Seco-Larm SB-P1012-26Q User Manual
SB-P1012-26Q / SB-L10V1-20Q
Plug-and-Play Backup Power
Manual
ENFORCER Plug-and-Play Backup Power units provide automatic continual power to CCTV
cameras, routers, modems, VOIP phone systems, alarm systems, or other small electronic devices
during power outages. In addition, they include protection against short-circuits and power surges.
The high quality GE™ batteries are protected from short-circuit, overcharge, over-discharge, and
overload.
Note: All trademarks named herein are the property of their respective owners.
SB-L10V1-20Q In-line Backup Power
SB-P1012-26Q Plug-in Backup Power
ENFORCER Plug-and-Play Backup Power
Model
SB-P1012-26Q
SB-L10V1-20Q
Type
Plug-in UPS adapter
In-line UPS
Input
85~265VAC@50/60Hz
5/7.5/9/12VDC±10%
Input protection
Overload and short-circuit fuse
Output
12VDC±5%
Auto-configure 5/7.5/9/12VDC±5%
Output power rating
10W
Output protection
Over-discharge, overload, short-circuit protection
Battery
Replaceable GE™ 18650 Li-Ion
3.7VDC/2600mAh
GE™ Lithium Polymer
3.7VDC/2000mAh
Battery Protection
Overcharge, over-discharge,
overload, short-circuit, battery polarity
Overcharge, over-discharge,
overload, short-circuit
Backup time
Half Load
70 min
60 min
Full Load
30 min
25 min
LED indicators
Power, backup
Voltage, power, alarm, backup
Output cord
5.5ft / 1.4m
12" (30.5cm)
Output jack
5.5x2.1mm
Operating temperature
32~104°F (0~40°C)
Operating humidity
0~95% non-condensing
Dimensions
37/16"x27/8x"15/32" (87x59.8x29mm)
33/8"x21/4x"121/32" (85x57x42mm)
Weight
4.3-oz (122g)
4.3-oz (121g)
Specifications:
Real-time backup power with no break
when input power is lost
DC UPS Auto-start
User-replaceable 2600mAh GE
™
18650
Li-Ion battery (SB-P1012-26Q only)
Over-discharge, overcharge, overload,
short-circuit, surge, and (SB-P1012-26Q
only) battery polarity protection
Parts List:
LED indicators for power and charging
Batteries provided by GE
™
Additional features for SB-L10V1-20Q
Auto-recognize voltage (5/7.5/9/12VDC)
input and sets corresponding output
2000mAh lithium polymer battery
Additional indicator LEDs for output voltage
and alarm (alarm is also audible)
LED Indicators
Power
Backup
12V 9V 7.5V 5V
Overview:
Power Input
Off/Reset
12V 9V 7.5V 5V
ENFORCER
®
SB-P1012-26Q
SB-L10V1-20Q
1x
UPS with battery and power cord
1x
Manual
LED Indicators
Status Indication
Voltage (Green)
On: Indicates detected input voltage and
supplied output voltage
Power (Green)
On: UPS protection on
Off: UPS protection off
Alarm (Red)*
On: Overload, input voltage out of range, or, input
voltage failure, Flashing: Battery low
Backup (Yellow)
On: Backup mode
Off: Line mode
*Audible alarm – Continuous long beep indicates alarm or failure (see troubleshooting), 5 short beeps
indicate transferring to backup power, and continuous short beeps indicate low battery
Features:
