Sennheiser SK 6212 Datasheet
PRODUCT SPECIFICATION
Digital 6000
SK 6212 | Bodypack transmitter
FEATURES
• Compact, ultra-small design with ergonomically optimized construction (63 x 47 x 20 mm)
• Designed for 12 hours of continuous operation
• Made with ultra-light robust metal housing weighing
only 112 grams
• Intermodulation-free transmission – permits more
channels even in very narrow frequency spaces thanks
to equidistant frequency grid and simple setup
• Superb sound and higher dynamic range thanks to
Sennheiser Digital Audio Codec (SeDAC) and long-range mode, also found in the Digital 9000 series
• Resistant to moisture and sweat
• Two detachable clips (0°/90°) for secure fit in any
position
• Exchangeable antenna and battery
• Can be used with a variety of lavalier microphones and
headsets
1/4
The SK 6212 has been specifically designed to meet the
demands of theatrical performances and broadcast applications. Weighing only 112 grams, it’s ultra-small design
makes every-day use easier for performers, make-up
artists and costume designers alike. For audio engineers,
the SK 6212 can still be directly operated and controlled
via a display and buttons, and the intermodulation-free
transmission technology is designed for an unbelievable 12
hours of continuous operation.
It’s robust construction, rounded ergonomic design, and
two versatile clips ensure the device is comfortable and
secure, whether the user is acting, dancing or singing. The
antennas and batteries are exchangeable and the metal
housing is sealed for sweat resistance.
The SK 6212 can be combined with lavalier microphones
and headsets. It provides maximum transmission reliability
thanks to the legendary ‘long-range mode’, and outstanding audio quality thanks to the Sennheiser Digital Audio
Codec (SeDAC), also used in the top-class Digital 9000
series. It’s sophisticated transmission electronics generate
no disruptive intermodulation, even when there are several
transmitters in a very small space. As a result, operation
within an equidistant frequency grid is possible. The available frequency spectrum is used efficiently and remains
easy to configure.
DELIVERY INCLUDES
• SK 6212 bodypack transmitter
• antenna
• clip, vertical
• clip, horizontal
• quick guide
• safety guide
• specification and manufacturer declaration sheet
PRODUCT VARIANTS
SK 6212 A1–A4 470.200 − 558.000 MHz Art. no.
508513
SK 6212 A5–A8 550.000 − 638.000 MHz Art. no.
508514
SK 6212 B1–B4 630.000 − 713.800 MHz Art. no.
508515
SK 6212 A5–A8 US 550.000 − 607.800 MHz Art. no.
508521
SK 6212 B1–B4 AU 630.000 − 693.800 MHz Art. no.
508529
SYSTEM COMPONENTS
• EM 6000 / EM 6000 DANTE
• SKM 6000
• SK 6000
• L 6000
PRODUCT SPECIFICATION
Digital 6000
SK 6212 | Bodypack transmitter
2/4
SPECIFICATIONS
Frequency range 470.200 to 713.800 MHz
Modulation scheme Digital modulation
Long Range Mode
Audio codec SeDAC (Sennheiser Digital
Audio Codec)
Switching bandwidth up to 88 MHz
Frequency stability < 5 ppm
Tuneability 25 kHz steps
Lower cut-off-frequency
(−3 dB)
RF output power standard mode:
Audio frequency response 30 Hz to 20 kHz (-3 dB)
Audio Gain Mic: adjustable in 3 dB
Audio input 3-pin audio socket
THD
(Total harmonic distortion)
SNR (Signal-to-noise ratio) typ. 113 dB(A)
Encryption AES 256
Antenna output coaxial socket
Operating time typ 12 h at 25 °C
Dimensions (H × W × D) approx. 63 × 47 × 20 mm
Weight approx. 112 g (with BA 62
adjustable: 30 Hz, 60 Hz,
80 Hz, 100 Hz, 120 Hz
15 mW rms
low power mode:
3.5 mW rms
steps from −6 dB to +42 dB
typ. 0.002%
(with BA 62 accupack)
accupack and beltclip)
COMPATIBLE WITH
• EM 9046 in Long Range mode
• EK 6042
ACCESSORIES
BA 62 Rechargeable battery Art. no. 508517
Clip, horizontal Art. no. 508570
Clip, vertical Art. no. 508571
Antenna A1-A4 Art. no. 508572
Antenna A5-A8 Art. no. 508573
Antenna B1-B4 Art. no. 508574
MKE 1–4 Lavalier microphone,
omni-directional
MKE 2–4 Lavalier microphone,
omni-directional)
MKE 40–4 Lavalier microphone,
cardioid
HSP 2 Headset microphone,
omni-directional
HSP 4 Headset microphone,
cardioid
SL Headmic 1-4 Headset microphone,
omni-directional
MKE Essential
Omni Black
MKE Essential
Omni Beige
HSP Essential
Omni Black
HSP Essential
Omni Beige
Lavalier microphone,
omni-directional
Lavalier microphone,
omni-directional
Headset microphone,
omni-directional
Headset microphone,
omni-directional
Art. no. 502167
Art. no. 004736
Art. no. 003579
Art. no. 009862
Art. no. 009864
Art. no. 506905
Art. no. 508251
Art. no. 508252
Art. no. 508247
Art. no. 508248
