474L
MULTI-DOOR
REFRIGERTOR
SC-520AU8FD
INSTRUCTION MANUAL
Please read this manual carefully before using, and keep it for future reference.
CONTENTS
General Safety 4
Product Overview 8
Installation 9
Control Panel 11
Temperature settings for Refrigerator 12
Temperature settings for Freezer 12
Variable Zone (vegetable/meat/drink) 12
Super Cool Mode 12
Super Freeze Mode 12
Control Panel Lock 13
Troubleshooting 14
Specifications 15
Customer Helpline Last Page
GENERAL SAFETY
IMPORTANT INFORMATION
Read this manual thoroughly before you start using the Refrigerator.
The safety precautions instructions reduces the risk of fire, electric shock and
injury when correctly complied to.
Please follow all instructions and take notice of all warnings.
Pay close attention to messages that follow this safety alert symbol
or the words DANGER, WARNING or CAUTION. These words will be
used to alert you of potential hazards that and injure you and others.
Following these instruction will tell you how to reduce the chance of
injury and the possible dangers if instructions aren’t followed.
This symbol alerts you to take care as the appliance contains flammable
materials: isobutane as refrigerant and cyclopentane as insulation
blowing gas. Do not expose it to high heat, sparks and open flames.
The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the
appliance, a gas with a high level of environmental compatibility, which is flammable.
During transportation and installation of the appliance, make sure that none of the
components of the refrigerant circuit become damaged.
WARNING: Never use an appliance with a damaged refrigerant circuit. If the refrigerant
circuit becomes damaged, avoid proximity to open fires and all types
of heat and ignition sources. Thoroughly ventilate the room in which the appliance is
located.
It is dangerous for anyone other than an authorised service person to work on this
appliance. In Queensland, the authorised service person MUST hold a Gas Work
Authorisation for hydrocarbon refrigerants to carry out servicing or repairs which
involve the removal of covers.
The room for installing the appliance must be at least 1m³ per 8g of refrigerant.
The amount and type of refrigerant in the appliance can be found in the Technical
Specifications at the back of the manual and on the appliance rating label.
4
GENERAL SAFETY INSTRUCTIONS (Cont.)
This appliance is intended to be used in household and similar applications such as: sta areas in shops, oces and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications
R600A WARNINGS
NOTE: This model uses 0.070Kg of R600a flammable refrigerant in its sealed system.
The following must be observed for your safety:
R600A Refrigerant Warning
• This appliance contains a small quantity of R600A refrigerant which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor
does it increase the greenhouse eect.
• During transportation and installation, ensure that the tubing of the refrigerant
circuit is not damaged.
• Leaking refrigerant can ignite and may damage the eyes.
• In the event any damage does occur, avoid exposure to open fires and any device
which creates a spark. Disconnect the appliance from the mains power.
• Thoroughly ventilate the room in which the appliance is located for several minutes.
• Notify Customer Service for necessary action and advice.
• The room for installing the appliance must be at least 1 cubic metre per 8 grams
of refrigerant. The refrigerant quantity contained in this appliance is listed above in
grams; it is also noted on the Rating Plate of the appliance.
It is hazardous for anyone other than an Authorised Service Person to carry out
servicing or repairs to this appliance. In Queensland the authorized person must hold
a Gas Work Authorisation for hydrocarbon refrigerants, before carrying out servicing
or repairs which involve the removal of covers.
WARNNING
1. Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear
of obstruction.
2.Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
3.Do not damage the refrigerant circuit.
4.Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
5.Do not store explosive substances such as aerosol cans with a flammable propellant
in the appliance.
The environment and personal safety must be considered when disposing of this
appliance. Please ensure the appliance is taken to a recycle center for safe recycling.
DO NOT dispose of the appliance in land fill as the insulation and refrigerant gas
contained in these appliances are flammable.
5
GENERAL SAFETY INSTRUCTIONS (Cont.)
To reduce risk of fire, electric shock or injury, always follow these basic precautions and
accident prevention measures when using this appliance, including the below:
INSTALLATION
• Heavy: The product is heavy, be careful when moving it. To avoid back or other
injury, have 2 people lift or mechanical aid when installing.
• Damage: When unnoxing, thoroughly inspect the appliance carefully for any
damage. If there is any damage, do not install the appliance. Contact our
support centre on info@ayonz.com for advice.
• Protection from moisture: Make sure the appliance is installed in an indoor area
away from wind, rain, water spray or drips.
• Protect from heat: Do not place the appliance next to an oven, grill or other
source of high heat, or where it will be exposed to direct sunlight for long
periods of time.
• WARNING: Ventilation: Make sure to have enough ventilation, keep any
ventilation openings, in the appliance enclosure or in the built-in structure,
clear all obstructions. Make sure plenty of air circulation around the appliance
to prevent overheating.
• Level: Install appliance level in order for proper operation.
ELECTRICAL SAFETY
• Voltage: Plug the appliance to a 220-240V, 50Hz, properly earthed power
outlet, it must be in good working order.
• Power connection: Do not use an adaptor or an extension cord. Plug the power plug
directly into a separate power point that cannot be accidentally turned o, and that
is easily accessible so you can switch it o if needed.
• Power cord: Do not kink or damage the power supply cord. Make sure it is
behind the appliance so no one can step on or place anything on the power
supply cord or against it. A damaged power plug may overheat and cause a fire.
• Damaged cord: Do not use a cord that shows cracks or abrasion damage. Any
damage to the cord may cause a short circuit, fire and/or electric shock. Contact
our support centre on info@ayonz.com for advice
• WARNING! The light supplied with this appliance cannot be replaced by the user.
Contact the authorised service agent for replacement or service.
• Disconnection: Never pull the powercord to unplug appliance. Grip the plug and
pull straight out from the power point.
• Electrical work: If the installation of this appliance requires any electrical work,
make sure it is carried out by an electrician.
Warning!
1. Do not locate multiple portable socket-outlets or portable supplies at the rear
of the appliances.
2. When positioning the appliance, ensure the supply cord is not trapped or damaged.
6
GENERAL SAFETY INSTRUCTIONS (Cont.)
USAGE CONDITIONS AND RESTRICTIONS
• Children: Supervision over children is to ensure that they do not play with the
appliance. Never allow them to use, play with or crawl inside the appliance.
Cleaning and maintenance must not be done by children.
• Usage restrictions: The appliance is not to be used by persons
(including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision
or instruction.
• Indoor domestic use only: Only for indoor domestic use only, such as in
households, kitchen areas in shops, oces and in other working environments,
use by clients in hotels, motels, bed and breakfast establishments and in catering
and similar non-retail applications. It is not to be used for industrial or
commercial use.
• Intended purpose: Do not use this product for anything other than its intended
purpose, and only use it as described in this manual. Do not attempt to alter or
modify this appliance.
• WARNING! Do not use any electrical or electronic appliances inside the
food storage compartments of the appliance, unless they are of the type
recommended by the manufacturer.
CLEANING AND MAINTENANCE
• Flames: Do not allow open flames or ignition sources enter the appliance.
• Disconnect: Make sure to unplug appliance before cleaning or servicing.
Failure to do so can result in electric shock, injury or death. Do not connect
or disconnect the plug when your hands are wet.
• Flammable/explosive substances: Do not store flammable or explosive
substances such as aerosol cans with flammable propellant in this appliance.
• Solvents: Do not use solvent based cleaning products or abrasives on the interior.
• WARNING! Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer
• Service: Never try to repair, modify or replace any part of the appliance, unless
this manual says you can do so. All other servicing is to be done by a qualified
technician, or contact our support centre on info@ayonz.com for advice.
REPONSIBLE DISPOSAL
• Do not throw this appliance out with your household rubbish. Observe any local
regulations regarding the disposal of electrical consumer goods and dispose
of it appropriately.
7
PRODUCT OVERVIEW
8
INSTALLATION
• Safety first: Before installing your new bar fridge, read all safety instructions in
this manual, especially the sections on electrical safety and installation.
• Do not tilt the appliance more than 45º from upright when moving.
• This appliance is designed to be freestanding only and is not be recessed
or built in.
• Do not apply force to any part such as the condenser or door.
• Place the bar fridge on a strong, level floor that is solid enough to support the
unit when it is fully loaded.
• To fix the balance, Adjust the levelling legs at the bottom of the appliance.
• Ensure there is nothing that could prevent the door from closing.
• SPACING: Allow 10cm clear space between the back and 5cm on the sides of
the appliance and your wall or anything else to make sure there is enough air
circulation, which is needed to allow for the cooling of the compressor
and condenser.
• If you have to position the refrigerator on carpet, use a plastic carpet protector
underneath the appliance.
SIDE VIEWTOP VIEW
Top
BE SURE TO PLACE APPLIANCE:
• Away from direct sunlight.
• Away from sources of heat (may increase power consumption).
• An area without excessive moisture and high humidity.
WARNING: Before you plug in the appliance, let it stand upright for 2 hours.
This will allow the refrigerant gases to settle into the compressor and reduce the
possibility of a malfunction in the cooling system from transportation.
100mm
100cm
Back
9
INSTALLATION (cont.)
LEVELLING THE REFRIGERATOR
LEVELLING THE DOORS
This refrigerators comes with three C-type washers (pic1),
you can use to realign the fridge compartment (upper) doors.
They may be slightly out of alignment after delivery, or after
youhave loaded items on the door balconies.
Should the doors need to aligned, please see following steps:
1. Before checking the door alignment, make sure that the appliance is
stand level and upright.
2. If the top of the two upper doors looks out of line, slightly lift the lower part
of the door and using pliers > insert 1 x C-type washer between the bottom of
the door and the middle hinge.
(pic1)
10
WARNING!
Please be careful so that you do not get your fingers
caught between the doors. Use a tool to avoid injury.
Keep the C-type washers out of children’s reach. They
are small parts and could easily be swallowed.
CONTROL PANEL
The control panel display lights up for 2 minutes once the door of the fridge or
freezer compartment is opened or when any control is pressed.
On first connection, the display shows the factory default temperatures for the
fridge/freezer compartments. During normal operation, the temperature
display of the fridge and freezer compartments show the temperature of the
current settings.
The control panel will be locked automatically 25 seconds after the last control
panel action, and the control panel illumination will turn off after 2 minutes.
DISPLAY:
1. Refrigerator Icon
2. Freezer icon
3. Super Cool/Freezing icon
4. Temperature Display
5. Fruit/Vegetable icon
6. Meat icon
7. Drink icon
CONTROLS:
a. Temperature Up
b. Temperature Zone
c. Temperature Down
d. Super Cool/Super Freeze
e. Variable Temperature
f. Lock/Unlock
11
CONTROL PANEL (Cont.)
TEMPERATURE SETTING FOR REFRIGERATOR
Press the Temperature Zone selection button to choose the setting temperature
zone of REFRIGERATOR, then press UP or DOWN arrow buttons to adjust the
temperature setting. Temperature range is from 2°C to 8°C
TEMPERATURE SETTING FOR FREEZER
Press the Temperature Zone selection button to choose the setting temperature
zone of FREEZER, then press UP or DOWN arrow buttons to adjust the
temperature setting. Temperature range is from -24°C to -16°C
VARIABLE ZONE (VEGETABLE/MEAT/DRINK ZONE)
Press the “VARIO TEMP” button to adjust the left compartment located inside
the refrigerator (marked below). The Meat icon for meats, Vegeteable icon for
Fruit/Vegetables and Drink icon for Drinks.
SUPER COOL MODE
When the super cool mode is set, temperature of refrigerator will automatically
be set to 2°C. Super cool mode ends after 6 hours. Press Super Cool again to exit
if you want to end the mode earlier.
SUPER FREEZE MODE
When the super freeze mode is set, temperature of freezer will automatically be
set to -24°C. Super freeze mode ends after 24 hours. Press Super Freeze again to
exit if you want to end the mode earlier.
12
OPERATIONS
CONTROL PANEL LOCK
• Touch and hold the UNLOCK control for 3 seconds until a beep occurs that the
control panel is now locked.
• To Unlock the control panel before any operation, touch and hold the UNLOCK
control for 3 seconds until a beep indicates that the control panel is
now unlocked.
13
TROUBLSHOOTING
14
SPECIFICATIONS
Total Capacity 474 Litres
Refrigerator Capacity 305 Litres
Freezer Capacity 169 Litres
Climate Class T
Rated Current 1.8 A
Power Supply 220-240V ~ 50Hz
Defrost Power 250W
Refrigerant R600a(70g)
Insulation Blowing Gas Cyclopentane
Weights Net: 85.5 kg / Gross: 94.5 kg
Dimensions 835 (w) x 653 (d) x 1775 (h) mm
CUSTOMER HELPLINE:
info@ayonz.com
DISTRIBUTED BY:
Ayonz Pty Ltd
15
CUSTOMER HELPLINE:
info@ayonz.com
DISTRIBUTED BY:
Ayonz Pty Ltd
Loading...
