Wireless Magnetic Contact
Manual
For use with RA-4961 series receivers
• Wirelessly monitor windows, doors, or
other areas
• Up to 1,000ft (305m) transmission range*
Activates each time the door or window
is moved.
• Magnet can be placed on either side.
• Adhesive mount - No screws required
CBA Wireless Magnetic Contact
Specifications:
Model number
RA-
4961-MCQ
Frequency
914.8MHz
Transmission range*
Up to 1,000ft (305m)
Channels
1
Power supply
2x
CR2032
Batteries
(included)
Current
Standby
8µA
Max 80mA
Estimated b
attery life
132 days (3 triggers/day)
Low battery indicator
Zone LED on receiver blinks continuously
Sound level
96dB@1ft(30cm)
Contact distance
3/8"(1cm)
Operating temperature
-4º~140º F (
-
20º~60º C)
Magnetic Contact
17/8"x1/4"x43/16" (48x
7x107 mm)
Magnet
3/8"x1/4"x19/16" (10x7x39 mm)
2x CR2032 Batteries
1x Magnet
Parts List:
1x Magnetic contact
2x Adhesive strips*
Dimensions:
Magnet
*Magnet ad
hesive strip comes pre
-
applied
1x Manual
Overview:
Speaker
Alarm switch
Battery compartm
ent
Status LED
Magnet
Alignment
Magnetic contact
17/8"
/4"
Side
Front
43/16"
19/16"
(39mm)
/8"
/4"
*Transmission range will vary depending on installation and operating environment
draw
Dimensions
(48mm)
1
(7mm)
3
(10mm)
1
(7mm)
(107mm)
Front
Side
marks
2 SECO-LARM U.S.A., Inc.
CBA Wireless Magnetic Contact
Installation:
1. Select the location where the magnetic contact and magnet will be mounted. The magnet may
Programming the Contact Notification Mode:
Pairing the Contact:
1. Follow the pairing instructions for the RA
-
4961-K1Q receiver or RA
-
4961-VPQ wireless receiver
1. The magnetic contact has three modes
— Remote Alarm, OFF, and
Local a
nd Remote Alarm
.
Remote
OFF
Local and
be installed on either side of the contact, but the alignment marks should be aligned with the
marks on the contact. The gap should be no more than 3/8"(1cm).
2. Use the included adhesive strips to mount the door contact and magnet.
2. When the switch is flipped to Remote Alarm, when the magnetic contact is triggered, the status
LED will switch on and there will be no sound from the contact. The receiver will operate as
programmed.
3. When the switch is flipped to OFF, the magnetic contact will not function.
4. When the switch is flipped to Local and Remote Alarm, when the door contact is triggered, the
built-in speaker will sound for 15 seconds or until the unit is switched to OFF. The receiver will
operate as programmed.
Remote
Alarm
Alarm
to enter the pairing mode (Refer to the RA-4961-K1Q or RA-4961-VPQ manual for detailed
instructions).
2. Switch the contact to either of the two operating modes.
3. Trigger the contact by moving the magnet away from the contact or by opening the door/window
if already mounted.
4. The receiver will beep once and cycle to the next channel to
confirm successful pairing.
SECO-LARM U.S.A., Inc. 3
CBA Wireless Magnetic Contact
Installing Batteries:
Also Available from SECO
-
LARM:
1. Slide the cover from the b
attery compartment on
Wireless
Wireless
Wireless
Wireless
Wireless
Note: Low battery is indicated on the receiver. Refe
r to the RA
-
4961-K1Q or RA
-
4961-VPQ manual
for more information.
+
Wireless
NOTICE
:
However, the
erves the right to
Trademarks
This material may not be reproduced or copied, in whole or
LIMITED
WARRANTY:
LARM product is warranted against defects in material and workmanship while
LARM’s obligation is limited to
This Warranty
misuse or abuse, neglect, repair or
LARM determines that such
The sole
LARM and the purchaser’s exclusive remedy, shall be limited to the replacement or repair only, at
LARM be liable for any special, collateral, incidental, or consequential
SECO
-
LARM
the front of the contact.
2. Place 2x CR2032 batteries (included) in the
battery compartment, making sure to observe
correct polarity.
3. Replace the cover.
+
