Sennheiser EM 100 User Manual

EM 100

Instruction manual

Contents

Important safety instructions .................................................................................................................. 2

The EM 100 G3 stationary receiver ......................................................................................................... 4

Areas of application ............................................................................................................................... 4

The frequency bank system ................................................................................................................. 5

Delivery includes .......................................................................................................................................... 7

Product overview ......................................................................................................................................... 8

Overview of the EM 100 G3 receiver .................................................................................................. 8

Overview of the displays ...................................................................................................................... 9

Putting the receiver into operation ...................................................................................................... 11

Preparing the receiver for use ........................................................................................................... 11

Connecting an amplifier/mixing console ......................................................................................... 17

Connecting the mains unit ................................................................................................................. 18

Using the receiver ...................................................................................................................................... 19

Switching the receiver on/off ............................................................................................................ 19

Synchronizing a transmitter with the receiver .............................................................................. 20

Deactivating the lock mode temporarily ......................................................................................... 22

Muting the audio signal ...................................................................................................................... 23

Selecting a standard display .............................................................................................................. 24

Using the operating menu ...................................................................................................................... 25

The buttons ........................................................................................................................................... 25

Overview of the operating menu ...................................................................................................... 26

Working with the operating menu ................................................................................................... 28

Adjustment tips and functions .............................................................................................................. 30

Standard displays with additional functions ................................................................................. 30

The main menu “Menu” ...................................................................................................................... 33

The extended menu “Advanced Menu” .......................................................................................... 38

Synchronizing transmitters with receivers ......................................................................................... 42

Synchronizing a transmitter with the receiver – individual operation ..................................... 42

Synchronizing transmitters with receivers – multi-channel operation .................................... 43

Cleaning the receiver ................................................................................................................................ 45

Recommendations and tips .................................................................................................................... 46

If a problem occurs ... ................................................................................................................................ 47

Accessories and spare parts .................................................................................................................... 49

Specifications ............................................................................................................................................. 51

Manufacturer Declarations ..................................................................................................................... 54

Index ............................................................................................................................................................. 56

An animated instruction manual can be viewed on the EM 100 G3 product page on our website at www.sennheiser.com.

Important safety instructions

• Read this instruction manual.

• Keep this instruction manual. Always include this instruction manual when passing the product on to third parties.

• Heed all warnings and follow all instructions in this instruction manual.

• Only clean the product when it is not connected to the mains. Use a cloth for cleaning.

• Refer all servicing to qualified service personnel. Servicing is required if the product has been damaged in any way, liquid has been spilled, objects have fallen inside, the product has been exposed to rain or moisture, does not operate properly or has been dropped.

• WARNING: To reduce the risk of short circuits, do not use the product near water and do not expose it to rain or moisture. Do not place objects filled with liquids, such as vases or coffee cups, on the product.

• Only use the supplied mains unit.

• Unplug the mains unit from the wall socket – to completely disconnect the product from the mains, – during lightning storms or – when unused for long periods of time.

• Only operate the mains unit from the type of power source specified in the chapter “Specifications” (see page 51).

• Ensure that the mains unit is – in a safe operating condition and easily accessible, – properly plugged into the wall socket, – only operated within the permissible temperature range, – not covered or exposed to direct sunlight for longer periods of time

in order to prevent heat accumulation (see “Specifications” on page 51).

• Do not block any ventilation openings. Install the product in accordance with the instructions given in this instruction manual.

• Do not install the product near any heat sources such as radiators, stoves, or other devices (including amplifiers) that produce heat.

• Only use attachments/accessories specified by Sennheiser.

Important safety instructions

Overloading

Do not overload wall outlets and extension cables as this may result in fire and electric shock.

Replacement parts

When replacement parts are required, be sure the service technician uses replacement parts specified by Sennheiser or those having the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

Danger due to high volumes

This product is capable of producing sound pressure exceeding 85 dB(A). 85 dB(A) is the sound pressure corresponding to the maximum permissible volume which is by law (in some countries) allowed to affect your hearing for the duration of a working day. It is used as a basis according to the specifications of industrial medicine. Higher volumes or longer durations can damage your hearing. At higher volumes, the duration must be shortened in order to prevent hearing damage. The following are sure signs that you have been subjected to excessive noise for too long a time:

• You can hear ringing or whistling sounds in your ears.

• You have the impression (even for a short time only) that you can no

longer hear high notes.

Intended use

Intended use of the ew 100 G3 series products includes:

• having read these instructions especially the chapter “Important

safety instructions”,

• using the products within the operating conditions and limitations

described in this instruction manual.

“Improper use” means using the products other than as described in this instruction manual, or under operating conditions which differ from those described herein.

The EM 100 G3 stationary receiver

533.875

ew100 G3

20.12

MUTE

MHz

SET

PEAK

-10

040

-20

-40 AF

-30

The EM 100 G3 stationary receiver

This receiver is part of the evolution wireless series generation 3 (ew G3). With this series, Sennheiser offers high-quality state-of-the-art RF transmission systems with a high level of operational reliability and ease of use. Transmitters and receivers permit wireless transmission with studioquality sound.

Features of the evolution wireless 100 G3 series:

• Optimized PLL synthesizer and microprocessor technology

• HDX noise reduction system

• Pilot tone squelch control

• True diversity technology

• Switching bandwidth of 42 MHz

• Scan function (Easy Setup) for scanning the frequency banks for unused channels

Areas of application

The receiver can be combined with the following optional components of the ew G3 series (see “Accessories and spare parts” on page 49):

Receiver Transmitters Combinable with

EM 100 G3 SK 100 G3 • Clip-on microphones:

ME 2, ME 4

•Headmic: ME 3

• Instrument cable: CI 1

SKM 100 G3 Interchangeable microphone heads:

• MMD 835-1, MMD 845-1

• MME 865-1

The EM 100 G3 stationary receiver

Frequency bank 1... 20

Frequency bank U

Channel 12 – frequency preset

Channel 1 – frequency preset

Channel 2 – frequency preset

Channel 12 – freely selectable frequency

Channel 1 – freely selectable frequency

Channel 2 – freely selectable frequency

The devices are available in the same UHF frequency ranges and are equipped with the same frequency bank system with factory-preset frequencies. An advantage of the factory-preset frequencies is that

• a transmission system is ready for immediate use after switch-on,

• several transmission systems can be operated simultaneously on the preset frequencies without causing intermodulation interference.

The frequency bank system

The receiver is available in 6 UHF frequency ranges with 1,680 frequencies per frequency range:

Range Range Range Range Range Range

516 – 558 566 – 608 626 – 668 734 – 776 780 – 822 823 – 865

Each frequency range (A–E, G) offers 21 frequency banks with up to 12 channels each:

The EM 100 G3 stationary receiver

Each of the channels in the frequency banks “1” to “20” has been factorypreset to a fixed frequency (frequency preset).

The factory-preset frequencies within one frequency bank are intermodulation-free. These frequencies cannot be changed.

For an overview of the frequency presets, please refer to the supplied frequency information sheet. Updated versions of the frequency information sheet can be downloaded from the EM 100 G3 product page on our website at www.sennheiser.com.

The frequency bank “U” allows you to freely select and store frequencies. It might be that these frequencies are not intermodulation-free (see page 44).

Delivery includes

The packaging contains the following items:

1 EM 100 G3 stationary receiver

1 NT 2-3 or NT 2-1 mains unit with one country adapter

2rod antennas

2 stacking elements

1 instruction manual

1 frequency information sheet

4 device feet

Delivery includes

Product overview

533.875

ew100 G3

20.12 MHz

XXXXXXX

0682

쐋



 





SET

PEAK

-10

25 10

-20

-30 AF

Product overview

Overview of the EM 100 G3 receiver

Operating elements – front panel Operating elements – rear panel

 button  Infra-red interface  Display panel, backlit in orange  SET button  UP/DOWN button  STANDBY button;

ESC function (cancel)

 Cable grip for power supply DC cable  DC socket (DC IN) for connection of

NT 2 mains unit

 Audio output (AF OUT BAL),

XLR-3M socket, balanced

 Audio output (AF OUT UNBAL),

¼” (6.3 mm) jack socket, unbalanced

 Service interface (DATA)  Service interface (DATA)  Antenna input II (ANT II) with remote

power supply input, BNC socket

 Type plate  Antenna input I (ANT I) with remote

power supply input, BNC socket

Product overview

533.875

ew100 G3

20.12

MUTE

MHz

PEAK

-10

25 10

-20

-30 AF





 햴

Diversity display:

Antenna input I is active

Antenna input II is active

RF signal level: Field strength of the received signal

Squelch threshold level

Modulation of the transmitter with peak hold function

When the display for audio level shows full deflection, the audio level is excessively high. When the transmitter is overmodulated frequently or for extended periods of time, the “PEAK” display is shown inverted.

Overview of the displays

After switch-on, the receiver displays the standard display “Receiver

Parameters”. For further illustrations and examples of the different stan-

dard displays, please refer to page 24. This standard display displays the operating states of the receiver.

Display Meaning

 RF level “RF”

(Radio Frequency)

25 10

 Audio level “AF”

 Frequency bank

 Frequency

 Name

(Audio Frequency, see page 36)

and channel (see page 35)

(see page 35)

(see page 36)

PEAK

-10

-20

-30 AF

Current frequency bank and channel number

Current receiving frequency

Freely selectable name of the receiver

Product overview

approx. 100% approx. 70% approx. 30%

icon is flashing; charge status is critical

Display Meaning

 Pilot tone “P”

(see page 40)

 Muting function

“MUTE” (see page 23)

 Battery status of

the transmitter

Activated pilot tone evaluation

Audio signal is muted (see also page 47)

Charge status:

 Lock mode icon

(see page 37)

Lock mode is activated

Putting the receiver into operation

Preparing the receiver for use

Recommendations for optimum reception

To ensure optimum reception even under difficult conditions, we recommend connecting remote antennas and, if necessary, using antenna splitters (see “Accessories and spare parts” on page 49).

When rack-mounting the receiver, you can mount the supplied antennas to the front of the rack by using an antenna front mount kit. When mounting more than one receiver into a rack, you should use remote antennas.

If you want to mount the receiver into a 19” rack:

왘 Read the corresponding chapter on page 13.

If you want to set up the receiver on a flat surface:

왘 Read the next chapter.

Setting up the receiver on a flat surface

CAUTION! Risk of staining of furniture surfaces!

Some furniture surfaces have been treated with varnish, polish or synthetics which might cause stains when they come into contact with other synthetics. Despite a thorough testing of the synthetics used by us, we cannot rule out the possibility of staining.

왘 Do not place the receiver on delicate surfaces.

Fastening the

stacking elements

The stacking elements are designed to help protect the operating elements from damage or deformation, e.g. if the receiver is dropped. Therefore, fasten the stacking elements, even if you do not want to stack your receivers.

Putting the receiver into operation



To fasten the stacking elements :

왘 Unscrew and remove the two recessed head screws (M4x8) on each

side of the receiver (see left-hand diagram).

왘 Secure the stacking elements  to the sides of the receiver using the

previously removed recessed head screws (see right-hand diagram).

Fitting the

device feet

If you want to stack receivers (see next section), only fit the device feet to the base of the lowermost receiver.

Do not fit the device feet when mounting the receiver into a 19” rack.

왘 Clean the base of the receiver where you want to fix the device feet.

왘 Fit the device feet to the four corners of the receiver as shown.

왘 Place the receiver on a flat, horizontal surface.

Stacking receivers You can stack several receivers on top of each other.

CAUTION! Danger of injury due to toppling receiver stacks!

High receiver stacks can easily topple over.

왘 Place the stack on an absolutely flat surface.

왘 Secure the stack against toppling over.

왘 Fasten the stacking elements as described in the previous section.

왘 Stack the receivers so that the recesses of the stacking elements

completely engage with each other.

Putting the receiver into operation

Connecting the

rod antennas

The supplied rod antennas  can be mounted quickly and easily and are suitable for all applications where – good reception conditions provided – a wireless transmission system is to be used without a large amount of installation work.

왘 Connect the two rod antennas  to the BNC sockets  and  at the

rear of the receiver.



XXX - XXX MHzFREQ. RANGE- X :

TRUE DIVERSITY RECEIVER EM 100

IDENT. NO.: XXXXXX SER. NO.: XXXXXXXXXX IC: 2099A- XXXXXXX

0682

DESIGNED IN GERMANY, ASSEMBLED IN USA

XXX - XXX MHzFREQ. RANGE-

TRUE DIVERSITY RECEIVER EM 100

IDENT. NO.: XXXXXX

XXXX

SER. NO.: XXXXXXXXXX IC: 2099A- XXX

0682

DESIGNED IN GERMANY, ASSEMBLED IN USA





왘 Align the rod antennas upwards in a V-shape.

When using more than one receiver, we recommend connecting remote antennas and, if necessary, using Sennheiser antenna accessories. Fore more information, visit the ew G3 product page at www.sennheiser.com.

Mounting the receiver into a 19” rack

Do not mount the stacking elements and do not fit the rubber feet when mounting the receiver into a 19” rack.

Putting the receiver into operation

CAUTION! Risks when rack mounting the receiver!

When installing the device in a closed or multi-rack assembly, please consider that, during operation, the ambient temperature, the mechanical loading and the electrical potentials will be different from those of devices which are not mounted into a rack.

왘 Make sure that the ambient temperature within the rack does not

exceed the permissible temperature limit specified in the specifications (see page 51).

왘 Ensure sufficient ventilation; if necessary, provide additional ventila-

tion.

왘 Make sure that the mechanical loading of the rack is even. 왘 When connecting to the power supply, observe the information indi-

cated on the type plate. Avoid circuit overloading. If necessary, provide overcurrent protection.

왘 When rack mounting, please note that intrinsically harmless leakage

currents of the individual mains units may accumulate, thereby exceeding the allowable limit value. As a remedy, ground the rack via an additional ground connection.

Rack mounting

one receiver

To mount the receiver into a rack, you require the GA 3 rack adapter (see “Accessories and spare parts” on page 49):

왘 Secure the rack mount “ears”  of the GA 3 rack adapter to the

receiver in the same way as described for the stacking elements (see page 11).

왘 Secure the blanking plate of the GA 3 rack adapter to one of the rack

mount “ears”  using two recessed head screws (M 6x10).



Putting the receiver into operation





왘 Connect the antennas. You have the following options:

– You can connect the supplied rod antennas  to the rear of the

receiver (see page 13). In this case, insert the two blanking plugs into the holes of the blanking plate.

– You can use the AM 2 antenna front mount kit (see “Accessories

and spare parts” on page 49) and mount the rod antennas to the blanking plate .

Rack mounting

two receivers

To mount the receiver into a 19” rack:

왘 Slide the receiver with the mounted blanking plate into the 19” rack.

왘 Secure the rack mount “ears”  to the 19” rack.

If you are using the supplied rod antennas:

왘 Align the antennas in a V-shape to obtain the best possible reception.

When rack mounting two receivers side by side, you can only front mount the antennas when using the ASA 1 antenna splitter in conjunction with the AM 2 antenna front mount kit and an additional GA 3 rack adapter (see “Accessories and spare parts” on page 49).

We recommend using remote antennas.

Putting the receiver into operation

To mount the receivers into a rack using the GA 3 rack adapter:

왘 Place the two receivers side by side upside-down onto a flat surface.

왘 Secure the jointing plate to the receivers using six recessed head

screws (M 3x6).

The rack mount “ears” are mounted instead of the stacking elements:

왘 Secure the rack mount “ears” to the receivers in the same way as

described for the stacking elements (see page 11).

To mount the antennas:

왘 Use remote antennas, if necessary in conjunction with the ASA 1

antenna splitter (see “Accessories and spare parts” on page 49).

To mount the receivers into the rack:

왘 Slide the receivers into the 19” rack.

왘 Secure the rack mount “ears” to the 19” rack.

Putting the receiver into operation

Connecting an amplifier/mixing console

The receiver’s ¼” (6.3 mm) jack socket  and XLR-3M socket  are connected in parallel, allowing you to simultaneously connect two devices (e.g. amplifier, mixing console) to the receiver.

왘 Use a suitable cable to connect the amplifier/mixing console to the

¼” (6.3 mm) jack socket  or the XLR-3M socket .

For detailed information on balanced and unbalanced connection, please refer to the chapter “Connector assignment” on page 53.

+ 41 hidden pages
