MRD 5800
Advanced Modular Receiver
User Manual
September 2016
8089Q www.sencore.com | 1.605.978.4600 Revision 1.18
MRD 5800 – User Manual
Copyright
© 2016 Sencore, Inc. All rights reserved.
3200 Sencore Drive, Sioux Falls, SD USA
www.sencore.com
This publication contains confidential, proprietary, and trade secret information. No part of this document
may be copied, photocopied, reproduced, translated, or reduced to any machine-readable or electronic
format without prior written permission from Sencore. Information in this document is subject to change
without notice and Sencore Inc. assumes no responsibility or liability for any errors or inaccuracies.
Sencore, Sencore Inc, and the Sencore logo are trademarks or registered trademarks in the United States
and other countries. All other products or services mentioned in this document are identified by the
trademarks, service marks, or product names as designated by the companies who market those products.
Inquiries should be made directly to those companies. This document may also have links to third-party web
pages that are beyond the control of Sencore. The presence of such links does not imply that Sencore
endorses or recommends the content on those pages. Sencore acknowledges the use of third-party open
source software and licenses in some Sencore products. This freely available source code can be obtained
by contacting Sencore Inc.
About Sencore
Sencore is an engineering leader in the development of high-quality signal transmission solutions for the
broadcast, cable, satellite, IPTV, telecommunications, and professional audio/video markets. The
company’s world-class portfolio includes video delivery products, system monitor ing and a naly si s solut ion s,
and test and measurement equipment, all designed to support system interoperability and backed by bestin-class customer support. Sencore meets the rapidly changing needs of modern media by ensuring the
efficient delivery of high-quality video from the source to the home. For more information, visit
www.sencore.com.
Page 2 (116)
Revision History
Date
Version
Description
Author
10/31/2012
0.1
First Draft
ACD
02/04/2013
1.0
Initial Release
ACD
04/18/2013
1.1
Specification Edits and GUI Changes
ACD
06/19/2013
1.2
Specifications Edits
GAK
06/20/2013
1.3
Edit & Updates for ver. 1.1.2 Release
GJL
07/10/2013
1.4
Edits
GJL
08/30/2013
1.5
Update for ver. 1.2.0 Release
NGJ
11/21/2013
1.6
Update for ver. 1.3.0 Release
NGJ
12/16/2013
1.7
Update noise figure
TLD
02/28/2014
1.8
Update for ver. 1.4.0 Release
CDP
05/07/2014
1.9
Update for ver. 2.0.0 Release
CDP
06/17/2014
1.10
Update for ver. 2.0.2 Release
CDP
09/18/2014
1.11
Update for ver. 2.1.0 Release
CDP
10/31/2014
1.12
Update for ver. 2.2.0 Release
CDP
02/05/2014
1.13
Update for ver. 2.2.2 Release
JDF
3/9/2015
1.14
Update for ver. 2.3.0 Release
CDP
7/8/2015
1.15
Update for ver. 2.4.0 Release
CDP
10/21/2015
1.16
Update for ver. 2.5.0 Release
CDP
2/24/2016
1.17
Update for ver. 3.0.0 Release
CDP
6/6/2016
1.18
Update for ver. 3.1.0 Release
CDP
9/23/2016
1.19
Update for ver. 3.2.0 Release
CDP
MRD 5800 – User Manual
Page 3 (116)
MRD 5800 – User Manual
Safety Instructions
• Read these instructions
• Keep these instructions
• Heed all warnings
• Follow all instructions
• Do not use this apparatus near water
• Clean only with dry cloth
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat
• Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long periods of
time.
• Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
• Do not expose this apparatus to dripping or splashing and ensure that no objects
filled with liquids, such as vases, are placed on the apparatus.
• To completely disconnect this apparatus from the AC Mains, disconnect the
power supply cord plug from the AC receptacle.
• The mains plug of the power supply cord shall remain readily operable.
• Damage Requiring Service: Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
o When the power-supply cord or plug is damaged.
o If liquid has been spilled, or objects have fallen into the product.
o If the product has been exposed to rain or water.
o If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of the controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation.
o If the product has been dropped or damaged in any way.
o The product exhibits a distinct change in performance.
• Replacement Parts: When replacement parts are required, be sure the service
technician uses replacement parts specified by Sencore, or parts having the
same operating characteristics as the original parts. Unauthorized part
substitutions made may result in fire, electric shock or other hazards.
Page 4 (116)
MRD 5800 – User Manual
SAFETY PRECAUTIONS
There is always a danger present when using electronic equipment.
Unexpected high voltages can be present at unusual locations in defective
equipment and signal distribution systems. Become familiar with the equipment
that you are working with and observe the following safety precautions.
• Every precaution has been taken in the design of your MRD 5800 to ensure that
it is as safe as possible. However, safe operation depends on you the operator.
• Always be sure your equipment is in good working order. Ensure that all points
of connection are secure to the chassis and that protective covers are in place
and secured with fasteners.
• Never work alone when working in hazardous conditions. Always have another
person close by in case of an accident.
• Always refer to the manual for safe operation. If you have a question about the
application or operation call Sencore for assistance.
• WARNING – To reduce the risk of fire or electrical shock never allow your
equipment to be exposed to water, rain or high moisture environments. If
exposed to a liquid, remove power safely (at the breaker) and send your
equipment to be serviced by a qualified technician.
• To reduce the risk of shock the MRD 5800 must be connected to a mains sock et
outlet with a protective earthing connection.
• For the MRD 5800 the mains plug is the main disconnect and should remain
readily accessible and operable at all times.
The MRD 5800 is equipped with an internal system battery. The MRD 5800
must be sent to Sencore service for replacement of this battery.
• When installing the MRD 5800 utilizing the DC power supply, the power supply
MUST be used in conjunction with an over-current protective device rated at 50
V, 5 A, type: Slow-blo, as part of battery-supply circuit.
• To reduce the risk of shock and damage to equipment, it is recommended that
the chassis grounding screw located on the rear of the MRD 5800 – be
connected to the installation’s rack, the vehicle’s chassis, t he battery’s negative
terminal, and/or earth ground.
CAUTION – Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type.
Page 5 (116)
MRD 5800 – User Manual
FCC Class A Information
The MRD 5800 has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instr uctions, may
cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his or her own expense.
Shielded cables must be used with this unit to ensure compliance with the Class A FCC
limits.
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
Dolby Digital Information
This product has been manufactured under license from Dolby Laboratories.
“Dolby Digital”, “AC-3”, and “Dolby Digital Plus” are licensed trademarks of Dolby
Laboratories.
Page 6 (116)
MRD 5800 – User Manual
Package Contents
The following is a list of the items that are included along with the MRD 5800:
1. Documentation CD
2. Declaration of Conformity
3. Quick Start Guide
4. AC Power Cable
Note: If any option cables were ordered with the MRD 5800, they will be included in the
box as well.
If any of these items were omitted from the packaging of the MRD 5800 please call 1800-SENCORE to obtain a replacement.
1) Documentation CD
4) AC Power Cable
2) Declaration of
Conformity
3) Quick Start Guide
Page 7 (116)
MRD 5800 – User Manual
Table of Contents
Section 1 Overview ........................................................................................... 10
1.1 Product Introduction ................................................................................................... 11
1.2 Front Panel Overview ................................................................................................ 11
1.3 Rear Panel Overview ................................................................................................. 11
1.4 Cooling ....................................................................................................................... 12
1.5 Rack Information ........................................................................................................ 12
Section 2 Installation ........................................................................................ 13
2.1 Rack Installation ........................................................................................................ 14
2.2 Power Connection ..................................................................................................... 14
2.3 AC Power Connection ............................................................................................... 14
2.4 AC Dual Redundant Power Connection (optional) .................................................... 15
2.5 DC Power Connection ............................................................................................... 15
2.6 Maintenance .............................................................................................................. 15
2.7 Network Setup via Front Panel .................................................................................. 15
Section 3 Operating the Front Panel ............................................................... 18
3.1 MRD 5800 Front Panel Overview .............................................................................. 19
Section 4 Operating the Web Interface ........................................................... 20
4.1 MRD 5800 Web Interface Overview .......................................................................... 21
4.1.1 Logging into the MRD 5800 Web Interface .......................................................... 21
4.1.2 Hiding Unused Inputs ........................................................................................... 21
4.1.3 Buttons and Status Indicators............................................................................... 21
4.1.4 Drag and Drop Menus .......................................................................................... 22
4.2 Main Panel ................................................................................................................. 22
4.2.1 Configuring Active Inputs ...................................................................................... 23
4.2.2 Configuring ASI Input ........................................................................................... 25
4.2.3 Configuring MPEG/IP Input .................................................................................. 26
4.2.4 Configuring DVB-S/S2 Input ................................................................................. 29
4.2.5 Configuring 8VSB/QAM Input ............................................................................... 31
4.2.6 Configuring Turbo PSK Input ............................................................................... 32
4.2.7 Configuring DVB-T2/C2/ISDB-T Input .................................................................. 33
4.2.8 Configuring DVB-CI Descrambling ....................................................................... 35
4.2.9 Configuring BISS Descram bli ng ........................................................................... 37
4.2.10 Configuring Service Se lection .............................................................................. 39
4.2.11 Configuring Video Services .................................................................................. 43
4.2.12 Configuring Secondary Video Services ................................................................ 45
4.2.13 Configuring Audio ................................................................................................. 47
4.2.14 Configuring Genlock ............................................................................................. 48
4.2.15 SCTE35 ................................................................................................................ 49
4.2.16 ESAM .................................................................................................................... 53
4.2.17 Configuring Ancil lar y Data O ptio ns ...................................................................... 55
4.2.18 Configuring SDI Outputs Port 1 & 2 ..................................................................... 55
4.2.19 Configuring SDI Audio Em bedd ing ....................................................................... 60
4.2.20 Configuring Secondary SDI Outputs .................................................................... 62
4.2.21 Configuring Secondary SDI Audio Embedding .................................................... 64
4.2.22 Configuring Composite Output ............................................................................. 66
4.2.23 Configuring Analog Aud io O utput ......................................................................... 67
4.2.24 Configuring Digita l Audio O utput .......................................................................... 68
4.2.25 PID Filter ............................................................................................................... 68
4.2.26 Configuring ASI Output ......................................................................................... 69
4.2.27 Configuring the MPEG/I P O utputs ....................................................................... 70
4.2.28 Configuring the MPEG/I P MP E Outp uts ............................................................... 72
Page 8 (116)
MRD 5800 – User Manual
4.2.29 Viewing PSIP Information ..................................................................................... 74
4.3 Admin Panel .............................................................................................................. 75
4.3.1 Changing Unit Password ...................................................................................... 76
4.3.2 Profiles .................................................................................................................. 76
4.3.3 General Settings ................................................................................................... 77
4.3.4 Unit Network Configuration................................................................................... 77
4.3.5 MPEG/IP Network Configuration .......................................................................... 78
4.3.6 Licensing............................................................................................................... 80
4.3.7 Date/Time ............................................................................................................. 80
4.3.8 Configuring SNMP ................................................................................................ 81
4.3.9 Syslog ................................................................................................................... 83
4.3.10 In-Band Control .................................................................................................... 84
4.3.11 Updating the MRD 5800 ....................................................................................... 84
4.3.12 Reboot Unit ........................................................................................................... 86
4.3.13 Reset Defaults ...................................................................................................... 86
4.4 Reporting Panel ......................................................................................................... 87
4.4.1 Active Alarms ........................................................................................................ 87
4.4.2 Event Logs ............................................................................................................ 88
4.4.3 Configuring the Logs ............................................................................................ 89
4.5 About Panel ............................................................................................................... 91
Section 5 Appendices ....................................................................................... 92
Appendix A – Acronyms and Glossary .................................................... 93
Appendix B – Error and Event List ........................................................... 96
Appendix C – Specifications ..................................................................... 99
Appendix D – Pinouts for Analog Audio and Relay Connectors ......... 108
108
Appendix E – MRD 5800 Audio Explanation ......................................... 109
Appendix F – MRD 5800 Discrete Audio Configuration ....................... 112
Appendix G – Open Source Software ..................................................... 113
Appendix H – Warranty ........................................................................... 115
Appendix I – Support and Contact Information ................................... 115
Page 9 (116)
MRD 5800 – User Manual
Section 1 Overview
Introduction
This section includes the following topics:
1.1 Product Introduction ................................................................................................... 11
1.2 Front Panel Overview ................................................................................................ 11
1.3 Rear Panel Overview ................................................................................................. 11
1.4 Cooling ....................................................................................................................... 12
1.5 Rack Information ........................................................................................................ 12
Page 10 (116)
MRD 5800 – User Manual
1
2
3
456
7
8
9
1
2
435
6
111210137
14
1.1 Product Introduction
The flagship MRD 5800 Advanced Modular Receiver continues Sencore’s long history of
leadership in the receiver/decoder space. The product boasts a full complement of
cutting-edge features, including 4:2:2 H.264 8bit/10bit decoding, up to 8 individual audio
PIDs, 16/32APSK satellite demodulation, and 1080p60 video support with 3G-SDI
output. This feature set makes the MRD 5800 the ideal choice for contribution reception
or demanding distribution applications which require a future-proof set of specifications.
Every MRD 5800 ships with a full complement of basic inputs and outputs built-in,
including ASI input and output and dual SD/HD/3G-SDI outputs. T he addition of a digital
video output means that video monitoring is as easy as finding the nearest standard
consumer television or PC monitor. In addition, available factory-configurable MPEG
over IP I/O and DVB-S2 receiver modules make adapting t he product to almost any use
case easy.
The receiver also maintains Sencore’s long tradition of ease of use, with a straightforward web interface accessible via all major browsers and complete control of the unit
via the front panel keypad, and is backed by Sencore’s best-in-class staff of ProCare
support engineers.
1.2 Front Panel Overview
The MRD 5800 can be controlled from the front panel using the LCD screen and buttons
that are shown below. A detailed description of using the front panel can found in
Section 3.1. All hardware listed below comes standard except for the DVB-CI slots which
are a factory installed option.
1. LCD screen
2. Input Indicator
3. Error Indicator
4. Up, Down, Left, Right buttons
5. Back and Enter Buttons
6. 2x DVB-CI Slots (Factory Option)
1.3 Rear Panel Overview
The MRD 5800 comes standard with all of the hardware listed below except where noted
as a factory installed option. The two option cards available for the MRD 5800 are the
Quad Input DVB-S/S2 card or dual port MPEG/IP Input/Output card. ASI is the standard
input on all MRD 5800 units. The external genlock reference connection is also a factory
installed option.
1. RJ45 Management Port
Page 11 (116)
MRD 5800 – User Manual
2. Relay Output Connector
3. External Genlock Reference Input (Factory Option)
4. Eight Digital Audio Outputs
5. Two 15-Pin Analog Audio Connectors
6. Composite Video Output
7. Two 3G/HD/SD-SDI Output Connectors (mirrored)
8. Digital Video Output Connector
9. ASI I/O Connectors
10. Option Card Slot #1 (factory installed)
11. Option Card Slot #2 (factory Installed)
12. Chassis ground
13. Optional Dual Power Supply
14. Optional Simultaneous SD Video Card (factory installed)
1.4 Cooling
The MRD 5800 is cooled via forced induction through the front of the unit and
exhausted through the vents in t he rear of the chassis. The MRD 5800 is equipped
with a temperature controlled status indicator. If the temperature inside the unit
exceeds 60°C the r ed “Error” text will i lluminate on the front panel and a description
of the error will appear in the “Error List.”
1.5 Rack Information
The MRD 5800 is intended to be mounted in a standard 19” rack. It occupies 1RU of
rack space and the connections are all on the rear of the unit.
Page 12 (116)
MRD 5800 – User Manual
Section 2 Installation
Introduction
This section includes the following topics:
2.1 Rack Installation ........................................................................................................ 14
2.2 Power Connection ..................................................................................................... 14
2.3 AC Power Connection ............................................................................................... 14
2.4 AC Dual Redundant Power Connection (optional) .................................................... 15
2.5 DC Power Connection ............................................................................................... 15
2.6 Maintenance .............................................................................................................. 15
2.7 Network Setup via Front Panel .................................................................................. 15
Page 13 (116)
MRD 5800 – User Manual
1. Determine the desired position in the rack for the MRD
4. Secure the MRD 5800 to the rack by installing the four
supplied screws through the front mounting holes and
If needed, secure a grounding wire use the grounding
2.1 Rack Installation
To install the MRD 5800 into a rack use the following steps:
5800 making sure that the air intake on the front of the
unit and the exhausts on the sides of the unit will not be
obstructed.
2. Insert the rack mount clips into place over the mounting
holes in the rack.
3. Slide the MRD 5800 into position in the rack.
tightening.
5.
location on the rear panel of the MRD 5800. See Section
1.3 for grounding location.
2.2 Power Connection
Using the proper power connections is vital to t he safe operation of the MRD 5800.
Only use the supplied 3-prong power connector or one with equal specifications.
NEVER tamper with or remove the 3
damage to the MRD 5800, personnel, or property.
rd
– prong grounding pin. This could cause
2.3 AC Power Connection
The MRD 5800 is intended for use on either 120V or 240V systems. The power
supply will automatically detect the system it is connected to. To hook up the power
use the following steps:
1. Locate the AC power cord that was included with the MRD 5800.
2. Plug the female end of the power cord (end with no prongs) into the back of the
unit.
3. Locate a protected outlet (usually inside of the rack) to plug the male end of the
power cable into.
Page 14 (116)
MRD 5800 – User Manual
↵
Active Errors
2.4 AC Dual Redundant Pow e r Conne c t ion (optional)
The Dual Redundant option allows the MRD 5800 to be powered by two separate
supplies either operating 120V or 240V systems. The power supply will automatically
detect the system it is connected to. To hook up the power use the following steps:
1. Locate the AC power cord that was included with the MRD 5800.
2. Plug the female end of the power cord (end with no prongs) into the back of the
unit.
3. Locate a protected outlet (usually inside of the rack) to plug the male end of the
power cable into.
2.5 DC Power Connection
The MRD 5800 with the DC chassis option is intended for use on 48V DC systems. A
power cable is not included for this option. In order to apply power to the unit in this
configuration, simply connect the screw terminals on rear of the unit to the rack’s DC
power rails.
Be sure that the power source and cable is used in conjunction with an over -current
protective device rated at 50 V, 5 A, type: Slow-blo fuse as part of battery-supply
circuit. Also, to reduce the risk of shock and damage to equipment, it is
recommended that the chassis grounding screw (1.3) located on the rear of the MRD
5800 – be connected to the installation’s rack, battery negative terminal, and/or earth
ground.
2.6 Maintenance
The MRD 5800 is virtually a maintenance-free piece of equipment. There are no user
serviceable parts on the inside of the unit
2.7 Network Setup via Front Panel
The MRD 5800 can be setup on a network connection to allow remote management and
SNMP configuration. For these features to work, the network settings for the MRD 5800
must first be configured properly for the network it is connected to.
Static IP Address
To setup the MRD 5800 with a static IP address, use the following steps:
1. Press the button.
2. Use the and buttons to
move the cursor to “Admin”, then
press the button.
Baseband Outputs
Transport Stream Outputs
>Admin
Main Menu ↔↕
Page 15 (116)
MRD 5800 – User Manual
Note: The first menu displayed is status
3. The cursor will now be on “Mask”.
5. The cursor will now be on “Gateway”.
to save the selection.
↵
Voltage Levels
↵
↵
Mask: 0.0.0.0
↵
Mask: 0.0.0.0
↵
>Mask: 000.000.000.000
↵
>Gateway: 000.000.000.000
3. Use the and buttons to
move the cursor to “Unit Networking”,
then press the button.
menu. In order to begin making
changes to networking settings press
the button.
4. Use the and buttons to
move the cursor to “DHCP”, then
press the button.
5. Use the and buttons to
change the selection to “Disabled”
then press the button.
IP Address/Subnet Mask/Gateway
Admin ↔↕
>Unit Networking
System Time
About System
Configure Network ↔↕
Host Name:
>DHCP: Disabled
1. Use the and buttons to
move the cursor to “IP”, then press the
button.
2. Use the and buttons to
select the column to edit and use the
and buttons to change the
IP, then press the button to
save the selection.
4. Use the and buttons to
select the column to edit and use the
and buttons to change the
Subnet Mask, then press the
button to save the selection.
6. Use the and buttons to
select the column to edit and use the
and buttons to change the
Gateway, then press the button
Configure Network ↔↕
Host Name:
DHCP: Disabled
>IP: 0.0.0.0
Configure Network ↔↕
Host Name:
DHCP: Disabled
>IP: 000.000.000.000
Configure Network ↔↕
Host Name:
DHCP: Disabled
IP: 0.0.0.0
Configure Network ↔↕
DHCP: Disabled
IP: 0.0.0.0
Mask: 0.0.0.0
Page 16 (116)
MRD 5800 – User Manual
↵
DHCP
The MRD 5800 can be configured to use DHCP to obtain an IP address/Subnet
Mask/Gateway.
1. Use the and buttons to move the
cursor to “DHCP:” then press the
button.
2. Use the and buttons to change
Host Name:
>DHCP: Enabled
the selection to “Enabled” then press the
button to save the selection.
Note: It may take up to a minute for the MRD 5800 to obtain an IP address. During
this time the unit will display a “busy” message next to DHCP.
Configure Network ↔↕
Page 17 (116)
MRD 5800 – User Manual
Section 3 Operating the Front
Panel
Introduction
This section includes the following topics:
3.1 MRD 5800 Front Panel Overview .............................................................................. 19
Page 18 (116)
MRD 5800 – User Manual
↵
Service: NBA TV HD
↵
Mask: 0.0.0.0
1
4
2
3
1
2
3
4
3.1 MRD 5800 Front Panel Overview
The MRD 5800 front panel allows the user to configure all settings that are present in the
web interface using the buttons located on the front of the unit. The screen below is the
idle screen of the MRD 5800. This idle screen allows the user to view the incoming
bitrate of the active input, which input is set to active, the management IP address of the
unit and the service currently set to decode.
↔↕
Bitrate: 68.502 Mbps
Input: MPEG/IP 2 Stream 1
IP: 10.0.7.106
1. Bitrate of incoming stream displayed in Mbps.
2. Current active input.
3. IP address of management port.
4. Current decoded service.
The following figure shows a typical screen on the front panel. Several important
features have been circled and noted below. These features are common to all screens
and assist when navigating, viewing and editing unit information. The button allows
the user to return to the home screen, cancel settings and go back a menu. In order to
edit a selected parameter the button must be pressed. Once a parameter has been
changed the button must be pressed again before the change takes effect on the
unit.
Configure Network ↔↕
Host Name:
DHCP: Disabled
>IP: 000.000.000.000
1. Screen title.
2. Icons indicate which control buttons are currently valid for entry.
3. Cursor shows which line is active.
4. W hen editing, active character or item is highlighted.
Page 19 (116)
MRD 5800 – User Manual
Section 4 Operating the Web
Interface
Introduction
This section includes the following topics:
4.1 MRD 5800 Web Interface Overview .......................................................................... 21
4.2 Main Panel ................................................................................................................. 22
4.3 Admin Panel .............................................................................................................. 72
4.4 Reporting Panel ......................................................................................................... 87
4.5 About Panel ............................................................................................................... 91
Page 20 (116)
MRD 5800 – User Manual
4.1 MRD 5800 Web Interface Overview
4.1.1 Logging into the MRD 5800 Web Interfa c e
To open the MRD 5800 web interface use one of the following supported browsers and
navigate to the unit’s IP address:
• Internet Explorer 7 & above
• Firefox 3.5 & above
• Google Chrome
The user will need to login to the web interface. By default the admin user account is
available without a password. Press the login button in order to login to the web
interface.
4.1.2 Hiding Unused Inputs
The MRD 5800 web interface allows the user to hide inactive inputs using the
button or show all available inputs by click the button. Only
the inputs configured as the Primary Input and Backup Input (see Section 4.2.1) will be
displayed when unused inputs are hidden.
4.1.3 Buttons and Status Indicators
When the icon is shown user configuration is available. Clicking this button wil l open
menus where settings can be changed by the user.
When t he icon is shown additional status information can be viewed. Click this button
will expand the menu to display the additional status informat ion. All text i n s t at us m enus
Page 21 (116)
MRD 5800 – User Manual
Status is good. No errors are present and function is operating
Status indicates function is affected by active error. To view the
shown in ORANGE are user configurable settings. Text shown in BLUE is not user
configurable and is strictly a status or value. To minimize the status windows again click
the icon.
Status in the MRD 5800 web interface is shown with LED status indicators:
Green LED
Red LED
Grey LED
normally.
errors navigate to Alarms panel to view Active Errors.
Status is inactive. Function is currently disabled or unavailable.
4.1.4 Drag and Drop Menus
Certain menus in the MRD 5800 allow the user to drag and drop items to auto populate
fields. Conditional Access and Service Selection menus are some examples of menus
that drag and drop can be used. In the example below a service in the transport stream
view on the right hand side of the window is selected and dragged over to auto populate
the PIDs in the service selection section.
4.2 Main Pa n el
The Main panel of the MRD 5800 web interface is used to configure the unit to decode,
de-encapsulate and demodulate. When configuring the MRD 5800 the user begins at the
top of the menu and works down. The inputs are configured, then descrambling (if
present), then service or PIDs are selected for decode, then outputs are configured.
Pictured below is a fully populated unit with all options licensed.
Page 22 (116)
MRD 5800 – User Manual
4.2.1 Configuring Active Inputs
This menu allows the user to configure a primary and backup input. In case there is an
input failover the MRD 5800 is capable of detecting the failed state and switching to a
secondary backup input in order to provide a continuous output. Which input is primary
and backup, how the inputs switchover and restore and switchover timing is all user
configurable. The user can force the MRD 5800 to switch between the Primary and
Backup Inputs by clicking the button. To change the active input and
failover settings click the icon next to Input Selection:
Page 23 (116)
MRD 5800 – User Manual
Setting
Range
Description
Primary Input
ASI
Used for both normal operation and input
Backup Input
ASI
During failover operation this input will
Switch On
Manual Only
Manual Only: the unit will not s witch inputs
Active Input Indicator
Active Input and Failover Configuration Menu
MPEG/IP Slot X Stream X
DVB-S2 Slot X Port X
8VSB/QAM Slot X
Turbo PSK Slot X
DVB-T2/C2/ISDB-T Slot X
None
MPEG/IP Slot X Stream X
DVB-S2 Slot X Port X
8VSB/QAM Slot X
Turbo PSK Slot X
DVB-T2/C2/ISDB-T Slot X
None
failover settings. During normal operation this
input will be the active input.
become the active input. The catalyst for
what causes the unit to switch to this input is
configured in the following settin g.
TS Sync Loss
Page 24 (116)
automatically. The user must manually
switch inputs.
MRD 5800 – User Manual
Decode Failure
TS Sync Loss: the MRD 5800 will switch
Restore On
Manual Only
Manual Only: the unit will not restore to the
Switchover
1-20 seconds
The time in seconds which Switch On or
from the primary to the backup input if the
primary stream loses synchronization for the
duration of the Switchover Interval.
Decode Failure: the unit wil l switch to the
backup input when it encounters decoding
errors on the primary input.
Primary Input TS Restored
Backup Input TS Sync Loss
Decode Failure
primary input automatically. The user must
manually switch inputs.
Primary Input TS Restored: the MRD 5800
restores to primary when the Primary input
regains transport stream synchronization.
Backup Input TS Sync Loss: the unit will
switch from backup to primary when the
backup stream loses synchronization for the
duration of the Switchover interval.
Decode Failure: the unit restores to the
Primary Input when the Backup Input
experiences a decoding error.
Restore On value must remain in the
configured state before the MRD 5800
switches between the Primary Input and
Backup Input or vice versa.
4.2.2 Configuring ASI Input
This menu allows the user to either Enable or Disable the ASI Input on the MRD 5800.
Beginning with revision J main boards the ASI ports can be configured as either an input
or output. Earlier revision remain configured as 1 input and 1 ouput port. Main board
version can be located on the About tab under the Options section.
Page 25 (116)
Rev I and earlier main board ASI options
MRD 5800 – User Manual
Setting
Range
Description
Direction
Input
Configrue the ASI port to either an input or
Port
Enabled
This setting allows the user to enable or
Null Stripped
Disabled
Enabling Null Stri pp e d allows the MRD 5800
Rev J and later main board ASI options
Output
Disabled
Enabled
an output. Applies only to main board
revision J or later. Main board version can be
located on the about tab under the Options
section.
disable the ASI Input to the MRD 5800.
to receive streams that do not contain null
packets. (i.e. VBR Transport Streams)
4.2.3 Configuring MPEG/IP Input
If the MPEG/IP Input card was selected as a factory installed option, the following menus
and options will be available for configuration. This menu allows the user to configure the
MPEG/IP inputs. Each MPEG/IP card has two ports that can be set to receive and/or
transmit. This menu is for setting up the reception of MPEG/IP unicast or multicast
transport streams. The menu for Stream 1 and 2 have the same settings. IGMPv2 is
used to join/leave multicast streams by default if no IGMP Filter addresses are entered.
If IGMP Filter Mode addresses are specified then IGMPv3 is used.
Page 26 (116)
MRD 5800 – User Manual
Setting
Range
Description
Receive
Enabled
This setting allows the user to enable or
Physical
Port 1
The physical connector on the MPEG/IP card
Mode
Multicast
Multicast setting allows the unit to receive
Destination IP
224.0.0.0 –
This setting is only available when receiving
Destination Port
0 - 65535
This is the UDP port the source device is
FEC
Enabled
Enabling FEC (Forward Error Correction)
tells the MRD 5800 to look at Destination
Connector
General and Advanced options for IP input
Disabled
Port 2
Unicast
239.255.255.255
disable these input stream settings.
that will be used to receive the input .
multicast streams. Multicast streams
originate from the IP range 224.0.0.0 –
239.255.255.255. Unicast allows the unit to
receive unicast streams. Unicast streams
originate directly from a source device.
a multicast stream. This address is the IP
address the source device is sending to.
sending to. This is the only setting required to
receive a unicast stream.
Page 27 (116)
MRD 5800 – User Manual
Disabled
Port +2 and Destination Por t +4 for a SMPTE
Internal Source
Enabled
Enabling Source filtering disables IGMP V3
Internal Source
0.0.0.0 – 255.255.255.255
Source IP for whitelist. All other source IP
IGMP Filter Mode
Exclude
Used on networks supporting IGMPv3. If this
Null Stripped
Enabled
Enabling Null Stri pp e d allows the MRD 5800
RTP SSRC
Enabled
Enabling RTP SSRC allows the MRD 5800 to
SSRC Filter Value
0 - 4294967295
The Filter Value the MRD 5800 checks for
Buffer Mode
Size (KB)
Allows option to set buffer mode to Size in
Buffer Size (KB)
1 – 4000 KB
This setting determines how much data is
Buffer Delay (ms)
1 – 4000 ms
The buffer delay setting allows the buffer size
Statistics Reset
Manual
Statistics can be viewed by hitting the +
Reset Interval
5-65535
Interval in which the Auto option will reset
2022 FEC Matrix.
Filter
Filter IP
Disabled
Include
Disabled
Disabled
Delay (ms)
filtering and allows a user to whitelist a single
IP address for a given multicast and block all
other source IP’s
addresses are blocked
setting is set to Exclude any streams
originating from the user defined IP
addresses will be rejected. If this setting is
set to Include any streams originating from
the user defined IP addresses will be
received.
to receive streams that do not contain null
packets. (i.e. VBR TS Streams)
filter the input by the user defined value. Only
streams containing the user defined value
will be received by the MRD 5800.
before receiving a stream with RTP SSRC.
KB or Delay ms
Mode
(min)
Auto
received before the MRD 5800 starts
decoding. Increasing this value will allow the
MRD 5800 is receive streams on networks
with high network jitter. Increasing this value
also increases the latency of the MRD 5800.
to be set by delay time. The Buffer delay time
will be determined by the input data rate.
symbol next to the MPEG/IP option card on
the main window. Selecting Auto will reset
the statistics on a chosen interval. When the
reset occurs, statistical information for that
period will be logged. Selecting Manual will
only clear the statistics by hitting the refresh
button.
and log the statistics displayed on the main
window
Page 28 (116)
MRD 5800 – User Manual
Setting
Range
Description
Port
Enabled
This setting allows the user to enable or
IP statistics menu
4.2.4 Configuring DVB-S/S 2 Input
If the DVB-S/S2 Input card was selected as a factory installed option, the following
menus and options will be available for configuration. This menu allows the user to
configure the DVB-S/S2 inputs. Each DVB-S/S2 input card has four ports (labeled A, B,
C and D) which only one port can be active at a time. This menu is for setting up the
reception of DVB-S/S2 satellite signals. The menu for Port A, B, C and D have the same
settings.
Disabled
Page 29 (116)
disable this reception port.
MRD 5800 – User Manual
Mode
DVB-S
This setting allows the user to choose
Satellite
C-Band: 4GHz – 8GHz
If LO Offset is set to 0 then L-Band frequency
Wide Search
Enable
When Enabled the search range may be
LO Offset
5150
The offset in MHz that the local oscillator is
Symbol Rate
Manual
The Manual option allows the user to choose
Symbol Rate
0 - 60
The symbol rate of incoming satellite signal
PLS Code
0 – 262141
The MRD 5800 has the ability to receive
LNB Power
Off
The MRD 5800 has the ability to provide the
22kHz Tone
Enabled
Enabling or disabling the 22khz tone allows
Multistream State
Enabled
The MRD 5800 has the ability to receive
multistream satellite signals. If the signal is
Frequency
Mode
DVB-S2
Auto
Ku Band: 11.2Ghz –
14.5Ghz
L-Band: 950MHz –
2150MHz
Dependent on LO Offset
Disable
9750
10600
10750
11250
Auto
between DVB-S or DVB-S2 modulation
schemes. Setting to Auto will have the unit
automatically detect wheth er the input is
DVB-S or DVB-S2.
is entered into the Satellite Frequency dialog
box. If LO Offset to set to a pre-defined
option then enter C-band or Ku-Band
frequency.
extended depending on the symbol rate. See
appendix C for more information.
operating.
the symbol rate. The A uto opt ion
automatically detects the incoming symbol
rate.
13 VDC
14 VDC
18 VDC
19 VDC
Disabled
Note: Acquisition time may be longer in auto
mode, especially when the symbol rate is
below 1MSps or above 55MSps.
in MSps. Accurate to one decimal place
(kSps). Used when Symbol Rate Mode is set
to Manual.
satellite signals scrambled using PL
Scrambling. In order to receive the stream,
enter the value of the incoming signals PL
Scrambling code.
necessary voltage to power an LNB. Select
the correct voltage to supply to the LNB.
the MRD 5800 to trigger the LNB to switch
polarities.
Page 30 (116)
MRD 5800 – User Manual
Disabled
multistream capable, enable this setting. This
ISI
0-255
This setting is the ISI (Input Stream Identifier)
Setting
Range
Description
Receive
Enabled
This setting allows the user to enable or
Mode
8VSB
This setting allows the user to choose
Channel Plan
Off Air
If 8 VSB is the selected Mode, the only
Channel
Off Air: 2-69
This setting is for the desired channel to be
option is only available in DVB-S2 Mode.
NOTE: This is a licensed feature.
the MRD 5800 uses to filter multistream
input. This option is only available if
Multistream is licensed and enabled.
4.2.5 Configuring 8VSB/QAM Input
If the 8VSB/QAM Input card was selected as a factory installed option, the following
menus and options will be available for configuration. This menu allows the user to
configure the 8VSB/QAM input. This menu is for setting up the reception of 8VSB off air
signals or QAM cable signals.
Disabled
64-QAMB
256-QAMB
FCC Cable
HRC Cable
IRC Cable
Page 31 (116)
disable this reception port.
between 8VSB or QAM modulation schemes.
available option is O ff Air. If either 64-QAMB
or 256-QAMB is the selected Mode, this
setting allows the user to choose which
Cable scheme is used.
FCC, HRC, or IRC Cable:
2-158
received.
Low RF Level
-34 - +40
This is the Low RF Level threshold when the
Low MER (dB)
0 - 40
This is the Low MER threshold when the Low
Setting
Range
Description
Recieve
Enabled
This setting allows the user to enable or
Mode
DVB-S
This setting allows the user to choose
Modulation
QPSK 1/2
This setting allows the user to select which
MRD 5800 – User Manual
(dBmV)
Low Level Alarm will be triggered in dBmV
MER Alarm will be triggered in dB.
4.2.6 Configuring Turbo PSK Input
If the Turbo PSK Input card was selected as a factory installed option, the following
menus and options will be available for configuration. This menu allows the user to
configure the Turbo PSK input. This menu is for setting up the reception of DVB-S and
Turbo PSK satellite signals.
Disabled
TurboPSK
QPSK 2/3
QPSK 3/4
QPSK 5/6
QPSK 7/8
8PSK 2/3
8PSK 3/4 (2.05)
8PSK 3/4 (2.10)
8PSK 3/4 (2.20)
disable this reception port.
between DVB-S or TurboPSK modulation
schemes.
modulation parameters are used for the
incoming signal and the dropdown list is
dependent on the mode that is selected.
Page 32 (116)
8PSK 5/6
8PSK 8/9
LO Offset
5150
The offset in MHz that the local oscillator is
Satellite
C-Band: 4GHz – 8GHz
If LO Offset is set to 0 then L-Band frequency
Symbol Rate
0.256 - 30
The symbol rate of incoming satellite signal
MRD 5800 – User Manual
operating.
is entered into the Satellite Frequency dialog
box. If LO Offset to set to a pre-defined
option then enter C-band or Ku-Band
frequency.
in MSps. Accurate to one decimal place
(kSps).
Frequency
9750
10600
10750
11250
Ku Band: 11.2Ghz –
14.5Ghz
L-Band: 950MHz –
2150MHz
Dependent on LO Offset
Note: Reception may not be possible at rates less than 1MSps
4.2.7 Configuring DVB-T2/C2/ISDB-T Input
If the DVB-T2/C2/ISDB-T Input card was selected as a factory installed option, the
following menus and options will be available for configuration. This menu allows the
user to configure a DVB-T/T2/C/C2 or ISDB-T input.
Page 33 (116)
MRD 5800 – User Manual
Setting
Range
Description
Recieve
Enabled
This setting allows the user to enable or
Mode
DVB-T
This setting allows the user to choose
Channel Plan
Australia
This setting allows the user to select which
Disabled
DVB-T2
DVB-C
DVB-C2
ISDB-T
Eur-Asia-Afr
Ireland
New Zealand
Taiwan
South Africa
disable this reception port.
between DVB-T/T2/C/C2 or ISDB-T
modulation schemes.
channel plan they would like to use. Channel
Plan options are tied to which modulation
mode is selected.
South America
United Kingdom
Page 34 (116)
European Cable
Japan
Channel
Select a channel from the channels available
Frequency (MHz)
42-1002
Selecting a channel from the channel
Bandwidth
1.7 MHz
Selecting a channel from the channel
PLP ID
Unique PLP ID used to select a particular
Profile
Auto
Select the DVB-T2 profile to use
Low RF Level
-34 - +40
This is the Low RF Level threshold when the
Low MER (dB)
0 - 40
This is the Low MER threshold when the Low
Philippines
MRD 5800 – User Manual
in the dropdown. The list of available
channels will be based on which channel
plan is selected
dropdown will populate this field
automatically based on the user selected
channel. A user can manually select a
frequency if desired
dropdown will populate this field
automatically based on the user selected
channel plan. A user can mannualy select
channel bandwidth if desired.
stream within the DVB-T2 or DVB-C2 input
signal
Low Level Alarm will be triggered in dBmV
MER Alarm will be triggered in dB.
(dBmV)
5 MHz
6 MHz
7 MHz
8 MHz
Base
Lite
4.2.8 Configuring DVB-CI Descr a m bling
This section will describe how to configure DVB-CI descrambling in the MRD 5800. First,
the user will need to configure the CAM slots and descrambling mode. Once this is
complete the user can configure which services or PIDs to descramble.
4.2.8.1 Configuring DVB-CI Slots
This menu allows the user configure the DVB-CI slots in the MRD 5800. The MRD 5800
has two DVB-CI slots, a top and bottom, where CAM Modules can be inserted. Both
slots are individually configurable using the Bottom Slot and Top Slot tabs. CAM
Modules can be reset manually using the button. The button opens the
MMI (Man Machine Interface) for the CAM in the respective slot. MMI support is
dependent on what is supported by the CAM
Page 35 (116)
MRD 5800 – User Manual
Setting
Range
Description
Mode
Descramble Decoded PIDs
Decoded PIDs sets the MRD to descramble
Top Slot
Enabled
This setting allows the user to enable or
.
Descramble Selected PIDs
Descramble Selected Services
Bottom Slot
Disabled
4.2.8.2 Configuring Service Descrambling
This menu allows the user to select the services the MRD 5800 will descramble using
the CAM Modules and Smart Cards inserted into the DVB-CI slots. See Section 4.2.8.1
to configure these slots. These options are applicable only if the Mode in the DVB-CI
settings is set to Selected PIDs or Selected Services (Refer to Section 4.2.8.1). The drag
and drop method can be used to drag services from the right column to the left column.
The drop down menu next to each selected service allows the user to ch oose either the
bottom or top slot to descramble the service. If in Selected PIDs mode, PIDs to
descramble can be added manually by clicking button. If in Selected Services
only the PIDs of the service that is currently
set to decode. If the PIDs change in the
incoming stream the MRD will adapt to these
changes, provided that Service Selection is
set to “Service Lock” (Refer to Section
4.2.8). Selected PIDs sets the MRD to
descramble PIDs set in the Descramble
Services window (Refer to Section 4.2.8.2).
If the PIDs change in the incoming stream
the MRD will not adapt to these changes and
will not be able to descramble. Selected
Services sets the MRD to descramble
Services set in the Descramble Services
window Refer to Section 4.2.8.2). If the
Services change in the incoming stream the
MRD will not be able to descramble.
disable the DVB-CI slot.
mode, Services to descramble can be added manually by clicking the
button. The icons next to each service indicate whether the service is scram bled or not
scrambled. Scrambled services will show the icon next to them while services that are
not scrambled will show the icon. Clicking the button forces the MRD 5800
to rescan the transport stream for changes.
Page 36 (116)
MRD 5800 – User Manual
DVB-CI Service Descrambling Menu
4.2.9 Configuring BISS Descrambling
This section will describe how to configure BISS descrambling in the MRD 5800. There
are two types of BISS descrambling.
In “Descramble All PIDs” or “Descramble Decoded PIDs” mode, the user simply
configures a BISS key set and selects it from the drop down.
For streams with multiple, per-service keys the user must first configure the key sets,
and then assign them to services.
4.2.9.1 Configuring BISS Keys
This menu allows the user to configure BISS descrambling. 12 unique BISS keys can be
entered. If the BISS mode is set to Mode E a icon will appear next to Mode E
Injected ID. This icon allows the user to unlock and modify the Injected ID.
Page 37 (116)
MRD 5800 – User Manual
Setting
Range
Description
Operation Mode
Disabled
Descramble Decoded PID’s will descramble
Selected Key
Key 1-12
Select a key to configure.
Alias
16 characters
Set an Alias for the selected key.
Mode
Mode 1
This setting sets the Mode of the BISS key
Mode 1 Session Word
N/A
If Mode 1 is selected the user enters the
Mode E Session Word
N/A
If Mode E is selected the user enters the
Mode E Injected ID
N/A
If Mode E is selected the user enters the
BISS Menu
Descramble Decoded
PIDs
Descramble Selected
Services
Descramble All PIDs
Mode E
the pids that are currently assigned to be
decoded by the MRD 5800.
Descramble Selected Services will allow the
user to select service(s) to be descrambled
on the Selected Services tab.
Descramble All PIDs will apply the selected
key to the entire transport stream.
that has scrambled the transport stream.
Page 38 (116)
BISS session word here.
BISS session word here.
MRD 5800 – User Manual
BISS injected ID here.
4.2.9.2 Configuring Per-Service Descrambling
This menu allows the user to select the services the MRD 5800 will descramble using
the BISS keys configured in Section 4.2.9.1. These options are applicable only if
Operation Mode in the BISS settings is set to Descramble Selected Services (Refer to
Section 4.2.8.1). The drag and dr op method can be used to drag ser vices from the right
column to the left column. The BISS key to descramble services can be selected using
the drop down menu next to each service. Services can be added manually by clicking
button. Clicking the button forces the MRD 5800 to rescan the
transport stream for changes.
4.2.10 Configuring Service Selection
This menu allows the user to configure the PIDs or Service the MRD 5800 will decode.
Depending on the Selection Mode that is set, the menu will change to reflect the
applicable settings.
Service Lock
In Service Lock mode the MRD is set to decode a specified service number or service
name. If the PIDs within the service change at any time, the MRD will continue to
decode the service. The drag and drop method can be used to populate the Service
Name or Service Number dialog boxes.
Page 39 (116)
BISS Service Descrambling Menu
MRD 5800 – User Manual
Setting
Range
Description
Selection Mode
Service Lock
Setting to Service Lock sets the unit to
On Backup
Use Primary Service
Sets the service the MRD 5800 will tune to in
Lock Mode
Service Name
If set to Service Name the MRD wil l decode
Service Lock Selection Menu
PID Lock
Auto Seek
Use Backup Service
Service Number
decode any PIDs associated with a service
number or service name. Setting to PID Lock
sets the unit to decode only the PIDs
specified in the PID Lock Configurat io n
matrix. Auto Seek mode will tune the unit to
the first service listed in the PAT if a transport
stream is present.
case of an input failover. If Use Primary
Service is selected the MRD 5800 will tune to
the service name specified in the Primary
section. If Use Backup Service is selected
the service name specified in the Backup
section will be tuned. How the MRD 5800
fails over inputs is configured in Section
4.2.1
only services matching the name specified
(SDT in DVB or TVCT in ATSC tables must
be present in this mode). If set to Service
Number the MRD will decode only services
matching the number specified.
Note: S302M Audio Type is now auto detected by the MRD5800
PID Lock Mode
Page 40 (116)
MRD 5800 – User Manual
Setting
Range
Description
On Backup
Use Primary PIDs
Sets the PIDs the MRD 5800 will tune to in
In PID Lock mode the MRD will only decode the PIDs specified by the user in the PID
Lock Configuration matrix. The drag and drop method can be used to auto-populate the
cells in the matrix. Stream types can be manually defined under the Primary Type and
Backup Type columns. Individual cells under Primary and Backup columns can be
selected and PIDs can be typed in manually.
Auto Seek Mode
In Auto Seek mode the MRD will decode first service listed in the PAT. All PIDs will
automatically be assigned and decoded. No other configurations are available in this
mode. This mode should only be used to verify the MRD is receiving a valid signal and it
able to decode. This mode is not recommended for a professional environment.
PID Lock Selection Menu
Use Backup PIDs
case of an input failover. If Use Primary PIDs
is selected the MRD 5800 will tune to the
PIDs specified in the Primary PID column. If
Use Backup PIDs is selected the service
name specified in the Backup PID column
will be tuned. How the MRD 5800 fails over
inputs is configured in
Section 4.2.1.
Page 41 (116)
MRD 5800 – User Manual
Auto Seek Menu
Page 42 (116)
MRD 5800 – User Manual
Setting
Range
Description
Format Mode
Auto
Setting to Auto the MRD 5800 will output
Manual Format
Refer to Appendix C
This setting is the video format the MRD
Raster Mode
Solid Color
If no input is present the MRD 5800 will
Raster Color
Black, White, Yellow,
Cyan, Magenta, Red,
If no input is present and solid color option is
chosen the MRD 5800 will output raster. This
4.2.11 Confi guring Video Services
The menu allows the user to configure the SDI, Digital Video and Composite output
formats of the MRD 5800. Please note that the composite video output is only active if
the output video format is SD. Overlays and image insertion are configured in this menu
as well. This menu will be labeled as Primary Video if a Simultaneous SD Video Card is
an installed option.
Page 43 (116)
General and Overlay Options
Manual
for supported
formats.
Last Frame
video to match the incoming native video
format. Setting to Manual the user can define
the video format the MRD 5800 will output.
5800 will output.
output either the last frame present or raster.
MRD 5800 – User Manual
Blue, Green, Gray
is the color of the video the MRD will output.
4x3 Output Aspect
Disabled
If 4x3 Auto Conversion is set to Disabled the
4x3 Output Aspect
Center-Cut
Center-Cut cuts off top and bottom of the
16x9 Output Aspect
Disabled
If 16x9 Auto Conversion is set to Disabled
16x9 Output Aspect
Center-Cut
Center-Cut cuts off the sides of the video.
Overlay Type
None
Closed Captions overlays burns closed
Closed Caption
NTSC
Sets the type of closed captions that will be
NTSC Service
CC1 – CC4
Sets the NTSC closed caption service that
DTVCC Service
Service 1-6
Sets the DTVCC closed caption service that
DVB Subtitles
Language Codes
If DVB Subtitles overlays are enabled this
Ratio Auto Conversion
Ratio Conversion
Mode
Ratio Auto Conversion
AFD
Letterbox
Anamorphic
AFD
MRD 5800 uses the 4x3 Conversion Mode
setting to format video. If 4x3 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 4x3 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 4x3 Conver si on Mode setti ng wi ll
be used.
video. Letterbox adds bars at the top and
bottom of the video. Anamorphic stretches
the video height and width to match the
format mode.
the MRD 5800 uses the 16x9 Conversion
Mode setting to format video. If 16x9 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 16x9 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 16x9 Conversion Mode setting
will be used.
Ratio Conversion
Mode
Pillarbox
Anamorphic
Closed Captions
DVB Subtitles
Teletext Subtitles
DTVCC
Pillarbox adds bars at the left and right of the
video. Anamorphic s tr etche s the video height
and width to match the format mode.
captioning in the video output. DVB Subtitles
burns subtitles in video output. Teletext
Subtitles burns subtitles in the video out p ut.
None disables overlays completely.
in the overlay.
will be displayed in the overlay. This setting
is only available if the Closed Caption option
is set to NTSC.
will be displayed in the overlay. This setting
is only available if the Closed Caption option
is set to DTVCC.
setting choosing the language which the
subtitles are displayed. Only the languages
present in the stream are given.
Page 44 (116)
MRD 5800 – User Manual
Teletext Subtitles
3 Hexidecimal
If Teletext Subtitles overlays are enabled this
Image Trigger
Disabled
This setting will enable or disable the image
SCTE35 Event ID
Specify the SCTE35 Event ID that will cause
Image Dithering
Enabled
Enable or Disable dithering of the uploaded
Image Transition
Fade
Specifiy if the image should fade in and out
Characters
SCTE 35
Decode Failure
Always Active
Disabled
Cut
setting choosing the page (language) of
which subtitles are displayed. Only the pages
present in the stream are given.
overlay in the video output. The SCTE 35
option will insert based on an event ID. The
decode failure option will overlay the image if
the video not decoding error is raised.
Always active will always overlay the image
in the video output.
the image overlay to trigger.
or cut in and out when using SCTE 35 or
Decode Failure options
4.2.12 Configuring Secondary Video Service s
This menu, if applicable, allows the user to configure the simultaneous SDI, and the
second Composite output of the MRD 5800. Please note the simultaneous SDI output is
limited to SD only. Also note the simultaneous SDI and simultaneous Composite outputs
will output the same selected service as the primary video output.
Page 45 (116)
MRD 5800 – User Manual
Setting
Range
Description
Format Mode
Auto
Setting to Auto the MRD 5800 will output
Manual Format
720x576i (4x3 or
This setting is the video format the MRD
Raster Mode
Solid Color
If no input is present the MRD 5800 will
Raster Color
Black, White, Yellow,
If no input is present and solid color option is
4x3 Output Aspect
Disabled
If 4x3 Auto Conversion is set to Disabled the
4x3 Output Aspect
Center-Cut
Center-Cut cuts off top and bottom of the
16x9 Output Aspect
Disabled
If 16x9 Auto Conversion is set to Disabled
16x9 Output Aspect
Center-Cut
Center-Cut cuts off the sides of the video.
Ratio Auto Conversion
Manual
16x9) @ 25Hz
720x480i (4x3 or
16x9) @ 29.97Hz
Last Frame
Cyan, Magenta, Red,
Blue, Green, Gray
AFD
video in an SD format based on the incoming
native video format. Setting to Manual the
user can define the SD video format the
MRD 5800 will output.
5800 will output.
output either the last frame present or raster.
chosen the MRD 5800 will output raster. This
is the color of the video the MRD will output.
MRD 5800 uses the 4x3 Conversion Mode
setting to format video. If 4x3 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 4x3 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 4x3 Conversion Mode setting will
be used.
Ratio Conversion
Mode
Ratio Auto Conversion
Ratio Conversion
Mode
Page 46 (116)
Letterbox
Anamorphic
AFD
Pillarbox
Anamorphic
video. Letterbox adds bars at the top and
bottom of the video. Anamorphic stretches
the video height and width to match the
format mode.
the MRD 5800 uses the 16x9 Conversion
Mode setting to format video. If 16x9 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 16x9 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 16x9 Conversion Mode setting
will be used.
Pillarbox adds bars at the left and right of the
video. Anamorphic s tr etche s the video height
and width to match the format mode.
MRD 5800 – User Manual
Setting
Range
Description
Operational Mode
Line Mode
Refer to Appendix E for explanation.
Processing Mode
Downmix
Refer to Appendix E for explanation.
Discrete Channels
Lf/Rf
Selectable Pairs of Discrete Channels(Refer
Dynamic Range
Enabled
Refer to Appendix E for explanation.
Downmix
Lo/Ro (Stereo)
When the audio is downmixed in the MRD
5800 two audio channels are created. The
4.2.13 Confi guri ng Audio
This menu allows the user to configure the audio downmix settings or select a pair of
discrete audio channels(if the 5.1 discrete audio license is present). Two audio presets
are available: Transmission and Monitor. These presets can be applied by clicking the
button. The menus for Audio 1 through Audio 8 all contain the same settings.
RF Mode
Custom 1
Custom 0
Discrete
C/LFE
Ls/Rs
Ch1/Ch2
Ch3/Ch4
Ch5/Ch6
Ch7/Ch8
Refer to Appendix F for explanation
to Appendix F)
Page 47 (116)
Disabled
MRD 5800 – User Manual
Lt/Rt (Dolby Surround)
channels can be configured using the
Dolby Format Mode
Consumer
This option selects the Dolby Digital format
Audio Offset(ms):
-50 to +100 ms
This setting will adjust the audio output timing
DolbyE Offset:
None
This setting will adjust the audio output timing
Lt/Rt (Auto)
Dual Mono
Dual Left
Dual Right
Professional
Advance 1 Frame
settings available in the drop down menu.
(Refer to
mode. (Refer to Append ix E)
from -50 ms to +100 ms. This setting will
affect all interfaces configured to output this
audio service.
for if this audio service is a DolbyE audio.
Setting to None no timing changes are made.
Setting to Advance 1 Frame will advance the
audio 1 frame. This setting will affect all
interfaces configured to output this audio
service.
Appendix E)
4.2.14 Configuring Genlock
If the Genlock Reference option was selected as a factory installed option, the following
menus and options will be available for configuration. This menu allows the user to
configure the genlock reference used by the MRD 5800. The MRD 5800 can be
configured to use an external user provided reference or disabled completely.
Page 48 (116)
MRD 5800 – User Manual
Setting
Range
Description
Reference Source
Disabled
Setting to Disabled will synchronize video
SD Vertical (Lines)
-312 - 312
Plus or minus half of the number of lines in
SD Horizontal (Pixels)
-431 - 432
Plus or minus half of the number of pixels in
Subcarrier (Degrees)
-180 - 180
Plus or minus 180 degrees of the color
HD Vertical (Lines)
-562 - 562
Plus or minus half of the number of lines in
HD Horizontal (Pixels)
-1374 – 1375
Plus or minus half of the number of pixels in
Setting
Range
Description
Heartbeat Timeout
1-60
Setting this value will determine the time in
External
output to the PCR carried in the transport
stream. Setting to External uses the user
provided external genlock reference.
the genlock reference for SD formats.
the genlock reference SD formats.
subcarrier.
the genlock reference for HD formats.
the genlock reference for HD formats.
Note: The Genlock reference connector if enabled requires external termination.
4.2.15 SCTE35
If the SCTE35 license is enabled, the following menus and options will be available for
configuration. The SCTE35 to SCTE104 and SCTE35 to Relay options are used in an
application where the MRD 5800 is receiving a transport stream with SCTE35 DPI splice
messages.
In an SCTE35 to 104 configuration, the MRD extracts SCTE 35 messages from the
transport stream and converts them to SCTE104 messages, and embeds them as
VANC packets on the SDI output.
In the SCTE35 to relay configuration the unit will trigger a relay based on SCTE35 DPI
splice message and user configurations for the relays.
The SCTE 35 insertion option contains configuration settings for manually triggered or
SNMP triggered SCTE 35 DPI splice messages.
(min)
minutes between SCTE35 messages before
Page 49 (116)
MRD 5800 – User Manual
the MRD 5800 will report an error
Page 50 (116)
MRD 5800 – User Manual
Setting
Range
Description
Relay Triggering
Enabled
Enable or Disable selected Trigger
Relay Output
Relay 1
Select which Relay the configured trigger will
Event ID Filter
Pass All
Selects whether all Events will trigger the
Event ID (Hex)
0-FFFFFFFF
Used in “Pass Event ID” mode to filter which
Event Source (Hex)
0-FFFFFFFF
Used in “Pass Event Source” mode to filter
Offset (ms)
-4000ms to 4000ms
Specify an offset for the Trigger
Relay Mode
Pulse
Specify a mode for the relay. In pulse mode
Pulse Event
Out of Network
Select which SCTE 35 splice_insert message
Pulse Duration (ms)
10-1000
Select a duration for the pulse
Disabled
Relay 2
Relay 3
Pass Event ID
Pass Event Source
Latch
Return to Network
use. See appendix D for relay pinout.
relay, or only those with a certain Event ID or
Source
SCTE 35 messages that will trigger the relay
which SCTE 35 messages that will trigger the
relay
the relay will fire once on either OON or RTN.
In latch mode the relay will remain energized
for the entire break duration
triggers the relay
Page 51 (116)
MRD 5800 – User Manual
Latch Timeout (ms)
1-300
Specify a duration for latch mode. Note:
Setting
Range
Description
State
Enabled
Enable or Disable SCTE 35 message
PID
0-8191
PID on which the inserted SCTE 35
Splice Type
Normal
Selects whether the SCTE 35 message will
Pre-Roll (ms)
0-20000
Configured offset prior to splice point
Event ID (Hex)
0-FFFFFFFF
Unique Event ID for the the SCTE 35
Network Event
Out of Network
Select which network transition signal is used
Break Duration (ms)
0-95443717
Duration in ms of the Out of Network Break
Unique Program ID
0-65535
Unique program identification within a service
Receiving a Return to Network message will
override the latch timeout.
Disabled
Immediate
Return to Network
Insertion
messages will be inserted
be of the “splice immediate” type (which can
trigger an instantaneous switch downstream)
or the normal type which uses a PTS-based
preroll value to time the insertion.
message
for the SCTE 35 message
Page 52 (116)
MRD 5800 – User Manual
Avail Num
0-255
Authentication for a specific avail in the
Avails Expected
0-255
Number of Avails expected in the current
Unique Program ID
viewing event
Messages can be manually inserted by clicking the green arrow that is shown when the
SCTE 35 section is expanded as shown below. In a typical operational scenario, the
splice insertion will be automated and triggered using the SNMP MIB.
4.2.16 ESAM
If the ESAM license is enabled, the following menu and options will be available for
configuration. The MRD interfaces with a Placement Opportunity Information Service
(POIS) using the CableLabs ESAM (Real-time Event Signaling and Management)
standard. When the ESAM feature is configured, each SCTE35 message which is
received in the incoming stream is sent to the POIS for processing (via the control
interface). The POIS can request that the MRD replace the message, pass the
message with no change, or delete the message.
Asynchronous SCTE 35 message insertion allows the ESAM server to create and insert
SCTE 35 messages onto a specified PID in the transport stream.
Page 53 (116)
MRD 5800 – User Manual
Setting
Range
Description
ESAM Processing
Enabled
Enable or Disable ESAM processing
POIS URI
Valid String
Specify the address of the POIS server
POIS Timeout (sec)
1-5
Specify a timeout to receive a response from
Timeout Behavior
Pass Message
Specify a behavior that is used by the MRD if
Acquisition Point ID
Valid String
Optional reference used by the POIS for
Acquisition Signal ID
Valid String
Optional reference used by the POIS for
State
Enabled
Enable or Disable Asynchronous message
Port
0-65535
Port on which the MRD 5800 will listen for
PID
SCTE 35 Pid present
PID on which the SCTE 35 messages will be
Disabled
Retry POIS
Discard Message
Disabled
the POIS
the timeout is reached
processing
processing
insertion
Page 54 (116)
in TS
SCTE 35 messages from the ESAM server
inserted in the transport stream
MRD 5800 – User Manual
Setting
Range
Description
Lookup Mode
Auto
Setting Lookup Mode t o aut o will use the
Manual Source ID
ASCII Characters
User defined Source ID will need to be less
Timeout (sec)
5 – 120 sec
This will define the timeout for automatic
Filter Mode
Pass All Operations
Setting Pass First Operation will filter SCTE
4.2.17 Configuring Ancillary Data Options
This menu allows the user to configure processing options relating to ancillary
(ANC/VBI) data generation. Currently it contains options for Source ID and, if the
SCTE35 license is enabled, it will also allow the user to configure the filter mode for
SCTE104 messages.
Manual
Pass First Operation
service information from the active stream
service information tables (if source id
present). Setting Lookup Mode to manual will
allow the user to input a user defined source
id.
than 14 characters
extraction.
104 messages with multiple OpIDs and only
pass the first OpID of that message.
4.2.18 Configuring SDI Outputs Port 1 & 2
The following menus allow the user to configure the embedded audio and auxiliary data
in the SDI video output for port 1 & 2. There are unique settings for SD and HD video. All
VANC embedding Line settings contain the values 4 through 19. All HANC embedding
Line settings contain the values 5 through 15.
Page 55 (116)
MRD 5800 – User Manual
Setting
Range
Description
Video Loss Mode
Disable SDI
Setting to Disab le SD I disables the SDI
General
Page 56 (116)
SD SDI Output Configuration Menu
Display Raster
output of the MRD in case of an error state.
Setting to Display Raster the MRD will
display the raster color selected in
4.2.10
Section
VANC Embedding
Setting
Range
Description
EIA 708-B
Enabled
Enable/Disable EIA 70 8-B Closed
ATC
Enabled
Enable/Disable Ancillary Time Code
TTX/VPS/WSS (S2031)
Enabled
Enable/Disable EN30177 5 VBI wa vef or m
AMOL/TVG2X/VITC
Enabled
Enable/Disable SCT E127 VBI wavef or m
AFD
Enabled
Enable/Disable Automatic Format
RDD11
Enabled
Enable/Disable Registered Disclosure
SMPTE2038
Enabled
Enable/Disable SMPTE2038 method of
VII AFD
Enabled
Enable/Disable AFD in Video Index Data
Source ID
Enabled
Enable/Disable Source ID embedding in
SCTE104
Enabled
Enable/Disable SCTE104 embedding in
Setting
Range
Description
TTX
Enabled
Enable/Disable Teletext embedding in the
VBI. The line which Teletext will be
MRD 5800 – User Manual
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Caption embedding in the VANC.
Choose one line between lines 4-19 to
embed data.
(ATC) embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
Description (AFD) embedding in the
VANC. Choose one line between lines 419 to embed data.
Document 11 (RDD11) embedding in the
VANC.
Disabled
Disabled
Disabled
Disabled
embedding data in the VANC.
embedding in the VANC. Choose one
line between lines 4-19 to embed data.
the VANC. Choose one line between
lines 4-19 to embed data.
the VANC. Choose one line between
lines 4-19 to embed data.
SD SDI VBI Embedding
When the MRD 5800 is configured to output SD video the VBI data can be encoded into
the vertical blanking as a VBI waveform. The options below allow the user to enable or
disable these waveforms.
Page 57 (116)
MRD 5800 – User Manual
Disabled
embedded is dependent on data in the
WSS
Enabled
Enable/Disable Widescreen Signaling (WSS)
VPS
Enabled
Enable/Disable Video Program System
AMOL
Enabled
Enable/Disable Automated Measurement of
TVG2X
Enabled
Enable/Disable TV Guide data embedding in
VITC
Enabled
Enable/Disable Vertical Interval Timecode
L21 Captions
Enabled
Enable/Disable Line 21 Closed Caption
incoming stream.
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
embedding in the VBI. WSS is output on line
23 in the VBI.
(VPS) embedding in the VBI. VPS is output
on line 16 in the VBI.
Lineups (AMOL) embedding in the VBI. The
line which AMOL will be embedded is
dependent on data in the incoming stream.
the VBI. The line which TVG2X will be
embedded is dependent on data in the
incoming stream.
embedding in the VBI. VITC is sourced from
the video elementary stream and is
embedded on line 14.
embedding in the VBI. Closed Captions are
output on line 21 in the VBI.
Page 58 (116)
MRD 5800 – User Manual
Setting
Range
Description
Video Loss Mode
Disable SDI
Setting to Disab le SD I squelches the SDI
General
Page 59 (116)
HD SDI Output Configuration Menu
Display Raster
output of the MRD in case of an error state.
Setting to Display Raster the MRD will
display the raster color selected in
4.2.9.
Section
MRD 5800 – User Manual
Setting
Range
Description
EIA 708-B
Enabled
Enable/Disable EIA 70 8-B Closed
VANC ATC
Enabled
Enable/Disable Ancillary Time Code
TTX/VPS/WSS (S2031)
Enabled
Enable/Disable EN30177 5 VBI wa vef or m
AMOL/TVG2X/VITC
Enabled
Enable/Disable SCT E127 VBI wavef or m
OP47
Enabled
Enable/Disable OP47 Subtitle
AFD
Enabled
Enable/Disable Automatic Format
RDD11
Enabled
Enable/Disable Registered Disclosure
HANC ATC
Enabled
Enable/Disable Ancillary Time Code
SMPTE2038
Enabled
Enable/Disable SMPTE2038 method of
Source ID
Enabled
Enable/Disable Source ID embedding in
SCTE104
Enabled
Enable/Disable SCTE104 embedding in
HD SDI VANC Embedding
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Caption embedding in the VANC.
Choose one line between lines 4-19 to
embed data.
(ATC) embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
embedding in the VANC. Choose one
line between lines 4-19 to embed data.
Description (AFD) embedding in the
VANC. Choose one line between lines 419 to embed data.
Disabled
Disabled
Disabled
Disabled
Disabled
Document 11 (RDD11) embedding in the
VANC.
(ATC) embedding in the HANC. Choose
one line between lines 5-15 to embed
data.
embedding data in the VANC.
the VANC. Choose one line between
lines 4-19 to embed data.
the VANC. Choose one line between
lines 4-19 to embed data.
4.2.19 Configuring SDI Audio Embedding
This menu allows the user to configure SDI embedded audio settings. The MRD 5800
comes standard with the ability to handle up to four audio services. With additional
licensing the MRD 5800 can handle up to eight unique audio services. When licensed for
eight audio services the user will have eight audio pairs available to embed audio in the
Page 60 (116)
MRD 5800 – User Manual
Setting
Range
Description
Group 1-4
Off
Assigning a PCM aud io to a Group Pa ir will em bed
SDI. These four groups consist of eight pairs, with two pairs to each group. All audio
pairs share the same options.
SDI Embedded Audio Configuration Menu
Pair 1-2
Page 61 (116)
Audio 1-8 PCM
Audio 1-8 Pass-through
the decoded or downmixed two channel audio using
the settings defined in
Pass-Through to a Group Pair will embed
unprocessed compressed audio in the SDI VANC.
Selecting Off disables the Group Pair completely.
Section 4.2.10. Assigning
MRD 5800 – User Manual
4.2.20 Configuring Secondary SDI Outputs
The following menus allow the user to configure the embedded audio and auxiliary data
in the secondary, simultaneous SDI video output. All VANC embedding Line settings
contain the values 4 through 19.
Page 62 (116)
General
Setting
Range
Description
Video Loss Mode
Disable SDI
Setting to Disab le SD I disables the SDI
Setting
Range
Description
EIA 708-B
Enabled
Enable/Disable EIA 70 8-B Closed
ATC
Enabled
Enable/Disable Ancillary Time Code
TTX/VPS/WSS (S2031)
Enabled
Enable/Disable EN30177 5 VBI wa vef or m
AMOL/TVG2X/VITC
Enabled
Enable/Disable SCT E127 VBI wavef or m
AFD
Enabled
Enable/Disable Automatic Format
RDD11
Enabled
Enable/Disable Registered Disclosure
SMPTE2038
Enabled
Enable/Disable SMPTE2038 method of
VII AFD
Enabled
Enable/Disable AFD in Video Index Data
Source ID
Enabled
Enable/Disable Source ID embedding in
SCTE104
Enabled
Enable/Disable SCTE104 embedding in
MRD 5800 – User Manual
VANC Embedding
Display Raster
Disabled
Disabled
Disabled
Disabled
output of the MRD in case of an error state.
Setting to Display Raster the MRD will
display the raster color selected in
4.2.9
Caption embedding in the VANC.
Choose one line between lines 4-19 to
embed data.
(ATC) embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
Section
Page 63 (116)
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Description (AFD) embedding in the
VANC. Choose one line between lines 419 to embed data.
Document 11 (RDD11) embedding in the
VANC.
embedding data in the VANC.
embedding in the VANC. Choose one
line between lines 4-19 to embed data.
the VANC. Choose one line between
lines 4-19 to embed data.
the VANC. Choose one line between
lines 4-19 to embed data.
MRD 5800 – User Manual
Setting
Range
Description
TTX
Enabled
Enable/Disable Teletext embedding in the
WSS
Enabled
Enable/Disable Widescreen Signaling (WSS)
VPS
Enabled
Enable/Disable Video Program System
AMOL
Enabled
Enable/Disable Automated Measurement of
TVG2X
Enabled
Enable/Disable TV Guide data embedding in
VITC
Enabled
Enable/Disable Vertical Interval Timecode
L21 Captions
Enabled
Enable/Disable Line 21 Closed Caption
SD SDI VBI Embedding
When the MRD 5800 is configured to output SD video the VBI data can be encoded into
the vertical blanking as a VBI waveform. The options below allow the user to enable or
disable these waveforms.
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
VBI. The line which Teletext will be
embedded is dependent on data in the
incoming stream.
embedding in the VBI. WSS is output on line
23 in the VBI.
(VPS) embedding in the VBI. VPS is output
on line 16 in the VBI.
Lineups (AMOL) embedding in the VBI. The
line which AMOL will be embedded is
dependent on data in the incoming stream.
the VBI. The line which TVG2X will be
embedded is dependent on data in the
incoming stream.
embedding in the VBI. VITC is sourced from
the video elementary stream and is
embedded on line 14.
embedding in the VBI. Closed Captions are
output on line 21 in the VBI.
4.2.21 Configuring Secondary SDI Audio Embedding
This menu allows the user to configure simultaneous SDI embedded audio settings. The
MRD 5800 comes standard with the ability to handle up to four audio services. With
additional licensing, the MRD 5800 can handle up to eight unique audio services. When
licensed for eight audio services, the user will have eight audio pairs available to embed
audio in the SDI output. These four groups consist of eight pairs, with two pairs to each
group. All audio pairs share the same options.
Page 64 (116)
MRD 5800 – User Manual
Setting
Range
Description
Group 1-4
Off
Assigning a PCM aud io to a Group Pa ir will em bed
Secondary SDI Embedded Audio Configuration Menu
Pair 1-2
Audio 1-8 PCM
Audio 1-8 Pass-through
Page 65 (116)
the decoded or downmixed two channel audio using
the settings defined in
Pass-Through to a Group Pair will embed
unprocessed compressed audio in the SDI VANC.
Selecting Off disables the Group Pair completely.
Section 4.2.10. Assigning
MRD 5800 – User Manual
Setting
Range
Description
Video Loss
Disable Composite
This option allows the user to define how the
NTSC Pedestal
Enabled
Enabling the NTSC Pedestal uses the NTSC
525 Standard
NTSC
Select the color subcarrier used for 525 line video
625 Standard
PAL-BGID
Select the color subcarrier used for 625 line video
TTX
Enabled
Enable/Disable Teletext embedding in the VBI. The
4.2.22 Configuring Composite Output
This menu allows the user to configure the composite video output (primary and
secondary if applicable) of the MRD 5800. Color subcarriers and VBI embedding are
configured in this menu. Please note that the composite video output is only active if the
output video format is SD.
Mode
Display Raster
Disabled
PAL-M
PAL-N
Disabled
composite video output reac ts when video is not
decoding. If Disable Composite is selected the
composite video output is squelched. If Display
Raster is selected the composite video output
displays the Raster Color defined in Section 4.2.9.
pedestal (7.5 IRE) for black levels.
formats.
formats.
line which Teletext will be embedded is dependent
on data in the incoming stream.
Page 66 (116)
MRD 5800 – User Manual
WSS
Enabled
Enable/Disable Widescreen Signaling (WSS)
VPS
Enabled
Enable/Disable Video Program System (VPS)
AMOL
Enabled
Enable/Disable Automated Measurement of Lineups
TVG2X
Enabled
Enable/Disable TV Guide data embedding in the
L21 Captions
Enabled
Enable/Disable Line 21 Closed Caption embedding
VITC
Enabled
Enable/Disable Vertical Interval Timecode (VITC)
Setting
Range
Description
Analog
Off
Assign Audio 1-8 to an analog audio output for
Level
-10-4
Level of the analog audio output in dBu.
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
embedding in the VBI. WSS is output on line 23 in
the VBI.
embedding in the VBI. VPS is output on line 16 in
the VBI.
(AMOL) embedding in the VBI. The line which
AMOL will be embedded is dependent on data in the
incoming stream.
VBI. The line which TVG2X will be embedded is
dependent on data in the incoming stream.
in the VBI. Closed Captions are output on line 21 in
the VBI.
embedding in the VBI. VITC is sourced from the
video elementary stream and is embedded on line
14.
4.2.23 Configuring Analog Audio Output
This menu allows the user to configure the analog output outputs of the MRD 5800. Four
analog audio outputs are available. The dBu level of the outputs can be adjusted for
each of the four audio outputs. For the Analog Output connector pin out refer to
Appendix C.
Output 1-4
Audio 1-8
Page 67 (116)
output. Select Off to disable the analog output
completely.
MRD 5800 – User Manual
Setting
Range
Description
Digital Output
Off
Assigning a PCM aud io to a digit al out put will outp ut
4.2.24 Configuring Digital Audio Output
This menu allows the user to configure the digital audio outputs of the MRD 5800. The
number of outputs available directly correlates with the number of audio services the unit
is licensed to support. Up to eig ht digital audio outputs are available.
1-8
Audio 1-8 PCM
Audio 1-8 Pass-through
the decoded or downmixed two channel audio using
the settings defined in
Pass-Through to a digita l output will output
unprocessed compressed audio. Selecting Off
disables the digital output completely.
Section 4.2.10. Assigning
4.2.25 PID Filter
If the PID/Service Filter license is enabled, the following menus and options will be
available for configuration. PID filtering will allow the user to create a new output TS by
selecting and dragging one or more services/PIDs from the incoming transport stream
into the Selected Services/Pids box or use the currently decoded stream. The user can
also configure a TS bitrate f or each PID filtered stream and select different table
inclusion options.
Page 68 (116)
MRD 5800 – User Manual
Setting
Range
Description
Select PID Filter
PID filter 1-10
Select which PID filter to configure
TS Bitrate (Mbps)
.25 to 160
Configure the TS Bitrate for the PID filter stream
Table Processing
PSI (MPEG)
Adjusted tables: PAT, PMT
Table Processing
SI (DVB)
Adjusted tables: PAT, PMT,SDT
Selection Mode
Use Selected
Use Selected Services/PIDs will allow the user to
selected
Mode
Mode
Services/PIDs
Use Decoded Service
Passed tables: CAT, NIT
Discarded tables: all remaining
Passed tables: CAT, NIT, EIT, RST, TDT, TOT
Discarded tables: TSDT, BAT
select which services are in the new TS. Use
Decoded Service will only include the service that
is currently selected for decoding by the MRD 5800
4.2.26 Configuring ASI Output
This menu allows the user to configure the ASI output of the MRD 5800. When enabled
this output acts as an active loop output of the active input. For example, if the DVBS/S2 input card is the current active input the ASI output port will output a demodulated
signal of the satellite input.
Page 69 (116)
MRD 5800 – User Manual
Setting
Range
Description
Port
Enabled
Enable or disable the ASI output port.
Source
Unmodified Input
Unmodified Input will pass the incoming TS to the
Disabled
Descrambled
Descrambled and
Processed
Pid Filter 1-10
output without applying any BISS or DVB-CI
decryption
Descrambled (or Descrambled and Processed) will
output the TS with any applied BISS or DVB-CI
decryption.
PID Filter will output the TS from the PID filter menu
option.
4.2.27 Configuring the MPEG/IP Outputs
This menu allows the user to configure the MPEG/IP outputs. Each MPEG/IP card has
two ports that can be set to receive and/or transmit. This menu is for setting up the
transmission of MPEG/IP unicast or multicast transport streams. The menu for Stream 1
and 2 have the same settings.The menu for Streams 3 through 10 will contain the same
options as Transmit 1 and Transmit 2 with one exception: Forward Error Correction is
only available (if licensed) on Transmit 1 and 2.
Page 70 (116)
MRD 5800 – User Manual
Setting
Range
Description
Transmit
Enabled
Enable or disable the MPEG/IP transmit group.
Source
Unmodified Input
Unmodified Input will pass the incoming TS to the
Physical
Port 1
The physical connector on the MPEG/IP card that
Destination IP
Multicast - 224.0.0.0 -
When sending to a unicast address the destination
Destination Port
0 - 65535
When sending to a unicast address, the destination
sending a multicast, any port within the accepted
Disabled
Descrambled
Descrambled and
Processed
Pid Filter 1-10
Connector
Port 2
239.255.255.255
output without applying any BISS or DVB-CI
decryption.
Descrambled (or Descrambled and Processed) will
output the TS with any applied BISS or DVB-CI
decryption.
PID Filter will output the TS from the PID filter
menu option.
will be used to transmit the output.
IP address must match the receiving device’s IP
address. When sending a multicast the address
must be sent within the multicast IP range.
port must match the receiving device’s port. When
Page 71 (116)
MRD 5800 – User Manual
range can be used, but it is good practice to always
Source Port
0 - 65535
This is the port used by the MRD 5800 to transmit
TS Packets Per IP
1-7
The number of TS packets that are contained with
Differentiated
Default
Define the quality of service (QoS) classification the
Encapsulation
UDP
Sets the Encapsulation to UDP or RTP.
FEC
Off
Sets the FEC Type or disables FEC.
FEC Columns
1-20 (Columns)
Defines the number of Columns used to construct
FEC Rows
4-20
Defines the number of Rows used to construct the
choose a port >1030 and an even number
the MPEG/IP stream.
Packet
Services
Assured Forwarding
1-1 to 4-3
Expedited
Forwarding
RTP
Columns
Colums/Rows
4-20 (Columns/Rows)
a single IP packet. Default is 7. Lowering this value
below default increases network overheard.
packets carry when transmitted.
the FEC Matrix. (Columns * Rows must be ≤ 100.)
FEC Matrix. (Columns * Rows must be ≤ 100.)
4.2.28 Configuring the MPEG/IP MPE Outputs
This menu allows the user to configure the MPEG/IP Multi-Protocol Encapsulation
(MPE) outputs. Each MPE Output allows the user to select an MPE data PID from the
transport stream to be output.
Page 72 (116)
MRD 5800 – User Manual
Setting
Range
Description
Transmit
Enabled
Enable or disable transmission of de-encapsulated
Physical
Port 1
The physical connector on the MPEG/IP card that
PID
Selected MPE PID from the transport stream to use
MAC Filter State
Enabled
Enable or Disable the filtering of output data based
MAC Address
00:00:00:00:00:00
Filtered MAC address that will be transmitted in the
Connector
Disabled
Port 2
Disabled
FF:FF:FF:FF:FF:FF
MPE data.
will be used to transmit the MPE data.
for MPE output
on a MAC address in the selected MPE PID
MPE output. All data with other MAC addresses in
the selected MPE PID will be discarded
Page 73 (116)
MRD 5800 – User Manual
4.2.29 Vie wing PSIP Informa tion
To view the PSIP information for the applied TS, select the View PSI Tables button
located on the right hand side of the Inputs section. This will open a new window that
displays all of the PSIP information for the applied TS. The tables displayed will include
PAT, PMT and CAT and tables associated with the stream type (DVB,ATSC). SDT
tables will be displayed for DVB streams and MGT,TVCT,EIT, ETT, STT tables will be
displayed for ATSC streams.
Clicking the Refresh button in the upper left corner will update the tables displayed.
Page 74 (116)
4.3 Admin Panel
MRD 5800 – User Manual
To access the Admin Control Panel, click on the tab. This menu allows the
user to control many aspects of the MRD 5800.
Page 75 (116)
MRD 5800 – User Manual
Action
Button
Description
Add New Profile
Adds a new profile from current settings. User must
Upload Profile
Allows the user to browse to external storage or
Apply Profile
Select a profile from the drop down menu and click
4.3.1 Changing Unit Password
The MRD 5800 can be assigned an access password and the current access password
can be changed. In order to make changes to passwords, click the
button. A window will appear to enter the current password and new password.
4.3.2 Profiles
The MRD 5800 has the ability to save all configured settings to multiple profiles. Profiles
can be saved locally, renamed and saved to external storage to be used on other MRD
5800s. Profiles can be used to quickly and easily change the configuration of an MRD
5800 to suit different inputs and decoding requirements.
Page 76 (116)
name profile before creation is complete.
workstation to upload profile to MRD 5800.
this button. The MRD 5800 will apply all settings
contained in the profile selected.
MRD 5800 – User Manual
Rename Profile
Select a profile from the drop down menu and click
Delete Profile
Select a profile from the drop down menu and click
Download Profile
Select a profile from the drop down menu and click
this button. The user will be prompted for a new
name for the profile.
this button. The user will be prompted to confirm
deletion of the profile.
this button. The user will be prompted to select a
directory to download the profile.
4.3.3 General Settings
The MRD 5800 can be assigned an alias which is displayed in the upper right hand
corner of the web interface. The alias can help define which MRD 5800 the operator is
currently logged into. The BISS-E Injected ID for BISS Mode E can also be protected
from being accidently changed. Setting the Protect BISS-E Injected ID to Yes will force
the user to unlock the dialog box in the BISS Descrambling configuration menu before
allowing any changes to be made. The edit the Unit Alias or protect the BISS-E Inj ected I
D click on the button. The Relay Power Cycle Behavior
dropdown allows the user to configure the relays to change state on power cyle or
remain in the same state on power cycle.
4.3.4 Unit Network Configura t ion
The management port of the MRD 5800 can be configured from the web interface. To
make changes to the management port click, the but t on under the Unit Network
Configuration section.
If the MRD 5800 contains a 58127 option card the unit can be configured to have an
optional 2
Page 77 (116)
nd
control port.
MRD 5800 – User Manual
Setting
Range
Description
Mode
DHCP
Setting to DHCP will allow the network assign an IP
Hostname
Valid characters:
This setting allows the user to define an optional
IP
Four decimal octets:
This option is only available if Static Mode is set.
Subnet Mask
255.0.0.0 –
This option is only available if Static Mode is set.
Gateway
Four decimal octets:
This option is only available if Static Mode is set.
NOTE: Exercise extreme caution when performing changes to this menu as
network communication can be lost with the MRD 5800.
Static
A through Z
0 through 9
- (hyphen)
XXX.XXX.XXX.XXX
255.255.255.254
XXX.XXX.XXX.XXX
address automatically to the MRD 5800 (if
supported). Setting to Static allows the user to
manually define all TCP/IP settings for the
management port.
unit Hostname.
This is the IP address assigned to the management
port.
This is the Subnet Mask assigned to the
management port.
This is the Gateway address assigned to the
management port.
The 2nd management port of the MRD 5800 can be configured from the web interface.
To mak e changes to which port is the 2nd management port click, the configure control
ports button under the Unit Network Configuration section.
4.3.5 MPEG/IP Network Configuration
The MPEG/IP card is used to receive MPEG over IP transport streams. The MPEG/IP
card supported unicast, multicast, UDP and RTP. The ports of t he MPEG/IP card on the
Page 78 (116)
MRD 5800 – User Manual
Setting
Range
Description
Default Gateway
Port 1
Setting to Port 1 uses the gateway address of port
ICMP Response
Enabled
Setting to enabled allows the MRD 5800 to respond
Setting
Range
Description
IP Address
1.0.0.0 - 126.0.0.0
This setting is the TCP/IP address assigned to the
Subnet Mask
255.0.0.0 –
This setting is the subnet mask assigned to the
MRD 5800 can be configured from the web interface. To configure the Default Gateway
and ICMP Response settings click the button.
Port 2
Disabled
1 as the default gateway. Setting to Port 2 uses the
gateway address of port 2 as the default gateway.
to ICMP requests (ping). If disabled the MRD 5800
will not respond to these requests.
To configure the TCP/IP settings of the MPEG/IP ports click the button under the
MPEG/IP Network Configuration section next to the corresponding port. The settings for
both ports are the same.
128.0.0.0 -
191.255.0.0
192.0.1.0 -
223.255.255.0
Page 79 (116)
port.
MRD 5800 – User Manual
255.255.255.254
port.
Gateway
1.0.0.0 - 126.0.0.0
This setting is the gateway address assigned to the
Link Speed
Auto
Setting Link Speed to Auto allows the MRD 5800 to
128.0.0.0 -
191.255.0.0
192.0.1.0 -
223.255.255.0
1000Mbps/Full
1000Mbps/Half
100Mbps/Full
100Mbps/Half
10Mbps/Full
10Mbps/Half
port.
determine the link speed of the network. If this is
not possible or the user wants to define a link
speed select one of the other values available.
4.3.6 Licensing
Certain features of the MRD 5800 require licenses in order to be functional. The
interface displays all licenses available as well as the following status:
• License Locked or Unlocked
• License is Supported or Unsupported by the installed hardware
If licenses need to be applied to the MRD 5800 click button. The menu
below will appear where the user can copy and paste the provided license key from
Sencore. The currently applied license key can be viewed by clicking the
button.
4.3.7 Date/Time
The MRD 5800 can be set to synchronize with an NTP server or a manual data and time
can be defined by the user. Click the button to configure the date
and time. These values are used to timestamp entries in the Alarm and Event logs under
the Reporting tab.
Page 80 (116)
MRD 5800 – User Manual
Setting
Range
Description
Update Mode
NTP
Setting to NTP uses the local network’s NTP server
NTP Server
Four decimal octets:
This is the IP Address or Domain Name of the local
Date
MM/DD/YYYY
This setting is the user defined date. A calendar
Time
00:00:00 – 24:00:00
This setting is the user defined time. The time is
Manual
XXX.XXX.XXX.XXX
Domain Name
to synchronize date and time. Manual allows the
user to define a date and time.
NTP Server on the network. This setting is only
available if Update Mode is set to NTP.
widget can be used to select the data by clicking
the button. This setting is only available if
Update Mode is set to Manual.
based on a 24 hour clock. This setting is only
available if the Update Mode is set to Manual.
4.3.8 Configuring SNMP
4.3.8.1 SNMP Communities
SNMP Communities define whether users have read-only or read-write SNMP rights.
These two communities are given unique names. The default names for these
communities are:
• Read –Only Community: public
• Read- Write Community: private
To modify the names of these communities click on the button.
Page 81 (116)
MRD 5800 – User Manual
Action
Button
Description
Add Manager
Clicking this button prompts the user for the IP
Delete All
Clicking this button prompts the user to confirm the
Delete Single Entry
Highlight a single SNMP trap manager IP address
4.3.8.2 SNMP Trap Managers
The SNMP trap managers are recipients of SNMP traps sent from the MRD 5800. The
following menu allows the user to configure the recipient’s IP addresses. To add and
remove recipients of the SNMP traps click the button.
4.3.8.3 Download SNMP MIB Files
The MRD 5800 stores the SNMP MIB files for the currently installed version of software
on the unit. These files can be downloaded directly from the MRD 5800 by clicking on
Page 82 (116)
address of the SNMP trap manager.
deletion of all SNMP trap manager IP addresses. If
the user confirms deletion all SNMP trap manager
IP addresses will be removed.
and click this button to delete the entry. A prompt
will appear confirming the deletion of IP address .
MRD 5800 – User Manual
Action
Range
Description
State
Enabled
Enable or Disable sending messages to Syslog
Network Protocol
UDP
Select which network protocol used to transmit to
IP Address
Four decimal octets:
IP of the Syslog server. 0.0.0.0 and
Port
0 - 65535
Destination port of the Syslog server
the button. The screen below will appear where the files can be downloaded
and saved off of the unit.
4.3.9 Syslog
The MRD 5800 can be configured to send error and event logs formatted in the syslog
protocol to a remote user specified Syslog server.
Disabled
TCP
server.
the Syslog server
XXX.XXX.XXX.XXX
Page 83 (116)
255.255.255.255 are not permitted
MRD 5800 – User Manual
Action
Range
Description
State
Enabled
Enable or Disable the In-Band Control.
PID
1-8190
Sets the unit to look for commands on the PID that
Group
None
This setting assigns the unit to a corresponding
4.3.10 In-Band Control
The In-Band Control is used to change settings and receive updates from data within a
PID in the incoming TS, as injected by the Sencore CMD 4000 In-band Control Server.
The following menu allows the user to configure the In-Band Control settings. To
configure the In-Band Control settings click the button.
Disabled
is set.
1-128
Group or No Group.
4.3.11 Updating the MRD 5800
4.3.11.1 Applying Software Updates
Updates to the MRD 5800 are performed through the web interface. A software update
file is provided by Sencore and then uploaded to the unit. Once uploaded, the software
update is applied to the unit. To upload software updates to the unit click on the
button. The current version and uploaded version is displayed in the
Software Versions section. The MRD 5800 will reboot after a software update is
complete.
Page 84 (116)
MRD 5800 – User Manual
Action
Button
Description
Upload Software
To upload software updates to the MRD 5800 click
Delete the
Clicking this button prompts the user to confirm the
Update Software to
Clicking the button starts the software update
Update
Uploaded Software
Uploaded Version
this button. The user will be prompted to navigate
to an update file. The file will then upload to the
MRD 5800. When complete the MRD 5800 with
prompt the user to either apply the update or
cancel
deletion of the software update from the MRD
5800. This will also clear the Uploaded Version
status of the Software Versions section.
process. The MRD 5800 will prompt the user to
confirm the update. Click Yes to continue or No to
cancel.
4.3.11.2 Rollback Software Updates
The MRD 5800 is capable of reverting back to a previous version of software using the
Rollback feature. The MRD 5800 maintains two separate software images; one is the
most current version of software with all current settings and the other is the previous
version of software with all settings. To perform a rollback, click the button
and then click the tab. The MRD 5800 will reboot after the rollback process is
complete.
Page 85 (116)
MRD 5800 – User Manual
Action
Button
Description
Rollback Software
Clicking this button starts the Rollback process.
The MRD 5800 will prompt the user to confirm the
rollback or click cancel to stop the process.
4.3.12 Reboot Unit
The MRD 5800 can be rebooted from the web interface. In order to perform a reboot
click the button. The MRD 5800 will prompt the user to confirm the reboot.
Once the reboot is complete the login screen will appear allowing the web interface to be
logged into.
4.3.13 Reset Defaults
The MRD 5800 settings can be reset to factory defaults. All settings will be r etur ned to
the factory defaults except the network management ports TCP/IP settings. All event
logs will be cleared. To reset all settings to default click the button. The
MRD 5800 will prompt the user to confirm the reset.
Page 86 (116)
4.4 Reporting Panel
Title
Description
MRD 5800 – User Manual
The tab in the MRD 5800 contains logs for active alarms currently affecting
the unit and an event log. The active alarms are updated periodically in order to reflect
the real-time state of the unit. Once an error is cleared it will be cleared from the active
alarms window. The event log can be used to view alarm and event history. Both the
active alarm and event logs can be configured to hide or change the behavior of alarms
and events.
4.4.1 Active Alarms
Clicking on the button displays the Active Alarms menu. This list displays all
of the active alarms currently affecting the unit. There are four columns in the log that
display different types of information.
Page 87 (116)
MRD 5800 – User Manual
State
This column displays the nature of the alarm. The icon means the log
Name
This column displays the description of the error. The function that is
Location
This column displays the hardware or function that is experiencing the
Last Changed
This column displays the data and time the error was raised. This data
Title
Description
Severity
This column displays the nature of the alarm. The icon means the log
entry is informational and is not an error. The icon means the log
entry is an active alarm.
experiencing an error condition is described here.
active error.
and time correlates with the Date and Time settings configured in
Section 4.3.7.
4.4.2 Event Logs
Clicking on the button displays the Event Log menu. This list displays all of
the events and alarms that have affected the unit. The MRD 5800 stores up to four days’
worth of logs. If the unit is rebooted or powered off and on the event logs are cleared.
The logs can be cleared manually by clicking the button. The logs can be
downloaded as a .tsv file and saved to an external location by clicking the
button. There are five columns in the log that display different types of information.
entry is informational and is not an error. The icon means the log
Page 88 (116)
MRD 5800 – User Manual
entry is an active alarm.
Timestamp
This column displays the data and time the error was raised or cleared.
Transition
This column displays when an alarm transition from a bad to good state.
Message
This column displays the description of the error or event. The function
Location
This column displays the hardware or function that experienced the
Title
Description
This data and time correlates with the Date and Time settings configured
in Section 4.3.7.
When an error is raised the icon is displayed. When an error is
cleared the icon is displayed. When an event takes place the icon
is displayed.
or hardware that experienced the event or error is described here.
alarm or event.
4.4.3 Configuring the Logs
The MRD 5800 allows the user to configure alarms and events. Events and alarms can
be hidden, set to send SNMP traps or close a relay when active. In order to configure
these options click the button while in the section of the
tab. The tab allows the user to configure the alarms reported by
the MRD 5800. The tab allows the user to configure the events reported by the
MRD 5800. Each column and its function are described below. A user configured time
offset can also be applied to allow viewing the logs in a local time zone.
Page 89 (116)
MRD 5800 – User Manual
Name
This column displays the name of the error or condition. This is
Location
This column displays the hardware or function that the alarm or event
Log
Checking the box in this column creates an entry in the event log in the
Log Severity
This column is only available in the tab This option allows the
Alarm
This column is only available in the tab This option allows the
SNMP Trap
This column allows the user to send an SNMP Trap if this alarm is
Relay
This column allows the user to set a Relay closure if this alarm is raised.
Relay #
This column allows the user to select which of the three relays available
Relay Duration
This column is only available in the tab. This option allows the
informational data: no options can be set here.
applies to. This is informational data; no options can be set here.
case this error or event is raised. If this box is unchecked this error or
event will be hidden and not logged if raised.
user to set the severity of the error to Info or Error. If Info is selected in
the drop down box the icon will displayed in the event log. If Error is
selected the icon will be displa yed in the event log.
user to enable or disable this alarm in the Active Alarms log. If checked
the alarm will be displayed in the Active Alarms log if raised. If this box is
unchecked this error will be hidden.
raised. If this box is checked an SNMP Trap is sent when this alarm is
raised. If this box is unchecked an SNMP is not sent.
If this box is checked a Relay will be closed. If this box is unchecked a
Relay will not be closed. See Appendix C for pinout.
on the MRD 5800 will be closed when the alarm is raised.
user to define the length of time in milliseconds the relay will be closed
after the event is logged. This setting can be configured from 100-1000
milliseconds.
Page 90 (116)
4.5 About Panel
MRD 5800 – User Manual
Under the tab, there are no user definable parameters but there is information
about software versions currently installed, which licenses are installed, how to contact
Sencore, and third party software information.
Page 91 (116)
MRD 5800 – User Manual
Section 5 Appendices
Introduction
This section includes the following appendices:
Appendix A – Acronyms and Glossary .................................................... 93
Appendix B – Error and Event List ........................................................... 96
Appendix C – Specifications ..................................................................... 99
Appendix D – Pinouts for Analog Audio and Relay Connectors ......... 108
108
Appendix E – MRD 5800 Dolby Audio Explanation ............................... 109
Appendix F – MRD 5800 Discrete Audio Configuration ....................... 112
Appendix G – Open Source Software ..................................................... 113
Appendix H – Warranty ........................................................................... 115
Appendix I – Support and Contact Information ................................... 115
Page 92 (116)
MRD 5800 – User Manual
Appendix A – Acr onyms and Glossary
8VSB: Vestigial sideband modulation with 8 discrete amplitude levels.
16VSB: Vestigial sideband modulation with 16 discrete amplitude levels.
AAC: Advanced Audio Coding
AC-3: Also known as Dolby Digital
AES: Audio Engineering Society
AFD: Auto Format Descriptor
ASI: Asynchronous Serial Interface
ATSC: Advanced Television Systems Committee
AV: Audio Video
Bit Rate: The rate at which the compressed bit stream is delivered from the channel to
the input of a decoder.
BNC: British Naval Connector
BPS: Bits per second.
CAM: Conditional Access Module
CAT: Conditional Access Table
CAT6: Category 6 – Cable standard for gigabit Ethernet
CC: Closed Caption
CI: Common Interface
CoP: Code of Practice
CRC: Cyclic Redundancy Check
CVCT: Cable Virtual Channel Table
dB: Decibel
DDPlus: Dolby Digital Plus
DHCP: Dynamic Host Configuration Protocol
DPI: Digital Program Insertion
DTVCC: Digital Television Closed Captioning
DVB: Digital Video Broadcasting
EBU: European Broadcasting Union
EIA: Electronic Industries Alliance
EIT: Event Information Table
EPG: Electronic Program Guide
ETM: Extended Text Message
ETT: Extended Text Table
Event: An event is defined as a collection of elementary streams with a common time
base, an associated start time, and an associated end time.
FCC: Federal Communications Commission
FEC: Forward Error Correction
Field: For an interlaced video signal, a “field” is the assembly of alternate lines of a
frame. Therefore, an interlaced frame is composed of two fields, a top field and a
bottom field.
Frame: A frame contains lines of spatial information of a video signal. For progressive
video, these lines contain samples starting from one time instant and continuing
through successive lines to the bottom of the frame. For interlaced video a frame
consists of two fields, a top field and a bottom field. One of these fields will
commence one field later than the other.
HANC: Horizontal Ancillary
HD: High Definition
High level: A range of allowed picture parameters defined by the MPEG-2 video coding
specification which corresponds to high definition television.
Page 93 (116)
MRD 5800 – User Manual
I/O: Input/Output
IP: Internet Protocol
Kbps: 1000 bit per second
LED: Light Emitting Diode
LNB: Low-Noise Block
MAC: Medium Access Control
Main level: A range of allowed picture parameters defined by the MPEG-2 video coding
specification with maximum resolution equivalent to ITU-R Recommendation 601.
Main profile: A subset of the syntax of the MPEG-2 video coding specification that is
expected to be supported over a large range of applications.
Mbps: 1,000,000 bits per second.
MER: Modulation Error Ratio
MGT: Master Guide Table
MIB: Management Information Base
MP@HL: Main profile at high level.
MP@ML: Main profile at main level.
MPEG: Refers to standards developed by the ISO/IEC JTC1/SC29 WG11, Moving
Picture Experts Group. MPEG may also refer to the Group.
MPEG-2: Refers to ISO/IEC standards 13818-1 (Systems), 13818-2 (Video), 13818-3
(Audio), 13818-4
MPTS: Multiprogram Transport Stream
MRD: Modular Receiver Decoder
NTP: Networking Time Protocol
NTSC: National Television System Committee
OSD: On Screen Display
PAL: Phase-Alternating Line
PAT: Program Association Table
PCM: Pulse-Code Modulation
PCR: Program Clock Reference
PCM: Pulse-code Modulation
PID: Packet Identifier. A unique integer value used to associate elementary streams of a
program in a single or multi-program transport stream.
PMT: Program Map Table
Profile: A defined subset of the syntax specified in the MPEG-2 video coding
specification
Program specific information (PSI):
PSI consists of normative data which is
necessary for the demultiplexing of transport streams and the successful
regeneration of programs.
Program: A program is a collection of program elements. Program elements may be
elementary streams. Program elements need not have any defined time base; those
that do have a common time base and are intended for synchronized presentation.
PTS: Presentation Time Stamp
QAM: Quadrature Amplitude Modulation
QPSK: Quadrature Phase-Shift Keying
RDS: Receiver Decoder System
RF: Radio Frequency
RGBHV: Red, Green, Blue, Horizontal, Vertical
RO: Read Only
RPM: Revolutions Per Minute
RRT: Rating Region Table
RS-232: Recommended Standard. A standard for serial binary data interconnection.
Page 94 (116)
MRD 5800 – User Manual
RU: Rack Unit
RW: Read/Write
SD: Standard Definition
SDI: Serial Digital Interface
SFP: Small Form-Factor Pluggable
SI: System Information
SMPTE: Society of Motion Pictures and Television Engineers
SNMP: Simple Network Management Protocol
SPTS: Single Program Transport Stream
SSRC: Synchronization Source
STD input buffer: A first-in, first-out buffer at the input of a system target decoder for
storage of compressed data from elementary streams before decoding.
STD: System Target Decoder. A hypothetical reference model of a decoding process
used to describe the semantics of the Digital Television Standard multiplexed bit
stream.
STT: System Time Table
TS: Transport Stream
TVCT: T errestr ial Virtual Channel Table
UTC: Coordinated Universal Time
VANC: Ver tical Ancillary
VBI: Video Blanking Interval
VCT: Virtu al Channel Table. Used in reference to either TVCT or CVCT.
XLR: Cannon “X” series connector, with a Latch, and Rubber around the contacts.
YPbPr: Component Red, Green, Blue
Page 95 (116)
MRD 5800 – User Manual
Error
Description
12V Supply Error
Voltage on 12V rail has exceeded safe operational range.
3.3V Supply Error
Voltage on 3.3V rail has exceeded safe operational range.
5V Supply Error
Voltage on 5V rail has exceeded safe operational range.
AFD Not Present
Auto Conversion is enabled in Video Service configuration but
ANC/VBI Line Conflict -
The VANC line AFD is currently set to be embedded on is
ANC/VBI Line Conflict -
The VANC line AMOL is currently set to be embedded on is
ANC/VBI Line Conflict -
The VANC line CC is currently set to be embedded on is
ANC/VBI Line Conflict –
The VANC line EN301 775 i s curr entl y set to be embedded on is
ANC/VBI Line Conflict –
The VANC line OP47 is currently set to be embedded on is
ANC/VBI Line Conflict –
The VANC line RDD11 is currently set to be embedded on is
ANC/VBI Line Conflict –
The VANC line SCTE127 is currently set to be embedded on is
ANC/VBI Line Conflict –
The VANC line SMPTE2038 is currently set to be embedded on
ANC/VBI Line Conflict –
The VANC line Source ID is currently set to be embedded on is
ANC/VBI Line Conflict –
The VANC line Timecode is currently set to be embedded on is
ANC/VBI Line Conflict -
The VANC line Teletext is currently set to be embedded on is
ANC/VBI Line Conflict –
The VANC line TVG2X is currently set to be embedded on is
ANC/VBI Line Conflict -
The VANC line VII is currently set to be embedded on is
ANC/VBI Line Conflict -
The VANC line VPS is currently set to be embedded on is
ANC/VBI Line Conflict -
The VANC line WSS is currently set to be embedded on is
Audio Not Decoding
Audio is corrupted in incoming stream or format is not supported.
Auto Video Format Error
MRD 5800 is unable to determine the native incoming video in
BISS Conflicting PIDs
PIDs selected to be descrambled by one BISS key are already
Appendix B – Error and Event List
the stream does not contain an AFD code.
AFD
AMOL
CC
EN301775
OP47
RDD11
SCTE127
SMPTE2038
Source ID
System Timecode
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
is conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
Teletext
TVG2X
VII
VPS
WSS
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
conflicting with another line of data in the VANC.
order to format output.
assigned to be descrambled by another BISS key.
Page 96 (116)
MRD 5800 – User Manual
BISS Service Not Found
Service that BISS key is assigned to descramble is not present in
Backup Input Active
Primary input is currently in a failed condition and the MRD 5800
Bitrate Exceeded Error
Total incoming transport stream bitrate has exceeded 213 Mbps.
CAM Descramble Fail
CAM Module is not descrambling selec ted pids or services
CAM Not Present
DVB-CI Descrambling is enabled but CAM Module is not
CAM PID Not Found
PID selected to be descrambled by the CAM is not present in the
ES Type Mismatch
Elementary stream type does not match the stream type defined
FEC Reception Error
Packets in incoming IP stream cannot be repaired with forward
Fan Speed Below Lower
Cooling fan in the MRD 5800 has failed.
Genlock Not Present
Genlock reference is enabled but not present.
IP Loss Error
No IP packets have been received by the MPEG/IP card for two
ISI Not Found
ISI value defined by the user is not found in the incoming
Incompatible Genlock
External genlock reference is not compatible with output video
Input Video Unsupported
Native format of incoming video is not a supported video format.
LNB Power Error
LNB Power is enabled but the MRD 5800 is detecting power is
Link Loss Error
Physical IP link is not present on the MPEG/IP card.
Loss of Carrier Lock
Receiver carrier lock source is lost.
Low Level
8VSB/QAM RF Level is below the user settable threshold
Low Mer
8VSB/QAM MER is below the user settable threshold
Multistream Mode Input
Multistream Mode is enabled and input signal is not multistream
No Services Detected
Service Lock service selection mode is enabled but no services
Pid Filter Overflow Error
Configured PID Filter TS rate is too low.
Pid Filter Selection Not
Selected Service or PID is not present for inclusion in the output
Power Supply Error
Power is lost to one of the Redu nda nt Po wer Suppl ies
RDD11 Overflow
RDD11 data cannot fit into the VANC em bedding li ne s elected .
RTP Reception Error
Uncorrectable out of order or duplicate packets are present in
the incoming stream.
Condition
Limit
Reference
has failed over to the Backup input.
installed.
incoming stream.
by the user.
error correction.
seconds.
multistream signal.
format.
Mismatch
Present
being provided by another source, there is excessive current
drain or an overvoltage has occurred.
capable or Multistream Mode is disabled and input signal is
multistream capable.
are present in the active input transport stream.
PID filter TS.
Page 97 (116)
MRD 5800 – User Manual
incoming IP stream.
SCTE35 Heartbeat
The user settable time limit has been exceeded between
ES Sync Error Condition
One of the in-use elementary streams is not synchronized to the
Selected Audio PID Not
PID Locked mode is set as service selection mode and audio PID
Selected PCR PID Not
PID Locked mode is set as service selection mode and PCR PID
Selected SCTE35 PID Not
PID Locked mode is set as service selection mode and SCTE35
Selected Video PID Not
PID Locked mode is set as service selection mode and video PID
Service Not Found
Service Lock service selection mode is enabled but service
Temperature Erro r
The MRD 5800 has detected the internal temperature is 60
Transport Error Indicator
The MRD 5800 has detected that the transport stream error
Transport Stream Not
The MRD 5800 has detected that the transport stream from the
TS Sync Loss
Transport stream sync for IP stream is not detected.
Unicast Receiver Not
The MRD 5800 cannot discover the destination for the unicast IP
Unlicensed Modulation
Input stream on active input is either 16APSK or 32APSK and the
Unlicensed
Input stream on the active input contains a multistream signal
Video Not Decoding
The configured service or video PID to be decoded is not being
Timeout
Present
Present
Present
Present
Present
SCTE35 messages.
PCR
defined by user is not present in the incoming stream.
defined by user is not present in the incoming stream.
PID defined by user is not present in the incoming stream.
defined by user is not present in the incoming stream.
defined by user is not present in the incoming stream.
degrees Celsius or above.
indicator is present on the active input.
active input is no longer present.
Found Error
VCM/Multistream
stream within 10 seconds after the initial ARP is sent.
modulations are no licensed on the MRD 5800.
and the MRD 5800 is not licensed for multistream.
successfully decoded by the MRD 5800.
Page 98 (116)
MRD 5800 – User Manual
Includes –
Display, keypad, embedded controller, chassis/case,
power supply/line cord
System –
Display Type:
LCD
Display Configuration:
240 pixels by 64 pixels
Keypad:
Snap-dome Membrane
Front Panel Lockout:
Password control, up to 8 alpha-numeric characters (no
punctuations or spaces allows)
Configurations Allows:
Single video decoder with up to two option cards
Rear Panel:
Fixed inputs and outputs with two option card slots.
Option cards not field upgradeable.
Remote Operation/Update Interface –
Type:
Ethernet, 10/100
Rear Panels indicators:
Link (Green LED), Activity (Amber LED)
Connector:
RJ45
Front Panel Indicators –
Error LED:
Red indicates error is occurring
Off indicates no errors detected
INPUT LED:
Green indicates valid input is present
Off indicates no valid input
Monitor and Control Interfaces –
Web server GUI:
HTTP via web browsing for control & monitoring
Front Panel:
Control & monitoring
SNMP:
Control & monitoring
Operating Altitudes
0 to 10000 feet
AC Power –
Operating Voltage:
100-240VAC
PSU Max Power:
150W
Current Draw:
Base Unit with no option cards –
38-40W
Base Unit with active ASI input –
54-55W
MPEG/IP option card with active input –
2-3W (additional)
DVB-S/S2 option card with active input and LNB load of
8-9W (additional)
DVB-CI Module option with 2 CAM Modu les inst a lled –
8VSB/QAM option card with acti ve input –
2-3W (additional)
Max Power Draw:
70-72W
Frequency:
48-63Hz
Connector:
IEC C14
Line Cord:
Detachable, 3-prong
Dual Redundant AC Po w er Option–
Operating Voltage:
100-240VAC
Appendix C – Specifications
MRD 5800 – Base Unit
Page 99 (116)
19V @ 500mA –
2-3W (additional)
MRD 5800 – User Manual
PSU Max Power:
150W
Current Draw:
Base Unit with no option cards –
38-40W
Base Unit with active ASI input –
54-55W
MPEG/IP option card with active input –
2-3W (additional)
DVB-S/S2 option card with active input and LNB load of
8-9W (additional)
DVB-CI Module option with 2 CAM Modules installed –
2-3W (additional)
Max Power Draw:
70-72W
Frequency:
50/60Hz
Connector:
IEC C14
Line Cord:
Detachable, 3-prong
Redundancy:
Load Sharing
DC Power –
Operating Voltage:
36-72V DC
PSU Max Power:
200W
Current Draw:
Base Unit with no option cards –
38-40W
Base Unit with active ASI input –
54-55W
MPEG/IP option card with active input –
2-3W (additional)
DVB-S/S2 option card with active input and LNB load of
8-9W (additional)
DVB-CI Module option with 2 CAM Modules installed –
8VSB/QAM option card with acti ve input –
2-3W (additional)
Max Power Draw:
70-72W
Connector:
2 pin terminal block
Genlock Interface (MRD 58701) Adds –
Genlock Connector:
75Ω Female BNC
Input Impedance:
10kΩ
Return Loss:
≥20 dB, 0Mhz to 8 Mhz
19V @ 500mA –
2-3W (additional)
8VSB/QAM option card with acti ve input –
Page 100 (116)
19V @ 500mA –
2-3W (additional)
Loading...
