CAL. W626, W671
DIGITAL QUARTZ
● Time/calendar
● Stopwatch
● Countdown timer
with preset and adjustable timer functions
● Daily alarm
● Auto illumination function (Cal. W671)
● Illuminating light
ENGLISH
Cal. W626
MODE CHANGE
○○○○○○○○○○○○
▲
English
2
TIME/
CALENDAR
mode
○○○
▲
A
With each press,
the mode changes in order.
ALARM
mode
○○○○○○○○○○○○○○
▲
STOPWATCH
mode
○○○○
▲
TIMER
mode
TIME/CALENDAR MODE
Cal. W626
Date
DayMonth
➡
➡
D
TIME display CALENDAR display
SHOWING THE CALENDAR DISPLAY
Press to show CALENDAR display.
D
* Month, date and day are displayed for 5 seconds, and then, the watch
automatically returns to the TIME display.
English
3
Cal. W626
BC
D
English
Selection of the digits
Seconds ➾ Minutes ➾ Hour ➾ Date
➾
12-/24-hour indication Year Month
4
TIME/CALENDAR SETTING
Press for 2 to 3 seconds.
B
▲
▲
Select the digits to be adjusted.
C
▲
Set the flashing digits.
D
▲
Return to TIME/CALENDAR
B
mode.
➾
➾
➾
Cal. W626
STOPWATCH MODE
● The stopwatch measures up to 100 hours in 1/100 second increments for the first
1 hour and in 1 second increments thereafter.
Start / Stop / Restart
C
Reset /
Split / Split release
D
Split time measurement
▲
C
START
D
SPLIT
▲
D
SPLIT
RELEASE
▲
C
STOP
▲
* Measurement and
release of split time
D
RESET
can be repeated by
pressing button D.
English
5
Cal. W626
Measurement of two competitors
C
START
▲
D
FINISH TIME
OF 1ST
COMPETITOR
English
6
▲
C
2ND
COMPETITOR
FINISHES
▲
D
FINISH TIME
OF 2ND
COMPETITOR
▲
D
RESET
Cal. W626
TIMER MODE
● Two types of timer are available: preset timer and adjustable timer.
● The adjustable timer can be set up to 60 minutes in minute increments.
PRESET TIMER SETTING
Select the preset time.
D
BC
Selection of the preset time
3 min. ➾ 5 min. ➾ 10 min.
➾
➾
60 min.
D
ADJUSTABLE TIMER SETTING
45 min.
Press for 2 to 3 seconds.
B
▲
Set the flashing digits.
D
▲
➾
30 min.
➾
15 min.
➾
English
7
Cal. W626
TIMER OPERATION
Return to TIMER mode.
B
B
C
English
D Reset
* When the set time is up, a warning sound beeps for 5 seconds.
To stop it manually, depress any one of the buttons.
8
Start / Stop / Restart
ALARM MODE
ALARM SETTING
Press for 2 to 3 seconds.
B
▲
BC
D
▲
Select the digits to be adjusted
C
▲
(hour/minutes).
Set the flashing digits.
D
▲
Return to ALARM mode.
B
* The alarm is automatically engaged.
Cal. W626
English
9
Cal. W626
Alarm engagement/disengagement
With each press, the alarm is
C
engaged and disengaged
alternately.
Turning on/off of hourly time signal and
button operation confirmation sound
English
With each press in TIME/
C
CALENDAR mode, the hourly
time signal and button operation
confirmation sound are turned
on and off alternately.
10
Alarm engaged
Alarm mark
“on” mark
Hourly time
signal mark
MODE CHANGE
○○ ○○○○○○○○○○
Cal. W671
▲
TIME/
CALENDAR
mode
ALARM
mode
Mode
mark
○○
▲
○○○○○○○○○○○○○○
▲
A
With each press,
the mode changes in order.
STOPWATCH
mode
○○
▲
TIMER
mode
English
11
English
12
Cal. W671
“A” (AM)/
“P” (PM)
mark
B
Selection of the digits
ILLUMINATION
TIME/CALENDAR MODE
DayDateMonth
AUTO
on/off
TIME/CALENDAR SETTING
Press for 2 to 3 seconds.
B
C
D
➾
▲
▲
Select the digits to be adjusted.
C
▲
Set the flashing digits.
D
▲
Return to TIME/CALENDAR
B
mode.
Seconds ➾ Minutes ➾ Hour ➾ Date
➾
12-/24-hour indication Year Month
➾
➾
➾
Cal. W671
AUTO ILLUMINATION FUNCTION
When AUTO ILLUMINATION FUNCTION is turned on:
● The display is illuminated with each press of a button to operate the watch.
● While the stopwatch or timer is counting, the display is illuminated every
minute to signal the lapse of time: For the first 19 minutes in the stopwatch
function and for the last 19 minutes in the timer function.
Press for 2 to 3 seconds.
B
▲
Turn on/off the AUTO
D
ILLUMINATION FUNCTION.
▲
Return to TIME/CALENDAR
B
mode.
The
function
is on.
The
function
is off.
English
13
Cal. W671
STOPWATCH MODE
● The stopwatch measures up to 10 hours in 1/100 second increments.
Time measured
English
Lap time measurement
C
START
14
Current time
▲
▲
D
LAP
LAP
B
▲
D
C
STOP
▲
C
D
D
RESET
Start / Stop / Restart
Reset /
Measure lap time
Lap No.
Lap time
MEMORY RECALL FUNCTION
● The stored data can be recalled either during or after the measurement.
Press to activate the memory
B
▲
recall function.
With each press, stored data
B
D
are recalled from the oldest to
▲
the newest.
Return to STOPWATCH mode.
B
**In memory recall after measurement, the
D
oldest measurement in memory is
displayed.
In memory recall during measurement,
the newest measurement in memory is
displayed.
**
Cal. W671
English
15
Cal. W671
TIMER MODE
● Two types of timer are available: preset timer and adjustable timer.
● The adjustable timer can be set up to 9 hours and 59 minutes in minute
increments.
Set time
BC
English
Time measured
16
the countdown is repeated
No. of times
PRESET TIMER SETTING
Select the preset time.
D
Selection of the preset time/
adjustable timer
Adjustable
timer
D
ADJUSTABLE TIMER SETTING
Select the adjustable timer.
D
▲
Press for 2 to 3 seconds.
B
▲
3 min. ➾ 5 min.
➾
➾
15 min. 10 min.
➾
➾
TIMER OPERATION
▲
Select the digits to be adjusted
C
▲
(hour/minutes).
Set the flashing digits.
D
▲
Return to TIMER mode.
B
Cal. W671
English
B
Start / Stop / Restart
C
D Reset
* When the set time is up, a warning sound beeps for 5 seconds.
To stop it manually, depress any one of the buttons.
17
Cal. W671
ALARM MODE
Current time
BC
English
D
“A” (AM)/
“P” (PM)
mark
18
Set alarm time
ALARM SETTING
Press for 2 to 3 seconds.
B
▲
▲
Select the digits to be adjusted
C
▲
(hour/minutes).
Set the flashing digits.
D
▲
Return to ALARM mode.
B
* The alarm is automatically engaged.
Alarm engagement/disengagement
With each press, the alarm is
C
engaged and disengaged
alternately.
Turning on/off of hourly time signal and
button operation confirmation sound
With each press in TIME/
C
CALENDAR mode, the hourly
time signal and button operation
confirmation sound are turned
on and off alternately.
Alarm engaged
Cal. W671
Alarm mark
“on” mark
Hourly time
signal mark
English
19
English
20
Cal. W671Cal. W626
ILLUMINATING LIGHT
Turn on the illuminating light.
The display panel is illuminated
for 3 seconds.
E
Cal. W671Cal. W626
NOTES ON USING THE WATCH
MODE CHANGE
● When the confirmation sound is turned on, a beep sounds with each press of button A
to change over the mode. It sounds in a different tone when the TIME/CALENDAR
mode appears, so that you can easily know the mode shown.
TIME/CALENDAR MODE
● The calendar automatically adjusts for odd and even months including February of leap
years.
● In second setting, when the seconds count any number from “30” to “59” and button
D is pressed, one minute is added and the seconds are reset to “00”.
● The flashing digits except the seconds and 12-/24-hour indication (and on/off of auto
illumination function for Cal. W671) move quickly if button D is kept pressed.
● Once the year, month and date have been set, the day of the week is automatically set.
● If the watch is left untouched with the digits flashing, it will automatically return to the
TIME/CALENDAR mode in 2 to 3 minutes.
● Note for Cal. W671:
Some models have a color glass over the digital display. If the display is difficult to read,
use the watch with the AUTO ILLUMINATION function turned on. When setting the
time/calendar, press button E to turn on the illuminating light for easy viewing.
English
21
Cal. W671Cal. W626
● Note on unusual display:
While setting the time/calendar, all the segments of the display will light up if both
buttons C and D are pressed at the same time. This is not a malfunction. Press any one
of the buttons to return to the TIME/CALENDAR mode, and then set the time/calendar
again.
STOPWATCH MODE
● Notes for Cal. W671:
1) Lap time measured and lap number remain displayed for 10 seconds, and then, the
current time appears in the upper row of the display.
2) The lap number counts up to “99”. After that, it is displayed in 2 digits such as “00”
for 100, “01” for 101, and so on.
English
3) The first 8 lap times are automatically stored in memory.
4) Even if the digits are reset to “00” in the stopwatch measurement, stored data is
not erased and can be recalled unless a new measurement is started.
5) When the button operation confirmation sound is turned on, a beep sounds every
minute to signal the lapse of time.
● Even if the STOPWATCH mode is changed to another while the measurement is in
progress, it continues counting properly and the flashing STOPWATCH mode mark
indicates that the stopwatch is in use. After the stopwatch is used, however, be sure
to reset it as the battery energy is consumed enormously to shorten the battery life.
22
Cal. W671Cal. W626
TIMER MODE
● After the set time is up, the timer counts down the set time repeatedly. After the timer
is used, therefore, be sure to reset it as the battery energy is consumed enormously to
shorten the battery life.
● In the adjustable timer setting, the flashing digits move quickly if button D is kept
pressed.
● If the watch is left untouched with the digits flashing, it will automatically return to the
TIMER mode in 2 to 3 minutes.
● Restart and stop of the timer can be repeated by pressing button C.
● Notes for Cal. W626:
1) By pressing button B for 2 to 3 seconds in any one of the preset timer displays, the
adjustable timer setting function is activated.
2) If button D is pressed while the time set for the adjustable timer is displayed, the
set time will be canceled.
● Notes for Cal. W671:
1) After the countdown is repeated 99 times, the number of times the countdown is
repeated is displayed in 2 digits such as “00” for 100, “01” for 101, and so on.
2) When the button operation confirmation sound is turned on, a beep sounds every
minute to signal the lapse of time.
3) Even if the TIMER mode is changed to another while the measurement is in
progress, it continues counting properly and the flashing TIMER mode mark
indicates that the timer is in use. After the timer is used, however, be sure to reset
it as the battery energy is consumed enormously to shorten the battery life.
English
23
Cal. W671Cal. W626
4) If the timer is left counting without being stopped, it will automatically be stopped
and reset to show the set time when more than 12 hours passed and the time
display reaches 0:00 a.m. or 0:00 p.m.
ALARM MODE
● At the designated time the alarm rings for 20 seconds, and the display is illuminated as
the alarm rings. To stop them manually, press any one of the buttons.
● In the alarm time setting, the flashing digits move quickly if button D is kept pressed.
● When the time function is displayed in the 24-hour indication, the alarm is also displayed
in the 24-hour indication.
● When setting the hour digits in the 12-hour indication, check that AM/PM is properly set.
● If the watch is left untouched with the digits flashing, it will automatically return to the
English
ALARM mode in 2 to 3 minutes.
● Alarm test: The alarm can be tested by keeping buttons C and D pressed in the TIME/
● When the hourly time signal mark is displayed, the hourly time signal rings every hour
on the hour and the confirmation sound beeps with each press of the buttons.
CALENDAR mode.
24
Cal. W671Cal. W626
BATTERY CHANGE
Battery life : Approx. 2 years
2
Years
●
The battery life may be less than 2 years if the stopwatch is used for more than 10 hours
a day, the timer for more than 10 hours a day, the alarm more than once a day, the
illuminating light more than 3 times a day, the confirmation sound more than 24 times
a day and/or the auto illumination more than 30 times a week (only for Cal. W671).
●
As the battery is inserted at the factory to check the function and performance of the
watch, its actual life once in your possession may be less than the specified period.
●
When the battery expires, be sure to replace it as soon as possible to prevent any malfunction.
●
We recommend that you contact an AUTHORIZED PULSAR DEALER for battery
replacement.
● Battery life indicator
When all the digits start flashing, have the battery replaced with a new one as soon as
possible.
● Necessary procedure after battery change
After the battery is replaced with a new one, or if an abnormal display (broken digits, etc.)
Battery : SEIKO CR2025
English
25
appears, follow the procedure below to reset the IC.
Press and hold buttons A, B, C and D
at the same time for 2 to 3 seconds.
The display shown at right appears.
* Before using the watch, set the time/
Cal. W671Cal. W626
calendar and alarm.
Cal. W626
“January 1st, Wednesday” is
shown in CALENDAR display.
WARNING
English
● Do not remove the battery from the watch.
● If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
● Never short-circuit, tamper with or heat the battery, and never expose
it to fire. The battery may burst, become very hot or catch fire.
CAUTION
● The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.
26
Cal. W671
TO PRESERVE THE QUALITY OF YOUR WATCH
WATER RESISTANCE
● Non-water resistant
• If the watch becomes wet, have it checked by an AUTHORIZED
PULSAR DEALER or SERVICE CENTER.
Cal. W671Cal. W626
English
● Water resistant 5/10/15/20 bar
• Do not operate the buttons when the watch is wet or in water.
If used in sea water, rinse the watch in fresh water and dry it
5 bar WR
10/15/20
bar WR
completely.
• When taking a shower with the water resistant 5 bar watch, or
taking a bath with the water resistant 10, 15 or 20 bar watch, be
sure to observe the following:
* Do not operate the buttons when the watch is wet with soapy
water or shampoo.
* If the watch is left in warm water, a slight time loss or gain may
be caused. This condition, however, will be corrected when the
watch returns to normal temperature.
27
Cal. W671Cal. W626
* Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the pressure
at a given depth. Care should also be taken on diving into water.
** We recommend that you wear a PULSAR Diver’s Watch for scuba diving.
TEMPERATURES
Your watch works
+50°C
with stable accuracy
within a temperature
-5°C
English
Temperatures over 50° C (122°
F) or below –5° C (+23° F) may
cause a slight time loss or gain
or battery leakage or shorten the
battery life.
However, the above conditions
will be corrected when the watch
returns to normal temperature.
28
range of 5° C and 35°
C (41° F and 95° F).
MAGNETISM
Your watch will not be affected
by magnetism.
S
N
CARE OF CASE AND BRACELET
To prevent possible rusting of
the case and bracelet caused
by dust, moisture and
perspiration, wipe them
periodically with a soft dry
cloth.
SHOCKS & VIBRATION
Light activities will not
affect your watch, but be
careful not to drop your
watch or hit it against hard
surfaces, as this may
cause damage.
CHEMICALS
Be careful not to expose
the watch to solvents,
mercury, cosmetic spray,
detergents, adhesives or
case, bracelet, etc. may become
discolored, deteriorated or damaged.
paints. Otherwise, the
Cal. W671Cal. W626
PERIODIC CHECK
It is recommended that the
2 - 3
Years
DEALER or SERVICE CENTER to
ensure that the case, buttons, gasket
and crystal seal remain intact.
watch be checked once
every 2 to 3 years. Have
your watch checked by an
AUTHORIZED PULSAR
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
If your watch has a
protective film and/or a
sticker on the case back,
be sure to peel them off
before using your watch.
English
29
Cal. W671Cal. W626
STATIC ELECTRICITY
The IC (Integrated
Circuit) used in your
watch will be affected
by static electricity
display. Keep the watch away
from close contact with objects
such as TV screens which emit
strong static electricity.
which may disturb the
English
30
LIQUID CRYSTAL PANEL
The normal life expectancy for
the liquid crystal panel of the
watch is approximately 5 years.
5 Years
read. Please contact your AUTHORIZED
PULSAR DEALER or SERVICE CENTER
if you wish to have a new panel fitted
(guaranteed one year).
After that it may decrease in
contrast, becoming difficult to
Loading...
