SENA TECHNOLOGIES SP08 A User Manual

| SMH10R

SMH10R

Low Profile Motorcycle Bluetooth Headset & Int e rc om

SENA www.senabluetooth.com User’s Guide

| SMH10R

Sena™ is a trademark of Sena Technologies, Inc. or its subsidiaries in the USA and other countries. SMH10™, SMH5™, SPH10™, SPH10S™, SPH10H™, SR10™, SM10™, SMH10R™ are trademarks of Sena Technologies, Inc. or its subsidiaries. These trademarks may not be used without the express permission of Sena.

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sena is under license.

iPhone, iPod touch are registered trademarks of Apple Inc. Zumo™ is a trademark of Garmin Ltd. or its subsidiaries. TomTom™ is the

trademark or registered trademark owned by TomTom International B.V. Other trademarks and tradenames are those of their respective

owners.

| SMH10R

CONTENTS

1. INTRODUCTION

2. PACKAGE CONTENTS 3, INSTALLING THE SMH10R ON YOUR HELMET

4. POWERING ON/OFF AND CHARGING

4.1 Powering On

4.2 Powering Off

4.3 Charging

4.4 Low Battery Warning

4.5 Checking the Battery Level

5. VOLUME ADJUSTMENT

6. SMH10 CONFIGURATION SETTING

6.1 Enabling/Disabling Voice Activated Phone Answering

6.2 Enabling/Disabling Voice Activated Intercom

6.3 Enabling/Disabling Voice Prompts

6.4 Enabling/Disabling PLC (Packet Loss Consealment)

6.5 Delete All Bluetooth Pairing Information

6.6 Exit Voice Configuration Menu

7. PAIRING THE SMH10R WITH BLUETOOTH DEVICES

7.1 Mobile Phone Pairing

7.2 Bluetooth Stereo Device Pairing

7.3 Bluetooth GPS Navigation Pairing

7.4 Pairing with the Sena SR10, Bluetooth Two-way Radio Adapter

8. PAIRING WITH SELECTIVE PROFILE: A2DP STEREO OR HANDSFREE

8.1 A2DP Stereo Music Only

8.2 HFP for Phone Call Only

9. INTERCOM PAIRING

9.1 Pairing with Other SMH10R Headsets for Intercom Conversation

9.2 Pairing with Other SENA Headset Models for Intercom Conversation

10. FUNCTION PRIORITY

11. STEREO MUSIC

11.1 By Bluetooth Wireless Stereo

12. MOBILE PHONE CALL MAKING AND ANSWERING

13. TWO-WAY INTERCOM

13.1 Start and End Two-way Intercom

13.2 Intercom and Mobile Phone Call

13.3 Intercom and GPS

13.4 Intercom and Two-way Radio

14. THREE-WAY CONFERENCE INTERCOM

14.1 Start Three-way Intercom

14.2 End Three-way Intercom

15. FOUR-WAY CONFERENCE INTERCOM

15.1 Start Four-way Intercom

15.2 End Four-way Intercom

16. THREE-WAY CONFERENCE PHONE CALL WITH INTERCOM PARTICIPANT

17. INTERCOM FAILURE

18. INTERCOM RECONNECTION

19. FAULT RESET

20. FIRMWARE UPGRADE

21. CASE STUDY

| SMH10R

BATTERY INFORMATION MAINTENANCE AND CARE DISPOSAL CERTIFICATION AND SAFETY APPROVALS

FCC Compliance Statement FCC RF Exposure Statement FCC Caution CE Declaration of Conformity Industry Canada Statement Bluetooth License

WAIVER AND GENERAL RELEASE

Two-Year Limited Warranty Limitation of Liability Return for Full Refund

WARNING

| SMH10R

1. INTRODUCTION

Thank you f or c hoosing t he S ena S MH10R, B luetooth S tereo H eadset an d I ntercom for s ports bi ke riders. W ith the

SMH10R, you c an c all h andsfree on your B luetooth mobile pho ne, l isten t o s tereo m usic or v oice i nstructions of G PS

navigations by Bluetooth wirelessly, and have intercom conversations in full duplex with a passenger or other sports bike

riders.

The S MH10R is c ompliant w ith t he Bluetooth 3 .0 s upporting t he following pr ofiles: Headset Profile, H ands-Free Profile

(HFP), Advanced Audio Distribution Profile (A2DP), and Audio Video Remote Control Profile (AVRCP). Please check with

the manufacturers of other devices to determine their compatibility with this headset.

Please r ead t his us er’s g uide c arefully before us ing the he adset. Also c heck www.senabluetooth.com/support

latest version of the user’s guide and additional information related to Sena Bluetooth products.

The SMH10R features:

● Bluetooth handsfree for Bluetooth mobile phones

for t he

● Bluetooth stereo headset for Bluetooth audio devices such as MP3 players

● Bluetooth stereo headset for Bluetooth GPS navigations

● Bluetooth intercom up to 900 meters (980 yards)

● Four-way conference intercom

● Three-way conference phone call with intercom participant

● Multipoint Bluetooth pairing with GPS navigation or Sena SR10 Two-way Radio Adapter

● Multipoint Bluetooth pairing for 2 mobile phones

● Ultra slim and feather light

● Firmware upgradeable

* in open terrain

Key Specifications:

● Bluetooth 3.0

● Supporting profiles: H eadset P rofile(HSP), H ands-Free Profile ( HFP), Advanced Audio Distribution Profile ( A2DP),

Audio Video Remote Control Profile (AVRCP)

| SMH10R

2. PACKAGE CONTENTS

Headset Main Unit

(+) Button / (-) Button

 Volume adjustment  Navigate through configuration menu  Track-forward and track-back

Center Button

 Answer and end a mobile phone call  Reject an incoming mobile phone call  Start and end intercom conversation  Play and pause Bluetooth stereo device  Enter into intercom pairing mode  Enter into voice configuration setting

DC Power Charging & Firmware Upgrade Port

 Speaker Connector (4 pin female type)  Battery Pack Connector (2 pin male type)  Microphone Connector (2 pin female type)

| SMH10R

 Speakers  Attachable Boom Microphone  Wired Microphone  Battery Pack  Speaker Pad  Attachable Boom Microphone Holder  Velcro Pad for Boom Microphone  Vel cro Pad for Speaker  Velcro Pad for Boom Microphone Holder  Velcro Pad for Wired Microphone  Velcro Pads for Battery Pack  Mounting Cradle  Microphone Sponge  USB Power & Data Cable

3. INSTALLING THE SMH10R ON YOUR HELMET

To securely install the SMH10R on the helmet, please follow the procedure.

1 Locate a proper surface on the helmet to attach the Mounting Cradle, clean the helmet surface location with a

moistened towel, and allow to drying thoroughly.

2 Adhere with double sided tape on the back side of the Mounting Cradle to the surface on the helmet.

3 Clamp the SMH10R main unit to the Mounting Cradle.

4 Place the helmet speakers along with the Velcro pads, centered to your ear, in the ear pockets of the helmet. If the

helmet has deep ear pockets, you can you the speaker pads to place the speakers closer to your ears. Connect it to

the 4 pin speaker connector of the SMH10R main unit.

5 There are 2 different type of microphone can be installed to your helmet. In case of the Attachable Boom Microphone,

place the Velcro end of the boom microphone between the internal helmet cheek pad and the internal wall of the

helmet shell. The Attachable boom microphone should be mounted so it is facing close to your mouth when you wear

the helmet. In the case of the Wired Microphone, attach the enclosed Velcro pad for wired microphone to the inside

of the chin guard for full-face helmets. Place the wired microphone on the Velcro pad and connect it to the 2 pin

connector of the SMH10R main unit.

6 Place the battery on the helmet and we recommend rear side of the helmet with Velcro, connect it to the 2 pin battery

connector of the SMH10R main unit.

| SMH10R

4. POWERING ON/OFF AND CHARGING

To power on and off the headset, press the Center Button and the + Button at the same time for about 1 second to power on, and you will get quick on-and-off convenience.

4.1 Powering On

Press the Center Button and the + Button at the same time for about 1 second to power on. The blue LED turns on and you will hear ascending beeps.

4.2 Powering Off

Just short press the Center Button and the + Button simultaneously, you don’t need to press and hold for a few seconds. The red LED turns on for a while until it turns off completely and you will hear descending beeps.

4.3 Charging

The LED turns on red while charging, and turns to blue when the headset is fully charged. It takes about 3.5 hours to be completely charged.

4.4 Low Battery Warning

When the battery is low, the blinking blue LED in stand-by mode turns to red and you will hear mid-tone triple beeps and a

voice prompt saying “Low Battery”.

4.5 Checking the Battery Level

You can check the battery level in two different ways when the headset is powering on.

4.5.1 LED Indicator

When the headset is powering on, the red LED flashes rapidly indicating the battery level.

4 flashes = High, 70~100%

3 flashes = Medium, 30~70%

2 flashes = Low, 0~30%

4.5.2 Voice Prompt Indicator

When you power on the headset, keep pressing the Center Button and the (+) Button simultaneously for about 3 seconds until you hear high tone triple beeps. Then you will hear voice prompt indicating the battery level. However, if you release the buttons as soon as the headset turns on, you will not hear the voice prompt of battery level indication.

5. Volume Adjustment

You c an eas ily a djust t he volume b y pressing the ( +) B utton or t he ( -) B utton. You will h ear a be ep when t he v olume reaches maximum or minimum level. The volume is set and maintained independently at different levels for each audio source even when you turn off and on the headset. For example, once you set the volume for mobile phone handsfree, it will no t c hange e ven i f you adj ust t he volume w hen you hear Bluetooth MP3 music. S o you c an always maintain t he preferred optimum volume level for each audio source.

| SMH10R

Voice Prompt

“Phone pairing”

Factory Default

N/A

Enable / Disable

Press the Center Button

Voice Prompt

“Multipoint pairing”

Factory Default

N/A

Enable / Disable

Press the Center Button

6. SMH10R CONFIGURATION SETTING

You can set the configuration of the SMH10R by the voice menu instruction as below.

1 To enter into voice configuration menu, press and hold the Center Button for 10 seconds until the LED shows solid

blue and you hear high tone double beeps. You will also hear a voice prompt saying “Configuration menu”.

2 Press the (+) Button or (-) Button to navigate between the menus. You will hear voice prompts for each menu items

as below.

3 You can enable the feature or execute the command by press the Center Button, or disable the feature by press the

Center Button again. If any button is not pressed within 10 seconds, the SMH10R will exit the configuration and goes back to stand-b y.

4 If you want to exit the configuration immediately, press the (+) Button or (-) Button and hold it until you hear a voice

prompt, “Exit configuration”, and press the Center Button.

The voice prompt for each menu item is as below:

(1) Phone pairing (2) Multipoint pairing (3) Phone selective pairing (4) Media Selective pairing (5) VOX phone (6) VOX intercom (7) VOX sensitivity (8) Voice prompt (9) Delete all pairings (10) Factory reset (11) Exit configuration

6.1 Mobile Phone Pairing

Press the (+) Button or the (-) Button until you hear a voice prompt, “Phone pairing” to select a phone pairing menu. If

this menu is selected, the SMH10R will enter phone pairing mode for your mobile phone. Please refer to the section 7.1 for details on mobile phone pairing. If you press the (+) or (-) Button for menu navigation, it will stop the pairing operation.

6.2 Multipoint Pairing

+ 19 hidden pages
