Product Manual
Seagate® 600 Pro SSD
Standard 2.5”
Managed Life models
ST480FP0001
ST400FP0001
ST240FP0001
ST200FP0001
ST120FP0001
ST100FP0001
Standard 2.5”
Usage Based models
ST480FP0021
ST400FP0021
ST240FP0021
ST200FP0021
ST120FP0021
ST100FP0021
100727924
Rev. A
May 2013
Document Revision History
Revision Date Description of changes
Rev. A 05/10/2013 Initial release.
© 2013 Seagate Technology LLC. All rights reserved.
Publication number: 100727924, Rev. A May 2013
Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or
other countries. Seagate 600 Pro SSD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or
one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does
not imply product endorsement by NIST, the U.S., or Canadian governments.All other trademarks or registered trademarks are the
property of their respective owners.
No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.
Call 877-PUB-TEK1 (877-782-8351) to request permission.
When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your
computer’s operating system may use a different standard of measurement and report a lower capacity. In addition, some of the listed
capacity is used for formatting and other functions, and thus will not be available for data storage. Actual quantities will vary based on
various factors, including file size, file format, features and application software. Actual data rates may vary depending on operating
environment and other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S.
Department of Commerce, Bureau of Industry and Security (for more information, visit www.bis.doc.gov), and controlled for import
and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.
Contents
Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.0 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 About the Serial ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Specification summary tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2.1 LBA mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Default logical geometry for ATA based systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4 Performance, Recording and interface technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4.1 Interface technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4.2 Recording technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4.3 Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.5 Physical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.6 Access time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.7 Time to Ready . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.8 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.8.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.8.2 DC power requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.9 Environmental specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.9.1 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.9.2 Temperature gradient. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.9.3 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.9.4 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.9.5 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.9.6 Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.10 Electromagnetic immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.11 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.11.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF). . . . . 16
2.11.2 Reliability specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.12 Agency certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.12.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.12.2 Electromagnetic compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.12.3 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.13 Environmental protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.13.1 European Union Restriction of Hazardous Substances (RoHS) Directive . . . . . 18
2.13.2 China Restriction of Hazardous Substances (RoHS) Directive . . . . . . . . . . . . 18
2.14 Corrosive environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Handling and static-discharge precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2 Configuring the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.3 Serial ATA cables and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.5 Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.0 Serial ATA (SATA) interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1 Hot-Plug compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2 Serial ATA device plug connector pin definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3.1 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.3.2 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.3.3 S.M.A.R.T. commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.3.4 SSD Percentage Endurance Remaining Indicator . . . . . . . . . . . . . . . . . . . . . . . 33
ii Seagate 600 Pro SSD Product Manual, Rev. A
FIGURES
Figure 1. Typical 5V Startup and Operation Current Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Figure 2. Attaching SATA cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Figure 3. Mounting configuration dimensions (7mm models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Figure 4. Air flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A III
Seagate® Technology Support Services
For information regarding online support and services, visit
Available services include:
• Presales & Technical support
• Global Support Services telephone numbers & business hours
• Authorized Service Centers
Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”.
Consult your Seagate sales representative for warranty terms and conditions.
For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/
For Seagate OEM and Distribution partner portal, visit:
For Seagate reseller portal, visit:
http://www.seagate.com/partners/my-spp-dashboard/
http://www.seagate.com/about/contact-us/technical-support/
http://www.seagate.com/partners/
Seagate 600 Pro SSD Product Manual, Rev. A 1
1.0 INTRODUCTION
This manual describes the functional, mechanical and interface specifications for the following Seagate® 600 Pro SSD model
drives:
2.5" M
These drives provide the following key features:
• Multi-Level Cell (MLC) NAND Flash storage.
• Serial ATA 3.1 Host Interface (SATA 6Gb/s).
• High instantaneous (burst) data-transfer rates (up to 520MB/s).
• Parallel flash access channels.
• State-of-the-art on-the-fly error-correction algorithms.
• Native Command Queueing with command ordering to increase performance in demanding applications.
• Highly integrated hardware functions.
• Power loss data protection.
• Data Set Management with Trim Support.
• Silent operation.
• SeaTools diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
• Support for S.M.A.R.T. drive monitoring and reporting.
• Supports latching SATA cables and connectors.
• Worldwide Name (WWN) capability uniquely identifies the drive.
ANAGED LIFE MODEL 2.5" USAGE BASED MODEL
ST480FP0001 ST480FP0021
ST400FP0001 ST400FP0021
ST240FP0001 ST240FP0021
ST200FP0001 ST200FP0021
ST120FP0001 ST120FP0021
ST100FP0001 ST100FP0021
1.1 ABOUT THE SERIAL ATA INTERFACE
The Serial ATA interface provides several advantages:
• Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options.
• Thinner and more flexible cabling for improved enclosure airflow and ease of installation.
• Scalability to higher performance levels.
The Serial ATA interface connects each drive in a point-to-point configuration with the Serial ATA host adapter. If two drives
are attached on one Serial ATA host adapter, the host operating system views the two devices as if they were both “masters”
on two separate ports.
Note. The host adapter may, optionally, emulate a master/slave environment to host software where two devices on
separate Serial ATA ports are represented to host software as a Device 0 (master) and Device 1 (slave)
accessed at the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two sets of shadow registers. This is not a typical Serial ATA environment.
The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide backward
compatibility with existing host systems and software. The Command and Control Block registers, PIO and DMA data
transfers, resets, and interrupts are all emulated.
The Serial ATA host adapter contains a set of registers that shadow the contents of the traditional device registers, referred
to as the Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how
Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The
specification can be downloaded from www.serialata.org.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 2
2.0 DRIVE SPECIFICATIONS
Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For
convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models:
Capacity
480GB 400Gb 240GB 200GB 120GB 100GB
2.5” Managed Life Warranty
2.5” Usage Based Warranty
Product data communicated in this manual is specific only to the model numbers listed in this manual. The data listed in this
manual may not be predictive of future generation specifications or requirements. If you are designing a system which will
use one of the models listed or future generation products and need further assistance, please contact your Customer
Technical Support Engineer or our global support services group as shown in See “Seagate® Technology Support Services”
on page 1.
2.1 SPECIFICATION SUMMARY TABLES
The specifications listed in the following table is for quick reference. For details on specification measurement or definition,
see the appropriate section of this manual.
ST480FP0001 ST400FP0001 ST240FP0001 ST200FP0001 ST120FP0001 ST100FP0001
ST480FP0021 ST400FP0021 ST240FP0021 ST200FP0021 ST120FP0021 ST100FP0021
Table 1Drive specifications summary for 2.5” - 400, 200 and 100 GB models
Drive specification
Formatted GB (512 bytes/sector)
Guaranteed logical block addresses (LBAs) 937,703,088 781,422,768 468,862,128 390,721,968 234,441,648 195,371,568
Emulated Bytes per LBA 512
Peak128KB sequential read/write data transfer rate
(MB/s max)
Sustained 128KB sequential read/write data transfer
rate (MB/s max)
Peak 4KB Random read/write command rate
(KIOPs)
Sustained 4KB Random read/write command rate
(KIOPs)
Flash Memory Type NAND MLC
I/O data-transfer rate (MB/s max) 600
Height (mm max) 7.00 mm (0.276 in)
Width (mm max) 70.10 mm (2.760 in)
Length (mm max) 100.45 mm (3.955 in)
Weight (max) 100 g (0.220 lb)
Power-on to ready (sec typ)
Standby to ready (sec max) 3 sec
Average LBA access time (μs typ) ~158 μs read; ~125 μs write
Data Retention (typical minimum at 40°C) 3 months
Sustainable Write Bandwidth under JEDEC Mix for
3 Year Endurance at 100% duty cycle in MB/sec
Startup current 5V (typical/peak) 550 / 600 mA
Voltage tolerance (including noise) 5V ± 5%
Temperature
Temperature gradient (°C per hour max)
Relative humidity
Relative humidity gradient 20% per hour max
Wet bulb temperature (°C max) 29
[1]
[2]
ST480FP0001
ST480FP0021
480 400 240 200 120 100
85/11 85/30 85/11 85/30 80/8 80/20
2.5 9.7 1.3 4.8 0.6 2.4
ST400FP0001
ST400FP0021
0° to 70°C (operating as reported by SMART attribute 194)
ST240FP0001
ST240FP0021
520/450 520/300
520/450 520/300
85/30 80/20
–40° to 75°C (nonoperating)
20°C (operating)
20°C (nonoperating)
5% to 95% (operating)
5% to 95% (nonoperating)
ST200FP0001
ST200FP0021
3 sec
ST120FP0001
ST120FP0021
ST100FP0001
ST100FP0021
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 3
Drive specification
Altitude, operating
Altitude, nonoperating
(below mean sea level, max)
Operational Shock (max at 0.5ms) 1000 Gs
Non-Operational Shock (max at 0.5ms) 1000 Gs
Vibration, random operating 20–2000 Hz: 11.08 Grms
Vibration, random nonoperating 20–2000 Hz: 11.08 Grms
Nonrecoverable read errors, max 1 LBA per 10
Annualized Failure Rate (AFR) 0.58%
Warranty 3
Lifetime Power cycles 25,000
Supports Hotplug operation per
Serial ATA Revision 3.0 specification
[1] One GB equals one billion bytes when referring to drive capacity. Accessible capacity may vary depending on operating environment and formatting.
[2] Max time approximately 30 sec when standby immediate was not issued before power down.
[3] Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”.
2.2 FORMATTED CAPACITY
[3]
Consult your Seagate sales representative for warranty terms and conditions.
ST480FP0001
ST480FP0021
ST400FP0001
ST400FP0021
5 Year Usage Based or 3 Year Life Managed configuration
ST240FP0001
ST240FP0021
–61 m to 3048 m
(–200 ft. to 10,000+ ft.)
–61 m to 12,192 m
(–200 ft to 40,000+ ft)
Yes
ST200FP0001
ST200FP0021
16
bits read
ST120FP0001
ST120FP0021
Formatted capacity* Guaranteed LBAs Emulated LBA Size (Bytes)
ST100FP0001
ST100FP0021
480GB 937,703,088
400GB 781,422,768
240GB 468,862,128
512
200GB 390,721,968
120GB 234,441,648
100GB 195,371,568
*One GB equals one billion bytes when referring to drive capacity. Accessible capacity may vary depending on operating environment and formatting.
2.2.1 LBA mode
When addressing these drives in LBA mode, all blocks (LBAs) are consecutively numbered from 0 to n–1, where n is the
number of guaranteed LBAs as defined above.
See Section 4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-bit addressing
support of drives with capacities over 137GB.
2.3 DEFAULT LOGICAL GEOMETRY FOR ATA BASED SYSTEMS
CYLINDERS READ/WRITE HEADS SECTORS PER TRACK
16,383 16 63
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 4
2.4 PERFORMANCE, RECORDING AND INTERFACE TECHNOLOGY
2.4.1 Interface technology
Interface
Interface Speeds
Supported
Maximum Burst
Transfer Rate
Hot Plug Support
Native Command
Queuing Support
Trim Support
Lifetime Endurance
Management Option
480GB
MODELS
Serial ATA (SATA-II)
6Gb/s, 3Gb/s, 1.5Gb/s
600MB/s
Yes
Yes
Yes
Yes
400GB
MODELS
240GB
MODELS
2.4.2 Recording technology
Flash Memory Type NAND MLC
Emulated LBA Size (Bytes) 512
Native Programmable Page size (User Bytes) 8192
Default transfer alignment offset 0
Typical Data Retention with Power removed (at 40°C) 3 months
200GB
MODELS
120GB
MODELS
100GB
MODELS
2.4.3 Performance
Notes 480GB 400GB 240GB 200GB 120GB 100GB
Maximum Burst Transfer Rate (MB/s) 520
Peak sequential 128KB read/write data
transfer rate (MB/s max)
Sustained sequential 128KB
read/write data transfer rate (MB/s)
Peak 4KB random read/write command
rate (KIOPs)
Sustained 4KB random read/write
command rate (KIOPs)
[4] 520/450 520/300
[4] 520/450 520/300
[5] 85/30 80/20
[5] 85/11 85/30 85/11 85/30 85/8 85/20
[4] Testing performed at Queue Depth = 32, Sequentially Preconditioned drive, using IOMeter 2006.7.27.
[5] Testing performed at Queue Depth = 32, Randomly Preconditioned drive, using IOMeter 2006.7.27.
[6] Testing performed at Queue Depth = 32, Non-Preconditioned drive, using IOMeter 2006.7.27.
Note. IOMeter is available at http://www.iometer.org/ or http://sourceforge.net/projects/iometer/.
IOMeter is licensed under the Intel Open Source License and the GNU General Public License. Intel does not
endorse any IOMeter results.
Peak performance is defined as the typical best case performance that the product will be able to achieve when the
product is preconditioned as mentioned and host commands are aligned on 4KB boundaries.
Sustained performance is defined as the typical worst case performance that the product will be able to achieve when the
product is preconditioned as mentioned and host commands are aligned on 4KB boundaries. For models that support Lifetime
Endurance Management, write values also take into account the worst case performance throttling that may occur to ensure
the product meets specified reliability specifications.
Due to the nature of Flash memory technologies there are many factors that can result in values different than those stated
in this specification. Some discrepancies can be caused by bandwidth limitations in the host adapter, operating system, or
driver limitations. It is not the intent of this manual to cover all possible causes of performance discrepancies.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 5
When evaluating performance of SSD devices, it is recommended to measure performance of the device in a method that
resembles the targeted application using real world data and workloads. Test time should also be adequately large to ensure
that sustainable metrics and measures are obtained.
2.5 PHYSICAL CHARACTERISTICS
Maximum height 7.00 mm (0.276 in)
Maximum width 70.10 mm (2.760 in)
Maximum length 100.45 mm (3.955 in)
Max weight 100 g (0.220 lb)
2.5” models
2.6 ACCESS TIME
Access measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive
diagnostics. The specifications in the table below are defined as follows:
• Page-to-page access time is an average of all possible page-to-page accesses in both directions for a sequentially preconditioned drive.
• Average access time is a true statistical random average of at least 5000 measurements of accesses between programmable pages, less overhead, on a randomly preconditioned drive.
*TYPICAL ACCESS TIMES (μs) READ WRITE
Average 158 125
Note. These drives are designed to provide the highest possible performance under typical conditions. However, due to
the nature of Flash memory technologies there are many factors that can result in values different than those
stated in this specification.
2.7 TIME TO READY
480GB
400GB
Power-on to Ready for non-Media related Commands (sec) 3 (typ)
Power-on to Ready for Media related commands (sec) 14 (max)
Standby to Ready (sec) 3 (max)
Ready to power removal (sec) 3 (max)
Power-on to Ready for non-media related commands is defined as the time that it will take the drive to respond from the
application power until it is ready to accept commands from the host that do not require access to the flash media. In some
cases the drive may accept media access commands during this time, but the commands will not be completed or status
returned to the host until the media can be accessed safely. Commands such as Check Power and Identify are examples of
non-media related commands.
Power-on to Ready for media related commands is defined as the time that it will take the drive to respond from the
application power until it is ready to accept commands from the host that require access to the flash media. Commands
such as FPDMA Read Extended and FPDMA Write Extended are examples of media related commands. This value includes
the time needed to charge the Power Loss Data Protection Circuit to a level that is adequate to protect customer data from
unexpected power loss.
The maximum time for Power-on to Ready is dependent on if a STANDBY IMMEDIATE was issued prior to power down and
the write workload profile prior to power down.
240GB
200GB
120GB
100GB
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 6
2.8 POWER SPECIFICATIONS
The drive receives DC power (+5V) through a native SATA power connector. See Figure 2 on page 19.
2.8.1 Power consumption
Power requirements for the drives are listed in the table on page 9. Typical power measurements are based on an average of
drives tested, under nominal conditions, at 35°C ambient temperature.
• Startup power
Startup power is measured from the time of power-on to the time that the drive reaches operating condition and can process media access commands.
• Peak operating mode
During peak operating mode, the drive is tested in various read and write access patterns to simulate the worst-case
power consumption.
• Idle mode power
Idle mode power is measured with the drive powered up and ready for media access commands, with no media access
commands having been received from the host.
• Standby mode
During Standby mode, the drive accepts commands, but not be able to immediately access the media because the drive
electronics are in a partial power-down mode.
2.8.2 DC power requirements
Table 2 480GB DC power requirements
Parameter ST480FP00x1 (6.0Gb)
Voltage +5V Power
Regulation +/- 5% (watts)
Average Idle Current 0.44 2.21
Average Sleep Current 0.09 0.47
Maximum Start Current
DC (Peak DC) 0.54 2.72
AC (Peak AC) 0.99 4.97
Delayed Motor Start (DC max) 0.10 0.48
Peak Operating Current (random read):
Typical DC 0.38 1.92
Maximum DC 0.39 1.96
Maximum DC (peak) 1.02 5.10
Peak Operating Current (random write):
Typical DC 0.55 2.76
Maximum DC 0.57 2.84
Maximum DC (peak) 1.44 7.20
Peak Operating Current (sequential read):
Typical DC 0.48 2.39
Maximum DC 0.49 2.43
Maximum DC (peak) 1.00 5.00
Peak Operating Current (sequential write):
Typical DC 0.62 3.12
Maximum DC 0.63 3.17
Maximum DC (peak) 1.38 6.90
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase power to operational levels.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 7
Table 3 400GB DC power requirements
Parameter ST400FP00x1 (6.0Gb)
Voltage +5V Power
Regulation +/- 5% (watts)
Average Idle Current 0.45 2.27
Average Sleep Current 0.10 0.52
Maximum Start Current
DC (Peak DC) 0.58 2.89
AC (Peak AC) 0.98 4.90
Delayed Motor Start (DC max) 0.10 0.49
Peak Operating Current (random read):
Typical DC 0.37 1.86
Maximum DC 0.38 1.90
Maximum DC (peak) 1.02 5.10
Peak Operating Current (random write):
Typical DC 0.40 2.00
Maximum DC 0.43 2.14
Maximum DC (peak) 1.48 7.40
Peak Operating Current (sequential read):
Typical DC 0.47 2.37
Maximum DC 0.48 2.41
Maximum DC (peak) 1.06 5.30
Peak Operating Current (sequential write):
Typical DC 0.59 2.97
Maximum DC 0.64 3.22
Maximum DC (peak) 1.42 7.10
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase power to operational levels.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 8
Table 4 240GB DC power requirements
Parameter ST240FP00x1 (6.0Gb)
Voltage +5V Power
Regulation +/- 5% (watts)
Average Idle Current 0.47 2.37
Average Sleep Current 0.10 0.49
Maximum Start Current
DC (Peak DC) 0.56 2.78
AC (Peak AC) 0.90 4.50
Delayed Motor Start (DC max) 0.10 0.48
Peak Operating Current (random read):
Typical DC 0.35 1.75
Maximum DC 0.37 1.83
Maximum DC (peak) 1.00 5.00
Peak Operating Current (random write):
Typical DC 0.41 2.06
Maximum DC 0.46 2.31
Maximum DC (peak) 1.26 6.30
Peak Operating Current (sequential read):
Typical DC 0.44 2.20
Maximum DC 0.45 2.24
Maximum DC (peak) 0.92 4.60
Peak Operating Current (sequential write):
Typical DC 0.58 2.92
Maximum DC 0.60 2.99
Maximum DC (peak) 1.28 6.40
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase power to operational levels.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 9
Table 5 200GB DC power requirements
Parameter ST200FP00x1 (6.0Gb)
Voltage +5V Power
Regulation +/- 5% (watts)
Average Idle Current 0.45 2.25
Average Sleep Current 0.09 0.47
Maximum Start Current
DC (Peak DC) 0.56 2.80
AC (Peak AC) 0.88 4.40
Delayed Motor Start (DC max) 0.10 0.48
Peak Operating Current (random read):
Typical DC 0.34 1.71
Maximum DC 0.36 1.80
Maximum DC (peak) 0.96 4.80
Peak Operating Current (random write):
Typical DC 0.38 1.92
Maximum DC 0.42 2.11
Maximum DC (peak) 1.20 6.00
Peak Operating Current (sequential read):
Typical DC 0.45 2.26
Maximum DC 0.46 2.28
Maximum DC (peak) 0.92 4.60
Peak Operating Current (sequential write):
Typical DC 0.52 2.62
Maximum DC 0.59 2.93
Maximum DC (peak) 1.26 6.30
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase power to operational levels.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 10
Table 6 120GB DC power requirements
Parameter ST120FP00x1 (6.0Gb)
Voltage +5V Power
Regulation +/- 5% (watts)
Average Idle Current 0.45 2.24
Average Sleep Current 0.09 0.46
Maximum Start Current
DC (Peak DC) 0.53 2.66
AC (Peak AC) 0.96 4.78
Delayed Motor Start (DC max) 0.10 0.48
Peak Operating Current (random read):
Typical DC 0.35 1.74
Maximum DC 0.36 1.81
Maximum DC (peak) 0.92 4.60
Peak Operating Current (random write):
Typical DC 0.49 2.43
Maximum DC 0.50 2.52
Maximum DC (peak) 1.12 5.60
Peak Operating Current (sequential read):
Typical DC 0.50 2.48
Maximum DC 0.51 2.54
Maximum DC (peak) 1.02 5.10
Peak Operating Current (sequential write):
Typical DC 0.52 2.61
Maximum DC 0.53 2.63
Maximum DC (peak) 1.16 5.80
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase power to operational levels.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 11
Table 7 100GB DC power requirements
Parameter ST100FP00x1 (6.0Gb)
Voltage +5V Power
Regulation +/- 5% (watts)
Average Idle Current 0.42 2.10
Average Sleep Current 0.09 0.46
Maximum Start Current
DC (Peak DC) 0.54 2.68
AC (Peak AC) 0.89 4.46
Delayed Motor Start (DC max) 0.10 0.48
Peak Operating Current (random read):
Typical DC 0.36 1.79
Maximum DC 0.36 1.80
Maximum DC (peak) 0.92 4.60
Peak Operating Current (random write):
Typical DC 0.42 2.12
Maximum DC 0.43 2.17
Maximum DC (peak) 1.08 5.40
Peak Operating Current (sequential read):
Typical DC 0.48 2.39
Maximum DC 0.48 2.42
Maximum DC (peak) 0.94 4.70
Peak Operating Current (sequential write):
Typical DC 0.53 2.66
Maximum DC 0.54 2.70
Maximum DC (peak) 1.12 5.60
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase power to operational levels.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 12
2.8.2.1 Typical current profiles
Figure 1. Typical 5V Startup and Operation Current Profile
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 13
2.9 ENVIRONMENTAL SPECIFICATIONS
2.9.1 Temperature
Temperature is defined as the drive's internal temperature as reported by SMART attribute 194 for operation or the drive
case temperature for non-operating.
Above 1000 feet (305 meters), the maximum temperature is derated linearly to 112°F (44°C) at 10,000 feet (3048 meters).
Operating: 0° to 70°C (32° to 158°F)
Nonoperating: –40° to 75°C (–40° to 167°F)
2.9.2 Temperature gradient
Operating: 20°C per hour (30°F per hour max), without condensation
Nonoperating: 20°C per hour (30°F per hour max)
2.9.3 Humidity
2.9.3.1 Relative humidity
Operating: 5% to 95% noncondensing (20% per hour max)
Nonoperating: 5% to 95% noncondensing (20% per hour max)
2.9.3.2 Wet bulb temperature
Operating: 29°C (84°F max)
Nonoperating: 29°C (84°F max)
2.9.4 Altitude
** Operating: –61 m to 3048 m (–200 ft. to 10,000+ ft.)
** Nonoperating: –61 m to 12,192 m (–200 ft. to 40,000+ ft.)
** Applies to atmospheric pressure only.
2.9.5 Shock
All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws.
Shock may be applied in the X, Y or Z axis.
2.9.5.1 Operating shock
These drives comply with the performance levels specified in this document when subjected to a maximum operating shock
of 1000 Gs based on half-sine shock pulses of 0.5ms. This specification does not cover connection issues that may result
from testing at this level.
2.9.5.2 Nonoperating shock
The nonoperating shock level that the drive can experience without incurring physical damage or degradation in
performance when subsequently put into operation is 1000 Gs based on a half-sine shock pulse of 0.5ms duration.
2.9.6 Vibration
All vibration specifications assume that the drive is mounted securely with the input vibration applied at the drive mounting
screws. Vibration may be applied in the X, Y or Z axis.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 14
2.9.6.1 Operating vibration
The maximum random vibration levels that the drive may experience while meeting the performance standards specified in
this document are specified below. This specification does not cover connection issues that may result from testing at this
level.
20–2000 Hz 11.08 Grms
2.9.6.2 Nonoperating vibration
The maximum random nonoperating vibration levels that the drive may experience without incurring physical damage or
degradation in performance when subsequently put into operation are specified below.
20–2000 Hz 11.08 Grms
2.10 ELECTROMAGNETIC IMMUNITY
When properly installed in a representative host system, the drive operates without errors or degradation in performance
when subjected to the radio frequency (RF) environments defined in the following table:
Table 8 Radio frequency environments
TEST DESCRIPTION
Electrostatic discharge Contact, HCP, VCP: ± 4 kV; Air: ± 8 kV B EN 61000-4-2: 95
Radiated RF immunity 80 to 1000 MHz, 3 V/m,
80% AM with 1 kHz sine
900 MHz, 3 V/m, 50% pulse modulation @ 200 Hz
Electrical fast transient ± 1 kV on AC mains, ± 0.5 kV on external I/O B EN 61000-4-4: 95
Surge immunity ± 1 kV differential, ± 2 kV common, AC mains B EN 61000-4-5: 95
Conducted RF immunity 150 kHz to 80 MHz, 3 Vrms, 80% AM with 1 kHz sine A EN 61000-4-6: 97
Voltage dips, interrupts 0% open, 5 seconds
0% short, 5 seconds
40%, 0.10 seconds
70%, 0.01 seconds
PERFORMANCE
LEVEL
A EN 61000-4-3: 96
C
C
C
B
REFERENCE
STANDARD
ENV 50204: 95
EN 61000-4-11: 94
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 15
2.11 RELIABILITY
2.11.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF)
The product shall achieve an Annualized Failure Rate - AFR - of 0.58%. AFR and MTBF are population statistics that are not
relevant to individual units.
AFR and MTBF specifications are based on the following assumptions:
• 8760 power-on-hours per year.
• 250 average power cycles per year.
• Operations at nominal voltages.
• Systems will provide adequate cooling to ensure the case temperatures do not exceed specification.
2.11.2 Reliability specifications
Unrecoverable read error rate during 1 LBA per 1016 bits read, max
Annualized Failure Rate (AFR)
[5]
0.58%
Power cycles 25,000 cycles
Warranty Warranty terms will vary based on type of warranty chosen:
Preventive maintenance None required.
Typical Data Retention with Power removed (at 40°C) 3 months
Endurance Method 1: 2 Drive Writes per Day
(at nominal voltage and temperature, with 60 cycles per hour
and a 50% duty cycle)
“Managed Life”
sales representative for warranty terms and conditions.
Method 2: TBW (per JEDEC JESD218)
[3]
or “Usage Based”
[1]
400GB = 834TB
200GB = 417TB
100GB = 209TB
[4]
Consult your Seagate
[2]
[1] As NAND Flash devices age with use, the capability of the media to retain a programmed value begins to
deteriorate. This deterioration is affected by the number of times a particular memory cell is programmed
and subsequently erased. When a device is new, it has a powered off data retention capability of up to ten
years. With use the retention capability of the device is reduced. Temperature also has an effect on how long
a Flash component can retain its programmed value with power removed. At high temperature the retention
capabilities of the device are reduced. Data retention is not an issue with power applied to the SSD. The
SSD drive contains firmware and hardware features that can monitor and refresh memory cells when power
is applied.
[2] Endurance is the expected write life of a product when subjected to a specified workload. The drive will sup-
port the end user writing the specified multiple of drive user capacity to the drive per day for the expected life
of the product. This value is based on randomly writing 4KB transfers aligned on 4KB boundaries across the
entire drive LBA range. For example a 200GB drive could be written to up to (n*200GB) of user data per day
for the product life.
[3] Managed Life Warranty: This warranty is term based and includes the Lifetime Endurance Management fea-
ture stated in Section 2.4.1.
[4] Usage Based Warranty: This warranty is based on the shorter of term and endurance usage of the drive.
[5] The AFR and MTBF specifications for the drive assumes the operating environment is designed to maintain
nominal internal temperature. The rated AFR is based upon a sustained internal temperature of 60°C. Occa-
sional excursions in operating temperature between the rated MTBF temperature and the maximum drive
operating temperature may occur without impact to the rated MTBF temperature. However continual or sus-
tained operation at temperatures beyond the rated MTBF temperature will degrade the drive MTBF and
reduce product reliability
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 16
2.12 AGENCY CERTIFICATION
2.12.1 Safety certification
These products are certified to meet the requirements of UL60950-1, CSA60950-1 and EN60950 and so marked as to the
certify agency.
2.12.2 Electromagnetic compatibility
Drives that display the CE mark comply with the European Union (EU) requirements specified in the Electromagnetic
Compatibility Directive (2004/108/EC) as put into place 20 July 2007. Testing is performed to the levels specified by the
product standards for Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the
immunity levels are defined by EN 55024.
Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph.
Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when
used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for
operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused
I/O ports. Computer manufacturers and system integrators should confirm EMC compliance and provide CE marking for their
products.
Korean KCC
If these drives have the Korean Communications Commission (KCC) logo, they comply with KN22 and KN61000.
Australian C-Tick (N176)
If these models have the C-Tick marking, they comply with the Australia/New Zealand Standard AS/NZ CISPR22 and meet
the Electromagnetic Compatibility (EMC) Framework requirements of the Australian Communication Authority (ACA).
2.12.3 FCC verification
These drives are intended to be contained solely within a personal computer or similar enclosure (not attached as an
external device). As such, each drive is considered to be a subassembly even when it is individually marketed to the
customer. As a subassembly, no Federal Communications Commission verification or certification of the device is required.
Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly
(enclosure, drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to
Subpart J, Part 15 of the FCC rules. Operation with noncertified assemblies is likely to result in interference to radio and
television reception.
Radio and television interference. This equipment generates and uses radio frequency energy and if not installed and
used in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.
This equipment is designed to provide reasonable protection against such interference in a residential installation. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to
radio or television, which can be determined by turning the equipment on and off, you are encouraged to try one or more of
the following corrective measures:
• Reorient the receiving antenna.
• Move the device to one side or the other of the radio or TV.
• Move the device farther away from the radio or TV.
• Plug the computer into a different outlet so that the receiver and computer are on different branch outlets.
If necessary, you should consult your dealer or an experienced radio/television technician for additional suggestions. You
may find helpful the following booklet prepared by the Federal Communications Commission: How to Identify and Resolve
Radio-Television Interference Problems. This booklet is available from the Superintendent of Documents, U.S. Government
Printing Office, Washington, DC 20402. Refer to publication number 004-000-00345-4.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 17
2.13 ENVIRONMENTAL PROTECTION
Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting
certain chemical substances.
2.13.1 European Union Restriction of Hazardous Substances (RoHS) Directive
The European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances,
including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006. This
drive is manufactured with components and materials that comply with the RoHS Directive.
2.13.2 China Restriction of Hazardous Substances (RoHS) Directive
This product has an Environmental Protection Use Period (EPUP) of 20 years. The following table contains
information mandated by China's "Marking Requirements for Control of Pollution Caused by Electronic
Information Products" Standard.
"O" indicates the hazardous and toxic substance content of the part (at the homogenous material level) is lower than the
threshold defined by the China RoHS MCV Standard.
"X" indicates the hazardous and toxic substance content of the part (at the homogenous material level) is over the threshold
defined by the China RoHS MCV Standard.
2.14 CORROSIVE ENVIRONMENT
Seagate electronic drive components pass accelerated corrosion testing equivalent to 10 years exposure to light industrial
environments containing sulfurous gases, chlorine and nitric oxide, classes G and H per ASTM B845. However, this
accelerated testing cannot duplicate every potential application environment. Users should use caution exposing any
electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability
can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are
especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In
addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board
assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. Materials used in cabinet fabrication, such
as vulcanized rubber, that can outgas corrosive compounds should be minimized or eliminated. The useful life of any
electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 18
3.0 CONFIGURING AND MOUNTING THE DRIVE
This section contains the specifications and instructions for configuring and mounting the drive.
3.1 HANDLING AND STATIC-DISCHARGE PRECAUTIONS
After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD)
hazards. Observe the following standard handling and static-discharge precautions:
Caution:
• Before handling the drive, put on a grounded wrist strap, or ground yourself frequently by touching the metal chassis of a
computer that is plugged into a grounded outlet. Wear a grounded wrist strap throughout the entire installation procedure.
• The drive is fragile—handle it with care.
• Always rest the drive on an antistatic surface until you mount it in the computer.
• Do not touch the connector pins or the printed circuit board.
• Do not remove the factory-installed labels from the drive or cover them with additional labels. Removal voids the warranty.
Some factory-installed labels contain information needed to service the drive.
3.2 CONFIGURING THE DRIVE
Each drive on the Serial ATA interface connects point-to-point with the Serial ATA host adapter. There is no master/slave
relationship because each drive is considered a master in a point-to-point relationship. If two drives are attached on one
Serial ATA host adapter, the host operating system views the two devices as if they were both “masters” on two separate
ports. Both drives behave as if they are Device 0 (master) devices.
Serial ATA drives are designed for easy installation. If you connect the drive and receive a “drive not detected” error, your
SATA equipped motherboard or host adapter may use a chipset that does not support SATA 6.0Gb speed autonegotiation.
You will need to install a SATA host adapter that supports autonegotiation.
3.3 SERIAL ATA CABLES AND CONNECTORS
The Serial ATA interface cable consists of four conductors in two differential pairs, plus three ground connections. The cable
size may be 30 to 26 AWG with a maximum length of one meter (39.37 inches). See Table 9 for connector pin definitions.
Either end of the SATA signal cable can be attached to the drive or host.
For direct backplane connection, the drive connectors are inserted directly into the host receptacle. The drive and the host
receptacle incorporate features that enable the direct connection to be hot pluggable and blind mateable.
For installations which require cables, you can connect the drive as illustrated in Figure 2.
Signal connector
Power connector
Signal cable
Power cable
Figure 2. Attaching SATA cabling
Each cable is keyed to ensure correct orientation. Seagate 600 Pro SSD drives support latching SATA connectors.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 19
3.4 DRIVE MOUNTING
You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottommounting holes. Follow these important mounting precautions when mounting the drive:
• Allow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling as a guideline.
Please refer to Section 3.5 for final cooling requirements.
• Use only M3 x 0.5 metric mounting screws.
• Four (4) threads (0.080 in) minimum screw engagement recommended. Also ensure maximum screw length does not bot-
tom out in mounting holes.
• Do not overtighten the mounting screws (maximum torque: 4.5 in-lb, ± 0.45 in-lb).
Refer to Figure 3 for detailed mounting configuration dimensions.
Weight: 7mm models 0.220 pounds 100 grams
Note. These dimensions conform to the Small Form Factor Standard documented in SFF-8201 and
SFF-8223 found at www.sffcommittee.org.
Figure 3. Mounting configuration dimensions (7mm models)
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 20
3.5 COOLING
Cabinet cooling must be designed by the customer so that the ambient temperature immediately surrounding the drive will
not exceed temperature conditions specified in Section 2.9.1, "Temperature."
The rack, cabinet, or drawer environment for the drive must provide heat removal. You should confirm that adequate heat
removal is provided using the temperature measurement guidelines described in Section 2.9.1.
Forced air flow may be required to keep temperatures at or below the temperatures specified in Section 2.9.1 in which case
the drive should be oriented, or air flow directed, so that the least amount of air flow resistance is created while providing air
flow to the drive. Also, the shortest possible path between the air inlet and exit should be chosen to minimize the travel length
of air heated by the drive and other heat sources within the rack, cabinet, or drawer environment.
If forced air is determined to be necessary, possible air-flow patterns are shown in Figure 4. The air-flow patterns are created
by one or more fans, either forcing or drawing air as shown in the illustrations. Conduction, convection, or other forced airflow patterns are acceptable as long as the temperature measurement guidelines of Section 2.9.1 are met.
Above unit
ote. Air flows in the direction shown (back to front)
or in reverse direction (front to back)
ote. Air flows in the direction shown or
in reverse direction (side to side)
Figure 4. Air flow
Under unit
Above unit
Under unit
Image may not represent actual product, for reference only.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 21
4.0 SERIAL ATA (SATA) INTERFACE
These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed
input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6.
For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”
specification.
4.1 HOT-PLUG COMPATIBILITY
Seagate 600 Pro SSD drives incorporate connectors which enable you to hot plug these drives in accordance with the Serial
ATA II: Extension to Serial ATA 1.0a specification. This specification can be downloaded from www.serialata.org.
4.2 SERIAL ATA DEVICE PLUG CONNECTOR PIN DEFINITIONS
Table 9 summarizes the 2.5” drive Signal and Power SATA Plug.
Table 9 2.5” SATA Connector Plug Pinout
Segment Pin Function Definition
S1 GND Ground
Signal
Power
S2 A+
S3 AS4 GND Ground
S5 BS6 B+
S7 GND Ground
Key and spacing separate signal and power segments
P1 V
P2 V
P3 V
33
33
33
P4 GND
P5 GND
P6 GND
P7 V
P9 V
5
5
5
P10 Ground Ground
P11 LED Signal Activity LED: Driven low to light
P12 Ground Ground
P13 V
P14 V
P15 V
12
12
12
Differential Signal Pair (Host to Drive)
Differential Signal Pair (Drive to Host)
Unused
Ground
[2]
[1]
5V power to DriveP8 V
[1]
Unused
[3]
Notes:
[1] Ground pins 4 and 12 mate first on SATA backplane connectors.
[2] The three V33 pins are unused but connected together on the drive. They can be used for a drive-in-place detection.
[3] The three V12 pins are unused but connected together on the drive. They can be used for a drive-in-place detection.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 22
Table 10 summarizes the 1.8” drive
Signal and Power SATA Plug.
Table 10 1.8” SATA Connector Plug Pinout
Segment Pin Function Definition
S1 GND Ground
Signal
S2 A+
S3 AS4 GND Ground
S5 BS6 B+
Differential Signal Pair (Host to Drive)
Differential Signal Pair (Drive to Host)
S7 GND Ground
Spacing separates signal and power segments
Power
P1 V
P2 V
P3 GND
P4 GND
P5 V
P6 V
33
33
Unused
Ground
5
5
5V power to Drive
P7 LED Signal Activity LED: Driven low to light
Key Key Keyway
P8 Optional
P9 Optional
Reserved for Seagate use.
Leave unconnected.
[2]
[1]
Notes:
[1] Ground pins 3 and 4 mate first on micro SATA backplane connectors
[2] The two V33 pins are unused but connected together on the drive. They can be used for a drive-in-place detection.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 23
4.3 SUPPORTED ATA COMMANDS
The fo llo win g tabl e lis ts Se rial A TA st and ard co mma nds t hat th e dri ve su ppo rts. F or a de tai led de scr ipt ion of t he AT A
commands, refer to the Serial ATA: High Speed Serialized AT Attachment specification. See “S.M .A.R. T. comm ands” o n
page 33 for details and subcommands used in the S.M.A.R.T. implementation.
Table 11 Supported ATA commands
COMMAND NAME COMMAND CODE (IN HEX)
Check Power Mode E5
Data Set Management with Trim Support 06
Download Microcode 92
Flush Cache E7
Flush Cache Extended EA
Identify Device EC
Idle E3
Idle Immediate E1
Initialize Device Parameters 91
NOP 00
Read Buffer E4
Read DMA C8
Read DMA Extended 25
Read FPDMA Queued 60
Read Log Ext 2F
Read Multiple C4
Read Multiple Extended 29
Read Native Max Address F8
Read Native Max Address Extended 27
Read Sectors 20
Read Sectors Extended 24
Read Verify Sectors 40
Read Verify Sectors Extended 42
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
Sanitize Block Erase B4H/0012
Sanitize Freeze Lock Ext B4H/0020
Sanitize Status Ext B4H/0000
Security Disable Password F6
Security Erase Prepare F3
Security Erase Unit F4
Security Freeze F5
Security Set Password F1
Security Unlock F2
Set Features EF
Set Max Address F9
Set Max Address Extended 37
H
H
H
H
H
H
H
H
H
H
H
H
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 24
COMMAND NAME COMMAND CODE (IN HEX)
Set Multiple Mode C6
Sleep E6
H
H
S.M.A.R.T. Disable Operations B0H / D9
S.M.A.R.T. Enable Operations B0H / D8
S.M.A.R.T. Execute Offline B0H / D4
S.M.A.R.T. Read Data B0H / D0
S.M.A.R.T. Read Log Sector B0H / D5
S.M.A.R.T. Return Status B0H / DA
S.M.A.R.T. Write Log Sector B0H / D6
Standby E2
Standby Immediate E0
Write Buffer E8
Write DMA CA
Write DMA Extended 35
Write DMA FUA Extended 3D
Write FPDMA Queued 61
Write Log Extended 3F
Write Multiple C5
Write Multiple Extended 39
Write Multiple FUA Extended CE
Write Sectors 30
Write Sectors Extended 34
Write Uncorrectable Extended 45
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 25
4.3.1 Identify Device command
The Identify Device command (command code ECH) transfers information about the drive to the host following power up.
The data is organized as a single 512-byte block of data, whose contents are shown in Table 11 on page 24. All reserved bits
or words should be set to zero. Parameters listed with an “x” are drive-specific or vary with the state of the drive. see Section
2.0 on page 3 for default parameter settings.
The following commands contain drive-specific features that may not be included in the Serial ATA specification.
WORD DESCRIPTION VALUE
0 General configuration 0C5A
1 Number of logical cylinders (obsolete) 16,383 3FFF
2 Specific configuration C837
3 Number of logical heads (obsolete) 16 0010
4-5 Retired 0000
6 Number of logical sectors per logical track (obsolete) 63 003F
7–8 Reserved for CompactFlash Association 0000
9 Retired 0000
10–19 Serial number: (ATA ASCII string padded with spaces (20H)) ASCII
20-21 Retired 0000
22 Obsolete 0004
23–26 Firmware revision (ATA ASCII string padded with spaces (20h)) ASCII
27–46 Model number (ATA ASCII string padded with spaces (20h)) ASCII
47 (Bits 7-0) Maximum number of logical sectors that shall be transferred
8010
per DRQ data block on READ/WRITE MULTIPLE commands. 16
48 Reserved for Trusted Computing feature set options 4000
49 Capabilities – Standby Timer, IORDY Support, etc 2F00
50 Capabilities Continued 4000
51 PIO data transfer cycle timing option (Obsolete) 0200
52 Retired 0200
53 Words 54–58, 64–70 and 88 are valid 0006
54 Number of current logical cylinders (Obsolete) 3FFF
55 Number of current logical heads (Obsolete) 0010
56 Number of current logical sectors per logical track (Obsolete) 003F
57–58 Current capacity in sectors (Obsolete) FC10
59 Number of LBAs transferred per Read Multiple or Write Multiple.
0010
Sanitize Command Support
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
00FB
H
60–61 Total number of user addressable logical sectors for 28-bit commands
XXXXXXXXH*
Note: The maximum value allowed in this field is: 0FFFFFFFh. If this
field contains 0FFFFFFFh and the device has user addressable LBAs
greater than or 137GB, then words 100..103 contain the total number
of user addressable LBAs
62 Obsolete 0000
63 Multiword DMA active and modes supported
(see note following this table)
64 Advanced PIO modes supported. SATA = 0003h 0003
65 Minimum Multiword DMA transfer cycle time per word (120ns) 0078
66 Recommended Multiword DMA transfer cycle time (120ns) 0078
0407
H
H
H
H
H
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 26
WORD DESCRIPTION VALUE
67 Minimum PIO transfer cycle time without flow control (120ns) 0078
68 Minimum PIO transfer cycle time with IORDY flow control (120ns) 0078
69 Additional Features and Commands supported.
5D20
Trim Features supported, DMA commands supported
70 Reserved 0000
71–74 Reserved for ATAPI 0000
75 Queue depth 001F
76 Serial ATA Capabilities Supported 850E
77 Reserved for Serial ATA 0004
78 Serial ATA features supported 0048
79 Serial ATA features enabled 0040
80 Major version number 01F0
81 Minor version number 0029
82 Commands and feature sets supported 346B
83 Commands and feature sets supported 7509
84 Commands and feature sets supported
4163
85 Commands and feature sets supported or enabled 3469
86 Commands and feature sets supported or enabled BC01
87 Commands and feature sets supported or enabled 4163
88 Ultra DMA support and current mode (see note following this table) 007F
89 Security erase time 0003
90 Enhanced security erase time 0003
91 Current APM level value FFFE
92 Master password Identifier 0000
93 Hardware reset result 0000
94 Reserved FE00
95–99 ATA-reserved 0000
100–103 Total Number of User Addressable Logical Blocks for 48-bit com-
mands. These words are required for drives that support the 48-bit
addressing feature. Maximum value: 0000FFFFFFFFFFFFh
480GB model = 937,703,088
400GB model = 781,422,768
240GB model = 468,862,128
200GB model = 390,721,968
120GB model = 234,441,648
100GB model = 195,371,568
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
104 Reserved for Streaming Command Set 0000
105 Maximum number of 512-byte blocks of LBA Range Entries
(see 4.18.3.2) per DATA SET MANAGEMENT command
106 Physical sector size / logical sector size 6004
107 Inter-seek delay for ISO 7779 standard acoustic testing 0000
108–111 World wide name XXXX
112–115 Reserved 0000
116 Reserved for TLC 0000
117–118 Logical sector size (DWord) 0000
119 Commands and feature sets supported 401C
0001
H
H
H
H
H
H
H
H
H
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 27
WORD DESCRIPTION VALUE
120 Commands and feature sets supported or enabled 401C
121–126 Reserved for expanded supported and enabled settings 0000
127 Obsolete 0000
128 Security status 0021
129–159 Vendor specific xxxx
160–167 Reserved for the CompactFlash Association 0000
168 Device Nominal Form Factor 0003
169 DATA SET MANAGEMENT features supported 0001
170–173 Additional Product Identifier (ATA String) 0000
174–175 Reserved 0000
176–205 Reserved 0000
206 SCT Command Transport 0000
207–208 Reserved for CE-ATA 0000
209 Alignment of logical blocks within a physical block 4000
210–211 Write-Read-Verify Sector Count Mode 3 0000
212–213 Write-Read-Verify Sector Count Mode 2 (DWord) 0000
214 NV Cache Capability 0000
215-216 NV Cache Size in Logical Blocks (DWord) 0000
217 Nominal media rotation rate 0001
218 Reserved 0000
219 NV Cache Options 0000
220 Write-Read-Verify feature set 0000
221 Reserved 0000
222 Transport major version number 1020
223 Transport minor version number 0000
224-233 Reserved 0000
234 Minimum number of 512-byte data blocks per
0000
DOWNLOAD MICROCODE command for mode 03h
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
235 Maximum number of 512-byte data blocks per
DOWNLOAD MICROCODE command for mode 03h
236-254 Reserved 0000
255 Integrity word (XXA5H) xxA5
0000
H
H
H
Note. See the bit descriptions below for words 49, 69, 76, 78, 82-87 and 119-120 of the Identify Drive data.
Description (if bit is set to 1)
Bit Word 49
8 DMA Supported
9 Shall be set to 1
10 IORDY May be disabled
11 IORDY supported
13 Standby Timer Values supported
Bit Word 50
14 Shall be set to 1
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 28
Bit Word 69
5 Read zero after Trim is supported
6 Optional ATA 28-bit commands supported
8 Download Microcode DMA supported
9 Set Max Password DMA and Set Max Unlock DMA supported
10 Write Buffer DMA Supported
11 Read Buffer DMA Supported
12 DEVICE CONFIGURATION IDENTIFY DMA and
DEVICE CONFIGURATION SET DMA are supported
13 Long Physical Sector Alignment Error Reporting Control is supported
14 Deterministic read after Trim is supported
Bit Word 76
0 Shall be cleared to zero
1 Supports SATA Gen1 Signaling Speed (1.5Gb/s)
2 Supports SATA Gen2 Signaling Speed (3.0Gb/s)
3 Supports SATA Gen3 Signaling Speed (6.0Gb/s)
4-7 Reserved for Serial ATA
8 Supports the NCQ feature set
9 Supports receipt of host initiated power management requests
10 Supports Phy Event Counters
11 Supports Unload while NCQ commands are outstanding
12 Supports NCQ priority information
13-15 Reserved for Serial ATA
Bit Word 78
0 Shall be cleared to zero
1 Device supports non-zero buffer offsets
2 Device supports DMA Setup auto-activation
3 Device supports initiating power management
4 Device supports in-order data delivery
5 Reserved for Serial ATA
6 Device supports Software Settings Preservation
7-15 Reserved for Serial ATA
Bit Word 82
0 The SMART feature set is supported
1 The Security feature set is supported
2 Obsolete
3 Mandatory Power Management feature set is supported
4 PACKET feature set is supported
5 Volatile write cache is supported
6 Read look-ahead is supported
7 Release interrupt is supported
8 SERVICE interrupt is supported
9 DEVICE RESET command is supported
10 HPA feature set is supported
11 Obsolete
12 WRITE BUFFER command is supported
13 READ BUFFER command is supported
14 NOP command is supported
15 Obsolete
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 29
Bit Word 83
0 DOWNLOAD MICROCODE command is supported
1 Obsolete
2 CFA feature set is supported
3 APM feature set is supported
4 Obsolete
5 PUIS feature set is supported
6 SET FEATURES subcommand is required to spin-up after power-up
7 Reserved
8 SET MAX security extension is supported
9 AAM feature set is supported
10 48-bit Address feature set is supported
11 DCO feature set is supported
12 Mandatory FLUSH CACHE command is supported
13 FLUSH CACHE EXT command is supported
14 Shall be set to one
15 Shall be cleared to zero
Bit Word 84
0 SMART error logging is supported
1 SMART self-test is supported
2 Media serial number is supported
3 Media Card Pass Through Command feature set is supported
4 Streaming feature set is supported
5 GPL feature set is supported
6 WRITE DMA FUA EXT and WRITE MULTIPLE FUA EXT commands are supported
7 Obsolete
8 64-bit World wide name is supported
9-10 Obsolete
11-12 Reserved for TLC
13 IDLE IMMEDIATE command with UNLOAD feature is supported
14 Shall be set to one
15 Shall be cleared to zero
Bit Word 85
9 DEVICE RESET command is not supported
10 HPA feature set is supported
11 Obsolete
12 WRITE BUFFER command is supported
13 READ BUFFER command is supported
14 NOP command is supported
15 Obsolete
Bit Word 86
0 DOWNLOAD MICROCODE command is supported
1 Obsolete
2 CFA feature set is supported
6 SET FEATURES subcommand is required to spin-up after power-up
10 The 48-bit Address features set is supported
11 The DCO feature set is supported
12 FLUSH CACHE command supported
13 FLUSH CACHE EXT command supported
15 Words 119 ...120 are valid
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 30
Bit Word 87
0 SMART error logging is supported
1 SMART self-test supported
3 The Media Card Pass Through Command feature set is supported
5 The GPL feature set is supported
6 WRITE DMA FUA EXT and WRITE MULTIPLE FUA EXT commands are supported
8 The 64-bit World wide name is supported
13 The IDLE IMMEDIATE command with UNLOAD FEATURE is supported
14 Shall be set to one
15 Shall be cleared to zero
Bit Word 119
0 Reserved
1 Write-Read-Verify feature set is supported
2 WRITE UNCORRECTABLE EXT command is supported
3 READ LOG DMA EXT and WRITE LOG DMA EXT commands are supported
4 DOWNLOAD MICROCODE command with mode 3 is supported
5 Free-fall Control feature set is supported
6 Extended Status Reporting feature set is supported
7 Extended Power Conditions feature set is supported
8-13 Reserved
14 Shall be set to one
15 Shall be cleared to zero
Bit Word 120
2 WRITE UNCORRECTABLE EXT command is supported
3 READ LOG DMA EXT and WRITE LOG DMA EXT commands are supported
4 DOWNLOAD MICROCODE command with mode 3 is supported
14 Shall be set to one
15 Shall be cleared to zero
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 31
4.3.2 Set Features command
This command controls the implementation of various features that the drive supports. When the drive receives this
command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in
the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read
look-ahead and write caching features enabled. The acceptable values for the Features register are defined as follows:
Table 12 Set Features command values
02
03
10
55
66
82
90
AA
CC
Enable write cache (default).
H
Set transfer mode (based on value in Sector Count register).
H
Sector Count register values:
Set PIO mode to default (PIO mode 2).
00
H
01HSet PIO mode to default and disable IORDY (PIO mode 2).
PIO mode 0
08
H
PIO mode 1
09
H
0AHPIO mode 2
PIO mode 3
0B
H
PIO mode 4 (default)
0C
H
Multiword DMA mode 0
20
H
21HMultiword DMA mode 1
Multiword DMA mode 2
22
H
Ultra DMA mode 0
40
H
Ultra DMA mode 1
41
H
Ultra DMA mode 2
42
H
43HUltra DMA mode 3
Ultra DMA mode 4
44
H
Ultra DMA mode 5
45
H
Ultra DMA mode 6
46
H
Enable use of SATA features
H
02HDMA Setup FIS Auto-Activate optimization
Device-initiated interface power state transitions
03
H
Software Settings Preservation
06
H
Disable read look-ahead (read cache) feature
H
Disable reverting to power-on defaults
H
Disable write cache
H
Disable use of SATA features
H
DMA Setup FIS Auto-Activate optimization
02
H
03HDevice-initiated interface power state transitions
Software Settings Preservation
06
H
Enable read look-ahead (read cache) feature (default).
H
Enable reverting to power-on defaults
H
Note. At power-on, or after a hardware or software reset, the default values of the features are as
indicated above.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 32
4.3.3 S.M.A.R.T. commands
S.M.A.R.T. provides near-term failure prediction for drives. When S.M.A.R.T. is enabled, the drive monitors predetermined
drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T.
makes a status report available to the host. Not all failures are predictable. S.M.A.R.T. predictability is limited to the attributes
the drive can monitor. For more information on S.M.A.R.T. commands and implementation, see the Draft ATA-8 Standard.
SeaTools diagnostic software activates a built-in drive self-test (DST S.M.A.R.T. command for D4
) that eliminates
H
unnecessary drive returns. The diagnostic software ships with all new drives and is also available at:
http://www.seagate.com/support/downloads/seatools/.
This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports
S.M.A.R.T. to enable this feature. The table below shows the S.M.A.R.T. command codes that the drive uses.
Table 13 S.M.A.R.T. commands
CODE IN FEATURES
REGISTER
D0
H
D4
H
D5
H
D6
H
D8
H
D9
H
DA
H
S.M.A.R.T. COMMAND
S.M.A.R.T. Read Data
S.M.A.R.T. Execute Off-line Immediate (runs DST)
S.M.A.R.T. Read Log Sector
S.M.A.R.T. Write Log Sector
S.M.A.R.T. Enable Operations
S.M.A.R.T. Disable Operations
S.M.A.R.T. Return Status
Note. If an appropriate code is not written to the Features Register, the command is aborted and 0x 04 (abort) is written
to the Error register.
4.3.4 SSD Percentage Endurance Remaining Indicator
An application can interrogate the drive through the host to determine an estimate of the percentage of device life that is
remaining. Seagate SeaTools diagnostic software has the capability to report the indicator value.
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 33
INDEX
A
ACA 17
acceleration 15
Access time 6
Agency certification 17
air flow
illustrated 21
altitude 14
ambient temperature 6, 7
Annualized Failure Rate (AFR) 16
ATA commands 24
Australia/New Zealand Standard AS/NZ CISPR22 17
Australian Communication Authority (ACA) 17
Australian C-Tick 17
Average seek time 6
C
cables and connectors 19
capacity 4
CE mark 17
certification 17
Check Power Mode 24
China RoHS directive 18
Class B computing device 17
compatibility 17
Conducted RF immunity 15
Configuring the drive 19
connectors 19
Corrosive environment 18
CSA60950-1 17
cycles 16
Cylinders 4
D
Data Set Management with Trim Support 24
data-transfer rates 2
DC power 7
Default logical geometry 4
dimensions 20
Download Microcode 24
European Union (EU) requirements 17
F
FCC verification 17
features 2
Federal Communications Commission 17
Flush Cache 24
Flush Cache Extended 24
Formatted capacity 4
G
geometry 4
Gs 15
guaranteed LBAs 4
H
Handling precautions 19
heads 4
height 6
humidity 14
I
Identify Device 24
Identify Device command 26
Idle 24
Idle Immediate 24
Idle mode 7
Idle mode power 7
Information Technology Equipment (ITE) 17
Initialize Device Parameters 24
interface 5, 22
Interface technology 5
is 6
ITE 17
K
KCC 17
Korean Communications Commission 17
Korean RRL 17
E
Electrical fast transient 15
Electromagnetic compatibility 17
Electromagnetic Compatibility Directive (2004/108/EC) 17
Electromagnetic immunity 15
Electrostatic discharge 15
electrostatic discharge (ESD) 19
EN 55022, Class B 17
EN 55024 17
EN60950 17
Environmental specifications 14
ESD 19
EU 17
EU RoHS directive 18
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 34
L
LBA mode 4
length 6
logical geometry 4
M
maintenance 16
Managed Life Warranty 16
master/slave 2
maximum temperature 14
mounting 20
mounting configuration 20
mounting configuration dimensions 20
mounting screws 14
INDEX
mounting the drive 19
N
nominal power 6
Nonoperating shock 14
Nonoperating vibration 15
NOP 24
O
Operating shock 14
Operating vibration 15
P
Page-to-page access 6
page-to-page accesses 6
Peak operating mode 7
Performance 5
Physical characteristics 6
point-to-point 2, 19
Power consumption 7
Power specifications 7
precautions 19
printed circuit board 19
Q
quick reference 3
R
Radiated RF immunity 15
Radio and television interference 17
radio frequency (RF) 15
Read Buffer 24
Read DMA 24
Read DMA Extended 24
Read FPDMA queued 24
Read Log Ext 24
Read Multiple 24
Read Multiple Extended 24
Read Native Max Address 24
Read Native Max Address Extended 24
Read Sectors 24
Read Sectors Extended 24
Read Verify Sectors 24
Read Verify Sectors Extended 24
Read/write heads 4
Recording technology 5
relative humidity 14
Reliability 16
RF 15
RoHS 18
S.M.A.R.T. Execute Offline 25
S.M.A.R.T. implementation 24
S.M.A.R.T. Read Data 25
S.M.A.R.T. Read Log Sector 25
S.M.A.R.T. Return Status 25
S.M.A.R.T. Write Log sector 25
Safety certification 17
Sanitize Block Erase 24
Sanitize Freeze Lock Ext 24
Sanitize Status Ext 24
SATA 22
screws 14
Seagate Technology Support Services 1
Sectors per track 4
Security Disable Password 24
Security Erase Prepare 24
Security Erase Unit 24
Security Freeze 24
Security Set Password 24
Security Unlock 24
Serial ATA (SATA) interface 22
serial ATA ports 2
Set Features 24
Set Max Address 24
Set Max Address Extended 24
Set Multiple Mode 25
Shock 14
Signal and Power SATA Plug and Nominal Mate Sequence
22, 23
Sleep 25
Specification summary table 3
SSD Percentage Endurance Remaining Indicator 33
Standby 25
Standby Immediate 25
Standby mode 7
Startup power 7
static-discharge 19
Surge immunity 15
T
temperature 6, 14
temperature gradient 14
Time to Ready 6
U
UL60950-1 17
Usage Based Warranty 16
V
Vibration 14
Voltage dips, interrupts 15
S
S.M.A.R.T. Disable Operations 25
S.M.A.R.T. Enable Operations 25
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 35
W
weight 6
wet bulb temperature 14
width 6
Write Buffer 25
Write DMA 25
Write DMA Extended 25
Write DMA FUA Extended 25
Write FPDMA queued 25
Write Log Extended 25
Write Multiple 25
Write Multiple Extended 25
Write Multiple FUA Extended 25
Write Sectors 25
Write Sectors Extended 25
write uncorrectable 25
INDEX
SEAGATE 600 PRO SSD PRODUCT MANUAL, REV. A 36
Seagate Technology LLC
AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000
ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888
EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00
Publication Number: 100727924, Rev. A
May 2013
Loading...
