SENA TECHNOLOGIES SP06 A User Manual

| SMH5

1

SMH5-FM

SMH5 Bluetooth Headset & Intercom for Scooters and Motorcycles

SENA

www.senabluetooth.com Users Guide v1.0.0

| SMH5

2

INTRODUCTION

Thank you for choosing the SENA SMH5, Bluetooth Stereo Headset and Intercom for motorcycles. With the SMH5, you
can call hands-free on your Bluetooth mobile phone, listen to stereo music or voice instructions of GPS navigations by
Bluetooth wirelessly, and have intercom conversations in full duplex with a passenger or other motorcycle riders.

The SMH5 is compliant with the Bluetooth Specification v3.0 supporting the following profiles: Headset Profile, Hands­Free Profile (HFP), Advanced Audio Distribution Profile (A2DP), and Audio Video Remote Control Profile (AVRCP).
Please check with the manufacturers of other devices to determine their compatibility with this headset.

Please read this user’s guide carefully before using the headset. Also check www.senabluetooth.com/support for the
latest version of the user’s guide and additional information related to SENA Bluetooth products.

The SMH5 features:

● Bluetooth hands-free for Bluetooth mobile phones

● Bluetooth stereo headset for Bluetooth audio devices such as MP3 players

● Bluetooth stereo headset for Bluetooth GPS navigations

● Smart Multi-Point Bluetooth: Connect two HFP devices simultaneoulsy

● Multi-Pair Bluetooth Intercom for 4 persons

● Firmware Upgradeable

● Power Spec: DC 3.7V

Key Specifications:

● Bluetooth v3.0, Class1 (2402 ~ 2480MHz)

● Supporting profiles: Headset Profile, Hand-Free Profile (HFP), Advanced Audio Distribution Profile (A2DP),

Audio Video Remote Control Profile (AVRCP)

Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Caution : Any changes or modifications in construction of this device which are not expressly approved by the party

responsible for compliance could void the user's authority to operate the equipment

Industry Canada(IC) Statement

This device complies with RSS-210 of the Industry Canada Rules.

| SMH5

3

Operation is subject to the following two conditions:

1) this device may not cause harmful interference and

2) this device must accept any interference. Including interference that
may cause undesired operation of device.
This class B digital apparatus complies with Canadian ICES-003

$YLVG,QGXVWULH&DQDGD

Cet appareil est conforme à norme CNR-210 des règlements d'Industrie
Canada. Son fonctionnement est sujet aux deux conditions suivantes:

1) Cet appareil ne doit pas provoquer d'interférences et

2) Cet appareil doit accepter toute les interférences. y compris celles
pouvant entraîner son dys-fonctionnement.
Cet appareil numérique de classe B est conforme à la norme NMB-003
du Canada.

,&5DGLDWLRQ([SRVXUH6WDWHPHQW

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

NOTE: THE MANUFACTURERE IS NO T RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.

$YLVG,QGXVWULH&DQDGDVXU,H[SRVLWLRQDX[UD\RQ Q HPHQWV

Cet appareil est conforme aux limites d'exposition aux rayonnements d'Industrie Canaca pour unenvironnement non
contrôlé.
II doit être installé de façon à garder une distance minimale de 20 centimètres entre la source de rayonnements et votre
corps.

REMARQUE: LE FABRICANT N'EST PAS RESPONSIBLE DES INTERFÉRENCES RADIOÉLECTRIQUES CAUSÉES
PAR DES MODIFICATIONS NON AUTORISÉES APPORTÉES APPORTÉES À CET APPAREIL.
DE TELLES MODIFICATIONS POURRAIT ANNULER L'AUTORISATION ACCORDÉE À L'UTILISATEUR DE FAIRE
FONCTIONNER L'APPAREIL.

| SMH5

4

PACKAGE CONTENTS

Headset Main Unit

Phone Button

● Making and Answering a mobile phone call

● Entering into Mobile Phone Pairing Mode

● Entering into Bluetooth Audio Device Pairing Mode (MP3, GPS navigation)

● Entering into Voice Activated Phone Answering Setting Mode

Jog Dial

● Start and End an Intercom Conversation

● Volume adjustment by rotating

● Play and Pause Bluetooth MP3 player

● Track-forward and Track-back by rotating while pressing the button

● Entering into Intercom Pairing Mode

● Entering into Voice Activated Intercom Setting Mode

● Reject an incoming mobile phone call

● Call Transfer

| SMH5

5

Microphone Sponges

Velcro Pads

Hex Key (Allen Wrench)

| SMH5

6

POWERING ON/OFF AND CHARGING

To power on and off the headset, you don’t need to press and hold any button for several seconds. Just short press the

Jog Dial and the Phone Button simultaneously, and you will get quick on-and-off convenience.

Powering On

Press the Jog Dial and the Phone Button at the same time for about 1 second to power on. The blue LED turns on and
you will hear ascending beeps.

Powering Off

Just short press the Jog Dial and the Phone Button simultaneously, you don’t need to press and hold for a few seconds.
The red LED turns on for a while until it turns off completely and you will hear descending beeps.

Charging

The LED turns on red while charging, and turns to blue when the headset is fully charged. It takes about 2.5 hours to be
completely charged.

Low Battery Warning

When the battery is low, the blinking blue LED in stand-by mode turns to red and you will hear mid-tone triple beeps.
