Seco-Larm SLI 820R A User Manual
OWNERS MANUAL
ENFORCER
SLI 820R • SLI 820R-4
SLI 820RTC • SLI 820RTC-4
SLI 820RTF • SLI 820RTF-4
(315 MHz) (433.92 MHz)
Factory Keyless Entry
Alarm Adapter Security System
®
SECO-LARM® U.S.A., INC.
16842 Millikan Avenue
Irvine, California 92606
FILE: MOI820R.pmd/OCT2002
ORDER PART# 760 923/91B
ENFORCER SLI 820R/-4
CONGRATULATIONS
From the moment you purchased this ENFORCER Vehicle Security System, you became a part of the SECO-LARM
family. You started taking advantage of over 30 years of advanced engineering. You joined a team of engineers,
technicians, designers, and people like yourself who know how important protecting your car is. You discovered the
SECO-LARM difference.
This difference is important because the ENFORCER is more than just an alarm. It is a complete security and
convenience system. It is like having your personal security guard and butler on call in your car, 24 hours a day.
Keep in mind that the best security systems will not work properly without careful installation. Therefore, the
ENFORCER
your needs, and
your dealer, and you!
IMPORTANT
This ENFORCER security system contains many innovative features and unique functions. Please read this Owners
Manual carefully in order to understand all of this alarms security and convenience features. Some features may
require the addition of sensors or accessories not included with this alarm. Please consult your professional
SECO-LARM dealer.
NOTICE
The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the
right to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical
errors.
Copyright © 2002 SECO-LARM® U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written permission of SECO-LARM. This vehicle security system is protected by patents
in the U.S.A., Great Britain, Germany, Hungary, Taiwan, China, Japan, and Korea. Other U.S.A. and international
patents are pending.
is designed for installation by your professional SECO-LARM dealer. He understands both his alarms and
will work hard to ensure the ENFORCER does its job for you. Welcome to the family: SECO-LARM,
Owner's Manual
TABLE OF CONTENTS
Arming (with factory remotes)............................ 3
Armed ............................................................... 4
Zone Bypass...................................................... 4
Total Protection ..................................................4
Disarming (with factory remotes) .......................5
Smart Disarming ............................................... 5
Emergency Disarm............................................. 5
Domelight Supervision .......................................5
Ignition-Controlled Power Door Locks ................. 6
Valet..................................................................6
Dual-stage Shock Sensor................................... 6
Tamper Indicators and Trigger Zone ID ................ 6
Transmitter Function (with ENFORCER remotes).
Arming (with ENFORCER remotes)......................7
Page 2
Emergency Call for Help (Panic)
(with ENFORCER remotes) ............................ 8
Sensor Bypass (with ENFORCER remotes) .........8
Disarming (with ENFORCER remotes)................ 8
Patented Stay-Safe Disarm
(with ENFORCER remotes) ............................ 9
Chirp Delete (with ENFORCER remotes) ............. 9
2nd Channel Output (with ENFORCER remotes)..
Appendix 1 Understanding the
Siren Chirps and Light Flashes....................10
Appendix 2 Understanding the
LED Flashes ...............................................11
Appendix 3 Programmable Features ..........11
7
Accessories ....................................................12
SECO-LARM U.S.A., Inc.
9
ENFORCER SLI 820R/-4
Owner's Manual
MODEL NO. REFERENCE:
l SLI 820R & SLI 820R-4 Excludes RF transmitter ( optional ).
l SLI 820RTF & SLI 820RTF-4 Includes 2 RF fixed code transmitters.
l SLI 820RTC & SLI 820RTC-4 Includes 2 RF code hopping transmitters.
NOTE: Model no. without -4 represents alarm units using 315 MHz frequency and model no. with -4 represents
alarm units using 433.92 MHz frequency.
ARMING (with factory remotes)
To arm the alarm, lock the doors by using the
factory remote or by pressing the lock switch on
the door panel. However, to suit user style and
preference, the SLI 820R/-4 offers a choice of
arming styles. Tell your dealer which is best for
you:
q Active Arming
Turn your ignition OFF and close all the doors.
Then arm the alarm by locking all the doors
with the factory remote. If the siren chirps
and parking lights flash once, the alarm is fully
armed.
If the siren chirps 3 times, the alarm is either
waiting for the vehicles delayed domelights to
turn OFF (if your vehicle is so equipped), or it is
telling you that one of the alarms zones (a
door, or the hood, or trunk) is either open or is
not functioning properly. (See ZONE BYPASS,
page 4). Also, check to make sure your cars
domelight switch was not left in the ON
position.
q Passive arming
Turn your ignition OFF, and open a door to exit
the car. When the last door is closed (and the
domelight turns OFF, if your car has delayed
domelights), the siren chirps and parking lights
flash once. The LED flashes quickly during the
30-second arming countdown, after which the
siren chirps and parking lights flash once more
to confirm the alarm is completely armed.
If you wish, you can open a door during the
arming countdown, and keep it open for as long
as needed. The LED turns OFF while the door
is opened. Close the last door, and the siren
will chirp and parking lights flash once to
show the 30-second arming countdown has
started again. The LED will also begin to
flash quickly.
If you close the last open door, and the siren
does not chirp and parking lights do not flash,
you know that one or more openings are not
closed properly. This is SECO-LARMs patented
Quick and Quiet Testing (Q.Q.T.), and it
prevents you from thinking your alarm is
armed when it may not be. In this case,
double-check that all the doors, as well as the
hood and trunk, are closed properly, and that
your vehicles domelights are OFF. If you
cannot locate the problem, but need to arm the
alarm, then press the lock button to
immediately arm the alarm and bypass
whatever zone is open (see ZONE BYPASS,
page 4).
NOTE Under passive arming, you can force your
alarm to arm immediately any time during the 30second arming countdown by pressing the factory
remote lock button.
NOTE Make sure your cars domelight switch is
not in the ON position when you arm your alarm
either actively or passively, otherwise the alarm
may not arm properly if the domelight switch is left
ON.
NOTE There are references to opening or closing
a door throughout this manual. Door also
includes your hood and trunk, if they are protected.
Consult your dealer.
Page 3
ENFORCER SLI 820R/-4
Owner's Manual
ARMED
When the 30-second arming countdown ends, or
when the factory remote lock button is pressed,
the siren chirps and parking lights flash once, and
ZONE BYPASS
the LED starts flashing to show the alarm is
armed.
When you lock all doors to arm the alarm, and the
alarm responds with three chirps and three parking
light flashes, there are two possibilities:
A. Delayed domelights Delayed domelights do
not immediately turn OFF when you close your
car door. This is normal. The alarm should
protect all doors once the domelights turn OFF.
B. A zone was bypassed In other words, the
alarm has armed, but a door may not be
protected (either because it is open, or
because its pin switch is broken). If the
bypassed door is later closed, it will be
restored.
TOTAL PROTECTION
While your alarm is armed, your car is protected in
the following ways:
l
Potential thieves or vandals should be deterred
by the flashing LED.
l
If anyone opens a door, hood or trunk, the alarm
will immediately sound the siren and flash the
parking lights for up to three 30-second cycles,
after which the alarm will rearm, bypassing any
open doors, hood or trunk.
l
Turning the ignition key ON will trigger the alarm
for 30 seconds.
l
The starter disable prevents the engine from
being started.
If your alarm indicates a bypassed zone, find the
cause as soon as possible to ensure your vehicle is
completely protected. For instance, if your drivers
door is not properly closed when you arm your
alarm, a thief may be able to open any door
without setting off the alarm.
NOTE The chirps to confirm zone bypass will
not sound if chirp delete is engaged. However, the
parking lights will still flash three times. See
CHIRP DELETE, page 9.
l
If the shock sensor detects light taps on the
car, it will trigger the pre-intrusion alert (the
siren chirps three times and the parking lights
flash three times) to warn potential thieves
and vandals. However, if the shock sensor
detects a strong shock to the car, it will trigger
the alarm for 30 seconds. (See DUAL-STAGE
SHOCK SENSOR, page 6.)
l
Optional SECO-LARM shock, motion, glassbreak, and microwave sensors will offer your
alarm additional protection. Consult your
SECO-LARM dealer.
Page 4
SECO-LARM U.S.A., Inc.
