Sennheiser GSX 1000 User Manual
GSX 1000
Headset Amplifier
User Guide
Bedienungsanleitung
Notice d’emploi
Istruzioni per l'uso
Instrucciones de uso
Manual de instruções
Bedieningsinstructies
Οδηγίες λειτουργίας
Betjeningsvejledning
Bruksanvisning
Käyttöohje
Instrukcja obsługi
Инструкция по
эксплуатации
使用说明书
使用說明書
Kullanım kılavuzu
取扱説明書
Buku petunjuk
사용 설명서
Chapter overview
Scope of
delivery
Lieferumfang | Contenu | Dotazione | Volumen de suministro |
Material fornecido | Omvang van de levering | Συσκευασία
παράδοσης | Leveringsomfang | Medföljande delar |
Toimitussisältö | Zakres dostawy | Комплект поставки |
供货范围 | 供貨範圍 | Teslimat kapsamı | 同梱品 |
Isi kemasan | 구성품
Product
overview
Produktübersicht | Vue d’ensemble de l’appareil |
Panoramica del prodotto | Vista general del producto |
Vista geral do produto | Productoverzicht |
Συνοπτική παρουσίαση προϊόντος | Produktoversigt |
Produktöversikt | Tuotteen yleiskatsaus | Przegląd produktów |
Общий вид изделия | 产品总览 | 產品各部件簡介 |
Ürüne Genel Bakış | 製品概要 | Ikhtisar Produk | 제품 개요
Connecting the
product
Produkt anschließen | Raccordement de l’appareil |
Collegamento del prodotto | Conectar el producto |
Ligar o produto | Product aansluiten | Σύνδεση προϊόντος |
Tilslutning af produktet | Anslut produkten | Liitä tuote |
Podłączanie produktu | Подключение изделия |
连接产品 | 連接產品 | Ürünün bağlanması | 製品の接続 |
Menyambungkan produk | 제품 연결
Installing the
product
Produkt installieren | Installation de l’appareil |
Installazione del prodotto | Instalar el producto |
Instalar o produto | Product installeren |
Εγκατάσταση προϊόντος | Installation af produktet |
Installera produkten | Asenna tuote| Instalowanie produktu |
Установка изделия | 安装产品 | 安裝產品 | Ürünün kurulumu |
製品 のインストール | Menginstal produk | 제품 설치
Changing
settings
Einstellungen ändern | Modification des paramètres | Modifica delle impostazioni | Modificar los ajustes |
Alterar definições| Instellingen wijzigen | Αλλαγή ρυθμίσεων | Ændring af indstillinger | Ändra
inställningarna | Muuta asetuksia | Zmiana ustawień | Изменение настроек | 更改设置 | 變更設定 |
Ayarların değiştirilmesi |設定の変更| Mengubah pengaturan | 설정 변경
Saving & loading
settings
Einstellungen speichern & laden | Sauvegarde et chargement des paramètres |
Memorizzazione e caricamento delle impostazioni | Guardar & cargar ajustes |
Guardar e carregar definições | Instellingen opslaan & laden | Αποθήκευση και φόρτωση ρυθμίσεων |
Lagring og indlæsning af indstillinger | Spara & hämta inställningar | Tallenna ja lataa asetukset |
Zapisywanie i ładowanie ustawień | Сохранение и загрузка настроек | 保存并加载设置 |
儲存並載入設定 | Ayarların kaydedilmesi ve yüklenmesi |設定の保存と呼び出し|
Menyimpan & memuat pengaturan | 설정 저장 & 불러오기
Using the
Tournament Mode
Turnier-Modus verwenden | Utilisation du mode tournois | Utilizzo della modalità Torneo |
Usar en modo torneo | Utilizar o Modo de Torneio | De toernooimodus gebruiken |
Χρήση της λειτουργίας Τουρνουά | Brug af turneringsmodus | Använda turneringsläget |
Turnaustilan käyttö | Używanie trybu turniejowego | Использование режима турнира |
使用巡回赛模式 | 使用競賽模式 | Turnuva Modunu kullanma |トーナメントモードの使用|
Menggunakan Mode Turnamen | 토너먼트 모드 사용
Cleaning the product /
Restoring factory settings
Produkt reinigen / Auf Werkseinstellungen zurücksetzen | Nettoyage de l’appareil / Réinitialisation des
paramètres d’usine | Pulizia del prodotto / Ripristino delle impostazioni di fabbrica |
Limpiar el producto / Restablecer los ajustes de fábrica | Limpar o produto / Repor as definições de
fábrica | Product reinigen / Resetten op fabrieksinstellingen |
Καθαρισμός προϊόντος / Επαναφορά εργοστασιακών ρυθμίσεων |
Rengøring af produktet / Tilbagestilling til fabriksindstillinger |
Rengör produkten / Återställ till fabriksinställningarna | Puhdista tuote / Palauta tehdasasetukset |
Czyszczenie produktu / Przywracanie ustawień domyślnych |
Очистка изделия / Сброс на заводские настройки |
清洁产品 / 恢复出厂设置 | 清潔產品 / 恢復出廠預設值 |
Ürünün temizlenmesi / Varsayılan fabrika ayarlarının geri yüklenmesi |
製品のお手入れ/工場出荷時の初期設定にリセットする |
Membersihkan produk / Mengatur ulang pengaturan default pabrik |
제품 청소 / 공장 설정값으로 리셋하기
Congratulations on your purchase of the Sennheiser
GSX 1000. Sennheiser has been a pioneer in the audio
industry since 1945, and we continue to innovate and
discover new frontiers in sound. The GSX 1000 is the latest
milestone in this journey, pushing the limits of immersive
audio in gaming, while also giving you control to get the
exact sound experience you demand.
The Sennheiser Virtual Surround algorithm is the result of
8 years of research into advanced HRTF algorithms and
countless man hours to create something that we consider
the best virtual surround sound on the market today.
It doesn’t matter if your goal is to become more immersed
in online worlds, or get a crucial advantage in a first person
shooter, the GSX 1000 will deliver the ultimate sound
experience for gaming.
And while the GSX 1000 is very simple to setup and there
are no driver installations needed, we still recommend you
take a bit of time to read through this manual to
understand the full power of the product you have just
acquired.
Sennheiser Gaming
The Sound Games
Are Made Of!
Chapter overview | Kapitelübersicht | Sommaire |
Panoramica dei capitoli | Vista general de capítulos | Visão geral dos capítulos |
Overzicht hoofdstukken | Επισκόπηση κεφαλαίων | Kapiteloversigt |
Innehållsförteckning | Kappaleen yleiskuvaus | Przegląd rozdziałów |
Оглавление | 章节概览 | 章節概覽 | Bölümlere genel bakış |
目次 | Ikhtisar Bab | 장 개요
1
Scope of
1
delivery
back side
right side
Quick
Guide
Safety
Guide
Scope of delivery | Lieferumfang | Contenu |
Dotazione | Volumen de suministro | Material fornecido |
Omvang van de levering | Συσκευασία παράδοσης | Leveringsomfang |
Medföljande delar | Toimitussisältö | Zakres dostawy |
Комплект поставки |
同梱品 | Isi kemasan | 구성품
供货范围 | 供貨範圍 | Teslimat kapsamı |
left side
2
Product
2
overview
Volume wheel
Save settings & load presets
Display & Touch control panel
Volume 0–99
Switch between sound systems:
Headset or Speaker
Equalizer settings:
Off, Music, Story or Esports
Surround Amplification:
Front, Back or Neutral
Sound Mode:
Stereo or 7.1 Surround Sound
Sidetone Level:
++ High, + Low or Neutral
Reverb (Evnironment):
++ Open World,
+ Confined Space or Neutral
Micro USB socket
3.5 mm Line Out socket
Microphone socket
Headphone socket
Volume wheel chat
Product overview | Produktübersicht | Vue d’ensemble de l’appareil |
Panoramica del prodotto | Vista general del producto | Vista geral do produto |
Productoverzicht | Συνοπτική παρουσίαση προϊόντος | Produktoversigt |
Produktöversikt | Tuotteen yleiskatsaus | Przegląd produktów |
Общий вид изделия |
製品概要 | Ikhtisar Produk | 제품 개요
产品总览 | 產品各部件簡介 | Ürüne Genel Bakış |
3
Connecting the
3
product
Connect to a computer
Connect a headset
2s dims
Connecting to a headset & a computer | Headset & Computer anschließen | Connexion du casque micro et de l’ordinateur | Collegamento dell'headset e del computer | Conectar headset & ordenador | Ligar os microauscultadores e o computador | Headset & computer aansluiten | Σύνδεση σετ κεφαλής και υπολογιστή | Tilslutning af headset og computer |
Anslut headset & dator | Liitä kuulokemikrofoni ja tietokone | Podłączanie zestawu słuchawkowego i komputera |
Подключение гарнитуры и компьютера |
ヘッドセットとＰＣの接続 | Menyambungkan headset & komputer | 헤드셋 & 컴퓨터 연결
将耳机跟电脑连接起来 | 連接頭戴式耳機與電腦 | Kulaklığın ve bilgisayarın bağlanması |
4
Connecting the
3
product
Connect loudspeakers
Audio IN
L R
Audio OUT
3.5 mm jack plug
Cable & speakers not included
Connecting to loudspeakers | Lautspecher anschließen | Connexion des haut-parleurs | Collegamento degli altoparlanti | Conectar altavoces | Ligar as colunas | Luidsprekers aansluiten | Σύνδεση ηχείου | Tilslutning af højttaleren |
Anslut högtalare | Liitä kaiuttimet | Podłączanie głośników |
Подключение динамиков |
スピーカーの接続| Menyambungkan loudspeaker | 스피커 연결
连接扬声器 | 連接揚聲器 | Hoparlörün bağlanması |
5
Installing the
4
product
Change audio settings: PC
1. Right-click the Audio icon.
2. Select “Playback devices”.
Changing the sound settings on a PC | Audioeinstellungen am PC anpassen | Réglage des paramètres audio du PC | Adattamento delle impostazioni audio sul PC | Ajustar los ajustes de audio en el PC | Ajustar as definições de áudio no PC | Audio-instellingen op de pc aanpassen | Προσαρμογή των ρυθμίσεων ήχου σε PC | Tilpasning af audioindstillinger på en pc |
Justera ljudinställningarna på datorn | Säädä tietokoneen audioasetukset | Dostosowywanie ustawień audio na komputerze PC |
Адаптация настроек звука на ПК |
オーディオ設定のＰＣでの変更| Menyesuaikan pengaturan audio pada PC | PC에서 오디오-설정 조정
调整电脑的音频设置 | 調整電腦的音訊設定 | Bilgisayarda ses ayarlarının uyarlanması |
3. Select “Speakers”
“GSX ... Main Audio”.
4. Select “Default Device”.
6
Installing the
4
product
5. Select “Headset Earphone”
“GSX ... Communication Audio”.
6. Select
“Default Communication Device”.
Changing the sound settings on a PC | Audioeinstellungen am PC anpassen | Réglage des paramètres audio du PC |
Adattamento delle impostazioni audio sul PC | Ajustar los ajustes de audio en el PC | Ajustar as definições de áudio no PC |
Audio-instellingen op de pc aanpassen | Προσαρμογή των ρυθμίσεων ήχου σε PC | Tilpasning af audioindstillinger på en pc |
Justera ljudinställningarna på datorn | Säädä tietokoneen audioasetukset | Dostosowywanie ustawień audio na komputerze PC |
Адаптация настроек звука на ПК |
オーディオ設定のＰＣでの変更| Menyesuaikan pengaturan audio pada PC | PC에서 오디오-설정 조정
调整电脑的音频设置 | 調整電腦的音訊設定 | Bilgisayarda ses ayarlarının uyarlanması |
7. Select tab “Recording”.
8. Select “GSX ... Communication Audio”.
7
Installing the
4
product
7.1 surround sound
9. Select “Default Device”.
10. Select tab “Communications”.
11. Select “Do nothing”.
Changing the sound settings on a PC | Audioeinstellungen am PC anpassen | Réglage des paramètres audio du PC |
Adattamento delle impostazioni audio sul PC | Ajustar los ajustes de audio en el PC | Ajustar as definições de áudio no PC |
Audio-instellingen op de pc aanpassen | Προσαρμογή των ρυθμίσεων ήχου σε PC | Tilpasning af audioindstillinger på en pc |
Justera ljudinställningarna på datorn | Säädä tietokoneen audioasetukset | Dostosowywanie ustawień audio na komputerze PC |
Адаптация настроек звука на ПК |
オーディオ設定のＰＣでの変更| Menyesuaikan pengaturan audio pada PC | PC에서 오디오-설정 조정
调整电脑的音频设置 | 調整電腦的音訊設定 | Bilgisayarda ses ayarlarının uyarlanması |
12. Select tab “Playback”.
13. Select Speakers “GSX ... Main Audio”.
14. Click “Configure”.
8
Installing the
4
product
15. Select “7.1 Surround” and click “Next”.
16. Make sure all options are
activated and click “Next”.
Changing the sound settings on a PC | Audioeinstellungen am PC anpassen | Réglage des paramètres audio du PC |
Adattamento delle impostazioni audio sul PC | Ajustar los ajustes de audio en el PC | Ajustar as definições de áudio no PC |
Audio-instellingen op de pc aanpassen | Προσαρμογή των ρυθμίσεων ήχου σε PC | Tilpasning af audioindstillinger på en pc |
Justera ljudinställningarna på datorn | Säädä tietokoneen audioasetukset | Dostosowywanie ustawień audio na komputerze PC |
Адаптация настроек звука на ПК |
オーディオ設定のＰＣでの変更| Menyesuaikan pengaturan audio pada PC | PC에서 오디오-설정 조정
For specific information and
Firmware update please visit
www.sennheiser.com/gaming-downloads
调整电脑的音频设置 | 調整電腦的音訊設定 | Bilgisayarda ses ayarlarının uyarlanması |
17. Activate all options and
click “Next” to close “Speaker Setup”.
18. Click “OK” to save settings and close the window.
9
