Page 1
HomeDVR-KT1B
One Outdoor Wired Camera System Kit – Audio,
Night Vision & SD Recorder
EASY TO USE
AUDIO
The HomeDVR-KT1B is a simple one camera recorder security system for home and small business. It includes one compact size
wired outdoor/indoor color camera with night vision and a palm size digital video recorder. The digital video recorder can records
24-404 total hours of audio and video using MPEG-4 compression into a SD card featuring time/date stamp, automatic overwrites
when SD card is full, and more.
RECORD SD
NIGHT VISION
COLOR
WEATHER
RESISTANT
Package includes:
• 1 x HomeDVR recorder and remote control
• 1 x Wired outdoor/indoor camera (SM-302) with
mounting bracket
• 2 x Power adapters (camera and recorder)
• 3 x AV cable
• 2 x Alarm cable
• 1 x USB cable
• Camera mounting screws
• Quick Start Guide and manuals (HomeDVR and SM-302)
• 1 x 100ft VP(video power) cable
Key specifications:
Image Sensor
Total Pixels
Video Format
Horizontal Resolution
Night Vision Range
SM-302 Camera
HomeDVR
Audio
Viewing Angle
Weatherproof
Connector Interface
Power Consumption
Operating Temperature
Operating Humidity
Dimensions (WxDXH)
Video Compression
Video/Audio Inputs
Video/Audio Output
Video Resolution (NTSC/PAL)
USB Mini
Operation
Features:
• Do-it-yourself (D.I.Y), easy to setup and use
• Small scale security system for home and business
• One compact size outdoor/indoor color camera (SM-302) with audio
• Best picture quality from wired camera; wireless interference free
• Built-in IR LEDs for night vision up to 23 (B/W)
• Future upgradeable by adding 1 more wireless or wired camera (select
one active channel for recording)
• Records audio and video to SD card (up to 32GB, SD card not included)
• Up to 24-404 video hours of recording time for a 32GB
• Overwrites when SD card is full
• Schedule, manual, or motion detection recording
• USB port for backup, download, and playback
1/4” CMOS Color
510(H) x 492(V)
NTSC
420 TV Lines
Up to 23ft (B/W)
Microphone built-in (audio monitoring up to 20ft)
45 degree
IP54
Audio/Video (RCA)
200 mA (IR ON) / 80 mA (IR OFF)
-10°C~+50°C / +14°F~+122°F
85%RH
2.4”x1.4”x1.4” (camera body)
MPEG4
2/2 (3.5mm interface, NTSC/PAL) (Choose one for recording)
1/1 (3.5mm interface)
350x240/352x288 (Recording)
704x480/704x576 (Preview/Playback image)
USB 1.1
Front panel and remote control (IR)
