prevent short circuit, fire breakout, electric shock or charger failure.

Don’t use the charger in the bathroom and other high humidity places; otherwise may cause

electric shock, fire breakout or charger damage.

Please don’t contact the charger, electrical wire and power socket with wet hands; otherwise it may

cause electric shock.

Don’t place heavy object on the power cord or reconstruct the electrical wire; otherwise may cause

electric shock or fire breakout.

Please pull out the charger plug from power sockert before the cleaning and maintenance.

Seize the charger when pulling the plug, pulling the power cord will damage the electrical wire, cause electric shock or fire breakout.

Don’t charge in the following places: direct sunlight and other high temperature places; wet and

ashy place or the place with large vibration (will cause failure); near TV, radio and other home appliances (will affect the image and sound effects).

3.5 Security Password

3.5.1 PIN

PIN (Personal Identification Number) is used to prevent your SIM card from being used illegally. PIN is usually provided with SIM card together. If you input wrong PIN for continuous three times, please input PUK to unlock it. Please contact with network operations company for more details.

3.5.2 PIN 2

You need to input PIN2 when entering some functions (such as call charge); if you input wrong PIN2 for continuous three times, you need to input PUK2 to unlock it. Please contact with network operations company for more details.

3.5.3 PUK

When changing the locked PIN, you need to input PUK (Personal Unlock Key). PUK is provided with SIM card together. If it is not provided, please contact with your service provider. If you input wrong PUK for continuous ten times, the SIM card can’t be used again. Please contact with your

service provider to buy a new card. You can’t change PUK. If you lose the code, please contact with

your service provider.

3.5.3 PUK2

When changing the locked PIN2, you need to input PUK2. If you input wrong PUK2 for continuous

ten times, you can’t use the functions that need PIN2. Please contact with your service provider to

buy new card. You can’t change PUK 2. If you lose the code, please contact with your service

provider.

3.6 Cleaning and Maintenance

Please don’t use the phone, the battery and the charger in the bathroom and other high humidity

places, and prevent them from rain.

Please clean the phone, the battery and the charger by using soft and dry cloth.

Please don’t wipe the phone by using alcohol, thinner or benzene and other chemical reagents.

The socket with dirt may cause poor contact and power-off, so that it can’t be charged, please clean it regularly.

Contents

Ⅰ. SAFETY PRECAUTIONS ········································································································································· 7 Ⅱ. BEFORE USE ····························································································································································· 8

1. INSTALL AND UNLOAD SIM CARD ····················································································································· 8

2. T-FLASH CARD ·················································································································································· 9

3. INSTALL AND UNLOAD BATTERY ························································································································ 9

4. CHARGING ························································································································································ 9

Ⅲ. QUICK USER GUIDE ·············································································································································· 10

1. POWER ON/OFF ··············································································································································· 10

2. TURN ON /OFF SCREEN ··································································································································· 10

3. LOCK AND UNLOCK ········································································································································· 10

4. SWITCH DESKTOPS ··········································································································································· 10

5. HOT BUTTONS ················································································································································· 11

6. DESKTOP MENU ·············································································································································· 11

7. MAIN MENU ···················································································································································· 11

8. MOVE APPLICATIONS ······································································································································· 11

9. DELETE APPLICATIONS ···································································································································· 11

10. NOTIFICATION BAR······································································································································ 11

11. STATUS BAR ················································································································································ 12

12. ADD TO HOME SCREEN ································································································································ 12

13. BLUETOOTH CONNECTION ··························································································································· 12

14. WLAN CONNECTION ·································································································································· 12

15. INPUT METHODS ········································································································································· 12

16. DESCRIPTION OF KEYS ································································································································ 12

Ⅳ . BASIC FUNCTIONS ·············································································································································· 13

1. DIALER INTERFACE ·········································································································································· 13

2. DIAL A CALL ··················································································································································· 13

3. PEOPLE ···························································································································································· 14

4. MESSAGING ····················································································································································· 15

5. CALL LOG ························································································································································ 16

6. BACKUP AND RESTORE ···································································································································· 17

7. BROWSER ························································································································································ 18

8. CALCULATOR ·················································································································································· 18

9. CALENDAR ······················································································································································ 18

10. CAMERA ····················································································································································· 19

11. CLOCK ························································································································································ 19

12. DOWNLOADS ··············································································································································· 19

13. EMAIL ························································································································································· 19

14. FILE MANAGER ··········································································································································· 21

15. FM RADIO ··················································································································································· 22

16. GALLERY ···················································································································································· 22

While driving or answering a call, please use an earphone or stop your car.

Mobile phone interferes with aircraft communication, please ensure that mobile phone power off during the entire flight.

All mobile phones may be disturbed, and affect their performance.

Please don’t use mobile phone and turn off your phone where medical equipments exist.

To ensure the best performance or avoid damage to mobile phone, please use the original accessories and batteries.

At the gas station and close to the fuel and chemicals and other dangerous goods, please power off your mobile phone to avoid explosion.

To avoid interference of the blasting operation, In the scene of the explosion or post "Turn off the radio" icon in the local, please power off your mobile phone.

Please don't burn batteries as ordinary garbage, to avoid the risk of life and damage to the environments. Please abide by the local environmental policy, timely deal with or recycle the waste batteries.

Before your mobile phone is connect with another equipment, please read carefully this manual to ensure safety.

Some small articles (such as T-Flash card, etc.) should be placed out of children reach, to prevent children swallowing or other hazard.

17. GMAIL ························································································································································· 22

18. LOCAL ························································································································································ 22

19. MAPS ·························································································································································· 22

20. MOVIE STUDIO ············································································································································ 22

21. MUSIC ························································································································································· 23

22. NAVIGATION ··············································································································································· 23

23. NEW&WEATHER ········································································································································· 23

24. PLAY STORE ················································································································································· 23

25. SETTINGS ···················································································································································· 24

26. SOUND RECORDER ······································································································································ 28

27. TALK ··························································································································································· 28

28. TODO ·························································································································································· 28

29. VIDEO PLAYER············································································································································· 29

30. VOICE SEARCH ············································································································································ 29

Ⅰ. Safety Precautions

Before using a mobile phone, please read and observe the following rules.

Please backup the important information or keep a written record, to prevent its loss.

When sending an emergency call, please ensure your mobile phone power on and in a service area, inform your position, without permission, please don't end this call.

Ⅱ. Before Use

1. Install and Unload SIM Card

1.1 About SIM Card

Before using the phone, you must insert valid SIM (Subscriber Identity Module) card in the phone. SIM card provided by network supplier.

All the information related to network connection are recorded in the chip of SIM card, also the names, telephone numbers and SMS that storing in the name card holder of SIM card. You can take out SIM card from your phone, and use it in any GSM mobile phone (new mobile phone can read SIM card automatically).

In order to avoid losing or damaging the information saves in SIM card, please don’t touch the metal contact surface, and place SIM card in the place that away from electricity and magnetic force. Once SIM card is damaged, you can’t use the phone normally.

Prompt: Please make sure to power off the phone before taking out SIM card. It is absolutely forbidden to insert or take out SIM card with external power supply; otherwise it may damage SIM card and the phone.

1.2 Insert and Unload SIM Card

Metal contact surface of SIM card is easily scratched. You must take out SIM card carefully before the assembly.

Power off the phone, remove the rear cover, battery or other external power supply. Make the end of SIM card without cutting angle inside and aim at the card slot of the phone and

metal surface of SIM card face downward, then insert SIM card to the card slot of the phone, the other SIM card is also inserted in this way.

When taking out SIM card, directly pull it outward and then can take out SIM card.

Prompt: Without special explanation inserting two SIM cards are defaulted in the manual. If you

just insert one SIM card, maybe some options of the menu will not be shown.

2. T-Flash Card

Aim at the T card slot and push the T card gently, and the card will be inserted correctly.

Prompt: If the memory card is failed, please check whether it is correctly placed and good contact of metal point.

3. Install and Unload Battery

Take off the rear cover of the mobile. Make one end of battery with metal surface aim at the battery connector. Then gently press the battery downward using the finger, and then press the other end to install the

battery.

Prompt: Please operate correctly to avoid damaging the battery connector.

4. Charging

4.1 Charger

Insert the charger on the charging interface at the top of the phone. After inserting the charging plug, battery strength icon stripe at the top right corner of the screen is scrolling, which means that the charging is processing; when the stripe is full of the whole icon and stop scrolling, which means that the battery charging is completed; when the charging is completed, please pull out the plug.

When electric quantity is not enough, warning message will be sent; and electric quantity shows empty. When electric quantity is too low, the phone will power off automatically. Please don’t make the battery in the status of not enough electric quantity for a long time; otherwise it may damage the battery quality and service life. Please don’t charge the battery for a long time.

Prompt: In order to ensure normal operation of the phone, please make sure to use the designated charger.

4.2 USB disk Identification

After USB disk is inserted, you can deal with data in USB disk after its light is on. Please refer to “File Manager” for the usage of USB Disk.

Prompt: It is forbidden to remove USB disk when data in USB disk is being copied, transferred or

deleted to prevent data damage.

4.3 Transferring Data With Computer

4.3.1 Install USB

Connect mobile phone to a computer with a USB cable, drag out the notification bar. Touch “USB

Connected”, choose and click “USB storage”, then on the computer, you can view data in Device

and SD Card storage. So data transferring can be performed between this device and the computer.

4.3.2 Disconnect USB

After data is mounted onto the computer, you can drag out the notification bar, touch to turn Off “USB Storage”, and then disconnect with USB link.

Prompt: It is forbidden to disconnect USB link during transferring data, because it can lead to data loss or damage.

Ⅲ. Quick User Guide

The phone has not only the basic functions of mobile phone, but also support rich, practical and rapid feature functions, can be briefly introduced as follows:

1. Power On/Off

In the power-off mode, long press [Power] key, it will power on; otherwise. In the power-on, long press [Power] key, and choose Power off, it will power off. If you set up SIM lock or phone lock, please input the code according to the requirements.

In any other interface, short press this button to lock the screen.

Warning: As mobile phone can cause interference and dangerous where you are prohibited to use

mobile phone, please power off your mobile phone.

2. Turn On /Off Screen

2.1 Turn Off Screen

Please short press [Power] to turn off the screen to save power.

Prompt: To save power, you can also set screen timeout time in Display Settings, when the timeout time is up, without any operation during the standby time, the screen will shut off automatically.

2.2 Turn On Screen

When the screen is off, please short press [Power] to wake up the screen.

3. Lock and Unlock

3.1 Lock

Please press [Power] to lock this screen to prevent some unexpected operations.

Prompt: If screen timeout time is set in system settings, this computer will turn off and lock its screen during the standby time if it is idle.

3.2 Unlock

After the screen is off, please press [Power] to wake up the screen, and then drag the slider

upwards to the green ball to unlock the screen.

Prompt: Drag the slider downwards to the white ball to switch between Sound and Vibrate state.

4. Switch desktops

In the idle mode, you can slide on the screen to switch between the 1st~5th screens.

+ 21 hidden pages
