Page 1
SMART BUILDING
TEMPERATURE
Ref : TEM-LAB-41NS
INDOOR
AMBIENT TEMPERATURE
MONITORING
SENLAB™ T IS A SMART WIRELESS DEVICE, FEATURING
THE LoRaWAN™ CONNECTIVITY PROTOCOL, EQUIPPED WITH
A HIGH-PRECISION TEMPERATURE SENSOR (±0.2°C).
20 years *
(replaceable battery)
15 km *
Local or Public
Network compliant
* Depending on the
operating conditions
Designed for indoor use, Senlab™ T offers a small casing with a discreet
aesthetic that makes it ideal for housing or ofce.
IP30
(Indoor use)
This Senlab offers best in class features such as :
• Battery life time more than 20 years
• Rich Data Content thanks to datalogging : Up to 24 measures / radio transmission
• Radio Performances
• Advanced set of functionalities
TYPICAL APPLICATIONS
• Building Energy Consumption Reduction
• Regulate and optimize home and ofces comfort
TECHNICAL SPECIFICATIONS
Physical
specications
RF
specications
EC Conformity :
Compliant with Directive
2014/53/UE (RED)
Dimensions 50 x 91,5 x 25 mm
Weight 60 gr
Operating temperature 0°C to +55°C
RF sensitivity -137 dBm
RF power +14 dBm (25 mW)
Radio band 868 MHz
EMC
Radio EN 300 220-2 v3.1.1
Magnetic eld exposure EN 62479
Safety EN 60950-1
• Monitor HVAC systems
• Protect temperature sensitive equipments
(servers rooms…)
Final draft EN 301 489-3 v2.1.1
Draft EN 301 489-1 v2.2.0
www.sensing-labs.com
Page 2
DIMENSIONAL DRAWING
25 mm
TECHNICAL FEATURES FOCUS
High congurability
• Temperature precision of ± 0.2°C typ., range [0 ; +55°C]
• High and Low threshold overrun configuration
• Log and transmit mode for battery lifetime enhancement
(up to 24 compressed measures per transmission)
• Reconfiguration possible over the air
Network Conguration
• LoRaWAN parameters (OTAA or ABP activation mode, initial datarate,...)
• Encryption keys customizable by client
• Standard LoRaWAN retries support
• Radio collisions avoidance by pseudo-randomization of transmissions
• Advanced transmission reliability mechanisms
(redundancy of data, recovery of lost messages, ...)
91,5 mm
50 mm
BEST IN ADVANCED FEATURES
The temporal redundancy improves the reception’s reliability of measures, at an optimized
energetic cost. If the radio signal is weak, it allows the transmission of a reminder of the
previous measures with the new physical measures in successive radio messages.
The flush mode allows to accumulate up to 10 days of temperature data recording, when
the network is not available. The Senlab T will transmit them as quickly as possible when
the network is available.
Advanced monitoring mode allows the data to be monitored up to every second. An alarm
can be triggered if the temperature rises within a given time period. This mode can be
activated in parallel with the classic operating mode.
BATTERY LIFE DURATION ESTIMATION
This following matrix provides the estimated battery lifetime depending on
the average spreading factor used by the Senlab and the transmission period.
Battery life (years) 10 min 15 min 30 min 1 h 2 h 4 h 6 h 8 h 12 h 24 h
SF7 14,6 16,3 18,3 19,6 >20 >20 >20 >20 >20 >20
SF8 12,1 14,1 16,8 18,7 19,8 >20 >20 >20 >20 >20
SF9
SF10
SF11
SF12
8,9 11,0 14,4 17,1 18,9 19,9 >20 >20 >20 >20
5,9 7,8 11,4 14,8 17,3 19,0 19,6 19,9 >20 >20
3,7 5,1 8,2 11,8 15,1 17,6 18,6 19,1 19,7 >20
2,2 3,1 5,4 8,6 12,2 15,4 16,9 17,8 18,7 19,8
www.sensing-labs.com
T : +33 (0)4 67 47 55 67
For guidance and information purposes only.6 measures per frame.
