SENA EXPAND-01 User manual
SENA
EXPAND
Bluetooth® Stereo Headset & Intercom
www.sena.com
User's Guide
EXPAND
© 1998-2015 Sena Technologies Inc. All rights reserved.
Sena Technologies Inc. reserves the right to make any changes and improvements to its product without prior
notice.
™
is a trademark of Sena Technologies Inc. or its subsidiaries in the USA and other countries. PRISM
Sena
™
, SMH10™, SMH10R™, SMH5™, SMH5-FM™, SPH10™, EXPAND™, SPH10H™, SPH10H-FM™, SPH10S™,
3S
™
, SR10i™, SM10™, EXPAND™, Bluetooth Pack for GoPro® are trademarks of Sena Technologies, Inc. or
SR10
its subsidiaries. These trademarks may not be used without the express permission of Sena.
®
is a registered trademark of Woodman Labs of San Mateo, California. Sena Technologies, Inc.
GoPro
(“Sena”) is not afliated with Woodman Labs. The Sena Bluetooth Pack for GoPro
specially designed and manufactured by Sena Technologies, Inc. for the GoPro
®
is an aftermarket accessory
®
Hero3 allowing for Bluetooth
capabilities.
®
The Bluetooth
word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Sena is
under license. Other trademarks and tradenames are those of their respective owners.
™
, 20S™,
EXPAND
CONTENTS
1. INTRODUCTION ..................................................... 5
2. PACKAGE CONTENTS .......................................... 6
3. GETTING STARTED .............................................. 7
3.1 Wearing the Sena Expand ..................................7
3.2 Installing the Microphone Windscreen ................. 8
3.3 Powering On ........................................................ 8
3.4 Powering Off.........................................................8
3.5 Volume Adjustment ..............................................8
3.6 Function Priority ................................................... 9
3.7 Charging .............................................................. 9
3.8 Low Battery Warning .......................................... 10
3.9 Checking the Battery Level ................................ 10
3.10 Fault Reset ......................................................... 10
4. CONFIGURATION SETTING ............................... 11
4.1 Mobile Phone Pairing ......................................... 12
4.2 Multipoint Pairing ............................................... 12
4.3 Phone Selective Pairing ..................................... 12
4.4 Media Selective Pairing ..................................... 13
4.5 Assigning Speed Dial ....................................... 13
4.6 Enabling/Disabling Voice Prompts .....................14
4.7 Enabling/Disabling Advanced Noise Control™ .... 14
4.8 Delete All Bluetooth Pairing Information ............ 14
4.9 Reset to Factory Default Setting ........................ 15
4.10 Exit Voice Conguration Menu ...........................15
5. PAIRING THE EXPAND WITH BLUETOOTH
DEVICES
5.1 Mobile Phone Pairing ......................................... 16
5.2 Multipoint Pairing ............................................... 16
5.3 Bluetooth Stereo Device Pairing ........................17
5.4 Pairing with the Sena SR10 Bluetooth Two-way
.............................................................. 16
Radio Adapter .................................................... 17
6. PAIRING WITH SELECTIVE PROFILE: HFP OR
A2DP STEREO ..................................................... 19
6.1 Phone Selective Pairing: HFP for Phone Call
Only ................................................................... 19
6.2 Media Selective Pairing: A2DP Stereo Music
Only ................................................................... 19
7. STEREO MUSIC ................................................... 20
8. MOBILE PHONE CALL MAKING AND
ANSWERING
8.1 Mobile Phone Call Making and Answering ........ 20
8.2 Speed Dialing .................................................... 21
........................................................ 20
9. INTERCOM ........................................................... 22
9.1 Pairing with Other Sena Expand Headsets for
Intercom Conversation ....................................... 22
9.2 Pairing with Other Sena Headset Models for
Intercom Conversation ....................................... 23
English
EXPAND
9.3 Two-way Intercom .............................................. 24
9.4 Three-way Intercom ...........................................26
9.5 Four-way Intercom..............................................28
9.6 Intercom Failure .................................................29
9.7 Intercom Reconnection ...................................... 29
10. MUSIC SHARING ................................................. 30
11. UNIVERSAL INTERCOM ...................................... 30
11.1 Universal Intercom Pairing ................................. 30
11.2 Two-way Universal Intercom .............................. 31
11.3 Three-way Universal Intercom ...........................31
11.4 Four-way Universal Intercom..............................32
12. FIRMWARE UPGRADE ........................................ 35
13. SENA BLUETOOTH CONNECTION CASE
STUDIES
Case 1 ................................................................... 35
Case 2 ................................................................... 36
Case 3 ................................................................... 36
............................................................... 35
14. OPERATION QUICK REFERENCE ..................... 37
CERTIFICATION AND SAFETY APPROVALS
• FCC Compliance Statement ................................... 38
• FCC RF Exposure Statement .................................. 38
• FCC Caution ........................................................... 38
• CE Declaration of Conformity ................................39
• Industry Canada Statement ..................................39
• Bluetooth License .................................................. 39
• WEEE (Waste Electrical and Electronic Equipment) ...40
.......... 38
SAFETY INFORMATION ........................................... 40
• Product Storage and Management ........................ 40
• Product Use ............................................................ 41
• Battery ....................................................................41
PRODUCT WARRANTY AND DISCLAIMER ............. 42
• Limited Warranty .................................................... 42
• Warranty Exclusions ............................................... 44
• Warranty Service .................................................... 45
• Return for Full Refund ............................................46
EXPAND
1. INTRODUCTION
The Sena Expand is a Bluetooth Stereo headset
with long-range Bluetooth intercom designed
specically for outdoor sports activities. With the
Sena Expand, you can listen to stereo music, call
handsfree on their Bluetooth mobile phone, and
have intercom conversations in full duplex with up
to four companions. Also, the easy-to-access and
intuitive headset makes the Sena Expand a perfect
companion for outdoor sports.
The Sena Expand is compliant with Bluetooth
3.0 supporting the following proles: Headset
Prole, Hands-Free Prole (HFP), Advanced Audio
Distribution Prole (A2DP), and Audio Video Remote
Control Prole (AVRCP). Please check with the
manufacturers of other devices to determine their
compatibility with this headset. Please read this
user’s guide carefully before using the headset. Also
check www.sena.com for the latest version of the
user’s guide and additional information related to
Sena Bluetooth products.
The Sena Expand features:
• Bluetooth 3.0
• Stable and secure t for active condition
• Durable, sweat and water resistant for active condition
• Advanced Noise Control™
•
Long-range Bluetooth intercom up to 300 meters (330 yards)*
• Four-way conference intercom
• Universal Intercom™
• Multipoint Bluetooth for dual mobile phone
• Crystal clear and natural sound quality
• Voice prompts
• Bluetooth stereo headset for Bluetooth audio devices
such as MP3 players
• Bluetooth music playback control by AVRCP
• Rich sound level with integrated audio booster
• Bluetooth handsfree for Bluetooth mobile phones
• Individual volume control for each audio source
• Firmware upgradeable
• Peace of mind – thanks to the two-year warranty
Key Specications:
• Bluetooth 3.0
• Supporting proles: Headset Prole, Hands-Free Prole
(HFP), Advanced Audio Distribution Prole (A2DP),
Audio Video Remote Control Prole (AVRCP)
* in open terrain
5
English
EXPAND
2. PACKAGE CONTENTS
•
Headset
Center Button
• Play and pause Bluetooth stereo device
• Answer and end a mobile phone call
• Reject an incoming mobile phone call
• Start and end intercom conversation
• Enter configuration menu
• Enter phone pairing mode
• Enter intercom pairing mode
Speakers
Microphone
Speakers
Status LED
<Left side>
<Right side>
Charging LED
(+) Button / (-) Button
• Volume adjustment
• Navigate through configuration menu
• MP3 Track-forward and track-back
DC Power Charging &
Firmware Upgrade Port
6
EXPAND
USB Power & Data Cable
Speaker Pads
Microphone Windscreens
3. GETTING STARTED
3.1 Wearing the Sena Expand
Proper t on your ear and head is important both for
comfort and optimal noise-reduction performance.
The speaker with microphone should be placed
on the left ear. Then you can place earhooks over
ears and pull the microphone in toward your lips as
positioning the microphone with its talk side facing in
as shown below.
<Left Side> <Right Side>
7
English
EXPAND
3.2 Installing the Microphone Windscreen
The microphone windscreen helps you to cut down
incoming microphone wind noise by protecting
the microphone from the wind and provide clearer
voice audio sound under the circumstances where
the winds be very strong. Insert the microphone
windscreen at the end of the left side of the
microphone as shown below.
3.3 Powering On
Press and hold the Center Button and the (+) Button
at the same time for 1 second to power on. The blue
LED turns on and you will hear ascending beeps and
“Hello”.
3.4 Powering Off
Press the Center Button and the (+) Button
simultaneously (you don’t need to press and hold in
order for the system to power off). The red LED turns
on for about 2 seconds until it turns off completely
and you will hear “Goodbye” and descending beeps.
3.5 Volume Adjustment
You can easily adjust the volume by pressing the (+)
Button or the (-) Button. You will hear a beep when
the volume reaches maximum or minimum level.
The volume is set and maintained independently at
different levels for each audio source even when you
turn the headset off and on. For example, once you
set the volume for mobile phone handsfree, it will not
change even if you adjust the volume when you hear
Bluetooth MP3 music. So you can always maintain
the preferred optimum volume level for each audio
source.
8
EXPAND
3.6 Function Priority
The Sena Expand operates in the following order of
priority:
(highest
) Mobile phone,
Intercom,
Music sharing by Bluetooth stereo music,
(lowest) Bluetooth stereo music
A lower priority function is always interrupted by a
higher priority function. For example, stereo music
is interrupted by an intercom call, and intercom
conversation is interrupted by an incoming mobile
phone call.
3.7 Charging
The charging LED beside the charging port turns red
while charging, and turns to blue when the headset
is fully charged. It takes about 2.5 hours to be
completely charged. You can use the Sena Expand
while it is charging.
English
9
EXPAND
3.8 Low Battery Warning
When the battery is low, the blinking blue LED in
stand-by mode turns to red and you will hear midtone triple beeps and a voice prompt, “Low battery”.
3.9 Checking the Battery Level
You can check the battery level in two different ways
when the headset is powering on.
3.9.1 LED Indicator
When the headset is powering on, the red LED
ashes rapidly indicating the battery level.
4 ashes = High, 70~100%
3 ashes = Medium, 30~70%
2 ashes = Low, 0~30%
3.9.2 Voice Prompt Indicator
When you power on the headset, keep pressing the
Center Button and the (+) Button simultaneously
for several seconds until you hear high tone triple
beeps. Then you will hear a voice prompt indicating
the battery level. However, if you release the buttons
as soon as the headset turns on, you will not hear the
voice prompt giving the battery level indication.
3.10 Fault Reset
When the Sena Expand is not working properly or
is faulty for any reason, you may reset it by pushing
the pinhole reset button at the back of the headset
main unit.
1. Rotate the speaker pad of the left headset counterclockwise to detach it.
10
EXPAND
2. Insert a paper clip into the reset pin-hole and
press the reset button for a second using light
pressure. The Sena Expand will be switched off,
and you have to turn the system back on and try
again. However, this will not restore the headset to
the factory default settings.
4. CONFIGURATION SETTING
You can set the conguration of the Sena Expand by
the voice menu instructions as below.
1. To enter the voice conguration menu, press and
hold the Center Button for 12 seconds until the
LED shows solid blue and you hear high tone
double beeps. You will also hear the voice prompt,
“Conguration menu”.
2. Press the (+) Button or (-) Button to navigate
between the menus. You will hear voice prompts
for each menu item as below.
3. You can enable / disable a feature or execute a
command by pressing the Center Button.
4. If you want to exit conguration immediately, press
and hold the (+) Button or (-) Button until you hear
the voice prompt, “Exit conguration”, then
press the Center Button.
English
11
EXPAND
The voice prompt for each menu item is as follows:
(1) Phone pairing (6) Voice prompt
(2) Multipoint pairing (7) Noise control
(3) Phone selective pairing (8) Delete all pairings
(4) Media selective pairing (9) Factory reset
(5) Speed dial (10) Exit conguration
Phone pairing
Multipoint pairing
Phone selective pairing
Media Selective pairing
Speed Dial
Voice prompt
Exit configuration
Factory reset
Delete all pairings
Noise control
4.1 Mobile Phone Pairing
Voice Prompt
Factory Default N/A
“Phone pairing”
To go into mobile phone pairing mode, press the (+)
Button or the (-) Button until you hear the voice prompt,
“Phone pairing”. Please refer to section 5.1 for details
on mobile phone pairing. If you press the (+) or (-)
Button, you can exit from the phone pairing mode.
12
4.2 Multipoint Pairing
Voice Prompt
Factory Default N/A
“Multipoint pairing”
To go into multipoint pairing mode, press the (+)
Button or the (-) Button until you hear the voice
prompt, “Multipoint pairing”. Please refer to section
5.2 for details on multipoint pairing. If you press the
(+) or (-) Button, you can exit from the multipoint
pairing mode.
4.3 Phone Selective Pairing
Voice Prompt
Factory Default N/A
“Phone selective pairing”
To go into phone selective pairing mode, press the
(+) Button or the (-) Button until you hear the voice
prompt, “Phone selective pairing”. Please refer
to section 6.1 for more details on phone selective
pairing. If you press the (+) or (-) Button, you can exit
from the phone selective pairing mode.
EXPAND
4.4 Media Selective Pairing
Voice Prompt
Factory Default N/A
“Media selective pairing”
To go into media selective pairing mode, press the
(+) Button or the (-) Button until you hear the voice
prompt, “Media selective pairing”. Please refer
to section 6.2 for more details on media selective
pairing. If you press the (+) or (-) Button, you can exit
from the media selective pairing mode.
4.5 Assigning Speed Dial
Voice Prompt
Factory Default N/A
Execute Press the Center Button
“Speed dial”
1. To assign a phone number as a speed dial, tap the
(+) Button or the (-) Button until you hear a voice
prompt, “Speed dial”.
2. Tap the Center Button, and you will hear a voice
prompt, “Speed dial one” and “Phone connected”.
3. Tap the (+) Button or the (-) Button to select one
of three speed dial numbers and you hear a voice
prompt, “Speed dial (#)”.
4. Call a phone number you want to assign and you
will hear a voice prompt, “Save speed dial (#)”.
The phone number is automatically assigned to
the selected speed dial number. Then the phone
call will hang up before being connected.
5. To exit the menu, tap the (+) Button or the (-)
Button until you hear a voice prompt, “Cancel”,
and tap the Center Button to conrm. You will then
hear a voice prompt, “Cancel”. If any button is not
pressed within 1 minute, the Sena Expand will exit
the conguration menu and go back to stand-by
mode.
Note:
1. After assigning a phone number to one of three speed
dials, you can continually assign another phone number to
the rest of two speed dials.
2. You can assign phone numbers to speed dials in your PC.
Please visit the Sena Bluetooth web site at www.sena.com
for more information.
English
13
EXPAND
4.6 Enabling/Disabling Voice Prompts
Voice Prompt
Factory Default Enable
Enable / Disable Press the Center Button
“Voice prompt”
You can disable voice prompts by conguration
setting, but the following voice prompts are always
on.
- Voice prompts for conguration setting menu
- Voice prompts for battery level Indicator
- Voice prompts for factory reset
4.7 Enabling/Disabling Advanced Noise Control™
Voice Prompt
Factory Default Enable
Enable / Disable Press the Center Button
“Noise control”
When Advanced Noise Control is enabled, the
background noise is reduced during an intercom
conversation. When it is disabled, the background
noise is mixed with your voice during intercom.
Note:
If you use your Sena Expand with the Bluetooth Audio Pack
for GoPro or Prism, you can enable or disable this feature
only during Normal Audio Recording Mode. This feature is
automatically disabled while in Ultra HD (UHD) Audio Mode.
4.8 Delete All Bluetooth Pairing Information
Voice Prompt
Factory Default N/A
Execute Press the Center Button
“Delete all pairings”
To delete all Bluetooth pairing information on the
Sena Expand, press the (+) Button or the (-) Button
until you hear the voice prompt, “Delete all pairings”.
Press the Center Button to conrm.
14
EXPAND
4.9 Reset to Factory Default Setting
Voice Prompt
Factory Default N/A
Execute Press the Center Button
“Factory reset”
To restore factory default settings on the Sena
Expand, press the (+) Button or the (-) Button until
you hear the voice prompt, “Factory reset”. Press the
Center Button to conrm. The Sena Expand powers
off with a voice prompt, “Headset reset, goodbye”.
4.10 ExitVoiceCongurationMenu
Voice Prompt
Factory Default N/A
Execute Press the Center Button
“Exit conguration”
To exit voice conguration menu and get back to
stand-by mode, press the (+) Button or (-) Button
until you hear the voice prompt, “Exit conguration”.
Press the Center Button to conrm.
Press (+) Button or
(-) Button
Phone Pairing None
Multipoint Pairing None
Phone Selective Pairing None
Media Selective Pairing None
Speed Dial Execute
Voice prompt Enable/Disable
Advanced Noise Control Enable/Disable
Delete All Pairings Execute
Factory Reset Execute
Exit Conguration Execute
Voice Conguration Menu & Button Operations
Press Center Button
English
15
Loading...
