Wireless Magnetic Contact
RA-4961-MCQ
Wireless Magnetic Contact
Features:
For use with the RA-4961 series receivers
Wirelessly monitor windows, doors, or other areas
Up to 1,000ft (305m) transmission range*
Activates each time the door or window is moved
Magnet can be placed on either side
Adhesive mount – no screws required
Specifications:
RA-4961-MCQ
* Line of sight. Transmission range will vary depending on installation and operating environment.
Model Number
RA-4961-MCQ
Frequency
914.8MHz
Transmission range*
Up to 1,000ft (305m)
Channels
1
Power supply
2x CR2032 Batteries (Included)
Current Draw
Standby
8μA
Max
80mA
Estimated battery life
132 days (3 triggers/day)
Low battery indicator
Zone LED on receiver blinks continuously
Sound level
96dB@1ft(30cm)
Contact distance
3
/8
”(1cm)
Operating Temperature
-4°~140°F (-20°~60°C)
Dimensions
Magnetic Contact
1
7
/8
”x
1
/4
”x4
3
/16
” (48x7x107mm)
Magnet
3
/8
”x
1
/4
”x1
9
/16
” (10x7x39mm)
