PC2011 ELECTRIC AIR COMPRESSOR
Parts Reference Guide
PDAC015-121297-DUBS
MTM003 Issue: 1/24/98 © 1998 by SENCO Products, Inc. Cincinnati, OH 45244-USA
Questons? Comments? call SENCO’s toll-free Action-line: 1-800-543-4596 or e-mail: toolprof@senco.com
1
PC2011 ELECTRIC AIR COMPRESSOR Parts Reference Guide
OMAC0011-121897-DUBS
2
PDAC014-121197-DUBS
3
SENCO PC2011 ELECTRIC AIR COMPRESSOR
REPLACEMENT PARTS LIST
Part No. Description
020089 MOTOR
030172 PUMP
070151 GRIPS
090045 CORD RELIEF
100083 FLYWHEEL
100089 PULLEY
100090 FLYWHEEL
110039 BELT
140068 WHEEL
140069 ISOLATOR
150175 HOSE
190078 FILTER
190080 FILTER
200314 SPACER
200420 AXLE
200421 BRACKET
200425 PLATE
200436 BRACKET
220228 VALVE
220231 REGULATOR
220232 SWITCH
220257 GAUGE
220258 VALVE
220263 PLATE
230069 HOSE BARB
230123 HOSE BARB
230309 TEE
230312 VALVE
230341 ADAPTER
240010 NIPPLE
260204 GASKET
260205 SEAL
270015 BOLT
270067 BOLT
270068 BOLT
270121 BOLT
270576 BOLT
278002 BOLT
278032 BOLT
278033 BOLT
278803 BOLT
278909 BOLT
278910 BOLT
278910 BOLT
278917 SCREW
278918 BOLT
279524 BOLT
280002 WASHER
280003 WASHER
280022 WASHER
280023 WASHER
280210 WASHER
281032 WASHER
300155 LOCKNUT
300157 LOCKNUT
300159 LOCKNUT
303023 HEX NUT
320003 TERMINAL
320444 CORD PLUG SET
320445 CORD
330264 WIRE CLIPS
340575 LABEL
340815 LABEL
340817 LABEL
340819 LABEL
340822 LABEL
340823 LABEL
340842 LABEL
390101 PLUG
420004 CLAMP
430073 KEY
430092 PIN
460780 HEAD
460781 CYLINDER
460782 DIPSTICK
460783 CAP
460784 CAP
480060 BEARING
620109 AIR CONVEYOR
700220 RING SET
854011 BELTGUARD BACK
854013 TUBE
854014 TUBE
854015 AIR T ANK
854016 BEL TGU ARD
4
